EM78P312N

8-Bit Microcontroller

1 General Description

The EM78P312N is an 8-bit microprocessor with low-power, high-speed CMOS technology and high noise immunity. It has an on-chip 4K×13-bits Electrical One Time Programmable Read Only Memory (OTP-ROM). It provides multi-protecti on bits to prevent intrusion of user’s OTP memory codes. Seven Option bits are also available to meet user’s requirements. With its OTP-ROM feature, the EM78P312N provides a convenient way of developing and verifying user’s programs. Moreover, this OTP device offers the advantages of easy and effective program updates, using development and programming tools. User can avail of the ELAN Writer to easily program his development code.

2 Features

 CPU configuration

z 4K×13 bits on-chip ROM z 144×8 bits on-chip registers (SRAM) z 8-level stacks for subroutine nesting z Less than 3.5mA at 5V/8MHz z Typically 0.8 μA, during sleep mode z Typically 1.1 μA, during idle mode

 I/O port configuration

z 4 bidirectional I/O ports : P6, P7, P8, P9 z 22 I/O pins z 10 Programmable pull-down I/O pins z 10 programmable pull-high I/O pins z External interrupt : P60, P61, P73, P80

 Operating voltage range:

z OTP version

Operating voltage range:2.5v~5.5v

 Operating temperature range:

z -40~85°C

 Operating frequency range:

Main clock

• Crystal mode:

DC ~ 20MHz/2clks @ 5V; DC ~100ns inst. cycle @ 5V DC ~ 8MHz/2clks @ 3V;DC ~ 250ns inst. cycle @ 3V

• ERC mode:

DC ~ 16MHz/2clks @ 5V;DC ~ 125ns inst. cycle @ 5V DC ~ 8MHz/2clks @ 3V;DC ~ 250ns inst. cycle @ 3V

 Peripheral configuration

z Serial peripheral interface (SPI) available z Universal asynchronous receiver transmitter interface

(UART)available

z 16 bits Counter/Timer

TC2: Timer/Counter/Window

z 8 bits Timer/Counter

TCC: 8-bit real time clock/counter with overflow

interrupt

TC3: Timer/Counter/Capture

TC4: Timer/Counter/ PWM (pulse width modulation) /

PDO (Programmable divider output)

z 8-bit channels Analog-to-Digital Converter with 10-bit

resolution

z Time Base Timer:(1Hz~16kHz at 8MHz) z Key tone output:(1kHz~8kHz at 8MHz) z 8-bit channels Analog-to-Digital Converter with 10-bit

resolution

 Fifteen available interrupts:

z WDT time-out interrupt z TCC overflow interrupt z Time base timer interrupt (the first falling edge of the

source clock)

z Serial UART transmit interrupt z Serial UART receive interrupt z Serial UART receive error interrupt z Four External interrupt z ADC completion interrupt z TC2 overflow interrupt z TC3 overflow interrupt z TC4 overflow interrupt z Serial SPI interrupt

 Special features

z Programmable free running watchdog timer z Two clocks per instruction cycle z Power-on Reset z High noise immunity z Power saving Sleep mode z Selectable Oscillation mode

 Package type:

z 28-pin DIP 600 mil: EM78P312NP z 28-pin Skinny DIP 300 mil: EM78P312NAK z 28-pin Skinny DIP 400 mil: EM78P312N z 28-pin SOP 300 mil: EM78P312NM z 28-pin SSOP 209 mil: EM78P312NS

3 Pin Assignment

(ACLK) OSCO

OSCI

TEST (AD0) P90 (AD1) P91 (AD2) P92 (AD3) P93 (AD4) P94 (AD5) P95 (AD6) P96

(AD7/VREF) P97 (TC3, INT3) P80

(TC4, /PW M, /PDO) P81

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

VSS

Fig. 3- Pin Assignment

• 1

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

EM78P312N

VDD

/RESET (VPP)

P67 (DINCK)

P66 (DATAIN)

P65 (PGMB)

P64 (/SS)(OEB)

P63 (/TONE)

P62 (TC2)

P61 (INT1)

P60 (/INT0)

P73 (/SLEEP, /INT5)

P72 (TX, SO)

P71(RX,SI) P70 (/SCK)

EM78P312N

8-Bit Microcontroller

4 Pin Description

Table 1

Symbol Pin No. Type Function

VDD

OSCI

OSCO

/RESET

P60~P67

P70~P73

P80~P81

P90~P97

VSS

OTP Programming Pins

VPP

ACLK

DATAIN

DINCK

PGMB

OEB

28 − Power supply

2 I

1 I/O

27 I

19~26 I/O

15~18 I/O

12~13 I/O

4~11 I/O

14 − Ground

3 − No connection

27 I Programming voltage input

1 I CLK for OTP memory address increment

25 I/O ROM code series input and series output pin

26 I ROM code input clock

24 I Program write enable pin. Active low.

23 I Output enable pin. Active low.

Crystal type: Crystal input terminal RC type: RC oscillator input pin

Crystal type: Output terminal for crystal oscillator RC type: Instruction clock output External clock signal input

Input pin with Schmitt Trigger. If this pin remains at logic low, the controller will also remain in reset condition.

8-bit bidiectional input/output pins.

P60 can be used as external Interrupt 0 (/INT0). P61 can be used as external Interrupt 1 (INT1). P62 can be used as 16-bit Timer/Counter 2 (TC2). P63 can be used as divider output (/TONE).

P64 slave mode enable (/SS). P60 ~ P63 can be used as pull-high or pull-low pins.

8-bit bidiectional input/output pins. P70 can be used as SPI serial clock input/output (/SCK) P71 can be used as SPI serial data input (SI) or UART data receive

input (RX)

P72 can be used as SPI serial data output (SO) or UART data

transmit output (TX)

P73 can be used as Sleep mode release input (/SLEEP) or external

interrupt Input 5 (/INT5)

P70 ~ P73 can be used as pull-high or pull-low pins

2-bit bidiectional input/output pins. P80 can be used as 8-bit Timer/Counter 3 (TC3) or external

Interrupt Input 3 (INT3).

P81 can be used as 8-bit Timer/Counter 4 (TC4) or programmable

divider output (PDO).

P80 ~ P81 can be used as pull-high or pull-low pins.

8-bit bidiectional input/output pins. P90~P97 can be used as 8 channel 10-bit resolution A/D converter. P97 can be used as AD reference power supply input (VREF).

2 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

5 Function Description

5.1 Functional Block Diagram

EM78P312N

8-Bit Microcontroller

P90 P91

P92 P93 P94 P95 P96 P97

P80

P81

P70 P71

P72 P73 P74 P75 P76

P77

P60 P61 P62 P63 P64 P65 P66

P67

ACC

ROM

Instruction

Decoder

ALU

Status Reg.

8-level stack

(13 bit)

Interrupt

Control

Interrupt

Circuit

Ext.

OSC.

Oscillation

Generation

Reset

Mux

RAM

Ext.

Start-up

Timer

WDT

TC2

TC3

TC4

UART

SPI

TCC

TBKTC

ADC

TC2

TC3

TC4

TX RX

Sin Sout SCK

TCC

Keytone

Ext INT0

Ext INT3Ext INT1 Ext INT5

Fig. 5-1 Functional Block Diagram

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 3

Ain 0~7

EM78P312N

8-Bit Microcontroller

5.2 Operating Registers

Address

00 01 02 03 04 05 06 07 08 09

0A 0B 0C 0D 0E 0F

Bank 0

R0/ IAR

R1/ TCC

R2/ PC

R3/ SR

R4/ RSR

SCR

Port 6

Port 7

Port 8

Port 9

Reserved

TC4CR

TC4D

ISFR0

ISFR1

ISFR2

16 Byte

Common Register

Bank 1

R3 (7, 6) = (0, 1)

TC3CR

TC3DA

TC3DB

TC2CR/ ADDL

TC2DH

TC2DL

ADCR

ADIC

ADDH

TBKTC

Reserved

Bank 2

R3 (7, 6) = (1, 0) R3 (7, ) = (1, 1)

URC1

URC2

URS

URRD

URTD

Reserved

Bank 3

SPIC1

SPIC2

SPID

Reserved

PHC1

PLC1

PHC2

PLC2

Reserved

Control

Reserved

IOC6

IOC7

IOC8

IOC9

Reserved

INTCR

ADOSCR

Reserved

IMR1

IMR2

Bank 0

R4 (7, 6) = (0, 0)

32 Byte

Common Register

Bank 1

R4 (7, 6) = (0, 1)

32 Byte

Common Register

Fig. 5-2 Operating Registers

4 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

R0 (Indirect Addressing Register)

R0 is not a physically implemented register. Its major function is to act as an indirect

addressing pointer. Any instruction using R0 as a pointer actually accesses data

pointed by the RAM Select Register (R4).

R1 (Time Clock /Counter)

This register is writable and readable just like the other registers. The contents of the

prescaler counter are cleared only when a value is written into the TCC register.

R2 (Program Counter) & Stack

z Depending on the device type, R2 and hardware stack are 10-bit wide. The

structure is depicted in Fig.5-3.

z Generates 8192 ×13 bits on-chip OTP ROM addresses to the relative

programming instruction codes. One program page is 1024 words long.

z R2 is set as all "0"s when under RESET condition

z "JMP" instruction allows direct loading of the lower 10 program counter bits.

Thus, "JMP" allows the PC to go to any location within a page.

z "CALL" instruction loads the lower 10 bits of the PC, and then PC+1 is pushed

onto the stack. Thus, the subroutine entry address can be located

anywhere within a page.

z "RET" ("RETL k", "RETI") instruction loads the program counter with the

contents of the top-level stack.

z All instructions are single instruction cycle (fclk/2 or fclk/4) except for the

instruction that would change the contents of R2. Such instruction will need

one more instruction cycle.

z For an interrupt trigger, the program ROM will jump to individual interrupt

vector at Page 0. The CPU will store ACC, R3 status and R5 PAGE

automatically, it will restore after instruction RETI.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 5

EM78P312N

8-Bit Microcontroller

A12

000 : PAGE0 0000~03F F 001 : PAGE1 0400~07F F 010 : PAGE2 0800~0BFF 011 : PAGE3 0C00~0FFF 100 : PAGE4 1000~13F F 101 : PAGE5 1400~17F F 110 : PAGE6 1800~1BFF 111 : PAGE7 1C00~1FFF

A11 A10 A9 A8 A7 ~ A0

CALL RET RETL RETI

Stack Level 1 Stack Level 2 Stack Level 3 Stack Level 4 Stack Level 5 Stack Level 6 Stack Level 7 Stack Level 8

Store ACC, R3, R5

Reset Vector WDT Timer Overflow External INT0 Pin Interrupt Occurs TCC Overflow External INT1 pin Interrupt Occurs Time Base Timer Interrupt UART Transmit Data Buffer Empty UART Receive Data Buffer Full UART Receive Error TC3 Interrupt SPI Interrupt TC4 Interrupt External INT3 Pin Interrupt Occurs AD Conversion Complete TC2 Interrupt External INT5 Pin Interrupt Occurs

On-chip Program Memory

0000h

0003h

0006h

0009h

000Fh

0012h

0015h

0018h

001Bh

0021h

0024h

0027h

002Ah

0030h

0033h

0036h

User Memory Space

1FFFh

Fig. 5-3 Program Counter Organization

R3 (Status Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

RBS1 RBS0 0 T P Z DC C

Bit 7 ~ Bit 6 (RBS1 ~ RBS0): R-Register page select

RBS1 RBS0 Register Bank (Address 05H ~ 0FH)

0 0 Bank 0

0 1 Bank 1

1 0 Bank 2

1 1 Bank 3

Bit 5: Not used Bit 4 (T): Time-out bit. Set to “1” with the "SLEP" and "WDTC" commands, or during

power up, and reset to “0” with the WDT time-out.

6 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

Bit 3 (P): Power down bit. Set to “1” during power on or by a "WDTC" command and

reset to “0” by a "SLEP" command.

Bit 2 (Z): Zero flag. Set to "1" if the result of an arithmetic or logic operation is zero. Bit 1 (DC) : Auxiliary carry flag Bit 0 (C) : Carry flag

R4 (RAM Select Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

GRBS1 RBS0 RSR5 RSR4 RSR3 RSR2 RSR1 RSR0

Bit 7: 6 ( GRBS1: GRBS0 ): determine which general purpose banks are activated

among the two banks. Use BANK instruction (e.g. BABK 1) to change bank.

GRBS1 GRBS0 General Purpose Register Bank (Address 20H ~ 3FH)

0 0 Bank 0 0 1 Bank 1

Bit 5: 0 ( RSR5 : RSR0 ): used to select the registers (Address: 00h~3Fh) in indirect

addressing mode. If no indirect addressing is used, the RSR can be used as

an 8-bit general-purpose read/write register. See the data memory

configuration in Fig. 5-2.

R5 (System Control Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 0 PS1 PS0 0 1 SIS REM

Bits 5~4 (PS1~PS0): ROM Page select bits. User can use PAGE instruction (e.g.

PAGE 1) or set PS1~PS0 bits to change the ROM page. When executing a

"JMP", "CALL", or other instructions which cause the program counter to

change (e.g. MOV R2, A), PS1~PS0 are loaded into the 12th to11th bits of the

program counter and select one of the available program memory pages. Note

that RET (RETL, RETI) instruction does not change the PS1~PS0 bits. That

is, return will always be to the page from where the subroutine was called,

regardless of the PS1~PS0 bits current setting.

PS1 PS0 Program Memory Page [Address]

0 0 Page 0 [0000~03FF]

0 1 Page 1 [0400~07FF]

1 0 Page 2 [0800~0BFF]

1 1 Page 3 [0C00~0FFF]

Bit 1 ( SIS ) : Sleep and Idle mode select

SIS = “0” : Idle mode SIS = “1” : Sleep mode

Bit 0 ( REM ) : Release method for sleep mode

REM = “0” : /SLEEP pin input rising edge released REM = “1” : /SLEEP pin input “H” level released

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 7

EM78P312N

8-Bit Microcontroller

R6 (Port 6 I/O Data Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

P67 P66 P65 P64 P63 P62 P61 P60

Bit 7 ~ Bit 0 ( P67 ~ P60 ) : 8-bit Port 6 I/O data register

User can use IOC6 register to define each bit whether input or output.

R7 (Port 7 I/O Data Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bit 3 ~ Bit 0 ( P73 ~ P70 ) : Port 73 ~ Port 70 I/O data register

User can use IOC7 register to define each bit whether input or output.

R8 (Port8 I/O Data Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 0 0 0 P73 P72 P71 P70

0 0 0 0 0 0 P81 P80

Bit 1 ~ Bit 0 ( P81 ~ P80 ) : Port 81 ~ Port 80 I/O data register

User can use IOC8 register to define each bit whether input or output.

R9 (Port9 I/O Data Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

P97 P96 P95 P94 P93 P92 P91 P90

Bit 7 ~ Bit 0 ( P97 ~ P90 ) : 8-bit Port 97 ~ Port 90 I/O data register

User can use IOC9 register to define each bit whether input or output.

