Icom IC-F21GM User Manual

INSTRUCTION MANUAL

UHF GMRS TRANSCEIVER

iF21GM

This device complies with Part 15 of the FCC rules. Oper­ation is subject to the following two conditions: (1) This de­vice may not cause harmful interference, and (2) this
device must accept any interference received, including in­terference that may cause undesired operation.

i

Your Icom radio generates RF electromagnetic
energy during transmit mode. This radio is de­signed for and classified as “Occupational Use
Only”, meaning it must be used only during the
course of employment by individuals aware of the

hazards, and the ways to minimize such hazards.
This radio is NOT intended for use by the “General Popula­tion” in an uncontrolled environment.

This radio has been tested and complies with the FCC RF expo­sure limits for “Occupational Use Only”. In addition, your Icom radio
complies with the following Standards and Guidelines with regard to
RF energy and electromagnetic energy levels and evaluation of
such levels for exposure to humans:

• FCC OET Bulletin 65 Edition 97-01 Supplement C, Evaluating
Compliance with FCC Guidelines for Human Exposure to Radio
Frequency Electromagnetic Fields.

• American National Standards Institute (C95.1 – 1992), IEEE Stan­dard for Safety Levels with Respect to Human Exposure to Radio
Frequency Electromagnetic Fields, 3 kHz to 300 GHz.

• American National Standards Institute (C95.3 – 1992), IEEE Rec­ommended Practice for the Measurement of Potentially Hazardous
Electromagnetic Fields – RF and Microwave.

To ensure that your exposure to RF electromag­netic energy is within the FCC allowable limits for
occupational use, always adhere to the following
guidelines:

• DO NOT operate the radio without a proper antenna attached, as
this may damage the radio and may also cause you to exceed FCC
RF exposure limits. A proper antenna is the antenna supplied with

WARNING

CAUTION

SAFETY TRAINING INFORMATION

ii

this radio by the manufacturer or an antenna specifically authorized
by the manufacturer for use with this radio.

• DO NOT transmit for more than 50% of total radio use time (

“

50%
duty cycle”). Transmitting more than 50% of the time can cause
FCC RF exposure compliance requirements to be exceeded. The
radio is transmitting when the “TX indicator” lights red. You can
cause the radio to transmit by pressing the “PTT” switch.

• ALWAYS use Icom authorized accessories (antennas, batteries,
belt clips, speaker/mics, etc). Use of unauthorized accessories can
cause the FCC RF exposure compliance requirements to be ex­ceeded.

• ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the
body when transmitting and only use the Icom belt-clips, listed in p. 22,
when attaching the radio to your belt, etc., to ensure FCC RF ex­posure compliance requirements are not exceeded. To provide the
recipients of your transmission the best sound quality, hold the an­tenna at least 5 cm (2 inches) from your mouth, and slightly off to
one side.

The information listed above provides the user with the information
needed to make him or her aware of RF exposure, and what to do to
assure that this radio operates within the FCC RF exposure limits of this
radio.

Electromagnetic Interference/Compatibility

During transmissions, your Icom radio generates RF energy that
can possibly cause interference with other devices or systems. To
avoid such interference, turn off the radio in areas where signs are
posted to do so. DO NOT operate the transmitter in areas that are
sensitive to electromagnetic radiation such as hospitals, aircraft,
and blasting sites.

iii

Your Icom F21GM operates on GMRS frequencies (Plus 7
channels shared with FRS ).

GENERAL MOBILE RADIO SERVICE (GMRS)

GMRS is a two-way personal radio service available to an individual
(one man or one woman) to facilitate the activities of the individ­ual's immediate family members. GMRS is not authorized for busi­ness uses.

Users must cooperate in the selection and use of channels to make
the most effective use of them and reduce the possibility of inter­ference. Channel 9 –15 are shared with FRS channels. You can
communicate with any FRS radios on these 7 channels. FRS is a
UHF two-way voice communication service for family, friends and
associates to communicate among themselves within their neigh­bourhood and while on group outings. Eight GMRS channels are
authorized for repeater operation*.

