QuickSpecs
HPE ProLiant DL160 Gen10 Server
Overview
Page 1
HPE ProLiant DL160 Gen10 Server
NOTE:
Please contact your local sales representative for additional information
The secure 2P 1U HPE ProLiant DL160 Gen10 server delivers the right balance of performance, storage, reliability, manageability
and efficiency in a dense and compact chassis, to meet the needs of growing businesses of a diverse set of
from SMB to
Service Providers running wide range of workloads - at a compelling price point.
8 SFF chassis - Front View
1.
Quick removal access panel
6.
iLO Service Port
2.
Serial no. label pull tab
7.
UID button/LED
3.
Health LED
8.
NIC Status LED
4.
Power On/Standby button and system power LED
9.
Standard 8 SAS/SATA/SSD drive bays
5.
USB 3.0 port
The HPE ProLiant DL160 Gen10 is not currently available in all countries.
customers –
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Overview
Page 2
4 LFF chassis - Front View
1.
Quick removal access panel
6.
NIC status LED
2.
Serial no. label pull tab
7.
Health LED
3.
iLO Service Port
8.
Power On/Standby button and system power LED
4.
USB 3.0 Port
9.
4 SAS/SATA/SSD drive bays
5.
UID button/LED
Rear View
1.
Slot 1 PCIe 3.0
5.
Embedded 2x 1GbE Adapter
2.
Slot 2 PCIe 3.0
6.
VGA Port
3.
Optional: Slot 3 PCIe 3.0 (Requires 2nd processor)
7.
iLO Management Port
4.
Power Supply (Redundant hot-plug shown)
8.
USB 3.0 Ports
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Overview
Page 3
8SFF chassis – with optional 2nd CPU - Internal View
1
Standard single rotor hot swap fans
1 CPU
Optional:
11
MicroSD card slot
2
Optional: Smart Storage Battery (No battery shown)
12
iLO Service Port Connector
3
DDR4 DIMM slots (Fully populated 16 DIMMs shown)
13
Primary (CPU1) PCIe 3.0 riser
4
Up to 2 processors (shown with standard heat sinks)
14
Mini-SAS port 1
5
Hard Drive backplane power connector
15
Mini-SAS port 2
6
System Battery
16
Mini-SAS port 3
7
Internal USB 3.0 connector
17
SATA port 4
8
Secondary (CPU2) PCIe 3.0 riser*
18
SATA port 5
9
Power supply (non-redundant power supply shown)
19
Front Power USB 3.0 connector
10
Flexible Smart Array Controller Connector
– 3 standard fans
2 CPUs – 6 standard fans (redundant fan shown)
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Overview
Page 4
Platform Information
Form Factor
1U rack
Chassis Types
8 SFF
4 LFF
System Fans
Standard – fan types included
Non-Redundant
1P Model
3 fans
2P Model
6 fans
NOTE: The second processor option kit contains 3 additional fans
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Standard Features
Page 5
Processors – Up to 2 of the following depending on model.
NOTE: For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon
Intel Xeon Models
CPU
Frequency
Cores
L3 Cache
Power
UPI
DDR4
Memory per
socket
Silver Processors
Silver 4110 Processor
2.1 GHz
8
11.00 MB
85W
2 @ 9.6 GT/s
2400 MT/s
768 GB
Bronze Processors
Bronze 3106 Processor
1.7 GHz
8
11.00 MB
85W
2 @ 9.6 GT/s
2133 MT/s
768 GB
NOTE: Silver – 4100 Series - 2 Socket supports 2UPI @ 9.6 GT/s, 6-Channel DDR4 @ 2400 MT/s providing up to 768 GB memory
bit FMA), 48 lanes PCIe 3.0,
Channel DDR4 @ 2133 MT/s providing up to
768GB memory capacity. Intel AVX-512(1x 512-bit FMA), 48 lanes PCIe 3.0, standard RAS supported.
Chipset
On System Management Chipset
Memory
Type:
HPE DDR4 SmartMemory,
Registered (RDIMM)
DIMM Slots Available
16
8 DIMM slots per processor, 6 channels per processor, 2 channels @ 2
DIMMs per channel, 4 channels @ 1 DIMM per channel
Maximum capacity (RDIMM)
256 GB
16 x 16 GB RDIMM @ 2666 MT/s
NOTE: The maximum memory by socket is limited by the processor selection.
Memory Protection
capacity. Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512(1x 512standard RAS supported.
NOTE: Bronze – 3100 Series - 2 Socket supports 2UPI @ 9.6 GT/s, supports 6-
Intel C622 Chipset
NOTE: For more information regarding Intel® chipsets, please see the following
URL: http://www.intel.com/products/server/chipsets/
HPE iLO 5 ASIC
NOTE: Read and learn more in the iLO QuickSpecs.
One of the following depending on model
For details on the HPE Server Memory Options RAS feature, visit: http://www.hpe.com/docs/memory-ras-feature.
