User Guid e Ty pe s 8131, 8137, 8138 Ty pe s 8122, 8123, 8124



User Guid e Ty pe s 8131, 8137, 8138 Ty pe s 8122, 8123, 8124



Note

Before using this information and the product it supports, be sure to read the “Important safety information” on page v and Appendix D, “Notices,” on page 43.

Third Edition (May 2006)

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.

Important safety information . . . . . .v

Conditions that require immediate action . . . . .v

General safety guidelines . . . . . . . . . .vi

Service . . . . . . . . . . . . . . .vi

Power cords and power adapters . . . . . . vii

Extension cords and related devices . . . . . vii

Plugs and outlets . . . . . . . . . . . viii

Batteries . . . . . . . . . . . . . . viii

Heat and product ventilation . . . . . . .ix

CD and DVD drive safety . . . . . . . . .ix

Additional safety information . . . . . . . . .x

Lithium battery notice . . . . . . . . . . .x

Modem safety information . . . . . . . . .xi

Laser compliance statement . . . . . . . . .xi

Power supply statement . . . . . . . . . . xii

Overview . . . . . . . . . . . . . xiii

Information resources . . . . . . . . . . . xiii

Chapter 1. Installing options . . . . . .1

Features . . . . . . . . . . . . . . . .1

Specifications . . . . . . . . . . . . . .4

Available options . . . . . . . . . . . . .5

Tools required . . . . . . . . . . . . . .5

Handling static-sensitive devices . . . . . . . .6

Installing external options . . . . . . . . . .6

Locating the connectors on the front of your

computer . . . . . . . . . . . . . .7

Locating the connectors on the rear of your

computer . . . . . . . . . . . . . .8

Obtaining device drivers . . . . . . . . .9

Removing the cover . . . . . . . . . . .10

Locating components . . . . . . . . . . .11

Identifying parts on the system board . . . . .12

Installing memory . . . . . . . . . . . .13

Installing adapters . . . . . . . . . . . .14

Installing internal drives . . . . . . . . . .15

Drive specifications . . . . . . . . . .15

Installing a drive in bay 1 or bay 2 . . . . .17

Connecting drives . . . . . . . . . . . .19

Connecting the first optical drive . . . . . .19

Connecting an additional optical drive, or

parallel ATA hard disk drive . . . . . . . .20

Connecting a serial ATA hard disk drive . . . .20

Installing security features . . . . . . . . .21

Identifying security locks . . . . . . . . .21

Padlock . . . . . . . . . . . . . . .22

Integrated cable lock . . . . . . . . . .23

Password protection . . . . . . . . . .23

Changing the battery . . . . . . . . . . .23

Erasing a lost or forgotten password (clearing

CMOS) . . . . . . . . . . . . . . . .24

Replacing the cover and connecting the cables . . .25

Chapter 2. Using the Setup Utility

program . . . . . . . . . . . . . .27

Starting the Setup Utility program . . . . . . .27

Viewing and changing settings . . . . . . . .27

Using passwords . . . . . . . . . . . .27

User Password . . . . . . . . . . . .27

Administrator Password . . . . . . . . .28

Setting, changing, and deleting a password . . .28

Using Security Profile by Device . . . . . . .28

Selecting a startup device . . . . . . . . . .29

Selecting a temporary startup device . . . . .29

Changing the startup sequence . . . . . . .29

Exiting from the Setup Utility program . . . . .29

Appendix A. Updating system

programs . . . . . . . . . . . . .31

System programs . . . . . . . . . . . .31

Updating (flashing) BIOS from a diskette or

CD-ROM . . . . . . . . . . . . . .31

Updating (flashing) BIOS from your operating

system . . . . . . . . . . . . . . .31

Recovering from a POST/BIOS update failure . . .32

Appendix B. Cleaning the mouse . . .33

Cleaning an optical mouse . . . . . . . . .33

Cleaning a mouse with a ball . . . . . . . .33

Appendix C. Manual modem

commands . . . . . . . . . . . . .35

Basic AT commands . . . . . . . . . . .35

Extended AT commands . . . . . . . . . .37

MNP/V.42/V.42bis/V.44 commands . . . . . .38

Fax Class 1 commands . . . . . . . . . .39

Fax Class 2 commands . . . . . . . . . .39

Voice commands . . . . . . . . . . . . .40

Appendix D. Notices . . . . . . . . .43

Television output notice . . . . . . . . . .44

Trademarks . . . . . . . . . . . . . .44

Index . . . . . . . . . . . . . . .45

iv User Guide

Important safety information

Note

Please read important safety information first.

This information can help you safely use your ThinkCentre

personal computer. Follow and retain all information included with your computer. The information in this document does not alter the terms of your purchase agreement or the Lenovo

Customer safety is important. Our products are developed to be safe and effective. However, personal computers are electronic devices. Power cords, power adapters, and other features can create potential safety risks that can result in physical injury or property damage, especially if misused. To reduce these risks, follow the instructions included with your product, observe all warnings on the product and in the operating instructions, and review the information included in this document carefully. By carefully following the information contained in this document and provided with your product, you can help protect yourself from hazards and create a safer computer work environment.

™

Statement of Limited Warranty.

or ThinkPad

Note: This information includes references to power adapters and batteries. In

addition to mobile personal computers, some products (such as speakers and monitors) ship with external power adapters. If you have such a product, this information applies to your product. In addition, your computer product may contain a coin-sized internal battery that provides power to your system clock even when the machine is unplugged, so the battery safety information applies to all computers.

Conditions that require immediate action

Products can become damaged due to misuse or neglect. Some product damage is serious enough that the product should not be used again until it has been inspected and, if necessary, repaired by an authorized servicer.

As with any electronic device, pay close attention to the product when it is turned on. On very rare occasions, you might notice an odor or see a puff of smoke or sparks vent from your machine. Or you might hear sounds like popping, cracking or hissing. These conditions might merely mean that an internal electronic component has failed in a safe and controlled manner. Or, they might indicate a potential safety issue. However, do not take risks or attempt to diagnose the situation yourself.

Frequently inspect your computer and its components for damage or wear or signs of danger. If you have any question about the condition of a component, do not use the product. Contact the Customer Support Center or the product manufacturer for instructions on how to inspect the product and have it repaired, if necessary.

In the unlikely event that you notice any of the conditions listed below, or if you have any safety concerns with your product, stop using the product and

unplug it from the power source and telecommunication lines until you can speak to the Customer Support Center for further guidance. See “Information resources” on page xiii.

v Power cords, plugs, power adapters, extension cords, surge protectors, or power

supplies that are cracked, broken or damaged.

v Signs of overheating, smoke, sparks or fire.

v Damage to a battery (such as cracks, dents, creases), discharge from a battery, or

a buildup of foreign substances on the battery.

v A cracking, hissing or popping sound, or strong odor that comes from the

product.

v Signs that liquid has been spilled or an object has fallen onto the computer

product, the power cord or power adapter.

v The computer product, the power cord or power adapter has been exposed to

water.

v The product has been dropped or damaged in any way.

v The product does not operate normally when you follow the operating

instructions.

If you notice these conditions with a product (such as an extension cord)

Note:

that is not manufactured for or by Lenovo, stop using that product until you can contact the product manufacturer for further instructions, or until you get a suitable replacement.

General safety guidelines

Always observe the following precautions to reduce the risk of injury and property damage.

Service

Do not attempt to service a product yourself unless instructed to do so by the Customer Support Center. Use only a service provider who is approved to repair your particular product.

Note: Some parts can be upgraded or replaced by the customer. These parts are

referred to as Customer Replaceable Units, or CRUs. Lenovo expressly identifies CRUs as such, and provides documentation with instructions when it is appropriate for customers to replace those parts. You must closely follow all instructions when performing such replacements. Always make sure that the power is turned off and that the product is unplugged from any power source before you attempt the replacement. If you have any questions or concerns, contact the Customer Support Center.

Although there are no moving parts in your computer after the power cord has been disconnected, the following warnings are required for proper UL certification.

vi User Guide

Danger

Hazardous moving parts. Keep fingers and other body parts away.

Attention

Before replacing any CRUs, turn off the computer and wait three to five minutes to let the computer cool before opening the cover.

Power cords and power adapters

Use only the power cords and power adapters supplied by the product manufacturer.

Never wrap a power cord around the power adapter or other object. Doing so can stress the cord in ways that can cause the cord to fray, crack or crimp. This can present a safety hazard.

