M55Hi-Plus PCI/ISA
System Board Manual
Document Number: 06-00273-01, Rev 3A
June 1996
221 Warren Ave., Fremont, CA 94539-7085
Copyright Notices
Copyright 1996 Micronics Computers, Inc. The information contained
2
in the M55Hi-Plus PCI/ISA system board manual has been carefully
checked and is believed to be accurate. Micronics assumes no responsibility for any inaccuracies that may be contained in this document. Micronics
makes no commitments to update or to keep the information in this
manual at a current level when changes are made to the product.
Micronics reserves the right to make improvements to this document
and/or product at any time and without notice. All Rights Reserved. No
part of this document may be photocopied, reproduced, translated, or
reduced to any medium or machine form without prior, written consent
from Micronics.
Portions of the Manual
Portions of this manual were copied (with permission) from Phoenix
Technologies, Ltd. and Micro Computer Systems, Inc. All rights reserved.
Trademarks
IBM is a registered trademark of International Business Machines. Microsoft and Windows are registered trademarks of Microsoft Corporation.
Intel and PCI are registered trademarks of Intel Corporation. All other
product names mentioned herein are used for identification purposes only
and may be the trademarks of their respective companies.
M55Hi-Plus System Board Manual
Table of Contents
Introduction 5
Features 6
Software Compatibility 7
Before You Begin 8
Section 1 - Quick Installation 9
Installing the M55Hi-Plus 9
Section 2 - Configuring the M55Hi-Plus 11
Static Electricity 11
Office Environment 11
M55Hi-Plus System Board 12
M55Hi-Plus Back Panel Connections 13
Jumper Settings 13
Section 3 - Installing the M55Hi-Plus 17
Introduction 17
System Memory Support 17
Installing the M55Hi-Plus 18
Tools Required 18
Equipment Required 18
System Memory 19
SIMMs Supported 19
Upgrading Rules 19
Mixing EDO and FPM Memory 20
Memory Configurations 21
Installing the SIMMs 22
Removing SIMMs 22
Installing a CPU 23
Installing a PCI Peripheral Card 24
M55Hi-Plus System Board Manual
1
Installing an ISA Peripheral Card 25
Installing a CD-ROM Drive 26
The M55Hi-Plus Sound Option 27
Connecting Sound Devices 27
Connecting the Telephony Option 28
Section 4 - The BIOS Setup Utility 29
Configuration 29
Initial Bootup 29
Setup 29
Running the Setup Procedure 31
Setting the Main Screen 31
Setting the Advanced Screen 36
Security Screen 39
Power Screen 42
Boot Screen 45
Exit Screen 46
Section 5 - Installing Sound Device Drivers 47
About Device Drivers 47
Installing the Sound Drivers 48
Appendix A - Technical Information 49
Specifications 49
Environmental Specifications 50
Temperature Range 50
Relative Humidity 50
Battery Disposal 51
Technical Support 52
Online Services 53
2
M55Hi-Plus System Board Manual
Appendix B - Post Messages 55
Appendix C - Beep and POST Codes 59
Appendix D - Hard Disk Drive Types 63
Appendix E - Updating the System BIOS 65
Limited Warranty 67
Non-Warranty Service 68
FCC Statement 69
Declaration of Conformity 70
Glossary 71
Index 75
M55Hi-Plus System Board Manual
3
List of Figures
Figure 1.1: Power-Up Screen 10
Figure 2.1: M55Hi-Plus System Board 12
Figure 2.2: M55Hi-Plus Back Panel Connections 12
Figure 3.1: Installing a 72-Pin SIMM 22
Figure 3.2: Installing a PCI Card 24
Figure 3.3: Installing an ISA Peripheral Card 25
Figure 3.4: Connecting External Sound Devices 27
Figure 4.1: Power-Up Screen 30
Figure 4.2: CMOS Main Screen 31
Figure 4.3: IDE Device Submenu 34
Figure 4.4: Advanced Screen 36
Figure 4.5: Security Setup Screen 39
Figure 4.6: Supervisor Password Submenu 40
Figure 4.7: Power Screen 42
Figure 4.8: Boot Screen 45
Figure 4.9: Exit Screen 46
List of Tables
Table 2.1: CPU Speed Selection 13
Table 2.2: AT Bus Clock Selection 13
Table 2.3: System Power Down Selection 14
Table 2.4: Clear CMOS Selection 14
Table 2.5: Cache DRAM Range Selection 14
Table 2.6: CPU Voltage Selection 15
Table 2.7: Recover Flash BIOS Selection 15
Table 2.8: Case and Peripheral Connections 15
Table 3.1: Memory Configurations 21
4
M55Hi-Plus System Board Manual
Introduction
Thank you for choosing the M55Hi-Plus system board.
The high-performance M55Hi-Plus provides the latest
enhancements in system board technology for the world’s
most advanced workstation applications.
Based on the Intel 430HX (Triton II) chipset, the M55HiPlus provides enhanced PCI throughput and performance as well as support of Universal Serial Bus (USB).
The USB interface has a maximum bandwidth of 12Mbps
and can connect as many as 127 devices to a host system.
USB supports both standard devices that operate at the
full 12-Mbps rate and low-end devices that use only a 1.5Mbps subchannel.
The M55Hi-Plus is designed to fit into the most modern
ATX form factor. The ATX form factor allows critical
components such as floppy and IDE connectors, chassis
fan, CPU and memory to be strategically located so that
full length cards can be used in all slots. The M55Hi-Plus
combined with the Intel 430HX chipset makes this
system board the ultimate desktop workstation solution.
The M55Hi-Plus comes with many features. These include support for Extended Data Out (EDO) and Fast
Page Mode (FPM) DRAM memory, Error Checking
Correction (ECC), the Phoenix Plug and Play BIOS and
an optional feature for integrated 16-bit sound.
For energy efficiency, full support is provided for the
Green PC specification. Micronics builds all products to
exacting standards, using the highest quality components available. We are proud to provide this system
board and believe you will be pleased with your purchase.
M55Hi-Plus System Board Manual
5
Features
The M55Hi-Plus includes the following features:
Single ZIF socket 7 for Intel Pentium processor support
for 90, 100, 120, 133, 150, 166 and 200MHz processors
Intel 430HX chipset
Intel PIIX 3
SMC FDC37C93X
Voltage Regulated Extension (VRE) and Voltage Regu-
lated (VR) support
Three 32-bit PCI slots, three 16-bit ISA slots and one
shared PCI or ISA slot
Up to 512K pipelined burst external Level 2 cache
Support for up to 256MB of onboard system memory
Supports FPM and EDO memory
ECC support via chipset
Primary and Secondary 40-pin IDE connectors
Mode 4 enhanced IDE (supports up to four IDE de-
vices)
Floppy controller for two floppy drives (supports 2.88MB,
1.44MB, 1.2MB, 720K or 360K floppy drives)
Two high speed NS16550 compatible serial ports
Bi-directional parallel port (ECP and EPP compatible)
Two Universal Serial Bus (USB) ports for desktop
peripheral expansion
Field upgradeable Flash Phoenix BIOS
Creative Labs VIBRA 16C Sound (optional)
Telephony header for desktop video conferencing (op-
tional)
M55Hi-Plus System Board Manual6
Software Compatibility
The M55Hi-Plus system board has been thoroughly tested
for compatibility with a variety of operating systems and
environments, including:
Windows 95 and Windows NT
OS/2 Warp
SCO UNIX and Open Desktop
Novell Netware
MS-DOS 5.0 and 6.2
PC-DOS
M55Hi-Plus System Board Manual
7
Before You Begin
This manual will familiarize you with the features, installation and use of your M55Hi-Plus. There are several symbols
and conventions used throughout this manual to help draw
your attention to a feature or to focus on important information:
When you see the Magnifying Glass, it refers
to something you should take a closer look at
before proceeding further.
When you see the Exclamation Mark, it gives
important information on avoiding damage.
Common Names
DRAM Dynamic Random Access Memory
ECC Error Checking and Correction
ECP Extended Capabilities Port
EDO Extended Data Out
EPP Enhanced Parallel Port
FPM Fast Page Mode
IDE Integrated Drive Electronics
PCI Peripheral Component Interconnect
SIMM Single Inline Memory Module
USB Universal Serial Bus
VR Voltage Regulated
VRE Voltage Regulated Extension
8
M55Hi-Plus System Board Manual
Section
1
STATIC!
Before
handling the
M55Hi-Plus,
be properly
grounded by
using a
special wrist
or ankle
strap, or
touch a
safely
grounded
object.
Section 1: Quick Installation
Quick Installation
We know that many experienced people prefer to read as
little of the documentation as possible. If this sounds like
you, here’s the short form to get up and running quickly.
Installing the M55Hi-Plus
1. Make backup copies of your installation and configuration diskettes.
2. Ground yourself to prevent damaging static discharge, then remove the M55Hi-Plus from its packaging.
3. Configure and verify the system board’s jumper settings (refer to Jumper Settings in Section 2).
4. Install the CPU and the system memory (refer to
Section 3).
5. Install the system board into the chassis and make all
necessary case connections.
6. Install any ISA and PCI add-on peripherals (refer to
Section 3).
7. Now you can connect any optional devices (refer to
Section 3).
8. Turn the computer on and press the <F2> key
when you see the screen in Figure 1.1.
