USERÕS MANUAL
QUESTIONS?
As a manufacturer, we are committed to providing complete
customer satisfaction. If you
have questions, or find that there
are missing or damaged parts,
we will guarantee complete satisfaction through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained technicians on our customer hot line
will provide immediate assistance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
Model No. IMHS80081
Serial No.
Write the serial number in the space
above for reference.
CAUTION
Read all precautions and instructions in this manual before using
this equipment. Save this manual
for future reference.
Serial Number Decal
¨
TABLE OF CONTENTS
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CHOOSING A LOCATION FOR THE HYDROTHERAPY SPA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
USING THE HYDROTHERAPY SPA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
TROUBLE-SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
Note: A PART LIST and an EXPLODED DRAWING are attached to the center of this manual. Remove the PART
LIST and EXPLODED DRAWING before beginning assembly.
2
IMAGE¨is a registered trademark of ICON Health & Fitness, Inc.
LIMITED WARRANTY
ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and
material, under normal use and service conditions, for a period of ninety (90) days from the date of purchase. This warranty extends only to the original purchaser. ICON's obligation under this warranty is limited to replacing or repairing, at ICON's option, the product at one of its authorized service centers. All
products for which warranty claim is made must be received by ICON at one of its authorized service centers with all freight and other transportation charges prepaid, accompanied by sufficient proof of purchase.
All returns must be pre-authorized by ICON. This warranty does not extend to any product or damage to
a product caused by or attributable to freight damage, abuse, misuse, improper or abnormal usage or
repairs not provided by an ICON authorized service center, products used for commercial or rental purposes, or products used as store display models. No other warranty beyond that specifically set forth
above is authorized by ICON.
ICON is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or damages with respect to any economic loss, loss
of property, loss of revenues or profits, loss of enjoyment or use, costs of removal, installation or other
consequential damages of whatsoever nature. Some states do not allow the exclusion or limitation of incidental or consequential damages. Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of
merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth
herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly, the above
limitation may not apply to you.
This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
ICON HEALTH & FITNESS, INC., 1500 S. 1000 W., LOGAN, UT 84321-9813
3
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the following
important precautions before using the hydrotherapy spa.
READ AND FOLLOW ALL INSTRUCTIONS
1. It is the responsibility of the owner to ensure
that all users of the hydrotherapy spa are
adequately informed of all precautions.
2. Use the hydrotherapy spa only as described
in this manual.
3. The hydrotherapy spa is intended for home
use only. Do not use the spa in any commercial, rental, or institutional setting.
4. Use the hydrotherapy spa only on a level
surface. Do not use the spa on carpet or
other materials that could be damaged by
moisture. Do not use the spa on rough or
sharp surfaces such as gravel or wood
chips.
5. The hydrotherapy spa will weigh approximately 2400 pounds when it is assembled
and filled with water. Be sure that the location you select for the spa will support this
weight, plus the weight of the occupants.
6. Inspect and tighten all parts regularly.
Replace any worn parts immediately.
7. DANGERÑRisk of injury: Do not remove or
alter the covers on the suction fittings. Never
operate the hydrotherapy spa if the suction
guard is missing or broken. Keep hair and
body away from the suction guard. If you
need to replace a suction fitting, be sure that
the flow rate of the replacement is compatible.
8. Do not bring any object into the hydrotherapy spa that could puncture the liner.
9. Never insert any object into any opening.
10. Do not sit on the spa cover or place objects
on it. It is not designed to support weight.
11. Remove any water which may collect on the
spa cover.
12. Keep children and pets away from the
hydrotherapy spa when it is not in use.
13. Keep all chemicals away from children and
pets.
14. The pH and chemical balance of the water
must be maintained as explained in this manual (see page 13). Failure to do so may cause
injury to users or damage to the spa jet unit,
and will void the warranty.
15. The water pump in the spa jet unit must be
primed before you use the hydrotherapy spa
the first time. You must also prime the pump
before using the unit each time you re-fill the
spa. The spa jet unit may be seriously damaged if the pump is not properly primed (see
PRIMING THE SPA JET UNIT on page 10).
16. DANGERÑWhen connecting the power cord
(see PLUGGING IN THE HYDROTHERAPY
SPA on page 10), plug the power cord directly into a grounded circuit capable of carrying
15 or more amps. No other appliance should
be on the same circuit. Replace the power
cord immediately if damaged.
17. Do not use an extension cord with the
hydrotherapy spa. This could damage the
motor and will void the warranty.
18. DANGERÑIf you will be using the hydrotherapy spa outside, do not bury the power cord;
you should also keep the power cord away
from lawn mowers, hedge trimmers, and
other similar equipment.
