English - 1
Your New Monitor
Please make sure the following items are included with your monitor . If any items are missing,
contact your dealer.
CD
Power Cord
(User's Guide & Installation Files)
Stand
Connecting Your Monitor
3
Turn off your computer and unplug
1
the power cord.
Signal cable
2
Connect the end of the signal cable to
your computer’s video port (Video
board, video card, or graphics card).
Power port
3
Connect the power cord for your
monitor to the power port on the back
of the monitor.
MENU
EXIT
EXIT
MENU
Monitor
Warranty & Safety Manual
Setup Guide
2
and the power cord for your computer
into a nearby outlet.
Turn on your computer and monitor.
5
If your monitor displays an image,
installation is complete.
Install monitor driver
6
•
Insert the provided CD into the
CD ROM drive, when prompted by
the operating system.
4
Power cords
4
Plug the power cord for the monitor
English - 2
Your New Monitor
Front Panel
EXIT
EXIT
1
EXIT ( ) button
1
Closes the OSD. It is also used to return to the previous menu when using the OSD.
MENU
MENU
3
2
4
The / ( / ) buttons
2
These buttons allow you to select and adjust items using the OSD. When adjusting an
item using the OSD, the button lowers the value of the selected function.
The button raises the value of the selected function. These buttons are also direct
access buttons for the Contrast and Brightness feature controls. (See the section below
on Direct Access Buttons.)
MENU ( ) button
3
Opens the OSD. It is also used to select a highlighted function, open a sub-menu, or
move between menus when using the OSD.
Power button
4
The power button turns the monitor on and off. The power indicator light glows green
during normal operation, see “Specifications” section.
Direct Access Buttons
EXIT
EXIT
Most of the adjustments you make to your monitor will be accessed through the OSD
described in the next section. The Contrast and Brightness features can also be accessed
directly from the front of your monitor.
MENU
MENU
FrançaisEspañolDeutschItaliano EnglishPortuguese
With the menu off, press the or button on the front of your monitor.
1
The button accesses the Brightness feature. The b utton accesses the
Contrast feature.
Push the button to increase or the button to decrease the value of the
2
selection.
Press the EXIT button twice to exit the OSD.
3
English - 3
Operation
On Screen Display(OSD)
Your monitor has an OSD, accessed by the buttons on the front of your monitor, that allows
you to adjust characteristics of the screen image. Display changes are indicated by on-screen
adjustment icons. Some functions have sub-menus.
Push the menu button to display the main menu.
1
Function icons are arranged across the top of the OSD.
Push the or button to move through the icons.
2
The name of the function will appear below the rows of function icons.
To select a function or open a sub-menu, push the button. The screen will display
3
the options for adjustment. If there is a sub-menu, use the or button to
highlight the feature you want to adjust, then push the button to select it.
Use the and buttons to make adjustments. increases values
4
and decreases values. On-screen calibration numbers show the effect of your
adjustment. If you are in a sub-menu, use the EXIT button to return to the previous
menu.
Push the EXIT button to exit and save your changes.
5
Function icons
Active function
Adjustment icons
Function
selection and
Menu navigation
Brightness
:
Access Function
:
Exit Menu
English - 4
Icon Monitor Function Control
Operation
Brightness
Bac kground brightness of screen.
-– Decreases brightness
+ Increases brightness
Contrast
Contrast of screen image.
-– Decreases contrast
+ Increases contrast
Horizontal Position
Horizontal screen position.
-– Moves screen lef t
+ Moves screen right
Vertical Position
V ertical screen position.
-– Moves screen down
+ Moves screen up
Horizontal Size
Horizontal screen size.
-– Decreases size
+ Increases size
Brightness
:
Access Function
Contrast
:
Access Function
H-Position
:
Access Function
V-Position
:
Access Function
H-Size
:
Access Function
FrançaisEspañolDeutschItaliano EnglishPortuguese
Vertical Size
V ertical screen size.
