Indesit DV 62 User Manual

DV 62
Dishwasher
Installation and use
Safety Is a Good Habit to Get Into
NOTICE Carefully read the instructions contained in this manual, as they provide important information which is essential to safe and proper installation, use and maintenance of the appliance.
This appliance complies with the following EEC directives:
- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent modifications;
- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility) and subsequent modifications.
1.Carefully dispose of the packing material.
2.After removing the packing, check to make sure that the
appliance is not damaged. If in doubt, contact a qualified professional.
3.The dishwasher must only be used by adults for the washing of household dishes and cooking utensils.
4.Fundamental rules to follow when using the appliance:
- Never touch the dishwasher when barefoot or with wet hands or feet;
- We discourage the use of extension cords and multiple sockets;
- During installation, the power supply cord must not be excessively or dangerously bent or flattened;
- If the appliance is not operating properly or maintenance must be performed, disconnect the appliance from the power supply .
5.Keep detergents out of the reach of children, who must also be kept away from the dishwasher when it is open.
6.This appliance cannot be installed outdoors, not even if the area in which it is installed is covered by a roof; it is also very dangerous to leave it exposed to the rain and elements.
7.Do not touch the heating element during or after a wash cycle.
8.Do not lean or sit on the door when it is open, as this could overturn the dishwasher.
9.If the appliance malfunctions, turn off water supply to the appliance and disconnect the plug from the wall socket. Then, consult the section entitled, "T roubleshooting." If you cannot resolve the problem, contact a service centre.
10.Appliances which are no longer being used must be made inoperable by cutting the power supply cord and removing the door lock.
To maintain the EFFICIENCY and SAFETY of this appliance, we recommend:
l call only the Service Centers authorized
by the manufacturer
l always use original Spare Parts
Close-up View (control panel)
B
A
ON - OFF Button
ON - OFF Light
C
D
Handle For Opening Door
Knob For Selecting Cycles
1
GB
Close-up View (Interior)
J
E
G
F
H
I
L
K
Upper Rack
T op Sprayer Arm
Rack Height Adjustor
Lower Rack
Bottom Sprayer Arm
Salt Container Cap
Washing Filter
Detergent and Rinse Aid Dispenser
Technical characteristics
Width cm. 59,5 Depth cm. 57 Height cm. 82 Capacity 12 standard place settings Mains water pressure 20 KPa÷ 1MPa (0,2 ÷10 bar)
Power voltage See data plate
Total absorber power See data plate Fuse See data plate
GB
2
Salt, Detergent and Rinse Aid
Salt
The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will form on the dishes and utensils. The appliance is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the water.
Loading the Salt into the Softener
Always use salt intended for use with dishwashers. The salt container is located beneath the lower rack and should be filled as follows:
1. Remove the lower rack and then unscrew and remove the cap from the salt container;
2. If you are filling the container for the first time, fill it with water;
3. Place the end of the funnel (supplied) into the hole and introduce about 2 kg of salt. It is normal for a small amount of water to come out of the salt container .
4. Carefully screw the cap back on.
The salt container should be filled after about every 30 wash cycles.
Warning: To prevent rust from forming , we advise you to load the salt before beginning a wash cycle.
Detergent
Detergent specifically intended for use with dishwashers must be used. The dispenser must be refilled before the start of each wash cycle following the instructions provided in the "Wash Cycle Table." The detergent dispenser is located on the inside panel of the door.
After pouring in the detergent, replace the lid, pressing down until it clicks.
Dishwasher detergent in tablets is now available on the market, in which case you should place one tablet into container "D" and close the lid. If you use powder or liquid detergent, you can also fit the 2 plugs provided in the two special housings in lid "A", before closing the latter . This way , your dishes will come out cleaner .
Notice: To facilitate closing the cover, remove any excess detergent on the edges of the dispenser .
Rinse Aid
This product makes dishes sparkle and helps them to dry without spotting. The dispenser is located on the inside panel of the door and should be filled after every 80 wash cycles (or when the rinse aid indicator light comes on for those models with this feature).
Loading the Rinse Aid
T o open the dispenser , turn the "C" cap in the anti-clockwise direction and then pour in the rinse aid, making sure not to overfill. The amount of rinse aid used for each cycle can be regulated by turning the "F" dose adjustor , located beneath the "C" cap, with a screwdriver. There are 6 different settings; the normal dosage setting is 4.
Important:
Proper dosage of the rinse aid improves drying. If drops of water remain on the dishes or spotting occurs, the dosage adjustor should be turned to a higher setting. If the dishes have white streaks, turn the dosage adjustor to a lower setting.
Loading the detergent
To open lid "A", press button "B". The cleaning detergent should be introduced into the two containers "C"and "D" up to the rim, as indicated in the wash cycle table.
A
D
22
gr.
8
C
gr.
B
F
C
3
GB
