Intergraph Mylex AcceleRAID 250 Installation Guide
AcceleRAID™
Installation Guide
AcceleRAID 200
AcceleRAID 250
PCI to Ultra2 SCSI
RAID Controllers
P/N: 775007-01
AcceleRAID™
Installation Guide
AcceleRAID 200
AcceleRAID 250
PCI to Ultra2 SCSI
RAID Controllers
Part Number 775007-01
© Copyright 1999 Mylex Corporation.
All Rights Reserved.
All contents of this manual are copyrighted by Mylex
Corporation. The information contained herein is the
exclusive property of Mylex Corporation and shall not be
copied, transferred, photocopied, translated on paper, film,
electronic media, or computer-readable form; or otherwise
reproduced in any way, without the express written
permission of Mylex C orporation.
Greetings
Thank you for purchasing the Mylex AcceleRAID™ controller. This manual describes the
installation of the Mylex AcceleRAID controllers. Requests for technical information
about this and other M ylex Corporation products should be made to your Mylex
authorized reselle r or Myl ex marketing representative.
Please Notice
Mylex is a registered trademark, and AcceleRAID, DAC960PRL, and DAC960PTL are a
trademarks of Mylex Corporation.
Microsoft, MS-DOS and Windows are registered trademarks of the Micr osoft
Corporation. Novell is a registere d t ra demark of Novell corporation. LSI and Symbios
Logic are registered t rademarks of LSI Logi c C orporation. Other names that are
trademarks may be used herein for the purpose of identifying the products or services of
their respective owners. Unless otherwise noted, companies, names and data used in
examples herein ar e ficti tious.
Our Policy
Although reason able efforts have been made to assure the accuracy of the inf o r m ation
contained herein, this publication could include technical inaccuracies or typographical
errors. Mylex Corporation expressly disclaims liability for any error in this information,
and for damages, w hether direct, indirec t, spe cial, exemplary, consequential or otherwi se,
that may result from such error, including but not limited to loss of profits resulting from
the use or misuse of the manual or information contained therein (even if Mylex
Corporation has been advised of the possibility of such damages). Any questions or
comments regarding this document or its contents should be addressed to Mylex
Corporation at the address shown on the cover.
The following paragraph does not apply to the United Kingdom or any country where such
provision s are inco n sistent with local l aw:
MYLEX CORPORATION PROVIDES THIS PUBLICATION “AS IS” WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
Some states do not allow disclaimer of express or implied warranties or the limitation or
exclusion of liability for indirect, special, exemplary, incidental or consequential damages
in certain transactions; therefore, this statement may not apply to you. Also, you may have
other rig hts which vary from jurisdiction to ju risdiction.
Information in this publication is subject to change without notice and does not represent a
commitment on the part of Mylex Corporation. Changes may be made periodically to the
information herein; th ese changes will be incorpora ted in new editions of the publ ic ation.
Mylex Corporatio n re serves the righ t to make i mpro v ement s and/ or ch ang es a t an y t ime in
the product(s) and/or program(s) described in this publication.
It is possible that this publication may contain reference to, or information about, Mylex
Corporation products (machines and programs), programming or services that are not
announced in your country. Such references or information must not be construed to mean
that Mylex Corporation intends to announce, provide, or make available such Mylex
products, programming, or services in your jurisdiction.
About This Manual
This installation guide covers hardware set-up and configuration procedu r es
necessary for the installation of Mylex AcceleRAID PCI to Ultra SCSI
RAID controllers.
Chapter 1 describes the controllers, standard package contents, and usersupplied items necessary for installation.
Chapter 2 describes steps to be performed prior to controller installation.
Chapter 3 describes the physical installation of the controller.
Chapter 4 describes controller start-up utilities and RAID EzAssist.
Appendix A describes hardware and environmental specifications.
Appendix B describes error messages and how to correct problems that
cause errors.
Appendix C provides information about enclosure management.
Appendix D provides regulatory information.
Conventions
Throughout the manual, the following conventions are used to describe user
interaction with the product:
prompt This style of type indicates screen display messages
Enter Press the key labeled “Enter” (or “Delete”, etc.)
