Indesit WM 12 X User Manual

Washing machine

Instructions for installation and use

WM 12 X

Quick guide

Here are the 12 topics explained in this manual. Read, learn and have fun: you will discover many secret ways to get a better wash, more easily and making your washing machine last longer .

Installation and removal (p. 10)

Installation, after delivery or transport, is the most important operation for the correct functioning of your washing machine. Always check:

1. That the electric system conforms to regulations;

2. That the inlet and draining pipes are connected correctly . Never use pipes that have already been used;

3. That the washing machine is levelled properly; something

worth checking to aid the performance of your washing machine;

4. That the drum's fixing screws have been removed from the back of the washing machine.

2. What goes in your washing machine and how

to start it (p. 2)

A correct distribution of your laundry is vital to the successful outcome of the wash and the life of the washing machine. Learn all the tips and secrets to dividing your linen: colour , type of f abric.

Guide to understanding labels (p. 5)

The symbols on the labels of your garments are easy to understand and equally important for the success of your wash. The guide includes simple instructions to help you choose the right temperature, wash cycles and ironing methods.

Useful tips to avoid mistakes (p. 6)

Years bac k, our gr andmothers were the ones who ga v e us good advice - and in those days synthetic fibres did not exist: washing was easy . Today, y our washing machine offers y ou helpful advice allowing you to wash wool even better than an expert laundress would by hand.

The detergent dispenser (p. 7)

How to use the detergent dispenser and the bleach compartment.

Understanding the control panel (p. 3)

Washing machine’ s control panel is very simple. It has only a fe w essential buttons to help you choose any type of wash cycle, ranging from the most energetic, capable of cleaning a mechanic’ s overalls, to the most delicate f or wool. Familiarising yourself with it will help you get the best out of your wash while helping your washing machine last longer. It’s easy.

8. Care and maintenance (p. 14)

With just a bit of care, it will repay you with loyalty and devotion. With the necessary upkeep, it will wash for years and years to come.

Problems and solutions (p. 8 and 9)

Before calling a technician, read these pages: immediate solutions may be found for a number of problems. If the problem persists, call your local Indesit customer services who will be pleased to help. Any failure will be repaired, as soon as possib le.

10.

Te chnical characteristics (p. 9)

Herein are the technical features of your washing machine: model type number, electric and water specifications, size, capacity, speed of the spin cycle and compliance with Italian and European regulations.

1 1. Safety for you and your family (p. 15)

Here you will find the necessary safety guidelines, and it is important for you to read this section carefully .

12.

Indesit stays with you after your purchase (p. 16)

Indesit supports its products after their purchase by offering you a range of special services, professional assistance, spare parts and quality accessories.

7. Guide to the wash programmes (p. 4)

Herein is an easy table to help you choose the right programme, temperature, detergents and possible additives. Choose the right programme and you will get better results with your wash while saving time, water and energy, day after day .

Instructions for installation and use

What goes in your washer?

Before washing, you can do a great deal to ensure better results. Divide your garments according to fabric and colour. Read the labels, follow their guidelines.

Dividing your garments

according to fabric and

colour, is very important

for good results

Before washing.

Divide your washing according to the type of fabric and colour fastness. Empty all pockets (coins, paper , money and small obejects) and ensure all loose buttons are repaired or removed prior to loading.

The labels say it all.

Always look at the labels: they tell you everything about your garment and how to wash it in the best possible way. The table on page 5 shows all meanings behind these symbols. Their recommendations are important to achieve better wash results.

Starting the washer

After installing your new washing machine, start a wash cycle by setting programme "1" at 90 degrees.

Starting your washing machine in the right way is important for the quality of your wash, to help prevent future problems and enhance life expectancy of your appliance. Once you have loaded your washing machine and added the detergent together with any fabric conditioner, alwa ys check that:

For more delicate

garments:

protect underwear, tights and stockings and delicate items by placing them in a

canvas pouch

1. The door is closed correctly.

2. The plug is secured in the socket.

3. The water supply is turned on.

4. Selector knob A is positioned on one of the symbols Reset).

Choose the desired programme

The programme is selected according to the type of garments that need to be washed. T o choose a programme, refer to the table on page 4. Turn knob A until the selected programme is aligned with the mark on the knob, turn knob B to the desired temperatu- re settings, i f necessary use buttons D, E and F, and lastly, press on/off button G (I position).

(Stop/

Big and small happily together.

This washing machine has a special electronic control device for even distribution: before the spin cycle starts, this device allows the garments to positions themselves, to minimise noise and vibrations during the spin cycle.

At the end of the wash cycle...

The I lamp to extinguish: it will take about three minutes. Then turn the washing machine off by pressing on-off button G (O position). You can now open the washing machine door safely . After ha ving removed the freshly cleaned washing, leave the door open to allow air circulation inside the drum. Always disconnect electricity at the socket and turn off the water supply .

Remember that, in the event of a power failure, or should the washing machine switch itself off, the programme chosen will remain in its memory.

