The TDX Family

Tradition. Innovation. Vision.

For the last two and a half decades, Invacare has been the industry leader

in powerchair electronics and bases. Every year, our engineers design

chairs, electronics, components and features that consistently raise the

bar for power wheelchair performance. Invacare’s rich powerchair history

started with the original Power Rolls IV in 1981, and continued with

innovations such as the original MKI electronics in 1989, and the

Storm Series

powerchairs in 1995.

Invacare revolutionized the powerchair industry once again in 2003 with

the introduction of the TDX®(Total Driving eXperience) powerchair. With

innovative features such as True Center-Wheel Drive, SureStep®, Stability

Lock, Traction Control Design (TCD™) and the latest MK series electronics,

this chair set the standard for high end rehab powerchairs.

Contents

02 History

03 TDX®Family

04 TDX®SP Led The Way

05 Traction Control Design/SureStep

06 MK6i™Electronics

07 Stability Lock/True Center-Wheel Drive

08 TDX®SP

09 TDX®SP Elegant Design

10 TDX®SP Seating Options

11 TDX®SP Speciﬁcations

12 TDX®SR

13 Gearless Brushless GB/TrueTrack

14 TDX®SR Seating Options

15 TDX®SR Speciﬁcations

16 TDX®SC

17 TDX®SC Speciﬁcations

18 TDX®Spree

19 TDX®Spree Features/Options

20 TDX®Spree Seating Options

21 TDX®Spree Speciﬁcations

22 Transport Ready Option

23 TDX Family

24-25 ANSI/RESNA Information

The New Invacare®TDX®Family

Things Just Keep Getting Better… The TDX SP led the way.

Now we've done it again. Invacare built upon a legacy of powerchair knowledge and design to develop the TDX®SP.

The TDX SP improves upon all the features of the TDX Series with enhanced performance, superior ride quality,

overall quieter chassis, and an elegantly simple design that is sure to turn heads. Now we are building upon this

successful platform with a new family of products. Invacare is the only choice for a complete package of Custom

Rehab Solutions.

TRACTION CONTROL DESIGN. ENHANCED SURESTEP

The new TDX®Family uses an

enhanced version of Invacare’s

patented SureStep®technology

that was made famous on the ﬁrst

generation TDX and the Pronto

series of wheelchairs.

With Enhanced SureStep, the TDX SP

and TDX SR climb up to a three-inch

obstacle going forward; the TDX SC

and the TDX Spree climb up to a

2.5-inch obstacle. As a new design

feature, the front casters also will

drop a full three inches, which makes

transitioning down an obstacle very

gentle and nearly silent. The

integrated Traction Control Design

also makes climbing over obstacles

up to one-inch high in reverse nearly

effortless.

SureStep transition up an obstacle.

SureStep transition down an obstacle.

Traction Control Design reverse transition.

ELECTRONICS. DESIGNED WITH BENEFITS FOR ALL.

MK Series electronics are the

benchmark in power wheelchair

drive systems. This is the result of

years of experience in the design

and manufacture of electronics

speciﬁcally for the needs of

wheelchair consumers.

MK6i™electronics take the MK

Series to the next level by offering

features that are easier to use than

any other MK Series system.

Advantages of MK6i include:

• MK

™

programming logic, so operators

do not need to learn a new system

• Reduced set-up and programming time

with the memory card feature

• Improved simplicity with

universal connectors

• Better information for programmers

and technicians

SPJ™+ BASIC JOYSTICK MPJ™ + REHAB JOYSTICK

TRUE CENTER-WHEEL DRIVE.

The tightest possible turning radius

comes from the True Center- Wheel

Drive chassis. The new TDX®Family

uses this type of wheelbase to

provide excellent maneuverability

and an intuitive driving experience.

This technology combined with

Enhanced SureStep®, Traction

Control Design and Quiet Stability

Lock makes the new TDX a great

indoor and outdoor chair.

Quiet Stability Lock.

QUIET STABILITY LOCK. THE DIFFERENCE MAKER IN REHAB.

The original TDX introduced quiet

Stability Lock, a feature that kept the

powerchair stable whenever it felt

that the driver's weight was rocking

forward. The new TDX®Family takes

that same feature to the next level.

