Icom PCR100 User Manual

INSTRUCTION MANUAL

This device complies with Part 15 of the FCC rules.Operation is sub­ject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept an y interference
received, including interference that may cause undesired operation.

iPCR100

COMMUNICATIONS RECEIVER FOR COMPUTER

i

IMPORTANT

READ ALL INSTRUCTIONS carefully and com-

pletely before using the receiver.

SA VE THIS INSTRUCTION MANUAL— This

instruction manual contains important operating instructions
for the IC-PCR100 COMMUNICATIONS RECEIVER FOR

COMPUTER.

USEantenna(s), such as a w ell-matched 50 Ωantenna and

feedline. For radio communications, the antenna is of critical
importance, along with sensitivity.

SYSTEM REQUIREMENTS

•IBM PC/AT compatible computer

•An RS-232C serial port (38400 bps or faster)

•Microsoft

®

Windows®95 or Microsoft®Windows®98

• Intel i486DX4 processor or faster (Pentium

®

100 MHz or

faster recommended)

•At least 16 MB RAM

•At least 10 MB of hard disk space

•At least 640 × 480 pixel display (800 × 600 pixel display rec­ommended)

OPERATING THEORY

Electromagnetic radiation which has frequencies of 20,000
Hz (20 kHz*) and above is called radio frequency (RF) energy
because it is useful in radio transmissions.The IC-PCR100
receives RF energy from 0.5 MHz* to 1300 MHz and converts
it into audio frequency (AF) energy which in turn actuates a
loudspeaker to create sound wav es .AF energy is in the range
of 20 to 20,000 Hz.

* kHz is an abbreviation of kilohertz or 1000 her tz, MHz is abbrevia-

tion of megahertz or 1,000,000 her tz, where hertz is a unit of fre ­quency.

OPERATING NOTES

The IC-PCR100 may receive its o wn oscillated frequency, re­sulting in no reception or only noise reception, on some fre­quencies.

The IC-PCR100 may receive interference from extremely
strong signals on different frequencies or when using an ex­ternal high-gain antenna.

Versions of the IC-PCR100 which display “CE” on the serial num­ber seal, comply with the essential requirements of the
89/336/EEC directive for Electromagnetic Compatibility.

CAUTIONS

RWARNING! NEVER connect the receiver to an AC

outlet. This may pose a fire hazard or result in an electric
shock.

NEVER connect other than the specified AC adapter to the

receiver .This connection will ruin the receiver.

NEVER connect the receiver to a power source of more

than 16 V DC such as a 24 V battery. This connection will ruin
the receiver .

NEVER expose the receiver to rain, snow or any liquids.
DO NOTuse or place the receiver in areas with tempera-

tures below 0°C (+32°F) or above +50°C (+122°F) or, in areas
subject to direct sunlight.

AVOID placing the receiver in excessively dusty environ-

ments.

AVOID the use of chemical agents such as benzine or al-

cohol when cleaning, as they damage the receiver surfaces.
Place unit in a secure place to avoid inadvertent use by children.

For U.S.A. only (FCC information)

CAUTION: Changes or modifications not expressly ap-

proved by Icom Inc.could void the user’s authority to operate
this receiver .

Class B digital device users

This equipment has been tested and found to comply with the limits
for Class B digital devices, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment gen­erates, uses and can radiate radio frequency energy and, if not in­stalled and used in accordance with the instruction manual, may
cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installa­tion. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equip­ment off and on, the user is encouraged to try to correct the interfer­ence by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

For Canada only

Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any in­terference, including interference that may cause undesired opera­tion of the device.

ii

IBM is registered trademark of International Business Machines Corporation in
the U.S.A.and other countries.Microsoft

®

and Windows®are registered trade­marks of Microsoft Corporation in the U.S.A and other countries.Screen shots
produced with permission from Microsoft Corporation. All other products or
brands are registered trademarks or trademarks of their respective holders.

iii

IMPORTANT ...................................... i

SYSTEM REQUIREMENTS .............. i

OPERA TING THEOR Y ....................... i

OPERATING NOTES ......................... i

CAUTIONS ........................................ ii

TABLE OF CONTENTS .................... iii

1 INSTALLATION ...................... 1 – 5

■Hardware installation ................ 1

■Antenna installation .................. 2

■Grounding ................................. 2

■AF output level selection ........... 3

■Software installation ................. 4

■RS-232C port setting ................ 5

■Mouse property setting ............. 5

2 PANEL DESCRIPTION ........ 6–15

■Multi-function receiver screen ... 6

■Function display ...................... 10

■Simple function receiver

screen ..................................... 12

■Function controller screen ...... 14

■Simple function receiver sub

screens ................................... 15

3 BASIC OPERATION ........... 16–21

■Receiving ................................ 16

■Setting a frequency ................. 17

■Setting a tuning step ............... 18

■Receive mode selection ......... 18

■Automatic mode selection ...... 19

■Setting squelch level ............... 20

■IF filter selection ..................... 20

■Attenuator function ................. 21

■Automatic noise limiter ........... 21

4 MEMORY CHANNELS ....... 22–25

■General ................................... 22

■Saving memory channels........ 22

■Selecting a memory channel... 23

■Memory channel

programming .......................... 24

■Clearing a memory channel .... 24

■Editing the memory list ........... 25

5 SCAN OPERATION ............ 26–33

■Scan types .............................. 26

■Programmed scan .................. 27

■Setting scan edges ................. 28

■Auto memory write scan ......... 29

■Memory scan .......................... 30

■Versatile memory scan ........... 31

■Scan resume condition ........... 32

■Scan speed setting.................. 33

6 BAND SCOPE .................... 34–35

■Operation ................................ 34

■Changing the automatic

sweep step limit ...................... 35

7

TONE SQUELCH OPERATION

... 36

8 TROUBLESHOOTING .............. 37

9

SPECIFICATIONS AND SUPPLIED
ACCESSORIES

.................... 38–39

■Specifications ......................... 38

■Supplied accessories .............. 39

TABLE OF CONTENTS

1

1

INSTALLATION

■ Hardware installation

Refer to the diagram below for connections.

Ground

Supplied antenna

to an AC adapter

to an
RS-232C port

External speaker

Personal computer

2

1

INSTALLATION

■ Antenna installation

Antennas play a very important role in receiver operation.
Connecting a poor quality antenna to the IC-PCR100 will re­sult in less than optimum performance.

Select antenna(s), such as a well-matched 50 Ω antenna and
feedline. 1.5:1 of Voltage Standing Wave Ratio (VSWR) is rec­ommended for a desired band. Of course, the antenna line
should be a coaxial cable.

CAUTION: Protect your receiver from lightning by

using a lightning arrestor.

NOTE:The supplied antenna is a simple plain antenna which
may not obtain indicated specifications. To obtain maximum
performance from the IC-PCR100, you must purchase an ex­ternal wide band antenna such as an optional Icom AH-7000
(25–1300 MHz), etc.

Contact your nearest Icom Dealer or Service Center for re­garding optimum antenna locations.

The antenna connector type is BNC, so an adapter ma y be
necessary to connect an optional antenna.

■ Grounding

R WARNING: NEVER use a gas pipe or electrical

conduit pipe for grounding.

To prevent accidents involving electricity and interference
from computers, ground the receiver through the GROUND
terminal on the rear panel.

For best results, connect a heavy gauge cable to a w ater pipe
or long, earth-sunk copper rod. Make the distance between
the [GND] terminal and ground as short as possible.

3

1

INSTALLATION

■ AF output level selection

The received audio can be input into your computer via the
sound card.

Before inputting the received audio into the [LINE IN] con­nector (connector name depends on your sound card), the
output level of the [EXT-SP] must be set properly. Perform as
follows:

CAUTION: Setting ‘STEREO’ and connecting a 2-con-

ductor plug cause a short-circuit. This may damage the
audio power amplifier .

