Infinity QX30 2017 User Manual

For your safety, read carefully and keep in this vehicle.

2017 Infiniti QX30

Owner’s Manual and Maintenance Information

Owner’s Manual Supplement

The information contained within this supplement revises “Checking tire pressure” information in the “Do–it–yourself” section of the 2017 INFINITI QX30 Owner’s Manual and Maintenance Information.

Read carefully and keep in vehicle

Printing: September 2016 (01)

Publication No. SU17E0 0H15U0

LDI0393

CHECKING TIRE PRESSURE

1. Remove the valve stem cap from the tire.

2. Press the pressure gauge squarely onto the valve stem. Do not press too hard or force the valve stem sideways, or air will escape. If the hissing sound of air escaping from the tire is heard while checking the pressure, reposition the gauge to eliminate this leakage.

3. Remove the gauge.

4. Read the tire pressure on the gauge stem and compare it to the specification shown on the Tire and Loading Information label.

5. Add air to the tire as needed. If too much air is added, press the core of the valve stem briefly with the tip of the gauge stem to release pressure. Recheck the pressure and add or release air as needed.

6. Install the valve stem cap.

7. Check the pressure of all other tires, including the spare.

Tire Size

235/ 50R18

235/45R19

Spare Tire NONE

(2WD)

(4WD/ AWD)

Cold Tire Inflation Pressure

Front Rear

35psi

(240kPa)

35psi

(240kPa)

32psi

(220kPa)

35psi

(240kPa)

29psi

(200kPa)

32psi

(220kPa)

Owner’s Manual Supplement

The information contained within this supplement updates the following information in the 2017 and 2018 INFINITI QX30 Owner’s Manual

In “ CHILD SAFETY REAR DOOR LOCK" in the “Pre-driving checks and

adjustments” section of the Owner’s Manual.

Read carefully and keep in vehicle.

Printing: March 2018

Publication No. SU18E0 0H15U0

CHILD SAFETY REAR DOOR LOCK

The child safety rear door locks help prevent doors from being opened accidentally, especially when small children are in the vehicle.

When the switch (lever) is in the LOCK position, the child safety rear door can only be opened from the outside door handles.

To disengage, move the switch(lever)to the unlock position

䊊

LSU2010

FOREWORD

Your INFINITI represents a new way of thinking about vehicle design. It integrates advanced engineering and superior craftsmanship with a simple, refined aesthetic sensitivity associated with traditional Japanese culture.

The result is a different notion of luxury and beauty. The car itself is important, but so is the sense of harmony that the vehicle evokes in its driver, and the sense of satisfaction you feel with the INFINITI — from the way it looks and drives to the high level of retailer service.

To ensure that you enjoy your INFINITI to the fullest, we encourage you to read this Owner’s Manual immediately. It explains all of the features, controls and performance characteristics of your INFINITI; it also provides important instructions and safety information.

A separate Warranty Information Booklet is included in your Owner’s literature portfolio. Always carry it with you when you take your vehicle to an INFINITI retailer. The Warranty Information Booklet contents provide complete information about all warranties covering this vehicle, the requirements to keep the warranties in effect as well as the INFINITI Roadside Assistance Program.

Additionally, a separate Customer Care and Lemon Law Information Booklet will explain how to resolve any concerns you may have with your vehicle, as well as clarify your rights under your state’s lemon law.

In addition to factory-installed options, your vehicle may also be equipped with additional accessories prior to delivery. It is recommended that you visit an INFINITI retailer for this service. It is important that you familiarize yourself with all disclosures, warnings, cautions and instructions concerning proper use of such accessories prior to operating the vehicle and/or accessory. It is recommended that you visit an INFINITI retailer for details concerning the particular accessories with which your vehicle is equipped.

READ FIRST — THEN DRIVE SAFELY

Before driving your vehicle, read this Owner’s Manual carefully. This will ensure familiarity with controls and maintenance requirements, assisting you in the safe operation of your vehicle.

WARNING

Important safety information reminders!

Follow these important driving rules to help ensure a safe and complete trip for you and your passengers!

• NEVER drive under the influence of alcohol

or drugs.

• ALWAYS observe posted speed limits and

never drive too fast for conditions.

• ALWAYS use your seat belts and appropri-

ate child restraint systems. Preteen children should be seated in the rear seat.

• ALWAYS give your full attention to driving

and avoid using vehicle features or taking other actions that could distract you.

• ALWAYS provide information about the

proper use of vehicle safety features to all occupants of the vehicle.

• ALWAYS review this Owner’s Manual for im-

portant safety information. As with other vehicles with features for offroad use, failure to operate all-wheel drive models correctly may result in loss of control or an accident. Be sure to read “Driving safety precautions” in the “Starting and driving” section of this manual.

ON-PAVEMENT AND OFF-ROAD DRIVING

This vehicle will handle and maneuver differently from an ordinary passenger car because it has a higher center of gravity for off-road use. As with other vehicles with features of this type, failure to operate this vehicle correctly may result in loss of control or an accident.

For additional information, refer to “Onpavement and off-road driving precautions”, “Avoiding collision and rollover” and “Driving safety precautions” in the “Starting and driving” section of this manual.

MODIFICATION OF YOUR VEHICLE

This vehicle should not be modified. Modification could affect its performance, safety or durability and may even violate governmental regulations. In addition, damage or performance problems resulting from modifications may not be covered under INFINITI warranties.

WARNING

Installing an aftermarket On-Board Diagnostic (OBD) plug-in device that uses the port during normal driving, for example remote insurance company monitoring, remote vehicle diagnostics, telematics or engine reprogramming, may

cause interference or damage to vehicle systems. We do not recommend or endorse the use of any aftermarket OBD plug-in devices, unless specifically approved by INFINITI. The vehicle warranty may not cover damage caused by any aftermarket plug-in device.

WHEN READING THE MANUAL

This manual includes information for all features and equipment available on this model. Features and equipment in your vehicle may vary depending on model, trim level, options selected, order, date of production, region or availability. Therefore, you may find information about features or equipment that are not included or installed on your vehicle.

All information, specifications and illustrations in this manual are those in effect at the time of printing. INFINITI reserves the right to change performance, design or component suppliers without notice and without obligation.

From time to time, INFINITI may update or revise this manual to provide Owners with the most accurate information currently available. Please carefully read and retain with this manual all revision updates sent to you by INFINITI to ensure you have access to accurate and up-todate information regarding your vehicle. Cur-

rent versions of vehicle Owner’s Manuals and any updates can also be found in the Owner section of the INFINITI website at https:// owners.infinitiusa.com/owners/navigation/ manualsandGuides. If you have questions concerning any information in your Owner’s Manual, contact INFINITI Consumer Affairs. See the INFINITI CUSTOMER CARE PROGRAM page in this Owner’s Manual for contact information.

IMPORTANT INFORMATION ABOUT THIS MANUAL

You will see various symbols in this manual. They are used in the following ways:

WARNING

This is used to indicate the presence of a hazard that could cause death or serious personal injury. To avoid or reduce the risk, the procedures must be followed precisely.

CAUTION

This is used to indicate the presence of a hazard that could cause minor or moderate personal injury or damage to your vehicle. To avoid or reduce the risk, the procedures must be followed carefully.

NOTE

Indicates additional helpful information.

If you see this symbol, it means “Do not do this” or “Do not let this happen”.

If you see a symbol similar to these in an illustration, it means the arrow points to the front of the vehicle.

<>:

Chevrons or angle brackets are used to indicate texts on controls like buttons or switches inside or on the vehicle.

CALIFORNIA PROPOSITION 65 WARNING

WARNING

Engine Exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by DENSO CORPORATION is under license. Other trademarks and trade names are those of their respective owners.

SiriusXM® services require a subscription after trial period and are sold separately or as a package. The satellite service is available only in the 48 contiguous USA and DC. SiriusXM® satellite service is also available in Canada: see www.siriusxm.ca

Arrows in an illustration that are similar to these indicate movement or action.

Arrows in an illustration that are similar to these call attention to an item in the illustration.

[]:

Square brackets are used to indicate messages, keys, or items displayed on a screen.

CALIFORNIA PERCHLORATE ADVISORY

Some vehicle parts, such as lithium batteries, may contain perchlorate material. The following advisory is provided: “Perchlorate Material special handling may apply, See www.dtsc.ca.gov/hazardouswaste/ perchlorate.”

Required SiriusXM Satellite Radio and SiriusXM Travel Link monthly subscriptions are sold separately. Sirius XM Travel Link is only available in select markets. For more information, see www.siriusxm.com/ travellink

“Made for iPod for iPhone electronic accessory has been designed to connect specifically to iPod

䊊

respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with

iPod

䊊

affect wireless performance. Apple, the Apple logo, iPhone iPod classic and iPod touch trademarks of Apple Inc., registered in the U.S. and other countries. Lightning is a trademark of Apple Inc. App Store is a service mark of Apple Inc.

䊊

” mean that an

䊊

or iPhone

, iPod

, iPod nano

䊊

” and “Made

䊊

may

䊊

are

䊊

Music recognition technology and related data are provided by Gracenote®. Gracenote is the industry standard in music recognition technology and related content delivery. For more information, visit www.gracenote.com. CD and music-related data from Gracenote, Inc., copyright 2000 to present Gracenote. Gracenote Software, copyright

2000 to present Gracenote.

䊊

One or more patents owned by Gracenote apply to this product and service. See the Gracenote website for a non-exhaustive

list of applicable Gracenote patents. Gracenote, CDDB, MusicID, MediaVOCS, the Gracenote logo and logotype, and the “Powered by Gracenote” logo are either registered trademarks or trademarks of Gracenote in the United States and/or other countries.

䊊

All rights reserved. No part of this Owner’s Manual may be reproduced or stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of Nissan Motor Co., Ltd.

INFINITI CUSTOMER CARE PROGRAM

INFINITI CARES ... Both INFINITI and your INFINITI retailer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your INFINITI retailer

are our primary concerns. Your INFINITI retailer is always available to assist you with all your automobile sales and service needs.

However, if there is something that your INFINITI retailer cannot assist you with or you would like to provide INFINITI directly with comments or questions, please contact our (INFINITI’s) Consumer Affairs Department using our toll-free number:

For U.S. customers

1-800-662-6200

For Canadian customers

1-800-361-4792

The Consumer Affairs Department will ask for the following information:

• Your name, address, and telephone number

• Vehicle identification number (on dash

panel)

• Date of purchase

• Current odometer reading

• Your INFINITI retailer’s name

• Your comments or questions

You can write to INFINITI with the information on the left at:

For U.S. customers

INFINITI Division Nissan North America, Inc.

Consumer Affairs Department

P.O. Box 685003

Franklin, TN 37068-5003

or via e-mail at:

nnaconsumeraffairs@nissan-usa. com

For Canadian customers

INFINITI Division

Nissan Canada Inc.

5290 Orbitor Drive

Mississauga, Ontario L4W 4Z5

or via e-mail at:

information.center@nissancanada. com

If you prefer, visit us at:

www.infinitiUSA.com (for U.S. customers) or

www.infiniti.ca (for Canadian customers)

We appreciate your interest in INFINITI and thank you for buying a quality INFINITI vehicle.

Illustrated table of contents

Safety — seats, seat belts and supplemental restraint system

Instruments and controls

Pre-driving checks and adjustments

Display screen, heater and air conditioner, and audio system

Starting and driving

In case of emergency

Appearance and care

Do-it-yourself

Maintenance and Schedules

Technical information

Index

0 Illustrated table of contents

Seats, Seat belts and Supplemental Restraint System

(SRS) ..............................0-2

Exterior front..........................0-3

Exterior rear ..........................0-4

Passenger compartment ...................0-5

Cockpit .............................0-6

Instrument panel .......................0-7

Meters and gauges ......................0-8

Engine compartment .....................0-9

2.0L Gasoline engine...................0-9

SEATS, SEAT BELTS AND SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

1. Rear seat belts (Page. 1-7)

3. Roof-mounted curtain side impact and rollover supplemental air bags (P. 1-39)

4. Front seat belts (P. 1-11)

5. Seat belt pretensioners (P. 1-54)

6. Air bag warning label (P. 1-55)

10. LATCH (Lower Anchors and Tethers for CHildren)/ ISOFIX child restraint system (P. 1-21)

11. Rear seats (P. 1-5)

— Child restraints (P. 1-20)

12. Head restraints/headrests (P. 1-7)

13. Front seat-mounted side impact supplemental air bags (P. 1-39)

14. Front seats (P. 1-3) — Occupant Classification System (OCS) (P. 1-47)

15. Front passenger air bag status light

(P. 1-47)

16. Driver and passenger supplemental knee air bags (P. 1-39)

*: if equipped

NIC2847

7. Driver Supplemental front-impact air bag (P. 1-38)

8. Passenger supplemental front-impact air bag (P. 1-38)

9. Top tether strap anchors (P. 1-23)

0-2 Illustrated table of contents

EXTERIOR FRONT

1. Power windows (P. 2-72)

2. Windshield wipers and washers — Switch operation (P. 2-59) — Blade replacement (P. 8-13) — Window washer fluid (P. 8-8) — Windshield de-icer* (P. 2-62)

6. Turn signal lights (P. 2-65, 8-22) — Side turn signal light (P. 8-22) Mirrors — Adjustment (P. 3-18)

*: if equipped

NIC2837

3. Recovery hook (P. 6-14)

4. Front fog lights (P. 2-69)

5. Headlights — Switch operation (P. 8-23)

Illustrated table of contents 0-3

EXTERIOR REAR

1. Antenna (P. 4-52)

2. High-mounted stop light (Bulb replacement) (P. 8-22)

3. Rear window defroster (P. 2-61)

7. Rear view camera* (P. 4-16)

8. Rear reflector

9. Rear combination lights (P. 8-24)

10. Fuel-filler door — Operation (P. 3-15) — Fuel information (P. 8-2)

*: if equipped

NIC2836

4. Rear window wiper and washer — Operation (P. 2-61) — Wiper blade replacement (P. 2-13)

5. Recovery hook (P. 6-15)

6. Lift gate (P. 3-7) — Intelligent Key system (P. 6-4)

0-4 Illustrated table of contents

PASSENGER COMPARTMENT

1. Rear armrest* (P. 1-7)

2. Rear personal lights (P. 2-86)

3. Overhead control panel (P. 2-75)

4. Sunshade switch* (P. 2-75)

5. Sun visor (P. 2-17)

6. Security system buttons (P. 3-58)

10. Front cup holders (P. 2-79)

11. Air conditioner controls (P. 4-42)

12. Glove box/storage (P. 2-78)

*: if equipped

NIC2701

7. Interior rear-view mirror (P. 3-17)

8. Door handle (P. 3-6)

9. Door armrest — Power windows controls (P. 2-72) — Exterior rear view mirror remote control switch (P. 2-17)

Illustrated table of contents 0-5

COCKPIT

1. Turn signal, wiper, washer, and high beam switch (P. 2-65, 2-59)

2. Steering-wheel-mounted controls (left side)

(P. 2-15)

3. Ignition switch (P. 3-16)

7. Cruise Control switch — Cruise Control (P. 5-44) — Intelligent Cruise Control (P. 2-47)

8. USB connection ports (P. 4-3)

9. Shift lever (P. 5-18)

10. Front cup holders (P. 2-79)

11. INFINITI controller (P. 4-2)

NIC2649

4. Steering-wheel-mounted controls (right side) (P. 4-3)

5. Light switch — Headlight (P. 2-63) — Fog light (P. 2-69)

6. Parking brake (P. 3-25)

0-6 Illustrated table of contents

INSTRUMENT PANEL

1. Ventilators (P. 4-41)

2. Center display* (P. 4-5)

3. Meters and gauges (P. 2-4)

4. Light switch (P. 2-63)

5. Parking brake (P. 3-25)

8. Ignition switch (P. 3-16)

9. Heater and air conditioner (P. 4-42)

10. Switch panel — Seat heater switches* (P. 2-70) — Hazard indicator flasher switch (P. 6-2) — Idle Stop/Start system on/off switch (P. 6-28) — Front passenger air bag status light (P. 6-47)

11. Vehicle Information Display (P. 2-15)

12. Glove box (P. 2-78)

13. Front passenger supplemental air bag

(P. 1-38)

*: if equipped

NIC2898

6. Steering wheel — Power steering system (P. 5-86) — Horn (P. 2-70) — Driver’s supplemental front-impact air bag (P. 1-38)

7. Audio system (P. 4-52)

Illustrated table of contents 0-7

METERS AND GAUGES

1. Speedometer (P. 2-4)

2. Vehicle information display (P. 2-15) — Odometer/twin trip odometer (P. 2-15)

3. Upper information display (P. 2-15)

NIC2651

4. Tachometer (P. 2-5)

5. Engine coolant temperature gauge (P. 2-6)

6. Fuel gauge (P. 2-6)

0-8 Illustrated table of contents

ENGINE COMPARTMENT

2.0L GASOLINE ENGINE

1. Engine coolant reservoir (P. 8-3)

2. Engine oil dipstick (P. 8-5)

3. Engine oil filler cap (P. 8-5)

4. Brake fluid reservoir (P. 8-7)

NIC2833

5. Engine air cleaner filter (P. 8-13)

6. Battery (P. 8-9)

7. Fuse box (P. 8-17)

8. Window washer fluid reservoir (P. 8-8)

Illustrated table of contents 0-9

NOTE

0-10 Illustrated table of contents

1 Safety — seats, seat belts and supplemental restraint system

Seats ..............................1-2

Front seats .........................1-3

Seat heater (if equipped).................1-5

Rear seats..........................1-5

Armrest (if equipped) ...................1-7

Head restraints/Headrests ..................1-7

Adjustable head restraint components ........1-8

Remove ...........................1-8

Install ............................1-9

Adjust ............................1-9

Rear seat head restraints/headrests .........1-10

Seat belts ...........................1-11

Precautions on seat belt usage ............1-11

Pregnant women .....................1-13

Injured persons ......................1-13

Seat belt warning light .................1-14

Three-point type seat belt with retractor .......1-14

Seat belt extenders ...................1-17

Seat belt maintenance..................1-17

Child safety ..........................1-18

Infants ...........................1-18

Small children ......................1-19

Larger children ......................1-19

Child restraints........................1-20

Precautions on child restraints ............1-20

Rear-facing child restraint installation using

LATCH ...........................1-23

Rear-facing child restraint installation using

the seat belts .......................1-25

Forward-facing child restraint installation using

LATCH ...........................1-28

Forward-facing child restraint installation

using the seat belts ...................1-31

Booster seats .......................1-35

Supplemental Restraint System (SRS) ..........1-38

Precautions on Supplemental Restraint System

(SRS) ............................1-38

Supplemental air bag systems.............1-45

Supplemental air bag warning labels........

