Jabra EASYGO

USER MANUAL

USER MANUAL - LANGUAGES

ENGLISH - NORTH AMERICA (Click here for manual) . . . . . . . . . . . . . . . . 3

FRANÇAIS - NORTH AMERICA (Cliquez ici pour le manuel) . . . . . . . . . 14

ESPAÑOL - NORTH AMERICA (Haga clic aquí para

acceder al manual) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

PORTUGUÊS - NORTH AMERICA (Clique aqui para

acessar o manual) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

CONTENTS

THANK YOU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

ABOUT YOUR JABRA EASYGO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

WHAT YOUR HEADSET DOES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

GETTING STARTED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

CHARGE YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

TURNING YOUR HEADSET ON AND OFF . . . . . . . . . . . . . . . . . . . . . . . . . 5

PAIRING IT WITH YOUR PHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

WEARING STYLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

HOW TO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

USING JABRA EASYGO WITH TWO MOBILE PHONES . . . . . . . . . . . . .8

TROUBLESHOOTING & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

NEED MORE HELP?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

TAKING CARE OF YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

english

JABRA E ASYGO

1

THANK YOU

Thank you for purchasing the Jabra EASYGO Bluetoo th® wireless
technology headset. We hope you enjoy it! This instruction manual
will get you started and ready to make the most of your headset.

ABOUT YOUR JABRA EASYGO

A Answer/end button

B On/o button

C StatusDisplay

connection indicator

D Charging socket

E Volume up/volume down

F Jabra Comfort Eargel

G Earhook

A

D

TM

With battery indicator and Bluetooth®

TM

B

F

C

english

E

G

JABRA E ASYGO

2

WHAT YOUR HEADSET DOES

Your Jabra EASYGO lets you do all this:

- Answer calls

- End calls

- Reject calls*

- Voice dialling*

- Last number redialling*

- Call waiting*

- Put call on hold*

- Mute

- Multiuse™ - being connected to two Bluetooth® devices at the
same time

Specications

- Talk time 6 hours

- Standby time 8 days

- Bluetooth® specication version 2.1 with EDR and eSCO

- Weight 8 gram

- Operating range up to 10 meters (approximately 33 feet)

- Supported Bluetooth® proles: HFP, HSP

- Internal rechargeable battery charged by wall charger

- Always see your battery and connection status on the
Jabra StatusDisplay™

- Digital sound enhancement via DSP technology

- Noise reduction on transmitted and received audio

- Noise dependent volume control*

- Automatic volume adjustment on receive audio

- Acoustic shock protection

- e-SCO for enhanced audio quality

- 128 bit encryption

* Phone dependent

JABRA E ASYGO

english

3

GETTING STARTED

Follow these three steps before using your headset:

1. Charge your headset

2. Activate Bluetooth® on your mobile phone (refer to the manual for
your Mobile phone)

3. Pair your headset to your mobile phone

The Jabra EASYGO is easy to operate. The answer/end button on
the headset performs dierent functions depending on how long
you press it.

Instruction Duration of press

Tap Press briey

Double Tap 2 quickly repeated taps

Press Approx: 1 second

Press and hold Approx: 5 seconds

CHARGE YOUR HEADSET

Make sure that your headset is fully charged for two hours before
you start using it. Use the AC power supply to charge from a
power socket. When the battery indicator has a solid red light,
your headset is charging. When the headset is fully charged
the battery indicator turns solid green for five minutes and is
then turned off.

Use only the charger provided in the box - do not use chargers
from any other devices as this may damage your headset.

Please note: The lifetime of the battery will be signicantly reduced
if your device is left uncharged for a long period. We therefore
recommend that you recharge your device at least once a month.

english

JABRA E ASYGO

4

TURNING YOUR HEADSET ON AND OFF

- Slide the on/off button towards the symbol “I” to turn the
headset ON. When you do so both indicators will ash on the
Jabra StatusDisplay™.

