Insignia NS-32E570A11 User Manual

User Guide

32" LED-LCD HDTV, 1080p

NS-32E570A11

Contents

CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Install the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using the remote control holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Programming your existing universal remote control to work with your TV . . . . . . . 8

Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Connecting power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting an antenna or cable TV without a cable box . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting an HDMI device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Connecting a component video device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Connecting a USB device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Connecting a digital sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Viewing channel information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Fitting the picture to the screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

www.insigniaproducts.com

Contents

Selecting the audio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Selecting the analog closed captioning mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Customizing digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Selecting the menu language and transparency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Using INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Turning Game Mode on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Restoring settings to the defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Viewing favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Viewing photos in a slide show . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Customizing slide show settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Video and audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Two-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

US and Canada Markets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Mexico Market . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

www.insigniaproducts.com

iii

Contents

www.insigniaproducts.com

It makes a difference how and where you use

As you enjoy your new product, keep these

The issue

The home theater entertainment experience is a growing trend, and larger TVs are popular purchases. However, TVs are not always supported on the proper stands or installed according to the manufacturer’s recommendations. We and the consumer electronics industry are committed to making home entertainment enjoyable and safe.

TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or carts may fall over and cause injury.

Tune into safety

• One size of TV stand does not fit all. Use only a TV stand

rated for the weight of your TV.

• Carefully read and understand all enclosed instructions

for proper use of this product.

• Don’t let children climb on or play with entertainment

system furniture and TVs.

• Don’t place TVs on furniture that can easily be used as

steps, such as a crate or chest of drawers.

• Remember that children can become excited while

watching a program, especially on a “larger-than-life” TV. Make sure that you place or install the TV where it cannot be pushed, pulled over, or knocked down.

• Make sure that you route all cords and cables so that they

cannot be pulled or grabbed by curious children.

CHILD SAFETY

your flat panel display

safety tips in mind

Wall mounting

If you decide to wall mount your TV, always remember:

• One size of wall mount does not fit all. Use only a wall mount rated for the weight of

your TV and that has been recommended by this TV manufacturer, listed in this manual, or otherwise listed by an independent laboratory as suitable for your TV.

• Follow all instructions supplied by the TV and wall mount manufacturers.

• If you have any doubts about your ability to safely wall mount your TV, get help from a

professional installer.

• Make sure that the wall where you are mounting the TV is

appropriate. Some wall mounts are not designed to be mounted to walls backed with steel studs or cinder blocks. If you are unsure, ask a professional installer.

• TVs can be heavy. At least two people are required for safe wall mount installation.

www.insigniaproducts.com

NS-32E570A11

Important safety instructions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your TV. This label is located on the back of your TV.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your TV.

1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this apparatus near water. 6 Clean only with a dry cloth. 7 Do not block any ventilation openings. Install in

accordance with the manufacturer's instructions.

8 Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9 Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11 Only use attachments/accessories specified by

the manufacturer.

12 Use only with a cart, stand, tripod,

bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms

or when unused for long periods of time.

14 Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

S3125A

15 The wall plug is the disconnecting device. The

plug must remain readily operable.

16 An apparatus with three-prong, grounding-type

plug is a Class I apparatus. Class I apparatus which needs to be grounded to prevent possible electric shock. Make sure that you connect the Class I apparatus to a grounding-type, three-prong outlet.

17 Remote control batteries should not be exposed

to excessive heat such as sunshine, fire, or the like.

18 The apparatus should not be exposed to

dripping or splashing, and no objects filled with liquids, such as vases, should be placed on the apparatus.

Warnings

Electric shock hazard

To reduce the risk of fire or electric shock, do not remove any cover or expose the device to rain or moisture. No user-serviceable parts are inside. Refer servicing to qualified service technicians.

Lightning

For added protection for your device receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the power outlet and disconnect any antenna or cable system. This helps prevent property damage and personal injury from lightning and power line surges.

Power lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Handling the LCD panel

• Your TV’s screen is made of glass. Do not drop your TV or hit, jolt, or press hard against the LCD panel. If the screen breaks, be careful of broken glass.

• If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inflammation.

• If the liquid gets in your mouth, immediately gargle, rinse, and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

Replacement parts

When replacement parts are required, make sure that the service technician uses replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, personal injury, or other hazards.

Safety check

After completing any service or repair to this device, ask the service technician to perform routine safety checks to determine that your TV is in correct operating condition.

www.insigniaproducts.com

Power source

Operate your TV only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult an electrician or your local power company.