How to eliminate the most common stains

Ink and biro Dab with a wad of cotton soaked in methyl alcohol or alcohol at 90°. Tar Dab with fresh butter, rub in turpentine then wash immediately. Wax Scrape away, then run a hot iron between two sheets of absorbent paper. Then rub in cotton with turpentine or

methyl alcohol.

Chewing gum Rub in nail polish remover and wipe with a clean rag. Mold Cotton and white linen should be placed in a solution of 5 parts water, one bleach and a spoon of vinegar, then

washed immediately. For other white fabrics, use hydrogen peroxide at 10 volumes and wash immediately.

Lipstick Dab with ether on wool or cotton. Use tricloroetilene for silk. Nail polish Place a sheet of absorbent paper on the side of the stain, wet it with nail polish remover, shifting the

garment as the sheet gradually changes colour. Grass Dab with a wad of cotton soaked in methyl alcohol.

Instructions for installation and use

Understanding the control panel

Here I’m in command

Making the right choice is important. And it’s easy.

Programme selector knob

Use this knob to select the wash programme.

T urn this knob clockwise only .

To select a programme, you should turn the knob so that the symbol/number of the desired programme is in line with the pointer on the knob. Now press on/off button G (position I), pilot lamp H will start flashing. After 5", the setting will be accepted, pilot lamp H will stop flashing (staying lit) and the wash cycle will begin. Should you wish to interrupt the programme in progress or set a new one, select one of the symbols 5" : when the cancellation has been accepted, pilot lamp H flashes, and you can then turn the appliance off. After the wash cycle has been set and accepted by the washing machine, turning the knob will have no effect (except for when it is on position

(Stop/Reset) and wait

Stop/Reset).

Temperature contr ol knob

It is used to set the wash temperature in the recommended programme table on pag. 4. It also allows you to reduce the temperature recommended for the selected programme, and even to set a cold wash cycle (

Detergent dispenser

It is divided into three compartments:

1.Detergent for pre-wash;

2.Detergent for the main cycle wash;

3. F abric conditioner.

The washing machine is equipped with an extra compartment 4 (provided as an accessory) for the bleach, to be inserted in compartment 1.

Easy iron

This function allows your washing to come out of the machine without creases, making it much easier to iron. Y ou can use it with prog rammes 3-4 (Cotton), 5-6-7 (Synthetics) and 9-10 (Delicates).

Press this button in programmes 5-6-7-9-10 and the wash cycle will come to a stop on symbol te it by pressing button D again.

. You can comple-

Important: this function should not be used when button F (Stain removal) has been pressed.

Slow spin

Use this button to reduce the spinning speed from 1200 to 600 rpm for the cotton and linen programmes and from 850 to 600 rpm for the synthetic fabrics programmes.

Stain removal (see page 7)

Thanks to this command, the washing machine will carry out a more intensive wash that optimises the effectiveness of the liquid additives, thus allowing more resistant stains to be removed. When you press the stain removal button, you cannot activate the pre-wash.

On-off

When button G is pressed, the washing machine is switched on, when it is not the machine is switched off.

Turning the appliance off does not cancel the selected programme.

The door block lamp

The safety lamp indicates that the washing machine door is locked to prevent it from being opened accidentally. To avoid any damages to lock mechanism, you must wait for the lamp to extinguish, before attempting to open the door which takes around three minutes.

The detergent dispenser with the

additional bleach compartment

is here.

Instructions for installation and use

The on-off lamp

Lamp H flashes when the appliance is switched on and awaiting a programme to be set. A steady light means the appliance has accepted the selected programme.

What are you washing today?

A programme for all seasons

Type of fabric and degree of soil Programme

COTTON

Exceptionally soiled whites (sheets, tablecl ot hs, et c.)

Heavily soiled whites and fast colour s

Slightly soiled whites and delicate colours (shirts, jumpers, et c.)

Rinse cycles/Bleach

Spin cycle Draining and final spin cycle Stop/Reset

SYNTHETICS

Heavily soiled fast colour synthetics (baby linen, etc.)

Delicate colour synthetics (all types of slightly soiled gar ments )

Delicate colour synthetics (all types of slightly soiled garments

Rinse cycles/Bleach

Fabric softener

Spin cycle Draining and delicate spin cycle Stop/Reset

DELICATES

Wool, hand wash

Particularly deli cate ga rmen ts and fabrics (curtains, silk, visco se, e tc.)

Rinse cycles Spin cycle Draining and delicate spin cycle Drain Drain Stop/Reset

knob

)

Temperature knob

1 90°C 2 90°C 3 60°C 4 40°C

5 60°C 6 50°C 7 40°C 8 30°C

9 40°C

10 30°C

Detergent for wash

Fabric softener

◆◆

◆

◆◆

◆

◆◆

◆

Stain rem. button/ Bleach

Del./Trad.