Supplemental

Repair and replacement procedure ..........1-56

bag warning light..........1-55

air

.1-55

SEATS

SSS0133AZ

• Do not adjust the driver’s seat while driving

so full attention may be given to vehicle operation. The seat may move suddenly and could cause loss of control of the vehicle.

CAUTION

When adjusting the seat positions, be sure not to contact any moving parts to avoid possible injuries and/or damage.

WARNING

• The seatback should not be reclined any

more than needed for comfort. Seat belts are most effective when the passenger sits well back and straight up in the seat. If the seat back is reclined, the risk of sliding under the lap belt and being injured is increased.

• For the most effective protection when the

vehicle is in motion, the seat should be upright. Always sit well back and upright in the seat with both feet on the floor and adjust the seat properly. (See ⬙Seat belts⬙ later in this section.)

make sure it is securely locked.

• To help avoid risk of injury or death through

unintended operation of the vehicle and/or its systems, do not leave children, people who require the assistance of others, or pets unattended in your vehicle. Additionally, the temperature inside a closed vehicle on a warm day can quickly become high enough to cause a significant risk of injury or death to people and pets.

• Do not leave children unattended inside the

vehicle. They could unknowingly activate switches or controls. Unattended children could become involved in serious accidents.

1-2 Safety — seats, seat belts and supplemental restraint system

• After adjustment, gently rock in the seat to

NIC2605 NIC2607

FRONT SEATS Manual seat adjustment

Forward and backward:

Pull the lever seat forward or backward to the preferred position. Release the lever to lock the seat in position.

Seat cushion angle (if equipped)

Adjust the angles so that your thighs are lightly supported. Turn handwheel backwards.

up and hold it while sliding the

䊊

forwards or

䊊

Seat lifter (if equipped)

Repeatedly pull up or push down the adjusting

lever desired position.

Seatback angle

Relieve the pressure on the seatback and turn handwheel

The reclining feature allows the adjustment of the seatback for occupants of different sizes to help obtain the proper seat belt fit. (See ⬙Seat belts⬙ later in this section.)

The seatback may be reclined to allow occupants to rest when the vehicle is parked.

, to adjust the seat height to the

䊊

forwards or backwards.

Lumbar support

The lumbar support feature provides lower back support to the driver.

Push each side of the adjusting switch to adjust the seat lumbar area until the desired position is achieved.

To raise the seatback contour

䊊

To soften the seatback contour

䊊

To lower the seatback contour

䊊

To harden the seatback contour

䊊

Safety — seats, seat belts and supplemental restraint system 1-3

Power seat adjustment

Operating tips:

• The power seat motor has an auto-reset

overload protection circuit. If the motor stops during the seat adjustment, wait 30 seconds, then reactivate the switch.

• To avoid discharge of the battery, do not

operate the power seats for a long period of time when the engine is not running.

NOTE You can store the seat settings using the

memory function (see ⬙ Memory function (if equipped)⬙ in the ⬙3. Pre-driving checks and adjustments⬙ section).

NIC2606

Forward and backward

Move forward or backward the adjusting switch

to the desired position.

䊊

Reclining

Move forward or backward the adjusting switch

䊊

The reclining feature allows the adjustment of the seatback for occupants of different sizes to help obtain the proper seat belt fit. (See ⬙Seat belts⬙ later in this section.)

The seatback may be reclined to allow occupants to rest when the vehicle is parked.

to the desired position.

Seat lifter (if equipped)

1. Pull up or push down the adjusting switch

to adjust the seat height until the desired

䊊

position is achieved.

2. Tilt up or down the adjusting switch adjust the front angle of the seat until the desired position is achieved.

䊊

1-4 Safety — seats, seat belts and supplemental restraint system

NIC2607

Lumbar support:

The lumbar support feature provides lower back support to the driver.

Push each side of the adjusting switch to adjust the seat lumbar area until the desired position is achieved.

To raise the seatback contour

䊊

To soften the seatback contour

䊊

To lower the seatback contour

䊊

To harden the seatback contour

䊊

SEAT HEATER (IF EQUIPPED)

The seats can be warmed by built-in heaters. The switches are located on the center console (for front seats) and can be operated independently of each other. For more information on the seat heater, see ⬙ Seat heating (if equipped)⬙ in the ⬙2. Instruments and controls⬙ section.

REAR SEATS

WARNING

• Never allow anyone to ride in the cargo area

or on the rear seat when it is in the folddown position. Use of these areas by passengers without proper restraints could result in serious injury or deathin an accident or sudden stop.

•

Properly secure all cargo with ropes or straps to help prevent it from sliding or shifting. Do not place cargo higher than the seatbacks. In a sudden stop or collision, unsecured cargo could cause personal injury.

• Do not allow people to ride in any area of

your vehicle that is not equipped with seats and seat belts. Be sure everyone in your vehicle is in a seat and using a seat belt properly.

• Do not allow more than one person to use

the same seat belt.

• Do not fold down the rear seats when occu-

pants are in the rear seat area or any luggage is on the rear seats.

– Make sure that the seat path is clear

before moving the seat.

– Be careful not to allow hands or feet to

get caught or pinched in the seat.

• Head restraints/headrests should be ad-

justed properly as they may provide significant protection against injury in an accident. Always replace and adjust them properly if they have been removed for any reason.

• If the head restraints/headrests are re-

moved for any reason, they should be securely stored to prevent them from causing injury to passengers or damage to the vehicle in case of sudden braking or an accident.

• When returning the seatbacks to the up-

right position, be certain they are completely secured in the latched position. If they are not completely secured, passengers may be injured in an accident or sudden stop.

Safety — seats, seat belts and supplemental restraint system 1-5

NPA1293 NIC2669

Folding

The luggage compartment loading capacity can be increased by folding the rear seat backs forward.

To fold the seat back

1. Ensure head restraints are properly stowed, see ⬙Head restraints/Headrests⬙ later in this section.

2. Release the seat back lock by pulling the

release handle.

3. Fold the seat back forward .

4. Insert the seat belt into the seat belt holder.

To return the seat back to an upright position

1. Make sure the seat belts are clear of the seat back latch mechanism.

2. Lift the seat back up and push firmly to lock.

3. If the red marker is visible then the seat back

has not latched properly — release and then re-latch the seat.

4. If the head restraint/headrest was removed,

reinstall and properly adjust the head restraint/headrest before an occupant uses the seating position. See ⬙Head restraints/Headrests⬙ later in this section.

WARNING

Always use the seat belt holder, and ensure that the seat belt is not trapped in the seat back latch mechanism. Failure to do so may cause damage to the seat belt, and this may increase the risk of serious injury or death in a collision.

1-6 Safety — seats, seat belts and supplemental restraint system

ARMREST (IF EQUIPPED) Rear

Pull the tab and draw the armrest until it is horizontal.

HEAD RESTRAINTS/HEADRESTS

NIC2611 NPA1500

Indicates that the seating position is

equipped with a head restraint.

䊊

forward

Indicates that the seating position is

equipped with a non-removable head rest.

WARNING

Head restraints/headrests supplement the other vehicle safety systems. They may provide additional protection against injury in certain rear end collisions. Adjustable head restraints/headrests must be adjusted properly, as specified in this section. Check the adjustment after someone else uses the seat. Do not attach anything to the head restraint/ headrest stalks or remove the head restraint/ headrest. Do not use the seat if the head restraint/headrest has been removed. If the head restraint/headrest was removed, rein-

stall and properly adjust the head restraint/ headrest before an occupant uses the seating position. Failure to follow these instructions can reduce the effectiveness of the head restraints/headrests. This may increase the risk of serious injury or death in a collision.

• Your vehicle is equipped with head

restraints/headrests that may be integrated, adjustable or non-adjustable.

• Adjustable head restraints/headrests have

multiple notches along the stalk to lock them in a desired adjustment position.

• The non-adjustable head restraints/

headrests have a single locking notch to secure them to the seat frame.

• Proper Adjustment:

– For the adjustable type, align the head

restraint/headrest so the center of your ear is approximately level with the center of the head restraint/headrest.

– If your ear position is still higher than the

recommended alignment, place the head restraint/headrest at the highest position.

Safety — seats, seat belts and supplemental restraint system 1-7

• If the head restraint/headrest has been re-

moved, ensure that it is reinstalled and locked in place before riding in that designated seating position.

NOTE For vehicles with sports seats you cannot adjust

the front head restraints/headrests or the outer rear head restraints/headrests.

ADJUSTABLE HEAD RESTRAINT COMPONENTS

1. Removable head restraint/headrest

2. Multiple notches

3. Lock knob

4. Stalks

SSS0992Z SSS1037Z

REMOVE

Use the following procedure to remove the head restraint/headrest.

1. Pull the head restraint/headrest up to the highest position.

2. Push and hold the lock knob.

3. Remove the head restraint/headrest from

the seat.

4. Store the head restraint/headrest properly

in a secure place so it is not loose in the vehicle.

5. Reinstall and properly adjust the head

restraint/headrest before an occupant uses the seating position.

1-8 Safety — seats, seat belts and supplemental restraint system

SSS1038Z SSS0997Z SSS1035Z

INSTALL

1. Align the head restraint/headrest stalks with the holes in the seat. Make sure that the head restraint/headrest is facing the correct direction. The stalk with the adjustment

notch the lock knob

2. Push and hold the lock knob and push the

head restraint/headrest down.

3. Properly adjust the head restraint/headrest

before an occupant uses the seating position.

must be installed in the hole with

䊊

ADJUST

For adjustable head restraint/ headrest

Adjust the head restraint/headrest so the center is level with the center of your ears. If your ear position is still higher than the recommended alignment, place the head restraint/ headrest at the highest position.

Safety — seats, seat belts and supplemental restraint system 1-9

Raise

To raise the head restraint/headrest, pull it up.

Make sure the head restraint/headrest is positioned from the stored position or any non-latch position so the lock knob is engaged in the notch before riding in that designated seating position.

SSS1036Z NIC2610 NIC2609

Lower

To lower, push and hold the lock knob push the head restraint/headrest down.

Make sure the head restraint/headrest is positioned so the lock knob is engaged in the notch before riding in that designated seating position.

䊊

Fore-aft

This function allows you to adjust the distance

and

between the head restraint/headrest and the back of the head.

• To move forwards: pull the head restraint/

headrest forwards in the direction of the arrow until it engages. There are a number of detents.

• To move backwards: press and hold button

and push the head restraint/headrest

䊊

backwards.

• When the head restraint/headrest is in the

desired position, release the button and make sure that the head restraint/headrest is engaged in position.

1-10 Safety — seats, seat belts and supplemental restraint system

REAR SEAT HEAD RESTRAINTS/ HEADRESTS

Adjusting the rear seat head restraint/headrest height

Use the head restraint/headrest in the notched stem positions after pulling it up from the stowed position to a position in which it locks securely in place.

• To raise: pull the head restraint/headrest up

to the desired height.

• To lower: press release catch

the head restraint/headrest down until it is in the desired position.

䊊

and push

SEAT BELTS

Removing and fitting the rear seat head restraints/headrests

The rear head restraints/headrests on the outer seats can be removed and refitted. For vehicles with sports seats the rear head restraints/ headrests cannot be removed and refitted.

Fold the seatback slightly forward in order to remove the head restraint/headrest.

• To remove: pull the head restraint/headrest

up to the stop.

Press release catch restraint/headrest out of the guides.

and pull the head

䊊

• To refit: insert the head restraint/headrest so

that the notches on the bar are on the left when viewed in the direction of travel.

Push the head restraint/headrest down until you hear it engage in position.

PRECAUTIONS ON SEAT BELT USAGE

If you are wearing your seat belt properly adjusted, and you are sitting upright and well back in your seat, your chances of being injured or killed in an accident and/or the severity of injury may be greatly reduced. INFINITI strongly encourages you and all of your passengers to buckle up every time you drive, even if your seating position includes a supplemental air bag.

Most U.S. states and Canadian provinces or territories specify that seat belts be worn at all times when a vehicle is being driven.

Safety — seats, seat belts and supplemental restraint system 1-11

Sit upright and well back

1-12 Safety — seats, seat belts and supplemental restraint system

SSS0134AZ

SSS0136AZ

SSS0016Z

SSS0014Z

WARNING

• Every person who drives or rides in this ve-

hicle should use a seat belt at all times. Children should be in the rear seats and in an appropriate restraint.

• The seat belt should be properly adjusted to

a snug fit. Failure to do so may reduce the effectiveness of the entire restraint system and increase the chance or severity of injury in an accident. Serious injury or death can occur if the seat belt is not worn properly.

• Always route the shoulder belt over your

shoulder and across your chest. Never put the belt behind your back, under your arm or across your neck. The belt should be away from your face and neck, but not falling off your shoulder.

• Position the lap belt as low and snug as

possible AROUND THE HIPS, NOT THE WAIST. A lap belt worn too high could increase the risk of internal injuries in an accident.

• Be sure the seat belt tongue is securely fas-

tened to the proper buckle.

• Do not wear the seat belt inside out or

twisted. Doing so may reduce its effectiveness.

• Do not allow more than one person to use

the same seat belt.

• Never carry more people in the vehicle than

there are seat belts.

• If the seat belt warning light glows continu-

ously while the ignition is turned ON with all doors closed and all seat belts fastened, it may indicate a malfunction in the system. Have the system checked. It is recommended that you visit an INFINITI retailer for this service.

• No changes should be made to the seat belt

system. For example, do not modify the seat belt, add material or install devices that may change the seat belt routing or tension. Doing so may affect the operation of the seat belt system. Modifying or tampering with the seat belt system may result in serious personal injury.

• Once a seat belt pretensioner has activated,

they cannot be reused and must be replaced together with the retractor. It is recommended that you visit an INFINITI retailer for this service.

• All seat belt assemblies, including retrac-

tors and attaching hardware, should be inspected after any collision. It is recommended that you visit an INFINITI retailer for this service. INFINITI recommends that all seat belt assemblies in use during a collision be replaced unless the collision was minor and the belts show no damage and

continue to operate properly. Seat belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.

• All child restraints and attaching hardware

should be inspected after any collision. Always follow the restraint manufacturer’s inspection instructions and replacement recommendations. The child restraints should be replaced if they are damaged.

