Black Cabinet
Black cabinet
Print black straight line
line width1.6mm
Transparent window
Electroplate button
CD Door: silver
RC window
Fonts silkscreen colr
black
Transparent window
POWER FUNCTION
AUX IN
VOLUME BALANCE BASS
TREBLE
SCAN
IR
SPK OUTPUT
TUN- TUN+
DC 12V 2A
FM ANT.
R+ R- L- L+
Black speaker cloth
lectroplate button
Engraved fonts
lectroplate button
Silver faceplate
Fonts silkscreen color
black
Electroplate button
Black speaker cloth
Fonts silkscreen color white
Fonts are Arial Narrow, 6pt
所用字体ArialNarrow,粗体字.
字体大小6号
FUNC
PROG
REPEAT
R
SSAB SSABELBERT ELBERTECNALAB ECNALAB
L
TUN-
SCAN
TUN+
遥控器贴纸
大小: 33x15mm
材质: 不干胶贴纸
黑底白字.过光胶
用量: 1pc
RC rating label
Size:33x15mm
QTY=1PC
Manufac tu re d: 06 20 19
Manufac tu re d: 06 20 19
4
铭牌贴纸
尺寸: 102x74mm
不干胶贴纸, 双 色印刷
表面过光胶
用量: 1pc
位置: 贴机器后 板
190600001
SERI AL NO LAB EL
SIZE : 30x 5mm
PRIN TED I N BLA CK ON W HIT E BAC KGR OUN D
QTY= 1pc
流水号贴纸
尺寸: 30x5mm
不干胶贴纸, 白 底黑字
用量: 1pc
位置: 贴机器后 板
190601410
46 .5
CARB贴纸
大小: 40.5x46.5mm
不干 胶贴 纸,白底 黑字.过 光胶
字体: Myriad pro/Regular/Semi Bold
用量: 3pcs
1张贴 彩盒 侧面 条码 上放, 1张 贴机 背, 1张贴 卡通 侧唛
Warning Label for Power cord
Size: 65x13mm
Printed in black on white background，d
Qty=1pc
电源线警告贴纸
大小: 65x13mm
双色印刷
用量: 1pc
,不干胶贴纸,过光胶
ouble color printing
LABEL POSITION
贴纸 位置参考下 图
品号：32272170000511
主机胶袋
大小: 550x400mm(短边开口)
材质: PE(防静电),厚度0.05mm
印红字,打6孔
用量: 3pcs
Polybag for main unit
Size:550x400mm
Material:PE,thickness0.05mm
QTY=3PCS
IM polybag
Size:240*180mm
Materials:PE,thickness:0.03MM
QTY=1PCS
