• Intel® 845D Chipset.

• Support Intel® Pentium® 4 processors and the Northwood processors in the

• Support Intel® Pentium® 4 processors system bus at 400MHz.

• Flexible motherboard design with on board VRM 9.0.

• A total of two 184-pin DDR SDRAM sockets.

• Max of 2 Double-Sided DIMMs (4 rows populated) with Unbuffered

• The largest memory capacity possible is 2GB (64Mx8Bx8 devices x

• Firmware Hub with security feature.

• PnP, APM, ATAPI and Windows® 95/98/2000.

• Full support of ACPI & DMI.

• Auto detects and supports LBA harddisks with capacities over 8.4GB.

• Easy to upgrade BIOS by end-user.

• On board two PCI fast IDE ports supporting up to 4 ATA, ATA2 , Ultra ATA33/

• One ECP/EPP parallel port.

• Two 16550 Compatible UART serial ports.

• One floppy port supports two FDD of 360KB, 720KB, 1.2MB , 1.44MB and

• Four USB ports .

• PS/2 keyboard connector.

• PS/2 mouse is supported.

• One Front Panel Sound Connector.

• Infrared (IrDA) is supported via a header.

• Supports Plug and Play specification 1.1.

• Plug and Play for DOS, Windows® 3.X, Windows® 95/98 as well as

• Fully steerable PCI interrupts.

• Integrated AC97 controller with standard AC97 Codec.

• Direct Sound and Sound Blaster compatible.

• Full-Duplex 16-bit record and play back.

• PnP and APM 1.2 support.

• Win® 95/98/2000, NT drivers ready.

• Line-in, Line-out, Mic-in and MIDI/Game port.

: :

478-pin package.

oltage Roltage R

oltage R

oltage Roltage R

DDR200 (with or without ECC). 4rows=2GB),using 512MB technology.

66/100 IDE HDDs, CD-ROMs, ZIP drives and LS-120 drives as boot drive.

2.88MB capacity.

Windows® 2000.

egulator Modules) on Boardegulator Modules) on Board

egulator Modules) on Board

egulator Modules) on Boardegulator Modules) on Board

TIONTION

TION

TIONTION

Hardware Configuration

On-board Creative PCI Sound (optional)On-board Creative PCI Sound (optional)

On-board Creative PCI Sound (optional)

On-board Creative PCI Sound (optional)On-board Creative PCI Sound (optional)

• PnP, creative 3D enhancement.

• Full-duplex, Sound Blaster 16 compatible.

• 128 voice wave table synthesizer.

• DOS game compatibility.

• PCI bus master for fast DMA.

• Fully compliant with AC97 power management specification.

• Win® 95, 98, NT drivers ready.

• Line-in, Line-out, Mic-in and MIDI/game port.

Power ManagementPower Management

Power Management

Power ManagementPower Management

• Supports SMM, APM and ACPI.

• Break switch for instant suspend/resume on system operations.

• Energy star “Green PC” compliant.

• Hardware monitoring circuit is supported, provide voltage, temperature, fan speed, etc. monitoring (optional).

• WOL (Wake-On-Lan) header support.

• External Modem Ring-in Wake-up support.

• Supports suspend-to-RAM(STR)(optional).

Expansion SlotsExpansion Slots

Expansion Slots

Expansion SlotsExpansion Slots

• 1 CNR slot (shares 1 PCI slot) (optional).

• 1 AGP slot (supports only 1.5V AGP card).

• 6 PCI bus master slots - ver. 2.1 compliant (1 PCI shares with CNR slot).

CAUTION

Static electricity can harm delicate components of the motherboard. To prevent damage caused by static electricity, discharge the static electricity from your body before you touch any of the computers electronic components.

Technical Reference Booklet

Motherboard LayoutMotherboard Layout

Motherboard Layout

Motherboard LayoutMotherboard Layout

The following diagrams show the relative positions of the jumpers, connectors, major components and memory banks on the motherboard.

If you are using standard ATX power supply (without P4 12V power connector), you MUST connect a peripheral power plug (the plug supplying power to HDD / CDROM) into JP4. Thus you can use either ATX 12V power supply or standard ATX power supply for this motherboard (Noted : NOT all kinds of standard ATX power supply are guaranteed to be applicable in this motherboard.).

NOTE

1) Be sure to check the cable orientation in order to match the colored strip to the pin 1 end of the connector.

2) When you start up the system, please wait for 5 seconds after you power on AC.

3) It is not recommended to add a metal spacer plate on the back of the Socket478. Otherwise, some components will be short and damaged.

