QuickSpecs

Overview

HP Compaq nc6400 Notebook PC

HP recommends Windows Vista™ Business

Volume Mute Button with LED

Volume Down Button

Volume Up Button

Integrated Microphone

Biometric Fingerprint Sensor

Pointstick

Pointstick Buttons

Stereo Speakers

SD Media Slot

10.

Fast Infrared Port

11.

Touchpad with scroll zone

12.

Touchpad Buttons

13.

Hard Drive Activity LED

14.

Battery Charging LED

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

15.

16.

17.

18.

19.

20.

21.

22.

23.

24.

25.

26.

27.

28.

Power/Standby LED Wireless On/Off LED PC Card Eject Button PC Card Slot Headphone Jack Microphone Jack 2 USB 2.0 Ports Power Button with LED HP Info Center Button Wireless On/Off Button with LED Presentation Mode Button Ambient Light Sensor Dual-band Wireless LAN Antennas 5-Band Wireless WAN Antennas (enabled with WWAN option)

Page 1

QuickSpecs

Overview

Integrated Smart Card Reader

MultiBay II Drive with Easy Release

Optical Drive Button

USB 2.0 Port

RJ-45 Port (NIC)

HP Compaq nc6400 Notebook PC

RJ-11 Port (Modem)

VGA/External Monitor Port

S-Video TV Out

Power Connector

10.

Kensington Lock Slot

At A Glance

Genuine Windows Vista Business 32, Genuine Windows Vista Home Basic 32, Genuine Windows XP Professional, Genuine Windows XP Home Edition, or FreeDOS Sleek light-weight design starting at under 4.4 lb (2.0 kg) and 1.1 inch (29.2 mm) thin at front

14.1-inch wide screen display Intel® Core™ 2 Duo processors, Intel Core Duo processors, or Intel Core Solo processor Mobile Intel 945GM Express Chipset or Mobil Intel 945PM Express Chipset Up to 4GB* of 533- or 667-MHz DDR2 SDRAM, dual channel memory support ATI Mobility Radeon X1300 or Intel Graphics Media Accelerator 950 Up to 100-GB 7200 rpm, user-removable hard drive Optional integrated HP ev2200 1xEV-DO or HP hs2300 HSDPA Broadband Wireless module (select countries only) Optional integrated 802.11 a/b/g or 802.11 b/g wireless LAN module and Bluetooth® Support for optional Intel Centrino™ Duo mobile technology Protected by three-year standard parts and labor warranty – certain restrictions and exclusions apply

* Above 3-GB, all memory may not be available due to system resource requirements.

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 2

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

Processors

Operating System

Intel Core 2 Duo Processor T7600 (2.33-GHz, 667-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7400 (2.16-GHz, 667-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T7200 (2.0-GHz, 667-MHz FSB, 4-MB L2 cache)*

Intel Core 2 Duo Processor T5600 (1.83-GHz, 667-MHz FSB, 2-MB L2 cache)*

Intel Core 2 Duo Processor T5500 (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)*

Intel Core Duo Processor T2600* (2.16-GHz, 667-MHz FSB, 2-MB L2 cache)

Intel Core Duo Processor T2500* (2.00-GHz, 667-MHz FSB, 2-MB L2 cache)

Intel Core Duo Processor T2400* (1.83-GHz, 667-MHz FSB, 2-MB L2 cache)

Intel Core Duo Processor T2300* (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)

Intel Core Duo processor T2300E* (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)

Intel Core Solo Processor T1300* (1.66-GHz, 667-MHz FSB, 2-MB L2 cache)

* Intel's numbering is not a measurement of higher performance.

NOTE:

speeds n battery optimization mode.

Preinstalled

Supported

(select drivers available on

http://www.hp.com

Certified

* Certain Windows Vista product features require advanced or additional hardware. See

http://www.microsoft.com/windowsvista/getready/capable.mspx

Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit

Processor speed denotes maximum performance mode; processors will run at lower

Genuine Windows Vista Business 32* Genuine Windows Vista Home Basic 32* Genuine Windows XP Professional SP2 Genuine Windows XP Home Edition SP2 FreeDOS

Genuine Windows Vista Business 64*† Genuine Windows Vista Enterprise 32/64*†

)

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx

Genuine Windows 2000

† 64-bit versions for Intel Core 2 Duo models only

SUSE Linux Enterprise Desktop 10

for details. Windows Vista Upgrade

http://www.windowsvista.com/upgradeadvisor

and

Chipset

Mobile Intel 945PM Express Chipset with 667-MHz front side bus (models with discrete graphics) or Mobile Intel 945GM Express Chipset with 667-MHz front side bus (models with integrated graphics)

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 3

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

Graphics

Display

For discrete graphics models with 256MB of system memory: ATI Mobility Radeon X1300 128MB HyperMemory* Microsoft DirectX 9 capable

For discrete graphics models with 512MB of system memory: ATI Mobility Radeon X1300 256MB HyperMemory** Microsoft DirectX 9 capable

For discrete graphics models with 1024MB or more of system memory: ATI Mobility Radeon X1300 512MB HyperMemory** Microsoft DirectX 9 capable

For integrated graphics models: Intel Graphics Media Accelerator 950 with up to 224MB shared system memory, depending on model Microsoft DirectX 9 capable

* Indicates dedicated video memory and shared system memory. 64MB dedicated video memory. ** Indicates dedicated video memory and shared system memory. Either 64MB or 128MB dedicated video memory, depending on model.

Internal

External

14.1-inch WXGA (1280 x 800 resolution and 16 M colors)

14.1-inch WXGA+ (1440 x 900 resolution and 16 M colors) Ambient Light Sensor

Up to 32-bit per pixel color depth

VGA

port supports resolutions up to 2048 x 1536 at 75 Hz, and lower

resolutions at up to 100 Hz

DVI

port in optional HP Docking Station (sold separately) supports resolutions up to 1600 x 1200 at both full and reduced blanking, and 1920 x 1200 at reduced blanking

NOTE:

Resolutions are dependent upon monitor capability, and

resolution and color depth settings.

Memory

Communications

Standard

Maximum

Dual-channel

NOTE:

recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. Above 3-GB, all memory may not be available due to system resource requirements.

Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)*

56K V.92 modem** with digital line guard

* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

** Designed for downloads from 56K modem compliant sources. Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.

Due to the non-industry standard nature of some third-party memory modules, we

256-MB, 512-MB, 1024-MB or 2048-MB 533-MHz or 667-MHz DDR2 SDRAM; two SODIMM slots supporting dual channel memory

Upgradeable to 4096-MB maximum (2048-MB SODIMM in slots 1 and

Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 4

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

Wireless Devices

Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry standards. Integrated Bluetooth is also an option (factory configurable only) and can be combined with any of the supported wireless LAN and wireless WAN options.

HP ev2200 1xEV-DO Broadband Wireless Module*

HP hs2300 HSDPA Broadband Wireless Module*

All integrated wireless LAN options

Intel PRO/Wireless 3945ABG Network Connection

Intel PRO/Wireless 3945BG Network Connection

Broadcom 4311AG WiFi Adapter

Broadcom 4311BG WiFi Adapter

HP Integrated Module with Bluetooth 2.0 Wireless Technology

* Broadband Wireless Module (WWAN) requires Microsoft Windows XP Professional and is available in select countries as a standard feature or as an option to be added later.

Integrated dual band 800-MHz (cellular) and 1900-MHz (PCS) WWAN module connects to the Verizon Wireless BroadbandAccess and NationalAccess networks (US only) Supports CDMA 1xEV-DO, 1xRTT connections

NOTE:

details, go to

Upgradeable design and two 800/900/1800/1900/2100-MHz antennas integrated in the top of the display panel support current and future WWAN technologies

Integrated WWAN module that provides connection to GSM, GPRS, EDGE, UMTS, and HSDPA mobile networks in many countries. Currently supported networks are the Cingular network in the U.S. and Vodafone networks in Australia, France, Italy, Germany, Netherlands, New Zealand, Spain, and UK, and roaming on Vodafone and partner networks in more than 60 countries.

