Page 1
The Platinum Family
Features and Benets
K E E P I N G T H E W O R L D S E W I N G
Page 2
All Platinum models Feature:
EASY THREADING
Follow the top threading guide
arrows for easy threading.
AUTOMATIC NEEDLE THREADER
Built-in needle threader eliminates
tedious hand threading.
TWO BUILT-IN SPOOL PINS
Easy threading for twin needle
and other specialty sewing and
topstitching techniques.
BOBBIN WINDS FROM NEEDLE
No need to unthread or rethread
to wind a bobbin.
AUTOMATIC BOBBIN THREAD
PICK-UP
No need to bring bobbin thread
up manually.
SNAP ON AND OFF PRESSER
FEET
Change presser feet quickly and
easily.
ADJUSTABLE PRESSER FOOT
PRESSURE
Even feed on bulky knits to ne
sheers.
DIRECT STITCH SELECTION
Select your stitches directly on your
Touch Panel.
ADJUSTABLE STITCH LENGTH
AND STITCH WIDTH
Adjust stitch width and length from
0 - 6 mm for specialty sewing.
25 NEEDLE POSITIONS
Set needle position perfectly for
quilting, stitching in the ditch,
topstitching, zippers, specialty
techniques and accessory presser
feet.
STOP FUNCTION
Touch STOP to nish stitch
pattern at end and tie off
automatically. Program STOP to
end sewing at a specic stitch or
program.
FIX FUNCTION
Touch FIX to stop and lock any
stitch instantly with tiny forward
and backward stitches.
MIRROR IMAGE
Flip stitches and/or stitch programs
side to side and/or end to end for
unlimited creative combinations
and easy fabric positioning while
you sew. For Platinum 730 and
Platinum Plus ip stitches and/or
stitch programs side to side.
SELECTIVE NEEDLE STOP UP/
DOWN
Set needle to stop up or down.
Tap the foot control or touch
needle up/down button to move
needle up or down at any time.
For Platinum 730, tap the foot
control to place the needle in
down position.
INSTANT AND PERMANENT
REVERSE
Touch reverse to sew any stitch in
reverse for a lockstitch and tie off.
Touch reverse twice for
continuous reverse.
ERGONOMICALLY DESIGNED
Convenient up-front threading,
bobbin winding and placement,
free arm, all settings at your
ngertips with simple function
buttons. One piece aluminium
casting is lightweight yet strong,
long lasting and prevents vibration.
The large foot control allows
comfortable sitting position.
SLIDE-ON ACCESSORY BOX
Store your bobbins, accessory feet,
needles and more, right at your
ngertips. The new extended
working area facilitates working
with larger projects.
BUILT-IN RULER
Ruler on front base of Platinum
lets you measure at your ngertips.
Convert from inches to centimeters
in an instant.
ATTRACTIVE CARRYING CASE
Easy to carry and protects your
Platinum and accessories for
storage and/or transport.
MADE IN SWEDEN
Husqvarna Viking has engineered
superior quality and cutting edge
technology sewing machines for
over 130 years.
PERMANENTLY LUBRICATED
No oiling means no oil on fabric.
JAMPROOF ROTARY HOOK
No tangled threads or threads
sewn down into the machine.
ELECTRONIC SPEED CONTROL
AND PIERCING POWER
Stitch by stitch control with full
needle penetration at any speed.
EDUCATION PACKAGE
All Husqvarna Viking Platinum
sewing machines come with a
User’s Guide plus a step by step
Handbook with exercises plus a
copy of the ZigZag magazine.
Husqvarna Viking Accessory
User’s Guide teaches you how to
use over 40 accessories to make
specialty technique sewing faster
and easier. Your Husqvarna Viking
Platinum 770, Platinum 750 Quilt,
and Platinum 730 come with a
companion video and your
Platinum Plus comes with companion
CD for visual guidance and
instruction on how to use
your new sewing machine. For the
Platinum Plus there’s even a
software demo CD plus the
Embroidery Collection booklet, all
included to guide and inspire your
joy of sewing.
Page 3
Platinum Plus
Embroidery Features
SLIDE-ON EMBROIDERY UNIT
Instant embroidery ability with
large embroidery support surface.
Easy to place and easy to remove.
AUTOMATIC FEED TEETH
Feed teeth lower automatically for
embroidery and come up
automatically for sewing.
HOOP
Husqvarna Viking Platinum Plus
includes the Large Hoop to sew
embroideries up to 9.6" x 6"
(240 x 150 mm).
EMBROIDERY d-CARDS
Husqvarna Viking Platinum Plus
includes the Embroidery d-Card
1005 featuring 21 beautiful
embroideries for all types of
projects. Also included is the
Embroidery d-Card 1002 ,
Clarendon, for monogramming
and numbering.
PLATINUM PLUS BOOKLET
The Platinum Plus Sampler
pictures designs actual size and
gives colors of thread by number.
PREVIEW DESIGN SIZE AND
PLACEMENT
Preview the size and placement by
touching the corner test function.