PREGNANT WOMEN

INFINITI recommends that pregnant women use seat belts. The seat belt should be worn snug, and always position the lap belt as low as possible around the hips, not the waist. Place the shoulder belt over your shoulder and across your chest. Never put the lap/shoulder belt over your abdominal area. Contact your doctor for specific recommendations.

INJURED PERSONS

INFINITI recommends that injured persons use seat belts. Check with your doctor for specific recommendations.

Safety — seats, seat belts and supplemental restraint system 1-13

NIC2743

SEAT BELT WARNING LIGHT

If the seat belt warning light flashes, together with an intermittent warning tone, this means that the driver or passenger has not fastened their seat belt, and the speed of the vehicle is exceeding 15 MPH (25 km/h).

For additional information, refer to ⬙Warning lights, indicator lights and audible reminders⬙ in the ⬙2. Instruments and controls⬙ section.

THREE-POINT TYPE SEAT BELT WITH RETRACTOR

WARNING

• Every person who drives or rides in this ve-

hicle should use a seat belt at all times. Children should be in the rear seats and in an appropriate restraint.

• Do not ride in a moving vehicle when the

seatback is reclined. This can be dangerous. The shoulder belt will not be against your body. In an accident, you could be thrown into it and receive neck or other serious injuries. You could also slide under the lap belt and receive serious internal injuries.

• For the most effective protection when the

vehicle is in motion, the seat should be upright. Always sit well back and upright in the seat with both feet on the floor and adjust the seat belt properly.

• Do not allow children to play with the seat

belts. Most seating positions are equipped with Automatic Locking Retractor (ALR) mode seat belts. If the seat belt becomes wrapped around a child’s neck with the ALR mode activated, the child can be seriously injured or killed if the seat belt retracts and becomes tight. This can occur even if the

vehicle is parked. Unbuckle the seat belt to release the child. If the seat belt cannot be unbuckled or is already unbuckled, release the child by cutting the seat belt with a suitable tool (such as a knife or scissors) to release the seat belt.

Fastening the seat belts

1. Adjust the seat. (See ⬙Seats⬙ earlier in this section.)

2. Slowly pull the seat belt out of the retractor

and insert the tongue into the buckle until you hear and feel the latch engage.

1-14 Safety — seats, seat belts and supplemental restraint system

SSS0292Z SSS0290Z

• The retractor is designed to lock during a

sudden stop or on impact. A slow pulling motion permits the belt to move and allows you some freedom of movement in the seat.

• If the seat belt cannot be pulled from its

fully retracted position, firmly pull the belt and release it. Then smoothly pull the belt out of the retractor.

3. Position the lap belt portion low and snug on the hips as shown

4. Pull the shoulder belt portion toward the retractor to take up extra slack. Be sure the shoulder belt is routed over your shoulder and across your chest.

The front passenger seat and the rear seating positions three-point seat belts have two modes of operation:

• Emergency Locking Retractor (ELR)

• Automatic Locking Retractor (ALR)

The ELR mode allows the seat belt to extend and retract to allow the driver and passengers some freedom of movement in the seat. The ELR locks the seat belt when the vehicle slows down rapidly or during certain impacts.

The ALR mode (child restraint mode) locks the seat belt for child restraint installation. When the ALR mode is activated, the seat belt cannot

be extended again until the seat belt tongue is detached from the buckle and fully retracted. The seat belt returns to the ELR mode after the seat belt fully retracts. For additional information, refer to ⬙Child restraints⬙ later in this section. The ALR mode should be used only for child restraint installation. During normal seat belt use by an occupant, the ALR mode should not be activated. If it is activated, it may cause uncomfortable seat belt tension. It can also change the operation of the front passenger air bag. For additional information, refer to ⬙Front passenger air bag and status light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

WARNING

When fastening the seat belts, be certain that the seatbacks are completely secured in the latched position. If they are not completely secured, passengers may be injured in an accident or sudden stop.

Safety — seats, seat belts and supplemental restraint system 1-15

SSS0326Z SSS0896Z

Unfastening the seat belts

To unfasten the seat belt, push the button on the buckle and guide the seat belt as it automatically retracts.

Checking seat belt operation

Seat belt retractors are designed to lock seat belt movement by two separate methods:

• When the belt is pulled quickly from the

retractor.

• When the vehicle slows down rapidly.

To increase your confidence in the seat belts, check the operation as follows:

• Grasp the shoulder belt and pull forward

quickly. The retractor should lock and restrict further belt movement.

If the retractor does not lock during this check, get the system checked. It is recommended that you visit an INFINITI retailer for this service, or to learn more about seat belt operation.

Shoulder belt height adjustment (if equipped)

The shoulder belt anchor height should be adjusted to the position that is best for you. (See ⬙Fastening the seat belts ⬙ earlier in this section).

• To adjust, push the button and then move

the shoulder belt anchor to the desired position so that the belt passes over the center of the shoulder. The belt should be away from your face and neck, but not falling off of your shoulder. Release the adjustment button to lock the shoulder belt anchor into position.

1-16 Safety — seats, seat belts and supplemental restraint system

WARNING

• After adjustment, release the adjustment

button and then try to move the shoulder belt down to make sure that it is securely fixed in position.

• The shoulder belt anchor height should be

adjusted to the position that is best for you. Failure to do so may reduce the effectiveness of the entire restraint system and increase the chance or severity of injury in an accident.

SEAT BELT EXTENDERS

If, because of body size or driving position, it is not possible to properly fit the lap/shoulder belt and fasten it, an extender that is compatible with the installed seat belts is available that can be purchased. The extender adds approximately 8 in (200 mm) of length and may be used for either the driver or front passenger seating position. It is recommended you visit an INFINITI retailer for assistance with purchasing an extender if an extender is required.

WARNING

• Only INFINITI seat belt extenders, made by

the same company which made the original equipment seat belts, should be used with the INFINITI seat belts.

• Adults and children who can use the stan-

dard seat belt should not use an extender. Such unnecessary use could result in serious personal injury in the event of an accident.

• Never use seat belt extenders to install

child restraints. If the child restraint is not secured properly, the child could be seriously injured in a collision or a sudden stop.

SEAT BELT MAINTENANCE

• To clean the seat belt webbing, apply a mild

soap solution or any solution recommended for cleaning upholstery or carpets. Then wipe with a cloth and allow the seat belts to dry in the shade. Do not allow the seat belts to retract until they are completely dry.

• If dirt builds up in the shoulder belt guide of

the seat belt anchors, the seat belts may retract slowly. Wipe the shoulder belt guide with a clean, dry cloth.

• Periodically check to see that the seat belt

and the metal components, such as buckles, tongues, retractors, flexible wires and anchors, work properly. If loose parts, deterioration, cuts or other damage on the webbing is found, the entire seat belt assembly should be replaced.

Safety — seats, seat belts and supplemental restraint system 1-17

CHILD SAFETY

WARNING

Do not allow children to play with the seat belts. Most seating positions are equipped with Automatic Locking Retractor (ALR) mode seat belts. If the seat belt becomes wrapped around a child’s neck with the ALR mode activated, the child can be seriously injured or killed if the seat belt retracts and becomes tight. This can occur even if the vehicle is parked. Unbuckle the seat belt to release the child. If the seat belt can not be unbuckled or is already unbuckled, release the child by cutting the seat belt with a suitable tool (such as a knife or scissors) to release the seat belt.

Children need adults to help protect them.

They need to be properly restrained.

In addition to the general information in this manual, child safety information is available from many other sources, including doctors, teachers, government traffic safety offices, and community organizations. Every child is different, so be sure to learn the best way to transport your child.

There are three basic types of child restraint systems:

• Rear-facing child restraint

• Forward-facing child restraint

• Booster seat

The proper restraint depends on the child’s size. Generally, infants up to about 1 year and less than 20 lb (9 kg) should be placed in rear-facing child restraints. Forward-facing child restraints are available for children who outgrow rear-facing child restraints and are at least 1 year old. Booster seats are used to help position a vehicle lap/ shoulder belt on a child who can no longer use a forward-facing child restraint.

Infants and children need special protection. The vehicle’s seat belts may not fit them properly. The shoulder belt may come too close to the face or neck. The lap belt may not fit over their small hip bones. In an accident, an improperly fitting seat belt could cause serious or fatal injury. Always use appropriate child restraints.

All U.S. states and Canadian provinces or territories require the use of approved child restraints for infants and small children. See ⬙Child restraints⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section for more information.

1-18 Safety — seats, seat belts and supplemental restraint system

WARNING

A child restraint may be secured in the vehicle by using either the LATCH (Lower Anchor and Tethers for CHildren) system or with the vehicle seat belt. For additional information, refer to ⬙Child restraints⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

INFINITI recommends that all pre-teens and children be restrained in the rear seat. Studies show that children are safer when properly restrained in the rear seat than in the front seat.

This is especially important because your vehicle has a supplemental restraint system (air bag system) for the front passenger. (See ⬙Supplemental Restraint System (SRS)⬙ later in this section.)

INFANTS

Infants up to at least 1 year old should be placed in a rear-facing child restraint. INFINITI recommends that infants be placed in child restraints that comply with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. You should choose a child restraint which fits your vehicle and always follow the manufacturer’s instructions for installation and use.

SMALL CHILDREN

Children that are over 1 year old and weigh at least 20 lbs (9 kg) should remain in a rearfacing child restraint as long as possible up to the height or weight limit of the child restraint. Children who outgrow the height or weight limit of the rear-facing child restraint and are at least 1 year old should be secured in a forward-facing child restraint with a harness. Refer to the manufacturer’s instructions for minimum and maximum weight and height recommendations. INFINITI recommends that small children be placed in child restraints that comply with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards. You should choose a child restraint that fits your vehicle and always follow the manufacturer’s instructions for installation and use.

LARGER CHILDREN

Children should remain in a forward-facing child restraint with a harness until they reach the maximum height or weight limit allowed by the child restraint manufacturer.

Children who are too large for child restraints should be seated and restrained by the seat belts which are provided. The seat belt may not fit properly if the child is less than 4 ft 9 in (142.5 cm) tall and weighs between 40 lbs

(18 kg) and 80 lbs (36 kg). A booster seat should be used to obtain proper seat belt fit.

Once a child outgrows the height or weight limit of the harness-equipped forward-facing child restraint, INFINITI recommends that the child be placed in a commercially available booster seat to obtain proper seat belt fit. For a seat belt to fit properly, the booster seat should raise the child so that the shoulder belt is properly positioned across the chest and the top, middle portion of the shoulder. The shoulder belt should not cross the neck or face and should not fall off the shoulder. The lap belt should lie snugly across the lower hips or upper thighs, not the abdomen. A booster seat can only be used in seating positions that have a threepoint type seat belt. The booster seat should fit the vehicle seat and have a label certifying that it complies with Federal Motor Vehicle Safety Standards or Canadian Motor Vehicle Safety Standards.

A booster seat should be used until the child can pass the seat belt fit test below:

• Are the child’s back and hips against the

vehicle seatback?

• Is the child able to sit without slouching?

• Do the child’s knees bend easily over the

front edge of the seat with feet flat on the floor?

• Can the child safely wear the seat belt (lap

belt low and snug across the hips and shoulder belt across mid-chest and shoulder)?

• Is the child able to use the properly adjusted

head restraint/headrest?

• Will the child be able to stay in position for

the entire ride?

If you answered no to any of these questions, the child should remain in a booster seat using a three-point type seat belt.

NOTE Laws in some communities may follow different

guidelines. Check local and state regulations to confirm your child is using the correct restraint system before traveling.

WARNING

Never let a child stand or kneel on any seat and do not allow a child in the cargo area. The child could be seriously injured or killed in a sudden stop or collision.

Safety — seats, seat belts and supplemental restraint system 1-19

CHILD RESTRAINTS

SSS0099Z WRS0256Z

PRECAUTIONS ON CHILD RESTRAINTS

WARNING

• Failure to follow the warnings and instruc-

tions for proper use and installation of child restraints could result in serious injury or death of a child or other passengers in a sudden stop or collision:

– The child restraint must be used and in-

stalled properly. Always follow all of the child restraint manufacturer’s instructions for installation and use.

– Infants and children should never be

held on anyone’s lap. Even the strongest adult cannot resist the forces of a collision.

– Do not put a seat belt around both a child

and another passenger.

– INFINITI recommends that all child re-

straints be installed in the rear seat. Studies show that children are safer when properly restrained in the rear seat than in the front seat. If you must install a forward-facing child restraint in the front seat, see ⬙Forward-facing child restraint installation using the seat belts⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

– Even with the INFINITI Advanced Air bag

System, never install a rear-facing child restraint in the front seat. An inflating air bag could seriously injure or kill a child. A rear-facing child restraint must only be used in the rear seat.

– Be sure to purchase a child restraint that

will fit the child and vehicle. Some child restraints may not fit properly in your vehicle.

– Child restraint anchorages are designed

to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach adult seat belts, or other items or equipment to the vehicle. Doing so could damage the child restraint anchorages. The child restraint will not be properly installed using the damaged anchorages, and a child could be seriously injured or killed in a collision.

– Never use the anchor points for adult

seat belts or harnesses.

– A child restraint with a top tether strap

should not be used in the front passenger seat.

– Keep seatbacks as upright as possible

after fitting the child restraint.

– Infants and children should always be

placed in an appropriate child restraint while in the vehicle.

– When the child restraint is not in use,

keep it secured with the LATCH system or a seat belt. In a sudden stop or collision, loose objects can injure occupants or damage the vehicle.

1-20 Safety — seats, seat belts and supplemental restraint system

CAUTION

Remember that a child restraint left in a closed vehicle can become very hot. Check the seating surface and buckles before placing your child in a child restraint.

This vehicle is equipped with a universal child restraint anchor system, referred to as the LATCH (Lower Anchors and Tethers for CHildren) system. Some child restraints include rigid or webbing-mounted attachments that can be connected to these anchors.

For details, see ⬙LATCH (Lower Anchors and Tethers for CHildren) system⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

If you do not have a LATCH compatible child restraint, the vehicle seat belts can be used.

Several manufacturers offer child restraints for infants and small children of various sizes. When selecting any child restraint, keep the following points in mind:

• Choose only a restraint with a label certifying

that it complies with Federal Motor Vehicle Safety Standard 213 or Canadian Motor Vehicle Safety Standard 213.

• Check the child restraint in your vehicle to be

sure it is compatible with the vehicle’s seat and seat belt system.

• If the child restraint is compatible with your

vehicle, place your child in the child restraint and check the various adjustments to be sure the child restraint is compatible with your child. Choose a child restraint that is designed for your child’s height and weight. Always follow all recommended procedures.

• If the combined weight of the child and child

restraint is less than 65 lb (29.5 kg), you may use either the LATCH anchors or the seat belt to install the child restraint (not both at the same time).

• If the combined weight of the child and child

restraint is greater than 65 lb (29.5 kg), use the vehicle’s seat belt (not the lower anchors) to install the child restraint.

• Be sure to follow the child restraint manufac-

turer’s instructions for installation.

NOTE All U.S. states and Canadian provinces or territo-

ries require that infants and small children be restrained in an approved child restraint at all times while the vehicle is being operated. Canadian law requires the top tether strap on front-

facing child restraints to be secured to the designated anchor point on the vehicle.

LATCH (Lower Anchors and Tethers for CHildren) system

Your vehicle is equipped with special anchor points that are used with LATCH system compatible child restraints. This system may also be referred to as the ISOFIX or ISOFIX compatible system. With this system, you do not have to use a vehicle seat belt to secure the child restraint unless the combined weight of the child and child restraint exceeds 65 lb (29.5 kg). If the combined weight of the child and child restraint is greater than 65 lb (29.5 kg), use the vehicle’s seat belt (not the lower anchors) to install the child restraint. Be sure to follow the child restraint manufacturer’s instructions for installation.

The LATCH anchor points are provided to install child restraints in the rear outboard seating positions only.

LATCH lower anchor

WARNING

Failure to follow the warnings and instructions for proper use and installation of child restraints could result in serious injury or death

Safety — seats, seat belts and supplemental restraint system 1-21

of a child or other passengers in a sudden stop or collision:

• Attach LATCH system compatible child re-

straints only at the locations shown in the illustration.

• Do not secure a child restraint in the center

rear seating position using the LATCH lower anchors. The child restraint will not be secured properly.