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Standard Features
Page 6
Expansion Slots
FlexibleLOM Riser
Slots #
Technology
Bus
Width
Connector Width
Slot Form Factor
Notes
1
PCIe 3.0
X8
X8
Flexible LOM
Proc 1
2
PCIe 3.0
X8
X8
Half-height,
half-length slot
Proc 1
NOTE: Bus Width Indicates the number of physical electrical lanes running to the connector.
NOTE: FlexibleLOM riser will replace standard CPU1 X16/X8 riser.
CPU2 Riser
Slots #
Technology
Bus
Width
Connector Width
Slot Form Factor
Notes
1
PCIe 3.0
X16
X16
Half-height,
half-length slot
Proc 2
NOTE:
NOTE: Max 3-PCIe slots are available on the DL160-Gen10.
Storage Controllers
kout
One of the following depending on model
Software RAID
additional controller will
HPE Smart Array S100i SR Gen10 SW RAID only supports Windows and does not support Linux. For Linux users, HPE
disk RAID 1 boot volume. For more information
Essential RAID Controller
HPE Smart Array E208e-p SR Gen10 Controller
Performance RAID Controller
NOTE: Performance RAID Controllers require the HPE Smart Storage Battery (P01366-B21) which is sold separately.
NOTE: This riser is mandatory for installing FlexibleLOMs
Bus Width Indicates the number of physical electrical lanes running to the connector.
NOTE: When populating the second optional riser slot, the second processor must be installed.
NOTE: Cannot be installed if type-a modular smart array controller is installed.
The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed brea
of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet.
HPE Smart Array S100i SR Gen10 SW RAID
NOTE: HPE Smart Array S100i SR Gen10 SW RAID will operate in UEFI mode only. For legacy support an
be needed.
NOTE: HPE Smart Array S100i SR Gen10 SW RAID is off by default and must be enabled.
NOTE:
offers a solution that uses in-distro open-source software to create a twovisit: https://downloads.linux.hpe.com/SDR/project/lsrrb/
HPE Smart Array E208i-a SR G10 LH Controller
HPE Smart Array E208i-p SR Gen10 Controller
HPE Smart Array P408i-a SR G10 LH Controller
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Standard Features
Page 7
Internal Storage Devices
None ship standard
Maximum Internal Storage
Capacity
Configuration
Hot Plug SFF SAS
9.6 TB
8 X 1.2 TB
Hot Plug LFF SAS
8 TB
4 X 2 TB
Hot Plug LFF SATA
4 TB
4 X 1 TB
Hot Plug SFF SAS SSD
3.2 TB
8 X 400GB
Hot Plug SFF SATA SSD
3.84 TB
8 X 480 GB
Power Supply
less
d
size" a power supply for specific server configurations. This flexibility helps
14 jumper cord (A0K02A). This jumper cord is also included with
HPE Server power supplies.
Interfaces
Video
1 rear – VGA Port (standard )
Network Ports
2 x 1 GbE ports embedded on board with optional FlexibleLOM
HPE iLO Remote Management
Network Port
1 Gb Dedicated
Front iLO Service Port
1 standard
Micro SD Slot
1 Micro SD
NOTE:
pluggable device. Customers should not attempt to plug an SD card into the SD slot while
the server is powered.
USB 3.0
Up to 4 total: 1 front, 2 rear, 1 internal
Hard Drives
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
NOTE: Available in 94% efficiency.
HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, toolinstallation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for high-efficiency operation an
offer multiple power output options, allowing users to "rightto reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center.
All pre-configured servers ship with a standard 6-foot IEC C-13/Ceach standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page.
For information on power specifications and technical content visit
The Micro SD slot is not a hot-
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Standard Features
Page 8
Operating Systems and Virtualization Software Support for ProLiant Servers**
Industry Standard Compliance
NOTE: UEFI is the default for the HPE ProLiant DL160 Gen10. Legacy mode can be selected in the field.
Graphics
• 4 Gbit DDR 3 with ECC protection
• Windows Server 2016
• Windows Server 2019
• VMware ESXi 6.0 U3
• VMware ESXi 6.5 U2
• VMware ESXi 6.7 U1
• Red Hat Enterprise Linux (RHEL) 7.6 (with Kbase)
• SUSE Linux Enterprise Server (SLES) 12 SP4
• SUSE Linux Enterprise Server (SLES) 15
**Certification pending
• ACPI 6.1 Compliant
• PCIe 3.0 Compliant
• WOL Support
• Microsoft® Logo certifications
• PXE Support
• USB 3.0 Compliant (internal)
• SMBIOS 3.1
• UEFI 2.6
• Redfish API
• IPMI 2.0
• Secure Digital 2.0
• Advanced Encryption Standard (AES)
• Triple Data Encrytion Standard (3DES)
• SNMP v3
• TLS 1.2
• DMTF Systems Management Architecture for Server Hardware Command Line Protocol (SMASH CLP)
• Active Directory v1.0
• ASHRAE A3/A4
NOTE: For additional technical thermal details regarding ambient temperatures, humidity and features support please
visit: http://www.hpe.com/servers/ashrae.
