Intel® Desktop Board DH67CL Product Guide
Order Number: G14702-002
Revision History
Revision Revision History Date
-001 First release of the Intel® Desktop Board DH67CL Product Guide November 2010
-002 Second release of the Intel® Desktop Board DH67CL Product Guide March 2011
Disclaimer
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR
GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR
SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. Intel products are not intended
for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and
product descriptions at any time, without notice.
Intel Desktop Board DH67CL may contain design defects or errors known as errata which may cause the
product to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing
your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel
literature, may be obtained from Intel Corporation by going to the World Wide Web site at:
http://www.intel.com/ or by calling 1-800-548-4725.
Intel, Intel Core, and Pentium are trademarks of Intel Corporation in the United States and other countries.
* Other names and brands may be claimed as the property of others.
Copyright © 2010, 2011, Intel Corporation. All rights reserved.
OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS
Preface
This Product Guide gives information about board layout, component installation, BIOS
update, and regulatory requirements for Intel
®
Desktop Board DH67CL.
Intended Audience
The Product Guide is intended for technically qualified personnel. It is not intended for
general audiences.
Use Only for Intended Applications
All Intel Desktop Boards are evaluated as Information Technology Equipment (I.T.E.)
for use in personal computers (PC) for installation in homes, offices, schools, computer
rooms, and similar locations. The suitability of this product for other PC or embedded
non-PC applications or other environments, such as medical, industrial, alarm systems,
test equipment, etc. may not be supported without further evaluation by Intel.
Document Organization
The chapters in this Product Guide are arranged as follows:
1 Desktop Board Features: a summary of product features
2 Installing and Replacing Desktop Board Components: instructions on how to install
the Desktop Board and other hardware components
3 Updating the BIOS: instructions on how to update the BIOS
A Error Messages and Indicators: information about BIOS error messages and beep
codes
B Regulatory Compliance: describes the board’s adherence to safety standards and
EMC regulations and its product certifications
Conventions
The following conventions are used in this manual:
CAUTION
Cautions warn the user about how to prevent damage to hardware or loss of data.
NOTE
Notes call attention to important information.
iii
Intel Desktop Board DH67CL Product Guide
Terminology
The table below gives descriptions of some common terms used in the product guide.
Term Description
GB Gigabyte (1,073,741,824 bytes)
GHz Gigahertz (one billion hertz)
KB Kilobyte (1024 bytes)
MB Megabyte (1,048,576 bytes)
Mb Megabit (1,048,576 bits)
MHz Megahertz (one million hertz)
iv
Contents
1 Desktop Board Features
Supported Operating Systems..............................................................................11
Desktop Board Components.................................................................................12
Processor..........................................................................................................14
®
Intel
H67 Express Chipset .................................................................................15
Main Memory.....................................................................................................15
Graphics Subsystem...........................................................................................16
Integrated Graphics ....................................................................................16
PCI Express* x16 Graphics ..........................................................................17
Audio Subsystem ...............................................................................................17
LAN Subsystem .................................................................................................18
USB Support .....................................................................................................19
SATA Support....................................................................................................19
Expandability.....................................................................................................19
Legacy I/O........................................................................................................20
BIOS................................................................................................................20
SATA Auto Configuration .............................................................................20
PCI*/PCI Express Auto Configuration.............................................................20
Security Passwords.....................................................................................21
Hardware Management .......................................................................................21
Hardware Monitoring and Fan Speed Control ..................................................21
Fan Monitoring ...........................................................................................21
Chassis Intrusion........................................................................................22
Power Management............................................................................................22
Software Support .......................................................................................22
Hardware Support ......................................................................................22
Speaker............................................................................................................25
Real-Time Clock Subsystem.................................................................................25
®
Intel
HD Graphics ..............................................................................16
High-Definition Multimedia Interface* (HDMI*)........................................16
Digital Visual Interface (DVI-I)..............................................................16