You must obtain a license for a GMRS system. Application is made
on FCC Form 605 or on line at http://www.fcc.gov/wtb/uls. As of
January, 2001, the license fee is $85 for a 5-year term. Schedule F
of the form permits immediate temporary operation during the ap­plication process. Form 605 and Form 159 remittance fee advice
are available for downloading at http://www.fcc.gov/formpage.html.

Applications may be mailed to Federal Communications Commis­sion, Wireless Bureau Applications, PO Box 358245, Pittsburgh, PA
15251-5245

Call 1-800-418 FORM to have the forms mailed to you, or call 1­202-418-0177 from your fax machine to have them faxed to you on
the FCC Fax-On-Demand system. For assistance completing the
forms call 1-800-CALL-FCC.

*Repeater use may require a subscription.

iv

v

FOREWORD

Thank you for purchasing the IC-F21GM FM transceiver.
READ ALL INSTRUCTIONS carefully and completely before using
the transceiver.

SAVE THIS INSTRUCTION MANUAL–This instruction manual
contains important operating instructions for the transceiver.

IMPORTANT

R CAUTION! NEVER hold the transceiver so that the antenna is
very close to, or touching exposed parts of the body, especially the
face or eyes, while transmitting. The transceiver will perform best if
the microphone is 2 to 4 in. (5 to 10 cm) away from the lips and the
transceiver is vertical.

R CAUTION! NEVER operate the transceiver with a headset or
other audio accessories at high volume levels.

R CAUTION! NEVER short the terminals of the battery pack.

DO NOT push the PTT when not actually desiring to transmit.

AVOID using or placing the transceiver in direct sunlight or in areas

with temperatures below –22°F (–30°C) or above +140°F (+60°C).

DO NOT modify the transceiver for any reason.

KEEP the transceiver from the heavy rain, and Never immerse it in

water. The transceiver construction is water resistant, not water­proof.

The use of non-Icom battery packs/chargers may impair transceiver
performance and invalidate the warranty.

FCC caution: Changes or modifications to this transceiver, not
expressly approved by Icom Inc., could void your authority to op­erate this transceiver under FCC regulations.

vi

TABLE OF CONTENTS

SAFETY TRAINING INFORMATION . . . . . . . . . . . . . . . . . . . .i-ii

ABOUT GMRS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii

FOREWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v

IMPORTANT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v

TABLE OF CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vi

1 PANEL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . .1–3

‘ Switches, controls, keys and connectors . . . . . . . . . . . .1–2

‘ LED indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

2 ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

3 BATTERY PACKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–11

‘ Battery pack replacement . . . . . . . . . . . . . . . . . . . . . . . . .5

‘ Battery cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

‘ Battery charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-9

‘ Charging NOTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

‘ Battery case (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . .11

44 SSEETT MMOODDEE .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..

12-19

‘ Set mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

5 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20-22

‘ Receiving and transmitting . . . . . . . . . . . . . . . . . . . . . . .20

‘ Setting squelch level . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

‘ Auto scan function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

‘ Wide/Narrow selection . . . . . . . . . . . . . . . . . . . . . . . . . . .22

6 OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23-24

Icom, Icom Inc. and the logo are registered trademarks of
Icom Incorporated (Japan) in the United states, the United King­dom, Germany, France, Spain, Russia and/or other countries.

1

PANEL DESCRIPTION

1

‘‘

Switches, controls, keys and
connectors

y

u

Speaker

Mic

w

e

r

t

q

i

SP

MIC

CH1↔CH16

Mic UP

Mic A

Mic Down

Mic B

• HM-75A (OPTION)

Mic Up Push and hold to open the noise/tone squelch.