RB (Timer/Counter 4 Control Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TC4FF1 TC4FF0 TC4S TC4CK2 TC4CK1 TC4CK0 TC4M1 TC4M0

Bit 7 ~ Bit 6 ( TC4FF1 ~ TC4FF0 ) : Timer/Counter 4 flip-flop control

TC4FF1 TC4FF0 Operating Mode

0 0 Clear

0 1 Toggle

1 0 Set

1 1 Reserved

Bit 5 ( TC4S ) : Timer/Counter 4 start control

TC4S = “0” : Stop and clear counter TC4S = “1” : Start

8 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

Bit 4 ~ Bit 2 ( TC4CK2 ~ TC4CK 0 ) : Timer/Counter 4 Clock Source Select

TC4CK2 TC4CK1 TC4CK0

0 0 0 Fc/211 256μS 65mS

0 0 1 Fc/27 16μS 4mS

0 1 0 Fc/25 4μS 1mS

0 1 1 Fc/23 1μS 255μS

1 0 0 Fc/22 500nS 127.5μS

1 0 1 Fc/21 250nS 63.8μS

1 1 0 Fc 125nS 31.9μS

1 1 1 External clock (TC4 pin) − −

Clock Source

( Normal, Idle )

Bit 1 ~ Bit 0 ( TC4M1 ~ TC4M0 ) : Timer/Counter 4 Operating Mode Select

TC4M1 TC4M0 Operating Mode

0 0 Timer/Counter

0 1 Reserved

1 0 Programmable Divider output

1 1 Pulse Width Modulation output

Resolution

( Fosc=8M )

Max. Tim e

( Fosc=8M )

RC (Timer 4 Data Buffer)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TC4D7 TC4D6 TC4D5 TC4D4 TC4D3 TC4D2 TC4D1 TC4D0

Bit 7 ~ Bit 0 ( TC4D7 ~ TC4D0 ) : Data buffer of 8-bit Timer/Counter 4.

RD (Interrupt Status Flag Register 0 and INT3 Edge Detect Flag)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 0 INT3F INT3R 0 0 WDTIF EXIF0

Bit 5 ( INT3F ) : External Interrupt 3 falling edge detect flag.

INT3F = “0” : Falling edge is not detected INT3F = “1” : Falling edge is detected

Bit 4 ( INT3R ) : External Interrupt 3 rising edge detect flag.

INT3R = “0” : Rising edge is not detected

INT3R = “1” : Rising edge is detected Bit 1 ( WDTIF ) : WDT time-out flag, flag cleared by software. Bit 0 ( EXIF0 ) : External interrupt flag (INT0). Flag cleared by software. If the INT0EN

is reset to “0”, the flag is cleared.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 9

EM78P312N

8-Bit Microcontroller

RE (Interrupt Status Flag Register 1)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

EXIF5 TCIF2 ADIF 0 EXIF3 TCIF4 SPIF TCIF3

Bit 7 ( EXIF5 ) : External Interrupt Flag (/INT5), flag cleared by software. Bit 6 ( TCIF2 ) : 16-bit Timer/Counter 2 Interrupt Flag, flag cleared by software. Bit 5 ( ADIF ) : AD conversion complete flag, flag cleared by software. Bit 3 ( EXIF3 ) : External Interrupt Flag (/INT3), flag cleared by software. Bit 2 ( TCIF4 ) : 8-bit Timer/Counter 4 Interrupt Flag, flag cleared by software. Bit 1 ( SPIF ) : SPI Mode Interrupt Flag, flag cleared by software. Bit 0 ( TCIF3 ) : 8-bit Timer/Counter 3 interrupt flag, flag cleared by software.

0 : means no interrupt request 1 : means with interrupt request

z ISFR1 can be cleared by instruction, but cannot be set by instruction

z IMR1 is the interrupt mask register

z Note that reading ISFR1 will obtain the result of the ISFR1 "logic AND" and

IMR1.

RF(Interrupt Status Flag Register 2)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 UERRIF RBFF TBEF TBIF EXIF1 0 TCIF0

Bit 6 (U ERRI F ) : UART Receiving Error Interrupt, cleared by software or UART

disabled.

Bit 5 (RBFF) : UART Receive Mode Data Buffer Full Interrupt Flag. Flag cleared by

software.

Bit 4 (TB E F ) : UART Transmit Mode Data Buffer Empty Interrupt Flag. Flag cleared by

software.

Bit 3 (TBIF) : Time Base Timer Interrupt Flag. Flag cleared by software. Bit 2 (EXIF1) : External Interrupt Flag (INT1). Flag cleared by software. Bit 0 (TCIF0) : TCC Overflow Interrupt Flag. Set as TCC overflows; flag cleared by

software.

0 : means no interrupt request 1 : means with interrupt request

10 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

z ISFR2 can be cleared by instruction, but cannot be set by instruction

z IMR2 is the interrupt mask register

z Note that reading ISFR2 will obtain the result of the ISFR2 "logic AND" and

IMR2

Bank 1 R5 TC3CR (Timer/Counter 3 Control Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TC3CAP TC3S TC3CK1 TC3CK0 TC3M 0 0 0

Bit 7 ( TC3CAP ) : Software capture control

TC3CAP = “0” : -

TC3CAP = “1” : Software capture Bit 6 ( TC3S ) : Timer/Counter 3 start control

TC3S = “0” : Stop and counter clear

TC3S = “1” : Start

Bit 5 ~ Bit 4 ( TC3CK1 ~ TC3CK0 ) : Timer/Counter 3 Clock Source Select

TC3CK1 TC3CK0

0 0 Fc/212 512μS 131.1mS

0 1 Fc/210 128μS 32.6mS

1 0 Fc/27 16μS 4.1mS

1 1 External clock (TC3 pin) - -

Clock source

( Normal, Idle )

Resolution

( Fc=8M )

Max. time

( Fc=8M )

Bit 3 ( TC3M ) : Timer/Counter 3 mode select

TC3M = “0” : Timer/Counter3 mode

TC3M = “1” : Capture mode

Bank 1 R6 TC3DA (Timer 3 Data Buffer A)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TC3DA7 TC3DA6 TC3DA5 TC3DA4 TC3DA3 TC3DA2 TC3DA1 TC3DA0

Bit 7 ~ Bit 0 ( TC3DA7 ~ TC3DA0 ) : Data buffer of 8-bit Timer/Counter 3.

Reset does not affect this register.

Bank 1 R7 TC3DB (Timer 3 Data Buffer B)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TC3DB7 TC3DB6 TC3DB5 TC3DB4 TC3DB3 TC3DB2 TC3DB1 TC3DB0

Bit 7 ~ Bit 0 ( TC3DB7 ~ TC3DB0 ) : Data buffer of 8-bit Timer/Counter 3

Reset does not affect this register.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 11

EM78P312N

8-Bit Microcontroller

Bank 1 R8 TC2CR/ ADDL (Timer/Counter 2 Control Register, AD Low 2 bits

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

ADD1 ADD0 0 TC2M TC2S TC2CK2 TC2CK1 TC2CK0

Bit 7 ~ Bit 6 ( ADD1 ~ ADD0 ) : AD low 2-bit data buffer Bit 4 ( TC2M ) : Timer/Counter 2 mode select

Bit 3 ( TC2S ) : Timer/Counter 2 start control

Bit 2 ~ Bit 0 ( TC2CK2 ~ TC2CK0 ) : Timer/Counter 2 Clock Source Select

TC2CK2 TC2CK1 TC2CK0

Data Buffer)

TC2M = “0” : Timer/counter mode

TC2M = “1” : Window mode

TC2S = “0” : Stop and counter clear

TC2S = “1” : Start

Clock Source

( Normal, Idle )

0 0 0 Fc/223 1.05s 19.1h

0 0 1 Fc/213 1.02ms 1.1min

0 1 0 Fc/28 32μs 2.1s

0 1 1 Fc/23 1μs 65.5ms

1 0 0 Fc 125ns 7.9ms

1 0 1 - - -

1 1 0 - - -

1 1 1 External clock (TC2 pin)

Resolution

( Fc=8M )

Max. Time

( Fc=8M )

Bank 1 R9 TC2DH (Timer 2 Data Buffer High Byte)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TC2D15 TC2D14 TC2D13 TC2D12 TC2D11 TC2D10 TC2D9 TC2D8

Bit 7 ~ Bit 0 ( TC2D15 ~ TC2D8 ) : 16-bit Timer/Counter 2 data buffer high byte.

Bank 1 RA TC2DL (Timer 2 Data Buffer Low Byte)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TC2D7 TC2D6 TC2D5 TC2D4 TC2D3 TC2D2 TC2D1 TC2D0

Bit 7 ~ Bit 0 ( TC2D7 ~ TC2D0 ) : 16-bit Timer/Counter 2 data buffer low byte.

Bank 1 RB ADCR (AD Control Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

ADREF ADRUN ADCK1 ADCK0 ADP ADIS2 ADIS1 ADIS0

Bit 7 ( ADREF ) : AD reference voltage input select.

ADREF = “0” : Internal VDD, P97 is used as IO.

ADREF = “1” : External reference pin, P97 is used as reference input pin.

12 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

8-Bit Microcontroller

Bit 6 ( ADRUN ) : AD Conversion start

ADRUN = “0” : Reset on completion of the conversion by hardware, this bit

cannot be reset by software.

ADRUN = “1” : Conversion starts Bit 5~ Bit 4 ( ADCK1 ~ ADCK0 ) : AD Conversion Time Select

EM78P312N

ADCK1 ADCK0

0 0 Fc/4 1MHz

0 1 Fc/16 4MHz

1 0 Fc/32 8MHz

1 1 Reserved -

Clock Source

( Normal, Idle )

Bit 3 ( ADP ) : AD power control

ADP = “0” : Power on

ADP = “1” : Power down Bit 2 ~ Bit 0 ( ADIS2 ~ ADIS0 ) : Analog Input Pin Select

ADIS2 ADIS1 ADIS0 Analog Input Pin

0 0 0 AD0

0 0 1 AD1

0 1 0 AD2

0 1 1 AD3

1 0 0 AD4

1 0 1 AD5

1 1 0 AD6

1 1 1 AD7

Max. Op erating Frequency (Fc)

Bank 1 RC ADIC (AD Input Pin Control)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

ADE7 ADE6 ADE5 ADE4 ADE3 ADE2 ADE1 ADE0

Bit 7 ~ Bit 0 ( ADE7 ~ ADE0 ) : AD input pin enable control.

ADEx = “0” : Port 9.x functions as I/O pin

ADEx = “1” : Port 9.x functions as analog input pin

Bank 1 RD ADDH (AD High 8-bit Data Buf fer)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

ADD9 ADD8 ADD7 ADD6 ADD5 ADD4 ADD3 ADD2

Bit 7 ~ Bit 0 ( ADD9 ~ ADD2 ) : AD high 8-bit data buffer

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 13

EM78P312N

8-Bit Microcontroller

Bank 1 RE TBKTC (TBT/Keytone Control)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

TEN TCK1 TCK0 0 TBTEN TBTCK2 TBTCK1 TBTCK0

Bit 7 ( TEN ) : Keytone enable control

Bit 6 ~ Bit 5 ( TCK1 ~ TCK0 ) : Keytone Output Clock Source Select

Bit 3 ( TBTEN ) : Time Base Timer Enable Control

TEN = “0” : Disable

TEN = “1” : Enable

TCK1 TCK0

0 0 Fc/213 0.976kHz

0 1 Fc/212 1.953kHz

1 0 Fc/211 3.906kHz

1 1 Fc/210 7.812kHz

Clock Source

( Normal, Idle )

Keytone Output Frequency

( Fc = 8MHz )

TBTEN = “0” : Disable

TBTEN = “1” : Enable Bit 2 ~ Bit 0 ( TBTCK2 ~ TBTCK0 ) : Time Base Timer Clock Source Select

TBTCK2 TBTCK1 TBTCK0

0 0 0 Fc/223 0.95Hz

0 0 1 Fc/221 3.81Hz

0 1 0 Fc/216 122.07Hz

0 1 1 Fc/214 488.28Hz

1 0 0 Fc/213 976.56Hz

1 0 1 Fc/212 1953.12Hz

1 1 0 Fc/211 3906.25Hz

1 1 1 Fc/29 15625Hz

Clock Source

( Normal, Idle )

Interrupt Frequency

( Fc = 8MHz )

Bank 2 R5 URC1 (UART Control Register 1)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

URTD8 UMODE1 UMODE0 BRATE2 BRATE1 BRATE0 UTBE TXE

Bit 7 ( URTD8 ) : Transmission data Bit 8 Bit 6 ~ Bit 5 ( UMODE1 ~ UMODE0 ) : UART Transmission Mode Select Bit

UMODE1 UMODE0 UART Mode

0 0 Mode 1: 7-bits

0 1 Mode 2: 8-bits

1 0 Mode 3: 9-bits

1 1 Reserved

14 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

Bit 4 ~ Bit 2 ( BRATE2 ~ BRATE1 ) : Transmit Baud Rate Select

BRATE2 BRATE1 BRATE0 Baud Rate e.g. Fc=8MHz

0 0 0 Fc/13 38400

0 0 1 Fc/26 19200

0 1 0 Fc/52 9600

0 1 1 Fc/104 4800

1 0 0 Fc/208 2400

1 0 1 Fc/416 1200

1 1 0 TC4 -

1 1 1 reserved -

Bit 1 ( UTBE ): UART transfer buffer empty flag. Set to 1 when transfer buffer is empty.

Reset to 0 automatically when writing into the URTD register. UTBE bit

will be cleared by hardware when enabling the transmission. UTBE bit

is read-only. Therefore, writing to the URTD register is necessary

when starting transmission shifting.

Bit 0 ( TXE ): Enable transmission

TXE = “0” : Disable

TXE = “1” : Enable

Bank 2 R6 URC2 (UART Control Register 2)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 0 SBIM1 SBIM0 UINVEN 0 0 0

Bit 5 ~ Bit 4 ( SBIM1 ~ SBIM0 ) : Serial bus interface operation mode select.

TC2CK1 TC2CK0 Operation Mode

0 0 I/O mode

0 1 SPI mode

1 0 UART mode

1 1 Reserved

Bit 3 ( UINVEN ) : Enable UART TXD and RXD port inverse output.

UINVEN = “0” : Disable TXD and RXD port inverse output.

UINVEN = “1” : Enable TXD and RXD port inverse output.

Bank 2 R7 URS (UART Status Register)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

URRD8 EVEN PRE PRERR OVERR FMERR URBF RXE

Bit 7 ( URRD8 ) : Receiving data Bit 8

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 15

EM78P312N

8-Bit Microcontroller

Bit 6 ( EVEN ) : Select parity check

Bit 5 ( PRE ) : Enable parity addition

Bit 4 ( PRERR ) : Parity error flag.

Bit 3 ( OVERR ) : Overrun error flag.

Bit 2 ( FMERR ) : Framing error flag.

Bit 1 ( URBF ) : UART read buffer full flag.