D Multi-function receiver screen

q Select ‘EXT-Speaker’ in the option menu to bring up the

[EXT-Speaker Setting] dialog box.

w Select the plug type as shown below.

•“STEREO” for 3-conductor stereo plug.

•“MONO” for 2-conductor

monaural plug.

e Select the output level

as shown at right.

•“SP” for internal or exter-
nal speaker.

•“LINE” for PC sound
card or headphones.

r Connect an appropriate cable between IC-PCR100 and

PC.

•Use a 3-conductor stereo plug for connecting to the receiver.

D Simple function receiver screen

q Right-click* the frequency indication to display shortcut

menu and select ‘EXT-Speaker’ in the Option menu to bring
up the [EXT-Speaker Setting] dialog box.

* When the mouse property is set for right-handed.

w Select the plug type.

•“STEREO” for 3-conductor stereo plug.

•“MONO” for 2-conductor monaural plug.

e Select the output level.

•“SP” for internal or external speaker.

•“LINE” for PC sound card or headphones.

r Connect an appropriate cable between IC-PCR100 and

PC.

[EXT-SP]

to [LINE IN]

(depends on
your sound card)

4

1

INSTALLATION

■ Software installation

NOTE: Before using the program, make a backup copy of

the original disk. After making a backup copy, keep the
original disk in a safe place.

NOTE: Depending on the Windows

®

system files, the PC
may require rebooting. In this case, repeat the installation
from the beginning.

D Installation

q Boot up Windows.

•Quit all applications when windows is running.

w Insert the backup disk 1 into the appropriate floppy drive.
e Select ‘Run’from the [Start] menu.
r Type the setup program name with full path name, then

press the [Enter] key.(A:\SETUP [Enter])

t Following dialog appears.Follow the prompts.

y Program group ‘IC-PCR100’ appears in the ‘Programs’

folder of the [Start] menu.

D Software update information

Software update information will be available at the Icom
America home page:

http://www.icomamerica.com/

5

1

INSTALLATION

■ RS-232C port setting

‘COM Port Error’or ‘Communication f ailed’dialog box appears
when the RS-232C serial port is not set correctly.

NOTE: When launching the program for the first time, this
setting dialog appears for setting the RS-232C serial port.

D Multi-function receiver screen

q Before launching the program, make sure the IC-PCR100

interface unit is connected correctly.

w Launch the IC-PCR100 software.
e Click the [POWER] button in the tool bar or select ‘Power

OFF’in the File menu to temporarily pause the program.

r Click the [PORT] button or select ‘COM Port’ in the Option

menu to bring up the [COM Port Setting] dialog box.

t Click the desired

COM port number to
choose it.

y Click the [OK] button.

D Simple function receiver screen

q Before launching the program, make sure the IC-PCR100

interface unit is connected correctly.

w Launch the IC-PCR100 software.

e Click the [POWER] button to temporarily pause the pro-

gram.

r Right-click* the frequency indication to display shortcut

menu and select ‘COM Port’ in the Option menu to bring
up the [COM Port Setting] dialog box.

* When the mouse property is set for right-handed.

t Click the desired COM port number to choose it.
y Click the [OK] button.

■ Mouse property setting

The IC-PCR100 uses left and right buttons to rotate a control
knob on the multi-function receiver screen or to call up the
shortcut menu from the simple function receiver screen. De­pending on the mouse property setting of the control panel,
main and sub mouse button functions are alternated.

In this instruction manual, the operation is described with
setting for right-handed (Windows

®

default setting).

D Setting the button configuration

q Select ‘Settings’ from the [Start] menu and click ‘Control

Panel.’

w Open the mouse control panel.
e Select the button configuration to right- or left-handed.
r Click [OK] to set and exit the control panel.

■

Multi-function receiver screen

q POWER BUTTON [POWER]

Toggles the receiver power ON and OFF.

w FILE MENU [File]

Used for turning the software on/off, saving memory chan­nel contents or quitting the program, etc.

e VIEW MENU [View]

Used for showing/hiding the memory list screen/tool bar or
selecting the simple function receiver screen.

r SIMPLE FUNCTION RECEIVER BUTTON

Push to selects the simple function receiver screen.

t BANK MENU [BANK]

Used for selecting the memory bank.

y MEMORY LIST SCREEN BUTTON

Push to display or to hide the memory list screen.

u EXTERNAL SPEAKER SETTING BUTTON (p.3)

Push to display the external speaker setting dialog box.

i OPTION MENU [Option]

Used for displaying the e xternal speaker setting dialog box
or COM port setting dialog box.

o COM PORT SETTING BUTTON (p.5)

Push to display the COM port setting dialog box.

!0 EXIT BUTTON

Push to quit and exit this software.

6

2

PANEL DESCRIPTION

Function display

quw erty i

o!0 !1

!2 !3 !7 !8 !9 @0 @1 @2 @3!4 !5 !6

7

2

PANEL DESCRIPTION

!1 CLOSE BUTTON

Push to quit and exit this software.

!2 ATTENUATOR BUTTON [ATT] (p.21)

Push to turn the 20 dB attenuator on and off.

!3 VOLUME CONTROL [VOLUME] (p.16)

Adjusts the audio output.

•Right-click* to increase the volume level; left-click* to decrease
the volume level.

!4 AUTOMATIC NOISE LIMITER BUTTON [ANL] (p. 21)

Push to turn the automatic noise limiter for receiving AM
signals on and off.

!5 SQUELCH CONTROL [SQUELCH] (p. 20)

Adjusts the squelch threshold level.The squelch removes
noise output from the speaker (closed condition) when no
signal is received.

•Right-click* to increase the squelch level; left-click* to decrease
the squelch level.

!6 TONE SQUELCH BUTTON [T-SQL] (p.36)

Push to show or hide the [TONE SQUELCH] dialog box for
setting tone squelch frequencies.

!7

RECEIVE MODE BUTTONS [FM],[WFM], [AM], [AUT-M]

(pgs.18, 19)
Select a receive mode. The [AUT-M] button, automatic
mode, selects a previously progr ammed receive mode au­tomatically depending on a receive frequency.

!8 SCAN SPEED CONTROL [SPEED] (p. 33)

Sets the speed at which scans search through frequen­cies/memories for signals.

•Right-click* to increase the speed; left-click* to decrease the
speed.

!9 SCAN DELAY TIME CONTROL [DELAY] (p.32)

Sets the period in which a scan pauses after receiving a
signal.

•Right-click* to increase the period;left-click* to decrease the pe­riod.

@0 TUNING STEP UP/DOWN BUTTONS [TSJ]/[TSK]

(p.18)
Push to select the tuning steps.

@1 TUNING DIAL (p. 17)

Push to set the receive frequency with the selected tuning
step.

•Right-click* to increase the frequency;left-click* to decrease the
frequency.

@2 MEMORY BANK UP/DOWN BUTTONS

[BANK

∧]/[BANK∨] (p.23)

Push to select the memory bank.

@3 MEMORY CHANNEL UP/DOWN BUTTONS

[CH

∧]/[CH∨] (p. 23)

Push to select the memory channel.

* When the mouse property is set for right-handed.

8

2

PANEL DESCRIPTION

@4 KEYPAD [0]–[9], [•], [CE] (p.17)

➥[0] to [9] are used to input a receive frequency or mem-

ory channel directly.

➥[•] (Decimal) button is used to set the MHz digit when in-

putting a frequency.

➥[CE] (Clear) button is used to clear mistakes while in-

putting a receive frequency or memory channel.

@5 IF FILTER BUTTONS [NAR]/[WID] (p. 20)

Push to change the IF filter in use.The [WID] button se­lects a wider filter, the [NAR] button selects a narrower fil-
ter.