The Stability Lock feature is designed

to operate and keep the powerchair

stable while it is in motion. It is not

intended to operate while the

powerchair ia at rest. This second

generation Stability Lock replaces

the metal gear set used on the ﬁrst

generation TDX with a gas locking

cylinder, making the feature

whisper quiet. It also provides a

shock-absorbing effect.

The Invacare®TDX®SP is the ﬁrst

model in the next generation of

TDX (Total Driving eXperience)

power wheelchairs. The TDX SP

takes all the best features of the

TDX series and improves upon

them with enhanced performance,

superior ride quality, quieter

chassis, and an elegantly simple

design.

TDXSP (Group 3 Rehab Seat) K0848 TDXSP (Group 3 Captain’s Seat) K0849 TDXSP HD (Group 3 Rehab Seat Heavy-Duty) K0850 TDXSP HD (Group 3 Captain’s Seat Heavy-Duty) K0851 TDXSP-CG (Group 3 Single Power) K0856 TDXSP-CG HD (Group 3 Single Power Heavy-Duty) K0858 TDXSP-MCG (Group 3 Multiple Power) K0861 TDXSP-MCG HD (Group 3 Multiple Power Heavy-Duty) K0862

ELEGANT SIMPLICITY. INSPIRING DESIGN.

Our designers started with sketches and drove the design so that aesthetics were never sacriﬁced for functionality.

The end result is an elegant design with a focus on simplicity and detail.

TDX SP SEATING OPTIONS. VERSATILITY.

Adjustable Rehab Seat

Van Seat

Elevating Rehab Seat

Formula

™

Tilt

The TDX®SP offers a wide variety of seating options that make it an

extremely versatile powerchair. The standard TDX SP offers a choice

of an adjustable Rehab (ASBA) seat that is growable in width and

depth. The ASBA seat starts in widths as low as 12" wide for smaller

applications, and can grow as wide as 24" and as deep as 22". Another

seating option on the TDX SP is a semi-recline captain’s seat. Available

in 16", 18", 20" and 22" widths, the

seat offers plush padding, generous

contours, and a reclining back providing

maximum comfort.

The TDX SP also offers the Formula

Powered Seating System which features

up to 7" of weight shift tilt.

The Formula

• Starting seat-to-ﬂoor height is

as low as 17.5"

• Up to 55˚ of tilt

• Up to 170˚ of recline

• Up to 7" of elevation

• All powered seating functions can

be operated either through or

separate from the driver control.

Pediatric Seat

Formula

™

Recline

Formula

™

Tilt/Recline

FASTER. MORE POWERFUL.

By optimizing the Torque speed curve, our motor/

electronics combination provides a 5.8 mph top speed

with ample torque. The chair gets consumers where they

need to go quickly, while also providing the power

required to handle those tough obstacles.

TDX®SP SPECIFICATIONS.

Adj. ASBA Rehab Seat FormulaCGTilt, Recline, FormulaCGElevate, Tilt/Elevate Van Seat

Overall dimensions Tilt/Recline Tilt/Recline/Elevate

Base Length (w/o front riggings) 35.25" 35.25" 35.25" 35.25" Base Width 24"/25.5" 24"/25.5" 24" 24"/25.5" Height 35.5" - 39.5" 36.5" - 40.5" 35.5" - 41.5" 38" w/o headrest

45" w/headrest

Seat Dimensions

Width 12" - 24" 12" - 24" 16 - 22" 16" - 22" Depth 12" - 22" 12" - 22" 16" - 22" 16" - 20" Back Height 12" - 24" 16" - 26" 20" - 26" 18"

with Headrest - - - 25"

Back Angle 85˚ - 105˚ 85˚ - 105˚ 85˚ - 105˚ 85˚ - 115˚

Seat-to-Floor Height

Low 16.5" @ 0˚ 17.5" @ 0˚ 18.5" @ 0˚ 21" Medium 18.5" @ 0˚ 18.5" @ 0˚ - -

Tall 20.5" @ 0˚ 19.5" @ 0˚ - -

Seat-to-Floor Height at 5˚ add 0.5" to each add 1" to each - - Weight

with batteries 264 lb. 315 lb. 285 lb. 277 lb.

without batteries 166 lb. 217 lb. 187 lb. 179 lb.

