Ingersoll-Rand 16574022 User Manual

Air Grinder and Die Grinders CD and CX Series, Horizontal

Part s Information

16574022

Edition 2

June 2006

Save These Instructions

CD and CX Grinder and Die Grinder Exploded Diagram

47

1

3

46

2

45

4A

4B

6A

4D

4C

4

7

CD200

13

CD250

CX200

5

CX250

10

11

9

CD300

CD350

CX300

12

12

8

6

21

22

23

13

34

35

36

37

30

27

ALL CD COLLET MODELS

38

28

30

29

40

39

ALL CX EXTENDED COLLET MODELS

32

33

ALL CD WHEEL MODELS

41

42

43

31

14

15

26A

16

BASIC CYCLONE POWER UNIT - ALL MODELS

44

17

19

19A

18

20

24

CD, CX MODELS

25

ALL

26

COLLET ASSEMBLY FOR

(Dwg. TPA1267-7)

2 16574022_ed2

CD and CX Grinder and Die Grinder Parts List

Item Part Description Part

Common parts for ALL CD and CX

1 Inlet Assembly LG1-A465A (20000 rpm) (grey) LG1-103-0
2 Inlet Screen R1602-61 for CD250 and CX250

• 3 Inlet Seal 85H-167 (25000 rpm) (brown) LG1-103-1
Throttle Valve Kit LG1-K300 for CD300 and CX300

4 Throttle Valve Case LG1-300A (30000 rpm) (khaki) LG1-103-2
4A Throttle Valve Spring Seat LG1-592 for CD350 (32000 rpm) (red) LG1-103-3
4B Throttle Valve Spring 7L-51 19 High Profile Flange LG1-23
4C Throttle Valve AG210-302 # 19A Low Profile Concentric Flange
4D Throttle Valve Seat LG1-303 (for all models ending in C or MC) LG1R-23
5 Motor Housing LG1-40 20 Flange Clamp LG1-29
6 Throttle Lever LG1-273 Additional p a rts
6A Locking Throttle Lever Assembly for all CD collet models

(standard equipment on models 21 Clamp Spacer LG1-46
ending in C, L, MC or ML; optional for 22 Clamp Nut LG1-27
all others) LG1-A400 23 Collet Body LG1-290

* Lever Lock LG1-402 Additional p art s for all collet models
* Lock Spring LG1-405 24 Collet
* Lock Pin 5UT-757 6 mm (-EU models) DG110-700-6mm

7 Throttle Lever Pin 61H-120 1/4” (standard domestic) DG110-700-G4
8 Throttle Valve Plunger LG1-191 1/8” (available at extra price) DG110-700-G2
9 Rear Rotor Bearing DG230-22 25 Nosepiece AG210-698A

• 10 Rear Rotor Bearing Spacer (2) DG20-278 26 Collet Nut AG210-699A

• 11 Rear Rotor Bearing Retainer LG1-118 26A Collet Wrench (11/16” x 7/16” )

12 Rotor (included with all models) (2) DG20-69A

• 13 Vane Packet (set of 5 Vanes) LG1-42-5 28 Clamp Sleeve LE1-276

14 Front End Plate LG1-11 29 Rear Arbor Bearin g AG210-24
15 Front End Plate Spacer DG10-65-5 30 Arbor Bearing Nut (2) LE1-85

• 16 Front Seal Cup LG1-32 31 Extension Arbor LE1-4A-3

17 Front Rotor Bearing LG1-24 32 Arbor Housing Assembly LE1-A20-3

Grinders

for CD300, CX300 and Additional parts for all
CD350 (3 slots) LG1-53-3 extended CX collet models
for all others (5 slots) LG1-53-5 27 Arbor Coupling LE1-304

Number

Item Part Description Part Number

18 Flow Ring

for CD200 and CX200

33 Front Arbor Bearing AGS241-511

* Not illustrated.

• To keep downtime to a minimum, it is desirable to have on hand certain repair parts. We recommend that you stock one

(pair or set) of each part indicated by a bullet (•) for every four tools in service.

WARNING

# Always install a Locking Throttle Lever Assembly (6A) on a tool with a Low Profile Concentric Flange (19A). Do not

equip a tool with a standard non-locking Throttle Lever (6) and Low Profile Concentric Flange. This can allow the tool
to continue to run if dropped or set down.

† When ordering a Piped-Away Exhaust Kit, m ake cer tain the wrench hex on the Inlet Assembly of your tool is threaded . If it is

NOT threaded, order a new Inlet Assembly (Part No. LG1-A465A).

+ Standard equipment on models ending in M, MC or ML and ALL Front Exhaust models; optional equipment on all other

models.