- Slide the on/o button towards the symbol “O” to turn the
headset o.

PAIRING IT WITH YOUR PHONE

Headsets are connected to phones using a procedure called
‘pairing’. By following a few simple steps, a phone can be paired
with a headset in a matter of minutes.

1 Put the headset in pairing mode

- When you turn on your Jabra EASYGO for the rst time, the
headset will automatically start up in pairing mode – i.e. it is
discoverable for your phone. When the headset is in pairing
mode the Bluetooth® status indication on the StatusDisplay™ is
ashing.

2 Set your Bluetooth® phone to ‘discover’ the EASYGO

- Follow your phone’s instruction guide. First make sure that
Bluetooth® is activated on your mobile phone. Then set your
phone to discover new devices. This usually involves going
to a ‘setup,’ ‘connect’ or ‘Bluetooth’ menu on your phone and
selecting the option to ‘discover’ or ‘add’ a Bluetooth® device.*

3 Your phone will nd the Jabra EASYGO

- Your phone will nd the headset under name “Jabra EASYGO”.
Your phone then asks if you want to pair with the headset.
Accept by pressing ‘Yes’ or ‘OK’ on the phone. You may be
asked to confirm with a passkey or PIN. Then use 0000
(4 zeros). Your phone will conrm when pairing is complete
and the Bluetooth® status indication on the StatusDisplay™ will
shift from ashing light to steady light and the headset voice
guidance will say “connected”.

english

* Phone dependent

JABRA E ASYGO

5

CONNECTIVITY

MobilSurf

BLUETOOTH

Infrared port
Wap options
Synchronization
Networks

SELECT

DEVICES FOUND

Jabra EASYGO

SELECT

Jabra EASYGO

Passkey:
****

OK

HANDSFREE

Jabra EASYGO
added.

The handsfree is
now ready for use

SELECT

Manual pairing mode

If you wish to use the headset with a dierent phone, or if the
pairing process was interrupted, you can manually set the headset
to pairing mode.

Make sure the headset is on. Press and hold the answer/end button
for approximately 5 seconds until the Bluetooth® icon turns from
a steady light to a ashing light. Then repeat steps 2 and 3 in the
above pairing guide.

Connecting with your phone

Pairing is only needed the rst time a headset and phone are
used together. When the headset and phone have been paired
once, they will automatically connect when the headset is on and
Bluetooth® is activated on the phone. The headset can be used
when it is “connected” to the phone. If the devices are paired, but
do not immediately connect, tap the answer/end button. When
your headset is connected the Bluetooth® connection icon in the
STATUSDISPLAY™ WILL BE CONSTANT ON FOR 3 SECONDS and
the headset voice guidance will say “connected”.

WEARING STYLE

The Jabra EASYGO is ready to be worn with or without the ear hook.
The ear hook can be removed and the headset can be used with
the Ultimate-t Eargels™.

The Ultimate-t Eargels™ can be used for both left and right wearing.
The Ultimate-t Eargels™ come in two dierent styles to t any ear.
You can also twist the eargel slightly to optimize the t and comfort.

For optimal performance, wear the Jabra EASYGO and your mobile
phone on the same side of your body or within line of sight. You will
get better performance when there are no obstructions between
your headset and your mobile phone.

english

JABRA E ASYGO

6

HOW TO

Answer a call

- Tap the answer/end button on your headset to answer a call.

End a call

- Tap the answer/end button to end an active call.

Reject a call*

- Press the answer/end button when the phone rings to reject an
incoming call. Depending on your phone settings, the person
who called you will either be forwarded to your voice mail or
will hear a busy signal.

Make a call

- When you make a call from your mobile phone, the call will
(subject to phone settings) automatically transfer to your
headset. If your phone does not allow this feature, tap on the
Jabra EASYGO’s answer/end button to transfer the call to the
headset.