• Inspect the lower anchors by inserting your

fingers into the lower anchor area. Feel to make sure there are no obstructions over the anchors such as seat belt webbing or seat cushion material. The child restraint will not be secured properly if the lower

anchors are obstructed. Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach adult seat belts, or other items or equipment to the vehicle. Doing so could damage the child restraint anchorages. The child restraint will not be properly installed using the damaged anchorage, and a child could be seriously injured or killed in a collision.

LATCH lower anchor locations

NIC2612

LATCH lower anchor location

The LATCH lower anchors are located at the rear of the seat cushion near the seatback. A label is attached to the seatback to help you locate the LATCH lower anchors.

LATCH webbing-mounted attachment

SSS0643Z

Installing child restraint LATCH lower anchor attachments

LATCH compatible child restraints include two rigid or webbing-mounted attachments that can be connected to two anchors located at certain seating positions in your vehicle. With this system, you do not have to use a vehicle seat belt to secure the child restraint. Check your child restraint for a label stating that it is compatible with LATCH. This information may also be in the instructions provided by the child restraint manufacturer. When installing a child restraint, carefully read and follow the instructions in this manual and those supplied with the child restraints.

1-22 Safety — seats, seat belts and supplemental restraint system

LATCH rigid-mounted attachment

SSS0644Z

Top tether anchor

WARNING

• Child restraint anchorages are designed to

withstand only those loads imposed by cor-

rectly fitted child restraints. Under no cir-

cumstances are they to be used to attach

adult seat belts, or other items or equip-

ment to the vehicle. Doing so could damage

the child restraint anchorages. The child re-

straint will not be properly installed using

the damaged anchorage, and a child could

be seriously injured or killed in a collision.

• If the cargo cover (if so equipped) contacts

the top tether strap when it is attached to

the top tether anchor, remove the cargo

cover from the vehicle or secure it on the

cargo floor below its attachment location. If the cargo cover is not removed, it may damage the top tether strap during a collision. A child could be seriously injured or killed in a collision if the top tether strap is damaged.

• Do not allow cargo to contact the top tether

strap when it is attached to the top tether anchor. Properly secure the cargo so it does not contact the top tether strap. Cargo that is not properly secured or cargo that contacts the top tether strap may damage it during a collision. A child could be seriously injured or killed in a collision if the top tether strap is damaged.

NIC2849

Top tether anchor point locations

Top tether straps

䊊

Anchor points

䊊

If you have any questions when installing a top tether strap, it is recommended that you visit an INFINITI retailer for this service.

REAR-FACING CHILD RESTRAINT INSTALLATION USING LATCH

For additional information, refer to all Warnings and Cautions in the ⬙Child safety⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section and ⬙Child restraints⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section before installing a child restraint. Do not use the lower anchors if the combined weight of the child and

Safety — seats, seat belts and supplemental restraint system 1-23

the child restraint exceeds 65 lb (29.5 kg). If the combined weight of the child and the child restraint is greater than 65 lb (29.5 kg), use the vehicle seat belt (not the lower anchors) to install the child restraint. Be sure to follow the child restraint manufacturer’s instructions for installation. Follow these steps to install a rear-facing child restraint in the 2nd row seats using the LATCH system:

1. Position the child restraint on the seat. Always follow the child restraint manufacturer’s instructions.

Rear-facing web-mounted — step 2

WRS0801Z

2. Secure the child restraint anchor attachments to the LATCH lower anchors. Check to make sure the LATCH attachment is properly attached to the lower anchors.

Rear-facing rigid-mounted — step 2

WRS0802Z

3. For child restraints that are equipped with webbing-mounted attachments, remove any additional slack from the anchor attachments. Press downward and rearward firmly in the center of the child restraint with your hand to compress the vehicle seat cushion and seatback while tightening the webbing of the anchor attachments.

1-24 Safety — seats, seat belts and supplemental restraint system

Rear-facing — step 3

LRS0673Z

4. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the LATCH attachment path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the LATCH attachment holds the restraint in place. If the restraint is not secure, tighten the LATCH attachment as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint or try installing by using the vehicle seat belt (if applicable). Not all child restraints fit in all types of vehicles.

Rear-facing — step 4

LRS0674Z

5. Check to make sure the child restraint is properly secured prior to each use. If the child restraint is loose, repeat steps 2 through 4.

REAR-FACING CHILD RESTRAINT INSTALLATION USING THE SEAT BELTS

WARNING

Do not use the lower anchors if the combined weight of the child and the child restraint exceeds 65 lb (29.5 kg). If the combined weight of the child and the child restraint is greater than 65 lb (29.5 kg), use the vehicle seat belt (not the lower anchors) to install the child restraint. Be sure to follow the child restraint manufacturer’s instructions for installation.

Follow these steps to install a rear-facing child restraint using the vehicle seat belts in the rear seats:

Safety — seats, seat belts and supplemental restraint system 1-25

Rear-facing — step 1

1. Child restraints for infants must be used in the rear-facing direction and therefore must not be used in the front seat. Position the

child restraint on the seat. Always follow the child restraint manufacturer’s instructions.

WRS0256Z

Rear-facing — step 2

2. Route the seat belt tongue through the child restraint and insert it into the buckle until you hear and feel the tongue engage. Be sure to follow the child restraint manufacturer’s instructions for belt routing.

1-26 Safety — seats, seat belts and supplemental restraint system

WRS0761Z

Rear-facing — step 3

LRS0669Z

3. Pull the shoulder belt until the belt is fully extended. At this time, the seat belt retractor is in the ALR mode (child restraint mode). It reverts to the ELR mode when the seat belt is fully retracted.

Rear-facing — step 4

LRS0670Z

4. Allow the seat belt to retract. Pull up on the shoulder belt to remove any slack in the belt.

Rear-facing — step 5

WRS0762Z

5. Remove any additional slack from the seat belt; press downward and rearward firmly in the center of the child restraint to compress the vehicle seat cushion and seatback while pulling up on the seat belt.

Safety — seats, seat belts and supplemental restraint system 1-27

Rear-facing — step 6

SSS0658Z

6. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the seat belt path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the belt holds the restraint in place. If the restraint is not secure, tighten the seat belt as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.

7. Check to make sure that the child restraint is properly secured prior to each use. If the seat belt is not locked, repeat steps 1 through 6.

After the child restraint is removed and the seat belt fully retracted, the ALR mode (child restraint mode) is canceled.

1. Position the child restraint on the seat. Always follow the child restraint manufacturer’s instructions.

FORWARD-FACING CHILD RESTRAINT INSTALLATION USING LATCH

Follow these steps to install a forward-facing child restraint in the rear seats using the LATCH system:

1-28 Safety — seats, seat belts and supplemental restraint system

Forward-facing web-mounted — step 2

SSS0645Z

2. Secure the child restraint anchor attachments to the LATCH lower anchors. Check to make sure the LATCH attachment is properly attached to the lower anchors.

If the child restraint is equipped with a top tether strap, route the top tether strap and secure the tether strap to the tether anchor point. For additional information, refer to ⬙Installing top tether strap⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

Do not install child restraints that require the use of a top tether strap in seating positions that do not have a top tether anchor.

3. The back of the child restraint should be secured against the vehicle seatback.

** Click HERE to see "Owner's Manual Supplement" **

Forward-rigid web-mounted — step 2

SSS0646Z

If necessary, adjust or remove the head restraint/headrest to obtain the correct child restraint fit. If the head restraint/headrest is removed, store it in a secure place. Be sure

to reinstall the head restraint/headrest when the child restraint is removed. For additional

information about head restraint/headrest adjustment, refer to ⬙Head restraints/Headrests⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section. If the seating position does not have an adjustable head restraint/ headrest and it is interfering with the proper child restraint fit, try another seating position or a different child restraint.

Forward-facing — step 4

SSS0647Z

4. For child restraints that are equipped with webbing-mounted attachments, remove any additional slack from the webbing of the anchor attachments. Press downward and rearward firmly in the center of the child restraint with your knee to compress the vehicle seat cushion and seatback while tightening the webbing of the anchor attachments.

5. Tighten the tether strap according to the manufacturer’s instructions to remove any slack.

Safety — seats, seat belts and supplemental restraint system 1-29

Forward-facing — step 6

SSS0638Z

6. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the LATCH attachment path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the LATCH attachment holds the restraint in place. If the restraint is not secure, tighten the LATCH attachment as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.

7. Check to make sure the child restraint is

properly secured prior to each use. If the child restraint is loose, repeat steps 3 through 6.

Installing top tether strap

The child restraint top tether strap must be used when installing the child restraint with the LATCH lower anchor attachments. First, secure the child restraint with the LATCH lower anchors (rear outboard seating positions only).

Child restraint anchorages are designed to withstand only those loads imposed by correctly fitted child restraints. Under no circumstances are they to be used to attach adult seat belts, or other items or equipment to the vehicle. Doing so could damage the child restraint anchorages. The child restraint will not be properly installed using the damaged anchorage, and a child could be seriously injured or killed in a collision.

Outboard seating positions with removable head restraints/headrests

1. If necessary, raise or remove the head restraint/headrest and store it in a secure place. Be sure to reinstall the head restraint/ headrest when the child restraint is re-

1-30 Safety — seats, seat belts and supplemental restraint system

WARNING

NIC2849

moved. For additional information about head restraint/headrest adjustment, removal and installation, refer to ⬙Head restraints/Headrests⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

2. Position the top tether strap seatback.

3. Secure the tether strap to the tether anchor

4. Tighten the tether strap according to the

Outboard seating positions with fixed head restraints/headrests

1. If the child restraint has a single tether strap,

2. Secure the tether strap to the tether anchor

3. Tighten the tether strap according to the

point restraint.

manufacturer’s instructions to remove any slack.

on the seatback behind the child

䊊

route the strap head restraint/headrest. If the child restraint has two tether straps, route them round each side of the outer head restraint/headrest.

point restraint.

manufacturer’s instructions to remove any slack.

on the seatback behind the child

䊊

over the top of the outer

䊊

over the

If you have any questions when installing a top tether strap, it is recommended that you visit an INFINITI retailer for this service.

FORWARD-FACING CHILD RESTRAINT INSTALLATION USING THE SEAT BELTS

WARNING

The three-point seat belt with Automatic Locking Retractor (ALR) must be used when installing a child restraint. Failure to use the ALR mode will result in the child restraint not being properly secured. The restraint could tip over or be loose and cause injury to a child in a sudden stop or collision. Also, it can change the operation of the front passenger air bag. For additional information, refer to ⬙Front passenger air bag and status light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

Follow these steps to install a forward-facing child restraint using the vehicle seat belt in the rear seats or in the front passenger seat:

Forward-facing (front passenger seat) — step 1

WRS0699Z

1. If you must install a child restraint in the front

seat, it should be placed in a forward-facing direction only. Move the seat to the rearmost position. Child restraints for infants must be used in the rear-facing direction and, therefore, must not be used in the front seat.

2. Position the child restraint on the seat. Always follow the child restraint manufacturer’s instructions. The back of the child restraint should be secured against the vehicle seatback. If necessary, adjust or remove the head restraint/headrest to obtain the correct child restraint fit. If the head restraint/ headrest is removed, store it in a secure place. Be sure to reinstall the head restraint/

headrest when the child restraint is removed.

For additional information about head restraint/headrest adjustment, removal and

Safety — seats, seat belts and supplemental restraint system 1-31

installation, refer to ⬙Head restraints/Headrests⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

If the seating position does not have an adjustable head restraint/headrest and it is interfering with the proper child restraint fit, try another seating position or a different child restraint.

Forward-facing — step 3

WRS0680Z

3. Route the seat belt tongue through the child restraint and insert it into the buckle until you hear and feel the tongue engage. Be sure to follow the child restraint manufacturer’s instructions for belt routing. If the child restraint is equipped with a top tether strap, route the top tether strap and secure the tether strap to the tether anchor point (rear seat installation only). For additional information, refer to ⬙Installing top tether strap⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

Do not install child restraints that require the use of a top tether strap in seating positions that do not have a top tether anchor.

Forward-facing — step 4

LRS0667Z

4. Pull the shoulder belt until the belt is fully extended. At this time, the seat belt retractor is in the ALR mode (child restraint mode). It reverts to ELR mode when the seat belt is fully retracted.

1-32 Safety — seats, seat belts and supplemental restraint system

Forward-facing — step 5

LRS0668Z

5. Allow the seat belt to retract. Pull up on the shoulder belt to remove any slack in the belt.

Forward-facing — step 6

WRS0681Z

6. Remove any additional slack from the seat belt; press downward and rearward firmly in the center of the child restraint with your knee to compress the vehicle seat cushion and seatback while pulling up on the seat belt.

7. Tighten the tether strap according to the manufacturer’s instructions to remove any slack.

Safety — seats, seat belts and supplemental restraint system 1-33

Forward-facing — step 8

WRS0698Z

8. After attaching the child restraint, test it before you place the child in it. Push it from side to side while holding the child restraint near the seat belt path. The child restraint should not move more than 1 inch (25 mm), from side to side. Try to tug it forward and check to see if the belt holds the restraint in place. If the restraint is not secure, tighten the seat belt as necessary, or put the restraint in another seat and test it again. You may need to try a different child restraint. Not all child restraints fit in all types of vehicles.

9. Check to make sure the child restraint is

properly secured prior to each use. If the seat belt is not locked, repeat steps 2 through 8.

passenger seat, the seat may not be used for a child restraint. Move the child restraint to another position. See ⬙Troubleshooting⬙ later in this section. Have the system checked. It is recommended you visit an INFINITI retailer for this service.

Installing top tether strap

Forward-facing — step 10

SSS0676Z

10. If the child restraint is installed in the front passenger seat, place the ignition switch in the ON position. The front passenger air bag status OFF light should illuminate. If this light is not illuminated refer to ⬙Front passenger air bag and status light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section. Move the

child restraint to another seating position.

Have the system checked. It is recommended you visit an INFINITI retailer for this service. After the child restraint is removed and the seat belt is fully retracted, the ALR mode (child restraint mode) is canceled.

If the <PASSENGER AIR BAG OFF> indicator lamp does NOT light continuously when a child restraint is installed on the front

The child restraint top tether strap must be used when installing the child restraint with seat belts.

First, secure the child restraint with the seat belt.

1-34 Safety — seats, seat belts and supplemental restraint system

WARNING

䊊

NIC2848

over the

Rear seat - Type A

Outboard seating positions with removable head restraints/headrests

1. If necessary raise or remove the head restraint/headrest and store it in a secure place. Be sure to reinstall the head restraint/ headrest when the child restraint is removed. For additional information about head restraint/headrest adjustment, removal and installation, refer to ⬙Head restraints/Headrests⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

2. Position the top tether strap

seatback.

3. Secure the tether strap to the tether anchor

point

䊊

restraint.

on the seatback behind the child

Rear seat - Type B

4. Tighten the tether strap according to the manufacturer’s instructions to remove any slack.

Outboard seating positions with fixed head restraints/headrests

1. If the child restraint has a single tether strap,

route the strap head restraint/headrest. If the child restraint has two tether straps, route them round each side of the outer head restraint/headrest.

2. Secure the tether strap to the tether anchor

3. Tighten the tether strap according to the

point

䊊

restraint.

manufacturer’s instructions to remove any slack.

over the top of the outer

䊊

on the seatback behind the child

NIC2903

Center seating position with adjustable head restraint/headrest

1. Raise the head restraint/headrest. For additional information about head restraint/ headrest adjustment, removal and installation, refer to ⬙Head restraints/Headrests⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

2. Position the top tether strap

head restraint/head rest and over the seatback, between the two head restraint/ headrest stalks.

3. Secure the tether strap to the tether anchor

4. Tighten the tether strap according to the

point

䊊

restraint.

manufacturer’s instructions to remove any slack.

If you have any questions when installing a top tether strap, it is recommended that you visit an INFINITI retailer for this service.

under the

䊊

on the seatback behind the child

BOOSTER SEATS

For additional information on installing a booster seat in your vehicle, follow the instructions outlined in this section.

Precautions on booster seats

WARNING

If a booster seat and seat belt are not used properly, the risk of a child being injured or killed in a sudden stop or collision greatly increases:

• Make sure the shoulder portion of the belt is

away from the child’s face and neck and the lap portion of the belt does not cross the stomach.

• Make sure the shoulder belt is not behind

the child or under the child’s arm.

• A booster seat must only be installed in a

seating position that has a lap/shoulder belt.

Safety — seats, seat belts and supplemental restraint system 1-35

LRS0501Z LRS0464Z LRS0455Z

Booster seats of various sizes are offered by several manufacturers. When selecting any booster seat, keep the following points in mind:

• Choose only a booster seat with a label

certifying that it complies with Federal Motor Vehicle Safety Standard 213 or Canadian Motor Vehicle Safety Standard 213.

