Intel SE7221BK1, SE7221BK1-E User Manual

Intel® Entry Server Board SE7221BK1-E User Guide

Order Number: C72987-002

Intel® Entry Server Board SE7221BK1-E User Guide Disclaimer

Disclaimer

Information in this document is provided in connection with Intel® products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of the Intel product could create a situation where personal injury or death may occur. Intel may make changes to specifications and product descriptions at any time, without notice.

Intel server boards contain a number of high-density VLSI and power delivery components that need adequate airflow for cooling. Intel’s own chassis are designed and tested to meet the intended thermal requirements of these components when the fully integrated system is used together. It is the responsibility of the system integrator that chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of airflow required for their specific application and environmental conditions. Intel Corporation can not be held responsible if components fail or the server board does not operate correctly when used outside any of their published operating or non-operating limits.

Intel, Intel Pentium, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

* Other names and brands may be claimed as the property of others.

Intel® Entry Server Board SE7221BK1-E User Guide Preface

Preface

About This Manual

Thank you for purchasing and using the Intel® Entry Server Board SE7221BK1-E. This manual is written for system technicians who are responsible for troubleshooting, upgrading, and repairing this server board. This document provides a brief overview of the features of the board/chassis, a list of accessories or other components you may need, troubleshooting information, and instructions on how to add and replace components on the Intel® Entry Server Board SE7221BK1-E. For the latest version of this manual, refer to

http://support.intel.com/support/motherboards/server/SE7221BK1-E.

Manual Organization

Chapter 1 provides a brief overview of the Intel® Entry Server Board SE7221BK1-E. In this chapter, you will find a list of the server board features, photos of the product, and product diagrams to help you identify components and their locations.

Chapter 2 provides instructions on adding and replacing components. Use this chapter for step-bystep instructions and diagrams for installing or replacing components such as the memory, processor, the battery, and other components.

Chapter 3 provides instructions on using the utilities that are shipped with the board or that may be required to update the system. This includes how to navigate through the BIOS Setup screens, how to perform a BIOS update, and how to reset the password or CMOS. Information about the specific BIOS settings and screens is available in the Technical Product Specification. See

http://support.intel.com/support/motherboards/server/se7221bk1-e/spec.htm

Technical Product Specification.

Chapter 4 provides troubleshooting information. In this chapter, you will find BIOS error messages and POST code messages. You will also find suggestions for performing troubleshooting activities to identify the source of a problem.

for a link to the

Product Accessories

This server board is compatible with the following Intel® Server Chassis:

Intel® Entry Server Platform SR1425BK1-E (Integrated 1U chassis and board)

Intel® Entry Server Chassis SC5250-E

You may need or want to purchase one or more of the following accessory items for your server:

Processor, memory DIMMs, hard drive, floppy drive, CDROM or DVDROM drive, operating system.

iii

Preface Intel® Entry Server Board SE7221BK1-E User Guide

For information about which accessories, memory, processors, and third-party hardware have been tested and can be used with your board, and for ordering information for Intel products, see

http://support.intel.com/support/motherboards/server/SE7221BK1-E

Additional Information and Software

If you need more information about this product or information about the accessories that can be used with this server board, go to this link to find the information below:

http://support.intel.com/support/motherboards/server/SE7221BK1-E

 In-depth technical information about this product, including the BIOS settings and chipset

information in the Intel

Entry Server Board SE7221BK1-E Technical Product Specification.

 The latest product information  Accessories or other Intel

server products

 Hardware (peripheral boards, adapter cards) and operating systems that have been tested with

this product

 Chassis that have been tested with this product  Processors that have been tested with this product  DIMMs that have been tested with this product  Power budget for this product  Software to manage your Intel Server  Diagnostics testing software  Firmware and BIOS updates  System drivers

Intel® Entry Server Board SE7221BK1-E User Guide Preface

 Safety Information

WARNING

Before working with your server product, whether you are using this guide or any other resource as a reference, pay close attention to the safety instructions. You must adhere to the assembly instructions in this guide to ensure and maintain compliance with existing product certifications and approvals. Use only the described, regulated components specified in this guide. Use of other products / components will void the UL listing and other regulatory approvals of the product and will most likely result in noncompliance with product regulations in the region(s) in which the product is sold.