Activate voice dialling*

- Press the answer/end button. For best results, record the voice
dialling tag through your headset. Please consult user manual
of your phone for more information about using this feature.

Redial last number*

- Double tap the answer/end button when the headset is on and
not used.

Adjust sound and volume*

- Tap the volume up or down to adjust the volume.

Mute/un-mute

- To mute, press both volume up and down at the same time.
A low beep alert plays during a muted call.

- To un-mute, tap either of the volume buttons.

english

* Phone dependent

JABRA E ASYGO

7

Call waiting and placing a call on hold*

- This lets you put a call on hold during a conversation and
answer a waiting call.

- Press the answer/end button once to put the active call on
hold and answer the waiting call.

- Press the answer/end button to switch between the two calls.

- Tap the answer/end button to end the active conversation.

HOW THE STATUSDISPLAY™ WORKS

Bluetooth®

Indicator

Battery
Indicator

To save battery the Jabra StatusDisplay™ is turned o after 3 seconds.
Get an instant status from the Jabra StatusDisplay™ by a tap on any
button on the headset when you are not on a call.

HOW THE VOICE GUIDANCE WORKS

When your headset has established a connection to your phone (or
other Bluetooth® device) the voice guidance will say “connected”.

When your headset has less than 30 minutes talk time remaining
the voice guidance will say “low battery”.

Indicates if your headset is connected to your
phone

- Solid light means headset is connected to your
phone

- Flashing light means headset is in ‘pairing mode’
and ready to be connected to a new phone

Indicates battery level and if headset is turned ON

- Green light indicates that the headset has more
than 30 minutes of talk time remaining

- Red light indicates that the headset has less
than 30 minutes of talk time remaining

english

USING JABRA EASYGO WITH TWO MOBILE PHONES

Jabra EASYGO is capable of having two mobile phones (or
Bluetooth® devices) connected to the headset at the same time.
This will give you the freedom of having only one headset to
operate both your mobile phones.

* Phone dependent

JABRA E ASYGO

8

In order to use the headset with two mobile phone please make
sure you have ”paired” the Jabra EASYGO with both phones. See
the section “PAIRING IT WITH YOUR PHONE” for instructions.

Once you have “paired” your headset with two phones simply
make sure your headset is on, and that Bluetooth® is enabled on
the phones and the headset will then automatically connect to
both phones.

Please note that Last Number Redial will dial the number from
the last outgoing call, independent of the mobile phone, and the
Voice Dialling function will only work on the last paired mobile
phone.

TROUBLESHOOTING & FAQ

I hear crackling noises

- Bluetooth® is a radio technology, which means it is sensitive to
objects between the headset and the connected device. It is
designed for the headset and the connected device to be used
within 10 meters (33 feet) of each other, with no major objects
in the way (walls, etc.).

I cannot hear anything in my headset

- Increase the volume in the headset.

- Ensure that the headset is paired to a device that is playing.

- Make sure your phone is connected to the headset by tapping
the Answer/End button.

I am having pairing problems

- You may have deleted your headset pairing connection in your
mobile phone. Follow the pairing instructions.

I want to reset the headset

It is possible to reset the headset. Turn the headset ON. Then
’Press and hold’ the volume down and answer/end buttons at
the same time for approx. 5 seconds until the battery icon and
Bluetooth® icon flash 5 times simultaneously - then the pairing
list is reset.

- Turn the headset OFF . The next time you power on, the headset
will go into pairing mode as the rst time you powered your
new EASYGO on.

JABRA E ASYGO

english

9

Will the Jabra EASYGO work with other Bluetooth® equipment?

- The Jabra EASYGO is designed to work with Bluetooth® mobile
phones. It can also work with other Bluetooth® devices that are
compliant with Bluetooth® version 1.1 or higher and support a
headset and hands-free prole.

I cannot use Reject call, call on hold, Redial or voice dialling

These features are dependent on the ability of your phone to
support a hands-free prole. Even if the hands-free prole is
implemented reject call, call hold and voice dialling are optional
features which are not supported by all devices. Please consult
your device manual for details.