UEFI (Unified Extensible Firmware Interface Forum)
Integrated Video Standard
• Video modes up to 1920 x 1200@60Hz (32 bpp)
• 16MB Video Memory
HPE iLO 5 on system management memory
• 32 MB Flash
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Standard Features
Page 9
HPE Server UEFI/Legacy ROM
Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured
at boot time. HPE ProLiant Gen10 servers have a UEFI Class 2
Based Setup Utility (RBSU) of legacy BIOS. For more
NOTE: For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI.
Embedded Management
HPE Integrated Lights-Out (HPE iLO)
Monitor your servers for ongoing management, service alerting, reporting and remote management with HPE iLO. Learn more
at http://www.hpe.com/info/ilo.
UEFI
boot your servers securely with industry standard Unified Extensible Firmware Interface (UEFI). Learn more
Intelligent Provisioning
http://www.hpe.com/servers/intelligentprovisioning
iLO RESTful API
RESTful API is Redfish API conformance and offers simplified server management automation such as configuration and
maintenance tasks based on modern industry standards. Learn more at http://www.hpe.com/info/restfulapi.
configuration than the legacy ROM while interacting with your server
implementation and support both UEFI Mode (default) and Legacy BIOS Mode.
NOTE: The UEFI System Utilities tool is analogous to the HPE ROMinformation, please visit http://www.hpe.com/servers/uefi.
• UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:
• Secure Boot and Secure Start enable for enhanced security
• Operating system specific functionality
• Support for > 2.2 TB (using GPT) boot drives
• USB 3.0 Stack
• Embedded UEFI Shell
• Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant
• PXE boot support for IPv6 networks
• Workload Profiles for simple performance optimization
• UEFI Boot Mode only:
• TPM 2.0 Support
• NVMe Boot Support
• iSCSI Software Initiator Support.
• HTTP/HTTPs Boot support as a PXE alternative.
• Boot support for option cards that only support a UEFI option ROM
Configure and
at http://www.hpe.com/servers/uefi.
Hassle free server and OS provisioning for 1 or more servers with Intelligent Provisioning. Learn more at
.
iLO
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Standard Features
Page 10
Server Utilities
Active Health System
ive
http://www.hpe.com/servers/ahs
Active Health System Viewer
repair
recommendations, to learn more visit: http://www.hpe.com/servers/ahsv.
Service Pack for ProLiant (SPP)
a single
solution stack, which is delivered as a single ISO image. Learn more at http://www.hpe.com/servers/spp
iLO Amplifier Pack
e,
E
ervers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities. Learn more
at http://www.hpe.com/servers/iLOamplifierpack.
HPE iLO Mobile Application
the ability to access, deploy, and manage your server anytime from anywhere from select smartphones and mobile devices.
For additional information please visit: http://www.hpe.com/info/ilo/mobileapp.
RESTful Interface Tool
at scale.
Learn more at http://www.hpe.com/info/resttool.
Scripting Tools
r
http://www.hpe.com/servers/stk
http://www.hpe.com/servers/powershell
HPE Systems Insight Manager (HPE SIM)
ity
quick and seamless firmware updates. Learn more at http://www.hpe.com/info/hpesim.
The HPE Active Health System (AHS) is an essential component of the iLO management portfolio that provides continuous, proact
health monitoring of HPE servers. Learn more at
Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed problem resolution with HPE self-
The Service Pack for ProLiant (SPP) is a comprehensive collection of server firmware, drivers, and system software tested as
Designed for large enterprise and service provider environments with hundreds of HPE servers, the iLO Amplifier Pack is a fre
downloadable open virtual application (OVA) that delivers the power to discover, inventory and update Gen8, Gen9 and Gen10 HP
s
.
Enables
RESTful Interface tool (iLOREST) is a single scripting tool to provision using iLO RESTful API to discover and deploy servers
Provision one to many servers using your own scripts to discover and deploy with Scripting Tool (STK) for Windows and Linux o
Scripting Tools for Windows PowerShell.
Learn more at
or
.
Ideal for environments already using HPE SIM, it allows you to monitor the health of your HPE ProLiant Servers and HPE Integr
Servers. Also provides you with basic support for non-HPE servers. HPE SIM also integrates with Smart Update Manager to provide
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Standard Features
Page 11
Security
• Secure erase of NAND/User data
Warranty
Services and a worldwide network
hree
nts to
s have either
Year Onsite support with next business day response. Warranty
through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1)
e
replace Optional CSR parts at no charge. Additional information regarding
http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/.
• UEFI Secure Boot and Secure Start support
• Immutable Silicon Root of Trust
• FIPS 140-2 validation
• Common Criteria certification
• Configurable for PCI DSS compliance
• Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
• Support for Commercial National Security Algorithms (CNSA)
• Tamper-free updates – components digitally signed and verified
• Secure Recovery – recover critical firmware to known good state on detection of compromised firmware
• Ability to rollback firmware
This product is covered by a global limited warranty and supported by Hewlett Packard Enterprise
of Hewlett Packard Enterprise Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for t
years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhanceme
warranty services are available through HPE Pointnext operational services or customized service agreements. Hard drive
a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.
NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-
repairs may be accomplished
Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replac
a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers
may choose to have Hewlett Packard Enterprise
worldwide limited warranty and technical support is available at:
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Optional Features
Page 12
Server Management
HPE iLO Advanced
ProLiant servers. The license includes
user collaboration, console record and replay, and
e enhanced security and power management
http://www.hpe.com/servers/iloadvanced.
HPE iLO Advanced Premium Security Edition
end security modes, unique security
m
Security Edition at: http://www.hpe.com/servers/ilopremium.
HPE Insight Cluster Management Utility (CMU)
are for the centralized
http://www.hpe.com/info/cmu
Rack and Power Infrastructure
The story may end with servers, but it starts with the foundation that makes compute go – and business grow. We’ve reinvented our
er words,
ter, and simpler infrastructure to help you get the most out of your IT equipment. As an industry leader,
is uniquely positioned to address the key concerns of power, cooling, cable management and system
coded outlets and
to
Learn more about HPE Racks, KVM, PDUs and UPSs at HPE Rack and Power Infrastructure.
One Config Simple (SCE)
in 3 to 5 minutes.
stom" rack
erprise Customer Business Center
HPE iLO Advanced licenses offer smart remote functionality without compromise, for all HPE
the full integrated remote console, virtual keyboard, video, and mouse (KVM), multiGUI-based and scripted virtual media and virtual folders. You can also activate th
functionality. Learn more about HPE iLO Advanced at
HPE iLO Advanced Premium Security Edition for iLO 5 includes iLO Advanced License plus highcapabilities, like Automatic FW recovery; Runtime FW verification, and Secure erase. Learn more about HPE iLO Advanced Premiu
HPE Insight Cluster Management Utility is a HyperScale management framework that includes softw
provisioning, management and monitoring of nodes and infrastructure. Learn more at
.
entire portfolio of rack and power products to make IT infrastructure more secure, more practical, and more efficient. In oth
we’ve created a stronger, smar
Hewlett Packard Enterprise
access.
HPE G2 Advanced and Enterprise Racks are perfect for the server room or today’s modern data center with enhanced airflow and
thermal management, flexible cable management, and a 10 year Warranty to support higher density computing.
HPE G2 PDUs offer reliable power in flexible form factors that operate at temperatures up to 60°, include colorload segments and a low-profile design for optimal access to the rack and support for dense rack environments.
HPE Uninterruptible Power Systems are cost-effective power protection for any type workload. Some UPSs include options for remote
management and extended runtime modules so you’re critical dense data center is covered in power outages.
HPE KVM Solutions include a console and switches designed to work with your server and IT equipment reliably. We’ve got a costeffective KVM switch for your first rack and multiple connection IP switches with remote management and security capabilities
keep your data center rack up and running.
SCE is a guided self-service tool to help sales and non-technical people provide customers with initial configurations
You may then send the configuration on for configuration help, or use in your existing ordering processes. If you require "cu
configuration or configuration for products not available in SCE, please contact Hewlett Packard Ent
or an Authorized Partner for assistance. https://h22174.www2.hpe.com/SimplifiedConfig/Welcome#
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Service and Support
Page 13
HPE Pointnext - Service and Support
Protect your business beyond warranty with HPE Support Services
ces
ervices
rations
ive new
is
ready to bring together all the pieces of the puzzle for you, with an eye on the future, and make the complex simple.
Connect your devices:
wn
you will receive
failure alerts, automatic call logging, and automatic parts dispatch. HPE Proactive Care Service and HPE
optimization. All of
Learn more about getting connected at http://www.hpe.com/services/getconnected
Other related Services
bringing
https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-9356EN.pdf
HPE Education Services
Book on a class today and learn
how to get the most from your technology investment. http://www.hpe.com/ww/learn
HPE Support Center
usiness
e with
allows you to resolve issues yourself or quickly connect to an agent for live support. Now, you
arranty, HPE Support Service
For more information: http://www.hpe.com/services
Parts and Materials
supported replacement parts and materials necessary to maintain the covered hardware
specs, or the technical product data sheet will not be provided, repaired, or replaced
ckard
HPE Pointnext provides a comprehensive portfolio including Advisory and Transformational, Professional, and Operational Servi
to help accelerate your digital transformation. From the onset of your transformation journey, Advisory and Transformational S
focus on designing the transformation and creating a solution roadmap. Professional Services specializes in creative configu
with flawless and on-time implementation, and on-budget execution. Finally, operational services provides innovat
approaches like Flexible Capacity and Datacenter Care, to keep your business at peak performance. Hewlett Packard Enterprise
Unlock all of the benefits of your technology investment by connecting your products to Hewlett Packard Enterprise. Reduce do
time and improve diagnostic accuracy with a single consolidated view of your environment. By connecting,
24x7monitoring, preDatacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase
these benefits are already available to you with your server storage and networking products, securely connected to HPE support.