VGA Displays......................................................................................17
ACPI..................................................................................................22
Power Connectors ...............................................................................22
Fan Headers .......................................................................................23
LAN Wake Capabilities..........................................................................23
Instantly Available PC Technology..........................................................23
+5 V Standby Power Indicator LED ........................................................24
Wake from USB ..................................................................................25
PCI Express WAKE# Signal Wake-up Support..........................................25
Wake from CIR ...................................................................................25
2 Installing and Replacing Desktop Board Components
Before You Begin ...............................................................................................27
Installation Precautions.......................................................................................28
Prevent Power Supply Overload ....................................................................28
Observe Safety and Regulatory Requirements.................................................28
v
Intel Desktop Board DH67CL Product Guide
Installing the I/O Shield ......................................................................................29
Installing and Removing the Desktop Board ...........................................................30
Installing and Removing a Processor.....................................................................31
Installing a Processor ..................................................................................31
Installing a Processor Fan Heat Sink..............................................................35
Connecting the Processor Fan Heat Sink Cable................................................35
Removing the Processor ..............................................................................35
Installing and Removing System Memory ..............................................................36
Guidelines for Dual Channel Memory Configuration..........................................36
Two or Four DIMMs .............................................................................36
Three DIMMs ......................................................................................37
Installing DIMMs ........................................................................................38
Removing DIMMs........................................................................................40
Installing and Removing PCI Express x16 Graphics Cards.........................................40
Installing a PCI Express x16 Graphics Card ....................................................40
Removing a PCI Express x16 Graphics Card....................................................42
Connecting SATA Drives......................................................................................43
Connecting to the Internal Headers ......................................................................44
Front Panel Audio Header ............................................................................45
Chassis Intrusion Header.............................................................................45
Consumer IR (CIR) Headers.........................................................................46
Alternate Front Panel Power LED Header........................................................47
Front Panel Header .....................................................................................47
Front Panel USB 2.0 Headers........................................................................48
S/PDIF Header ...........................................................................................48
Connecting to the Audio System...........................................................................49
Connecting Chassis Fan and Power Supply Cables...................................................50
Connecting a Chassis Fan ............................................................................50
Connecting Power Supply Cables ..................................................................51
Setting the BIOS Configuration Jumper .................................................................52
Clearing Passwords ............................................................................................53
Replacing the Battery .........................................................................................54
3 Updating the BIOS
Updating the BIOS with the Intel
Updating the BIOS Using the F7 Function Key ........................................................62
Updating the BIOS with the Intel® Flash Memory Update Utility or the ISO
Image BIOS Update File ................................................................................62
Obtaining the BIOS Update File ....................................................................62
Updating the BIOS with the Intel Flash Memory Update Utility...........................63
Updating the BIOS with the ISO Image BIOS Update File .................................63
Recovering the BIOS...................................................................................64
®
Express BIOS Update Utility.................................61
A Error Messages and Indicators
BIOS Error Codes...............................................................................................65
BIOS Error Messages..........................................................................................66
vi
Contents
B Regulatory Compliance
Safety Standards ...............................................................................................67
Battery Caution..........................................................................................67
European Union Declaration of Conformity Statement..............................................68
Product Ecology Statements ................................................................................69
Recycling Considerations .............................................................................69
China RoHS ...............................................................................................72
