Husqvarna ProFlex 18 User Manual

Operator´s manual

Rider ProFlex 18

Please read these instructions carefully and make sure

you understand them before using the machine. English

Operator’s Manual for

Rider ProFlex 18

Contents

Contents ..................................................................1

Introduction ............................................................3

Congratulations ...................................................3

Driving and Transport on Public Roads ..............3

Towing ................................................................3

Use ......................................................................3

Proper Service ....................................................4

Serial Number .....................................................4

Symbols and decals ..............................................5

Safety instructions .................................................7

General use ........................................................7

Driving on slopes ................................................9

Children .............................................................10

Maintenance .....................................................10

Transport ...........................................................12

Presentation .........................................................13

Placement of Controls .......................................14

Throttle Control .................................................15

Choke Lever ......................................................15

Accelerator ........................................................15

Cutting unit ........................................................16

Accessories .......................................................16

Lights and power outlet .....................................16

Cutting height adjustment lever ........................17

Lever for hydraulic lift of attachments ...............17

Mechanical lifting lever for cutting unit ..............18

Parking brake ....................................................19

Seat ...................................................................19

Fuelling .............................................................19

Clutch control ....................................................20

Chronometer .....................................................20

Mowing tips .......................................................21

Clutch control ....................................................21

Driving ...................................................................22

Before Starting ..................................................22

Starting the engine ............................................22

Driving the Rider ...............................................24

Braking ..............................................................25

Stopping the engine ..........................................26

Maintenance .........................................................27

Maintenance schedule ......................................27

Removing the Rider’s covers ............................30

Left-hand wing cover .........................................31

Checking the engine’s cooling air intake ...........31

Checking the transmission air intake ................32

Checking and adjusting the steering cables .....32

Checking and adjusting the throttle cable .........33

Checking and adjusting the choke cable ..........33

Inspecting the muffler ........................................33

Adjusting the hydrostatic transmission cable ....34

Cable holder ......................................................34

Adjusting the parking brake ..............................35

Replacing the air filter ...................................... 36

Replacing the fuel filter ..................................... 38

Cleaning the pulse air filter ............................... 38

Checking the fuel pump’s air filter .................... 38

Checking the tyre pressures ............................ 39

Checking the battery acid level ........................ 39

Ignition system ................................................. 39

Fuses ............................................................... 40

Checking the safety system ............................. 41

Replacing the light bulbs .................................. 42

The cutting unit components ............................ 43

Attaching the cutting unit .................................. 43

Adjusting the cutting height,

parallelism and ground pressure ...................... 46

The cutting unit’s service position .................... 47

Cutting unit model ............................................ 48

Checking the blades ......................................... 48

Removing the cutting unit ................................. 49

Removing the unit frame .................................. 51

Removing the belt ............................................ 51

Attaching the belt ............................................. 52

Changing the cutting unit’s belt ........................ 53

Removal of BioClip Plug .................................. 54

Lubrication ........................................................... 55

Lubrication schedule ........................................ 55

General ............................................................ 56

Lubricating the cables ...................................... 56

Accessories ...................................................... 56

Lubricating in accordance with the lubrication

schedule ........................................................... 57

1. Pedal mechanism in frame tunnel ................ 57

2. Chains in the frame tunnel ........................... 57

3. Engine oil ..................................................... 58

4. Gear lever .................................................... 60

5. Transmission and hydraulic system ............. 60

6. Cutting unit ................................................... 60

7. Three-point Link ........................................... 60

8. Driver’s seat ................................................. 61

9. Throttle and choke cables, lever bearings ... 61

10. Hydraulic oil filter, change .......................... 62

11. Oil filter, change ......................................... 62

12. Parking Brake Cable .................................. 63

13. Transmission oil level ................................. 63

Trouble Shooting Guide ..................................... 65

Storage ................................................................. 67

Winter Storage ................................................. 67

Service ............................................................. 68

Electrical system ................................................. 69

Hydraulic system ................................................ 71

Technical data ..................................................... 73

EU Declaration of Conformity ............................ 75

EU Declaration of Conformity

(only applies to Europe) ................................... 75

Service journal .................................................... 77

English-

1

IMPORTANT INFORMATION

Read carefully through the operator’s manual
so that you know how to use and maintain
the Rider before you use it.

For service measures other than those
described in this manual, please contact an
authorised dealer that provides parts and
service.

English-

2

INTRODUCTION

Introduction

Congratulations

Thank you for purchasing a Husqvarna Rider. Husqvarna Riders have been designed according to a
unique concept with a front mounted cutting unit and patented rear wheel steering. The Rider is built to give
maximum efficiency even in small and confined areas. Collected controls and a hydrostatic transmission
controlled by pedals also contribute to the machine’s performance.

This operator’s manual is a valuable document. Following the instructions (use, service, maintenance, etc.)
can considerably increase the life span of your machine and even increase its resale value.

When you sell your Rider, make sure to give the operator’s manual to the new owner.

The final chapter of this operator’s manual comprises a Service Journal. Ensure that service and repair
work is documented. A well-kept service journal reduces service costs for the season-based maintenance
and affects the machine’s resale value. Take the operator’s manual along when the Rider is left to the
workshop for service.

Driving and Transport on Public Roads

Check applicable road traffic regulations before driving and transport on public roads. You should always
use approved fasteners during transport and ensure that the machine is well secured.

Towing

Rider ProFlex 18 is equipped with a hydrostatic transmission and, if necessary, you should only tow the
machine over short distances and at a low speed, otherwise there is a risk of damaging the transmission.

The power transmission must be disengaged when towing, see “Clutch control” on page 21.

Use

This machine has been designed to mow grass on lawns and other open and level ground surfaces without
obstacles such as stones, tree stubs, etc., even when the machine is equipped with special accessories
provided by the manufacturer, for which the operating instructions are enclosed with the delivery. All other
types of use are incorrect. The manufacturer’s instructions with regard to driving, maintenance, and repair
must be followed precisely.

The machine may only be operated, maintained, and repaired by persons that are fully conversant with the
machine’s special characteristics and safety regulations.

Accident prevention regulations, other general safety regulations, occupational safety rules, and traffic
regulations must be observed.

Unauthorised modifications to the design of the machine may absolve the manufacturer from liability for
any resulting personal injury or property damage.

English-

3

INTRODUCTION

Proper Service

Husqvarna’s products are sold all over the world and only by specialised retail traders offering complete
service. This ensures that you as a customer receive only the best support and service. Before the product
is delivered, the machine has, for example, been inspected and adjusted by your retailer, see the certificate
in the Service Journal in this operator’s manual.

When you need spare parts or support concerning service, warranty issues, etc., please consult the
following professional:

This operator’s manual belongs to the
machine bearing serial number:

Engine Transmission

Serial Number

The serial number can be found on the printed plate attached to the front, left-hand side under the seat.
Stated on the plate, from the top, are:

• The machine’s type designation.

• The manufacturer’s type number.

• The machine’s serial number.

Please state the type designation and serial number when ordering spare parts.

The engine’s serial number is found on a barcode sticker. This is placed on the left side of the crankcase,
in front of the starter. The sticker states:

• The engine’s serial number (E/NO).

• Code.

Please state these when ordering spare parts.

The transmission’s serial number is found on the barcode sticker located on the front of the housing on
the left-hand drive shaft:

• The type designation is stated above the barcode and starts with the letter K.

• The serial number is stated above the barcode and has the prefix s/n.

• The manufacturer’s type number is stated under the barcode and has the prefix p/n.

Please state the type designation and serial number when ordering spare parts.

English-

4

o
T

EXPLANATION OF SYMBOLS

Symbols and decals

These symbols can be found on the Rider and in the operator’s manual.
Study them carefully so that you know what they mean.

FastNeutral

Oil level Cutting Height Reversing Forward

Use hearing
protection

Noise emission to surroundings
in accordance with the directive

f the European Community.

he machine’s emission is
indicated in the TECHNICAL
DATA chapter and on the decal.

Hydrostatic free
wheeling

Slow

Warning! Rotating
blades

Engine off

Parking
brake

Warning! Risk of the
Rider overturning

Choke

Read the
operator’s manual.

Never drive directly
across a slope

Fuel

Tyre pressure

Ignition

Warning

CE conformity
marking

Never use the Rider if persons,
especially children or pets, are
in the immediate vicinity.

Starting instructions
Read the operator’s manual
Check the engine oil level
Check the oil level in the hydrostat
Lift up the cutting unit
Put the hydrostat pedals in the neutral
position
Apply the parking brake
Use the choke if the engine is cold
Start the engine
Disengage the parking brake before
driving

Never carry passengers on
the Rider or on its tools.

Do not insert your
hands or feet under
the cover when the
engine is running.

Accelerator pedal forward

Neutral position

Accelerator pedal reversing

Switch off the engine and
remove the ignition cable
before carrying out repairs or
maintenance

Drive very slowly
without the cutting
unit.

English-

5

EXPLANATION OF SYMBOLS

WARNING!
XXXXXXX XXXX XXXXXXXX XXX X.
XXXXX XXXXXX XX.
XX XXXXXXXX XXXXX XXX XX.

Used in this publication to notify the reader of a risk of personal injury , particularly if the reader should
neglect to follow instructions given in the manual.

IMPORTANT INFORMATION

Xxxxxxx xxxx xxxxxxxx xxx xxx
xxxx xxxxxx xx.

Used in this publication to notify the reader of a risk of material damage , particularly if the reader should
neglect to follow instructions given in the manual. Used also when there is a potential for misuse or
misassembly.

Avoid hosing the decals with high pressure washers. Replace damaged decals before the machine is used.

English-

6

SAFETY INSTRUCTIONS

Safety instructions

These instructions are for your safety. Read them
carefully.

WARNING!

The inserted symbol means that
important safety instructions needed
to be observed. It applies to your
safety.

General use

• Read all instructions in this operator’s manual and
on the machine before starting it. Ensure you
understand them and then observe them.

• Learn how to use the machine and its controls
safely and learn how to stop quickly. Also learn
to recognize the safety decals.

• Only allow the machine to be used by adults who
are familiar with its use.

• Make sure nobody else is in the vicinity of the
machine when you start the engine, engage the
drive, or run the machine.

• Clear the area of objects such as stones, toys, steel
wire, etc. that may become caught in the blades and
be thrown out.

• Beware of the ejector and do not point it at any one.