EVEN = “0” : Odd parity EVEN = “1” : Even parity

PRE = “0” : Disable PRE = “1” : Enable

Set to 1 when parity error occurred, and cleared to 0 by software.

Set to 1 when overrun error occurred, and cleared to 0 by software.

Set to 1 when framing error occurred, and cleared to 0 by software.

Set to 1 when one character is received. Reset to 0 automatically when read

from the URS register. URBF will be cleared by hardware when receiving is

enabled. URBF bit is read-only. Therefore, reading the URS register is

necessary to avoid an overrun error.

Bit 0 ( RXE ) : Enable receiving

RXE = “0” : Disable RXE = “1” : Enable

Bank 2 R8 URRD (UART Receive Data Buffer)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

URRD7 URRD6 URRD5 URRD4 URRD3 URRD2 URRD1 URRD0

Bit 7 ~ Bit 0 ( UR RD7 ~ URRD0 ) : UART receive data buffer. Read only.

Bank 2 R9 URTD ( UART Transmit Data Buffer)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

URTD 7 URTD 6 URTD 5 URTD 4 URTD 3 URTD 2 URTD 1 URTD0

Bit 7 ~ Bit 0 ( UR TD 7 ~ URTD 0) : UART transmit data buffer. Write only.

Bank 3 R5 SPIC1 (SPI Control Register 1)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

SMP DCOL BRS2 BRS1 BRS0 EDS DORD WBE

Bit 7 ( SMP ) : SPI data input sample phase.

SMP = “0” : Input data sampled at middle of data output time SMP = “1” : Input data sampled at the end of data output time

16 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

In using the external clock, data input sample is fixed at the middle of data output time.

Bit 6 ( DCOL ) : SPI Data collision.

DCOL = “0” : No occurrence of Data collision

DCOL = “1” : Data collision occurred. It should be cleared by software. Bit 5 ~ Bit 3 ( BRS0 ~ BRS2 ) : SPI Clock Source Select

BRS2 BRS1 BRS0

0 0 0 Fc/213 0.95Kbit/s

0 0 1 Fc/211 3.8Kbit/s

0 1 0 Fc/210 7.6Kbit/s

0 1 1 Fc/28 30.5Kbit/s

1 0 0 Fc/26 122Kbit/s

1 0 1 Fc/25 244Kbit/s

1 1 0 External clock (/SCK pin) Enable /ss pin

1 1 1 External clock (/SCK pin) Disable /ss pin

Clock Sour ce

( Normal, Idle )

Max. Transfer Rate

( Fc = 8MHz )

Bit 2 ( EDS ) : Data shift out edge select.

EDS = “0” : Rising edge

EDS = “1” : Falling edge Bit 1 ( DORD ) : Data transmission order.

DORD = “0” : Shift left (MSB first)

DORD = “1” : Shift right (LSB first) Bit 0 ( WBE ) : Write buffer empty flag. Read only.

WBE = “0” : Write buffer empty

WBE = “1” : Not empty, set to “1” automatically when writing data to the data

buffer.

Bank 3 R6 SPIC2 (SPI Control Register 2)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

SPIS 0 0 0 0 SPIM1 SPIM0 RBF

Bit 7 ( SPIS ) : SPI start shift, set the bit to “1” and shift register starts to shift. It is

cleared by hardware when shifting is finished. In transferring the next data, it

must be set to “1” again.

SPIS = “0” : Finish shifting

SPIS = “1” : Start shifting

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 17

EM78P312N

8-Bit Microcontroller

Bit 2 ~ Bit 1 ( SPIM1 ~ SPIM0) : SPI Transfer Mode Select

Bit 0 ( RBF ) : Set to 1 by Buffer Full Detector, and cleared to 0 automatically when

Bank 3 R7 SPID (SPI Data Buffer)

Bit 7 Bit 6 Bi t 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

SPID7 SPID6 SPID5 SPID4 SPID3 SPID2 SPID1 SPID0

Bit 7 ~ Bit 0 ( SPID7 ~ SPID0 ) : SPI data buffer.

Bank 3 RA PHC1 (Pull High Control Register 1)

TC2CK1 TC2CK0 Transfer Mode

0 0 8-bit Transmit/Receive mode

0 1 8-bit Transmit mode

1 0 8-bit Receive mode

1 1 Reserved

reading data from the SPID register. RBF bit will be cleared by hardware

when enabling SPI. And RBF bit is read-only. Therefore, reading the

SPRL register is necessary to avoid data collision to occur (DCOL).

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

- - /PHE81 /PHE80 /PHE63 /PHE62 /PHE61 /PHE60

Bit 5 ~ 4 ( /PHE81 ~ /PHE80 ) : bits 1, 0 of Port 8 Pull high enable bit

/PHE8x = “0” : Enable P8x pull high

/PHE8x = “1” : Disable P8x pull high Bit 3 ~ 0 ( /PHE63 ~ /PHE60 ) : Bits 3 ~ 0 of Port 6 Pull high enable bit

/PHE6x = “0” : Enable P6x pull high

/PHE6x = “1” : Disable P6x pull high

Bank 3 RB PLC1 (Pull Low Control Register 1)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

- - /PLE81 /PLE80 /PLE63 /PLE62 /PLE61 /PLE60

Bit 5 ~ 4 ( /PLE81 ~ /PLE8 0 ) : Bits 1, 0 of Port 8 Pull low enable bit

/PLE8x = “0” : Enable P8x pull low

/PLE8x = “1” : Disable P8x pull low Bit 3 ~ 0 ( /PLE63 ~ /PLE60 ) : Bits 3 ~ 0 of Port 6 Pull low enable bit

/PLE6x = “0” : Enable P6x pull low

/PLE6x = “1” : Disable P6x pull low

18 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

Bank 3 RC PHC2 (Pull High Control Register 2)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

- - - - /PHE73 /PHE72 /PHE71 /PHE70

Bit 3 ~ 0 ( /PHE73 ~ /PHE70 ) : Bits 3 ~ 0 of Port 7 Pull high enable bit

/PHE7x = “0” : Enable P7x pull high

/PHE7x = “1” : Disable P7x pull high

Bank 3 RD PLC2 (Pull Low Control Register 2)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

- - - - /PLE73 /PLE72 /PLE71 /PLE70

Bit 3 ~ 0 ( /PLE73 ~ /PLE7 0 ) : Bits 3 ~ 0 of Port 7 Pull low enable bit

/PLE7x = “0” : Enable P7x pull low

/PLE7x = “1” : Disable P7x pull low

R10~R1F and R20~R3F (including Banks 0~3) are General Purpose Register

5.3 Special Purpose Registers

EM78P312N

8-Bit Microcontroller

A (Accumulator)

Internal data transfer operation, or instruction operand holding usually involves the

temporary storage function of the Accumulator. It is not an addressable register.

CONT (Contro l Registe r)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

WDTO /INT WDTP1 WDTP0 WDTE PSR2 PSR1 PSR0

The CONT register is both readable and writable.

Bit 7 ( WDTO ) : WDT output select

WDTO = “0” : Interrupt request

WDTO = “1” : Internal reset Bit 6 ( /INT ) : Interrupt enable flag

/INT = “0” : masked by DISI or hardware interrupt

/INT = “1” : enabled by ENI/RETI instructions Bit 5 ~ Bit 4 ( WDTP1 ~ WDTP 0 ) : WDT prescaler bits

WDTP1 WDTP0 Operating Mode

0 0 1:4

0 1 1:16

1 0 1:64

1 1 1:256

Bit 3 ( WDTE ) : WDT enable control.

WDTE = “0” : Disable WDTE = “1” : Enable

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 19

EM78P312N

8-Bit Microcontroller

Bit 2 ( PSR2 ) ~ Bit 0 ( PSR0 ) : TCC prescaler bits

IOC6 ~ IOC9 − I/O Port Co ntrol Registe r

INTCR − INT Control Register ( Address : 0Bh )

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

PSR2 PSR1 PSR0 Operating Mode

0 0 0 1:2

0 0 1 1:4

0 1 0 1:8

0 1 1 1:16

1 0 0 1:32

1 0 1 1:64

1 1 0 1:128

1 1 1 1:256

z "1" puts the relative I/O pin into high impedance, while "0" defines the relative

I/O pin as output.

z IOC6 and IOC9 registers are both readable and writable.

INT1NR INT0EN 0 INT3ES1 INT3ES0 0 INT1ES TC2ES

Bit 7 ( INT1NR ) : INT1 noise reject time select

INT1NR = “0” : Pulses less than 63/fc are eliminated as noise INT1NR = “1” : Pulses less than 15/fc are eliminated as noise

Bit 6 ( INT0EN ) : INT0 enable control

INT0E N = “0” : General I/O

INT0E N = “1” : /INT0 pin Bit 5 : Reserved Bit 4 ~ Bit 3 ( INT3ES1 ~ INT3ES0) : INT3 edge select

INT3ES1 INT3ES0 Edge Select

0 0 Rising

0 1 Falling

1 0 Both edge

1 1 Reserved

Bit 2: Reserved Bit 1 ( INT1ES ) : INT1 edge select

INT1ES = “0” : Rising edge

INT1ES = “1” : Falling edge Bit 0 (TC2ES) : Timer/Counter 2 edge select.

TC2ES = “0” : Rising edge

TC2ES = “1” : Falling edge

20 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

External Interrupt

INT Pin

/INT0 P60 ENI + INT0EN (IOCB) Falling -

INT1 P61 ENI + EXIE1 (IMR2) Rising or Falling 15/Fc, 63/Fc

INT3 P80, TC3 ENI + EXIE3 (IMR2)

/INT5 P73, /SLEEP ENI + EXIE5 (IMR2) - -

Secondary

Function Pin

Enable Condition Edge

Rising or Falling or Rising/Falling

ADOSCR − AD Offset Control Regi ster ( Address : 0Ch )

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

CALI SIGN VOF[2] VOF[1] VOF[0] 0 0 0

Bit 7 (CALI) : Calibration enable bit for A/D offset

CALI = “0” : disable Calibration

CALI = “1” : enable Calibration Bit 6 ( SIGN ) : Offset voltage Polarity bit

SIGN = “0” : Negative voltage

SIGN = “1” : Positive voltage

Digital Noise

Reject

7/Fc

Bit 5 ~ Bit 3 ( VOF[2] ~ VOF[0] ) : Offset voltage bits

IMR1 − Interrupt Mask Register 1 ( Address : 0Eh )

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

EXIE5 TCIE2 ADIE 0 EXIE3 TCIE4 SPIE TCIE3

Bit 7 ( EXIE5 ) : External/INT5 pin Interrupt enable bit.

EXIE5 = “0” : disable EXIF5 interrupt

EXIE5 = “1” : enable EXIF5 interrupt Bit 6 ( TCIE2 ) : Timer/Counter 2 Interrupt enable bit.

TCIE2 = “0” : disable TCIF2 interrupt

TCIE2 = “1” : enable TCIF2 interrupt Bit 5 ( ADIE ) : ADC complete interrupt enable bit.

ADIE = “0” : disable ADIF interrupt

ADIE = “1” : enable ADIF interrupt Bit 3 ( EXIE3 ) : External INT3 pin Interrupt enable bit.

EXIE3 = “0” : disable EXIF3 interrupt

EXIE3 = “1” : enable EXIF3 interrupt Bit 2 ( TCIE4 ) : Timer/Counter 4 Interrupt enable bit.

TCIE4 = “0” : disable TCIF4 interrupt

TCIE4 = “1” : enable TCIF4 interrupt

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 21

EM78P312N

8-Bit Microcontroller

Bit 1 ( SPIE ) : SPI Interrupt enable bit.

Bit 0 ( TCIE3 ) : Timer/Counter 3 Interrupt enable bit.

Individual interrupt is enabled by setting its associated control bit in the IMR1 to "1".

Global interrupt is enabled by the ENI instruction and is disabled by the DISI instruction.

The IMR1 register is both readable and writable.

IMR2 − Interrupt M ask Registe r 2( Address: 0Fh )

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bit 6 ( UERRIE ) : UART receive error interrupt enable bit.

SPIE = “0” : disable SPIF interrupt

SPIE = “1” : enable SPIF interrupt

TCIE3 = “0” : disable TCIF3 interrupt

TCIE3 = “1” : enable TCIF3 interrupt

0 UERRIE URIE UTIE TBIE EXIE1 0 TCIE0

UERRIE = “0” : disable UERRIF interrupt

UERRIE = “1” : enable UERRIF interrupt Bit 5 ( URIE ) : UART receive mode interrupt enable bit.

URIE = “0” : disable RBFF interrupt

URIE = “1” : enable RBFF interrupt Bit 4 ( UTIE ) : UART transmit mode interrupt enable bit.

UTI E = “0” : disable TBEF interrupt

UTI E = “1” : enable TBEF interrupt Bit 3 ( TBIE ) : Time base timer interrupt enable bit.

TBIE = “0” : disable TBIF interrupt

TBIE = “1” : enable TBIF interrupt Bit 2 ( EXIE1 ) : External INT 1 Interrupt enable bit.

EXIE1 = “0” : disable EXIF1 interrupt EXIE1 = “1” : enable EXIF1 interrupt

Bit 0 ( TCIE0 ) : TCC Interrupt enable bit.

TCIE0 = “0” : disable TCIF0 interrupt TCIE0 = “1” : enable TCIF0 interrupt

Individual interrupt is enabled by setting its associated control bit in the IMR2 to "1".

Global interrupt is enabled by the ENI instruction and is disabled by the DISI instruction.

The IMR2 register is both readable and writable.

22 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

5.4 CPU Operation Mode

Registers for CPU Operation Mode

R_BANK Address NAME Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 0 0X05 SCR 0 PS2 PS1 PS0 0 1 SIS REM

− − − − R/W R/W R/W − − R/W R/W

* R_BANK: Register Bank (Bits 7, 6 of R3), R/W: Read/Write

Reset Occurs

EM78P312N

8-Bit Microcontroller

SIS=1 + SLEP

Sleep Mode

CPU : Halts

Fosc: Stops

/SLEEP Pin Input

Idle Mode

CPU : Halts

Fosc: Oscillates

SIS=0 + SLEP

Normal Mode

CPU : Operating

Fosc: Oscillates

Interrupt

Fig. 5-4 Operation Mode and Switching

Table 2. Mode Switching Control

Mode Switch Switch Method Note

Normal Æ Sleep Set SIS = 1, execute SLEP instruction −

Sleep Æ Normal /SLEEP pin wake up −

Normal Æ Idle Set SIS = 0, execute SLEP instruction −

Idle Æ Normal Interrupt −

Table 3. Operation Mode

Operation Mode Frequency CPU Code

Reset Reset Reset

Signal

Clock

Normal Fosc

Idle

Sleep Turn off

Turn on

Halt

On-chip

Peripherals

Fosc

Halt

In Normal mode, the CPU core and on-chip peripherals operate in oscillator frequency.

In Idle mode, the CPU core halts, but the on-chip peripheral and oscillator circuit remain

active. Idle mode is released to Normal mode by any interrupt source. If the ENI

instruction is set, an interrupt will be serviced first followed by executing the next

instruction which is after the Idle mode is released and the interrupt service is finished.