Mic Down Same as [W/N] key. (p. 22)

Mic A Push to start/stop scan function. (P. 22)

Mic B Push several times to select output power; Low1,

Low2 and High. (p. 13)

2

1

PANEL DESCRIPTION

q CHANNEL SELECTOR/SW [CH] (p. 14)

Turn to select CH1 to CH16.

w VOLUME CONTROL [OFF/VOL]

Turns power ON and adjusts the audio level.

e MONITOR (Audi) key [MONI] (p. 21)

• Push and hold to open the noise/tone squelch.

• Push to turn the noise/tone squelch ON.

r PTT SWITCH [PTT]

Push and hold to transmit; release to receive.

t WIDE/NARROW KEY [W/N] (p. 22)

• Push to select Wide FM mode.

• Push and hold to select Narrow FM mode.

y ANTENNA CONNECTOR

Connects the supplied antenna.

u TX/RX INDICATOR LED (p. 3)

• Lights red while transmitting.

• Lights green while receiving a signal, or squelch is open.

i [SP]/[MIC] JACK

Connects optional speaker-microphone.

DD

HM-75A Speaker Microphone key reference (OPTION)*

*These functions are available when the optional Speaker/Mic. is con-

nected.

‘‘

LED indicator

The TX/RX indicator LED indicates informa­tion in several ways as follows;
(Ref.; R=Red, G=Green)

PANEL DESCRIPTION

1

3

R R R R

R R

R R R R

R R

G

R

G

GG

• TX: Turns Red while transmitting a signal.

• RX: Turns Green while receiving a signal.

• Low BATT1: You should charge the battery. (blinks slowly)

• Low BATT2: You must charge the battery. (blinks fast)

• TX low BATT1: Low BATT1 was detected during TX mode.

• TX low BATT2: Low BATT2 was detected during TX mode.

CAUTION:

• Low BATT3: If you did not charge the battery after Low BATT2
warning has appeared, the Low BATT3 warning beep emits for 15
sec. then the power turns OFF automatically.

• Auto scan: LED blinks during scan operation. (p. 22)

2

ACCESSORIES

4

‘‘

Accessory attachment

D Supplied accessories

The transceiver comes supplied with the following accessories.

q Flexible antenna
w Belt clip

D Antenna

The antenna screws onto the transceiver as
illustrated at right.

D Belt clip

Attach the belt clip to the transceiver as illustrated below.

q

w

5

3

BATTERY PACKS

‘‘

Battery pack replacement

Before replacing the battery pack, the volume control MUST be ro­tated fully counterclockwise,
until a click is heard, to turn the
power OFF.

• Push the battery release for­ward, then pull the battery
pack upward with the trans­ceiver facing you.

DD

BATTERY PACKS

*1Operating periods are calculated under the following conditions;

Tx : Rx : standby =5 : 5 : 90
*1Operating period depends on the alkaline cells used. (BP-208 only)
*2Output power is automatically reduced to 1 W to retain sufficient power

in case of an emergency, etc.

*3Operating period measured with the 2 W model.

yrettaB

kcap

egatloV yticapaC

doirepgnigrahC

gnitarepO

*doirep

1

BC-146

BP-208*

2

AArofesacyretta

B

)6R( × enilakla6

902-PB V2.7srh21srh5.1srh8

012-PB V2.7

0561

hAm

18.5 hrs srh0.2srh11

1100

mAh

BP-222*

3

V2.7

006

hAm

rh1

hrs

5.5*

3

6.5 hrs

BC-144,

BC-119 or

BC-121

6

3

BATTERY PACKS

‘‘

Battery cautions

• CAUTION! NEVER short the terminals of the battery pack (or
charging terminals of the transceiver). Also, current may flow into
nearby metal objects such as a necklace, so be careful when plac­ing battery packs (or the transceiver) in handbags, etc.

Simply carrying with or placing near metal objects such as a neck­lace, etc. causes shorting. This will damage not only the battery
pack, but also the transceiver.

• NEVER incinerate used battery packs. Internal battery gas may

cause an explosion.

• NEVER immerse the battery pack in water. If the battery pack be-

comes wet, be sure to wipe it dry BEFORE attaching it to the
transceiver.