Delicate

Length of the cycle (minutes)

165

145

130

100

Description o f wash cycle

Warm prewash, wash cycle at 90 °C, rin se cycles, intermediate an d f ina l sp in c ycles

Wash cycle at 90°C, r inse cycles, intermediate and final spin cycles

Wash cycle at 60°C, r inse cycles, intermediate and final spin cycles

Wash cycle at 40°C, r inse cycles, intermediate and final spin cycles

Rinse cycles, intermediate a nd fin al spin cycles

Interrupts/Cancels the selected programme

Wash cycle at 60°C, r inse cycles, anti-crease or delicate spin cycle

Wash cycle at 50°C, r inse cycles, anti-crease or delicate spin cycle

Wash cycle at 40°C, r inse cycles, anti-crease or delicate spin cycle

Wash cycle at 30°C, r inse cycles and delicate spin cyc le

Rinse cycles, anti-crease or delicate spin cycel

Rinse cycles with automatic introduction of softener, anti-crease or de licate spin cycle

Interrupts/Cancels the selected programme

Wash cycle at 40°C, r i nse cycles and delicate spin cyc le

Wash cycle at 30°C, r inse cycles, anti-crease or drain ing

Rinse cyclesi, anti-crease or dra ining

Interrupts/Cancels the selected programme

Important: to cancel the wash programme you have just set, select one of the symbols (Stop/Reset) and wait for at least 5 seconds.

The data found in the table is purely indicative, and can vary according to the quantity and type of washing, the water system temperature and

the room temperature.

Special programme

Daily wash Y our washer has a programme available for the washing of lightly soiled garments in a short amount of time. By setting programme 8 at a temperature of 30°C, you can wash different types of fabrics together (except for wool and silk), with a maximum load of 3 kg. This programmes allows you to save on both time and energy as it only lasts around 30 minutes.

WE RECOMMEND THE USE LIQUID DETERGENT.

Instructions for installation and use

Understanding labels

Learn the meaning of these symbols and you will get better results, your garments will last longer resulting in an improved wash.

All over Europe, garment labels contain messages expressed in small yet important symbols. Understanding them is very important if you want to get better results and treat your

These symbols are divided in five different categories and shapes: washing ironing drying

, bleaching ,

, dry cleaning and

. garments the way they deserve to be treated.

Useful tips

Turn shirts inside out to get better results and make them last longer.

Always empty pockets of their contents. Look at the label: it will always give you useful

advice. When loading your washing, try to have a mixture

of large to small items.

Consult and learn the symbols in this table: they will help you obtain a better wash, treat your clothes properly, and get a better performance out of your washing machine.

Make sure you select the right

temperature!

Strong

action

Wash Bleaching Ironing Dry cleaning Drying

Wash at

95°C

Delicate

action

Blea ch ing on ly in

cold water

Hot iron at max

200°C

Dry clean with any

solvent Machine dryable

High

Temp.

Dry clean only with

Wash at

60°C Do not bleach

Medium hot

ironing at

max 150°C

perchloride, benzine

av., pure alcohol,

R111 and R113

Do not machine

Dry clean with av.

Wash at

40°C

Wash at

30°C Not ironable Do not dry clean

Hand wash

Iron at max

110°C

benzine, pure alcohol

and R113 Spread to dry

Hang to dry without s pin

drying

Dry on clothes

hanger

Low

Temperat.

dry

Not

washable in

water

Instructions for installation and use

Useful tips

Never use your washing

machine to wash... torn, fraying

or non-hemmed linen. If it is absolutely neccessary, place it in a bag for protection. Do not wash coloured linen with whites.

Watch the weight! For best results, do not exceed the weight limits stated below (figures show weight of dry garments):

- Resistant fabrics:

5,5 kg maximum

- Synthetic fabrics:

2.5 kg maximum

- Delicate fabrics:

2 kg maximum

- Pure new wool:

1 kg maximum

How much does it weigh? 1 sheet 400-500 gr. 1 pillow case 150-200 gr. 1 tablecloth 400-500 gr . 1 bathrobe 900-1,200 gr. 1 towel 150-250 gr .

Coloured T-shirts, printed ones and shirts last longer if turned inside out before washing. Printed T-shir ts and sweatshirts should always be ironed inside out.

Dungaree alert. Very popular “salopette” type overalls have straps with hooks that can damage the drum of your washing machine or other garments during the wash. To minimise the risk, place hooks in the pocket and fasten with safety pins.

Holidays: unplug the

appliance.

It is recommended that you should unplug the machine from the socket and turn off the water supply. Leave the door ajar to allow air circulation to the draw and the door gasket area. This will prevent unpleasant odours.

WOOL CYCLE

For best results, we recommend you use a specific detergent, taking care not to wash more than 1 kg of laundry .

How to wash almost anything

Curtains. Curtains tend to crease a great deal. A useful tip to reduce creasing: fold the curtains and place them in a pillow case or mesh bag. Do not load anything else inside the appliance, this will ensure that the overall weight does not exceed the half load. Remember to use the specific programme 10 which automatically excludes the spin cycle.

Quilted coats and anorak. Y ou can w ash quilted coats and wind-cheaters, too, if they are padded with goose or duck down. Do not load more than 2-3 kg and never load 5,5 kg. Repeat rinse once or twice using the gentle spin.

