Intermec’s
FlexDock
Design Your Own:
Choose your Base and add the appropriate Cups, Power Supply and Line Cord.
System
A uniquely scalable
and modular docking
system giving users
the flexibility to
design the docking
system that best
suites their needs
today, as well as
in the future.
Accessories Guide
CONTENTS
Design Your Own:
Bases ............................................. 1
Destop Modules ............................2
Power Supplies .............................2
AC Line Cords ................................2
Mobile Computer Cups .................3
Mobile Printer Cups ......................3
Mobile Scanner Cups...................3
Mobile Computers and Printers
Battery Cups ............................. 4
Covers ........................................... 4
Mounting Kits .............................. 4
Bases
Accessory Name Part Number Description
Quad Charge Only 852-916-002 Provides 4 bays for charging individual
devices and/or battery packs. Power
supplies and country specific line cords
must be ordered separately.
Quad Ethernet
Back View
Dual Charge Only 852-918-002 Provides 2 bays for charging individual
Dual Ethernet
852-917-002 Provides 4 bays for Ethernet
communications and charging individual
devices and/or battery packs. Power
supplies and country specific line cords
must be ordered separately.
devices and/or battery packs. Power
supplies and country specific line cords
must be ordered separately.
852-919-002 Provides 2 bays for Ethernet
communications and charging individual
devices and/or battery packs. Power
supplies and country specific line cords
must be ordered separately.
Common Mixed
Configurations........................5
Pre-Configured:
CN70 & CN70e FlexDocks ............ 6
CN3, CN3e, CN4 & CN 4e
FlexDocks ..................................7
CN50 FlexDocks ............................7
CS40 FlexDocks ........................... 8
CK7 0 & CK71 Fl exDocks ............... 9
CK3 FlexDocks ............................10
Mobile Receipt Printers ..............11
Mobile Scanner FlexDocks..........11
Desktop
Assembled
Desktop
Dock
Bay 1:
Computer Cup
Back View
852-920-002 Provides (2) bays with dedicated
functionality. Bay 1: Accommodates
mobile device for charging and Ethernet or
modem or USB host communications, as
well as USB client connectivity. Ethernet
and modem communications require
add-on modules listed below. Bay 2: Used
for charging up to (2) batteries. Power
supplies and country specific line cords
must be ordered separately.
Bay 2:
Dedicated
Battery Cup
Intermec’s
FlexDock
System
Destop Modules
Accessory Name Part Number Description
Desktop Dock Ethernet Module
871-238-011 Module plugs into USB port of Desktop
base to provide Ethernet communications.
Accessory Guide
Desktop Dock
w/ Ethernet
Module
Ethernet Module
Desktop Dock Modum Module 871-238-002 Module plugs into USB port of Desktop
base to provide modem communications.
Power Supplies
Accessory Name Part Number Description
Quad Base Power Supplies 851-064-327 A 100W power supply for use with Quad
Charge Only and Quad Ethernet Bases.
Requires country specific line cord to be
ordered separately.
Dual or Desktop Base
Power Supply
851-095-131 A 48W power supply for use with Dual
Charge Only, Dual Ethernet, and Desktop
Bases. Requires country specific line cord
to be ordered separately.
AC Line Cords
Power Cord - China
Power Cord - Europe
Power Cord - UK
Power Cord - Australia
Power Cord - Italy
Power Cord - Japan
Power Cord - Denmark
Power Cord - India/S Africa
Power Cord - US
2
Power Cord - Switzerland
071918
1-974027-025
1-974029-020
1-974030-025
321-471-002
321-500-002
321-501-002
321-502-002
1-074028-025
321-470-001
Intermec’s
FlexDock
System
Mobile Computer Cups
Accessory Name Part Number Description
CK3 Mobile Computer Cup 203-916-001 Supports (1) mobile computer when
snapped into a bay of base unit.
Accessory Guide
CK70/71 Mobile Computer Cup 203-921-001 Supports (1) mobile computer when
snapped into a bay of base unit.
CN3(e)/CN4(e) Mobile Computer Cup 203-914-001 Supports (1) mobile computer when
snapped into a bay of base unit.
CN50 Mobile Computer Cup 203-918-002 Supports (1) mobile computer when
snapped into a bay of base unit.
