IBM RS/6000 7024 E Service Manual

RS/6000 7024 E Series IBM
Service Guide
SA38-0502-03
Fourth Edition (April 1997)
The following paragraph does not apply to the United Kingdom or any country where such provisions are inconsistent with local law: THIS PUBLICATION IS PROVIDED “AS
IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. The manufacturer may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time, without notice.
It is possible that this publication may contain reference to, or information about, products (machines and programs), programming, or services that are not announced in your country. Such references or information must not be construed to mean that these products, programming, or services will be announced in your country. Any reference to a specific licensed program in this publication is not intended to state or imply that you can use only that licensed program. You can use any functionally equivalent program instead.
Requests for technical information about products should be made to your authorized reseller or marketing representative.
International Business Machines Corporation 1995, 1997. All rights reserved.
Note to U.S. Government Users -- Documentation related to restricted rights -- Use, duplication or disclosure is subject to restrictions set forth is GSA ADP Schedule Contract with IBM Corp.
Contents
Communications Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Federal Communications Commission (FCC) Statement .............. vii
European Union (EU) Statement ............................ viii
International Electrotechnical Commission (IEC) Statement ............ viii
United Kingdom Telecommunications Safety Requirements ............ viii
Avis de conformité aux normes du ministère des Communications du Canada . ix
Canadian Department of Communications Compliance Statement ........ ix
VCCI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Radio Protection for Germany .............................. x
Federal Communications Commission (FCC) Statement .............. xi
European Union (EU) Statement ............................ xi
International Electrotechnical Commission (IEC) Statement ............ xii
United Kingdom Telecommunications Safety Requirements ............ xii
Avis de conformité aux normes du ministère des Communications du Canada . xii
Canadian Department of Communications Compliance Statement ........ xii
VCCI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Radio Protection for Germany ............................. xiv
Safety Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
Electrical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
Laser Safety Information ................................ xvii
About This Book .................................... xix
ISO 9000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xix
Chapter 1. Reference Information . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
System Unit Locations .................................. 1-1
System Board Locations ................................. 1-5
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Power Switch and Indicator LEDs ........................... 1-8
Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Service Inspection Guide ............................... 1-11
Chapter 2. Maintenance Analysis Procedures (MAPs) ............. 2-1
Entry Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Quick Entry MAP ..................................... 2-2
MAP 1020: Problem Determination .......................... 2-7
MAP 1520: Power ................................... 2-12
MAP 1540: Minimum Configuration ......................... 2-18
Preface iii
Chapter 3. Error Code to FRU Index ........................ 3-1
Chapter 4. Loading the System Diagnostics ................... 4-1
Chapter 5. System Management Services ..................... 5-1
Graphical System Management Services ....................... 5-2
Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Text-Based System Management Services Programs ............... 5-11
Select Boot Devices .................................. 5-12
Test the Computer ................................... 5-13
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
ASCII Terminal System Management Services Programs ............ 5-16
Select Boot Devices .................................. 5-17
Test the Computer ................................... 5-18
Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Chapter 6. Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Boot Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Firmware Core . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Virtual Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Password Design Description .............................. 6-6
Firmware Flash Update Design ............................. 6-7
Power On Self Test (POST) .............................. 6-9
Post Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Chapter 7. Removal and Replacement Procedures ............... 7-1
Handling Static–Sensitive Devices ........................... 7-2
Acclimation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
Media Drive in Bays 3 through 8 ............................ 7-9
Diskette Drive and Lower Hard Disk Drive ..................... 7-12
Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Memory Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17
CPU Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-22
Service Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-23
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-25
Fan and Speaker Assembly .............................. 7-27
Operator Panel Display ................................ 7-28
System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-31
Chapter 8. Parts Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
iv Service Guide
Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Appendix A. Firmware Checkpoint Three-Digit Codes ............ A-1
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X-1
Preface v
vi Service Guide
Communications Statements
The following statement applies to this product. The statement for other products intended for use with this product appears in their accompanying manuals.
If Feature Codes 2743, 3615, 6218, 8130 or 8134 are NOT installed, this system complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Federal Communications Commission (FCC) Statement
Note: The
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.Increase the separation between the equipment and receiver.Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult an authorized dealer or service representative for help.
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Proper cables and connectors are available from authorized dealers. Neither the provider nor the manufacturer are responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment.
IBM RS/6000 7024 E Series Server has
been tested and found to
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Responsible Party:
International Business Machines Corporation
Preface vii
Old Orchard Road Armonk, New York 10504 Telephone: (919) 543-2193
European Union (EU) Statement
This product is in conformity with the protection requirements of EU Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. The manufacturer cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of option cards supplied by third parties. Consult with your dealer or sales representative for details on your specific hardware.
This product has been tested and found to comply with the limits for Class B Information Technology Equipment according to CISPR 22 / European Standard EN
55022. The limits for Class B equipment were derived for typical residential environments to provide reasonable protection against interference with licensed communication devices.
International Electrotechnical Commission (IEC) Statement
This product has been designed and built to comply with IEC Standard 950.
United Kingdom Telecommunications Safety Requirements
This equipment is manufactured to the International Safety Standard EN60950 and as such is approved in the UK under the General Approval Number NS/G/1234/J/100003 for indirect connection to the public telecommunication network.
The network adapter interfaces housed within this equipment are approved separately, each one having its own independent approval number. These interface adapters, supplied by the manufacturer, do not use or contain excessive voltages. An excessive voltage is one which exceeds 70.7 V peak ac or 120 V dc. They interface with this equipment using Safe Extra Low Voltages only. In order to maintain the separate (independent) approval of the manufacturer's adapters, it is essential that other optional cards, not supplied by the manufacturer, do not use main voltages or any other excessive voltages. Seek advice from a competent engineer before installing other adapters not supplied by the manufacturer.
viii Service Guide
Avis de conformité aux normes du ministère des Communications du Canada
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur le matériel brouilleur du Canada.
Canadian Department of Communications Compliance Statement
This Class B digital apparatus meets the requirements of the Canadian Interference-Causing Equipment Regulations.
VCCI Statement
The following is a summary of the VCCI Japanese statement in the box above. This equipment is in the Class 2 category (information equipment to be used in a
residential area or an adjacent area thereto) and conforms to the standards set by the Voluntary Control Council For Interference by Data Processing Equipment and Electronic Office Machines aimed at preventing radio interference in such residential area.
When used near a radio or TV receiver, it may become the cause of radio interference.
Read the instructions for correct handling.
Preface ix
Radio Protection for Germany
Dieses Gerät ist berechtigt in Übereinstimmung mit dem deutschen EMVG vom
9.Nov.92 das EG–Konformitätszeichen zu führen. Der Aussteller der Konformitätserklärung ist die IBM Germany. Dieses Gerät erfüllt die Bedingungen der EN 55022 Klasse B.
x Service Guide
If Feature Codes 2743, 3615, 6218, 8130 or 8134 are installed, this system complies with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Federal Communications Commission (FCC) Statement
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Neither the provider nor the manufacturer are responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,and (2) this device must accept any interference received, including interference that may cause undesired operation.
European Union (EU) Statement
This product is in conformity with the protection requirements of EU Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. The manufacturer cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of option cards supplied by third parties. Consult with your dealer or sales representative for details on your specific hardware.
This product has been tested and found to comply with the limits for Class A Information Technology Equipment according to CISPR 22 / European Standard EN
55022. The limits for Class A equipment were derived for commercial and industrial environments to provide reasonable protection against interference with licensed communication equipment.
Preface xi
Attention: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
International Electrotechnical Commission (IEC) Statement
This product has been designed and built to comply with IEC Standard 950.
United Kingdom Telecommunications Safety Requirements
This equipment is manufactured to the International Safety Standard EN60950 and as such is approved in the UK under the General Approval Number NS/G/1234/J/100003 for indirect connection to the public telecommunication network.
The network adapter interfaces housed within this equipment are approved separately, each one having its own independent approval number. These interface adapters, supplied by the manufacturer, do not use or contain excessive voltages. An excessive voltage is one which exceeds 70.7 V peak ac or 120 V dc. They interface with this equipment using Safe Extra Low Voltages only. In order to maintain the separate (independent) approval of the manufacturer's adapters, it is essential that other optional cards, not supplied by the manufacturer, do not use main voltages or any other excessive voltages. Seek advice from a competent engineer before installing other adapters not supplied by the manufacturer.
Avis de conformité aux normes du ministère des Communications du Canada
Cet appareil numérique de la classe A respecte toutes les exigences du Réglement sur le matériel brouilleur du Canada.
Canadian Department of Communications Compliance Statement
This Class A digital apparatus meets the requirements of the Canadian Interference–Causing Equipment Regulations.
xii Service Guide
VCCI Statement
The following is a summary of the VCCI Japanese statement in the box above. This equipment is in the Class 1 category (information equipment to be used in
commercial and/or industrial areas) and conforms to the standards set by the Voluntary Control Council For Interference by Data Processing Equipment and Electronic Office Machines aimed at preventing radio interference in commercial and/or industrial areas.
Consequently, when used in a residential area or in an adjacent area thereto, radio interference may be caused to radios and TV receivers, etc.
Read the instructions for correct handling. VCCI-1.
Preface xiii
Radio Protection for Germany
Dieses Gerät ist berechtigt in Übereinstimmung mit dem deutschen EMVG vom
9.Nov.92 das EG–Konformitätszeichen zu führen. Der Aussteller der Konformitätserklärung ist die IBM Germany. Dieses Gerät erfüllt die Bedingungen der EN 55022 Klasse A. Für diese von
Geräten gilt folgende Bestimmung nach dem EMVG: Geräte dürfen an Orten, für die sie nicht ausreichend entstört sind, nur mit
besonderer Genehmigung des Bundesministers für Post und Telekommunikation oder des Bundesamtes für Post und Telekommunikation betrieben werden. Die Genehmigung wird erteilt, wenn keine elektromagnetischen Störungen zu erwarten sind.
(Auszug aus dem EMVG vom 9.Nov.92, Para.3, Abs.4) Hinweis Dieses Genehmigungsverfahren ist von der Deutschen Bundespost noch nicht
veröffentlicht worden.
xiv Service Guide
Safety Notices
A
danger
death or serious personal injury. A
caution
moderate or minor personal injury.
Electrical Safety
Observe the following safety instructions any time you are connecting or disconnecting devices attached to the workstation.
DANGER
notice indicates the presence of a hazard that has the potential of causing
notice indicates the presence of a hazard that has the potential of causing
An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of the system or the devices that attach to the system. It is the responsibility of the customer to ensure that the outlet is correctly wired and grounded to prevent an electrical shock.
Before installing or removing signal cables, ensure that the power cables for the system unit and all attached devices are unplugged.
When adding or removing any additional devices to or from the system, ensure that the power cables for those devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.
Use one hand, when possible, to connect or disconnect signal cables to prevent a possible shock from touching two surfaces with different electrical potentials.
During an electrical storm, do not connect cables for display stations , printers, telephones, or station protectors for communication lines.
CAUTION: This product is equipped with a three–wire power cable and plug for the user's safety. Use this power cable with a properly grounded electrical outlet to avoid electrical shock.
Preface xv
DANGER
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.
xvi Service Guide
Laser Safety Information
The optical drive in this system unit is a laser product. The optical drive has a label that identifies its classification. The label, located on the drive, is shown below.
