Welcome to use HUAWEI WiMAX USB Stick!
Online Help
Issue 02
Date 2009-11-15
Part Number 00557491
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: terminal@huawei.com
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
Copyright © Huawei Technologies Co., Ltd. 2009. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means
without prior written consent of Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted software of Huawei
Technologies Co., Ltd and possible licensors. Customers shall not in any manner
reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer,
lease, assign, or sublicense the said software, unless such restrictions are prohibited by
applicable laws or such actions are approved by respective copyright holders under
licenses.
Trademarks and Permissions
, , and
Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are the property of
their respective owners.
are trademarks or registered trademarks of Huawei
Notice
Some features of the product and its accessories described herein rely on the software
installed, capacities and settings of local network, and may not be activated or may be
limited by local network operators or network service providers, thus the descriptions
herein may not exactly match the product or its accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify any information or
specifications contained in this ma nual w ithou t prio r notice or obl igation .
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS". EXCEPT AS
REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE
SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,
BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and regulations and will
obtain all necessary governmental permits and licenses in order to export, re-export or
import the product mentioned in this manual including the software and technical data
therein.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
Warnings and Precautions
To use the device properly and safely, read these warnings and precautions carefully
and strictly observe them during operation.
Basic Requirements
z During storage, transportation, and operation of the device, keep it dry and prevent
it from colliding with other objects.
z Do not dismantle the device. In case of any fault, contact an authorized service
center for assistance or repair.
z Without authorization, no organization or individual can change the mechanical,
safety, or performance design of the device.
z When using the device, observe all applicable laws and regulations and respect the
legal rights of other people.
Environmental Requirements for Using the Device
z Before connecting and disconnecting cables, stop using the device, and then
disconnect it from the power supply. Ensure that your hands are dry during
operation.
z Keep the device far from sources of heat and fire, such as a heater or a candle.
z Keep the device far from electronic appliances that generate strong magnetic or
electric fields, such as a microwave oven or a refrigerator.
z Place the device on a stable surface.
z Place the device in a cool and well-ventilated indoor area. Do not expose the device
to direct sunlight. Use the device in an area with a temperature ranging from 0°C to
40°C.
z During thunderstorms, power off the device, and then remove all the cables
connected to it to prevent it from getting damaged due to lightning strikes.
Precautions for Using Wireless Devices
z Do not use the device where using wireless devices is prohibited or may cause
interference or danger.
z The radio waves generated by the device may interfere with the operation of
electronic medical devices. If you are using any electrical medical device, contact
its manufacturer for the restrictions on the use of the device.
z Do not take the device into operating rooms, intensive care units (ICUs), or
coronary care units (CCUs).
Areas with Inflammables and Explosives
z Do not use the device where inflammables or explosives are stored, for example, in
a gas station, oil depot, or chemical plant. Otherwise, explosions or fires may occur.
In addition, follow the instructions indicated in text or symbols.
z Do not store or transport the device in the same box as inflammable liquids, gases,
or explosives.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
Accessory Requirements
Use only the accessories supplied or authorized by the device manufacturer. Otherwise,
the performance of the device may get affected, the warranty for the device or the laws
and regulations related to telecommunications terminals may become null and void, or
an injury may occur.
Safety of Children
Keep the device and its accessories out of the reach of children. Otherwise, they may
damage the device and its accessories by mistake, or they may swallow the small
components of the device, causing suffocation or other dangerous situations.
Maintenance
z If the device is not used for a long time, power it off, and then remove all the cables
connected to it.
z If any exception occurs, for example, if the device emits any smoke or unusual
sound or smell, stop using the device immediately, power it off, remove all the
cables connected to it, and then contact an authorized service center.
z Do not trample, pull, or overbend any cable. Otherwise, the cable may get damaged,
causing malfunction of the device.
z Before cleaning the device, stop using it, power it off, and then remove all the
cables connected to it.
z Use a clean, soft, and dry cloth to clean the device shell. Do not use any cleaning
agent or spray to clean the device shell.
Traffic Security
z Observe local laws and regulations while using the device. To prevent accidents, do
not use your wireless device while driving.
z RF signals may affect electronic systems of motor vehicles. For more information,
consult the vehicle manufacturer.
z In a motor vehicle, do not place the device over the air bag or in the air bag
deployment area. Otherwise, the device may hurt you owing to the strong force
when the air bag inflates.
