Jabra Evolve 65 User Manual

Jabra

Evolve 65

User manual

© 2014 GN Audio A/S. All rights reserved. Jabra® is a trademark

MSIP-CMM-

GNM-HSC018W

of GN Audio A/S . The Bluetooth

®

word mark and logos are
registered trademarks owned by the Bluetooth SIG, Inc. and
any use of such marks by GN Audio A/S is under license.

MADE IN CHINA
MODEL: HSC018WEND040W
FCC ID: BCEHSC018WBCEEND040W
IC: 2386CHSC018W2386CEND040W

Declaration of Conformity can be found on

www.jabra.com/CP/US/declarations-of-conformity

1. Welcome ......................................... 4

2. Jabra Evolve 65 overview ...........5

2.1 Stereo variant

2.2 Mono variant

2.3 Included accessories
(stereo and mono)

3. How to wear ...................................7

3.1 Left or right wearing style

3.2 Adjust the headband

3.3 Position the microphone

3.4 Storing the microphone

4. How to charge the battery ...... 10

5. How to connect .......................... 11

5.1 Connect to PC (using jabra Link 370)

5.2 Connect to mobile device
(using Bluetooth)

5.3 Connect to PC (using USB cable)

6. How to use ................................. 14

6.1 Everyday use

6.2 Multiple call handling

6.3 Busylight

ENGLISH

7. Support ........................................ 18

7.1 faq

7.2 How to care for your headset

8. Technical specifications ........... 19

Jabra Evolve 65

3

1. Welcome

Thank you for using the Jabra Evolve 65. We
hope you will enjoy it!

Jabra Evolve 65 features

 Connects to PC via Jabra Link 370 bluetooth

adapter or USB cable
 Connects to mobile devices via Bluetooth
 Integrated busylight
 Discreet microphone boom-arm that

integrates into the headband when not on calls
 Superior music and voice capabilities
 Hi-Fi Sound

ENGLISH

Jabra Evolve 65

4

2. Jabra Evolve 65 overview

2.1 Stereo variant

Magnetic
microphone groove

Adjustable headband

Volume up

Busylight indicator

Multi-function
button

Battery
indicator

Bluetooth
indicator

On/o/connect switch

USB connect &
charging port

Microphone
boom-arm

ENGLISH

Volume down

Jabra Evolve 65

5

2.2 Mono variant

Magnetic
microphone groove

Adjustable headband

Volume up

Busylight indicator

Multi-function
button

ENGLISH

Volume down

Battery
indicator

Bluetooth
indicator

On/o/connect switch

2.3 Included accessories

(stereo and mono)

Carry pouch

USB cable

Jabra Evolve 65

USB connect &
charging port

Microphone
boom-arm

6

3. How to wear

3.1 Left or right wearing style

The Jabra Evolve 65 can be worn on the left or
right by flipping the microphone to the other
side (270° limit).

ENGLISH

270°

Jabra Evolve 65

7

3.2 Adjust the headband

Adjust the headband to find the most
comfortable fit.

3.3 Position the microphone

It is recommended to position the microphone
close to your mouth (0.5 inches).

ENGLISH

Jabra Evolve 65

8

The microphone is bendable for personal
preference.

3.4 Storing the microphone

When listening to music or outdoors, the
microphone can be magnetically stored in the
headband groove.

ENGLISH

Jabra Evolve 65

9

4. How to charge the battery

The headset battery will charge when
connected to a PC using a USB cable, or when
using any USB charger supplied with your
mobile device.

The headset can still be used for calls while
charging using a USB cable connected to a PC.

It takes approx. 3 hours to charge the battery.

ENGLISH

Jabra Evolve 65

10

5. How to connect

5.1 Connect to PC (using jabra Link 370)

1. Ensure the headset is switched on.

2. Plug the Jabra Link 370 dongle into a USB

port on your PC. The headset and Jabra Link
370 are already pre-connected.

ENGLISH

Jabra Evolve 65

11

5.2 Connect to mobile device

(using Bluetooth)

1. Wear the headset.

2. Hold (3 secs) the On/off/connect switch in

the connect position until you hear the voice
guided instructions. The Bluetooth indicator
will flash blue.