CLASS 1 LASER PRODUCT LASER KLASSE 1 LUOKAN 1 LASERLAITE APPAREIL A LASERDE CLASSE1
IEC 825:1984 CENELEC EN 60 825:1991
The optical drive in this system unit is certified in the U.S. to conform to the requirements of the Department of Health and Human Services 21 Code of Federal Regulations (DHHS 21 CFR) Subchapter J for Class 1 laser products. Elsewhere, the drive is certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 (1st edition 1984) and CENELEC EN 60 825:1991 for Class 1 laser products.
CAUTION: A class 3 laser is contained in the device. Do not attempt to operate the drive while it is disassembled. Do not attempt to open the covers of the drive as it is not serviceable and is to be replaced as a unit.
Class 1 laser products are not considered to be hazardous. The optical drive contains internally a Class 3B gallium-arsenide laser that is nominally 30 milliwatts at 830 nanometers. The design incorporates a combination of enclosures, electronics, and redundant interlocks such that there is no exposure to laser radiation above a Class 1 level during normal operation, user maintenance, or servicing conditions.
Preface xvii
xviii Service Guide
About This Book
This book provides maintenance information that is specific to the system unit, adapters, and devices that do not have their own service information. It also contains Manintenance Analysis Procedures (MAPs) that are not common to other systems.
MAPs that are common to all systems are contained in the
Information for Multiple Bus Systems
This book is used by the service technician to repair system failures. This book assumes that the service technician has had training on the system unit.
ISO 9000
ISO 9000 registered quality systems were used in the development and manufacturing of this product.
Related Publications
The following publications are available for purchase:
The
The
The
IBM RS/6000 7024 E Series User's Guide
set up, install options, configure, modify, and solve minor problems.
IBM RS/6000 Diagnostic Information for Multiple Bus Systems
common diagnostic procedures, error codes, service request numbers, and failing function codes. This manual is intended for trained service technicians.
IBM RS/6000 Adapters, Devices, and Cable Information for Multiple Bus
Systems
manual is intended to supplement information found in the
contains information about adapters, external devices, and cabling. This
Diagnostic Information for Multiple Bus Systems
.
contains information to help users
.
IBM RS/6000 Diagnostic
contains
IBM RS/6000
The
Preface xix
Site and Hardware Planning Information
plan your installation.
contains information to help you
xx Service Guide
Chapter 1. Reference Information
System Unit Locations
Front View with Door Open
Chapter 1. Reference Information 1-1
Rear View
1-2 Service Guide
Side View with Covers Removed
Chapter 1. Reference Information 1-3
Recommended SCSI IDs
1-4 Service Guide
System Board Locations
J1 CPU Card Connector J2 through J9 Memory Module (DIMM) Connectors J10 Power Supply (P1 and P2) J12 Power Supply J13 Parallel Port Connector J14 16-bit SCSI Connector (16-bit and 8-Bit SCSI connectors are
mutally exclusive)
J15 8-bit SCSI Connector (8-bit and 16-Bit SCSI connectors are
mutally exclusive)
J17 Diskette Connector J18 Serial Port 1 Connector
Chapter 1. Reference Information 1-5
J19 Serial Port 2 Connector J20 Keyboard Connector J21 Mouse J22 through 27 PCI Adapter Connectors J28 through J30 ISA Adapter Connectors J31 Disk Drive LED Connector J32 Power LED Connector J33 Speaker Connector J34 Fan Connector J38 Power Supply J44 Hardware Service Processor Connector J45 Operator Panel Connector U5 VPD Module
1-6 Service Guide
Specifications
The mechanical packaging, cooling, power supply, and environmental requirements for the server is shown in the following:
Dimensions
Height - 648 mm (25.5 inches) Depth - 450 mm (17.7 inches) Width - 315 mm (12.4 inches)
Weight - Configuration dependent Operating Environment - Class B
Temperature - 16° to 32°C (60° to 90°F) Humidity - 8% to 80% noncondensing Maximum Altitude - 2135 m (7000 feet)
Power Source Loading
0.32 kVA
Power Supply
300 watts
Operating Voltage (Selectable)
100 to 125V ac; 50 to 60 Hz 200 to 240V ac; 50 to 60 Hz
Heat Output (Maximum)
1020 BTU/hr
Chapter 1. Reference Information 1-7
Power Switch and Indicator LEDs
The power switch and light-emitting diodes (LEDs) on the front of your server allow you control power to the server, observe system power status, and observe disk activity.
These features also have other built-in capabilities to assist you in diagnosing system problems and observing system status:
As soon as the system unit is connected to a power source, the power LED will
begin blinking slowly (about 2 flashes per second) to indicate that Standby Power is on, even though the system unit is not powered on or running.
When the system unit is turned on by pressing the power switch, the power LED
lights steadily.
If the operating system is loaded and running, a memory dump of system information can be requested.
To enable this function, the sysdumpdev -K command must be executed before
an error condition exists.
To request a memory dump, press and hold the power switch for longer than two
seconds. Requesting a memory dump directs the operating system to save system information to a predefined file before turning off the system. This feature can be used to assist in recovery from system problems.
1-8 Service Guide
When a memory dump has been requested the power LED will blink quickly
(about 10 flashes per second) to indicate that the dump has been started. This blinking will cease after about a minute whether or not the dump is complete, and the LED will return to its steady, lit state until the system turns off or reboots when the dump is complete.
The memory dump file can be viewed by entering the the operating system
command:
sysdumpdev -L
The disk drive LED lights whenever the hard disk drives within the server are being used.
The disk drive LED also provides basic system diagnostic information:
If no memory can be found as the system boots, the disk drive LED lights and
the system stops the boot process.
If an error is detected in the firmware boot program, this LED lights and the
system stops, and the diskette activity LED begins blinking. This condition indicates that the system is requesting a Firmware Recovery Diskette, which should be made to facilitate resolution of system problems. For instructions on creating a Firmware Recovery Diskette, see Chapter 5, “System Management Services” on page 5-1.
Chapter 1. Reference Information 1-9
Power Cables
To avoid electrical shock, a power cable with a grounded attachment plug is provided. Use only properly grounded outlets.
Power cables used in the United States and Canada are listed by Underwriter's Laboratories (UL) and certified by the Canadian Standards Association (CSA). These power cords consist of:
Electrical cables, Type SVT or SJT.Attachment plugs complying with National Electrical Manufacturers Association
(NEMA) 5-15P. That is:
"For 115 V operation, use a UL listed cable set consisting of a minimum 18 AWG, Type SVT or SJT three-conductor cord a maximum of 15 feet in length and a parallel blade, grounding type attachment plug rated at 15 A, 125 V."
"For 230 V operation in the United States use a UL listed cable set consisting of a minimum 18 AWG, Type SVT or SJT three-conductor cable a maximum of 15 feet in length, and a tandem blade, grounding type attachment plug rated at 15 A, 250 V."
Appliance couplers complying with International Electrotechnical Commission
(IEC) Standard 320, Sheet C13.
Power cables used in other countries consist of the following:
Electrical cables, Type HD21.Attachment plugs approved by the appropriate testing organization for the
specific countries where they are used.
"For units set at 230 V (outside of U.S.): use a cable set consisting of a minimum 18 AWG cable and grounding type attachment plug rated 15 A, 250 V. The cable set should have the appropriate safety approvals for the country in which the equipment will be installed and should be marked HAR'."
1-10 Service Guide
Service Inspection Guide
Perform a service inspection on the system when: The system is inspected for a maintenance agreement.
Service is requested and service has not recently been performed.An alterations and attachments review is performed.Changes have been made to the equipment that may affect the safe operation of
the equipment.
External devices with their own power cables have those cables attached.
If the inspection indicates an unacceptable safety condition, the condition must be corrected before anyone can service the machine.
Note: The correction of any unsafe condition is the responsibility of the owner of the system.
Perform the following checks:
1. Check the covers for sharp edges and for damage or alterations that expose the internal parts of the system unit.
2. Check the covers for proper fit to the system unit. They should be in place and secure.
3. Gently rock the system unit from side to side to determine if it is steady.
4. Set the power switch of the system unit to Off.
5. Remove the covers.
6. Check for alterations or attachments. If there are any, check for obvious safety hazards such as broken wires, sharp edges, or broken insulation.
7. Check the internal cables for damage.
8. Check for dirt, water, and any other contamination within the system unit.
9. Check the voltage label on the back of the system unit to ensure that it matches the voltage at the outlet.
10. Check the external power cable for damage.
11. With the external power cable connected to the system unit, check for 0.1 ohm or less resistance between the ground lug on the external power cable plug and the metal frame.
12. Perform the following checks on each device that has its own power cables:
a. Check for damage to the power cord.
Chapter 1. Reference Information 1-11
b. Check for the correct grounded power cable. c. With the external power cable connected to the device, check for 0.1 ohm or
less resistance between the ground lug on the external power cable the metal frame of the device.
13. Install the covers.
1-12 Service Guide
Chapter 2. Maintenance Analysis Procedures (MAPs)
Entry Map
Use the following table to determine your starting point. Note: When possible, run Online Diagnostics in Service Mode. Online Diagnostics
perform additional functions, compared to Standalone Diagnostics. This will ensure that the error state of the system is captured in NVRAM for your use in fixing the problem. The AIX error log and SMIT are only available when running online diagnostics.
Symptom Starting Point
You have a problem that does not prevent the system from booting.
You do not have a symptom. Go to MAP 0020 in the
You have an SRN. Go to the Fast Path MAP in the
The system stops and a 3-digit number is displayed in the operator panel display.
You have an 8-digit error code. Go to “Quick Entry MAP” on page 2-2. The system will not boot. Go to “Quick Entry MAP” on page 2-2.
Go to the Fast Path MAP in the
Diagnostic Information for Multiple Bus Systems
IBM RS/6000 Diagnostic
Information for Multiple Bus Systems
Diagnostic Information for Multiple Bus Systems
Record SRN 101-xxx, where xxx is the 3-digit number displayed in the operator panel display, then go to the Fast Path MAP in the
Diagnostic Information for Multiple Bus Systems
IBM RS/6000
IBM RS/6000
IBM RS/6000
.
.
.
Chapter 2. Maintenance Analysis Procedures 2-1
Quick Entry MAP
Quick Entry MAP Table of Contents
Problem Description Page No.
Service Actions 2-3 8-Digit Error Codes 2-3 System Stops With an 8-Digit Number Displayed 2-3 There Appears to be a Display Problem (Distortion, Blurring,Etc.) 2-3 Power and Cooling Problems 2-3 Intermittent Memory Problems 2-4 Other Symptoms 2-4 Miscellaneous Problems 2-6 Flashing 888 in Operator Panel Display 2-6
2-2 Service Guide
Symptoms What You Should Do
Service Actions
You have parts to exchange or a corrective action to perform.
1. Go to the
Procedures
2. Go to the
Removal and Replacement
.
Repair Checkout Procedure IBM RS/6000 Diagnostic Information for Multiple Bus Systems
You need to verify that a part exchange or corrective action corrected the problem.
Go to the
IBM RS/6000 Diagnostic Information for Multiple Bus Systems
You need to verify correct system operation. Go to the
Repair Checkout Procedure
.
System Checkout Procedure
.
in the
in the
IBM RS/6000 Diagnostic Information for Multiple Bus Systems
8-Digit Error Codes
You have an 8-Digit Error Code. Look up "8-Digit Error" in Chapter 3, “Error
Code to FRU Index” and do the listed action.