M55Hi-Plus System Board Manual
9
Section 1: Quick Installation
Figure 1.1: Power-Up Screen
9. Set the time and date. Adjust the BIOS settings to
match your configuration. If installing an IDE drive,
select the IDE device you wish to configure. Press
ENTER with Autotype Fixed Disk selected and the
BIOS will automatically configure the drive for you
(refer to Section 4).
10. After you have configured the Main Setup menu,
make any desired setting configurations in the Advanced and Security menu. When finished, go to the
exit screen, select “Save Changes and Exit” and you
are finished with the BIOS configuration (see Section 4).
11. Install your IDE CD-ROM drive and its device
drivers (refer to Section 3).
12. Install the sound controller device drivers (optional).
Refer to Section 5.
10
M55Hi-Plus System Board Manual
Section 2: Configuring the M55Hi-Plus
Section
2
Configuring the M55Hi-Plus
Although the M55Hi-Plus system board is packaged in
protective materials, it is important to use care while
unpacking and setting up.
Static Electricity
The M55Hi-Plus is shipped from the factory in an
antistatic bag. To reduce the possibility of damage, it is
important to neutralize any accumulated static charges
on your body before handling the board. The best way to
do this is to ground yourself using a special wrist or ankle
strap. If you do not have a strap, you should touch both
of your hands to a safely grounded object. After you have
grounded yourself, ground the M55Hi-Plus via the solder pads surrounding one of its mounting holes.
Once the M55Hi-Plus is removed from its packaging,
place it on top of the antistatic bag. Carefully inspect the
board for damage which may have occurred during
shipment.
Office Environment
Make sure the finished computer system is in an area
with good ventilation. The system should not be in direct
sunlight, near heaters, or exposed to moisture, dust or
dirt.
M55Hi-Plus System Board Manual
11
Section 2: Configuring the M55Hi-Plus
M55Hi-Plus System Board
12
Figure 2.1: M55Hi-Plus System Board
M55Hi-Plus System Board Manual
Section 2: Configuring the M55Hi-Plus
M55Hi-Plus Back Panel Connections
Figure 2.2: M55Hi-Plus Back Panel Connections
Jumper Settings
This section gives you the jumper settings used for the M55Hi-Plus
system board.
Table 2-1: Jumper settings to select the speed of the CPU.
CPU Speed 90MHz 100MHz 120MHz 133MHz 150MHz 166MHz 200MHz
Jumper
W1 Close Open Close Open Close Open Open
W2 Open Close Open Close Open Close Close
W4 Close Open Close Open Close Open Open
W5 Open Open Open Open Close Close Close
W6 Open Open Close Close Close Close Open
Table 2-1: CPU Speed Selection
Table 2-2: Jumper settings for the AT Bus clock selection.
Jumper Function Settings
W13 1/4 (default)
1/3
Table 2-2: AT Bus Clock Selection
Close
Open
M55Hi-Plus System Board Manual
13
Section 2: Configuring the M55Hi-Plus
Table 2-3: Jumper settings for the system soft power down.
Jumper Function Settings
W14 Enable (default)
Disable
Table 2-3: System Power Down Selection
Open
Close
Table 2-4: Jumper settings to clear the BIOS CMOS
settings. With your computer's power off, close pins 2-3,
then turn the power on for about five seconds. Turn the
power off and place the jumper back on pins 1-2. (The
jumper must be placed back on pins 1-2 for the system to
function properly.)
NOTE: This will reset all BIOS default settings. Any changes
you have made will be lost.
Jumper Function Settings
W10 Normal (default)
Clear CMOS
1-2
2-3
Table 2-4: Clear CMOS Selection
Table 2-5: Jumper settings to configure the cacheable
DRAM range (optional).
Jumper Function Settings
14
W12 Normal (default)
Extended
Table 2-5: Cache DRAM Range Selection
M55Hi-Plus System Board Manual
Open
Close
Section 2: Configuring the M55Hi-Plus
Connector Function Notes
J1 MIC-In Connector
J2 Line-In Connector
J3 Line-Out Connector
J4 Speaker-Out Connector
J5 Game Port
J6 USB Connector
J8 Keyboard/Mouse
Connector
PS/2
J13 CD-In
J14 Wavetable
J15 Modem Optional Telephony Header
Table 2-6: Jumper settings to select the CPU voltage
regulator mode.
Jumper Function Settings
W7 VRE (default)VROpen
Close
Table 2-6: CPU V oltage Selection
Table 2-7: Jumper settings to recover the flash BIOS from
the boot block.
Jumper Function Settings
W8 Normal (default)
Reserved
T a ble 2-7:Recover Flash BIOS Selection
1-2
2-3
Table 2-8: Case and peripheral connections.
M55Hi-Plus System Board Manual
Table 2-8: Case & Peripher al Connections
15
Section 2: Configuring the M55Hi-Plus
Connector Function Notes
J16 External Audio (Enabled) Left - Close 7-8
Right - Close 9-10
J17 Parallel Port Connector Can be disabled at the CMOS
configuration screen
J18 Serial Port (COM 2) Can be disabled at the CMOS
configuration screen
J19 Serial Port (COM1) Can be disabled at the CMOS
configuration screen
J25 Secondary IDE
J26 Power Connector ATX standard
J27 Primary IDE
J28 Floppy Connector
U50 Infrared Connector 6 - Transmit Data; 7 - Ground;
8- Receive Data; 9 - Ground;
10 - +5V DC
" System Power On/Off 1 - Power; 2 - Ground
" Turbo LED 25 - Turbo; 26 - Ground
" Reset 12 - Reset; 13 - Ground
" Hard Disk LED 23 - Positive; 24 - Negative
" Keylock 21 - Keylock; 22 - Ground
" Power LED 18 - Power; 20 - Ground
" Speaker 14 - Speaker; 17 - +5V DC
W3 Case Fan
W9 CPU Fan
Table 2-8B: Case & Per ipheral Connections
16
M55Hi-Plus System Board Manual
Section 3: Installing the M55Hi-Plus
Section
3
Installing the M55Hi-Plus
Introduction
This section explains how to install the M55Hi-Plus
system board, memory, CPU and peripherals.
WARNING: Before installing or removing any peripherals
or components, make sure you have a clear work space and
that you adhere to all anti-static precautions described in
Section 1. Micronics recommends only trained technicians
install and configure the system board.
Damage which occurs to the board while adding or removing
peripherals or components may void the warranty. If problems arise while installing peripherals, contact the computer
dealer where you purchased the peripheral or Micronics’
Technical Support Department.
System Memory Support
The flexibility of the M55Hi-Plus is augmented by its
support for Error Checking and Correction (ECC),
Extended Data Out (EDO) DRAM memory and Fast
Page Mode (FPM) DRAM memory. The M55Hi-Plus
allows vast memory capability without worrying about
memory errors. It does this by providing ECC which
enables parity checking to detect and correct memory
errors.
EDO memory is designed to keep data available to the
processor for an extended period of time. The EDO
memory support extends the performance of conventional DRAM memory. The result is an improvement in
memory-access performance on the M55Hi-Plus system
board.
M55Hi-Plus System Board Manual
17
Section 3: Installing the M55Hi-Plus
Installing the M55Hi-Plus
Installation of the M55Hi-Plus system board depends on
the type of case you use. The M55Hi-Plus is designed for
the ATX form factor and must be installed in an ATX
chassis. NOTE: If you are unfamiliar with installing a
system board, Micronics highly recommends that you
read the computer user’s manual or contact your dealer’s
technical support department.
Tools Required
Micronics recommends using the following tools to install the M55Hi-Plus:
Small Phillips screwdriver
Tweezers or a pair of needle-nose pliers
Tray (to hold loose screws)
Equipment Required
Micronics recommends using the following equipment
with the M55Hi-Plus for a typical configuration:
ATX chassis with standard hardware.
A high-quality ATX power supply capable of provid-
ing continuous power within a 3 volt range. A power
filter may be used with a noisy AC power source.
PS/2 mouse and compatible keyboard.
Eight ohm speaker.
Standard ribbon cables for internal connections.
Standard power cord (grounded).
Heat sink with cooling fan for CPU (required).
18
M55Hi-Plus System Board Manual
For long
term
reliability,
Micronics
recommends
using SIMMs
with tinplated
contacts.
The use of
gold-plated
contacts
may conflict
with the tinalloy on the
SIMM
socket.
Section 3: Installing the M55Hi-Plus
System Memory
System memory devices, commonly known as SIMMs,
are necessary to operate the M55Hi-Plus system board.
The M55Hi-Plus has four 32/36-bit SIMM sockets and
can be upgraded to 256 Megabytes of RAM. In addition,
support is provided for Error Checking (ECC), Extended
Data Out (EDO) DRAM memory and Fast Page Mode
(FPM) DRAM memory.
This section will explain the type of SIMMs supported,
list the rules for adding memory to the M55Hi-Plus, give
some examples of common memory configurations and
show how to physically install the new SIMMs.
SIMMs Supported
The M55Hi-Plus supports the following types of 60 or
70ns SIMMs:
4MB (1MBx32/36)
8MB (2MBx32/36)
16MB (4MBx32/36)
32MB (8MBx32/36)
64MB (16MBx32/36)
Upgrading Rules
The following is a list of rules to follow when upgrading
SIMMs. If you follow these rules, your upgrade should be
trouble-free:
Use 70ns or faster SIMMs.