19. WARNINGÑThe power cord is equipped with
a Ground Fault Circuit Interrupter (GFCI),
located at the end of the power cord. The
GFCI must be tested before each use. To test
the GFCI, press the ÒtestÓ button while the
spa jet unit is running. The spa jet unit
should shut off. Press the ÒresetÓ button.
The spa jet unit should resume normal operation. If the spa jet unit continues to run after
the ÒtestÓ button is pressed, then the GFCI is
damaged. Do not use the hydrotherapy spa
until the GFCI has been repaired or replaced
by a qualified electrician.
20. Keep all electrical appliances such as radios,
telephones, televisions, and lights at least
five feet (1.52 meters) away from the water.
21. A wire connector is provided on the pump
4
motor of this unit to connect a minimum No.
8 AWG (804 mm2) solid copper conductor
between this unit and any metal equipment,
electrical enclosure made of metal, metal
water pipes, or conduit within five feet
(1.52m) of the unit.
22. DANGERÑRisk of electric shock: Do not set
up the hydrotherapy spa within five feet of
any metal objects or surfaces. As an alternative, you may use the spa within five feet of
metal objects if each metal object is permanently connected to the wire connector on
the pump motor of this unit by a minimum
No. 8 AWG (804 mm2) solid copper conductor
(see instruction 21).
23. DANGERÑRisk of drowning: Exercise
extreme caution to prevent unauthorized and
unsupervised use of the hydrotherapy spa by
children. Children must always be supervised.
24. DANGERÑTo reduce the risk of drowning:
¥ Never use the spa alone;
¥ Children should not use the spa unless
they are supervised by an adult;
¥ Keep pets away from the spa at all times;
¥ Always replace and lock the spa cover
when the spa is not in use.
25. WARNINGÑTo reduce the risk of injury: The
water temperature should never exceed
104¡F (40¡C). Temperatures between 100¡F
(38¡C) and 104¡F (40¡C) are considered to be
safe for healthy adults. However, if you plan
to remain in the hydrotherapy spa for more
than 10 to 15 minutes, a lower temperature is
recommended. Lower temperatures are also
recommended for children.
26. WARNINGÑTo reduce the risk of injury:
Always use an accurate thermometer to
determine the water temperature before
using the hydrotherapy spa.
27. WARNINGÑTo reduce the risk of injury:
Pregnant women should consult with their
physician before using the hydrotherapy spa.
Pregnant women should not use the spa if
the water temperature is above 100¡F (38¡C);
the unborn child could be seriously harmed.
28. DANGERÑTo reduce the risk of drowning:
Prolonged immersion in the hydrotherapy
spa may cause hyperthermia, a dangerous
condition which occurs when the internal
body temperature rises several degrees
above the normal body temperature of 98.6¡F.
The symptoms of hyperthermia are nausea,
dizziness, drowsiness, and fainting. Effects
include: a lack of awareness, inability to perceive heat or danger, and a greater risk of
drowning due to a loss of consciousness.
Special note: Individuals suffering from
hyperthermia may be unable to realize that
they must exit the spa, and they also may be
physically unable to do so.
29. WARNINGÑTo reduce the risk of drowning:
Heat from the water, in conjunction with alcohol or drugs can cause unconsciousness. Do
not use the hydrotherapy spa if you are
under the influence of drugs or alcohol.
30. WARNINGÑTo reduce the risk of injury or
drowning: Consult your physician about possible side-effects of any medications you may
be taking before using the hydrotherapy spa.
Heat from the water, in conjunction with some
medications may cause drowsiness and
increase the risk of drowning. Others can
effect blood pressure, heart rate, and circulation.
31. WARNINGÑTo reduce the risk of injury: It is
especially important for persons over the age
of 35 or persons with pre-existing health
problems, such as obesity, heart disease,
high or low blood pressure, circulatory problems, or diabetes to consult your physician
before using this product.
32. If you feel pain or dizziness at any time while
using the hydrotherapy spa, discontinue use
and contact a physician.
33. WARNINGÑThe spa jets produce a stream of
water with relatively high pressure.
Prolonged exposure of a localized area of the
body may cause bruises to the skin.
WARNING: Read all instructions before using the hydrotherapy spa. ICON assumes no responsibility
for personal injury or property damage sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS
5
WARNING LABEL IDENTIFICATION
The warning labels shown below have been placed on the spa cover, printed inside the inflatable spa
liner, and placed on the side of the spa jet unit of the hydrotherapy spa. Locate the labels and familiarize
yourself with this information. The label on the side of the spa jet unit is an adhesive decal. If this decal
is missing, or if it is not legible, please call our Customer Service Department toll-free at 1-800-999-3756,
Monday through Friday, 6 a.m. until 6 p.m. Mountain Time, to order a replacement decal. Apply the decal
in the location shown.