• Clean the battery terminals to avoid rust or miss contact.

• Keep battery contacts clean. It’s a good idea to clean battery ter-

minals once a week.

If your battery pack seems to have no capacity even after being
charged, completely discharge them, then fully charge the battery
pack again. If the battery pack still does not retain a charge (or only
very little charge), a new battery pack must be purchased.

DD

Recycling information (U.S.A. only)

The battery (BP-209, BP-210 or BP-222) that you
have purchased is recyclable. At the end of its life,
under various state and local laws, it may be illegal
to dispose of this battery into the municipal waste
stream. Call 1-800-822-8837 for battery recycling
options in your area or contact your dealer.

7

3

BATTERY PACKS

‘‘

Battery charging

D Rapid charging with the BC-144+AD-99

The optional BC-144 provides rapid charging of optional battery
packs.
The following are additionally required:

• One AD-99 (depends on version.).

• An AC adaptor (may be supplied with the BC-144 depending on

version).

AC adaptor
BC-145A/E/V/UK

BP-209, BP-210

or BP-222 only

Charging indicator

Check orientation.

8

3

BATTERY PACKS

D Rapid charging with the BC-144+AD-99

DD

Spacer combination.

• Be sure to attach the

spacer (Spacer B/C) to
the adaptor (Spacer A)
with the orientation as il­lustrated in the diagram at
right.

• Attach the spacer

(Spacer B/C) to the adap­tor with the orientation of the stamp “” pointing up.

NOTE: Push the notch carefully
when removing the spacer from the
adaptor.

Turn power OFF

BP-209, BP-210

or BP-222 attached

to the transceiver.

AC adaptor
BC-145A/E/V/UK

Charging indicator

Check orientation

and

Spacer A

Spacer B/C

Check orientation
and the spacer com­bination as follows.

9

3

BATTERY PACKS

D Rapid charging with the BC-121+AD-94 (#11)

The optional BC-121 allows up to 6 battery packs to be charged si­multaneously. The following are additionally required.

• Six AD-94 (#11) (Some versions require additional AD-99s).

• An AC adaptor (may be supplied with the BC-121 depending on

version).

D Regular charging with the BC-146

The optional BC-146 pro­vides regular charging of
optional battery pack with/
without transceiver.
The following is additionally
required:

• An optional AC adaptor.

(A charging spacer is sup­plied with BC-146.)

MULTI-CHARGER

AC adapter
(purchased
separately)

Charge indicator
(each indicator functions independently)

Turn power OFF.

AD-99

Check orientation
for correct charg­ing.

(Insert togeth­er with charging
adapter.)

Turn power OFF.

BC-146

10

3

BATTERY PACKS

‘‘

Charging NOTE

Prior to using the transceiver for the first time, the battery pack must
be fully charged for optimum life and operation.

• Recommended temperature range for charging:
+10°C to +40°C (50°F to 140°F).

• Use the supplied charger or optional charger (BC-119/BC-121/BC­144 for rapid charging, BC-146 for regular charging) only. NEVER
use other manufacturers’ chargers.

The optional BP-209, BP-210 or BP-222 battery packs include
rechargeable Ni-Cd(Ni-MH: BP-210) batteries and can be charged
approx. 300 times. Charge the battery pack before first operating
the transceiver or when the battery pack becomes exhausted.
If you want to charge the battery pack more than 300 times, the fol­lowing points should be observed:

• Avoid overcharging–batteries must be removed from the charger
to stop charging. Batteries should not be charged for more than
15 hours after the LED indicator turns green.

• Use the battery until it becomes almost completely exhausted
under normal conditions.

DD

Battery pack life

When the operating period becomes extremely short even after
charging the battery pack fully, a new battery pack is needed.

NOTE: The charger rapidly charges a battery pack to a speci­fied level, not a completed level, to prevent overcharging. Leave
the battery pack in the charger for a few more hours (up to
15 hours; depending on battery condition) after the LED indica­tor turns green, to charge the battery completely.