-– Decreases size
+ Increases size
English - 5
V-Size
Access Function
:
Icon Monitor Function Control
Operation
Pincushion
Straightens screen vertical edges.
-– Curves image inward
+ Curves image outward
Geometry
Trapezoid
Width of top and bottom of screen.
-– Widens bottom of screen
+ Widens top of screen
Parallelogram
-– Skews screen image left
+ Skews screen image right
Pinbalance
-– Curves vertical lines to left
+ Curves vertical lines to right
V-Linearity
-– Compresses image at top of screen
+ Compresses image at bottom of screen
1.
2.
Pincushion
:
Access Function
Geometry
:
Access Function
Exit Menu
:
Trapezoid
Select Function
+ - :
Previous Menu
:
English - 6
Icon Monitor Function Control
Language
-– and + scroll through on-screen
language options.
(English/ Español/ Português/ Italiano/
Français/ Deutsch)
Advanced
H- Moiré
Corrects for on-screen moiré
pattern.
-– and + clear Horizontal Moiré
Operation
1.
Language
:
Access Function
:
Exit Menu
Advanced
:
Access Function
Exit Menu
:
FrançaisEspañolDeutschItaliano EnglishPortuguese
V- Moiré
Corrects for on-screen moiré
pattern.
-– and + clear Vertical Moiré
Video Input Level
Selects the video signal level
-– Select 0.7 V
+ Select 1.0 V
Color Temperature
-– 9300k more blue
+ 6500k more red
2.
H-Moiré
Select Function
+ - :
Previous Menu
:
English - 7
Icon Monitor Function Control
Operation
Zoom
-– Reduces view of display area
+ Enlarges view of display area
Degauss
Removes color distortion caused by
magnetic fields. Do not use more than
once in 30 minutes.
Recall
Returns monitor to original settings.
-– No
+ Yes
Display Timing
Monitor display settings.
-– Factory timing
+ User timing
OSD Lock/Unlock
Allows you to secure the current control
settings so that they cannot be
inadvertently changed. You can unlock
the OSD controls at any time by using
the same procedure.
Push and hold the Menu ( ) butt on
for 10 seconds or more to Lock or to
Unlock.
Zoom
:
Access Function
Degauss
:
Access Function
Recall
:
Access Function
Display Timing
:
User Mode
OSD Lock/Unlock
Control Lock
Locked
English - 8
Troubleshooting
Before calling for service, check the information in this section to see if you can solve the
problem yourself.
There is no screen image
Check to see that both the monitor and the computer are plugged in and turned on.
“No Connection, Check Signal Cable” appears
Check the signal cable connection between the computer and the monitor.
“Sync. Out of Range” appears
The input signal frequency is over or under the synchronization range of the monitor , see
“Specifications” section.
The screen image is too light or too dark
Adjust the brightness or contrast settings, see On Screen Dispaly section.
The screen image is too large or too small
Adjust the size settings, see H-size and V-Size On Screen Dispaly section.
Adjust the Zoom setting, see On Screen Dispaly section.
The colors are distorted with dark or shadowed areas
Activate the degauss feature, see On Screen Dispaly section.
Adjust the color temperature, see On Screen Dispaly section.
The power indicator light is blinking green
The monitor is using its power management system, see “PowerSaver” section.
You need the monitor driver software
Download the driver from the internet at http: //www.ibm.com/support
FrançaisEspañolDeutschItaliano EnglishPortuguese
English - 9
Help & Service
Machine Name - E50 Color Monitor (M/T 6518)
Warranty Period - Three (3) Years
See the IBM Statement of Limited Warranty included in this publication for IBM's warranty
terms and conditions.
The IBM Machine Warranty worldwide Web site at
http://www-1.ibm.com/servers/support/machine_warranties/
of IBM's Limited Warranty for IBM Machines, a Glossary of IBM definitions, Frequently Asked
Questions (FAQs) and Support by Product (Machine) with links to Product Support pages.