Hardware Configuration

Jumper SettingsJumper Settings

Jumper Settings

Jumper SettingsJumper Settings

This chapter explains how to configure the motherboard’s hardware. Before using your computer, make sure all jumpers and DRAM modules are set correctly. Refer to this chapter whenever in doubt.

EDS1

J8H1

CPU Speed SelectionCPU Speed Selection

CPU Speed Selection

CPU Speed SelectionCPU Speed Selection

In this motherboard, jumperless feature is implemented such that no jumper is required to be set for different type of CPU installed.

Notice:

1. Be sure to save the CMOS setting when exit the CMOS.

2. If the CPU is frequency multiplier locked, no CPU speed change will be seen even if the frequency multiplier setting in CMOS setup is changed.

EDS1 - On Board AC97 Codec SoundEDS1 - On Board AC97 Codec Sound

EDS1 - On Board AC97 Codec Sound

EDS1 - On Board AC97 Codec SoundEDS1 - On Board AC97 Codec Sound

EDS1 Function

2-3 AC97 Sound Disable 1-2* AC97 Sound Enable*

J8H1 - CMOS ClearJ8H1 - CMOS Clear

J8H1 - CMOS Clear

J8H1 - CMOS ClearJ8H1 - CMOS Clear

J8H1 Selection

1-2* Normal* 2-3 CMOS Clear

JVSB1 - Keyboard Power SelectJVSB1 - Keyboard Power Select

JVSB1 - Keyboard Power Select

JVSB1 - Keyboard Power SelectJVSB1 - Keyboard Power Select

JVSB1 Select

2-3 Powered by +5V 1-2* Powered by +5V Standby*

(Allows Keyboard Power On)

JVSB1

1 2 3 4 5 6

SW1

Technical Reference Booklet

Close Open

* = Default setting.

SW1 - Code to VSW1 - Code to V

SW1 - Code to V

SW1 - Code to VSW1 - Code to V

oltage Definition (optional)oltage Definition (optional)

oltage Definition (optional)

oltage Definition (optional)oltage Definition (optional)

SW1[1:6] VCC_CORE SW1[1:6] VCC_CORE

1 2 3 4 5 6

Off 1.500

1.100 1.525

1 2 3 4 5 6

1.125 1.550

1 2 3 4 5 6

1.150 1.575

1 2 3 4 5 6

1.175 1.600

1 2 3 4 5 6

1.200 1.625

1.225 1.650

1.250 1.675

1.275 1.700

1.300 1.725

1 2 3 4 5 6

1.325 1.750

1 2 3 4 5 6

1.350 1.775

1 2 3 4 5 6

1.375 1.800

1 2 3 4 5 6

1.400 1.825

1 2 3 4 5 6

1.425 1.850

1 2 3 4 5 6

1.450 Auto*

1 2 3 4 5 6

1.475

On Off * =Auto.

Hardware Configuration

Pin AssignmentPin Assignment

Pin Assignment

Pin AssignmentPin Assignment

Internal Audio Connector

UX1 : AUX1 : A

UX1 : A

UX1 : AUX1 : A

CDS2 : CD-INCDS2 : CD-IN

CDS2 : CD-IN

CDS2 : CD-INCDS2 : CD-IN

R G L GR G L G

R G L G

R G L GR G L G

USB ConnectorUSB Connector

USB Connector

USB ConnectorUSB Connector

JP4JP4

JP4

JP4JP4

UXUX

-IN-IN

-IN

-IN-IN

PinPin

1 AUX-L 2 GND 3 GND

4 AUX-R

PinPin

1 CD-R 2 GND 3 CD-L 4 GND

PinPin

1 VCC 2 GND 3 USBP14 USBP0+ 5 USBP1+ 6 USBP07 GND 8 VCC

PinPin

1 12V 2 GND 3 GND 4 VCC

AssignmentAssignment

Assignment

AssignmentAssignment

Assignment

AssignmentAssignment

Assignment

AssignmentAssignment

Assignment

AssignmentAssignment

CDS1 : CD-INCDS1 : CD-IN

CDS1 : CD-IN

CDS1 : CD-INCDS1 : CD-IN

CDS3 : CD-INCDS3 : CD-IN

CDS3 : CD-IN

CDS3 : CD-INCDS3 : CD-IN

G L G RG L G R

G L G R

G L G RG L G R

Front PanelFront Panel

Front Panel

Front PanelFront Panel

Sound ConnectorSound Connector

Sound Connector

Sound ConnectorSound Connector

LINEOUTR

10 9

MICIN

GND

PinPin

1 CD-L 2 GND 3 GND 4 CD-R

PinPin

1 GND 2 CD-L 3 GND 4 CD-R

CN1CN1

CN1

CN1CN1

AssignmentAssignment

Assignment

AssignmentAssignment

Assignment

AssignmentAssignment

LINEOUTL GND BIAS GND LINEINLLINEINR

Technical Reference Booklet Hardware Configuration

FP1

FRONT PANEL HEADER

HEADER 2x12

GND 24 KEYLOCK 22 GND 20

(3-pin/5-pin connector)