Emissions Disclaimer

To ensure EMC compliance with your local regional rules and regulations, the final configuration of your end system product may require additional EMC compliance testing. For more information please contact your local Intel Representative.

See the “Regulatory and Integration Information

” for product safety compliance and EMC regulatory compliance information. This is an FCC Class A device. Integration of it into a Class B chassis does not result in a Class B device.

Intended Uses

This product was evaluated as Information Technology Equipment (ITE), which may be installed in offices, schools, computer rooms, and similar commercial type locations. The suitability of this product for other product categories and environments (such as: medical, industrial, telecommunications, NEBS, residential, alarm systems, test equipment, etc.), other than an ITE application, may require further evaluation

EMC Testing

Before computer integration, make sure that the chassis, power supply, and other modules have passed EMC testing using a server board with a microprocessor from the same family (or higher) and operating at the same (or higher) speed as the microprocessor used on this server board.

WARNING

System power on/off: The power button DOES NOT turn off the system

AC power. To remove power from system, you must unplug the AC power cord from the wall outlet. Make sure the AC power cord is unplugged before you open the chassis, add, or remove any components.

Hazardous conditions, devices and cables: Hazardous electrical conditions may be present on power, telephone, and communication cables. Turn off the server and disconnect the power cord, telecommunications systems, networks, and modems attached to the server before opening it. Otherwise, personal injury or equipment damage can result.

Electrostatic Discharge (ESD) and ESD Protection: ESD can damage disk drives, boards, and other parts. We recommend that you perform all procedures in this chapter only at an ESD workstation. If one is not available, provide some ESD protection by wearing an antistatic wrist

Preface Intel® Entry Server Board SE7221BK1-E User Guide

strap attached to chassis groundany unpainted metal surfaceon your server when handling parts.

ESD and Handling Boards: Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by their edges. After removing a board from its protective wrapper or from the server, place the board component side up on a grounded, static free surface. Use a conductive foam pad if available (not the board wrapper). Do not slide board over any surface.

Installing or Removing Jumpers: A jumper is a small plastic encased conductor that slips over two jumper pins. Some jumpers have a small tab on top that you can grip with your fingertips or with a pair of fine needle nosed pliers. If your jumpers do not have such a tab, take care when using needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with the pliers, never the wide sides. Gripping the wide sides can damage the contacts inside the jumper, causing intermittent problems with the function controlled by that jumper. Take care to grip with, but not squeeze, the pliers or other tool you use to remove a jumper, or you may bend or break the pins on the board.

Intel® Entry Server Board SE7221BK1-E User Guide Preface

Safety Cautions

Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the Resource CD and/or at

http://support.intel.com/support/motherboards/server/sb/CS-010770.htm

SAFETY STEPS: Whenever you remove the chassis covers to access the inside of the system, follow these steps:

1. Turn off all peripheral devices connected to the system.

2. Turn off the system by pressing the power button.

3. Unplug all AC power cords from the system or from wall outlets.

4. Label and disconnect all cables connected to I/O connectors or ports on the back of the system.

5. Provide some electrostatic discharge (ESD) protection by wearing an antistatic wrist strap attached to chassis ground of the system—any unpainted metal surface— when handling components.

6. Do not operate the system with the chassis covers removed.

A microprocessor and heat sink may be hot if the system has been running. Also, there may be sharp pins and edges on some board and chassis parts. Contact should be made with care. Consider wearing protective gloves.

Wichtige Sicherheitshinweise

Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu IntelServerplatinen und -Servergehäusen auf der Ressourcen-CD oder unter

http://support.intel.com/support/motherboards/server/sb/CS-010770.htm

SICHERHEISMASSNAHMEN: Immer wenn Sie die Gehäuseabdeckung abnehmen um an das Systeminnere zu gelangen, sollten Sie folgende Schritte beachten:

1. Schalten Sie alle an Ihr System angeschlossenen Peripheriegeräte aus.

2. Schalten Sie das System mit dem Hauptschalter aus.

3. Ziehen Sie den Stromanschlußstecker Ihres Systems aus der Steckdose.

4. Auf der Rückseite des Systems beschriften und ziehen Sie alle Anschlußkabel von den I/O Anschlüssen oder Ports ab.

5. Tragen Sie ein geerdetes Antistatik Gelenkband, um elektrostatische Ladungen (ESD) über blanke Metallstellen bei der Handhabung der Komponenten zu vermeiden.