Always route power cords so that they will not be walked on, tripped over, or pinched by objects.

Protect the cord and power adapters from liquids. For instance, do not leave your cord or power adapter near sinks, tubs, toilets, or on floors that are cleaned with liquid cleansers. Liquids can cause a short circuit, particularly if the cord or power adapter has been stressed by misuse. Liquids can also cause gradual corrosion of the power cord terminals and/or the connector terminals on the adapter which can eventually result in overheating.

Always connect power cords and signal cables in the correct order and ensure that all power cord connectors are securely and completely plugged into receptacles.

Do not use any power adapter that shows corrosion at the ac input pins and/or shows signs of overheating (such as deformed plastic) at the ac input or anywhere on the power adapter.

Do not use any power cords where the electrical contacts on either end show signs of corrosion or overheating or where the power cord appears to have been damaged in any way.

Extension cords and related devices

Ensure that extension cords, surge protectors, uninterruptible power supplies, and power strips that you use are rated to handle the electrical requirements of the

Important safety information vii

product. Never overload these devices. If power strips are used, the load should not exceed the power strip input rating. Consult an electrician for more information if you have questions about power loads, power requirements, and input ratings.

Plugs and outlets

If a receptacle (power outlet) that you intend to use with your computer equipment appears to be damaged or corroded, do not use the outlet until it is replaced by a qualified electrician.

Do not bend or modify the plug. If the plug is damaged, contact the manufacturer to obtain a replacement.

Some products are equipped with a three-pronged plug. This plug fits only into a grounded electrical outlet. This is a safety feature. Do not defeat this safety feature by trying to insert it into a non-grounded outlet. If you cannot insert the plug into the outlet, contact an electrician for an approved outlet adapter or to replace the outlet with one that enables this safety feature. Never overload an electrical outlet. The overall system load should not exceed 80 percent of the branch circuit rating. Consult an electrician for more information if you have questions about power loads and branch circuit ratings.

Be sure that the power outlet you are using is properly wired, easily accessible, and located close to the equipment. Do not fully extend power cords in a way that will stress the cords.

Carefully connect and disconnect the equipment from the electrical outlet.

Batteries

All personal computers manufactured by Lenovo contain a non-rechargeable coin cell battery to provide power to the system clock. In addition many mobile products such as ThinkPad notebook PCs utilize a rechargeable battery pack to provide system power when in portable mode. Batteries supplied by Lenovo for use with your product have been tested for compatibility and should only be replaced with approved parts.

Never attempt to open or service any battery. Do not crush, puncture, or incinerate batteries or short circuit the metal contacts. Do not expose the battery to water or other liquids. Only recharge the battery pack strictly according to instructions included in the product documentation.

Battery abuse or mishandling can cause the battery to overheat, which can cause gasses or flame to “vent” from the battery pack or coin cell. If your battery is damaged, or if you notice any discharge from your battery or the buildup of foreign materials on the battery leads, stop using the battery and obtain a replacement from the battery manufacturer.

viii User Guide

Batteries can degrade when they are left unused for long periods of time. For some rechargeable batteries (particularly Lithium Ion batteries), leaving a battery unused in a discharged state could increase the risk of a battery short circuit, which could shorten the life of the battery and can also pose a safety hazard. Do not let rechargeable Lithium-Ion batteries completely discharge or store these batteries in a discharged state.

Heat and product ventilation

Computers generate heat when turned on and when batteries are charging. Notebook PCs can generate a significant amount of heat due to their compact size. Always follow these basic precautions:

v Do not leave the base of your computer in contact with your lap or any part of

your body for an extended period when the computer is functioning or when the battery is charging. Your computer produces some heat during normal operation. Extended contact with the body could cause discomfort or, potentially, a skin burn.

v Do not operate your computer or charge the battery near flammable materials or

in explosive environments.

v Ventilation slots, fans and/or heat sinks are provided with the product for safety,

comfort, and reliable operation. These features might inadvertently become blocked by placing the product on a bed, sofa, carpet, or other flexible surface. Never block, cover or disable these features.

should inspect your desktop computer for dust accumulation at least once

You every three months. Before inspecting your computer, turn off the power and unplug the computer’s power cord from the electrical outlet; then remove any dust from vents and perforations in the bezel. If you notice external dust accumulation, you should also examine and remove dust from the inside of the computer including heat sink inlet fins, power supply vents, and fans. Always turn off and unplug the computer before opening the cover. If possible, avoid operating your computer within 2 feet of high-traffic areas. If you must operate your computer in or near a high-traffic area, you should inspect and, if necessary, clean your computer more frequently.

For your safety and to maintain optimum computer performance, always follow these basic precautions with your desktop computer:

v Keep the cover closed whenever the computer is plugged in.

v Regularly inspect the outside of the computer for dust accumulation.

v Remove dust from vents and any perforations in the bezel. More frequent

cleanings might be required for computers in dusty or high-traffic areas.

v Do not block or restrict airflow into the front of the computer.

v Do not block the airflow vents on the back of the computer.

v Do not store or operate your computer inside furniture, as this might increase

the risk of overheating.

v Airflow temperatures into the computer should not exceed 35° C (95° F).

v Do not use non-ThinkCentre air filtration devices.

CD and DVD drive safety

CD and DVD drives spin discs at a high speed. If a CD or DVD is cracked or otherwise physically damaged, it is possible for the disc to break apart or even shatter when the CD drive is in use. To protect against possible injury due to this situation, and to reduce the risk of damage to your machine, do the following:

v Always store CD/DVD discs in their original packaging

v Always store CD/DVD discs out of direct sunlight and away from direct heat

sources

v Remove CD/DVD discs from the computer when not in use

v Do not bend or flex CD/DVD discs, or force them into the computer or their

packaging

Important safety information ix

v Check CD/DVD discs for cracks before each use. Do not use cracked or

damaged discs

Additional safety information

Danger Electrical current from power, telephone, and communication cables is hazardous.

To avoid a shock hazard:

v Do not connect or disconnect any cables or perform installation, maintenance,

or reconfiguration of this product during an electrical storm.

v Connect all power cords to a properly wired and grounded electrical outlet.

v Connect to properly wired outlets any equipment that will be attached to this

product.

v When possible, use one hand only to connect or disconnect signal cables.

v Never turn on any equipment when there is evidence of fire, water, or

structural damage.

v Disconnect the attached power cords, telecommunications systems, networks,

and modems before you open the device covers, unless instructed otherwise in the installation and configuration procedures.

v Connect and disconnect cables as described in the following table when

installing, moving, or opening covers on this product or attached devices.

To connect:

1. Turn everything OFF.

2. First, attach all cables to devices.

3. Attach signal cables to connectors.

4. Attach power cords to outlet.

5. Turn device ON.

Lithium battery notice

Caution Danger of explosion if battery is incorrectly replaced.

When replacing the battery, use only Part Number 33F8354 or an equivalent type

battery recommended by the manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.

Do not:

v Throw or immerse into water v Heat to more than 100°C (212°F) v Repair or disassemble

To disconnect:

1. Turn everything OFF.

2. First, remove power cords from outlet.

3. Remove signal cables from connectors.

4. Remove all cables from devices.

x User Guide

Dispose

of the battery as required by local ordinances or regulations.

Modem safety information

Caution To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.

To reduce the risk of fire, electrical shock, or injury when using telephone

equipment, always follow basic safety precautions, such as:

v Never install telephone wiring during a lightning storm.

v Never install telephone jacks in wet locations unless the jack is specifically

designed for wet locations.

v Never touch uninsulated telephone wires or terminals unless the telephone line

has been disconnected at the network interface.

v Use caution when installing or modifying telephone lines.

v Avoid using a telephone (other than a cordless type) during an electrical storm.

There may be a remote risk of electric shock from lightning.

v Do not use the telephone to report a gas leak in the vicinity of the leak.

Laser compliance statement

Some personal computer models are equipped from the factory with a CD-ROM drive or a DVD-ROM drive. CD-ROM drives and DVD-ROM drives are also sold separately as options. CD-ROM drives and DVD-ROM drives are laser products. These drives are certified in the U.S. to conform to the requirements of the Department of Health and Human Services 21 Code of Federal Regulations (DHHS 21 CFR) Subchapter J for Class 1 laser products. Elsewhere, these drives are certified to conform to the requirements of the International Electrotechnical Commission (IEC) 825 and CENELEC EN 60 825 for Class 1 laser products.

