Icom IC-F6062, IC-F5062 User Manual

INSTRUCTION MANUAL

VHF MOBILE TRANSCEIVER

iF5062

UHF MOBILE TRANSCEIVER

iF6062

i

EXPLICIT DEFINITIONS

RWARNING! NEVER connect the transceiver to an

AC outlet. This may pose a fire hazard or result in an electric
shock.

NEVER connect the transceiver to a power source of more

than 16 V DC such as a 24 V battery. This connection will ruin
the transceiver.

NEVER cut the DC power cable between the DC plug and

fuse holder. If an incorrect connection is made after cutting,
the transceiver might be damaged.

NEVER place the transceiver where normal operation of

the vehicle may be hindered or where it could cause bodily
injury.

NEVER allow children to touch the transceiver.
NEVER expose the transceiver to rain, snow or any liquids.
USE the specified microphone only. Other microphones

have different pin assignments and may damage the trans­ceiver.

DO NOT use or place the transceiver in areas with tem-

peratures below –25°C or above +55°C, or in areas subject to
direct sunlight, such as the dashboard.

PRECAUTIONS

WORD DEFINITION

RWARNING

Personal injury, fire hazard or electric shock
may occur.

CAUTION

Equipment damage may occur.

NOTE

If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.

READ ALL INSTRUCTIONS carefully and com-

pletely before using the transceiver.

SAVE THIS INSTRUCTION MANUAL— This

instruction manual contains important operating instructions
for the IC-F5062 and IC-F6062 VHF/UHF MOBILE TRANS-
CEIVERS.

IMPORTANT

Icom, Icom Inc. and the logo are registered trademarks of Icom
Incorporated (Japan) in the United States, the United Kingdom, Germany,
France, Spain, Russia and/or other countries.
LTR is a registered trademark of the E.F.Johnson Company.
All other products or brands are registered trademarks or trademarks of their
respective holders.

See the operating guide for details of BIIS, MDC and LTR

®

system operations. Ask your dealer for details.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

ii

AVOID operating the transceiver without running the vehi-

cle’s engine. The vehicle’s battery will quickly run out if the
transceiver transmits while the vehicle’s engine OFF.

AVOID placing the transceiver in excessively dusty envi-

ronments.

AVOID placing the transceiver against walls. Otherwise

heat dissipation will be obstructed.

AVOID the use of chemical agents such as benzine or

alcohol when cleaning, as they damage the transceiver sur­faces.

BE CAREFUL! The transceiver will become hot when

operating continuously for long periods.

TABLE OF CONTENTS

IMPORTANT .................................................................................... i

EXPLICIT DEFINITIONS ................................................................. i

PRECAUTIONS ............................................................................... i

TABLE OF CONTENTS .................................................................. ii

1 PANEL DESCRIPTION ........................................................... 1–6

■ Front panel ............................................................................... 1

■ Function display ....................................................................... 2

■ Programmable function keys ................................................... 3

2 BASIC OPERATION ............................................................. 7–12

■ Turning power ON .................................................................... 7

■ Channel selection .................................................................... 7

■ Call procedure .......................................................................... 8

■ Receiving and transmitting ....................................................... 8

D Transmitting notes ................................................................. 9

D TX code channel selection .................................................... 9

D TX code number edit ........................................................... 10

D DTMF transmission.............................................................. 11

■ Scrambler function ................................................................. 11

■ User set mode ........................................................................ 12

3 CONNECTION AND MAINTENANCE ................................ 13–15

■ Rear panel connection ........................................................... 13

■ Supplied Accessories ............................................................. 14

■ Mounting the transceiver......................................................... 14

■ Antenna ................................................................................... 15

■ Fuse replacement .................................................................. 15

■ Cleaning ................................................................................. 15

■ Options ................................................................................... 15

4 DOC ..................................................................................... 16–17

1

1

PANEL DESCRIPTION

Icom Inc.

qe

y

SpeakerFunction display (p. 2)

w r

t

■ Front panel

q AF VOLUME CONTROL KNOB [VOL]

Rotate the knob to adjust the audio output level.

• Minimum audio level is pre-programmed.

w LED INDICATOR

➥ Lights red while transmitting a signal.
➥ Lights green while receiving a signal.

e UP/DOWN KEYS [CH Up]/[CH Down]

Push to select an operating channel, etc.

