Icom IC-FR5000, IC-FR6000 User Manual

VHF AND UHF REPEATERS

(

VHF Repeater

)

(

UHF Repeater

)

IDAS bridges the gap between analog and digital systems

IDAS is Icom's digital land mobile radio system using the NXDN™ common air interface. It has
useful calling features including selective calling, status message, radio stun/kill/revive and GPS
position reporting, etc. The IDAS system is ideal for business and industry users who may want
to migrate to a digital system or to the future FCC mandated narrow band spacing.

■ Double your channel capacity

IDAS doubles the capacity of the current

12.5kHz channel allocation. Icom allows you
to meet any narrow banding requirements
today, and provides a solution to any future
spectrum deficiencies.

Double your channel capacity

Existing Analog FM

(12.5kHz)

IDAS Digital

(12.5kHz)

■

Digital/analog mixed mode operation

The IC-FR5000 series can receive both
analog and digital signals on a single chan­nel. You can partially introduce the IDAS
system, while using the existing analog ra­dios in a system. The IDAS system allows
you to scale migration to narrow band digi­tal at your own pace and need.

■ Improved audio quality

The IDAS system occupies only 6.25kHz
spacing per channel. With the improved
sensitivity of narrow band communications,
increased communication greater than

12.5kHz analog mode can be achieved.
The IDAS system uses the AMBE+2™
codec, which provides clear audio and si­multaneous data communication.

■ Network interface*

1

The IDAS repeater has a network inter­face* and can be connected to a LAN or
the Internet via Ethernet cable. Communi­cation range is vastly extended by the In­ternet connection and eliminates the need
for expensive leased lines. When con­nected to a PC via a LAN or the Internet,
you can remotely maintain the repeater
configuration remotely from your PC.

* Option (Available in the future)

■ Digital trunking capability*

1

The repeater will also have digital trunking
capability in the near future. This will allow
you further effective channel management
by sharing a minimum of channels with a
large number of users.

*1Some features are planned and released in the future.

Max. 6 channels with three repeaters
saving rack space.

Stable, Flexible and High-Performing Repeater

UHF REPEATERVHF REPEATER

19-inch rack mount
2U height low profile design

A 2U height configuration allows you to
stack multiple units in an industry standard
19-inch rack.

Two RF channel modules in one unit

Two RF modules* can be installed in a
chassis to reduce installation space, while
the RF modules can be programmed and
operated independently. LEDs on the front

Two RF units can be installed in the unit. (Left side is an option.)

panel show both channel conditions.

* Optional UR-FR5000/UR-FR6000 required.

Easy-to-see display and
5 programmable buttons

The 12-digit dot-matrix display, 5 program­mable buttons, 32 memory channels and
internal speaker allow you to use the re­peater as a base station or to check re­peater activity.

D-SUB 25-pin accessory connector

The IC-FR5000 series has a programma­ble D-SUB 25-pin accessory connector for
connecting various trunking controllers or
external remote control devices. Also, mod­ulation/demodulation signals can be input/
output from the D-SUB connector.

Other features

• Audio compander*

• PTT priority setting

or repeater operation)

• Built-in inversion type voice scrambler
and optional voice scrambler UT-109R or
UT-110R*

• 5-Tone and DTMF encoder/decoder* and
CW ID transmitter

• Analog wide/narrow
spacing programmable*

• Normal and priority scan

• Convenient key assign stickers supplied

• Quick and easy programming from a PC

*

For analog mode only

(Local Mic., external PTT

(12.5/25kHz)

channel

50W output at 50% duty cycle,
25W 100% duty cycle operation

Employing a high stability ±0.5ppm oscilla­tor and high performance power amplifier,
the IC-FR5000 series provides a reliable
100% duty cycle operation at 25W output.
When operated at the high power setting of
50W, the repeater operates with a 50%
duty cycle.

Multiple CTCSS, DTCS tone and
RAN code decode

The IC-FR5000 series decodes multiple
CTCSS and DTCS as well as digital RAN

(Radio Access Number) codes on a per chan-

nel basis
links the received signal with a specified
tone/code. This function is useful for shar­ing a channel with multiple groups and pro­vides quiet stand-by while using other
groups.

(up to 16 tones/codes) and down-

VHF AND UHF REPEATERS

TX Antenna
Connector

RX Antenna
Connector

Installation space for optional
channel module.

D-SUB 25-Pin
Accessory
Connector

External
Speaker
Connector

DC Power
Receptacle