• Stop the engine and prevent it from starting before
you clean the cutting unit.

• Remember that the driver is responsible for dangers
or accidents.

• Never take passengers. The machine is only
intended to be used by one person.

• Always look down and behind before and during
reversing manoeuvres. Keep watch for both large
and small obstacles.

• Slow down before turning.

• Shut down the blades when not mowing.

• Be careful when rounding fixed objects, so that the
blades do not hit them. Never run the machine over
foreign objects.

WARNING!

This machine can sever hands and
feet as well as throw objects.
Failure to observe the safety
instructions can result in serious
injuries.

8010-047

Read the operator’s manual before starting the
machine

6003-002

Clear the area of objects before mowing

8010-052

Never take passengers

English-

7

SAFETY INSTRUCTIONS

WARNING!

Engine exhaust, some of its
constituents and certain vehicle
components contain or emit chemicals
considered to cause cancer, birth
defects or other reproductive
impairment. The engine emits carbon
monoxide, which is a colourless,
poisonous gas. Do not use the machine
in enclosed spaces.

• Only use the machine in daylight or in other well-lit
conditions. Keep the machine at a safe distance
from holes or other irregularities in the ground. Pay
attention to other possible risks.

• Never use the machine if you are tired, if you have
consumed alcohol, or if you are taking other drugs
or medication that can affect your vision, judgment,
or co-ordination.

• Beware of traffic when working near or crossing
a road.

• Never leave the machine unsupervised with the
engine running. Always stop the blades, apply the
parking brake, stop the engine and remove the keys
before leaving the machine.

• Never allow children or other persons not trained in
the use of the machine to use or service it. Local
laws may regulate the age of the user.

WARNING!

You must use approved personal pro­tective equipment whenever you use
the machine. Personal protective
equipment cannot eliminate the risk of
injury but it will reduce the degree of
injury if an accident does happen. Ask
your dealer for help in choosing the
right equipment.

6003-006

Keep children away from the work area

• Use hearing protection to minimise the risk of
hearing impairment.

• Always wear approved protective glasses or a full
visor when assembling or driving.

• Never wear loose clothing that can fasten in moving
parts.

• Never use the machine when barefoot. Always wear
protective shoes or protective boots, preferably with
steel toe caps.

• Make sure that you have first aid equipment close at
hand when using the machine.

English-

8

8011-292

Personal protective equipment

SAFETY INSTRUCTIONS

Driving on slopes

Driving on slopes is one of the operations where the
risk of the driver losing control of the machine or of it
overturning is the greatest; this can result in serious
injury or death. All slopes demand extra care. If you
cannot reverse up a slope or if you feel unsure, do not
mow it.

IMPORTANT INFORMATION

Do not drive down slopes with the unit raised.

Do as follows

• Remove obstacles such as stones, tree branches,

etc.

• Mow up and down, not side-to-side.

• Never drive the machine on terrain that slopes more

than 15°.

• Avoid starting or stopping on a slope. If the tyres

start to slip, stop the blades and drive slowly down
the slope.

• Always drive evenly and slowly on slopes.

• Make no sudden changes in speed or direction.

• Avoid unnecessary turns on slopes, and if it proves

necessary, turn slowly and gradually downward,
if possible.

• Watch out for and avoid driving over furrows, holes,

and bumps. It is easier for the machine to overturn
on uneven ground. Tall grass can hide obstacles.

• Drive slowly. Do not turn the wheel sharply.

• Be extra cautious with any additional equipment,

which can alter the machine’s stability.

• Do not mow near verges, ditches, or banks. The

machine can suddenly overturn if one wheel comes
over the edge of a steep slope or a ditch, or if an
edge gives way.

• Do not mow wet grass. It is slippery, and tyres can

lose their grip so that the machine skids.

• Try not to stabilise the machine by putting a foot

on the ground.

• When cleaning under the machine, it may never be

driven near verges or ditches.

• Follow the manufacturer’s recommendations

regarding wheel weights or counterbalance weights
to increase machine stability.

6003-004

Mow upwards and downwards on slopes, not sideways

8010-054

Be extra cautious when driving on slopes

IMPORTANT INFORMATION

Wheel weights fitted on the rear wheels are
recommended when driving on slopes for safer
steering and improved manoeuvrability.
Consult your dealer concerning the use of
wheel weights if you are unsure.

English-

9

SAFETY INSTRUCTIONS

Children

• Serious accidents may occur if you fail to be
observant for children in the vicinity of the machine.
Children are often attracted to the machine and
mowing. Never assume that children will stay where
you last saw them.

• Keep children away from the mowing area and
under close supervision by another adult.

• Keep an eye out and shut off the machine if children
enter the work area.

• Before and during a reversing manoeuvre, look
backward and downward for small children.

• Never allow a child to ride with you. They can fall off
and seriously injure themselves or be in the way for
safe manoeuvring of the machine.

• Never allow children to operate the machine.

• Be particularly careful near corners, bushes, trees
or other objects that block your view.

Never allow children to operate the machine

8010-057

Maintenance

• Stop the engine. Prevent the engine from starting
by removing the spark plug cables from the spark
plugs or by removing the ignition key before making
any adjustments or performing maintenance.

• Never fill the fuel tank indoors.

• Petrol and petrol fumes are poisonous and
extremely flammable. Be especially careful when
handling petrol, as carelessness can result in
personal injury or fire.

• Only store fuel in containers approved for the
purpose.

• Never remove the fuel cap or fill the fuel tank while
the engine is running.

• Allow the engine to cool before refuelling. Do not
smoke. Do not fill petrol in the vicinity of sparks or
naked flames.

• Handle oil, oil filters, fuel and battery carefully, of
environmental considerations. Observe applicable
recyling regulations.

• Electrical shocks can cause injuries. Do not touch
cables when the engine is running. Do not test the
ignition system with your fingers.

8010-058

Never fill the fuel tank indoors

English-

10

SAFETY INSTRUCTIONS

WARNING!

The engine and components of the
exhaust and hydraulic systems become
extremely hot during operation. Risk of
burn injuries if touched.

• If leaks arise in the fuel system, the engine must not

be started until the problem has been resolved.

• Store the machine and fuel in such a way that there

is no risk of leaking fuel or fuel vapour leading to
damages.

• Check the fuel level before each use and leave

space for the fuel to expand, because the heat from
the engine and the sun may otherwise cause the
fuel to expand and overflow.

• Avoid overfilling. If you spill petrol on the machine,

wipe up the spill and wait until it has evaporated
before starting the engine. If you spill petrol on your
clothing, change your clothing.

• Allow the machine to cool before taking any actions

in the engine room.

WARNING!

The battery contains lead and lead
compounds, chemicals that are
considered to cause cancer, birth
defects, and other reproductive
impairment. Wash you hands after
touching the battery.

• Be especially careful when handling battery acid.

Acid on the skin can cause serious corrosive
injuries. In the event of spillage on the skin wash
immediately with water.

• Acid in the eyes can cause blindness, contact

a doctor immediately.

• Be careful when servicing the battery. Explosive

gases form in the battery. Never perform
maintenance on the battery while smoking or in the
vicinity of open flames or sparks. This can cause
the battery to explode and cause serious injuries.

• Make sure all nuts and screws are tightened

correctly and that the equipment is in good
condition.

• Do not modify safety equipment. Check regularly to

be sure it works properly. The machine must not be
driven if protective plates, protective covers, safety
switches or other protective devices are not fitted or
are defective.

• Do not change the settings of governors and avoid

running the engine with overly high engine speeds.
If you run too fast, you risk damaging the machine
components.

6003-009

Do not smoke when carrying out maintenance

English-

11

SAFETY INSTRUCTIONS

• Never use the machine indoors or in spaces lacking
proper ventilation. Exhaust fumes contain carbon
monoxide, an odourless, poisonous and highly
dangerous gas.

• Stop and inspect the equipment if you run over or
into anything. If necessary, make repairs before
starting.

• Never make adjustments with the engine running.

• The machine is tested and approved only with the
equipment originally provided or recommended by
the manufacturer.

• The blades are sharp and can cause cuts and
gashes. Wrap the blades or wear protective gloves
when handling them.

• Check the parking brake’s functionality regularly.
Adjust and maintain as required.

• The mulching unit should only be used where better
quality mowing is required and in known areas.

• Reduce the risk of fire by removing grass, leaves
and other debris that may have fastened in the
machine. Allow the machine to cool before putting
it in storage.

Never drive the machine in an enclosed space

8009-467

Transport

IMPORTANT INFORMATION

The parking brake is not sufficient to lock the
machine during transport. Ensure you secure
the machine firmly to the transporting vehicle.

• The machine is heavy and can cause serious crush
injuries. Be especially careful when it is loaded in or
out of a car or on and off of a trailer.

• Use an approved trailer to transport the machine.
Activate the parking brake and secure the machine
using approved fasteners, such as straps, chains or
ropes when transporting.

• Check and abide by local traffic regulations before
transporting or driving the machine on any road.

8010-061

Regularly clean grass, leaves and other debris from the
machine

English-

12

PRESENTATION

Presentation

Congratulations on your choice of an exceptionally
high quality product. This operator’s manual describes
Rider ProFlex 18.

Rider ProFlex 18 is fitted with a Kawasaki four-stroke
V-Twin engine developing 18 horse power.

8009-551

Rider ProFlex 18 is equipped with servo steering and
hydraulic lifts, powered by the gearbox and differential
lock.

The power transmission from the engine is handled by
a hydrostatic gearbox, which allows variable speed
control by using the pedals. One pedal to drive
forwards and one pedal to reverse.

Rider ProFlex 18 is equipped with lighting.

English-

13

Placement of Controls

PRESENTATION

1. Power outlet

2. Ignition key

3. Switch for the power outlet

4. Choke Lever

5. Switch for the lights

6. Throttle - regulates the engine speed

7. Chronometer

8. Lever for hydraulic lift of attachments

9. Cutting Height Adjustment Lever

10. Mechanical lifting lever with locking button

for attachments

8009-676

11. Accelerator for reversing

12. Accelerator for driving forwards

13. Pedal for parking brake

14. Lock button for parking brake

15. Lever for setting of seat

16. Fuel cap

17. Hood lock

18. Clutch control

English-

14

PRESENTATION

Throttle Control

The throttle is used to control the speed of the engine
and thereby also the rotation speed of the blades.