*The desired function can be assigned by your dealer. (p. 3)

r POWER SWITCH [ ]

Push to turn the power ON and OFF.

• Automatic scan start, Password prompt and Set mode access
are available at power ON.

t DEALER-PROGRAMMABLE KEYS

Desired functions can be programmed independently by
your dealer. (p. 3)

y MICROPHONE CONNECTOR

Connect the supplied or optional microphone.

NEVER connect non-specified microphones. The pin
assignments may be different and the transceiver may
be damaged.

DD

MICROPHONE

The supplied microphone has a PTT switch and a hanger hook.

• The following functions are available when the microphone is on or
off hook (depending on the setting):

- Automatic scan start when on hook.

- Scan is cancelled when off hook.

- Scan is paused when off hook.

- Automatic priority channel selection is available when off hook.

- Sets to ‘Inaudible’ condition (mute condition) when on hook.

- Sets to ‘Audible’ condition (unmute condition) when off hook.

2

1

PANEL DESCRIPTION

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

■ Function display

q SIGNAL STRENGTH INDICATOR

Indicates relative signal strength level as below.

w LOW POWER INDICATOR

Appears when low output power is selected.

e AUDIBLE INDICATOR

➥ Appears when the channel is in the ‘audible’ (unmute)

condition.

➥ Appears when the specified 2/5-tone/BIIS*

1

/MDC*

2

code is received.

r COMPANDER INDICATOR

Appears when the compander function is activated.

t SCRAMBLER INDICATOR

Appears when the voice scrambler function is activated.

y BELL INDICATOR

Appears/blinks when the specific 2/5-tone/BIIS*

1

/MDC*

2

code is received, according to the pre-programming.

u CALL CODE MEMORY INDICATOR

➥ Appears when the call code memory is selected.
➥ Appears when a phone call is received.*

3

i SCROLL INDICATOR

Appears when the received SDM includes more than 12
characters.*

1

o SDM INDICATOR

Appears when an SDM is received, or a transmit SDM is
selected.*

1

!0 ALPHANUMERIC DISPLAY

➥ Displays an operating channel number, channel name,

Set mode contents, DTMF code, etc.

➥ The indication mode can be selected from 1 line or 2

lines. Ask your dealer for details.

• In this instruction manual, the LCD illustration is described
using the 2 lines indication mode.

!1 ACTIVATED KEY INDICATOR

Appears above the key assigned as [Scan A Start/Stop],
[Scan B Start/Stop], [Scan Add/Del(Tag)], [Lock], [Talk
Around], [Surveillance] and [Digital]*

1

keys during that key

is activated.

*1BIIS operation only *2MDC operation only
*3LTR®operation only

See the operating guide for details of BIIS, MDC and LTR

®

system operations. Ask your dealer for details.

Weak ⇐ Receive Signal level ⇒ Strong

Icom Inc.

qw ertyuio

!0

!1

3

1

PANEL DESCRIPTION

■ Programmable function keys

The following functions can be assigned to [UP], [DOWN],
[P0], [P1], [P2], [P3] and [P4] programmable function keys.

Consult your Icom dealer or system operator for details con­cerning your transceivers programming.
If the programmable function names are bracketed in the fol­lowing explanations, the specific key is used to activate the
function depends on the programming.

CH UP AND DOWN KEYS

➥ Push to select an operating channel.
➥ Push to select a transmit code channel after pushing [TX

Code CH Select].

➥ Push to select a DTMF channel after pushing [DTMF

Autodial].

➥ Push to select a scan group after pushing and holding

[Scan A Start/Stop]/[Scan B Start/Stop] for 1 sec.

ZONE KEY

Push this key, then select the desired zone using [CH Up]/
[CH Down].

What is “zone”?—The desired channels are assigned
into a zone according to the intended use for grouping.
For example, ‘Staff A’ and ‘Staff B’ are assigned into a
“Business” zone, and ‘John’ and ‘Cindy’ are assigned into a
“Private” zone.

SCAN A START/STOP KEY

➥ This key’s operation depends on the Power ON Scan setting.

When the power ON scan function is turned OFF;

Push to start and cancel scanning operation.

When the power ON scan function is turned ON;

Push to pause scanning, then resumes scanning after a
specified time period has passed.

➥ Push and hold this key for 1 sec. to indicate the scan group,

then select the desired group using [CH Up]/[CH Down].