NOTE:

required. Upgradeable design and two 800/900/1800/1900/2100-MHz antennas integrated in the top of the display panel support current and future WWAN technologies.

Wi-Fi certified Cisco Compatible Extensions support (Version 3.0) Wired Equivalent Privacy (WEP) support up to 128-bit keys Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAPGTC, PEAP-MSCHAPv2, and LEAP Advanced Encryption Standard (AES) support WiFi certified for WPA2, WMM Dual antennas integrated in the display enclosure

Intel Centrino mobile technology Integrated support for 802.11a, b and g Up to 54-mbps data rate

Intel Centrino mobile technology Integrated support for 802.11 b and g Up to 54-mbps data rate

Integrated support for 802.11a, b and g Up to 54-mbps data rate

Integrated support for 802.11 b and g Up to 54-mbps data rate

Bluetooth Specification v2.0 compliant Works with a wide range of Bluetooth devices

Separately purchased Verizon Wireless service is required. For

http://www.hp.com/go/broadbandwireless

Separately purchased mobile network operator service is

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 5

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

Keyboard

One-Touch Productivity Buttons

Pointing Device

Expansion Card Slots

The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. US and International key layouts are available. Other features include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and other features, 19-mm x 19-mm key pitch (center-to-center spacing), 2.5-mm stroke, comfort-dished keycaps, and bright key legends for improved visibility in low light conditions.

Provide one-touch access to the following features: HP Info Center, Wireless On/Off, Presentation Mode, Volume Up, Volume Down, and Volume Mute

Dual pointing devices: Touchpad with scroll zone, two soft-touch buttons and Pointstick, two soft-touch buttons

One Type I/II PC Card slot

Integrated Smart Card Reader

Supports 32-bit CardBus and 16-bit PC Cards

Compatible with ISO 7816 compliant Smart Cards PC/SC interface support

Media Slots

Storage

Secure Digital slot

Hard Drives

NOTE:

cycles. Up to 8 GB is reserved for the system recovery software.

HP Mobile Data Protection System 3D

Optical Drives

These hard drives are customer removable and will withstand multiple insertion/removal

Supports SD (Secure Digital), MMC (MultiMedia Card)

60-, 80-, 100-GB 7200 rpm SMART SATA 40-, 60-, 80-, 100-GB 5400 rpm SMART SATA

Hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive. Uses three-axis digital motion detection with intelligent sensitivity to help protect the hard drive during normal use from shock and vibration.

MultiBay II (9.5-mm)

DVD-ROM MultiBay II Drive DVD/CD-RW Combo MultiBay II Drive DVD+/-RW SuperMulti MultiBay II Drive with Double Layer

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 6

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

Interfaces

Audio

PC Card Slot

Smart Card Reader

External Monitor

External Microphone

Headphone/Line out

Power Connector

RJ-11

(Modem)

RJ-45

(NIC)

Fast Infrared Port

S-Video TV Out

USB 2.0

Docking Connector

Accessory Battery Connector

LED Status Indicators

PremierSound audio/speaker subsystem ADI1981HD High Definition CODEC Integrated 16-bit Sound Blaster Pro compatible audio 24-bit DAC Integrated stereo speakers Integrated microphone External volume up, volume down, and mute buttons Stereo headphone/line out Stereo microphone in

One Type I/II

One

One – VGA

One

One (4-Mb/s support) IrDA 4-MB compliant; IR performance will vary depending on performance of IR peripherals and application used.

One (Support for NTSC/PAL)

Three

One

Eleven

Software

Preinstalled Software with Windows Vista or Windows XP

NOTE:

running the Software Setup utility.

Software marked with an asterisk is loaded on the hard drive and can be installed by

Adobe Acrobat Reader* HP Backup and Recovery Manager HP Help and Support Center* HP Mobile Print Driver* (Windows XP models) HP ProtectTools Security Manager*: BIOS Configuration for HP ProtectTools Embedded Security for HP ProtectTools Credential Manager for HP ProtectTools HP Quick Launch Buttons HP Wireless Assistant HP OpenView Radia Management Solutions* Sonic Digital Media Plus* (Windows XP models): RecordNow! (for optional DVD+/-RW and DVD/CDRW drives) MyDVD (DVD Authoring for optional DVD+/-RW drives) Roxio Creator 9 (Window Vista models with optional DVD+/-RW or DVD/CDRW drives) Synaptics Touchpad Driver Symantec Norton Internet Security* with complimentary 60-day live update Intervideo WinDVD* – DVD Player (for optional DVD+/-RW, DVD/CDRW and DVD drives)

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 7

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

HP Backup and Recovery Manager

HP OpenView Radia Management Solutions

HP Client Management Interface

Additional software available from the Web

Each unit is shipped with HP Backup and Recovery Manager. HP Backup and Recovery Manager can provide data and system file protection for HP business PCs to enable fast recovery if the system becomes corrupted or if important information is accidentally deleted. HP Backup and Recovery Manager can perform scheduled or manual backups of the entire drive or individual files and folders. Up to 8 GB of the hard drive is reserved for the system recovery software. HP Backup and Recovery Manager can also create software recovery CDs or DVDs (requires optional hardware).

HP OpenView Radia Management Solutions automate the management of software such as operating systems, software, software updates, content, and configuration settings to ensure that each computer is maintained in the correct configuration.

HP Client Management Interface is based on industry standards that include Microsoft Windows Management Interface (MS WMI), Web Based Enterprise Management (WBEM), System Management BIOS (SMBIOS), and Advanced Configuration and Power Interface (ACPI). HP CMI is a foundation technology utilized in HP Client Management Solutions.

HP Client Manager Software Smart Card Security for HP ProtectTools Device Access Manager for HP ProtectTools

SMBIOS Version 2.4

HP ProtectTools Security Manager

System Management BIOS, previously known as DMI BIOS, is used to store system management information.

HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP ProtectTools Security Manager is an extensible client security console that delivers enhanced security capabilities through add-on software modules. Modules currently available are:

- Smart Card Security for HP ProtectTools

- BIOS Configuration for HP ProtectTools

- Credential Manager for HP ProtectTools

- Embedded Security for HP ProtectTools

- Device Access Manager for HP ProtectTools

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 8

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

Security

Power Supply

*Fast Charge Technology recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge Technology does not apply to 12-cell Ultra Capacity batteries.

Standard Features

Optional Features

NOTE:

For more information on HP security solutions refer to

External Smart AC Adapter (65-watt standard with integrated graphics; 90-watt standard with discrete graphics), 6-foot (1.8-meter) power cord included. Total length including External AC adapter is 12 feet (3.66 meter). HP Fast Charge Technology*

TPM module disabled where use is restricted by law; for example, Russia.

HP ProtectTools Security Manager HP Biometric Fingerprint Sensor Integrated Smart Card Reader TPM 1.2 Embedded Security Chip* Configuration Control Hardware Memory Change Alert Ownership Tag Setup Password Power-On Password DriveLock TPM Enhanced DriveLock* HP Disk Sanitizer Kensington Lock Slot Support for Computrace / LoJack for Laptops (must be purchased separately)

HP Privacy Filter

Narrows viewing area so that screen data is visible only to persons directly in front of the monitor

http://www.hp.com/go/security

Battery

Battery Life

System Standby Time

Primary Battery

Optional HP 8-Cell Extended Life Battery

Optional HP 12-Cell Ultra-Capacity Battery

Primary Battery

Primary Battery and optional HP 8-Cell Extended Life Battery

Primary Battery and optional HP 12-Cell Ultra-Capacity Battery

NOTE:

Battery life will vary depending on the product configuration, product model, applications loaded on the product, power management settings of the product, and the product features used by the customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.