Trainers. Once you have removed mud and dirt from trainers, you can even wash them with jeans or any other tough garments. Do not wash trainers with whites.

Instructions for installation and use

It’ s important for a good wash

Useful tips about the detergent dispenser

The first secret is the easiest: the detergent dispenser is opened by rotating it outwards.

You must follow the dosage recommendations provided by the manufacturers when adding detergent or fabric conditioner. Doses will vary according to the wash load, the water hardness and how soiled the washing is. Experience will help you select the right dosage almost automatically: it will become your secret. Before adding detergent for prewashing in compartment 1, make sure that the extra compartment for bleach 4 has not been inserted. Ensure no overfilling when adding fabric conditioner in compartment 3. The washing machine automatically adds the softener to the wash in each programme. Liquid detergent is poured into compartment 2 just a few seconds before starting the wash cycle.

Cutting costs efficiently

Remember that liquid detergent is only designed for wash cycles of up to 60 degrees on non pre-wash items. Special containers are sold with liquid or powder detergents for placing inside the washing machine drum, these are positioned according to the instructions found in the detergent box Never use hand wash detergent, because it may form too much foam, which could damage the washing machine. Detergents that are specifically formulated for both hand and machine wash are an exception. One last secret: when washing with cold water, alw a ys reduce the amount of detergent you use: it dissolves less easily in cold water than in hot water , so part of it would be wasted.

The detergent dispenser can be removed and cleaned: pull it outwards, as indicated in the figure. Then leave it under running water for a few minutes.

Bleach cycle and stain remover

button

If bleaching is necessary, the extra case 4 (provided) must be inserted into compartment 1 of the detergent dispenser. When pouring in the bleach, be careful not to exceed the "max" level indicated on the central pivot (see illustration). The use of the additional bleach container excludes the possibility of using the pre-wash cycle. Traditional bleach can

only be used on sturdy white fabrics, whereas delicate bleach can be used for coloured fabrics, synthetics and for wool.

A guide to environmentally friendly and economic use of your appliance.

MAXIMISE THE LOAD SIZE

Achieve the best use of energy, water, detergent and time by using the recommended maximum load size. SAVE up to 50% energy by washing a full load instead of 2 half loads.

DO YOU NEED TO PRE-WASH?

For heavily soiled laundry only! SAVE detergent, time, water and between 5 to 15% energy consumption by NOT selecting Prewash for slight to normally soiled laundry.

In compartment 1: Detergent for pre-washing (powder)

In compartment 2: Detergent for washing (powder or liquid)

In compartment 3: Additives (softeners, perfumes, etc.)

In compartment 4: Bleach and delicate bleach.

MAX

You cannot bleach with the “Silk” programme and with the “special programmes” (see page 4). Use the stain removal button every time you want to bleach. Should you want to do it separately you must pour the bleach into the additional container 4, press button F (stain removal), start the washing machine, then select one of the symbols according to the type of fabric. When you bleach during a normal wash cycle, pour the detergent and any additives in the special compartments, press button F (stain removal), set the programme you desire and turn the washing machine on.

IS A HOT W ASH REQUIRED?

Pretreat stains with stain remover or soak dried in stains in water before washing to reduce the necessity of a hot wash programme. SAVE up to 50% energy by using a 60°C wash programme.

BEFORE USING A DRYING PROGRAMME ...

SAVE energy and time by selecting the highest suitable spin speed to reduce the water content in laundry before using a drying programme.

Instructions for installation and use

Troubleshooting

Before calling, read the f ollowing

In most cases, when your washing machine fails to work, the problems arising can be easily solved without having to call for a technician. Before calling for assistance, always check these points.

The washing machine fails to start.

Is the plug correctly inserted into the socket? It could have

been moved whilst cleaning.

Is there electricity in the house?

A circuit breaker may have switched off as a result of too many electrical appliances working at the same time. Or maybe due to a general failure in your entire area.

Is the washing machine door closed properly?

For safety reasons, the washing machine cannot work

if the door is open or not shut properly .

Is the On/Off button pressed?

If it is, then a programmed start has been set.

Is the programmed start knob, in the correct position for those models concerned?

Is the water supply turned on? For safety reasons, if the

washing machine does not load water, it cannot start a wash cycle.

But where did all the water go?

Simple: with the new Indesit technology, you need less than half of it, to get good results on twice as much! This is why you cannot see the water through the door: because there is little, very little of it, to respect the environment yet without renouncing maximum cleanliness. And, on top of that, you are also saving electricity.

select one of the symbols stop/reset back on. If the knob continues to turn, call for assistance because it is showing an anomaly.

, then switch it

RIGHT WR ONG

Turn off the water supply after use. This will eliminate the possibility of leakage.

Always leave the appliance door ajar to avoid bad odours.

Clean the appliance’s exteriors gently. To clean the exteriors and the rubber parts of the appliance, always use a soft cloth dipped in warm and soapy water.