Disposal and Recycling Information
This symbol on the device (and any included batteries) indicates that the device
(and any included batteries) should not be disposed of as normal household
garbage. Do not dispose of your device or batteries as unsorted municipal waste.
The device (and any batteries) should be handed over to a certified collection
point for recycling or proper disposal at the end of its life.
z For more detailed information about the recycling of the device or batteries, contact
your local city office, the household waste disposal service, or the retail store
where you purchased this device.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
z The disposal of this device is subject to the Waste from Electrical and Electronic
Equipment (WEEE) Directive of the European Union. The purpose for separating
WEEE and batteries from other waste is to minimize any environmental impact and
health hazard due to the presence of hazardous substances.
Reduction of Hazardous Substances
This device is compliant with the EU Registration, Evaluation, Authorisation and
Restriction of Chemicals (REACH) Regulation (Regulation No 1907/2006/EC of the
European Parliament and of the Council) and the EU Restriction of Hazardous
Substances (RoHS) Directive (Directive 2002/95/EC of the European Parliament and
of the Council). For more information about the REACH compliance of the device,
visit the Web site www.huaweidevice.com/certification. You are recommended to visit
the Web site regularly for up-to-date information.
EU Regulatory Conformance
z Български: С настоящето Huawei Technologies Co., Ltd. декларира, че този
уред съответства на основните изисквания и другите разпоредби на
Директива 1999/5/EC.
z Česky: Huawei Technologies Co., Ltd., tímto prohlašuje, že toto zařízení je ve
shodě se základními požadavky a dalšími souvisejícími opatřeními směrnice
1999/5/EC.
z Dansk: Huawei Technologies Co., Ltd. erklærer hermed at denne enhed er i
overensstemmelse med de obligatoriske krav og andre relevante bestemmelser i
direktiv 1999/5/EF.
z Nederlands: Hierbij verklaart Huawei Technologies Co., Ltd. dat dit apparaat in
overeenstemming is met de essentiële eisen en de andere relevante bepalingen van
richtlijn 1999/5/EC.
z English: Hereby, Huawei Technologies Co., Ltd. declares that this device is in
compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
z Eesti: Käesolevaga kinnitab Huawei Technologies Co., Ltd., et see seade vastab
Direktiivi 1999/5/EÜ põhinõudmistele ja teistele asjakohastele määrustele.
z Suomi: Huawei Technologies Co., Ltd. vakuuttaa täten, että tämä laite on
yhdenmukainen direktiivin 1999/5/EY olennaisten vaatimusten ja direktiivin
muiden asiaankuuluvien lausumien kanssa.
z Français (Européen) : Le fabricant déclare que ce produit est conforme aux
exigences essentielles et aux autres dispositions pertinentes de la directive
1999/5/CE.
z Deutsch: Huawei Technologies Co., Ltd. erklärt hiermit, dass dieses Produkt die
erforderlichen Bestimmungen und andere relevante Verordnungen der Richtlinie
1999/5/EG einhält.
z Ελληνικά: Δια της παρούσης η Huawei Technologies Co., Ltd. δηλώνει ότι αυτή η
συσκευή συμμορφώνεται με τις βασικές απαιτήσεις και άλλες σχετικές διατάξεις
της οδηγίας 1999/5/Ε.Κ.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
z Magyar: Jelen nyilatkozaton keresztül a Huawei Technologies Co., Ltd. kijelenti,
hogy a készülék megfelel az EC/5/1999 Irányelv összes lényeges követelményének
és vonatkozó előírásának.
z Gaeilge: Fograíonn Huawei Technologies Co., Ltd leis seo go bhfuil an fheiste seo
i gcomhlíonadh leis na fíor-riachtanais agus na forálacha eile maidir le Treoir
1999/5/AE.
z Italiano: Col presente documento, Huawei Technologies Co., Ltd. dichiara che
questo dispositivo è conforme ai requisiti essenziali e alle altre disposizioni
applicabili della Direttiva 1999/5/CE.
z Latviski: Ar šo Huawei Technologies Co., Ltd. paziņo, ka šī ierīce atbilst
Direktīvas 1999/5/EC pamatprasībām un piemērojamajiem nosacījumiem.
z Lietuviškai: Šiuo Huawei Technologies Co., Ltd. praneša, kad šis įtaisas atitinka
Direktyvos 1999/5/EC pagrindinius reikalavimus ir taikomas sąlygas.