• Check the booster seat in your vehicle to be

sure it is compatible with the vehicle’s seat and seat belt system.

• Make sure the child’s head will be properly

supported by the booster seat or vehicle seat. The seatback must be at or above the center of the child’s ears. For example, if a low back booster seat vehicle seatback must be at or above the center of the child’s ears. If the seatback is

is chosen, the

䊊

lower than the center of the child’s ears, a high back booster seat

• If the booster seat is compatible with your

vehicle, place the child in the booster seat and check the various adjustments to be sure the booster seat is compatible with the child. Always follow all recommended procedures.

All U.S. states and Canadian provinces or territories require that infants and small children be restrained in an approved child restraint at all times while the vehicle is being operated.

The instructions in this section apply to booster seat installation in the rear seats or the front passenger seat.

1-36 Safety — seats, seat belts and supplemental restraint system

should be used.

䊊

Booster seat installation

WARNING

If a booster seat and seat belt are not used properly, the risk of a child being injured or killed in a sudden stop or collision greatly increases:

• Make sure the shoulder portion of the belt is

away from the child’s face and neck and the lap portion of the belt does not cross the stomach.

• Make sure the shoulder belt is not behind

the child or under the child’s arm.

• A booster seat must only be installed in a

seating position that has a lap/shoulder belt.

To avoid injury to a child, do not use the lap/ shoulder belt in the Automatic Locking Retractor (ALR) mode when using a booster seat with the seat belts.

For additional information, refer to all Warnings and Cautions in the ⬙Child safety⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section, ⬙Child restraints⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section and ⬙Booster seats⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section before installing a child restraint.

Follow these steps to install a booster seat in the rear seat or in the front passenger seat:

WRS0699Z LRS0451Z

1. If you must install a booster seat in the front

seat, move the seat to the rearmost position.

2. Position the booster seat on the seat. Only

place it in a front-facing direction. Always follow the booster seat manufacturer’s instructions.

Rear center position

3. The booster seat should be positioned on the vehicle seat so that it is stable.

If necessary, adjust or remove the head restraint to obtain the correct booster seat fit. If the head restraint is removed, store it in a secure place. Be sure to reinstall the

head restraint when the booster seat is removed.

For additional information about head restraint/headrest adjustment, removal and installation, refer to ⬙Head restraints/Headrests⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

If the seating position does not have an adjustable head restraint/headrest and it is interfering with the proper booster seat fit,

Safety — seats, seat belts and supplemental restraint system 1-37

** Click HERE to see "Owner's Manual Supplement" **

LRS0452Z

Rear outboard position

try another seating position or a different booster seat.

4. Position the lap portion of the seat belt low and snug on the child’s hips. Be sure to follow the booster seat manufacturer’s instructions for adjusting the seat belt routing.

5. Pull the shoulder belt portion of the seat belt toward the retractor to take up extra slack. Be sure the shoulder belt is positioned across the top, middle portion of the child’s shoulder. Be sure to follow the booster seat manufacturer’s instructions for adjusting the seat belt routing.

6. Follow the warnings, cautions and instructions for properly fastening a seat belt shown in ⬙Precautions on seat belt usage⬙ earlier in this section.

NIC2740

7. If the booster seat is installed in the front passenger seat, place the ignition switch in the ON position. Either the <PASSENGER AIR BAG ON> GER AIR BAG OFF> will illuminate depending on the size of the child and the type of booster seat used. See ⬙Front passenger air bag and status light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

indicator light or <PASSEN-

䊊

indicator light

䊊

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

PRECAUTIONS ON SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

This Supplemental Restraint System (SRS) section contains important information concerning the following systems:

• Driver and passenger supplemental front im-

pact air bags (INFINITI Advanced Air Bag System)

• Driver and passenger supplemental knee air

bags

• Front seat-mounted side-impact supplemen-

tal air bag

• Roof-mounted curtain side-impact supple-

mental air bags

• Seat belts with pretensioner

Supplemental front-impact air bag system

The INFINITI Advanced Air Bag System can help cushion the impact force to the head and chest of the driver and front passenger in certain frontal collisions.

1-38 Safety — seats, seat belts and supplemental restraint system

** Click HERE to see "Owner's Manual Supplement" **

Driver’s and passenger’s supplemental knee air bags

This system can help cushion the impact force to the driver’s and passenger’s knees in certain collisions.

Front seat-mounted side-impact supplemental air bag system

This system can help cushion the impact force to the chest and pelvis areas of the driver and front passenger in certain side-impact collisions. The side air bag is designed to inflate on the side where the vehicle is impacted.

Window bag/roof-mounted curtain side-impact and rollover supplemental air bags

This system can help cushion the impact force to the head of occupants in the outboard seating positions in certain side-impact or rollover collisions. In a side impact, the curtain air bags are designed to inflate on the side where the vehicle is impacted. In a rollover, curtain air bags on both sides are designed to inflate and remain inflated for a short time.

Curtain air bags are also designed to inflate in certain types of rollover collisions or near rollovers. As a result, certain vehicle movements

(for example, during severe off-roading) may cause the curtain air bags to inflate.

The SRS is designed to supplement the crash protection provided by the driver and front passenger seat belts and is not a substitute for them. Seat belts should always be correctly worn and the occupant seated a suitable distance away from the steering wheel, instrument panel and front door finishers. For additional information, see ⬙Seat belts⬙ earlier in this section.

The supplemental air bags operate only when the ignition switch is placed in the ON position.

After placing the ignition switch in the ON, the air bag warning light will illuminate. The air bag warning light will turn off within a few seconds after the engine is started if the system is operational. See ⬙Warning lights, indicator lights and audible reminders⬙ in the ⬙2. Instruments and controls⬙ section for further details.

Safety — seats, seat belts and supplemental restraint system 1-39

Sit upright and well back

** Click HERE to see "Owner's Manual Supplement" **

WARNING

• The front-air bags ordinarily will not inflate

in the event of a side impact, rear impact, rollover, or lower severity frontal collision. Always wear the seat belts to help reduce the risk or severity of injury in accidents.

• The front passenger air bag will not inflate if

the passenger air bag status light is lit or if

WRS0031Z

the front passenger seat is unoccupied. For additional information, refer to ⬙Front passenger air bag and status light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

• The seat belts and the front-impact air bags

are most effective when you are sitting well back and upright in the seat. The front air bags inflate with great force. Even with the INFINITI Advanced Air Bag System, if you are unrestrained, leaning forward, sitting sideways, or out of position in any way, you are

ARS1133Z

at greater risk of injury or death in a crash. You may also receive serious or fatal injuries from the front air bag if you are up against it when it inflates. Always sit back against the seatback and as far away as practical from the steering wheel. Always properly use the seat belts.

1-40 Safety — seats, seat belts and supplemental restraint system

** Click HERE to see "Owner's Manual Supplement" **

• The driver and front passenger seat belt

buckles are equipped with sensors that detect if the seat belts are fastened. The INFINITI Advanced Air Bag System monitors the severity of a collision and seat belt usage then inflates the air bags as needed. Failure to properly wear seat belts can increase the risk or severity of injury in an accident.

• The front passenger seat is equipped with

an occupant classification sensor (pressure sensor) that turns the front passenger air bag OFF under some conditions. This sensor is only used in this seat. Failure to be properly seated and wearing the seat belt can increase the risk or severity of injury in an accident. For additional information, refer to ⬙Front passenger air bag and status light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

• Keep hands on the outside of the steering

wheel. Placing them inside the steering wheel rim could increase the risk that they are injured when the front air bag inflates.

WARNING

Never let children ride unrestrained or extend their hands or face out of the window. Do not attempt to hold them in your lap or arms. Some examples of dangerous riding positions are shown in the illustrations.

SSS0100Z

WARNING

• Even with the INFINITI Advanced Air Bag

System, never install a rear-facing child restraint in the front seat. An inflating front air bag could seriously injure or kill your child. For additional information, refer to ⬙Child restraints⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

• Children may be severely injured or killed

when the front air bags, side air bags or curtain air bags inflate if they are not properly restrained. Pre-teens and children should be properly restrained in the rear seat, if possible.

Safety — seats, seat belts and supplemental restraint system 1-41

WARNING

• Front seat-mounted side-impact supple-

mental air bags and roof-mounted curtain side-impact and rollover supplemental air bags:

• The side air bags and curtain air bags ordi-

narily will not inflate in the event of a frontal impact, rear impact, or lower severity side collision. Always wear your seat belts to help reduce the risk or severity of injury in various kinds of accidents.

** Click HERE to see "Owner's Manual Supplement" **

ARS1041Z

ARS1043Z

1-42 Safety — seats, seat belts and supplemental restraint system

ARS1042Z

ARS1044Z

** Click HERE to see "Owner's Manual Supplement" **

ARS1045Z

ARS1046Z

WRS0431Z

SSS0162Z

WRS0365Z

SSS0159Z

Safety — seats, seat belts and supplemental restraint system 1-43

WRS0363Z

WARNING

• The seat belts, the side air bags and curtain

air bags are most effective when you are sitting well back and upright in the seat with both feet on the floor. The side air bag and curtain air bag inflate with great force. Do not allow anyone to place their hand, leg or face near the side air bag on the side of the seatback of the front seat or near the side roof rails. Do not allow anyone sitting in the front seats or rear outboard seats to extend their hand out of the window or lean against the door. Some examples of dangerous riding positions are shown in the previous illustrations.

** Click HERE to see "Owner's Manual Supplement" **

• When sitting in the rear seats, do not hold

onto the seatback of the front seats. If side air bags and curtain air bags inflate, you may be seriously injured. Be especially careful with children, who should always be properly restrained. Some examples of dangerous riding positions are shown in the illustrations.

• Do not use seat covers on the front seat-

backs. They may interfere with the side air bag inflation.

1-44 Safety — seats, seat belts and supplemental restraint system

SUPPLEMENTAL AIR BAG SYSTEMS

1. Crash zone sensor

2. Supplemental front-impact air bag modules

3. Front seat-mounted side-impact supplemental air bag modules

** Click HERE to see "Owner's Manual Supplement" **

NIC2754

4. Window bag/Roof-mounted curtain sideimpact and rollover supplemental air bag inflators

5. Window bag/Roof-mounted curtain sideimpact and rollover supplemental air bag modules

6. Driver and passenger supplemental knee air bags

7. Front door pressure sensors

8. Front seat belt with pretensioners

9. Satellite sensors

10. Air bag Control Unit (ACU)

11. Rear seat belt with pretensioners

WARNING

To ensure proper operation of the passenger’s INFINITI Advanced Air Bag System, please observe the following items:

• If a forward-facing child restraint is in-

stalled in the front passenger seat, do not position the front passenger seat so the child restraint contacts the instrument panel. If the child restraint does contact the instrument panel, the system may determine the seat is occupied and the passenger air bag may deploy in a collision. For additional information about installing and using child restraints, refer to ⬙Child restraints⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

• Confirm the operating condition with the

front passenger air bag status light.

Safety — seats, seat belts and supplemental restraint system 1-45

** Click HERE to see "Owner's Manual Supplement" **

• If you notice that the front passenger air bag

status light is not operating as described in this section. It is recommended that you visit an INFINITI retailer to check the occupant classification system.

• Until you have confirmed with a retailer that

your passenger seat occupant classification system is working properly, position the occupants in the rear seating positions.

This vehicle is equipped with the INFINITI Advanced Air Bag System for the driver and front passenger seats. This system is designed to meet certification requirements under U.S. regulations. It is also permitted in Canada.

All of the information, cautions and warnings in this manual still apply and must be followed.

The driver supplemental front-impact air bag is located in the center of the steering wheel. The front passenger supplemental front-impact air bag is mounted in the dashboard above the glove box. The front air bags are designed to inflate in higher severity frontal collisions, although they may inflate if the forces in another type of collision are similar to those of a higher severity frontal impact. They may not inflate in certain frontal collisions. Vehicle damage (or

lack of it) is not always an indication of proper front air bag system operation.

The INFINITI Advanced Air Bag System monitors information from the crash zone sensor, the Air bag Control Unit (ACU), seat belt buckle sensor and occupant classification sensor (pressure sensor). Inflator operation is based on the severity of a collision and seat belt usage for the driver. For the front passenger, the occupant classification sensor is also monitored. Based on information from the sensor, only one front air bag may inflate in a crash, depending on the crash severity and whether the front occupants are belted or unbelted. Additionally, the front passenger air bag may be automatically turned off under some conditions, depending on the weight detected on the passenger seat and how the seat belt is used. If the front passenger air bag is OFF, the front passenger air bag status light will be illuminated (if the seat is unoccupied, the light will not be illuminated, but the air bag will be off). For additional information, refer to ⬙Front passenger air bag and status light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section. One front air bag inflating does not indicate improper performance of the system.

If a crash occurs in which the vehicle’s air bags deploy, by design the vehicle may not restart. If

1-46 Safety — seats, seat belts and supplemental restraint system

this occurs, it is recommended that you visit an INFINITI retailer for repair.

If you have any questions about your air bag system, it is recommended that you visit an INFINITI retailer to obtain information about the system. If you are considering modification of your vehicle due to a disability, you may also contact INFINITI. Contact information is contained in the front of this Owner’s Manual.

When a front air bag inflates, a fairly loud noise may be heard, followed by the release of smoke. This smoke is not harmful and does not indicate a fire. Care should be taken to not inhale it, as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly.

Front air bags, along with the use of seat belts, help to cushion the impact force on the face and chest of the front occupants. They can help save lives and reduce serious injuries. However, an inflating front air bag may cause facial abrasions or other injuries. Front air bags do not provide restraint to the lower body.

Even with INFINITI Advanced Air Bags, seat belts should be correctly worn and the driver and passenger seated upright as far as practical away from the steering wheel or instrument panel. The front air bags inflate quickly in order to help protect the front occupants. Because of

** Click HERE to see "Owner's Manual Supplement" **

this, the force of the front air bag inflating can increase the risk of injury if the occupant is too close to, or is against, the front air bag module during inflation. The front air bags deflate quickly after a collision.

The front air bags operate only when the ignition switch is placed in the ON position. After placing the ignition switch in the ON position, the supplemental air bag warning light illuminates. The supplemental air bag warning light will turn off a few seconds after the engine starts if the system is operational.

Front passenger air bag and status light

WARNING

The front passenger air bag is designed to automatically turn OFF under some conditions. Read this section carefully to learn how it operates. Proper use of the seat, seat belt and child restraints is necessary for most effective protection. Failure to follow all instructions in this manual concerning the use of seats, seat belts and child restraints can increase the risk or severity of injury in an accident.

<PASSENGER AIR BAG ON> indicator

䊊

lamp

<PASSENGER AIR BAG OFF> indicator

䊊

lamp

SSS0676Z

NIC2740

Status light

The indicator lamps inform you whether the front-passenger front air bag is disabled or enabled.

Turn the key to the ACC or ON position in the ignition switch. The system carries out a selfdiagnosis.

The <PASSENGER AIRBAG OFF> and <PASSENGER AIRBAG ON> indicator lamps must light up simultaneously for approximately six seconds.

The indicator lamps display the status of the front-passenger front air bag:

• <PASSENGER AIRBAG ON> lights up: the front-

passenger front air bag is enabled. If, in the event of an accident, all deployment criteria are met, the front-passenger front air bag is deployed.

• <PASSENGER AIRBAG OFF> lights up: the

front-passenger front air bag is disabled. It will then not be deployed in the event of an accident.

If the status of the front-passenger front air bag changes while the vehicle is in motion, an air bag display message appears in the vehicle information display (see ⬙ Supplemental Restraint System (SRS) air bag warning light⬙

Safety — seats, seat belts and supplemental restraint system 1-47

** Click HERE to see "Owner's Manual Supplement" **

earlier in this section). When the front passenger seat is occupied, always pay attention to the <PASSENGER AIRBAG ON> and <PASSENGER AIRBAG OFF> indicator lamps. Be aware of the status of the front-passenger front air bag both before and during the journey.

If the <PASSENGER AIRBAG OFF> indicator lamp remains off and/or the <PASSENGER AIRBAG ON> indicator lamp lights up, do not install a rearward-facing child restraint system on the front-passenger seat. For further information see ⬙Troubleshooting⬙ later in this section.