System Stops With a 8-Digit Number Displayed
The system stops with an 8-Digit Error Code displayed when booting.
There Appears to be a Display Problem (Distortion, Blurring, Etc.)
A long beep followed immediately by a short beep is heard.
All other display problems. 1. If using a graphics display, go to the
1. Record the 8-Digit Error Code.
2. Look up "8-Digit Error" in Chapter 3, “Error Code to FRU Index” and do the listed action.
A display adapter problem is indicated.
1. Replace the graphics adapter.
Problem Determination Procedures
display.
2. If you do not find a problem then replace the display adapter.
3. If the problem is with the ASCII terminal go to the for the terminal.
4. If you do not find a problem then replace the system board.
.
for the
Problem Determination Procedures
in the
You cannot power on the system Go to “MAP 1520: Power” on page 2-12. The power light does not come on, or stay on. Go to “MAP 1520: Power” on page 2-12.
Chapter 2. Maintenance Analysis Procedures 2-3
Power and Cooling Problems
Symptoms What You Should Do
Intermittent Memory Problems
"Loop on Memory Test" is provided by SMS. It can be used to test for intermittent memory problems.
Other Symptoms
The system stops with the disk activity indicator LED OFF and no beep occurred.
The system stops with the disk activity indicator LED ON continuously and no beep occurred.
The system stops after issuing one short beep and the disk activity indicator LED is ON.
The disk activity indicator LED is blinking rapidly.
The system stops and POST indicators are displayed.
The system stops and the message "STARTING SOFTWARE PLEASE WAIT..." is displayed.
Refer to Chapter 5, “System Management Services” on page 5-1 for more information.
The processor POST failed or did not execute. There may be a problem with the CPU card or system board.
1. Replace the CPU card. If the problem still exists after replacing the CPU card, go to “MAP 1540: Minimum Configuration” on page 2-18.
No good memory could be found.
1. If there is only one memory module installed, replace it.
2. If there is more than one memory module installed, go to “MAP 1540: Minimum Configuration” on page 2-18.
Less than 3MB of memory tested good.
1. If there is only one memory module installed, replace it.
2. If there is more than one memory module installed, go to “MAP 1540: Minimum Configuration” on page 2-18.
The flash EPROM data is corrupted. The recovery procedure for the flash EPROM should be executed.
1. Use “MAP 1540: Minimum Configuration” on page 2-18 to isolate the problem.
Go to “MAP 1020: Problem Determination” on page 2-7.
2-4 Service Guide
Symptoms What You Should Do
The System Management Services menu is displayed.
The system will not respond to the password being entered or the system login prompt is displayed when booting in service mode.
A short and long beep are heard. However, nothing is displayed.
Only a short beep, disk activity indicator LED is OFF, and no POST indicators are displayed.
The device or media you are attempting to boot from may be faulty.
1. Check the SMS error log for any errors. To check the error log:
Choose tools
Choose error logIf an error is logged, check the time
stamp.
If the error was logged during the
current boot attempt, record it.
Look up the error in Chapter 3, “Error
Code to FRU Index” and do the listed action.
If no recent error is logged in the error
log, continue to the next step below.
2. Try to boot from an alternate boot device connected to the same controller as the original boot device. If the boot succeeds, replace the original boot device (for removable media devices try the media first).
3. Go to “MAP 1540: Minimum Configuration” on page 2-18.
The keyboard or it's controller may be faulty.
1. If entering the password from the keyboard which is attached to the system, replace the keyboard. If replacing the keyboard does not fix the problem, replace the system board.
2. If entering the password from a keyboard which is attached to a ASCII terminal, suspect the ASCII terminal. Use the Problem Determination Procedures for the terminal. Replace the system board if these procedures do not reveal a problem.
1. If using a graphic display, go to the
Determination Procedures
2. If you do not find a problem then replace the display adapter.
3. Go to “MAP 1540: Minimum Configuration” on page 2-18.
Go to “MAP 1540: Minimum Configuration” on page 2-18.
Problem
for the display.
Chapter 2. Maintenance Analysis Procedures 2-5
Symptoms What You Should Do
Miscellaneous Problems
You suspect a cable problem. See the
Cable Information for Multiple Bus Systems
Flashing 888
Flashing 888 in Operator Panel Display Go to the Fast Path MAP in the
IBM RS/6000 Adapters, Devices, and
.
IBM RS/6000
Diagnostic Information for Multiple Bus Systems
You Cannot Find the Symptom in this Table
All other problems. Go to “MAP 1020: Problem Determination” on
page 2-7.
.
2-6 Service Guide
MAP 1020: Problem Determination
Purpose of This MAP
Use this MAP to get a eight-digit error code if you were not provided with one by the customer or you are unable to load diagnostics. If you are able to load the diagnostics, go to MAP 0020 in the
Bus Systems
.
IBM RS/6000 Diagnostic Information for Multiple
Be prepared to record code numbers and use those numbers in the course of analyzing a problem. Go to “Step 1020-1.”
Step 1020-1
The following steps analyze a failure to load the diagnostic programs. Note: You will be asked questions regarding whether the system produced a beep
or beeps. You will also be asked to perform certain actions based on displayed POST indicators. Please be observant of these conditions.
1. Turn the power off.
2. Turn the power on.
3. Insert the diagnostic CD-ROM disc into the CD-ROM drive.
4. If the keyboard POST indicator appears, press F5 on the direct attached keyboard or number 5 on an ASCII terminal.
Chapter 2. Maintenance Analysis Procedures 2-7
5. Enter any requested passwords.
6. Follow displayed instructions until diagnostic operating instructions are displayed or the system appears to stop.
7. Find your symptom in the following table; then follow the instructions given in the Action column.
Symptom Action
The disk activity indicator LED is blinking rapidly.
The system stops with a prompt to enter a password.
The diagnostic operating instructions are displayed.
The power good LED does not come on or does not stay on.
The system stops with an eight-digit error code(s) displayed on the console.
The system login prompt is displayed. You may not have pressed the correct key or
The system unit produces one long beep immediately followed by a short beep.
A continuous beep is heard from the system unit.
A short and long beep are heard. However, nothing is displayed.
The system appears to be stopped, the disk activity indicator LED is OFF and a beep was NOT heard from the system unit.
The flash EPROM data is corrupted. The recovery procedure for the flash EPROM should be executed.
Enter the password. You will not be allowed to continue until a correct password has been entered. When you have entered a valid password go to the beginning of this table and wait for one of the other conditions to occur.
Go to MAP 0020 in the
Information for Multiple Bus Systems
Go to “MAP 1520: Power” on page 2-12.
Record the error code(s), then go to “Step 1020-3” on page 2-10.
you may not have pressed the key soon enough when you were to indicate a Service Mode IPL of the diagnostic programs. If this was the case start over at the beginning of this Step.
Note: Perform the systems shutdown
procedure before turning off the system.
If you are sure you pressed the correct key in a timely manner, go to “Step 1020-2” on page 2-10.
Record error code M0GA0000, then go to “Step 1020-3” on page 2-10.
Record error code M0SPK000, then go to “Step 1020-3” on page 2-10.
1. If using a graphic display, go to the
Determination Procedures
2. If you do not find a problem then replace the display adapter.
3. Go to “MAP 1540: Minimum Configuration” on page 2-18.
Record error code M0CPU000, then go to “Step 1020-3” on page 2-10.
IBM RS/6000 Diagnostic
.
Problem
for the display.
2-8 Service Guide
Symptom Action
Only a short beep, disk activity indicator LED is OFF, and no POST indicators are displayed.
The system appears to be stopped and the disk activity indicator LED is ON continuously and a beep was NOT heard from the system unit.
The system appears to be stopped and the disk activity indicator LED is ON continuously and a beep was heard from the system unit.
The System Management Services menu is displayed.
The system stops and POST indicators are displayed.
The diagnostics are loaded and there was no beep heard from the system unit during the IPL sequence.
The system does not respond when the password is entered.
The system stops and the message "STARTING SOFTWARE PLEASE WAIT..." is displayed or only a cursor is displayed.
The system stopped and a POST indicator is displayed on the system console and an eight-digit error code is not displayed.
Go to “MAP 1540: Minimum Configuration” on page 2-18.
Record error code M0MEM000, then go to “Step 1020-3” on page 2-10.
Record error code M0MEM001, then go to “Step 1020-3” on page 2-10.
Go to “Step 1020-4” on page 2-11.
Go to “MAP 1540: Minimum Configuration” on page 2-18.
Record error code M0SPK001, then go to “Step 1020-3” on page 2-10.
Go to “Step 1020-2” on page 2-10.
Go to “MAP 1540: Minimum Configuration” on page 2-18.
If the POST indicator represents:
a keyboard, record error code M0KBD000.boot disk, record error code M0HD0000.memory, record error code M0MEM002.a diskette drive, record error code
M0FD0000.
SCSI, record error code M0CON000.
Go to “Step 1020-3” on page 2-10.
Chapter 2. Maintenance Analysis Procedures 2-9
Step 1020-2
There is a problem with the keyboard. Find the type of keyboard you are using in the following table; then follow the
instructions given in the Action column.
Keyboard Type Action
Type 101 keyboard (U.S.). Identify by the size of the Enter key. The Enter key is in only one horizontal row of keys.
Type 102 keyboard (W.T.). Identify by the size of the Enter key. The Enter key extends into two horizontal rows.
Kanji-type keyboard. (Identify by the Japanese characters.)
ASCII terminal keyboard Go to the documentation for this type of ASCII
Record error code M0KBD001; then go to “Step 1020-3.”
Record error code M0KBD002; then go to “Step 1020-3.”
Record error code M0KBD003; then go to “Step 1020-3.”
terminal and continue problem determination.
Step 1020-3
Take the following actions:
1. Find the eight-digit error code in Chapter 3, “Error Code to FRU Index” on page 3-1.
Note: If the eight-digit error code is not listed in Chapter 3, “Error Code to FRU Index,” look for it in the following:
Any supplemental service manual for the deviceThe diagnostic problem report screen for additional informationThe Service Hints service aidThe CEREADME file (by using the Service Hints service aid).
2. Perform the action listed.
2-10 Service Guide
Step 1020-4
1. Check the SMS error log for any errors. To check the error log: Choose tools
Choose error logIf an error is logged, check the time stamp.If the error was logged during the current boot attempt, record it.Look up the error in the Error-Code-to FRU Index and do the listed action.If no recent error is logged in the error log, go to “MAP 1540: Minimum
Configuration” on page 2-18.
Chapter 2. Maintenance Analysis Procedures 2-11
MAP 1520: Power
Note: This is not a start of call MAP. Use this Power MAP only if you have been
directed here from a MAP step in the
Multiple Bus Systems
.
This procedure is used to locate power problems in system units. If a problem is detected, this procedure helps you isolate the problem to a failing unit.
Observe the following safety notice during service procedures.
DANGER
An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of the system or the devices that attach to the system. It is the responsibility of the customer to ensure that the outlet is correctly wired and grounded to prevent and electrical shock.
Before installing or removing signal cables, ensure that the power cables for the system unit and all attached devices are unplugged.
When adding or removing any additional devices to or from the system, ensure that the power cables for those devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.
IBM RS/6000 Diagnostic Information for
Use on hand, when possible, to connect or disconnect signal cables to prevent a possible shock from touching two surfaces with different electrical potentials.