Upgrade SIMMs one bank at a time. Each bank must
contain two SIMMs of the same size and preferably
from the same manufacturer. For example, to add
16MB of memory to the system board, install two
8MB SIMMs into the same bank.
When installing SIMMs, fill bank 0, then bank 1.
M55Hi-Plus System Board Manual
19
Section 3: Installing the M55Hi-Plus
Mixing EDO and FPM Memory
The M55Hi-Plus can handle a combination of EDO and
FPM memory. The memory will default to the speed of
the slowest RAM installed.
Follow the rules below:
Install the two types of memory in separate banks.
(For example, install EDO memory in Bank 0 and
FPM memory in Bank 1.)
When installing SIMMs, fill Bank 0, then Bank 1.
NOTE: Mixing EDO and FPM memory is not recommended.
20
M55Hi-Plus System Board Manual
Section 3: Installing the M55Hi-Plus
Memory Configurations
There is no
need to set
any jumpers.
When you
reboot, the
size and
type of
memory are
automatically
detected.
The table below lists the most common memory configurations. The memory available depends on the number of
SIMMs installed.
Memory Bank 0 Bank 1
8MB (2) 1MBx32/36
16MB (2) 1MBx32/36 (2) 1MBx32/36
16MB (2) 2MBx32/36
24MB (2) 2MBx32/36 (2) 1MBx32/36
32MB (2) 4MBx32/36
32MB (2) 2MBx32/36 (2) 2MBx32/36
40MB (2) 4MBx32/36 (2) 1MBx32/36
48MB (2) 4MBx32/36 (2) 2MBx32/36
64MB (2) 8MBx32/36
64MB (2) 4MBx32/36 (2) 4MBx32/36
72MB (2) 8MBx32/36 (2) 1MBx32/36
80MB (2) 8MBx32/36 (2) 2MBx32/36
96MB (2) 8MBx32/36 (2) 4MBx32/36
128MB (2) 8MBx32/36 (2) 8MBx32/36
128MB (2) 16MBx32/36
256MB (2) 16MBx32/36 (2) 16MBx32/36
T able 3-1: Memory Configurations
M55Hi-Plus System Board Manual
21
Section 3: Installing the M55Hi-Plus
Installing the SIMMs
To install the SIMMs, locate the memory banks on the
system board and perform the following steps:
1. Hold the SIMM so that the notched edge is aligned
with the notch on the SIMM socket (Figure 3-1).
2. Insert the SIMM at a 45 degree angle.
3. Gently push the SIMM into an upright position until
it locks into place (past the release tabs).
Figure 3-1: Installing a 72-Pin SIMM
Removing SIMMs
To remove SIMMs, follow the steps below:
1. With both thumbs (or fingers), press the release tabs
away from the socket.
2. With the SIMM free from the release tabs, lift the
module up and place in an anti-static bag or package.
22
M55Hi-Plus System Board Manual
Section 3: Installing the M55Hi-Plus
Installing a CPU
The M55Hi-Plus is designed to support a variety of
Pentium processors. Follow the steps below to install a
processor:
1. Turn off the computer and remove its cover.
2. Locate the ZIF socket illustrated in Figure 2-1.
3. Lift the lever of the socket.
4. Locate pin 1 on the processor and pin 1 on the socket
(refer to Figure 2-1). Gently place the processor into
the socket, making sure pin 1 on the processor and
pin 1 on the socket are aligned.
5. Push the lever down until it locks into place.
6. Make sure the speed selection jumpers are set correctly (refer to Section 2 - Jumper Settings).
WARNING: Pentium processors require a heat-sink with a
cooling fan. Failure to provide adequate cooling of the processor may seriously affect system performance or cause permanent damage to the processor.
M55Hi-Plus System Board Manual
23
Section 3: Installing the M55Hi-Plus
Installing a PCI Peripheral Card
Micronics PCI slots accommodate all PCI peripherals
that meet the PCI 2.1 specifications. Follow the steps
below to install a PCI card:
1. Turn the computer system off and remove its cover.
2. Choose an unused PCI slot and remove the slot
cover.
3. Insert the card with the bottom edge level to the slot.
Never insert the card at an angle.
4. Carefully push the card straight down, making sure
the card is fully inserted.
5. Replace the screw which holds the card into place.
6. Replace the computer cover.
7. Refer to the PCI card’s documentation additional
instructions regarding installation and software drivers.
24
Figure 3-2: Installing a PCI Card
M55Hi-Plus System Board Manual
Section 3: Installing the M55Hi-Plus
Installing an ISA Peripheral Card
Micronics ISA slots accommodate all standard ISA peripherals. Follow the steps below to install a PCI card:
1. Turn the computer system off and remove its cover.
2. Choose an unused ISA slot and remove the slot
cover.
3. Insert the card with the bottom edge level to the slot.
Never insert the card at an angle.
4. Carefully push the card straight down, making sure
the card is inserted fully.
5. Replace the screw that holds the card into place.
6. Replace the computer cover.
7. Refer to the ISA card’s documentation for additional instructions regarding installation and software drivers.
Figure 3-3: Installing an ISA Peripheral Card
M55Hi-Plus System Board Manual
25
Section 3: Installing the M55Hi-Plus
Installing a CD-ROM Drive
If you are installing a CD-ROM drive, Micronics recommends the installation of an IDE CD-ROM drive. The
instructions below will help you with the installation, but also
refer to the documentation that accompanied your CD-ROM
drive.
Before starting the setup and installation, make sure your
computer is off and the power cord is disconnected from
the wall outlet. Your CD-ROM drive kit should contain
the following items for a successful installation:
❏ CD-ROM Drive with installation hardware
❏ Interface Cable
❏ CD Audio Cable
1. Connect the ribbon cable as described in the CDROM’s documentation, making sure the red stripe on
the cable is aligned with pin 1 of the connectors.
2. Connect the audio cable to the CD-ROM drive's
audio connector.
3. Connect the other end of the audio cable to the
MPC-2 compatible CD-ROM audio connector on
the M55Hi-Plus system board (see Figure 2.1).
4. Connect the power supply cable to the CD-ROM
drive's power connector.
Try to avoid
excessive
twists or
bends in the
cables that
might
damage
them or
interfere with
other
peripherals
in your
computer.
5. Install the CD-ROM device drivers. CD-ROM drives
require device drivers to access the drive and are
generally provided by the manufacturer of the CDROM drive. Usually one device driver is added to the
CONFIG.SYS file and one to the AUTOEXEC.BAT
file.
6. If you are using the CD-ROM drive in an MS-DOS
environment, the utility MSCDEX.EXE must also be
added to the AUTOEXEC.BAT file. Consult your
DOS manual for more information.
M55Hi-Plus System Board Manual26
Section 3: Installing the M55Hi-Plus
The M55HI-Plus Sound Option
You can connect external sound devices to your M55HiPlus system board to take advantage of the optional
sound support (refer to Figure 2.2). The sound option
includes 16-bit stereo sound, a game and MIDI port, a
telephony header and additional front speaker and microphone headers. See Section 5 for information on
installing sound device drivers.
Connecting Sound Devices
Figure 3-4: Connecting External Sound Devices
M55Hi-Plus System Board Manual
27
Section 3: Installing the M55Hi-Plus
Game Port
You can use the Game Port connector to connect an IBM
PC compatible joystick or MIDI instrument.
Speaker Out
You may connect 4 or 8 ohm external speakers or headphones to the audio controller. Additional front speaker
and microphone headers are also available.
Line Out
The Line Out jack allows you to connect the audio output
of the audio controller to your home stereo, VCR, or
amplified speakers.
Line In
You may connect an external mono or stereo audio source
to the audio controller, such as a tape player or radio. Use
the appropriate converter cable to interface to your
external equipment.
MIC IN
The MIC IN jack will accommodate a 300-600 ohm
microphone.
Connecting the Telephony Option
The M55Hi-Plus system board can be upgraded to include a header for computer telephony (pronounced teh
- leh' - fuh - nee) support. Telephony allows you to
increase your communications productivity. You can
integrate facsimile technology, sound and desktop video
conferencing. The telephony option is enabled by connecting your modem cable to header J15.
28
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
Section
4
The BIOS Setup Utility
Configuration
After the M55Hi-Plus system board and all hardware is
installed, the system is ready for configuration. Before
turning on the computer, make sure all cables are correctly connected and all jumpers are correctly set.
It is recommended you keep the computer cover off the
first time you boot the system. This will make it easier to
correct any difficulties that might arise.
Initial Boot Up
Power up the M55Hi-Plus. If the system does not properly boot, check all your cables and peripherals for bad
connections. You may also get beep codes or error
messages. If this occurs, consult Appendices B and/or C
for a guide to possible solutions.
After the system properly boots, it is ready to be configured. The following information explains the proper
procedures for BIOS configuration.
Setup
The Setup program is used to configure the computer’s
BIOS (Basic Input/Output System). The computer’s
BIOS is responsible for configuring the system board and
providing hardware information to the operating system.
In order for the computer to run properly, run the Setup
procedure after first installing the system board and
whenever you make a hardware change to the system.