PWRLED+ 16

VCC

IRTX 10 GND 8

IRRX 6 GND 4

SUS+ 2

Hardware SetupHardware Setup

Hardware Setup

Hardware SetupHardware Setup

o Install DDR DIMMso Install DDR DIMMs

o Install DDR DIMMs

o Install DDR DIMMso Install DDR DIMMs

1. Locate the DDR DIMM sockets.

2. Holding the DDR DIMM by the edges, remove it from its antistatic package.

3. Make sure the clips at either end of the socket are pushed away from the socket.

X X

Clip

14 12

NC +

+ TX

- SW +SUS

SPKER

KEYLOCK

RST+

IrDA

LED -

HDD+

LED -

PWR+

SW -

21 GND

17 SPEAKER

15 GND 13 RST+ 11 HDDLED9 HDDLED+ 7 PWRLED-

5 PWRLED+ 3 GND

1 PWR+

DDR DIMM

VCC

Clip

DDR DIMM Socket

Notch

4. Position the DDR DIMM above the socket. Align the notch in the bottom edge of the DDR DIMM with the keys in the socket.

5. Insert the bottom edge of the DDR DIMM into the socket.

6. When the DDR DIMM is seated, push down on the top edge of the DDR DIMM until the retaining clips at the ends of the socket snap into place. Make sure the clips are firmly in place.

Turn system power off before installing and removing any device, otherwise you’ll cause the system damage.

Hardware Configuration

1010

Installing a New ProcessorInstalling a New Processor

Installing a New Processor

Installing a New ProcessorInstalling a New Processor

An upgrade processor can dramatically increase general system speed and performance. Most microprocessor upgrade kits include the following items:

• Microprocessor chip

• Installation instructions and technical data

Before installing the processor, please refer to the installation notes that available with the CPU package.

o Install a Processor to ZIF Socko Install a Processor to ZIF Sock

o Install a Processor to ZIF Sock

o Install a Processor to ZIF Socko Install a Processor to ZIF Sock

To install the processor, follow these steps:

1. If the system microprocessor is already on the motherboard socket, you need to remove it from the motherboard socket. The socket is a Zero Insertion Force (ZIF) socket which has a metal arm at one side. Carefully grasp this arm, move it horizontally away from the socket and lift it up. Eventually you will be able to lift the chip straight up out of the socket. Be careful not to bend any pins.

Be careful not to bend any of the pins when removing the microprocessor chip from its socket. The microprocessor chip can be permanently damaged.

2. Unpack the new microprocessor chip.

3. Carefully align the processor with the correct orientation to the socket on the motherboard.

4. Carefully insert the processor into the socket, and move the metal arm downward to replace it in its original position.

etet

Connect the Processor Fan ConnectorConnect the Processor Fan Connector

Connect the Processor Fan Connector

Connect the Processor Fan ConnectorConnect the Processor Fan Connector

The CPU should always have a Heat Sink and cooling fan attached to prevent overheating.

Please follow the setup to install the Heat Sink and cooling fan. Then connect the processor fan cable to the fan connector that located on the motherboard near the processor and ensure the fan can operate. Otherwise the CPU can overheat and cause

damage to both CPU and motherboard.

Setting the Processor SpeedSetting the Processor Speed

Setting the Processor Speed

Setting the Processor SpeedSetting the Processor Speed

After you install the processor into the motherboard, set the processor speed by CMOS setup.

Technical Reference Booklet

1111

BIOS SetupBIOS Setup

BIOS Setup

BIOS SetupBIOS Setup

This chapter discusses Award’s Setup Program built into the ROM BIOS. The Setup Program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM, which retains the setup information when the power is turned off.

Starting SetupStarting Setup

Starting Setup

Starting SetupStarting Setup

The Award BIOS is immediately activated when you turn on the computer. The BIOS reads the system information contained in the CMOS and begins the process of checking out the system and configuring it. When it finishes, the BIOS will seek an operating system on one of the disks and then launch and turn control over to the operating system.