During an electrical storm, do not connect cables for display stations, printers, telephones, or station protectors for communication lines.
CAUTION: This product is equipped with a three–wire power cable and plug for the user's safety. Use this power cable with a properly grounded electrical outlet to avoid electrical shock.
DANGER
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.
2-12 Service Guide
Step 1520-1
You may be directed to this MAP for one of these reasons:
1. There is no indication of activity, even when the start/stop switch is pressed. None of the LEDs light and the power supply fan does not turn.
Go to “Step 1520-2.”
2. With the power good LED blinking slowly when the start/stop switch is pressed, the system begins to power on, but the power good LED does not stay on.
Go to “Step 1520-3” on page 2-14.
Step 1520-2
1. Turn the power off.
2. Check that the external power cable to the system unit has continuity.
3. Check that the power outlet has been wired correctly with the correct voltage.
4. Check that the external power cable is plugged into both the system unit and the power outlet.
Did you find a problem? NO Go to “Step 1520-3” on page 2-14. YES Correct the problem. Go to "Map 0410: Repair Checkout" in the
RS/6000 Diagnostic Information for Multiple Bus Systems
Chapter 2. Maintenance Analysis Procedures 2-13
IBM
.
Step 1520-3
Note: Either the power supply, the system board or the start/stop switch is
defective. Check the power supply first.
1. Unplug the power cord from the system. Press and hold the start/stop switch for a few seconds (to discharge the power supply).
2. Connect the power cord to the system.
3. There is a small black and white cable with a 2-pin connector hanging from the main power supply. With a small screwdriver or similar tool, short the two pins together for a few seconds.
Does the system power up while you short the pins? (You will hear the fan and see the power good LED turn on. When you release the short, the system will power down).
NO Replace the power supply and go to “Step 1520-5” on page 2-15. YES Go to “Step 1520-4.”
Step 1520-4
The power supply is working properly. Ensure that the start/stop switch is securely connected to the system board
connector (J37).
Did you find the problem? NO Go to “Step 1520-5” on page 2-15. YES Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
2-14 Service Guide
IBM RS/6000 Diagnostic
.
Step 1520-5
Unplug the start/stop switch connector from J37. Check the operation of the start/stop switch with an Ohm meter. (The switch is normally open and closes when pressed.)
Does the switch operate correctly? NO Replace the start/stop switch (Be sure to connect it to the system board
connector (J37). Go to “Step 1520-6.”
YES Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
IBM RS/6000 Diagnostic
.
Step 1520-6
Turn the power on.
Does the fan in the power supply turn on and the power good LED come on and stay on?
NO Reinstall the original operator panel electronics assembly and go to “Step
1520-7” on page 2-16.
YES Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
IBM RS/6000 Diagnostic
.
Chapter 2. Maintenance Analysis Procedures 2-15
Step 1520-7
1. Turn the power off.
2. Unplug the system unit power cable from the wall outlet.
3. Record the slot numbers of all the ISA and PCI adapters. Label and record the location of any cables attached to the adapters. Remove all the adapters.
4. Remove all the memory modules.
5. Remove the CPU card.
6. Unplug the power cables from all the SCSI devices.
7. Unplug all the fans, except the fan in the power supply.
8. Connect the system unit power cable to the wall outlet.
9. Turn the power on.
Does the fan in the power supply turn on and the power good LED come on and stay on?
NO Replace the system board. Go to "Map 0410: Repair Checkout" in the
IBM RS/6000 Diagnostic Information for Multiple Bus Systems
YES Go to “Step 1520-8” on page 2-17.
.
2-16 Service Guide
Step 1520-8
One of the parts that was removed or unplugged is causing the problem. Install or connect the parts in the following order.
1. CPU card.
2. Memory modules.
3. SCSI devices, lowest bay to highest bay.
4. PCI cards, lowest slot to highest slot.
5. ISA cards, lowest slot to highest slot.
6. Fans. Turn the power on after each part is installed or connected. If the system does not
power on or the power good LED does not stay on, the most recently installed or connected part is causing the failure.
1. Turn the power off.
2. Unplug the system unit power cable from the wall outlet.
3. Install or connect one of the parts in the list.
4. Connect the system unit power cable to the wall outlet.
5. Turn the power on.
Does the fan in the power supply turn on and the power good LED come on and stay on?
NO Replace the last part you installed.
Repeat these steps until all the parts have been installed. If the symptom did not change and all the parts have been replaced, call
your service support person for assistance. If the symptom has changed, check for loose cards, cables, and obvious
problems. If you do not find a problem, return to “Step 1520-1” on page 2-13 in this MAP and follow the instructions for the new symptom.
YES Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
Chapter 2. Maintenance Analysis Procedures 2-17
IBM RS/6000 Diagnostic
.
MAP 1540: Minimum Configuration
Notes:
1. This MAP assumes that a CD-ROM drive is installed and connected to the integrated SCSI adapter, and a Diagnostics CD-ROM disc is available.
2. If a power-on password or privileged-access password is installed, you will be prompted to enter the password before the diagnostic CD-ROM will load.
3. The term "POST indicators" refer to the ICONs (graphic display) or device mnemonics (ASCII terminal) that display while the POST is executing.
Purpose of this MAP
This MAP is used to locate defective FRUs not found by normal diagnostics. For this procedure, diagnostics are run on a minimally-configured system. If a failure is detected on the minimally-configured system, the remaining FRUs are exchanged one at a time until the failing FRU is identified. If a failure is not detected, FRUs are added back until the failure occurs. The failure is then isolated to the failing FRU.
The MAP steps on the following pages instruct you to reduce the system to one or more of the following configurations:
System board, CPU card, 1 memory module.
If no failure is detected, the green power LED will be on and the system will beep twice (one short beep, followed by one long beep up to a minute or more later). Any other response means one of the remaining FRUs is failing.
System board, CPU card, all memory modules and a terminal attached to the S1
port or a keyboard, display, and graphics adapter. If no failure is detected, The power LED will be on and the system will beep
twice (one short, followed by one long beep up to a minute or more later). The SMS screen will be displayed.
System board, CPU card, all memory modules, CD-ROM drive, and a terminal
attached to the S1 port or a keyboard, display, and graphics adapter. If no failure is detected, The power LED will be on and the system will beep
twice (one short, followed by one long beep up to minute or more later). The POST indicators will be displayed. After the CD-ROM loads a screen titled "Please define the System Console" will be displayed. Any other response means one of the remaining FRUs is failing.
2-18 Service Guide
Step 1540-1
1. Ensure that the diagnostics and the operating system are shut down.
2. Turn the power off.
3. Turn the power on.
4. Insert the diagnostic CD-ROM into the CD-ROM drive.
5. When the POST indicators are displayed and before the long beep, press the F5 key (Graphics) or number 5 key (ASCII terminal).
6. Wait until the "Please define the system console" screen is displayed or the system appears to stop.
Is the "Please define the System Console" screen displayed? NO Go to “Step 1540-2” on page 2-20. YES Go to “Step 1540-13” on page 2-30.
Chapter 2. Maintenance Analysis Procedures 2-19
Step 1540-2
1. Turn the power off.
2. Record the slot numbers of the ISA and PCI adapters. Label and record the location of any cables attached to the adapters. Remove all the adapters.
3. Record the slot numbers of the memory modules, and then remove all but one of the memory modules.
4. Remove the service processor (if present).
5. Disconnect the SCSI cable from the SCSI connector on the system board.
6. Disconnect the diskette drive cable from the diskette drive connector on the system board.
7. Disconnect the serial and parallel port cables from the rear of the system unit.
8. Disconnect the keyboard and mouse cables from the rear of the system unit.
9. Turn the power on.
10. Wait until the system beeps twice (one short, followed by one long beep up to a minute or more later) or the system appears to stop.
Did the system beep twice? NO Go to “Step 1540-3” on page 2-21. YES Go to “Step 1540-4” on page 2-22.
2-20 Service Guide
Step 1540-3
One of the FRUs remaining in the system unit is defective. If the disk activity indicator LED is ON, exchange FRU's in this order:
1. System board
2. Memory module
3. CPU card If the disk activity indicator LED is OFF, exchange FRU's in this order:
1. CPU card
2. System board
3. Memory module The system is working correctly if it beeps twice (one short, and a minute or more
later, one long).
1. Turn the power off.
2. Exchange one of the FRUs in the list, based on the order you determined above.
3. Turn the power on.
Did the system beep twice? NO Reinstall the original FRU.
Repeat the FRU replacement steps until the defective FRU is identified or all the FRUs have been exchanged.
If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.
If the symptom has changed, check for loose cards, cables, and obvious problems. If you do not find a problem, return to “Step 1540-1” on page 2-19 in this MAP and follow the instructions for the new symptom.
YES Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
Chapter 2. Maintenance Analysis Procedures 2-21
IBM RS/6000 Diagnostic
.
Step 1540-4
No failure was detected with this configuration.
1. Turn the power off.
2. Install a memory module.
3. Turn the power on.
4. Wait until the system beeps twice or the system appears to stop.
5. The system beeps once (one short).
6. The system does not beep.
Did the system beep twice? NO Go to “Step 1540-5.” YES Repeat this step until all the memory modules are installed and tested.
After all the memory modules are installed and tested, turn the power to off.
Go to “Step 1540-7” on page 2-24.
Step 1540-5
The failure may be caused by the last memory module installed. To isolate the failing FRU, do the following:
1. Turn the power off.
2. Exchange the last memory module installed.
3. Turn the power on.
Did the system beep twice? NO Go to “Step 1540-6” on page 2-23. YES Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
2-22 Service Guide
IBM RS/6000 Diagnostic
.
Step 1540-6
One of the FRUs remaining in the system unit is defective. To test each FRU, exchange the FRUs that have not already been exchanged in the
following order: System board Power supply.
The system is working correctly if it beeps twice (one short, and a minute or more later, one long).
1. Turn the power off.
2. Exchange one of the FRUs in the list.
3. Turn the power on.
Did the system beep twice? NO Reinstall the original FRU.
Repeat this step until the defective FRU is identified or all the FRUs have been exchanged.
If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.
If the symptom has changed, check for loose cards, cables, and obvious problems. If you do not find a problem, return to “Step 1540-1” on page 2-19 in this MAP, and follow the instructions for the new symptom.
YES Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
Chapter 2. Maintenance Analysis Procedures 2-23
IBM RS/6000 Diagnostic
.
Step 1540-7
If you removed a service processor in “Step 1540-2” on page 2-20, continue with this step.
If you did not remove a service processor in “Step 1540-2” on page 2-20, go to “Step 1540-8” on page 2-25.
1. Turn the power off.
2. Install the service processor.
3. Turn the power on.
4. Wait until the system beeps twice or the system appears to stop.
Did the system beep twice? NO Replace the service processor. YES Go to “Step 1540-8” on page 2-25.
2-24 Service Guide
Step 1540-8
1. Turn the power off.
2. Reconnect the system console.
Notes:
a. If a terminal attached to S1 or S2 is the system console, plug the terminal
cable into the S1 or S2 connector on the rear of the system unit.
b. If a display attached to a display adapter is the system console, install the
display adapter and connect the display to it. Plug the keyboard into the keyboard connector on the rear of the system unit.
3. Turn the power on.
4. Wait until the SMS screen is displayed or the system appears to stop.
Is the SMS screen displayed? NO One of the FRUs remaining in the system unit is defective.