‘‘

Battery case (Option)

When using a BP-208 OPTIONAL BATTERY CASE attached to the
transceiver, install 6 AA (R6) size alkaline batteries as illustrated
below.

NOTE: Output power is automatically reduced to 1 W to retain suffi-

cient power in case of an emergency, etc.

DD

CAUTIONS

• Use ALKALINE batteries only.

• Make sure all battery cells are the same brand, type and ca-

pacity.

• Never mix old and new batteries.
Either of the above may cause a fire hazard or damage the
transceiver, if ignored.

• Never incinerate used battery cells since internal battery gas
may cause them to rupture.

• Never expose a detached battery case to water.
If the battery case gets wet, be sure to wipe it dry before using
it.

11

3

BATTERY PACKS

12

4

SET MODE

‘‘

Set mode

Set mode is used for programming infrequently changed values or
conditions of functions.

• All settings performed with [CH selector], [OFF/VOL], [MONI],
[PTT] and [W/N] keys.

DD

SELECTING RF OUTPUT
POWER

The RF output can be selected
from one of 3 modes. (p. 13)

DD

SETTING THE SIMPLEX/DU­PLEX OPERATION

The Simplex/Duplex function
changes duplex operation to sim­plex operation. (pgs. 13–14)

DD

SETTING THE CTCSS TONE
FREQUENCY

CTCSS (Continuous Tone Coded Squelch System) encoder/decoder
are standard, providing quiet stand-by. (pgs. 15–16)

DD

CTCSS FIND

This transceiver can detect the CTCSS tone frequency in the re­ceived signal. (p. 19)

DD

SETTING THE DTCS CODE

DTCS (Digital Tone Coded Squelch system) encoder/decoder are
standard, providing quiet stand-by. (pgs. 17–18)

[MONI]

[PTT]

[W/N]

[OFF
/VOL]

[CH selector]

13

2

CHAPTER CONTINUED

DD

SELECTING RF OUTPUT POWER

The transceiver has 3 output power levels to suit your operating re­quirements. Low out put power settings during short-distance com­munications may reduce the possibility of interference to other
stations, and will reduce current consumption.

q While pushing and holding [PTT], [MONI], turn [OFF/VOL] to

power ON.

w Push [MONI] to toggle between Low1 (1 W ; Pi), Low2 (2 W ;

PiPi) and High (4 W ; PiPiPi).

e Turn the power OFF, and then ON again.

DD

SETTING THE SIMPLEX/DUPLEX OPERATION

The Simplex/Duplex function changes duplex channels to simplex
channels.

q While pushing and holding [PTT], [MONI], turn [OFF/VOL] to

power ON.

w Turn CH selector knob to select the desired channel.
e Push [W/N] to turn the simplex mode ON.

• A beep (Pi) is emitted.

or
e Push and hold [W/N] to turn the duplex mode ON.

• A long beep (Pii) is emitted.

r Turn the power OFF, and then ON again.

NOTE: Duplex mode is available between CH 1 to CH 8. (see
right.)

14

2

CHAPTER CONTINUED

No.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

Rx/Tx Freq.*

1

462.5500

462.5750

462.6000

462.6250

462.6500

462.6750

462.7000

462.7250

462.5625

462.5875

462.6125

462.6375

462.6625

462.6875

462.7125

Auto Scan

Wide/Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

Narrow

------

Note

White

Black

Orange

• Frequency channel list

*1: Simplex operation/Duplex receive frequency
*

2

: Duplex transmit frequency

Wide/Narrow: Wide FM/Narrow FM (default)

Tx Freq.*

2

467.5500

467.5750

467.6000

467.6250

467.6500

467.6750

467.7000

467.7250

------

------

------

------

------

------

------

------

(Unit: MHz)

15

4

SET MODE

DD

SETTING THE CTCSS TONE FREQUENCY

This transceiver is equipped with 52 CTCSS codes. (See right.)
CTCSS operation provides communication with silent standby since
you will only receive calls from group members using the same
CTCSS number.
You can assign different numbers to CH 1 to CH 15 independently.

q While pushing and holding [PTT], [MONI], [W/N], turn [OFF/VOL]

to power ON.

w Select the desired CH 1 to CH 15 that you want to assign the

CTCSS tone frequency to.

e Push and hold [MONI] until a beep (Pi) is emitted.
r Push [PTT] the necessary number of times to choose the 10 digit

of the desired channel from the channel list.

t Push [MONI].