z Malti: Hawnhekk, Huawei Technologies Co., Ltd. tiddikjara li dan it-tagħmir hu
konformi mal-ħtiġijiet essenzjali u provvedimenti rilevanti oħrajn ta’ Direttiva
1999/5/KE.
z Polski: Wymieniona w tym dokumencie firma Huawei Technologies Co., Ltd.
deklaruje, że niniejsze urządzenie spełnia zasadnicze wymagania w zakresie
zgodności oraz inne odnośne postanowienia Dyrektywy 1999/5/EC.
z Português (Europeu) : Deste modo, a Huawei Technologies Co., Ltd. declara que
este dispositivo está em conformidade com os requisitos essenciais e outras
provisões relevantes da Directiva 1999/5/CE.
z Română: Prin prezenta Huawei Technologies Co., Ltd. declară că acest dispozitiv
este conform cu cerinţele esenţiale şi alte prevederi relevante ale directivei
1999/5/CE.
z Slovenčina: Huawei Technologies Co., Ltd. týmto vyhlasuje, že zariadenie je v
súlade so základnými požiadavkami a inými relevantnými predpismi Smernice
1999/5/ES.
z Slovenščina: Huawei Technologies Co., Ltd. izjavlja, da je ta naprava v skladu z
bistvenimi zahtevami in drugimi ustreznimi določbami Direktive 1999/5/ES.
z Español (Europeo) : Con el presente documento, Huawei Technologies Co., Ltd.
declara que este dispositivo cumple con los requisitos esenciales y con las demás
disposiciones correspondientes de la Directiva 1999/5/CE.
z Svenska: Huawei Technologies Co., Ltd. förklarar härmed att denna produkt
överensstämmer med de grundläggande kraven och andra relevanta föreskrifter i
direktiv 1999/5/EG.
z For the declaration of conformity, visit the Web site
www.huaweidevice.com/certification.
z Notice: Observe the national local regulations in the location where the device is to
be used. This device may be restricted for use in some or all countries of European
Union.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
Certification Information (SAR)
z Your wireless device is a radio transmitter and receiver. It is designed not to exceed
the limits for exposure to radio waves recommended by international guidelines.
These guidelines are developed by the independent scientific organization
International Commission on Non-Ionizing Radiation Protection (ICNIRP) and
include safety margins designed to assure the protection of all persons, regardless
of age and health.
z The guidelines use a unit of measurement known as the Specific Absorption Rate,
or SAR. The SAR limit for wireless devices is 2.0 watts/kilogram (W/kg) and the
highest SAR value for this device when tested complies with this limit.
Body Worn Operation
Important safety information regarding radiofrequency (RF) radiation exposure is as
follows:
z To ensure compliance with RF exposure guidelines, the device must be used with a
minimum of 2.5cm distance from the body.
z Failure to observe these instructions could result in your RF exposure exceeding
the relevant guideline limits.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
Online Help Contents
Contents
1 Getting to Know Your USB Stick ......................................................................1-1
1.1 Functions and Features................................................................................................ 1-1
1.2 Requirements on PC Configuration.............................................................................1-1
2 Installation Guide.................................................................................................2-1
2.1 Connecting the USB Stick...........................................................................................2-1
2.2 Installing the Management Program............................................................................2-1
2.3 Uninstalling the Management Program....................................................................... 2-1
2.4 Removing the USB Stick ............................................................................................2-2
3 Common Operations............................................................................................3-1
3.1 Connecting and Disconnecting Network.....................................................................3-1
3.2 Switching the Management Program Language.......................................................... 3-1
3.3 Restoring Default Settings...........................................................................................3-1
3.4 Upgrading the USB Stick............................................................................................ 3-2
3.5 Switching the Management Program User.................................................................. 3-2
4 Viewing Information about the USB Stick......................................................4-1
5 Troubleshooting....................................................................................................5-1
6 Acronyms and Abbreviations.............................................................................6-1
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
i
Online Help 1 Getting to Know Your USB Stick
1 Getting to Know Your USB Stick
1.1 Functions and Features
HUAWEI WiMAX USB Stick (hereinafter referred to as the USB Stick) is applicable to
the Worldwide Interoperability for Microwave Access (WiMAX) network. In areas
covered by the network, you can enjoy the high-performance broadband network
services anywhere and anytime. You can wirelessly surf the Internet with brand new
experiences.