In the following order, exchange the FRUs that have not been exchanged:
1. Go to the Problem Determination Procedures (test procedures) for the device attached to the SIO serial port or the display attached to the graphics adapter, and test those devices. If a problem is found, follow the procedures for correcting the problem on that device.
2. Graphics adapter (if installed).
3. Cable (async or graphics).
4. System board. Repeat this step until the defective FRU is identified or all the FRUs have
been exchanged. If the symptom did not change and all the FRUs have been exchanged,
call your service support person for assistance. If the symptom changed, check for loose cards and obvious problems. If
you do not find a problem, return to “Step 1540-1” on page 2-19 and follow the instructions for the new symptom.
YES Go to “Step 1540-9” on page 2-26.
Chapter 2. Maintenance Analysis Procedures 2-25
Step 1540-9
1. Turn the power off.
2. Plug the SCSI cable into the SCSI connector on the system board.
3. Disconnect the signal and power connectors from all the SCSI devices except the CD-ROM drive.
4. Turn the power on.
5. Insert the diagnostic CD-ROM into the CD-ROM drive.
6. After the POST indicators are displayed and before the long beep press the F5 key on a direct attached keyboard or the number 5 key on a ASCII terminal keyboard.
7. Wait until the "Please define the System Console" screen is displayed or the system appears to stop.
Is the "Please define the System Console" screen displayed? NO One of the FRUs remaining in the system unit is defective.
In the following order, exchange the FRUs that have not been exchanged:
1. System board
2. CPU card
3. Last SCSI device connected (CD-ROM drive, tape drive, etc)
4. SCSI cable Repeat this step until the defective FRU is identified or all the FRUs have
been exchanged. If the symptom did not change and all the FRUs have been exchanged
call your service support person for assistance. If the symptom has changed check for loose cards, cables, and obvious
problems. If you do not find a problem return to “Step 1540-1” on page 2-19 in this MAP and follow the instructions for the new symptom.
YES Repeat this step until all the SCSI devices that were attached to the
integrated SCSI adapter are connected and tested. Go to “Step 1540-10” on page 2-27.
2-26 Service Guide
Step 1540-10
The system is working correctly with this configuration. One of the FRUs (adapters) that you removed is probably defective.
1. Turn the power off.
2. Plug the diskette drive cable into the diskette drive connector on the system board.
3. Turn the power on.
4. Insert the diagnostic CD-ROM disc into the CD-ROM drive.
5. After the POST indicators are displayed and before the long beep press the F5 key on a direct attached keyboard or the number 5 key on a ASCII terminal keyboard.
6. Wait until the "Please define the System Console" screen is displayed or the system appears to stop.
Is the "Please define the System Console" screen displayed? NO One of the FRUs remaining in the system is defective.
In the following order, exchange the FRUs that have not been exchanged.
1. Diskette drive
2. Diskette drive cable
3. System board
4. Power supply Repeat this step until the defective FRU is identified or all the FRUs have
been exchanged. If the symptom did not change and all the FRUs have been exchanged,
call your service support person for assistance. If the symptom has changed check for loose cards, cables, and obvious
problems. If you do not find a problem return to “Step 1540-1” on page 2-19 in this MAP and follow the instructions for the new symptom.
YES Go to “Step 1540-11” on page 2-28.
Chapter 2. Maintenance Analysis Procedures 2-27
Step 1540-11
The system is working correctly with this configuration. One of the FRUs (adapters) that you removed is probably defective,
1. Turn the power off.
2. Install a FRU (adapter) and connect any cables and devices that were attached to it.
3. Turn the power on.
4. Insert the diagnostic CD-ROM disc into the CD-ROM drive.
5. After the POST indicators are displayed and before the long beep press the F5 key on a direct attached keyboard or the number 5 key on a ASCII terminal keyboard.
6. Wait until the "Please define the System Console" screen is displayed or the system appears to stop.
Is the "Please define the System Console" screen displayed? NO Go to “Step 1540-12” on page 2-29. YES Repeat this step until all of the FRUs (adapters) are installed. If you have
exchanged all of the FRUs (adapters) and the sympton did not change, go to MAP 0020 in the
Bus Systems
.
IBM RS/6000 Diagnostic Information for Multiple
2-28 Service Guide
Step 1540-12
1. Turn the power off.
2. Starting with the last installed adapter, disconnect one attached device and cable.
3. Turn the power on.
4. Insert the diagnostic CD-ROM disc into the CD-ROM drive.
5. After the POST indicators are displayed and before the long beep press the F5 key on a direct attached keyboard or the number 5 key on a ASCII terminal keyboard.
6. Wait until the "Please define the System Console" screen is displayed or the system appears to stop.
Is the "Please define the System Console" screen displayed? NO Repeat this step until the defective device or cable is identified or all the
devices and cables have been disconnected. If all the devices and cables have been removed, then one of the FRUs
remaining in the system unit is defective. To test each FRU, exchange the FRUs in the following order:
1. Adapter (last one installed)
2. System board
3. Power supply If the symptom did not change and all the FRUs have been exchanged,
call your service support person for assistance. If the symptom has changed check for loose cards, cables, and obvious
problems. If you do not find a problem return to “Step 1540-1” on page 2-19 in this MAP and follow the instructions for the new symptom.
YES The last device or cable that you disconnected is defective.
Exchange the defective device or cable. Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
Chapter 2. Maintenance Analysis Procedures 2-29
IBM RS/6000 Diagnostic
.
Step 1540-13
1. Turn the power off.
2. Record the slot numbers of the ISA and PCI adapters. Label and record the location of any cables attached to the adapters. Remove all the adapters except the display adapter (if installed and the attached display will be the system console).
3. Disconnect any cables that are plugged into connectors S1, S2, P, K, and M on the rear of the system unit.
Note: If a terminal attached to S1 or S2 will be the system console, do not disconnect it. If a display attached to a display adapter will be the system console, do not disconnect the keyboard.
4. Turn the power on.
5. Insert the diagnostic CD-ROM disc into the CD-ROM drive.
6. After the POST indicators are displayed and before the long beep press the F5 key on a direct attached keyboard or the number 5 key on a ASCII terminal keyboard.
7. Wait until the "Please define the System Console" screen is displayed or the system appears to stop.
Is the "Please define the System Console" screen displayed? NO The symptom has changed. Check for loose cards, cables, and obvious
problems. If you do not find a problem return to “Step 1540-1” on page 2-19 in this MAP and follow the instructions for the new symptom.
YES Go to “Step 1540-14” on page 2-31.
2-30 Service Guide
Step 1540-14
1. Follow the instructions on the screen to select the system console.
2. When the DIAGNOSTIC OPERATING INSTRUCTIONS screen is displayed, press Enter.
3. If the terminal type has not been defined, you must use the Initial Terminal option on the FUNCTION SELECTION menu to initialize the AIX operating system environment before you can continue with the diagnostics. This is a separate and different operation than selecting the console display.
4. Select Advanced Diagnostic Routines.
5. When the DIAGNOSTIC MODE SELECTION menu displays, select System Verification.
6. Start with the first item on the list and test all the adapters and devices.
Did you get an SRN? NO Go to “Step 1540-16” on page 2-32. YES Go to “Step 1540-15.”
Step 1540-15
Look at the FRU part numbers associated with the SRN.
Have you exchanged all the FRUs that correspond to the failing function codes?
NO Exchange the FRU with the highest failure percentage that has not been
changed. Repeat this step until all the FRUs associated with the SRN have been
exchanged or diagnostics run with no trouble found. Run diagnostics after each FRU is exchanged.
Go to "Map 0410: Repair Checkout" in the
Information for Multiple Bus Systems
YES If the symptom did not change and all the FRUs have been exchanged,
call your service support person for assistance.
Chapter 2. Maintenance Analysis Procedures 2-31
IBM RS/6000 Diagnostic
.
Step 1540-16
One of the adapters or devices you removed is causing the problem. Install the adapters and devices one at a time to determine the failing adapter or
device. If the adapter you are installing is an ISA adapter, go to the Service Aids to configure it. If the adapter or device you are installing (ISA or PCI) will not configure or causes the system to stop, replace the adapter or device. Test each adapter or device after installing it.
Repeat this step until all the adapters and devices you removed are installed. Go to "MAP 0410: Repair Checkout" in the
Multiple Bus Systems
.
IBM RS/6000 Diagnostic Information for
If the symptom did not change and all the FRUs have been exchanged, call your service support person for assistance.
2-32 Service Guide
Chapter 3. Error Code to FRU Index
The Error Code to FRU Index lists error symptoms and possible causes. The most likely cause is listed first. Use this index to help you decide which FRUs to replace when servicing the system. If you replace FRUs and the problem is still not corrected, go to MAP 0030 in the
Bus Systems
.
Some three digit Fxx codes may appear to the left of the top row on the Liquid Crystal Display(LCD) which is located on the front panel of the system. The intended use of the three digit Fxx codes is to assure the observer that the Firmware is operational after power on, and before information appears on the console display.
If any action is to be taken, it is listed in column two of the following table. If the three digit Fxx code is not in the following table, and an action is still required, go to “MAP 1540: Minimum Configuration” on page 2-18.
See Appendix A, “Firmware Checkpoint Three-Digit Codes” on page A-1 for the complete list of three digit Fxx codes.
Table 3-1. POST Error Codes
Error Code F Code / Description Action / Possible Failing
00010000 An error occurred during the CPU test. CPU card 0001000A Machine check occurred. Go to MAP 1540. 0001500x An error occurred while erasing the system
firmware. Firmware update was not completed.
00016000 F46 Interrupt (IRQ13) stuck high 1. System board; swap old
F47 No system board VPD data. Module
missing or bad CRC.
F49 Environmental condition
40111022/40111082, 5V high/low. EPOW register could not be cleared.
IBM RS/6000 Diagnostic Information for Multiple
FRU
CPU card
VPD module to new system board
2. Service processor, if present
System board; swap old VPD module to new system board
1. Power supply
2. CPU card
3. System board; swap old VPD module to new system board
Chapter 3. Error Code to FRU Index 3-1
Table 3-2. POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
00016000 (continued)
F4A Environmental condition
40111052/401110B2/40111062/401110C2, +-12V high/low. EPOW register could not be cleared.
F4B Environmental condition 40200021.
CPU card over temperature. EPOW register could not be cleared.
F4F Environmental condition
40200031/40200041, system board/memory over temprature. EPOW register could not be cleared.
F51 Environmental condition 40200023.
CPU card critical temperature. EPOW register could not be cleared.
F51 Environmental condition
40200033/40200043, system board/memory critical temperature. EPOW register could not be cleared.
1. Power supply
2. CPU card
3. System board; swap old VPD module to new system board
1. Check for cool air flow obstructions to the system
2. System board; swap old VPD module to new system board
System board; swap old VPD module to new system board
1. Check for cool air flow obstructions to the system
2. Replace CPU card if the problem persists
3. System board; swap old VPD module to new system board
1. Check for cool air flow obstructions to the system
2. System board; swap old VPD module to new system board
3-2 Service Guide
Table 3-3 (Page 1 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
00016000 (continued)
00016010 System VPD access failure 1. System board; swap
00017001 CMOS error was detected due to battery drainage. Replace your battery 00017002 Error was detected in CMOS, CMOS data is gone!