The IBM Statement of Limited Warranty is also available on this site in 29 languages via
pdf files.
Service and support
With the original purchase of an IBM machine, you have access to extensive support
coverage. During the IBM machine warranty period, you may call IBM or your reseller for
problem determination assistance under the terms of the IBM Statement of Limited Warranty.
You may seek help as follows:
Call IBM HelpCenter
In the US call 1-800-772-2227
In Canada (Toronto only) call 416-383-3344
(all others) call 1-800-565-3344
In other countries, contact your dealer, retailer, or other IBM authorized servicer. Before
calling, please have available as much of the following information as possible:
1. Type, model and serial number from the label on the back of your monitor.
2. Purchase receipt.
3. Description of problem.
4. Computer type and model.
5. System configuration (hardware fitted etc.).
6. System BIOS version number.
7. Operating System and version number.
8. Display driver version number.
If possible, stay by your computer system. Your technical support representative might want
to go through the problem with you during the call.
provides a worldwide overview
English - 10
PowerSaver
This monitor has a built-in power management system called PowerSaver. This system saves
energy by switching your monitor into a low-power mode when it has not been used for a
certain amount of time. The monitor automatically returns to normal operation when you
move the computer's mouse or press a key on the keyboard. For energy conservation, turn
your monitor OFF when it is not needed, or when leaving it unattended for long periods. The
PowerSaver system operates with a VESA DPMS compliant video card installed in your
computer. Use a software utility installed on your computer to set up this feature.
State Normal Operation Power-off Mode (EPA/ENERGY 2000)
Power Indicator Green Green, Blinking (1 sec. interval)
Power
Consumption
NOTE:
This monitor is EPA E
computer equipped with VESA DPMS functionality.
75 W (Maximum)
61 W (Nominal)
NERGY STAR
Less than 2 W
® compliant and ENERGY 2000 compliant when used with a
Display Modes
Display Mode Vertical Frequency (Hz)
FrançaisEspañolDeutschItaliano EnglishPortuguese
IBM, VGA2, 720 x 400
IBM, VGA3, 640 x 480
VESA, 640 x 480
VESA, 640 x 480
VESA, 800 x 600
VESA, 800 x 600
VESA, 800 x 600
70
60
75
85
60
75
85
English - 11
Specifications
Specifications Model: IBM E50
Picture Tube • 15” (38 cm) Full square type (35 cm Viewable)
• 90
°
Deflection
• Dot pitch: 0.28 mm (0.24mm horizontal)
• Aluminized tri-color phosphor dot trio with black matrix.
• Anti-doming invar shadow mask.
Synchronization • Horizontal:
• Vertical:
Display Color • Over 16 million
Maximum Resolution • 1024 Dots • 768 Lines
30 kHz to 54 kHz
50 Hz to 120 Hz
Active Display • Horizontal:
• Vertical:
Input Signal,
Terminated
Maximum Pixel Clock • 65 MHz
Power Supply • AC
Power Consumption • 75 W (maximum)
Dimensions/Weight
(WxDxH)
Environmental
Considerations
Analog: 0
•
•
Separate Sync.:
100-240 V, 50 Hz / 60Hz
• Unit : 356 x 379 x 369.5 / 11.9kg
• Carton : 457 x 474 x 390 mm / 13.7kg
• Operating temperature:
Humidity:
• Storage temperature:
Humidity:
10.5 ± 0.16 inch (267.0 ± 4 mm)
7.9 ± 0.16 in ch (200. 0 ± 4 mm)
.7 Vpp positive at 75 ohms
TTL level, positive or negative
°
F to 104°F (5°C to 40°C)
41
10% to 80%
-4°F to 113°F (-20°C to 45°C)
20% to 80%
Design and specifications are subject to change without notice.
English - 12
Loading...