Leave the washing machine plugged in while cleaning. Even during maintenance, the appliance should always be unplugged.

Use solvents and aggressive abrasives. Never use solvents or abrasives to clean the external and rubber parts of the washing machine.

Neglect the detergent dispenser. It is removable and can easily be cleaned by leaving it under running water.

Go on holiday without thinking about her. Before leaving, always make sure that the washing machine is unplugged and that the water supply is turned off.

The washing machine fails to fill with water .

Is the hose correctly connected to the tap?

Is there a water shortage ?

There could be work in progress in your building or street.

Is there sufficient water pressure? The autoclave

may be malfunctioning. Is the tap filter clean? If the

water is very calcareous, or if work has recently been carried out on the water piping, the tap filter could be clogged with particles and debris.

Is the rubber hose kinked?

The tract of the rubber hose bringing water to washing machine must be as straight as possible. Make sure it is not squashed or kinked.

The programme selector knob keeps turning?

Wait a few minutes for the drain pump to empty the tub, switch the washer off,

The washing machine continuously fills and drains water .

Is the drain hose positioned too low? It must be installed

at a height ranging from 60 to 100 cm.

Is the end of the hose

immersed in water? Does the wall drainage

system have a breather pipe? If the problem persists

even after these checks, turn the water supply off the machine and call for assistance. If you live on an upper floor of your building, there may be a problem with your drain trap. To solve this problem, a special valve must be installed.

Instructions for installation and us

Is the washing machine’s drain duct clogged? Is there

an extension of the drain hose? If so, is it positioned incorrectly, blocking the water flow?

Is there space between the machine and adjacent units? If it is not a built-in

model, the washing machine will oscillate a bit during the spin cycle. A few cm of space should therefore be left around it.

The washing machine does not drain or spin.

Does the selected programme incorporates water draining? Some

programmes stop at the end of the wash cycles and draining will have to be selected manually .

Is the “Easy ir on" function

-where provided - enabled?

This function requires manual selection for draining.

Is the drain hose kinked?

The tract of the drain hose must be as straight as possible. Make sure the drain hose is not squashed or kinked.

Always get

assistance from

authorised

technicians and

always insist on

original spare parts.

Excessive vibration during the spin cycle.

Have all transit screws been removed durind installation? See the following

page on installation procedures.

Has the washing machine been levelled correctly? The

levelling of the appliance should be checked periodically. Adjust the feet and check them with a level.

The washing machine leaks.

Is the metal ring of the inlet hose properly attached?

Turn off the water supply, unplug the appliance and try tightening its attachment without forcing it.

Is the detergent dispenser obstructed? Remove and

wash it under tap water .

Is the drain hose well attached? Turn off the water

supply , unplug the appliance and try tightening its attachment.

Too much foam.

Is the detergent appropriate for machine washing?

Check whether the definition on its label reads “for machine wash” or “hand and machine wash”, or any other similar wording.

Is the correct amount being used? An excessive amount

of detergent, besides producing too much foam, does not guarantee a more effective wash, and causes scaling in the internal parts of the appliance.

If, despite all checks, the washing machine fails to function and the problem persists, call your nearest authorised Customer Service Centre, providing the following information:

- the nature of malfunction

- the model type no. (Mod. ....)

- the serial number (S/N ....)

This information can be found on the data plate situated at the back of the washing machine.

Technical characteristics

Model Dimensions

Capacity Electrical

connections Water connections

Spinning sp ee d

Control programs in compliance with IEC regulation 456

Instructions for installation and use

WM 12 X width 59,5 cm

height 82 cm depth 53,7 cm

from 1 to 5,5 kg voltage 230/240 Volt 50 Hz

maximum absorbed power 2050 W maximum pressu r e 1 MP a ( 10 b ar)

minimum pressure 0,05 MPa (0,5 bar) drum capacity 46 litre

up to 1200 rpm

programme 3; temperature 60°C; carried out with 5 kg load.

This appliance conforms with the following E.E.C. directiv es:

- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent modifications

- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility) and subsequent modifications

Installation and removal

When the new washer arrives

Whether new or just transported to a new house, installation is extremely important for the correct functioning of your washing machine.

After removing the appliance from its packaging, check that it is intact. If in doubt, contact a qualified technician immediately .

The inside of the machine is supported, for transportation, by four screws on the back panel.

Before using the washing machine, remove the screws, remove the spacers together with the rubber tubes attached to them (keeping all the parts) and use the plastic plugs provided to fill in the holes. Important: Use the cap (provided) to close the 3 holes which housed the stop pin, situated in the right-hand part of the lower back of the washing machine.

Levelling

The washing machine must be levelled appropriatey in order to guarantee its correct functioning. T o level the appliance, the front feet must be adjusted; the angle of inclination, measured according to the worktop, must not exceed 2°. When placed on carpet, make sure the ventilation is not reduced.