M55Hi-Plus System Board Manual
29
Section 4: The BIOS Setup Utility
After the system is turned on and goes through a memory
test, the Power-Up screen (Figure 4-1) will appear on
your monitor:
Figure 4-1: Power-Up Screen
When “Press <F2> to enter SETUP” appears at the
bottom of the screen, press the <F2> key to begin the
Setup procedure. The CMOS Main Screen (Figure 4-2)
should appear and the prompt should be on the time
line. The Setup procedure can only be activated during
the boot sequence.
30
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
Running the Setup Procedure
The M55Hi-Plus system board has four primary CMOS
configuration screens: the Main Screen, the Advanced
Screen, the Security Screen and the Exit Screen. To
toggle between the screens, press the right arrow <→>
and the left arrow < ←> keys.
Setting the Main Screen
The CMOS Main screen (Figure 4-2) is used to set the
time and date, to set the floppy drive types, to configure
the hard disks and to configure the video. This section
explains how to configure each of these categories. To
move between the categories, use the up and down arrow
<↑/↓> keys.
Figure 4-2: CMOS Main Screen
M55Hi-Plus System Board Manual
31
Section 4: The BIOS Setup Utility
System Time and Date
To set the time, use the <-> key to decrease the number
and the <+> key to increase the number. To move the
prompt forward, use the <Tab> key; to move the
prompt backward, use the <Shift-Tab> key. To set the
date, use the up and down arrows<↑/↓> to highlight the
System Date and follow the same procedure used to set
the time.
Diskette A or B
To configure a floppy drive added to or removed from
your computer, use the up and down arrow keys <↑/↓>
to select the desired drive. Use the <+/-> keys to
change the setting until it matches the floppy drive you
installed. The BIOS supports 2.88MB, 1.44MB, 1.2MB,
720KB, and 360KB floppy drives.
IDE Adapters (Hard Disk Setup)
If you are setting up a SCSI hard disk, select None in the
IDE Device parameters (see your SCSI card manual for
more details). To install an IDE device, select the device
to configure and press ENTER. An IDE Device submenu
will appear (see Figure 4-3).
Video System
This sets the type of video board installed into the system.
You may choose EGA/VGA (default), CGA 80x25 or
MONO.
Video BIOS
The Video BIOS category allows you to Shadow or
Shadow & Cache the video BIOS. Choosing Shadowed
copies the video BIOS into RAM for faster execution.
32
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
Choosing Shadowed & Cached caches the shadowed
video BIOS for even higher performance. To disable the
Video BIOS category, select Disabled.
System BIOS
This option allows you to cache the system BIOS. The
system BIOS will always be shadowed.
External Cache
This selection allows you to enable the external memory
cache. For optimal performance, select Enabled.
System Memory
The System Memory category identifies the size of the
base memory. It cannot be changed.
Extended Memory
The Extended Memory category automatically detects
the amount of memory installed above the amount in the
System Memory category. Because the BIOS automatically calculates the amount of memory installed in your
system, you cannot change this category without adding
or removing memory.
M55Hi-Plus System Board Manual
33
Section 4: The BIOS Setup Utility
Figure 4-3: IDE Device Submenu
Autotype Fixed Disk
The easiest way to set your IDE devices is to let the BIOS
do it for you. When the IDE Device submenu first
appears, the Autotype Fixed Disk selection is highlighted. Simply press ENTER and the remaining information is entered automatically. Do not adjust the rest
of the settings unless absolutely necessary. The BIOS
automatically enters the optimal settings.
Type
This category selects the drive type installed in the
system. The options are None, 1-39, Auto (default) and
User.
If Autotype Fixed Disk does not find your drive’s parameters, fill this information in manually under the User
category. This information may be in the manual that
came with your system. If not, contact your dealer or the
34
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
hard drive manufacturer to fill in this category. If you are
using a SCSI hard drive, select None and refer to the
documentation which came with the SCSI adapter.
Multiple-Sector Transfers
This category determines the number of sectors per block
for multiple sector transfers. The options are Disabled
(default), 2 Sectors, 4 Sectors, 8 Sectors and 16 Sectors.
LBA Mode Control
Enable LBA (Logical Block Addressing) to support IDE
drives larger than 528MB in size. The default setting is
Disabled.
32-Bit I/O
This category allows you to enable the 32-bit I/O function
of the PCI IDE controller. Select Disabled if your drive
will not run at this speed. The default setting is Disabled.
This option is not available on ISA IDE Adapter 1.
Transfer Mode
This category provides the transfer modes for the PCI
IDE controller. The options are Fast PIO 4, Fast PIO 3,
Fast PIO 2, Fast PIO 1 and Standard (default).
Fast PIO 4 is equivalent to Mode 4 supporting a minimum
cycle time of 120ns (15.5 MB/sec.). Fast PIO 3 is equivalent to Mode 3 supporting a minimum cycle time of 180ns
(11.1 MB/sec.). Fast PIO 2 supports a minimum cycle
time of 240ns (8.33 MB/sec.). Fast PIO 1 supports a
minimum cycle time of 383ns (5.22 MB/sec.). Standard
supports a minimum cycle time of 600ns (3.3 MB/sec.).
See your drive specifications before setting this category.
This option is not available on ISA IDE Adapter 1.
M55Hi-Plus System Board Manual
35
Section 4: The BIOS Setup Utility
Setting the Advanced Screen
To move to the Advanced screen, use the left and right
arrow keys <←/→> keys until you see the screen below.
Figure 4-4: Advanced Screen
Serial Port A
Serial Port A may be set for Auto (default), COM1,
COM2, COM3, COM4 or Disabled.
Serial Port B
Serial Port B may be set for Auto (default), COM1,
COM2, COM3, COM4 or Disabled.
Serial Port B Mode
Serial Port B Mode may be set for COM Port (default),
IrDA or ASK-IR. This selection sets the interface to
standard or infrared.
36
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
Parallel Port
The parallel port may be set for Auto (default), LPT1,
LPT2 or may be disabled.
Parallel Port Mode
The parallel port may be set for output mode (AT)
(default), bidirectional mode (PS/2), Extended Capabilities Port (ECP) or Disabled.
Diskette Controller
The floppy disk controller may be enabled or disabled.
Integrated PCI IDE
Enables the integrated Local Bus IDE adapter. The PCI
IDE controller may be set for Primary (up to two hard
disks), Both (up to four hard disks) or it may be disabled.
The default setting is Both.
DRAM Type
This selection can be set for Non-Parity (default), Parity
or ECC. Selecting ECC will detect the parity error and
allow you to correct the error.
Integrated Sound
This selection enables or disables the onboard sound
controller.
IRQ12
This selection routes IRQ12 to the PS/2 Mouse (default)
or the ISA bus.
M55Hi-Plus System Board Manual
37
Section 4: The BIOS Setup Utility
Plug & Play O/S
This selection, when set to YES, allows the system to
work with a Plug and Play operating system such as
Windows 95. The default setting is NO.
Reset Configuration Data
Select Yes to clear the system configuration data. The
default setting is No.
Large Disk Access Mode
If you are using a DOS operating system (MS-DOS, DRDOS, or PC-DOS), set to DOS (default). If you are using
anything else, set to OTHER.
38
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
Security Screen
The Security screen (Figure 4-5) controls access to the
computer. The security screen allows for settings of two
passwords. The Supervisor Password allows access to the
system and Setup. The User Password allows access to the
system, but not to all Setup features.
Figure 4-5: Security Setup Screen
Supervisor Password
If a Supervisor Password is set up for the system, it reads
Enabled. If the password is not set up, it reads Disabled
(default).
User Password
If a User Password is set up for the system, it reads
Enabled. If the password is not set up, it reads Disabled
(default).
M55Hi-Plus System Board Manual
39
Section 4: The BIOS Setup Utility
Set Supervisor Password
Press the ENTER key to enter the Supervisor Password submenu.
Figure 4-6: Supervisor Password Submenu
Type the password and press the ENTER key. Retype
the password and press the ENTER key again. Write
down the password somewhere safe so it will not be
forgotten. The password may be disabled by setting the
new password to nothing (pressing the ENTER key
without first typing a password).
WARNING: If you forget the Supervisor Password, it
cannot be disabled without discharging the CMOS.
Set User Password
Follow the same procedure used to set the Supervisor
Password. NOTE: After a password is entered, it is saved
immediately. All other changes may still be discarded (see
Exit Screen).
40
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
Password on Boot
When enabled, the system requires a password upon
power-up. Either the Supervisor or User Password may
be entered.
Diskette Access
This selection allows floppy disk access with an option of
the supervisor or user. Selecting Supervisor gives floppy
disk access to the supervisor only. Selecting User (default) gives floppy disk access to both the user and the
supervisor. If the passwords are enabled, this option may
only be changed by the supervisor.
Fixed Disk Boot Sector
This selection allows the boot sector of the fixed disk to
be write protected. The default setting is Normal. When
set for Write Protect, it serves as a form of virus protection. If the passwords are enabled, this option may only
be changed by the supervisor.
M55Hi-Plus System Board Manual
41
Section 4: The BIOS Setup Utility
Power Screen
The Power screen controls the power management functions of the system. To move to the Power Screen, use the
left and right arrow <←/→> keys until it appears
(Figure 4-7). To move between the categories, use the up
and down arrow keys <↑/↓>.
Figure 4-7: Power Screen
Fan Failure Detection
This selection enables the CPU Fan Failure detection,
which helps prevent damage to the system. When enabled, a message is displayed in Windows to indicate fan
failure. The default setting is Disabled.