Front passenger air bag

The front passenger air bag is designed to automatically turn OFF when the vehicle is operated under some conditions as described below in accordance with U.S. regulations. If the front passenger air bag is OFF, it will not inflate in a crash. The driver air bag and other air bags in your vehicle are not part of this system. The purpose of the regulation is to help reduce the risk of injury or death from an inflating air bag to certain front passenger seat occupants, such as children, by requiring the air bag to be automatically turned OFF. Certain sensors are used to meet the requirements.

The occupant classification sensor in this vehicle is a pressure sensor. It is designed to

detect an occupant and objects on the seat by weight. For example, if a child is in the front passenger seat, the INFINITI Advanced Air Bag System is designed to turn the front passenger air bag OFF in accordance with the regulations. Also, if a child restraint of the type specified in the regulations is on the seat, its weight and the child’s weight can be detected and cause the air bag to turn OFF. Front passenger seat adult occupants who are properly seated and using the seat belt as outlined in this manual should not cause the front passenger air bag to be automatically turned OFF. For small adults it may be turned OFF, however if the occupant takes his/her weight off the seat cushion (for example, by not sitting upright, by sitting on an edge of the seat, or by otherwise being out of position), this could cause the sensor to turn the air bag OFF. Always be sure to be seated and wearing the seat belt properly for the most effective protection by the seat belt and supplemental air bag. INFINITI recommends that preteens and children be properly restrained in a rear seat. INFINITI also recommends that appropriate child restraints and booster seats be properly installed in a rear seat. If this is not possible, the occupant classification sensor is designed to operate as described above to turn the front passenger air bag OFF for specified child restraints as required by the regulations. Failing to properly secure child restraints and to

use the ALR mode may allow the restraint to tip or move in a collision or sudden stop. This can also result in the passenger air bag inflating in a crash instead of being OFF. For additional information about proper use and installation, refer to ⬙Child restraints⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

If the front passenger seat is not occupied, the front passenger air bag is designed not to inflate in a crash. However, heavy objects placed on the seat could result in air bag inflation, because of the object’s weight detected by the occupant classification sensor. Other conditions could also result in air bag inflation, such as if a child is standing on the seat, or if two children are on the seat, contrary to the instructions in this manual. Always be sure that you and all vehicle occupants are seated and restrained properly.

If the automatic front-passenger air bag deactivation system detects that:

• The front-passenger seat is unoccupied, the

<PASSENGER AIRBAG OFF> indicator lamp lights up after the system self-test and remains lit. This indicates that the front passenger front air bag is disabled.

1-48 Safety — seats, seat belts and supplemental restraint system

** Click HERE to see "Owner's Manual Supplement" **

• The front-passenger seat is occupied by a

child in a rearward-facing child restraint system, the <PASSENGER AIRBAG OFF> indicator lamp lights up after the system self test and remains lit. This indicates that the frontpassenger front air bag is disabled.

If the <PASSENGER AIR BAG OFF> indicator lamp remains off and/or the <PASSENGER AIR BAG ON> indicator lamp lights up, do not install a rearward facing child restraint system on the front passenger seat. For further information see ⬙Troubleshooting⬙ later in this section.

• The front-passenger seat is occupied by a

child in a forward-facing child restraint system, either the <PASSENGER AIRBAG ON> or <PASSENGER AIRBAG OFF> indicator lamp lights up and remains lit after the system self-test depending on the result of the classification. The result of the classification is dependent on, among other factors, the child restraint system and the child’s build.

Move the front-passenger seat as far back as possible. See ⬙Child restraints⬙ earlier in this section.

• The front-passenger seat is occupied by a

person with a smaller build (e.g. a teenager or small adult), either the <PASSENGER AIR-

BAG ON> or <PASSENGER AIRBAG OFF> indicator lamp lights up and remains lit after the system self test depending on the result of the classification.

– If the <PASSENGER AIRBAG ON> indicator

lamp lights up, move the front-passenger seat as far back as possible. Alternatively, a person with a small build can sit on a rear seat.

– If the <PASSENGER AIRBAG OFF> indicator

lamp is lit, a person with a smaller build should not use the front-passenger seat.

• The front-passenger seat is occupied by an

adult or a person with a build corresponding to that of an adult, the <PASSENGER AIRBAG ON> indicator lamp lights up after the system self-test and remains lit. This indicates that the front-passenger front air bag is enabled.

If the automatic front-passenger front air bag deactivation system is malfunctioning, the red

restraint system warning lamp in the combination meter and the <PASSENGER AIRBAG OFF> indicator lamp light up simultaneously. The front-passenger front air bag is disabled in this case and does not deploy during an accident. Have the system checked as soon as possible by qualified technicians. It is recommended that you visit an INFINITI retailer for this service.

Safety — seats, seat belts and supplemental restraint system 1-49

Troubleshooting

Problem Possible causes/consequences and solutions

The <PASSENGER AIRBAG OFF> indicator lamp lights up and remains lit, even though the front passenger seat is occupied by an adult or a person with a build corresponding to that of an adult

The <PASSENGER AIRBAG OFF> indicator lamp does not light up and/or does not stay on. The front passenger seat is empty, or occupied by a rearward-facing child restraint system.

The classification of the person on the front-passenger seat is incorrect.

• Make sure the conditions for a correct classification of the person on the front-passenger seat are met (see ⬙Front passenger air bag⬙ earlier

in this section).

• If the <PASSENGER AIRBAG OFF> indicator lamp remains lit, the front-passenger seat may not be used.

• Have the automatic front-passenger front air bag deactivation system checked as soon as possible. It is recommended that you vist an

INFINITI retailer for this service.

The automatic front-passenger air bag deactivation system is malfunctioning.

• Make sure there is nothing between the seat and the child restraint system.

• Make sure that the entire base of the child restraint system rests on the seat cushion of the front-passenger seat.

• When installing the child restraint system, make sure that the seat belt is tight. Do not pull the seat belt tight with the front passenger

seat adjustment. This could result in the seat belt and the child restraint system being pulled too tightly.

• Check that the child restraint system is installed correctly.

• Make sure that no objects are applying additional weight to the seat.

• If the <PASSENGER AIRBAG OFF> indicator lamp remains off and/or the <PASSENGER AIRBAG ON> indicator lamp lights up, do not install a

rearward-facing child restraint system on the front passenger seat. It is recommended that you fit the child restraint system to a suitable rear seat.

• Have the automatic front-passenger front air bag deactivation system checked as soon as possible. It is recommended that you vist an

INFINITI retailer for this service.

** Click HERE to see "Owner's Manual Supplement" **

1-50 Safety — seats, seat belts and supplemental restraint system

** Click HERE to see "Owner's Manual Supplement" **

Other supplemental front-impact air bag precautions

WARNING

• Do not place any objects on the steering

wheel pad or on the instrument panel. Also, do not place any objects between any occupant and the steering wheel or instrument panel. Such objects may become dangerous projectiles and cause injury if the front air bags inflate.

• Immediately after inflation, several front air

bag system components will be hot. Do not touch them; you may severely burn yourself.

• No unauthorized changes should be made

to any components or wiring of the supplemental air bag system. This is to prevent accidental inflation of the supplemental air bag or damage to the supplemental air bag system.

• Do not make unauthorized changes to your

vehicle’s electrical system, suspension system or front end structure. This could affect proper operation of the front air bag system.

• Tampering with the front air bag system

may result in serious personal injury. Tam-

pering includes changes to the steering wheel and the instrument panel assembly by placing material over the steering wheel pad and above the instrument panel or by installing additional trim material around the air bag system.

• Removing or modifying the front passenger

seat may affect the function of the air bag system and result in serious personal injury.

• Modifying or tampering with the front pas-

senger seat may result in serious personal injury. For example, do not change the front seats by placing material on the seat cushion or by installing additional trim material, such as seat covers, on the seat that are not specifically designed to assure proper air bag operation. Additionally, do not stow any objects under the front passenger seat or the seat cushion and seatback. Such objects may interfere with the proper operation of the occupant classification sensor (pressure sensor).

• No unauthorized changes should be made

to any components or wiring of the seat belt system. This may affect the front air bag system. Tampering with the seat belt system may result in serious personal injury.

• It is recommended that you visit an INFINITI

retailer for work on and around the front air bag. It is also recommended that you visit an INFINITI retailer for installation of electrical equipment. The Supplemental Restraint System (SRS) wiring harnesses* should not be modified or disconnected. Unauthorized electrical test equipment and probing devices should not be used on the air bag system.

• A cracked windshield should be replaced

immediately by a qualified repair facility. A cracked windshield could affect the function of the supplemental air bag system. * The SRS wiring harness connectors are yellow and orange for easy identification.

When selling your vehicle, we request that you inform the buyer about the front air bag system and guide the buyer to the appropriate sections in this Owner’s Manual.

Safety — seats, seat belts and supplemental restraint system 1-51

** Click HERE to see "Owner's Manual Supplement" **

certain types of rollover collisions or near rollovers. As a result, certain vehicle movements (for example, during severe off-roading) may cause the curtain air bags to inflate.

Vehicle damage (or lack of it) is not always an indication of proper side air bag and curtain air bag operation.

When the side air bags and curtain air bags inflate, a fairly loud noise may be heard, fol-

NPA849Z

Front seat-mounted side-impact supplemental air bag and window bag/roof-mounted curtain side-impact and rollover supplemental air bag systems

The side air bags are located in the outside of the seatback of the front seats. The curtain air bags are located in the side roof rails. All of the

information, cautions and warnings in this manual apply and must be followed. The side air

bags and curtain air bags are designed to inflate in higher severity side collisions, although they may inflate if the forces in another type of collision are similar to those of a higher severity impact. They are designed to inflate on the side where the vehicle is impacted. They may not inflate in certain side collisions. Curtain air bags are also designed to inflate in

lowed by release of smoke. This smoke is not harmful and does not indicate a fire. Care should be taken not to inhale it, as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly.

Side air bags, along with the use of seat belts, help to cushion the impact force on the chest of the front occupants. Curtain air bags help to cushion the impact force to the head of occupants in the front and rear outboard seating positions in all rows. They can help save lives and reduce serious injuries. However, an inflating side air bag or curtain air bag may cause abrasions or other injuries. Side air bags and curtain air bags do not provide restraint to the lower body.

The seat belts should be correctly worn and the driver and front passenger seated upright as far as practical away from the side air bag. Rear

1-52 Safety — seats, seat belts and supplemental restraint system

seat passengers should be seated as far away as practical from the door finishers and side roof rails. The side air bags and curtain air bags inflate quickly in order to help protect the occupants. Because of this, the force of the side air bags and curtain air bags inflating can increase the risk of injury if the occupant is too close to, or is against, these air bag modules during inflation. The side air bag will deflate quickly after the collision is over.

The curtain air bag will remain inflated for a short time.

The side air bags and curtain air bags operate only when the ignition switch is placed in the ON position. After placing the ignition switch in the ON position, the supplemental air bag warning light illuminates. The supplemental air bag warning light will turn off a few seconds after the engine starts if the system is operational.

WARNING

• Do not place any objects near the seatback

of the front seats. Also, do not place any objects (an umbrella, bag, etc.) between the front door finisher and the front seat. Such objects may become dangerous projectiles and cause injury if a side air bag inflates.

** Click HERE to see "Owner's Manual Supplement" **

• Right after inflation, several side air bag

and curtain air bag system components will be hot. Do not touch them; you may severely burn yourself.

• No unauthorized changes should be made

to any components or wiring of the side air bag and curtain air bag systems. This is to prevent damage to or accidental inflation of the side air bag and curtain air bag systems.

• Do not make unauthorized changes to your

vehicle’s electrical system, suspension system or side panel. This could affect proper operation of the curtain air bag systems.

• Tampering with the side air bag system may

result in serious personal injury. For example, do not change the front seats by placing material near the seatbacks or by installing additional trim material, such as seat covers, around the side air bag.

• It is recommended that you visit an INFINITI

retailer for work on and around the front air bag. It is also recommended that you visit an INFINITI retailer for installation of electrical equipment. The SRS wiring harnesses* should not be modified or disconnected. Unauthorized electrical test equipment and probing devices should not be used on the side air bag or curtain air bag systems.

Driver and passenger supplemental knee air bags

The driver’s knee air bag deploys under the steering column, while the passenger’s knee air bag deploys under the glove box. All of the information, cautions and warnings in this manual apply and must be followed. The driver’s and passenger’s knee air bags are triggered together with the front air bag. The knee air bags are designed to inflate in higher severity frontal collisions, although they may inflate if the forces in another type of collision are similar to those of a higher severity frontal impact. They may not inflate in certain collisions.

Vehicle damage (or lack of it) is not always an indication of proper knee air bag operation.

When a knee air bag inflates, a fairly loud noise may be heard, followed by release of smoke. This smoke is not harmful and does not indicate a fire. Care should be taken not to inhale it, as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly

The knee air bags help to cushion the impact force on the knees of the driver and front passenger. They can help reduce serious injuries. However, an inflating knee air bag may

cause abrasions or other injuries. The knee air bag provides restraint to the lower body.

The knee air bag inflates quickly in order to help protect the occupants. Because of this, the force of the knee air bag inflating can increase the risk of injury if the occupant is too close to, or is against, this air bag module during inflation. The knee air bag will deflate quickly after the collision is over OR the knee air bag will remain inflated for a short time.

The knee air bags operate only when the ignition switch is placed in the ON position. After placing the ignition switch in the ON position, the supplemental air bag warning light illuminates. The supplemental air bag warning light will turn off a few seconds after the engine starts if the system is operational.

WARNING

• Do not place any objects between the knee

bolster and the driver’s seat. Such objects may become dangerous projectiles and cause injury if a knee air bag inflates.

• Right after inflation, the knee air bag sys-

tem components will be hot. Do not touch them; you may severely burn yourself.

• No unauthorized changes should be made

to any components or wiring of the knee air

Safety — seats, seat belts and supplemental restraint system 1-53

** Click HERE to see "Owner's Manual Supplement" **

bag system. This is to prevent damage to or accidental inflation of the knee air bag system.

• Do not make unauthorized changes to your

vehicle’s electrical system or suspension system. This could affect proper operation of the knee air bag system.

• Tampering with the knee air bag system

may result in serious personal injury. For example, do not change the driver knee bolster or install additional trim material around the knee air bag.

• It is recommended that you visit an INFINITI

* The SRS wiring harness or connectors are

yellow or orange for easy identification.

When selling your vehicle, we request that you inform the buyer about the knee air bag system and guide the buyer to the appropriate sections in this manual.

Seat belt with pretensioner(s)

• The pretensioner(s) cannot be reused after

activation. They must be replaced together with the retractor and buckle as a unit.

• If the vehicle becomes involved in a colli-

sion but pretensioner(s) are not activated, be sure to have the pretensioner system checked and, if necessary, replaced. It is recommended that you visit an INFINITI retailer for this service.

• No unauthorized changes should be made

to any components or wiring of the pretensioner system. This is to prevent damage to or accidental activation of the pretensioner(s). Tampering with the pretensioner system may result in serious personal injury.

• It is recommended that you visit an INFINITI

retailer for work on and around the pretensioner system. It is also recommended that you visit an INFINITI retailer for installation of electrical equipment. Unauthorized electrical test equipment and probing devices should not be used on the pretensioner system.

1-54 Safety — seats, seat belts and supplemental restraint system

WARNING

• If you need to dispose of the pretensioner(s)

or scrap the vehicle, it is recommended that you visit an INFINITI retailer for this service. Incorrect disposal procedures could cause personal injury.

The pretensioner system may activate with the supplemental air bag system in certain types of collisions. Working with the seat belt retractor, the pretensioner(s) help tighten the seat belt when the vehicle becomes involved in certain types of collisions, helping to restrain front seat occupants. The pretensioner(s) are encased within the seat belt retractor and to the seat belt anchor affixed to the floor of the vehicle. These seat belts are used the same way as conventional seat belts. When pretensioner(s) activate, smoke is released and a loud noise may be heard. This smoke is not harmful and does not indicate a fire. Care should be taken not to inhale it, as it may cause irritation and choking. Those with a history of a breathing condition should get fresh air promptly. After the pretensioner(s)’s activation, load limiters allow the seat belt to release webbing (if necessary) to reduce forces against the chest. The supplemental air bag warning light is used to

indicate malfunctions in the pretensioner system. For additional information, refer to Supplemental air bag warning light in this section. If the operation of the supplemental air bag warning light indicates there is a malfunction, have the system checked. It is recommended that you visit an INFINITI retailer for this service. When selling your vehicle, we request that you inform the buyer about the pretensioner system and guide the buyer to the appropriate sections in this Owner’s Manual.