HPE Server Hardware Installation
Provides for the basic hardware installation of HPE branded servers, storage devices and networking options to assist you in
your new hardware into operation in a timely and professional manner.
Keep your IT staff trained making sure they have the right skills to deliver on your business outcomes.
The HPE Support Center is a personalized online support portal with access to information, tools and experts to support HPE b
products. Submit support cases online, chat with Hewlett Packard Enterprise experts, access support resources or collaborat
peers. Learn more http://www.hpe.com/support/hpesc
The HPE Support Center Mobile App*
can get access to personalized IT support anywhere, anytime.
HPE Insight Remote Support and HPE Support Center are available at no additional cost with a HPE w
or HPE contractual support agreement.
*HPE Support Center Mobile App is subject to local availability.
Hewlett Packard Enterprise will provide HPEproduct in operating condition, including parts and materials for available and recommended engineering improvements.
Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the
manufacturer's operating manual, product quickas part of these services.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by Hewlett Pa
Enterprise due to malfunction.
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Configuration Information
Page 14
1. Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section of
y additional options
**These SKUs are not currently available in all countries. Please contact your local sales representative for additional information
Entry Model
Base Model
SKU Number
**878968-B21
**878970-B21
Model Name
HPE ProLiant DL160 Gen10 3106 1.7GHz 8-core
1P 16GB-R S100i 4LFF 1x500W PS Server
HPE ProLiant DL160 Gen10 4110 2.1GHz 8core 1P 16GB-R S100i 8SFF 1x500W PS Server
Chassis
4LFF
8SFF
Processor
3106 (1.7GHz/8-core/85W)
4110 (2.1GHz/8-core/85W)
Number of Processors
One processor
With standard heatsink
One processor
With standard heatsink
Memory
16 GB RDIMM 1R 2666 MT/s
limitation
16 GB RDIMM 1R 2666 MT/s
limitation.
Network Controller
Embedded 2-port 1GbE
Embedded 2-port 1GbE
Storage Controller
Embedded 14-port S100i
NOTE:
Embedded 14-port S100i
NOTE: SATA only.
Hard Drive
None included
None included
Optical Drive
None included
None included
PCIe Slots
2 PCIe: 1 x16 FH / 1 x8 LP
2 PCIe: 1 x16 FH / 1 x8 LP
Power Supply
1x 500W Hot Plug
1x 500W Hot Plug
Fans
3 - Standard
3 - Standard
Management
HPE iLO 5
HPE iLO 5
Rail Kit
1U Easy Install
1U Easy Install
Energy Star
Energy Star 2.1
Form Factor
1U Rack
Warranty
3-year parts, 3-year labor, 3-year onsite support with next business day response.
NOTE: UEFI is the standard default for all Pre-configured models.
this QuickSpecs.
2. Hewlett Packard Enterprise does not allow factory integration of options into pre-configured models. An
purchased will be shipped separately.
(1x 16 GB)
NOTE: Runs at 2133 MT/s due to processor
(1x 16 GB)
NOTE: Runs at 2400 MT/s due to processor
SATA only.
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Core Options
Page 15
HPE Processors
Processor Option Kits
HPE DL160 Gen10 Intel Xeon-Silver 4110 (2.1GHz/8-core/85W) Processor Kit
878947-B21
HPE DL160 Gen10 Intel Xeon-Bronze 3106 (1.7GHz/8-core/85W) Processor Kit
878945-B21
NOTE: Up to two processors supported.
NOTE: Turbo2: Intel® Turbo Boost Technology 2.0 provides more computing power when you need it with performance that
adapts to spikes in your workload and delivers more performance upside than then previou
NOTE:
of DIMMs installed.
NOTE:
NOTE: Maximum memory per socket depends on the processor.
Memory Selection
To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability,
Packard
Enterprise
HPE Memory
HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit
815098-B21
NOTE: Memory DIMM availability with a server platform is dependent upon completion of certification testing.
NOTE: The maximum memory speed is a function of the memory type, memory configuration, and processor model.
HPE Drives
Enterprise - 12G SAS - SFF Drives
HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872475-B21
HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872477-B21
HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872479-B21
Midline - 12G SAS - LFF Drives
HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
833926-B21
Midline - 6G SATA - LFF Drives
HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
861686-B21
SSD Selection
To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability, Hewlett Packard
Enterprise
To further assist with configuration, HPE also offers an SSD Selector Tool located here: http://ssd.hpe.com
SAS - Mixed Use - SFF - Solid State Drives
HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04525-B21
SATA - Mixed Use - SFF - Solid State Drives
HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P07922-B21
HPE Networking
FlexibleLOM adapters
HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter
817749-B21
NOTE: The HPE ProLiant DL160 Gen10 chassis ships with 2x 1 Gb embedded.
NOTE: Only one FlexibleLOM can be added to the server. These options are upgradeable and can be changed from the original
configuration after the server is shipped.
NOTE:
s generation turbo technology.
DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on the quantity and type
The xxxxxx-B21 is the 2nd processor and ships with 3 additional fans for factory or field installation.