Cautions

Damage requiring service

Unplug this TV from the power outlet and refer servicing to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If liquid has been spilled or objects have fallen into your TV.

• If your TV has been exposed to rain or water.

• If your TV does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions because incorrect adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore your TV to its normal operation.

• If your TV has been dropped or damaged in any way.

• When your TV exhibits a distinct change in performance.

Outdoor antenna grounding

If an outside antenna or cable system is connected to your TV, make sure that the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to correct grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of the antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Note to CATV system installer

Article 820 of the National Electrical Code, ANSI/NFPA No. 40 provides guidance for correct grounding. Specifically, it states that the cable ground must be connected to the grounding system of the building as close to the point of cable entry as practical.

Condensation

Moisture will form on the TV if the TV is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, the TV's performance may be impaired. To prevent this, let the TV stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually.

Condensation may also form during the summer if the TV is exposed to the breeze from an air conditioner. In such cases, change the location of the TV.

Mobile telephone warning

To avoid interference with your TV picture and sound, operating problems, or even damage, keep your cordless and cellular telephones away from the TV.

End of life directives

Your TV contains tin-lead solder and a fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated for environmental reasons. Your TV also contains material that can be recycled and reused. For disposal or recycling information, contact your local authorities or the Electronic Industries Alliance at www.eia.org to find a recycler in your area.

Non-active pixels

The LCD panel contains almost 3 million thin film transistors, which provide exceptionally sharp video quality. Occasionally, a few non-active pixels may appear on the screen as a fixed blue, green, or red point. These non-active pixels do not adversely affect the performance of your TV, and are not considered defects.

Antenna lead-in wire

Grounding clamp

Antenna discharge unit

Grounding conductors

Ground clamps

Power service grounding electrode system

Electric service equipment

www.insigniaproducts.com

NS-32E570A11 Insignia 32" LED-LCD HDTV, 1080p

Insignia 32" LED-LCD HDTV, 1080p

Introduction

Congratulations on your purchase of a high-quality Insignia product. Your NS-32E570A11 represents the state of the art in LED-LCD HDTV design and is designed for reliable and trouble-free performance.

AUDYSSEY Dynamic Volume plus Dynamic EQ:

Have you ever caught yourself wishing that you didn't constantly need to adjust the volume: wishing that the commercials wouldn't blare and that you could better hear whispering during a movie scene? Audyssey Dynamic Volume is a feature that lets you put the remote control down and enjoy your show while Audyssey adjusts the sound levels for you automatically. Audyssey Dynamic EQ is a feature that automatically finds the richest sound settings-including enhanced bass-for each scene, even when the volume level is held steady, making the sound coming from your TV speakers sound more lifelike. See page 18 for instructions on how to adjust the audio settings to take advantage of Audyssey.

SRS TruSurround HD:

At Insignia, providing you with superior audio quality is just as important as exceptional picture quality. That's why we added SRS TruSurround HD, which provides you with a theater-like surround-sound experience, with the clearer dialog and the enhanced bass sounds that movie viewers and gamers crave.

Insignia Motion 120Hz:

With a 120 Hz screen refresh rate twice the rate of a 60 Hz screen, a screen with 1,080 lines of resolution (up from 720 lines in the last generation of HDTVs), and special motion-detection technology, you will be experiencing a picture with clearer detail and brightness, smoother transitions, and reduced motion blurring, particularly when watching fast-motion sports and action scenes. (See page 17 for instructions on how to adjust the TV picture)

Game mode:

Video games generally require adjustments to the television picture settings to get the maximum experience. By simply pressing a button on your remote control, your television settings will automatically adjust for video games. It couldn't be easier. (See page 24 for instruction on how to turn Game Mode on and off)

INlink:

Enjoy the benefit of having HDMI CEC compatible products plug and play! No setup is needed! CEC technology lets different components discover and communicate with each other. (See page 31 for instructions on how to use INlink)

www.insigniaproducts.com

Insignia 32" LED-LCD HDTV, 1080p

Install the stand or wall-mount bracket

Installing the stand

To install the stand:

1 Carefully place your TV screen face-down on a

cushioned, clean surface to protect the screen from damages and scratches.

Cushion

Installing a wall-mount bracket

Note

To avoid interference between the jacks, wall-mount bracket, and wall, the wall-mount bracket must be more than 40 mm thick, and the RF or VGA cable must have a 90-degree plug.

To attach your TV to a wall-mount bracket:

1 If the stand is attached to your TV, carefully

place your TV screen face-down on a cushioned, clean surface to protect the screen from damages and scratches.

