HTC PB74100 Users Manual

User Manual

www.htc.com

Please Read Before Proceeding

THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU DISASSEMBLE OR ATTEMPT TO DISASSEMBLE THE DEVICE.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your phone.

INTELLECTUAL PROPERTY RIGHT INFORMATION

HTC, the HTC logo, HTC Innovation, ExtUSB, TouchFLO, HTC Touch, and HTC Care are trademarks and/or service marks of HTC Corporation.

Microsoft, Windows, Windows Mobile, Windows XP, Windows Vista, ActiveSync, Windows Mobile Device Center, Internet Explorer, MSN, Hotmail, Windows Live, Outlook, Excel, PowerPoint, Word, OneNote and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.

Java, J2ME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

microSD is a trademark of SD Card Association.

Google, Google Maps, and YouTube are trademarks of Google, Inc. in the United States and other countries.

Licensed by QUALCOMM Incorporated under one or more of the following patents:

4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,778,338 5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,710,784 5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,659,569 5,600,754 5,414,796 5,657,420 5,416,797

All other company, product and service names mentioned herein are trademarks, registered trademarks or service marks of their respective owners.

HTC shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from furnishing this material. The information is provided “as is” without warranty of any kind and is subject to change without notice. HTC also reserves the right to revise the content of this document at any time without prior notice.

No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording or storing in a retrieval system, or translated into any language in any form without prior written permission of HTC.

Disclaimers

THE WEATHER INFORMATION, DATA AND DOCUMENTATION ARE PROVIDED “AS IS” AND WITHOUT WARRANTY OR TECHNICAL SUPPORT OF ANY KIND FROM HTC. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HTC AND ITS AFFILIATES expressly disclaim any and all representations and warranties, express or implied, arising by law or otherwise, regarding the Weather Information, Data, Documentation, or any other Products and services, including without limitation any express or implied warranty of merchantability, express or implied warranty of fitness for a particular purpose, non-infringement, quality, accuracy, completeness, effectiveness, reliability, usefulness, that the Weather Information, Data and/or Documentation will be error-free, or implied warranties arising from course of dealing or course of performance.

Without limiting the foregoing, it is further understood that HTC and its Providers are not responsible for Your use or misuse of the Weather Information, Data and/or Documentation or the results from such use. HTC and its Providers make no express or implied warranties, guarantees or affirmations that weather information will occur or has occurred as the reports, forecasts, data, or information state, represent or depict and it shall have no responsibility or liability whatsoever to any person or entity, parties and non-parties alike, for any inconsistency, inaccuracy, or omission for weather or events predicted or depicted, reported, occurring or occurred. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, YOU ACKNOWLEDGE THAT THE WEATHER INFORMATION, DATA AND/OR DOCUMENTATION MAY INCLUDE INACCURACIES AND YOU WILL USE COMMON SENSE AND FOLLOW STANDARD SAFETY PRECAUTIONS IN CONNECTION WITH THE USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION.

Limitation of Damages

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HTC OR ITS PROVIDERS BE LIABLE TO USER OR ANY THIRD PARTY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND, IN CONTRACT OR TORT, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS ARISING OUT OF, OR RELATED TO, IN ANY MANNER, OR THE DELIVERY, PERFORMANCE OR NONPERFORMANCE OF OBLIGATIONS, OR USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION HEREUNDER REGARDLESS OF THE FORESEEABILITY THEREOF.

Important Health Information and Safety Precautions

When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION

CAUTION: Connecting to an improperly grounded equipment can result in an

electric shock to your device.

This product is equipped with a USB Cable for connecting with desktop or notebook computer. Be sure your computer is properly grounded (earthed) before connecting this product to the computer. The power supply cord of a desktop or

notebook computer has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

• Use the correct external power source

A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product.

• Handle battery packs carefully

This product contains a Li-ion battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures higher than 60˚C (140˚F).

WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk

of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 60° C (140° F), or dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product.

