HTC PG59100 Users Manual
User guide
HTC Confidential
2 Contents
HTC Confidential
Contents
Getting started 8
Inside the box 8
Your phone 8
Back cover 10
SIM card 11
Storage card 12
Battery 13
Switching your phone on or off 15
Entering your PIN 15
Finger gestures 15
Setting up your phone for the first time 16
Ways of getting contacts into your phone 16
Home screen 17
Basics 18
Adjusting the volume 18
Sleep mode 19
Status and notifications 20
Notifications panel 22
Connecting your phone to a computer 24
Copying files to or from the storage card 24
Copying text, looking up information, and sharing 25
Personalizing 27
Making your phone truly yours 27
Personalizing your phone with scenes 27
Changing your wallpaper 28
Applying a new skin 29
Personalizing your Home screen with widgets 29
Adding icons and other shortcuts on your Home screen 31
Adding folders on your Home screen 31
Rearranging or removing widgets and icons on your Home screen 32
Rearranging the Home screen 32
Using sound sets 33
Changing your ringtones and alarms 34
Rearranging or hiding application tabs 35
Phone calls 36
Different ways of making calls 36
Making a call on the Phone dialer screen 36
Using Speed dial 37
Calling a phone number in a text message 37
Calling a phone number in an email 38
Making an emergency call 38
Receiving calls 39
What can I do during a call? 40
Setting up a conference call 42
Internet calls 42
3 Contents
HTC Confidential
Using Call history 43
Using Home dialing 44
Call services 45
Turning Airplane mode on or off 46
Messages 47
Opening Messages 47
Sending a text message (SMS) 47
Sending a multimedia message (MMS) 48
Resuming a draft message 50
Viewing and replying to a message 50
Viewing and saving an attachment from a multimedia message 51
Push messages 52
Managing message conversations 52
Setting message options 54
People 55
Transferring contacts from your old phone 55
About the People app 56
Setting up your profile 57
Importing contacts from your SIM card 58
Adding a new contact 58
Importing a contact from an Exchange ActiveSync account 58
Merging contact information 59
Filtering your contacts list 60
Backing up your contacts to the storage card 61
Contact information and conversations 61
Sending contact information as a vCard 62
Contact groups 63
Adding People widgets 65
Email 67
Gmail 67
Mail 69
Calendar 75
About Calendar 75
Creating an event 75
Changing Calendar views 77
Managing Calendar events 78
Dismissing or snoozing event reminders 79
Displaying and synchronizing reminders 80
Changing Calendar settings 81
About the Calendar widget 81
Search and Web browser 82
Searching your phone and the web 82
Using your phone’s web browser 83
Downloading from the Web 86
Viewing bookmarks and previously visited pages 86
Setting browser options 88
4 Contents
HTC Confidential
Camera 89
Camera basics 89
Taking a photo 90
Recording video 91
Adding effects 92
After capturing 92
Changing camera settings 93
Photos, videos, and music 94
Gallery 94
Music 101
Connected Media 107
Accounts and sync 109
About online accounts 109
Synchronizing with a Google Account 109
Adding a social network account 110
Managing your online accounts 110
Social 112
Facebook for HTC Sense 112
Facebook app 113
Tweeting on your phone using Peep 114
Using Friend Stream 116
Chatting in Google Talk 119
Maps and location 121
Location settings 121
Locations 121
Google Maps 130
Market and other apps 133
Finding and installing apps from Android Market 133
Using the Clock 135
Checking Weather 137
Reading eBooks 139
Reading news feeds 141
Keeping track of your stocks 143
Working on documents, spreadsheets, and presentations 144
Watching videos on YouTube 145
Listening to FM Radio 146
Recording your voice 147
Using Flashlight 148
Sharing games and apps 148
HTC Sync 149
About HTC Sync 149
Installing HTC Sync that came with the storage card 150
Setting up HTC Sync to recognize your phone 150
Getting to know the workspace 151
Setting up synchronization 151
5 Contents
HTC Confidential
Synchronizing your phone 154
Installing an app from your computer to your phone 154
Synchronizing another phone with your computer 155
Downloading the latest HTC Sync upgrade 155
HTCSense.com 156
Signing up for your HTCSense.com account 156
Using HTCSense.com 156
Deleting your HTCSense.com account 158
Keyboard 159
Using the onscreen keyboard 159
Entering words with predictive text 160
Entering text by speaking 162
Editing text 163
Adjusting input settings 164
Internet connections 165
Data connection 165
Wi-Fi 166
About connection widgets 168
Connecting to a virtual private network (VPN) 168
Using your phone as a modem (USB tethering) 169
Connecting your phone to the Internet through a computer (Internet Pass-through) 170
Using your phone as a wireless router 170
Bluetooth 171
Bluetooth basics 171
Connecting a Bluetooth headset or car kit 171
Disconnecting or unpairing from a Bluetooth device 172
Sending information using Bluetooth 173
Receiving information using Bluetooth 174
Security 176
Protecting your SIM card with a PIN 176
Protecting your phone with a screen lock pattern, PIN or password 177
Settings 178
Settings on your phone 178
Changing display settings 179
Changing sound settings 181
Changing the phone language 182
Optimizing your phone’s battery life 182
Managing memory 183
Checking information about your phone 184
Update and reset 185
Phone software updates 185
Restarting your phone 186
Resetting your phone 186
6 Contents
HTC Confidential
Trademarks and copyrights 187
Index 188
7 Conventions used in this guide
HTC Confidential
Conventions used in this guide
In this user guide, we use the following symbols to indicate useful and important
information:
This is a note. A note often gives additional information, such as what happens on your phone
when you choose to do or not to do a certain action. A note also provides information that
may only be applicable to some situations.