If the ENI instruction is not set, the next instruction will be executed which is after the

Idle mode start instruction. Idle mode can also be released by setting the /RESET pin

to low and executing a reset operation.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 23

EM78P312N

8-Bit Microcontroller

In Sleep mode, the internal oscillator is turned off and all system operation is halted. Sleep mode is released by /SLEEP pin (level sensitive or edge sensitive can be set by System Control Register (SCR) Bit 0 (REM)). After a warm-up period, the next instruction will be executed which is after the Sleep mode start instruction. Sleep mode can also be released by setting the /RESET pin to low and executing a reset operation. In level sensitive mode, the /SLEEP pin must be confirmed in low level before entering Sleep mode. In edge sensitive mode, Sleep mode is started even when the /SLEEP pin is in high level.

Table 4. Wake-up Methods

1. Individual interrupt source in IMR1, IMR2

2. WDT interrupt request

3. /INT0

4. ENI instruction is not executed

1. Individual interrupt source in IMR1, IMR2

2. WDT interrupt request

3. /INT0

4. Execute ENI instruction

/SLEEP pin

/RESET pin Reset Reset Reset

WDT time out Reset Reset Reset

Note: * Don’t care

Sleep Mode

Wake-up Signal

R5 (SIS) = 1+SLEP

Instruction

No effect **

1. Wake-up

2. Jump to the next instruction or enter Sleep mode

** Interrupt request flag will be recorded

Idle Mode

R5 (SIS)= 0 + SLEP

Normal Mode

R5 (SIS)=(*)

Instruction

1. Wake-up

2. Jump to the next instruction or enter

No effect**

Idle mode

1. Wake-up

2. Jump to an Interrupt vector after RETI instruction, then jump

Interrupt

to the next instruction or enter Idle mode

No effect No effect

5.5 AD Converter

Registers for AD Converter Circuit

R_BANK Address NAME Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 1 0X0B ADCR

Bank 1 0X0C ADIC

Bank 1 0X0D ADDH

Bank 1 0X08 ADDL

Bank 0 0x0E ISFR1

SPR 0x0C ADOSCR

SPR 0x0E IMR1

* R_BANK : Register Bank (Bits 7, 6 of R3), R/W: Read / Write

* SPR : Special Purpose Registers

24 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

ADREF ADRUN ADCK1 ADCK0 ADP ADIS2 ADIS1 ADIS0

R/W R/W R/W R/W R/W R/W R/W R/W

ADE7 ADE6 ADE5 ADE4 ADE3 ADE2 ADE1 ADE0

R/W R/W R/W R/W R/W R/W R/W R/W

ADD9 ADD8 ADD7 ADD6 ADD5 ADD4 ADD3 ADD2

R R R R R R R R

ADD1 ADD0 0 TC2M TC2S TC2CK2 TC2CK1 TC2CK0

R R -- R/W R/W R/W R/W R/W

EXIF5 TCIF2 ADIF 0 EXIF3 TCIF4 SPIF TCIF3

R/W R/W R/W 0 R/W R/W R/W R/W

CALI SIGN VOF[2] VOF[1] VOF[0] 0 0 0

R/W R/W R/W R/W R/W -- -- --

EXIE5 TCIE2 ADIE 0 EXIE3 TCIE4 SPIE TCIE3

R/W R/W R/W 0 R/W R/W R/W R/W

AD7 (P97)

AD6 (P96)

AD5 (P95)

AD4 (P94)

AD3 (P93)

AD2 (P92)

AD1 (P91)

AD0 (P90)

EM78P312N

8-Bit Microcontroller

8 to 1 Analog swi tch

ADC

Fosc/4 Fosc/16 Fosc/32

4 to 1

MUX

(Successive Approximation)

VDD

VREF

Power Down

Start to Convert

7 - 0 2 1 0

5 4

5 5 9 8 7 6 5 4 3 2 1 0

IMR1ISFR1ADCRADCRADIC

DATA BUS

6 3 7

ADCR

Fig. 5-5 AD Converter

It is a 10-bit successive approximation type AD converter. The upper side of analog reference voltage can select either internal VDD or external input pin P97 (VREF) by setting the ADREF bit in ADCR.

ADC Dat a Re gister

When the A/D conversion is completed, the result is loaded to the ADDH (8 bit) and ADDL (2 bit). The START/END bit is cleared, and the ADIF is set.

A/D Sampling Time

The accuracy, linearity, and speed of the successive approximation A/D converter are dependent on the properties of the ADC. The source impedance and the internal sampling impedance directly affect the time required to charge the sample holding capacitor. The application program controls the length of the sample time to meet the specified accuracy. Generally speaking, the program should wait for 2 μs for each KΩ of the analog source impedance and at least 2 μs for the low-impedance source. The maximum recommended impedance for the analog source is 10KΩ at V

DD =5V. After

the analog input channel is selected, this acquisition time must be done before A/D conversion can be started.

A/D Conversion Time

ADCK0 and ADCK1 select the conversion time (Tct), in terms of instruction cycles. This allows the MCU to run at maximum frequency without sacrificing accuracy of A/D conversion. For the EM78P312N, the conversion time per bit is about 4μs. Table 5 shows the relationship between Tct and the maximum operating frequencies.

Table 5

ADCK1:0 Operation Mode

0 0 Fc/4 1MHz 250kHz (4μs) 48μs (20.8kHz)

0 1 Fc/16 4MHz 250kHz (4μs) 48μs (20.8kHz)

1 0 Fc/32 8MHz 250kHz (4μs) 48μs (20.8kHz)

1 1 Reserved - - -

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

Max. Frequency

• 25

(Fc)

Max. Conversion

Rate per Bit

Max. Conversion

Rate

EM78P312N

8-Bit Microcontroller

5.6 Time Base Timer and Keytone Generator

Registers for AD Converter Circuit

R_BANK Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 1 0X0E TBKTC

Bank 0 0x0F ISFR2

SPR 0x0F IMR2

TEN TCK1 TCK0 0 TBTE N TBTCK 2 TBTCK1 TBTCK 0

R/W R/W R/W -- R/W R/W R/W R/W

0 UERRIF RBFF TBEF TBIF EXIF1 0 TCIF0

0 R/W R/W R/W R/W R/W 0 R/W 0 UERRIE URIE UTIE TBIE EXIE1 0 TCIE0

0 R/W R/W R/W R/W R/W 0 R/W

Output Enable (P63)

/TONE Pin Fosc/2 Fosc/2 Fosc/2 Fosc/2

Data Output

TCK1:0

MUX

Output Latch

D Q

TEN

TBKTC

Fig. 5-6 Tone Output Pin Configuration

The Keytone output can generate 50% duty pulse for driving a piezo-electric buzzer.

The P63 must be set to “1” before the keytone is enabled and it can be halted by setting

P63 to “0”.

P63

TEN

TONE Pin

Fig. 5-7 Tone Output Pi n Timing Chart

26 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

Fosc/2

EM78P312N

8-Bit Microcontroller

MUX

TBTEN

Falling Edge

Detector

TBT

Interrupt

TBTCK2:0

TBKTC

Fig. 5-8 TBT Confi guration

The Time Base Timer is used to generate the base time for key scan or dynamic

display processing. The interrupt is generated in the first falling edge of the source

clock after TBTEN is set to “1”.

Source Clock

TBTEN

TBT Interrupt

Fig. 5-9 Time Base Timer Timing Chart

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 27

EM78P312N

8-Bit Microcontroller

5.7 UART (Universal As ynchronous Receiver/Transmitter)

Registers for UART Circuit

R_BANK A ddress Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 2 0X05 URC1

Bank 2 0X06 URC2

Bank 2 0X07 URS

Bank 2 0X08 URRD

Bank 2 0X09 URTD

Bank 0 0x0F ISFR2

SFR 0x0F IMR2

URTD8 UMODE1 UMODE0 BRATE2 BRATE1 BRATE0 UTBE TXE

R/W R/W R/W R/W R/W R/W R R/W

0 0 SBIM1 SBIM0 UINVEN 0 0 0

-- -- R/W R/W R/W -- -- --

URRD8 EVEN PRE PRERR OVERR FMERR URBF RXE

R/W R/W R/W R/W R/W R/W R R/W

URRD7 URRD6 URRD5 URRD4 URRD3 URRD2 URRD1 URRD0

R R R R R R R R

URTD 7 URTD 6 URTD 5 URTD 4 URTD 3 URTD 2 URTD 1 URTD0

W W W W W W W W

0 UERRIF RBFF TBEF TBIF EXIF1 0 TCIF0

-- R/W R/W R/W R/W R/W -- R/W 0 UERRIE URIE UTIE TBIE EXIE1 0 TCIE0

-- R/W R/W R/W R/W R/W -- R/W

TC4

Selector

Fsystem

RXE

RX shift re gister

UINVEN

Baud rate generator

RX Control TX ControlInterrupt

URRD

Control

Parity control

Error flag

Data Bus

URTD8

TXE

URTDURRD8

UINVEN

Fig. 5-10 Function Block Diagram

In Universal Asynchronous Receiver Transmitter (UART), each transmitted or received

character is individually synchronized by framing it with a start bit and stop bit.

Full duplex data transfer is possible since the UART has independent transmit and

receive sections. Double buffering for both sections allows the UART to be

programmed for continuous data transfer.

28 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

The figure below shows the general format of one character sent or received. The

communication channel is normally held in the marked state (high). Character

transmission or reception starts with a transition to the space state (low).

The first bit transmitted or received is the start bit (low). It is followed by the data bits, in

which the least significant bit (LSB) comes first. The data bits are followed by the parity

bit. If present, then the stop bit or bits (high) confirm the end of the frame.

In receiving, the UART synchronizes on the falling edge of the start bit. When two or

three “0” are detected during three samples, it is recognized as normal start bit and the

receiving operation is started.

Idle state

START bit

D0 D1 D2 Dn

Parity bit

STOP bit

(mark)

1 bit 7 or 8 bits

One charac ter or frame

1 bit 1 bits

Fig. 5-11 Data Format in UART

5.7.1 UART Mode

There are three UART modes. Mode 1 (7 bits data) and Mode 2 (8 bits data) allow the

addition of a parity bit. The parity bit addition is not available in Mode 3. The Figure

below shows the data format in each mode.

12345 11109876

START

7 bits DATA

7 bits DATA Parity

8 bits DATA

8 bits DATA Parity

9 bits DATA

Fig. 5-12 UART Mode

STOP

Mode 1

Mode 2

Mode 3

UMODE PRE 0 0 0

0 0 1

0 1 0

0 1 1

1 0 X

5.7.2 Transmitting

In transmitting serial data, the UART operates as follows:

1. Set the TXE bit of the URC1 register to enable the UART transmission function.

2. Write data into the URTD register and the UTBE bit of the URC1 register will be set

by hardware.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 29

EM78P312N

8-Bit Microcontroller

3. Start transmitting.

4. Serially transmitted data are transmitted in the following order from the TX pin.

5. Start bit: one “0” bit is output.

6. Transmit data: 7, 8 or 9 bits data are output from the LSB to the MSB.

7. Parity bit: one parity bit (odd or even selectable) is output.

8. Stop bit: one “1” bit (stop bit) is output.

Mark state: output “1” continues until the start bit of the next transmitted data.

After transmitting the stop bit, the UART generates a TBEF interrupt (if enabled).

5.7.3 Receiving

In receiving, the UART operates as follows:

1. Set RXE bit of the URS register to enable the UART receiving function.

The UART monitors the RX pin and synchronizes internally when it detects a start

bit.

2. Receive data is shifted into the URRD register in the order from LSB to MSB.

3. The parity bit and the stop bit are received.

After one character received, the UART generates a RBFF interrupt (if enable).

And URBF bit of URS register will be set to 1.

4. The UART makes the following checks:

(a) Parity check: The number of 1 of the received data must match the even or

odd parity setting of the EVEN bit in the URS register.

(b) Frame check: The start bit must be 0 and the stop bit must be 1.

means the URRD register should be read out) before next received data is

loaded into the URRD register.

If any checks failed, the UERRIF interrupt will be generated (if enabled), and an

error flag is indicated in PRERR, OVERR or FMERR bit. The error flag should be

cleared by software else the UERRIF interrupt will occur when the next byte is

received.

5. Read received data from URRD register. And URBF bit will be clear by hardware.

5.7.4 Baud Rate Generator

The baud rate generator is comprised of a circuit that generates a clock pulse to

determine the transfer speed for transmission/reception in the UART.

The BRATE2~BRATE0 bits of the URC1 register can determine the desired baud rate.

30 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

5.8 SPI (Serial Peripheral Interface)

Registers for the SPI Circuit

R_BANK Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 3 0X05 SPIC1

Bank 3 0X06 SPIC2

Bank 3 0X07 SPID

Bank 0 0x0E ISFR1

SFR 0x0E IMR1

SMP DCOL BRS2 BRS1 BRS0 EDS DORD WBE

R/W R/W R/W R/W R/W R/W R/W R

SPIS 0 0 0 0 SPIM1 SPIM0 RBF

R/W -- -- -- -- R/W R/W R

SPID7 SPID6 SPID5 SPID4 SPID3 SPID2 SPID1 SPID0

R/W R/W R/W R/W R/W R/W R/W R/W

EXIF5 TCIF2 ADIF 0 EXIF3 TCIF4 SPIF TCIF3

R/W R/W R/W -- R/W R/W R/W R/W

EXIE5 TCIE2 ADIE 0 EXIE3 TCIE4 SPIE TCIE3

R/W R/W R/W -- R/W R/W R/W R/W

EM78P312N

8-Bit Microcontroller

SDI

SDO

/SS

Tsystem

DCOL

Collision Detector

BRS2~0

/SS enable

4, 16, 64, 256,1024

TC1/2

RBFI

RBF

Set to 1

Buffer Full

Detector

SHIFT Register

BRS2~0

Prescaler

Fig. 5-13 SPI Block Diagram

Clear

Tx Empty

Detector

SPID re g

(8 bits)

SMP

DORD

Master/Slave

Edge Select

EDS

TLS0~1

Edge

Select

EDS

SCK

The serial interface are connected to external devices via P70 (/SCK), P71 (SI), P72

(SO). The serial interface can also be used as I/O port. In the transmit mode, P71 can

be used as normal I/O port and in receive mode, P72 and P71 can be used as normal

I/O ports.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 31

EM78P312N

8-Bit Microcontroller

5.8.1 Serial Clock

Six internal clocks can be selected by setting BRS0 ~ BRS2 and the clock output to the

outside from /SCK (P70) pin. The External clock can also be used and connected to

/SCK (P70) pin.

5.8.2 Shift Direction and Sample Phase

Setting up the DORD bit of the SPIC1 register can determine the shift direction. Setting

up the EDS bit of the SPIC1 register can select the rising edge or falling edge and latch

the data. Setting up the SMP bit of the SPIC2 register can select the sample phase at

the middle or at the end of the data output time.