CN70/70e Mobile Computer Cup 203-920-001 Supports (1) mobile computer when
snapped into a bay of base unit.
CS40 Mobile Computer Cup 203-923-001 Supports (1) mobile computer when
snapped into a bay of base unit.
Mobile Printer Cups
Accessory Name Part Number Description
PR2/PR3 Mobile Receipt Printer Cup 203-964-001 Supports (1) mobile printer when
snapped into a bay of base unit.
Mobile Scanner Cups
Accessory Name Part Number Description
SF61B Scanner Cup 213-007-001 Supports (2) scanners when snapped
into a bay of base unit.
3
Intermec’s
FlexDock
System
Accessory Guide
Mobile Computers and Printers Battery Cups
Accessory Name Part Number Description
CK70/71 & CK3 Battery Cup 203-917-001 Supports charging of (2) batteries when
snapped into a bay of base unit.
CN70/70e Battery Cup 203-922-002 Supports charging of (2) batteries when
snapped into a bay of base unit.
CS40 Battery Cup 203-924-001 Supports charging of (2) standard batteries
when snapped into a bay of base unit.
PR2/PR3 Mobile Receipt
Printer Battery Cup
203-965-001 Supports charging of (2) batteries when
snapped into a bay of base unit.
Covers
Accessory Name Part Number Description
Blank Cover 203-926-001 Optional cover for base bays currently not
in use. Intended to prevent debris from
accumulating on exposed bay contacts.
Mounting Kits
Accessory Name Part Number Description
Wall Mounting Kit 203-641-002 Consists of (1) metal rack with pre-drilled
holes for securing FlexDock bases and
mounting to wall surface. Also used with
700 Series, CK61, and CN3 / CN4 Series.
Rack Mounting Kit 203-945-001 Consists of (1) metal rack with pre-drilled
holes for securing FlexDock bases and
for mounting vertically to uprights of
standard 19" (48 cm) IT equipment rack.
Includes thumbscrews and two adapters
for mounting racks upto 15 degree angle
for better viewability. (Standard IT rack
must be ordered separately.)
4
FlexDock
Common Mixed Configurations:Intermec’s
System
Accessory Guide
Accessory Name Part Numbers Description
CN50/PR2 Dual Charge 852-918-001
203-918-001
203-964-002
851-095-131
CN70/PR2 Dual Charge 852-918-001
203-920-001
203-964-002
851-095-131
PR2/3 Battery and Printer
Quad Charge
852-916-001
203-964-001 x 2
203-965-001 x 2
851-064-327
Supports charging (1) CN50 computer and
(1) PR2 or PR3 receipt printer. Country
specific line cords must be ordered
separately.
Supports charging (1) CN70 or CN70e
computer and (1) PR2 or PR3 receipt
printer. Country specific line cords must
be ordered separately.
Support charging (4) PR2/3 battery packs
and (2) PR2 or PR3 printers. Country
specific line cords must be ordered
separately.
For additional options, see the “Design Your Own” Section.
5
Intermec’s
FlexDock
Pre-Configured:
Ready to Go out of the box.
System
Accessory Guide
CN70 & CN70e FlexDocks
Accessory Name Part Number Description
CN70/70e Quad Charge Only DX4A2111100
DX4A2111110 (incls NA cord)
CN70/70e Quad Ethernet
Back View
CN70/70e Dual Charge Only DX2A21120
CN70/70e Dual Ethernet
DX4A1111100
DX4A1111110 (incls NA co rd)
DX2A21110 (incls NA co rd)
DX2A11120
DX2A11110 (incls NA co rd)
Supports charging for up to (4) CN70 and/
or CN70e computers. Includes power
supply. Country specific line cords must be
ordered separately.
Supports Ethernet communications
and charging for up to (4) CN70 and/or
CN70e computers. Includes power supply.
Country specific line cords must be
ordered separately.
Supports charging for up to (2) CN70 and/
or CN70e computers. Includes power
supply. Country specific line cords must be
ordered separately.
Supports Ethernet communications
and charging for up to (2) CN70 and/or
CN70e computers. Includes power supply.
Country specific line cords must be
ordered separately.