☛
Note
Supplementary information that can ha ve an effect on
system performance
m Caution
Notification that a proscribed action has the potential
to adversely affect equipment operation, system
performance, or data integrity
,
WARNING
Notification th at a proscribed action will
result i n equipment da mage, data los s , or p er s on al
injury
definitely
Contents
Chapter 1
Introduction
Product Description ...........................................................................1-1
Controller Features and Functions .............................................1-2
Operating System Support ................................................... ...... ..... ..1-3
Standard Package Contents .............................................................1-3
Hardware .................................................................................... 1-3
Software ..................................................................................... 1-3
User-supplied Items ..........................................................................1-4
Chapter 2
Preinstallation Planning
SCSI Termination .............................................................................2-2
AcceleRAID 200 Termination .....................................................2-2
AcceleRAID 250 Termination ............................................................2-4
SCSI Cabling ...................................... ...... ..... ...... ..............................2-6
SCSI Drive Preparation ................................................................... ..2-8
Chapter 3
Installation
This chapter describes: .....................................................................3-1
Before You Begin ..............................................................................3-1
Connectors and Jumpers ..................................................................3-2
Installing the Controller ......................................................................3-3
Chapter 4
Controller Start-up
Procedural Overview .........................................................................4-1
Controller Start-up .............................................................................4-2
BIOS Options Sequence ...................................................................4-2
Setting BIOS Options ................................................................4-3
Using RAID EzAssist .........................................................................4-5
Operating System .......................................... ...... ..............................4-7
Installing the AcceleRAID as the Primary Controller ..................4-7
Installing the AcceleRAID into an Existing System with a
SCSI Boot Device ....................................................................4-7
Operating System Device Drivers .....................................................4-8
Global Array Manager (GAM) ............................................................4-8
In Case of Problems ..........................................................................4-9
Manual No. 775007 v
Appendix A
AcceleRAID Specifications
General Hardware Specifications ......................................................A-1
AcceleRAID ................................................................................A-1
Environmental Specifications ............................................................A-2
DAC960PTL Block Diagram ..............................................................A-3
Appendix B
AcceleRAID Error Messages
Error Messages .................................................................................B-1
Start-up Error Messages ............................................................B-1
Drive Check Error Messages ......................... ...... ...... ..... ............B-1
Aborted Installation ............................................................................B-2
NVRAM Error .............................................................................B-2
System Reboot or Power Down .........................................................B-3
Appendix C
Enclosure Management
Introduction ....................................................................................... C-1
SAF-TE ...........................................................................................C-1
Appendix D
Regulatory Information
FCC Class B Compliance ..........................................................D-1
FCC Declaration of Conformity ..................................................D-2
CE Declaration of Conformity ....................................................D-3
CE Community of Europe ..........................................................D-4
Underwriters Laboratories Listing and Warning ........................D-5
Glossary
vi AcceleRAID Installation Guide
This chapter describes:
• Product description
• Standard package contents
• User supplied items
Chapter 1
Introduction
AcceleRAID 200
Figure 1-1. AcceleRAID Disk Array Controllers
AcceleRAID 250
Product Description
The Mylex AcceleRAID™ 200 (D AC960PTL-0™) and AcceleRAID™ 250
(DAC 960PTL-1™) controllers are I
SCSI RAID controllers designed to add RAID capability to SCSI channels
that are resident on a system board. Mylex AcceleRAID controllers supply
the necessary signals that enable SCSI Interrupt Steering Logic (SISL)
hardware to capture and control the embedded SCSI channels(s) on the
system board. This feature implements RAID capabilities on the system
board resident SCSI channels.
The AcceleRAID 200 controller must reside in a PCI slot specifically preconfigured to support SISL. The AcceleRAID 250 may reside in the
dedicated slot (for a SISL implementation), or in any other PCI slot (to
function as a standard PCI to Ultra2 SCSI RAID controller). System boards
that support the AcceleRAID controllers include the Intel
board.
Manual No. 775007 1-1
O ready, half-length, PCI to Ultra2
2
®
N440BX server
Product Description
Controller Features and Functions
AcceleRAID 200 Features:
• SISL to implement RAID on system board resident SCSI channels
• Support for Wide and Narrow Ultra2 SCSI LVD, and most other SCSI
drive types
☛
Note
Supported SCSI drive types include SCSI -1, Fast
SCSI, Wide Fast SCSI, Ultra SCSI, Wide Ultra SCSI,
and Wide Ultra2 SCSI.