Please note that some features can only be operated from the
primary device e.g. voice dial using Jabra EASYGO with 2 mobile
phones.

NEED MORE HELP?

1. Web: www.jabra.com/nasupport

(for the latest support info and online User Manuals)

2. Phone:

1 [phone] (U.S)
1 [phone] (Canada)

TAKING CARE OF YOUR HEADSET

- Always store the Jabra EASYGO with the power o and safely
protected

- Avoid storage at extreme temperatures (above 45°C/113°F –
including direct sunlight – or below -10°C/14°F). This can shorten
battery life and may aect operation. High temperatures may
also degrade performance.

- Do not expose the Jabra EASYGO to rain or other liquids.

english

JABRA E ASYGO

10

GLOSSARY

1. Bluetooth® is a radio technology that connects devices,
such as mobile phones and headsets, without wires or cords
over a short distance approx. 33 feet (10 meters). Get more
information at www.bluetooth.com

2. Bluetooth® proles are the dierent ways that Bluetooth®
devices communicate with other devices. Bluetooth® phones
support either the headset prole, the hands-free prole
or both. In order to support a certain prole, a phone
manufacturer must implement certain mandatory features
within the phone’s software.

3. Pairing creates a unique and encrypted link between two
Bluetooth® devices and lets them communicate with each
other. Bluetooth® devices will not work if the devices have not
been paired.

4. Passkey or PIN is a code that you enter on your mobile phone
to pair it with your Jabra EASYGO. This makes your phone and
the Jabra EASYGO recognize each other and automatically
work together.

5. Standby mode is when the Jabra EASYGO is passively waiting
for a call. When you ‘end’ a call on your mobile phone, the
headset goes into standby mode.

english

Dispose of the product according
to local standards and regulations.

www.jabra.com/weee

JABRA E ASYGO

11

TABLE DES MATIÈRES

MERCI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

À PROPOS DE VOTRE JABRAEASYGO . . . . . . . . . . . . . . . . . . . . . . . . . . 2

FONCTIONNALITÉS DE VOTRE OREILLETTE . . . . . . . . . . . . . . . . . . . . . 3

MISE EN ROUTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

CHARGEMENT DE VOTRE OREILLETTE . . . . . . . . . . . . . . . . . . . . . . . . . . 4

MISE EN MARCHE ET ARRÊT DE L’OREILLETTE . . . . . . . . . . . . . . . . . . 5

APPAIRAGE AVEC VOTRE TÉLÉPHONE . . . . . . . . . . . . . . . . . . . . . . . . . . 5

STYLE DE PORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

COMMENT.... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

UTILISATION DE VOTRE JABRAEASYGO AVEC

DEUXTÉLÉPHONES MOBILES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

DÉPANNAGE ET FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

BESOIN D’AIDE SUPPLÉMENTAIRE ? . . . . . . . . . . . . . . . . . . . . . . . . . . .11

ENTRETIEN DE VOTRE OREILLETTE . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

GLOSSAIRE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

anglais

JABRAE ASYGO

1

MERCI

Nous vous remercions d’avoir acheté la JabraEASYGO, une oreillette
stéréo dotée de la technologie Bluetooth
que vous en serez satisfait. Ce mode d’emploi vous permettra
d’utiliser vite votre appareil et d’en tirer le meilleur parti.

MD

sans l. Nous espérons

À PROPOS DE VOTRE JABRA EASYGO

A Touche Réponse/Fin

B Bouton Marche/Arrêt

C StatusDisplay

de connexion Bluetooth

D Prise de charge

E Volume sonore haut/bas

F JabraComfortEargel

G Contour d’oreille

A

D

MC

avec voyant d’état de la batterie et voyant

MD

MC

B

F

C

anglais

E

G

JABRAE ASYGO

2
