Intel® Desktop Board DG45ID Product Guide
Order Number: E30021-001
Revision History
Revision Revision History Date
-001 First release of the Intel® Desktop Board DG45ID Product Guide May 2008
If an FCC declaration of conformity marking is present on the board, the following statement applies:
FCC Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
For questions related to the EMC performance of this product, contact:
Intel Corporation, 5200 N.E. Elam Young Parkway, Hillsboro, OR 97124
1-800-628-8686
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit other than the one to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to the equipment not expressly approved by Intel Corporation could void the
user’s authority to operate the equipment.
Tested to comply with FCC standards for home or office use.
Canadian Department of Communications Compliance Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set
out in the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numerique német pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la classe B prescrites dans le Réglement sur le broullage radioélectrique édicté par
le ministére des Communications du Canada.
Disclaimer
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE,
EXPRESS OR IMPLIED, BY ESTOPPEL OR
GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR
SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR
IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR
WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT
OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. Intel products are not intended
for use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and
product descriptions at any time, without notice.
Desktop Board DG45ID may contain design defects or errors known as errata which may cause the product
to deviate from published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing
your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel
literature, may be obtained from Intel Corporation by going to the World Wide Web site at:
http://intel.com/ or by calling 1-800-548-4725.
Intel, the Intel logo, and Intel Viiv are trademarks of Intel Corporation in the U.S. and other countries.
* Other names and brands may be claimed as the property of others.
Copyright © 2008, Intel Corporation. All rights reserved.
OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS
Preface
This Product Guide gives information about board layout, component installation, BIOS
update, and regulatory requirements for Intel
®
Desktop Board DG45ID.
Intended Audience
The Product Guide is intended for technically qualified personnel. It is not intended for
general audiences.
Use Only for Intended Applications
All Intel Desktop Boards are evaluated as Information Technology Equipment (I.T.E.)
for use in personal computers (PC) for installation in homes, offices, schools, computer
rooms, and similar locations. The suitability of this product for other PC or embedded
non-PC applications or other environments, such as medical, industrial, alarm systems,
test equipment, etc. may not be supported without further evaluation by Intel.
Document Organization
The chapters in this Product Guide are arranged as follows:
1 Desktop Board Features: a summary of product features
2 Installing and Replacing Desktop Board Components: instructions on how to install
the Desktop Board and other hardware components
3 Updating the BIOS: instructions on how to update the BIOS
4 Configuring for RAID (Intel
about configuring your system for RAID
5 Configuring for Intel
configuring your system for Intel Rapid Recover Technology
A Error Messages and Indicators: information about BIOS error messages and beep
codes
B Regulatory Compliance: safety standards, regulations, and product certifications
®
®
Matrix Storage Technology (Intel® MST)): information
Rapid Recover Technology (Intel® RRT): information about
Conventions
The following conventions are used in this manual:
CAUTION
Cautions warn the user about how to prevent damage to hardware or loss of data.
iii
Intel Desktop Board DG45ID Product Guide
NOTE
Notes call attention to important information.
Terminology
The table below gives descriptions of some common terms used in the product guide.