This is a tip. A tip gives you an alternative way to do a particular step or procedure, or lets you
know of an option that you may find helpful.
This indicates important information that you need in order to accomplish a certain task or to
get a phone feature to work properly.
This provides safety precaution information, that is, information that you need to be careful
about to prevent potential problems when using your phone.
8 Getting started Getting started
HTC Confidential
Getting started
Inside the box
You will find the following inside the box:
Phone
Battery (preinstalled)
microSD™ card (preinstalled)
USB cable
3.5mm stereo headset
Power adapter
Quick start guide
Safety and regulatory guide
Call center card (hotline card)
Warranty card
Your phone
Front panel
1
2
8
7
1 Earpiece
Touch screen
2 Touch screen
3 HOME
4 MENU
5 BACK
6 SEARCH
7 Notification LED
8 Front camera
9 Camera
3
4
6
5
9 Getting started
HTC Confidential
Left panel
1 VOLUME UP
2 VOLUME DOWN
Back panel
4
1
2
3
3 USB connector
2
1 Speaker
2 8 megapixel camera
3
3
3 LED flash
4 Microphone
1
Top panel
2
1
1 3.5mm headset jack
2 POWER
10 Getting started
HTC Confidential
Back cover
Removing the back cover
Remove the back cover to access the battery, SIM card slot, and storage card slot.
With the phone turned off, hold your phone securely with the front facing down.
1.
With your thumb, pull the back cover out to remove it.
2.
Replacing the back cover
Align the two teeth underneath the back cover (one on each side) with the two
1.
notches on the bottom of the phone.
2. Place the back cover on the phone, gently press down on the cover with your
thumbs, and then push it in until it clicks and locks into place.
Your phone’s antenna is placed underneath the back cover. We recommend that you make
sure the back cover is correctly secured to the phone’s back panel to get the best radio
reception for your phone.
11 Getting started
HTC Confidential
SIM card
The SIM card contains your phone number, service details, and phonebook/message
memory. Your phone supports both 1.8V and 3V SIM cards.
Some legacy SIM cards may not function with your phone. You should consult with your
mobile operator for a replacement SIM card. There may be fees for this service.
Inserting the SIM card
Take the back cover off.
1.
2. Remove the battery.
3. With the SIM card’s gold contacts facing down and its cut-off corner facing out,
insert the SIM card into the SIM card slot.
Removing the SIM card
Make sure to switch off your phone before removing your SIM card.
1. Take the back cover off.
2. Remove the battery.
3. With your thumb, slide the SIM card out from the SIM card slot.
12 Getting started
HTC Confidential
Storage card
Use the storage card to store your photos, videos, and music. You’ll find the storage
card already inserted in your phone.
Inserting the storage card
1. Take the back cover off.
2. Open the battery compartment door.
3. Insert the storage card into the storage card slot with its gold contacts facing
down and push it until it clicks into place.
Removing the storage card
If your phone is on you must first “unmount” the storage card before removing it to prevent
corrupting or damaging the files in the storage card.
1. Take the back cover off.
2. Push the storage card in to eject it from its slot.
3. Slide the storage card out from its slot.
Unmounting the storage card
If you want to format your storage card, you need to unmount it first.
From the Home screen, press , and then tap Settings.
1.
Scroll down the screen, and then tap SD & phone storage.