• Take extra precautions

• Keep the battery or device dry and away from water or any liquid as it may

cause a short circuit.

• Keep metal objects away so they don’t come in contact with the battery or

its connectors as it may lead to short circuit during operation.

• The phone should only be connected to products that bear the USB-IF

logo or have completed the USB-IF compliance program.

• Do not use a battery that appears damaged, deformed, or discolored, or

the one that has any rust on its casing, overheats, or emits a foul odor.

• Always keep the battery out of the reach of babies and small children, to

avoid swallowing of the battery. Consult the doctor immediately if the battery is swallowed.

• If the battery leaks:

• Do not allow the leaking fluid to come in contact with skin or clothing.

If already in contact, flush the affected area immediately with clean water and seek medical advice.

• Do not allow the leaking fluid to come in contact with eyes. If already

in contact, DO NOT rub; rinse with clean water immediately and seek medical advice.

• Take extra precautions to keep a leaking battery away from fire as

there is a danger of ignition or explosion.

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or

headphones are used at high volume for prolonged periods of time.

NOTE: For France, Earphone (listed below) for this device have been tested to comply with the Sound Pressure Level requirement laid down in the applicable NF EN 503321:2000 and/or NF EN 50332-2:2003 standards as required by French Article L. 5232-1.

• Earphone, manufactured by HTC, Model HS G235.

SAFETY IN AIRCRAFT

Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most countries. If you want to use this device when on board an aircraft, remember to turn off your phone by switching to Airplane Mode.

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck on boats, chemical plants, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where

blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the case of emergency. In some countries, using handsfree devices as an alternative is allowed.

SAFETY PRECAUTIONS FOR RF EXPOSURE

• Avoid using your phone near metal structures (for example, the steel frame of

a building).

• Avoid using your phone near strong electromagnetic sources, such as

microwave ovens, sound speakers, TV and radio.

• Use only original manufacturer-approved accessories, or accessories that do

not contain any metal.

• Use of non-original manufacturer-approved accessories may violate your

local RF exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this device is forbidden in most hospitals and medical clinics.

If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider, or call the customer service line to discuss alternatives.

NONIONIZING RADIATION

Your device has an internal antenna. This product should be operated in its normaluse position to ensure the radiative performance and safety of the interference. As with other mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is recommended that no part of the human body be allowed to come too close to the antenna during operation of the equipment.

Use only the supplied integral antenna. Use of unauthorized or modified antennas may impair call quality and damage the phone, causing loss of performance and SAR levels exceeding the recommended limits as well as result in non-compliance with local regulatory requirements in your country.

To assure optimal phone performance and ensure human exposure to RF energy is within the guidelines set forth in the relevant standards, always use your device only in its normal-use position. Contact with the antenna area may impair call quality and cause your device to operate at a higher power level than needed. Avoiding contact with the antenna area when the phone is IN USE optimizes the antenna performance and the battery life.

Antenna location

General Precautions

• Avoid applying excessive pressure to the device

Do not apply excessive pressure on the screen and the device to prevent damaging them and remove the device from your pants’ pocket before sitting down. It is also recommended that you store the device in a protective case and only use the device stylus or your finger when interacting with the touch screen. Cracked display screens due to improper handling are not covered by the warranty.

• Device getting warm after prolonged use

When using your device for prolonged periods of time, such as when you’re talking on the phone, charging the battery or browsing the web, the device may become warm. In most cases, this condition is normal and therefore should not be interpreted as a problem with the device.

• Heed service markings

Except as explained elsewhere in the Operating or Service documentation, do not service any product yourself. Service needed on components inside the device should be done by an authorized service technician or provider.

• Damage requiring service

Unplug the product from the electrical outlet and refer servicing to an authorized service technician or provider under the following conditions:

• Liquid has been spilled or an object has fallen onto the product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the operating

instructions.

• Avoid hot areas

The product should be placed away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

• Avoid wet areas

Never use the product in a wet location.