In order to increase or decrease the engine speed, the
control is moved forwards or backwards respectively.

Avoid idling the engine for long periods, as there is
a risk of carbon build-up on the spark plugs.

Choke Lever

The choke lever is used for cold starts in order to
provide the engine with a richer fuel mixture.

8009-533

For cold starts, the lever shall be moved backwards
to its endpoint.

Accelerator

The speed of the machine is variably controlled using
two pedals. Pedal (1) is used to travel forwards and
pedal (2) to reverse.

WARNING!

Make sure that no branches can
interfere with the pedals when mowing
under bushes.

8009-534

1

2

6004-206

English-

15

PRESENTATION

Cutting unit

Rider ProFlex can be equipped with a cutting unit of
the types Combi 112 with a 112 cm cutting width and
Combi 122 with a 122 cm cutting width.

The Combi unit functions as a BioClip unit when a
BioClip plug is fitted, but can be set to rear ejection
by removing the BioClip plug.

The unit’s BioClip function finely chops the grass
several times before returning it to the lawn as fertiliser.
The rear ejector ejects the clippings behind the unit
without finely chopping them.

Accessories

The accessories are described in separate operator’s
manuals. Contact your dealer if you require an
accessory.

A selection of the available Rider ProFlex accessories:

• Brush

• Snow blower

• Snow Blade

• Wheel Weights

• Snow Chains

• Dutch Hoe

• Edge Trimmer

• Gravel Harrow

• Trailer

• Spreader

Lights and power outlet

The lights are switched on and off using power switch
(1) on the control panel.

A seat heater or mobile phone charger are examples of
articles that can be connected to the power socket (2).
The power outlet is switched on and off using power
switch (3) on the control panel.

The electrical outlet socket is fuse protected by its own
fuse, which is located below the ignition switch.

1

2

English-

3

8009-546

16

PRESENTATION

Cutting height adjustment lever

Using the cutting height lever, the cutting height can
be adjusted between 7 different positions.

It is important that the air pressure in both front wheels
is equal, 60 kPa / 0.6 bar / 9 PSI, to produce an even
cutting height.

Lever for hydraulic lift of attachments

The lifting lever is used to put the cutting unit in either
the transport or mowing position when hydraulic
pressure is available.

8009-557

In the transport position, the blade brake is
automatically activated so that the blades stop within
about 5 seconds.

Lifting the cutting unit (transport position)

Pull the lever backwards to engage the transport
position.

The unit is raised and the blades stop rotating.

Secure the cutting unit if necessary using the
mechanical lifting lever.

Lowering the unit (mowing position)

If the cutting unit is secured in the transport position
using the mechanical lifting lever, move the mechanical
lifting lever to the cutting position.

Move the hydraulic lifting lever forwards to engage the
cutting position. The unit is lowered and the blades
begin to rotate.

In order to ensure that the hydraulic cylinder is in the
outer position, hold the lever in the forward position
for a half to one second.

8009-536

Raising the cutting unit with the hydraulic lifting lever

Lowering the unit with the hydraulic lifting lever

8009-538

English-

17

PRESENTATION

r

Mechanical lifting lever for cutting unit

The lever is used as a backup lever to put the cutting
unit in either the transport or mowing position when
hydraulic pressure is unavailable. It can also be used
to mechanically secure the cutting unit in the transport
position.

The lever must be used when starting the engine, if the
engine stopped with the unit in the mowing position,
in order to raise the unit so that the start lock circuit is
disengaged.

In the transport position, the blade brake is
automatically activated so that the blades stop
within about 5 seconds.

Transport position

Pull the lever backwards to the locked position
to engage the transport position.

The unit is raised and the blades stop rotating.

Mowing position

Depress the lock button and move the lever forwards
to engage the mowing position.

The unit is lowered and the blades begin to rotate.

8009-554

Raising the cutting unit with the mechanical lifting leve

English-

8009-555

Lowering the unit with the mechanical lifting lever

18

PRESENTATION

Parking brake

The parking brake is activated as follows:

1. Press down the parking brake pedal.

2. Completely depress the lock button on the

steering servo housing.

3. Release the parking brake pedal while keeping the

button pressed in.

The parking brake lock is automatically disengaged
when the parking brake pedal is pressed down.

Seat

The seat has a hinged mounting on the front edge and
can be tipped forwards.

The seat can also be adjusted lengthways.

8009-328

When making adjustments, the lever under the front
edge of the seat is moved to the left, after which the
seat can be moved backwards or forwards to the
desired position.

The seat springs can be adjusted by moving the rubber
blocks in their brackets on the underside of the seat.
Set both blocks in the front, centre or rear positions.

Fuelling

8009-602

8009-491

The engine should be run on a minimum of 87-octane
unleaded petrol (no oil mix). It can be beneficial to use
environmentally adapted alkylate petrol. See also
“Technical Data” concerning methanol and ethanol
fuels.

WARNING!

Petrol is highly flammable. Observe
caution and fill the tank outdoors,
(see the safety instructions).

8009-330

English-

19

PRESENTATION

Clutch control

The clutch control is used to move the Rider when
the engine is not running.

• Control drawn out, drive system disengaged.

• Control depressed, drive system engaged.

Chronometer

The chronometer shows how many hours the engine
has been running. Any time when the engine is not
running but the ignition is switched on is not registered.
The last digit shows tenths of an hour (6 minutes).

8009-142

8009-567

English-20

DRIVING

Mowing tips

WARNING!

Clear the lawn of stones and other
objects that can be thrown out by the
blades.

• Localise and mark rocks and other fixed objects in

order to avoid collisions.

• Begin with a high cutting height and reduce it until

the desired mowing result is attained.

• The best mowing result will be obtained at a high

engine speed (the blades rotate rapidly) and low
speed (the Rider moves slowly). If the grass is
not too long and thick the driving speed can be
increased without significantly impairing the
mowing result.

6007-212

Mowing patterns

WARNING!

Never drive the Rider on terrain that
slopes more than 15°. Mow upwards and
downwards on slopes, never sideways.
Avoid sudden changes in direction.

• The finest lawns are obtained by mowing often.

Mowing will be more even and the clippings will be
more evenly distributed across the area. The overall
mowing time will not be longer as higher driving
speeds can be selected without impairing the
mowing result.

• Avoid mowing wet lawns. The mowing result will be

poorer as the wheels will sink into the soft lawn.

• Hose beneath the cutting unit with water after each

use. When cleaning, the cutting unit should be
moved into the service position.

• It is important to mow frequently when mowing

with the mulching function.

Clutch control

The clutch control must be pulled out in order for the
Rider to be moved when the engine is shut off.

MAX 15

6016-104

8009-337

English-21

DRIVING

Driving

IMPORTANT INFORMATION

The air intake grille in the engine cover behind
the driver's seat must not be blocked by, for
example, clothing, leaves, grass or dirt. Impaired
cooling of the engine. Risk of major engine
damage.

Before Starting

• Read section “Safety instructions” on page 7 and
“Presentation” on page 13.

• Carry out daily maintenance according to
“Maintenance schedule” on page 27).

• Adjust the seat to the desired position.

8009-489

Starting the engine

1. Raise the cutting unit by pulling the mechanical

lifting lever backwards to the locked position
(transport position).

2. Apply the parking brake by holding down the pedal

and at the same time press in the release button.

8009-554

8009-328

English-22

DRIVING

3. Move the throttle to the middle position.

4. If the engine is cold, the choke control shall be

moved backwards to its end position.

8009-562

5. Turn the ignition key to the start position.

6. When the engine starts, immediately release the

ignition key so that it returns to the neutral
position.

IMPORTANT INFORMATION

Do not run the starter motor for more than
5 seconds at a time. If the engine does not start
wait about 15 seconds before trying again.

8009-534

8009-558

8009-559

English-23

DRIVING

7. Move the choke lever gradually forward once the

engine has started.

8. Set the desired engine speed with the throttle.

Allow the engine to run at a moderate speed,
“half throttle”, for 3-5 minutes before loading it too
heavily.

WARNING!

Never run the engine indoors, in
enclosed or badly ventilated areas.
Engine exhaust fumes contain
poisonous carbon monoxide.

8009-560

Driving the Rider

1. Release the parking brake by first pressing down

the parking brake pedal and then lifting off the
parking brake pedal.

2. Carefully press down one of the pedals until the

required speed is attained.

Pedal (1) is pressed down to travel forwards and
pedal (2) to reverse.

WARNING!

Never run the engine indoors, in
enclosed or badly ventilated areas.
Engine exhaust fumes contain
poisonous carbon monoxide.

8009-533

6007-208

1

2

English-24

6007-209

DRIVING

3. Select the required cutting height (1-7) using the

cutting height lever.

4. Depress the lock button on the mechanical lifting

lever and move the lever to its most forward
position. The cutting unit lowers and starts.

8009-539

5. If the cutting unit does not lower completely, or if

the blades do not rotate, lower the cutting unit
completely using the hydraulic lifting lever.

In order to ensure that the hydraulic cylinder is in
the outer position, hold the lever in the forward
position for a half to one second.

Braking

Release the drive pedals. The machine slows and is
stopped by the drive system. Do not use the parking
brake as the drive brake.

8009-537

8009-538

English-25

DRIVING

Stopping the engine

If the engine has been worked hard, it is preferable to
let the engine idle for a minute so it runs at its normal
working temperature when stopped. Avoid idling the
engine for long periods, as there is a risk of carbon
build-up on the spark plugs.

1. Lift the cutting unit with the hydraulic lifting lever.

The unit can then be secured in the raised position
if necessary by moving the mechanical lifting lever
backwards to the lock position.

If the cutting unit is left in the lower position,
the start lock circuit will prevent you starting
the engine.

8009-536

2. Move the throttle control to the “MIN” position. Turn

the ignition key to “STOP”.

3. When the Rider is at a standstill apply the parking

brake by holding down the pedal and at the same
time press in the release button.

8009-535

8009-544

English-26

8009-328

MAINTENANCE

Maintenance

Maintenance schedule

The following is a list of maintenance procedures that
must be performed on the Rider. For points marked with
footnote number 4, turn to an authorised service

representative.

● = Described in this manual.
❍ = Not described in this manual.