2 Remove the four screws holding the TV to its

stand, then remove the stand.

Screws

Stand

2 Slide the stand into the stand grove, then secure

the stand to the screen with the four provided screws.

Stand groove

Screws

Stand

3 Secure the wall-mount bracket to the back of

your TV using the M6 screws provided with bracket.

7.84 in. (200 mm)

Wall mount brackets

TV components

Accessories

• Remote control

• Remote control holder

• Batteries (2 AAA)

•Power cord

•Component cable

•Audio cable

• Cleaning cloth

• TV stand and screws

• Quick Setup Guide

www.insigniaproducts.com

Front Back

# Item Description

Remote control sensor Receives signals from the remote control. Do not block.

Lights blue when your TV is turned on.

Power indic ator

Lights red when your TV is in standby mode. Turns off when the power cord is unplugged.

# Item Description

MENU Press to open the on-screen menu.

INPUT Press to select the video input source.

VOL –/VOL + Press to decrease or increase the volume.

CH /CH

(power)

Press to go to the next or previous channel in the channel list.

Press to turn on your TV. Press again to put your TV in standby mode.

When your TV is in standby mode, power still flows through it. To completely disconnect power, unplug the power cord.

NS-32E570A11 Insignia 32" LED-LCD HDTV, 1080p

Connect headphones to this jack. For more

(headphone)

HDMI1/HDMI2/ HDMI3/HDMI4

USB

AUDIO IN

COMPONEN T IN

ANT/CABLE IN

VGA IN (VGA and PC/DVI AUDIO IN) jacks

DIGITAL OUTPUT

information, see “Connecting headphones” on page 12.

Connect an HDMI devices to this jacks. An HDMI cable carries both video and sound. You do not need to make an audio connection for an HDMI device.

For more information, see “Connecting an HDMI device” on page 10.

Connect a USB device, such as USB flash drive, to this jack. For more information, see “Connecting a USB device” on page 12.

Connect the audio for a component video device to these jacks. For more information, see “Connecting a component video device” on page 11.

Connect the video for a component video device to these jacks. For more information, see “Connecting a component video device” on page 11.

Connect an antenna, cable TV, or satellite TV box to this jack. For more information, see “Connecting an antenna or cable TV without a cable box” on page 9.

Connect the video and audio for a computer to these jacks. For more information, see “Connecting a computer” on page 11.

Connect a digital optical sound system to this jack to send the TV audio through the sound system. For more information, see “Connecting a digital sound system” on page 13.

www.insigniaproducts.com

Insignia 32" LED-LCD HDTV, 1080p

Remote control

# Button Description

Press to turn on your TV. Press again to put your TV in standby mode.

(power)

FAV

SLEEP

Numbers

INFO

VOL+/VOL– Press to increase or decrease the volume.

GUIDE

MUTE

ENTER

When your TV is in standby mode, power still flows through it. To completely disconnect power, unplug the power cord.

Press to open the favorite channel list. For more information, see “Viewing a favorite channel” on page 21.

Press to set the sleep timer. For more information, see “Setting the sleep timer” on page 29.

Press to enter channel numbe rs or the parental control password.

Press to select a digital sub-channel. For more information, see “Selecting a channel” on page 16.

Press to display the channel banner. For more information, see “Viewing channel information” on page 16.

Press to open the program guide for digital channels (if available). For more information, see “Viewing channel information” on page 16.

Press to turn off the sound. Press again to turn the sound back on.

Press to navigate in on-screen menus. For more information, see “Navigating the menus” on page 15.

Press to open a sub-menu or to confirm selections in the on-screen menus. For more information, see “Navigating the menus” on page 15.

# Button Description

MENU Press to open the on-screen menu.

Press repeatedly to toggle between the Audyssey

AUDIO


MTS/SAP

TV Press to select the TV as the video input source.

INPUT

RECALL Press to go to the last viewed channel.

CH+/CH–

GAME

EXIT Press to close the on-screen menu.

CCD

ZOOM

INlink control buttons

Dynamic Volume, SRS TruSurround HD, Treble, Bass and Balance settings screens where you can adjust the settings.

Press to select the picture mode. For more information, see “Adjusting the TV picture” on page 16.

Press to select the audio mode for an analog channel. Press to select the audio track for a digital channel if

more than one audio track is available. For more information, see “Selecting the audio mode”

on page 19.

Press to open the Input Source list. For more information, see “Selecting the video input source” on page 14.

Press to go to the previous or next channel in the channel list. For more information, see “Selecting a channel” on page 16.