SCAN B START/STOP KEY

➥ Push to start and cancel scanning operation. Scan

resumes after a specified time period has passed when
scan is cancelled except for this key.

➥ Push and hold this key for 1 sec. to indicate the scan group,

then select the desired group using [CH Up]/[CH Down].

SCAN ADD/DEL (TAG) KEY

➥ Push to add or delete the selected channel to/from the

scan group.

1. Push to indicate the scan group, then push [CH Up] or [CH
Down] to select the desired group.

2. Push to add or delete the channel to/from the selected scan
group.

3. Push and hold for 1 sec. to exit the scan group selection mode.

➥ Push this key while scan is paused (a signal is detected)

on a channel (except for priority channel,) the channel is
cleared from the scan group.

Depending on the setting, the cleared channel is added
to the scan group again after the scan is cancelled.

4

1

PANEL DESCRIPTION

1

PRIO A/B KEYS

➥ Push to select Priority A or Priority B channel.
➥ Push and hold [Prio A (Rewrite)] or [Prio B (Rewrite)] to set

the operating channel as the Priority A or Priority B chan­nel.

MR-CH 1/2/3/4 KEYS

Push to select the memory channel 1 to 4 directly.

MONI (AUDI) KEY

➥ Mute and release the CTCSS (DTCS) or 2-tone squelch

mute. Open any squelch/deactivate any mute while push­ing and holding this key. (LMR operation only)

➥ Activates one of (or two of) the following functions on each

channel independently: (PMR or BIIS PMR operation only)

• Push and hold to un-mute the channel (audio is emitted;
‘Audible’ condition).

• Push to mute the channel (sets to ‘Inaudible’ only).

• Push to un-mute the channel (sets to ‘Audible’ only).

• Push after the communication is finished to send a ‘reset code’.
(BIIS PMR operation only)

NOTE: The un-mute condition (‘Audible’ condition) may
automatically return to the mute condition (‘Inaudible’ con­dition) after a specified period depending on programming.

PUBLIC ADDRESS KEY

Push to activate the Public Address (PA) function for voice
amplification. When the PA function is activated, the audio
output can be controlled from the transceiver separately with
the [VOL] control knob.

• This function is available when the external unit, such as a audio
amplifier, speaker, etc. is additionally connected.

•Push this key, then speak into the microphone while pushing and

holding [PTT].

•[CH Up]/[CH Down] also allow you to set the audio output level.

RX SPEAKER KEY

The received audio can be heard via the external speaker
when this key is pushed.

• This function is available when the external speaker is additionally
connected.

•This function is useful when you are out of the vehicle.

•The audio output level is linked to the transceiver’s volume control.

LIGHT KEY

Push to turn the transceiver’s backlight ON for about 5 sec.
when the backlight function is turned OFF in user set mode.

LOCK KEY

Push and hold to electronically lock all programmable keys
except the following:

[Moni(Audi)], [Light], [Lock], [Call] (incl. Call A and Call B),
[Emergency Single]/[Emergency Repeat] (incl. Silent), [Surveillance]
and [OPT 1/2/3].

5

1

PANEL DESCRIPTION

HIGH/LOW KEY

Push to select the transmit output power temporarily or per­manently, depending on the pre-setting.

•Ask your dealer for the output power level for each selection.

C.TONE CH ENT KEY

Push to select the continuous tone channel using [CH Up]/[CH
Down] to change the tone frequency/code setting after push­ing this key. The selected channel remains set as the continu­ous tone channel until another channel is designated as such.

TALK AROUND KEY

Push to turn the talk around function ON and OFF.

•The talk around function equalizes the transmit frequency to the
receive frequency for transceiver-to-transceiver communication.

WIDE/NARROW KEY

Push to toggle the IF bandwidth between wide and narrow.

• The wide passband width can be selected from 25.0 or 20.0 kHz

using the CS-F5060

CLONING SOFTWARE

. (PMR or BIIS PMR opera-

tion only) Ask your dealer for details.

DTMF AUTODIAL KEY

Push to enter the DTMF channel selection mode. Then select
the desired DTMF channel using [CH Up]/[CH Down].
After selecting the DTMF channel, push again to transmit the
selected DTMF code.

RE-DIAL KEY

Push to transmit the last-transmitted DTMF code.

• TX memories are cleared after turning the transceiver OFF.

SCRAMBLER FUNCTION

Push to toggle the voice scrambler function ON and OFF.