00017003 Power interruption occurred during last Boot
00017006 Tamper Evident is detected or new battery was just
F52 Environmental condition
40210011/40210014, slow/locked fan. EPOW register could not be cleared.
F53 Environmental condition
40210011/40210014, slow/locked fan. EPOW register successfully cleared.
F55 Unsupported EPOW 1. System board; swap old
F56 Environmental condition
40111032/40111092/40111042/401110A2,
3.3V/2.5V high/low. EPOW register could not be cleared.
CMOS not yet initialized if battery just replaced.
Sequence update.
being installed.
1. Room operating temperature
2. System fans
3. System board; swap old VPD module to new system board
1. Fan(s)
2. System board; swap old VPD module to new system board
3. Service processor if present
VPD module to new system board
2. Service processor if present
1. CPU card
2. Power supply
3. System board; swap old VPD module to new system board
4. Service processor if present
old VPD module to new system board
2. If problem persists, swap new VPD module onto new system board; also see step 3)
3. If customer has protected licensed software installed then advise customer to contact all protected software suppliers for a licence update.
Replace battery if you haven't done so.
Update the Boot Sequence again.
Security violation possible.
Chapter 3. Error Code to FRU Index 3-3
Table 3-3 (Page 2 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
00017007 Maximum number of tries was reached!!
Time and Date are logged! Computer is stopping.
00017008 Maximum number of tries was reached!!
Computer is stopping.
00017013 No power on password entered.
Unattended mode can not be set.
00017015 Tamper Evident is detected. Security violation or Bad
00018000 Bad flash image discovered during system start-up CPU card 00020000 An error occurred during the memory test. Use System Management
000210y0 An error occurred during the memory test.
y represents memory module slot number
00031100 The keyboard is in the wrong port. Check keyboard cable and
00031300 Failed to register keyboard interrupt 1. Keyboard
00070000 Service processor POST failure 1. Service processor
00070001 CPU card or power supply failure 1. CPU card
00070006 Slow or stuck fan 1. Fans
00070007 System over temperature 1. Check for cool air flow
Turn machine off and back on, re-enter password
Turn machine off and back on, re-enter password
1. Quit unattended mode
2. Set power-on password
3. Retry operation
CMOS battery.
Services to test the memory.
Memory module slot number y (y = 1 to 8) is bad or unsupported.
connector.
2. System board; swap old VPD module onto new system board.
2. System board; swap old VPD module onto new system board
2. Power supply
2. Service processor, if present
3. System board; swap old VPD module onto new system board
obstructions to the system
2. Replace system board if the problem persists; also swap old VPD module onto new system board
3. CPU card
3-4 Service Guide
Table 3-3 (Page 3 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
00070008 F4F Environmental condition
40200031/40200041, system board/memory over temperature. EPOW register successfully cleared.
F51 Environmental condition
40200033/40200043, system board/memory critical temperature. EPOW register successfully cleared.
00070009 F4B Environmental condition 40200021,
CPU card over temperature. EPOW register successfully cleared.
F51 Environmental condition 40200023,
CPU card critical temperature. EPOW register successfully cleared.
00070010 F48 Environmental condition 40100005. AC
loss eminent.
F4A Environmental condition
40111052/401110B2/40111062/401110C2, +-12V high/low. EPOW register successfully cleared.
1. Check for cool air flow obstructions to the system
2. Replace system board if the problem persists; also swap old VPD module onto new system board
3. Memory
1. Check for cool air flow obstructions to the system
2. Replace system board if the problem persists; also swap old VPD module onto new system board
3. Memory
1. Check for cool air flow obstructions to the system
2. Replace CPU card if the problem persists
3. System board; swap old VPD module onto new system board
1. Check for cool air flow obstructions to the system
2. Replace CPU card if the problem persists
3. System board; swap old VPD module onto new system board
1. Power supply
2. System board; swap old VPD module onto new system board
3. Service processor, if present
1. Power supply
2. System board; swap old VPD module onto new system board
Chapter 3. Error Code to FRU Index 3-5
Table 3-3 (Page 4 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
00070011 Environmental condition 40111022/40111082, 5V
high/low. EPOW register successfully cleared.
00070012 Service processor reports self-test failure 1. Service processor, if
00070013 Bad NVRAM CRC error 1. Battery
00070014 Bad service processor firmware Use service processor
00070015 Bad service processor VPD 1. Service processor, if
00070016 Service processor firmware failure 1. Retry service processor
00070017 Bad or low battery 1. Battery
00070018 EPOW test failure 1. Service processor, if
00070019 Interrupt (IRQ13) test failure 1. System board; swap
1. Power supply
2. CPU card
3. System board; swap old VPD module onto new system board
present
2. System board; swap old VPD module onto new system board
2. System board; swap old VPD module onto new system board
firmware diskette to re-program firmware
present
2. System board; swap old VPD module onto new system board
firmware update
2. Service processor, if present
2. Service processor, if present
3. System board; swap old VPD module onto new system board
present
2. System board; swap old VPD module onto new system board
old VPD module onto new system board
2. Service processor, if present
3-6 Service Guide
Table 3-3 (Page 5 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
0037cyyi SCSI controller interface error.
c = SCSI Controller ID assigned by search order PCI slot 1, 2, integrated controller, PCI slot 3 through last.
Example: #1
1st SCSI controller card in slot 2 = ID 0
Integrated SCSI controller = ID 1
Example: #2
Integrated SCSI controller = ID 0
1st SCSI controller card in slot 3 = ID 1
yy = See Table 3-4 on page 3-16
i = SCSI ID( 0 to 9 or A through F). F normally indicates the controller.
01291000 An error occurred during the L2 Cache tests. CPU Card
1. Ensure that the controller and each device on the SCSI bus is assigned a unique SCSI ID.
2. Ensure SCSI bus terminator is installed properly.
3. Ensure SCSI cable/connector are securely connected and not damaged.
4. SCSI controller or Integrated SCSI Controller on system board as identified by "c" in the error code.
Chapter 3. Error Code to FRU Index 3-7
Table 3-3 (Page 6 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
0208cyyi SCSI device/adapter error.
c = SCSI Controller ID assigned by search order PCI slot 1, 2, integrated controller, PCI slot 3 through last.
Example: #1
1st SCSI controller card in slot 2 = ID 0
Integrated SCSI controller = ID 1
Example: #2
Integrated SCSI controller = ID 0
1st SCSI controller card in slot 3 = ID 1
yy = See Table 3-4 on page 3-16
i = SCSI ID( 0 to 9 or A through F). F normally indicates the controller.
1. Ensure that the controller and each device on the SCSI bus is assigned a unique SCSI ID.
2. Ensure SCSI bus terminator is installed properly.
3. Ensure SCSI cable/connector are securely connected and not damaged.
4. SCSI device as identified by "i".
If the device is not the CD-ROM drive, remove the device. Try loading standalone diagnostics. If the diagnostics load, replace the device identified by "i".
If the device is the CD-ROM drive or the diagnostics will not load with the device identified by "i" removed, remove all devices except the CD-ROM drive. Try loading standalone diagnostics. If the diagnostics load, add the devices back one at a time until the failing device is identified. Check each device by loading standalone diagnostics.
If the diagnostics do not load, replace the CD-ROM drive. If the diagnostics still do not load, then replace the SCSI controller identified by "c".
3-8 Service Guide
Table 3-3 (Page 7 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
0210cyyi SCSI DASD error.
c = SCSI Controller ID assigned by search order PCI slot 1, 2, integrated controller, PCI slot 3 through last.
Example: #1
1st SCSI controller card in slot 2 = ID 0
Integrated SCSI controller = ID 1
Example: #2
Integrated SCSI controller = ID 0
1st SCSI controller card in slot 3 = ID 1
yy = See Table 3-4 on page 3-16
i = SCSI ID( 0 to 9 or A through F). F normally indicates the controller.
0211cyyi SCSI tape error.
c = SCSI Controller ID assigned by search order PCI slot 1, 2, integrated controller, PCI slot 3 through last.
Example: #1
1st SCSI controller card in slot 2 = ID 0
Integrated SCSI controller = ID 1
Example: #2
Integrated SCSI controller = ID 0
1st SCSI controller card in slot 3 = ID 1
yy = See Table 3-4 on page 3-16
i = SCSI ID( 0 to 9 or A through F). F normally indicates the controller.
1. Ensure that the controller and each device on the SCSI bus is assigned a unique SCSI ID.
2. Ensure SCSI bus terminator is installed properly.
3. Ensure SCSI cable/connector are securely connected and not damaged.
4. SCSI Disk Device connected to SCSI adapter "c" and assigned SCSI ID="i".
1. Ensure that the controller and each device on the SCSI bus is assigned a unique SCSI ID.
2. Ensure SCSI bus terminator is installed properly.
3. Ensure SCSI cable/connector are securely connected and not damaged.
4. SCSI Tape Device connected to SCSI adapter "c" and assigned SCSI ID="i".
Chapter 3. Error Code to FRU Index 3-9
Table 3-3 (Page 8 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
0215cyyi SCSI CDROM error.
c = SCSI Controller ID assigned by search order PCI slot 1, 2, integrated controller, PCI slot 3 through last.
Example: #1
1st SCSI controller card in slot 2 = ID 0
Integrated SCSI controller = ID 1
Example: #2
Integrated SCSI controller = ID 0
1st SCSI controller card in slot 3 = ID 1
yy = See Table 3-4 on page 3-16
i = SCSI ID( 0 to 9 or A through F). F normally indicates the controller.
0243025y The Graphics Controller, DAC, Frame Buffer,
Graphics Function test failed.
40100005 A loss of system power detected. Possible main power loss.
40111002 An unknown power problem detected. 1. Power supply
40111022 A high 5.0 voltage reading detected. 1. Power supply
40111032 A high 3.3 voltage reading detected. 1. CPU card
40111042 A high 2.5 voltage reading detected. 1. CPU card
40111052 A high +12 voltage reading detected. 1. Power supply
40111062 A high 12 voltage reading detected. 1. Power supply
40111082 A low 5.0 voltage reading detected. 1. Power supply
1. Ensure that the controller and each device on the SCSI bus is assigned a unique SCSI ID.
2. Ensure SCSI bus terminator is installed properly.
3. Ensure SCSI cable/connector are securely connected and not damaged.
4. SCSI CDROM Device connected to SCSI adapter "c" and assigned SCSI ID="i".
Graphic PCI card in slot y
If not, replace power supply.
2. System board; swap old VPD module to new system board
3. Service processor, if present
2. CPU card
2. Power supply
2. Power supply
2. System board; swap old VPD module to new system board
2. System board; swap old VPD module to new system board
2. CPU card
3-10 Service Guide
Table 3-3 (Page 9 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
40111092 A low 3.3 voltage reading detected. 1. CPU card
2. Power supply
401110A2 A low 2.5 voltage reading detected. 1. CPU card
2. Power supply
401110B2 A low +12 voltage reading detected. 1. Power supply
2. System board; swap old VPD module to new system board
401110C2 A low 12 voltage reading detected. 1. Power supply
2. System board; swap old VPD module to new system board
40200001 An unknown cooling problem detected. Cooling problem; check
system fans.
40200021 A CPU temperature warning detected. Over temperature on CPU
card.
40200023 A critical CPU temperature condition detected. Critical temperature on
CPU card.
40200031 An I/O planar temperature warning detected. Over temperature on
system board.
