HPE P17201-B21 Product Data Sheet

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Overview

HPE ProLiant DL325 Gen10 Server

The HPE ProLiant DL325 Gen10 Server is the secure and versatile single socket server for virtualization and I/O intensive workloads. This

Get the most out of

your virtualized environment with this versatile server.

8SFF Front View – 8SFF + ODD Shown

Quick removal access panel

USB 3.0 port

Serial no. label pull tab

NIC status LED

Optional Media Bay*

iLO Service Port

Power On/Standby button and system power LED

UID button/LED

Health LED

10.

Standard 8 SAS/SATA drive bays

NOTE:Option Shown: DVD-RW or DVD-ROM NOTE: NOTE:

1P, 1U server delivers an exceptional balance of processor, memory and I/O for 2P performance at 1P TCO.

Option: +2 SFF SAS/SATA (total 10 SFF) Option: +2 SFF NVMe drives

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Overview

NVMe SFF Front View – 10 SFF NVMe Shown

Quick removal access panel

USB 3.0 port

Serial no. label pull tab

NIC status LED

Optional Media Bay*.

iLO Service Port

Power On/Standby button and system power LED

UID button/LED

Health LED

10.

Standard 8 NVMe drive bays

NOTE:*Option Shown: +2 SFF NVMe drives (total 10SFF NVMe) NOTE: NOTE:*Option: DVD-RW or DVD-ROM

4LFF Front View – with Optional ODD shown

Quick removal access panel

UID button/LED

Optional: DVD-RW or DVD-ROM shown

NIC status LED

Serial no. label pull tab

8 Health LED

iLO Service Port

Power On/Standby button and system power LED

USB 3.0 Port

10.

Standard 4 SAS/SATA drive bays

*Option: +2 SFF SAS/SATA

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Overview

Internal View 8SFF chassis –with optional FlexLOM, Smart array shown

Fan cage shown with 5 Performance Hot-swappable fans

Hot Plug redundant HPE Flexible Slot Power supplies

Optional HPE Smart Storage Battery

Optional HPE Flexible Smart Array Controller (P408i-a shown)

Hard drive Backplane Power Connector

Serial Port Connector

Chassis intrusion detection connector

(Under) Optional Flexible LOM slot

Processor (heatsinks shown)

Primary PCIe riser, standard

DDR4 DIMM slots. Shown fully populated in 16 slots

Internal USB 3.0 connector

Connection for second (optional) riser

MicroSD card slot

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Overview

Rear View – With optional Fl1exLOM shown.

Slot 1 PCIe 3.0

iLO Management Port

Slot 2 PCIe 3.0

UID LED

Optional Slot 3 PCIe 3.0

Embedded 4x 1GbE Adapter

HPE Flexible Slot Power Supply Bay

VGA Port

USB 3.0 Ports

Option: FlexibleLOM (Shown: 4x 1GbE)

NOTE: Supports Various NICs up to 25GbE.

What’s New

•

• Support for GPU - Tesla NVIDIA T4 for improving computational performance

Platform Information

Form Factor

1U rack

Chassis Types

8 SFF with optional Optical Drive, 2 SFF SAS/SATA or 2 NVMe drive bay options 8 SFF NVMe with optional Optical Drive 2 SFF SAS/SATA or 2 NVMe drive bay options 4 LFF with an optional Optical Drive bay

NOTE: The 8 SFF can be upgraded with either an additional 2SFF SAS/SATA kit for a total 10 SAS/SATA drives or 2SFF NVMe

Kit for a total of 8 SAS/SATA + 2 NVMe drives.

NOTE:

10 NVMe drives or 2SFF

SAS/SATA kit for a total of 8NVMe + 2 SAS/SATA drives.

System Fans

4LFF Chassis includes 5 Single Rotor Hot Swappable cable fans 8SFF Chassis includes 5 Dual Rotor Hot Swappable cable fans NVMe Chassis includes 7 Dual Rotor Hot Swappable cable fans

New 64GB RDIMMS using the 16Gb memory technology providing better performance and power efficiency New SATA Read Intensive SSD drives New NVMe Read Intensive and Mixed Use SSD drives AMD® EPYC® 7000 Processor Family Support for upto 10 NVMe drives Support for PCIe Smart Array controllers for internal drives Support for AMD® EPYC® 7371 processor

The NVMe chassis can be upgraded with either an additional 2SFF NVMe kit for a total of

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Standard Features

AMD EPYC

Processor

Base

Frequency

Max

Frequency

Max

Memory

EPYC 7601

2.2GHz

3.2GHz

2TB

180

64MB

2666MT/S

EPYC 7501

2.0GHz

3.0GHz

2TB

155/170

64MB

2666MT/S

EPYC 7451

2.3GHz

3.2GHz

2TB

180

64MB

2400/2666MT/S

EPYC 7401P

2.0GHz

3.0GHz

2TB

155/170

64MB

2400/2666MT/S

EPYC 7301

2.2GHz

2.7GHz

2TB

155/170

64MB

2400/2666MT/S

EPYC 7281

2.1GHz

2.7GHz

2TB

155/170

32MB

2400/2666MT/S

EPYC 7261

2.5GHz

2.9GHz

2TB

155/170

64MB

2400/2666MT/S

EPYC 7251

2.1GHz

2.9GHz

2TB

120

32MB

2400MT/S

EPYC 7371

3.1GHz

3.8GHz

2TB

155/170

64MB

2400/2666MT/S

NOTE: All AMD EPYC processors can support up to 2TB of memory each.