** Click HERE to see "Owner's Manual Supplement" **

SSS1016Z SPA1097Z

SUPPLEMENTAL AIR BAG WARNING LABELS

Warning labels about the supplemental front impact air bag system are placed in the vehicle as shown in the illustration.

WARNING

Do not use a rear-facing child restraint on a seat protected by an air bag in front of it. If the air bag deploys, it may cause serious injury or death.

SUPPLEMENTAL AIR BAG WARNING LIGHT

The supplemental air bag warning light, displaying the circuits for the air bag systems, pretensioner(s) and all related wiring.

When the ignition switch is placed in the ON position, the supplemental air bag warning light illuminates. The air bag warning light will turn off within a few seconds after the engine is started, if the system is operational.

If any of the following conditions occur, the front air bag, side air bag, curtain air bag and pretensioner systems need servicing:

in the instrument panel, monitors

• The supplemental air bag warning light re-

mains on after approximately 7 seconds.

Safety — seats, seat belts and supplemental restraint system 1-55

** Click HERE to see "Owner's Manual Supplement" **

• The supplemental air bag warning light

flashes intermittently.

• The supplemental air bag warning light does

not come on at all.

Under these conditions, the front air bag, side air bag, curtain air bag, knee air bag or pretensioner systems may not operate properly. They must be checked and repaired. It is recommended that you visit an INFINITI retailer for this service.

WARNING

If the supplemental air bag warning light is on, it could mean that the front air bag, side air bag, knee air bag, curtain air bag and/or pretensioner systems will not operate in an accident. To help avoid injury to yourself or others, have your vehicle checked as soon as possible. It is recommended that you visit an INFINITI retailer for this service.

REPAIR AND REPLACEMENT PROCEDURE

The front air bags, side air bags, curtain air bags, knee air bags and pretensioner(s) are designed to inflate on a one-time-only basis. As a reminder, unless it is damaged, the supplemental air bag warning light remains illuminated after inflation has occurred.

These systems should be repaired and/or replaced as soon as possible. It is recommended that you visit an INFINITI retailer for this service.

When maintenance work is required on the vehicle, the front air bags, side air bags, curtain air bags, knee air bags, pretensioner(s) and related parts should be pointed out to the person performing the maintenance. The ignition switch should always be in the LOCK position when working under the hood or inside the vehicle.

WARNING

• Once a front air bag, side air bag, knee air

bag, or curtain air bag has inflated, the air bag module will not function again and must be replaced. Additionally, the activated pretensioner(s) must also be replaced. The air bag module and pretensioner(s) should be replaced. It is recommended that you visit

an INFINITI retailer for this service. However, the air bag module and pretensioner(s) cannot be repaired.

• The front air bag, side air bag, knee air bag,

curtain air bag systems and the pretensioner system should be inspected if there is any damage to the front end or side portion of the vehicle. It is recommended that you visit an INFINITI retailer for this service.

• If you need to dispose of a supplemental air

bag or pretensioner systems or scrap the vehicle, it is recommended you visit an INFINITI retailer. Incorrect disposal procedures could cause personal injury.

• If there is an impact to your vehicle from any

direction, your automatic front-passenger air bag deactivation system should be checked to verify it is still functioning correctly. It is recommended that you visit an INFINITI retailer for this service. The system should be checked even if no air bags deploy as a result of the impact. Failure to verify proper automatic front-passenger air bag deactivation system function may result in an improper air bag deployment resulting in injury or death.

1-56 Safety — seats, seat belts and supplemental restraint system

NOTE

Safety — seats, seat belts and supplemental restraint system 1-57

2 Instruments and controls

Cockpit .............................2-2

Instrument panel .......................2-3

Meters and gauges ......................2-4

Speedometer and odometer...............2-4

Outside temperature display ..............2-5

Tachometer .........................2-5

Engine coolant temperature gauge ..........2-6

Fuel gauge .........................2-6

Warning lights, indicator lights and audible

reminders ...........................2-8

Checking lights ......................2-8

Warning lights .......................2-8

Indicator lights ......................2-13

Audible reminders ....................2-14

Vehicle information display ................2-15

Menus and submenus..................2-16

Display Messages ....................2-29

Security system .......................2-58

Immobiliser ........................2-58

Anti-theft alarm system (if equipped) ........2-58

Wiper and washer switch .................2-59

Switching the windshield wipers on/off.......2-60

Switching the rear window wiper on/off.......2-61

Rear window and outside mirror defroster switch . . .2-61

Windshield de-icer switch (if equipped) .........2-62

Headlight and turn signal switches ...........2-63

Headlight switch.....................2-63

Combination switch ...................2-65

Adaptive front lighting system (LED headlight

only) (if equipped)....................2-65

High beam assist (LED headlight only) .......2-67

Headlights misted up on the inside .........2-68

Instrument brightness control.............2-69

Fog light switch (If so equipped) .............2-69

Front fog lights .....................2-69

Rear fog light.......................2-69

Horn .............................

heating

Seat

Windows ...........................2-72

Power windows .....................2-72

Fixed glass roof (if equipped) ...............2-75

Sunshade operation ...................2-75

Clock..............................2-76

Adjusting time ......................2-76

Power outlet .........................2-76

Storage ............................2-77

Glove box .........................2-78

Front console compartment ..............2-78

Console box .......................2-78

Card holder ........................2-79

(if equipped) .................2-70

.2-70

Cup holders........................2-79

Coat hooks ........................2-80

Cargo tie-down hooks .................2-80

Luggage hooks ......................2-81

Front seat storage boxes (if equipped) .......2-82

Map pocket (if equipped) ...............2-82

Storage nets (if equipped) ...............2-82

Parcel shelf ........................2-82

Roof rack (if equipped) .................2-83

Ski hatch (if equipped) .................2-84

Compartment under trunk floor ............2-84

Interior lights.........................2-85

Front overhead control panel .............2-85

Rear reading lights (if equipped) ...........2-86

Rear room light (if equipped) .............2-86

Vanity mirror lights ...................2-86

Luggage compartment light ..............2-86

Battery saver system ..................2-86

HomeLink® Universal Transceiver (if equipped) . . . .2-86

Programming HomeLink® ...............2-87

Programming trouble diagnosis............2-89

Operating the HomeLink® Universal

Transceiver ........................2-89

Clearing the programmed information ........2-90

If your vehicle is stolen ................2-90

COCKPIT

1. Turn signal, wiper, washer, and high beam switch (P. 2-65, 2-59)

2. Steering-wheel-mounted controls (left side)

(P. 2-15)

3. Ignition switch (P. 3-16)

7. Cruise Control switch — Cruise Control (P. 5-44) — Intelligent Cruise Control (P. 2-47)

8. USB connection ports (P. 4-3)

9. Shift lever (P. 5-18)

10. Front cup holders (P. 2-79)

11. INFINITI controller (P. 4-2)

NIC2649

4. Steering-wheel-mounted controls (right side) (P. 4-3)

5. Light switch — Headlight (P. 2-63) — Fog light (P. 2-69)

6. Parking brake (P. 3-25)

2-2 Instruments and controls

INSTRUMENT PANEL

1. Ventilators (P. 4-41)

2. Center display* (P. 4-5)

3. Meters and gauges (P. 2-4)

4. Light switch (P. 2-63)

5. Parking brake (P. 3-25)

8. Ignition switch (P. 3-16)

9. Heater and air conditioner (P. 4-42)

10. Switch panel — Seat heater switches* (P. 2-70) — Hazard indicator flasher switch (P. 6-2) — Idle Stop/Start system on/off switch (P. 6-28) — Front passenger air bag status light (P. 6-47)

11. Vehicle Information Display (P. 2-15)

12. Glove box (P. 2-78)

13. Front passenger supplemental air bag

(P. 1-38)

*: if equipped

NIC2898

6. Steering wheel — Power steering system (P. 5-86) — Horn (P. 2-70) — Driver’s supplemental front-impact air bag (P. 1-38)

7. Audio system (P. 4-52)

Instruments and controls 2-3

METERS AND GAUGES

1. Speedometer (P. 2-4)

2. Vehicle information display (P. 2-15) — Odometer/twin trip odometer (P. 2-15)

3. Upper information display (P. 2-15)

4. Tachometer (P. 2-5)

5. Engine coolant temperature gauge (P. 2-6)

CAUTION

• For cleaning, use a soft cloth, dampened

with water. Never use a rough cloth, alcohol, thinner or any kind of solvent or paper towel with a chemical cleaning agent. They will scratch or cause discoloration to the lens.

• Do not spray any liquid such as water on the

meter lens. Spraying liquid may cause the system to malfunction.

SPEEDOMETER AND ODOMETER

This vehicle is equipped with a speedometer and odometer. The speedometer is located on the right side of the meter cluster. The odometer is located below the vehicle information display.

NIC2651

6. Fuel gauge (P. 2-6)

NOTE The needle indicators may move slightly after

the ignition switch is put in the “OFF” position. This is not a malfunction.

2-4 Instruments and controls

NIC2824Z NIC2824AZ

Speedometer

The speedometer indicates vehicle speed.

The speedometer is divided into segments

䊊

Cruise Control.

The segments in the speedometer indicate which speed range is available (see ⬙Displays in the speedometer⬙ in the ⬙5. Starting and driving⬙ section).

and

only on vehicles with Intelligent

䊊

Odometer/Twin trip odometer

The odometer and the twin trip odometer are displayed in the Vehicle Information Display see ⬙Vehicle information display⬙ in the ⬙5. Starting and driving⬙ section.

With segments

OUTSIDE TEMPERATURE DISPLAY

You should pay special attention to road conditions when temperatures are around freezing point.

Bear in mind that the outside temperature display indicates the measured air temperature and not the road surface temperature

Depending on the vehicle specification, the outside temperature display is in either the upper display or the main screen of the vehicle information display. See ⬙Vehicle information display⬙ in the ⬙2. Instruments and controls⬙ section.

NSD619

TACHOMETER

The tachometer indicates the engine speed in revolutions per minute (rpm). Do not rev the

engine in the red zone.

CAUTION

When engine speed approaches the red zone, shift to a higher gear or reduce engine speed. Operating the engine in the red zone may cause serious engine damage.

Instruments and controls 2-5

NIC2829 NIC2831 NIC2653

ENGINE COOLANT TEMPERATURE GAUGE

The gauge indicates the engine coolant temperature. The engine coolant temperature is within the normal range needle points within the zone shown in the illustration. The engine coolant temperature varies with the outside air temperature and driving conditions.

when the gauge

䊊

2-6 Instruments and controls

CAUTION

If the gauge indicates coolant temperature near the hot (H) end of the normal range, reduce vehicle speed to decrease temperature. If the gauge is over the normal range, stop the vehicle as soon as safely possible. If the engine is overheated, continued operation of the vehicle may seriously damage the engine. For additional information, refer to ⬙If your vehicle overheats⬙ in the ⬙6. In case of emergency⬙ section for immediate action required.

FUEL GAUGE

The fuel gauge indicates the approximate fuel level in the tank when the ignition switch is in the ON position.

The gauge may move slightly during braking, turning, accelerating, or going up and down hills due to movement of fuel in the tank.

The gauge needle returns to 0 (Empty) after the ignition switch is placed in the OFF position.

The low fuel warning vehicle information display when the fuel level in the tank is getting low.

Refill the fuel tank before the gauge registers 0 (Empty).

The arrow, lid is located on the left side of the vehicle.

, indicates that the fuel-filler

appears on the

CAUTION

• If the vehicle runs out of fuel, the Malfunc-

tion Indicator Light (MIL) may come on. Refuel as soon as possible. After a few driving trips. the light should turn off. If the light remains on after a few driving trips, have the vehicle inspected. It is recommended that you visit an INFINITI retailer for this service.

• For additional information, refer to ⬙ Mal-

function Indicator light (MIL) (yellow)⬙ in the ⬙2. Instruments and controls⬙ section.

Instruments and controls 2-7

WARNING LIGHTS, INDICATOR LIGHTS AND AUDIBLE REMINDERS

Anti-lock Braking System (ABS) warning light

Brake warning light (red) Supplemental Restraint System (SRS) air

Low tire pressure warning light* Low fuel warning light Side light indicator light

Malfunction indicator light (yellow) Turn signal/hazard indicator lights Vehicle Dynamic Control (VDC) warning

Distance warning light* Low beam indicator light Front passenger air bag status light**

Parking brake warning light (red) Vehicle Dynamic Control (VDC) OFF indica-

Parking brake warning light (yellow) Front fog light indicator light*

Coolant warning light High beam assist indicator light * *: if equipped

Some indicators and warnings are also displayed in the vehicle information display between the speedometer and tachometer see

⬙Vehicle information display⬙ in the ⬙2. Instruments and controls⬙ section.

Seat belt (driver and front passenger) warning light

bag warning light

tor light

CHECKING LIGHTS

With all doors closed, apply the parking brake, fasten the seat belts and place the ignition switch in the ON position without starting the engine. The following lights (if so equipped) will

come on, <BRAKE>,

, , , , . These lights should go out within a few seconds after starting the engine. If any light fails to come on or operates in a way other than described, it may

, , , ,

High beam indicator light

Rear fog light indicator light

light

**: located above heater and air conditioner controls

indicate a burned out bulb and/or a system malfunction. Have the system checked. It is recommended you visit an INFINITI retailer for this service.

WARNING LIGHTS

Also see ⬙Vehicle information display⬙ later in this section.

2-8 Instruments and controls

Anti-lock Braking System (ABS) warning light

When the ignition switch is in the ON position, the ABS warning light illuminates to indicate that the ABS is operational. The light then turns off within a few seconds after the engine is started.

If the ABS light comes on while the engine is running, it may indicate the anti-lock braking system is not functioning properly. Have the system checked. It is recommended that you visit an INFINITI retailer for this service.

If the ABS warning light comes on while driving, it may indicate the ABS is not functioning properly. Observe the additional display messages (if any) in the vehicle information display. Have the system checked by an INFINITI retailer.

If an ABS malfunction occurs, the anti-lock function is turned off. The brake system then operates normally, but without anti-lock assistance (see ⬙Brake system⬙ in the ⬙5. Starting and driving⬙ section).

BRAKE warning light (red)

WARNING

• Your brake system may not be working

properly if the warning light is on. Driving could be dangerous. If you judge it to be safe, drive carefully to the nearest service station for repairs. Otherwise, have your vehicle towed because driving it could be dangerous.

• Pressing the brake pedal when the ignition

switch is not in the ON position and/or when the brake fluid level is low may increase the stopping distance and braking will require greater pedal effort as well as pedal travel.

• If the brake fluid level is below the minimum

or MIN mark on the brake fluid reservoir, do not drive until the brake system has been checked. It is recommended that you visit an INFINITI retailer for this service.

When the ignition switch is placed in the ON position, the light remains illuminated and turns off when the engine is started. If the light illuminates at any other time, it may indicate that the brake system is not functioning properly. If the BRAKE warning light illuminates,

stop the vehicle immediately and contact an INFINITI retailer.

This light functions for both the parking brake and the foot brake systems.

Low tire pressure warning light (if equipped)

Your vehicle is equipped with a Tire Pressure Monitoring System (TPMS) that monitors the tire pressure of all its tires.

The low tire pressure warning light warns of low tire pressure or indicates that the TPMS is not functioning properly.

When the ignition switch is in the ON position, the Low tire pressure warming light illuminates to indicate that the system is operational. The light then tuns off within a few seconds after the engine is started.

Low tire pressure warning

If the vehicle is being driven with low tire pressure, the warning light will illuminate. A tire pressure warning message also appears in the vehicle information display.

When the low tire pressure warning light illuminates, you should stop and adjust the tire pressure of all 4 tires to the recommended COLD tire

Instruments and controls 2-9

pressure shown on the Tire and Loading Information label located in the driver’s door opening, see ⬙Tire and loading information label⬙ in the ⬙9. Maintenance and Schedules⬙ section. The low tire pressure warning light does not automatically turn off when the tire pressure is adjusted. After the tire is inflated to the recommended pressure, the vehicle must be driven at speeds above 16 MPH (25 km/h) to activate the TPMS and turn off the low tire pressure warning light. Use a tire pressure gauge to check the tire pressure.

The low tire pressure warning message appears each time the ignition switch is placed in the ON position as long as the low tire pressure warning light remains illuminated.

For additional information, see ⬙Vehicle information display⬙ later in this section and ⬙Tire Pressure Monitoring System (TPMS)⬙ in the ⬙5. Starting and driving⬙ section.