Maintenance Page Daily main-

Check for fuel and oil leaks - ❍

Check the parking brake 35 ●

Check the engine’s oil level
(every refuelling)

Check the fuel pump’s air filter 38 ●

Check the safety switch, seat 41 ●

Check the safety switch, lifting lever 41 ●

Check the safety switch, pedal system 41 ●

Check the muffler 33 ●

Check/clean the engine’s cooling
air intake

Check the cutting unit: 46 ●

• securing of the blades 48 ●

• condition of the blades
(sharpness, shape, etc.)

tenance

before after 25 50 100 300

58 ●●

31 ●●

48 ●

Weekly

3

main-

tenance

At
least
once
a year

Maintenance interval
in hours

Check the steering cables
(any play, etc.)

Check fastenings (screws, nuts, etc.) - ❍

Start the engine and blades, listen
for unusual sounds

Clean under the cutting unit 47 ●

Clean the transmission’s cooling air
intake

Check the battery’s acid level 39 ●

Check the transmission oil level 63 ●

Check the condition of belts, belt
pulleys, etc.

Check for damage - ❍

32 ●

22 ●

32 ●●

- ❍

English-27

● = Described in this manual.

25 50 100 300

❍ = Not described in this manual.

MAINTENANCE

Maintenance Page Daily main-

tenance

before after

Check the air pressure in the tyres

39 ●

Weekly

3

main-

tenance

(60 kPa)

Check to ensure that the cable

34 ●

seats in the middle are undamaged

Clean thoroughly around the engine 31 ●

Clean thoroughly around the

- ❍

transmission

Clean around all belts, belt pulleys,

56 ●

etc.

Clean carefully around the muffler 31 ●

Lubricate the driver seat 61 ●

Lubricate all cables 56 ●

Lubricate the safety catch in the

60 ●

cutting unit

Lubricate the interior plug in the

60 ●

cutting unit

At
least
once
a year

Maintenance interval
in hours

Lubricate the groove for the cutting

60 ●

unit’s equipment frame

Lubricate links in the cutting unit 60 ●

Clean the frame tunnel - ❍

Lubricate the pedal mechanism in

57 ●

the frame tunnel

Lubricate the gear lever 60 ●

Lubricate the parking brake cable 63 ●

Lubricate the throttle 61 ●

Lubricate the choke control 61 ●

Lubricate the guide chain in the

57 ●

frame tunnel

Check the steering cables in the

32 ●

frame tunnel

Clean the engine’s cooling air intake 31 ●●

Clean the air filter's pre-cleaner

36 ●●

(foamed plastic)

Change the engine oil

Clean the air cleaner’s filter
cartridge

English-28

2)

(paper filter)

1)

58 ●●

36 ●●

● = Described in this manual.
❍ = Not described in this manual.

MAINTENANCE

Maintenance Page Daily main-

tenance

before after 25 50 100 300

Weekly

3

main-

tenance

At
least
once
a year

Maintenance interval
in hours

Check/adjust the cutting height 46 ●●

Check/adjust the parking brake 35 ●●

Inspect the flame arrester/spark

- ❍❍

extinguisher (extra equipment)

Replace the hydraulic oil filter

62 ●●

(every 200 hours)

Replace the engine oil filter

62 ●●

(every 200 hours)

Clean/replace the spark plugs 40 ●●

Change the inline fuel filter 38 ●●

Clean the pulse air filter 38 ●●

Clean the cooling fins - ❍❍

Check the play on the engine

4)

valves

- ❍❍

Check to see if the oil needs chang-

4)

ing

or the filter needs changing 4)

- ❍❍

in the gear box (every 500 hours)

Replace the air filter's pre-cleaner
(foamed plastic)

2)

Replace the air filter (paper filter)

36 ●●

2)

36 ●●

(every 200 hours)

Perform the 300-hour service

4

)

- ❍❍

1) First change after 8 hours. When operating with a heavy load or at high ambient temperatures, replace
every 50 hours.

2) Maintenance and replacement are required more often in dusty conditions.

3) The Rider should be lubricated twice weekly with daily use.

4) Performed by an authorised service workshop.

WARNING!

No service operations may be performed
on the engine or cutting unit unless:

• The engine is stopped.

• The parking brake is actuated.

• The ignition key has been removed.

• The cutting unit is disengaged.

• The ignition cables have been

removed from the spark plugs.

English-29

MAINTENANCE

Removing the Rider’s covers

Engine cover

1. Push the seat to its most forward position and then

tip it back.

2. Turn the cover lock on the top of the engine cover

anti-clockwise a 1/4 turn.

3. Fold up the engine cover.

If necessary the engine cover can be lifted off by
removing the hinge pins.

8009-509

Front cover

Loosen the quick-action catch and lift off the front
cover.

The Right-hand wing cover

Remove the accelerator knob (1), screws (2 and 3),
and remove the wing cover.

8009-510

6016-106

English-30

8009-499

MAINTENANCE

Left-hand wing cover

Loosen the screws (2) and remove the wing cover.

Transmission cover

Loosen both screws (one on each side) and lift off the
transmission cover.

8009-501

Checking the engine’s cooling air intake

Clean the air intake grille in the engine cover behind
the driver's seat.

Open the engine cover.

Check that the cooling intake is free from leaves, grass
and dirt.

Check the air duct, located on the inside of the engine
cover, ensure it is clean and does not rub against the
cooling air intake.

A clogged air intake grille, air duct or cooling air intake
impairs the cooling of the engine, which may result in
engine damage.

6008-209

8009-489

Air intake grille

Cooling air intake

8009-152

English-31

MAINTENANCE

Checking the transmission air intake

Check to ensure that the air intake valve to the
transmission is not clogged.

Checking and adjusting the steering
cables

The steering is governed by means of cables.

After a period of use these can become stretched,
which means the steering setting may have changed.

Steering is checked and adjusted as follows:

6008-208

1. Remove the frame plate by loosening the two

screws.

2. Ensure that the cables are properly situated under

the steering cable pulleys in the frame tunnel.
Check the tension of the steering cables by
squeezing the cables together (at the arrows). It
should be possible to squeeze the cables so that
the distance between them is half the size, without
using too much force.

Change the cable if it has a damaged strand
causing loose threads to protrude.

3. If necessary, the cables can be stretched by first

loosening the lock nut and then tightening the
adjustment nut (one cable on each side of the
machine).

Hold the cable with, for example, an adjustable
wrench so that it does not twist. If the adjustment
is only made on one side, the middle position of
the steering will be affected.

Do not over tighten the cables; they should only be
drawn in towards the steering collar.

Check the cable tension after you have made the
adjustment as described in point 2.

8009-340

6008-212

8009-341

English-32

MAINTENANCE

Checking and adjusting the throttle cable

Check that the engine responds to throttle increases
and that a good engine speed is attained at full throttle.

If doubts arise, contact your service representative.

If adjustments are necessary, they can be made as
follows for the lower cable:

1. Loosen the clamping screw for the cable’s outer

casing and move the throttle to the full throttle
position.

2. Check that the throttle cable is mounted in the

correct hole in the lower lever, see illustration.

3. Push the throttle cable’s outer casing as far to the

left as possible and tighten the clamping screw.

Checking and adjusting the choke cable

If the engine produces black smoke or is difficult to
start, this can be because the choke cable is
incorrectly adjusted (upper cable).

8009-144

If doubts arise, contact your service representative.

If adjustments are necessary, they can be made as
follows:

1. Loosen the clamping screw for the cable’s outer

casing and move the choke lever to the full choke
position.

2. Check that the choke cable is mounted in the

upper lever, see illustration.

3. Pull the choke cable’s outer casing as far to the

right as possible and tighten the clamping screw.

Inspecting the muffler

Check regularly that the muffler is complete and
secured correctly.

Temperature variations and vibrations can mean that
the tightening torque for the screws drops. The screws
should be checked when servicing to guarantee the
correct torque. The tightening torque should be about
10 Nm. Never use a defective muffler.

8009-145

10mm

~ 10Nm

WARNING!

The muffler gets very hot in use and
remains so for a short time afterwards.
Contact can result in burns. Remember
the risk of fire.

8009-685

English-33

MAINTENANCE

Adjusting the hydrostatic transmission
cable

The hydrostatic transmission cable (on the left side)
is adjusted in the following manner:

1. Remove the transmission cover. Loosen both

screws (one on each side) and lift off the
transmission cover.

2. Take apart the lower ball joint, which is locked with

a locking spring.

3. Ensure that the forward drive pedal is pressed

down completely.

4. Switch the vertical arm to the maximum position

and check that the ball and socket in the lower ball
joint are aligned.

5. Adjust the socket on the cable if needed.

6. Assemble the lower ball joint.

7. Put the ball joint’s locking spring in place.

6008-209

Cable holder

The cable seat in the middle protects the cables and
the hydraulic tubes so that they do not get pinched
during turns. It is situated close to the ground and can
be damaged by objects or careless driving, especially
when reversing.

Check to ensure that it is undamaged and that the belt
guide is properly centred on the rear side of the pulley.

6020-002

8009-364

English-34

MAINTENANCE

Adjusting the parking brake

The parking brake is adjusted in the following manner:

1. Remove the transmission cover. Loosen both

screws (one on each side) and lift off the
transmission cover.

2. Unhook spring (A) from the screw (B) on the right-

hand side

6008-209

3. Check that the parking brake is not on.

4. Adjust the play between the casing and the

adjustment screw to 1 mm when you pull the
casing.
Adjust with the nuts on the adjustment screw.

5. Tighten the nuts moderately to avoid damaging

the threads.

6. Replace the spring (A).

7. Check that the parking brake works.

WARNING!

A poorly adjusted parking brake can
result in reduced braking ability.

A

B

6020-005

English-35

MAINTENANCE

Replacing the air filter

If the engine seems to lack power or does not run
smoothly this may be because the air filter is clogged.
If run with a soiled air filter, carbon can build-up on the
spark plugs and lead to malfunction.

For this reason, it is important to replace the air filter
regularly (see “Maintenance schedule” on page 27
for the proper service interval).

WARNING!

Allow the exhaust system to cool before
performing service. Risk for burns.

Replacing the air filter

1. Open the engine cover.

2. Undo both of the snap catches and lift off the cover

on the air filter housing.

3. Remove the foam rubber pre-filter and clean using

a mild detergent.

Squeeze it dry with a clean cloth.

8009-148

8009-149

English-36

MAINTENANCE

4. Remove the wing nut in the air filter and remove

the paper filter.

5. Tap the paper filter against a fixed surface to

remove dust.