Chipset

No chipset – System on Chip (SoC) design.

On System Management Chipset

NOTE: Read and learn more in the iLO QuickSpecs.

Memory

One of the following depending on model

Type:

HPE DDR4 SmartMemory, Registered (RDIMM), Load Reduced (LRDIMM)

DIMM Slots Available

16 DIMM slots per processor, 8 channels per processor, 2 DIMMs per channel

Maximum capacity (LRDIMM)

2.0 TB

16 x 128 GB LRDIMM @ 2666 MT/S

Maximum capacity (RDIMM)

1.0 TB

16 x 64 GB RDIMM @ 2666 MT/S

NOTE: The maximum memory speed is limited by the processor selection.

NOTE:

Expansion Slots

Default Primary Riser

Slots #

Technology

Bus

Width

Connector

Width

Slot Form Factor

Notes

PCIe 3.0

X16

X16 Full-height,

full-length slot

Proc 1

PCIe 3.0

X8 Low Profile

Proc 1

NOTE: Bus Width Indicates the number of physical electrical lanes running to the connector.

Processors – One of the following depending on model.

NOTE: For more information regarding AMD EPYC processors, please see the following:

https://www.amd.com/en/products/epyc.

Cores

Wattage Cache

EPYC 7551P 32 2.0GHz 3.0GHz 2TB 180 64MB

EPYC 7351P 16 2.4GHz 2.9GHz 2TB 155/170 64MB

HPE iLO 5 ASIC

NOTE: Mixing of RDIMM and LRDIMM memory is not supported.

When 2DIMMs are populated per channel, memory speed drops to 2133 MT/S

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Standard Features

Secondary Riser

Slots #

Technology

Bus

Width

Connector

Width

Slot Form Factor

Notes

PCIe 3.0

X16

X16 Low Profile

Proc 1

NOTE: Secondary riser cannot be installed with Modular Smart Array Options NOTE:

Storage Controllers

kout

One of the following depending on model

Software RAID

For legacy support an additional controller will

HPE Smart Array S100i SR Gen10 SW RAID is supported only on 4LFF chassis or when optional 2SFF SAS/SATA Kit is

NOTE: HPE Smart Array S100i SR Gen10 SW RAID can support M.2 SSDs

Essential RAID Controller

HPE Smart Array E208e-p SR Gen10 Controller

Performance RAID Controller

NOTE:

Internal Storage Devices

One of the following depending on model

Optical Drive

Optional: DVD-ROM, DVD-RW

Hard Drives

None ship standard

Maximum Internal Storage

Capacity

Configuration

Hot Plug SFF SAS

24.0 TB

8+2 x 2.4 TB (with optional 2SFF drive cage)

Hot Plug SFF SATA

20.0 TB

8+2 x 2 TB (with optional 2SFF drive cage)

Hot Plug LFF SAS

56 TB

4 x 14 TB

Hot Plug LFF SATA

56 TB

4 x 14 TB

Hot Plug SFF SAS SSD

153 TB

8+2 x 15.3 TB (with optional 2SFF drive cage)

Hot Plug LFF SATA SSD

7.68 TB

4 x 1.92 TB

Hot Plug SFF SATA SSD

76.8 TB

8+2 x 7.68 TB (with optional 2SFF drive cage)

Hot Plug SFF NVMe PCIe SSD

76.8 TB

8+2 x 7.68 TB

Bus width indicated the number of physical electrical lanes running to the connector.

The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed brea of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet.

HPE Smart Array S100i SR Gen10 SW RAID

NOTE: HPE Smart Array S100i SR Gen10 SW RAID will operate in UEFI mode only. be needed, and for CTO orders please also select the Legacy mode settings part, 758959-B22.

NOTE: HPE Smart Array S100i SR Gen10 SW RAID is off by default and must be enabled. NOTE: HPE Smart Array S100i SR Gen10 SW RAID can operate only in Windows OS NOTE:

selected on the 8SFF chasiss/ 8SFF SFF NVMe chassis. NOTE: A maximum of 4 devices can be connected to HPE Smart Array S100i SR Gen10 SW RAID.

HPE Smart Array E208i-a SR G10 LH Controller

HPE Smart Array P408i-a SR G10 LH Controller HPE Smart Array P408e-p SR Gen10 Controller HPE Smart Array P816i-a SR G10 LH Controller

Performance RAID Controllers require the HPE Smart Storage Battery (P01366-B21) which is sold separately.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Standard Features

Power Supply

less

efficiency operation and

size" a power supply for specific server configurations. This flexibility

14 jumper cord (A0K02A). This jumper cord is also included with

Interfaces

Serial

Optional, rear

Video Port

1 Rear VGA Port - Standard

Network Ports

4 x 1 Gb ports shipping standard with optional FlexibleLOM or stand up card

HPE iLO Remote Management Network Port

1 Gb Dedicated

Front iLO Service Port

1 standard

Micro SD Slot

1 Micro SD

NOTE: The Micro SD slot is not a hot-pluggable device. Customers should not attempt to plug an SD card into the SD slot while

the server is powered.