EMC Regulations ................................................................................................73
FCC Declaration of Conformity......................................................................73
Canadian Department of Communications Compliance Statement......................74
Japan VCCI Statement ................................................................................74
Korea Class B Statement .............................................................................75
Ensure Electromagnetic Compatibility (EMC) Compliance..................................75
Product Certifications..........................................................................................76
Board-Level Certifications ............................................................................76
Chassis- and Component-Level Certifications..................................................77
ENERGY STAR*, e-Standby, and ErP Compliance ....................................................77
Figures
1. Intel Desktop Board DH67CL Components........................................................12
2. LAN Connector LEDs .....................................................................................18
3. Location of the Standby Power Indicator ..........................................................24
4. Installing the I/O Shield ................................................................................29
5. Intel Desktop Board DH67CL Mounting Screw Hole Locations..............................30
6. Unlatch the Socket Lever...............................................................................31
7. Lift the Load Plate.........................................................................................32
8. Remove the Processor from the Protective Cover ..............................................33
9. Install the Processor .....................................................................................33
10. Secure the Load Plate in Place........................................................................34
11. Connecting the Processor Fan Heat Sink Power Cable to the Processor
Fan Header..................................................................................................35
12. Example Dual Channel Memory Configuration with Two DIMMs ...........................36
13. Example Dual Channel Memory Configuration with Four DIMMs...........................36
14. Example Dual Channel Memory Configuration with Three DIMMs .........................37
15. Use DDR3 DIMMs .........................................................................................38
16. Installing a DIMM .........................................................................................39
17. Installing a PCI Express x16 Graphics Card ......................................................41
18. Removing a PCI Express x16 Graphics Card......................................................42
19. Connecting a SATA Drive...............................................................................43
20. Internal Headers ..........................................................................................44
21. Back Panel Audio Connectors .........................................................................49
22. Location of the Chassis Fan Header .................................................................50
23. Connecting Power Supply Cables ....................................................................51
24. Location of the BIOS Configuration Jumper Block ..............................................52
25. Removing the Battery ...................................................................................59
26. Intel Desktop Board DH67CL China RoHS Material Self Declaration Table..............72
vii
Intel Desktop Board DH67CL Product Guide
Tables
1. Feature Summary.......................................................................................... 9
2. Intel Desktop Board DH67CL Components........................................................13
3. Audio Jack Retasking Support.........................................................................18
4. LAN Connector LEDs .....................................................................................19
5. Front Panel Audio Signal Names for Intel HD Audio............................................45
6. Front Panel Audio Header Signal Names for AC ’97 Audio ...................................45
7. Chassis Intrusion Header Signal Names ...........................................................45
8. Front Panel CIR Receiver (Input) Header Signal Names......................................46
9. Back Panel CIR Emitter (Output) Header Signal Names ......................................46
10. Alternate Front Panel Power LED Header Signal Names ......................................47
11. Front Panel Header Signal Names ...................................................................47
12. USB 2.0 Header Signal Names........................................................................48
13. S/PDIF Header Signal Names .........................................................................48
14. Jumper Settings for the BIOS Setup Program Modes..........................................53
15. BIOS Beep Codes .........................................................................................65
16. Front-panel Power LED Blink Codes.................................................................66
17. BIOS Error Messages ....................................................................................66
18. Safety Standards..........................................................................................67
19. EMC Regulations...........................................................................................73
20. Regulatory Compliance Marks.........................................................................76
viii
1 Desktop Board Features
This chapter briefly describes the features of Intel® Desktop Board DH67CL. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor
Processor
Chipset Intel® H67 Express Chipset consisting of the Intel® H67 Express
Memory
Graphics
Audio
Expansion
Capabilities
ATX (243.84 millimeters [9.6 inches] x 294.64 millimeters
[11.6 inches])
• Intel® Core™ i7, Intel® Core™ i5, and Intel® Core™ i3 processors in
an LGA1155 socket:
― Integrated graphics processing (processors with Intel
Graphics 2000 and 3000)
― External graphics interface controller
― Integrated memory controller
Platform Controller Hub (PCH)
• Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets
• Dual Channel DDR3 1333 MHz and DDR3 1066 MHz support
• Support for 1 Gb, 2 Gb, and 4 Gb memory technology
• Support for up to 32 GB of system memory with four DIMMs using
4 Gb memory technology
• Support for non-ECC memory
• Support for 1.35 V low voltage JEDEC memory
• Integrated graphics support for processors with Intel HD 2000 or
3000 Graphics:
― High-Definition Multi-media Interface* (HDMI*)
― DVI-I
• Discrete graphics support for a PCI Express* 2.0 x16 add-in
graphics card
• 10-channel (7.1+2) Intel
using a Realtek* ALC892 audio codec including:
― Front panel audio header with support for Intel HD Audio and
AC ’97 Audio
― Five analog audio jacks on the back panel
― Onboard S/PDIF out header and back panel optical S/PDIF out
connector
• 8-channel (7.1) Intel HD Audio via the HDMI interface
One PCI Express 2.0 x16 add-in card connector
Two PCI Express 2.0 x1 add-in card connectors
Three Conventional PCI bus add-in card connectors
®
High Definition Audio (Intel® HD Audio)
®
HD
continued
9
Intel Desktop Board DH67CL Product Guide
Table 1. Feature Summary (continued)
Peripheral
Interfaces
Legacy I/O
LAN Support Intel® 82579V Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
BIOS
Instantly Available
PC Technology
Hardware
Management
USB Support:
• Two USB 3.0 ports implemented with stacked back panel
connectors
• Fourteen USB 2.0 ports:
― Six ports implemented with stacked back panel connectors
― Eight front panel ports implemented with four dual-port
internal headers
Serial ATA Support:
• Two Serial ATA (SATA) 6.0 Gb/s ports
• Two Serial ATA (SATA) 3.0 Gb/s ports
• Two external SATA (eSATA) 3.0 Gb/s ports (one on the board and
one on the back panel)
Legacy I/O Controller (Nuvoton* W83677HG-I) that provides
Consumer Infrared (CIR) support
including an RJ-45 back panel connector with integrated status LEDs
• Intel
®
BIOS resident in an Serial Peripheral Interface (SPI) Flash
device
• Support for Advanced Configuration and Power Interface (ACPI),
Plug and Play, and System Management BIOS (SMBIOS)
• Unified Extensible Firmware Interface (UEFI) to support hard disk
drives larger than 2 TB
• BIOS support for Hyper Boot
• Support for PCI Local Bus Specification Revision 2.3
• Support for PCI Express Base Specification Revision 2.0
• Suspend to RAM support
• Wake on PCI Express, LAN, front panel, CIR, and USB ports
Nuvoton W83677HG-I based subsystem, including:
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers using Pulse Width Modulation (PWM) control
• 4-pin headers for processor and chassis fans
• 4-wire and 3-wire (linear) fan speed control support for the
chassis fans
• Support for Platform Environmental Control Interface (PECI)
10
Desktop Board Features
Supported Operating Systems
The Desktop Board provides full support for the following operating systems:
• Microsoft Windows* 7 Ultimate 64-bit edition
• Microsoft Windows 7 Ultimate 32-bit edition
• Microsoft Windows 7 Home Basic 64-bit edition
• Microsoft Windows 7 Home Premium 64-bit edition
• Microsoft Windows 7 Home Premium 32-bit edition
• Microsoft Windows 7 Home Basic 32-bit edition
• Microsoft Windows Vista* Ultimate 32-bit edition
• Microsoft Windows Vista Business 32-bit edition
• Microsoft Windows Vista Home Premium 32-bit edition
• Microsoft Windows Vista Home Basic 32-bit edition
• Microsoft Windows Vista Ultimate 64-bit edition
• Microsoft Windows Vista Business 64-bit edition
• Microsoft Windows Vista Home Premium 64-bit edition
• Microsoft Windows Vista Home Basic 64-bit edition
The Desktop Board provides minimal BIOS and driver support for the following
operating systems:
• Microsoft Windows* XP Media Center Edition 2005
• Microsoft Windows XP Professional
• Microsoft Windows XP Professional x64 Edition
• Microsoft Windows XP Home
11
Intel Desktop Board DH67CL Product Guide
Desktop Board Components
Figure 1 shows the approximate location of the major components on Intel Desktop
Board DH67CL.
12
Figure 1. Intel Desktop Board DH67CL Components
Table 2. Intel Desktop Board DH67CL Components
Label Description
A Conventional PCI bus connector
B Conventional PCI bus connector
C Conventional PCI bus connector
D PCI Express 2.0 x1 add-in card connector
E PCI Express 2.0 x1 add-in card connector
F PCI Express 2.0 x16 add-in card connector
G Back panel connectors
H 12 V processor core voltage connector (2 x 2 pin)
I Rear chassis fan header
J Processor socket
K Processor fan header
L DDR3 DIMM 3 socket
M DDR3 DIMM 1 socket
N DDR3 DIMM 4 socket
O DDR3 DIMM 2 socket
P Front chassis fan header
Q Chassis intrusion header
R Front panel CIR receiver (input) header
S Back panel CIR emitter (output) header
T Main power connector (2 x 12 pin)
U Battery
V Speaker
W SATA connectors
X Alternate front panel power LED header
Y Front panel header
Z BIOS configuration jumper block
AA Standby power indicator LED
BB Front panel USB 2.0 headers
CC S/PDIF header
DD Front panel audio header
Desktop Board Features
13
Intel Desktop Board DH67CL Product Guide
Online Support
For more information on Intel Desktop Board DH67CL consult the following online
resources:
• Intel Desktop Board DH67CL http://www.intel.com/products/motherboard/index.ht
m
• Desktop Board Support http://www.intel.com/p/en_US/support?iid=hdr+supp
ort
• Available configurations for Intel
Desktop Board DH67CL
• Supported processors http://processormatch.intel.com
• Chipset information http://www.intel.com/products/desktop/chipsets/inde
• BIOS and driver updates http://downloadcenter.intel.com/
• Integration information http://www.intel.com/support/go/buildit
http://ark.intel.com
x.htm
Processor
CAUTION
Failure to use an appropriate power supply and/or not connecting the 12 V (2 x 2 pin)
power connector to the Desktop Board may result in damage to the board, or the
system may not function properly.
Intel Desktop Board DH67CL supports the Intel Core i7, Intel Core i5, and Intel Core i3
processors in an LGA1155 socket. Processors are not included with the Desktop Board
and must be purchased separately. The processor connects to the Desktop Board
through the LGA1155 socket.
For information on supported processors for Intel Desktop Board DH67CL, go to
http://processormatch.intel.com
.
14