• Avoid using your device after a dramatic change in temperature

When you move your device between environments with very different temperature and/or humidity ranges, condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the moisture to evaporate before using the device.

NOTICE: When taking the device from low-temperature conditions into a warmer

environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on power.

• Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are provided for ventilation. These openings must not be blocked or covered.

• Mounting accessories

Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

• Avoid unstable mounting

Do not place the product with an unstable base.

• Use product with approved equipment

This product should be used only with personal computers and options identied as suitable for use with your equipment.

• Adjust the volume

Turn down the volume before using headphones or other audio devices.

• Cleaning

Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but NEVER use water to clean the LCD screen.

Contents

Chapter 1 Getting Started 22

1.1 Inside the Box .................................................................................................. 22

1.2 Getting to Know Your Phone .......................................................................... 22

Top and bottom panels ............................................................................................................22

Front panel ....................................................................................................................................23

Back panel ..................................................................................................................................... 24

Left panel .......................................................................................................................................25

Right panel ....................................................................................................................................25

1.3 Installing the SIM Card, Battery, and Storage Card ...................................... 26

SIM card..........................................................................................................................................27

Battery ............................................................................................................................................28

Storage card .................................................................................................................................29

1.4 Charging the Battery ....................................................................................... 30

1.5 Starting Up ....................................................................................................... 31

Turning the power on and off ................................................................................................31

Switching to Sleep mode.........................................................................................................31

1.6 Home Screen .................................................................................................... 32

1.7 Status Icons ...................................................................................................... 33

1.8 Notifications.....................................................................................................35

1.9 Start Screen ......................................................................................................36

1.10 Quick Menu ......................................................................................................37

1.11 Lock Screen ......................................................................................................38

Locking your phone ..................................................................................................................38

Unlocking your phone ..............................................................................................................39

Checking notifications when the phone is locked .........................................................39

Receiving a call when the phone is locked .......................................................................40

1.12 Adjusting the Volume...................................................................................... 40

1.13 Using Finger Gestures ..................................................................................... 42

Finger scrolling ............................................................................................................................42

Finger panning ............................................................................................................................ 42

1.14 Using the Zoom Bar ......................................................................................... 43

1.15 Connecting Your Phone to a Computer ......................................................... 44

Chapter 2 Contacts and Phone Calls 45

2.1 Contacts ............................................................................................................45

Opening the Contacts screen ................................................................................................45

Adding new contacts to your phone ..................................................................................45

Adding a contact to your SIM card .......................................................................................46

Assigning contacts with categories ..................................................................................... 46

Browsing and filtering the contacts list ..............................................................................46

Creating an email or messaging group .............................................................................. 47

Sharing contact information ..................................................................................................48

Working with multiple contacts ............................................................................................48

2.2 Making Calls .....................................................................................................49

Making a call from the Phone dialer screen ......................................................................49

Making calls from received messages and calendar reminders ................................ 51

Making an emergency call ......................................................................................................51

Making an international call ...................................................................................................51

Calling voicemail .........................................................................................................................51

2.3 Answering and Ending Calls ........................................................................... 52

Accepting or rejecting an incoming call ............................................................................ 52

During a call ..................................................................................................................................53

2.4 Making Conference Calls.................................................................................54

2.5 Call History ....................................................................................................... 56

2.6 Speed Dial ........................................................................................................ 57

Creating a Speed Dial entry ....................................................................................................57

Making a call using Speed Dial .............................................................................................. 57

2.7 Turning the Phone Connection On and Off ................................................... 58

Chapter 3 Using the Home Screen 59

3.1 What’s on the Home Screen ............................................................................59

Switching between the tabs of the Home screen ..........................................................60

3.2 Home ................................................................................................................ 61

3.3 People ...............................................................................................................62

Adding contacts to your phone ............................................................................................62

Adding favorite contacts to the People tab ......................................................................62

Quickly calling or sending a message to a favorite contact........................................63

Removing a favorite contact ..................................................................................................63

3.4 Messages .......................................................................................................... 64