5.8.3 Transfer Mode

The transmit, receive, transmit/receive mode can be selected by setting SPIM0 ~

SPIM1.

(a) 8-bit Transmit Mode

Set SPIM0 ~ SPIM12 to transmit mode and write data to the data buffer SPID.

Set SPIS to “1” to start transmission. The data are output sequentially to the SO

pin in synchronous with the serial clock. When the final bit of transfer data has

been transferred, the SPI interrupt is generated and SPIS is cleared to “0” by

hardware. In order to transmit the next data, the SPIS must be set to “1” again by

software. If the next data is not written to the data buffer, the transfer is not

started when using the internal clock.

shi f t star t shi f t st art

SPI S

RBF

WBE

SO pi n

a0 a1 a2 a3 a4 a5 a6 a7

shi f t f i ni sh

b0 b1 b2 b3 b4 b5 b6 b7

SPI F

SPI D

write data

Fig. 5-14 Transmit Mode (8-bit, 1 word)

32 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

write data

EM78P312N

8-Bit Microcontroller

(b) 8-bit Receive Mode

Setting SPIM0 ~ SPIM1 to receive mode and setting SPIS to “1” to start receiving.

The data are input sequentially from the SI pin in synchronous with the serial

clock. When the final bit of transfer data has been received, the SPI interrupt is

generated and SPIS is cleared to “0” by hardware. In order to receive the next

data, the SPIS must be set to “1” again by software. If the current data is not read

out from the data buffer, receiving is not started when using internal clock.

shi f t st ar t

RBF

shift start

shift finish

WBE

/SCK pin

SI p i n

a0 a1 a2 a3 a4 a5 a6 a7

b0 b1 b2 b3 b4 b5 b6 b7

SPI F

SPI D

Fig. 5-15 Receive Mode (8-bit , 1 word)

r ead da t a

r ead d at a

Set SPIM0 ~ SPIM1 to transmit/receive mode and write data to data buffer SPID.

Set SPIS to “1” to start transferring. The data are output to the SO pin and input

from the SI pin sequentially in synchronous with the serial clock. When the

number of data words specified has been transferred, the SPI interrupt is

generated and SPIS is cleared to “0” by hardware. In order to receive the next

data, the SPIS must be set to “1” again by software. Writing data in transmit

mode and reading data in receive mode use the same data buffer. If the current

data is not read out from the data buffer and then write the data to data buffer, the

transfer is not started when using internal clock. Always write the data to be

transmitted after reading the received data.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 33

EM78P312N

8-Bit Microcontroller

shift start shift start

SPI S

RBF

WBE

shift finish

/SCK pin

SO p i n

SI p i n

a0 a1 a2 a3 a4 a5 a6 a7

c0 c1 c2 c3 c4 c5 c6 c7

b0 b1 b2 b3 b4 b5 b6 b7

d0 d1 d2 d3 d4 d5 d6 d7

SPI F

SPI D

write data

read data

write data

Fig. 5-16 Transmit/Receive Mode (8-bit, 1 word)

r ead dat a

(d) Multiple Device Connect (/SS)

When selecting external clock for transfer clock source, the /SS function can be

used. This pin (/SS) will be active when the /SS function is enabled, else the /SS

pin is a general purpose I/O. Ignore the data on the SDI and SDO pins while /SS

is high, since the SDO is no longer driven.

SDO SDI SCK

/SS

P.67

P67 P66 P 65

P65 P 64

P64

/SS

Slave Device 2

SCK

SDO

SDI

/SS

SCK

Slave Device 3

SDO

SDI

/SS

SCK

Slave Device 4

SDO

SDI

/SS

SCK

Slave Device 1

Master

SDO

SDI

Fig. 5-17 Th e SPI Configuration Example of Si ngle-Mast er and Multi-Slaves

34 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

5.9 Timer/Counter 2

Registers for Timer/Counter 2 Circuit

R_BANK Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 1 0X08 TC2CR

Bank 1 0X09 TC2DH

Bank 1 0X0A TC2DL

Bank 0 0x0E ISFR1

SFR 0x0B INTCR

SFR 0x0E IMR1

ADD1 ADD0 0 TC2M TC2S TC2CK2 TC2CK1 TC2CK0

R R -- R/W R/W R/W R/W R/W

TC2D15 TC2D14 TC2D13 TC2D12 TC2D11 TC2D10 TC2D9 TC2D8

R/W R/W R/W R/W R/W R/W R/W R/W

TC2D7 TC2D6 TC2D5 TC2D4 TC2D3 TC2D2 TC2D1 TC2D0

R/W R/W R/W R/W R/W R/W R/W R/W

EXIF5 TCIF2 ADIF 0 EXIF3 TCIF4 SPIF TCIF3

R/W R/W R/W -- R/W R/W R/W R/W

INT1NR INT0EN 0 INT3ES1 INT3ES0 0 INT1ES TC2ES

R/W R/W R/W R/W R/W R/W

EXIE5 TCIE2 ADIE 0 EXIE3 TCIE4 SPIE TCIE3

R/W R/W R/W -- R/W R/W R/W R/W

TC2ES

TC2

fc/2 fc/2 fc/2 fc/2

TC2CK

MUX

TC2CR

Window

TC2S

16-bit Up-counter

TCR2H

TCR2L

Clear

Comparator

TC2 Interrupt

Fig. 5-18 Co nfiguration of Timer/Counter 2

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 35

EM78P312N

8-Bit Microcontroller

5.9.1 Timer Mode

In Timer mode, counting up is performed using the internal clock. When the contents of

the up-counter matched with the TCR2 (TCR2H+TCR2L), then interrupt is generated

and the counter is cleared. Counting up resumes after the counter is cleared.

Internal clock

Up- counter

TCR2

TC2 int er rupt

01 2 4 n-1 n

n-2n- 33

mat ch

counter

cl ear

Fig. 5-19 Timer Mode Timing Chart

5.9.2 Counter Mode

In Counter mode, counting up is performed using the external clock input pin (TC2 pin)

and either rising or falling can be selected by setting TC2ES. When the contents of

the up-counter matched with the TCR2 (TCR2H+TCR2L), then interrupt is generated

and the counter is cleared. Counting up resumes after the counter is cleared.

TC2 Pin

Up- counter

TCR2

01 2 3 n- 1 n

n-2

match

counter

cl ear

TC2 interrupt

Fig. 5-20 Counter Mode Timing Chart (TC2ES = 1)

5.9.3 Window Mode

In Window mode, counting up is performed on the rising or falling edge of the pulse

that is logical AND of an internal clock and the TC2 pin (window pulse). When the

contents of the up-counter matched with the TCR2 (TCR2H+TCR2L), then interrupt is

generated and the counter is cleared. The frequency (window pulse) must be slower

than the selected internal clock.

Writing to the TCR2L, the comparison is inhibited until TCR2H is written.

36 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

TC2 pin

Internal clock

EM78P312N

8-Bit Microcontroller

Up- counter

TCR2

01 2 n-3 n-1 n

n-2

match

TC2 interrupt

Fig. 5-21 Window Mode Timing Chart

5.10 Timer/Counter 3

Registers for Timer/Counter 3 Circuit

R_BANK Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 1 0X05 TC3CR

Bank 1 0X06 TC3DA

Bank 1 0X07 TC3DB

Bank 0 0x0E ISFR1

SFR 0x0B INTCR

SFR 0x0E IMR1

TC3CAP TC3S TC3CK1 TC3CK0 TC3M 0 0 0

R/W R/W R/W R/W R/W -- -- --

TC3DA7 TC3DA6 TC3DA5 TC3DA4 TC3DA3 TC3DA2 TC3DA1 TC3DA0

R/W R/W R/W R/W R/W R/W R/W R/W

TC3DB7 TC3DB6 TC3DB5 TC3DB4 TC3DB3 TC3DB2 TC3DB1 TC3DB0

R/W R/W R/W R/W R/W R/W R/W R/W

EXIF5 TCIF2 ADIF 0 EXIF3 TCIF4 SPIF TCIF3

R/W R/W R/W -- R/W R/W R/W R/W

INT1NR INT0EN 0 INT3ES1 INT3ES0 0 INT1ES TC2ES

R/W R/W -- R/W R/W -- R/W R/W

EXIE5 TCIE2 ADIE 0 EXIE3 TCIE4 SPIE TCIE3

R/W R/W R/W -- R/W R/W R/W R/W

counter

cl ear

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 37

EM78P312N

8-Bit Microcontroller

INT3ES

TC3 pin

Edge

Detector

TC3M

Falling

InhibitRising

Capture Control

TC3

Interrupt

TC2CK

MUX

TC3CR

TC3S

CAP

Capture

TCR3B

8-bit Up-counter

TCR3A

Overflow

Comparator

Capture

fc/2

fs/2

fc/2 fc/2

fs/2

Fig. 5-22 Configuratio n of Timer/Counter3

5.10.1 Timer Mode

In Timer mode, counting up is performed using the internal clock. When the contents of

the up-counter matched with the TCR3DA, then interrupt is generated and the counter

is cleared. Counting up resumes after the counter is cleared. The current contents of

the up-counter are loaded into the TCR3DB by setting TC3CAP to “1” and the TC3CAP

is cleared to “0” after capture automatically.

5.10.2 Counter Mode

In Counter mode, counting up is performed using the external clock input pin (TC3 pin)

and either rising or falling edge can be selected by INT3ES0 but both edge cannot

be used. When the contents of the up-counter matched with the TCR3DA, then

interrupt is generated and the counter is cleared. Counting up resumes after the

counter is cleared. The current contents of the up-counter are loaded into the TCR3DB

by setting TC3CAP to “1” and the TC3CAP is cleared to “0” after capture automatically.

5.10.3 Capture Mode

In Capture mode, the pulse width, period and duty of the TC3 input pin are measured in

this mode, which can be used in decoding the remote control signal. The counter is

free running by the internal clock. On the rising (falling) edge of TC3 pin input, the

contents of the counter is loaded into TCR3DA, then the counter is cleared and

interrupt is generated. On the falling (rising) edge of TC3 pin input, the contents of the

counter are loaded into TCR3DB. The counter is still counting, on the next rising edge

38 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

of the TC3 pin input, the contents of the counter are loaded into TCR3A, counter is

cleared and interrupt is generated again. If an overflow before the edge is detected,

the FFH is loaded into TCR3DA and an overflow interrupt is generated. During

interrupt processing, it can be determined whether or not there is an overflow by

checking whether the TCR3DA value is FFH. After an interrupt (capture to TCR3DA or

overflow detection) is generated, capture and overflow detection are halted until

TCR3DA is read out.

Source Clock

Up-counter

K-2 K-1 K

m-1 m m+1 n-1 n

1 2 3 FE FF 0 123

TC3 Pin Input

TCR3DA

TCR3DB

TC3 Interrupt

Capture Capture

n FF (Overflow)

Overflow

Reading TCR3DA

Fig. 5-23 Timing Chart of Capture Mo de

5.11 Timer/Counter 4

Registers for Timer 4 Circuit

R_BANK Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bank 0 0X0B TC4CR

Bank 0 0X0C TC4D

Bank 0 0x0E ISFR1

SFR 0x0E IMR1

TC4FF1 TC4FF0 TC4S TC4CK2 TC4CK1 TC4CK0 TC4M1 TC4M0

R/W R/W R/W R/W R/W R/W R/W R/W

TC4D7 TC4D6 TC4D5 TC4D4 TC4D3 TC4D2 TC4D1 TC4D0

R/W R/W R/W R/W R/W R/W R/W R/W

EXIF5 TCIF2 ADIF 0 EXIF3 TCIF4 SPIF TCIF3

R/W R/W R/W -- R/W R/W R/W R/W

EXIE5 TCIE2 ADIE 0 EXIE3 TCIE4 SPIE TCIE3

R/W R/W R/W -- R/W R/W R/W R/W

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 39

EM78P312N

8-Bit Microcontroller

TC4 pin

fc/2 fc/2

fc/2

TC4M(1,*)

TC4FF

TC4 Interrupt

F/F

Clear

Set

Toggle

TC4M (1,1)

TC4CK

MUX

TC4S

TC4CR

Clear

8-bit Up-counter

TCR4

Overflow

Match

Comparator

Fig. 5-24 Timer/Counter 4 Configurat ion

5.11.1 Timer Mode

In Timer mode, counting up is performed using the internal clock. When the contents of the up-counter matched with the TCR4, then interrupt is generated and the counter is cleared. Counting up resumes after the counter is cleared.

5.11.2 Counter Mode

In Counter mode, counting up is performed on the rising edge of the external clock

input pin (TC4 pin). When the contents of the up-counter matched with the TCR4, then interrupt is generated and the counter is cleared. Counting up resumes after the counter is cleared.

/PWM, /PDO Pin

5.11.3 PDO Mode

In Programmable Divider Output (PDO) mode, counting up is performed using the internal clock. The contents of TCR4 are compared with the contents of the up-counter. The F/F output is toggled and the counter is cleared each time a match is found. The F/F output is inverted and output to /PDO pin. This mode can generate 50% duty pulse output. The F/F can be initialized by the program and it is initialized to

40 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

“0” during a reset. A TC4 interrupt is generated each time the /PDO output is toggled.

Source Clock

Up-counter

TCR4

F/F

/PDO Pin

TC4 Interrupt

n-1

01 3

n-1

Fig. 5-25 Timing Chart for PDO Mod e

01 n-1

012

EM78P312N

8-Bit Microcontroller

5.11.4 PWM Mode

In Pulse Width Modulation (PWM) Output mode, counting up is performed using the

internal clock. The contents of the TCR4 are compared with the contents of the

up-counter. The F/F is toggled when match is found. The counter is still counting, the

F/F is toggled again when the counter overflows, then the counter is cleared. The F/F

output is inverted and output to the /PWM pin. A TC4 interrupt is generated each time

an overflow occurs. TCR4 is configured as a 2-stage shift register and, during output,

will not switch until one output cycle is completed even if TCR4 is overwritten.

Therefore, the output can be changed continuously. TRC4 is also shifted the first time

by setting TC4S to “1” after data is loaded to TCR4.

Source Clock

Up-counter

n+1

n-1

n+2

FE FF

n-1

n+2

n+1

FE FF

m-1

TCR4

n/n

Match

F/F

/PWM

TC4 Interrupt

Fig. 5-26 Timing Chart for PWM Mode

5.12 TCC/WDT & Prescaler

An 8-bit counter is available as prescaler for the TCC. The PSR0~PSR2 bits determine

the ratio. The prescaler is cleared each time the instruction is written to TCC under

TCC mode.

R1 (TCC) is an 8-bit timer/counter. The clock source of TCC is the internal clock. If the

TCC signal source is from the internal clock, TCC will increase by 1 at every instruction

cycle (without prescaler). CLK=Fosc/2 or CLK=Fosc/4 selection is determined by the

CODE Option bit CLK status. CLK=Fosc/2 is used if CLK bit is "0", and CLK=Fosc/4 is

used if CLK bit is "1".