Battery Options 22NF/Group 24 22NF/Group 24/(3)22NF 22NF 22NF/Group 24 Wheel and caster size

Front/rear casters 6" x 2" 6" x 2" 6" x 2" 6" x 2"

Drive wheels 14" x 3" 14" x 3" 14" x 3" 14" x 3"

Maximum Speed

5.8 mph / 5 mph (heavy duty) 5.8 mph / 5 mph (heavy duty) 5.8 mph 5.8 mph / 5 mph (heavy duty)

Incline Capability 9˚ 9˚ 9˚ 9˚ Weight Capacity 300 lb. / 400 lb. (option) 300 lb. / 400 lb. (option) 300 lb. 300 lb. / 400 lb. (option) Turning radius

(including Center Mount Footboard)

22" 22" 22" 22"

Ground clearance 3" 3" 3" 3" Standard MK6i™Electronics MK690/SPJ™+ MK690/ACC/SPJ+ or MPJ™+ MK690/ACC/SPJ™+ w/PSS MK690/SPJ™+ Limited warranties

Base Frame 60 months 60 months 60 months 60 months Seat Frame 36 months 36 months 36 months 36 months Electronics 12 months 12 months 12 months 12 months Motor/gearbox 12 months 12 months 12 months 12 months

n1 24" width with (2) 22 NF batteries. Elevate systems require 22 NF batteries.

25.5" width with (2) Group 24 batteries or (3) 22 NF batteries.

n2 12" - 16" width available with Tilt only system, Recline and Tilt/Recline sizes range from

16" - 24" wide

n3 Elevate 16" -24" backheight, curved ABS or Adjustable ASBA. n4 Elevate only is 16.8" or Tilt/Recline/Elevate 18.5". n5 315 lb. for Tilt only system. 325 lb. Recline only and 370 lb. for Tilt/Recline. n6 Elevate Seat only.

The TDX®SR builds off of the proven TDX®SP platform and offers the

beneﬁts of Gearless Brushless TrueTrack motors. TrueTrack allows the

chair to maintain its true forward path keeping the chair tracking straight.

TrueTrack motors ultimately result in less fatigue for drivers of alternative

driver controls.

The TDX SR offers the same performance

features of the TDX SP including:

• Enhanced SureStep

• Quiet Stability Lock

• Contemporary Aesthetics

• Wider Rear Caster Spacing

TDXSR (Group 4 Rehab Seat) K0868 TDXSRV (Group 4 Captain’s Seat) K0869 TDXSR-HD (Group 4 Rehab Seat Heavy-duty) K0870 TDXSR-CG (Group 4 Single Power) K0877 TDXSR-CG-HD (Group 4 Single Power Heavy-duty) K0879 TDXSR-MCG (Group 4 Multiple Power) K0884 TDXSR-MCG-HD (Group 4 Multiple Power Heavy-duty) K0886

GEARLESS-BRUSHLESS GB™MOTOR.

Invacare®GB™motors are not only a key component of

TrueTrack technology, the design is 75% efﬁcient resulting

in 17% more battery range than Invacare’s 4-pole motors.

Battery range is an important feature for active users and

users requiring powered seating systems.

TRUETRACK TECHNOLOGY.

The patented TrueTrack technology features GB motors

and motor controller. This feature helps keep the power

wheelchair on a true forward path – even on many

slopes, thresholds and uneven terrains. TrueTrack mini-

mizes the need for veer correction, diminishing fatigue

for joystick and switch drivers.

TrueTrack Technology is beneﬁcial for the client for the

following reasons:

• As the power wheelchair holds a truer course, the

driver needs to make fewer course corrections.

This makes driving more efﬁcient by reducing the

necessary amount of movement. Reducing the

required movement can increase overall speed

(i.e. the client may be able to move down a hallway

faster, as less compensatory movements are required),

decrease fatigue, and promote safety/independence

while driving, because the chair is not pulled off

course. This is true for drivers using a proportional

control as well as a digital or non-proportional system.

• This feature is critical for clients who fatigue easily,

as less compensatory movements are required.

• This feature also is critical for clients who use a

non-proportional or digital access method (i.e. a

head array with proximity switches or pneumatic

sip-n-puff controls). Driving with switches can be

very tedious and inefﬁcient. Making frequent course

corrections signiﬁcantly increases the effort, time and

energy required. Fewer course corrections translates

to a more efﬁcient, safer driver.