•Usable IF filters vary according to receive mode.

@6 SCAN STOP BUTTON [STOP] (p. 26)

Push to cancel scan operation.

@7 PROGRAMMED SCAN BUTTON [PROG] (p. 27)

Push to start/stop programmed scan.

•“PROG”flashes while scanning.

@8 SPAN +/– BUTTONS [SPAN+]/[SPAN–] (p.34)

Push to select one of four levels for the band scope fre­quency span.

@9 AUTO MEMORY WRITE SCAN BUTTON [AUTO] (p.29)

Push to start/stop auto memory write scan.

•“AUTO”flashes while scanning.

@4

@5 @6 @7 @8 @9 #1 #2 #3 #6 #7#4 #5#0

9

2

PANEL DESCRIPTION

#0 SWEEP START/PAUSE BUTTON [ss/❙❙] (p. 34)

Push to start/pause the band scope (sweep) function
which is used to observe signal conditions around the re­ceive frequency.

NOTE: While using the band scope function, audio is
NOT output. To monitor the frequency, push [s/❙❙] to

pause the function, or push [■] to cancel the function.

#1 MEMORY SCAN BUTTON [MEMO] (p.30)

Push to start/stop any of the memory scans.

•“MEMO”flashes while scanning.

#2 SWEEP STOP BUTTON [■] (p. 34)

Push to stop a band scope (sweep) function.

#3 SET BUTTON [SET]

Push to show the setting screen used to adjust settings for
scan functions, the band scope function and the automatic
mode function.

10

2

PANEL DESCRIPTION

■ Function display

q MEMORY BANK INDICATOR (p. 23)

Indicates the memory bank number (and its name if it has
one) being received.

w MEMORY CHANNEL INDICATOR (p.23)

Indicates the memory channel number (and its name if it
has one) being received.

•The name darkens when the receive frequency changes from the
stored one.

e FREQUENCY INDICATION (p.17)

Indicates the receive frequency and data as it is being
input such as memory channel numbers, etc.

r S (SIGNAL) METER (pgs. 16, 20)

Indicates the receive signal strength. Also indicates the
S-meter squelch receive lev el set via the [SQ UELCH] con­trol.

t BAND SCOPE PAUSE INDICATOR [PAUSE] (p. 34)

Appears when pausing the band scope.

y BUSY INDICATOR [BUSY]

Appears when receiving a signal or when signal noise
opens the squelch.

u RECEIVE MODE INDICATORS (p. 18)

Indicate the current receive mode.

•“WFM” lights in red when receiving a stereo broadcast program.

i TUNING STEP INDICATOR (p. 18)

This is the frequency increment used when selecting a fre­quency using the tuning dial and when searching for sig­nals using a scan function.

o IF FILTER INDICATOR (p. 20)

Indicates the selected IF filter and signal passband width.

!0 ATTENUATOR INDICATOR [ATT] (p. 21)

Appears when the attenuator function is on.

e

qw

!2 !3

!7!4 !4!5

!6

u

r
t

y

i
o

!0 !1

11

2

PANEL DESCRIPTION

!1 AUTOMATIC NOISE LIMITER INDICATOR [ANL] (p.21)

Appears when the automatic noise limiter is on.

!2 TONE SQUELCH INDICATOR [T-SQL] (p.36)

Appears when the tone squelch is on.

!3 AUTOMATIC MODE INDICATOR [AUT-M] (p. 19)

Appears when the automatic mode function is on.

!4 MAXIMUM FREQUENCY SPAN INDICATORS (p. 34)

➥Indicate the upper and lower observable frequency limits

around a receive frequency.

➥In the diagram, the upper and lower limits are +100 kHz

and –100 kHz.

!5 FREQUENCY SPAN INDICATION (p.34)

Indicates the frequency span selected with the [SPAN–] or
[SPAN+] button.

!6 CENTER FREQUENCY INDICATOR (p. 34)

Indicates the center frequency of the frequency span; this
is for the currently received frequency.

!7 SWEEP STEP INDICATOR (p. 34)

Indicates band scope sweep step.

!8 LIMIT INDICATOR (p. 35)

➥Indicates when the tuning step is greater than the auto-

matic sweep step setting.

➥In the diagram, the tuning step is greater than the auto-

matic sweep step setting and the tuning step (TS) and
the sweep step width are not the same.

12

2

PANEL DESCRIPTION

q POWER BUTTON [PWR]

Toggles the receiver power ON and OFF.

w AUTOMATIC MODE INDICATOR [AUT-M] (p. 19)

Appears when the automatic mode function is on.

e RECEIVE MODE INDICATOR (p. 18)

Indicates the current receive mode.

•“WFM” lights in red when receiving a stereo broadcast program.

r S (SIGNAL) METER (pgs. 16, 20)

Indicates the receive signal strength. Also indicates the
S-meter squelch receive level set via the [SQLJ]/[SQLK]
buttons.

t FREQUENCY INDICATION (p.17)

Indicates the receive frequency.

•Double-click to display/hide the information display.

•Right-click* to bring up the shortcut menu.

•Shortcut menu

y MEMORY CHANNEL NAME INDICATOR

Indicates the memory channel name (if it has one).

•The name darkens when the receive frequency changes from the
stored one.

•Double-click to display/hide the information display.

•Right-click* to bring up the shortcut menu.

■ Simple function receiver screen

Information display

Simple function
receiver

qwer t y u i o !0 !1

!2 !3 !4 !8 !9!5 !6 !7

13

2

PANEL DESCRIPTION

u MEMORY BANK BUTTON [BANK] (p.23)

Click to indicate the memory bank menu to select the
memory bank number.

i MEMORY CHANNEL BUTTONS [1] – [5] (p.23)

Select memory channels between 1 to 5 and indicate the
selected memory channel number.

•The selected memory channel number lights red.

•Memory channels 6 – 50 cannot be selected with these buttons.

Use the memory list screen to select these memory channels.

o MENU BUTTON [MENU]

Click to indicate the simple receiver menu to display/hide
the sub menu screen such as memory list screen.

•The information display automatically appears when the function
controller screen is selected.

•Menu screen

!0 VOLUME BUTTONS [J]/[K] (p. 16)

Adjust the audio output.

!1 VOLUME INDICATOR (p.16)

Indicates the audio output level.

!2 BUSY INDICATOR [BUSY]

Appears when receiving a signal or when signal noise
opens the squelch.

!3 ATTENUATOR INDICATOR [ATT] (p.21)

Appears when the attenuator function is on.

!4 AUTOMATIC NOISE LIMITER INDICATOR [ANL] (p.21)

Appears when the automatic noise limiter is on.

!5 MEMORY BANK INDICATOR (p. 23)

Indicates the memory bank number.

!6 MEMORY BANK NAME INDICATOR (p. 23)

Indicates the memory bank name (if it has one).

!7 IF FILTER INDICATOR (p. 20)

Indicates the selected IF filter and signal passband width.

!8 TUNING STEP INDICATOR (p. 18)

Indicates the frequency increment used when selecting a
frequency using the tuning dial and when searching for sig­nals using a scan function.

!9 TONE SQUELCH INDICATOR (p.36)

Indicates the selected tone squelch frequency when the
tone squelch is on.

* When the mouse property is set for right-handed.