USB 3.0

Up to 4 total: 1 front, 2 rear, 1 internal (secure)

HPE 500W Non Hot Plug Low Halogen FIO Power Supply

NOTE: Available in 92% efficiency.

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% efficiency.

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% and 96% efficiency. NOTE: Also available in -48VDC and 227VAC/380VDC power inputs.

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% efficiency. NOTE: 240v power input only.

The HPE 500W FIO Power Supply offers Gold-certified 80 Plus power efficiency up to 92% with an optimized set of features for nonredundant power configurations for Gen10 ProLiant ML 10/100 Series Servers, as well as ML350 Gen10 and DL325 Gen10.

HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, toolinstallation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for highoffer multiple power output options, allowing users to "righthelps to reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center.

All pre-configured servers ship with a standard 6-foot IEC C-13/Ceach standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page.

To review the power requirements for your selected system, please use the HPE Power Advisor Tool.

For information on power specifications and technical content visit HPE Server power supplies.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Standard Features

Operating Systems and Virtualization Software Support for ProLiant Servers

premise solutions without sacrificing security and ease of use. HPE

an intuitive web based graphical user

premise, and an Application Marketplace with over 100 apps and growing. Whether

CentOS

CentOS not directly supported / Community Supported (Based on RHEL so RHEL testing and enablement applicable to

or more information on Hewlett Packard Enterprise Certified and Supported ProLiant Servers for OS and Virtualization

Software and latest listing of software drivers available for your server http://www.hpe.com/info/ossupport.

Industry Standard Compliance

For additional technical thermal details regarding ambient temperatures, humidity and features support please

Windows Server 2012 R2 (Most Recent Version) Windows Server 2016 (Most Recent Version) VMware ESXi 6.5 U2 and 6.7 Red Hat Enterprise Linux (RHEL) 7.4 and 7.5 SUSE Linux Enterprise Server (SLES) 12 SP3 ClearOS

HPE and ClearCenter will help you lower the cost of building onProLiant servers with ClearOS give you a simple, secure, and affordable operating system with interface that provides a cloud-like experience onyou’re starting out or scaling, you decide what applications you need and pay as you grow.

NOTE: ClearOS allows you to build a fully functional server that is just right for you at no upfront cost. For more information on ClearOS, please visit http://www.hpe.com/servers/clearos

NOTE: CentOS) CentOS 7.4/ CentOS 7.5 NOTE: F

ACPI 6.1 Compliant PCIe 3.0 Compliant WOL Support Microsoft® Logo certifications PXE Support VGA Port USB 3.0 Compliant (internal) USB 2.0 Compliant (external ports via SUV) Energy Star SMBIOS 3.1 UEFI 2.6 Redfish API IPMI 2.0 Secure Digital 2.0 Advanced Encryption Standard (AES) Triple Data Encrytion Standard (3DES) SNMP v3 TLS 1.2 DMTF Systems Management Architecture for Server Hardware Command Line Protocol (SMASH CLP) Active Directory v1.0 ASHRAE A3/A4

NOTE:

visit: http://www.hpe.com/servers/ashrae.

UEFI (Unified Extensible Firmware Interface Forum)

NOTE: UEFI is the default for the DL325 Gen10. Legacy mode can be selected in the field or as a CTO option (758959-B22).

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Standard Features

Graphics

• 4 Gbit DDR 3 with ECC protection

HPE Server UEFI/Legacy ROM

Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured

legacy ROM while interacting with your server at boot time. HPE ProLiant Gen10 servers have a UEFI Class 2

ProLiant Gen10 Server.

Embedded Management

remote management with HPE iLO. Learn more

UEFI

Configure and boot your servers securely with industry standard Unified Extensible Firmware Interface (UEFI).

Intelligent Provisioning

https://www.hpe.com/us/en/product-catalog/detail/pip.5219984.html

iLO RESTful API

offers simplified server management automation such as configuration and

http://www.hpe.com/info/restfulapi

Integrated Video Standard

• Video modes up to 1920 x 1200@60Hz (32 bpp)

• 16MB Video Memory

HPE iLO 5 on system management memory

• 32 MB Flash

configuration than the implementation and support both UEFI Mode (default) and Legacy BIOS Mode.

UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:

• Secure Boot and Secure Start enable for enhanced security

• Operating system specific functionality

• Support for > 2.2 TB (using GPT) boot drives

• USB 3.0 Stack

• Embedded UEFI Shell

• Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant

• PXE boot support for IPv6 networks

• Workload Profiles for simple performance optimization

• UEFI Boot Mode only:

• TPM 2.0 Support

• NVMe Boot Support

• iSCSI Software Initiator Support.

• HTTP/HTTPs Boot support as a PXE alternative.

• Boot support for option cards that only support a UEFI option ROM

NOTE: For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI. NOTE: UEFI FIO Setting (758959-B22) can be selected to configure the system in Legacy mode in the factory for your HPE

HPE Integrated Lights-Out (HPE iLO)

Monitor your servers for ongoing management, service alerting, reporting and at http://www.hpe.com/info/ilo.

Hassle free server and OS provisioning for 1 or more servers with Intelligent Provisioning. Learn more at

iLO RESTful API is Redfish API conformance and maintenance tasks based on modern industry standards. Learn more at

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Standard Features

Server Utilities

Active Health System

ive

http://www.hpe.com/servers/ahs

Active Health System Viewer

repair

recommendations, to learn more visit: http://www.hpe.com/servers/ahsv.