Hewlett
recommends memory from the list located here: http://www.hpe.com/products/recommend.
recommends SSDs from the list located here: http://www.hpe.com/products/recommend.
.
FlexibleLOM Enablement Kit (875748-B21) is required to install these adapters
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Core Options
Page 16
HPE I/O Expansion Options
HPE DL160 Gen10 FlexibleLOM/NVMe Riser Kit
875748-B21
NOTE: Supported on CPU1
NOTE: This riser is mandatorily required to use FlexibleLOM adapters
HPE DL160 Gen10 CPU2 x16 PCIe Riser Kit
866436-B21
NOTE: Requires second processor to be installed
HPE Power Supplies
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
865408-B21
NOTE: Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard C-14 power inlet connector.
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Additional Options
Page 17
Embedded Management
HPE iLO Advanced
HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
E6U59ABE
HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
512485-B21
HPE iLO Advanced Flexible Quantity License with 1yr Support on iLO Licensed Features
512486-B21
HPE iLO Advanced AKA Tracking License with 1yr Support on iLO Licensed Features
512487-B21
HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
E6U64ABE
HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
BD505A
HPE iLO Advanced Flexible Quantity License with 3yr Support on iLO Licensed Features
BD506A
HPE iLO Advanced AKA Tracking License with 3yr Support on iLO Licensed Features
BD507A
HPE iLO Advanced Security
HPE iLO Advanced Premium Security Edition License with 1yr Support on Licensed Features
Q7E31A
HPE iLO Advanced Premium Security Flex Qty License with 1yr Support on Licensed Features
Q7E32A
HPE iLO Advanced Premium Security Edition Electronic License with 1yr Support on Licensed Features
Q7E32AAE
HPE iLO Advanced Premium Security AKA Tracking License with 1yr Support on Licensed Features
Q7E35A
HPE iLO Advanced Premium Security Upgrade Electronic License with 3yr Support on Licensed Features
Q7E12AAE
HPE iLO Advanced Premium Security Edition License with 3yr Support on Licensed Features
Q7E33A
HPE iLO Advanced Premium Security Flex Qty License with 3yr Support on Licensed Features
Q7E34A
HPE iLO Advanced Premium Security Edition Electronic License with 3yr Support on Licensed Features
Q7E34AAE
HPE iLO Advanced Premium Security AKA Tracking License with 3yr Support on Licensed Features
Q7E36A
NOTE: There is no Oneview support on the HPE ProLiant DL160 Gen10
HPE Smart Array Controllers
The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed breakout
of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet.
Performance RAID Controllers
), which supports multiple
devices and is sold separately.
HPE Smart Array P408i-a SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS Modular LH Controller
869081-B21
NOTE: Does not occupy a PCIe expansion slot.
Essential RAID Controllers
HPE Smart Array E208i-a SR Gen10 (8 Internal Lanes/No Cache) 12G SAS Modular LH Controller
869079-B21
NOTE: Does not occupy a PCIe expansion slot.
HPE Smart Array E208i-p SR Gen10 (8 Internal Lanes/No Cache) 12G SAS PCIe Plug-in Controller
804394-B21
HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller
804398-B21
NOTE: All performance RAID controllers are supported by the HPE Smart Storage Battery (P01366-B21
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Additional Options
Page 18
HPE Cable Options
HPE 1U Gen10 4LFF Smart Array SAS Cable Kit
866452-B21
HPE 1U Gen10 8SFF Smart Array SAS Cable Kit
866448-B21
Optional Software
HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU
Q2F26AAE
HPE Smart Array SR SmartCache (Single Key/Single Server) LTU
D7S26A
HPE Smart Array SR SmartCache (Single Key/Multiple Servers) LTU
D7S27A
HPE Smart Array SR SmartCache (Single Key/Multiple Servers) E-LTU
D7S27AAE
NOTE: SmartCache is offered on HPE Smart Array performance RAID controllers and comes standard (no licensing is required) if
the HPE Smart Array P816i-a SR Gen10 Controller is installed in the server.
Optional Upgrades
HPE 96W Smart Storage Battery (up to 20 Devices/145mm Cable) Kit
P01366-B21
NOTE: Provides backup power for multiple HPE Smart Array controllers or other devices. Is required with performance RAID
controllers.
HPE Tape Backup
http://www.hpe.com/storage/BURAcompatibility
HPE Racks
HPE Power Distribution Units (PDUs)
for information on these products and their
for information on these products and their
for information on these products and their
for information on these products
and their specifications.
HPE Uninterruptible Power Systems (UPS)
for information on these products
on these products and their
specifications.
HPE Rack Options
NOTE: For the complete range of tape drives, autoloaders, libraries and media see:
https://www.hpe.com/us/en/storage/storeever-tape-storage.html.
For hardware and software compatibility of Hewlett Packard Enterprise tape backup products
.
NOTE: Please see the HPE Advanced Series Racks QuickSpecs for information on additional racks options and rack specifications.