High Speed
z
Supporting the IEEE802.16e-2005 WiMAX air interface.
z
Supporting downlink transmission rate of up to 15Mbit/s and uplink transmission
rate of up to 5Mbit/s.
Portable and Fashionable Design
z
Providing a user-friendly graphical user interface (GUI).
z
Supporting plug and play.
z
Featuring a fashionable and elegant appearance.
1.2 Requirements on PC Configuration
Your PC must meet the following configuration re quirements for using the USB S tick. If
the configuration of your PC cannot meet the requirements, the p erformance of th e USB
Stick may be degraded.
Item Configuration
Memory 128 MB RAM or above
Free hard disk
space
OS
USB interface USB 2.0 full speed
Display
resolution
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
50 MB or above
z
Windows XP (with Service Pack 2 or a patch of a later version)
z
Windows Vista
800 × 600 or above (1024 × 768 is recommended.)
Copyright © Huawei T echnologies Co., Ltd
1-1
Online Help 1 Getting to Know Your USB Stick
Item Configuration
Note:
OS = operating system
RAM = random access memory
Log in to the OS as a user or an administrator to use this application. Using this application as
a guest may lead to a malfunction of the USB Stick.
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
1-2
Online Help 2 Installation Guide
2 Installation Guide
The procedure for installing the management program depends on the OS installed on
your PC. The following section takes Windows XP as an example.
2.1 Connecting the USB Stick
z Ensure that the PC is powered on when you connect the USB Stick to the PC.
Otherwise, the USB Stick cannot be used.
z During lightning storms, disconnect the USB Stick from the computer.
To connect the USB Stick to the PC, do as follows:
Step 1
Step 2
Power on the PC.
Connect the USB Stick to the PC.
----End
2.2 Installing the Management Program
The management program is the program used to configure the USB Stick parameters.
Step 1
Step 2
Step 3
Step 4
Step 5
Power on the PC.
Connect the USB Stick to the PC.
The OS prompts finding new hardware and prompts you to install the management
program.
Install the management program according to the prompts.
After the program is installed, the shortcut icon of the manag ement program is displayed
on the desktop.
----End
2.3 Uninstalling the Management Program
Step 1
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Quit the management program.
Copyright © Huawei T echnologies Co., Ltd
2-1
Online Help 2 Installation Guide
Step 2
Step 3
Step 4
Step 5
Step 6
Choose
Click
Find the management program.
Click
Uninstall the management program according to the prompts.
Start
>
Control Panel
>
Change/Remove Programs
Change/Remove
.
Add/Remove Programs
.
.
----End
It is recommended to restart the PC after the uninstallation to ensure that the management
program is completely uninstalled.
2.4 Removing the USB Stick
z
If is not displayed on the system tray, perform the following steps:
Step 1
Step 2
Step 1
Step 2
Step 3
Quit the management program.
Disconnect the USB Stick from the PC.
----End
z
If is displayed on the system tray, perform the following steps:
Double-click
Stop running the corresponding hardware of the USB Stick on the device manager.
Disconnect the USB Stick from the PC after the OS prompts that you can remove the
on the system tray. The system prompts "Safely remove hardware."
hardware safely.
----End
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
2-2
Online Help 3 Common Operations
3 Common Operations
3.1 Connecting and Disconnecting Network
Connecting to a Network
To connect the USB Stick to a WiMAX network, do as follows:
Step 1
Step 2
Step 3
Disconnecting from a Network
Step 1
Step 2
Start the management program and click
Enter the user name and password provided by the Internet service provider (ISP), and
save the user account.
Click
Connect
Then the USB Stick tries to connect to the network automatically. When the connection
is established, the icons indicating a successful network connection and the signal
strength are displayed at the bottom of the management program window.
----End
When you do not use the Internet, you can disconnect the USB Stick from the network
manually. After you disconnect the network connection, you need to connect the USB
Stick to the network again before accessing the Internet.
Start the management program and click
Click
Disconnect
----End
.
.
Connection
Connection
.
.
3.2 Switching the Management Program Language
The USB Stick facilitates your choice and operation by providing multiple GUI
languages.
When the management program is running, choose Tools > Language to select a proper
GUI language.
3.3 Restoring Default Settings
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
3-1
Online Help 3 Common Operations
After you restore default settings, you need to reset the parameters of the USB Stick.
Therefore, restore the default settings with caution.
To restore default settings, do as follows:
Step 1
Step 2
Start the management program and click
Click
to restore the USB Stick to default settings.
Restore
Device
.