3.5 Mail ................................................................................................................... 65

Adding your Internet email account ...................................................................................65

Adding your Outlook work account .................................................................................... 66

Checking and reading email ..................................................................................................67

3.6 Internet .............................................................................................................68

3.7 Photos and Videos ........................................................................................... 69

Setting a favorite album...........................................................................................................70

3.8 Music .................................................................................................................71

Playing music ............................................................................................................................... 71

The Library ....................................................................................................................................72

Playlists ...........................................................................................................................................73

3.9 Weather ............................................................................................................ 75

Adding a city ................................................................................................................................75

Weather settings .........................................................................................................................76

3.10 Map Search (Available by Country) ................................................................ 77

3.11 Settings ............................................................................................................ 78

3.12 Programs .......................................................................................................... 79

Chapter 4 Entering Text 80

4.1 Using the On-screen Keyboard ....................................................................... 80

Full QWERTY ................................................................................................................................. 81

Compact QWERTY ...................................................................................................................... 81

Phone Keypad ..............................................................................................................................81

Entering text .................................................................................................................................82

On-screen navigation pad .......................................................................................................83

4.2 Using Predictive Mode .................................................................................... 83

4.3 Entering Numbers and Symbols ..................................................................... 85

4.4 Text Input Settings .......................................................................................... 86

Chapter 5 Synchronizing Information 87

5.1 Ways of Synchronizing Your Phone ................................................................87

5.2 Before Synchronizing With Your Computer ................................................... 88

5.3 Setting Up Windows Mobile® Device Center on Windows Vista® ................. 88

Setting up synchronization in Windows Mobile Device Center ................................89

Using Windows Mobile Device Center ................................................................................90

5.4 Setting Up ActiveSync® on Windows® XP ...................................................... 91

Setting up synchronization in ActiveSync .........................................................................91

5.5 Synchronizing With Your Computer ............................................................... 92

Starting and stopping synchronization..............................................................................92

Selecting information to sync ................................................................................................ 93

Troubleshooting sync connection problem ..................................................................... 93

5.6 Synchronizing via Bluetooth ..........................................................................94

5.7 Synchronizing Music and Video ..................................................................... 95

5.8 Synchronizing With Microsoft® My Phone .....................................................96

Setting up your My Phone account .....................................................................................96

Changing sync settings ............................................................................................................ 96

Stopping sync partnership with your My Phone Web account .................................97

Managing your My Phone Web account from your computer ..................................97

Chapter 6 Exchanging Messages 98

6.1 Text Messages .................................................................................................. 98

Creating and sending a new text message ....................................................................... 98

Managing text messages in your Inbox .............................................................................99

Directly making calls from text messages ...................................................................... 100

6.2 Multimedia Messages ...................................................................................101

Changing the MMS settings ................................................................................................ 101

Creating and sending MMS messages ............................................................................. 102

Viewing and replying to MMS messages ........................................................................ 104

Blocking a phone number from sending you MMS messages ............................... 104

6.3 Email ............................................................................................................... 105

Synchronizing Outlook email with your computer ..................................................... 105

Setting up your Internet email account .......................................................................... 105

Creating and replying to email messages ...................................................................... 106

When viewing email ............................................................................................................... 107

Downloading file attachments ........................................................................................... 108

Directly making calls from email messages ................................................................... 108

Synchronizing email messages ..........................................................................................109

Customizing email settings ................................................................................................. 109

6.4 Adding Your Signature in Sent Messages ....................................................111

6.5 Filtering Your Inbox .......................................................................................111

Chapter 7 Working With Calendar and Company Email 112

7.1 Using Calendar ...............................................................................................112

Creating appointments ......................................................................................................... 112

Viewing appointments .......................................................................................................... 113

Setting the reminder time for new appointments ...................................................... 114

Sending meeting requests ................................................................................................... 114

Making a call from a meeting request or reminder .................................................... 115

7.2 Synchronizing With the Exchange Server .................................................... 115

Setting up an Exchange Server connection .................................................................. 115