6. Schalten Sie das System niemals ohne ordnungsgemäß montiertes Gehäuse ein.

Der Mikroprozessor und der Kühler sind möglicherweise erhitzt, wenn das System in Betrieb ist. Außerdem können einige Platinen und Gehäuseteile scharfe Spitzen und Kanten aufweisen. Arbeiten an Platinen und Gehäuse sollten vorsichtig ausgeführt werden. Sie sollten Schutzhandschuhe tragen.

vii

Preface Intel® Entry Server Board SE7221BK1-E User Guide

重要安全指

在行任何指令之前，本文档中的所有注意事及安全声明。参 Resource CD（源光）和/或 http://support.intel.com/support/motherboards/server/sb/CS-010770.htm 上的

Intel Server Boards and Server Chassis Safety Information

（《Intel

服器主板与服器机箱安全信息》）。

Consignes de sécurité

Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document avant de suivre toute instruction. Consultez Intel Server Boards and Server Chassis Safety Information sur le CD Resource CD ou bien rendez-vous sur le site

http://support.intel.com/support/motherboards/server/sb/CS-010770.htm

CONSIGNES DE SÉCURITÉ -Lorsque vous ouvrez le boîtier pour accéder à l’intérieur du système, suivez les consignes suivantes:

1. Mettez hors tension tous les périphériques connectés au système.

2. Mettez le système hors tension en mettant l’interrupteur général en position OFF (bouton-poussoir).

3. Débranchez tous les cordons d’alimentation c.a. du système et des prises murales.

4. Identifiez et débranchez tous les câbles reliés aux connecteurs d’E-S ou aux accès derrière le système.

5. Pour prévenir les décharges électrostatiques lorsque vous touchez aux composants, portez une bande antistatique pour poignet et reliez-la à la masse du système (toute surface métallique non peinte du boîtier).

6. Ne faites pas fonctionner le système tandis que le boîtier est ouvert.

Le microprocesseur et le dissipateur de chaleur peuvent être chauds si le système a été sous tension. Faites également attention aux broches aiguës des cartes et aux bords tranchants du capot. Nous vous recommandons l'usage de gants de protection.

viii

Intel® Entry Server Board SE7221BK1-E User Guide Preface

Instrucciones de seguridad importantes

Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en el CD Resource y/o en http://support.intel.com/support/motherboards/server/sb/CS-010770.htm

INSTRUCCIONES DE SEGURIDAD: Cuando extraiga la tapa del chasis para acceder al interior del sistema, siga las siguientes instrucciones:

1. Apague todos los dispositivos periféricos conectados al sistema.

2. Apague el sistema presionando el interruptor encendido/apagado.

3. Desconecte todos los cables de alimentación CA del sistema o de las tomas de corriente alterna.

4. Identifique y desconecte todos los cables enchufados a los conectores E/S o a los puertos situados en la parte posterior del sistema.

5. Cuando manipule los componentes, es importante protegerse contra la descarga electrostática (ESD). Puede hacerlo si utiliza una muñequera antiestática sujetada a la toma de tierra del chasis — o a cualquier tipo de superficie de metal sin pintar.

6. No ponga en marcha el sistema si se han extraído las tapas del chasis.

Si el sistema ha estado en funcionamiento, el microprocesador y el disipador de calor pueden estar aún calientes. También conviene tener en cuenta que en el chasis o en el tablero puede haber piezas cortantes o punzantes. Por ello, se recomienda precaución y el uso de guantes protectores.

AVVERTENZA: Italiano

PASSI DI SICUREZZA: Qualora si rimuovano le coperture del telaio per accedere

all’interno del sistema, seguire i seguenti passi:

1. Spegnere tutti i dispositivi periferici collegati al sistema.

2. Spegnere il sistema, usando il pulsante spento/acceso dell’interruttore del sistema.

3. Togliere tutte le spine dei cavi del sistema dalle prese elettriche.

4. Identificare e sconnettere tutti i cavi attaccati ai collegamenti I/O od alle prese

5. Qualora si tocchino i componenti, proteggersi dallo scarico elettrostatico (SES),

6. Non far operare il sistema quando il telaio è senza le coperture.

Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti taglienti sulle schede e sul telaio. È consigliabile l'uso di guanti di protezione.

installate sul retro del sistema.

portando un cinghia anti-statica da polso che è attaccata alla presa a terra del telaio del sistema – qualsiasi superficie non dipinta – .