Smart Update Keep your servers up to date with the HPE Smart Update solution by using Smart Update Manager (SUM) to optimize the firmware

software/hpe-system-server-software-management-software/smart-update-manager-%28sum%29/p/5182020.

iLO Amplifier Pack

Pack is a free,

Learn more at http://www.hpe.com/servers/iLOamplifierpack.

HPE iLO Mobile Application

devices.

http://www.hpe.com/info/ilo/mobileapp

RESTful Interface Tool

at scale.

http://www.hpe.com/info/resttool

Scripting Tools

Provision one to many servers using your own scripts to discover and deploy with Scripting Tool (STK) for Windows and Linux or Scripting Tools for Windows PowerShell. Learn more at http://www.hpe.com/servers/powershell.

HPE OneView Standard

nitor

defined

functionality is not available. Learn more at http://www.hpe.com/info/oneview.

HPE Systems Insight Manager (HPE SIM)

ur HPE ProLiant Servers and HPE Integrity

HPE servers. HPE SIM also integrates with Smart Update Manager to provide

quick and seamless firmware updates. Learn more at http://www.hpe.com/info/hpesim.

The HPE Active Health System (AHS) is an essential component of the iLO management portfolio that provides continuous, proact health monitoring of HPE servers. Learn more at

Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed problem resolution with HPE self-

and driver updates of the Service Pack for ProLiant (SPP). Learn more at

https://buy.hpe.com/b2c/us/en/enterprise-software/infrastructure-management-software/system-server-management-

Designed for large enterprise and service provider environments with hundreds of HPE servers, the iLO Amplifier downloadable open virtual application (OVA) that delivers the power to discover, inventory and update Gen8, Gen9 and Gen10 HP servers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities.

Enables the ability to access, deploy, and manage your server anytime from anywhere from select smartphones and mobile For additional information please visit:

RESTful Interface tool (iLOREST) is a single scripting tool to provision using iLO RESTful API to discover and deploy servers Learn more at

HPE OneView Standard can be used for inventory, health monitoring, alerting, and reporting without additional fees. It can mo multiple HPE server generations. The user interface is similar to the HPE OneView Advanced version, but the software-

Ideal for environments already using HPE SIM, it allows you to monitor the health of yo Servers. Also provides you with basic support for non-

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Standard Features

Security

Chassis Intrusion detection option

Warranty

for three years from date of purchase. Support for

rough

drives have either a one year or three year warranty;

Year Onsite support with next business day response. Warranty

accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1)

2) Optional CSR parts are also designed for easy replacement but may involve added complexity. replace Optional CSR parts at no charge. Additional information

http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/.

UEFI Secure Boot and Secure Start support Immutable Silicon Root of Trust FIPS 140-2 validation (iLO 5 certification in progress) Common Criteria certification (iLO 5 certification in progress) Configurable for PCI DSS compliance Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser Support for Commercial National Security Algorithms (CNSA) Tamper-free updates – components digitally signed and verified Secure Recovery – recover critical firmware to known good state on detection of compromised firmware Ability to rollback firmware Secure erase of NAND/User data TPM (Trusted Platform Module) 1.2 option TPM (Trusted Platform Module) 2.0 option Bezel Locking Kit option

This product is covered by a global limited warranty and supported by HPE Services and a worldwide network of HPE Authorized Channel Partners resellers. Hardware diagnostic support and repair is available software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available th HPE Pointnext operational services or customized service agreements. Hard refer to the specific hard drive QuickSpecs for details.

NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-

repairs may be Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replac a Mandatory CSR part; Customers may choose to have Hewlett Packard Enterprise regarding worldwide limited warranty and technical support is available at:

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Optional Features

Server Management

udes

lay, and

based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management

HPE OneView Advanced

ased

for managing Gen8, Gen9 and Gen10 servers. To learn more visit http://www.hpe.com/info/oneview.

HPE InfoSight for Servers

ght with the health and performance monitoring of

Active Health System (AHS) and iLO to optimize performance and predict and prevent problems. The end result is an intelligent

predicting and preventing the infrastructure

Learn more at https://www.hpe.com/servers/infosight

HPE Insight Cluster Management Utility (CMU) HPE Insight Cluster Management Utility is a HyperScale management framework that includes software for the centralized

http://www.hpe.com/info/cmu

Accelerator and GPU Information

Hewlett Packard Enterprise supports various accelerators on select HPE Proliant servers to support different workloads. The

performance computing, large data

m reliability and tight integration with system monitoring and management tools such as HPE

Rack and Power Infrastructure

business grow. We’ve reinvented our

er words,

t out of your IT equipment. As an industry leader,

is uniquely positioned to address the key concerns of power, cooling, cable management and system

today’s modern data center with enhanced airflow and

coded outlets and

e options for remote

HPE Rack and Power Infrastructure.

HPE iLO Advanced

HPE iLO Advanced licenses offer smart remote functionality without compromise, for all HPE ProLiant servers. The license incl the full integrated remote console, virtual keyboard, video, and mouse (KVM), multi-user collaboration, console record and rep GUIfunctionality.