NOTE: Please see the HPE Enterprise Series Racks QuickSpecs for information on additional racks options and rack specifications.
NOTE: Please see the HPE Basic Power Distribution Units (PDU) QuickSpecs
specifications.
NOTE: Please see the HPE Metered Power Distribution Units (PDU) QuickSpecs
specifications.
NOTE: Please see the HPE Intelligent Power Distribution Unit (PDU) QuickSpecs
specifications.
NOTE: Please see the HPE Metered and Switched Power Distribution Units (PDU) QuickSpecs
NOTE: To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web page.
NOTE: Please see the HPE DirectFlow Three Phase Uninterruptible Power System QuickSpecs
and their specifications.
NOTE: Please see the HPE Line Interactive Single Phase UPS QuickSpecs for information
NOTE: Please see the HPE IT Access and Control for information on these products and their specifications.
QuickSpecs
HPE ProLiant DL160
Gen10 Server
Memory
Page 19
Memory Population guidelines
HPE DL160/DL180 Gen 10 Servers Front Server
(2+1+1 slots per channel)
HPE ProLiant Gen10 8 slot per CPU DIMM population order
*Unbalanced, not recommended
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Memory
Page 20
General Memory Population Rules and Guidelines:
To realize the performance memory capabilities listed in this document, HPE DDR4 SmartMemory is required. For additional
information, please see the HPE DDR4 SmartMemory QuickSpecs.
HPE DDR4 SmartMemory
DIMM Type
Register DIMM (RDIMM)
HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-1919-19 Registered Smart Memory Kit
815098-B21
SKU Description
HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19
Registered Smart Memory Kit
DIMM Rank ->
Single Rank (1R)
DIMM Capacity ->
16GB
Voltage
1.2V
DRAM depth [bit]
2G
DRAM Width [bit]
x4
DRAM Density
8Gb
CAS Latency
19-19-19
DIMM Native Speed (MT/s)
2666 MT/s
HPE Server Memory Speed (MT/s): Intel Xeon®Platinum 41xx Processors *
1 DIMM Per Channel
2 DIMM Per Channel
2400 MT/s
HPE Server Memory Speed (MT/s): Intel Xeon®Platinum 31xx Processors *
1 DIMM Per Channel
2133 MT/s
2 DIMM Per Channel
2133 MT/s
NOTE: The maximum memory speed is a function of the memory type, memory configuration, and processor model.
Standard and Maximum Memory Capacity (Pre-configured Models)
Pre Configured
Models
3106 Entry LFF
16GB (1x16 GB RDIMM DR)
256 GB (16x 16 GB)
4110 Base SFF
16GB (1x16 GB RDIMM DR)
256 GB (16x 16 GB)
DDR4 memory options part number decoder
• Install DIMMs only if the corresponding processor is installed.
• If only one processor is installed in a two-processor system, only half of the DIMM slots are available.
• To maximize performance, it is recommended to balance the total memory capacity between all installed processors.
• When two processors are installed, balance the DIMMs across the two processors.
• White DIMM slots denote the first slot to be populated in a channel.
• The maximum memory speed is a function of the memory type, memory configuration, and processor model.
• The maximum memory capacity is a function of the number of DIMM slots on the platform, the largest DIMM capacity qualified
on the platform, the number and model of installed processors qualified on the platform.
•
2400 MT/s
Standard Memory Maximum Memory
NOTE: Capacity references are rounded to the common gigabyte (GB) values.
• 16GB = 16,384 MB
For more information on memory, please see the Memory Quickspecs: HPE DDR4 SmartMemory
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Technical Specifications
Page 21
System Unit
Dimensions
4.29 x 43.46 x 61.49 cm
1.69 x 17.11 x 24.21 in
Weight (approximate)
24.19lb
10.97
30.69 lb
13.92 kg
25
11.65 kg
34.69
15.74kg
SFF Minimum: 8 SFF chassis with 1x SFF HDD, 1 X Memory DIMM, 3 Fans,
1 Processor with heatsink, 1 power supply
SFF Maximum: 8SFF chassis with 8 SFF HDD, 1 X Memory DIMM, 6 Fans,
2 Processors with heatsink, 2 power supplies
LFF Minimum: 4 LFF chassis with 1X LFF Hard Drive, 1X Memory DIMM,
3 Fans, 1 Processor with heatsink, 1 power supply
LFF Maximum: 4 LFF chassis with 4X LFF Hard Drive, 1X Memory DIMM,
6 Fans, 2 Processors with heatsink, 2 power supplies
Input Requirements
Rated Line Voltage
100 to 120 VAC
200 to 240 VAC
BTU Rating
Maximum
For 500W Power Supply: 1979 BTU/hr (at 100 VAC), 1911 BTU/hr (at
200 VAC), 1965 BTU/hr (at 240 VAC) for China Only
Power Supply Output
Rated Steady-State Power
For 500W Power Supply: 500W (at 100 VAC), 500W (at 240 VAC), 500W
(at 240 VAC) input for China only
Maximum Peak Power
For 500W Power Supply: 500W (at 100 to 127 VAC), 500W (at 200 to
240 VAC), 500W (at 240 VAC) input for China only
System Inlet Temperature
Standard Operating
Temperature
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C
per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum
of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of
change is 20°C/hr (36°F/hr). The upper limit and rate of change may be
limited by the type and number of options installed.