If the paper filter is still dirty, it must be replaced.

IMPORTANT INFORMATION

Do not use compressed air to clean the paper
filter.
Do not wash the paper filter.
Do not oil the paper filter.

8009-150

6. Refit the air filter as follows:

Fit the paper filter in the air filter housing and
tighten the wing nut.

7. Insert the prefilter on the rectangular part of the

paper filter.

8. Replace the cover over the air filter housing. Move

the cover up from below and ensure that the
prefilter does not fall out of position. Secure with
both snap catches

8009-151

English-37

MAINTENANCE

Replacing the fuel filter

Replace the fuel filter mounted on the supply line after
every 100 hours (once per season) or more frequently
if it is clogged.

Replace the filter as follows:

1. Open the engine cover.

2. Move the hose clamps away from the filter.

Use a pair of flat pliers.

3. Pull the filter loose from the hose ends.

4. Push the new filter into the hose ends. Position the

filter with the “FLOW” arrow pointing up towards
the fuel pump. If necessary, a soap solution can be
applied to the ends of the filter to simplify
assembly.

5. Move the hose clamps back toward the filter.

Cleaning the pulse air filter

8009-146

1. Open the engine cover.

2. Loosen the four snap catches, remove the cover,

and remove the filter.

3. Blow the filter clean with compressed air.

Replace the filter if it is damaged or cannot be
blown clean.

4. Place the filter back in the cover and fasten the

cover with the snap catches. Close the engine
cover.

Checking the fuel pump’s air filter

8009-342

Check regularly that the fuel pump’s air filter is not
clogged by dirt.

Remove the screws and open the pump, no hoses
need be removed.

The filter can be cleaned using a brush, if necessary.

Replace the pump on the console.

English-38

8009-147

MAINTENANCE

Checking the tyre pressures

The tyre pressure should be 60 kPa / 0.6 bar / 9 PSI on
all wheels.

In order to improve drive power, the pressure in the
rear tyres can be reduced to 40 kPa / 0.4 bar / 6 PSI.

Highest permitted pressure = 80 kPa / 0.8 bar / 12 PSI.

IMPORTANT INFORMATION

Different air pressure in the front tyres will
result in the blades mowing the grass at
different heights.

Checking the battery acid level

Check that the acid level in the battery lies between the
markings. When refilling, only distilled water may be
used to fill the cells.

6016-109

WARNING!

What to do in case of contact with
battery acid

• Externally: Rinse thoroughly with
water.

• Internally: Drink large quantities of
water or milk. Contact a doctor as
soon as possible.

• Eyes: Rinse thoroughly with water.
Contact a doctor as soon as possible.

The battery emits explosive gases.
Sparks, flames, and cigarettes must not
be present in the vicinity of the battery.

Ignition system

The engine is equipped with an electronic ignition
system. Only the spark plugs require maintenance.

Recommended spark plug, see “Technical data” on
page 73.

6008-216

IMPORTANT INFORMATION

The wrong spark plug type can damage the
engine.

English-39

MAINTENANCE

Replacing the spark plug

1. Remove the ignition cable shoe and clean around
the spark plug.

2. Remove the spark plug with a 3/4" (19 mm) spark
plug socket wrench.

3. Check the spark plug.

Replace the spark plug if the electrodes are burnt
or if the insulation is cracked or damaged.

Clean the spark plug with a wire brush if it is to be
reused.

4. Measure the electrode gap with a gapping tool.
The gap should be 0.7 - 0.8 mm / 0.030". Adjust as
necessary by bending the side electrode.

5. Reinsert the spark plug, turning by hand to avoid
damaging the threads.

IMPORTANT INFORMATION

Inadequately tightened spark plugs can cause
overheating and damage the engine. Tightening
the spark plug too much can damage the threads
in the cylinder head.

6. Tighten the spark plug, once it touches the
seating, with the spark plug spanner.

Tighten the spark plug so that the washer is
compressed.

A used spark plug should be turned 1/8 of a turn
from the seated position. A new spark plug should
be turned 1/4 a turn from the seated position.

7. Replace the ignition cable shoe.

8011-054

Electrode gap

Fuses

The main fuse is placed in a detachable holder under
the battery case’s cover, in front of the battery.
Type: Flat pin, 15 A.

The fuse for the power outlet is placed under the
ignition switch, behind the side plate on the control
panel.
Type: Flat pin, 7.5 A.

Do not use any other type of fuse when replacing.

A blown fuse is indicated by a burnt connector. Pull
the fuse from the holder when replacing.

The fuse is there to protect the electrical system. If it
blows again shortly after replacement, it is due to a
short circuit, which must be fixed before the machine
can be put into operation again.

8009-370

Main fuse

8009-610

Fuse power outlet

English-40

MAINTENANCE

Checking the safety system

The Rider is equipped with a safety system that
prevents starting or driving under the following
conditions.

It should only be possible to start the engine when the
cutting unit is in its raised position and the hydrostat
pedals are in the neutral position.

The driver does not need to be seated in the driver’s
seat.

Check daily to ensure that the safety system works
by attempting to start the engine when one of the
conditions is not met. Change the conditions and try
again.

Check that the engine stops if you temporarily move
out of the driver’s seat while the cutting unit is lowered
or the hydrostat pedals are not in the neutral position.

Starter

Ignition System

Works

Does not work

Main fuse

8009-370

8009-433
8009-436
8009-434
8009-435
8009-153

English-41

MAINTENANCE

Replacing the light bulbs

For information about the bulb type, see “Technical data”.

1. Unscrew the two screws holding the cover on the
power servo housing.

Lift up the cover and turn it around the steering
shaft.

2. Unscrew the two screws holding the lamp insert.

Lift out the lamp insert.

8009-511

3. Disconnect the cables from the bulbs.

4. Lift out the bulbs from the insert.

5. Insert the new bulbs. Make sure you use your
thumb to support the front.

8009-512

8009-513

6. Refit the cables, lamp insert and the cover on the
power servo housing.

English-42

8009-522

MAINTENANCE

The cutting unit components

In the instructions below, a cutting unit with a rear
ejector is shown, but the same principles apply to
all cutting units unless otherwise stated.

The components mentioned are:

• A Catch

• B Inner pin

• C Catch guard

• D Handle

• E Height adjustment strut

• F Parallelism strut

• G Lowest height adjustment stop

Attaching the cutting unit

WARNING!

Exercise caution.
Risk of crush injuries

D

E

C

B

A

G

F

8009-188

Starting point for attaching the cutting unit:

• Place the machine on a flat surface.

• Lock the brake by pressing down the pedal and
locking with the push-button.

• Equipment hydraulics in the lower position.

• Equipment frame in lowered position.

• Equipment frame locked with safety catch and locks
(A) in the inset position.

• Unit frame mounted on the cutting unit, see
“Removing the unit frame” on page 51.

A

A

8009-022

English-43

MAINTENANCE

1. Attach the unit to the equipment frame’s outer
hooks.

8009-024

2. Pull out the catch (A) and loosen the safety catch
by pushing its handle (D) back.

3. Raise the unit by pulling up the mechanical lifting
lever, located on the driver’s right side.

4. Push the unit in so that the interior plugs (B) touch
the bottom of the equipment frame’s grooves.

D

A

8009-167

5. Hook in the height adjustment strut’s (E) rear
fastener:

Move the cutting height lever to the forward
position. Loosen the strut by pulling the frame’s
forward section up or down.

WARNING!

Watch your fingers. Do not turn the
blades or the belt.

English-44

8009-018

E

8009-168

MAINTENANCE

6. Loosen the belt tensioner spring and attach the
belt to the front belt pulley. A new belt is short.
Turn the forward pulley as needed with a spanner
on the centre screw.

7. Refit the belt tensioner spring.

IMPORTANT INFORMATION

Check that the belt is around the idler.

8009-008

Belt Sketch

• 1. Drive belt

• 2. Forward pulley

• 3. Belt idler

• 4. Belt tensioner spring

8. Fit the front cover.

3

4

1

2

6016-105

English-45

MAINTENANCE

Adjusting the cutting height, parallelism
and ground pressure

When a new cutting unit is attached, you need to adjust
the cutting height, parallelism and ground pressure.

Adjustment must be made in the stated order.

Starting position:

• Check the air pressure in the tyres 60 kPa / 0.6 bar /
9 PSI.

• The cutting unit shall be lowered onto a flat surface.

• The height adjustment lever shall be set to the
lowest cutting height.

Cutting height

1. Loosen the nut on the height adjustment strut.

2. Measure the distance between the ground and the

front edges of the cover.

The distance between front edge and the ground
must be 35 mm.

3. Tighten the nut.

4. Check and align the parallelism if necessary.

5. Check and adjust the cutting unit’s ground

pressure if necessary according to “Ground
pressure” on page 47.

6. Fit the front cover.

IMPORTANT INFORMATION

When changing the cutting unit, you must
readjust the parallelism and cutting height.

Parallelism

1. Loosen the two nuts on the strut.

2. Measure the distance between the ground and the

front and back edges of the unit’s cover.

3. Place a spanner over the bevel in the middle of the

strut and tighten so that the cutting unit’s rear edge
is 2-4 mm higher than its front.

4. Check the measurement.

5. Then tighten the two nuts on the strut.

8009-028 8009-556

English-46

8009-027
8009-026

MAINTENANCE

Ground pressure

In order to achieve the best mowing result the cutting
unit should follow the ground without touching it too
heavily. Pressure is adjusted using a screw and spring
on each side of the Rider.

Adjust the cutting unit’s ground pressure in the
following manner:

1. Place a set of bathroom scales under the cutting

unit’s frame (on the front edge) so that the unit
rests on the scales. If necessary a block can be
placed between the frame and the scales so that
the anti-scalp rollers do not support any weight.

2. Adjust the cutting unit’s ground pressure by

screwing the adjuster screws, which are located
behind the front wheels on both sides, in or out.

The ground pressure should be between 12
and 15 kg and the springs evenly tensioned.

8009-369

The cutting unit’s service position

In order to provide good accessibility for cleaning,
repair and servicing, the unit can be set in the service
position. The service position means that the unit is
raised and locked in the vertical position.

Placing in the service position

1. Place the unit so that it hangs on the outer hooks

by carrying out steps 1-11 under “Removing the
cutting unit” on page 49.