40200033 A critical I/O planar temperature condition detected. Critical temperature on
system board.
40200041 A memory temperature warning detected. Over temperature on
system board.
40200043 A critical memory temperature condition detected. Critical temperature on
system board.
40210011 A slow fan detected. Check:
1. Room operating temperature
2. System fans
40210014 A stopped fan detected. Failing fan.
Chapter 3. Error Code to FRU Index 3-11
Table 3-3 (Page 10 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
40A00000 System firmware IPL failure. 1. Surveillance mode
control is from the Service Processor (SP) Menus.
2. Verify that the system firmware supports SP surveillance.
3. CPU card
4. System board
5. Service processor
6. If the problem still exists, go to MAP 1540.
7. If the problem persists, call the support center for assistance.
40B00000 The operating system surveillance interval
exceeded.
40D00003 An unknown slow shutdown commanded. Critical cooling problem. 40D00004 An unknown fast shutdown commanded. Locked fan failure detected. 80001200 The firmware recovery information could not be
written to the diskette.
1. Surveillance mode control is from the Service Processor(SP) Menus.
2. Verify that the Operating System (OS) Heartbeat Utility is installed and has been activated.
3. Check for errors or unusual conditions that might prevent the OS from reporting Heartbeat messages; such as system dump, machine check or checkstop error. Review the error log.
4. System board; swap old VPD module to new system board
5. Service processor
6. If the problem persists, call the support center for assistance.
1. Check diskette media write protect tab.
2. Diskette drive
3-12 Service Guide
Table 3-3 (Page 11 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
80001300 The firmware update file is the same level as the
system firmware. Firmware update cancelled.
80001400 The firmware update file does not support this
system. Firmware update cancelled.
80001500 The firmware update file on the current drive is
corrupted. Firmware update cancelled.
80001600 The firmware update file could not be located on
the current drive. Firmware update cancelled.
80001700 The firmware update file on the current drive is
corrupted. Firmware update cancelled.
80001800 A valid firmware update file could not be located on
the current drive. Firmware update cancelled.
80001900 The firmware update file does not support this
system. Firmware update cancelled.
80002000 Two flash images found.
User cancelled out of file select
80002100 The firmware update file could not be loaded from
the current drive. Firmware update cancelled.
80002200 The firmware update module is write protected.
Firmware update cancelled.
80002300 This version of the update utility does not support
this system. Firmware update cancelled.
1. Obtain new level of firmware
2. Retry operation
1. Obtain the correct firmware file
2. Retry operation
1. Obtain new firmware file
2. Retry operation Specify the correct drive
and path name for firmware file.
1. Obtain new firmware file
2. Retry operation
1. Specify the correct drive and path name for firmware file.
2. Obtain new firmware file
3. Retry operation
1. Obtain new firmware file
2. Retry operation Retry operation
Specify the correct drive and path name for firmware file.
1. Turn the system off and then back on.
2. Retry operation
3. CPU card
4. If problem persists, call support center for assistance.
1. Turn the system off and then back on.
2. Retry operation
3. CPU card
4. If problem persists, call support center for assistance.
Chapter 3. Error Code to FRU Index 3-13
Table 3-3 (Page 12 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
80002400 The firmware module is not supported.
Firmware update cancelled.
80002500 The firmware module is not supported.
Firmware update cancelled.
80002600 The firmware module is write protected. 1. Turn the system off and
80002700 Backup recovery diskette is not inside the drive. Insert backup diskette 80002800 Update system firmware diskette is not inside the
drive.
80072000 The service processor is not installed. Service
processor update cancelled.
91001100 Remote IPL error. Insufficient memory. 1. Run memory test,
91001200 Remote IPL error. Incorrect IP format for client IP
address.
91001300 Remote IPL error. Incorrect IP format for server IP
address.
91001400 Remote IPL error. Incorrect IP format for gateway
IP address. 91001500 Remote IPL error. Incorrect IP format for netmask. Change/Update IP format 91001600 Remote IPL error. Error writing to NVRAM. System board; swap old
91001700 Remote IPL error. Ethernet adapter not found. Ensure network card is
91001900 Remote IPL error. Token-Ring adapter not found. Ensure network card is
91002000 Remote IPL error. No network adapters
recognized. 91002200 Remote IPL error. Ping failed. Possible IP address or
M0CON000 The system hung during POST. Go to MAP 1540.
Flash module on CPU card is malfunctioning.
Flash module on CPU card is malfunctioning.
then back on.
2. Retry operation
3. CPU card
4. If problem persists, call support center for assistance.
Insert diskette
1. Install the service processor
2. Retry operation
replace defective memory module.
2. This system has insufficient memory for this operation.
Change/Update IP format
Change/Update IP format
Change/Update IP format
VPD module onto new system board
properly installed.
properly installed. Ensure network card is
properly installed.
network problem.
3-14 Service Guide
Table 3-3 (Page 13 of 13). POST Error Codes
Error Code F Code / Description Action / Possible Failing
FRU
M0CPU000 The CPU POST failed. 1. CPU Card
2. System Board
M0CPU001 Checkstop occurred. 1. CPU card
2. System board
M0FD0000 The system hung during diskette POST. 1. System board
2. Diskette drive. M0GA0000 Graphics adapter POST failed. Graphics adapter M0HD0000 The system hung during boot POST. Go to MAP 1540. M0KBD000 The system hung during keyboard POST. 1. System board
2. Keyboard M00KBD01 The system did not respond to a keyboard entry. Type 101 keyboard M0KBD002 The system did not respond to a keyboard entry. Type 102 keyboard M0KBD003 The system did not respond to a keyboard entry. Kanji-type keyboard M0MC0001 A machine check occurred. Go to MAP 1540. M0MEM000 No good memory could be found. 1. Memory
2. System board
Note: If only one memory module is installed, replace it. If there are multiple memory modules installed, go to MAP 1540.
M0MEM001 No good memory could be found. 1. Memory
2. System board. M0MEM002 The system hung during memory POST. Go to MAP 1540. M0PS0000 Power failure. Go to MAP 1520. M0SCSI00 Unable to load diagnostics. Go to MAP 1540. M0SCSI01 Unable to load diagnostics. Go to Map 1540. M0SPK000 A continuous beep is heard from the system. System board M0SPK001 The system does not beep. 1. System board
2. Speaker
Chapter 3. Error Code to FRU Index 3-15
Table 3-4 (Page 1 of 2). POST Error Status Codes
Error Status
08 Invalid device number 11 No SCSI card 13 Command failed 28 Reservation conflict 29 Device not available 43 Not enough memory 47 Waiting for completion 49 Sense needed 51 Reset needed 55 Not ready or no media 56 Invalid (unsupported) command 57 Write protected 59 Media error 60 Hardware error 61 Unit attention 62 Blank check 63 Command abort 64 Busy 65 Media 66 Script error 67 Invalid address 68 Media changed 69 Device reset 70 Format in progress 71 Format corrupt 72 Start required 73 Device ID conflict 74 Manual intervention 75 Media not found 76 In progress 77 Media eject failed 78 Write protect failed 79 Controller memory to memory transfer test failed 80 - 81 SCSI Controller interface error 82 SCSI bus access error
3-16 Service Guide
Table 3-4 (Page 2 of 2). POST Error Status Codes
Error Status
83 SCSI fuse bad or PTC 84 SCSI Device command failed 85 - 86 SCSI Controller interface error 87 Short record error 88 SCSI bus parity error 89 SCSI device no reset 90 Time out error 91 SCSI no audio 92 SCSI incompatible media 93 Tape requested/actual block size mismatch
(normally) 94 Filemark or setmark read on tape device 95 Wide data transfer data miscompare error 96 Wide data transfer error other than data
miscompare 97 Command not supported by device (eg. wide
data transfer) 99 SCSI Controller interface error
Chapter 3. Error Code to FRU Index 3-17
3-18 Service Guide
Chapter 4. Loading the System Diagnostics
The system unit can be booted either from the default boot list or from the custom boot list. (See Chapter 5, “System Management Services” on page 5-1 for instructions on defining the custom boot list.)
To load Standalone diagnostics from the default boot list, perform the following procedure:
1. Verify with the system administrator and users that all programs may be stopped, then do so.
2. Turn off the system.
3. Wait 30 seconds, and turn on the system.
4. Immediately insert the diagnostic CD-ROM into the CD-ROM drive.
5. When or after the diskette indicator appears during startup, press the F5 key on a directly-attached keyboard (or the number 5 key on an ASCII terminal).
6. Enter any requested passwords.
Online diagnostics can be loaded by booting from the custom boot list by pressing the F6 key (on a directly-attached keyboard) or the number 6 key on an ASCII terminal.
The procedure for booting from the devices listed in the custom boot list (Online diagnostics) is the following:
1. Verify with the system administrator and users that all programs may be stopped, then do so.
2. Turn off the system.
3. Wait 30 seconds, and turn on the system.
4. When or after the diskette indicator appears during startup, press the F6 key on a directly-attached keyboard (or the number 6 key on an ASCII terminal).
5. Enter any requested passwords.
After any requested passwords have been entered, the system will attempt to boot from the first device of each type found on the list. If no bootable image is found on the first device of each type on the list, the system does not search through the other devices of that type for a bootable image; instead, it will poll the first device of the next type.
Chapter 4. Loading the System Diagnostics 4-1
If all types of devices in the boot list have been polled without finding a bootable image, the system will will restart, this gives the user the opportunity to start the System Management Services ( by pressing the F1 key on a directly attached keyboard or the number 1 on an ASCII terminal) before the system attempts to boot again.
Custom Boot List and Default Boot List
The default boot list is:
1. Diskette
2. CD-ROM
3. Hard File
4. Network Token-Ring Ethernet
Pressing the F5 key on a directly-attached keyboard (or the number 5 key on an ASCII terminal) causes the system to boot in service mode from this list.
Pressing the F6 key on a directly-attached keyboard (or number 6 key on an ASCII terminal) selects a service mode boot from the custom boot list, which is the boot list defined using the System Management Services described in Chapter 5, “System Management Services” on page 5-1. Like the default boot list, the custom boot list can contain four entries. The F6 or 6 keys work like the F5 or 5 keys, with the following exceptions:
The system will search for a boot record according to the custom boot list.If the custom boot list is discovered by a cyclical redundancy check to be
corrupted, the system will rebuild the custom boot list according to the default boot list. (The default boot list contains four entries, and for each matching device type found in the system unit, the system makes an entry in the custom boot list.)
If no custom boot list is present, the system enters "none" in the corresponding
location within the custom boot list.
4-2 Service Guide
Chapter 5. System Management Services
These programs make it possible for you to view information about your system, run memory tests, and set the storage device from which the server boots.
If you have a graphical display connected to a display adapter in your system unit, then you can use the graphical System Management Services. Otherwise, you must use the text-based version of the System Management Services.
The graphical System Management Services is described in “Graphical System Management Services” on page 5-2; the text-based System Management Services is described beginning in “Text-Based System Management Services Programs” on page 5-11; the ASCII terminal is described beginning in “ASCII Terminal System Management Services Programs” on page 5-16.
To start the programs:
1. Turn on or shutdown and restart the system.
2. When the first screen appears, press the F1 key to use the graphical System Management Services. To use the text-based System Management Services, press the F4 key or number 4 key on an ASCII terminal.