System performance during standard operating support may be reduced
if operating with a fan fault or above 30°C (86°F).
Extended Ambient
Operating Temperature
For approved hardware configurations, the supported system inlet range
is extended to be: 5° to 10°C (41° to 50°F) and 35° to 40°C (95° to
104°F) at sea level with an altitude derating of 1.0°C per every 175 m
(1.8°F per every 574 ft) above 900 m (2953 ft) to a maximum of 3050
m (10,000 ft). The approved hardware configurations for this system are
listed at the URL:
http://www.hpe.com/servers/ashrae
For approved hardware configurations, the supported system inlet range
is extended to be: 40° to 45°C (104° to 113°F) at sea level with an altitude
derating of 1.0°C per every 125 m (1.8°F per every 410 ft) above 900 m
(2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware
configurations for this system are listed at the URL:
http://www.hpe.com/servers/ashrae
System performance may be reduced if operating in the extended
ambient operating range or with a fan fault.
Non-operating
-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr
(36°F/hr).
(per power supply)
kg
.69 lb
lb
,
(per power supply)
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Technical Specifications
Page 22
Relative Humidity
Operating
8% to 90% - Relative humidity (Rh), 28°C maximum wet bulb temperature,
non-condensing.
(non-condensing)
Non-operating
5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb
temperature, non-condensing..
Altitude
Operating
3050 m (10,000 ft). This value may be limited by the type and number of
options installed. Maximum allowable altitude change rate is 457 m/min
(1500 ft/min).
Non-operating
9144 m (30,000 ft). Maximum allowable altitude change rate is 457
m/min (1500 ft/min).
Acoustic Noise
Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander
position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient
environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared
in accordance with ISO 9296 (ECMA 109). The listed sound levels apply to standard shipping
configurations. Additional options may result in increased sound levels. Please have your HPE
representative provide information from the HPE EMESC website for further technical details
regarding the configurations listed below.
Configuration SKU
LFF Config
SFF Config
Idle
LWAd
4.5 B
4.5 B
LpAm
28.1 dBA
27.8 dBA
Operating
LWAd
5.1 B
5.1 B
LpAm
34.0 dBA
33.0 dBA
NOTE: Acoustics levels will vary depending on system configuration. Values are based on below
configurations and are for reference only.
NOTE:
Product conformance to cited product specifications is based on sample (type) testing,
evaluation, or assessment. This product or family of products is eligible to bear the appropriate
NOTE:
B 3104 processor, two HP 4TB SATA
7.2K LFF HDD, two 8GB PC4
NOTE:
S 4108 processor, two HP 500GB 6G
SATA 7.2K SFF HDD, two 16GB
R, three system fans, one 1U 500W 12V HTPLG RED
HE
Emissions Classification (EMC) – Regulatory Information
http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts
Additional options may result in increased sound levels.
NOTE:
compliance logos and statements.
LFF configuration included one Intel SKL-SP Xeon-
-2666V-R, three system fans and one 500W 12V no AUX Pwr Sply.
SFF configuration included one Intel SKL-SP Xeon-
PC4-2666V-
-P-A, one Smart Array E208i-a SR Gen10 Ctrlr.
To view the regulatory information for your product, view the Safety and Compliance Information for Server, Storage, Power,
Networking, and Rack Products, available at the Hewlett Packard Enterprise Support Center:
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Technical Specifications
Page 23
HPE Smart Array
https://h20195.www2.hpe.com/v2/getdocument.aspx?docname=a00047736enw
Environment-friendly Products and Approach - End-of-life Management and Recycling
, in many geographic areas, for our
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by
who
integrate and re-sell Hewlett Packard Enterprise equipment.
For latest information on HPE Smart Array Gen10 Controllers for HPE ProLiant DL, ML and Apollo Servers
QuickSpecs. (E208i-a,E208i-p,E208e-p,P408i-a,P408i-p,P408e-p,P816i-a)
Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling programs
products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.
treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site. These
instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM customers
please refer to their
QuickSpecs
HPE ProLiant DL160 Gen10 Server
Summary of Changes
Page 24
Date
Version History
Action
Description of Change
04-Feb-2019
Version 1
New
New QuickSpecs
Sign up for updates
© Copyright 2019 Hewlett Packard Enterprise Development LP. The information contained herein is subject
to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set
forth in the express warranty statements accompanying such pr
be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for
technical or editorial errors or omissions contained herein.
Intel and Xeon are registered trademarks of In
Microsoft, Windows, and Windows Server are U.S. registered trademarks of the Microsoft group of companies.
For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less
a00021860enw – 16057 - Worldwide - V1 - 04- February -2019
oducts and services. Nothing herein should
tel Corporation in the U.S. and other countries.
Loading...