NOTE: You must have a fan with a power connector that
connects to the system board.
42
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
APM
When enabled the power management features are active. The default setting is Disabled. If you enable this
selection, you must also set the other power management
options.
Power Management Mode
This selection may be set for Maximum power savings,
Medium power savings, Minimum power savings, Customized or Disabled (default). If you set this selection for
Maximum, Medium or Minimum power savings, you do
not need to make any more adjustments. If you select
Customized, you must set the following five categories.
Standby Timeout
The Standby Timeout category sets the amount of time
that elapses for the system to enter the power saving
mode. The options are Disabled (default), 2 min., 15
min., 30 min., 60 min., 2 hr., 3 hr. or 4 hr. Before making
changes, "Customized" must be selected in the Power
Management Mode category.
Suspend Timeout
The Suspend Timeout category sets the amount of time
that elapses for the system to enter the Suspend Mode.
The timer starts when the Standby Mode is activated.
The options are Disabled (default), 2 min., 15 min., 30
min., 60 min., 2 hr., 3 hr., and 4 hr. Before making
changes, "Customized" must be selected in the Power
Management Mode category.
Standby CPU Speed
This category sets the CPU speed during power saving
mode. The options are Maximum (default), Medium,
M55Hi-Plus System Board Manual
43
Section 4: The BIOS Setup Utility
Minimum and Slowest. Before making changes, "Customized" must be selected in the Power Management
Mode category.
Fixed Disk Timeout
This category sets the amount of time that elapses
before the IDE drive enters spin-down mode to conserve power. The options are Disabled (default), 1 min.,
2 min., 5 min., 10 min., or 15 min. Before making
changes, "Customized" must be selected in the Power
Management Mode category. NOTE: Do not enable this
category unless your IDE drive supports spin-down mode.
CRT
Selecting OFF in Standby (default) powers down the
display while the system is in power saving mode. Before
making changes, “Customized” must be selected in the
Power Management Mode category.
Mouse Wakeup Event
This selection causes the system to "wakeup" from a
power savings mode if the mouse is moved or a button
is pressed. The selections are PS/2 (IRQ12), COM1
(IRQ4), COM2 (IRQ3) or Disabled. The default setting is PS/2.
Standby Break Events
Setting an IRQ category to Enabled causes the system to
“wakeup” from a power savings mode if any activity
occurs at that IRQ. For example, if you have a modem
on IRQ3 and you set IRQ3 to enabled, the system
automatically wakes up every time the modem gets a
phone call. The default setting is Disabled.
44
M55Hi-Plus System Board Manual
Section 4: The BIOS Setup Utility
Boot Screen
The Boot screen allows you to configure the power-up
system configuration settings.
Figure 4-8: Boot Screen
Boot Sequence
This selection will read the diskette drive (default) and
the hard drive in sequence on boot.
Setup Prompt
If this selection is enabled, the message "Press F2 to enter
Setup" is displayed on boot. The default setting is Enabled.
POST Errors
If this selection is enabled (default) and an error occurs
on boot, the BIOS will display a SETUP entry or resume
prompt. If this selection is disabled, the system will always
attempt to boot.
M55Hi-Plus System Board Manual
45
Section 4: The BIOS Setup Utility
Numlock
This selection activates Numlock upon boot. Setting this
to Auto activates Numlock if the BIOS detects a numeric
keyboard. It may also be turned ON or OFF.
Exit Screen
After you complete configuring the BIOS, select the Exit
screen.
Figure 4-9: Exit Screen
Choose “Save Changes and Exit” and reboot the computer. Your computer is ready for use.
46
M55Hi-Plus System Board Manual
Section
5
Section 5: Installing Sound Device Drivers
Installing Sound Device Drivers
This section explains how to install the sound drivers
necessary to utilize the onboard sound support. Prior to
installing any drivers, follow the instructions in Section 3
on how to install a CD-ROM drive and how to connect
external sound devices.
About Device Drivers
Device drivers are necessary for the computer system to
communicate with devices such as CD-ROM drives,
sound controllers, graphics adapters or devices that are
not natively supported by the system BIOS. Once started,
device drivers remain active in the background of the
computer system. Usually a device driver is added to the
CONFIG.SYS file, the AUTOEXEC.BAT file or both.
M55Hi-Plus System Board Manual
47
Section 5: Installing Sound Device Drivers
Installing the Sound Drivers
Once you have connected your external sound devices, you
can install the sound drivers. NOTE: If you are installing a
CD-ROM drive, it is recommended you install it before
setting up the sound devices. See Installing a CD-ROM
Drive in Section 3.
1. Follow the instructions in Section 3 on connecting external sound devices.
2. If you previously installed another sound card, remove
it and all associated files from your AUTOEXEC.BAT
and CONFIG.SYS files. If you are using W indows 3.1x,
you must also remove all associated files from the
WIN.INI and SYSTEM.INI files. (For more information, please contact the sound driver manufacturer.)
3. Start your computer system.
4. Insert the sound driver disk into your floppy drive.
5. If you are using W indows 3.1x, go to the Program Manager File menu, click on Run and type A:\SETUP.
6. If you are using Windows 95, refer to the Windows 95
user’s manual for instructions on how to install sound
drivers.
7. If you are using OS/2, refer to the README file on
the OS/2 disk for instructions on how to install sound
drivers.
8. Once the software is copied, the install program
automatically updates the system files.
48
M55Hi-Plus System Board Manual
Appendix A: Technical Information
Appendix
A
Technical Information
Specifications
Part Number: 09-00273-01
Processor: 90MHz, 100MHz, 120MHz,
133MHz, 150MHz, 166MHz or
200MHz Pentium processors.
VR and VRE Support.
Chipset: Intel 430HX PCI chipset.
Intel PIIX 3.
SMC FDC37C93X Ultra I/O chip.
CPU Clock Select: Frequency synthesizer chip. Jumper
selectable CPU speed.
Form Factor: ATX footprint (12" x 9.6")
Expansion: Three 32-bit PCI slots.
Three 16-bit ISA slots.
One shared PCI/ISA slot.
BIOS: Phoenix 4.0X Plug and Play BIOS on
1MB Flash EPROM.
Auto-detection of memory size.
Auto-detection and display of ECC
and EDO memory.
Auto-configuration of IDE hard disk
drives.
Instant on and quick boot SMI and
DMI.
RAM Capacity: 4MB to 256MB.
Supports EDO memory.
Keyboard: PS/2 compatible.
M55Hi-Plus System Board Manual
49
Appendix A: Technical Information
Internal Cache: 16K on-chip Level 1 write back .
Up to 512K pipelined burst external
Level 2 cache.
Onboard Sound: 16-bit sound controller based on
Creative Labs Vibra 16C chipset.
Sound Blaster Compatible 16-bit stereo.
I/O Ports: Two high speed serial ports (16550 compatible).
Enhanced Parallel Port with EPP and ECP support.
Support for IrDA, HP-SIR and ASK-IR
Two USB ports for desktop peripheral expansion.
Floppy Port: Supports two floppy drives
(2.88MB, 1.44MB, 1.2MB, 720KB, 360KB).
PCI IDE Ports: Supports up to four IDE devices
Mode 4 Enhanced IDE with Bus Mastering.
Multiple sector transfer support.
Auto detection of add-in IDE board.
Environmental Specifications
The environment in which the M55Hi-Plus is located is critical. Micronics recommends the following environmental specifications:
Temperature Range
Operating: 50 to 104 degrees Fahrenheit (10 to 40 degrees Celsius).
Non -Operating: 50 to 140 degrees Fahrenheit (10 to 60 degrees
Celsius). Shipping: -22 to 140 degrees Fahrenheit (-30 to 60 degrees
Celsius).
Relative Humidity
Operating: 20% to 80%.
Non-Operating: 5% to 90%.
50
M55Hi-Plus System Board Manual
Appendix A: Technical Information
Battery Disposal
WARNING:
Please do not open battery, dispose of in fire, recharge, put in backwards
or mix with used or other battery types. The battery may explode or leak
and cause personal injury.
M55Hi-Plus System Board Manual
51
Appendix A: Technical Information
Technical Support
If you need technical assistance, our Technical Support
staff will be glad to assist you. You can contact us via
telephone, fax or Bulletin Board System (BBS). Before
calling please have the following information ready:
❏ The model name and 09 part number of your Micronics
product.
❏ Your computer information such as CPU type, operat-
ing system, amount of installed memory and other
peripherals installed in your computer.
❏ Try to call from the location of your computer.
NOTE: For Return Material Authorization (RMA) pur-
poses, please keep a copy of your product receipt.
In the United States:
Technical Support (510) 661-3000
Technical Support Fax (510) 651-6982
RMA Department (510) 683-0428
In Europe:
United Kingdom Technical Support (44) 1 256 844 899
United Kingdom Technical Support Fax
(44) 1 256 54476
Germany Technical Support 49-89-6881646
Germany Technical Support Fax 49-89-429517
France Technical Support +33 (1) 45 16 33 96
France Technical Support Fax +33 (1) 45 16 31 10
52
M55Hi-Plus System Board Manual
Appendix A: Technical Information
Online Services
Bulletin Board (BBS)
In the United States:
Technical Support BBS - 14400 baud rate, Parity=N, Data
Bits=8, Stop Bits=1, YMODEM and ZMODEM (recommended file transfer protocols)
(510) 651-6837
In Europe:
United Kingdom Technical Support BBS
(44) 1 256 63373
Germany Technical Support BBS 49-89-6881686
France Technical Support BBS +33 14 784 7057
World Wide Web
You will find information on product support, new product
releases and other categories of information. Access the
Internet and type: http://www.micronics.com
M55Hi-Plus System Board Manual
53
Appendix A: Technical Information
54
M55Hi-Plus System Board Manual
Appendix B: POST Messages
Appendix
B
POST Messages
The following table lists the Power On Self Test (POST)
messages, possible causes and solutions.