CALL KEYS

Push to transmit a 2/5-tone/BIIS ID code.

•Call transmission is necessary before calling another station
depending on your signalling system.

•[Call A] and/or [Call B] may be available when your system employs
selective ‘Individual/Group’ calls. Ask your dealer which call is
assigned to each key.

EMERGENCY KEYS

➥ Push and hold to transmit an emergency call.
➥ When [Emergency Single (Silent)] or [Emergency Repeat

(Silent)] is pushed, an emergency call is transmitted with
no beep emission and LCD indication change.

• If you want to cancel the emergency call, push (or push and
hold) the key again before transmitting the call.

• The emergency call is transmitted one time only or repeatedly
until receiving a control code depending on the pre-setting.

SURVEILLANCE KEY

Push to turn the surveillance function ON or OFF.
When this function is turned ON, the beep is not emitted and
the LCD backlight and the LED indicator do not light when a
signal is received or a key is pushed.

COMPANDER KEY

Push to toggle the compander function ON and OFF.
The compander function reduces noise components from the
transmitted audio to provide clear communication.

6

1

PANEL DESCRIPTION

1

TX CODE ENTER KEY (PMR or BIIS PMR operation only)
Push to enter the ID code edit mode directly, for both 5-tone
and MSK. Then set the desired digit using [CH Up]/
[CH Down]. (p. 10)

TX CODE CHANNEL SELECT KEY

➥ Push to enter the ID code channel selection mode directly.

Then set the desired channel using [CH Up]/[CH Down].
(p. 9)

➥ During ID code channel selection mode, push for 1 sec. to

enter the ID code edit mode for 5-tone and MSK. Then set
the desired digit using [CH Up]/[CH Down]. (p. 10)

TX CODE CHANNEL UP/DOWN KEYS

➥ Push to select a TX code channel directly.
➥ Push to set the desired digit during the ID code edit mode.

ID-MR SELECT KEY (PMR or BIIS PMR operation only)

➥ Recalls detected ID codes.

• Push this key, then select the ID code using [CH Up]/[CH Down].

• Up to 5 ID’s are memorized.

➥ Push and hold for 1 sec. to erase the selected ID’s.

HOOK SCAN KEY

When the on hook scan function is activated, push this key
to disables on hook scan function (stop scanning) temporari­ly. Push this key again to re-start scanning.

USER SET MODE KEY

➥ Push and hold to enter user set mode.

• During user set mode, push this key to select an item, and
change the value or condition using push [CH Up]/[CH Down].

➥ Push and hold this key again to exit user set mode.
User set mode is also available via the ‘Power ON function.’
Refer to p. 12 also.

MR-CH ENT KEYS

Push to enter the memory channel selection mode, then enter
the desired channel number using the 10-keypad of the con­nected microphone.

OPT 1/2/3 KEYS

Push to control the output signal level from the optional unit
connector.

7

2

BASIC OPERATION

■ Turning power ON

q Push []to turn the power ON.
w If the transceiver is programmed for a start up password,

input the digit codes as directed by your dealer.

• The keys as below can be used for password input:
The transceiver detects numbers in the same block as identical.
Therefore “01234” and “56789” are the same.

e When the “PASSWORD” indication does not clear after

inputting 6 digits, the input code number may be incorrect.
Turn the power off and start over in this case.

■ Channel selection

Several types of channel selections are available. Methods
may differ according to your system set up.

NON-ZONE TYPE:

Push [CH Up] or [CH Down] to select the desired operating
channel, in sequence; or, push one of [MR-CH 1] to [MR-CH
4] keys to select a channel directly.

ZONE TYPE:

Push [Zone] then push [CH Up] or [CH Down] to select the
desired zone.

AUTOMATIC SCAN TYPE:

Channel setting is not necessary for this type. When turning
power ON, the transceiver automatically starts scanning.
Scanning stops when receiving a call.

KEY

NUMBER

0

5

4

9

3

8

2

7

1

6

8

2

BASIC OPERATION

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

■ Call procedure

When your system employs tone signaling (excluding CTCSS
and DTCS), the call procedure may be necessary prior to voice
transmission. The tone signalling employed may be a selec­tive calling system which allows you to call specific station(s)
only and prevent unwanted stations from contacting you.

q Select the desired TX code channel or 2/5-tone code

according to your System Operator’s instructions.