2.
Tap Unmount SD card.
3.
13 Getting started
HTC Confidential
Battery
Your phone uses a rechargeable battery. Please use only original batteries and
accessories that came with your phone or replacements that we recommend.
How long the battery can last before it needs recharging depends on how you
use your phone. Among these are the phone features and accessories you use
(for example, leaving your Bluetooth™ connection always on uses more power).
Long phone calls and frequent web browsing uses up a lot of battery power. Also,
consider your location: poor signal strength from your mobile network and extreme
temperature make the battery work harder.
Removing the battery
1. Take the back cover off.
2. Pull the battery out.
Inserting the battery
1. Take the back cover off.
2. Insert the battery (with its exposed copper contacts first) into the battery
compartment.
14 Getting started
HTC Confidential
Charging the battery
The battery is partially charged when shipped. Before you turn on and start using your
phone, it is recommended that you charge the battery. Some batteries perform best
after several full charge/discharge cycles.
When the phone is shipped, the battery is already installed on your phone. A thin film is
inserted between the battery and the compartment. You need to remove this film before
you can charge the battery.
Only the power adapter and USB sync cable provided with your phone must be used to
charge the battery.
Do not remove the battery from the phone while you are charging it using the power or car
adapter.
1. Plug the power adapter into the USB connector of your phone.
2. Plug in the power adapter to an electrical outlet to start charging the battery.
As the battery is being charged, the notification LED shows a solid orange light. The
light turns to solid green when the phone is fully charged.
When you charge the battery while the phone is on, the charging battery icon
is displayed in your phone’s status bar. After the battery has been fully charged,
the charging battery icon turns to a full battery icon .
As a safety precaution, the battery stops charging when it overheats.
15 Getting started
HTC Confidential
Switching your phone on or off
Switching your phone on
Press the POWER button. Easy.
When you turn on the phone for the first time, you’ll need to set it up.
Switching your phone off
1. If the display is off, press the POWER button to turn it back on, then unlock the
screen by sliding the bar down on the lock screen.
2. Press and hold the POWER button for a few seconds.
3. When the Power options menu appears, tap Power off.
Entering your PIN
Most SIM cards come with a PIN (personal identification number) set by your mobile
operator. If you’re asked for a PIN, enter it and then tap OK.
If you enter the wrong PIN three times, your SIM card is blocked. No problem. Just contact
your mobile operator and ask for the PUK (PIN Unblocking Key).
Finger gestures
Tap When you want to type using the keyboard, select items onscreen such as
application and settings icons, or press onscreen buttons, simply tap them
with your finger.
Press and hold To open the available options for an item (for example, a contact or link in a
web page), simply press and hold the item.
Swipe or slide To swipe or slide means to quickly drag your finger vertically or horizontally
across the screen.
Drag Press and hold your finger with some pressure before you start to drag.
While dragging, do not release your finger until you have reached the
target position.
Flick Flicking the screen is similar to swiping, except that you need to swipe your
finger in light, quicker strokes. This finger gesture is always in a vertical
direction, such as when flicking the contacts or message list.
Rotate For most screens, you can automatically change the screen orientation
from portrait to landscape by turning the phone sideways. When entering
text, you can turn the phone sideways to bring up a bigger keyboard.
Pinch In some apps, like Gallery or the web browser, you can “pinch” the screen
using two fingers (for example, thumb and index finger) to zoom in or
zoom out when viewing a picture or a web page.
16 Getting started
HTC Confidential
Setting up your phone for the first time
When you switch on your phone for the first time, you’ll be asked to set up your
phone. You can choose your language, how you want to connect to the Internet,
and whether you want your current location to be automatically detected. If you still
have personal contacts and calendar events stored on your old phone, you can easily
transfer them to your new phone through Bluetooth as well.
Be sure to sign in to your Google Account so you can use Google apps like Gmail™
and Android Market™. You can also set up your other email accounts, favorite social
networks like Facebook and Twitter™, and more.
Just follow the onscreen instructions and you’ll be up and running with your phone in
no time.
Some features that need to connect to the Internet such as location-based services and autosync of your online accounts may incur extra data fees from your mobile operator. Don’t worry.
You can enable or disable them in your phone’s settings as you go along later on.
Ways of getting contacts into your phone
There are several ways you can add contacts to your phone. You can sync your phone
with contacts from your Google Account, computer, Facebook, and more.
HTC Sync Sync the contacts from your old phone to your computer, and then use
HTC Sync to sync your new HTC phone with your computer’s Microsoft
Outlook, Outlook Express or Windows Contacts.