Message Possible Cause Solution
CPU FAN FAILED
DURING
PREVIOUS
OPERATION
DISKETTE DRIVE
A FAILURE
DISKETTE DRIVE
B FAILURE
EXTENDED RAM
FAILED AT
OFFSET: nnnn
FAILING BITS:
nnnn
FIXED DISK X
FAILURE (where X
=0 or 1)
FIXED DISK
CONTROLLER
FAILURE
INCORRECT
DRIVE A TYPE
INCORRECT
DRIVE B TYPE
INVALID NVRAM
MEDIA TYPE
KEYBOARD
ERROR, or
KEYBOARD
CONTROLLER
ERROR
Fan failed due to a
fan electrical problem,
or the option enabled
with incorrect fan
used.
Drive A failed or is
missing.
Drive B failed or is
missing.
Extended memory not
working or configured
properly.
Memory failure in
System, Extended, or
Shadow memory.
The hard disk is not
configured or working
properly.
The controller card
has failed.
Floppy drive A: not
set correctly in Setup.
Floppy drive B: not
set correctly in Setup.
NVRAM chip is bad. Requires repair of
The keyboard or
keyboard controller
failed.
Replace bad fan.
You must use a fan
with a power
connector that
connects to the
system board.
Check Setup and
cable connections.
Check Setup and
cable connections.
Replace defective
memory.
Replace defective
memory.
Rerun SETUP and
check connections,
or replace hard disk.
Check configuration
and connections, or
replace controller
card.
Run Setup.
Run Setup.
system board.
Check connections.
You may have to
replace the keyboard
or controller.
M55Hi-Plus System Board Manual
55
Appendix B: POST Messages
Message Possible Cause Solution
KEYBOARD
ERROR nn
A key is jammed or
was held down during
boot.
Make sure the keys
are not jammed or
dirty.
KEYBOARD
LOCKED
MONITOR TYPE
DOES NOT
MATCH CMOS
OPERATING
SYSTEM NOT
FOUND
PARITY CHECK 1
nnnn
PARITY CHECK 2
nnnn
PREVIOUS BOOT
INCOMPLETE DEFAULT
CONFIGURATION
USED
REAL TIME
CLOCK ERROR
Keyswitch on the
front of the case is
locked.
Monitor type not
correctly identified in
Setup.
Operating system
cannot be located on
Drive C: or Drive A:
Parity error found in
the system bus.
Parity error found in
the I/O bus.
Previous POST did
not complete
successfully.
Real-time clock failed
BIOS test.
Unlock the
keyswitch.
Run Setup and enter
correct monitor type.
Check Setup to see
if Drive A: and C: are
properly configured,
or put a bootable
disk in Drive A:
Check Setup. Board
repair may be
required.
Check Setup. Board
repair may be
required.
Run Setup, load
default BIOS
settings, make any
necessary
adjustments, and
save the changes.
May require battery
replacement or board
repair.
SHADOW RAM
FAILED AT
OFFSET
SYSTEM
BATTERY IS DEAD
56
M55Hi-Plus System Board Manual
Shadow RAM failed. May require repair of
system board.
System battery died. Replace the system
battery and run
Setup to reconfigure
the system.
Appendix B: POST Messages
Message Possible Cause Solution
SYSTEM CACHE
ERROR - CACHE
DISABLED
External (L2) cache
failed BIOS test.
System will still run,
but slower. Replace
cache at
convenience.
SYSTEM CMOS
CHECKSUM BAD RUN SETUP
System CMOS has
been corrupted or
modified incorrectly.
Run Setup and
reconfigure the
system.
SYSTEM RAM
FAILED AT
OFFSET: nnnn
System RAM failed. Replace defective
RAM.
SYSTEM TIMER
ERROR
Timer test failed. Requires repair of
system board.
M55Hi-Plus System Board Manual
57
Appendix B: POST Messages
58
M55Hi-Plus System Board Manual
Appendix C: Beep and POST Codes
Appendix
C
Beep and POST Codes
Beep codes are a series of beeps sent through the
speaker which indicate a problem during the Power On
Self Test (POST). If text appears on the video screen,
the M55Hi-Plus has completed POST; any other tone
from the speaker indicates something other than a
POST error. These tones are not described in the tables
on the following pages.
The beep error codes are a series of beeps. The duration
of the beep tones are constant, but the length of the
pauses between the beeps varies. For example: a 1-33 beep code will sound like one beep, a pause; three
beeps consecutively, another pause and then three
more beeps.
One beep code is often misunderstood. If a video card
is not installed or is failing, the system board will
generate a long-short-long-short beep code. This is
often interpreted as a 1-2-1 beep code. But POST
errors always vary in the length of the pause and not the
duration of the beep tone.
Another way of identifying a POST error is to use a
device called a POST card. This peripheral card is
inserted into one of the ISA slots and has an LED (or
LCD) read out showing the contents of port 80h.
The following tables list all beep codes and POST
routines.
M55Hi-Plus System Board Manual
59
Appendix C: Beep and POST Codes
Code Beeps POST Routine Descripti o n
02 Verify Real Mode.
04 Get CPU type.
06 Initialize system hardware.
08 Initialize chipset registers with initial POST values.
09 Get in POST Reg.
0A Initialize CPU registers.
0C Initialize cache initial POST values.
OE Initialize I/O.
OF Initialize the localbus IDE.
10 Initialize Pow er Ma nagem ent .
11 Load alternate registers with initial POST values.
12 Jump to UserPatch0.
14 Initialize keyboa rd contr oll er .
16 2-2-3 BIOS ROM checksum.
18 8254 timer initialization.
1A 8237 DMA controller initialization.
1C Reset Programmable Interrupt Controller.
20 3-1-1 Test DRAM refresh.
22 3-1-3 Test 8742 Keyboard Controller.
24 Set ES segment register to 4 GB.
28 Autosize DRAM.
2A Clear 512K base RAM.
2C 3-4-1 Test 512K base address lines.
2E 3-4-3 Test 512K base memory.
32 Test CPU bus-clock frequency.
34 Test CMOS RAM.
35 Initialize alternate chipset registers.
37 Reinitialize the chipset (MB only).
38 Shadow system BIOS ROM.
39 Reinitialize the c ache (M B only).
3A Autosize cache.
3C Configure advanced chipset registers.
3D Load alternate registers with CMOS values.
40 Set initial CPU speed.
42 Initialize interrupt vectors.
44 Initialize BIOS interrupts.
46 2-1-2-3 Check ROM copyright notice.
47 Initialize man ager for PCI Opti on ROMs.
48 Check video configur ation agains t CMOS.
49 Initialize PCI bus and devices.
60
M55Hi-Plus System Board Manual
Appendix C: Beep and POST Codes
Code Beeps POST Routine Description
4A Initialize all video adapters in system.
4C Shadow video BIOS ROM.
4E Display copyright notice.
50 Display CPU type and speed.
51 Initialize EISA board.
52 Test keyboard.
54 Set key click if enabled.
56 Enable keyboard.
58 2-2-3-1 Test for unexpected interrupts.
5A Display prompt “Press F2 to enter SETUP”.
5C Test RAM between 512 and 640k.
60 Test extended memory.
62 Test extended memory address lines.
64 Jump to UserPatch1.
66 Configure advanced cache registers.
68 Enable external and CPU caches.
6A Displ ay external cache size.
6C Display shadow message.
6E Displ ay non-disposable segments.
70 Display error messages.
72 Check for configuration errors.
74 Test real-time clock.
76 Check for keyboard errors.
7C Set up hardware interrupt vectors.
7E Test coprocessor if present.
80 Disable onboard I/O ports.
82 Detect and install external RS232 ports.
84 Detect and install external parallel ports.
86 Re-initialize on-board I/O ports.
88 Initialize BIOSData Area.
8A Initiali ze Extended BIOS Data Area.
8C Initialize floppy controller.
90 Initialize hard-disk controller.
91 Initialize localbus hard-di sk controller .
92 Jump to UserPatch2.
93 Build MPTABLE for multi-processor boards.
94 Disable A20 address line.
96 Clear huge ES segment register.
98 Search for option ROMs.
9A Shadow option ROMs.
M55Hi-Plus System Board Manual
61
Appendix C: Beep and POST Codes
Code Beeps POST Routine Description
9C Set up Power Management.
9E Enable hardware interrupts.
A0 Set time of day.
A2 Check key lock.
A4 Initialize typematic rate.
A8 Erase F2 prompt.
AA Scan for F2 keystroke.
AC Enter SETUP.
AE Clear in-POST flag.
B0 Check for errors.
B2 POST done - prepare to boot operating system.
B4 One beep.
B6 Check password (optional).
B8 Clear global descriptor tabl e.
