Huawei WDR814G, WDR814IG User Manual

HUAWEI

Aolynk WDR814g / WDR814Ig

ADSL2+ Wireless Router

User’s Manual

Aolynk WDR814g / WDR814Ig ADSL2+ Wireless Router User’s Manual

Volume Manual Version Product Version BOM

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address: Administration Building, Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, P. R. China Postal Code: 518129 Website: http://www.huawei-3com.com Email: support@huawei-3com.com

No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.

Trademarks

, HUAWEI, C&C08, EAST8000, HONET, , ViewPoint, INtess, ETS, DMC, TELLIN, InfoLink, Netkey, Quidway, SYNLOCK, Radium, M900/M1800, TELESIGHT, Quidview, Musa, Airbridge, Tellwin, Inmedia, VRP, DOPRA, iTELLIN, HUAWEIOptiX, C&C08 iNET, NETENGINE, OptiX, iSite, U-SYS, iMUSE, OpenEye, Lansway, SmartAX, infoX, TopEng are trademarks of Huawei Technologies Co., Ltd.

All other trademarks mentioned in this manual are the property of their respective holders.

Notice

The information in this document is subject to change without notice. Every effort has been made in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document don't constitute the warranty of any kind, express or implied.

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual Contents

1 Introduction...........................................................................................................................7

1.1 About the ADSL Wireless Router.............................................................................................7

1.2 Contents of the ADSL Wireless Router Package......................................................................8

1.3 Features of the ADSL Wireless Router.....................................................................................9

2 Hardware Installation & Setup..........................................................................................10

2.1 Rear Panel & Connections....................................................................................................10

2.2 Front Panel LEDs...................................................................................................................11

2.3 POTS Splitter........................................................................................................................12

2.4 System Requirements and Setup..........................................................................................12

2.4.1 Installing the TCP/IP Protocol.......................................................................................13

2.4.2 Fixed IP Addresses Configuration.................................................................................16

2.4.3 Installing the USB driver...............................................................................................18

3 Internet Access.....................................................................................................................22

3.1 Prepare your network............................................................................................................22

3.2 Web-based User Interface.....................................................................................................23

3.3 Quick Start this ADSL Wireless Router...................................................................................24

3.4 WAN Setup...........................................................................................................................25

3.4.1 Internet Connection Setup............................................................................................25

3.4.2 DDNS Setup.................................................................................................................29

3.4.3 NTP Setup....................................................................................................................30

3.5 LAN Setup............................................................................................................................31

3.5.1 LAN IP setting & DHCP setting.....................................................................................31

3.5.2 Routing Setting.............................................................................................................32

3.6 Wireless Setup......................................................................................................................34

3.7 Advanced Wireless Setting....................................................................................................35

3.8 Advanced Applications...........................................................................................................38

3.9 Security.................................................................................................................................38

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual Contents

3.9.1 Access Policy...............................................................................................................38

3.9.2 Firewall.........................................................................................................................39

3.10 Services..............................................................................................................................40

3.10.1 Virtual Server..............................................................................................................40

3.10.2 Forwarding.................................................................................................................42

3.10.3 Trigger........................................................................................................................43

3.10.4 DMZ Host...................................................................................................................44

4 Management.........................................................................................................................45

4.1 Management Settings...........................................................................................................45

4.2 Log.......................................................................................................................................46

4.3 Diagnostic-Ping.....................................................................................................................47

4.4 Upgrade Firmware.................................................................................................................48

5 Troubleshooting..................................................................................................................50

A FAQ......................................................................................................................................52

B Technical Specifications....................................................................................................54

C Glossary...............................................................................................................................56

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual About This Manual

About this Manual

Related Manuals

None

Organization

The manual has the following organization.

Chapter Description

Chapter 1 Introduction

Chapter 2 Hardware Installation & Setup

Chapter 3 Internet Access

Chapter 4 Advanced Applications

Chapter 5 Management

Chapter 6 Troubleshooting

This chapter describes the package contents and provides a list of features and application illustrations of the ADSL Wireless Router.

This chapter provides information about your ADSL Wireless Router’s physical features and gives step-by-step installation instructions for hardware installation and software configuration.