TDX SR with Formula

™

Tilt

TDX SR with Formula

™

Tilt/Recline

TDX SR with Formula

™

Recline

TDX SR with Van Seating

TDX SR with Rehab Seating

The TDX SR is available with the adjustable rehab seat,

captain’s seating, and the full range of powered seating

options. The FormulaCGPowered Seating system offers

up to 7" of weight shift tilt, a low starting seat to ﬂoor

height of 17.5", numerous back type options, and

six combinations of tilt, recline, and elevate including:

• Tilt only

• Recline only

• Elevating seat

• Tilt/Recline combination

• Tilt/Elevate combination

• Tilt/Recline/Elevate combination

The TDX SR offers Smart Actuators standard at no

additional upcharge. Smart Actuators allow the

client to achieve a pre-set tilt, recline, and power

leg extension through use of the Power Center-Mount

front rigging. An audible alarm sounds to let the

client know that it is time to weight shift.

TDX SR SEATING OPTIONS.

TDX®SR SPECIFICATIONS.

Adj. ASBA Rehab Seat FormulaCGTilt, Recline, FormulaCGElevate, Tilt/Elevate Van Seat

Overall dimensions Tilt/Recline Tilt/Recline/Elevate

Base Length (w/o front riggings) 35.25" 35.25" 35.25" 35.25" Base Length (w/front riggings) 43" 43" 43" 43" Base Width 25.5" (w/o joystick) 25.5" (w/o joystick) 25.5" (w/o joystick) 25.5" (w/o joystick) Height 35.5" - 39.5" 36.5" - 40.5" 35.5" - 41.5" 38" w/o headrest

- - - 45" w/headrest

Motor Package TrueTrack GB TrueTrack GB TrueTrack GB TrueTrack GB Seat Dimensions

Width 12" - 24" 12" - 24" 16" - 22" 16", 18", 20", 22" Depth 12" - 22" 12" - 22" 16" - 22" Back Height 12" - 24" 16" - 26" 20" - 26" 18"

with Headrest - - - 25"

Back Angle 85˚ - 105˚ 85˚ - 105˚ 85˚ - 105˚ 85˚ - 115˚

Seat-to-Floor Height

Low 16.5" @ 0˚ 17.5" @ 0˚ 18.5" 21" Medium 18.5" @ 0˚ 18.5" @ 0˚ - -

Tall 20.5" @ 0˚ 19.5" @ 0˚ - -

Seat-to-Floor Height at 5˚ add 0.5" to each add 1" to each - Weight

with batteries 350 lb. 425 lb. 425 lb. 340 lb.

without batteries 252 lb. 327 lb. 327 lb. 242 lb.

Battery Options 22NF/Group 24 22NF/Group 24 22NF 22NF/Group 24 Wheel and caster size

Front/rear casters 6" x 2" 6" x 2" 6" x 2" 6" x 2"

Drive wheels 14" x 3" 14" x 3" 14" x 3" 14" x 3"

Maximum Speed

7 mph 7 mph 7 mph 7 mph

Incline Capability 9˚ 9˚ 9˚ 9˚ Weight Capacity 300/400 lb. (option) 300/400 lb. (option) 300 lb. 300/400 lb. (option) Turning radius

22" 22" 22" 22"

Ground clearance 3" 3" 3" 3" Standard MK6i™Electronics MKTT/MPJ™+ MKTT/MPJ™+ MKTT/MPJ™+ MKTT/MPJ™+ Limited warranties

Base Frame 60 months 60 months 60 months 60 months Seat Frame 36 months 36 months 36 months 36 months Electronics 12 months 12 months 12 months 12 months Motor/gearbox 60 months 60 months 60 months 60 months

n1 90˚ front rigging. n2 12"-16" width only available with tilt systems. All other powered seating systems start out at 16" n3 16" and 18" wide set to 16", 17", or 18" depth. 20 " and 22"wide set to 18", 19", or 20" depth.

n4. Elevate 16" -24" backheight, curved ABS or Adjustable ASBA. n5. Elevate only is 16.8" or Tilt/Recline Elevate is 18.5". n6. 6.8 mph top speed with maximum weight capacity of 400 lb., 7.1 mph top speed with typical user

weight of 200 lb.