3. Follow the voice guided instructions to

connect.

ENGLISH

Jabra Evolve 65

12

5.3 Connect to PC (using USB cable)

1. Ensure the headset is switched on.

2. Plug the headset into a USB port on your PC

using the supplied USB cable.

ENGLISH

Jabra Evolve 65

13

6. How to use

Volume up

Busylight indicator

Multi-function
button

ENGLISH

Volume down

Battery
indicator

Bluetooth
indicator

On/o/connect switch

Jabra Evolve 65

USB connect &
charging port

14

6.1 Everyday use

Function Action

Headset on/oSlide the On/o/connect

Answer/end
call

Reject call

Battery and
connection
status

Enable/
disable Voice
prompts

Adjust
volume

Manual
busylight
on/o

Enable/
disable
Busylight
function

Mute/unmute
microphone

switch

Multi-function button

Tap the

Double-tap the
button

Tap the
when not on a call

Press and hold the
Multi-function button while
turning on the headset

Tap the Volume up or Volume
down button

Simultaneously tap the
Volume up and Volume down
buttons

Simultaneously press and hold
(3 secs) the
Volume down buttons

Press and hold (2 secs) the

Volume down button

Multi-function

Multi-function button

Volume up and

ENGLISH

Jabra Evolve 65

15

6.2 Multiple call handling

The headset can accept and handle multiple
calls at the same time.

Function Action

End current call and
answer incoming call

Switch between held
call and active call

Put current call on
hold and answer
incoming call

Reject incoming call,
when on a call

Tap the
Multi-function button

Press and hold
(2 secs) the

Multi-function

button

Press and hold
(2 secs) the

Multi-function

button

Double-tap the

Multi-function

button

ENGLISH

Jabra Evolve 65

16

6.3 Busylight

The busylight indicator on the headset can be
turned on to let others know that you are busy.

MANUALLY TURN BUSYLIGHT ONOFF

To manually turn the busylight on/off, tap both
the Volume up and Volume down buttons at
the same time.

ENABLEDISABLE BUSYLIGHT FUNCTION

To enable/disable the busylight function, press
and hold (3 secs) both the Volume up and
Volume down buttons at the same time.

ENGLISH

Jabra Evolve 65

17

7. Support

7.1 FAQ

View the FAQs on Jabra.com/evolve65

7. 2 How to care for your headset

 Always store the headset with the power off

and safely protected.

 Avoid storage at extreme temperatures

(above 55°C/131°F or below -10°C/14°F). This
can shorten battery life and may adversely
affect the headset.

ENGLISH

Jabra Evolve 65

18

8. Technical specifications

Jabra Evolve 65 headset Specification

Headset weight:

Headset dimensions:

Microphones:

Speaker:

Speaker maximum input
power:

Speaker frequency
range:

Operating temperature:

Storage temperature: -20°C to 25°C (-4°F to 77°F)

Mono headset: 79 g
Stereo headset: 111 g

Mono headset: L 154.4 mm
x W 58.6 mm x H 170.4 mm
Stereo headset: L 155.5 mm
x W 58.6 mm x H 170.5 mm

Noise cancelling
microphone

28 mm Dynamic PureSound
speakers (Hi-Fi)

10 mW

70 hz - 20 kHz

-10°C to 55°C (14°F to
131°F)

ENGLISH

Jabra Evolve 65

19

BLUETOOTH ADAPTER
JABRA LINK 370

PC connection: USB 2.0

Bluetooth version: 4.2

Bluetooth range: Up to 30m (100 feet), Class 1

Bluetooth profiles:

Simultaneous Bluetooth
connections:

Bluetooth audio bandwidth HD voice (wideband), A2DP

Visual indicators: Multicolor LED

SPECIFICATION

A2DP (v1.2), Hands free profile
(v1.6)

1

ENGLISH

Jabra Evolve 65

20

ENGLISH

jabra.com/evolve65

Jabra Evolve 65

21

REV E
