Invacare 1195 User Manual
FREEWAY
LITE
AEROSOL COMPRESSOR
MODEL IRC 1195
OWNER’S MANUAL
SPECIAL NOTES
SPECIAL NOTES
DANGER/WARNING/CAUTION notices as used in this
manual apply to hazards or unsafe practices which
could result in personal injury or property damage.
NOTICE
The information in this manual is subject to change
without notice.
This aerosol compressor is intended for household use.
WARNING
DO NOT install, maintain or operate this equipment
without first reading and understanding this manual.
If you are unable to understand the WARNINGS and
INSTRUCTIONS, contact your Home Healthcare Dealer
before attempting to use this equipment - otherwise
injury or damage may result.
“Caution: Federal law restricts this device to sale by or
on the order of a physician.”
2
TABLE OF CONTENTS
TABLE OF CONTENTS
SPECIAL NOTES .............................................................................................. 2
TABLE OF CONTENTS ................................................................................... 3
SAFETY SUMMARY ......................................................................................... 4
SPECIFICATIONS............................................................................................. 5
FEATURES........................................................................................................ 6
INTRODUCTION .............................................................................................. 9
OPERATION...................................................................................................... 9
Charging the Batteries ................................................................................. 9
Initial Battery Charging............................................................................. 9
Normal Battery Charging........................................................................ 10
Operating your Freeway Lite ..................................................................... 10
Power Supply Options ............................................................................ 10
Operation from the Wall Outlet.............................................................. 10
Operating from the Freeway Lite Battery Pack ....................................... 11
Operating from a Car or a Boat ............................................................. 11
Traveling with the Freeway Lite ............................................................ 12
Preparing for Treatment ............................................................................ 12
Taking the Treatment ................................................................................. 13
After the Treatment..................................................................................... 13
MAINTENANCE .............................................................................................. 14
Prolonging the Life of your Battery .......................................................... 14
Cleaning the Outer Case ........................................................................... 15
Care of your Freeway Lite.......................................................................... 15
Cleaning the Sidestream Nebulizer ......................................................... 15
Replacing the Intake Filter ........................................................................ 17
Fuse Replacement ...................................................................................... 17
ACCESSORIES AND SPARE PARTS............................................................ 17
Servicing ..................................................................................................... 18
TROUBLESHOOTING................................................................................... 18
LIMITED WARRANTY..................................................................................... 19
3
SAFETY SUMMARY
SAFETY SUMMARY
READ ALL INSTRUCTIONS BEFORE USING.
When using electrical products, especially when children are present, basic safety
precautions should always be followed, including the following:
DANGER
TO REDUCE THE RISK OF ELECTROCUTION:
Always unplug this product IMMEDIATELY after using.
DO NOT use while bathing.
DO NOT place or store product where it can fall or be pulled into a tub or sink.
DO NOT reach for product that has fallen into water. UNPLUG IMMEDIATELY.
DO NOT place in or drop into water or liquid.
WARNING
TO REDUCE THE RISK OF BURNS, ELECTROCUTION, FIRE OR INJURY TO PERSONS:
A product should NEVER be left unattended when plugged into a power source.
Close supervision is necessary when this product is used by, on or near
CHILDREN AND PHYSICALLY CHALLENGED INDIVIDUALS.
DO NOT operate unit longer than 20 minutes continuously. Allow 40 min-
utes for the unit to cool before operating again.
Use this product only for its intended use as described in this manual. Use
this product only under a physician's direction. DO NOT use attachments
NOT recommended by the manufacturer.
NEVER operate this aerosol compressor if it has a damaged cord or plug, if
it is NOT working properly, if it has been dropped or damaged, or dropped
into water; call Qualified Service Personnel for examination and repair.
Keep the cord away from HEATED or HOT surfaces.
NEVER drop or insert any object into any opening.
NEVER use while sleeping or drowsy.
DO NOT operate where aerosol (spray) products are being used or where
oxygen is being administered in a closed environment such as an oxygen tent.
This unit is oil-less. DO NOT lubricate.
DO NOT operate in the rain or other wet environments.
WARNING
Risk of electric shock. DO NOT disassemble. Refer servicing to qualified
service personnel.
SA VE THESE INSTRUCTIONS.
4
SPECIFICATIONS
MODEL IRC 1195 SPECIFICATIONS
Electrical Requirements: 90-240 VAC, 50-60Hz, or 12 -14 VDC
Running Current: 2A @ 10 psig @ 12 volts (approximately)
Ambient Temperature Range: 10
Power Wattage: 24 Watts, 60VA~
Thermal Protector: Internal Solid State - Auto Resettable
Safety Systems: Class II - Double Insulated
Intake Filter: 300 micron, polyethylene
Flowrate: Flowrate (typical): 6 lpm @ 10 psig
Width: 6.6-inches
Height: 6.1-inches
Depth: 5.1-inches (7.5-inches w/accessory bag)
o
C - 40o C (50o F - 104o F)
NOTE: Operating at temperature extremes may
increase treatment times.
NOTE: The Freeway Lite unit and Battery
Pack each have an internal resettable thermal fuse in case of overheating (operating
longer than 20 minutes) or using incorrect
polarity DC jack.
Type BF
*Weight: 4.1lbs (5.6 lbs. w/all accessories)
Battery Pack Dimensions: 4.7 x 2.0 x 2.1-inches
IMPORTANT DC Inlet
Polarity: External Positive + - Internal Negative
* Weights given include the 1.1 lb. removable battery.
Stands for Direct Current
~ Stands for Alternating Current
5
FEATURES
FEATURES
FREEWAY LITE
When you unpack your Freeway Lite, you will notice that the battery pack, nebulizer kit,
12 volt DC lead, AC/DC power pack and power cord are separated from the main unit.
The 12 volt DC lead, AC/DC power pack and power cord may be stored in the detachable accessory bag.
The battery pack fits into the front of the aerosol compressor unit. Remove the rubber
covers (black protective battery covers) over connector pins from the Freeway Lite
before installing the battery pack. The rubber covers can be stored in the clear pocket of
the inside flap of the carrying case.
NOTE: When the battery pack is not in place, it is essential to protect the battery
connections with the protective rubber covers provided.
There is a storage compartment for your nebulizer and medication (Nebulizer/Holder stand).
CAUTION
NEVER store your nebulizer and medication in the section of the
carrying case with the aerosol compressor. Liquid medication
may seriously damage the aerosol compressor.
Freeway
is a trademark of Medic-Aid Ltd.
6
