P/N 070505-001
Getting Started Guide
™
5023 Data
Collection PC
ContentsContents
ContentsContents
Contents
Introducing the 5023 Data Collection PC 5
Equipment You Need to Get Started 5
Turning On the 5023 and Verifying Operation 9
About the Bridge Battery 8
Charging and Installing the Main Battery Pack 6
Unpacking the 5023 6
Specifications 10
Getting the 5023 Up and Running 5
Where to Find Other Information 11
32
Intermec Technologies Corporation
6001 36th Avenue West
P.O. Box 4280
Everett, WA 98203-9280
U.S. service and technical support: 1-800-755-5505
U.S. media supplies ordering information: 1-800-227-9947
Canadian service and technical support: 1-800-688-7043
Canadian media supplies ordering information: 1-800-268-6936
Outside U.S. and Canada: Contact your local Intermec service supplier.
The information contained herein is proprietary and is provided solely for
the purpose of allowing customers to operate and/or service Intermec
manufactured equipment and is not to be released, reproduced, or used
for any other purpose without written permission of Intermec.
Information and specifications in this manual are subject to change
without notice.
2000 by Intermec Technologies Corporation
All Rights Reserved
The word Intermec, the Intermec logo, JANUS, IRL, Trakker, Antares,
Universal Access Point, UAP, TE2000, Data Collection Browser,
dcBrowser, Data Collection PC, Adara, Duratherm, EZBuilder, Precision
Print, PrintSet, Virtual Wedge, and CrossBar are either trademarks or
registered trademarks of Intermec Technologies Corporation.
Throughout this manual, trademarked names may be used. Rather than put
a trademark ( or ) symbol in every occurrence of a trademarked name,
we state that we are using the names only in an editorial fashion, and to
the benefit of the trademark owner, with no intention of infringement.
3
2
0
5
Introducing the 5023 Data Collection PC
The 5023 Data Collection PC™ is a portable hand-held computer that
comes ready to connect to your RF network. With an IEEE 802.11B High
Rate (HR) radio, Smart Card reader, and handle with scanner trigger, the
5023 makes data collection easy and is engineered to take full advantage
of its Microsoft Windows CE operating system.
Equipment You Need to Get Started
(Part No. 065236) or D5020 Communications Dock
To use the 5023 Data Collection PC, you need this equipment:
• Lithium-ion main battery pack (Part No. 068537, sold separately)
• Z2400 battery charger
• (Optional) L5020 Serial Communications Adapter and power supply
Getting the 5023 Up and Running
Unpack the 5023 and documentation.
Charge and install a main battery pack.
Turn on the 5023 and verify correct operation.
1
2
Follow these steps to start using your new 5023:
3
These steps are described in detail in the next sections.