When a CD-ROM drive or a DVD-ROM drive is installed, note the following handling instructions.

Caution Use of controls or adjustments or performance of procedures other than those specified herein might result in hazardous radiation exposure.

Removing the covers of the CD-ROM drive or DVD-ROM drive could result in

exposure to hazardous laser radiation. There are no serviceable parts inside the CD-ROM drive or DVD-ROM drive. Do not remove the drive covers.

Some CD-ROM drives and DVD-ROM drives contain an embedded Class 3A or Class 3B laser diode. Note the following statement.

Danger Laser radiation when open. Do not stare into the beam, do not view directly with optical instruments, and avoid direct exposure to the beam.

Important safety information xi

Power supply statement

Never remove the cover on a power supply or any part that has the following label attached.

Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components. If you suspect a problem with one of these parts, contact a service technician.

xii User Guide

Overview

Thank you for selecting this computer. Your computer incorporates many of the latest advances in computer technology and can be upgraded as your needs change.

Adding hardware options to your computer is an easy way to increase its capabilities. Instructions for installing external and internal options are included in this publication. When adding an option, use these instructions along with the instructions that come along with the option.

Information resources

The Quick Reference that comes with your computer provides information for installing your computer and starting the operating system. It also includes basic troubleshooting information, software recovery procedures, help and service information, and warranty information.

The Access IBM program, on your desktop, provides a link to more information about your computer.

If you have Internet access, the most up-to-date information for your computer is available from the World Wide Web.

You can find the following information:

v CRU removal and installation instructions v Publications v Troubleshooting information v Parts information v Downloads and drivers v Links to other useful sources of information v Support phone list

To access this information, point your browser to: http://www.lenovo.com/think/support/

xiv User Guide

Chapter 1. Installing options

Features

This chapter provides an introduction to the features and options that are available for your computer. You can expand the capabilities of your computer by adding memory, adapters, or drives. When installing an option, use these instructions along with the instructions that come with the option.

Important

Before you install or remove any option, read “Important safety information” on page v. These precautions and guidelines will help you work safely.

Note: Use only the parts provided by Lenovo.

This section provides an overview of the computer features and preinstalled software.

System information

The following information covers a variety of models. For information for your specific model, refer to the Setup Utility program. See Chapter 2, “Using the Setup Utility program,” on page 27.

Microprocessor (varies by model type)

v Intel

Pentium

4 processor with HyperThreading Technology

v Intel Pentium 4 processor

v Intel Celeron

processor

v Internal cache (size varies by model type)

Memory

v Support for four double data rate 2 (DDR2) dual inline memory modules

(DIMM)

v 512 KB flash memory for system programs

Internal

drives

v 3.5-inch, slim, 1.44 MB diskette drive

v Serial Advanced Technology Attachment (SATA) internal hard disk drive

v Optical drive (some models)

subsystem

Video

v An integrated graphics controller for a Video Graphics Array (VGA) monitor

v Peripheral component interconnect (PCI) Express (x16) graphics connector on the

system board (some models)

Audio subsystem

v AC’97 with ADI 1988B Audio Codec

v Microphone and headphone connectors on the front panel

v Line in, line out, and microphone connectors on the rear panel

v IEEE 1394 front connector (some models)

v Mono internal speaker (some models)

Connectivity

v 10/100 Mbps integrated Broadcom Ethernet controller (some models)

v 10/100/1000 Mbps integrated Broadcom Ethernet controller (some models)

v Support for the Wake on LAN

feature

v PCI V.90 Data/Fax modem (some models)

System

management features

v Remote Program Load (RPL) and Dynamic Host Configuration Protocol (DHCP)

v Wake on LAN

v Wake on Ring (in the Setup Utility program, this feature is called Serial Port

Ring Detect for an external modem)

v Remote Administration

v Automatic power-on startup

v System Management (SM) BIOS and SM software

v Ability to store power-on self-test (POST) hardware test results

Input/output

features

v 25-pin, Extended Capabilities Port (ECP)/Extended Parallel Port (EPP)

v Two 9-pin serial connectors (some models)

v Six 4-pin, USB connectors (two on front panel and four on rear panel)

v Standard mouse connector

v Standard keyboard connector

v Ethernet connector

v VGA monitor connector

v Audio connectors (see Audio subsystem)

2 User Guide

Expansion

v Four drive bays

v Two standard PCI adapter connectors

v One PCI Express (x1) adapter connector

v One PCI Express (x16) graphics adapter connector (some models)

Power

v 230 W power supply with manual voltage selection switch (some models)

v 310 W power supply with manual voltage selection switch (some models)

v Automatic 50/60 Hz input frequency switching

v Advanced Configuration and Power Interface (ACPI) support

Security

features

v User and administrator passwords for BIOS access

v User and master passwords for hard disk drive (some models)

v Support for the addition of a padlock to secure the cover

v Support for the addition of an integrated cable lock to secure the cover

v Startup sequence control

v Startup without diskette drive, keyboard, or mouse

v Unattended start mode

v Diskette and hard disk I/O control

v Serial and parallel port I/O control

v Security profile by device

Preinstalled

software

Your computer might come with preinstalled software. If it does, an operating system, device drivers to support built-in features, and other support programs are included.

Operating systems, preinstalled (varies by model type)

Note: Not all countries or regions will have these operating systems.

v Microsoft

Windows

XP Home

v Microsoft Windows XP Professional

Operating

systems certified or tested for compatibility

v Microsoft Windows 2000

v Linux

1. The operating systems listed here are being certified or tested for compatibility at the time this publication goes to press. Additional operating systems might be identified by Lenovo as compatible with your computer following the publication of this booklet. Corrections and additions to this list are subject to change. To determine if an operating system has been certified or tested for compatibility, check the We b site of the operating system vendor.

Chapter 1. Installing options 3

Specifications

This section lists the physical specifications for your computer.

Dimensions

Height: 432 mm (17.0 in.)

Width: 178 mm (7.0 in.)

Depth: 450 mm (17.7 in.)

Weight

Minimum configuration: 10.5 kg (23 lb)

Maximum configuration: 13.5 kg (30 lb)

Environment

Air temperature:

Humidity:

Electrical

Input voltage:

High range:

Input kilovolt-amperes (kVA) (approximate):

System on: 10° to 35°C (50° to 95° F) System off: 10° to 60°C (50° to 140° F)

Maximum altitude: 914 m (3000 ft) Note: The maximum altitude, 914 m (3000 ft), is the maximum altitude at which the specified air temperatures apply. At higher altitudes, the maximum air temperatures are lower than those specified.

System on: 10% to 80%

System off: 10% to 90%

input

Low range:

Minimum: 100 V ac

Maximum: 127 V ac

Input frequency range: 50-60 Hz

Voltage switch setting: 115 V ac

Minimum: 200 V ac

Maximum: 240 V ac

Input frequency range: 50-60 Hz

Voltage switch setting: 230 V ac

Minimum configuration as shipped: 0.09 kVA

Maximum configuration: 0.32 kVA

Heat output (approximate) in British thermal units (Btu) per hour:

Minimum configuration: 256 Btu/hr (75 watts)

Maximum configuration: 1058 Btu/hr (310 watts)

Airflow

Approximately 1.13 cubic meters per minute (40 cubic feet per minute) maximum

Acoustical

Declared (upper limit) sound-power levels:

noise-emission values

Average sound-pressure levels:

At operator position:

Idle: 29 dBA

Operating: 33 dBA

At bystander position - 1 meter (3.3 ft):

Idle: 25 dBA

Operating: 30 dBA

Idle: 4.0 bels

Operating: 4.3 bels

Note: These levels were measured in controlled acoustical environments according to the procedures specified by the American National Standards Institute (ANSI) S12.10 and ISO 7779 and are reported in accordance with ISO 9296. Actual sound-pressure levels in a given location might exceed the average values stated because of room reflections and other nearby noise sources. The declared sound-power levels indicate an upper limit, below which a large number of computers will operate.

Note: Power consumption and heat output vary depending on the number and type of optional features installed and the power-management optional features in use.