14

2

PANEL DESCRIPTION

■ Function controller screen

q RECEIVE MODE BUTTONS [AM], [FM], [WFM] (p.18)

Select a receive mode.

w AUTOMATIC RECEIVE MODE BUTTON [AUT-M] (p. 19)

Selects an automatic receive mode.This mode selects a
previously programmed receive mode automatically de­pending on the receive frequency.

e TONE SQUELCH BUTTON [TSQL] (p.36)

Push to show or hide the [TONE SQUELCH] dialog box for
setting tone squelch frequencies.

r SQUELCH UP/DOWN BUTTONS [SQLJ]/[SQLK]

(p.20)
Adjust the squelch threshold level.The squelch removes
noise output from the speaker (closed condition) when no
signal is received.

t IF FILTER BUTTONS [NAR]/[WID] (p. 20)

Push to change the IF filter in use.The [WID] button se­lects a wider filter, the [NAR] button selects a narrower fil-
ter.

•Usable IF filters vary according to receive mode.

y ATTENUATOR BUTTON [ATT] (p.21)

Push to turn the 20 dB attenuator on and off.

u AUTOMATIC NOISE LIMITER BUTTON [ANL] (p. 21)

Push to turn the automatic noise limiter for receiving AM
signals on and off.

i FREQUENCY UP/DOWN BUTTONS

[FREQJ]/[FREQK] (p.17)

Push to set the receive frequency with the selected tuning
step.

o TUNING STEP UP/DOWN BUTTONS [TSJ]/[TSK]

(p.18)
Push to select the tuning steps.

q

w

e

u

r

t
y

i

o

15

2

PANEL DESCRIPTION

•Information display

Double clicking the simple receiver also
toggles the information display on/off.

•Memory list screen

•Setting screen

•Band scoop screen

•Function controller screen

•Scan controller screen

■ Simple function receiver sub screens

The simple function receiver screen has an information display and 5 sub
screens for saving desktop space and performing various operation.The follow­ing sub screens are available.

16

3

BASIC OPERATION

■ Receiving

Make sure the hardware installation is finished.(p. 1)

D Using the multi-function receiver screen

q Click [POWER] to turn power ON.
w Click the [VOLUME] control with the sub mouse button to

increase the audio level; click the [VOLUME] control with
the main mouse button to decrease the audio level.

•When clicking and holding the control, the audio level scrolls up
or down.

•Pushing the PC’s [c] or [d] key also sets the audio level.

e Set an operating frequency and mode. (pgs.17, 18)
r Click the [SQUELCH] control with the sub mouse button to

increase the squelch level (tight squelch); click the
[SQUELCH] control with the main mouse button to de­crease the squelch level (loose squelch).

•When clicking and holding the control, the squelch level scrolls
up or down.

t When a signal is received:

➥Squelch opens and audio is emitted from the speaker.
➥The S-meter shows the relative signal strength.

D Using the simple function receiver screen

q Click [PWR] to turn power ON.
w Click [MENU] and select the ‘Function Controller’ when it

is not displayed.

e Click [VOLJ] or [VOLK] to set the desired audio level.

•When clicking and holding either button, the volume level scrolls
up or down.

•Pushing the PC’s [c] or [d] key also sets the audio level.

r Set an operating frequency and mode. (pgs.17, 18)
t Click [SQLJ] or [SQLK] to set the desired squelch level.

•When clicking and holding either button, the squelch level scrolls
up or down.

y When a signal is received:

➥Squelch opens and audio is emitted from the speaker.
➥The S-meter shows the relative signal strength.

q Power switch e Select mode

w Set volume

e Set frequency

r Set the squelch level

17

3

BASIC OPERATION

■ Setting a frequency

Depending on the situation, the receive frequency can be set
using the following methods. Frequencies can be set from

0.01000 to 1300.00000 MHz.

D Using the tuning dial

➥Click the tuning dial with the sub mouse button to increase

the frequency; click the tuning dial with the main mouse
button to decrease the frequency.

•The frequency changes according to the preset tuning steps.See
the next page for selecting the tuning step.

•When clicking and holding either button the frequency scrolls up
or down.

D Using the simple function receiver screen

q Click [MENU] and select the ‘Function Controller’ when it

is not displayed.

w Click [FREQ J] or [FREQK] on the function controller to

set the frequency according to the selected tuning step.

•The frequency changes according to the selected tuning steps.
See the next page for selecting the tuning step.

•When clicking and holding either button the frequency scrolls up
or down.

D Using the keypad

➥Click the desired numeral buttons, then click [ENT] to set

the frequency.

•When making a mistake while inputting a frequency, click [CE] to
clear the input and return to the previous frequency.

•When you want to change the 100 kHz digit and below, click [•]
first, then the numeral buttons and then [ENT].

•When you want to set the 100 kHz digit and below to 0, input the

MHz digits and then click [ENT].

•When inputting a frequency outside of the allowed receive fre­quency range, the previously selected frequency is automatically
selected after clicking [ENT].

D Using the PC keyboard

➥Push the desired numeral k e ys , then push [Enter] to set the

frequency.

•When inputting from the keyboard, click anywhere in the receiver
screen first, then begin inputting from the keyboard.

•When making a mistake while inputting a frequency, push [Esc]
to clear the input and return to the previous frequency.

•When you want to change the 100 kHz digit and below, push [•]
first, then the numeral keys and then [Enter].

•When you want to set the 100 kHz digit and below to 0, input the

MHz digits and then push [Enter].

•Push [b] or [a] to set the frequency according to the selected
tuning step.

•When inputting a frequency outside of the allowed receive fre­quency range, the previously selected frequency is automatically
selected after clicking [Enter].

18

3

BASIC OPERATION

■ Setting a tuning step

When using the tuning dial or [FREQJ]/[FREQK] buttons to
change the frequency, or when a scan function is activated,
the frequency changes in increments determined by the set
tuning step.This can be changed if desired.

The following tuning step are available.

•1 kHz •5 kHz •6.25 kHz•9 kHz •10 kHz •12.5 kHz

•15 kHz •20 kHz •25 kHz •30 kHz •50 kHz •100 kHz

•500 kHz •1 MHz •10 MHz

D Using the multi-function receiver screen

➥Click [TSJ] or [TSK] to set the desired tuning step.

•The selected tuning step is displayed in the function display.

D Using the simple function receiver screen

q Click [MENU] and select the ‘Function Controller’ when it

is not displayed.

w Click [TSJ] or [TS K] on the function controller screen to

select the desired tuning step.

•The selected tuning step is displayed in the information display if
the information display is in use.

■ Receive mode selection

Receive modes are determined by the physical properties of
the radio signals.The receiver has 3 receive modes:FM, AM
and WFM modes.

Typically, AM mode is used for the AM broadcast stations
(0.495–1.620 MHz) and air band (118–135.995 MHz), and
WFM is used for FM broadcast stations (76–107.9 MHz).

When using the automatic mode function, a receive mode,
tuning step and filter selection are automatically selected after
inputting a frequency.

D Using the multi-function receiver screen

➥Click [FM], [WFM], [AM] or [A UT-M] to select the desired re-

ceive mode.

D Using the simple function receiver screen

q Click [MENU] and select the ‘Function Controller’ when it

is not displayed.

w Click [AM], [FM], [WFM] or [AUT-M] to select the desired

receive mode.

19

3

BASIC OPERATION

■ Automatic mode selection

An automatic mode function is available to automatically set
the receive mode, IF filter passband width and tuning step
after inputting a frequency.

Each click of the [AUT-M] button toggles the automatic mode
function on and off.

•For the simple function receiv er screen, the [AUT-M] button is on the
function controller screen.

D Setting the automatic mode function

The default setting for the automatic mode function can be
added to, changed or deleted.Up to 20 ranges can be mem­orized into the automatic mode function settings.

q For the multi-function receiver screen, click the [SET] but-

ton to call up the setting screen.
For the simple function receiver screen, click the [MENU]
button and select the ‘Function Setting (SET)’to call up the
setting screen.

w Click the [Auto Mode] tab to display the automatic mode

list.

e Click a cell in the [Freq Low] column and the desired line.
r Input the lower frequency of the frequency range from the

keyboard, then push [Enter].