6
BEFORE YOU BEGIN
Thank you for selecting the IMAGE¨RENEW 800. The
innovative RENEW 800 offers the features and quality
of a traditional hot tub at an affordable price. Best of
all, the RENEW 800 is fully portable, so you can take
it wherever there is an electrical outlet. The RENEW
800 allows you to relax and unwind in the comfort of
your own home.
For your benefit, read this manual carefully before
using the IMAGE¨RENEW 800. If you have addition-
al questions, please call our Customer Service
Department toll-free at 1-800-999-3756, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time
(excluding holidays). To help us assist you, please
note the product model number and serial number
before calling. The model number is IMHS80081. The
serial number can be found on a decal attached to spa
jet unit (see the front cover of this manual).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Spa Jet Unit
Inflation ValveLocking Buckle
Console (Under
Spa Cover)
Spa Cover
Power Cord
Ground Fault Circuit
Interrupter (GFCI)
7
CHOOSING A LOCATION FOR THE HYDROTHERAPY SPA
There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary
depending on whether you use the hydrotherapy spa inside or outside. We have listed several factors you may
wish to consider as you decide where you want to use the hydrotherapy spa.
If you set up the hydrotherapy spa inside:
1. The hydrotherapy spa will increase the level of
humidity in your home. The location you choose
should be well ventilated. You may need to install
a ventilation fan or use a dehumidifier.
2. The location must be close to an electrical outlet.
Do not use an extension cord with the
hydrotherapy spa.
3. The hydrotherapy spa should be close to a source
of water.
4. Do not use the hydrotherapy spa on carpet or
other material that may be damaged by moisture.
We recommend that you place the hydrotherapy
spa on a water- and stain-resistant, non-slip surface with a floor drain for any water that may
splash from the hydrotherapy spa.
5. Be sure that the location you choose is stable. It
must be able to support the weight of the
hydrotherapy spa when it is filled with water, plus
the weight of the occupants. The hydrotherapy
spa weighs approximately 2400 pounds when
filled with water.
6. Do not use the hydrotherapy spa above a finished
living area, due to the risk of water damage.
7. Be sure that there is room around the hydrotherapy spa to permit servicing of the unit. The diameter of the tub is 69Ó. You should allow for this size,
plus the size of the spa jet unit, when choosing
the location.
8. Be sure to note any other considerations, such as
aesthetics or privacy concerns, that may affect the
safety or enjoyment of using the hydrotherapy
spa.
If you set up the hydrotherapy spa outside:
1. You should check your local building codes concerning the use of outdoor spas.
2. The location must be close to an electrical outlet.
Do not use an extension cord with the
hydrotherapy spa.
3. The hydrotherapy spa should be close to a source
of water.
4. We recommend that you place the hydrotherapy
spa on a water- and stain-resistant, non-slip surface.
5. Be sure that the location you choose is stable. It
must be able to support the weight of the
hydrotherapy spa when it is filled with water, plus
the weight of the occupants. The hydrotherapy
spa weighs approximately 2400 pounds when
filled with water.
6. Think about environmental factors, such as rain,
wind, shade, sunlight, and so forth.
7. You should be able to monitor the use of the
hydrotherapy spa from your home, to prevent
unauthorized use by children.
8. Be sure that there is room around the hydrotherapy spa to permit servicing of the unit. The diameter of the tub is 69Ó. You should allow for this size,
plus the size of the spa jet unit, when choosing
the location.
9. Be sure to note any other considerations, such as
aesthetics or privacy concerns, which may affect
the safety or enjoyment of using the hydrotherapy
spa.
8
1. Before beginning assembly, be sure that you
have read and understand the information in the
box above and on the previous page.
Unfold the pre-assembled Fabric Spa Surround (8)
and Side Panels (1, 2) until the assembled unit is
round.
Check the self-attaching connections between the
Fabric Spa Surround (8) and Side Panels (1, 2) to
be sure that all connections are firm. Be sure that all
six cover buckles are fully inserted through the slots
in the Side Panels (1, 2).
2. Unfold the Inflatable Spa Liner (9).
Attach the nozzle on the included air pump to the
valve on the side of the Inflatable Spa Liner (9). Use
the air pump to fill the sides of the Inflatable Spa
Liner with air.
Attach the nozzle on the air pump to the valve on
the floor of the Inflatable Spa Liner (9). Use the air
pump to fill the bottom of the Inflatable Spa Liner
with air.
Attach the nozzle on the air pump to the valve on
top of the Inflatable Spa Liner (9). Use the air pump
to fill the cushion on the top of the Inflatable Spa
Liner with air.