The watchdog timer is a free running on-chip RC oscillator. During normal operation

mode, a WDT time-out (if enabled) will cause the device to reset or interrupt by setting

WDTO. The WDT can be enabled or disabled any time during normal mode by

software programming. Without prescaler, the WDT time-out period is approximately

18 ms (default). The WDT can also be used as a timer to generate an interrupt at fixed

interval.

Overflow

n/m m/m

Match

Overwrite

Overflow

1 Period

Shift

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 41

EM78P312N

8-Bit Microcontroller

5.13 I/O Ports

The I/O registers, Port 6, Port 7, Port 8, and Port 9 are bi-directional tri-state I/O ports.

Each I/O pin can be defined as “input” or “output” pin by the I/O control register (IOC6 ~

IOC9). The I/O registers and I/O control registers are both readable and writable. The

I/O interface circuits for Port 6, Port 7, Port 8, and Port 9 are shown in Fig. 5-26.

PCRD

CLK

PCWR

PORT

Fig. 5-27 The I/O Port and I/O Control Register Circuit

5.14 Reset and Wake-up

5.14.1 Reset

A reset is initiated by one of the following events:

(1) Power-on reset

(2) /RESET pin input “low”

(3) WDT timeout. (if enabled)

The device is kept in a reset condition for a period of approx. 18ms

start-up timer period) after the reset is detected. Once a reset occurs, the following

functions are performed.

 The oscillator starts or is running

CLK

PDWR

PDRD

IOD

(one oscillator

 The Program Counter (R2) is reset to all “0”.

 When power is switched on, the upper two bits of R3, the upper two bits of R4 and

the Bits 6 ~ 4 of R5 are cleared.

 All I/O port pins are configured as input mode (high-impedance state).

Note: VDD = 5V, set up time period = 16.2ms ± 30%

DD = 3V, set up time period = 19.6ms ± 30%

42 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

 The Watchdog timer and prescaler are cleared.

 Upon power on, the upper two bits of R3 are cleared.

 Upon power on, the upper two bits of R4 are cleared.

 Upon power on, the upper three bits of R5 are cleared.

 The bits of CONT register are set to all “1” except Bit 6 (INT flag).

 ISFR0, ISFR1, ISFR2 register and IMR1, IMR2 registers are cleared.

The controller has two modes for power saving.

(1) SLEEP mode: R5 (SIS) = 1, SLEP instruction.

The internal oscillator is turned off and all system operation is halted.

(2) Idle mode: R5 (SIS) = 0, SLEP instruction

The CPU core halts but the on-chip peripheral and oscillator circuit remain active.

5.14.2 Wake-up from Sleep Mode

(1) External /SLEEP pin

The controller will be waken up and execute the next instruction after entering Sleep

mode. All the registers will maintain their original values before “SLEP” instruction was

executed.

(2) /RESET pin pull low

This will reset the controller and starts the program at address zero.

(3) WDT time out

This will reset the controller and run the program at address zero.

5.14.3 Wake-up from Idle Mode

(1) All interrupt

In all these cases, user should always enable the circuit before entering Idle mode.

After wake-up, all registers will maintain their original values before entering “SLEP”

instruction, then service an interrupt subroutine or proceed with next instruction by

setting individual interrupt enable bit. After servicing an interrupt sub-routine (“RETI”

instruction), the program will jump from “SLEP” instruction to the next instruction.

(2) /RESET pin pull low

This will reset the controller and run the program at address zero.

(3) WDT time out

This will reset the controller and run the program at address zero.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 43

EM78P312N

8-Bit Microcontroller

Address Name Reset Type Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0x06 IOC6

0x07 IOC7

0x08 IOC8

0x09 IOC9

0x0B INTCR

ADOSC

0x0C

0x0E IMR1

0x0F IMR2

N/A CONT

0x00

0x01

0x02

0x03

0x04

(IAR)

(TCC)

(PC)

(SR)

(RSR)

Table 6. Summary of the Initialized Values for Registers

Bit Name C67 C66 C65 C64 C63 C62 C61 C60

Power-on 1 1 1 1 1 1 1 1

/RESET and WDT time out 1 1 1 1 1 1 1 1

Wake-up from Sleep, Idle mode P P P P P P P P Bit Name X X X X C73 C72 C71 C70 Power-on U U U U 1 1 1 1 /RESET and WDT time out U U U U 1 1 1 1 Wake-up from Sleep, Idle mode U U U U P P P P Bit Name X X X X X X C81 C80 Power-on U U U U U U 1 1 /RESET and WDT time out U U U U U U 1 1 Wake-up from Sleep, Idle mode U U U U U U P P Bit Name C97 C96 C95 C94 C93 C92 C91 C90 Power-on 1 1 1 1 1 1 1 1 /RESET and WDT time out 1 1 1 1 1 1 1 1 Wake-up from Sleep, Idle mode P P P P P P P P Bit Name INT1NR INT0EN X Power-on 0 0 0 0 0 0 0 0 /RESET and WDT time out 0 0 0 0 0 0 0 0 Wake-Up from Sleep, Idle mode P P P P P P P P Bit Name CALI SIGN VOF2 VOF1 VOF0 X X X Power-on 0 0 0 0 0 U U U /RESET and WDT time out 0 P P P P U U U Wake-up from Sleep, Idle mode 0 P P P P U U U Bit Name EXIE5 TCIE2 ADIE X EXIE3 TCIE4 SPIE TCIE3 Power-on 0 0 0 U 0 0 0 0 /RESET and WDT time out 0 0 0 U 0 0 0 0 Wake-up from Sleep, Idle mode P P P U P P P P Bit Name X Power-on U 0 0 0 0 0 U 0 /RESET and WDT time out U 0 0 0 0 0 U 0 Wake-Up from Sleep, Idle mode U P P P P P U P Bit Name WDT0 /INT WDTP1 WDTP0 WDTE PSR2 PSR1 PSR0 Power-on 0 0 0 0 0 0 0 0 /RESET and WDT time out 0 0 0 0 0 0 0 0 Wake-up from Sleep, Idle mode P P P P P P P P Bit Name - - - - - - - -

Power-on U U U U U U U U

/RESET and WDT time out P P P P P P P P

Wake-up from Sleep, Idle mode

Bit Name - - - - - - - -

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name - - - - - - - -

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode Jump to interrupt vector or execute next instruction Bit Name RBS1 RBS0 X T P Z DC C Power-on 0 0 0 1 1 U U U /RESET and WDT time out 0 0 0 t t P P P Wake-up from Sleep, Idle mode P P P t t P P P Bit Name X GRBS0 RSR5 RSR4 RSR3 RSR2 RSR1 RSR0 Power-on 0 0 U U U U U U /RESET and WDT time out 0 0 P P P P P P Wake-Up from Sleep, Idle mode P P P P P P P P

UERRIE

P P P P P P P P

INT3ES1 INT3ES0

URIE UTIE TBIE EXIE1 X TCIE0

X INT1ES TC2ES

44 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

Address Name Reset Type Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bit Name X X X PS0 X X SIS REM

0x05 SCR

0x06 Port 6

0x07 Port 7

0x08 Port 8

0x09 Port 9

0x0B TC4CR

0x0C TC4D

0X0D ISFR0

0X0E ISFR1

0X0F ISFR2

Power-on U 0 0 0 U U 0 0

/RESET and WDT time out U 0 0 0 U U 0 0

Wake-up from Sleep, Idle mode U P P P U U P P

Bit Name P67 P66 P65 P64 P63 P62 P61 P60

Power-on 1 1 1 1 1 1 1 1

/RESET and WDT time out 1 1 1 1 1 1 1 1

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name X X X X P73 P72 P71 P70

Power-on U U U U 1 1 1 1

/RESET and WDT time out U U U U 1 1 1 1

Wake-up from Sleep, Idle mode U U U U P P P P

Bit Name X X X X X X P81 P80

Power-on U U U U U U 1 1

/RESET and WDT time out U U U U U U 1 1

Wake-up from Sleep, Idle mode U U U U U U P P

Bit Name P97 P96 P95 P94 P93 P92 P91 P90

Power-on 1 1 1 1 1 1 1 1

/RESET and WDT time out 1 1 1 1 1 1 1 1

Wake-Up from Sleep, Idle mode P P P P P P P P

Bit Name TC4FF1 TC4 FF0 TC4S TC4CK2 TC4 CK1 TC4 CK0 TC4M1 TC4M0

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name TC4D7 TC4D6 TC4D5 TC4D4 TC4D3 TC4D2 TC4D1 TC4D0

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name X X INT3F INT3R X X WDTIF EXIF0

Power-on U U 0 0 U U 0 0

/RESET and WDT time out U U 0 0 U U 0 0

Wake-up from Sleep, Idle mode U U P P U U P P

Bit Name EXIF5 TCIF2 ADIF X EXIF3 TCIF4 SPIF TCIF3

Power-on 0 0 0 U 0 0 0 0

/RESET and WDT time out 0 0 0 U 0 0 0 0

Wake-up from Sleep, Idle mode U P P U P P P P

Bit Name X UE RRIF RBFF TBEF TBIF EXIF1 X TCIF0

Power-on U 0 0 0 0 0 U 0

/RESET and WDT time out U 0 0 0 0 0 U 0

Wake-up from Sleep, Idle mode U P P P P P U P

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 45

EM78P312N

8-Bit Microcontroller

Addres

0X0D ADDH

Name Reset Type Bit 7 Bit 6 Bi t 5 Bit 4 Bit 3 Bit 2 Bit 1 Bi t 0

Bit Name TC3CAP TC3 S TC3CK1 TC3 CK0 TC3M X X X

0x05 TC3CR

0x06 TC3DA

0x07 TC3DB

TC2CR/

0x08

0x09 TC2DH

0x0A TC2DL

0x0B ADCR

0x0C ADIC

0X0E TBKTC

Power-on 0 0 0 0 0 U U U

/RESET and WDT time out 0 0 0 0 0 U U U

Wake-up from Sleep, Idle mode P P P P P U U U

Bit Name TC3DA7 TC3DA6 TC3D A5 TC3DA 4 TC3DA3 TC3DA 2 TC3DA1 TC3DA 0

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name TC3DB7 TC3DB6 TC3D B5 TC3DB 4 TC3DB3 TC3DB 2 TC3DB1 TC3DB 0

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name ADD1 ADD0 X TC2M TC2S TC2 CK2 TC2CK1 TC2 CK0

Power-on U U U 0 0 0 0 0

ADDL

/RESET and WDT time out P P U 0 0 0 0 0

Wake-up from Sleep, Idle mode P P U P 0 P P P

Bit Name TC2D 15 TC2D14 TC2D13 TC2D12 TC2D11 TC2D10 TC2D9 TC2D8

Power-On 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name TC2D7 TC2D6 TC2D5 TC2D4 TC2D3 TC2D2 TC2D1 TC2D0

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name ADREF ADRUN ADCK1 ADCK0 ADP ADIS2 ADIS1 ADIS0

Power-on 0 0 0 0 1 0 0 0

/RESET and WDT time out 0 0 0 0 1 0 0 0

Wake-up from Sleep, Idle mode P (*) P P P P P P

Bit Name ADE7 ADE6 ADE5 ADE4 ADE3 ADE2 ADE1 ADE0

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name ADD9 ADD8 ADD7 ADD6 ADD5 ADD4 ADD3 ADD2

Power-on U U U U U U U U

/RESET and WDT time out P P P P P P P P

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name TEN TCK1 TCK0 X TBTEN TBTCK2 TB TCK1 TBTCK0

Power-on 0 0 0 0 0 0 0 0

/RESET and WDT time out 0 0 0 0 0 0 0 0

Wake-up from Sleep, Idle mode 0 P P P 0 P P P

46 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

Address Name Reset Ty pe Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

Bit Name URTD8 UMODE 1 UMODE0 BRATE2 BRATE1 BRATE0 UTBE TXE

0x05 URC1

0x06 URC2

0x07 URS

0x08 URRD

0x09 URTD

Power-on U 0 0 0 0 0 0 0

/RESET and WDT time out P P P P P P 0 0

Wake-up from Sleep, Idle mode P 0 P P P P P 0

Bit Name X X SBIM1 SBIM0 UINVEN X X X

Power-on U U 0 0 0 U U U

/RESET and WDT time out U U P P P U U U

Wake-up from Sleep, Idle mode U U P P P U U U

Bit Name URRD8 EVEN PRE PRERR OVERR FMERR URBF RXE

Power-on U 0 0 0 0 0 0 0

/RESET and WDT time out P P P 0 0 0 0 0

Wake-up from Sleep, Idle mode P P P P P P P 0

Bit Name URRD7 URRD6 URRD5 URRD4 URRD3 URRD2 URRD1 URRD0

Power-on U U U U U U U U

/RESET and WDT time out P P P P P P P P

Wake-up from Sleep, Idle mode P P P P P P P P

Bit Name URTD 7 URTD 6 URTD 5 URTD 4 URTD 3 URTD 2 URTD 1 URTD0

Power-on U U U U U U U U

/RESET and WDT time out P P P P P P P P

Wake-up from Sleep, Idle mode P P P P P P P P

Address Name R ese t Type Bit 7 Bit 6 Bit 5 Bit 4 Bi t 3 Bit 2 Bit 1 Bit 0

Bit Name SMP DCOL BRS2 BRS1 BRS0 EDS DORD WBE

0x05 SPIC1

0x06 SPIC2

0x07 SPID1

0x0A PHC1

0x0B PLC2

0x0C PHC2

0x0D PLC2

Power-on 0 0 0 0 0 0 0 0 /RESET and WDT time out P P P P P P P 0 Wake-up from Sleep, Idle mode P P P P P P P P Bit Name SPIS X X X X SPIM1 SPIM0 RBF Power-on 0 0 0 0 0 0 0 0 /RESET and WDT time out 0 0 0 0 0 P P 0 Wake-up from Sleep, Idle mode 0 P P P P P P P Bit Name SPID17 SPID16 SPID15 SPID14 SPID13 SPID12 SPID11 SPID10 Power-on U U U U U U U U /RESET and WDT time out P P P P P P P P Wake-up from Sleep, Idle mode P P P P P P P P Bit Name X X /PHE81 /PHE80 /PHE63 /PHE62 /PHE61 /PHE60 Power-on U U 1 1 1 1 1 1 /RESET and WDT time out U U 1 1 1 1 1 1 Wake-up from Sleep, Idle mode U U P P P P P P Bit Name X X /PLE81 /PLE80 /PLE63 /PLE62 /PLE61 /PLE60 Power-on U U 1 1 1 1 1 1 /RESET and WDT time out U U 1 1 1 1 1 1 Wake-up from Sleep, Idle mode U U P P P P P P Bit Name X X X X /PHE73 /PHE72 /PHE71 /PHE70 Power-on U U U U 1 1 1 1 /RESET and WDT time out U U U U 1 1 1 1 Wake-up from Sleep, Idle mode U U U U P P P P Bit Name X X X X /PLE73 /PLE72 /PLE71 /PLE70 Power-on U U U U 1 1 1 1 /RESET and WDT time out U U U U 1 1 1 1 Wake-up from Sleep, Idle mode U U U U P P P P

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 47

EM78P312N

8-Bit Microcontroller

Address Name R ese t Type Bit 7 Bit 6 Bit 5 Bit 4 Bi t 3 Bit 2 Bit 1 Bit 0

0x10

0x3F

Bit Name - - - - - - - -

R10

Power-on U U U U U U U U

/RESET and WDT time out P P P P P P P P

R3F

Wake-up from Sleep, Idle mode P P P P P P P P

General Purpose Registers

Legend: “×” = not used “P” = previous value before reset “u” = unknown or don’t care “t” = check Table 7

5.14.4 The Status of RST, T, and P of the Status Register

The values of T and P are used to verify the event that triggered the processor to wake

up. Table 7 shows the events that may affect the status of T and P.