The TDX®SC, also built off of the successful TDX®SP platform, features

10" drive tires, U1 batteries, and 2 pole motors. The TDX SC is an

extension of the TDX SP family and continues to offer the distinguishing

features of Enhanced SureStep®, Quiet Stability Lock, contemporary

aesthetics, and wider rear caster spacing for easy interfacing with

aftermarket docking devices. The TDX SC offers a variety of seating

options including an adjustable rehab seat, a van seat, Formula

Powered Tilt and Powered Elevating Seat.

TDX SC with Formula

™

Tilt

TDX SC with Van Seating

TDX SC with Rehab Seating

TDXSC (Group 3 Rehab Seat) K0848 TDXSCV (Group 2 Captain’s Seat) K0823 TDXSC2-CG (Group 2 Single Power) K0835

TDX®SC SPECIFICATIONS.

Adj. ASBA Rehab Seat FormulaCGTilt FormulaCGElevating Seat Van Seat

Overall dimensions

Base Length (w/o front riggings) 34" 34" 34" 34" Base Length (w/front riggings*) 39" 39" 39" 39" Base Width (w/o joystick) 24" 24" 24" 24"

Height** 36.5" - 38.5" 37.75" - 39.25" 36.75" - 41.75" 38 " w/o headrest

- - - 45 " w/headrest

Motor Package 2-pole 2-pole 2-pole 2-pole Seat Dimensions

Width 16" - 20" 16" - 20" 16" - 20" 16" - 22" Depth 16" - 20" 16" - 20" 16" - 20" 16" - 20" Back Height 16" - 24" 16" - 24" 16" - 24" 18"

with Headrest - - 25"

Back Angle 85˚ - 105˚ 85˚ - 105˚ 85˚ - 105˚ 85˚ - 115˚

Seat-to-Floor Height

Low 16.5" @ 0˚ 17.75" @ 0˚ 16.75" @ 0˚ 21" Medium 17.5" @ 0˚ 18.5" @ 0˚ - -

Tall 18.5" @ 0˚ 19.25" @ 0˚ - -

Seat-to-Floor Height at 5˚ 18" Med., 19" Tall 19.5" Med., 20.5" Tall - - Weight

with batteries 225 lb. 275 lb. 230 lb. 230 lb.

without batteries 178 lb. 228 lb. 183 lb. 183 lb.

Battery Options U1 U1 U1 U1 Wheel and caster size

Front/rear casters 6" x 2" 6" x 2" 6" x 2" 6" x 2"

Drive wheels 10.5" x 3.5" 10.5" x 3.5" 10.5" x 3.5" 10.5" x 3.5"

Maximum Speed

4.8 mph 4.8 mph 4.8 mph 4.8 mph

Incline Capability 9˚ 9˚ 9˚ 9˚ Weight Capacity 250 lb. 250 lb. 250 lb. 250 lb. Turning radius

19" 19" 19" 19"

Standard MK6i™Electronics MK660ACC/SPJ™+ MK660ACC/SPJ™+ w/PSS MK660ACC/SPJ™+ w/PSS MK660ACC/SPJ™+ Limited warranties

* Manual center-mount. ** With 20" back height and zero degree seat angle.

TDXSPREE (Group 3 Rehab Seat) K0848 TDXSPREE-CG (Group 3 Single Power) K0856

• Currently pending SADMERC approval

The TDX®Spree is a

distinctive and fun power

wheelchair for designed for

smaller clients.

• Gain access to areas not

previously reachable.

• Experience a smooth ride

in everyday terrain.

• Feel the intuitive

maneuverability of centerwheel drive technology.

• Admire the compact frame

We invite you to fall in love

with the TDX Spree!

TRANSPORT READY OPTION.

The TDX Spree offers standard a transport package standard. Please refer to page

22 for more information on Invacare’s Transport Ready Options.

Standard features of the TDX Spree:

• Adjustable rehab seat featuring

1" adjustment within a width range of 12"-16" and a depth range of 12"-18"

• 165 pound maximum weight

capacity

• Powered height adjustment of 5"

• Starting seat-to-ﬂoor height of

14.5", Medium and Tall of 16.5" and 18.5" respectively

• 2 pole motors

• 4.8 mph top speed

• U1 battery tray

• Transport tie-down options

• Enhanced SureStep curb climbing

capability of 2.5"

• Quiet Stability Lock

• 3" ground clearance

• Wider rear caster spacing for

interfacing with aftermarket docking devices

• MK6i

™

Single Drive Joystick

• Swingaway front riggings

• 8 fun color selections

Optional features for the TDX Spree:

• 45˚ manual tilt

• 45˚ Formula

™

power tilt

• MK6i Multiple Purpose Joystick

• Alternative driver controls

• Center-Mount front rigging

• One-sided fork package

Transport Ready Option

TDX Spree with Power Tilt

TDX Spree with Powered

Seat Height Adjustment

Manual Tilt

TDX Spree with Powered

Seat Height Adjustment

Power Tilt

TDX Spree with Powered

Seat Height Adjustment

TDX Spree

The TDX®Spree is designed to meet a wide variety

of rehab needs for smaller clients. The powered seat

height adjuster allows the client to reach peer level

and the low seat-to-ﬂoor height allows for easy access

to the ground. The optional tilt feature can be operated

manually by a caregiver or powered for the client to

accomplish their own weight shift positioning. The

TDX Spree allows the consumer to get to levels that

may not have been reachable before.

TDX®SPREE SPECIFICATIONS.

Adj. ASBA Rehab Seat Adj. ASBA Rehab Seat FormulaCGPowered Tilt

Overall dimensions (Manual Tilt)

Base Length (w/o front riggings) 34" 34" 34" Base Length (w/ front riggings*) 39" 39" 39" Base Width (w/o joystick) 24" 24" 24"

Height** 34.5" - 38.5" 34.5" - 38.5" 36.75" - 38.75"

Motor Package 2-pole 2-pole 2-pole Seat Dimensions

Width 12" - 16" 12" - 16" 12" - 16" Depth 12" - 18" 12" - 18" 12" - 18" Back Angle 85˚ - 105˚ 85˚ - 105˚ 85˚ - 105˚

Seat-to-Floor Height

Low 14.5" @ 0˚ 14.5" @ 0˚ 16.75" @ 0˚ Medium 16.5" @ 0˚ 16.5" @ 0˚ 17.75" @ 0˚ Tall 18.5" @ 0˚ 18.5" @ 0˚ 18.75" @ 0˚

Weight

with batteries 230 lb. 230 lb. 280 lb.

without batteries 183 lb. 183 lb. 233 lb.

Battery Options U1 U1 U1 Wheel and caster size

Front/rear casters 6" x 2" 6" x 2" 6" x 2"

Drive wheels 10.5" x 3.5" 10.5" x 3.5" 10.5" x 3.5"

Maximum Speed

4.8 mph 4.8 mph 4.8 mph

Incline Capability 9˚ 9˚ 9˚ Weight Capacity 165 lb. 165 lb. 165 lb. Turning radius

19" 19" 19"

Ground clearance 3" 3" 3" Standard MK6i™Electronics MK660ACC/SPJ™+ w/PSS MK660ACC/SPJ™+ w/PSS MK660ACC/SPJ™+ w/PSS Limited warranties

Base Frame 60 months 60 months 60 months Seat Frame 36 months 36 months 36 months Electronics 12 months 12 months 12 months Motor/gearbox 12 months 12 months 12 months

* Manual center-mount. ** With 20" back height and zero degree seat angle.

TRANSPORT READY OPTIONS.*

The new TDX®Family offers a

transport ready option (TRRO) that

includes four tie-down locations, a

battery securement system and a

wheelchair-anchored pelvic belt.

The chairs with TRRO conﬁguration

have been crash-tested in accordance

with the ANSI/RESNA Vol. 1 Section

19.5.3 Frontal Impact Test (W/C 19).**

Invacare also offers the TRBKTS

option. Unlike the TRRO conﬁgura-

tion, a chair with TRBKTS option

does not have a pelvic belt and it has

not been crash-tested in accordance

with W/C 19 or any other standard.

These options reinforce Invacare’s

market leadership in transport-ready

wheelchairs for consumers.

* As of this date, the U.S. Department of

Transportation has not approved any tie-down system for transportation of a user while in a wheelchair in a moving vehicle of any type. Accordingly, Invacare recommends that wheelchair users not be transported in vehicles of any kind while in wheelchairs and should be transferred for transportation into appropriate seating in vehicles and use the restraints made available by the auto industry.

** Please refer to the TDX SP (06-034) sell sheet or

page 25 of this lierature for the required ANSI/RESNA W/C19 sec. 6.2 Presale Literature Notiﬁcation.

Rear transport bracket.

Front transport bracket.