•When nothing is input into the [Freq Low] or [Freq High] column,
settings for other columns cannot be made.

•When inputting a new frequency, other data automatically ap­pears in the other column.

•To delete a frequency range setting, enter [0] or [Space] into the
[Freq Low] column from the keyboard.

t Input the higher frequency of the frequency range into the

[Freq High] column, push the [Enter] key.

y Set other data such as mode, tuning step, etc., if desired.

•Double-click the desired cell, select the desired item and double­click the selection.

u Click the close (["]) button to close the setting screen.

Click to bring up the
setting screen.

20

3

BASIC OPERATION

■ Setting squelch level

The squelch function sets a minimum receive signal level
below which no audio is emitted from the speaker. This con­veniently prevents noise and static from being emitted when
receiving weak signals or no signals at all.

Further setting of squelch removes weak signals.The remove
level is displayed on the S-meter (S-meter squelch). The
squelch does not open if a signal below the set S-meter level
is received.

D Using the multi-function receiver screen

➥Click the [SQUELCH] control with the sub mouse button to

increase the squelch level (tight squelch); click the
[SQUELCH] control with the main mouse button to de­crease the squelch level (loose squelch).

•The S-meter squelch level is displayed in the function display.

D Using the simple function receiver screen

q Click [MENU] and select the ‘Function controller’when it is

not displayed.

w Click [SQLJ] or [SQLK] on the function controller to select

the desired squelch level.

•The S-meter squelch lev el is displayed under the frequency indi­cation.

■ IF filter selection

Increasing or decreasing the width of incoming signals can
help eliminate interference.Available filters vary according to
the receive mode.See the table below.

K: Factory setting; K: Selectable;–: Not selectable

D Using the multi-function receiver screen

➥Click the [WID] or [NAR] buttons to toggle between filter

widths.

D Using the simple function receiver screen

q Click [MENU] and select the ‘Function controller’when it is

not displayed.

w Click [WID] or [NAR] on the function controller to select the

filter width.

6 kHzIF filter

FM

WFM

AM

K

–

K

15 kHz

K

–

–K

50 kHz

K

K

230 kHz

K

–

K

21

3

BASIC OPERATION

■ Attenuator function

Strong signals (such as from broadcast stations, pocket beep­ers, nearby amateur radio stations, etc.) can cause distortion
of receive signals.The attenuator function can reduce signal
strength of interfering signals by approx.20 dB.

D Using the multi-function receiver screen

➥Click [ATT] to toggle the attenuator function ON and OFF.

•“ATT”appears in the function display.

D Using the simple function receiver screen

q Click [MENU] and select the ‘Function controller’when it is

not displayed.

w Click [ATT] on the function controller to toggle the attenua-

tor function ON and OFF.

•“ATT”appears in the information display if the information display
is in use.

■ Automatic noise limiter

The automatic noise limiter removes noise components from
an AM signal.

D Using the multi-function receiver screen

➥Click [ANL] to toggle the automatic noise limiter ON and

OFF.

•“ANL” appears in the function display.

D Using the simple function receiver screen

q Click [MENU] and select the ‘Function controller’when it is

not displayed.

w Click [ANL] on the function controller to toggle the auto-

matic noise limiter ON and OFF.

•“ANL” appears in the information
display if the information display
is in use.

[ATT]

[ANL]

22

4

MEMORY CHANNELS

■ General

The receiver has 1000 memory channels in 20 banks for stor­age of often-used frequencies.

D Memory channel contents

The following information can be programmed into memory
channels:

•Memory channel name

•Operating frequency (p.17)

•Receive mode (p. 18)

•IF filter selection (p.20)

•Attenuator ON/OFF (p.21)

•Tuning step (p. 18)

•Select memory scan setting (p.31)

•Memory skip scan setting (p.31)

•Tone squelch ON/OFF and it’s frequency (p.36)

•Memory channel comment

■ Saving memory channels

The memory channels can be stored as a PC file.

D Using the multi-function receiver screen

➥Select [Save] or [Save As] on the [File] menu to back up

memory channel data.

➥Select [Open] on the [File] menu to open memory channel

data.

➥Select [New] on the [File] menu to make a new file for

memory channel data.

D Using the simple function receiver screen

➥Select [Save] or [Save As] in the [File] menu on the short-

cut menu to back up memory channel data.

➥Select [Open] in the [File] menu on the shortcut menu to

open memory channel data.

➥Select [New] in the [File] menu on the shortcut menu to

make a new file for memory channel data.

23

4

MEMORY CHANNELS

■ Selecting a memory channel

D Using the up/down button on the multi-

function receiver screen

q Click the [BANK∧] or [BANK∨] button to select a memory

bank.

w Click the [CH

∧] or [CH∨] button to select a memory chan-

nel.

D Using the [Mch] button on the multi-

function receiver screen

➥Click the desired numeral b uttons (1 to 50), then clic k [Mch]

to set memory channel.

•When making a mistake while inputting a memory channel, click
[CE] to clear the input and return to the previous frequency.

D Using the simple function receiver screen

q Click the [BANK] button and select a desired memory

bank.

w Click a numeral button, [1]–[5], to select memory channels

1–5.

•Use the memory list screen to select memory channels 6
to 50.

D Using the memory list screen

q Call up the memory list screen if it is not displayed.

•For the multi-function receiver screen, click the memory list
screen button or select ‘Memory List’from the [View] menu.

•For the simple function receiver screen, click the [MENU] button
and select the ‘Memory List.’

w Click [BANK#]/[BANK$] or select a bank name with [$]

to select a memory bank.

e Click the memory channel number in the [CH] column to

set the desired memory contents.

•Click the data area you want to call up, then click [Rx Entry] to
call up the data.

w Select memory bank

e Select memory channel

24

4

MEMORY CHANNELS

■

Memory channel programming

Each memory bank (1 to 20) can hold up to 50 channels and
can store the information listed below.

Bank name, memory name, frequency, mode, filter, atten­uator, tuning step , select memory scan, skip channel, tone
squelch and remark.

D Using the multi-function receiver screen

q Click the [BANK∧] or [BANK∨] button to select a memory

bank to be programmed.

w Click the [CH

∧] or [CH∨] button to select a memory chan-

nel to be programmed.

e Set a frequency and mode, etc. that you want to memo-

rize.

r Click the [MW] button to program the displayed frequency

into the memory channel.

•“NONAME” appears in the memory channel indicator.

D Using the memory list screen

q Call up the memory list screen if it is not displayed.

•For the multi-function receiver screen, click the memory list
screen button or select ‘Memory List’from the [View] menu.

•For the simple function receiver screen, click the [MENU] button
and select the ‘Memory List.’

w Click [BANK#]/[BANK$] or select a bank name with [$]

to select a memory bank.

e Click a cell in the [Frequency] column and the desired

memory channel line.

r Input the receive frequency from the keyboard, then push

[Enter].

•Input frequency first in order for other data to be input.

t Set other data such as mode, tuning step, etc., if desired.

•Double-click the desired cell, select the desired item and double­click the selection.

■ Clearing a

memory channel

D Using the multi-function receiver screen

q Select a desired memory channel to be cleared with

[BANK

∧]/[BANK∨] and [CH∧]/[CH∨].

w Click the [MCL] button to clear the memory channel con-

tents.

e Select desired cell t Set other data, if desired

25

4

MEMORY CHANNELS

■ Editing the memory list

D Editing a bank name

Bank names and memory names can be set or changed for
the screen being used.

q Call up the memory list screen if it is not displayed.

•For the multi-function receiver screen, click the memory list
screen button or select ‘Memory List’from the [View] menu.