Up to 1 week

55Wh 6-cell Lithium-Ion 37Wh 4-cell Lithium-Ion (available only on integrated graphics models)

52Wh 8-cell high capacity Lithium-Ion

95Wh 12-cell high capacity Lithium-Ion

6-cell Primary with integrated graphics

Up to 6 hours Up to 4 hours

Up to 12 hours and 15 minutes

Up to 16 hours and 15 minutes

6-cell Primary with discrete graphics

and 30 minutes

Up to 8 hours and 30 minutes

Up to 13 hours Up to 13 hours

4-cell Primary with integrated graphics

Up to 3 hours and 30 minutes

Up to 6 hours and 45 minutes

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 9

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

Power Conservation

Docking

Service and Support

Supports enhanced Intel SpeedStep technology with Intel Core Duo and Intel Core Solo processors (allows Battery Optimized Mode, Maximum Performance Mode, or Automatic mode)

Intel Display Power Saving technology (models with integrated graphics) ATI PowerPlay technology (models with discrete graphics)

Hibernation

Standby

ACPI compliance

HP Docking Station HP Advanced Docking Station HP External MultiBay II HP Adjustable Notebook Stand

HP's shared docking solutions provide simple and convenient port replication and cable management. Features include Gigabit NIC pass through, modem pass through, legacy parallel and serial ports, S-video TV out, USB 2.0 ports, integrated security mechanism*, integrated MultiBay II and ExpressCard** slots. These docking solutions are compatible across multiple Business Notebook platforms enabling a lower total cost of ownership.

* HP/Kensington Cable Lock required (purchased separately) ** HP Advanced Docking Station only

HP Services includes a three-year standard parts and labor warranty, pick-up or carry-in, and tollfree 7 x 24 hardware technical phone support. On-site service and warranty upgrades are also available.

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

Select Model(s)

nc6400

RM100AW#XXX (may vary based on local regulatory requirements)

Processor

Operating System

System Memory

Hard Drive

Display

Graphics

Audio

Communications

Integrated Wireless

Integrated Security

Pointing Device

MultiBay II Drive

Intel Core 2 Duo Processor T5600*

Genuine Windows XP Professional

1024 MB 667-MHz DDR2 (1 DIMM)

80-GB 5400 rpm SATA

14.1-inch WXGA

Intel Graphics Media Accelerator 950

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone

56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)

Intel PRO/Wireless 3945ABG Network Connection (may vary based on local regulatory requirements) Bluetooth 2.0

TPM 1.2 Embedded Security Chip** HP Biometric Fingerprint Sensor Smart Card Reader

Dual pointing devices (both Pointstick and Touchpad)

DVD/CD-RW Combo MultiBay II Drive

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 10

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

nc6400

RM106AW#XXX (may vary based on local regulatory requirements)

Battery

Power

Warranty

* Intel's numbering system is not a measurement of higher performance. ** TPM module disabled where use is restricted by law; for example, Russia.

Processor

Operating System

System Memory

Hard Drive

Display

Graphics

Audio

Communications

Integrated Wireless

Integrated Security

Pointing Device

MultiBay II Drive

Battery

Power

Warranty

* Intel's numbering system is not a measurement of higher performance. ** 256MB HyperMemory is a total of 64MB dedicated video memory and 192MB shared system memory. *** TPM module disabled where use is restricted by law; for example, Russia.

6-cell (55 WHr) Lithium-Ion

External 65W adapter

3/3/0

Intel Core 2 Duo Processor T7200*

Genuine Windows XP Professional

1024 MB 667-MHz DDR2 (1 DIMM)

80-GB 5400 rpm SATA

14.1-inch WXGA

ATI Mobility Radeon 256MB HyperMemory**

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone

56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)

Intel PRO/Wireless 3945ABG Network Connection (may vary based on local regulatory requirements) Bluetooth 2.0

TPM 1.2 Embedded Security Chip*** HP Biometric Fingerprint Sensor Smart Card Reader

Dual pointing devices (both Pointstick and Touchpad)

DVD/CD-RW Combo MultiBay II Drive

6-cell (55 WHr) Lithium-Ion

External 90W adapter

3/3/0

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 11

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

nc6400

RC454AW#XXX (may vary based on local regulatory requirements)

Processor

Operating System

System Memory

Hard Drive

Display

Graphics

Audio

Communications

Integrated Wireless

Integrated Security

Pointing Device

MultiBay II Drive

Battery

Power

Warranty

* Intel's numbering system is not a measurement of higher performance. ** TPM module disabled where use is restricted by law; for example, Russia.

Intel Core Duo Processor T2400*

Genuine Windows XP Professional

1024 MB 667-MHz DDR2 (1 DIMM)

60-GB 5400 rpm SATA

14.1-inch WXGA

Intel Graphics Media Accelerator 950

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone

56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)

Intel PRO/Wireless 3945ABG Network Connection (may vary based on local regulatory requirements) Bluetooth 2.0

TPM 1.2 Embedded Security Chip** HP Biometric Fingerprint Sensor Smart Card Reader

Dual pointing devices (both Pointstick and Touchpad)

DVD/CD-RW Combo MultiBay II Drive

6-cell (55 WHr) Lithium-Ion

External 65W adapter

3/3/0

nc6400

RA252AW#XXX (may vary based on local regulatory requirements)

Processor

Operating System

System Memory

Hard Drive

Display

Graphics

Audio

Communications

Integrated Wireless

Integrated Security

Pointing Device

MultiBay II Drive

Battery

Power

Warranty

Intel Core Duo Processor T2400*

Genuine Windows XP Professional

512 MB 667-MHz DDR2 (1 DIMM)

60-GB 5400 rpm SATA

14.1-inch WXGA

Intel Graphics Media Accelerator 950

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone

56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)

Intel PRO/Wireless 3945ABG Network Connection (may vary based on local regulatory requirements) Bluetooth 2.0

TPM 1.2 Embedded Security Chip** HP Biometric Fingerprint Sensor Smart Card Reader

Dual pointing devices (both Pointstick and Touchpad)

DVD/CD-RW Combo MultiBay II Drive

6-cell (55 WHr) Lithium-Ion

External 65W adapter

3/3/0

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 12

QuickSpecs

Standard Features

HP Compaq nc6400 Notebook PC

nc6400

RA253AW#XXX (may vary based on local regulatory requirements)

* Intel's numbering system is not a measurement of higher performance. ** TPM module disabled where use is restricted by law; for example, Russia.

Processor

Operating System

System Memory

Hard Drive

Display

Graphics

Audio

Communications

Integrated Wireless

Integrated Security

Pointing Device

MultiBay II Drive

Battery

Power

Warranty

Intel Core Duo Processor T2500*

Genuine Windows XP Professional

512 MB 667-MHz DDR2 (1 DIMM)

60-GB 5400 rpm SATA

14.1-inch WXGA

ATI Mobility Radeon 256MB HyperMemory**

ADI High Definition CODEC line out/headphone and microphone jacks integrated microphone

56K V.92 modem Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller (10/100/1000 NIC)

Intel PRO/Wireless 3945ABG Network Connection (may vary based on local regulatory requirements) Bluetooth 2.0

TPM 1.2 Embedded Security Chip*** HP Biometric Fingerprint Sensor Smart Card Reader

Dual pointing devices (both Pointstick and Touchpad)

DVD/CD-RW Combo MultiBay II Drive

6-cell (55 WHr) Lithium-Ion

External 90W adapter

3/3/0

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 13

QuickSpecs

Options

HP Compaq nc6400 Notebook PC

Memory

MultiBay II Storage

(9.5-mm)

Other Storage

Communications

256-MB 533-MHz DDR2 SDRAM

512-MB 533-MHz DDR2 SDRAM

1024-MB 533-MHz DDR2 SDRAM

512-MB 667-MHz DDR2 SDRAM

1024-MB 667-MHz DDR2 SDRAM

2048-MB 667-MHz DDR2 SDRAM

DVD-ROM MultiBay II Drive

Combo DVD/CD-RW MultiBay II Drive

DVD+/-RW SuperMulti with Double Layer MultiBay II Drive

80-GB 5400 rpm MultiBay II Hard Drive

80-GB 5400 rpm Primary SATA Hard Drive

HP USB Digital Drive + 256-MB Secure Digital Card

HP USB Diskette Drive

Intel PRO/Wireless 3945ABG 802.11 a/b/g WLAN option kit

HP ev2200 1xEV-DO Broadband Wireless Module (Verizon software)

HP hs2300 HSDPA Broadband Wireless Module (Vodaphone software)*

HP hs2300 HSDPA Broadband Wireless Module (Cingular software)

*NOTE

: SIM card comes with Vodaphone service; not provided with HP module.