4 User Guide

Available options

The following are some available options:

v External options

Internal options

– Parallel port devices, such as printers and external drives

– Serial port devices, such as external modems and digital cameras

– Audio devices, such as external speakers for the sound system

– USB devices, such as printers, joysticks, and scanners

– Security device, such as a padlock or integrated cable lock

– Monitors

– IEEE 1394 devices (requires an IEEE 1394 adapter)

– System memory

– PCI adapters

– PCI Express (x1) adapter

– PCI Express (x16) graphics adapter (some models)

– Internal drives, such as:

- Optical drives, such as CD and DVD drives

- Hard disk drive

- Diskette drives and other removable media drives

Tools required

the latest information about available options, see the following World Wide

For Web pages:

v http://www.lenovo.com/think/en

v http://www.lenovo.com/think/support/

also can obtain information by calling the following telephone numbers:

You

v Within the United States, call 1-800-426-2968, your Lenovo reseller, or Lenovo

marketing representative.

v Within Canada, call 1-800-565-3344 or 1-800-426-2968.

v Outside the United States and Canada, contact your Lenovo reseller or Lenovo

marketing representative.

To install some options in your computer, you might need a flat-blade or Phillips screwdriver. Additional tools might be needed for certain options. See the instructions that come with the option.

Chapter 1. Installing options 5

Handling static-sensitive devices

Static electricity, although harmless to you, can seriously damage computer components and options.

When you add an option, do not open the static-protective package containing the option until you are instructed to do so.

When you handle options and other computer components, take these precautions to avoid static electricity damage:

v Limit your movement. Movement can cause static electricity to build up around

you.

v Always handle components carefully. Handle adapters and memory modules by

the edges. Never touch any exposed circuitry.

v Prevent others from touching components.

v When you install a new option, touch the static-protective package containing

the option to a metal expansion-slot cover or other unpainted metal surface on the computer for at least two seconds. This reduces static electricity in the package and your body.

v When possible, remove the option and install it directly in the computer without

setting the option down. When this is not possible, place the static-protective package that the option came in on a smooth, level surface and place the option on it.

v Do not place the option on the computer cover or other metal surface.

Installing external options

This section shows the various external connectors on your computer to which you can attach external options, such as external speakers, a printer, or a scanner. For some external options, you must install additional software in addition to making the physical connection. When adding an external option, use the information in this section to identify the required connector, and then use the instructions that come with the option to help you make the connection and install any software or device drivers that are required for the option.

6 User Guide

Locating the connectors on the front of your computer

The following illustration shows the locations of the connectors on the front of the computer.

Note: Not all computer models will have the following connectors.

1 3 9 4

1 IEEE 1394 connector (some models) 4 Microphone connector 2 USB connector 5 Headphone connector 3 USB connector

Chapter 1. Installing options 7

Locating the connectors on the rear of your computer

The following illustration shows the locations of the connectors on the rear of the computer.

1 Diagnostic LEDs 11 Ethernet connector 2 Voltage selection switch 12 USB connectors (2) 3 Power connector 13 Keyboard connector 4 Audio line in connector 14 Mouse connector 5 Audio line out connector 15 PCI Express (x16) graphics

adapter connector (some models)

6 Microphone connector 16 PCI adapter connector 7 Serial connector (COM 1) 17 PCI adapter connector 8 Parallel connector 18 PCI Express (x1) adapter connector 9 VGA monitor connector 19 Serial connector (COM 2) (some models) 10 USB connectors (2)

Note: Some connectors on the rear of the computer are color-coded to help you

determine where to connect the cables on your computer.

8 User Guide

Connector Description

Audio line in connector Used to receive audio signals from an external audio device,

such as a stereo system. When you attach an external audio device, a cable is connected between the audio line out connector of the device and the audio line in connector of the computer.

Audio line out connector Used to send audio signals from the computer to external

devices, such as powered stereo speakers (speakers with built-in amplifiers), headphones, multimedia keyboards, or the audio line in connector on a stereo system or other external recording device.

Ethernet connector Used to attach an Ethernet cable for a local area network

(LAN). Note: To operate the computer within FCC Class B limits, use a Category 5 Ethernet cable.

Keyboard connector Used to attach a keyboard that uses a standard keyboard

connector.

Microphone connector Used to attach a microphone to your computer when you want

to record voice or other sounds on the hard disk if you use speech-recognition software.

Mouse connector Used to attach a mouse, trackball, or other pointing device that

uses a standard mouse connector.

Parallel connector Used to attach a parallel printer, parallel scanner, or other

devices that use a 25-pin parallel connector.

Serial connector Used to attach an external modem, serial printer, or other

devices that use a 9-pin serial connector.

USB connectors Used to attach a device that requires a Universal Serial Bus

(USB) connection, such as a USB scanner or USB printer. If you have more than eight USB devices, you can purchase a USB hub, which you can use to connect additional USB devices.

Obtaining device drivers

You can obtain device drivers for operating systems that are not preinstalled at http://www.lenovo.com/think/support/ on the World Wide Web. Installation instructions are provided in README files with the device-driver files.

Chapter 1. Installing options 9

Removing the cover

Important

Read “Important safety information” on page v and “Handling static-sensitive devices” on page 6 before removing the cover.

To remove the cover:

1. Shut down your operating system, remove any media (diskettes, CDs, or tapes)

from the drives, and turn off all attached devices and the computer.

2. Unplug all power cords from electrical outlets.

3. Disconnect all cables attached to the computer. This includes power cords,

input/output (I/O) cables, and any other cables that are connected to the computer.

4. Remove any locking devices such as a padlock or Kensington lock that secure

the cover.

5. Press the cover-release button on the right side cover, slide the cover to the

rear, and lift off.

10 User Guide

Locating components

The following illustration will help you locate the various components in your computer.

1 Optical drive 2 Memory modules 3 Power supply 4 PCI adapter connector 5 PCI adapter card 6 System board 7 Hard disk drive 8 Internal speaker 9 Diskette drive

Chapter 1. Installing options 11

Identifying parts on the system board

The system board (sometimes called the planar or motherboard) is the main circuit board in your computer. It provides basic computer functions and supports a variety of devices that are factory-installed or that you can install later.

The following illustration shows the locations of parts on the system board.

1 Speaker connector 12 PCI adapter connector 1 2 Memory connector 4 13 PCI adapter connector 2 3 Memory connector 3 14 Serial connector 4 Memory connector 2 15 PCI Express (x1) adapter

connector

5 Memory connector 1 16 Clear CMOS/Recovery jumper 6 Front panel I/Oconnector 17 Battery 7 Power supply connector 18 Microprocessor fan connector 8 PATA IDE connectors 19 Microprocessor 9 System fan connector 20 Microprocessor heat sink 10 SATA connectors 21 12v power connector 11 PCI Express (x16) graphics

22 Diskette drive connector

adapter connector (some models)

12 User Guide

Installing memory

Your computer has four connectors for installing dual inline memory modules (DIMMs) that provide up to a maximum of 4.0 GB of system memory.

When installing DDR2 type memory modules, the following rules apply:

v Use 1.8 V, 240-pin DDR2 synchronous dynamic random access memory

v Use 256 MB, 512 MB or 1.0 GB memory modules in any combination.

1. Remove the cover. See “Removing the cover” on page 10.

2. Locate the memory connectors. See “Identifying parts on the system board” on

3. Open the retaining clips.

(SDRAM).

install a memory module:

page 12.

4. Make sure that the notch 1 on the memory module aligns correctly with the connector key2 on the system board. Push the memory module straight down into the connector until the retaining clips close.

What to do next:

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Replacing the cover and connecting the

cables” on page 25.

Chapter 1. Installing options 13

Installing adapters

This section provides information and instructions for installing and removing adapters. Your computer has two expansion connectors for PCI adapters, one for a PCI Express (x1) adapter, and one for a PCI Express (x16) adapter.

To install an adapter:

1. Remove the cover. See “Removing the cover” on page 10.

2. Push the adapter latch and remove the slot cover for the appropriate PCI

connector.

3. Remove the adapter from its static-protective package.

4. Install the adapter into the appropriate connector on the system board.

5. Close the adapter latch and snap it into the closed position.

14 User Guide

What to do next

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Replacing the cover and connecting the

cables” on page 25.

Installing internal drives

This section provides information and instructions for installing and removing internal drives.

Internal drives are devices that your computer uses to read and store data. Yo u can add drives to your computer to increase storage capacity and to enable your computer to read other types of media. Some of the different drives that are available for your computer are:

v Serial ATA hard disk drives

v Parallel ATA hard disk drives

v Optical drives, such as CD drives or DVD drives

v Removable media drives

These different drives are also referred to as integrated drive electronics

Note:

(IDE) drives.