•For the simple function receiver screen, click the [MENU] button
and select the ‘Memory List.’

w Click [BANK#]/[BANK$] or select a bank name with [$]

to select a memory bank.

e Click the memory bank name indicator or a memory name

cell on the memory list screen.

•The memory bank name or memory name is highlighted.

r Input the name from the keyboard.

•Push [Enter] first to modify the previously input name.

t Push the [Enter] key to input the name.

D Inserting and deleting channels

New blank channels can be inserted into the channel list and
channels no longer needed can be deleted from the channel
list.

q Call up the memory list screen if it is not displayed.

•For the multi-function receiver screen, click the memory list
screen button or select ‘Memory List’from the [View] menu.

•For the simple function receiver screen, click the [MENU] button
and select the ‘Memory List.’

w Click [BANK#]/[BANK$] or select a bank name with [$]

to select a memory bank.

e Click the position where you want to insert/delete a chan-

nel.

r Click [Insert CH] or [Delete CH] to insert or delete the

channel at the selected position.

•When memory channel 50 is not a blank channel, a new blank
channel can not be inserted. Delete a channel or use another
memory bank in this case.

Memory name column

Memory bank name

26

5

SCAN OPERATION

■ Scan types

Up to 20 programmed scan ranges, memory scan, memory
select scan, memory skip scan, mode select memor y scan
and auto memory write scan provide scanning versatility.

PROGRAMMED SCAN

(p. 27)

Repeatedly scans between
two user-programmed fre­quencies. Used for checking
for frequencies within a
specified range such as
repeater output frequencies,
etc.

Scan

Jump

Scan edges

Scan edge

Scan edge

SELECT MEMORY SCAN

(p. 31)

Repeatedly scans only select
memory channels within a
memory bank. This function
can be turned ON/OFF in
[Memory SCAN] tab. Select
channels can be set in the
memory list screen.

Not yet
programmed

ch 50

ch 1 ch 2 ch 3

ch 4

ch 5

ch 6ch 49

Not yet programmed

ch 50

ch 1 ch 2 ch 3

ch 4

ch 5

ch 6ch 49

MEMORY SKIP SCAN

(p. 31)

Skips unwanted memory
channels that inconvenient­ly stop scanning. This func­tion can be turned ON/OFF
in [Memory SCAN] tab.
Skip channels can be set in
the memory list screen.

Not yet
programmed

ch 50

ch 1 ch 2 ch 3

ch 4

ch 5

ch 6ch 49

MEMORY SCAN
(p. 30)

Repeatedly scans memory
channels within a memory
bank (1–20).

Not yet
programmed

SKIP

ch 50

ch 1 ch 2 ch 3

SEL

SEL

SKIP

SELSEL

SEL

SEL

MODE SELECT MEMORY
SCAN (p. 31)

Repeatedly scans only
selected mode channels
within a memory bank. This
function can be set in
[Memory SCAN] tab of the
setting screen.

FM

AM

FMFMFM

FM

FM

ch 5

ch 6ch 49

ch 4

AUTO MEMORY WRITE
SCAN (p. 29)

The frequencies that the
programmed scan stops
are automatically program­med into a selected memo­ry bank.

ch 1 ch 2

Pause

Program Program

Pause

Scan

27

5

SCAN OPERATION

■ Programmed scan

Programmed scan automatically searches for signals within
a specified frequency range.

For programmed scan, scan edges must be programmed
in advance.See the next section for details.

D Using the multi-function receiver screen

q Make sure the squelch is set to the threshold point.(closed

condition)

w Click the [SET] button to call up the setting screen if it is

not displayed.

e Click the [Program SCAN] tab to show the program list.
r Select a programmed scan range to be scanned with the

mouse, then click the close (["]) button.

t Click the [PROG] button to start programmed scan.

•“PROG”flashes while scanning.

y To cancel the scan, click [STOP] or [PROG].

•When the frequency is changed after cancelling a scan and a
new scan is activated, scan starts from the starting frequency of
the specified frequency range. When the frequency is not
changed, scan starts from the previously stopped frequency.

D Using the simple function receiver screen

q Make sure the squelch is set to the threshold point.(closed

condition)

w Call up the setting screen if it is not displayed.

•Click the [MENU] button and select the ‘Function Setting (SET).’

•When the scan controller screen is in use, click the [SET] button

on the screen.

e Click the [Program SCAN] tab to show the program list.
r Select a programmed scan range to be scanned with the

mouse, then click the close (["]) button.

t Call up the scan controller screen if it is not displayed.

•Click the [MENU] button and select the ‘Scan Controller.’

y Click the [PROG] button in the scan controller screen to

start programmed scan.

•“Program SCAN” flashes in the scan controller screen while
scanning.

u To cancel the scan, click [STOP] or [PROG].

•When the frequency is changed after cancelling a scan and a
new scan is activated, scan starts from the starting frequency of
the specified frequency range. When the frequency is not
changed, scan starts from the previously stopped frequency.

[PROG]

[STOP]

[SET]

28

5

SCAN OPERATION

■ Setting scan edges

Settings such as frequency range, receive mode , tuning step,
etc. must be set in advance. Up to 20 settings can be pro­grammed.

q Call up the setting screen if it is not displayed.

•For the multi-function receiver screen, click the [SET] button.

•For the simple function receiver screen, click the [MENU] button

and select the ‘Function Setting (SET).’ When the scan controller
screen is in use, click the [SET] button on the screen.

w Click the [Program SCAN] tab to show the program list.
e Click a start frequency cell in the [START] column to se-

lect the data input condition.

•When a cell is clicked, the scan edges of the line are automati­cally set as scan edges.

r Input the start frequency into the selected cell from the

keyboard, then push [Enter] (data appears automatically in
other cells when new range is entered.).

•Data must be set in this cell or the [END] cell before data can be
set in other cells.

•To erase the data, push the [Delete] key after selecting a [ST ART]
or [END] cell.

t Set data into other cells as desired, then click the close

(["]) button to close the program list.

Selected scan edge number

Set other data, if desired

Scan edge frequency

29

5

SCAN OPERATION

■ Auto memory write scan

Auto memory write scan does the same as the programmed
scan and then writes paused signal frequencies into memory
channels of a specified memory bank. Scan edges must be
programmed in advance.(p.28)

D Using the multi-function receiver screen

q Make sure the squelch is set to the threshold point.(closed

condition)

w Click the [SET] button to call up the setting screen if it is

not displayed.

e Click the [Program SCAN] tab to show the program list.
r Select the programmed scan edges to be scanned with the

mouse, then click the [Auto MW SCAN] tab.

t Select a memory bank to be written.

•To clear the selected memory bank contents, click [All Clear].

y Click the [AUTO] button to start auto memory write scan.

•“AUTO”flashes while scanning.

u To cancel the scan, click [STOP] or [AUTO].

D Using the simple function receiver screen

q Make sure the squelch is set to the threshold point.(closed

condition)

w Call up the setting screen if it is not displayed.

•Click the [MENU] button and select the ‘Function Setting (SET).’

•When the scan controller screen is in use, click the [SET] button

on the screen.

e Click the [Program SCAN] tab to show the program list.
r Select the programmed scan edges to be scanned with the

mouse, then click the [Auto MW SCAN] tab.

t Select a memory bank to be written.

•To clear the selected memory bank contents, click [All Clear].

y Call up the scan controller screen if it is not displayed.

•Click the [MENU] button and select the ‘Scan Controller.’

u Click the [AUTO] button to start auto memory write scan.

•“Auto MW SCAN”flashes while scanning.

i To cancel the scan, click [STOP] or [AUTO].

[AUTO]

[STOP]

[SET]

30

5

SCAN OPERATION

■ Memory scan

This function searches all memory channels in a selected
memory bank.