Press to turn on Game Mode for video games. Game Mode is only available when the input source is Component, VGA, HDMI 1, HDMI 2, HDMI 3, or HDMI 4.

Press to turn closed captioning on or off. For more information, see “Turning closed captioning on or off” on page 27.

Press to select the aspect ratio. For more information, see “Adjusting the TV picture” on page 16.

Press these buttons to control the basic playback functions of an HDMI CEC compatible device that is connected to your TV. For more information, see “Using INlink” on page 31.

Note: The actual functions of t he INlink control buttons may vary depending on the devices connected.

Using the remote control

Installing remote control batteries

To install the remote control batteries:

1 While pressing the release button on the battery

compartment cover on the back of the remote, lift the cover off the remote.

www.insigniaproducts.com

NS-32E570A11 Insignia 32" LED-LCD HDTV, 1080p

2 Insert two AAA batteries into the battery

compartment. Make sure that the + and – symbols on the batteries align with the + and – symbols in the battery compartment.

3 Replace the cover.

Warnings

• Batteries should not be exposed to excessive heat, such as sunshine, heat registers, or fire.

• Battery chemicals can cause a rash. If the batteries leak, clean the battery compartment with a cloth. If chemicals touch your skin, wash immediately.

• Make sure that batteries are disposed of correctly. Do not burn or incinerate.

Notes

• Do not mix batteries of different types.

• Do not mix old and new batteries.

• Remove batteries when the charge is depleted.

• If the remote control is not going to be used for an extended period of time, remove the batteries.

Aiming the remote control

Using the remote control holder

Your TV comes with a remote control holder you can put the remote control in when you are not using it.

Programming your existing universal remote control to work with your TV

You can operate your Insignia TV with a new or existing universal remote control.

To program a universal remote control:

1 See the table below for common codes. If you

have problems programming your remote or need a different remote control code, visit www.insigniaproducts.com for the latest remote control code information.

Insignia TV codes for universal remote controls

(for all Insignia TVs manufactured after Jan. 1, 2007)

Universal remote control makes and models

Philips PHDVD5,

PH5DSS,

PMDVR8, PDVR8

115 135 0464

RCA

RCU807

One for All URC-6690

Sony

RM-VL600

8043

To aim the remote control:

• Point the remote control toward the remote control sensor on the front of your TV.

Notes

• Do not expose the remote control to shock.

• Do not expose the remote control to liquids and do not use the remote control in an area with high humidity.

• Do not place the remote control in areas of high heat or direct sunlight. The heat may warp the battery case.

• The remote control may not work correctly if sunlight or bright light is shining on the remote control sensor. To correct this problem, move your TV or use the remote control closer to the remote control sensor.

Comcast

M1057

0463 720 0463 0091 10463

Codes for other remote controls are available online at:

www.insigniaproducts.com

Tips

www.insigniaproducts.com

Set-top box makes and models

Dish Network

VIP508, VIP622

• The brand name is often visible on the front of the universal remote control, and the model number is often visible on the back.

• If your universal remote control isn’t listed on the chart, refer to your universal remote control’s instructions and try codes for the brands Orion, Emerson, Memorex, Sansui, Sylvania, or Zenith. You may need to try several codes before finding a match.

Motorola

DRC800

TIVO

Series 3, HD

DirectTV

RC23

Insignia 32" LED-LCD HDTV, 1080p

2 Follow your universal remote control’s

instructions to enter the TV code you found in Step 1.

Tips

• If your universal remote control has a code search feature, run a code search to identify a code that matches your T V. See your universal remote control’s instructions for details.

• If your universal remote control has a “Learn” feature, you can manually program it using the Insignia TV remote to “teach” the commands one at a time. See your universal remote control’s instructions for details.

3 If all else fails, you must use a different universal

remote control that can operate both your set-top box and your TV. Four such remotes are listed on the chart, but many other compatible models are available in the market.

For more help, go to insigniaproducts.com or call technical support for your universal remote control or set-top box manufacturer, or call the Insignia Customer Care Center. For US and Canada markets, call 1-877-467-4289. For Mexico markets, call 01 800-926-3000 .

Making connections

Connecting an antenna or cable TV without a cable box

To connect an antenna or cable TV without a cable box:

1 Connect a coaxial cable (not provided) to the

ANT/CABLE IN jack on the back of your TV and

to the antenna or cable TV wall jack.

Back of TV

Antenna or cable TV wall jack.

Cautions

• Check the jacks for position and type before making any connections.

• Loose connections can result in image or color problems. Make sure that all connections are tight and secure.