Internal drives are installed in bays. In this book, the bays are referred to as bay 1, bay 2, and so on.

When you install an internal drive, it is important to note what type and size of drive that you can install in each bay. Also, it is important to correctly connect the internal drive cables to the installed drive.

Drive specifications

Your computer comes with the following factory-installed drives:

v An optical drive in bay 1 (some models)

v A 3.5-inch diskette disk drive in bay 3

v A 3.5-inch hard drive in bay 4

bay that does not have a drive installed has a static shield and bay panel

Any installed.

Chapter 1. Installing options 15

The following illustration shows the locations of the drive bays.

The following list describes the types and size of drives you can install in each bay:

1Bay 1 - Maximum height: 43.0 mm (1.7 in.) v Optical drive such as CD drive or DVD

drive (preinstalled in some models)

v 5.25-inch hard disk drive v 3.5-inch hard disk drive (requires a

Universal Adapter Bracket, 5.25 to

3.5-inch)*

2Bay 2 - Maximum height: 43.0 mm (1.7 in.) v Optical drive such as CD drive or DVD

drive

v 5.25-inch removable media drive v 3.5-inch hard disk drive (requires a

Universal Adapter Bracket, 5.25 to

3.5-inch)*

3Bay 3 - Maximum height: 25.8 mm (1.0 in.) 3.5-inch diskette drive (preinstalled) 4Bay 4 - Maximum height: 25.8 mm (1.0 in.) 3.5-inch S ATA hard disk drive

(preinstalled)

* Yo u can obtain a Universal Adapter Bracket, 5.25 to 3.5-inch, from a local computer retailer or by contacting the Customer Support Center.

16 User Guide

Installing a drive in bay 1 or bay 2

To install a drive in bay 1 or bay 2, follow these steps:

1. Remove the cover. See “Removing the cover” on page 10.

2. Remove the front bezel by pressing downward on the plastic tabs 1 and

pulling the bezel as shown.

3. Remove the static shield from the drive bay by using a flat-blade screwdriver

to gently pry it loose.

4. Remove the plastic panel in the bezel for bay 1 or 2 by squeezing the plastic

tabs that secure the panel on the inside of the bezel.

Chapter 1. Installing options 17

5. If you are installing any type of drive other than a serial ATA hard disk drive,

make sure the drive that you are installing is set correctly as either a master or a slave device.

Note: A serial ATA hard disk drive does not need to be set as either a master

or a slave device.

v If it is the first CD drive or DVD drive, set it as a master device.

v If it is an additional CD drive or DVD drive, set it as a slave device.

v If it is an additional parallel ATA hard disk drive, set it as a slave device.

Refer to the documentation that comes with your drive for master/slave jumper information.

6. For the 5.25-inch drive, install a retainer bracket on the side of the drive.

7. For the 3.5-inch drive, install the drive into the Universal Adapter Bracket,

5.25 to 3.5-inch.

8. Install the drive into the bay until it snaps into position.

18 User Guide

9. Install the front bezel by aligning the plastic tabs on the bottom of the bezel

10. Continue at “Connecting drives.”

Connecting drives

The steps to connect a drive are different depending on the type of drive. Use one of the following procedures for your drive connection.

Connecting the first optical drive

1. The drive requires two cables; a power cable that connects to the power supply

2. Locate the three-connector signal cable that comes with your computer or with

3. Locate the PATA IDE connector on the system board. See “Identifying parts on

4. Connect one end of the signal cable to the drive and the other to the PATA IDE

5. Locate the extra four-wire power connector labelled P4 and connect it to the

with the corresponding holes in chassis and press it onto the chassis until it snaps into position.

and a signal cable that connects to the system board.

the new drive.

the system board” on page 12.

connector on the system board. To reduce electronic noise, use the connectors at the end of the cable only.

drive.

Chapter 1. Installing options 19

Connecting an additional optical drive, or parallel ATA hard disk drive

1. Locate the extra connector on the three-connector signal cable that is attached

to the PATA IDE connector on the system board. See “Identifying parts on the system board” on page 12.

2. Connect the extra connector on the signal cable to the new drive.

3. Locate the extra four-wire power connector and connect it to the drive.

Connecting a serial ATA hard disk drive

A serial hard disk drive can be connected to any available SATA IDE connector.

1. Locate the signal cable that comes with the new drive.

2. Locate an available SATA IDE connector on the system board. See “Identifying

parts on the system board” on page 12.

3. Connect one end of the signal cable to the drive and the other to an available

SATA IDE connector on the system board.

4. Locate one of the extra five-wire power connectors and connect it to the drive.

20 User Guide

What to do next

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Replacing the cover and connecting the

cables” on page 25.

Installing security features

To help prevent hardware theft and unauthorized access to your computer, several security lock options are available. The following sections will help you identify and install the various types of locks that might be available for your computer. In addition to physical locks, unauthorized use of your computer can be prevented by a software lock that locks the keyboard until a correct password is typed in.

Make sure that any security cables you install do not interfere with other computer cables.

Identifying security locks

The following illustration shows the locations of the security locks on the rear of the computer.

1 Padlock loop 2 Integrated cable lock

Chapter 1. Installing options 21

Padlock

Your computer is equipped with a padlock loop such that the cover cannot be removed when a padlock is installed.

22 User Guide

Integrated cable lock

With an integrated cable lock (sometimes referred to as a Kensington lock), you can secure your computer to a desk, table, or other non-permanent fixture. This lock also secures the computer cover. The cable lock attaches to a security slot at the rear of your computer and is operated with a key. This is the same type of lock used with many laptop computers. You can order a cable lock directly from Lenovo. Go to http://www.lenovo.com.think/support and search on Kensington.

Password protection

To deter unauthorized use of your computer, you can use the Setup Utility program to set passwords. See “Using passwords” on page 27.

What to do next

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Replacing the cover and connecting the

cables” on page 25

Changing the battery

Your computer has a special type of memory that maintains the date, time, and settings for built-in features, such as parallel-port assignments (configuration). A battery keeps this information active when you turn off the computer.

The battery normally requires no charging or maintenance throughout its life; however, no battery lasts forever. If the battery fails, the date, time, and

Chapter 1. Installing options 23

configuration information (including passwords) are lost. An error message is displayed when you turn on the computer.

Refer to “Lithium battery notice” on page x for information about replacing and disposing of the battery.

To change the battery:

1. Turn off the computer and all attached devices.

2. Remove the cover. See “Removing the cover” on page 10.

3. Locate the battery. See “Identifying parts on the system board” on page 12.

4. If necessary, remove any adapters that impede access to the battery. See

“Installing adapters” on page 14 for more information.

5. Remove the old battery.

6. Install the new battery.

7. Replace any adapters that were removed to gain access to the battery. See

“Installing adapters” on page 14 for instructions for replacing adapters.

8. Replace the cover, and plug in the power cord. See “Replacing the cover and

connecting the cables” on page 25.

Note: When the computer is turned on for the first time after battery

replacement, an error message might be displayed. This is normal after replacing the battery.

9. Turn on the computer and all attached devices.

10. Use the Setup Utility program to set the date and time and any passwords.

See Chapter 2, “Using the Setup Utility program,” on page 27.

Erasing a lost or forgotten password (clearing CMOS)

This section applies to lost or forgotten passwords. For more information about lost or forgotten passwords, see the Access IBM program on your desktop.

To erase a forgotten password:

1. Turn off the computer and all attached devices.

2. Remove the cover. See “Removing the cover” on page 10.

3. Locate the Clear CMOS/Recovery jumper on the system board. See

“Identifying parts on the system board” on page 12.

4. If necessary, see “Installing adapters” on page 14 to remove any adapters that

impede access to the Clear CMOS/Recovery jumper.

24 User Guide

5. Move the jumper from the standard position (pins 1 and 2) to the

maintenance or configure position (pins 2 and 3).

6. Replace the cover and connect the power cord. See “Replacing the cover and

connecting the cables.”

7. Restart the computer, leave it on for approximately ten seconds. Turn off the

computer by holding the power switch for approximately five seconds. The computer will turn off.

8. Repeat steps 2 through 4 on page 24.

9. Move the jumper back to the standard (pins 1 and 2).

10. Replace the cover and connect the power cord. See “Replacing the cover and

connecting the cables.”

