Huawei G2201 User Manual
G2201
GSM Mobile Phone
User Guide
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129,
People's Republic of China
Tel: +86-755-28780808 Global Hotline: +86-755-28560808
E-mail: mobile@huawei.com Website: www.huawei.com
Copyright © Huawei Technologies Co., Ltd. 20 09.
All rights reserved.
No part of this document may be reproduced or
transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
The product described in this manual may include
copyrighted software of Huawei Technologies Co., Ltd
and possible licensors. Customers shall not in any
manner reproduce, distribute, modify, decompile,
disassemble, decrypt, extract, reverse engineer, lease,
assign, or sublicense the said software, unless such
restrictions are prohibited by applicable laws or such
actions are approved by respective copyright holders
under licenses.
Trademarks and Permissions
, HUAWEI, and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, products, services, and company
names mentioned are the property of their respective
owners.
Notice
Some features of the product and its accessories
described herein rely on the software installed,
capacities and settings of local network, and may not be
activated or may be limited by local network operators
or network service providers. Thus the descriptions
herein may not exactly match the product or its
accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to
change or modify any information or specifications
contained in this manual without prior notice or
obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS
IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO.,
LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL,
INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST
PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR
ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or
import laws and regulations and will obtain all necessary
governmental permits and licenses in order to export,
re-export or import the product mentioned in this
manual including the software and technical data
therein.
Table of Contents
SIM Card ...................................................... 1
Charging the Battery ...................................... 1
Your Phone....................................................2
Keys and Functions ........................................ 3
Screen Icons ................................................. 5
Using the Function Menu.................................6
Phone Lock ................................................... 6
PIN and PUK.................................................. 7
Locking the Keypad........................................7
Making a Call................................................. 7
Answering a Call............................................ 8
Text Input Modes ........................................... 9
Writing and Sending a Message ..................... 11
Creating a Contact ....................................... 11
FM Radio..................................................... 12
Warnings and Precautions ............................. 13
SIM Card
Insert your SIM card before using your phone. Remove
the SIM card and the battery only after powering off
your phone.
The following figures show the installation of the SIM
card.
1. Remove the battery cover.
2. Insert the SIM card.
3. Insert the battery.
Charging the Battery
1. Connect the charger to an AC power socket.
2. Connect the charger to the charger jack on the
phone.
3. Wait until the battery is completely charged.
During the charging, the charging icon is displaying in
animation. When the charging icon becomes static,
the battery is fully charged.
1
4. Disconnect the charger from the phone.
5. Disconnect the charger from the AC power socket.
Your Phone
The following figure shows the appearance of your
phone and it is for your reference only.
1 Earpiece 8
2 Screen 9
3 Navigation keys 10 Right soft key
4 Left soft key 11 Confirm key
# key
End/Power key
2
5 Call/Answer key 12
6 Number keys 13
Charger jack
Headset jack
7 * key
Keys and Functions
In this manual, the navigation keys of your phone are
indicated by the follow icons: , , , ,
and .
Press… To…
z
Make a call.
z
Answer an incoming call.
z
View dialed calls in standby mode.
z
Power on or off the phone (by pressing and
holding the key for about 5s).
z
End a call, or reject an incoming call.
z
Return to the standby mode.
z
Display Menu in standby mode.
z
Select the highlighted item.
z
Display Contacts in standby mode.
z
Return to the previous menu.
3
Press… To…
z
Access: Profiles ( ), Messages
(
), Create Message ( ), and
Alarm Clock (
z
During a call, increase the volume ( )
) in standby mode.
or decrease the volume (
z
Display Menu in standby mode.
z
Confirm a selection.
z
Enter numbers, letters, and characters.
z
Call the voice mail center in standby mode
(by pressing and holding the 1 key for
about 3s).
–
z
Speed-dial phone numbers in standby
mode (by pressing and holding the 2–9
keys for about 3s).
z
In standby mode, press the key once to
enter *.
z
Enable or disable the Silent profile in
standby mode (by pressing and holding the
key for about 3s).
z
Display the symbol list in any input mode.
4
).