• The external audio/video equipment shown may be different from your equipment. If you have questions, refer to the documentation that came with your equipment.

• Always unplug the power cord when connecting external equipment.

Connecting power

To connect the power:

• Plug the AC power cord into a power outlet.

Notes

• Your TV should only be operated from the power source indicated on the label.

• Always unplug the AC power cord from the power outlet when you will not be using your TV for an extended period of time.

Notes

• Use a coaxial cable to eliminate interference and noise from radio waves.

• Do not bundle the coaxial cable with the power cord or other cables.

• If the antenna is not installed correctly, contact qualified service personnel to correct the problem.

www.insigniaproducts.com

NS-32E570A11 Insignia 32" LED-LCD HDTV, 1080p

Connecting a cable or satellite box

Many cable or satellite TV boxes have more than one connection type. To get the best video, you should use the best connection type available.

Connection type Video quality

HDMI Best

Component Better than RF

RF Good

To connect a cable or satellite box:

1 Connect the incoming cable from the cable wall

jack to the cable-in jack on the cable or satellite TV box.

HDMI

Connecting an HDMI device

Note

If your device has an HDMI connection, we recommend that you use the HDMI connection to get the best quality possible.

To connect an HDMI device:

1 Make sure that your TV’s power cord is

unplugged and the HDMI device is turned off.

2 Connect an HDMI cable (not provided) to the

HDMI1, HDMI2, HDMI3, or HDMI4 jack on the

side of your TV and to the HDMI OUT jack on the HDMI device.

Side of TV

Component

Cable or satellite TV box

2 Depending on the jacks available on the cable

or satellite TV box, connect a cable (not provided) from the outgoing jacks on the cable or satellite TV box to the corresponding jacks on the side of your TV. The connection can be to an

HDMI jack or the COMPONENT IN jacks.

3 If you use the COMPONENT IN jacks, connect an

audio cable (not provided) to the AUDIO IN jacks.

Note

If the cable or satellite TV box does not have an HDMI or component jack, connect the cable or satellite TV box to the ANT/CABLE IN jack on the back of your TV. For more information, see “Connecting an antenna or cable TV without a cable box” on page 9.

HDMI device

To play from an HDMI device:

1 Turn on your TV, then press INPUT to open the

Input Source list.

2 Press or to select HDMI 1, HDMI 2, HDMI 3,

or HDMI4, then press ENTER.

3 Turn on the HDMI device, then set it to the

output mode. See the documentation that came with the device for more information.

Note

If the device only has a DVI jack, use a DVI-to-HDMI adapter to connect the DVI jack to an HDMI jack on your TV, then connect the audio to the PC/DVI AUDIO IN jack.

You can p ress INPUT repeatedly to select an HDMI device.

www.insigniaproducts.com

Insignia 32" LED-LCD HDTV, 1080p

Connecting a component video device

To connect a component video device:

1 Make sure that your TV’s power cord is

unplugged and the component video device is turned off.

2 Connect a component video cable (provided) to

the COMPONENT IN jacks on the side of your TV and to the COMPONENT OUT jacks on the component video device.

Side of TV

Component video device

Connecting a computer

Tip

Some computers have an HDMI jack. You can use an HDMI cable to connect the computer for a better picture.

To connect a computer:

1 Make sure that your TV’s power cord is

unplugged and the computer is turned off.

2 Connect a VGA cable (not provided) to the

VGA IN jack on the back of your TV and to the VGA jack on the computer.

Note

The VGA cable should be a 15-pin D-Sub (analog RGB) cable.

Back of TV

Component video cable

Cables are often color-coded to match colo r-coded jacks.

Audio cable

3 Connect an audio cable (not provided) to the

AUDIO IN jacks on the side of your TV and to the AUDIO OUT jacks on the component video

device.

To play from the component video device:

1 Turn on your TV, then press INPUT to open the

Input Source list.

2 Press or to select Component, then press

ENTER.

Note

You can also press INPUT repeatedly to select the component video device.

3 Turn on the component video device, then set it

to the output mode. See the documentation that came with the device for more information.

VGA cable

Audio cable with stereo mini plugs

3 Connect an audio cable with stereo mini plugs

to the VGA IN audio jack on the back of your TV and to the LINE OUT or AUDIO OUT jack on the computer.

To play video from the computer:

1 Turn on your TV, then press INPUT to open the

Input Source list.

2 Press or to select VGA, then press ENTER. 3 Turn on the computer and adjust the display

properties if necessary.

Note

You can also press INPUT repeatedly to select the computer.

www.insigniaproducts.com

+ 33 hidden pages