Table 7. The Values of RST, T and P after a reset

Reset Type T P

Power on 1 1

/RESET during Operation mode *P *P

/RESET wake-up during Sleep mode *P *P

/RESET wake-up during Idle mode *P *P

WDT during Operation mode 0 *P

WDT wake-up during Sleep mode 0 *P

WDT wake-up during Idle mode 0 *P

*P: Previous status before reset

Table 8 The Events that may affect the T and P Status

Event T P

Power on 1 1

WDTC instruction 1 1

WDT time-out 0 *P

SLEP instruction 1 0

Wake-Up during Sleep mode *P *P

*P: Previous value before reset

48 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

VDD

Power-on

Reset

Voltage Detector

WDTE

/RESET

5.15 Interrupt

The EM78P312N has 15 interrupts (9 external, 6 internal) as listed below:

Table 9 Interrupt Vector

Interrupt Source Enable Condition Int. Flag Int. Vector Priority

Internal /

External

Internal WDT ENI + WDTEN WDTIF 0003 1

External INT0 ENI + INT0EN=1 EXIEF0 0006 2

Internal TCC ENI + TCIE0=1 TCIF0 0009 3

External INT1 ENI + EXIE1=1 EXIF1 000F 4

Internal TBT ENI + TBIE=1 TBIF 0012 5

Internal UART Transmit ENI + UTIE=1 TBEF 0015 6

Internal UART Receive ENI + URIE=1 TBFF 0018 7

Internal UART Receive error ENI+UERRIE=1 UERRIF 001B 8

Internal TC3 ENI + TCIE3=1 TCIF3 0021 9

Internal SPI ENI + SPIE=1 SPIF 0024 10

Internal TC4 ENI + TCIE4=1 TCIF4 0027 11

External INT3 ENI + EXIE3=1 EXIF3 002A 12

Internal AD ENI + ADIE=1 ADIF 0030 13

Internal TC2 ENI + TCIE2=1 TCIF2 0033 14

External INT5 ENI + EXIE5=1 EXIF5 0036 Low 15

Oscillator

CLK

CLR

WDT

WDT Timeout

Setup Time

RESET

Fig. 5-28 C ontroller R eset B lock Diagram

Reset − − 0000 High 0

CLK

ISFR0, ISFR1 and ISFR2 are the interrupt status registers that record the interrupt requests in the relative flags/bits. IMR1 and IMR2 are the interrupt mask registers. The global interrupt is enabled by the ENI instruction and is disabled by the DISI instruction. When one of the interrupts (enabled) occurs, the next instruction will be fetched from individual address. The interrupt flag bit must be cleared by instructions before leaving the interrupt service routine and before interrupts are enabled to avoid recursive interrupts.

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 49

EM78P312N

8-Bit Microcontroller

The flag (except ICIF bit) in the Interrupt Status Register (ISFR 2) is set regardless of

the status of its mask bit or the execution of ENI. The RETI instruction ends the

interrupt routine and enables the global interrupt (the execution of ENI).

5.16 Oscillator

5.16.1 Oscillator Modes

The EM78P312N can operate in two different oscillator modes, i.e., Crystal oscillator

mode and External RC oscillator mode (ERC) oscillator mode. User can select which

mode by Code Option Register. The maximum limit for operational frequencies of the

crystal/resonator under different VDDs is listed below.

Table 10 Oscillator Modes Defined by SDCS and OSC

Mode OSC Oscillator

Single Clock

1 High frequency oscillator

0 ERC

Table 11 The Summary of Maximum Operating Speeds

Condition VDD Max . Fxt. (MHz)

High frequency oscillator

3.0 4.0

5.0 10.0

5.16.2 Crystal Oscillator/Ceramic Resonators (Crystal)

EM78P312N has a clock generator. i.e. fc (high frequency) which can be driven by an

external clock signal through the OSCI pin.

In most applications, Pin OSCI and Pin OSCO can be connected with a crystal or

ceramic resonator to generate oscillation. Table 12 provides the recommended values

of C1 and C2. Since each resonator has its own attribute, user should refer to its

specification for appropriate values of C1 and C2. A serial resistor Rs may be

necessary for AT strip cut crystal.

50 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

OSCI

OSCO

EM78P312N

EM78P809N

Ext. Clock

Fig. 5-29 Crystal/Resonator Circuit

OSCI

EM78P312N

EM78P809N

XTAL

OSCO

Fig. 5-30 Crystal/Resonator Circuit

Table12. Capacitor Selection Guide for Crystal Oscillator or Ceramic Resonator

Oscillator Type Frequency Mode Frequency C1 (p F) C2 (pF)

Ceramic Resonator HXT

Crystal Oscillator HXT

2.0 MHz 20~40 20~40

4.0 MHz 10~30 10~30

1.0 MHz 15~30 15~30

2.0 MHz 15 15

4.0 MHz 15 15

OSCI

EM78P312N

EM78P809N

Fig. 5-31 Crystal/Resonator-Series Mode Circuit

Product Specification ( V 1 . 0) 10 . 0 3 . 2 006

(This specification is subject to change without further notice)

• 51

740

XTAL

EM78P312N

8-Bit Microcontroller

4.7 K

Vdd

OSCI

EM78P809N

EM78P312N

740

XTAL

Fig. 5-32 Cr ystal/Resonator-Parall el Mode Cir cuit

5.16.3 External RC Oscill ato r Mode

For applications that do not need very precise timing calculation, the RC oscillator

offers a lot of cost savings. Nevertheless, it should be noted that the frequency of the

RC oscillator is influenced by the supply voltage, the values of the resistor (Rext), the

capacitor (Cext), and even by the operation temperature. Moreover, the frequency

also varies slightly from one chip to another due to the manufacturing process variation.

In order to maintain a stable system frequency, the values of the Cext should not be

less than 20pF, and the value of Rext should not be greater than 1 M

frequency is easily affected by noise, humidity, and leakage.

The smaller the Rext in the RC oscillator, the faster its frequency will be. On the

contrary, for very low Rext values, for instance, 1 K

Ω, the oscillator becomes unstable

because the NMOS cannot correctly discharge the current of the capacitance.

, otherwise, the

Hence, it must be noted that the supply voltage, the operation temperature, the RC

oscillator components, the package types, and the PCB layout, will affect the system

frequency.

Vdd

Rext

OSC1

OSCI

EM78P312N

EM78P809N

Cext

Fig. 5-33 External RC Oscillator Mode Circuit

52 •

Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

Table13. RC Oscillator Frequencies

Cext Rext Average Fosc 5V, 25°C Average Fosc 3V, 25°C

3.3k 4.32 MHz 3.56 MHz

20 pF

100 pF

300 pF

Note:

: Measured based on DIP packages.

: The values are for design reference only.

5.1k 2.83 MHz 2.8 MHz

10k 1.62 MHz 1.57 MHz

100k 184kHz 187kHz

3.3k 1.39 MHz 1.35 MHz

5.1k 950kHz 930kHz

10k 500kHz 490kHz

100k 54kHz 55kHz

3.3k 580kHz 550kHz

5.1k 390kHz 380kHz

10k 200kHz 200kHz

100k 21kHz 21kHz

5.17 Code Option Register

The EM78P312N has one CODE option word that is not part of the normal program

memory. The option bits cannot be accessed during normal program execution.

EM78P312N

8-Bit Microcontroller

Code Option Register and Customer ID Register arrangement distribution:

Word 0 Word 1 Word 2

Bit 12~Bit 0 Bit 12~Bit 0 Bit 12~Bit 0

5.17.1 Code Opti on R egi st e r (Wo r d 0)

Word 0

Bit 12 ~ 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

- CLKS ENWDTB CYES - OSC HLP PR2 PR1 PR0

Bit 12 ~ 9 : Not used Bit 8 ( CLKS) : Instruction period option bit

CLKS = “0” : two oscillator periods CLKS = “1” : four oscillator periods.

Refer to the Instruction Set section.

Bit 7 (ENWDTB) : Watchdog timer enable bit

ENWDTB = “0” : Enable ENWDTB = “1” : Disable

Bit 6 (CYES) : Cycle selection for JMP, CALL instruction

CYES = “0” : One cycle CYES = “1” : Two cycles

Product Specification

(This specification is subject to change without further notice)

(V1.0) 10 . 03.2006 • 53

EM78P312N

8-Bit Microcontroller

Bit 4 (OSC) : Oscillator type selection

Bit 3 (HLP) : Power selection

Bit 2~0 (PR2~PR0) : Protect Bit

PR2~PR0 are write-protect bits, configured as follow s:

5.17.2 Customer ID Register

OSC = “0” : RC type OSC = “1” : Crystal type

HLP = “0” : Low power HLP = “1” : High power

PR2 PR1 PR0 Protect

Others Enable

1 1 1 Disable

Word 1

Bit 12~Bit 0

XXXXXXXXXXXXX

Bits 12 ~ 0: Customer’s ID code

5.18 Power-on Considerations

Any microcontroller is not guaranteed to start and operate properly before the power

supply maintains at its steady state. The EM78P312N has a built-in Power On Voltage

Detector (POVD) with a detecting level of 2.1V. It will work well if V

(10 ms or less). In many critical applications, however, additional components are

required to provide solutions on probable power-up problems.

5.18.1 External P ow er-on Res et Circ ui t

The circuit shown in Fig. 5-33 use an external RC to produce the reset pulse. The

pulse width (time constant) should be kept long enough for V

operation voltage. This circuit is used when the power supply has slow rise time.

Because the current leakage from the /RESET pin is about

that R should not be greater than 40K. In this way, the /RESET pin voltage is held

below 0.2V. The diode (D) acts as a short circuit at the moment of power down. The

capacitor C will discharge rapidly and fully. Rin, the current-limited resistor, will prevent

high current or ESD (electrostatic discharge) from flowing to pin /RESET.

Word 2

Bit 12~Bit 0

DD rises fast enough

DD to reach minimum

±5μA, it is recommended

• Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

Vdd

Rin

/RESET

EM78P312N

EM78P809N

Fig. 5-34 External Power-Up Reset Circuit

5.18.2 Residue-Voltage Protection

When battery is replaced, device power (VDD) is taken off but residue-voltage remains.

The residue-voltage may trip below V

cause a poor power-on reset. Fig.35 and Fig. 36 show how to build the residue-voltage

protection circuit.

Vdd

EM78P312N

EM78P809N

DD minimum, but not to zero. This condition may

33K

10K

Vdd

/RESET

40K

Fig. 5-35 Residue Voltage Protect ion Circuit 1

Vdd

EM78P312N

EM78P809N

/RESET

40K

Product Specification

(This specification is subject to change without further notice)

(V1.0) 10 . 03.2006 • 55

Fig. 5-36 Residue Voltage Protection Circuit 2

1N4684

Vdd

EM78P312N

8-Bit Microcontroller

5.19 Instruction Set

Each instruction in the instruction set is a 13-bit word divided into an OP code and one or more operands. Normally, all instructions are executed within one single instruction cycle (one instruction consists of 2 oscillator periods), unless the program counter is changed by instruction "MOV R2,A", "ADD R2,A", or by instructions of arithmetic or logic operation on R2 (e.g. "SUB R2,A", "BS(C) R2,6", "CLR R2", execution takes two instruction cycles.

In case the instruction cycle specification is not suitable for certain applications, try to modify the instruction as follows:

(A) Change one instruction cycle to consist of 4 oscillator periods.

(B) The following commands are executed within two instruction cycles; "JMP", "CALL", "RET", "RETL", "RETI", including the conditional skip ("JBS", "JBC", "JZ", "JZA", "DJZ", "DJZA") instructions. In addition, instructions that are written to the program counter are executed within two instruction cycles.

Case (A) is selected by the CODE Option bit, called CLK. One instruction cycle consists of two oscillator clocks if CLK is low, and four oscillator clocks if CLK is high.

Note that once the 4 oscillator periods within one instruction cycle is selected as in Case (A), the internal clock source to TCC should be CLK=Fosc/4, not Fosc/2.

⋅⋅⋅⋅). In this case, the

Furthermore, the instruction set has the following features:

(1) Every bit of any register can be set, cleared, or tested directly.

(2) The I/O register can be regarded as general register. That is, the same instruction can operate on I/O register.

