TAG Heuer Connected Watch (Draft)
INSTRUCTIONS AND INTERNATIONAL LIMITED GUARANTEE
PART I. QUICK START GUIDEPART II. INTERNATIONAL WARRANTY
PART I: QUICK START GUIDE - USER MANUAL
Congratulations on your purchase. This document is a quick start guide providing information on your TAG Heuer
connected device basic functions only. For more information and exclusive content, go to : http://customer-
service.tagheuer.com.
Each TAG Heuer Connected Watch is built to meet the most exacting requirements. We paid the very same careful
attention to detail on this connected watch from design, conception to finishing that we constantly do on our watches
for more than 150 years years while partnering with the best partners Google and Intel.
The materials used in our devices make them exceptionally resilient, even when used under the most rigorous
conditions. Before a new TAG Heuer product is launched, it is put through numbers of reliability and quality tests.
With its modern, unique and timeless design, your new TAG Heuer Connected Watch combines Swiss quality
watchmaking tradition with technology. We hope it will bring you complete satisfaction.
MODULARITY
Your TAG Heuer Connected watch presents an inner-modularity aspect enabling you to create various looks by
swapping parts of your watch. To check which additional accessories you can buy to make the most of the inner-
modularity of your product, go to: www.tagheuer.com
Warning: Some accessories taking part into the inner-modularity are small and sharp. Inner-modularity should only
be practiced by adults, instructions below read carefully and steps followed in order. Risk to break or scratch your
product by misreading the information below is high and will void your warranty.
Contact your nearest customer service center if help is needed. List of inner-modular accessories:
View of watch with inner-modularity
DISASSEMBLY PROCESS
Process starting with a fully-assembled product leading to dis-assembly for part replacement purpose.
A. First, you will separate the entity horn-strap (b)-(c) from the module (a).
1. Take your watch fully assembled and lay it down on the opposite side of the power button on a smooth surface so
that you can see the caseback. On one side, place your thumb on the push button located under the horn while
keeping your index and middle fingers on top of the horns. With your other hand, hold the module in the middle.
2. While pressing on the power button located under the horn(b), push down the entity horn- strap(b) -(c)
perpendicularly to dislocate it from the module(a).
3&4. Repeat step 1 & 2 on the opposite side of your module to detach the
horn-strap (b)-(c) entity on the other side.
5. You should now have the module (a) completely detached from the rest
of the accessories (b,c,d).
B. Second, you will detach your horns (b) from your strap (c)
1. Take your horn(b) strap(c)entity by one side. With one hand hold the horns by the side between your thumb and
index. Be careful, those can be sharp. With your other hand hold the strap
2. . In an opposite movement, pull the horns horizontally in one direction while pulling the strap in the opposite
direction. You should now have your horns and strap separated on one side.
3&4 Repeat step 1 & 2 on the other horn-strap entity to disassemble it.
5. You should now have your module (a) and horns (b) separated from your strap
and buckle (c) & (d).
C. Third, detach your buckle (d) from your strap(c)
(Relevant only for rubber and calfskin straps, skip this step if your strap is made entirely out of links).
3. Take your strap and press on the push buttons to open the buckle.
4. Once unclasped, hold the middle part of your opened buckle with one hand and hold the strap part not directly
attached with the part with the push buttons. Rotate the strap part you are holding for it to be perpendicular
to the middle part of buckle you are holding.
5. After rotating, pull your strap out so that it can be freed from the buckle. You should have only one strap part
remaining attached to your buckle.
6. Focusing on the buckle part: The goal is to detach the remaining strap from the
buckle. The detachment can only occur between the end metal part of the strap and the link with “Tag Heuer”
engraving (see fig. 7). The other pieces cannot be separated from one another. Hold the link with “TAG Heuer
engraving” between your index and thumb with one hand while holding with the other hand the strap.
7. Turn the strap inside to have it positioned at 90° with link and push it like you wanted to have your strap leaning
on the inside part of your power button buckle.
8. You should see the strap metal part of your strap free itself from the link. enabling you to have your strap and
buckle apart.
9. ASSEMBLY PROCESS
When starting your assembly process, please make sure you follow the right steps depending at which state your
product is. Read the description of the elements described in the dis-assembly process to understand below terms.
A. Attaching the buckle (d) to the strap (c). (Relevant only for rubber and calfskin straps, skip this step if your strap
is made entirely out of links).
Make sure your folding clasp is opened to ease below steps.
1. strap part with metal ending and insert it into the link with “TAG Heuer” engraving. Check that your strap is in
the right position meaning that the top part of your strap which will be attached to horns later on should be facing
inwards, opposite to the link with “TAG Heuer” engraving.
2&3. Once your strap metal part is in the link of your buckle, make sure all the
parts of your strap, metal strap, link and buckle are aligned.
4&5. Take your loose strap part remaining to attach it to the buckle. You will
insert the end piece into the dedicated end piece. Adjust the angle of insertion for smooth fitting. You can adjust the
size of your strap by sliding this strap part here. As for the strap with metal part, make sure it is inserted in the right
position to welcome horns later on.
6. Close your buckle.B. Assembling your strap (c ) with the horns (b).
1&2. Take your strap by one side and adjust it onto the horns. You should make sure the little balls visible on the top
of horns are hidden by the strap part on top of it and make sure you have heard a “click” noise, insuring you the right
assembly of both elements.
3&4. Repeat operation on the opposite side.
5. You should now have the strap and horns assembled together while the module is on its own.
C. Assembling horn-strap entity (b-c) to the module (a).
1. Placeahorm-strapentityperpendicularlyunderthemoduleandgentlyclip it.
2. Make sure you have heard a “click” noise, insuring you the right assembly of both elements.
3&4. Repeat operation on the opposite side. 7. Your watch should be fully assembled.
COMPATIBILITY
Your TAG Heuer Connected is compatible with phones running Android 4.3+ and iOS 8.2+. Visit g.co/wear check
from your phone to find out if it is compatible. »
CHARGING ACCESSORIES PROVIDED WITH TAG HEUER CONNECTED WATCH
Your TAG Heuer Connected Watch should be provided with a charging cradle, micro USB cable* and wall plug*.
*Design or availability may vary depending on the region.
TURNING ON YOUR TAG HEUER CONNECTED WATCH
1. Connect your watch to a power source2. Press and hold the power button for a few seconds 3. Tap the screen to
begin
4. Tap a language
TURNING OFF YOUR TAG HEUER CONNECTED WATCH
1. Press on power button
2. Look for settings, tap system and select turn off.
3. When prompted with message “Turn off: Are you sure?” Tap check mark.
CHARGING YOUR TAG HEUER CONNECTED WATCH
Before using your watch for the first time, you should charge the battery. Use the charging cradle, micro USB
cable* and wall plug* provided with the watch to charge its battery.
*Design may vary from the one provided with your TAG Heuer Connected Watch.
1. Please insert the micro USB cable into the charging cradle.
2. Align the shield logo of your power button on the watch with the shield
you can find on the right side of the charging cradle. Magnets on charger will help both items be aligned correctly.
3. Make sure Micro USB cable is plugged into an authorized power source. You will see a charging symbol on the
watch letting you know that it is charging.
Recommendation: Charge your watch every night to get the most of your day.
PAIRING YOUR TAG HEUER CONNECTED WATCH
1. Turn on your watch to follow the instructions on the watch. Tap a language.
2. Connect your phone to Wi-Fi and turn on Bluetooth.
3. Launch Android Wear application on your phone and follow the instructions.
4. A confirmation message on your watch will be displayed once it is paired.
5. Follow the onscreen instructions on the watch to complete the initial set up.