MOVE DESIGN IN HOOP
Touch positioning buttons to
move design within hoop for
precision placement.
ENLARGE AND REDUCE SIZE
Sew different sizes for each
design. Change embroidery size
quickly by touching the stitch
length and width buttons.
STEP THROUGH DESIGNS
Step through designs by color or
by stitch to move forward or
backward to any part of a design
or to sew only parts of a design.
CHANGE THE BOBBIN THREAD
WITHOUT REMOVING THE
HOOP
Touch bobbin access symbol to
conveniently move the hoop to
the proper position to easily
remove the bobbin.
PARK POSITION
Touch the park position symbol to
move the embroidery arm to rest
position.
FIX BASTE
Touch FIX to baste fabric in the
hoop and outline the embroidery
area.
COLOR STOPS
Platinum Plus stops sewing and
beeps to alert you when it’s time
for color change.
EASY ONE COLOR EMBROIDERY
Simply touch the STOP button to
cancel color stops to sew one
color and tone on tone
embroideries.
EMBROIDERY ROTATION
Rotate designs easily in 90 degree
steps for additional design
opportunities and easy hooping.
EMBROIDERY MIRROR IMAGE
Flip designs for twice as many
design possibilities and easy
hooping.
PLACEMENT TEMPLATE
Placement template is included.
Trace the design onto the
placement template and mark
placement lines.
EMBROIDERY SEWING SPEED
Speed is computer controlled for
best stitch quality or control
manually for specialty threads.
HUSQVARNA VIKING
EMBROIDERY COLLECTION
Highest quality embroidery designs
from top name sewing designers.
OPTIONAL EMBROIDERY
ACCESSORIES
HUSQVARNA VIKING
MEGA HOOP
Embroider bigger designs than ever
- up to 14.2" x 6" (360 x 150 mm).
HUSQVARNA VIKING
MIDSIZE HOOP
Embroider designs up to
6 3/8" x 4" (170 x 100 mm).
HUSQVARNA VIKING
STANDARD HOOP
Embroider designs up to 4" x 4"
(100 x 100 mm).
HUSQVARNA VIKING
EMBROIDERY SPRING HOOP
Use the Spring Hoop, design area
4" x 4" (100 x 100 mm), for quick
and easy hooping.
HUSQVARNA VIKING MINI
EMBROIDERY SPRING HOOP
Use the Mini Spring hoop, design
area 1.6" x 1.6" (40 x 40 mm), for
perfect result on smaller pieces of
fabrics like collars and pockets.
HUSQVARNA VIKING
EMBROIDERY SOFTWARE
Choose from the most advanced
Embroidery Software for the home
sewer. Purchase step by step or all
at once. Husqvarna Viking provides
programs that allow sewers the
option to move at their own pace
as their creativity ourishes.
d-CARD READER/WRITER FOR
PLATINUM PLUS
Includes Personal d-Card for
transferring designs from your
computer via USB-port to be
embroidered on your Platinum Plus.
Page 4
TOTAL AMOUNT OF STITCHES
Platinum Plus – 133 stitches
Platinum 770 – 337 stitches plus Cyrillic 64 and
Hiragana 64
Platinum 750 Quilt – 168 stitches
Platinum 730 – 42 stitches
Choose between a wide selection of utility
stitches, decorative stitches, lettering, numbering,
and special characters.
UTILITY STITCHES
Platinum Plus – 19 stitches
Platinum 770 – 35 stitches
Platinum 750 Quilt – 35 stitches
Platinum 730 – 21 stitches
Choose between a wide selection of utility
stitches including different buttonhole styles used
for garment and project sewing, mending and
darning.
DECORATIVE STITCHES
Platinum Plus – 16 stitches
Platinum 770 – 105 stitches
Platinum 750 Quilt – 35 stitches
Platinum 730 – 21 stitches
Personalize your sewing projects with the
different decorative stitches ranging from fashion,
quilting, heirloom stitches, and more.
ALPHABETS
Platinum Plus – Outline block alphabet
Platinum 770 – Outline block alphabet/Script
alphabet plus Cyrillic/Hiragana alphabet
Platinum 750 Quilt – Outline block alphabet
The alphabets include upper and lower case
letters, numbers 0 - 9 and special characters.
Great for labelling kid’s clothing, quilts and
keepsakes!
PBB - PERFECTLY BALANCED
BUTTONHOLES
Perfectly balanced buttonholes means both
columns of your buttonhole are sewn in the same
direction. PBB ensures professional looking
buttonholes on all Platinum models and are easy
to sew.
PERMANENT MEMORIES
Platinum Plus – 4 memories
Platinum 770 – 4 memories
Platinum 750 Quilt – 2 memories
Platinum 730 – 1 memory
Use the Platinum memories to save stitches and/
or lettering. Save up to 30 stitches per memory.
For Platinum 770 save up to 55 stitches.
VSM Group AB • SE-561 84 Huskvarna, Sweden
www.husqvarnaviking.com
• Printed on environmental freindly paper • Printed in Sweden • © 2004 • VSM Group AB • All rights reserved • 0403. •
105 64 27-26