While the BIOS is in control, the Setup Program can be activated :

1. By pressing <Del> immediately after switching the system on, or

2. By pressing the <Del> key when the following message appears briefly at the bottom of the screen during the POST (Power On Self Test )

Press DEL to enter SETUPPress DEL to enter SETUP

Press DEL to enter SETUP

Press DEL to enter SETUPPress DEL to enter SETUP

If the message disappears before you can respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the “RESET” button on the system case. You may also restart by simultaneously pressing the <Ctrl>, <Alt>, and <Delete> keys. If you do not press the keys at the correct time and the system does not reset, an error message will be displayed and you will again be asked to ...

PRESS F1 TO CONTINUE, DEL TO ENTER SETUPPRESS F1 TO CONTINUE, DEL TO ENTER SETUP

PRESS F1 TO CONTINUE, DEL TO ENTER SETUP

PRESS F1 TO CONTINUE, DEL TO ENTER SETUPPRESS F1 TO CONTINUE, DEL TO ENTER SETUP

Getting HelpGetting Help

Getting Help

Getting HelpGetting Help

Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window press <Esc> or the F1 key again.

In Case of ProblemsIn Case of Problems

In Case of Problems

In Case of ProblemsIn Case of Problems

If, after making and saving system changes with the Setup Program, you discover that your computer does not reset, use the Award BIOS defaults to override the CMOS settings.

BIOS Setup

1212

Main MenuMain Menu

Main Menu

Main MenuMain Menu

Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from various setup functions and two exit choices. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu.

Standard CMOS Features



Advanced BIOS Features Load Fail-Safe Defaults



Advanced Chipset Features Load Optimized Defaults



Integrated Peripherals Set Supervisor Password



Power Management Setup Set User Password



PnP/PCI Configurations Save & Exit Setup



PC Health Status Exit Without Saving



Esc : Quit  : Select Item F10 : Save & Exit Setup

Time, Date, Hard Disk Type ... ...

(Note : The figures of BIOS Setup Menu included here only show a typical case, and may not be exactly the same as the one on your unit.)

Note that a brief description of each highlighted item will appear at the bottom of the screen.

Standard This setup page includes all the items of Award™ special standard CMOS Features features.

Frequency/Voltage Control



Advanced BIOS This setup page includes all the items of Award™ special enhanced Features features.

Advanced This setup page includes all the items of chipset special features. Chipset Features

Integrated This section page includes all the items of IDE hard drive and Peripherals Programmed Input / Output features.

Power This entry only appears if your system supports Power Management Management “Green PC” standards. Setup

PNP/PCI This entry appears if your system supports PNP/PCI. Configurations

PC Health Status Display CPU and Case Fan Speed. Frequency/ CPU speed setting are settings of CPU speed. You should refer to

Voltage Control your CPU marking.

Technical Reference Booklet

1313

Load Fail-Safe The BIOS defaults have been set by the manufacturer and represent Defaults settings which provide the minimum requirements for your system

Load Optimized The chipset defaults are settings which provide for maximum Defaults system performance. While Award has designed the

Set Supervisor/ Changes, sets, or disables password. It allows you to limit User Password access to the system and the Setup Program.

Save & Exit Saves value changes to CMOS and exits setup. Setup

Exit Without Abandons all CMOS value changes and exits setup. Saving

Standard CMOS FeaturesStandard CMOS Features

Standard CMOS Features

Standard CMOS FeaturesStandard CMOS Features

The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes one or more setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> key to select the desired value in each item.



to operate.

custom BIOS to maximize performance, the manufacturer has the right to change these defaults to meet its needs.

hh ss



 Move Enter

(Note : The figures of BIOS Setup Menu included here only show a typical case, and may not be exactly the same as the one on your unit.)

BIOS Setup

1414

Date The date format is <day-of-the-week>. <month> <day> <year>. Time The time format is <hour> <Minute> <second> displayed in

Primary These categories identify the types of the two channels that Master/Primary have been installed in the computer. Slave/Secondary Master/Secondary If the controller of the HDD interface is SCSI, the selection shall

Drive A Type / This category identifies the types of floppy disk drive A or drive Drive B Type B that has been installed in the computer.

Video The default setting is EGA/VGA. Halt on You can select which type of error will cause the system to halt.

Advanced BIOS FeaturesAdvanced BIOS Features

Advanced BIOS Features

Advanced BIOS FeaturesAdvanced BIOS Features

This section allows you to configure your system for basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security.

Advanced Chipset FeaturesAdvanced Chipset Features

Advanced Chipset Features

Advanced Chipset FeaturesAdvanced Chipset Features

The Chipset Features Setup option is used to change the values of the chipset registers. These registers control most of the system options in the computer.

This section allows you to configure the system based on the specific features of the installed chipset. This chipset manages bus speeds and access to system memory resources, such as DRAM and the external cache. It must be stated that these items should not be altered. The default settings have been chosen because they provide the best operating conditions for your system.