Intel® Entry Server Board SE7221BK1-E User Guide

Contents Intel® Entry Server Board SE7221BK1-E User Guide

Contents

1 Server Board Features................................................................................... 1

Connector and Component Locations................................................................................ 4

Configuration Jumpers......................................................................................................... 5

System Recovery and Update.....................................................................................5

Back Panel Connectors........................................................................................................ 6

Hardware Requirements.......................................................................................................7

2 Hardware Installations and Upgrades.......................................................... 9

Before You Begin..................................................................................................................9

Tools and Supplies Needed ................................................................................................. 9

Installing and Removing Memory...................................................................................... 10

Installing DIMMs......................................................................................................... 10

Removing DIMMs .......................................................................................................11

Installing or Replacing the Processor............................................................................... 12

Installing the Processor.............................................................................................12

Removing the Processor........................................................................................... 15

Installing a PCI, PCI-X, or PCI-Express* Card ..................................................................16

Replacing the Backup Battery ..................................................................................17

3 Server Utilities .............................................................................................. 20

BIOS Setup ..........................................................................................................................20

Localization .........................................................................................................................20

Console Redirection ........................................................................................................... 20

Configuration Reset............................................................................................................20

Keyboard Commands.........................................................................................................21

Upgrading the BIOS............................................................................................................ 22

Preparing for the Upgrade.........................................................................................22

BIOS Selection and On-line Updates........................................................................ 24

Recovering the BIOS ..........................................................................................................25

Manually Recovering the BIOS ................................................................................. 25

Clearing the Password .......................................................................................................26

Clearing the CMOS..............................................................................................................26

4 Troubleshooting........................................................................................... 27

Resetting the System..........................................................................................................27

Problems Following Initial System Installation................................................................ 27

First Steps Checklist.................................................................................................. 27

Hardware Diagnostic Testing.............................................................................................28

Verifying Proper Operation of Key System Lights.................................................. 29

Confirming Loading of the Operating System......................................................... 29

Specific Problems and Corrective Actions....................................................................... 29

Power Light Does Not Light ...................................................................................... 29

No Characters Appear on Screen.............................................................................30

Contents Intel® Entry Server Board SE7221BK1-E User Guide

Characters Are Distorted or Incorrect...................................................................... 30

System Cooling Fans Do Not Rotate Properly ........................................................ 31

Diskette Drive Activity Light Does Not Light...........................................................31

CD-ROM Drive or DVD-ROM Drive Activity Light Does Not Light .........................31

Cannot Connect to a Server......................................................................................32

Problems with Network..............................................................................................32

System Boots When Installing PCI Card.................................................................. 33

Problems With Newly Installed Application Software ............................................33

Problems With Application Software That Ran Correctly Earlier ..........................33

Devices Are Not Recognized Under Device Manager (Windows* Operating

System)......................................................................................................... 34

Hard Drive(s) Are Not Recognized............................................................................ 34

Bootable CD-ROM Is Not Detected...........................................................................34

Error Handling and Reporting............................................................................................ 35

LED Information .........................................................................................................35

BIOS Event Log .......................................................................................................... 36

BIOS POST Beep Codes............................................................................................37

Regulatory and Compliance Information........................................................ 39

Product Regulatory Compliance .......................................................................................39

Product Safety Compliance.......................................................................................39

Product EMC Compliance – Class A Compliance................................................... 39

Certifications / Registrations / Declarations............................................................ 39

Product Regulatory Compliance Markings.............................................................. 40

Electromagnetic Compatibility Notices ............................................................................40

FCC (USA)................................................................................................................... 40

Industry Canada (ICES-003) ...................................................................................... 41

Europe (CE Declaration of Conformity) ...................................................................41

Taiwan Declaration of Conformity (BSMI)................................................................ 42

Korean Compliance (RRL).........................................................................................42

Getting Help ....................................................................................................... 43

Intel® Server Issue Report Form....................................................................... 45

xii

Intel® Entry Server Board SE7221BK1-E User Guide Contents

Figures

Figure 1. Intel® Server Board SE7221BK1-E...............................................................................1