• Full support of RAID plug-and-play, for I
• Supports RAID levels 0, 1, 3, 5, 0+1, 10, 30, 50, and JBOD on
embedded SCSI controller(s)
• On-board, high performance RISC processor and EDO ECC DRAM
cache for high speed, fault tolerant I/O transfers
• 512KB, 8-bit flash EEPROM for BIOS and code supports future
enhancements through firmware upgrad es
O compliant system boards
2
AcceleRAID 250 Features
Includes all of the features of the AcceleRAID 200, plus the following:
• An additional Wide Ultra2 SCSI RAID LVD channel on the controller
to extend the number of channels on the system board
• Ability to operate in an ordinary (not specifically configured) PCI slot
as a single channel controller
☛
Note
The AcceleRAID 250 will work as a single-channel,
Wide Ultra2 SCSI LVD RAID controller with a
system board that has an available PCI slot.
A specially configured, dedicated PCI slot is required
to enable SISL, which allows the controller to add
RAID capability to the system board’s built-in SCSI
channels.
1-2 AcceleRAID Installation Guide
Introduction
Operating System Support
MS-DOS 5.x, 6.x, and above are supported using drivers that reside in the
AcceleRAID BIOS. Many other popular operating systems are supported
using software drivers in the Disk Array Controller Software Kit that is
included with the AcceleRAID controller (see the Disk Array Controller
Software Kit Installation Guide and User Manual – P/N 771929)
Standard Package Contents
The following items are supplied with the standard shipping package:
Hardware
• AcceleRAID 200 or AcceleRAID 250 Disk Array Controller with
documentation
Software
• RAID EzAssist (Disk Array Controller Configuration Utility) with
documentation on CDROM
• Disk Array Controller Software Kit (OS drivers, and GAM Server)
with documentation on CDROM
• Global Array Manager (GAM client) with documentation on CDROM
AcceleRAI DController
Hardware Quick
Install Guide
Diskette
with
Drivers
CDROM with Additional
Hardware Manuals,
SoftwareManuals,
and GAM Client
Software
Figure 1-2. S t an dard Package Contents
Manual No. 775007 1-3
User-supplied Items
User-supplied Items
The following user-supplied items are required to perform this installation:
• Compatible host system with a PCI slot (PCI 2.1 compliant) prewired
for SCSI Interrupt Steering Logic control of the embedded SCSI
channel(s)
• Network operating system software (as required)
• Static grounding strap or electrostatic discharge (ESD) safe work area
• Disk array enclosure (or equivalent) and SCSI disk drives
☛
Note
The supported SCSI drive types include Ultra2 SCSI
with LVD as well as the following single-ended SCSI
types: SCSI-1, Fast SCSI, Wide Fast SCSI, Ultra
SCSI, and Wide Ultra SCSI.
• SCSI cables to connect between the system board SCSI conn ectors and
disk drives (and if an AcceleRAID 250 is installed, between the
AcceleRAID controller and disk drives).
Figure 1-3. AcceleRAID 250 External Connector (0.8mm UHD Centronics 68F):
68-Pin Very High Density Cable Interconnect (VHDCI)
Figure 1-4. AcceleRAID 250 Internal Connector (HD DB68F):
68-Pin High Density
1-4 AcceleRAID Installation Guide
Chapter 2
Preinstallation Planning
This chapter describes:
• SCSI termination
• SCSI cabling
• SCSI drive preparation
There are some configuration steps that need to be performed prior to
installing an AcceleRAID controller into the system. These steps include:
checking the SCSI termination requirements, selecting the appropriate SCSI
cabling, and preparing the SCSI drives for use in the array.
AcceleRAID 200
AcceleRAID 250
Figure 2-1. AcceleRAID Controllers
Manual No. 775007 2-1
SCSI Termination
SCSI Termination
Correct termination is critical for the SCSI channels. Ter mination on the end
of the cable connecting the disk drives (or other SCSI devices) is required.
If an AcceleRAID 250 is installed, the controller’s terminat ion is
automatically set.
AcceleRAID 200 T ermination
The system board contains the SCSI I/O chips and termination used by the
AcceleRAID controller. Refer to the instructions and/or specifications
furnished with the system board for information regarding how termination
is implemented.
See Figure 2-2 for an example of terminating an internal – external drive
configuration.
☛
Note
For purposes of this discussion, it is assumed that the
illustrated internal and external connectors are both on
the same SCSI channel.
It is better to terminate the ends of the SCSI bus itself
than it is to terminate the end devices o n the bus. This
allows hot sw ap devices to be added or removed from
the SCSI bus without affecting termination.