This chapter describes the procedures necessary to configure the basic functions and begin using your ADSL Wireless Router. If you follow these procedures correctly, there should be no problem in accessing the Internet via your ADSL Wireless Router.

This chapter provides information on how to set up and use the advanced functions of your ADSL Wireless Router.

This chapter provides information on using Macintosh computers in your network. The instructions given here are for system software version 8.0 or above, which comes with the TCP/IP Protocol preloaded and supports DHCP Addressing.

This chapter provides solutions to problems you may encounter

during installation and operation of your ADSL Wireless Router. Appendix A FAQ …… Appendix B

Technical Specifications

Appendix C Glossary

……

iii

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual About This Manual

Intended Audience

The manual is for:

WDR814g ADSL2+ Wireless Router

WDR814Ig ADSL2+ Wireless Router

Conventions

The manual uses the following conventions.

Symbol Conventions

Symbol Description

GUI Conventions

& Important Note:

& Note: A note notice with this symbol indicates additional, helpful,

Convention Description

Boldface Button names and menu items are in Boldface. For example, Click

/ Multi-level menus are in bold and separated by forward slashes. For

Convention Description

< > Button name are inside angle brackets. For example, click the <OK>

[ ] Window names, menu items, data table and field names are inside

An important note notice with this symbol helps you avoid an

undesirable situation or indicates important supplementary

information.

non-critical information.

OK.

example, Select the File/Create/Folder menu.

button

square brackets. For example, pop up the [New User] window. / Multi-level menus are separated by forward slashes. For example,

[File/Create/Folder].

Keyboard Operation

Format Description

<Key> Press the key with the key name inside angle brackets. For example,

<Enter>, <Tab>, <Backspace>, or <A>. <Key1 + Key2> Press the keys concurrently. For example, <Ctrl+Alt+A> means the

three keys should be pressed concurrently. <Key1, Key2> Press the keys in turn. For example, <Alt, A> means the two keys

should be pressed in turn.

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual About This Manual

Mouse Operation

Action Description

Select Press and hold the primary mouse button (left mouse button by default). Click Select and release the primary mouse button without moving the pointer. Double-click Press the primary mouse button twice continuously and quickly without

moving the pointer.

Drag Press and hold the primary mouse button and move the pointer to a certain

position.

Syntax Conventions

Convention Description

Italics means new words, terms, or special emphasis. E.g. Getting to know your

ADSL Wireless Router.

Boldface means you can select buttons, checkboxes, or items from screens, menus,

or dialog boxes. E.g. Click “OK” to restart

Bold Italics are samples only and you should enter other names, numbers, or words to

Environmental Protection

This product has been designed to comply with the requirements on environmental protection. For the proper storage, use and disposal of this product, national laws and regulations must be observed

substitute.

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 1 Introduction

Preface

Congratulations on your purchase of this ADSL Wireless Router. This ADSL Wireless Router is an ideal solution for SOHO users who require fast Internet access over existing copper wires. This ADSL-based router can provide up to 20Mbps Internet downstream speed and 1Mbps upstream speed. All users in the LAN side allow sharing this high-speed broadband connection with embedded NAT and DHCP server.

Integrated 802.11b/g wireless AP, 4-port 10/100 Mbps Ethernet switch and 1 USB port; it is quick and easy to deploy wireless and wire LAN without spending extra cost of a wireless access point, hub or switch. Especially , the extra USB port offers a fast and convenient connection to the Internet. All LAN users are able to share internal network data, like files, printers, and other networking resources in a blazing speed.

The built-in 802.11 b/g wireless AP enables you to move your computer freely around your living or working environment. The 802.11g technology is an extension of

802.11b, the basis of the majority wireless LANs and being widespread today. 802.11g not only provides data rates up to maximum 54 Mbps, but also is backward compatible with 802.11b.

The ADSL Wireless Router also provides a complete security solution that protects your network from hacker attacks and Internet intruders, as well as filters objectionable Web sites or contents.

With a web-based UI (User Interface), this ADSL Wireless Router is easy to configure and maintain. All functions can be configured with this exclusive, easy and friendly User Interface via web browsers such as Internet Explorer and Netscape Communicator.