BC Clear parity checkers.
BE Clear screen (optional) .
BF Check virus and backup reminders.
C0 Try to boot with INT 19.
D0 Interrupt handler error.
D2 Unknown interrupt error.
D4 Pending Interrupt.
D6 Initialize option ROM error.
D8 Shutdown error.
DA Ex tended Block Move.
DC Shutdown 10 error.
The following are for boot block in Flash ROM:
E2 Initialize the chipset.
E3 Initia li ze refresh counter.
E4 Check for Forced Flash.
E5 Check HW status of ROM.
E6 BIOS ROM i s OK.
E7 Do a complete RAM test.
E8 Do OEM initialization.
E9 Initialize interrupt controller.
EA Read in the bootstrap code.
EB Initialize all vectors.
EC Boot the Flash program.
ED Initialize the boot device.
EE Boot code was read OK.
62
M55Hi-Plus System Board Manual
Appendix D: Hard Disk Drive Types
Appendix
D
Hard Disk Drive Types
The following table lists the hard disk types supported by
the M55Hi-Plus.
Type Cylinders Heads Write
Precomp
1 306 4 128 17 10
2 615 4 300 17 21
3 615 6 300 17 32
4 940 8 512 17 65
5 940 6 512 17 99
6 615 4 none 17 21
7 462 8 256 17 32
8 733 5 none 17 31
9 900 15 none 17 117
10 820 3 none 17 21
11 855 5 none 17 37
12 855 7 none 17 52
13 306 8 128 17 21
14 733 7 none 17 44
15 N/A N/A N/A N/A N/A
16 612 4 0 17 21
17 977 5 300 17 42
18 977 7 none 17 59
19 1024 7 512 17 62
20 733 5 300 17 31
21 733 7 300 17 94
22 733 5 300 17 31
23 306 4 0 17 10
24 612 4 305 17 21
25 612 2 300 17 10
26 614 4 none 17 21
27 820 6 none 17 42
28 977 5 none 17 42
29 1218 15 none 36 336
30 1224 15 none 17 159
Sectors Size
M55Hi-Plus System Board Manual
63
Appendix D: Hard Disk Drive Types
Type Cylinders Heads Write
Precomp
31 823 10 512 17 71
32 809 6 128 17 42
33 830 7 none 17 50
34 830 10 none 17 72
35 1024 5 none 17 44
36 1024 8 none 17 71
37 615 8 128 17 42
38 1024 8 none 26 109
39 925 9 none 17 72
Sectors Size
64
M55Hi-Plus System Board Manual
Appendix E: Updating the System BIOS
Appendix
E
If you
encounter
any
problems
during this
process, or
if you have
questions
about the
procedure,
please call
Technical
Support.
Updating the System BIOS
The Micronics system boards are designed so that the
BIOS can be reprogrammed using a BIOS file. You can
easily FLASH a BIOS by following the steps below:
1) After downloading the appropriate BIOS file from
our BBS or Website, extract it to a bootable MSDOS 6.X or Windows 95 diskette.
2) If you are using MS-DOS 6.X, reboot your system
with the bootable diskette in the A: drive. To make
sure a clean DOS environment is loaded, press the
F5 key while "Starting MS-DOS" is displayed. After
the system has rebooted, the cursor will appear at
the A:\> prompt.
3) If you are using Windows 95, press F8 when you see
"Starting MS Windows 95." Select the option "Safe
Mode Command Prompt."
4) Now you can run the FLASH utility. The filename
will be either "FSH" (or FSH20, FSH20G, etc.) or
"PHLASH." Type this filename at the A:\> prompt
(but don’t include its extension), followed by a space
and the BIOS ROM image’s filename. This file will
be included in the download and has a file length of
about 131K. For example, to update the M55HiPlus to BIOS version 02, you would type:
PHLASH M55HIPLS.02P [ENTER]
5) After the update process is completed, turn off the
system.
6.) Turn the system back on and verify that the new
BIOS version appears on the screen.
NOTE: If the BIOS is somehow erased or doesn’t seem
to accept the upgrade, you can have your original BIOS
chip reprogrammed manually by Technical Support.
There is a $29.95 fee for this service, which includes
M55Hi-Plus System Board Manual
65
Appendix E: Updating the System BIOS
shipping charges to send your FLASH EPROM chip back
to you. Also, a preprogrammed FLASH EPROM chip can
be purchased from Technical Support for $50.00. Overnight shipping costs an additional $10.00. (Price and
availability subject to change.)
If you prefer to send your system board in for the upgrade,
the RMA department offers this service free of charge if
your system board is under warranty.
66
M55Hi-Plus System Board Manual
Limited Warranty
Limited Warranty
Except as described below, Micronics warrants the products to be free from defects in material and workmanship
in normal use for a period of one (1) year from date of
purchase. Should any product fail to perform according
to this warranty at any time during the warranty period,
except as provided below, Micronics or its authorized
service centers will, at Micronics’ option, repair or replace the product at no additional charge.
The warranty does not cover loss or damage which occurs
in shipment or which is due to: (1) improper installation
or maintenance, misuse, neglect or any cause other than
ordinary commercial application, including without limitation, accidents or acts of God; (2) adjustment, repair, or
modification by other than a Micronics authorized service center; (3) improper environment, excessive or
inadequate heating or air conditioning, or electrical
power failures, surges or other irregularities; (4) any
statement about the product other than those set forth in
this warranty; or (5) nonconformity to models or samples
shown to the purchaser. Any models or samples were for
the sole purpose of suggesting the character of the product and are not intended to form the basis of the bargain.
A receipt or copy of the invoice with the date of purchase
from a Micronics reseller is required before any warranty
service can be rendered. Service can be obtained by
calling Micronics for a Return Merchandise Authorization (RMA) Number.
The RMA Number should be prominently displayed on
the outside of the shipping carton of the returned product. Returned product should be shipped prepaid or hand
carried to Micronics. The purchaser assumes risk of loss
or damage in transit, and unless otherwise agreed to in
writing by Micronics, will pay inbound shipping charges.
The exclusive remedy of the purchaser under this warranty above will be repair or replace at Micronics’ option,
M55Hi-Plus System Board Manual
67
Limited Warranty
but if for any reason that remedy should fail of its essential
purpose, the exclusive remedy of the purchaser shall then
be actual damages up to amounts paid for the defective
product by the purchaser. This limited warranty shall be
deemed to “fail of its essential purpose” if, after repeated
efforts, Micronics is unable to make the product operate
as warranted. Micronics’ liability for damages to the
purchaser for any cause whatsoever; regardless of the
form of action and whether in contract or in tort, shall be
limited to the purchase price in effect when the cause of
action arose for the product that is the basis of the claim.
Micronics will not be liable for any lost profits or any
indirect, special incidental or consequential damages in
connection with the product, even if Micronics has been
advised of the possibility of such damages.
Micronics makes no warranties or representations as to
performance of products or as to service to distributor or
to any person, except as set forth in Micronics; limited
warranty accompanying delivery of product.
Micronics disclaims all other warranties whether oral,
written, expressed, or implied, including without limitation, the warranties of design, merchantability, or fitness
for a particular purpose, if applicable, or arising from a
course of dealing, usage or trade practice.
Non-Warranty Service
After the one year warranty service is no longer in effect,
repair service is still available for Micronics products. For
more information, contact Micronics’ RMA department
at (510) 683-0428. The RMA department is open between 8:30 A.M. and 5 P.M. Pacific Standard Time.
68
M55Hi-Plus System Board Manual
FCC Statement
FCC Statement
This equipment has been tested and found to comply
within the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if
not used in accordance with the instructions, may cause
harmful interference to radio communications. Interference to radio or television reception can be determined
by turning the equipment off and on. You are encouraged
to try to correct the interference by one or more of the
following measures:
Reorient the receiving antenna.
Increase the separation between the equipment
and the receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult your dealer or an experienced radio/TV
technician for help.
To meet FCC requirements, shielded cables are required.
NOTE: Changes or modifications not expressly approved by
Micronics could void your authority to operate the equipment.
M55Hi-Plus System Board Manual
69
Declaration of Conformity
Declaration of Conformity
Application of Council Directives 89/336/EEC. Standards to
which the conformity is declared:
EN50082-1
Manufacturer's Name: Micronics Computers, Inc.
Manufacturers Address: 221 Warren Avenue
Fremont, California 94539
USA
Tel: (510) 661-2300
Fax: (510) 651-9450
Type of Equipment: Motherboard (ATX form factor)
Mid Tower Personal Computer
Model Name: M55Hi-Plus
Tested by: Rockford Engineering Services, Inc.
9959 Calaveras Road
P.O. Box 543
Sunol, CA. 94586-0543
Telephone: (510) 862-2944
Fax: (510) 862-9013
Test Engineers John Y. Chan /Micronics
(EN50082-1)
Paramjeet Singh /RES (EN50082-1)
I, the undersigned, hereby declare that the specified equipment
conforms to the directives and standards listed above.
Ming Ming Hsu
Vice President of Engineering
June 4, 1996
70
M55Hi-Plus System Board Manual
Glossary
Glossary
16550 UART - A high speed chip for
controlling serial ports. Although unnecessary for a mouse, it is required
for modems that are 14,400 baud or
faster.
486DX - A type of 32-bit CPU with a
built-in math-coprocessor and internal cache.