3. Be sure that the flap on the Fabric Spa Surround (8)
is on the outside of the Fabric Spa Surround and
Side Panels (1, 2). Insert the Inflatable Spa Liner (9)
into the Fabric Spa Surround. Align the valve in the
Inflatable Spa Liner with the hole in the Fabric Spa
Surround and the Inflation Side Panel (2).
Flip the flap on the Fabric Spa Surround (8) over the
low section of the Inflatable Spa Liner (9).
3
1
9
1, 2
8ÑFlap
Valve must
be visible in
this hole
8
Buckle
Slot
1, 2
2
ASSEMBLY
Before beginning assembly, carefully read the
following information and instructions:
¥ Place all parts in a cleared area and remove the
packing materials; do not dispose of the packing
materials until assembly is completed.
¥ Assembly requires two people.
¥ Assembly requires the included air pump.
¥ Read each assembly step before you begin.
¥ During assembly, make sure that all parts are ori-
ented as shown in the drawings.
9
Inflate here
first
Inflate here
third
Inflate here
second
9
4. Remove the power cord from the Spa Jet Unit (13).
With the help of a second person, place the Spa Jet
Unit (13) over the Side Panel (1) and the section of
the Inflatable Spa Liner (9) which does not have the
cushion. Be extremely careful not to tear the
Inflatable Spa Liner (9) as you slide the Spa Jet
Unit into place.
5. Before you fill the hydrotherapy spa, be sure that it
is in the position you want, and that it can be easily
serviced, if needed. Once the hydrotherapy spa is
filled with water, it will need to be drained to be
moved.
Using a garden hose or other clean water source,
begin filling the hydrotherapy spa, until the jet and
filter openings on the Spa Jet Unit (13) are covered
with water. Do not fill the RENEW 800 more than
20Ó deep with water.
After the RENEW 800 is full, you must prime the
Spa Jet Unit (13) before using the hydrotherapy
spa (see PRIMING THE SPA JET UNIT on page
10).
6. Insert the Support Ball (4) into the mesh pocket on
the underside of the Spa Cover (11).
See inset drawing A. Insert the inflation tube into
the hole in the Support Ball (4). Inflate the Support
Ball.
See inset drawing B. When the Support Ball (4) is
inflated, remove the inflation tube from the Support
Ball and insert the ball plug through the mesh into
the Support Ball. The head of the ball plug will
hold the Support Ball in place.
Note: The Support Ball (4) is not a toy.
4
5
1
9
13
13
9
Power
Cord
BA
11
Mesh Pocket
4
4
Inflation
Tube
Ball
Plug
4
6
10
USING THE HYDROTHERAPY SPA
The hydrotherapy spa is designed for up to four
adults. The six water jets can be regulated to provide
a relaxing massage to sooth away stress, and the
strength of the water massage can be adjusted by the
air control. The hydrotherapy spa holds 300 gallons of
water and offers an automatic, programmable heating
(70¡F to 104¡F) and filtration system.
The guidelines below explain how to properly use the
hydrotherapy spa. Follow these guidelines to maintain
the spa for your long-term enjoyment.
PRIMING THE SPA JET UNIT
The water pump in the spa jet unit must be primed
before you use the hydrotherapy spa the first time.
You must also prime the pump before using the unit
each time you re-fill the hydrotherapy spa.
To prime the spa jet
unit, remove the
primer cap from the
console. Fill the spa
jet unit with at least 64
oz. of water. Replace
and tighten the
primer cap. IMPORTANT: The spa jet
unit may be seriously damaged if the pump is not
properly primed, or if the primer cap is not
replaced and fully tightened.
PLUGGING IN THE HYDROTHERAPY SPA
Once the hydrotherapy spa is filled with enough water
to cover the water jets and the pump has been
primed, the power cord can be plugged in and the spa
jet unit can be turned on. Note: The first time the
power cord is plugged in, the spa jet unit will turn on
automatically.
When connecting the power cord, plug the power cord
directly into a grounded circuit capable of carrying 15
or more amps. No other appliance should be on the
same circuit. Replace the power cord immediately if it
becomes damaged.
The power cord is equipped with a Ground Fault
Circuit Interrupter (GFCI), located at the end of the
power cord. You should always test the GFCI before
using the hydrotherapy spa.
First, turn on the hydrotherapy spa by pressing the
power button on the console. Once the unit is running, press the GFCI ÒtestÓ button. The hydrotherapy
spa should shut off. Press the ÒresetÓ button. The
hydrotherapy spa should resume normal operation. If
the hydrotherapy spa continues to run after the ÒtestÓ
button is pressed, then the GFCI is damaged. Do not
use the hydrotherapy spa until the GFCI has been
repaired or replaced by a qualified electrician.