Figure 2. Intel® Entry Server Board SE7221BK1-E Connections................................................. 4

Figure 3. Configuration Jumper Location (J1F2) ..........................................................................5

Figure 4. Back Panel Connectors .................................................................................................6

Figure 5. DIMM Install................................................................................................................. 10

Figure 6. Processor Install .......................................................................................................... 13

Figure 7. Installing the Processor in the Processor Socket ........................................................13

Figure 8. Processor Install .......................................................................................................... 13

Figure 9. Attaching the Heat Sink to the Processor....................................................................14

Figure 10. Heat Sink ................................................................................................................... 14

Figure 11. Heat Sink Snap.......................................................................................................... 15

Figure 12. Add-in Riser...............................................................................................................16

Figure 13. Add-in Card................................................................................................................ 16

Figure 14. Replacing the Battery ................................................................................................18

Figure 15. BIOS Recovery Jumper .............................................................................................25

Tables

Table 1. Server Board Features.................................................................................................... 2

Table 2. Configuration Jumper [J1F2]........................................................................................... 5

Table 3. NIC LEDs ........................................................................................................................6

Table 4. Board Power Supply Voltage Specification..................................................................... 7

Table 5. PCI Buses.......................................................................................................................8

Table 6. BIOS Setup Keyboard Command Bar Options .............................................................21

Table 7. LED Information............................................................................................................35

Table 8. Post Error Messages and Handling .............................................................................. 36

Table 9. Beep Codes .................................................................................................................. 37

Table 10. Product Certification Markings ....................................................................................40

xiii

Intel® Entry Server Board SE7221BK1-E User Guide Server Board Features

1 Server Board Features

This chapter briefly describes the main features of Intel® Entry Server Board SE7221BK1-E. This chapter provides a photograph of the product, a list of the server board features, and diagrams showing the location of important components and connections on the server board. This server board is available in three options:

 The Intel® Entry Server Board SE7221BK1-E includes Serial ATA host controller for 4 ports

with support for RAID 0, 1, and 10 provided. It also includes dual-channel Parallel ATA support and an on-board Intel® 82541PI Ethernet Controller.

 The Intel® Entry Server Board SE7221BK1-E (LX SKU) adds a second Intel® 82541PI

Ethernet Controller, Intel® Adaptive Slot technology, additional fan headers, and LED diagnostics.

 The Intel® Entry Server Platform SR1425BK1-E based on the Intel® Server Chassis SR1400

and the Intel® Entry Server Board SE7221BK1-E (LX SKU).

The Intel® Server Board SE7221BK1-E with second NIC and Adaptive Slot is shown.

Figure 1. Intel® Server Board SE7221BK1-E

Server Board Features Intel® Entry Server Board SE7221BK1-E User Guide

Table 1. Server Board Features

Feature Description

Processors Support for an Intel® Pentium® 4 processor with Intel® Hyper-Threading Technology

in an LGA775 package with an 800 MHz system bus. Frequencies starting at 2.8 GHz

Memory

 Four DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets  Support for 256MB to 4 GB Unbuffered ECC on Non-ECC DDR2 400/533 system

memory

 Support for single-sided or double-sided DIMMs (DDR2 400/533)

- To run DDR2 400 MHz memory at full speed requires an Intel® Pentium® 4 processor with 800 MHz system bus frequency.

- DIMMs must be ECC x8 or Non-ECC x8 or x16 DDR2 unbuffered.

- Supports Intel x4 SDDC only with x4 DIMMS

Chipset Intel® E7221 chipset, consisting of:

 Intel  Intel

E7221 Memory Controller Hub (GMCH)

ICH6R I/O Controller Hub

 Intel® PXH PCI-X Hub  National Semiconductor* PC87431M mini-Baseboard Management Controller

I/O Control National Semiconductor* PC87427 Super I/O controller chip Peripheral Interfaces

 Two external USB 2.0 ports on the back panel with an additional internal header,

which provides support for two additional USB ports with front panel support (four total possible USB 2.0 ports)

 One external serial port and one serial header  One 40 pin ATA-100 IDE connector  An integrated Serial ATA controller with 4 serial ports output. Support for Raid 0,