2. Take hold of the unit’s front edge and lift it to

a vertical position. The unit locks automatically
in the vertical position.

Releasing the service position

1. Ease up the unit’s edge (tilt it back), move the

handle forward and slowly lower the unit to the
horizontal position.

2. Slide the unit into its working position by carrying

out steps 4-8 under “Attaching the cutting unit” on
page 43.

8009-611

8009-016

8009-015

English-47

MAINTENANCE

Cutting unit model

ProFlex can be equipped with two different types of
cutting unit:

• Combi 112

• Combi 122

Other cutting units cannot be mounted without
changing the drive belt.

8009-288

Combi 112

Checking the blades

It is important that the blades are undamaged and well­ground to give the best mowing result.

Check that the blades’ securing screws are tightened
with the torque:

• Combi 112: 45 - 50 Nm / 32 - 36 lbft

• Combi 122: 75 - 80 Nm / 53 - 56 lbft

IMPORTANT INFORMATION

Replacement or sharpening of the blades
should be carried out by an authorised service
representative.

The blades should be balanced after sharpening.

Damaged blades should be replaced when hitting
obstacles that result in a breakdown. Let the servicing
dealer judge whether the blade can be repaired/ground
or must be discarded.

8009-290

Combi 122

6012-088

English-48

WARNING!

If the blades are cracked, whether
caused by poor repair or other damage,
they could break while being used. The
risk increases if the blades are poorly
balanced.

MAINTENANCE

Removing the cutting unit

WARNING!

Exercise caution. Risk of crush injuries

1. Place the machine on a flat surface.

2. Lock the brake by pressing down the pedal and

locking with the push-button.

3. Lift the cutting unit with the mechanical lifting

lever.

4. Remove the front cover.

8009-328

5. Loosen the belt tensioner spring.

6. Remove the belt from the front pulley.

7. Refit the belt tensioner spring.

8. Hang the belt around the handle.

8009-375

8009-008

8009-009

English-49

MAINTENANCE

9. Unhook the height adjustment strut (E) by moving

the rear part upwards:

Unload the strut if necessary by pulling the frame’s
forward section up or down.

10. Pull the handle (D) and unit simultaneously.

Release the handle when the unit has come
out a bit.

8009-169

11. Pull out the unit so that it catches on the outer

hooks.

In this position, the unit can be set in the service
position, when required.

12. Lower the unit with the lifting lever on the driver’s

right side.

13. Pull the handle (D) so that the safety catch locks.

Check that the catch (A) is in the inset position.

8009-170

8009-024

14. Remove the unit from the machine.

English-50

8009-171

MAINTENANCE

Removing the unit frame

Starting position for removing the cutting unit frame:

• Cutting unit removed.

1. Twist the catch out so that the forward fastener

can be lifted from the cutting unit.

2. Move the unit frame backwards so that the tongue

of the cutting unit releases its grip on the bar of the
unit frame and lift the frame off.

Assemble the parts in the reverse order.

8009-184

Removing the belt

Starting position for removing the belt:

• No unit is attached to the machine.

• The belt’s forward part is hung around the handle of

the safety catch.

Removal of the forward part of the belt from the
forward pulley is described in steps 5-8 under
“Removing the cutting unit” on page 49.

The entire belt is removed according to the following
only when a snow blade is to be attached to the
machine.

1. Press the guide plate under the anti-scalp roller.

2. Unhook the spring to the blade brake.

3. Take the belt off of the centre pulley.

4. Dismantle the belt.

8009-185

8009-343

8009-005

English-51

MAINTENANCE

Attaching the belt

1. Place the forward part of the belt in place and

hang the forward part around the handle of the
safety catch.

2. Put the belt on the centre pulley and against the

cross member.

3. Press the guide plate down under the anti-scalp

roller and push the belt into place.

8009-613

4. Hook the spring to the blade brake.

Fitting the belt on the forward pulley is described in
steps 6-7 under “Attaching the cutting unit” on page 43.

8009-343

8009-005

English-52

MAINTENANCE

Changing the cutting unit’s belt

WARNING!

Protect your hands with gloves when
working with the blades.
There is a risk of crush injuries when
working with the belt.

Changing the belt on the Combi unit

On these cutting units with “collision-proof” blades,
the blades are driven by one V-belt. Do as follows
to replace the V-belt:

1. Dismantle the cutting unit, see page 49.

2. Loosen the unit frame (1) see page 51, the screw

on the parallelism strut (2) and the two screws on
the cover (3). Lift the protective cover from the
belts.

3

3

1

3. Loosen the spring (4) that tensions the V-belt and

pull the belt off.

4. Attach the new belt.

The belt tightening schedule is located on a decal
on the inside of the protective cover.

5. Check that the belt tensioning equipment is not

jammed or binding and replace the spring.

6. Replace the protective cover and attach the

parallelism strut and unit frame.

7. Attach the cutting unit to the machine, see

“Attaching the cutting unit” on page 43.

2

6016-113

8009-376

English-53

MAINTENANCE

Removal of BioClip Plug

To change a Combi unit from the BioClip function to a
cutting unit with rear ejection, remove the BioClip plug,
which is located under the unit, attached with three
screws.

1. Put the unit in service position, see “The cutting

unit’s service position” on page 47.

2. Remove the three screws holding the BioClip plug,

and remove the plug.

Tip: Fit three full-thread screws M8x15 mm in the
screw holes to protect the threads.

3. Return the unit to the normal position.

Fit the BioClip plug in the reverse order.

8009-289

Removal of BioClip Plug

English-54

LUBRICATION

Lubrication

Lubrication schedule

When in daily use, the weekly lubrication (1/52)
schedule should be carried out twice a week.

The position numbers for the lubrication points refer to
the lubrication instructions on the following pages.

8009-675

English-55

LUBRICATION

General

Remove the ignition key to prevent unintentional
movements during lubrication.

When lubricating with an oil can, it ought to be filled
with engine oil.

When lubricating with grease, unless otherwise stated,
grease 503 98 96-01 or another chassis or ball bearing
grease offering good corrosion protection shall be used.

With daily use, the Rider should be lubricated twice
weekly.

Wipe away excess grease after lubrication.

It is important to avoid getting lubricant on the belts
or the drive surfaces on the belt pulleys. Should this
happen, attempt to clean them with spirit. If the belt
continues to slip after cleaning with spirit, it must be
replaced. Petrol or other petroleum products must not
be used to clean belts.

Lubricating the cables

Grease both ends of the cables and move the controls
to end stop positions when lubricating. Re-attach the
rubber covers on the cables after lubrication. Cables
with sheaths will jam if they are not lubricated regularly.
A jammed cable may cause malfunction, such as the
parking braking being applied.

If a cable binds, remove the cable and hang it vertically.
Lubricate it with thin engine oil until the oil begins to
escape from the bottom. Tip: Fill a small plastic bag
with oil and tape it so that it seals against the casing
and allow the cable to hang vertically from the bag
overnight. If you do not succeed in lubricating the
cable, it must be replaced.

Accessories

Lubrication or other maintenance of optional
equipment or accessories, see “Accessories” on
page 16, is not described in this manual. This
equipment too, naturally, requires maintenance. See
the manuals for the respective accessories for
instructions.

It’s good practice to make a note of maintenance or
necessary actions preformed on this page.

English-56

LUBRICATION

Lubricating in accordance with the
lubrication schedule

The numbers in the following headings refer to the
lubrication points as described in “Lubrication
schedule” on page 55.

1. Pedal mechanism in frame tunnel

Lubricate the pedal mechanism in the frame tunnel.

Remove the cover over the frame tunnel by loosening
the two screws.

8009-340

Work the pedals and lubricate the moving parts with an
oil can.

Lubricate the cables to the brake and drive pedals with
an oil can.

Lubricate the point “2. Chains in the frame tunnel” on
page 57 before replacing the cover to the frame tunnel.

2. Chains in the frame tunnel

Remove the cover from the frame tunnel, see "1. Pedal
mechanism in frame tunnel” on page 57.

Lubricate the chains in the frame tunnel with an oil can
or chain lubricant spray for motorcycles.

Lubricate the steering cable pulley axle with grease.
Move the pulleys to one side and brush grease on the
axle.

8009-345

Replace the cover on the frame tunnel.

8009-346

English-57

LUBRICATION

3. Engine oil

Check the oil level in the engine when the Rider stands
horizontal with the engine switched off.

Fold up the engine cover.

Remove the dipstick and wipe it clean. Now insert
the dipstick again, without tightening it.

Take the dipstick out again and read the oil level.

The oil level should be between the markings on the
dipstick. If the level is approaching the “ADD” mark,
top up the oil to the “FULL” mark on the dipstick.

Never fill above the “FULL” mark.

8009-158

8009-159

The oil is topped up through the hole the dipstick
sits in.

Fill the oil slowly. Tighten the dipstick correctly before
starting the engine. Start and run the engine at idling
speed for approx. 30 seconds. Turn off the engine.
Wait 30 seconds and check the oil level. If necessary
fill so that the oil comes up to the “FULL” mark on the
dipstick.

Use engine oil SAE 30 or SAE 10W/30 or, alternately,
10W/40, class SF-SJ (over 0° C/+32°F).

Over +20°C/+68 °F SAE 40 can be used.

Use engine oil SAE 5W/20, class SF-SJ
(under 0° C/+32°F).

The engine holds 1.5 litres of oil excluding the filter
(including filter 1.7 litres).

8009-140

English-58

LUBRICATION

Replacing the engine oil

The engine oil should be changed the first time after
8 hours running time. It should then be changed after
every 100 hours of running time.

WARNING!

Engine oil can be very hot if it is drained
directly after stopping the engine. Allow
the engine to cool somewhat first.

1. Open the engine cover.

2. Place a container underneath the engine’s left oil

drain plug.

3. Remove the dipstick. Remove the drain plug from

the engine’s left side.

4. Let the oil run out into the container.

IMPORTANT INFORMATION

Used engine oil is a health hazard and must not
be disposed of on the ground or in nature; it
should always be disposed of at a workshop or
appropriate disposal location.
Avoid skin contact; wash with soap and water in
case of spills.

5. Then replace the oil drain plug and tighten it.

6. Replace the oil filter if necessary.

7. Fill with up to the “FULL” mark on the dipstick.

Use engine oil as set out above.

8. Run the engine warm, then check that there is no

leakage from the oil plug or oil filter.