2-2 AcceleRAID Installation Guide
SCSI Termination
T
on System Board
Must be Enabled
Preinstallation Planning
T
AcceleRAID Controller
Internal Drive
Configuration
SCSI Termination
T
on System Bo ard
T
Must be Enabled
AcceleRAID Controller
External Drive
Configuration
T
SCSI Termination
on System Board
T
Must be Disabled
AcceleRA ID Controller
Internal – E xternal
Drive Configuration
Figure 2-2. System Board SCSI Termination Examples
Manual No. 775007 2-3
AcceleRAID 250 Termination
AcceleRAID 250 Termination
The AcceleRAID 250 is equipped with automatic SCSI termination
circuitry. If the controller is at the end of the SCSI bus, it automatically
enables on-board termination.
If all the SCSI devices on the channel are connected either to the internal
connector or to the external connecto r, the end of the SCSI bus farthest from
the controller must have a terminator installed. In this case, the controller
automatically enables on-board termination. See Figure 2-3 for examples of
internal or external drive configurations.
If some SCSI devices on the channel are con nected to the internal con nector,
and some are connected to the external connector, the two ends of the SCSI
bus farthest from the controller must each be terminated. In this case, the
controller automatically disables on-board termination. See Figure 2-3 for an
example of an internal – external drive configuration.
☛
Note
The illustrated internal and external connectors are
both on the same channel.
It is better to terminate the ends of the SCSI bus itself
than it is to terminate the end devices o n the bus. This
allows hot sw ap devices to be added or removed from
the SCSI bus without affecting termination.
2-4 AcceleRAID Installation Guide
Preinstallation Planning
T
T
Auto Termination
Enabled
Auto Termination
T
Enabled
T
Auto Termination
Disabled
T
Internal Dr ive
Configuration
External Drive
Configuration
T
Internal – External
Drive Configuration
Figure 2-3. AcceleRAID 250 SCSI Termination Examples
Manual No. 775007 2-5
SCSI Cabling
SCSI Cabling
An Ultra SCSI or an Ultra2 SCSI channel supports up to 15 drives.
m Caution
Wide and narrow SCSI drives must not be installed
together on any one channel, or AcceleRAID
controller malfunction may occur.
LVD Mode
The controller supports Ultra2 SCSI with LVD. If all drives attached to a
controller drive channel support Ultra2 SCSI with LVD, then that channel
will operate at 40 mega-transfers per second (or 80 MB with Wide Ultra2
SCSI). This setup allows a maximum SCSI bus length of up to 12 meters.
☛
Note
The SCSI bus length can be extended to 25 meters if
only the controller and one drive are on the bus.
Single-ended Mode
If any device on the channel is not Ultra2 SCSI capable, the channel will
revert to single-ended operation mode. The SCSI bus lengths will then be
limited to the single-ended bus lengths shown in Table 2-1.
2-6 AcceleRAID Installation Guide
Preinstallation Planning
Table 2-1. Supported SCSI Formats and Bus Lengths
Bus
Speed,
SCSI Drive Type*
SCSI-1 5 8 6 - 8
Fast SCSI 10 8 3 - 8
Fast Wide SCSI 20 16 3 - 16
Ultra SCSI 20 8 1.5 - 8
Ultra SCSI 20 8 3 - 4
Wide Ultra SCSI 40 16 - - 16 †
Wide Ultra SCSI 40 16 1.5 - 8
Wide Ultra SCSI 40 16 3 - 4
Ultra2 SC SI 40 8 Not Defined 12 8
Wide Ultra2 SCSI 80 16 Not Defined 12 16
SCSI Trade Association (STA) Terms
*
MB/Sec,
Max.
† The maximum number of devices allowed on a Wide Ultra SCSI bus is 8 unless
bus extender technology is used
Bus
Width,
Bits
Max. Bus Length, Meters* Max. Device
Single-ended Low-Voltage
Differential
Support
(Including
Controller)
Manual No. 775007 2-7
SCSI Drive Preparation
SCSI Drive Preparation
Prepare the drives for installation as follows:
• Remove any terminators attached to the drive or set any drive
termination jumpers to the disabled position.
• Set the SCSI addresses on the drives.
☛
Note
Each drive must have a unique ID chosen from 0
through 6 or 8 through 15. ID 7 cannot be used as a
drive ID because it is reserved for the controller.
• Enable termination power on the drives.
Refer to the drive manual for specific information about drive configuration
settings.