1, and 10

 One standard 34 pin front panel connector supporting floppy drive interface with

support for one drive, for use with or without backplane

keyboard and mouse ports

LAN

 PS/2  One Intel® 82541PI Ethernet Controller Platform LAN Connect (PLC) device for

10/100/1000 Mbits/second Ethernet LAN connectivity

 Intel® Entry Server Board SE7221BK1-E (LX and SR SKUs only) Additional

Intel® 82547EI Platform LAN Connect (PLC) device for 10/100/1000 Mbps Ethernet LAN connectivity

Expansion Capabilities

Four independent PCI buses

1. One PCI 2.3 32-bit/33 MHz, 5 V connector supporting full length PCI add-in cards and one 82541PI Gigabit Ethernet Controller

2. A second 32-bit/33 MHz 82541PI Gigabit Ethernet Controller (Intel® Entry Server Board SE7221BK1-E (LX and SR SKUs only)

3. Two PCI-X 64 bit 3.3 volt slots which can support either:

 Two full length PCI / PCI-X add-in cards at 66 MHz or  One PCI-X 64-bit/100 MHz, 3.3 V card

4. One x8 PCI-Express* slot supporting x1, 2, x4 or x8 (SC5250E) or

One riser card supporting PCI, PCI-X or PCI-Express* add-in card

(SR1425BK1-E) Integrated Graphics Fans Support for up to four system fan modules and one processor fan

Integrated graphics supporting SVGA

Intel® Entry Server Board SE7221BK1-E User Guide Server Board Features

Feature Description

BIOS Intel/AMI BIOS with support for:

 Advanced Configuration and Power Interface (ACPI)  8 megabit symmetrical flash memory  Support for SMBIOS

Power Management Support for ACPI:

 Support for S0, S1, S4, and S5  Wake on USB, PCI, RS-232, PS/2, LAN, and front panel

Intel

Server Management

Server Management support via National Semiconductor* mini-Baseboard

Management Controller (mBMC)

Server Board Features Intel® Entry Server Board SE7221BK1-E User Guide

Connector and Component Locations

The connections you make depend on the chassis and the components you are installing.

HA B C D E F G

DD CC

BB AA

CPU

Socket

DIMM 2B Socket

DIMM 1B Socket

DIMM 1A Socket

DIMM 2A Socket

V U T S NR Q P

M L

TP01326

Figure 2. Intel® Entry Server Board SE7221BK1-E Connections

A Chassis Intrusion Header

B PCI Slot N Front USB Header (optional) X Serial ATA (SATA) 2 Connector C PCI-X 100 SLOT O System Fan Headers (for Intel®

D PCI-X 100 SLOT P System Fan #4 Z BIOS Control Jumper E PCI-Express* or Riser Connector Slot F +12v CPU Power R Main Power Connector BB HDD LED Header G System Fan #1 (optional) S Floppy Connector CC HSBP Header H Back Panel I/O Connectors T IDE Connector DD Battery I System Fan #2 (optional) U SATA 4 Connector EE Serial B Header J CPU Fan (optional) V SATA 3 Connector K CPU Socket L DIMM Sockets (two – from left to right: DIMM 1B, DIMM 2B)

M DIMM Sockets (two – from left to right: DIMM 1A, DIMM 2A)

Server Board SR1425BK1-E)

Q System Fan #3 (optional) AA BIOS Select Jumper

W 34-pin Front Panel Connector

Y SATA 1 Connector

Intel® Entry Server Board SE7221BK1-E User Guide Server Board Features

Configuration Jumpers

System Recovery and Update

Figure 3. Configuration Jumper Location (J1F2)

NOTE

✏

Pin 1 is close to the SATA Header. This view is from the CPU side insert.

Table 2. Configuration Jumper [J1F2]

Function Pin – Pin Function Description

CLEAR

1-2 MBMC control CMOS CLEAR 2-3 Force erase 5-6 Protect PASSWORD 6-7 Erase

9-10 Normal BOOT RECOVERY BOOT 10-11 Recovery BOOT

CMOS settings will be cleared on the next reset. Normal operation – Jumper 1-2

Administrator and user passwords will be cleared on the next reset. Normal operation – Jumper 5-6

BIOS recovery can be attempted by loading BIOS code into flash device from a floppy.

+ 42 hidden pages

Intel SE7221BK1, SE7221BK1-E User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