Starting synchronization ...................................................................................................... 115

7.3 Working With Company Email Messages .....................................................116

Automatic synchronization through Direct Push ........................................................ 116

Scheduled synchronization .................................................................................................117

Instant download through Fetch Mail ............................................................................. 117

Searching for email messages on the Exchange Server ............................................ 118

Flagging your messages ....................................................................................................... 118

Out-of-office auto-reply ........................................................................................................ 119

Replying to meeting requests............................................................................................. 119

7.4 Finding Contacts in the Company Directory ............................................... 120

When browsing contacts, composing email, or creating a meeting request .... 120

When viewing a received Outlook email message .....................................................121

Chapter 8 Internet 122

8.1 Ways of Connecting to the Internet ............................................................. 122

Wi-Fi .............................................................................................................................................. 122

GPRS/3G ...................................................................................................................................... 124

Dial-up ......................................................................................................................................... 125

Starting a data connection .................................................................................................. 125

8.2 Using Internet Explorer® Mobile ..................................................................126

The browser screen ................................................................................................................. 126

Entering a website address and adding it to your Web favorites .......................... 127

Zooming and panning........................................................................................................... 128

8.3 Using YouTube™ .............................................................................................129

The YouTube main screen ..................................................................................................... 129

Searching videos ..................................................................................................................... 130

Using the Program Guide ..................................................................................................... 130

Watching videos ...................................................................................................................... 131

8.4 Using Streaming Media ................................................................................. 132

8.5 Using Windows Live™ .................................................................................... 133

The Windows Live screen...................................................................................................... 134

Using Windows Live Messenger ......................................................................................... 134

8.6 Using Your Phone as a Modem (Internet Sharing) ......................................136

Before you proceed ................................................................................................................ 136

Setting up your phone as a USB modem ........................................................................ 136

Using your phone as a Bluetooth modem .....................................................................137

Ending the Internet connection ......................................................................................... 138

Chapter 9 Bluetooth 139

9.1 Bluetooth Modes ........................................................................................... 139

Turning Bluetooth on and making your phone visible.............................................. 139

9.2 Bluetooth Partnerships ................................................................................. 140

Creating a Bluetooth partnership ...................................................................................... 140

Accepting a Bluetooth partnership .................................................................................. 141

9.3 Connecting a Bluetooth Hands-free or Stereo Headset .............................142

9.4 Sending and Receiving Information Using Bluetooth ................................143

Sending information from your phone to a computer .............................................. 143

Sending a file to another Bluetooth-enabled device ................................................. 145

Receiving information from another Bluetooth-enabled device .......................... 145

Changing the folder for saving received files ................................................................ 145

9.5 Printing via Bluetooth ................................................................................... 146

Printing a photo ....................................................................................................................... 146

9.6 Connecting to Car Kit Phones ....................................................................... 147

Chapter 10 Navigating on the Road 148

10.1 Google™ Maps (Available by Country) .........................................................148

Opening Google Maps .......................................................................................................... 148

Searching a place of interest ............................................................................................... 149

10.2 Guidelines and Preparation for Using GPS ..................................................150

10.3 Downloading Location Data via QuickGPS .................................................152

Changing the download options ...................................................................................... 152

Chapter 11 Camera and Multimedia 153

11.1 Taking Photos and Videos .............................................................................153

Changing the capture mode ............................................................................................... 153

Zooming ..................................................................................................................................... 154

Capturing photos and videos ............................................................................................. 155

On-screen controls .................................................................................................................. 156

Basic settings ............................................................................................................................. 156

Advanced settings................................................................................................................... 157

11.2 Viewing Photos and Videos Using Album ....................................................159

Viewing photos ........................................................................................................................ 160

Playing videos ........................................................................................................................... 161

Closing Album .......................................................................................................................... 161

11.3 Using Windows Media® Player Mobile ......................................................... 161

Playing media ........................................................................................................................... 161