Connection to the water mains

Both hot and cold water supplies are preferable and they should be between 34.5kN/m²(5lb/in²) and

1034.2kN/m² (150lb/in²) pressure. The hose having the red end fitting should be encountered between the hot supply and the threaded connection adjacent to the letter H on the rear of the machine. The hose having the white end fittings should be connected between the cold supply and the threaded connection adjacent to the letter C on the rear of the machine. Remember to insert a sealing washer at each connection to ensure watertight joints. Do not overtighten the connections by using tools -hand tight is sufficient to prevent leaks. It is generally more convenient to have these supplies away from the sink taps. Where no suitable hot water supply is available or it does not meet these requirements, both inlet hoses may be connected to a cold supply by using two taps etc., or a «T» junction on the plumbing howev er, use of cold water only will increase programme times. Note: the maximum temperature should not exceed 70°C (158°F).

Connecting the drain hose

The drain hose (hooked pipe) is secured to the rear of the machine by support clips and may be routed to right or left as required.

The hook to be used in case the drain

hose ends at a height below 60 cm.

The drain hose should be placed in a stand pipe with a minimum internal diameter of 38 mm (1½ inches) or it can be positioned over a sink or it can be connected as shown in Fig. A. The height of stand pipe or sink should be between 60 and 100 cm (24 and 40 inches). Care must be taken that the hose is not obstructed, twisted, submerged or kinked. If the hose is connected with an airtight joining, provision should be made to prevent syphoning.

Electric connection

Your appliance is now supplied with a 13 amp fused plug it can be plugged into a 13 amp socket for immediate use. Before using the appliance please read the instructions below.

WARNING - THIS APPLIANCE MUST BE EARTHED . THE FOLLOWING OPERATIONS SHOULD BE CARRIED OUT BY A QUALIFIED ELECTRICIAN.

Replacing the fuse:

When replacing a faulty fuse, a 13 amp ASTA approved fuse to BS 1362 should always be used, and the fuse cover re-fitted. If the fuse cover is lost, the plug must not be used until a replacement is obtained.

Replacement fuse covers:

If a replacement fuse cover is fitted, it must be of the correct colour as indicated by the coloured marking or the colour that is embossed in words on the base of the plug. Replacements can be obtained directly from your nearest Service Depot.

The front feet are adjustable.

Retain the transit screws,

spacers and washers.

Should you move house

then these should be

replaced to support the

inside of the machine to

prevent damage when

transporting the machine.

The rubber gasket.

Connect the inlet hose to the threaded connector on the machine rear.

Water pipe inlet at the top right.

The guide for draining into tubs and

sinks.

Fig. A

The company denies all

Warning!

liability if and when these

norms are not respected.

Plastic bags, expanded

styrofoam, nails and other

packaging parts are not

children’s toys, and are

potentially dangerous.

Instructions for installation and use

Removing the plug:

If your appliance has a nonrewireable moulded plug and you should wish to re-route the mains cable through partitions, units etc., please ensure that either: the plug is replaced by a fused 13 ampere re-wearable plug bearing the BSI mark of approval. or: the mains cable is wired directly into a 13 amp cable outlet, controlled by a switch, (in compliance with BS 5733) which is accessible without moving the appliance.

Disposing of the plug:

Ensure that before disposing of the plug itself, you make the pins unusable so that it cannot be accidentally inserted into a socket.

Instructions for connecting cable to an alternative plug: Important: the wires in the

mains lead are coloured in accordance with the following code: Green & Yellow Earth Blue Neutral Brown Live As the colours of the wires in the lead may not correspond with the coloured markings identifyng the terminals in your plug, proceed as follows: Connect Green & Yellow wire to terminal marked E or

or coloured Green or Green & Y ellow. Connect Brown wire to terminal marked L or coloured Red. Connect Blue wire to terminal marked N or coloured Black. If a 13 amp plug (BS 1363) is used it must be fitted with a 13 amp fuse, either in the plug or adaptor or at the distribution board. If you are in any doubt the electrical supply to your machine, consult a qualified electrician before use.

How to connect an alternative plug:

The wires in this mains lead are coloured in accordance with the following code: BLUE NEUTRAL (N) BROWN LIVE (L) GREEN & YELLOW EARTH (E)

Disposing of the appliance:

When disposing of the appliance please remove the plug by cutting the mains cable as close as possible to the plug body and dispose of it as described above.

GREEN & YELLOW

BROWN

BLUE

13 ampere fuse

CROSS-BAR CORD GRIP

Instructions for installation and use

Instructions for the fitter

Mounting the wooden panel onto the door and inserting the machine into cabinets:

In the case where the machine must be shipped for final installation after the wooden panel has been mounted, we suggest leaving it in its original packaging. The packaging was designed to make it possible to mount the wooden panel onto the machine without removing it completely (see figures below).

The wooden panel that covers the face of the machine must not be less than 18 mm in thickness and can be hinged on either the right or left. For the sake of practicality when using the machine, we recommend that the panel be hinged on the same side as the door for the machine itself - the left.