TDX Spree with Powered

Seat Height Adjustment

Manual Tilt

TDX SC with Formula

™

Tilt

TDX SC with Van Seating

Adjustable Rehab Seat

Formula

™

Tilt

TDX SR with Formula

™

Tilt/Recline

TDX SR with Rehab Seating

TDX Spree with Powered

Seat Height Adjustment

Power Tilt

The TDX Family…The Right Rehab Solution From One Source.

A. Minimum turning radius 23.6" with (2) 22NF batteries.

Minimum turning radius 24.4" with (2) Group 24 batteries. Minimum turn-around width 43.7" with (2) 22NF batteries. Minimum turn-around width 44.9" with (2) Group 24 batteries.

B. The TDX SP wheelchair with (2) 22NF batteries has a maximum

length of 35.25" (895 mm) and the TDX SP wheelchair with (2) Group 24 batteries has a maximum length of 35.63" (905 mm), meeting the ADA definition of a common wheelchair and the maximum length requirements of lifts on public vehicles.

C. Total wheelchair mass for TDX SP with (2) 22NF batteries = 280 lbs

(127.3 kg) Adult and 286 lb. (130 kg) Junior including front riggings, wheel locks, TRO brackets, wheelchair-anchored pelvic belt, and seating. Total wheelchair mass for TDX SP with (2) Group 24 batteries = 315 lb. (142.9 kg) Adult and 317 lb. (143.8 kg) Junior including front riggings, wheel locks, TRO brackets, wheelchairanchored pelvic belt, and seating.

D. Average lateral dummy displacement for TDX SP with

(2) 22NF batteries = approximately .53" (13.4 mm) Adult and .57" (14.4 mm) Junior. Average lateral dummy displacement for TDX SP with (2) Group 24 batteries = approximately .54" (13.7 mm) Adult and .51" (12.9 mm) Junior.

E. Overall Score for TDX SP Adult with (2) 22NF batteries =

18, Overall Rating = A Overall Score for TDX SP Junior with (2) 22NF batteries = 14, Overall Rating = B Overall Score for TDX SP Adult with (2) Group 24 batteries = 17, Overall Rating = A Overall Score for TDX SP Junior with (2) Group 24 batteries = 14, Overall Rating = B

F. i. The TDX SP tested was sized to accommodate a 168 lb. test

dummy (17" x 17" x 18" high and 14" Center-Wheel Drive tires.)

ii. The TDX SP was tied down using four tie-down brackets –

2 brackets located on the front of the base frame and 2 brackets located on the rear of the base frame.

iii. The TDX SP was tested with a 168 lb. test dummy.

iv. The TDX SP tested used a wheelchair-anchored pelvic belt and

vehicle-anchored shoulder belt.

v. The TDX SP tested complies with the performance requirements

of ANSI/RESNA W/C 19 sec. 5.3.

G. For all types of vehicles, the TDX SP requires four SAE J2249-

compliant tie-down strap assemblies for effective securement.

H. The TDX SP provides a location for anchoring of an Invacare-

provided pelvic belt. This belt has been tested in accordance with ANSI/RESNA W/C 19.

I. The wheelchair-anchored pelvic belt is supplied by Invacare.

ANSI/RESNA W/C 19 sec 6.2 Presale Literature Notification – TDX SP

ANSI/RESNA W/C 19 sec 6.2 Presale Literature Notification – TDX SR

A. Minimum turning radius 22.5" with (2) Group 24 batteries.

Minimum turn-around width 29" with (2) Group 24 batteries.

B. The TDX SR wheelchair with (2) Group 24 batteries has a maximum

length of 44" (1118 mm) and the maximum length requirements of lifts on public vehicles.

C. Total wheelchair mass for TDX SR with (2) Group 24 batteries =

347 lb. (158 kg) Adult.

D. Average lateral dummy displacement for TDX SR with (2) Group 24

batteries = approximately .53" (13.4 mm) Adult.

E. Overall Score for TDX SR Adult with (2) Group 24 batteries = 18,

Overall Rating = A

F. i. The TDX SR tested was sized to accommodate a 168 lb. test

dummy (17" x 17" x 22" high and 14" Center-Wheel Drive tires.)

ii. The TDX SR was tied down using four tie-down brackets –

2 brackets located on the front of the base frame and 2 brackets located on the rear of the base frame.

iii. The TDX SR was tested with a 168 lb. test dummy.

iv. The TDX SR tested used a wheelchair-anchored pelvic belt and

vehicle-anchored shoulder belt.

v. The TDX SR tested complies with the performance requirements

of ANSI/RESNA W/C 19 sec. 5.3.