Replacing the cover and connecting the cables

After working with options, you need to install any removed parts, replace the cover, and reconnect any cables, including telephone lines and power cords. Also, depending on the option that is installed, you might need to confirm the updated information in the Setup Utility program.

To replace the cover and connect cables to your computer:

1. Ensure that all components have been reassembled correctly and that no tools or loose screws are left inside your computer.

2. Clear any cables that might impede the replacement of the cover.

3. Position the cover on the chassis so that the rail guides on the bottom of the

cover engage the rails and push the cover closed until it latches.

4. Install any cover locking devices such as a cable lock or padlock as necessary.

5. Reconnect the external cables and power cords to the computer. See “Installing

external options” on page 6.

6. To update the configuration, see Chapter 2, “Using the Setup Utility program,” on page 27.

Chapter 1. Installing options 25

26 User Guide

Chapter 2. Using the Setup Utility program

The Setup Utility program is stored in the electrically erasable programmable read-only memory (EEPROM) of your computer. The Setup Utility program is used to view and change the configuration settings of your computer, regardless of which operating system you are using. However, the operating-system settings might override any similar settings in the Setup Utility program.

Starting the Setup Utility program

To start the Setup Utility program, do the following:

1. If your computer is already on when you start this procedure, shut down the operating system and turn off the computer.

2. Press and hold the F1 key then turn on the computer. When you hear multiple beeps, release the F1 key.

Notes:

a. If you have a USB keyboard installed on your computer and the Setup

Utility does not display using this method, turn on the computer, then immediately press and release the F1 key repeatedly until the Setup Utility displays.

b. If a user password or an administrator password has been set, the Setup

Utility program menu is not displayed until you type your password. See “Using passwords” for more information.

Setup Utility might start automatically when POST detects that hardware has

The been removed or new hardware has been installed in your computer.

Viewing and changing settings

The Setup Utility program menu lists items that identify system configuration topics.

When working with the Setup Utility program menu, you must use the keyboard. The keys used to perform various tasks are displayed at the bottom of each screen.

Using passwords

By using the Setup Utility program, you can set passwords to prevent unauthorized persons from gaining access to your computer and data. The following types of passwords are available:

v User Password

v Administrator Password

do not have to set any passwords to use your computer. However, if you

You decide to set any passwords, read the following sections.

User Password

When a User Password is set, the user is prompted to type a valid password each time the computer is turned on. The computer cannot be used until a valid password is typed from the keyboard.

Administrator Password

Setting an Administrator Password deters unauthorized persons from changing configuration settings. If you are responsible for maintaining the settings of several computers, you might want to set an Administrator Password.

After you set an Administrator Password, a password prompt is displayed each time you try to access the Setup Utility program. If you type the wrong password, you will see an error message. If you type the wrong password three times, you must turn the computer off and start again.

If both the user and administrator passwords are set, you can type either password. However, to change any configuration settings, you must use your administrator password.

Setting, changing, and deleting a password

To set, change, or delete a password, do the following:

Note: A password can be any combination of up to 12 characters (A- Z, a-z, and

0-9).

1. Start the Setup Utility program (see “Starting the Setup Utility program” on

page 27).

2. From the Setup Utility program menu, select Security.

3. Select Set Passwords. Read the information displayed on the right side of the

screen.

Using Security Profile by Device

Security Profile by Device is used to enable or disable user access to the following devices:

IDE controller When this feature is set to Disable, all devices connected to the

IDE controller (such as hard disk drives or the CD-ROM drive) are disabled and will not be displayed in the system configuration.

Diskette Drive Access When this feature is set to Disable, the diskette drive cannot be

accessed.

Diskette Write Protect When this feature is set to Enable, all diskettes are treated as if

they are write-protected. You can read from the diskette, but you cannot write to the diskette.

To set Security Profile by Device, do the following:

1. Start the Setup Utility program (see “Starting the Setup Utility program” on

page 27).

2. From the Setup Utility program menu, select Security.

3. Select Security Profile by Device.

4. Select the desired devices and settings and press Enter.

5. Return to the Setup Utility program menu and select Exit and then Save

Settings.

28 User Guide

Selecting a startup device

If your computer does not start up (boot) from a device such as the CD-ROM, diskette, or hard disk as expected, use one of the following procedures to select a startup device.

Selecting a temporary startup device

Use this procedure to startup from any boot device.

Note: Not all CDs, hard disks, and diskettes are startable (bootable).

1. Turn off your computer.

2. Press and hold the F12 key then turn on the computer. When the Startup

Device Menu appears, release the F12 key.

Note: If you have a USB keyboard installed on your computer and the Startup

Device Menu does not display using this method, turn on the computer, then immediately press and release the F12 key repeatedly until the Startup Device Menu displays.

3. Select the desired startup device from the Startup Device Menu and press Enter to begin.

Selecting a startup device from the Startup Device Menu does not

Note:

permanently change the startup sequence.

Changing the startup sequence

To view or change the primary or automatic power-on startup sequence, do the following:

1. Start the Setup Utility program (see “Starting the Setup Utility program” on page 27).

2. Select Startup.

3. Select Startup Sequence. See the information displayed on the right side of the

screen.

4. Select the sequence of devices for the Primary Startup Sequence, the Automatic Startup Sequence, and the Error Startup Sequence.

5. Select Exit from the Setup Utility menu and then Save Settings.

If you have changed these settings and want to return to the default settings, select Load Default Settings on the Exit menu.

Exiting from the Setup Utility program

When you finish viewing or changing settings, press Esc to return to the Setup Utility program menu (you might have to press Esc several times). If you want to save the new settings, select Save Settings before you exit. Otherwise, your changes will not be saved.

Chapter 2. Using the Setup Utility program 29

30 User Guide

Appendix A. Updating system programs

This appendix contains information about updating system programs and how to recover from a POST/BIOS update failure.

System programs

System programs are the basic layer of software that is built into your computer. They include the power-on self-test (POST), the basic input/output system (BIOS) code, and the Setup Utility program. POST is a set of tests and procedures that is performed each time you turn on your computer. BIOS is a layer of software that translates instructions from other layers of software into electrical signals that the computer hardware can understand. You can use the Setup Utility program to view and change the configuration and setup of your computer.

Your computer system board has a module called electrically erasable programmable read-only memory (EEPROM, also referred to as flash memory). You can easily update POST, BIOS, and the Setup Utility program by starting your computer using a flash update diskette or by running a special update program from your operating system.

Lenovo might make changes and enhancements to the system programs. When updates are released, they are available as downloadable files on the World Wide Web (see the Quick Reference). Instructions for using the system program updates are available in a .txt file that is included with the update files. For most models, you can download either an update program to create a system-program-update (flash) diskette or an update program that can be run from the operating system.

Updating (flashing) BIOS from a diskette or CD-ROM

To update (flash) the BIOS from a diskette or CD_ROM, do the following:

1. Insert a system program update (flash) diskette or CD-ROM into the diskette drive or optical drive. System program updates are available at http://www.lenovo.com/think/support on the World Wide Web.

2. Turn on the computer. If it is on already, you must turn it off and back on again. The update begins.

3. When you are prompted to select a language, press the number on your keyboard which corresponds to the language then press Enter.

4. When prompted to change the serial number, press Y.

5. Type in the seven character serial number of your computer then press Enter.

6. When prompted to change the machine type/model, press Y.

7. Type in the seven character machine type/model of your computer then press

Enter.

8. Follow the instructions on the screen to complete the update.

Updating (flashing) BIOS from your operating system

Note: Due to constant improvements being made to the Web site, Web page

content (including the links referenced in the following procedure) is subject to change.

1. From your browser, type http://www.lenovo.com/think/support in the

address field and press Enter.

2. Locate the Downloadable files for your machine type as follows:

a. Under Use Quick path, type your machine type and click Go.

b. Click Continue.

c. Click Downloads and drivers.

d. Under the BIOS category, click the Flash BIOS update .

e. Click the .txt file that contains the installation instructions for the flash BIOS

update (flash from the operating system version).

Print these instructions. This is very important since they are not on the screen

after the download begins.

4. From your browser, click Back to return to the list of files. Carefully follow the

printed instructions to download, extract, and install the update.