Term Description
GB Gigabyte (1,073,741,824 bytes)
GHz Gigahertz (one billion hertz)
KB Kilobyte (1024 bytes)
MB Megabyte (1,048,576 bytes)
Mbit Megabit (1,048,576 bits)
MHz Megahertz (one million hertz)
iv
Contents
1 Desktop Board Features ................................................................9
Desktop Board Components.................................................................................11
Processor..........................................................................................................13
Main Memory.....................................................................................................13
®
Intel
G45 Express Chipset .................................................................................14
Intel G45 Graphics Subsystem......................................................................14
DVI-I Support.....................................................................................15
HDMI* Technology Support ..................................................................15
PCI Express x16 Graphics.....................................................................16
®
Intel
Viiv™ Technology ..............................................................................16
Audio Subsystem ...............................................................................................16
Legacy Input/Output (I/O) Controller....................................................................17
LAN Subsystem .................................................................................................17
LAN Subsystem Software.............................................................................17
LAN Status Indicators..................................................................................18
Hi-Speed USB 2.0 Support ..................................................................................18
Serial ATA.........................................................................................................19
Serial ATA RAID .........................................................................................19
Intel® Rapid Recover Technology (Intel
Expandability.....................................................................................................19
BIOS................................................................................................................20
Serial ATA Auto Configuration.......................................................................20
PCI and PCI Express* Auto Configuration.......................................................20
Security Passwords.....................................................................................20
Hardware Management Features ..........................................................................21
Fan Speed, Thermal, and Voltage Monitoring and Control .................................21
Chassis Intrusion........................................................................................21
Power Management Features ...............................................................................22
ACPI.........................................................................................................22
Hardware Support ......................................................................................22
Power Connectors ...............................................................................22
Fan Headers .......................................................................................23
LAN Wake Capabilities..........................................................................23
Instantly Available PC Technology..........................................................23
+5 V Standby Power Indicator...............................................................24
Wake from USB ..................................................................................25
PME# Signal Wake-up Support..............................................................25
WAKE# Signal Wake-up Support ...........................................................25
Wake from CIR ...................................................................................25
ENERGY STAR* Qualified .............................................................................25
Speaker............................................................................................................25
Battery.............................................................................................................25
Real-Time Clock.................................................................................................25
®
RRT) ................................................19
v
Intel Desktop Board DG45ID Product Guide
2 Installing and Replacing Desktop Board Components .................27
Before You Begin ...............................................................................................27
Installation Precautions.......................................................................................28
Prevent Power Supply Overload ....................................................................28
Observe Safety and Regulatory Requirements.................................................28
Installing the I/O Shield ......................................................................................29
Installing and Removing the Desktop Board ...........................................................30
Installing and Removing a Processor.....................................................................31
Installing a Processor ..................................................................................31
Installing a Processor Fan Heat Sink..............................................................34
Connecting the Processor Fan Heat Sink Cable................................................35
Removing the Processor ..............................................................................35
Installing and Removing Memory..........................................................................36
Guidelines for Dual Channel Memory Configuration..........................................36
Two or Four DIMMs .............................................................................36
Three DIMMs ......................................................................................37
Installing DIMMs ........................................................................................38
Removing DIMMs........................................................................................40
Installing and Removing a PCI Express x16 Card ....................................................41
Installing a PCI Express x16 Card .................................................................41
Removing the PCI Express x16 Card..............................................................42
Connecting Serial ATA (SATA) Cables....................................................................43
Connecting to Internal Headers and Connectors .....................................................44
HD Audio Link Header .................................................................................45