PE830A

PE831A

PE832A

EM993AA

EM994AA

EM995AA

PA849A

PA850A

PA851A

PH357A

ET354AA

DL702AA

DC361B

EX150AA#xxx

EX149AA#ABA

RN005AA#AC3

RN052AA#ABA

Expansion Solutions

Power

HP Docking Station

HP Advanced Docking Station

HP 3-in-1 NAS Docking Station

HP Monitor Stand

HP Adjustable Notebook Stand

HP External MultiBay II (9.5-mm)

HP 4-port USB 2.0 Hub

HP 2-bay Battery Charging Station

HP 10-bay Battery Charging Station

Battery Adapter kit #1

65W Smart AC Adapter

90W Smart AC Adapter

90W Smart Auto Adapter

65W Air/Auto/AC Combo Adapter

Primary 6-cell Battery Pack

HP 8-cell Extended Life Battery

HP 12-cell Ultra-Capacity Battery

EN488AA#xxx

EN489AA#xxx

EM537AA#xxx

PA507A

PA508A

PA509A#xxx

DG954A

DT533A#xxx

DT534A#ABA

PK402A

ED494AA#xxx

ED495AA#xxx

ED493AA

ED993AA#xxx

PB994A

PB993A

EJ092AA

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 14

QuickSpecs

Options

HP Compaq nc6400 Notebook PC

Carrying Cases

Security

Input/Output Devices

HP Entry Value Case

HP Top Load Nylon

HP Executive Leather case

HP Sport Backpack

HP PCMCIA Smart Card Reader

HP/Kensington Cable Lock

Privacy Film for 6400 Series

USB/PS2 Keyboard

USB/PS2 Optical Mouse

HP USB Optical Travel Mouse

DL617A

DC915A

PA847A

DG102A

DC350B

PC766A

ES216AA

DC852A#xxx

DC369A

F2100A

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 15

QuickSpecs

Memory

Support for up to 4096 MB* of 533- or 667-MHz DDR2 SDRAM Two DIMM slots DIMM sizes supported: 256 MB, 512 MB, 1024 MB, and 2048 MB

Standard Memory

256 MB (256 MB x 1) 512 MB (512 MB x 1 or 256 MB x 2) 1024 MB (1024 MB x 1 or 512 MB x 2) 2048 MB (1024 MB x 2)

HP Compaq nc6400 Notebook PC

Optional Memory Upgrades

Support for up to 4096 MB* of memory is available (with the installation of optional DDR2 SDRAM memory kits). Both memory slots are user accessible. Please refer to the Hardware and Software Guide for installation procedures. Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.

Up to

768 MB 512 MB 256 MB 1024 MB 1024 MB 1024 MB 1280 MB 1024 MB 1536 MB 1024 MB 2048 MB 1024 MB 1024 MB

4096 MB*

Memory Upgrades

* Above 3-GB, all memory may not be available due to system resource requirements.

NOTE:

standard nature of some third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.

256-MB 533-MHz DDR2 SDRAM

512-MB 533-MHz DDR2 SDRAM

1024-MB 533-MHz DDR2 SDRAM

512-MB 667-MHz DDR2 SDRAM

1024-MB 667-MHz DDR2 SDRAM

2048-MB 667-MHz DDR2 SDRAM

This chart does not represent all possible memory configurations. Due to the non-industry

Slot 1 Slot 2

512 MB 512 MB

2048 MB 2048 MB

Empty

256 MB 512 MB

PE830A

PE831A

PE832A

EM993AA

EM994AA

EM995AA

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 16

QuickSpecs

Storage

Removable Media Drive Support

HP Compaq nc6400 Notebook PC

DVD+/-RW SuperMulti MultiBay II Drive with Double Layer*

DVD/CD-RW Combo MultiBay II Drive*

DVD-ROM MultiBay II Drive*

Quantity Supported

One

Drive Bay

MultiBay II

Hard Drive Support

Primary Hard Drives

100-GB 7200 rpm SMART SATA Hard Drive

80-GB 7200 rpm SMART SATA Hard Drive

60-GB 7200 rpm SMART SATA Hard Drive

100-GB 5400 rpm SMART SATA Hard Drive

80-GB 5400 rpm SMART SATA Hard Drive

60-GB 5400 rpm SMART SATA Hard Drive

40-GB 5400 rpm SMART SATA Hard Drive

* MultiBay II drives supported in the internal MultiBay II are also supported in the optional HP External MultiBay II and the HP Advanced Docking Station.

Quantity Supported

One

Up to two

One

Drive Bay

Dedicated hard drive bay

Dedicated hard drive bay and/or MultiBay II

Dedicated hard drive bay

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 17

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

System Unit

Dimensions

Weight

NOTE:

includes integrated graphics, battery, 60-GB hard drive, 512-MB memory, 802.11 wireless communications module, and TPM Embedded Security Chip. Weight varies by configuration and components.

Stand-Alone Power Requirements

Temperature

Relative Humidity

Shock

Random Vibration

Altitude

(unpressurized)

Industry Standard Certifications

(HxWxD)

Height varies depending upon where on the notebook the measurement is made. Weight

1.1 (at front) x 13.0 x 9.4 in (29.2 (at front) x 330 x 239 mm)

with MultiBay II weight saver and 4-cell battery

with MultiBay II weight saver and 6-cell battery

with MultiBay II DVD/CDRW Combo Drive and 6-cell battery

Normal Operating Voltage

Average Operating Power

Max Operating Power

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

CSA

FCC Compliance

Energy Star Compliant

ICES

Australia / NZ A-Tick Compliance

CCC

Japan VCCI Compliance

MIC

BSMI

CE Marking Compliance

BNCI or BELUS

CIT

GOST

4.4 lb (2.0 kg)

4.6 lb (2.1 kg)

5.0 lb (2.27 kg)

18.5 V

22 W (models with integrated graphics) 29 W (models with discrete graphics)

< 65 W (models with integrated graphics) < 90 W (models with discrete graphics)

32° to 95° F (0° to 35° C) (not writing optical)

41° to 95° F (5° to 35° C) (writing optical)

-4° to 140° F (-20° to 60° C)

10% to 90%, non-condensing

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

125 G, 2 ms, half-sine

200 G, 2 ms, half-sine

0.75 grms

1.50 grms

-50 to 10,000 ft (-15.24 to 3,048 m)

-50 to 40,000 ft (-15.24 to 12,192 m)

Yes

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 18

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

HP 90W Smart AC Adapter

discrete graphics)

(models with

Dimensions

Weight

Input

Output

Connector

Environmental Design

EMI and Safety Certifications

Option Kit Contents

Saudi Arabian Compliance (ICCP)

SABS

UKRSERTCOMPUTER

5.24 x 2.28 x 1.1 in (13.3 x 5.8 x 2.9 cm)

0.86 lb (390 g)

100 to 240 VAC

Input Efficiency

Input frequency range

Input AC current

Output power 65W

DC output

Hold-up time

Output current limit

3 pin/grounded, mates with interchangeable cords

Operating temperature

Non-operating (storage) temperature

Altitude

Humidity

Storage Humidity

CE Mark – full compliance with LVD and EMC directives; Worldwide safety standards – IEC950, EN60950, UL1950, Class2, SELV; Agency approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCIB, NOM-1 NYCE; MTBF– over 200,000 hours at 25°C ambient condition.