D Using the multi-function receiver screen

q Make sure the squelch is set to the threshold point.(closed

condition)

w Click the [BANK

∧] or [BANK∨] button to select the de-

sired memory bank.

•When using the memory list screen, click [BANK #]/[BANK$]
or select a bank name with [$] to select a memory bank.

e Click the [SET] button to call up the setting screen if it is

not displayed.

r Click the [Memory SCAN] tab.
t Make sure the check boxes are not chec ked (%) then click

the close (["]) button.

y Click the [MEMO] button to start memory scan.

•“MEMO”flashes while scanning.

u To cancel the scan, click [STOP] or [MEMO].

D Using the multi-function receiver screen

q Make sure the squelch is set to the threshold point.(closed

condition)

w Click the [BANK] button and select the desired memory

bank.

•When using the memory list screen, click [BANK #]/[BANK$]
or select a bank name with [$] to select a memory bank.

e Call up the setting screen if it is not displayed.

•Click the [MENU] button and select the ‘Function Setting (SET).’

•When the scan controller screen is in use, click the [SET] button

on the screen.

r Click the [Memory SCAN] tab.
t Make sure the check boxes are not chec ked (%) then click

the close (["]) button.

y Click the [MEMO] button in the scan controller screen to

start memory scan.

•“Memory SCAN”flashes while scanning.

u To cancel the scan, click [STOP] or [MEMO].

Not checked for the memory scan

31

5

SCAN OPERATION

■ Versatile memory scan

Using the [Memory SCAN] tab in the setting screen you can
set conditions specific only to memory channels during mem­ory scan.

q Call up the setting screen if it is not displayed.

•For the multi-function receiver screen, click the [SET] button.

•For the simple function receiver screen, click the [MENU] button

and select the ‘Function Setting (SET).’ When the scan controller
screen is in use, click the [SET] button on the screen.

w Click the [Memory SCAN] tab.
e Make sure the desired check boxes are checked (%).

•When selecting the [SEL] box (select memory scan), only
memory channels specified as SEL (select) are scanned.

•When selecting the [SKIP] box (memory skip scan),
memory channels specified as SKIP channels are not
scanned.

•When selecting the [MODE SEL] box (mode select mem­ory scan), only memory channels programmed with the
specified receive mode (in the [Select Mode] check box)
are scanned.

r Click the close (["]) button.
t Start the desired memory scan.

•For the multi-function receiver screen, click the [MEMO] button.

•For the simple function receiv er screen, click the [MEMO] button

in the scan controller screen.

y To cancel the scan, click [STOP] or [MEMO].

•All settings can be used simultaneously.

•SEL, SKIP and receive mode are set in the memory list

screen.

•At least 2 memory channels must be programmed with
the desired condition for scan to proceed.

Check for select memory scan

Check for memory skip scan

Check for mode
select memory scan

Check the desired
modes for mode select
memory scan

32

5

SCAN OPERATION

■ Scan resume condition

When receiving a signal, scan automatically pauses on that
signal.The scan resume condition sets the time that the scan
pauses before resuming or whether scan stops instead of
pausing.

q Call up the setting screen if it is not displayed.

•For the multi-function receiver screen, click the [SET] button.

•For the simple function receiver screen, click the [MENU] button

and select the ‘Function Setting (SET).’ When the scan controller
screen is in use, click the [SET] button on the screen.

w Click the [SCAN Delay] tab, then click to select a resume

condition from [DELAY Timing].

(a) ‘Pause until Signal disappears’

Scan pauses when receiving a signal and remains
paused until the signal disappears.

(b) ‘Dela y V olume’

When setting a delay time using the [DELAY] control
(multi-function receiver screen) or [DELAY] scroll bar
(scan controller screen), scan pauses when receiving a
signal and then resumes after the specified delay.

(c) ‘SCAN Stop’

When a signal is received during scan, scan stops and
does not resume.

e Click to select a restart delay time from [Restart Delay].

This setting is valid when selecting (a) or (b) above.

(a) 0 Sec.

Scan resumes immediately after the signal disappears.

(b) 1 Sec.

Scan resumes 1 sec. after the signal disappears.

(c) 2 Sec.

Scan resumes 2 sec. after the signal disappears.

r Click the close (["]) button to close the setting screen.

[DELAY][DELAY]

33

5

SCAN OPERATION

■ Scan speed setting

The searching speed of frequencies or memory channels is
variable.

D Using the multi-function receiver screen

➥Click the [SPEED] control with the sub mouse button to in-

crease the scan speed; click the [SPEED] control with the
main mouse button to decrease the scan speed.

•When clicking and holding the control, the scan speed scrolls up
or down.

D Using the simple function receiver screen

q Call up the scan controller screen if it is not displayed.

•Click the [MENU] button and select the ‘Scan Controller.’

w Drag the [SPEED] scroll bar upward to increase the scan

speed and downward to decrease the scan speed.

[SPEED]

[SPEED]

34

6

BAND SCOPE

■ Operation

The band scope function allows you to visually check a spec­ified frequency range.

Receive audio is muted while monitoring the band scope.
Push [s/❙❙] to pause sweeping and receive the audio.

D Using the multi-function receiver screen

q Click the sweep start/pause button ([s/❙❙]) to begin a

sweep;signal conditions appear starting from the center of
the range.

•Conditions over the entire set frequency span can be observed
around the center frequency of the currently received frequency.

w Click the [SPAN+] or [SPAN–] button to select the sweep

width through SPAN1 (±100 kHz) to SPAN4 (±2 MHz).

e Click the [TSJ] or [TSK] button to select the sweep tuning

step.

•“LIMIT” appears when a tuning step greater than the sweep step
range is selected.

r Click the waveform to select the frequency of the signal.

•Click the [s/❙❙] button to pause a sweep and monitor the fre-
quency. Repeat to resume the sweep.

•While pausing the band scope, you can also select the frequency
by clicking the waveform. The current receive frequency is
marked by a dotted line and the previous receive frequency is
displayed at center.

t Click the sweep stop button ([‘]) to cancel a sweep.

D Using the simple function receiver screen

q Call up the band scope screen if it is not displayed.

•Click the [MENU] button and select the ‘Band Scope.’

w Click the sweep start/pause button ([s/❙❙]) to begin a

sweep;signal conditions appear starting from the center of
the range.

•Conditions over the entire set frequency span can be observed
around the center frequency of the currently received frequency.

e Click the [∫] or [√] button to select the sweep width

through SPAN1 (±100 kHz) to SPAN4 (±2 MHz).

•Choose [SPAN1] when band conditions are crowded (many sig­nals are present); choose [SPAN4] when f e w signals are present.

r Click the [TSJ] or [TSK] button on the function controller

screen to select the sweep tuning step.

•Click [MENU] and select the ‘Function controller’ when it is not
displayed.

•“LIMIT” appears when a tuning step greater than the sweep step
range is selected.

Click to select sweep width.

Click to start or pause sweeping.

35

6

BAND SCOPE

t Click the waveform to select the frequency of the signal.

•Click the [s/❙❙] button to pause a sweep and monitor the fre-
quency. Repeat to resume the sweep.

•While pausing the band scope, you can also select the frequency
by clicking the waveform. The current receive frequency is
marked by a dotted line and the previous receive frequency is
displayed at center.

y Click the close (["]) button to stop sweeping and close the

band scope screen.

■ Changing the automatic

sweep step limit

The frequency steps used while sweeping are automatically
set according to the tuning step.However , these steps can be
defined using the [BAND SCOPE] tab on the setting screen.

q Call up the setting screen if it is not displayed.

•For the multi-function receiver screen, click the [SET] button.

•For the simple function receiver screen, click the [MENU] button

and select the ‘Function Setting (SET).’ When the scan controller
screen is in use, click the [SET] button on the screen.

w Click the [BAND SCOPE] tab.
e Click a frequency step range from inside the [Automatic

Sweep-Step Limit].