S/PDIF Connector.......................................................................................45
Front Panel HD Audio Header .......................................................................45
Consumer IR (CIR) Headers.........................................................................46
Serial Port Header ......................................................................................47
Chassis Intrusion Header.............................................................................47
Alternate Front Panel Power LED Header........................................................47
Front Panel Header .....................................................................................48
USB 2.0 Headers ........................................................................................48
IEEE 1394a Header.....................................................................................49
Connecting to the Audio System...........................................................................49
Connecting Chassis Fan and Power Supply Cables...................................................50
Chassis Fan Cables .....................................................................................50
Power Supply Cables...................................................................................51
Setting the BIOS Configuration Jumper .................................................................52
Clearing Passwords ............................................................................................53
3 Updating the BIOS.......................................................................61
Updating the BIOS with the Intel
Updating the BIOS with the ISO Image BIOS Update File or the Iflash Memory Update
Utility .........................................................................................................62
Obtaining the BIOS Update File ....................................................................62
Updating the BIOS with the ISO Image BIOS Update File .................................62
Updating the BIOS with the Iflash Memory Update Utility .................................63
Recovering the BIOS...................................................................................64
vi
®
Express BIOS Update Utility.................................61
Contents
4 Configuring for RAID (Intel
®
Matrix Storage Technology (Intel®
MST)) ..........................................................................................65
Configuring the BIOS for Intel Matrix Storage Technology ................................65
Creating Your RAID Set ...............................................................................65
Loading the Intel Matrix Storage Technology RAID Drivers and Software ............66
Setting Up a “RAID Ready” System ...............................................................66
5 Configuring for Intel® Rapid Recover Technology........................67
Enabling Intel Rapid Recover Technology...............................................................67
Creating a Recovery Volume................................................................................68
Creating a Recovery Volume Using the RAID Option ROM .................................68
Creating a Recovery Volume Using the Intel Matrix Storage Console ..................68
Disk Synchronization Mode..................................................................................69
Mounting the Recovery Disk ................................................................................69
A Error Messages and Indicators ....................................................71
BIOS Beep Codes...............................................................................................71
BIOS Error Messages..........................................................................................71
B Regulatory Compliance................................................................73
Safety Standards ...............................................................................................73
Place Battery Marking .................................................................................73
European Union Declaration of Conformity Statement..............................................74
Product Ecology Statements ................................................................................75
Recycling Considerations .............................................................................75
Lead-free 2LI/Pb-free 2LI Board ...................................................................78
Restriction of Hazardous Substances (RoHS) ..................................................79
EU RoHS ............................................................................................79
China RoHS ........................................................................................80
EMC Regulations ................................................................................................82
Ensure Electromagnetic Compatibility (EMC) Compliance..................................83
Product Certifications..........................................................................................84
Board-Level Certification Markings ................................................................84
Chassis and Component Certifications............................................................85
Figures
1. Desktop Board DG45ID Components ...............................................................11
2. LAN Status LEDs ..........................................................................................18
3. Locati
4. Installing the I/O Shield ................................................................................29
5. Desktop
6. Li
7. Li
8. Remove the
9. Remove the
10. Install
11. Close
12. Conn
13. Dual
14. Dual
15. Dual
on of the +5 V Standby Power Indicator ..................................................24
Board DG45ID Mounting Screw Hole Locations .....................................30
ft the Socket Lever.....................................................................................31
ft the Load Plate.........................................................................................32
Protective Socket Cover ...............................................................32
Processor from the Protective Processor Cover ................................33
the Processor .....................................................................................33
the Load Plate .....................................................................................34
ecting the Processor Fan Heat Sink Cable..................................................35
Channel Memory Configuration with Two DIMMs ........................................36
Channel Memory Configuration with Four DIMMs........................................37
Channel Memory Configuration with Three DIMMs......................................37
vii
Intel Desktop Board DG45ID Product Guide
16. Use DDR2 DIMMs .........................................................................................38