• Confirmation beep is emitted. (See p. 17)

y Push [PTT] the necessary number of times to choose the 1 digit

of the desired channel from the frequency list.

u Push [MONI].
i Turn the power OFF, and then ON again.

[Example]

To assign No. 28 as CH1;

q While pushing and holding [PTT], [MONI] and [W/N], turn

[OFF/VOL] to power ON.

w Select the CH 1.
e Push and hold [MONI] until a beep (Pi) is emitted.
r Push [PTT] twice to choose the 10 digit of the desired channel.
t Push [MONI].
y Push [PTT] eight times to choose the 1 digit of the desired chan-

nel.

u Push [MONI].
i Turn the power OFF, and then ON again.

16

4

SET MODE

No.

0

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

Freq.*

OFF

67.0

69.3

71.0

71.9

74.4

77.0

79.7

82.5

85.4

88.5

91.5

94.8

97.4

100.0

103.5

No.

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

Freq.*

107.2

110.9

114.8

118.8

123.0

127.3

131.8

136.5

141.3

146.2

151.4

156.7

159.8

162.2

165.5

167.9

No.

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

No.

48

49

50

51

52

Freq.*

233.6

241.8

250.3

254.1

270.4

Freq.*

171.3

173.8

177.3

179.9

183.5

186.2

189.9

192.8

196.6

199.5

203.5

205.5

210.7

218.1

225.7

229.1

• CTCSS tone code list

(Unit: Hz)

: EIA/TIA standard code (Recommended to use these.)

17

4

SET MODE

DD

SETTING THE CTCSS TONE FREQUENCY (continued)

• CTCSS confirmation beep

●; Single beep
; Long beep

Push [PTT]

no
1 (Once)
2 (Twice)
3 (Third)
4 (Fourth)

Confirmation beep

●

●

●●

●●●

●●●●

Push [PTT]

5 (Fifth)
6 (Sixth)
7 (Seventh)
8 (eighth)
9 (ninth)

Confirmation beep

●●●●●

●

●●

●●●

●●●●

DD

SETTING THE DTCS CODE

This transceiver is equipped with 83 DTCS codes. DTCS operation
provides communication with silent standby since you will only re­ceive calls from group members using the same DTCS number.
You can assign different numbers to CH 1 to CH 15 independently.

q While pushing and holding [PTT], [MONI], [W/N], turn [OFF/VOL]

to power ON.

w Select the desired CH 1 to CH 15 that you want to assign the

DTCS code to.

e Push and hold [W/N] until a beep (Pi) is emitted.
r Push [PTT] the necessary number of times to choose the 100

digit of the desired code number.

t Push [MONI].

• Confirmation beep is emitted. (See p. 17)

y Push [PTT] the necessary number of times to choose the 10 digit

of the desired code number.

u Push [MONI].

• Confirmation beep is emitted. (See p. 17)

i Push [PTT] the necessary number of times to choose the 1 digit

of the desired code number.

o Push [MONI].

• DTCS code list

4

SET MODE

18

023
025
026
031
032
043
047
051
054
065

071
072
073
074

114
115

116
125
131
132

134
143
152
155
156
162
165
172
174
205

223
226
243
244
245
251
261
263
265
271

306
311
315
331
343
346
351
364
365
371

411
412
413
423
431
432
445
464
465
466

734
743
754

631
632
654
662
664
703
712
723
731
732

503
506
516
532
546
565
606
612
624
627

• Confirmation beep is emitted. (See p. 17)

!0 Push [PTT] once more, if you want to use Inverse mode.
!1 Push [MONI] to complete the setting.