90W AC Adapter, power cable, warranty booklet

Yes

83% min at 115 VAC

47 to 63 Hz

1.5 A at 90 VAC, 0.75 A at 180 VAC PFC Version

2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC Version

90W

18.5V

5 msec at 115 VAC input

<11A, Over voltage protection- 29V max automatic shutdown

32° to 104° F (0° to 40° C)

-4° to 149° F (-20° to 65° C)

0 to 10,000 ft (0 to 3,048 m)

20% to 80%

10% to 90%

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 19

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

HP 65W Smart AC Adapter

integrated graphics)

(models with

Dimensions

Weight

Input

Output

Connector

Environmental Design

EMI and Safety Certifications

Option Kit Contents

4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)

0.62 lb (280 g)

100 to 240 VAC

Input Efficiency

Input frequency range

Input AC current

Output power 65W

DC output

Hold-up time

Output current limit

3 pin/grounded, mates with interchangeable cords

Operating temperature

Non-operating (storage) temperature

Altitude

Humidity

Storage Humidity

CE Mark – full compliance with LVD and EMC directives; Worldwide safety standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over 200,000 hours at 25°C ambient condition.

65W AC Adapter, power cable, warranty booklet

83% min at 115 VAC

47 to 63 Hz

1.7 A at 90 VAC, 0.85 A at 180 VAC

65W

18.5V

5 msec at 115 VAC input

<11A, Over voltage protection- 29V max automatic shutdown

32° to 104° F (0° to 40° C)

-4° to 149° F (-20° to 65° C)

0 to 10,000 ft (0 to 3,048 m)

20% to 80%

10% to 90%

Optional HP 12-Cell Ultra-Capacity Battery

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Fuel Gauge

(H x W x L)

1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)

1.77 lb (0.803 kg)

12-cell Lithium-Ion

Voltage

Watt-hour Capacity

Amp-hour Capacity

Operating (Charging)

Operating (Discharging)

Non-operating

Smart Adapter

System ON

When pressed, LEDs light indicating level of charge remaining on battery

14.8V

95Wh

6.45Ah

32° to 113° F (0° to 45° C)

14° to 140° F (–10° to 60° C)

–4° to 140° F (–20° to 60° C)

3 to 4 hours

4 to 5 hours (depending on system power consumption)

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 20

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Optional HP 8-Cell Extended Life Battery

55Wh Primary 6-Cell Battery

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Fuel Gauge

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

(H x W x L)

1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)

1.00 lb (0.455 kg)

8-cell Lithium-Ion

Voltage

Watt-hour Capacity

Amp-hour Capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF mode or Standby

System ON

HP Fast Charge Technology

When pressed, LEDs light indicating level of charge remaining on battery

0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)

0.737 lb (0.335 kg)

6-cell Lithium-Ion

Voltage

Watt-hour Capacity

Amp-hour Capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF Mode or Standby

System ON

HP Fast Charge Technology

14.4V

52Wh

3.6Ah

32° to 113° F (0° to 45° C)

14° to 140° F (–10° to 60° C)

–4° to 140° F (–20° to 60° C)

3 hours

3 to 5 hours (depending on system power consumption)

Charges the battery up to 90% within 90 minutes when system is OFF

10.8V

55Wh

5.1Ah

32° to 113° F (0° to 45° C)

14° to 140° F (–10° to 60° C)

–4° to 140° F (–20° to 60° C)

2.5 hours

3 to 5 hours (depending on system power consumption)

Charges the battery up to 90% within 90 minutes when system is OFF

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 21

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

37Wh Primary 4-Cell Battery

14.1-Inch Color TFT WXGA Display

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Active Area

Diagonal Size

Surface Treatment

Number of Colors

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

(H x W x L)

(W x H)

0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)

0.55 lb (0.249 kg)

4-cell Lithium-Ion

Voltage

Watt-hour Capacity

Amp-hour Capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF mode or Standby

System ON

HP Fast Charge Technology

11.9 x 7.5 in (30.3 x 19.0 cm)

14.1 in (35.7 cm)

Anti-glare

Up to 16M

300:1 (typical)

60 Hz

200 nit (typical)

Pitch

Format

Configuration

CCFL

107

±45° Horizontal, ±25° Vertical (typical)

14.4V

37Wh

2.55Ah

32° to 113° F (0° to 45° C)

14° to 140° F (–10° to 60° C)

–4° to 140° F (–20° to 60° C)

2.5 hours

3 to 5 hours (depending on system power consumption)

Charges the battery up to 90% within 90 minutes when system is OFF (does not apply to 12-cell Ultra-Capacity batteries)

0.237 mm

1280x800

RGB Stripe

14.1-Inch Color TFT WXGA+ Display

Active Area

Diagonal Size

Surface Treatment

Number of Colors

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

(W x H)

11.9 x 7.5 in (30.3 x 19.0 cm)

14.1 in (35.7 cm)

Anti-glare

Up to 16M

300:1 (typical)

60 Hz

200 nit (typical)

Pitch

Format

Configuration

CCFL

121

±45° Horizontal, ±25° Vertical (typical)

0.210 mm

1440 x 900

RGB Stripe

Page 22

QuickSpecs

Technical Specifications

Hard Drives

HP Compaq nc6400 Notebook PC

100-GB 7200 rpm SATA

80-GB 7200 rpm SATA

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

0.25 lb (113 g)

100 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-7 / SATA 1.0a

Synchronous (maximum)

Single Track

Average

Maximum

7200 rpm

195,371,568

41° to 140° F (5° to 60° C) [case temp]

ATA Security

0.25 lb (113 g)

80 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-7 / SATA 1.0a

Synchronous (maximum)

Single Track

Average

Maximum

7200 rpm

156,301,488

41° to 140° F (5° to 60° C) [case temp]

ATA Security

100 MB/s (Drive Capability)

1 ms

10 ms

18 ms

100 MB/s (Drive Capability)

1 ms

10 ms

18 ms

60-GB 7200 rpm SATA

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

0.25 lb (113 g)

60 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-7 / SATA 1.0a

Synchronous (maximum)

Single Track

Average

Maximum

7200 rpm

117,231,408

41° to 140° F (5° to 60° C) [case temp]

ATA Security

100 MB/s (Drive Capability)

1 ms

10 ms

18 ms

Page 23

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

100-GB 5400 rpm SATA

80-GB 5400 rpm SATA

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

0.22 lb (101 g)

100 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-7 / SATA 1.0a

Synchronous (maximum)

Single Track

Average

Maximum

5400 rpm

195,371,568

41° to 140° F (5° to 60° C) [case temp]

ATA Security

0.22 lb (101 g)

80 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-7 / SATA 1.0a

Synchronous (maximum)

Single Track

Average

Maximum

5400 rpm

156,301,488

41° to 140° F (5° to 60° C) [case temp]

ATA Security

100 MB/s (Drive Capability)

3 ms

13 ms

24 ms

100 MB/s (Drive Capability)

3 ms

13 ms

24 ms

60-GB 5400 rpm SATA

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

0.22 lb (101 g)

60 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-7 / SATA 1.0a

Synchronous (maximum)

Single Track

Average

Maximum

5400 rpm

117,231,408

41° to 140° F (5° to 60° C) [case temp]

ATA Security

100 MB/s (Drive Capability)

3 ms

13 ms

24 ms

Page 24

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

40-GB 5400 rpm SATA

Removable Storage Drives – MultiBay II

DVD-ROM MultiBay II Drive

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

Dimensions

Weight

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Supported Media

Max Media Capacity

(read)

Transport

(read)

(write)

0.22 lb (101 g)

40 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-7 / SATA 1.0a

Synchronous (maximum)

Single Track

Average

Maximum

5400 rpm

78,165,360

41° to 140° F (5° to 60° C) [case temp]

ATA Security

0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)

0.45 lb (205 g)

Random

24X-CD-ROM

8X-DVD

Multiword DMA Mode 2

EIDE

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW

None

8.5 GB

Tray Loading

100 MB/s (Drive Capability)

3 ms

13 ms

24 ms

<120 ms CD

<200 ms DVD

3,600 KB/s

10,800 KB/s

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 25

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

DVD/CD-RW Combo MultiBay II Drive

Dimensions

Weight

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Supported Media

Max Media Capacity

(read)

Max Media Capacity

(write)