HPE OneView brings a new level of automation to infrastructure management by taking a template driven approach to provisionin updating, and integrating compute, storage, and networking infrastructure. It provides full-featured licenses which can be purch

HPE InfoSight for Servers combines the cloud-based machine learning of InfoSi

environment that modernizes IT operations and enhances the support experience by issues that lead to application disruptions, wasted IT staff time and missed business opportunities.

provisioning, management and monitoring of nodes and infrastructure. Learn more at

accelerators enable seamless integration of GPU computing with HPE ProLiant servers for highcenter graphics, deep learning and virtual desktop deployments. These accelerators deliver all of the standard benefits of GP computing while enabling maximu Insight Cluster Management Utility.

The story may end with servers, but it starts with the foundation that makes compute go – and entire portfolio of rack and power products to make IT infrastructure more secure, more practical, and more efficient. In oth we’ve created a stronger, smarter, and simpler infrastructure to help you get the mos Hewlett Packard Enterprise access. HPE G2 Advanced and Enterprise Racks are perfect for the server room or thermal management, flexible cable management, and a 10 year Warranty to support higher density computing. HPE G2 PDUs offer reliable power in flexible form factors that operate at temperatures up to 60°C, include colorload segments and a low-profile design for optimal access to the rack and support for dense rack environments.

HPE Uninterruptible Power Systems are cost-effective power protection for any type workload. Some UPSs includ management and extended runtime modules so you’re critical dense data center is covered in power outages. HPE KVM Solutions include a console and switches designed to work with your server and IT equipment reliably. We’ve got a costeffective KVM switch for your first rack and multiple connection IP switches with remote management and security capabilities t keep your data center rack up and running. Learn more about HPE Racks, KVM, PDUs and UPSs at

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Optional Features

One Config Simple (SCE)

technical people provide customers with initial configurations in 3 to 5 minutes.

ire "custom" rack

Center

or an Authorized Partner for assistance. https://h22174.www2.hpe.com/SimplifiedConfig/Welcome

SCE is a guided self-service tool to help sales and nonYou may then send the configuration on for configuration help, or use in your existing ordering processes. If you requ configuration or configuration for products not available in SCE, please contact Hewlett Packard Enterprise Customer Business

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Service and Support

HPE Pointnext - Service and Support

Achieve maximum return from your IT investment

Get the expertise you need at every step of

. We help you lower your risks and costs using proven best practices, automation and methodologies that have been tested and refined by HPE experts through thousands of deployments globally.

focus on your business outcomes and goals, partnering with you to

design your transformation and build a roadmap tuned

can

be leveraged to speed up time

in flawless

and on

budget execution, and creative configurations that get the most out of software and hardware alike.

Consume IT on your terms HPE

combines the simplicity, agility, and economics of public cloud with the security and performance benefits of on With its agile pay

•

• Improve time to market by maintaining a safe buffer of capacity, ready for use when you need it

• Keep capacity ahead of demand with re

• Pay for only the capacity used, not the capacity deployed

• Reduce IT risk with tailored support

Connect your devices:

products to Hewlett Packard Enterprise. Reduce down

time and improve diagnostic accuracy with a single consolidated view of your environment. By connecting, you will receive

ispatch. HPE Proactive Care Service and HPE

n. All of

Learn more about getting connected at http://www.hpe.com/services/getconnected

HPE Proactive Care

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care helps

a 4

reactive support when there is a problem with

experience and start to finish case management with proactive reporting and advice. This service also includes

the most of these services and

receive all the deliverables

HPE Proactive Care Advanced

includes personalized support from a

local, assigned Account Support Manager who will share best practice advice and personalized recommendations designed to help

e unplanned downtime. Leverage your system’s ability to

For business critical incidents, Proactive Care

resolution. HPE Service Credits are included to redeem for

e levels:

receive all the deliverables.

your IT journey with HPE Pointnext services and support

 With Advisory Services, we

to your unique challenges. Our Professional and Operational Services

-to-production, boost performance and accelerate your business. HPE Pointnext specializes

-time implementation, on-

GreenLake Flex Capacity

-premises IT. You determine your own “Right Mix” of Hybrid IT and workload placement without having to use.

-per-use service, HPE GreenLake Flex Capacity can help your IT organization:

Avoid IT expenses stemming from overprovisioning

gular monitoring—and a simple change order to replenish

Unlock all of the benefits of your technology investment by connecting your

24x7monitoring, pre-failure alerts, automatic call logging, and automatic parts d Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase optimizatio these benefits are already available to you with your server storage and networking products, securely connected to HPE support.

prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice. HPE Proactive Care is available in 3, 4 and 5 year terms with a choice of response levels: Next Business day (NBD), 24x7 with hour response, and 24x7 with 6 hour call to repair (CTR). This Service combines both an enhanced call collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc.).