•

Confirmation beep is emitted. (See p. 17)

!2 Turn the power OFF, and then ON again.

[Example]

To assign code ‘261 (normal)’ as CH12;

q While pushing and holding [PTT], [MONI], [W/N], turn [OFF/VOL]

to power ON.

w Select CH 12.
e Push and hold [W/N] until a beep (Pi) is emitted.
r Push [PTT] twice to choose the 100 digit of the code number.
t Push [MONI].

•

Confirmation beep is emitted. (See p. 17)

y Push [PTT] six times to choose the 10 digit of the code number.
u Push [MONI].

•

Confirmation beep is emitted. (See p. 17)

i Push [PTT] once to choose the 1 digit of the code number.
o Push [MONI].

•

Confirmation beep is emitted. (See p. 17)

!0 Push [MONI] to complete the setting.

•

Confirmation beep is emitted. (See p. 17)

!1 Turn the power OFF, and then ON again.

19

4

SET MODE

DD

CTCSS FIND

This transceiver can detect the CTCSS tone frequency in the re­ceived signal. By monitoring a signal that is being transmitted from
the other station, you can determine the tone frequency required to
communicate with them.
This function very useful when you are going to communicate with
unknown CTCSS channel number stations. ‘CTCSS FIND’ scans
all of the CTCSS channels, then stops when a tone frequency is
detected.

q While pushing and holding [MONI], [W/N], turn [OFF/VOL] to

power ON.

w Select the desired CH 1 to CH 15 that you want to assign the

CTCSS tone frequency.

e Push and hold [MONI] until a beep (Pi) is emitted.

• ‘

CTCSS FIND’ start to scan the signal.

r ‘CTCSS FIND’ stops when the tone signal is detected.
t Push [MONI] to determine the tone number.
y Turn the power OFF, and then ON again.

20

5

OPERATION

‘‘

Receiving and transmitting

NOTE: Transmitting without an antenna may damage the trans-

ceiver. See p.4 for antenna attachment.
Turn power ON as described on p. 2.

Program the SIMPLEX/DUPLEX OPERATION and CTCSS
/DTCS tone number (select CH 0 if you will not use the CTCSS
function) before operation.

Receiving:

q Select the desired channel.
w Listen for a transmission and adjust [VOL] to a comfortable lis-

tening level.

• When no transmission is heard, push and hold [MONI] while
adjusting [VOL].

The transceiver is now set to receive desired calls on the selected
channel.

Transmitting:

Wait for the channel to become clear to avoid interference.
e While pushing and holding [PTT], speak into the microphone at a

normal voice level.

r Release [PTT] to return to receive.

IMPORTANT: To maximize the readability of your transmitted sig­nal, pause a few sec. after pushing [PTT], hold the microphone 10
to 15 cm from your mouth and speak at a normal voice level.

OPERATION

21

5

DD

MONITOR AUDIBLE FUNCTION

The monitor function allows you to open the transceiver’s squelch
manually to check whether a channel is busy or not. The trans­ceiver has 2 conditions for receive standby:

Audible condition:

This condition mutes audio ONLY when
no carrier is present. You can receive (or
monitor) any signals on a channel.

• Push and hold the [MONI], switch to se­lect the audible condition.

Any audio mute functions are cancelled
while pushing the [MONI] switch.

Inaudible condition:

This condition mutes ALL signals except
those directed to you. Therefore you
should check a channel’s condition (busy
or not) with the monitor function before
transmitting.

• Push the [MONI] switch momentarily to

select the inaudible condition.

DD

TIME-OUT TIMER

After continuous transmission for a pre-programmed period, the
time-out timer is activated, causing the transceiver to stop transmit­ting and automatically selects receive.

• The time-out timer function is automatically turned ON when 3
min. has passed.