G. For all types of vehicles, the TDX SR requires four SAE J2249-

compliant tie-down strap assemblies for effective securement.

H. The TDX SR provides a location for anchoring of an Invacare-

provided pelvic belt. This belt has been tested in accordance with ANSI/RESNA W/C 19.

I. The wheelchair-anchored pelvic belt is supplied by Invacare.

ANSI/RESNA W/C 19 sec 6.2 Presale Literature Notification – TDX SPREE

A. Minimum turning radius 18.9" with (2) U1 batteries.

Minimum turn-around width 29" with (2) U1 batteries.

B. The TDX SPREE wheelchair with (2) U1 batteries has a maximum

length of 39" (991 mm) and the maximum length requirements of lifts on public vehicles.

C. Total wheelchair mass for TDX SPREE with (2) U1 batteries = 237 lb.

(108 kg).

D. Average lateral dummy displacement for TDX SPREE with (2) U1

batteries = approximately .53" (13.4 mm).

E. Overall Score for TDX SPREE with (2) U1 batteries = 19,

Overall Rating = A Overall

F. i. The TDX SPREE tested was sized to accommodate a 130 lb. test

dummy (16" x 16" x 22" high and 10" Center-Wheel Drive tires.)

ii. The TDX SPREE was tied down using four tie-down brackets –

2 brackets located on the front of the base frame and 2 brackets located on the rear of the base frame.

iii. The TDX SPREE was tested with a 130 lb. test dummy.

iv. The TDX SPREE tested used a wheelchair-anchored pelvic belt

and vehicle-anchored shoulder belt.

v. The TDX SPREE tested complies with the performance require-

ments of ANSI/RESNA W/C 19 sec. 5.3.

G. For all types of vehicles, the TDX SPREE requires four SAE J2249-

compliant tie-down strap assemblies for effective securement.

H. The TDX SPREE provides a location for anchoring of an Invacare-

provided pelvic belt. This belt has been tested in accordance with ANSI/RESNA W/C 19.

I. The wheelchair-anchored pelvic belt is supplied by Invacare.

ANSI/RESNA W/C 19 sec 6.2 Presale Literature Notification – TDX SC

A. Minimum turning radius 20.1" with (2) U1 batteries.

Minimum turn-around width 31" with (2) U1 batteries.

B. The TDX SC wheelchair with (2) 22NF batteries has a maximum

C. Total wheelchair mass for TDX SC with (2) U1 batteries = 235 lb.

(106.8.3 kg) Adult.

D. Average lateral dummy displacement for TDX SC with (2) U1

batteries = approximately .47" (11.9 mm) Adult.

E. Overall Score for TDX SC Adult with (2) U1 batteries = 18,

Overall Rating = A

F. i. The TDX SC tested was sized to accommodate a 168 lb. test

dummy (17" x 17" x 22" high and 10" Center-Wheel Drive tires.)

ii. The TDX SC was tied down using four tie-down brackets –

2 brackets located on the front of the base frame and 2 brackets located on the rear of the base frame.

iii. The TDX SC was tested with a 168 lb. test dummy.

iv. The TDX SC tested used a wheelchair-anchored pelvic belt and

vehicle-anchored shoulder belt.

v. The TDX SC tested complies with the performance requirements

of ANSI/RESNA W/C 19 sec. 5.3.

G. For all types of vehicles, the TDX SC requires four SAE J2249-

compliant tie-down strap assemblies for effective securement.

H. The TDX SC provides a location for anchoring of an Invacare-

provided pelvic belt. This belt has been tested in accordance with ANSI/RESNA W/C 19.

I. The wheelchair-anchored pelvic belt is supplied by Invacare.

Invacare Corporation

www.invacare.com

USA One Invacare Way Elyria, Ohio 44035-4190 (800) 333-6900

Canada 570 Matheson Blvd. E., Unit 8 Mississauga, Ontario L4Z 4G4 Canada (800) 668-5324

and ®. All trademarks are owned by or licensed to Invacare Corporation unless otherwise noted.

Invacare TDXSR, TDX SC, TDX SP User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