Test and Reset
Buttons
Grounded circuit capable of
carrying 15 or more amps
GFCI
Primer
Cap
7
1, 2
11
13
Latches and Buckles
7. Place the Spa Cover (11) over the Side Panels (1,
2) and the Spa Jet Unit (13). Be sure that the Spa
Cover is properly centered and that the straps
on the Spa Cover line up with the straps extending from the slots in the Side Panels (1, 2).
Snap each of the six latches on the Spa Cover (11)
into the buckles on the straps extending from the
slots in the Side Panels (1, 2).
11
STARTING THE HYDROTHERAPY SPA
Once you have tested the GFCI, you should verify the
water flow from the pumping unit. Set the air control
on the console to the lowest setting (see USING THE
CONSOLE on the next page). The pumping unit will
heat the water as it pumps. Cover the hydrotherapy
spa with the spa cover. The spa cover must be
tight. The water will heat at about 1.7¡F an hour with
the cover on. If you are using the hydrotherapy spa
indoors, and the room temperature is maintained at
70¡F, it will take approximately 20 to 28 hours for the
water to reach the set temperature.
The temperature and water flow can be set or
changed by the controls on the console (see USING
THE CONSOLE on the next page).
TESTING AND TREATING THE WATER
The hydrotherapy spa comes with a starter chemical
pack for maintaining the water in the spa. Disregard
the directions on the individual packages of ÒQUICK
pHix It DOWNÓ and ÒQUICK pHix It UP.Ó However, the
directions on the bottle of ÒNon-chlorine ShoxÓ and
ÒBromine BaseÓ are correct. Always keep the chemi-
cals away from children and pets.
The first time you use the spa, you should test and
treat the water. Once you have verified that the spa
jet unit is functioning properly, and have allowed the
water to circulate for a while, you should remove the
spa cover and add 1/3 of the ÒBromine BaseÓ bottle,
and 1/3 of the ÒNon-chlorine ShoxÓ bottle to the water
in the spa. Allow the water to circulate for five minutes. You should now test the pH level of the water.
Use the included test strips to check the pH of the
water. Refer to the instructions on the test strip packaging to see how to use the test strips.
If the level is too low, add half of one of the ÒQUICK
pHix It UPÓ packets to the water. Let the water circulate through the spa jet unit for five minutes. Test the
pH level again. Repeat until the pH level is correct.
If the level is too high, add half of one of the ÒQUICK
pHix It DOWNÓ packets to the water. Let the water circulate through the spa jet unit for five minutes. Test
the pH level again. Repeat until the pH level is correct.
Replace the spa cover and allow the water to continue to heat.
See WATER CHEMISTRY on page 13 for information
concerning proper water maintenance.
SECURING THE SPA COVER
The spa cover can be
secured by snapping
the latches on the spa
cover into the buckles
on the side panels.
The buckles can be
locked by inserting the
key and turning it clockwise a quarter turn. To
unlock the buckles, insert the key and turn it counterclockwise a quarter turn.
Always keep the buckles locked when the spa is
not in use. Keep the keys in a safe place, out of
the reach of children.
Key
Latch
Buckle
12
SPA JET UNIT OPERATION
The spa jet unit features three hydro-therapy jets, a
whirlpool jet, a suction vent, and a filter housing.
The three hydro-therapy jets (A), located on the
front of the spa jet unit, focus the water massage on
your neck and back.
The whirlpool jet (B), located on the left side of the
spa jet unit, directs the flow of the water to create a
whirlpool action in the hydrotherapy spa.
The suction vent (C),
located on the right
side of the spa jet unit,
pulls the water into the
spa unit, in order to
operate the system.
The suction cover
should always be in
place over the suction
vent. Never operate
the spa without the
suction cover in
place.
The filter (D), is located on the left side of
the spa jet unit, behind
the filter cover. The filter can be removed for
cleaning and replace-
A
B
D
C
C
USING THE CONSOLE
Refer to the console diagram above. The function of
each console control is explained below:
Primer: This opening allows you to prime the spa jet
unit before operation (see PRIMING THE SPA JET
UNIT on page 10).
Air Control: Determines the amount of air that is in
the spa jet system during operation. If the control is
turned to the left, the amount of air flowing through
the jets will increase. If the control is turned to the
right, the amount will decrease.
Thermostat: Controls the temperature of the water.
The water heats at about 1.7¡F an hour with the cover
on. The thermostat can be set to heat the water from
70¡F to 104¡F. Use a medical or other accurate thermometer to check the temperature of the water.