Gmail Google contacts are imported to your phone after you sign in to your
Google Account. You can also create more Google contacts right from your
phone.
Facebook Log in to your Facebook account through Facebook for HTC Sense to
import your Facebook friends’ contact information.
Phone contacts You can choose to create and store contacts in your phone memory or
transfer existing ones from your old phone.
SIM card Copy all your SIM contacts to your phone.
Microsoft
Exchange
ActiveSync
Transfer Data Use the Transfer Data app to transfer not only your contacts, but also
Your phone syncs your work contacts from the Microsoft Exchange
ActiveSync Server in your workplace.
calendar events and text messages from your old phone to your new HTC
phone.
17 Getting started
HTC Confidential
Home screen
Your Home screen is where you make your phone your own. It comes with a weather
clock widget that shows the time and weather in your current location. You can also
add your favorite applications, shortcuts, folders and widgets so they’re always just a
tap away. To find out how, see Personalizing on page 30.
Extended Home screen
As you start to do more things with your phone, you might find that one Home screen
is not enough. No problem. You can use up to six extra screens. It should be plenty.
Slide your finger horizontally to the left or right and you’ll discover more space for
adding icons, widgets, and more.
Press to return to the main Home screen (that is, the center home screen).
Using Leap view
To jump straight to the screen that you want, press or pinch the screen to showor pinch the screen to show
the Leap view. It reveals all seven Home screens as thumbnails.
Just tap the one you want and you’ll leap right there.
18 Basics
HTC Confidential
Basics
Adjusting the volume
Adjusting the ringer volume changes the volume level of the phone ringtone, while
adjusting the media volume changes the volume level of sound notifications and music
or video playback.
Adjusting the ringer volume
Press the VOLUME UP or VOLUME DOWN button on the left panel of the
phone to adjust the ringer volume to your desired level. The Ringer volume
window appears on the screen to display the volume levels.
While in the lowest ringer volume level (Silent mode), press VOLUME DOWN
once to set your phone to Vibrate mode. The phone vibrates and the vibrate
mode icon appears in the status bar.
While in Vibrate mode, press VOLUME UP once to switch to silent mode. The
speaker mute icon displays in the status bar.
Adjusting the media volume
When playing music or watching video, press the VOLUME UP or VOLUME DOWN
button on the left panel of the phone to adjust the volume. The Media volume window
appears on the screen to display the volume level.
Adjusting the earpiece volume for phone calls
During a phone call, press the VOLUME UP or VOLUME DOWN button.
Adjusting the volume via settings
1. From the Home screen, press , and then tap Settings > Sound > Volume.
2. Drag the volume sliders to the left or right to adjust the volume levels of your
phone’s ringtone, media playback, alarms, and notifications. Your phone briefly
plays a sample tone with the volume being adjusted as you drag a slider.
3. If you want the same volume for your ringtone and notifications, select Use
incoming call volume for notifications.
4. When you’re done, tap OK.
19 Basics
HTC Confidential
Sleep mode
Sleep mode saves battery power by putting your phone into a low power state while
the display is off. It also stops accidental button presses when the phone’s in your bag
or pocket. You’ll still receive messages and calls though.
Switching to Sleep mode
Briefly press the POWER button to turn off the display and switch your phone to Sleep
mode. Your phone also automatically goes into Sleep mode when it’s idle for a while.
Waking up from Sleep mode
To wake your phone up manually, press the POWER button. You’ll need to unlock the
screen.
Your phone automatically wakes up when you have an incoming call.
Unlocking the screen
Press the bar on the lock screen and then slide your finger down to unlock the screen
or answer an incoming call.
If you have set up a screen unlock pattern, pin, or password, you will be asked to draw the
pattern on the screen or enter the PIN or password before it unlocks.
20 Basics
HTC Confidential
Status and notifications
Status icons
You can tell a lot about your phone by checking the icons in its status bar.
Here’s what each icon means:
Signal strength Battery is full
GPRS connected Battery is charging
GPRS in use Battery is low (20% remaining)
EDGE connected Battery is very low (10% remaining)
EDGE in use Silent mode
3G connected Vibrate mode
3G in use Phone microphone is mute
HSDPA connected Speakerphone is on
HSDPA in use Wired microphone headset connected
Roaming Wired headset connected
No signal Bluetooth is on
No SIM card installed Connected to a Bluetooth device
Connected to a Wi-Fi network Airplane mode
Data synchronizing GPS is on
Network sharing is on Alarm is set
Loading...