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf 

NOTE: HPE Proactive Care requires that the customer connect their devices to HPE to help make

HPE Proactive Care Advanced incorporates all the deliverables of HPE Proactive Care plus

improve availability and performance to help increase stability and reduc connect to HPE for pre-failure alerts, automatic call logging and parts dispatch.  Advanced offers critical event management to help reduce mean time to technical and operational services. HPE Proactive Care Advanced is offered in 3, 4, and 5 year terms with a choice of respons Next Business day (NBD), 24x7 with a 4 hour response, and 24x7 with 6 hour call to repair (CTR).

https://www.hpe.com/h20195/v2/getdocument.aspx?docname=4AA5-3259ENW 

NOTE: HPE Proactive Care requires that the customer connect their devices to HPE to help make the most of these services and

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Service and Support

HPE Foundation Care– (choose the response level that meets your needs)

: Next

Repair Service

this includes our highest level commitment

d respond to software questions within two hours. In addition,

https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en 

Other related Services

bringing

https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-9356EN.pdf

HPE Education Services

Book on a class today and

HPE Support Center

usiness

e with

allows you to resolve issues yourself or quickly connect to an agent for live support. Now, you

http://www.hpe.com/services

Parts and Materials

supported replacement parts and materials necessary to maintain the covered hardware

ched their maximum supported lifetime and/or the maximum usage limitations as set forth in the

specs, or the technical product data sheet will not be provided, repaired, or replaced

Hewlett Packard

Enterprise due to malfunction.

HPE Foundation Care helps when there is a problem and is available in 3, 4, and 5 year terms with a choice of response levels Business day (NBD), 24x7 with a 4 hour response, and 24x7 with 6 hour call to repair (CTR). Note that Call-Toconnects you to HPE 24 hours a day, seven days a week for assistance on resolving issues to repair hardware within six hours after opening your case an Collaborative software support is included and provides troubleshooting assistance on industry leading software running on yo server. Simplify your support experience and make HPE your first call to help resolve hardware or software problems.

HPE Server Hardware Installation

Provides for the basic hardware installation of HPE branded servers, storage devices and networking options to assist you in your new hardware into operation in a timely and professional manner.

Keep your IT staff trained making sure they have the right skills to deliver on your business outcomes. learn how to get the most from your technology investment. http://www.hpe.com/ww/learn

The HPE Support Center is a personalized online support portal with access to information, tools and experts to support HPE b products. Submit support cases online, chat with Hewlett Packard Enterprise experts, access support resources or collaborat peers. Learn more http://www.hpe.com/support/hpesc

The HPE Support Center Mobile App* can get access to personalized IT support anywhere, anytime. HPE Insight Remote Support and HPE Support Center are available at no additional cost with a HPE warranty, HPE Support Servic or HPE contractual support agreement.

NOTE:*HPE Support Center Mobile App is subject to local availability.

For more information:

Hewlett Packard Enterprise will provide HPEproduct in operating condition, including parts and materials for available and recommended engineering improvements.

Parts and components that have rea manufacturer's operating manual, product quickas part of these services.

The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Pre

-configured Models

Entry Models

Performance Model

[SKU Number]

P04646-xx1

P04647-xx1

Model Name

HPE ProLiant DL325 Gen10 7251 2.1GHz 8-core 1P

HPE ProLiant DL325 Gen10 7351P 2.4GHz 16-core

Server

Processor

7251 (8-Core, 2.1 GHz, 120W)

7351P (16-Core, 2.4 GHz, 155/170W)

Number of Processors

One processor

Memory

8 GB RDIMM SR 2666 MT/s (1x 8 GB)

16 GB RDIMM SR 2666 MT/s (2x 8 GB)

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus optional

Storage Controller

E208i-a

NOTE: 8-Port modular Smart Array.

E208i-a

NOTE: 8-Port modular Smart Array.

Hard Drive

None ship as standard

Internal Storage

4 LFF chassis

8 SFF Chassis

Optical Drive Bay

Optional

Optical Drive

None ship as standard

PCI-Express Slots

2-slots (x16, x8) as standard

Power Supply

500W HPE Non-Hot-Plug/Non-RPS Power Supply

1x 500W HPE FlexSlot Power Supply

Fans

5-standard fans

5-performance fans

Management

Default: HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (requires download)

Optional (require licenses): HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, HPE OneView

Advanced

Energy Star

2.1 certified

Form Factor

1U Rack, Easy Install rails without CMA

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

8GB-R E208i-a 4LFF 500W PS Entry Server

HPE FlexibleLOM or stand up card

1P 16GB-R E208i-a 8SFF 1x500W PS Performance

HPE FlexibleLOM or stand up card

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Pre

-configured Models

Performance Model

[SKU Number]

P04651-xx1

P04648-xx1

Model Name

HPE ProLiant DL325 Gen10 7351P 2.4GHz 16-

Performance Server

HPE ProLiant DL325 Gen10 7401P 2GHz 24-core 1P

Processor

7351P (16-Core, 2.4 GHz, 155/170W)

7401P (24-Core, 2.0 GHz, 155/170W)

Number of Processors

One processor

Memory

16 GB RDIMM DR 2666 MT/s (1x 16 GB)

32 GB RDIMM DR 2666 MT/s (2x 16 GB)

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus

HPE 1Gb Ethernet 4-Port 331i Adapter plus optional

Storage Controller

P408i-a

Hard Drive

None ship as standard

Internal Storage

8 SFF Chassis

Optical Drive Bay

Optional

Optical Drive

Optional

PCI-Express Slots

2-slots (x16, x8) as standard

Power Supply

1x 500W HPE FlexSlot Power Supply

1x 800W HPE FlexSlot power supply

Fans

5-performance fans

Management

Default: HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (requires download)

Advanced

Energy Star

2.1 certified

Form Factor

1U Rack, Easy Install rails without CMA

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

core 1P 16GB-R P408i-a 8SFF 500W RPS

optional HPE FlexibleLOM or stand up card

NOTE: 8-Port modular Smart Array.