On/Off: Turns the spa jet unit on and off. When you
first press the on/off button, the spa jet unit will run at
low speed, providing gentle hydrotherapy. Press the
button again and the jet unit will run at high speed,
providing more intense hydrotherapy. Press the button
a third time and the spa jet unit will shut off.
The spa jet unit also features an automatic mode,
which heats and filters the water when the spa is left
unattended. When the spa jet unit is first plugged in,
or if the buttons on the console have not been used
for longer than twenty minutes, the automatic mode
will begin filtering or heating the water, as needed.
Note: to keep the filter and heat cycles from running, the power cord must be unplugged.
DIAGRAM OF THE CONSOLE
Filter Cover
Screws
Filter Cover
D
13
CLEANING THE INFLATABLE SPA LINER
The liner should be cleaned with a mild soap solution.
Do not use solvents. The liner should always be clean
and dry before being moved or stored.
CHECKING AND CLEANING THE FILTER
The filter should be checked periodically for build-up
of dirt and oil. If the filter needs to be cleaned, follow
the steps below:
1. Turn off the power.
2. Remove the two screws and cover from the
spa jet. Then pull the filter out of the unit.
3. Check the filter for any dirt or debris. If the filter needs to be cleaned, rinse the filter with a
hose. If the filter still is dirty, you will need to
soak it in a cleaning solution which can be
obtained from a pool and spa supply store.
4. Inspect the filter for damage. Replace the filter if there are any signs of damage.
5. Re-insert the cleaned filter and re-attach the
two screws and cover to the spa jet unit.
MAINTAINING THE SPA COVER
The spa cover should be cleaned monthly. Remove
the support ball from the spa cover, then hang the spa
cover over a clothes line and spray it with a hose.
Leave the cover on the clothes line until it is fully dry.
WINTER USE AND CARE
The hydrotherapy spa is designed for year-round use.
If you decide to store the spa for the winter, store it in
a warm, dry location. (See DRAINING THE
HYDROTHERAPY SPA and DRAINING THE PUMP
on this page.)
WATER CHEMISTRY
The hydrotherapy spa comes with a starter chemical
pack for maintaining the water in the spa. (See TESTING AND TREATING THE WATER on page 11.)
Additional chemicals can be purchased at a pool and
spa supply store.
CAUTION: The chemicals used to maintain the pH
balance of the water and to sanitize the water can
be dangerous. Always follow these basic guide-
MAINTENANCE
ment by removing the filter cover and the two filter
cover screws and then pulling the filter from the spa jet
unit.
The spa jet unit features an automatic filter cycle and
freeze protection. If the spa jet unit has not been operated for three hours, the pump will begin circulating
the water for twenty minutes to filter any impurities.
Also, if the water temperature falls below 40¡F, the
pump will begin circulating and heating the water to
prevent the water from freezing.
DRAINING THE HYDROTHERAPY SPA
To drain the hydrotherapy spa, you must use a garden
hose to siphon the water. Place one end of the hose in
the spa and hold it in front of a hydrotherapy jet until
there is a flow of water coming out of the hose. Turn
off the spa unit and unplug the power cord. The
unit will be damaged if it is run without water circulating. Be sure the end of the hose in the spa is on
the floor of the spa.
DRAINING THE PUMP
After the hydrotherapy spa is drained (see DRAINING
THE HYDROTHERAPY SPA above), the pump in the
spa jet unit should also be drained if the spa will be
stored for more than thirty days, or if it may be
exposed to freezing temperatures.
To drain the pump,
remove the spa jet unit
from the side panels.
Be careful not to tear
the inflatable spa
liner. Locate the pump
inside the spa jet unit.
Remove the drain plug
from the pump. Tip the
spa jet unit slightly,
until all the water has drained from the pump. Replace
the drain plug.
Drain Plug
Pump
14
1. SYMPTOM: THE SPA WILL NOT OPERATE
a. Check the power cord. The power cord must
be plugged into a grounded outlet (see PLUGGING IN THE HYDROTHERAPY SPA on page
10).
b. Check to see if the GFCI breaker is tripped, or
was not turned on. Reset the GFCI breaker.
2. SYMPTOM: THE CIRCUIT BREAKER OR GFCI
BREAKER TRIPS WHILE THE SPA IS
OPERATING
a. Reset the circuit breaker. If the circuit breaker
trips again, contact a qualified electrician for
service.
3. SYMPTOM: THE PUMP HUMS
a. The filter may be dirty or damaged. Remove
the filter housing from the spa jet unit and clean
or replace the filter.
b. The pump may have a foreign object stuck in
the impeller. Contact our customer service
department.
c. The pump may have a loose wire connection.