Convention:

R = Register designator that specifies which one of the registers (including operation and general purpose

registers) is to be utilized by the instruction.

b = Bit field designator that selects the value for the bit located in the register R and which affects the

operation.

k = 8 or 10-bit constant or literal value

Binary Instruct io n Hex Mnemonic Operation

0 0000 0000 0000 0000 NOP No Operation None 0 0000 0000 0001 0001 DAA Decimal Adjust A C 0 0000 0000 0010 0002 CONTW A → CONT None

0 0000 0000 0011 0003 SLEP

0 0000 0000 0100 0004 WDTC 0 → WDT T, P 0 0000 0000 rrrr 000r IOW R A → IOCR None 1 0 0000 0001 0000 0010 ENI Enable Interrupt None 0 0000 0001 0001 0011 DISI Disable Interrupt None 0 0000 0001 0010 0012 RET [Top of Stack] → PC None

0 0000 0001 0011 0013 RETI

0 0000 0001 0100 0014 CONTR CONT → A None 0 0000 0001 rrrr 001r IOR R IOCR → A None 1

0 → WDT, Stop oscillator

[Top of Stack] → PC, Enable Interrupt

T, P

None

Status

Affected

• Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

Binary Instruct io n Hex Mnemonic Operation

0 0000 01rr rrrr 00rr MOV R, A A → R None 0 0000 1000 0000 0080 CLRA 0 → A Z 0 0000 11rr rrrr 00rr CLR R 0 → R Z 0 0001 00rr rrrr 01rr SUB A, R R-A → A Z,C,DC 0 0001 01rr rrrr 01rr SUB R, A R-A → R Z,C,DC 0 0001 10rr rrrr 01rr DECA R R-1 → A Z 0 0001 11rr rrrr 01rr DEC R R-1 → R Z 0 0010 00rr rrrr 02rr OR A, R A ∨ R → A Z 0 0010 01rr rrrr 02rr OR R, A A ∨ R → R Z 0 0010 10rr rrrr 02rr AND A, R A & R → A Z 0 0010 11rr rrrr 02rr AND R, A A & R → R Z 0 0011 00rr rrrr 03rr XOR A, R A ⊕ R → A Z 0 0011 01rr rrrr 03rr XOR R, A A ⊕ R → R Z 0 0011 10rr rrrr 03rr ADD A, R A + R → A Z,C,DC 0 0011 11rr rrrr 03rr ADD R, A A + R → R Z,C,DC 0 0100 00rr rrrr 04rr MOV A, R R → A Z 0 0100 01rr rrrr 04rr MOV R, R R → R Z 0 0100 10rr rrrr 04rr COMA R /R → A Z 0 0100 11rr rrrr 04rr COM R /R → R Z 0 0101 00rr rrrr 05rr INCA R R+1 → A Z 0 0101 01rr rrrr 05rr INC R R+1 → R Z 0 0101 10rr rrrr 05rr DJZA R R-1 → A, skip if zero None 0 0101 11rr rrrr 05rr DJZ R R-1 → R, skip if zero None

0 0110 00rr rrrr 06rr RRCA R

0 0110 01rr rrrr 06rr RRC R

0 0110 10rr rrrr 06rr RLCA R

0 0110 11rr rrrr 06rr RLC R

0 0111 00rr rrrr 07rr SWAPA R

R(n) → A(n-1), R(0) → C, C → A(7) R(n) → R(n-1), R(0) → C, C → R(7) R(n) → A(n+1), R(7) → C, C → A(0) R(n) → R(n+1), R(7) → (C), C → (R(0) R(0-3) → ( A(4-7),

R(4-7) → ( A(0-3) 0 0111 01rr rrrr 07rr SWAP R R(0-3) → ( R(4-7) None 0 0111 10rr rrrr 07rr JZA R R+1 → A, skip if zero None 0 0111 11rr rrrr 07rr JZ R R+1 → R, skip if zero None 0 100b bbrr rrrr 0xxx BC R, b 0→ ( R(b) None 0 101b bbrr rrrr 0xxx BS R, b 1→ ( R(b) None 0 110b bbrr rrrr 0xxx JBC R, b if R(b)=0, skip None 0 111b bbrr rrrr 0xxx JBS R, b if R(b)=1, skip None

1 00kk kkkk kkkk 1kkk CALL k

PC+1 → [SP],

(Page, k) → (PC) 1 01kk kkkk kkkk 1kkk JMP k (Page, k) → (PC) None 1 1000 kkkk kkkk 18kk MOV A, k k → A None 1 1001 kkkk kkkk 19kk OR A, k A v k → A Z 1 1010 kkkk kkkk 1Akk AND A, k A & k → A Z 1 1011 kkkk kkkk 1Bkk XOR A, k A ⊕ k → A Z

1 1100 kkkk kkkk 1Ckk RETL k

k → A, [Top of Stack] →

PC 1 1101 kkkk kkkk 1Dkk SUB A, k k-A → A Z,C,DC 1 1111 kkkk kkkk 1Fkk ADD A, k k+A → A Z,C,DC 1 1110 1000 kkkk 1E8k PAGE k K->R5(6:4) None 1 1110 1001 kkkk 1E9k BANK k K->R4(7:6) None

Note:

This instruction is applicable to IOC6~IOCA, IMR1, IMR2 only.

Status

Affected

None

Product Specification

(This specification is subject to change without further notice)

(V1.0) 10 . 03.2006 • 57

EM78P312N

8-Bit Microcontroller

6 Absolute Maximum Ratings

6.1 Absolute Maximum Ratings

Items Rating

Temperature under bias -40°C to 85°C

Storage temperature -65°C to 150°C

Input voltage -0.3V to +6.0V

Output voltage -0.3V to +6.0V

Operating Frequency (2clk) DC to 10MHz

6.2 Recommended Operating Conditions

Vss = 0V

Symbol Parameter Condition Min. Typ. Max. Unit

VDD Supply Voltage

Crystal: VDD 4.5 to 5.5V 1 − 10

Crystal: VDD 2.5 to 5.5V

Fc = 10MHz 4.0 −

Fc = 4MHz 2.5 −

Two cycles with two clocks

5.5 V

1 − 4

MHz

• Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

7 Electrical Characteristics

7.1 DC Electrical Characteristics

Ta= 25 °C, VDD= 5.0V ± 5%, VSS= 0V

Symbol Parameter Condition Min. Typ. Max. Unit

Fc Crystal: 4.5V to VDD Two cycles with two clocks 1 − 10 MHz

ERC ERC: VDD = 5V R: 5.1KΩ, C: 100 pF 630 900 1170 kHz

VIHRC

VILRC

VIHT1

VIHX1 Clock Input High Voltage OSCI in crystal mode 0.7VDD − VDD+0.3V V VILX1 Clock Input Low Voltage OSCI in crystal mode -0.3V − 0.3VDD V

Note: * Data in the Minimum, Typical, Maximum (“Min”, “Typ”, ”Max”) columns are based on characterization results at 25°C.

Input High Threshold Voltage (Schmitt Trigger )

IRC1 Sink current VI from low to high , VI=5V 15.5 22 28.5 mA

Input Low Threshold Voltage (Schmitt Trigger )

IRC2 Sink current VI from high to low , VI=2V 12 17 22 mA

Input Leakage Current for input

IIL

pins Input High Voltage

VIH1

(Schmitt Trigger) Input Low Voltage

VIL1

(Schmitt Trigger) Input High Threshold Voltage (Schmitt Trigger) Input Low Threshold Voltage

VILT1

(Schmitt Trigger)

Output High Voltage

IOH1

(Ports 6, 7, 8, 9) Output Low Voltage

IOL1

(Port 9) Output Low Voltage

IOL2

(Ports 6, Port 7, Port 8)

IPH Pull-high current Pull-high active, input pin at VSS -50 -75 -100 μA

IPL Pull-Low current Pull-high active, input pin at VDD 50 75 100 μA

Sleep mode

ISB1

Power down current Sleep mode

ISB2

Power down current Idle mode

ICC3

Operating supply current at two clocks Normal mode

ICC4

Operating supply current at two clocks

OSCI in RC mode 2.8 4 4.5 V

OSCI in RC mode 1.3 1.8 2.7 V

VIN = VDD, VSS -1 0 1 μA

Ports 6, 7, 8, 9 0.7VDD − VDD +0.3V V

Ports 6, 7, 8, 9, -0.3V − 0.3 VDD V

/RESET, TCC, INT 0.7 VDD − VDD +0.3V V

/RESET, TCC, INT -0.3V − 0.3 VDD V

VOH = VDD-0.4V -3.5 -5 -6.5 mA

VOL = VSS+0.4V 3 5 7 mA

VOL = VSS+0.4V 12 15 20 mA

All input and I/O pins at VDD, output pin floating

VDD=5V, /RESET= 'High', Fc=8MHz, CLKS="0", output pin floating, WDT enabled

WDT disabled WDT enabled

− 0.8 1.5 μA

− 6 10 μA

− 1.1 1.5 mA

− 3.0 3.5 mA

Product Specification

(This specification is subject to change without further notice)

(V1.0) 10 . 03.2006 • 59

EM78P312N

8-Bit Microcontroller

Ta= 25

Symbol Parameter Condition Min. Typ. Max. Unit

Fc Crystal: 2.5V to VDD Two cyclea with two clocks 1 − 4 MHz

ERC ERC: VDD = 3V R: 5.1KΩ, C: 100 pF 600 850 1100 kHz

VIHRC

IRC1 Sink current VI from low to high , VI=5V 7 9.5 12 μA

VILRC

IRC2 Sink current VI from high to low , VI=2V 6 8.5 11 μA

IIL

VIH1

VIL1

VIHT2

VILT2

VIHX1 Clock Input High Voltage LOSCI, OSCI in crystal mode 0.7 VDD − VDD +0.3V V

VILX1 Clock Input Low Voltage LOSCI, OSCI in crystal mode -0.3V − 0.3 VDD V

IOH1

IOL1

IOL2

IPH Pull-high current Pull-high active, input pin at VSS -15 -23 -31 μA

IPL Pull-low current Pull-low active, input pin at VDD 15 23 30 μA

ISB1

ISB2

ICC3

ICC4

Note: * Data in the Minimum, Typical, Maximum (“Min”, “Typ”, ”Max”) columns are based on characterization results at 25°C.

Input High Threshold Voltage (Schmitt Trigger)

Input Low Threshold Voltage (Schmitt Trigger)

Input Leakage Current for input pins Input High Voltage (Schmitt Trigger) Input Low Voltage (Schmitt Trigger) Input High Threshold Voltage (Schmitt Trigger) Input Low Threshold Voltage (Schmitt Trigger)

Output High Voltage (Ports 6, 7, 8, 9) Output Low Voltage (Port 9) Output Low Voltage (Ports 6,Port7, Port8)

Sleep mode Power down current Sleep mode Power down current Idle mode Operating supply current at two clocks Normal mode Operating supply current at two clocks

°C, VDD= 3.0V ± 5%, VSS= 0V

OSCI in RC mode 1.6 2.3 2.8 V

OSCI in RC mode 0.7 1 1.3 V

VIN = VDD, VSS -1 0 1 μA

Ports 6,7,8,9,A 0.7VDD − VDD+0.3V V

Ports 6,7,8,9,A -0.3V − 0.3VDD V

/RESET, TCC 0.7 VDD − VDD +0.3V V

/RESET, TCC -0.3V − 0.3 VDD V

VOH = VDD-0.4V -2 -3.5 -5 mA

VOL = VSS+0.4V 2 3.5 5 mA

VOL = VSS+0.4V 10 13 16 mA

All input and I/O

pins at VDD,

output pin floating

VDD=3V, /RESET= 'High',

Fc=4MHz, CLKS="0", output pin

floating, WDT enabled

WDT disabled − 0.4 0.8 μA

WDT enabled − 1.5 3 μA

− 0.3 0.5 mA

− 1.1 1.5 mA

• Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

EM78P312N

8-Bit Microcontroller

A/D Converter Characteristic (Vdd =2.5V to 5.5V, Vss=0V, Ta = -40 to 85°C)

Symbol Parameter Condition Min. Typ. Max. Unit

VAREF 2.5 − VDD V

VASS

VAI Analog input voltage

IAI1

IAI2

RN Resolution VDD =VAREF=5.0V, VASS =0.0V 9 10 − Bits

LN Linearity error VDD = 2.5 to 5.5V Ta=25°C 0 ±1 ±2 LSB

DNL

FSE Full scale error VDD =VAREF=5.0V, VASS =0.0V ±0 ±1 ±2 LSB

OE Offset error VDD =VAREF=5.0V, VASS =0.0V ±0 ±0.5 ±1 LSB

ZAI

TAD A/D clock period VDD =VAREF=5.0V, VASS =0.0V 4 − − μs

TCN A/D conversion time VDD =VAREF=5.0V, VASS =0.0V 14 − 14 TAD

ADIV A/D input voltage range VDD =VAREF=5.0V, VASS =0.0V 0 − VAREF V

ADOV A/D output voltage swing

PSR Power Supply Rejection VDD =5.0V±0.5V ±0 ±2 LSB

Analog reference voltage VAREF - VASS≧2.5V

Vss − Vss V

−

IVDD 750 850 1000 μA

Analog supply current

Ivref

IVDD 500 600 820 μA

Analog supply current

IVref

Differential nonlinear error

DD =VAREF=5.0V, VASS =0.0V

(V reference from V

DD =VAREF=5.0V, VASS =0.0V

DD)

(V reference from VREF)

VDD = 2.5 to 5.5V Ta=25°C 0 ±0.5 ±0.9 LSB

VASS − VAREF V

-10 0 +10 μA

200 250 300 μA

Recommended impedance of analog

− 0 8 10 K

voltage source

DD =VAREF=5.0V, VASS =0.0V,

RL=10K

0 0.2 0.3

4.7 4.8 5

Product Specification

(This specification is subject to change without further notice)

(V1.0) 10 . 03.2006 • 61

EM78P312N

8-Bit Microcontroller

7.2 AC Electrical Characteristic

Ta=- 40°C ~ 85 °C, VDD=5V ± 5%, VSS=0V

Symbol Parameter Conditions Min Typ Max Unit

Dclk Input CLK duty cycle − 45 50 55 %

Instruction cycle time

Tins

(CLKS="0")

Ttcc TCC input period −

Tdrh

Twdt

Tset Input pin setup time − − 0 − ns

Thold Input pin hold time − − 20 − ns

Tdelay Output pin delay time Cload=20pF − 50 − ns

Tstup1 SDI data setup time Setup time of SDI data input to SCK↑or SCK↓ − 25 50 ns

Thold1 SDI data hold time Hold time of SDI data input to SCK↓or SCK↑ − 25 50 ns

Tvalid1 SDO output valid time SCK↑or SCK↓to SDO data output − 25 50 ns

Tsckh SCK input high time Slave mode (Fmain=8 MHz) 200 − − ns

Tsckl SCK input low time Slave mode (Fmain=8 MHz) 200 − − ns

Tsetup2

Tdelay1

Device reset hold time

Trst /RESET pulse width Ta = 25°C 2000 − − ns

Watchdog timer period

Slave mode setup time Slave mode unselect delay time

* N= selected prescaler ratio

Crystal type (high frequency) 200 − DC ns

RC type 500 − DC ns

(Tins+20)/

Ta = 25°C 11.3 16.2 21.6 ms

/SS↓ to SCK↑or SCK↓(Fmain=8 MHz) 400 − − ns

/SS↑ to SDO output hi-impedance delay time − 25 50 ns

− − ns

• Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

7.3 Timing Diagram

AC Test Input/Output Waveform

EM78P312N

8-Bit Microcontroller

2.4

0.4

AC Testing : Input is driven at 2.4V for logic "1",and 0.4V for logic "0".Tim ing measurements are

made at 2.0V for log ic "1",and 0.8V fo r logic "0".

2.0

0.8

TEST POINTS

2.0

0.8

RESET Timing (CLK="0")

NOP

CLK

/RESET

Tdrh

Instruction 1

Executed

TCC Input Tim ing (CLKS="0")

Tins

CLK

TCC

Ttcc

Product Specification

(This specification is subject to change without further notice)

(V1.0) 10 . 03.2006 • 63

EM78P312N

8-Bit Microcontroller

A Package Types:

OTP MCU Package Type Pin Count Package Size

EM78P312NP DIP 28 600 mil

EM78P312NK SDIP 28 400 mil

EM78P312NAK SDIP 28 300 mil

EM78P312NM SOP 28 300 mil

EM78P312NS SSOP 28 209 mil

 Y/S/J：Green product does not contain hazardous substances.

The third edition of Sony SS-00259 standard.

APPENDIX

Pb content should be less than 100ppm.

Pb content to fit in with Sony spec.

Part No. EM78P311SxY EM78P311SxS/xJ

Electroplate type Sn/Cu Pure Tin

Ingredient (%) Cu:1.0~3.0% Sn :100%

Melting point(°C) ~227°C 232°C

Electrical resistivity

(μΩ-cm)

Hardness (hv) 10~12 8~10

Elongation (%) 40% >50%

13 11.4

• Product Specification (V1.0) 10.03.2006

(This specification is subject to change without further notice)

IBM EM78P312N User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