----End
3.4 Upgrading the USB Stick
z When upgrading the USB Stick, do not disconnect and reconnect the USB Stick and
ensure the uninterrupted power supply to the device.
z You need to restart the USB Stick after the upgrade is complete. Wait patiently for a
while.
To perform the upgrade, do as follows:
Step 1
Step 2
Step 3
Start the management program. Then click
Click
Click
to choose the upgrade file on the computer.
Browse
Upgrade
to start the upgrade.
Device
The upgrade progress is displayed in the progress bar.
.
The Current Version number indicates the software version number before the upgrade and
the Upgrade Version number indicates the software version number after the upgrade.
----End
3.5 Switching the Management Program User
When you use the advanced functions for management program, you need log in as
administrator. You can click Tools, and click Expert Login/Logout to login. It is only
used for the professionals.
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
3-2
Online Help 4 Viewing I nformation about the USB Stick
4 Viewing Information about the USB Stick
The device information includes the S/N, MAC address, the version information of the
USB Stick, and throughput information.
Start the management program and click Device to view the network information.
Click IP Detail to view the detail information inc ludes the frequ ency, the bandwidth, the
IP address, default gateway, subnet mask, Dynamic Host Configuration Protocol ( DHCP)
server address, and Domain Name Server (DNS) address.
Click Check to view the detail information of the USB Stick.
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
4-1
Online Help 5 Troubleshooting
5 Troubleshooting
When the USB Stick is connected to the PC for the first time, the system
does not prompt you to install the management program.
z
After the system recognizes the new hardware, you need to wait a few minutes for
the system to prepare the installation of the program.
z
Ensure that the USB Stick is connected to th e PC correc tly and is displayed on
the system tray. Otherwise, unplug the USB Stick and connect it to the PC again.
z
Check whether the disk icon is displayed in the My Computer window.
1. If yes, double-click the icon.
2. If no, remove the USB Stick from the PC and restart the PC. Then connect the
USB Stick to the PC again.
z
Log in to the website designated by the ISP to download the installation program,
and then install the program.
z
Ensure that the auto play function of the OS is enabled.
The management program cannot start automatically after the installation.
z
Check whether the shortcut icon of the management program is displayed on the
desktop or in the notification area. If yes, double-click the icon to start the
management program.
z
Ensure that the USB Stick is correctly connected to the PC, do as follows:
1. Uninstall the management program.
2. Remove the USB Stick from the PC after uninstallation, and then connect the
USB Stick to the PC again.
3. Install the management program again according to the prompts.
z
Remove the USB Stick safely and restart the PC. Then connect the USB Stick to
the PC again.
z
Ensure that the auto-play function of the OS is enabled.
The USB Stick cannot access the Internet.
z
Ensure that you are in the service area.
z
Ensure that the USB Stick is connected to the PC correctly and the management
program is correctly installed.
z
Ensure that you have subscribed the Internet access service. Contact your local ISP
for how to subscribe the service.
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
5-1
Online Help 5 Troubleshooting
When you power on the PC after the USB Stick is connected, the Wi ndo ws
OS hangs.
z
Check the settings of devices such as the USB interface and the ne twork adapter in
the Basic Input/Output System (BIOS) of the PC. It is recommended that you
enable devices such as the USB interface and the network adapter.
z
Remove the USB Stick safely and restart the PC. Then connect the USB Stick to
the PC again.
The indicator is off.
Ensure that the USB Stick is connected to the PC correctly and the management
program is correctly installed.
The network signals cannot be searched out.
z
Ensure that the network signals are not blocked by any obstacles around the USB
Stick.
z
Ensure that the network frequency is set properly.
The system prompts that the software is damaged.
The USB Stick can repair the software automatically. When the software is damaged,
the system prompts you to repair the software. You can repair th e software according
to the on-screen instructions.
Contact your local ISP if the automatic repair of the software fails.
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
5-2
Online Help 6 Acronyms and Abbreviations
6 Acronyms and Abbreviations
DHCP
DNS
ISP
GUI
OS
RAM
URL
WiMAX
Dynamic Host Configuration Protocol
Domain Name Server
Internet service provider
Graphical User Interface
Operating System
Random Access Memory
Universal Resource Locator
Worldwide Interoperability for Microwave Access
Issue 02 (2009-11-15) Huawei Proprietary and Confidential
Copyright © Huawei T echnologies Co., Ltd
6-1
Loading...