Contact our customer service department.
4. SYMPTOM: THE PUMP HUMS BUT DOES NOT
ROTATE
a. The pump may be jammed. Contact our cus-
tomer service department.
5. SYMPTOM: THE PUMP IS NOISY WHILE
OPERATING
a. There may be debris in the pump. Contact our
customer service department.
TROUBLE-SHOOTING
Most problems can be solved by following the simple steps below. Find the symptom that applies, and
follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at
1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time.
lines when handling the chemicals:
1. Always read and follow the directions on
the label, unless directed otherwise.
2. Never mix different chemicals.
3. Keep all chemicals out of the reach of children and pets.
4. Do not exceed the recommended
amountsÑfollow the directions on the label
closely.
5. Keep all containers closed tightly when not
in use.
6. Never add water to the chemicalsÑalways
add the chemicals to the water as directed.
7. Always store chemicals in a cool, dry place.
MAINTAINING THE PROPER PH BALANCE
The pH factor is a measure of relative acidity or alkalinity in the water. It is measured on a scale of 1 to 14.
Pure water has a value of 7, which is neutral. Any
value above 7 is alkaline, and any value below 7 is
acidic. You should maintain a slightly alkaline pH level,
between 7.2 and 7.8, in the hydrotherapy spa.
Severe problems can occur when the pH balance is
not maintained within this range. If the pH level
exceeds 7.8, dissolved minerals can build-up and clog
the plumbing in the spa jet unit. If the pH level falls
below 7.2, the acid level in the water will begin to corrode the metal parts in the spa jet unit. Also, the sani-
tation agents in the water will not be effective if the pH
level is not properly maintained. Damage caused by
improper pH levels is not covered under the warranty.
To maintain the proper pH level, you should test the
pH of the water regularly. To test the water you can
either purchase additional test strips or purchase a pH
test kit at a pool and spa supply store. The pH reading
should be between 7.2 and 7.8. If the level is too low,
add a pH increaser (usually soda ash). If the level is
too high, add a pH reducer (usually sodium bisulfate).
Test the water again after five minutes. See the
instructions with your test strips or pH test kit for additional information about testing and adjusting the pH.
SANITIZING THE HYDROTHERAPY SPA
Please refer to your local pool and spa supplier for
information concerning which chemicals you should
use in your area to sanitize the spa.
The most common sanitizing agent is a solid bromine
concentrate. The amount required varies according to
several factors, such as user load, temperature, water
conditions, and so forth.
Proper water maintenance is a fairly complex process.
We recommend that you contact your local pool and
spa supplier for information on how you should best
accomplish this.
15
b. The pump may have a bad bearing. Contact
our customer service department.
6. SYMPTOM: THE WATER DOES NOT HEAT
a. The heater is attached to the pump in the spa
jet unit. If the pump is operating, the water
should heat. Cover the hydrotherapy spa with
the spa cover. The spa cover must be tight.
Set the air control to low. The water will heat at
a rate of 1.7¡F an hour. If you are using the spa
indoors, and the room temperature is maintained at 70¡F, it will take approximately 20 to
28 hours for the water to reach the set temperature.
b. If you are using the hydrotherapy spa outdoors,
it may take longer for the water to heat. See
the chart below for the approximate heating
time.
Air Temperature Heating Time
70¡F
+
20 to 28 hours
50¡FÐ70¡F 1 to 2 days
30¡FÐ50¡F 2 to 3 days
b. If the water still has not heated after three
days, contact our customer service department.
7. SYMPTOM: THE WATER IS NOT BEING
CLEANED BY THE FILTER
a. Check to see if the filter is in place. Clean the
filter if it is dirty.
b. Check the chemical balance of the water. If the
pH is incorrect, the sanitizing agents will not
function properly.
8. SYMPTOM: THE WATER PULSATES OR
THERE IS MINIMUM WATER FLOW
a. Adjust the water level. This usually occurs only
when the water level is low. Add water until the
filter and jets are covered.
b. This problem is caused by excess air in the
pump circulation system. Check to see if the
primer cap is fully tightened. Prime the pump
again and fully tighten the primer cap (see
PRIMING THE SPA JET UNIT on page 10).
9. SYMPTOM: THE SPA JET UNIT CAVITATES
DURING USE
a. Adjust the water level. This usually occurs only
when the water level is low. Add water until the
filter and jets are covered.
b. This problem is caused by excess air in the
pump circulation system. Check to see if the
primer cap is fully tightened. Prime the pump
again and fully tighten the primer cap (see
PRIMING THE SPA JET UNIT on page 10).