NOTE: Smart Storage battery included.

32GB-R P408i-a 8SFF 1x800W PS Performance Server

HPE FlexibleLOM or stand up card

NOTE: 8-Port modular Smart Array.

NOTE: Smart Storage battery included.

Optional (require licenses): HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, HPE OneView

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Pre

-configured Models

SMB Solution Model

[SKU Number]

P04649-B21/291

Model Name

HPE ProLiant DL325 Gen10 7251 2.1GHz 8-core 1P 16GB-R P408i-a 8SFF 2x500W PS Solution Server

Processor

7251 (8-Core, 2.1 GHz, 120W)

Number of Processors

One processor

Memory

16 GB RDIMM DR 2666 MT/s (1x 16 GB)

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus optional HPE FlexibleLOM or stand up card

Storage Controller

P408i-a

NOTE: Smart Storage battery included.

Hard Drive

None ship as standard

Internal Storage

8 SFF Chassis

Optical Drive Bay

Optional

Optical Drive

Optional

PCI-Express Slots

2-slots (x16, x8) as standard

Power Supply

2x 500W HPE FlexSlot power supply

Fans

5-standard fans

Software

ClearOS/ClearVM

NOTE: ClearOS/VM installer on a 8GB USB flash key pre-built inside the system.

Management

Default: HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (requires download)

Energy Star

2.1 certified

Form Factor

1U Rack, Easy Install rails without CMA

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Country Code Key

xx1 = B21

Worldwide

NOTE: The -B21 WW SKU is to be ordered in all countries other than Japan.

xx1 = 291

Japan

xx1 = AA1

PRC

NOTE: 8-Port modular Smart Array.

Optional (require licenses): HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, HPE OneView

Advanced

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Configuration Information

This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for

Step 1: Base Configuration (choose one of the following configurable models)

CTO Server

HPE ProLiant DL325 Gen10 4

LFF CTO Server

HPE ProLiant DL325 Gen10 8

SFF CTO Server

HPE ProLiant DL325 Gen10 NVMe

SFF CTO Server

SKU Number

P04653-B21

P04654-B21

P04662-B21

TAA SKU

P04652-B21

P04848-B21

P05046-B21

Processor

Not included as standard

DIMM Slots

16-DIMM slots

PCIe

Two standard in primary riser

Drive Cage -

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus optional HPE FlexibleLOM or stand up card

Fans

5-Standard

5-Performance

7-Performance

Management

HPE iLO with Intelligent Provisioning (standard), iLO Advances and OneView (optional)

Front: 1 USB 3.0 + iLO service

Internal: 1 USB 3.0

Front: 1 USB 3.0 + iLO service

Internal: 1 USB 3.0

Front: 1 USB 3.0 + iLO service port

NOTE: HPE offers multiple Trade Agreement Act (TAA) compliant configurations to meet the needs of US Federal Government

TAA compliance is only

NOTE: CTO servers do not ship with Rail Kits ,they need to be ordered seperately

information on configurable product offerings and requirements.

1. Factory Integrated Models must start with a CTO Server.

2. FIO indicates that this option is only available as a factory installable option.

3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives ordered with the server.

4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.

Storage Controller

included

USB

4 LFF 8 SFF 8 SFF NVMe

port

Rear: 2 USB 3.0

Choice of HPE modular Smart Array and PCIe plug-in controller

port

Rear: 2 USB 3.0

Internal: 1 USB 3.0

customers. These products are either manufactured or substantially transformed in a designated country. provided when HPE options are included as part of factory integrated orders (CTO).

NOTE: TAA chassis are only orderable in North America and Canada. NOTE: The HPE ProLiant DL325 Gen10 NVMe SFF CTO Server ships with the cable required for 8 NVMe drives installation. NOTE: All CTO servers are Energy Star 2.1 compliant.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Configuration Information

CTO Server

8 SFF CTO Chassis

4 LFF CTO Chassis

NVMe SFF CTO Chassis

Included Drive Cage

8 SFF SAS/SATA

4 LFF + UMB

8 NVMe Chassis

Additional drive cages

- - -

Universal Media Bay

1 Optional

1 Included

1 Optional

ODD

1 Optional with UMB

1 Optional

1 Optional with UMB

2 SFF SAS/SATA

1 Optional

Not available

1 Optional

2 SFF NVMe

1 Optional

Not available

1 Optional

NOTE: This aplies to CTO configurations, field upgrades may differ depending field configuration. NOTE: Only one of the 2 SFF SAS/SATA or 2 SFF NVMe can be selected at any time.

Step 2a: Choose Required Options – Processors (only one of the following unless otherwise noted)

Please select one –L21 processor required below.

Processor Option Kits

Required

Processor

HPE DL325 Gen10 AMD EPYC 7601 (2.2GHz/32-core/180W) FIO Processor Kit

P04851-L21

NOTE: Ships with Performance Heatsink.

HPE DL325 Gen10 AMD EPYC 7551P (2.0 GHz/32-core/180W) FIO Processor Kit

P04852-L21

NOTE: Ships with Performance Heatsink.

HPE DL325 Gen10 AMD EPYC 7501 (2.0GHz/32-core/155-170W) FIO Processor Kit

P04853-L21

NOTE: Ships with Standard Heatsink.

