Ihome IBT15 User Manual

instruction manual

Model: iBT15

Drop+

Splashproof

Wireless Speaker

with Speakerphone

CHARGE

BEFORE

USE

Introduction

Thank you for purchasing the iHome iBT15. This product is designed to provide high quality wireless
sound for your iPad, iPhone, iPod, computer, PDA or other Bluetooth audio device.
This instruction booklet explains the basic operation and care of the unit. Please read them carefully and
keep for future reference.

IMPORTANT INFORMATION ABOUT SPLASH PROOF USE

For proper splash-proof operation, make sure the seal on the left side of the unit is completely flush with
the unit by pressing along the entire edge of the seal until it is completely and securely in place.

• The unit is IPX5 rated, meaning it will repel a stream of water for up to 5 minutes.

• DO NOT immerse the unit in water.

• Make sure seal and surrounding surfaces are completely dry before opening seal to prevent moisture
from damaging the internal electronics.

• Keep seal free of dirt, sand, or other objects that can interfere with proper sealing. If for any reason
the seal is not making a tight seal, water may enter the unit.

• DO NOT clean unit with oily soaps or use chemicals or solvents. Clean with damp cloth.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other

protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents,

such as benzene, thinner or similar materials can damage the surface of the unit.

1

What’s Included

• iBT15 speaker

• micro USB charging cable

• carry strap

micro USB charging cableiBT15 speaker

carry strap

2

Meet Your iBT15

iBT15

Reset Button
(insert
paperclip to
reset unit)

USB Charging
Port

Aux-in Jack

Splash-resistant Cover

Left Side

Right Side

Talk/Bluetooth Pairing/
Play/Pause Button

+ Volume Button

Press the

The unit will respond in a moment.

3

Power/End Call

Button

– Volume Button

Power/End Call
Button

to turn ON or OFF.

Top

Status indicator LED

iBT15

TIP: On some iOS (Apple) devices, you
can view the iBT15 battery status on
your device’s screen. When device is
paired and connected, look for a
vertical battery icon next to the
Bluetooth icon on the
upper right corner of the
device’s screen.

Status indicator Status

Solid red LED
Flashing red LED
Solid blue LED
Quickly flashing blue LED
Slowly flashing blue LED

Unit is charging
Unit needs charging

Active Bluetooth connection / Aux mode

Unit is attempting to pair with Bluetooth device
Unit is attempting to auto link to already

paired Bluetooth device

Microphone

4