Back View
CN70/70e Desktop DX1A01A20
DX1A01A10 (incls NA co rd)
CN70/70e 4-Position Battery
Charger
CN70/70e 8-Position Battery
Charger
6
DX2A2AA20
DX2A2AA10 (incls NA co rd)
DX4A2AAAA00
DX4A2AAAA10 (incls NA c ord)
Supports (1) CN70 or CN70e computer for
charging and Ethernet or modem or USB
host communications, as well as USB client
connectivity; and battery charging for up to
(2) CN70/e batteries. Ethernet and modem
communications require add-on modules
listed under “Design Your Own” section.
Includes power supply. Country specific line
cords must be ordered separately.
Supports charging for up to (4) CN70 or
CN70e batteries. Includes power supply.
Country specfic line cords must be ordered
separately.
Supports charging for up to (8) CN70 or
CN70e batteries. Includes power supply.
Country specfic line cords must be ordered
separately.
Intermec’s
FlexDock
System
Accessory Guide
CN3, CN3e, CN4 & CN4e FlexDocks
Accessory Name Part Number Description
CN3/CN4 Quad Charge Only DX4A2333300
DX4A2333310 (incls NA cor d)
CN3/CN4 Quad Ethernet
Back View
DX4A1333300
DX4A1333310 (incls N A cord)
Supports charging for up to (4) CN3/e
and/or CN4/e computers. Includes power
supply. Country specific line cords must be
ordered separately.
Supports Ethernet communications
and charging for up to (4) CN3/e and/or
CN4/e computers. Includes power supply.
Country specific line cords must be
ordered separately.
CN50 FlexDocks
Accessory Name Part Number Description
CN50 Quad Charge Only DX4A2555500
DX4A2555510 (incls NA cor d)
CN50 Quad Ethernet
Back View
DX4A1555500
DX4A1555510 (incls NA cor d)
Supports charging for up to (4) CN50
computers. Includes power supply.
Country specific line cords must be
ordered separately.
Supports Ethernet communications and
charging for up to (4) CN50 computers.
Includes power supply. Country specific
line cords must be ordered separately.
7
Intermec’s
FlexDock
System
CS40 FlexDocks
Accessory Name Part Number Description
CS40 Quad Charge Only DX4A2666600
DX4A2666610 (incls N A cord)
Supports charging for up to (4) CS40
computers. Includes power supply.
Country specific line cords must be
ordered separately.
Accessory Guide
CS40 Quad Ethernet
Back View
CS40 Dual Charge Only DX2A26620
CS40 Dual Ethernet
Back View
DX4A1666600
DX4A1666610 (incls N A cord)
DX2A26610 (incls NA cor d)
DX2A16620
DX2A16610 (incls NA cor d)
Supports Ethernet communications and
charging for up to (4) CS40 computers.
Includes power supply. Country specific
line cords must be ordered separately.
Supports charging for up to (2) CS40
computers. Includes power supply.
Country specific line cords must be
ordered separately.
Supports Ethernet communications and
charging for up to (2) CS40 computers.
Includes power supply. Country specific
line cords must be ordered separately.
CS40 Desktop DX1A06E20
DX1A06E10 (incls NA co rd)
CS40 4-Position Battery
Charger
CS40 8-Position Battery
Charger
DX2A2EE20
DX2A2EE10 (incls NA co rd)
DX4A2EEEE00
DX4A2EEEE10 (incls N A cord)
Supports (1) CS40 computer for charging
and Ethernet or modem or USB host
communications, as well as USB client
connectivity; and battery charging for up
to (2) standard CS40 batteries. Ethernet
and modem communications require
add-on modules listed under “Design Your
Own” section. Includes power supply.
Country specific line cords must be
ordered separately.
Supports charging for up to (4) standard
CS40 batteries. Includes power supply.
Country specfic line cords must be ordered
separately.
Supports charging for up to (8) standard
CS40 batteries. Includes power supply.
Country specfic line cords must be ordered
separately.
8
Intermec’s
FlexDock
System
CK70 & CK71 FlexDocks
Accessory Name Part Number Description
CK70/71 Quad Charge Only DX4A2222200
DX4A2222210 (incls N A cord)
Supports charging for up to (4) CK70
and/or CK71 computers. Includes power
supply. Country specific line cords must be
ordered separately.