10. SYMPTOM: THE SPA JET UNIT CONTINUES
TO RUN AFTER IT HAS BEEN SHUT OFF
a. When you press the on/off button once, the spa
jet unit will run at low speed, heating the water.
Press the button again and the spa jet unit will
run at high speed, filtering the water. Press the
button a third time and the spa jet unit will shut
off. The spa jet unit also features an automatic
mode, which heats and filters the water when
the spa is left unattended. When the spa jet
unit is first plugged in, or if the buttons on the
console have not been used for longer than
twenty minutes, the automatic mode will begin
filtering or heating the water, as needed. To
keep the filter and heat cycles from running,
the power cord must be unplugged. Special
Note: If the unit is to be kept outdoors in
cold weather, you must allow the spa to
maintain a safe temperature by running in
automatic mode. Allowing the spa jet unit to
freeze will damage the unit. If you do not
want to use the spa during the winter, store
it in a warm, dry location (see WINTER USE
AND CARE on page 13).
11. SYMPTOM: THE WATER LEVEL DROPS
a. Some water loss due to evaporation is normal.
If rapid water loss occurs, or if you notice wetness on the floor around the hydrotherapy spa,
then the liner may have a leak. Locate the leak,
and patch it using a pool patch kit that you can
purchase at any pool and spa supply store.
b. A clamp or seal inside the spa jet may be
loose. Check the floor around the spa jet unit
for excess water, and watch the spa jet unit
while it is operating to see if water drips from
the spa jet unit housing. If you can identify the
location of the leak inside the spa jet unit, tighten the clamp or replace the damaged seal.
12. SYMPTOM: THE INFLATABLE SPA LINER
LOSES AIR
a. Over time, some air loss is normal. If rapid air
loss occurs, then the liner may have an air
leak. Locate the leak, and patch it using a pool
patch kit that you can purchase at any pool and
spa supply store.
Part No. 154414 J00437AC R0499A Printed in USA © 1999 ICON Health & Fitness, Inc.
ORDERING REPLACEMENT PARTS
To order replacement parts, simply call our Customer Service Department toll-free at 1-800-999-3756, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling:
1. The MODEL NUMBER of the product (IMHS80081).
2. The NAME of the product (IMAGE¨RENEW 800).
3. The SERIAL NUMBER of the product (see the front cover of this manual).
4. The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST/EXPLODED DRAWING attached to
the center of this manual).
PART LISTÑModel No. IMHS80081 R0399A
Note: Ò#Ó indicates a non-illustrated part. Specifications are subject to change without notice.
Key No. Qty. Description
1 1 Side Panel
2 1 Rubber Grommet
3 1 Dual Temperature Probe
4 1 Support Ball
5 4 #8 x 5/8Ó Screw
6 2 Removable Collar
7 4 1/4Ó x 1 1/2Ó Bolt
8 1 Fabric Spa Surround
9 1 Inflatable Spa Liner
10 4 Fixed Jet
11 1 Spa Cover
12 1 Lower Heater Gasket
13 1 Spa Jet Unit
14 1 Heater
15 2 #4 x 3/8Ó Screw
16 1 Filter
17 1 #10 x 1 1/4Ó Screw
18 1 Suction Cover
19 1 Suction Guard
20 1 Pump Motor
21 1 Heater Terminal Cover
22 1 Heat Controller
23 1 Heater Wire Harness
24 5 #10 Keep Nut
25 1 Electronic Control
26 1 Primer Housing
27 1 Headrest w/Fasteners
28 4 1/4Ó Nut
29 1 Heat Control Nut
30 4 5/16Ó Rubber Washer
31 4 5/16Ó Washer
32 1 On/Off Switch Bracket
Key No. Qty. Description
33 1 Rubber Damper
34 1 Wire Harness
35 1 Air Control Knob
36 1 On/Off Switch Assembly
37 1 Thermostat Knob
38 1 Primer Cap
39 15 #8 x 1/2Ó Screw
40 1 Console Overlay
41 1 On/Off Wire Harness
42 2 #10 x 1Ó Screw
43 2 #10 Nut
44 1 Motor Mount Bracket
45 1 Right Side Support
46 5 Wire Ties
47 1 Filter Cover
48 2 3/8Ó Compression Fittings
49 1 Temperature Tube
50 1 Trim
51 1 Primer O-ring
52 1 Upper Heater Gasket
53 4 #8 x 3/4Ó Screw
54 2 #10 Washer
55 1 Left Side Support
56 1 Pressure Switch
# 1 Heater Ground Wire
# 1 Air Pump
# 2 Key
# 1 Warning Decal
# 1 UserÕs Manual
# 1 Water Treatment Kit
# 1 Water Test Strips
# 1 Video
Loading...