Synchronizing video and audio files ................................................................................ 162

Creating playlists ..................................................................................................................... 165

Troubleshooting ...................................................................................................................... 165

11.4 Using Audio Booster ......................................................................................166

11.5 Using FM Radio .............................................................................................. 167

Saving presets ........................................................................................................................... 168

Minimizing or turning off FM Radio .................................................................................. 168

Chapter 12 Other Programs 169

12.1 Facebook® ......................................................................................................169

12.2 Microsoft® Office Mobile ............................................................................... 170

12.3 JBlend .............................................................................................................171

Installing and launching MIDlets/MIDlet suites ...........................................................171

12.4 Using RSS Hub ................................................................................................172

Subscribing to and browsing news channels ...............................................................172

Viewing headlines ................................................................................................................... 174

Sharing the headline link ...................................................................................................... 175

12.5 SIM Manager ..................................................................................................175

12.6 Windows® Marketplace ................................................................................. 176

12.7 Installing and Uninstalling Programs ..........................................................177

Chapter 13 Managing Your Phone 178

13.1 Copying and Managing Files ........................................................................178

13.2 Settings on Your Phone .................................................................................180

Settings screen ......................................................................................................................... 180

Personal folder .......................................................................................................................... 181

Connections folder ................................................................................................................. 181

System folder ............................................................................................................................ 182

13.3 Changing Basic Settings ............................................................................... 184

Wallpaper ................................................................................................................................... 184

Sound settings .......................................................................................................................... 184

Power saving and display settings .................................................................................... 186

Device name .............................................................................................................................. 187

Phone services .......................................................................................................................... 188

13.4 Using Comm Manager ................................................................................... 189

13.5 Using Connection Setup ...............................................................................190

13.6 Using Task Manager ......................................................................................191

13.7 Protecting Your Phone .................................................................................. 192

Protecting your SIM card with a PIN ................................................................................. 192

Protecting your phone with a password ......................................................................... 192

Encrypting files on your storage card ..............................................................................193

13.8 Resetting Your Phone ....................................................................................194

Performing a soft reset .......................................................................................................... 194

Performing a hard reset ........................................................................................................ 194

Using Clear Storage ................................................................................................................ 195

Appendix 196

A.1 Specifications ................................................................................................. 196

A.2 Regulatory Notices ........................................................................................198

Index 205

Chapter 1

Getting Started

1.1 Inside the Box

The product package includes:

HTC Touch2

•

USB sync cable

•

Battery

•

1.2 Getting to Know Your Phone

AC adapter

•

3.5mm stereo headset

•

Quick Start Guide

•

Top and bottom panels

3.5mm Audio Jack

Connect a 3.5mm wired headset for hands-free conversation or for listening to music.

Microphone

Sync Connector

Connect the power adapter to recharge

• the battery. Connect the supplied USB cable to sync

• your phone with your computer.

Front panel

Chapter 1 Getting Started 23

Notification LED

Touch Screen

TALK/SEND

HOME

Button Function

Notification LED This LED shows a:

Earpiece Listen to a phone call from here.

•

Flashing green light when there is a missed call, new text message, new email, or other notification. Solid green light when the phone is connected to the power adapter

• or a computer and the battery is fully charged. Solid amber light when the battery is being charged.

• Flashing amber light when the remaining battery level reaches

• below 10%.

Earpiece

Zoom Bar

END/POWER

BACK

START

24 Chapter 1 Getting Started

Button Function

TALK/SEND Press to answer a call or dial out.

HOME Press to return to the Home tab of the Home screen.

START Press to open or close the Start screen.

BACK Press to return to the previous screen.

END/POWER While in a call, press to end the call.

Zoom bar Use for zooming in and out.

Back panel

• During a call, press and hold to turn the speakerphone on and off.

• While viewing a message, press to call the sender.

•

• Press to turn the display on or off.

• Press and hold to display the Quick List and choose whether to

• turn the power off, lock your phone, set your phone to vibrate, or disconnect the data connection.