486DX2 - A 486DX CPU where the
internal speed of the CPU operates at
twice the external speed.
486DX4 - A 486DX CPU where the
internal speed of the CPU operates at
three times the external speed.
486SX - A 486DX CPU with no mathcoprocessor.
ATX - A system board size measuring
approximately 12” x 9.6”.
Asynchronous - Operations that do
not require the clocks of communicating devices to be coordinated. See
Synchronous.
Bidirectional Parallel Port - A type of
parallel port that can send and receive
information.
BIOS - An Acronym for Basic Input/
Output System. Configures the system board and provides hardware information to the operating system.
Bit - A contraction of Binary digit.
The smallest unit of information in a
binary number system. A bit represents a choice between either zero or
one.
Boot - To start up the computer and
load the operating system software.
See cold boot and warm boot.
Bus - A group of electronic paths used
to send data between parts of the system. On a system board, the bus connects the peripheral cards with the
microprocessor via the expansion
slots.
Bus Mastering - The ability of an peripheral card to control the bus without requiring intervention of the CPU .
Byte - A group of adjacent bits treated
as a unit. Eight bits are typically considered one byte. Also called a character.
Cache - A process where information
is copied from the slower memory
(DRAM) to the faster memory
(SRAM). Information that is likely to
be read or edited is stored in the cache
providing significant performance increases.
Cache Hit - The percentage of request for data from memory that can
be served from the cache.
Cache Miss - A memory access which
cannot be supplied from cache.
Cold Boot - Starting the computer by
turning on the power or pressing the
RESET button. A cold boot makes the
processor execute all of the diagnostics. See boot and warm boot.
CPU - An acronym for Central Processing Unit. A CPU performs arithmetic calculations, makes logical de-
M55Hi-Plus System Board Manual
71
Glossary
cisions, and directs the operation of
the computer in conjunction with the
operating system.
Disk Drive - A hardware device
which provides for the storage of data
on diskettes or hard metal disks that
have a magnetic coating. A disk drive
functions by spinning at high speed
while moving a device called the read/
write head across the disk’s surface in
order to read or write data in magnetic code.
DRAM - An acronym for Dynamic
Random Access Memory. A type of
memory chip that only keeps its
memory if supplied with regular clock
pulses and a chance to regularly refresh its data. It is slower and more
cost effective than SRAM. See
SRAM.
ECC - An acronym for Error Checking and Correction. ECC enables parity checking and can detect and correct memory errors on the system
board.
ECP - An acronym for Extended Capabilities Port. A standard set by
Hewlett Packard and Microsoft Corporation to expand the capabilities of
the parallel port.
EDO Memory - An acronym for Extended Data Out. A type of DRAM
with built-in cache for enhanced performance.
EISA - An acronym for Extended Industry Standard Architecture. EISA
is a bus design standard which is fully
backward compatible with the ISA
bus. Although it is a 32-bit bus, it only
runs at 8MHz. See PCI, VESA Local
Bus and ISA.
EPP - An acronym for Enhanced Par allel Port. A standard which increases
the capabilities of the parallel port.
EPROM - Acronym for Erasable Programmable Read Only Memory. A
type of ROM chip that can be programmed with relatively simple tools
that will retain its data until erased. It
can only be erased by exposing the circuitry in the chip to ultraviolet light.
See also Flash ROM.
Flash ROM - A type of ROM chip
that will retain its data until erased. It
can be erased or reprogrammed by
supplying it with +12V of voltage. See
ROM and EPROM.
Gigabyte - A disk storage capacity
measurement. Approximately one
thousand megabytes or 1,073,741,824
bytes.
IDE - An acronym for Integrated Device Electronics. A standard for communicating between a hard drive and
a computer.
Internal Cache - Cache which is built
into the CPU. See Cache.
72
M55Hi-Plus System Board Manual
Glossary
ISA - An acronym for Industry Standard Architecture. A well-established
bus standard that originated with the
IBM AT. See PCI, VESA Local Bus
and EISA.
Parallel - A form of data transmission
in which the data is sent one byte at a
time over several wires that each carry
one byte. In parallel transmission, all
the bytes arrive simultaneously, as opposed to serial transmission in which
bits arrive one by one.
Parallel Port - A connection for a
printer or similar peripheral. Generally, parallel ports are output only. See
Bidirectional Parallel Port and ECP.
PCI - An acronym for Peripheral
Component Interconnect. A high performance 32-bit or 64-bit bus developed by Intel Corporation. PCI is designed to be independent of the hardware architecture to ensure compatibility with future computer systems.
See EISA, VESA Local Bus and ISA.
POST - An acronym for Power On
Self Test. A diagnostic program that
is run whenever the system is cold
booted.
RAM - An acronym for Random Access Memory. A type of memory that
is used as the “working memory” of a
computer system. See DRAM and
SRAM.
ROM - An acronym for Read Only
Memory. A type of memory that retains its data without requiring power.
Once written, it cannot be modified.
See EPROM and Flash ROM.
Serial - A type of data transmission
in which the data is sent one bit at a
time over a single wire. See Parallel.
Serial Port - A communications port
used to connect peripherals such as
modems and mice.
Setup - A program that allows you to
make changes to the system configuration.
Pentium - A high performance 64-bit
CISC processor designed and manufactured by Intel Corporation. As of
this writing, Pentium is the highest
performing X86 processor available.
Plug and Play - A standard developed
to ensure easy installation of peripherals. Theoretically, a newly installed
card will automatically configure itself
and work properly without requiring
jumper configuration or device drivers.
M55Hi-Plus System Board Manual
Shadow RAM - A technique used to
load a duplicate copy of BIOS from
slower ROM into faster RAM. This
enhances system performance because it provides higher access speed
to the BIOS.
SIMM - An acronym for Standard
Inline Memory Module. A small
printed circuit board containing
memory chips.
SRAM - An acronym for Static Random Access Memory. A type of
memory that can retain data without
requiring a regular clock signal. Al-
73
Glossary
though they are faster than DRAM,
they hold less data and are more expensive.
Synchronous - Protocols that require
the clocks of communicating machines or devices to be coordinated.
Synchronous Cache - A type of cache
that uses a clock signal to latch the
inputs and the data output. This structure spreads the cache access across
two or three cycles while maintaining
a bandwidth of one access per cycle.
Improves performance by 5-10%.
Terabyte - A measurement for very
large storage capacity. One Terabyte
is equivalent one-thousand gigabytes,
one-million megabytes, or
1,099,511,627,766 bytes.
VESA - An acronym for Video Electronics and Standards Association.
VESA Local Bus (VL-Bus) - A high
performance bus designed by VESA.
A 32-bit version of the ISA bus which
operates at the speed of the
computer’s CPU. See PCI, EISA and
ISA.
Warm Boot - Restarting the system
by simultaneously pressing the
<Ctrl>, <Alt> and <Delete> keys.
Write-Back Cache - Upon a cache
hit, the cache is updated and the main
memory is not affected. Upon a cache
miss, only the main memory is updated.
Write-Through Cache - Upon a
cache hit, the cache and the main
memory are updated. Upon a cache
miss, only the main memory is updated.
VGA - An acronym for Video Graphics Array. A standard for monitor displays.
VR - Pentium CPU voltage ranging
from 3.300 - 3.465 Volts.
VRE - Pentium CPU voltage ranging
from 3.400 - 3.600 Volts.
74
M55Hi-Plus System Board Manual
Index
A
ATX
Chassis - 18
Form Factor - 5
Power Supply - 18
B
Back Panel Connections - 13
Battery Disposal - 51
Beep and POST Codes - 59
BIOS
Configuration - 29
Setup - 29, 31
Bulletin Board System (BBS) - 53
Index
C
Configuring the M55Hi-Plus - 11
D
Diagram (M55Hi-Plus) - 12
E
Extended Data Out (EDO) Memory - 17, 19
Environmental Specifications - 50
Error Checking (ECC) - 17, 19
M55Hi-Plus System Board Manual
75
Index
F
Fast Page Mode (FPM) Memory - 17, 19
H
Hard Disk Drive Types - 63
Help
Bulletin Board System (BBS) - 53
Telephone Numbers - 52, 53
Troubleshooting - 55
I
Installation
CD-ROM Drive - 26
CPU - 23
Installing your M55Hi-Plus - 18
ISA Peripheral Card - 25
PCI Peripheral Card - 24
Quick Installation - 9
Sound Drivers - 47
76
J
Jumper Settings - 13
M
M55Hi-Plus Back Panel Connections - 13
M55Hi-Plus System Board Diagram - 12
Memory
Configurations - 21
Installing - 22
M55Hi-Plus System Board Manual
Mixing - 20
Removing - 22
Supported - 17, 19
O
Online Services - 53
P
POST Messages - 55
S
Sound Option - 27
Specifications - 49
System BIOS - 65
Index
T
Technical Specifications - 49
Technical Support - 52
Telephony Option - 28
Troubleshooting - 55
U
Updating the System BIOS - 65
Utility Programs
Advanced Screen - 36
BIOS Setup - 29
Boot Screen - 45
Exit Screen - 46
IDE Device Submenu - 34
M55Hi-Plus System Board Manual
77
Index
W
Main Screen - 31
Power Screen - 42
Security Screen - 39
World Wide Web - 53
78
M55Hi-Plus System Board Manual
Loading...