Transport

(read)

(write)

0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)

0.45 lb (205 g)

Random

24X CD-ROM

8X DVD

24X CD-R

24X CD-RW

Multiword DMA Mode 2

EIDE

CD-R, CD-RW

8.5 GB

700 MB

Tray loading

<120 ms CD

<155 ms DVD

3,600 KB/s

10,800 KB/s

3,600 KB/s

DVD+/-RW SuperMulti MultiBay II Drive with Double Layer

Dimensions

Weight

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Supported Media

Max Media Capacity

(read)

Max Media Capacity

(write)

Transport

(read)

(write)

0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)

0.45 lb (205 g)

Random

24X CD-ROM

8X DVD

24X CD-R

10X CD-RW

4X DVD+R

2.4X DVD+RW

4X DVD-R

2X DVD-RW

2X DVD-RAM

Multiword DMA Mode 2

EIDE

CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM

8.5 GB

Tray Loading

<150 ms CD

<125 ms DVD

3,600 KB/s

10,800 KB/s

3,600 KB/s

1,500 KB/s

5,400 KB/s

3,240 KB/s

5,400 KB/s

2,700 KB/s

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 26

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

80-GB 5400 rpm MultiBay II Hard Drive

HP Biometric Fingerprint Sensor

MultiBay II Drive Adapter

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

Mobile Voltage Operation

Operating Temperature

Current Consumption @ 3.3V

High-Rate Image Capture

ESD Resistance

Detection Matrix

Dimensions (H x W x D)

Weight

0.22 lb (101 g)

80 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-6

Synchronous (maximum)

Single Track

Average

Maximum

5400 rpm

156,301,488

41° to 131° F (5° to 55° C)

ATA Security

3.0V–3.6V Single Supply

32° – 158°F (0° – 70°C)

Less than 70 mA peak imaging and scrolling Less than 25 mA hardware finger detection Advanced Power Management

Up to 240 image frames /sec

IEC 61000-4-2 Level 4 (±15KV)

192 x 16 Pixels

9.7 mm x 0.81 mm 500 ppi High-Resolution Images

0.37 x 5.51 x 5.04 in (0.95 x 14.0 x 12.8 cm)

0.16 lb (72 g)

100 MB/s (Drive Capability)

3 ms

13 ms

24 ms

PremierSound Audio

Hardware

Implementation

Volume Controls

Full Duplex

Sound Blaster Pro compatible

Microphone Jack

Headphone/Line Out Jack

Integrated Microphone

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

ADI1981HD High Definition CODEC

Up, down, and mute buttons

Yes

Stereo or mono

Stereo

Yes

Page 27

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Audio Output Quality

Internal Speakers

Communications

Integrated Broadcom NetXtreme Gigabit Ethernet PCI Express Controller

(BCM5753M)

Frequency Response

Signal to Noise Ratio

Total Harmonic Distortion

Noise Floor

Play/Record Sampling Rate

(s)

DAC

ADC

Power Rating

Impedance

Ethernet Features

Power Management

Performance Features

Manageability

Interface

NIC Device Driver Name

Drivers Available

20 Hz – 20 kHz

>85 dB

0.01%

-110 dB

8 kHz – 48kHz

16, 20 or 24-bit

16 or 20-bit

2 Watts

4 Ohms

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-

14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3z and 802.3ab; IEEE

802.3 clauses 34-42) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s IEEE 802.1p QoS (Quality of Service) Support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)

ACPI compliant -- multiple power modes Situation-sensitive features reduce power consumption NIC Battery Saving Mode (enabled by default)

TCP/IP/UDP Checksum Offload (configurable) TCP Segmentation Offload CPU Task Offload Adaptive Interrupts

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Cable Analyzer

PCI Express x1

Broadcom NetXtreme Gigabit Ethernet

Microsoft Windows XP Microsoft Windows 2000

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 28

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

V.92 56K Data/Fax Modem

Form Factor

Power Management Support

Approvals/ Certifications

Data Mode Capabilities

Fax Mode Capabilities

Command Set

MDC 1.5 Daughtercard

APM Revision 1.2, ACPI

UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other Countries

V.92 data

V.8bis

V.80

V44, V.42bis, MNP5 (Compression)

V.42 (LAPM, MNP2-4) (Error Correction)

Optional symbol rates:

2800, 3429 Asymmetric Symbol rates

Synchronous primary channel data signaling rates:

3600, 31200 Automatic rate re-negotiation V.34 V.32bis V.32 V.23 V.22bis V.22 V.21 Bell 212A Bell 103J

TIA/EIA-578-B (Class 1) T.30, T.4 (Group 3) V.17 V.29 V.27ter V.21 Channel 2

V.250 (Partial) TIA-602 Identification: +GMI, +GMM, +GMR Port control: +IPR, +ICF, +IFC, +ILRR Modulation: +MS, +MR, +MA Error control: +ES, +ER, +EB, +ESR, +ETBM Data compression: +DS, +DR V.251

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 29

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

HP ev2200 1xEV-DO Broadband Wireless Module

Band and Power Class

Wireless Protocol Standards

Wireless Parametric Standards

Interoperability

Frequency Band

Data Rates

Mode)

Chipset and Module

Maximum Output Power

Power Consumption

(maximum)

Power Consumption, Sleep Mode

Power Management

Antenna Type

Form Factor

Weight

Dimensions

Width x Thickness)

Voltage, Operating

Temperature, Operating

TIA/EIA/IS-98-D)

Temperature, Nonoperating, 96 hours

(from MIL-STD 202 Method 108)

Humidity, Nonoperating

Configuration Utilities

LED Activity

(Packet

(Length x

(from

0 (North American Cellular) – Class III; 1 (North American PCS) – Class II

CDMA 1x Release 0/A; IS-95A, IS-95B, IS-2000

Meets or exceeds TIA/EIA IS-98-D

CDG 22 (TIA/EIA/IS-95-A) CDG 53(TIA/EIA/IS-95-B) C.S0031 (TIA/EIA/IS-2000) CDG 64 (TIA/EIA/IS-2000) C.S0032 (TIA/EIA/IS-866)

Dual Band: 800 MHz (Cellular) and 1900 MHz (PCS)

IS-856 rates up to 2.4 Mbps IS-2000 data rates up to 307.2 kbps

Qualcomm MSM6500 chipset; Sierra Wireless MC5720 module

24dBm (+/-1)

500mA

1.7mA – 3.5mA

USB selective suspend CDMA slotted mode sleep and dormant modes

High efficiency dual band antennae with spatial diversity, mounted in the display enclosure

PCI-Express MiniCard

0.35 oz (10 g)

2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)

3.3v +/- 10%

-22° to 140° F (-30° to 60° C) (full RF performance)

-22° to 167° F (-30° to 75° C) (reduced RF performance)

-40° to 185° F (-40° to 85° C)

85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

Verizon Wireless VZAccess Manager

LED Off – Radio Off; Solid LED On – Radio On

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 30

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

HP hs2300 HSDPA Broadband Wireless Module

Frequency Bands and Power Class

Wireless Protocol Standards

Wireless Parametric Standards

Additional Standards Compliance

Data Rates

(Packet Mode)

Chipset and Module

Maximum Output Power

Power Consumption

(maximum)

Power Consumption, Sleep Mode

Power Management

Antenna Type

Form Factor

Weight

Dimensions

Width x Thickness)

Voltage, Operating

Temperature, Operating

Temperature, Nonoperating, 96 hours

(from MIL-STD 202 Method 108)

Humidity, Nonoperating

LED Activity

Configuration Utilities

(Length x

850/1900/2100MHz WCDMA Power class 3 (+24dBm) 850MHz GSM/GPRS/EDGE 900MHz GSM/GPRS/EDGE, 1800MHz GSM/GPRS/EDGE 1900MHz GSM/GPRS/EDGE EDGE E2 power GPRS/EDGE Multislot Class 12 GPRS PCS/DCS power class 1 GSM power class 4