Recovering from a POST/BIOS update failure

If power to your computer is interrupted while POST/BIOS is being updated (flash update), your computer might not restart correctly. If this happens, perform the following procedure (also known as a Boot-block Recovery):

1. Turn off the computer and any attached devices, such as printers, monitors,

and external drives.

2. Unplug all power cords from electrical outlets, and remove the cover. See

“Removing the cover” on page 10.

3. Locate the Clear CMOS/Recovery jumper on the system board. See

“Identifying parts on the system board” on page 12.

4. If necessary, refer to Installing adapters to remove any adapters that impede

access to the Clear CMOS/Recovery jumper.

5. Move the jumper from the standard position (pins 1 and 2) to pins 2 and 3.

6. Replace the cover. See “Replacing the cover and connecting the cables” on

page 25.

7. Reconnect the power cords for the computer and monitor to electrical outlets.

8. Insert the POST/BIOS update (flash) diskette into drive A, and turn on the

computer and the monitor.

9. After the update session is completed, there will be no video and the series of

beeps will end. Remove the diskette from the diskette drive, and turn off the computer and monitor.

10. Repeat steps 2 through 4.

11. Move the Clear CMOS/Recovery jumper to its original position.

12. Replace any adapters that were removed.

13. Replace the cover and reconnect any cables that were disconnected.

14. Turn on the computer to restart the operating system.

32 User Guide

Appendix B. Cleaning the mouse

This appendix provides instructions on how to clean your mouse. The procedure will be different depending on which type of mouse you have.

Cleaning an optical mouse

If you experience some problems with your optical mouse, check the following:

1. Turn the mouse over and look carefully at the lens area.

a. If there is a smudge on the lens, gently clean the area with a plain

cotton-tipped swab.

b. If there is some debris in the lens, gently blow the debris away from the

area.

Check the surface on which you are using the mouse. If you have a very

intricate picture or pattern beneath the mouse it is difficult for the digital signal processor (DSP) to determine changes in the mouse position.

Cleaning a mouse with a ball

If the pointer on the screen does not move smoothly with the mouse, you might need to clean the mouse.

Note: The following illustration might be slightly different from your mouse.

1 Retainer ring 2 Ball 3 Plastic rollers 4 Ball cage

To clean a mouse with a ball:

1. Turn off your computer.

2. Turn the mouse over, with the top side down, and look carefully at the bottom.

Twist the retainer ring1to the unlocked position to remove the ball.

3. Place your hand over the retainer ring and ball2, and then turn the mouse

over, top side up, so that the retainer ring and ball fall out into your hand.

4. Wash the ball in warm, soapy water then dry it with a clean cloth. Blow air

carefully into the ball cage4to dislodge dust and lint.

5. Look for a build up of dirt on the plastic rollers3inside the ball cage. This

build up usually appears as a stripe running across the middle of the rollers.

6. If the rollers are dirty, clean them by using a cotton swab soaked in isopropyl

(rubbing) alcohol. Turn the rollers with your finger and continue swabbing them until all the dirt is removed. Be sure the rollers are still centered in their channels after you clean them.

7. Remove any fibers from the swab that might be remaining on the rollers.

8. Replace the ball and the retainer ring.

9. Turn your computer back on.

34 User Guide

Appendix C. Manual modem commands

The following section lists commands for manually programming your modem.

Commands are accepted by the modem while it is in Command Mode. Your modem is automatically in Command Mode until you dial a number and establish a connection. Commands can be sent to your modem from a PC running communication software or any other terminal devices.

All commands sent to the modem must begin with AT and end with ENTER. All commands can be typed in either upper or lower case, but not mixed. To make the command line more readable, spaces can be inserted between commands. If you omit a parameter from a command that requires one, it is just like specifying a parameter of 0.

Example:

ATH [ENTER]

Basic AT commands

In the following listings, all default settings are printed in bold text.

Command Function

A Manually answer incoming call.

A/ Repeat last command executed. Do not

D_ 0 - 9, A-D, # and *

DS=n Dial one of the four telephone numbers

E_ E0 Commands are not echoed

+++ Escape Characters - Switch from Data Mode

H_ H0 Force modem on-hook (hang up)

precede A/ with AT or follow with ENTER.

L last number redial

P pulse dialing

Note: Pulse dialing is not supported for Australia, New Zealand, Norway, and South Africa.

T touch-tone dialing

W wait for second dial tone

, pause

@ wait for five seconds of silence

! flash

; return to Command Mode after dialing

(n=0-3) stored in the modem non-volatile memory.

E1 Commands are echoed

to Command Mode (T.I.E.S. Command)

Command Function

H1 Force modem off-hook (make busy)

Note: H1 command is not supported for Italy

I_ I0 Display product-identification code

I1 Factory ROM checksum test

I2 Internal memory test

I3 Firmware ID

I4 Reserved ID

L_ L0 Low speaker volume

L1 Low speaker volume

L2 Medium speaker volume

L3 High speaker volume

M_ M0 Internal speaker off

M1 Internal speaker on until carrier detected

M2 Internal speaker always on

M3 Internal speaker on until carrier detected and

off while dialing

N_ Included for compatibility only, provides no

effect

O_ O0 Return to Data Mode

O1 Return to Data Mode and initiate an equalizer

retrain

P Set Pulse dial as default

Q_ Q0 Modem sends responses

Sr? Read and display value in register r.

Sr=n Set register r to value n (n = 0-255).

T Set Tone Dial as default

V_ V0 Numeric responses

V1 Word responses

W_ W0 Report DTE speed only

W1 Report line speed, error correction protocol,

and DTE speed.

W2 Report DCE speed only

X_ X0 Hayes Smartmodem 300 compatible

responses/blind dialing.

X1 Same as X0 plus all CONNECT

responses/blind dialing

X2 Same as X1 plus dial tone detection

X3 Same as X1 plus busy detection/blind dialing

X4 All responses and dial tone and busy signal

detection

Z_ Z0 Reset and retrieve active profile 0

Z1 Reset and retrieve active profile 1

36 User Guide

Extended AT commands

Command Function

&C_ &C0 Force Carrier Detect Signal High (ON)

&C1 Turn on CD when remote carrier is present

&D_ &D0 Modem ignores the DTR signal

&D1 Modem returns to Command Mode after DTR

toggle

&D2 Modem hangs up, returns to the Command

Mode after DTR toggle

&D3 Resets modem after DTR toggle

&F_ &F Recall factory default configuration

&G_ &G0 Guard tone disabled

&G1 Guard tone disabled

&G2 1800 Hz guard tone

&K_ &K0 Disable flow control

&K3 Enable RTS/CTS hardware flow control

&K4 Enable XON/XOFF software flow control

&K5 Enable transparent XON/XOFF flow control

&K6 Enable both RTS/CTS and XON/XOFF flow

control

&M_ &M0 Asynchronous operation

&P_ &P0 US setting for off-hook-to-on-hook ratio

&P1 UK and Hong Kong off-hook-to-on-hook ratio

&P2 Same as &P0 setting but at 20 pulses per

minute

&P3 Same as &P1 setting but at 20 pulses per

minute

&R_ &R0 Reserved

&R1 CTS operates per flow control requirements

&S_ &S0 Force DSR Signal High (ON)

&S1 DSR off in command mode, on in on-line

mode

&T_ &T0 Ends test in progress

&T1 Perform Local Analog Loopback Test

&T3 Perform Local Digital Loopback Test

&T4 Grant Remote Digital Loopback Test request

by remote modem

&T5 Deny Remote Digital Loopback Test request

&T6 Perform a Remote Digital Loopback Test

&T7 Perform a Remote Digital Loopback Test and

Self-Test

&T8 Perform Local Analog Loopback Test and

Self-Test

&V &V0 Displays Active and Stored Profiles

Appendix C. Manual modem commands 37

Command Function

&V1 Display Last Connection Statistics

&W_ &W0 Stores the active profile as Profile 0

&W1 Stores the active profile as Profile 1

%E_ %E0 Disable auto-retrain

%E1 Enable auto-retrain

+MS? Displays the current Select Modulation

settings

+MS=? Displays a list of supported Select Modulation

options

+MS=a,b,c,e,f Select modulation where: a=0, 1, 2, 3, 9, 10, 11,

12, 56, 64, 69; b=0-1; c=300-56000; d=30056000; e=0-1; and f=0-1. A, b, c, d, e, f default=12, 1, 300, 56000, 0, 0. Parameter ″a″ specifies the modulation protocol desired where: 0=V.21, 1=V.22, 2=V.22bis, 3=V.23, 9=V.32, 10=V.32bis, 11=V.34,

12=V.90,K56Flex,V.34......,56=K 56Flex,

V.90,V.34......, 64=Bell 103, and 69=Bell 212.