TPMS malfunction

If the TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 1 minute when the ignition switch is placed in the ON position. The light will remain on after 1 minute. Have the system checked. It is recommended that you visit an INFINITI retailer

for this service. The low tire pressure warning does not appear if the low tire pressure warning light illuminates to indicate a TPMS malfunction.

For additional information, see ⬙Tire Pressure Monitoring System (TPMS)⬙ in the ⬙5. Starting and driving⬙ section.

WARNING

• Radio waves could adversely affect electric

medical equipment. Those who use a pacemaker should contact the electric medical equipment manufacturer for the possible influences before use.

• If the light does not illuminate with the ig-

nition switch pushed ON, have the vehicle checked. It is recommended you visit an INFINITI retailer for this service.

• If the light illuminates while driving, avoid

sudden steering maneuvers or abrupt braking, reduce vehicle speed, pull off the road to a safe location and stop the vehicle as soon as possible. Driving with underinflated tires may permanently damage the tires and increase the likelihood of tire failure. Serious vehicle damage could occur and may lead to an accident and could result in serious personal injury or death. Check

the tire pressure for all four tires. Adjust the tire pressure to the recommended COLD tire pressure shown on the tire placard, located in the driver’s door opening, to turn the low tire pressure warning light off. If the light still illuminates while driving after adjusting the tire pressure, a tire may be flat. If you have a flat tire, replace it with a replacement tire as soon as possible.

• If a replacement tire is mounted or a wheel

is replaced without a TPMS sensor tire pressure will not be indicated, the TPMS will not function and the low tire pressure warning light will flash for approximately 1 minute. The light will remain on after 1 minute. Have your vehicle’s tires replaced and/or TPMS system reset as soon as possible. It is recommended you visit an INFINITI retailer for these services.

• Replacing tires with those not originally

specified by INFINITI could affect the proper operation of the TPMS.

CAUTION

• The TPMS is not a substitute for the regular

tire pressure check. Be sure to check the tire pressure regularly.

2-10 Instruments and controls

• If the vehicle is being driven at speeds of

less than 16 MPH (25 km/h), the TPMS may not operate correctly.

• Be sure to install the specified size of tires

to all four wheels correctly.

Malfunction Indicator light (MIL) (yellow)

When the ignition switch is turned to the ON position, the yellow Malfunction Indicator light illuminates. This means that the system is operational.

If the yellow engine malfunction indicator light lights up while the engine is running, there may be a fault, for example:

• In the engine management

• In the fuel injection system

• In the exhaust system

• In the ignition system (for vehicles with

gasoline engines)

• In the fuel system

• In other monitored items, for example the

automatic transmission.

The emission limit values may be exceeded and the engine may be running in emergency mode.

CAUTION

Continued vehicle operation without having the engine control system checked and repaired as necessary could lead to poor driveability, reduced fuel economy and possible damage to the engine control system.

Incorrect setting of the engine control system may lead to non-compliance of local and national emission laws and regulations.

Have the vehicle checked as soon as possible. It is recommended you visit an INFINITI retailer for this service.

Distance warning light (if equipped)

This light illuminates if the distance to the vehicle in front is too small for the speed selected.

If a warning tone also sounds, you are approaching a vehicle or stationary obstacle in your line of travel at too high a speed. For additional information see ⬙ Forward emergency braking (FEB) system (if equipped)⬙ in the ⬙5. Starting and driving⬙ section.

Electric parking brake warning light

The red indicator illuminates when the electric parking brake is engaged.

If the red indicator light for the electric parking brake flashes or is lit and/or the yellow warning light for the electric parking brake is lit, observe the additional messages displayed in the vehicle information display.

For further parking brake operation information see ⬙Parking brake⬙ in the ⬙3. Pre-driving checks and adjustments⬙ section.

Seat belt (driver and front passenger) warning light

The seat belt warning light reminds you to fasten your seat belts. The light illuminates if the engine is started, all doors are closed and the driver’s and/or front passenger’s seat belt is unfastened. It will remain illuminated until the driver and/or front passenger fastens their seat belt. A chime will sound once the vehicle is in motion, see ⬙Seat belt reminder chime⬙ later in this section. See ⬙Seat belts⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section for precautions on seat belt usage.

Instruments and controls 2-11

The seat belt warning light may also illuminate if there are objects on the front passenger seat. Remove the objects and stow them in a safe place.

Supplemental Restraint System (SRS) air bag warning light

WARNING

If the supplemental air bag warning light is on, it could mean that the front air bag, driver’s knee air bag, side air bag, curtain air bag and/or pretensioner systems will not operate in an accident. To help avoid injury to yourself or others, have your vehicle checked by an INFINITI retailer as soon as possible.

When the ignition switch is in the ON position, the Supplemental Restraint System (SRS) air bag warning light illuminates to indicate that the system is operational. The light then tuns off within a few seconds after the engine is started.

If any of the following conditions occur, the front air bag, front seat-mounted side-impact air bag, roof-mounted curtain air bag and pretensioner systems need servicing:

• The supplemental air bag warning light re-

mains on for longer than a few seconds once the engine is running.

• The supplemental air bag warning light

flashes intermittently.

• The supplemental air bag warning light does

not come on at all.

It is recommended you visit an INFINITI retailer for these services. Unless checked and repaired, the supplemental restraint system (air bag system) and/or the pretensioner systems may not function properly. For additional information, refer to ⬙Supplemental Restraint System (SRS)⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

Coolant warning light

WARNING

If the coolant warning light is lit, the engine may not be being cooled sufficiently and may be damaged. Never drive with an overheated engine. Driving when your engine is overheated can cause

some fluids which may have leaked into the engine compartment to catch fire. In addition, steam from an overheated engine can cause serious burns, which can occur just by opening the hood. There is a risk of injury

If the red coolant warning light lights up while the engine is running and the coolant temperature gauge is at the start of the scale, the temperature sensor for the coolant temperature gauge is faulty. The coolant temperature is no longer being monitored. There is a risk of engine damage if the coolant temperature is too high.

Stop the vehicle immediately, paying attention to road and traffic conditions, and switch off the engine. Do not continue driving under any circumstances.

Consult an INFINITI retailer.

If the red coolant warning light comes on while the engine is running, with or without an accompanying warning tone, it could mean that:

• The coolant level is too low.

• If the coolant level is correct, the airflow to

the engine radiator may be blocked or the electric engine radiator fan may be malfunctioning.

2-12 Instruments and controls

• The coolant is too hot and the engine is no

longer being cooled sufficiently.

Observe the additional display messages in the vehicle information display.

Stop the vehicle immediately, paying attention to road and traffic conditions, and switch off the engine.

Secure the vehicle against rolling away.

Leave the vehicle and keep a safe distance from the vehicle until the engine has cooled down.

Check the coolant level and top up the coolant, observing the warning notes (see ⬙If your vehicle overheats⬙ in the ⬙6. In case of emergency⬙ section).

If you have to top up the coolant frequently, have the engine cooling system checked.

Make sure that the air supply to the engine radiator is not blocked, e. g. by frozen slush.

Do not start the engine again until the coolant temperature is below 250 engine may otherwise be damaged.

F (120oC). The

Low fuel warning light

This light comes on when the fuel level in the fuel tank is getting low. Refuel as soon as it is convenient, preferably before the fuel gauge reaches 0

(Empty). There will be a small reserve of fuel in the

tank when the fuel gauge reaches 0 (Empty).

Vehicle Dynamic Control (VDC) warning light

The VDC warning light blinks when the Vehicle Dynamic Control (VDC) system is operating, thus alerting the driver to the fact that the road surface is slippery and the vehicle is nearing its traction limits.

You may feel or hear the system working, this is normal.

The light will continue to blink for a few seconds after the VDC system stops limiting wheel spin.

Cruise control or Intelligent Cruise Control is deactivated.

For additional information see ⬙ Vehicle Dynamic Control (VDC) OFF indicator light ⬙ in the ⬙2. Instruments and controls⬙ section and ⬙Vehicle Dynamic Control (VDC) system⬙ in the ⬙5. Starting and driving⬙ section.

INDICATOR LIGHTS

Turn signal/hazard indicator lights

The appropriate light flashes when the turn signal switch is activated. Both lights flash when the hazard switch is turned on.

Low beam indicator light

This light comes on when the switch is turned to the position: and front side, tail, number plate and instrument lights remain on.

The headlights will come on

Vehicle Dynamic Control (VDC) OFF indicator light

The light comes on when the Vehicle Dynamic Control (VDC) has been disabled. This indicates that the VDC system is not operating.

Disabling the VDC system causes the Forward Emergency Braking system to become unavailable. See ⬙ Forward emergency braking (FEB) system (if equipped)⬙ in the ⬙5. Starting and driving⬙ section for more details.

This light also comes on briefly when the ignition switch is turned to the ON position. The light will turn off after approximately 1 second if the VDC system is operational.

When the VDC OFF indicator light and VDC warning light (see ⬙ Vehicle Dynamic Control (VDC) warning light⬙ later in this section) come on with the VDC system turned on, it alerts the driver to the fact that the system’s fail-safe mode is operating. This means that the system may not be functioning properly. Have the

Instruments and controls 2-13

system checked. It is recommended you visit an INFINITI retailer for these services.

If an abnormality occurs in the system, the VDC system function will be canceled, but the vehicle is still driveable. For additional information, see ⬙Vehicle Dynamic Control (VDC) system⬙ in the ⬙5. Starting and driving⬙ section.

WARNING

VDC should remain on unless freeing a vehicle from mud or snow.

While the VDC system is operating, you might feel a slight vibration or hear the system working when starting the vehicle or accelerating, but this is normal.

Front fog light indicator light (if equipped)

The light comes on when the front fog lights are switched on (see ⬙ Fog light switch (If so equipped)⬙ later in this section).

High beam assist indicator light (if equipped)

The indicator light illuminates when the headlights come on while the headlight switch is in the AUTO position with the high beam selected. This indicates that the high beam assist system is operational. (See 2-63.)

High beam indicator light

This blue light comes on when the headlight high beams are on and goes out when the low beams are selected.

The high beam indicator light also comes on when the passing signal is activated.

Rear fog light indicator light

The light comes on when the rear fog light is switched on (see ⬙ Fog light switch (If so equipped)⬙ later in this section).

Side light and headlight indicator light

This light comes on when the side light or headlight position is selected, see ⬙Headlight and turn signal switches⬙ later in this section for further details.

/ Front passenger air

bag status light

The front passenger air bag status light ( ) located on the center console above the shift lever will illuminate when the front passenger air bag is turned OFF. When the front passenger air bag is turned on, the front passenger air bag status light ON (

For more details, see ⬙Front passenger air bag and status light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

) will illuminate.

AUDIBLE REMINDERS Parking brake reminder chime

A chime will sound when driving away if the parking brake has not been released. Stop the vehicle and release the parking brake.

Light reminder chime

With the ignition switch placed in the OFF position, a chime sounds when the driver’s door is opened if the side lights are on. Turn the headlight control switch off before leaving the vehicle.

2-14 Instruments and controls

Seat belt reminder chime

A chime will sound for approximately 120 seconds if the vehicle’s speed exceeds 16 MPH (25 km/h) and the driver’s seat belt or front passenger’s seat belt, if occupied is not securely fastened. See ⬙Seat belt warning light⬙ in the ⬙1. Safety — seats, seat belts and supplemental restraint system⬙ section.

Idle Stop/Start System reminder chime (if equipped)

The engine will shift to the normal stopped state if any of the following operations is made during Idle Stop/Start System activation, and the Idle Stop/Start System chime will sound if:

– The vehicle engine hood is open.

When the above condition continues for over 3 minutes the Idle Stop/Start System chime will sound in 5-minute intervals as a reminder to prevent the possibility of a discharged battery. Use the ignition switch to turn off the engine.

Close the hood or the driver’s door, or fasten the seat belt then restart the engine using the ignition switch.

For more information, see ⬙ Idle Stop/Start System (if equipped)⬙ in the ⬙5. Starting and driving⬙ section.

VEHICLE INFORMATION DISPLAY

NIC2751 NIC2752

The vehicle information display between the tachometer and the speedometer.

is located

䊊

Permanent display: depending on vehicle

䊊

specification: outside temperature or speed

Time

䊊

Text field

䊊

Menu bar

䊊

Drive program

䊊

Shift lever position

䊊

Text field submenu as well as display messages.

NOTE Set the time using the INFINITI controller and the

[Settings] menu available in the central display (see ⬙Clock settings⬙ in the ⬙4. Display screen, heater and air conditioner, and audio system⬙ section).

shows the selected menu or

䊊

Instruments and controls 2-15

MENUS AND SUBMENUS

To call up the menu bar press the wheel. Menu bar seconds.

Depending on the equipment fitted in the vehicle, you can call up the following menus:

or button on the steering

and select a menu,

䊊

disappears after a few

䊊

• [Trip] menu

• [Navi] menu (navigation instructions)

• [Audio] menu

• [DriveAssist] menu

• [Serv.] menu

• [Settings] menu

The [Audio] and [Navi] menus differ slightly in vehicles with an audio system and in vehicles with a navigation system. The examples given in this Owner’s Manual apply to vehicles equipped with navigation.

NIC2753 NIC2711

[Trip] menu

Standard display:

Press and hold the button on the steering wheel until the [Trip] menu with trip meter and total distance recorder

is shown.

䊊

Trip computer [From start] or [From reset]

Distance

䊊

Driving time

䊊

Average speed

䊊

Average fuel consumption

䊊

Press the wheel to select the [Trip] menu.

Press the start] or [From reset].

The values in the [From start] submenu are calculated from the start of a journey whilst the values in the [From reset] submenu are calculated from the last time the submenu was reset.

or button on the steering

or button to select [From

2-16 Instruments and controls

The [From start] trip computer is automatically reset when:

• The ignition has been switched off for more

than four hours.

• 999 hours have been exceeded.

• 9999 kilometers have been exceeded.

The [From reset] trip computer is automatically reset if the value exceeds 9999 hours or 99999 kilometers.

NIC2713 NIC2714

Displaying the range and current fuel consump-

tion

Press the or button on the steering wheel to select the [Trip] menu.

Press the approximate range sumption

Approximate range calculated according to your current driving style and the amount of fuel in the tank. If there is only a small amount of fuel left in the fuel tank, the display shows a vehicle being refuelled instead of approximate range

䊊

or button to select

and current fuel con-

䊊

that can be covered is

䊊

Digital speedometer

Press the or button on the steering wheel to select the [Trip] menu.

Press the speedometer

A gearshift recommendation displayed.

Observe the information on gearshift recommendation ing manually) (see ⬙Driving with Automatic Transmission⬙ in the ⬙5. Starting and driving⬙ section).

䊊

or button to select digital

䊊

can also be

䊊

for automatic transmission (shift-

Instruments and controls 2-17

NIC2718 NIC2719

Resetting values:

Press the or button on the steering wheel to select the [Trip] menu.

Press the function that you wish to reset.

Press the <OK> button.

Select

You can reset the values of the following functions:

or button to select the

[Yes] and press <OK> to confirm.

• Trip meter

• [From start] trip computer

• [From reset] trip computer

Navigation menu ([Navi])

Displaying navigation instructions:

In the [Navi] menu, the vehicle information display shows navigation instructions.

You can find further information on navigation in the audio system or navigation system operating instructions.

Switch on the audio system or navigation system.

Press the wheel to select the [Navi] menu.

or button on the steering

Route guidance not active

Direction of travel

䊊

Current road

䊊

2-18 Instruments and controls

NIC2720 NIC2721 NIC2838

Route guidance active — No change of direction announced

䊊

Distance to the destination Distance to the next change of direction Symbol indicating ⬙follow the road’s course⬙. Current road

Route guidance active — Change of direction without lane recommendation

Road to which the change of direction

䊊

leads

Distance to change of direction and visual

䊊

distance display

Change of direction symbol

䊊

When a change of direction is to be made, you will see symbol and distance graphic the top of the display as you approach the point of the announced change of direction. The change of direction starts once the distance display reaches zero.

for the change of direction

䊊

. This shortens towards

Route guidance active — Change of direction announced with a lane recommendation

Road to which the change of direction

䊊

leads

Distance to change of direction and visual

䊊

distance display

Recommended lane and new lane during a

䊊

change of direction

Recommended lane

䊊

Lanes not recommended

䊊

Change of direction symbol

䊊

On multi-lane roads, new lane recommendations can be displayed for the next change of direction if the digital map supports this data. During the change of direction, new lanes may be added.

Instruments and controls 2-19