Speaker

3.2 Megapixel Camera

Back Cover

Strap Holder

Left panel Right panel

VOLUME UP

Press to increase the earpiece volume during a call or the speaker volume.

VOLUME DOWN

Press to decrease the earpiece volume during a call or the speaker volume.

microSD Card Slot

(See “Storage card” later in this chapter for details.)

Stylus

Chapter 1 Getting Started 25

26 Chapter 1 Getting Started

1.3 Installing the SIM Card, Battery, and Storage Card

You need to remove the back cover before you can install the SIM card, battery and storage card on your phone. Also, make sure to always turn off the power before installing or replacing the SIM card and battery.

To remove the back cover

1. Make sure your phone is turned off.

2. Hold your phone securely with the front facing down.

3. With your thumb or finger, lift open the top of the back cover.

To replace the back cover

1. Secure the bottom part of the back cover first by aligning into the two

openings located at the bottom part of the back of the phone.

2. Press the sides and the top part of the back cover down to lock the cover into

place. You will hear a click when the back cover is locked in place.

Chapter 1 Getting Started 27

SIM card

The SIM card contains your phone number, service details, and phonebook/ message memory. Your phone supports both 1.8V and 3V SIM cards.

Note Some legacy SIM cards may not function with your phone. You should consult with

your mobile operator for a replacement SIM card. There may be fees for this service.

To install the SIM card

1. Make sure your phone is turned off.

2. Locate the SIM card slot, then insert

the SIM card with its gold contacts facing down and its cut-off corner facing out.

3. Slide the SIM card completely into the

slot.

To remove the SIM card

1. If the battery is installed, remove it

to reveal the SIM card slot. See “To remove the battery” for instructions.

2. With your left thumb or finger, press

down the small tab located at the left side of the SIM card slot.

3. With your right thumb or finger, slide

the SIM card out from the slot.

28 Chapter 1 Getting Started

Battery

Your phone comes with a rechargeable Lithium-ion battery and is designed to use only manufacturer-specified original batteries and accessories. Battery performance depends on many factors, including network configuration, signal strength, and usage patterns.

Warning! To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire or

water.

• Do not expose to temperatures above 60

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local regulations.

To install the battery

1. Align the battery’s exposed

copper contacts with the battery connectors inside the battery compartment.

2. Insert the contacts side of the

battery first and then gently push the battery into place.

3. Replace the back cover. For

instructions, see “To replace the back cover” in this chapter.

To remove the battery

1. Make sure your phone is turned off.

2. Remove the back cover. See “To remove the back cover” for instructions.

3. Lift up the battery from the small opening on the right side of the battery

compartment.

C (140oF).

Chapter 1 Getting Started 29

Storage card

To have additional storage for your photos, videos, music, and files, you can purchase a microSD™ card and install it into the your phone.

To install the microSD card

1. Remove the back cover. See

“To remove the back cover” for instructions.

2. From the side of your phone, open

the microSD slot cover.

3. Insert the microSD card into the

slot with its gold contacts facing down until it clicks into place.

4. Close the microSD slot cover and

replace the back cover.

To remove the microSD card

Press the microSD card to eject it from the slot.

30 Chapter 1 Getting Started

1.4 Charging the Battery

New batteries are shipped partially charged. Before you start using your phone, it is recommended that you install and charge the battery. Some batteries perform best after several full charge/discharge cycles.

To charge the battery

1. Connect the USB connector of the AC

adapter to the sync connector on your phone.

2. Plug in the AC adapter to an electrical

outlet to start charging the battery.

Note Only the AC adapter and USB sync cable

provided with your phone must be used to charge the battery.

As the battery is being charged while the power is on, a charging icon appears in the title bar of the Home screen. After the battery has been fully charged, a full battery icon

Warning! • Do not remove the battery from the phone while you are charging it using

appears in the title bar of the Home screen.

the AC or car adapter.

• As a safety precaution, the battery stops charging when it overheats.

+ 180 hidden pages