Parameter ″b″ specifies automode operations where: 0=automode disabled, 1= automode enabled with V.8/V.32 Annex A. Parameter ″c″ specifies the minimum connection data rate (300- 56000). Parameter ″d″ specifies the maximum connection rate (300-56000); Parameter ″e″ specifies the codec type (0= Law, and 1=A-Law). Parameter ″f″ specifies ″robbed bit″ signaling detection (0=detection disabled 1=detection enabled)

MNP/V.42/V.42bis/V.44 commands

Command Function

%C_ %C0 Disable MNP Class 5 and V.42bis data compression

%C1 Enable MNP Class 5 data compression only

%C2 Enable V.42bis data compression only

%C3 Enable MNP Class 5 and V.42bis data compression

&Q_ &Q0 Direct data link only (same as \N1)

&Q5 V.42 data link with fallback options

&Q6 Normal data link only (same as \N0)

+DS44=0, 0 Disable V.44

+DS44=3, 0 Enable V.44

+DS44? Current values

+DS44=? List of support values

38 User Guide

Fax Class 1 commands

+FAE=n Data/Fax Auto Answer

+FCLASS=n Service Class

+FRH=n Receive data with HDLC framing

+FRM=n Receive data

+FRS=n Receive silence

+FTH=n Transmit data with HDLC framing

+FTM=n Transmit data

+FTS=n Stop transmission and wait

Fax Class 2 commands

+FCLASS=n Services class.

+FAA=n Adaptive answer.

+FAXERR Fax error value.

+FBOR Phase C data bit order.

+FBUF? Buffer size (read only).

+FCFR Indicate confirmation to receive.

+FCLASS= Service class.

+FCON Facsimile connection response.

+FCIG Set the polled station identification.

+FCIG: Report the polled station identification.

+FCR Capability to receive.

+FCR= Capability to receive.

+FCSI: Report the called station ID.

+FDCC= DCE capabilities parameters.

+FDCS: Report current session.

+FDCS= Current session results.

+FDIS: Report remote capabilities.

+FDIS= Current sessions parameters.

+FDR Begin or continue phase C receive data.

+FDT= Data transmission.

+FDTC: Report the polled station capabilities.

+FET: Post page message response.

+FET=N Transmit page punctuation.

+FHNG Call termination with status.

+FK Session termination.

+FLID= Local ID string.

+FLPL Document for polling.

+FMDL? Identify model.

+FMFR? Identify manufacturer.

Appendix C. Manual modem commands 39

+FPHCTO Phase C time out.

+FPOLL Indicates polling request.

+FPTS: Page transfer status.

+FPTS= Page transfer status.

+FREV? Identify revision.

+FSPT Enable polling.

+FTSI: Report the transmit station ID.

Voice commands

#BDR Select Baud Rate

#CID Enable Caller ID detection and reporting format

#CLS Select Data, Fax or Voice/Audio

#MDL? Identify Model

#MFR? Identify Manufacturer

#REV? Identify Revision Level

#TL Audio output transmit level

#VBQ? Query Buffer Size

#VBS Bits per sample (ADPCM or PCM)

#VBT Beep Tone Timer

#VCI? Identify Compression Method

#VLS Voice line select

#VRA Ringback goes away timer

#VRN Ringback never came timer

#VRX Voice Receive Mode

#VSDB Silence deletion tuner

#VSK Buffer skid setting

#VSP Silence detection period

#VSR Sampling rate selection

#VSS Silence deletion tuner

#VTD DTMF tone reporting capability

#VTM Enable timing mark placement

#VTS Generate tone signals

#VTX Voice transmit mode

40 User Guide

Attention Switzerland User:

If your Swisscom phone line does not have Taxsignal switched OFF, modem function may be impaired. The impairment may be resolved by a filter with the following specifications:

Telekom PTT SCR-BE Taximpulssperrfilter-12kHz PTT Art. 444.112.7 Bakom 93.0291.Z.N

Appendix C. Manual modem commands 41

42 User Guide

Appendix D. Notices

Lenovo may not offer the products, services, or features discussed in this document in all countries. Consult your local Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. However, it is the user’s responsibility to evaluate and verify the operation of any other product, program, or service.

Lenovo may have patents or pending patent applications covering subject matter described in this document. The furnishing of this document does not give you any license to these patents. You can send license inquiries, in writing, to:

Lenovo (United States), Inc. 500 Park Offices Drive, Hwy. 54 Research Triangle Park, NC 27709 U.S.A. Attention: Lenovo Director of Licensing

LENOVO

GROUP LTD. PROVIDES THIS PUBLICATION “AS IS” WITHOUT

WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This information could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. Lenovo may make improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time without notice.

The products described in this document are not intended for use in implantation or other life support applications where malfunction may result in injury or death to persons. The information contained in this document does not affect or change Lenovo product specifications or warranties. Nothing in this document shall operate as an express or implied license or indemnity under the intellectual property rights of Lenovo or third parties. All information contained in this document was obtained in specific environments and is presented as an illustration. The result obtained in other operating environments may vary.

Lenovo may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you.

Any references in this publication to non-Lenovo Web sites are provided for convenience only and do not in any manner serve as an endorsement of those Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk.

Any performance data contained herein was determined in a controlled environment. Therefore, the result obtained in other operating environments may

vary significantly. Some measurements may have been made on development-level systems and there is no guarantee that these measurements will be the same on generally available systems. Furthermore, some measurements may have been estimated through extrapolation. Actual results may vary. Users of this document should verify the applicable data for their specific environment.

Television output notice

The following notice applies to models that have the factory-installed television-output feature.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Trademarks

The following terms are trademarks of Lenovo in the United States, other countries, or both:

Lenovo ThinkCentre ThinkPad

The following terms are trademarks of International Business Machines Corporation in the United States, other countries, or both:

IBM (used under license) Wake on LAN

Microsoft and Windows are trademarks of Microsoft Corporation in the United States, other countries, or both.

Intel, Celeron, and Pentium are trademarks of Intel Corporation in the United States, other countries, or both.

Linux is a trademark of Linus Torvalds in the United States, other countries, or both.

Other company, product, or service names may be trademarks or service marks of others.

44 User Guide

Index

adapters

installing 14 peripheral component interconnect (PCI) 5

slots 14 audio line in connector 9 audio line out connector 9 audio, subsystem 2

battery location 12 boot-block recovery 32

cables, connecting 25 changing the battery 23 cleaning the mouse 33 CMOS, clearing 24 configuration utility 27 connecting drives 19 connector description 9 cover

removing 10

replacing 25

installing options (continued)

external memory 13 memory modules 13 security features 21

keyboard connector 9

memory

inline memory modules (DIMMs) 13

dual installing 13

system 13 memory modules, installing 13 microphone connector 9 modem commands

AT 35

Basic

Extended AT 37

Fax Class 1 39

Fax Class 2 39

MNP/V.42/V.42bis/V.44 38

Voice 40 mouse connector 9

device, drivers 9 drives

bays 3, 15 connecting 19 diskette 5 hard disk 5 installing 17 internal 2, 15 optical 5 removable media 5 specifications 15

environment, operating 4 Ethernet connector 9

hard disk drive security 27

information resources xiii input/output (I/O)

features 2

installing options

adapters 14 DIMMs 13

noise level 4

options

available 4

external 5

internal 5 overview xiii

parallel connector 9 password

physical specifications 4 power

erasing

lost or forgotten 24

setting, changing, deleting 28

Advanced

support 3

Configuration and Power Interface (ACPI)

recovering from a POST/BIOS update failure 32 removing the cover 10 replacing the cover 25

security

features 3, 21 hard disk drive 27

integrated cable lock 22, 23 security profile by device 28 serial connector 9 Setup Utility program 27 system board

connectors 12

identifying parts 12

location 12

memory 5, 12 system programs 31

USB connectors 9 using

passwords 27

security profile by device 28

Setup Utility program 27

video, subsystem 2

46 User Guide



Part Number: 39J7710

Printed in USA

(1P) P/N: 39J7710

IBM 8122, 8138, 8137, 8123, 8131 User Manual