17. Installing a DIMM .........................................................................................39
18. Installing a PCI Express x16 Card
19. Removi
20. Conn
21. Internal
22. Back Pa
23. Location
24. Conn
25. Locati
26. Removing t
27. Desktop
ng a PCI Express x16 Card ..................................................................42
ecting a Serial ATA Cable........................................................................43
Headers and Connectors....................................................................44
nel Audio Connectors .........................................................................49
of the Chassis Fan Headers................................................................50
ecting Power Supply Cables ....................................................................51
on of the BIOS Configuration Jumper Block ..............................................52
he Battery ...................................................................................59
Board DG45ID China RoHS Material Self Declaration Table .....................81
...................................................................41
Tables
1. Feature Summary.......................................................................................... 9
2. Desktop Board DG45ID Components ...............................................................12
3. Audio Jack Retasking Support.........................................................................17
4. LAN Connector LEDs .....................................................................................18
5. HD Audio Link Header Signal Names ...............................................................45
6. S/PDIF Connector Signal Names .....................................................................45
7. Front Panel Audio Header Signal Names...........................................................45
8. Front Panel CIR Receiver (Input) Header Signal Names ......................................46
9. Back Panel CIR Emitter (Output) Header Signal Names ......................................46
10. Serial Port Header Signal Names.....................................................................47
11. Chassis Intrusion Header Signal Names ...........................................................47
12. Alternate Front Panel Power LED Header Signal Names ......................................47
13. Front Panel Header Signal Names ...................................................................48
14. USB 2.0 Header Signal Names........................................................................48
15. IEEE 1394a Header Signal Names ...................................................................49
16. Jumper Settings for the BIOS Setup Program Modes..........................................53
17. Beep Codes .................................................................................................71
18. BIOS Error Messages ....................................................................................71
19. Safety Standards..........................................................................................73
20. Lead-Free Second Level Interconnect Marks .....................................................79
21. China RoHS Environmentally Friendly Use Period Mark.......................................80
22. EMC Regulations...........................................................................................82
23. Product Certification Markings ........................................................................84
viii
1 Desktop Board Features
This chapter briefly describes the features of Intel® Desktop Board DG45ID. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor
Processor Support for an Intel® processor in the LGA775 package
Main Memory
Chipset Intel® G45 Express Chipset consisting of:
Graphics
Audio Onboard subsystem, featuring:
Expansion
Capabilities
Legacy I/O Support Legacy I/O Controller that provides:
microATX (243.84 millimeters [9.60 inches] x 243.84 millimeters
[9.60 inches])
• Four 240-pin, DDR2 1.8 V SDRAM Dual Inline Memory Module
(DIMM) sockets
• 800/667 MHz single or dual channel DDR2 SDRAM interface
• Support for up to 8 GB of system memory
• Intel G45 Express Chipset Graphics and Memory Controller Hub
(GMCH)
• Intel
• Intel G45 Express Chipset with
• One PCI Express* 2.0 x16 connector supporting PCI Express
• High-Definition Multimedia Interface* (HDMI*) output
• Support for dual independent displays via the HDMI/DVI-I ports
• Independent 8-channel (7.1) audio streams
• 2-channel stereo audio streams via an onboard header
• Intel
• IDT* 92HD73E audio codec
• Back panel optical S/PDIF output connector and an onboard 3-pin
• Dolby Home Theater* certified audio
• One PCI Express 2.0 x16 connector
• Two PCI Express 1.1 x1 connectors
• One PCI* connector
• Consumer Infrared (CIR) support
• One serial port via an onboard header
®
82801JR I/O Controller Hub (ICH10R)
X4500HD (Intel
graphics add-in cards
®
High Definition Audio (Intel® HD Audio) interface
S/PDIF output connector
®
GMA X4500HD)
Intel® Graphics Media Accelerator
continued
9
Intel Desktop Board DG45ID Product Guide
Table 1. Feature Summary (continued)
Peripheral
Interfaces
BIOS
Power Management
Hardware
Management
LAN Support Intel® 82567LF Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
Operating System
Support
• Up to 12 USB 2.0 ports:
― Six ports routed to the back panel
― Six ports routed to three USB headers
• Up to two IEEE 1394a ports:
― One port routed to the back panel
― One port routed to an onboard IEEE 1394a header
• Six Serial ATA (SATA) channels (3.0 Gb/s) via ICH10R including one
external SATA (eSATA) channel
®
• SATA RAID support via Intel
MST) including support for Intel
Matrix Storage Technology (Intel®
®
Rapid Recover Technology (Intel®
RRT)
• Intel
®
Platform Innovation Framework for EFI
• 32 Mbit symmetrical flash memory device
• Support for SMBIOS
• Intel
• Intel
®
Rapid BIOS Boot
®
Express BIOS Update
• Support for Advanced Configuration and Power Interface (ACPI)
• Suspend to RAM (STR)
• Wake on USB, PCI Express, LAN, front panel, and Consumer IR
• ENERGY STAR* capable
Hardware monitor with:
• Three fan sensing inputs used to monitor fan activity
• Intel
®
Quiet System Technology (Intel® QST) fan speed control
• Voltage sensing to detect out of range values
• Microsoft Windows Vista* Ultimate
• Microsoft Windows Vista Enterprise
• Microsoft Windows Vista Business
• Microsoft Windows Vista Home Premium
• Microsoft Windows Vista Home Basic
• Microsoft Windows Vista Ultimate 64-bit edition
• Microsoft Windows Vista Enterprise 64-bit edition
• Microsoft Windows Vista Business 64-bit edition
• Microsoft Windows Vista Home Premium 64-bit edition
• Microsoft Windows Vista Home Basic 64-bit edition
• Microsoft Windows* XP Media Center Edition 2005
• Microsoft Windows XP Professional
• Microsoft Windows XP Professional x64 Edition
• Microsoft Windows XP Home
For more information about Desktop Board DG45ID, including the Technical Product
Specification (TPS), BIOS updates, and device drivers, go to
http://support.intel.com/support/motherboards/desktop/
.
10
Loading...