Door Mounting Accessories

(Fig. 1-2-3-4-5)

N° 2 Hinge Supports

Fig. 1

N° 2 Hinges

Fig. 2

lavabiancheria

achine

ashing m

achine laver

aschine

waschm

rta

r sid

rte

te po

eite

r s

lavabiancheria washing machine machine laver

aschine

waschm

r s

rte

N° 1 Magnet

5 4 3 2 1

Fig. 3

N° 1 Magnet plate

Fig. 4

N° 1 Rubber plug

Fig. 5

- No. 6 type A self-threading

6 5 4 3 2 1

screws, l =13 mm.

- No. 2 type B metric, countersunk screws, l =25; for fastening the magnet plate to the cabinet.

- No. 4 type C metric screws, l =15 mm; for mounting the hinge supports to the cabinet.

- No. 4 type D metric screws, l =7 mm; for mounting the hinges on the supports.

Fig. 4/B

N° 1 Spacer

Instructions for installation and use

Mounting the Parts onto the Face of the Machine

- Mount the hinge supports onto the face of the machine, positioning the hole indicated by the arrow in fig. 1 towards the inside of the face and using the type C screws.

- Mount the magnetic plate on the opposite side, at the top, using the two type B screws.

- Place the spacer illustrated in fig. 4/B between the appliance front and the magnet receiver.

Using the Drilling T emplate

- To trace the positions of the holes on the left-hand side of the panel, align the drilling template to the top left side of the panel using the lines traced on the extremities as a reference.

- To trace the positions of the holes on the right-hand side of

0 m

537

the panel, align the drilling template to the top right side of the panel.

- Use an appropriately sized router to mill the holes for the two hinges, the rubber plug and the magnet.

Mounding the Parts onto the Wooden P anel (Door)

- Insert the hinges into the holes (the movable part of the hinge must be positioned facing away from the panel) and fasten them with the 4 type A screws.

- Insert the magnet into the top hole on the opposite side of the hinges and fasten it with the two type B screws.

- Insert the rubber plug into the bottom hole. The panel is now ready to be mounted onto the machine.

Mounting the Panel into the machine

Insert the nib of the hinge (indicated by the arrow in fig. 2) into the hole for the hinge and push the panel towards the front of the machine. F asten the two hinges with the type D screws.

Fastening the plinth guide

If the machine is installed at the end of a set of modular cabinets, mount either one or both of the guides for the base molding (as shown in fig. 8). Adjust them for depth based on the position of the base molding, and, if necessary, fasten the base to the guides (fig. 9).

This is how to assemble the plinth guide (fig.8):

Fasten angle P using screw R, insert plinth guide Q into the special slot and once it is in the desired position, lock it in place using angle P and screw R.

Inserting the machine into the Cabinet

- Push the machine into the opening, aligning it with the cabinets (fig. 6).

- Regulate the adjustable feet to raise the machine to the appropriate height.

- To adjust the position of the wooden panel in both the vertical and horizontal directions, use the C and D screws, as shown in fig. 7.

Important: close the lower part of the appliance front by ensuring that the plinth rests against the floor.

81 mm

820

Fig. 6 Fig. 7 Fig. 9

Accessories provided for the height adjustment

The following can be found inside the polystyrene lid (fig. 10): 2 crossbars (G), 1 strip (M)

Fig. 10

the following can be found inside the appliance drum: 4 additional feet (H), 4 screws (I), 4 screws (R), 4 nuts (L), 2 plinth guides (Q)

570

820 ÷ 900

Fig. 8

Adjusting the appliance height

The height of the appliance can be adjusted (from 820 mm to 835 mm), by turning the 4 feet. Should you require the appliance to be placed higher than the above height, you need to use the following accessories to raise it to up to 870 mm:

- the two crossbars (G)

- the 4 feet (H)

- the 4 screws (I)

- the 4 nuts (L) then perform the following

operations (fig. 11): remove the 4 original feet, place a crossbar G at the front of the appliance, fastening it in place using screws I (screwing them in where the original feet were) then insert the new feet H.

Repeat the same operation at the back of the appliance. Now adjust feet H to raise or lower the appliance from 835 mm to 870 mm. Once you have reached the desired height, lock nuts L onto crossbar G.

To adjust the appliance to a height between 870 mm and 900 mm, you need to mount strip M, adjusting feet H to the required height.

Insert the strip as follows: loosen the three screws N situated at the front of the Top cover of the appliance, insert strip M as shown in fig. 12, then fasten screws N.

Fig. 11

Fig. 12

Instructions for installation and use

Easy Care and Maintenance

T reat your machine well and it will provide many years of tr ouble free service

Your washing machine is a reliable companion in life and on the job. It is just as important for you to keep it in shape.

Your washing machine is designed to provide reliable service over many years. A few simple steps will help to prolong its life and avoid problems. It is advisable, to turn off water taps when the machine is not to be used, this protects the hoses, etc. If the water in your area is too hard, use a deliming product (water is hard if it often leaves whitish stains around taps or drains, especially of bath tubs. For more accurate information as to the type of water in your system, call the local water works or a local plumber). Pockets must always be emptied removing even pins, badges and any other hard object. The washing machine exterior should be cleaned with a rag dipped in lukewarm water and soap.