This guide contains information about installing and configuring your ADSL Wireless Router. It is designed to guide users through the correct setup procedures for appropriate hardware installation and basic configuration. Later, it shows how to complete advanced configurations to get the best operating performance from this ADSL Wireless Router.

There are 2 models of this router, the different of they are shown below, and the rest is same as each other.

Model DSL Different

WDR814g ADSL2+ over POTS WDR814Ig ADSL2+ over ISDN

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 1 Introduction

1 Introduction

This chapter describes the package contents and provides a list of features and application illustrations of the ADSL Wireless Router.

1.1 About the ADSL Wireless Router

DSL (Digital Subscriber Line) refers to a technology used to increase the data capacity of standard twisted-pair wires that are generally used to connect most households to the phone network. In addition, this technology allows simultaneous voice and high-speed data transmission over a single pair of telephone wires.

There are several kinds of DSL services, each with its own compromises between speed, distance, cost, and reliability. These services are either symmetrical (data flows at the same speed in both directions), or asymmetrical (the downstream capacity is higher than the upstream capacity).

ADSL

Asymmetric Digital Subscriber Line (ADSL), as its name indicates, is an asymmetrical data transmission technology which provides high-speed data transfer over existing telephone or ISDN lines by making good use of the previously unused high-frequency band-width. ADSL provides much higher downstream speed than upstream speed. It is much popular as ordinary users download much more data than what they upload.

ADSL provides a dedicated secure communication between you and the ISP (Internet Service Provider) and the connection is high-speed and always-on.

Ethernet / Fast Ethernet / USB

Ethernet is the most widely-used network access method, especially in a Local Area Network (LAN) and is defined by the IEEE 802.3 standard. Normally, Ethernet is a shared media LAN. All stations on the segment share the total bandwidth, which could be 10Mbps (Ethernet), 100Mbps (Fast Ethernet), or 1000Mbps (Gigabit Ethernet). With a switched Ethernet, each sender and receiver has the full bandwidth.

Fast Ethernet is defined as IEEE 802.3u standard, a high-speed version of Ethernet with 100Mbps transmission rate.

USB (Universal Serial Bus) is a data communication standard which allows the PC/desktop to detect new devices such as printers, joysticks, keyboards, mice, adapters, storage devices, audio devices, digital cameras and things with this technology. The advantage of USB is to replace different types of serial and parallel port connectors with one standardized plug and port combination with the data transfer rate up to 12Mbps. Also low-power devices can draw power from USB and don’t require an extra adapter. Before you use this connector, you may need to install the USB driver first.

Wireless LAN

Wireless Local Area Network systems (WLANs) transmit and receive data over the air by using radio frequency (RF). This offers some advantages like mobility, ease of installation, and scalability over traditional wired systems.

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 1 Introduction

Mobility: WLANs combine data connectivity with user mobility. This provides users with access to network anywhere in their organization. For example, users can roam from a conference room to their office without being disconnected from the LAN. This is impossible with wired networks.

Ease of Installation: Eliminating the need to deploy network cables in walls and ceilings, Installing WLANs is easy for novice and expert users alike.

Scalability: WLAN topologies are easy to change in various ways from peer-to-peer networks for a small group of users to full infrastructure networks for hundreds of users roaming over a broad area.

Wireless LAN is suitable for difficult-to-wire and frequently changing environments. It’s also an ideal solution for mobile workers to access network resource and for setting a temporary LAN when necessary

Wireless LANs can be set as “Ad-hoc” network and “Infrastructure” network. Unlike the “Ad-hoc network”, where users on the LAN send data directly to each other, the “Infrastructure” network includes an access point and users on the “Infrastructure” network send data to that dedicated access point. ADSL Wireless Router uses “Infrastructure” network as Wireless LANs. Each wireless LAN PC within the range of the access point can communicate with other wireless LAN PCs within the range.