•The sweep step range can be selected from one of 1 kHz to 100
kHz, 1 kHz to 50 kHz or 1 kHz to 25 kHz.

r Click the close (["]) button to close the setting screen.

D About the limit indicator

When using the band scope function and the selected tuning
step (TS) is outside the automatic sweep step setting, [LIMIT]
appears in the band scope display. This indicates that the tun­ing step (TS) and the sweep step width are not the same.

36

7

TONE SQUELCH OPERATION

The tone squelch opens only when receiving a signal con­taining a matching subaudible tone in FM mode. For exam­ple, you can silently wait for calls from group members using
the same tone in an amateur band.

D Using the multi-function receiver screen

q Click the [FM] button to select FM mode.
w Click the [T-SQL] button to bring up the [TONE SQUELCH]

dialog box.

•“T-SQL” appears in the function display.

e Click the [$] button, then select the desired tone squelch

frequency.

•Fifty-one tone frequencies from 67.0 to 254.1 Hz are available.

r Click the close (["]) button to close the [TONE SQUELCH]

dialog box.

t When the received signal includes a matching tone,

squelch opens and the signal can be heard.

•When the received signal’s tone does not match, tone squelch
does not open, however, the S-indicator shows signal strength.

y Click the [T-SQL] button to cancel the tone squelch.

•“T-SQL” disappears.

D Using the simple function receiver screen

q Click [MENU] and select the ‘Function Controller’ when it

is not displayed.

w Click the [FM] button in the function controller screen to se-

lect FM mode.

e Click the [TSQL] button to bring up the [TONE SQUELCH]

dialog box.

•“T-SQL” and tone squelch frequency appear in the information
display.

r Click the [$] button, then select the desired tone squelch

frequency.

•Fifty-one tone frequencies from 67.0 to 254.1 Hz are available.

t Click the close (["]) button to close the [TONE SQUELCH]

dialog box.

y When the received signal includes a matching tone,

squelch opens and the signal can be heard.

•When the received signal’s tone does not match, tone squelch
does not open, however, the S-indicator shows signal strength.

u Click the [TSQL] button to cancel the tone squelch.

•“T-SQL” and tone squelch frequency disappear.

•Available tone squelch frequencies (unit: Hz)

67.0

69.3

71.0

71.9

74.4

77.0

79.7

82.5

85.4

88.5

91.5

94.8

097.4

100.0

103.5

107.2

110.9

114.8

118.8

123.0

127.3

131.8

136.5

141.3

146.2

151.4

156.7

159.8

162.2

165.5

167.9

171.3

173.8

177.3

179.9

183.5

186.2

189.9

192.8

196.6

199.5

203.5

206.5

210.7

218.1

225.7

229.1

233.6

241.8

250.3

254.1

37

8

TROUBLESHOOTING

If your receiver seems to be malfunctioning, please check the
following points before sending it to a service center.

PROBLEM POSSIBLE CAUSE SOLUTION REF.

No power comes ON. •The RS-232C cable is not connected

correctly.

•The RS-232C port is not selected correctly .

No sound comes from the
speaker.

Receive audio is
distorted.

Sensitivity is low. •The attenuator is activated. •Click the [ATT] button to cancel the function. p. 21

•V olume lev el is too low .

•The squelch is closed.

•Band scope function is in use.

•Different tone is selected with tone squelch.

•The operating mode is not selected correctly .

•The IF filter is not selected correctly .

•Check the RS-232C cable .

•Select the RS-232C port correctly .

•Click the [V OLUME] control with the sub mouse button

or click the volume [J] button to obtain a suitable le vel.

•Click the [SQUELCH] control with the main mouse
button or click the [SQLK] b utton to open the squelch.

•Pause or cancel the band scope function.

•Check the tone squelch frequency .

•Select a suitable operating mode with [FM], [WFM],

[AM] or [AUT-M].

•Select a suitable IF filter with [NAR] or [WID].

p. 1

p. 5
p. 16

p. 20

p. 34
p. 36

pgs.
18, 19
p. 20

38

9

SPECIFICATIONS AND SUPPLIED ACCESSORIES

■ Specifications

•Frequency coverage (MHz):
U.S.A.version 0.01–823.999,*

849.001–868.999, 894.001–1300

Non-U.S.A.versions 0.01–1300*

*Specifications guaranteed 0.5–1300 MHz only.

•Receive system : Triple superheterodyne (AM/FM)

Double superheterodyne (WFM)

•Mode : FM, AM, WFM,

•Frequency stability : ±5 ppm at 1300 MHz

(0°C to +50°C;
32°F to +122°F)

•Frequency resolution : 1 kHz (minimum)

•Power supply : 13.8 V DC ±15 % for receiver

requirement unit; or, supplied AC adapter

(negative ground)

•Current drain (at 13.8 V DC):
Standby (software OFF) 0.1 A
Receive (squelched) 0.6 A
Receive (max.audio) 0.7 A

•Usable temp.range : 0°C to +50°C;

+32°F to +122°F

•Intermediate frequencies:
1st 266.7 MHz
2nd 10.7 MHz
3rd 450 kHz (except WFM)

•Receive sensitivity (typical)*:

* When 230 kHz (for WFM), 15 kHz (for FM) and 6 kHz (for AM)

passband widths are selected.

•Squelch sensitivity (threshold):

Frequency

(MHz)

AM

(10 dB S/N)FM(12 dB SINAD)

WFM

(12 dB SINAD)

0.5–1.799 2.5 µV

—

—1.8–27.999

1.8 µV

50–699.999

0.5 µV

700–1300 1.3 µV 0.4 µV 1.0 µV

1.0 µV 0.32 µV 0.79 µV

28–49.999

Frequency

(MHz)

AM

(10 dB S/N)FM(12 dB SINAD)

WFM

(12 dB SINAD)

0.5–1.799 1.8 µV

—

—1.8–27.999

0.89 µV

50–699.999

0.63 µV

700–1300 0.89 µV 0.63 µV 10 µV

0.71 µV 0.5 µV 5.6 µV

28–49.999

•Selectivity (typical) :
FM/AM 6 kHz/–6 dB
FM/AM 15 kHz/–6 dB
WFM/FM/AM 50 kHz/–6 dB
WFM 230 kHz/–6 dB

•Max.audio output : 0.2 W (monaural)

0.1 W × 2 (stereo)

(at 10% distortion with an 8 Ω load)

•Antenna connector : BNC (50 Ω)

•RS-232C connector : D-sub 9-pin (female)

•Ext.speaker connector : 3-conductor 3.5 (d) mm (

1

⁄8″)/

4–8 Ω

•Dimensions (projections not included):

131(W)× 33.5(H)× 154.5(D) mm
5

5

⁄32(W)× 15⁄16(H)× 63⁄32(D) in

•Weight : approx.0.5 kg; 1 lb 2 oz.

■ Supplied accessories

Accessories included with the receiver: Qty.

q Wire antenna .................................................................. 1

w RS-232C cable (OPC-743) ............................................. 1

e AC adapter (BC-123A/E or BM-104E)* .......................... 1

r Software floppy disks ................................................ 1 set

* For versions which do not come with an AC adapter, a DC power

cable (OPC-131) and 2 fuses (FGB 2 A) are supplied. An optional
AC adapter (BC-123E or BM-104E) is also available.

q

w

e

r

39

9

SPECIFICATIONS AND SUPPLIED ACCESSORIES

All stated specifications are subject to change without
notice or obligation.

Count on us!

6-9-16 Kamihigashi, Hirano-ku, Osaka 547-0002 Japan

A-5548H-1EX-q
Printed in Japan
© 1998 Icom Inc.