☛
Note
The supported SCSI drive types include Ultra2 SCSI
with LVD as well as the following single-ended SCSI
types: SCSI-1, Fast SCSI, Wide Fast SCSI, Ultra
SCSI, Wide Ultra SCSI, and Wide Ultra2 SCSI.
m Caution
If wide drives are to be connected to a narrow SCSI
connector (by a 68-pin to 50-pin adapter), the 8-bit
bus width parameter must be set first, using RAID
EzAssist.
Instructions on how to force the 8-bit bus width are in
the RAID EzAssist Configuration Utility User
Reference Guide (P/N 775029), under “Advanced
Parameters.”
2-8 AcceleRAID Installation Guide
Chapter 3
Installation
This chapter describes:
• Before you begin
• Connectors and Jumpers
• Safety considerations
• Installing the controller
Before You Begin
Installing an AcceleRAID PCI to Ultra2 SCSI RAID controller is no more
difficult than installing any PCI adapter card. Follow these steps and then
follow the installation procedures in this chapter.
, WARNING
Disconnect the system from the electrical wall
outlet before opening the system cabinet. Working
with the system covers off and power applied to the
system can result in shock and serious injury.
1. Power off the system and disconnect the power cables before starting
the installation. Refer to the instructions provided in your system
documentation. Do not disconnect cables or power cords while system
power is on.
2. Read all of the instructions in this chapter completely b efore pro c eeding. Follow the Notes, Cautions, and Warnings described in this manual
and marked on the equipment.
3. Safety check the installation before powering on the system.
• Make sure that all of the cabling Pin 1 locations are correct and that
all cables are firmly seated in the connectors.
• Make sure all SCSI conventions (cable type, cable length,
termination, SCSI IDs, etc.) are followed.
Manual No. 775007 3-1
Connectors and Jumpers
Connectors and Jumpers
m Caution
Anti-static handling procedures are required. Leave
the controller in its anti-static bag until it is time to
plug the controller into the PCI slot. The use of a
grounded wrist strap and other ESD protective
measures are highly recommended.
The AcceleRAID controller jumper locations are illustrated in Figure 3-1.
J1
J2
External
Connector
(VHDCI)
Internal Connector
(68-Pin High Density)
JP10
JP1
JP4
JP5
Note:
J1 and J2 are both on the same Channel.
Figure 3-1. AcceleRAID Jump ers and Connectors
Table 3-1. AcceleRAID Jumper Descriptions
Component Description Default
JP1 Header for front Panel SCSI Activity & Cache Dirty LEDs*
JP4 Mylex factory use only. –
JP5 Not Used Off
JP10 Enables SCSI Interrupt Steering Logic (SISL) control.
Removable on AcceleRAID 150 and 250 only.
J1 Channel 0 Internal Ultra2 SCSI LVD Connector –
68-Pin High Density (not present on AcceleRAID 200)
J2 Channel 0 External Ultra2 SCSI LVD Connector –
68-Pin Very High Density Cable Interconnect (VHDCI)
(not present on AcceleRAID 200)
* For the JP1 pinout, see Figure 3-7.
3-2 AcceleRAID Installation Guide
On
–
–
Installation
Installing the Controller
m Caution
Anti-static handling procedures are required. Leave
the controller in its anti-static bag until it is time to
plug the controller into the PCI slot. The use of a
grounded wrist strap and other ESD protective
measures are highly recommended.
, WARNING
Disconnect the system from the electrical wall
outlet before opening the system cabinet. Working
with the system covers off and power applied to the
system can result in shock and serious injury.
Standard Installation
In a standard installation, the AcceleRAID 250 functions as a singlechannel, standard PCI to Ultra2 SCSI, LVD RAID controller. In a standard
installation, the AcceleRAID 250 can be installed into any system board
with an available PCI (2.1 compliant) slot.
SCSI Interrupt Steering Logic (SISL) Installation
In a SISL installation, the AcceleRAID 200 adds RAID functionality to a
system board that has one or more embedded SCSI channels. The
AcceleRAID 250 adds an Ultra2 SCSI, L VD RAID channel as well as RAID
functionality to a system board that has one or more embedded SCSI
channels. For a SISL implementation, the AcceleRAID controllers must be
plugged into a special, pre-wired PCI slot in a system board that is specially
designed for this type of installation. Check with the ma nufacturer of your
system board to find out if it has embedded SCSI channels that can be
controlled by a PCI to SCSI RAID controller with SCSI Interrupt Steering
Logic (a requirement for the AcceleRAID 200).
Manual No. 775007 3-3
Loading...