Firewall

DoS is an abbreviation for Denial of Service. This occurs when a computer or network is overwhelmed to the point that it can no longer function normally. For example, a hacker may use fake IP addresses to accumulate numbers connections in orders to flood the server he wants to attack. The way TCP works is that a SYN packet is sent to the server from the client. After the server receives the SYN packet, a SYN-ACK is sent back to client. The server will then wait for the reply from the SYN-ACK. If the hacker sent hundreds or thousands of SYN packets to the server with bogus IP addresses, the server allocates computer and memory resources to establishing a connection since the server does not know a legitimate SYN message from a bogus message. By flooding the server with a large volume of requests, the server’s maximum capacity can be used by these bogus and useless connection attempts

SPI is an acronym for Stateful Packet Inspection. The SPI engine examines not just the headers of the packet, but also the packet content. It can then determine more about the packet than just its source and destination information. Moreover, stateful inspection firewalls also close off ports until a connection to the specific port is requested.

1.2 Contents of the ADSL Wireless Router Package

After carefully unpacking the shipping carton, check the contents listed below.

1 Aolynk ADLS2+ router

1 Power adaptor

1 Telephone cables

1 Ethernet cable

1 USB cable

2 Screw and anchor

1 Quick Start Manual

1 Driver & Manual CD

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 1 Introduction

1 Quality card

1.3 Features of the ADSL Wireless Router

Your ADSL Wireless Router contains the following features which done the absolutely excellent work for network connections.

Asymmetrical data rates of up to 8Mbps downstream and 832kbps upstream.

Supports ITU G.dmt, ITU G.lite, ANSI T1.413 issue 2, ADSL2 and ADSL2+ standards.

Allows multiple users to access the Internet at the same time by providing maximum Internet utilization to multiple users sharing a single public IP Address.

Allows users on Ethernet LAN and Wireless LAN to transfer data to each other through wireless-to-wire Bridge.

Provides wireless access roaming, best access point selection, loading balance, network traffic filtering included in wireless roaming function.

Provides 64bits/128bits key WEP (Wired Equivalent Privacy) wireless data encryption to secure wireless communication.

Fully supports 802.11 open and shared key authentications.

Integrates four 10/100BASE-T/TX auto-sensing switch ports.

Uses NAT to allow your entire network’s PCs to connect to the Internet using only one (purchased) IP address.

Supports PPPoE enabling users to seamlessly connect to ISPs with the familiar “dial-up” connection interface.

Built-in web-based user interface for easy configuration and management through common web browsers such as Netscape Communication 6.0 or later and Internet Explorer 5.0 or later.

Built-in firewall to protect your PCs from outside intruders (NAT).

Supports DHCP client to receive both a dynamic IP Address and a fixed IP Address from ISP.

Built-in DHCP server to automatically assign and manage LAN IP addresses.

Allow administrators to block specific internal users from accessing specified applications or services.

Allows external Internet users to access information from the internal target host by setting the Virtual Server.

Provides unrestricted two-way communication between one PC on your LAN and certain Internet services such as conferencing, video and gaming applications.

Enhances routing performance by using Dynamic and Static routing settings.

Compatible with all popular Internet applications.

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 2 Hardware Installation & Setup

2 Hardware Installation & Setup

This chapter provides information about your ADSL Wireless Router’s physical features and gives step-by-step installation instructions for hardware installation and software configuration.

2.1 Rear Panel & Connections

The following figures show the rear view of the ADSL Wireless Router and illustrate how the cables connect to the interfaces on the rear panel.

Step1 Plug one end of the ADSL line (Standard phone line) into the ADSL port, the other into

the wall jack that is connected to the ADSL service.

Step2 Connect the Ethernet NIC (Network Interface Card) port of a PC to one of the LAN

Ports.

Step3 Connect the external power supply to the ADSL Wireless Router. Step4 The Reset button is used to reboot and re-initialize the device (press once quickly), or

for clearing configuration settings back to factory default values (press for longer than 3 seconds).

& Note:

If you are Macintosh users, please refer to Chapter 6 Macintosh Setup for more

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 2 Hardware Installation & Setup

detailed information about configuring TCP/IP, hardware installation and so on.

2.2 Front Panel LEDs

The following figure shows the front view of the ADSL Wireless Router. The LEDs on the front panel indicate the status of the unit. You can easily view the operation of your High-Performance Wireless Router from this panel.

& Note:

Please refer to the model on your hand to find proper description.

The LEDs on the front panel indicate the status of the unit. You can easily view the operation of your ADSL Wireless Router from this panel.

LED Status Description

Power

Power has been switched on and is working normally

OFF Power is switched off or fails.