It is important to wash

the detergent dispenser

regularly.

T o prevent dried washing

powder from

accumulating, place the

dispenser under running

water for a few minutes.

Never exaggerate with doses.

Normal detergents already contain deliming agents. Only if the water is particularly hard, that is, rich in lime content, do we recommend the use of a specific product at every wash. A periodical wash cycle with a dose of a deliming product, without detergents or washing, may prove useful. Never use too much detergent or additives because this could cause an excess amount of foam, scaling and possible damage to the component parts of your washing machine.

Do not forget to empty all pockets: small objects can

cause damage to your washer.

When in need, check the pump and the rubber hose.

The washer comes equipped with a self-cleaning pump that does not require any cleaning or maintenance. The water inlet hose

Check the rubber hose at least once a year. If you see any cracks, replace it immediately. When you use your washing machine, water pressure is very strong and a cracked tube could easily split open.

Instructions for installation and use

Important for the safe use of your washing machine

Your safety and that of

Your washer has been built in compliance with the strictest international safety regulations. To protect you and all your family.

your family

Read these instructions and all the information in this manual carefully: the y are an important source, not only of numerous useful tips, but also of vital information on safety, use and maintenance.

1. the machine should not be

installed in an outdoor environment, not even

when a roof shelters the area, because it may be very dangerous to leave it exposed to rain and thunderstorms.

2. It must only be used by

adults and exclusively for

washing clothes following the instructions provided in this manual.

3. Should it have to be moved,

proceed with the help of two or three people and handle it with the utmost care. Never try to do this alone, because the appliance is

very heavy.

4. Before loading the washing

machine, make sure the drum is empty .

5. Never touch the washing

machine when barefoot or with wet or damp hands or feet.

6. Never use extensions or

multiple plugs, which are

particularly dangerous in humid environments. The power supply cable must never be bent or dangerously compressed.

I only want an authorised specialised technician with original Indesit spare parts!

7. Never open the detergent dispenser while the appliance is functioning; do not use hand wash detergent because the

abundance of foam could damage its internal parts.

8. Never pull on the supply

cable or the washing

machine to disconnect it from the wall socket: it is extremely dangerous.

9. While the appliance is functioning, do not touch the drain water as it could reach very high temperatures. The

appliance door, during wash cycles, tends to become hot; ensure that children do no touch it. Never force the washing machine door because

this could damage the safety lock which prevents accidental opening when the nachine is working. Allow a few minutes at the end of the program for the lock to release.

10. In case of malfunctioning, first close the water tap and unplug the appliance from the wall socket; do not

under any circumstances touch internal parts in order to attempt repairs.

How to change the power supply cable

The washing machine power supply cable is special and can be purchased exclusively from authorised Technical Service Centres.

To replace the cable:

1. Make sure that the machine is switched off and unplugged.

Fig. 13 Fig. 14 Fig. 15 Fig. 16

Instructions for installation and use

2. Remove the cover by unscrewing screws I [fig 13].

3. Disconnect the wires from the radio interference suppressor F [fig. 14] noting as to their position (Blue=N wire; Brown=L wire) leaving the earth wire until last . N.B.: letters L, N and the symbol are indicated on the

radio interference suppressor.

4. Remove the screw and washer V [fig. 15], which act as a stop for the cable passageway .

5. Remove the upper part of the cable slightly from the back panel of the appliance, pull the power supply cable upwards and take it out [fig. 16].

To connect the new power supply cable, reverse the procedure.

It is important for your safety that you reassemble all parts and screws used.

Sta y in touch

THANK YOU for choosing an Indesit appliance. W e are confident you have made a good choice and that your new appliance will give

many years of excellent service. And we're there when you need us.

This will confirm your entitlement to enter our quarterly prize draw where you have the possibility to recover the cost of your purchase. Simply complete and return the Registration Form supplied with the appliance documents, using the FREEPOST envelope supplied. Or call the Registration Hotline on 0870 010 4305.

W e're as close to you as your telephone

For direct access to Genuine Indesit Spare Parts and Accessories, call 0870 558 5850 and speak to our skilled staff who can help you to identify and purchase the item you require.

For a Rapid Response to a problem with your appliance, call 0870 607 0805. W e're open from Monday to Saturday (8am - 5.30pm weekdays, 9am - 5pm Saturday). W e have our own department of highly trained Indesit service staff. For most calls, our Service Engineer can fix the problem on the first visit.

Please have the following details to hand when you ring us: The nature of the problem, the Model Number and the Serial Number . These numbers can be found on the appliance and on the portion of the Registration Card which you retain.

Instructions for installation and use

Merloni Elettrodomestici

Viale Aristide Merloni 47

60044 Fabriano

Italy

Tel +39 0732 6611

Fax +39 0732 662501

www.merloni.com

Leader for young Europe

12/2001 - 195032734.00 - XEROX BUSINESS SERVICES - DOCUTECH

Indesit WM 12 X User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