• This may not be necessary depending on programming.

• Refer to pgs. 9–10 for selection.

w Push the call key (assigned to one of the dealer program-

mable keys) or [PTT].

e After transmitting, the remainder of your communication

can be carried out in the normal fashion.

■ Receiving and transmitting

Receiving:

q Push [ ] to turn the power ON.
w Push [CH Up] or [CH Down] to select a channel, in

sequence.

e When receiving a call, adjust the audio output level to a

comfortable listening level.

Transmitting:

Wait for the channel to become clear to avoid interference.
q Take the microphone off hook.

• 2/5-tone mute may be released. (The ‘audible’ condition is
selected and BUSY indicator lights green.)

• A priority channel may be selected automatically.

w Wait for the channel to become clear.

• The channel is busy when BUSY indicator lights green.

e Push [CALL] when initiating a call from your side.

• Coded audio may be heard from the transceiver, then “ ”
appears.

• This operation may not be necessary depending on your signal­ing system. Ask your dealer for details.

r While pushing and holding [PTT], speak into the micro-

phone at your normal voice level.

t Release [PTT] to receive.

IMPORTANT: To maximize the readability of your signal;

1. Pause briefly after pushing [PTT].

2. Hold the microphone 5 to 10 cm (2 to 4 inches) from

your mouth, then speak into the microphone at a normal
voice level.

Selective calling

Non-selective calling

9

2

BASIC OPERATION

D Transmitting notes

• Transmit inhibit function

The transceiver has several inhibit functions which restrict
transmission under the following conditions:

- The channel is in mute condition (‘Inaudible’ condition;
“ ” does not appear.)

- The channel is busy.

- Un-matched (or matched) CTCSS is received.

(Depending on the pre-setting)

- The selected channel is a ‘receive only’ channel.

• Time-out timer

After continuous transmission for the pre-programmed time
period, the time-out timer is activated, causing the transceiv­er to stop transmitting.

• Penalty timer

Once the time-out timer is activated, transmission is further
inhibited for a period determined by the penalty timer.

D TX code channel selection

If the transceiver has [TX Code CH Select] assigned to it, the
indication can be toggled between the operating channel
number (or name) and TX code channel number (or name).
When the TX code channel number (or name) is displayed,
[CH Up]/[CH Down] selects the TX code channel.

USING [TX CODE CH SELECT] KEY:

q Push [TX Code CH Select]— a TX code channel number

(or name) appears.

w Push [CH Up] or [CH Down] to select the desired TX code

channel.

e Push [Call] to transmit the selected TX code.

USING [TX CODE CH UP]/[TX CODE CH DOWN] KEY:

If the transceiver has a [TX Code CH Up] or [TX Code CH
Down] key assignment, the programmed TX code channel
can be selected directly when pushed.

NOTE for PMR or BIIS PMR operation:

• The LCD indication does not change when the operating
channel number (or name) is displayed.

• To check the selected TX code, push [TX Code CH
Select].

10

2

BASIC OPERATION

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

D TX code number edit

(PMR or BIIS PMR operation only)
If the transceiver has [TX Code CH Select] or [TX Code
Enter] assigned to it, TX code contents can be edited within
the allowable digits.

USING [TX CODE CH SELECT] KEY:

q Push [TX Code CH Select] to enter the TX code channel

selection mode.

• Select the desired channel before entering the TX code channel
selection mode if necessary.

w Push [TX Code CH Select] for 1 sec. to enter the TX code

edit mode.

e Push [TX Code CH Select] to select the desired digit to be

edited.

• The digit to be edited blinks.

r Push [CH Up] or [CH Down] to set the desired digit.
t Push [TX Code CH Select] to set the digit. The digit to the

right will blink automatically.

y Repeat r and t to input all allowable digits.
u Push [Call] to transmit the edited TX code.

USING [TX CODE ENTER] KEY:

q After pushing [TX Code CH Select], push [CH Up] or [CH

Down], or push [TX Code CH Up] or [TX Code CH Down]
to select the desired TX code channel.

w Push [TX Code Enter] to enter the TX code edit mode.

• The digit to be edited blinks.

e Push [TX Code Enter] to select the desired digit to be edit-

ed.

r Push [CH Up] or [CH Down] to set the desired digit.
t Push [TX Code Enter] to set the digit. The digit to the right

will blink automatically.

y Repeat r and t to input all allowable digits.
u Push [Call] to transmit the edited TX code.