Accessory Guide
CK70/71 Quad Ethernet
Back View
CK70/71 Dual Charge Only DX2A22220
CK70/71 Dual Ethernet
Back View
DX4A1222200
DX4A1222210 (incls N A cord)
DX2A22210 (incls NA co rd)
DX2A12220
DX2A12210 (incls NA co rd)
Supports Ethernet communications
and charging for up to (4) CK70 and/or
CK71 computers. Includes power supply.
Country specific line cords must be
ordered separately.
Supports charging for up to (2) CK70
and/or CK71 computers. Includes power
supply. Country specific line cords must be
ordered separately.
Supports Ethernet communications
and charging for up to (2) CK70 and/or
CK71 computers. Includes power supply.
Country specific line cords must be
ordered separately.
CK70/71 Desktop DX1A02B20
DX1A02B10 (incls NA cor d)
CK70/71 4-Position
Battery Charger
CK70/71 8-Position
Battery Charger
9
DX2A2BB20
DX2A2BB10 (incls NA co rd)
DX4A2BBBB00
DX4A2BBBB10 (incls N A cord)
Supports (1) CK70 or CK71 computer for
charging and Ethernet or modem or USB
host communications, as well as USB
client connectivity; and battery charging
for up to (2) CK70, CK71 or CK3 batteries.
Ethernet and modem communications
require add-on modules listed under
"Design Your Own" section. Includes
power supply. Country specific line cords
must be ordered separately.
Supports charging for up to (4) CK7x or
CK3 batteries. Includes power supply.
Country specfic line cords must be ordered
separately
Supports charging for up to (8) CK7x or
CK3 batteries. Includes power supply.
Country specfic line cords must be ordered
separately.
Intermec’s
FlexDock
System
Accessory Guide
CK3 FlexDocks
Accessory Name Part Number Description
CK3 Quad Charge Only DX4A2444400
DX4A2444410 (incls N A cord)
Supports charging for up to (4) CK3
computers. Includes power supply.
Country specific line cords must be
ordered separately.
CK3 Quad Ethernet
CK3 4-Position Battery
Charger
CK3 8-Position Battery
Charger
Back View
DX4A1444400
DX4A1444410 (incls NA cor d)
DX2A2BB20
DX2A2BB10 (incls NA co rd)
DX4A2BBBB00
DX4A2BBBB10 (incls N A cord)
Supports Ethernet communications and
charging for up to (4) CK3 computers.
Includes power supply. Country specific
line cords must be ordered separately.
Supports charging for up to (4) CK3
and/or CK7x batteries. Includes power
supply. Country specfic line cords must
be ordered separately.
Supports charging for up to (8) CK3
and/or CK7x batteries. Includes power
supply. Country specfic line cords must
be ordered separately.
10
Intermec’s
FlexDock
System
Accessory Guide
Mobile Receipt Printers FlexDocks
Accessory Name Part Number Description
PR2/3 Quad Charge Only DX4A2777700
DX4A2777710 (incls NA cor d)
Supports charging for up to (4) PR2 or
PR3 receipt printers. Includes power
supply. Country specific line cords must
be ordered separately.
PR2/3 Dual Charge Only DX2A27710 (incls NA co rd)
DX2A27720
PR2/3 4-Position Battery
Charger
PR2/3 8-Position Battery
Charger
DX2A2FF10 (inc ls NA cord)
DX2A2FF20
DX4A2FFFF00
DX4A2FFFF10 (incls NA cor d)
Supports charging for up to (2) PR2 or
PR3 receipt printers. Includes power
supply. Country specific line cords must
be ordered separately.
Supports charging for up to (4) PR2 or PR3
batteries. Includes power supply. Country
specific line cords must be ordered
separately.
Supports charging for up to (8) PR2 or PR3
batteries. Includes power supply. Country
specific line cords must be ordered
separately.
© 201 4 Honeyw ell Interna tional Inc.
612 150-C 05/ 14
11
Mobile Scanner FlexDocks
Accessory Name Part Number Description
SF61B 4-Position Charger DX2A28810
DX2A28820
Supports charging for up to (4) SF61B
scanners. Includes power supply.
Country specific line cords must be
ordered separately.
Loading...