Note: You must press F1 or F4 key after the diskette indicator appears on the
screen, but before the last indicator appears. After you have pressed the F1 or F4 key, the initialization indicators continue to display, and the System Management Services screen displays after the last indicator.
Note: It is recommended that you create a Firmware Recovery Diskette using the
Update Firmware selection in the System Management Services Tools section described in this chapter.
Chapter 5. System Management Services 5-1
Graphical System Management Services
When the graphical System Management Services program begins, the following screen appears.
The System Management Services screen contains the following objects.
Start Up: This function allows you to define a custom boot list, which defines the sequence in which devices are searched by the operating system for a bootable image.
Test: Allows you to repeatedly test the memory in your system.
5-2 Service Guide
Tools: Enables you to set and remove passwords and to set the unattended start mode. In addition, you can view information about your system and update system programs.
Exit: Returns you to the previous screen.
To select an object, use the arrow keys to highlight an object and then press Enter or the Spacebar. To leave the current screen, either press the Esc or select the Exit object.
Chapter 5. System Management Services 5-3
Start Up
Dskt 1
Cancel
CD ROM 1
Default
HDD 1
Select
OK
This selection enables you to define a custom boot list or reset default list, which determines the order in which devices are searched by the firmware for a bootable image. The screen may show the following objects.
Diskette: Diskette drive.
CD-ROM: CD-ROM drive.
HDD: Hard disk drive.
5-4 Service Guide
Highlight the device which the system will search for first when booting, and press the Spacebar. Notice that numbers appear over the objects, indicating the order of the startup sequence. Up to four devices can be specified. To cancel your selection, select the Cancel object. The Default object sets the sequence to:
Diskette drive CD-ROM drive
Hard disk drive
Tape drive
Network (if installed)
If your system has more devices than shown in the list, their objects will be displayed after those in the default sequence.
Attention: If you change your custom boot list, you must be extremely careful when doing
write
operations (for example, saving or formatting). You can accidentally
overwrite data or programs if you select the wrong drive.
Test
Selecting this object enables you to test the memory in your system unit.
Chapter 5. System Management Services 5-5
To begin the test, select the Test object.
The Loop Test object, when selected, allows the memory to be tested in a continuous loop. The test can be stopped by pressing the S key.
If a problem is detected during testing, an error code similar to the one below will be displayed under the object for the failing device.
00020000 If an error code appears, make a written record of the error code.
5-6 Service Guide
Tools
Selecting this object enables you to perform various tasks and view additional information about your system. The following screen appears with objects presented for your selection.
The following describes the objects on this screen.
Chapter 5. System Management Services 5-7
Power-On Password: Setting a power-on password helps protect information stored in your system. When you select this object, a screen with 8 empty boxes appears. Type your password in these boxes. You can use any combination of up to eight characters (A–Z, a–z, and 0–9) for your password. As you type a character, a key appears in the box. Press Enter when you are finished; you will be required to type the password again for verification. If you make a mistake, select the Cancel object and start again.
If you already had set a power-on password and wanted to remove it, select the following object.
Note: If you
forget
your password, you will have to remove the battery for at least 30 seconds to disable the password. See “Battery” on page 7-25.
A password can be set only after system power has been turned off and then on again. You cannot set a password after using the Ctrl+Alt+Del combination (or
warm boot
) to restart
the system.
Privileged-Access Password: The privileged-access password protects against the unauthorized starting of the system programs. Follow the same procedure described for the power-on password.
As with the power-on password, you must turn system power off and then on again before setting a privileged-access password.
5-8 Service Guide
Remote Mode: The remote mode, when enabled, allows the system to start from the defined boot device. This mode is ideal for network servers and other systems that operate unattended. You
must
set a power-on password before you can enable the remote mode. When the remote mode is set, the object changes to Remote On.
If you remove the power-on password, the remote mode is automatically reset, and the object returns to Remote Off.
Selecting Remote On resets the startup mode to the normal startup sequence.
Firmware: Enables you to update system firmware. Firmware should be selected only when a change to the
system firmware is needed. A
Firmware Update
diskette will be
made available to you when such an update is needed. Firmware updates take several minutes, and you need a DOS
formatted 1.44MB diskette. The procedure for updating the firmware is as follows.
Attention: Do not turn off power to your system during this procedure.
1. Select Tools, and then Firmware.
2. Make a backup copy of the system firmware using a DOS
3. When the backup is complete, insert the
Error Log: Enables you to view error log information that is stored if an error occurs.
Chapter 5. System Management Services 5-9
formatted 1.44MB diskette as prompted. This backup is a Firmware Recovery Diskette that may be used later to recover from system problems.
Firmware Update
diskette. The system firmware will be updated, and the system will automatically restart upon completion.
Service Processor: Enables you to update service processor firmware.
Service Processor should be selected only when a change to the service processor firmware is needed. A
Update
diskette will be made available to you when such an
Service Processor
update is needed. Service processor updates take several minutes, and you need
a DOS formatted 1.44MB diskette. The procedure for updating the service processor firmware is as follows.
Attention: Do not turn off power to your system during this procedure.
1. Select Tools, and then Service Processor.
2. Make a backup copy of the service processor firmware using a DOS formatted 1.44MB diskette as prompted. This backup is a Service Processor Firmware Diskette that may be used later to recover from system problems.
3. When the backup is complete, insert the
Firmware Update
diskette. The service processor firmware
Service Processor
will be updated, and the system will automatically restart upon completion.
RIPL: Allows you to select a remote system to load programs from when your system is first powered on.
Overriding the Stored Boot Sequence
In order to override the stored boot sequence for the current boot, press F5 after the keyboard indicator appears on the screen, but before the last indicator appears. This forces the firmware to search for startup code on the devices listed in the default sequence, either diskette, CD-ROM, hard disk drive, or token-ring (if installed) or ethernet (if token-ring is not installed). Pressing F5 does not modify what has already been selected through “Start Up” on page 5-4. That information is still stored in the system. Pressing F5 is limited to the current boot.
5-10 Service Guide
Text-Based System Management Services Programs
To start the programs:
1. Turn on or shutdown and restart the system.
2. As soon as the first screen appears, press the F4 key. Note: You must press F4 after the diskette indicator appears on the screen, but
before the last indicator appears.
The System Management Services screen appears.
à ð
Select one:
3. Utilities
Enter Esc=Quit F1=Help F3=Reboot F9=Start OS
á
System Management Services
1. Select Boot Devices
2. Test the Computer
4. Select Language
ñ
Use the Up Arrow and Down Arrow keys ( or ) to highlight your selection; then press Enter.
You can get help information about any item on a menu by highlighting the item and pressing F1. The bottom of the screen shows which keys are active.
Chapter 5. System Management Services 5-11
Select Boot Devices
à ð
Select one:
3. Utilities
Enter Esc=Quit F1=Help F3=Reboot F9=Start OS
á
System Management Services
1. Select Boot Devices
2. Test the Computer
4. Select Language
ñ
This selection enables you to view and change the sequence in which devices are read at startup time. You also can set or change a particular startup device, or specify the device the system is to start from.
à ð
Boot Sequence Selection
1. Display Current Settings
2. Restore Default Settings
3. Configure 1st Boot Device
4. Configure 2nd Boot Device
5. Configure 3rd Boot Device
6. Configure 4th Boot Device
7. Boot Other Device
Enter Esc=Quit F1=Help F3=Reboot F9=Start OS
á
5-12 Service Guide
ñ
Test the Computer
à ð
Select one:
3. Utilities
Enter Esc=Quit F1=Help F3=Reboot F9=Start OS
á
System Management Services
1. Select Boot Devices
2. Test the Computer
4. Select Language
ñ
This selection enables you to test devices and functions of your system. The screen that displays, is similar to the screen that follows.
à ð
Esc=Quit
F1=Help [ ] Test Memory Spacebar=Choose [ ] Test Memory
F4=Parm Setup
F6=Execute
Select Device to Test
F9=Display Error Log
á
When you have selected the devices you want to test, press F4 to set the test requirements, such as the number of times the tests are to be run, and whether testing should stop if an error occurs. After you set the requirements, press Enter to return to the Select the Device to Test screen; then press F6 to start the tests.
To see if any errors were recorded in previous tests, press F9 to display the error log.
Chapter 5. System Management Services 5-13
ñ
Utilities
à ð
Select one:
3. Utilities
Enter Esc=Quit F1=Help F3=Reboot F9=Start OS
á
System Management Services
1. Select Boot Devices
2. Test the Computer
4. Select Language
ñ
Selecting Utilities enables you to select from the System Management Utilities window. It has the following choices.
à ð
Select one:
Enter Esc=Quit F1=Help
á
System Management Utilities
1. Set Power-On Password
2. Set Privileged-Access Password
3. Enable Unattended Start Mode
4. Disable Unattended Start Mode
5. Remove Power-On Password
6. Remove Privileged-Access Password
7. Update System Firmware
8. Display Error Log
9. Remote Initial Program Load Setup
1ð. Update Service Processor Firmware
ñ
The Power-On and Privileged-Access Password are security features that help protect your system and stored information.
The Unattended Start Mode, when enabled, allows the system to start from the defined boot device.
5-14 Service Guide
Update System Firmware enables you to make these changes to the firmware of your system. To receive the latest updates, contact your authorized reseller or marketing representative. Firmware updates take several minutes, and you need a DOS formatted 1.44MB diskette. The procedure for updating the firmware is as follows.
Attention: Do not turn off power to your system during this procedure.
1. Select Utilities, and then Update System Firmware.
2. Make a backup copy of the system firmware using a DOS formatted 1.44MB diskette as prompted. This backup is a Firmware Recovery Diskette that may be used later to recover from system problems.
3. When the backup is complete, insert the
Firmware Update
diskette. The system firmware will be updated, and the system will automatically restart upon completion.
Display Error Log lets you see what problems have been recorded in previous tests.
Remote Initial Program Load Setup allows you to view parameters. Update Service Processor Firmware enables you to make changes to the service
processor firmware of your system. To receive the latest updates, contact your authorized reseller or marketing representative. Service processor updates take several minutes, and you need a DOS formatted 1.44MB diskette. The procedure for updating the firmware is as follows.
Attention: Do not turn off power to your system during this procedure.
1. Select Utilities, and then Update Service Processor Firmware.
2. Make a backup copy of the service processor firmware using a DOS formatted
1.44MB diskette as prompted. This backup is a Service Processor Firmware Recovery Diskette that may be used later to recover from system problems.
3. When the backup is complete, insert the
Service Processor Firmware Update
diskette. The service processor firmware will be updated, and the system will automatically restart upon completion.
Chapter 5. System Management Services 5-15
ASCII Terminal System Management Services Programs
To start the programs:
1. Turn on or shutdown and restart the system.
2. As soon as the first screen appears, press the 1 or 4 key.
Note: You must press 1 or 4 key before the last indicator (boot .....) appears.
The System Management Services screen appears.
à ð
Select one:
3. Utilities
n=next-item -
-------------
á
System Management Services
1. Select Boot Devices
2. Test the Computer
4. Select Language
Enter - q=Quit - h=Help - r=Reboot - s=Start OS - p=prev-item -
------- -------- -------- ---------- ------------ -------------
Press enter to select item number 1.
ñ
Use the next (n) and previous (p) keys to make your selection; then press Enter. You can get help information about any item on a menu by pressing the h key. The
bottom of the screen shows which keys are active.
5-16 Service Guide