11

2

BASIC OPERATION

D DTMF transmission

If the transceiver has [DTMF Autodial] assigned to it, the auto­matic DTMF transmission function is available. Up to 8 DTMF
channels are available.

q Push [DTMF Autodial]— a DTMF channel appears.
w Push [CH Up] or [CH Down] to select the desired DTMF

channel.

e Push [DTMF Autodial] to transmit the DTMF code in the

selected DTMF channel.

■ Scrambler function

The voice scrambler function provides private communication
between stations. The frequency inversion type is equipped
to all versions, moreover, the optional Rolling or Non-rolling
type can be available.

q Push [Scrambler] to turn the scrambler function ON.

• “ ” appears.

w Push [Scrambler] again to turn the scrambler function

OFF.

• “ ” disappears.

12

2

BASIC OPERATION

2

■ User set mode

User set mode is accessed with [User Set Mode] and allows
you to set seldom-changed settings. In this case you can
“customize” the transceiver operation to suit your preferences
and operating style.

Entering the user set mode:

q While pushing and holding [P1] and [P2], push [ ] to turn

the power ON. Then, push and hold [P0] for 1 sec. to enter
user set mode.

• You should hold [P1] and [P2] until “SET MODE” appears.

w Push [P0] several times to select the appropriate item.

Then, push [Up] or [Down] to set the desired level/condi­tion.

• Available set mode functions are Backlight, LCD Contrast,

Beep, Beep Level, Ringer Level, SQL Level, AF Min Level,
Mic Gain, Horn and Signal Moni.

e Push and hold [ ] for 1 sec. to turn power OFF, then ON

again to exit set mode.

User set mode is also available via a programmable key.
Please refer to p. 6 [User Set Mode] section.

[ ]

[P0] [Up]/[Down]

[P1][P0] [P2] [ ]

13

3

CONNECTION AND MAINTENANCE

■ Rear panel connection

Antenna

q ANTENNA CONNECTOR

Connects to an antenna.
Contact your dealer about
antenna selection and
placement.

w D-Sub 25-pin

Connect an exter­nal unit.

e EXTERNAL

SPEAKER JACK

Connect a 4–8 Ω
external speaker.

Optional speaker

Microphone

q

y DC POWER RECEPTACLE

Connects to a 12 V DC battery. Pay atten­tion to polarities. NEVER connect to a 24 V
battery. This could damage the transceiver.

Red

12V
Battery

R CAUTION! NEVER remove
the fuse-holder from the DC
power cable.

t

Black

e

y

w

NOTE: Use the terminals as shown
below for the cable connections.

Crimp

Solder

r

r MICROPHONE HANGER

Connect the supplied mi­crophone hanger to the
vehicle’s ground for mi­crophone on/off hook
functions. (See p. 1)

t IGNITION LEAD

Connects to a ignition line.

R

Do not put a pressure to
this lead.
Binding to the DC power
cable is recommended.

14

3

CONNECTION AND MAINTENANCE

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

■ Supplied Accessories ■ Mounting the transceiver

The universal mounting bracket supplied with your transceiv­er allows overhead mounting.

•Mount the transceiver securely with the 4 supplied screws
to a thick surface which can support more than 1.5 kg.

Flat washer

Felt*

Spring washer

When using
self-tapping screws

Felt*

*Felts reduce the vibration effects.

Microphone

Microphone hanger
and screw set

Microphone
hanger cable

DC power cable Sponges*

2

Mounting bracket
and felts

Flat washers

Spring washers

Bracket bolts

Mounting screws
(M5×12)

Self-tapping screws
(M5×16)

Nuts

Function name
stickers*

1

Felts are already
attached.

*

2

Used for labelling the programmable
function keys according to their assin­ged functions.
Used for the optional unit installation.
Ask your dealer for details.

*

1

15

3

CONNECTION AND MAINTENANCE

■ Antenna

A key element in the performance of any communication sys­tem is an antenna. Contact your dealer about antennas and
the best places to mount them.

■ Fuse replacement

A fuse is installed in each fuse holder of the supplied DC
power cable. If a fuse blows or the transceiver stops func­tioning, track down the source of the problem if possible, and
replace the damaged fuse with a new rated one.

❑ Fuse rating: 10 A

USE the 10 A fuse only.