Integrated PeripheralsIntegrated Peripherals

Integrated Peripherals

Integrated PeripheralsIntegrated Peripherals

The Integrated Peripherals Setup allows the user to configure the onboard IDE controller, floppy disk controller, the printer port and the serial ports.

Power Management SetupPower Management Setup

Power Management Setup

Power Management SetupPower Management Setup

The Power Management Setup Menu allows you to configure your system to most save energy while operating in a manner consistent with your own style of computer use.

PNP/PCI ConfigurationsPNP/PCI Configurations

PNP/PCI Configurations

PNP/PCI ConfigurationsPNP/PCI Configurations

This section describes how to configure the PCI bus system. This section covers some very technical items and it is recommended that only experienced users should make any changes to the default settings.

PC Health StatusPC Health Status

PC Health Status

PC Health StatusPC Health Status

The PC Health Status display CPU and Case Fan Speed.

Frequency/VFrequency/V

Frequency/V

Frequency/VFrequency/V

This section allows you to set CPU Speed.

24-hour military-time clock. For example, 1 p. m. is displayed as 13:00:00.

be “None”.

oltage Controloltage Control

oltage Control

oltage Controloltage Control

Technical Reference Booklet

1515

Set Supervisor/User PasswordSet Supervisor/User Password

Set Supervisor/User Password

Set Supervisor/User PasswordSet Supervisor/User Password

You can set either supervisor or user password, or both of them. The difference between them are:

Supervisor Password : You can enter the Setup Program and change

the options of the setup menus.

User Password : You can enter the Setup Program but can not

change the options of the setup menus.

When you select this function, the following message will appear at the center of the screen to assist you in creating a password.

ENTER PENTER P

ENTER P

ENTER PENTER P

Type the password, up to eight characters in length, and press<Enter>. The new password will clear the previously entered password from the CMOS memory. You will be asked to confirm the password. Type the password again and press <Enter>. You may also press <Esc> to abort the selection and operate without a password.

To disable a password, just press <Enter> when you are prompted to enter the password. A message will be displayed to confirm that the password is disabled.

ASSWORD DISABLEDASSWORD DISABLED

ASSWORD DISABLED

ASSWORD DISABLEDASSWORD DISABLED

Once the password is disabled, the system will reset and you can enter the Setup Program freely.

When a password is enabled, you will be prompted to enter it every time you try to enter setup. This prevents an unauthorized person from changing any setting of your system configuration.

In addition, when a password is enabled, you can require the BIOS to request a password every time your system is rebooted. This would further prevent unauthorized use of your computer.

The password requirement is defined by the Security Option of the BIOS Features Setup Menu. If the Security Option is set to “System”, the password will be required both at resetting and at entering setup. If the option is set to “Setup”, the prompt only appears when you try to enter setup.

ASSWORDASSWORD

ASSWORD

ASSWORDASSWORD

BIOS Setup

1616

Flash Update ProcedureFlash Update Procedure

Flash Update Procedure

Flash Update ProcedureFlash Update Procedure

A program AWDFLASH.EXE is included in the utility diskette or CD (X:\Utility\ AWDFLASH.EXE). The user is recommended to follow the procedure below to update the flash BIOS. (X: your CD driver letter).

1. Create a DOS-bootable floppy diskette. Copy the new BIOS file (just obtained or downloaded) and the utility program AWDFLASH.EXE to the diskette.

2. Allow the PC system to boot from the DOS diskette.

3. At the DOS prompt, key in

AWDFLASHAWDFLASH

AWDFLASH

AWDFLASHAWDFLASH

and hit <ENTER>

4. Enter the file name of the new BIOS.

5. The question: “Do you want to save BIOS (Y/N)?” is displayed.

Key in “N” if there is no need to save the existing BIOS content.. Key in “Y” if a backup copy of the existing BIOS is needed. (A file name has to be assigned to the existing BIOS binary file.)

6. The question : “Are you sure to program (Y/N)?” is displayed.

Key in “Y”

7. Wait until the flash-update is completed.

8. Power down the PC system.

9. Restart the PC.

Warning:

DO not turn off or RESET the computer during the flash process. If you are unsure how to upgrade the BIOS, it is best to take your

computer to an Authorized Service Center and have a trained technician do the work for you.

APPENDIXAPPENDIX

APPENDIX

APPENDIXAPPENDIX

Note to User:Note to User:

Note to User:

Note to User:Note to User:

The bundled driver CD attached an Auto-Run feature for all the drivers that the motherboard need. Please select the drivers that you want to install and click the button on the installation panel.