8009-529

English-59

LUBRICATION

4. Gear lever

Remove the transmission cover, two screws.

Lubricate the joints and bearings on the left side with
an oil can.

Remove the rubber casing and lubricate the
hydrostatic transmission cable with an oil can.
Press the pedal a few times and lubricate again.

Replace the rubber cover.

Replace the transmission cover.

5. Transmission and hydraulic system

The oil and filter should be changed by an authorised
service representative, as described in the Workshop
Manual.

Work on the system entails particular demands on
cleanliness and the system must be vented before the
machine is used.

6008-209

6. Cutting unit

Remove the front cover.

Lubricate using an oil can:

A. The safety catch

- Joints and bearings

Lubricate using grease:

B. Interior plug

C. Groove for equipment frame

7. Three-point Link

Lubrication nipple located behind right front wheel.

6020-024

6020-004

Lubricate with grease gun until grease appears.

Use molybdenum disulphide grease.

English-60

6008-233

LUBRICATION

8. Driver’s seat

Tilt the seat back.

Lubricate the lengthways adjustment mechanism
with the oil can.

Lubricate the lengthways adjustment runners with
grease. Pull the seat back and forth and lubricate on
both sides.

9. Throttle and choke cables,
lever bearings

Remove the right side cover on the lever housing
(2 screws) and open the engine cover. Lubricate the
cables’ free ends with the oil can, even those by the
carburettor. Move the controls to the end points and
lubricate again.

Lubricate the joints, catches, and bearings for the
cutting unit’s control levers with an oil can.

8009-347

Replace the lever housing’s side cover.

8009-349

8009-157

English-61

LUBRICATION

10. Hydraulic oil filter, change

IMPORTANT INFORMATION

Used engine or transmission oil is health­impairing and must not be disposed of in the
ground or in nature.
Replaced filters must be handed in to the
workshop or other allotted placed for disposal.
Avoid skin contact; wash with soap and water in
case of spills.

1. Remove the oil filter. If necessary, use a filter

remover.

2. Wipe new, clean engine oil onto the seal for the

new filter.

3. Fit the filter by hand with + 3/4 turn.

4. Remove the transmission cover and fill the

transmission’s oil tank, about 0.3 l oil.
See “13. Transmission oil level” on page 63.
Be observant when running the engine as
described below and fill so that the tank is not
emptied.

5. Run the engine warm, manipulate the equipment

lift and power steering, and then check that there
are no leaks around the oil filter seal.

6. Check the oil level in the transmission, top up if

necessary. The oil filter holds 0.3 litres of oil.

7. Replace the transmission cover.

8009-350

11. Oil filter, change

WARNING!

Engine oil can be very hot if it is drained
directly after stopping the engine. Allow
the engine to cool somewhat first.

IMPORTANT INFORMATION

Used engine or transmission oil is health­impairing and must not be disposed of in the
ground or in nature.
Replaced filters must be handed in to the
workshop or other allotted placed for disposal.
Avoid skin contact; wash with soap and water in
case of spills.

1. Open the engine cover.

2. Drain the engine oil as described in “3. Engine oil”

on page 58.

3. Remove the oil filter. If necessary, use a filter

remover.

8009-161

English-62

LUBRICATION

4. Wipe new, clean engine oil onto the seal for

the new filter.

5. Fit the filter by hand with + 3/4 turn.

6. Run the engine warm, then check that there are

no leaks around the oil filter seal.

7. Check the oil level in the engine, top up if

necessary. The oil filter holds 0.2 litres of oil.

12. Parking Brake Cable

Remove the transmission cover, see "4. Gear lever” on
page 60.

Unhook the spring (A) from the screw (B) if required.

Remove the cable’s rubber casing when lubricating.

Lubricate the cable with an oil can, press the parking
brake pedal a few times and lubricate again.

Replace the spring (A) and the transmission cover.

A

B

6020-005

13. Transmission oil level

1. Check the oil level in the transmission by looking

through the air intake mesh. The oil level shall be
between the MIN and MAX markings on the oil
container when at +20°C.

If the oil needs to be filled, you must first remove
the transmission cover.

2. Unscrew the oil container’s cover and fill with SAE

10W/30 engine oil, class SF-CC, until the oil level
reaches the “MAX” mark. Then screw the oil
container’s cap into place and attach the
transmission cover.

6008-210

English-63

LUBRICATION

English-64

TROUBLE SHOOTING

Trouble Shooting Guide

Problem Cause

The engine will not start. • Fuel tank empty

• Incorrect fuel type

• Faulty spark plugs

• Faulty spark plug connections

• Dirt in the carburettor or fuel line

Starter does not turn the engine • Cutting unit in incorrect position

• Brake not applied

• Hydrostat pedals not in the neutral position

• Discharged battery

• Poor contact affecting the battery terminal cable
connections, ignition lock, or starter

• Main fuse blown The fuse is found in front of the
battery, under the battery cover

• Faulty ignition lock

• Faulty starter

The engine runs erratically • Faulty spark plug

• Incorrect carburettor setting

• Clogged air filter

• Blocked fuel tank ventilation

• Incorrect ignition setting

• Dirt in the carburettor or fuel line

• Choking or incorrectly adjusted choke cable

• Incorrect fuel type

Abnormal exhaust smoke • Black smoke:

• Choking or incorrectly adjusted choke cable

• Incorrect carburettor setting

• Clogged air filter

• Blue smoke:

• Oil mixed with fuel in tank

• Serious engine damage

• Thick pale smoke:

• Tank filled with diesel

The engine lacks power • Clogged air filter

• Faulty spark plugs

• Dirt in the carburettor or fuel line

• Incorrect carburettor setting

• Choking or incorrectly adjusted choke cable

• Incorrect fuel type

English-65

TROUBLE SHOOTING

Problem Cause

Engine overheating • Engine overloaded

• Air intake or cooling fins clogged

• Damaged fan

• Too little or no oil in the engine

• Faulty pre-ignition

• Faulty spark plugs

Battery does not charge • One or more battery cells faulty

• Poor contact on the battery terminal cable connectors

• Faulty generator or regulator

• Insufficient battery maintenance

The Rider vibrates • The blades are loose

• The engine is loose

• Pulley loose or bearing worn

• One or more blades is imbalanced, caused by damage
or poor balancing after sharpening

Uneven cutting result • Blades blunt

• Cutting unit set incorrectly

• Long or wet grass

• Grass build-up under the cover

• Different air pressure in the right and left tyres

• Driving speed too high

• Engine speed too low

• Drive belt slips

English-66

STORAGE

Storage

Winter Storage

At the end of the mowing season, the Rider should be
readied for storage, likewise if it will not be in use for
more than 30 days. Fuel allowed to stand for long
periods of time (30 days or more) can leave sticky
residues that can clog the carburettor and disrupt
engine function.

Fuel stabilisers are an acceptable option as regards
sticky residues during storage. If alkylate petrol is
used, stabilisers are unnecessary because this fuel is
stable. However, you should avoid switching between
standard and alkylate petrol as sensitive rubber
components can harden. Add stabiliser to the fuel in
the tank or in the storage container. Always use the
mixing ratios specified by the manufacturer of the
stabiliser. Run the engine for at least 10 minutes after
adding the stabiliser so that it reaches the carburettor.
Do not empty the fuel tank and the carburettor if you
have added stabiliser.

WARNING!

Never store an engine with fuel in the
tank indoors or in poorly ventilated
spaces where fuel vapour can come in
contact with open flames, sparks, or a
pilot light such as in a boiler, hot water
tank, clothes drier, etc. Handle the fuel
with care. It is very flammable and
careless use can cause serious
personal injury and property damage.
Drain the fuel into an approved
container outdoors and far away from
open flames. Never use petrol for
cleaning. Use a degreasing agent and
warm water instead.

To ready the Rider for storage, follow these steps:

1. Clean the Rider thoroughly, especially under the
cutting unit. Touch up damaged paint to prevent
rust.

2. Inspect the Rider for worn or damaged parts and
tighten any nuts or screws that may have become
loose.

3. Change the engine oil; dispose of properly.

4. Empty the fuel tank. Start the engine and let it run
so that even the petrol in the carburettor is
emptied.

English-67

STORAGE

5. Remove the spark plugs and pour about a
tablespoon of engine oil into each cylinder. Turn
over the engine so that the oil is evenly distributed
and then refit the spark plugs.

6. Lubricate all grease nipples, joints, and shafts.

7. Remove the battery. Clean, charge, and store
in a cool place.

8. Store the Rider in a clean, dry place and cover
it for extra protection.

Service

Low season is the most suitable time to perform a
service or overhaul of the machine in order to ensure
high functional safety during the high season.

When ordering spare parts, please specify the
purchase year, model, type, and serial number of
the Rider.

Always use genuine Husqvarna spare parts.

An annual check-up or trimming at an authorised
service representative is a good way to ensure that
your Rider performs at its best the following season.

English-68

8009-551

ELECTRICAL AND HYDRAULIC SYSTEMS

Electrical system

Electrical system

8009-549

Numbers correspond to: Colour abbreviations:

1. Microswitch, hydrostatic transmission

2. Microswitch, cutting unit

3. Microswitch, seat

4. Ignition key

5. Chronometer

6. Start relay

7. Engine connectors

8. Main fuse 15A

9. Fuse 7,5A

10. Switch for the power outlet

11. Power outlet

12. Switch for the lights

13. Lights

RD = Red

BL = Blue

VT = White

SV = Black

GL = Yellow

GR = Green

BR = Brown

English-69

ELECTRICAL AND HYDRAULIC SYSTEMS

Electrical system

English-70

8009-588

ELECTRICAL AND HYDRAULIC SYSTEMS

Hydraulic system

Hydraulic System: component locations

Hydraulic System: component locations:

1. Power steering

2. Pump in hydrostatic transmission

3. Hydraulic oil filter

Keep the hydraulic system clean. Remember to:

• Thoroughly clean before the filling cap is opened or
any connector is loosened.

• Use clean containers when filling the oil.

• Only use clean oil that has been stored in a sealed
container.

• Do not reuse drained oil.

• Change the oil and filter according to the intervals
specified in “Maintenance schedule” on page 27.

In order for a hydraulic system to function without
problem, it must be free from foreign objects. When
used, the system produces particles, which can cause
both wear and abnormal function. In order to remove
these particles, the system contains filters. The filters
are sized so as to capture the produced particles, but if
contaminants are introduced from outside the system,
the filters can quickly become clogged and fail to
function as intended. If there are contaminants in the
system, further contamination will be produced in a
self-propagating cycle. The result will be function
disruptions and much work to clean the system.