Diag - For factory test only

ON ADSL loop is brought UP.

Link

Blinking Startup. OFF ADSL loop is down.

Blinking

Act

Data is being transmitted or received through

ADSL. OFF No data transmission activities present on the link. ON Wireless connection established

Wireless

OFF Wireless function disabled ON USB connection established

USB

OFF No USB cable connected

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 2 Hardware Installation & Setup

LED Status Description

ON Ethernet link is up.

LAN0/1/2/3

2.3 POTS Splitter

If your ISP offers ADSL services and POTS (plain old telephone service) in the same telephone line, you can connect and use ADSL and ordinary phone services at the same time by using a POTS Splitter. The following figure shows how to connect a POTS Splitter into your ADSL connection. (A POTS splitter is likely to be provided by your ISP)

Blinking

Ethernet interface is transmitting or receiving

data. OFF No link is up.

12x6x8x2x9x3x10x4x11x5x7x

789101112

Ethernet

123456

2.4 System Requirements and Setup

To connect to the Internet, an external ADSL or Cable modem and an Internet access account from an ISP is required. In order to operate with the ADSL Wireless Router, each PC that is to be connected to the ADSL Wireless Router should have the following things installed:

Ethernet NIC (Network Interface Card: a 10Base-T or 10/100Base-T/TX Ethernet card), or wireless client card for wireless connection.

Standard twisted-pair Ethernet cable (UTP network cable) with RJ-45 connectors. Or the USB cable.

System OS: Windows 95/98, Windows NT4.0, Windows 2000/XP, or other OS with web browser installed.

TCP/IP network protocol.

Web browser, such as Microsoft Internet Explorer 5.0 or later, or Netscape Navigator 6.0 or later.

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 2 Hardware Installation & Setup

2.4.1 Installing the TCP/IP Protocol

If you are not sure whether the TCP/IP Protocol has been installed, follow these steps to check, and if necessary, install TCP/IP onto your PCs.

Step1 Click the “Start” button. Choose “Settings”, then “Control Panel”. Double-click the

“Network” icon. Your Network window should appear as follows:

Step2 Select the “Configuration” tab.

& Important Note:

Settings for Windows 2000/XP and Windows 98/ME/NT might differ slightly. See the following for reference.

Click the “Local Area Connection” icon on the lower right hand side of your desktop screen.

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 2 Hardware Installation & Setup

In the “Local Area Connection Status” window, click the “Properties” button then your Network window will appear.

Step3 Check whether the TCP/IP Protocol has already been installed onto your computer’s

Ethernet card. Note that TCP/IP Protocol can be installed for a computer’s Dial-Up Adapter as well as for the Ethernet card.

− If yes, go to step 7.

− If no, click the “Add” button.

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 2 Hardware Installation & Setup

Step4 Double-click “Protocol” in the Select Network Component Type or highlight

“Protocol” then click “Add”.

Step5 Highlight “Microsoft” under the list of manufacturers. Double-click “TCP/IP” from

the list on the right or highlight “TCP/IP” then click “OK” to install TCP/IP.

Step6 After a few seconds, you will be returned to the Network window. The TCP/IP Protocol

should now be on the list of installed network components (see 3 above).

Aolynk WDR814(I)g ADSL2+ Wireless Router User Manual 2 Hardware Installation & Setup

Step7 Click the “Properties” button. The TCP/IP Properties window consists of several tabs.

Choose the “IP Address” tab.

Step8 Select “Obtain an IP address automatically”. Click “OK”. Restart your PC to

complete the TCP/IP installation.

2.4.2 Fixed IP Addresses Configuration

Fixed IP addresses may be assigned to network devices for many reasons, such as the server PCs or printers which are consistently accessed by multiple users. To set up computers with fixed IP Addresses, go to the “IP Address” tab of the “TCP/IP Properties” window as shown above.

Step1 Select “Specify an IP address” and enter “192.168.1.xxx” in the “IP Address ”

location (where xxx is a number between 2 and 254 used by the High-Performance Wireless Router to identify each computer), and the default “Subnet Mask”

255.255.255.0”. Note that no two computers on the same LAN can have the same IP address.

+ 44 hidden pages