DD

POWER SAVE FUNCTION

The power save function reduces the current drain to conserve bat­tery power.

• The power save function is automatically turned ON when no
operation is performed or no signal is received for 5 sec.

All signals are
received

Only signals con­taining the proper
tone are received

22

5

OPERATION

‘‘

Setting squelch level

The squelch circuit mutes the received audio signal depending on
the signal strength. Scan proceeds in sequence from lower channel
to higher channel numbers.

q While pushing [PTT] and [W/N], turn the transceiver’s power on

to enter the squelch adjustment mode.

w Push [MONI] to increase the squelch level (tight squelch) or

[W/N] to decrease the squelch level (loose squelch).

• Squelch level will be fixed after 1 sec.

‘‘

Auto scan function

Auto scan function proceeds in sequence from lower channel to
higher channel numbers. Scanning searches for signals automati­cally and makes it easier to locate new stations for contact or lis­tening purpose.

q Turn the CH select knob to CH 16. Scan starts automatically.

• When receiving a signal, scan pauses until a signal disappears.

NOTE: You can perform the scan start/stop by optional HM-75A

SPEAKER-MICROPHONE’ [Mic A] key.

‘‘

Wide/Narrow selection

You can easily to toggle between wide FM mode and narrow FM
mode by pushing [W/N] key.

• Push [W/N]: Turns to wide FM mode.

• Pushing and holding [W/N]: Turns to narrow FM mode.

23

6

OPTION

‘‘

Options

DD

BATTERY PACKS

• BP-208 BATTERY CASE
Allows a set of Alkaline batteries to operate the handheld when
charging the rechargeable battery or in emergencies, etc. 6 AA
(R6) cells are required.

• BP-209 Ni-Cd BATTERY PACK

7.2 V/1100 mAh Ni-Cd battery pack, allows more than 8 hours op­eration.

• BP-210 Ni-MH BATTERY PACK

7.2 V/1650 mAh Ni-MH battery pack, allows approx. 11 hours op­eration.

• BP-222 Ni-Cd BATTERY PACK

7.2 V/600 mAh Ni-Cd battery pack, allows approx. 5.5* hours op­eration (Same as supplied with 2 W models).
*When used with 2 W model.

DD

CHARGER

• BC-119 DESKTOP CHARGER + AD-94 (#11)
For rapid charging of battery packs. An AC adaptor is supplied
with the charger. Charging time: 1.5 to 2 hrs.

• BC-121 MULTI-CHARGER + AD-94 (#11)
For rapid charging up to 6 battery packs simultaneously. An AC
adaptor may be supplied depending on version. Six AD-94 ’s
(#11) are necessary. Charging time: 1.5 to 2 hrs.

• AD-99 CHARGER ADAPTOR

• BC-144 DESKTOP CHARGER

For rapid charging of BP-209 (Ni-Cd), BP-210 (Ni-MH) and BP­222 (Ni-Cd).

• BC-146 DESKTOP CHARGER
For regular charging of BP-209 (Ni-Cd), BP-210 (Ni-MH) and BP­222 (Ni-Cd).

24

6

OPTION

DD

OTHER OPTIONS

• HM-46L/HM-75A/HM-131L SPEAKER-MICROPHONES
Combination speaker-microphone that provides convenient oper­ation while hanging the transceiver from your belt.
HM-75A has programmable function key Mic Up, Mic Down, Mic
A, Mic B.
HM-131L has moisture proof construction.

• HS-51 HEAD SET
Allows you hands-free operation. Includes PTT and TOT.

• SP-13 EARPHONE
Provides clear receive audio in noisy environments.

• MB-68 BELT CLIP
Same as that supplied with the transceiver.

• MB-74 BELT CLIP
Exclusive alligator-type belt clip.

• AD-98FSC ANTENNA CONNECTOR ADAPTOR
Allows you to connect a BNC-type antenna.

1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 Japan

A-6023D-1GM-q
Printed in Japan
© 2001 Icom Inc.

Count on us!