4. Pneumatic cylinder

5. Pressure limiting valve

6. Control valve for pneumatic cylinder

8009-357

English-71

ELECTRICAL AND HYDRAULIC SYSTEMS

English-72

TECHNICAL DATA

Technical data

Data Rider ProFlex 18

Dimensions

Length, base machine 2080 mm / 6,82 ft

Width, base machine 900 mm / 2,95 ft

Height 1160 mm / 3,80 ft

Operating weight, base machine 309 kg / 682 lb

Wheelbase 1000 mm / 3.28 ft

Track width 710 mm / 2.38 ft

Tyre dimensions 195/65-8

Engine

Manufacturer Kawasaki

Model FH 531V-BS50

Power 13.2 / 18 kW/hk

Displacement

Fuel at least 87 octane unleaded

max ethanol 5%, max ethanol 10%, max

Tank volume 17 litres

Oil SAE 30 or SAE 10W/30,

SAE 10W/40 class SF-SJ

Oil volume 1.5 litres / 1.6 US qt

Oil volume including filter 1.7 litres / 1.8 US qt

Start Electric start

Noise emissions

Measured noise level 101 dB(A)

Guaranteed noise level 102 dB(A)

Electrical System

Type 12 V, negative grounded

494 cm

MTBE 15%

3

Battery 12 V, 24Ah

Main fuse Flat pin, 15 A

Fuse Flat pin, 7.5A

Spark plug Champion RCJ8Y

Electrode gap 0.75 mm / 0.030"

Bulbs 2x12V 20W

English-73

TECHNICAL DATA

Data Rider ProFlex 18

Hydraulic System

Max. working pressure 45 bar / 630 PSI

Transmission

Manufacturer Tuff Torq K 66

Oil SAE 10W/30, class SF-CC

Oil volume, total 3.2 litres

Cutting unit Combi 112

Cutting width 1120 mm / 44"

Cutting heights 40 - 100 mm / 1.57" - 3.93"

Blade length 420 mm / 16.5"

Width 1230 mm / 48.4"

Weight 50 kg / 110 lb

Additional weight, ProFlex 8 kg / 17.6 lb

Length machine with unit 2450 mm / 8.04 ft

Cutting unit Combi 122

Cutting width 1220 mm / 48"

Cutting heights 40 - 100 mm / 1.57" - 3.93"

Blade length 450 mm / 17.7"

Width 1330 mm / 52.4"

Weight 60 kg / 17.6 lb

Additional weight, ProFlex 8 kg / 17.6 lb

Length machine with unit 2550 mm / 8.37 ft

IMPORTANT INFORMATION

When this product is spent and is no longer
used it should be returned to the dealer or other
authority for recycling.

IMPORTANT INFORMATION

In order to introduce improvements the
specification and design are subject to
alteration without prior notice.

Note that no legal demands whatsoever can be
made with the support of the information in this
operator’s manual.

Only use original spare parts with repairs. The
use of other parts invalidates the warranty.

English-74

EU DECLARATION OF CONFORMITY

EU Declaration of Conformity

EU Declaration of Conformity (only applies to Europe)

We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: [phone], declare under sole

responsibility that Rider Husqvarna Rider ProFlex 18 dating from 2005 serial numbers and onwards
(the year is clearly stated on the rating plate, followed by the serial number), comply with the
requirements of the COUNCIL’S DIRECTIVE:

-of June 22, 1998 “relating to machinery” 98/37/EC, annex IIA.

-of May 3, 1989 “relating to electromagnetic compatibility” 89/336/EEC, and applicable supplements.

-of May 8, 2000 “relating to the emission of noise to surroundings” 2000/14/EC.
Information regarding noise emissions and the cutting width, see Technical Data.

The following harmonised standards have been applied: EN292-2, EN836.

The registered body 0404, SMP Svensk Maskinprovning AB, Fyristorgsgatan 3, SE-754 50 Uppsala,
Sweden has issued the report with number

ProFlex 18: 01/901/009

regarding the assessment of conformity according to annex VI to the COUNCIL’S DIRECTIVE of May 8,
2000 “relating to the emission of noise to surroundings” 2000/14/EC.

Huskvarna October 1, 2004

Roger Andersson, Development Manager/Garden Products

English-75

EU DECLARATION OF CONFORMITY

English-76

SERVICE JOURNAL

Service journal

Action

1. Delivery Service

2. Fill the battery with battery acid and charge for four hours.

3. Fit the steering wheel, seat and, where applicable, other
components.

4. Attach the cutting unit.

5. Adjust the cutting unit:

Adjust the lifting springs (the “weight” of the cutting unit should
be 12-15 kg, if a brush is to be used, set to maximum spring
force).

Adjust the cutting unit so that its rear edge is about 2-4 mm
higher than its front edge.

Adjust the cutting unit’s cutting height setting so that the
cutting height limit is 5 mm above the unit frame at the lowest
cutting height.

Check that the right amount of oil is in the engine and
transmission.

6. Check and adjust the air pressure in the tyres
(60 kPa / 0.6 bar / 9 PSI.

7. Connect the battery.

8. Fill the fuel tank and start the engine.

9. Check that the machine does not move in neutral.

10. Check:

Driving forwards.

Reversing.

Engaging the blades.

Safety switch in the seat.

Safety switch for the lifting lever.

The safety switch for the hydrostat pedals.

11. Check the engine speed: 2,900 ±75 rpm.

12. Bleed the hydraulic system.

13. Check the screws on the muffler (10 Nm).

14. Inform the customer about:

15. The need and advantages of following the service schedule.

16. The need and advantages of leaving the machine for service
every 300 hours.

17. The effects of service and maintaining a service journal on the
machine’s resale value.

18. Application areas for Mulching.

19. Fill in the sales papers, etc.

After the First 8 Hours

1. Change engine oil.

Delivery service has been
carried out.

No remaining remarks.

Certified:

Date, mileage reading, stamp,
signature

English-77

SERVICE JOURNAL

Action Date, mileage reading, stamp,

25-Hour Service

1. Clean the air cleaner’s pre-filter (Foam element).
(shorter intervals in dusty operating conditions)

2. Clean the engine’s cooling air intake and the transmission’s air
intake.

3. Clean the fuel pump’s air filter.
(in dusty operating conditions)

4. Check the screws on the muffler (10 Nm).

This field is intended for keeping a journal

signature

Notes

English-78

SERVICE JOURNAL

Action Date, mileage reading, stamp,

50-Hour Service

1. Clean/change the air cleaner’s pre-filter (Foam element).
(shorter intervals in dusty operating conditions)

2. Clean the engine’s cooling air intake and the transmission’s air
intake.

3. Clean the fuel pump’s air filter.

4. Clean the fuel pump’s air filter.

5. Check the screws on the muffler (10 Nm).

6. Check/adjust the cutting height.

7. Check/adjust the parking brake.

8. Inspect the flame arrester/spark extinguisher (extra equipment).

This field is intended for keeping a journal

signature

Notes

English-79

SERVICE JOURNAL

Action Date, mileage reading, stamp,

100/200-Hour Service

1. Change engine oil. Replace the oil filter every 200 hours.

2. Clean/change the air cleaner’s pre-filter (Foam element).

3. Clean the air cleaner’s paper filter. Replace every 200 hours.
(shorter intervals for dusty operating conditions)

4. Check the screws on the muffler (10 Nm).

5. Clean the engine’s cooling air intake and the transmission’s air
intake.

6. Clean the cooling fins on the cylinder and cylinder head.

7. Check/adjust the cutting height.

8. Check/adjust the parking brake.

9. Inspect the flame arrester/spark extinguisher (extra equipment).

10. Clean/replace the spark plugs.

11. Change the inline fuel filter.

12. Replace the hydraulic oil filter every 200 hours.

13. Clean the fuel pump’s air filter.

14. Clean the pulse air filter.

15. Check nuts and screws for tightness.

16. Check whether the oil and filter need to be changed in gearbox
K66 (every 500 hours).

signature

Notes

This field is intended for keeping a journal

English-80

SERVICE JOURNAL

Action Date, mileage reading, stamp,

300-Hour Service

1. Inspect the machine. Additional work?

2. Change engine oil.

3. Change the air filter (Foam element).

4. Change the air filter (paper filter).

5. Check the screws on the muffler (10 Nm).

6. Clean the fuel pump’s air filter.

7. Check/adjust the cutting height.

8. Check/adjust the parking brake.

9. Inspect the flame arrester/spark extinguisher (extra equipment).

10. Replace the engine oil filter (200 hours).

11. Replace the hydraulic oil filter (200 hours)

12. Clean/replace the spark plugs.

13. Change the inline fuel filter.

14. Clean the pulse air filter.

15. Check the play on the engine valves.

16. Check whether the oil and filter need to be changed in gearbox
K66 (every 500 hours).

signature

Notes

This field is intended for keeping a journal

English-81

SERVICE JOURNAL

Action Date, mileage reading, stamp,

At Least Once Each Season

1. Change the engine oil (100 hours).

2. Clean/change the air cleaner’s pre-filter (Foam element)
(25 hours). (shorter intervals in dusty operating conditions)

3. Clean/change the air filter’s paper filter (100 hours).
(shorter intervals in dusty operating conditions)

4. Clean the fuel pump’s air filter (50 hours).

5. Check the screws on the muffler (10 Nm).

6. Adjust the cutting height (50 hours).

7. Adjust the parking brake (50 hours).

8. Inspect the flame arrester/spark extinguisher, extra equipment
(50 hours).

9. Replace the engine oil filter (200 hours).

10. Replace the hydraulic oil filter (200 hours).

11. Clean/change the spark plugs (100 hours).

12. Change the inline fuel filter (100 hours).

13. Clean the pulse air filter (100 hours).

14. Clean the cooling fins on the cylinders and cylinder head
(100 hours).
(shorter intervals in dusty operating conditions)

15. Check the play on the engine valves (300 hours).

16. Change the oil and filter in gearbox K66 (500 hours).

17. Perform the 300-hour service at an authorised service
representative.

signature

Notes

This field is intended for keeping a journal

English-82

SERVICE JOURNAL

Action Date, mileage reading, stamp,