■ Cleaning

If the transceiver becomes dusty or dirty, wipe it clean with a
soft and dry cloth.

AVOID the use of solvents such as benzene or
alcohol, as they may damage the transceiver sur­faces.

■ Options

• RMK-3

SEPARATION KIT

+ OPC-609

SEPARATION CABLE

Allows you to install the transceiver main unit separately
from the front panel for operating convenience.

• SP-5/SP-10/SP-22

EXTERNAL SPEAKERS

Input impedance : 4 Ω

Max. input power : 5 W
SP-5 : Large speaker for good audio quality.
SP-10 : For all-round mobile operation.
SP-22 : Compact and easy-to-install.

• HM-152/HM-152T/HM-148

HAND MICROPHONES

HM-152 : Hand microphone
HM-152T : DTMF microphone
HM-148 : Heavy duty microphone

• SM-25

DESKTOP MICROPHONE

• UT-109R/UT-110R

SCRAMBLER UNITS

Non-rolling type (UT-109R)/Rolling type (UT-110R) voice
scrambler unit provides higher communication security.

• UT-96R

5

TONE UNIT

Some options may not available in some countries. Ask your dealer
for details.

16

4

DOC

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

CE Versions of the IC-F5062 and IC-F6062
which display the “CE” symbol on the serial
number seal, comply with the essential require­ments of the European Radio and
Telecommunication Terminal Directive
1999/5/EC.

This warning symbol indicates that this equipment
operates in non-harmonised frequency bands
and/or may be subject to licensing conditions in the
country of use. Be sure to check that you have the
correct version of this radio or the correct pro­gramming of this radio, to comply with national
licensing requirement.

DECLARATION

OF CONFORMITY

We Icom Inc. Japan

1-1-32, Kamiminami, Hirano-ku
Osaka 547-0003, Japan

Kind of equipment:

VHF TRANSCEIVER

Type-designation: iC-

f5062

Signature

Authorized representative name

Place and date of issue

Declare on our sole responsibility that this equipment complies with the
essential requirements of the Radio and Telecommunications Terminal
Equipment Directive, 1999/5/EC, and that any applicable Essential Test
Suite measurements have been performed.

Version (where applicable):

This compliance is based on conformity with the following harmonised
standards, specifications or documents:

i) EN 60950-1 2001
ii) EN 301 489-1 v1.4.1 (August 2002)
iii) EN 301 489-5 v1.3.1 (August 2002)
iv) EN 300 086-2 (March 2001)
v) EN 300 219-2 (March 2001)
vi) EN 300 113-2 (April 2002)

H. Ikegami
General Manager

10th Jan 2007

0168

136–174 MHz 12.5 KHz/25 KHz
136–174 MHz 12.5 KHz/20 KHz

17

4

DOC

DECLARATION

OF CONFORMITY

We Icom Inc. Japan

1-1-32, Kamiminami, Hirano-ku
Osaka 547-0003, Japan

Kind of equipment:

UHF TRANSCEIVER

Type-designation: iC-

f6062

Signature

Authorized representative name

Place and date of issue

Declare on our sole responsibility that this equipment complies with the
essential requirements of the Radio and Telecommunications Terminal
Equipment Directive, 1999/5/EC, and that any applicable Essential Test
Suite measurements have been performed.

Version (where applicable):

This compliance is based on conformity with the following harmonised
standards, specifications or documents:

i) EN 60950-1 2001
ii) EN 301 489-1 v1.4.1 (August 2002)
iii) EN 301 489-5 v1.3.1 (August 2002)
iv) EN 300 086-2 (March 2001)
v) EN 300 219-2 (March 2001)
vi) EN 300 113-2 (April 2002)

H. Ikegami
General Manager

9th Feb. 2007

0168

400–470 MHz 12.5 KHz/25 KHz
400–470 MHz 12.5 KHz/20 KHz

About e-marking: Detailed installation notes for Icom
mobile transceivers to be fitted into vehicles are available.
Please contact your Icom dealer or distributor.

MEMO

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

MEMO

MEMO

1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan

< Intended Country of Use >

GER
AUT
GBR
IRL
NOR

FRA
NED
BEL
LUX

ESP
POR
ITA
GRE

SWE
DEN
FIN
SUI

A-6566D-1EU-q
Printed in Japan
© 2007 Icom Inc.

Printed on recycled paper with soy ink.