GPRS/EDGE: 3GPP R99 GERAN P1 WCDMA Release 5 (R5) High-Speed Downlink Packet Access (HSDPA) 3.6Mbps GSM Phase 2+

Complies with 3GPP specifications

FCC parts 15/22/24, CE, Microsoft WHQL, R&TTE directive 1999/5/EC (health, safety, EMC, spectrum), GCF-CC (Module), European Union Directive 2002/95/EC (restrictions of the use of certain Hazardous Substances (RoHS) in electronic equipment), Infrastructure Interoperability Testing (IOT)

Designed maximum data rate: EDGE 118 kbps UL / 236 kbps DL UMTS 384 kbps UL / 384 kbps DL HSDPA 384 kbps UL / 3.6 Mbps DL

Qualcomm MSM6280 chipset; Sierra Wireless MC8775 module

32 dBm (+/-2) GSM/EDGE GMSK mode

800mA

4 – 8mA

USB Selective Suspend sleep and standby mode

High efficiency 5- band antennae, mounted in the display enclosure

PCI-Express MiniCard

0.35 oz (10 g)

2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)

3.3v +/- 10%

-22° to 140° F (-30° to 60° C) (full RF performance)

-22° to 167° F (-30° to 75° C) (reduced RF performance)

-40° to 185° F (-40° to 85° C)

85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

LED Off – Radio Off; Solid LED On – Radio On

Varies per country and mobile network operator

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 31

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Broadcom 4311BG

802.11b/g WiFi Adapter

Wireless LAN Standards

Interoperability

Frequency Band

Data Rates

Modulation

Security

Sub-channels

Media Access Protocol

Network Architecture Models

Roaming

Output Power

CKK)

Output Power

OFDM; power varies by data rate)

Power Consumption

Power Management

Receiver Sensitivity454 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

Antenna type

Range

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

(for

IEEE 802.11b IEEE 802.11g

Wi-Fi certified Cisco Compatible Extensions Program compliant (details at

2.4 GHz

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.

Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program Version 4).

Multinational support with frequency bands and channels compliant to local regulations.

CSMA/CA (Collision Avoidance) with ACK

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between access points

17.5 dBm

15 dBm

Transmit: 2.0 W (max) Receive: 1.5 W (max) Idle mode3: 390 mW (nominal) Sleep mode: 20 mW (max)

ACPI compliant power management

802.11 compliant power saving mode

High efficiency dual band antenna with spatial diversity, mounted in the display enclosure

802.11 b – Typical (@1 Mbps)

802.11 g – Typical (@1 Mbps)

PCI-Express MiniCard

0.026 lb (12 g)

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

3.3v +/- 10%

Operating Non-operating

www.hp.com/go/notebooks/WLAN

1200 feet – Outdoor Open Area 300 feet – Indoor, Office environment

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C)

10% to 90% (non-condensing) 5% to 95% (non-condensing)

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

)

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 32

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Broadcom 4311AG

802.11a/b/g WiFi Adapter

Configuration Utility5Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager Broadcom Wireless Configuration Utility (required for Cisco Compatible Extensions support)

LED Activity

Check latest software/driver release for updates on supported security features.

1. Maximum output power may vary by country according to local regulations.

2. In Power Save Polling mode.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

4. and a packet error rate of 10% for 802.11a/g (OFDM modulation). WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN

5. may also be compatible with certain third-party software supplicants.

Wireless LAN Standards

Interoperability

Frequency Band

Data Rates

Modulation

Security

LED Off – Radio OFF; Solid LED On – Radio ON

IEEE 802.11a IEEE 802.11b IEEE 802.11g

Wi-Fi certified Cisco Compatible Extensions Program compliant (details at

2.4 GHz and 5 GHz

802.11b: 1, 2, 5.5, 11 Mbps

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.

www.hp.com/go/notebooks/WLAN

)

Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program Version 4).

Sub-channels

Media Access Protocol

Network Architecture Models

Roaming

Output Power

CKK)

Output Power

OFDM; power varies by data rate)

Power Consumption

Power Management

Receiver Sensitivity454 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

Antenna type

(for

Multinational support with frequency bands and channels compliant to local regulations.

CSMA/CA (Collision Avoidance) with ACK

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between access points

17.5 dBm

15 dBm

Transmit: 2.0 W (max) Receive: 1.5 W (max) Idle mode3: 390 mW (nominal) Sleep mode: 20 mW (max)

ACPI compliant power management

802.11 compliant power saving mode

High efficiency dual band antenna with spatial diversity, mounted in the display enclosure

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 33

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Range

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

Configuration Utility5Choice of Configuration Utility:

LED Activity

Check latest software/driver release for updates on supported security features.

1. Maximum output power may vary by country according to local regulations.

2. In Power Save Polling mode.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

4. and a packet error rate of 10% for 802.11a/g (OFDM modulation). WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN

5. may also be compatible with certain third-party software supplicants.

802.11 a – Typical (@6 Mbps)

802.11 b – Typical (@1 Mbps)

802.11 g – Typical (@1 Mbps)

PCI-Express MiniCard

0.026 lb (12 g)

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

3.3v +/- 10%

Operating Non-operating

Microsoft Windows XP Wireless Network Connection Manager Broadcom Wireless Configuration Utility (required for Cisco Compatible Extensions support)

LED Off – Radio OFF; Solid LED On – Radio ON

600 feet – Outdoor Open Area 150 feet – Indoor, Office environment

1200 feet – Outdoor Open Area 300 feet – Indoor, Office environment

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C)

10% to 90% (non-condensing) 5% to 95% (non-condensing)

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

Intel PRO/Wireless 3945ABG 802.11a/b/g Network Connection

Wireless LAN Standards

Interoperability

Frequency Band

Data Rates

Modulation

Security

Sub-channels

Media Access Protocol

IEEE 802.11a IEEE 802.11b IEEE 802.11g

Wi-Fi certified Cisco Compatible Extensions Program compliant (details at

2.4 GHz and 5 GHz

802.11b: 1, 2, 5.5, 11 Mbps

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.

Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program Version 4).

Multinational support with frequency bands and channels compliant to local regulations.

CSMA/CA (Collision Avoidance) with ACK

www.hp.com/go/notebooks/WLAN

)

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 34

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Network Architecture Models

Roaming

Output Power

CKK)

Output Power

OFDM; power varies by data rate)

Power Consumption

Power Management

Receiver Sensitivity454 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

Antenna type

Range

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

Configuration Utility5Choice of Configuration Utility:

(for

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between access points

15 dBm

Transmit: 1.8 Watts (max) Receive: 1.4 Watts (max) Idle mode3: 150 mW (nominal) Sleep mode: 30 mW (max)

ACPI compliant power management

802.11 compliant power saving mode

High efficiency dual band antenna with spatial diversity, mounted in the display enclosure

802.11 a – Typical (@6 Mbps)

802.11 b – Typical (@1 Mbps)

802.11 g – Typical (@1 Mbps)

PCI-Express MiniCard

0.013 lb (6 g)

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

3.3v +/- 10%

Operating Non-operating

600 feet – Outdoor Open Area 150 feet – Indoor, Office environment

1200 feet – Outdoor Open Area 300 feet – Indoor, Office environment

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C)

10% to 90% (non-condensing) 5% to 95% (non-condensing)

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

Microsoft Windows XP Wireless Network Connection Manager Intel PROSet (required for Cisco Compatible Extensions support)

LED Activity

Check latest software/driver release for updates on supported security features.

1. Maximum output power may vary by country according to local regulations.

2. In Power Save Polling mode.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

4. and a packet error rate of 10% for 802.11a/g (OFDM modulation). WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN

5. may also be compatible with certain third-party software supplicants.

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

LED Off – Radio OFF; Solid LED On – Radio ON

Page 35

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Intel PRO/Wireless 3945BG 802.11b/g Network Connection

Wireless LAN Standards

Interoperability

Frequency Band

Data Rates

Modulation

Security

Sub-channels

Media Access Protocol

Network Architecture Models

Roaming

Output Power

CKK)

Output Power

OFDM; power varies by data rate)

Power Consumption

Power Management

Receiver Sensitivity454 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm

Antenna type

Range

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

(for

IEEE 802.11b IEEE 802.11g

Wi-Fi certified Cisco Compatible Extensions Program compliant (details at

2.4 GHz

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST, EAP-SIM.

Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program Version 4).

Multinational support with frequency bands and channels compliant to local regulations.

CSMA/CA (Collision Avoidance) with ACK

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between access points

15 dBm

Transmit: 1.8 Watts (max) Receive: 1.4 Watts (max) Idle mode3: 150 mW (nominal) Sleep mode: 30 mW (max)

ACPI compliant power management

802.11 compliant power saving mode

High efficiency dual band antenna with spatial diversity, mounted in the display enclosure

802.11 b – Typical (@1 Mbps)

802.11 g – Typical (@1 Mbps)

PCI-Express MiniCard

0.013 lb (6 g)

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

3.3v +/- 10%

Operating Non-operating

www.hp.com/go/notebooks/WLAN

1200 feet – Outdoor Open Area 300 feet – Indoor, Office environment

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C)

10% to 90% (non-condensing) 5% to 95% (non-condensing)

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

)

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 36

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

HP Integrated Module with Bluetooth Wireless Technology

Configuration Utility5Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager Intel PROSet (required for Cisco Compatible Extensions support)

LED Activity

Check latest software/driver release for updates on supported security features.

1. Maximum output power may vary by country according to local regulations.

2. In Power Save Polling mode.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

4. and a packet error rate of 10% for 802.11a/g (OFDM modulation). WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN

5. may also be compatible with certain third-party software supplicants.

Bluetooth Specification

Dimensions

Frequency Band

Number of Available Channels

Data Rates and Throughput

Transmit Power

Receiver Sensitivity

Power Consumption

Antenna

Range

Electrical Interface

OS Support

Bluetooth Software Supported

Link Topology

Security

Power Management

Certifications

Temperature

Humidity

LED Off – Radio OFF; Solid LED On – Radio ON

2.0 Compliant

1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)

2402 to 2480 MHz

79 (1 MHz) available channels

3 Mbps data rate; throughput up to 2.17 Mbps

Synchronous Connection Oriented links up to 3, 64 kbps, voice channels

Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or 1306.9 kbps symmetric

-6 dBm to 4 dBm (Bluetooth Class II)

Better than -80 dBM at 0.1 % raw bit error rate

Peak (Tx) 264 mW

Peak (Rx) 231 mW

Sleep <1 mW

Internally integrated within module

Up 33 ft (10 m)

USB 2.0 compliant

Microsoft Windows Plug and Play compliant

Microsoft Windows XP Professional and Home

Microsoft Windows 2000

Broadcom Bluetooth for Windows

Microsoft Windows XP Bluetooth Software

Point to Point, Multipoint Pico Nets up to 7 slaves

Full support of Bluetooth Security Provisions

Microsoft Windows ACPI, and USB Bus Support

Self configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff

All necessary regulatory approvals for supported countries, including:

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

UL, CSA, and CE Mark

Operating

Non-operating

Operating

-4° to 158° F (-20° to 70° C)

-40° to 176° F (-40° to 80° C)

10% to 90%

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 37

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Altitude

Bluetooth Profiles Supported

indicates the profile is also supported by Microsoft Windows XP SP2

Non-operating

Operating

Non-operating

(with Bluetooth for Windows 4.0 software)

Serial Port Profile (SPP)*

Dial-Up Networking (DUN)*

Generic Object Exchange Profile (GOEP)

Object Push Profile (OPP)*

File Transfer Profile (FTP)

Synchronization Profile (SYNC)

Hard Copy Cable Replacement (HCRP)*

Personal Area Networking Profile (PAN)*

Human Interface Device Profile (HID)*

FAX Profile (FAX)

Basic Imaging Profile (BIP)

Headset Profile (HSP)

Hands Free Profile (HFP)

Advanced Audio Distribution Profile (A2DP)

5% to 95%

15,000 ft (4,572 m)

40,000 ft (12,192 m)

Environmental Data

Eco-Label Certifications

System Configuration

Energy Consumption

Normal Operation

Sleep (Energy Star low power mode)

Off

Heat Dissipation*

Normal Operation

Sleep

Off

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

US Energy Star US Federal Energy Management Program (FEMP) Taiwan Green Mark China Energy Conservation Program IT ECO declaration

The configuration used for the Energy Consumption and Declared Noise Emissions data is based on a "Typically Configured Notebook."

115 VAC 230 VAC 100 VAC

25.6 W 25.6 W 25.6 W

2.1 W 2.6 W 2.1 W

2.0 W 2.4 W 2.0 W

115 VAC 230 VAC 100 VAC

87.3 BTU/hr 87.3 BTU/hr 87.3 BTU/hr

7.2 BTU/hr 8.9 BTU/hr 7.2 BTU/hr

6.8 BTU/hr 7.2 BTU/hr 6.8 BTU/hr

*NOTE

: Heat dissipation is calculated based on the measured watts,

assuming the service level is attained for one hour.

This product is in compliance with US executive order 13221, WOL (wake on LAN) disabled.

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 38

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

Declared Noise Emissions

(in accordance with ISO 7779 and ISO 9296)

Idle

Fixed Disk (random writes)

Batteries

Additional Information

Sound Power

(LWAd, bels)

3.40 25.1

3.43 34.1

This product complies with ISO standards:

EU Directive 91/ 157/ EEC EU Directive 93/ 86/ EEC EU Directive 98/ 101/ EEC

Batteries used in the product do not contain:

Mercury greater than 5ppm by weight Cadmium greater than 10ppm by weight Lead greater than 4000 ppm by weight.

Battery type and chemistry used in the product:

Primary battery 6-cell or 4-cell high capacity Lithium-Ion battery pack

Real Time Clock battery CR2032L/DBE (coin cell), Lithium

This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive – 2002/95/EC.

Sound Pressure

(LpAm, decibels)

This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive – 2002/96/EC.

Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and ISO/IEC 15412

Input devices of this product comply with ISO 9241, part 9.

Plastics parts weighing over 0.055 pounds (25 grams) used in the product are marked per ISO 11469 and ISO1043.

This product contains 0% recycled materials (by wt.)

This product is greater than 94% recycle-able when properly disposed of at end of life.

Packaging

Packaging Materials

External:

Corrugated Paper – 0.89 lb (402 g)

Internal:

Corrugated – 0.10 lb (46 g)

PET Bag– 0.03 lb (15 g) The plastic packaging material is made from at least 20% postconsumer recycled content. The corrugated paper packaging materials contains at least 80% recycled content.

HP follows these guidelines to decrease the environmental impact of product packaging:

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 39

QuickSpecs

Technical Specifications

Material Usage

HP Compaq nc6400 Notebook PC

Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging materials. Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

This product does not contain any of the following substances in excess of regulatory limits (for reference of these limits please refer to the HP General Specification of the Environment (

http://www.hp.com/hpinfo/globalcitizenship/environment/

supplychain/gen_specifications.html

Asbestos Certain Azo Colorants Certain Brominated Flame Retardants – may not be used as flame retardants in plastics Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel - finishes must not be used on the external surface designed to be frequently handled or carried by the user. Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been voluntarily removed from most applications. Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 40

QuickSpecs

Technical Specifications

HP Compaq nc6400 Notebook PC

All rights reserved. Microsoft, Windows, Windows Vista, and Windows XP are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Core Duo, Centrino, and SpeedStep are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies.

End-of-life Management and Recycling

Hewlett-Packard Corporate Environmental Information

HP offers our customers several other options for handling their aging computers while also minimizing the impact on the environmentincluding product trade-in and leasing services-in addition to recycling services. Please go to: sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

For more information about HP's commitment to the environment:

Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Environment website

http://www.hp.com/environment

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/ productdesign/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/ operations/envmanagement.html

http://www.hp.com/recycle

, or contact your nearest HP

The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 41

Intel nc6400 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Options

Memory

Storage

Technical Specifications