HPE DL325 Gen10 AMD EPYC 7451 (2.3GHz/24-core/180W) FIO Processor Kit

P04854-L21

NOTE: Ships with Performance Heatsink.

HPE DL325 Gen10 AMD EPYC 7401P (2.0GHz/24-core/155-170W) FIO Processor Kit

P04855-L21

NOTE: Ships with Standard Heatsink.

HPE DL325 Gen10 AMD EPYC 7351P (2.4GHz/16-core/155-170W) FIO Processor Kit

P04856-L21

NOTE: Ships with Standard Heatsink.

HPE DL325 Gen10 AMD EPYC 7301 (2.2GHz/16-core/155-170W) FIO Processor Kit

P04857-L21

NOTE: Ships with Standard Heatsink.

HPE DL325 Gen10 AMD EPYC 7281 (2.1GHz/16-core/155-170W) FIO Processor Kit

P04858-L21

NOTE: Ships with Standard Heatsink.

HPE DL325 Gen10 AMD EPYC 7261 (2.5GHz/8-core/155-170W) FIO Processor Kit

P05918-L21

NOTE: Ships with Standard Heatsink.

HPE DL325 Gen10 AMD EPYC 7251 (2.1GHz/8-core/120W) FIO Processor Kit

P04859-L21

NOTE: Ships with Standard Heatsink.

HPE DL325 Gen10 AMD EPYC 7371 (3.1GHz/16-core/200W) FIO Processor Kit

P12253-L21

NOTE: Ships with Standard Heatsink.

NOTE: All CTO Models ship with redundant fan configuration. NOTE: DDR4 memory speed will depend on the quantity and type of DIMMs installed. NOTE: Processors with greater than 170W will ship with the High Performance heatsink.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Configuration Information

Step 2b: Choose Memory Options

Please select one or more memory from below.

NOTE: The maximum memory speed is a function of the memory type, memory configuration, and processor model.

Registered DIMMs (RDIMMs)

HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

838079-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

838089-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

838083-B21

HPE 64GB (1x64GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

P05592-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

838081-B21

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666 CAS-19-19-19 Load Reduced Smart Memory Kit

838085-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2666 CAS-22-19-19 3DS Load Reduced Smart Memory Kit

838087-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P19041-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P19043-B21

Step 2c: Choose Power Supplies

Select one or two power supplies from below.

NOTE: Mixing of 2 different power supplies is NOT allowed.

HPE ProLiant Gen10 Entry Level Server Power Supplies – Non-Redundant

HPE 500W Low Halogen FIO Power Supply Kit

837074-B21

NOTE: This is a Factory Installed Option (FIO) only.

NOTE: Supports Gold-level efficiency (92%) with a standard C14 inlet connector. No support for HPE Power Discovery Services.

HPE ProLiant Gen10 Flexible Slot Power Supplies – Redundant

Select one or two power supplies from below.

B21) is mandatory to use any of the following

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865408-B21

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865414-B21

HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit

865438-B21

HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply Kit

865434-B21

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

830272-B21

HPE 800W Flex Slot Universal Hot Plug Low Halogen Power Supply Kit

865428-B21

NOTE: Prior to making a power supply selection it is highly recommended that the HPE Power Advisor is run to determine the

NOTE: All power supplies in a server should match. Mixing Power Supplies is not supported.

Step 3: Choose Additional Factory Integratable Options

One of the following from each list may be selected if desired at time of factory integration

HPE Unique Options

HPE DL325 Gen10 2SFF Smart Array SAS FIO Cable Kit

P05036-B21

NOTE: This option kit is required to connect the 2SFF FIO Enablement Kit (881179-B21) to E208i-a or P408i-a controller.

For new Gen10 memory population rule whitepaper and optimal memory performance guidelines, please go to:

http://www.hpe.com/docs/amd-population-rules

NOTE: Memory DIMM availability with a server platform is dependent upon completion of certification testing.

NOTE: Mixing of 2 different power supplies is NOT allowed. NOTE: HPE DL325 Gen10 Redundant Power Supply Enablement Kit (P04983-

power supplies.

right size power supply for your server configuration. The HPE Power Advisor is located at:

http://www.hpe.com/info/hppoweradvisor.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Configuration Information

HPE DL325 Gen10 8SFF Embedded SATA Controller FIO Cable Kit

P05030-B21

NOTE: This option kit is used with the 8SFF CTO to connect to the embedded SATA controller on mother board.

HPE DL325 Gen10 2SFF Embedded SATA Controller FIO Cable Kit

P05039-B21

NOTE: This option kit is used with the 2SFF SAS/SATA FIO Enablement Kit to connect to the embedded SATA controller on

NOTE: The embedded SATA controller works only in the AHCI mode and does not support RAID.

HPE 1U Gen10 4LFF Embedded SATA Controller FIO Cable Kit

866444-B21

NOTE: This option kit is used with the 4LFF CTO to connect to the embedded SATA controller on mother board. NOTE: The embedded SATA controller works only in the AHCI mode and does not support SW RAID

HPE 1U Gen10 2SFF SAS/SATA FIO Enablement Kit without Cables

881179-B21

NOTE: This option can be selected only on 8SFF CTO or NVMe SFF CTO.

NOTE: This option kit will enable 2SFF SAS/SATA drives.

Security

HPE Gen10 TPM 1.2 FIO Setting

872108-B21

NOTE: HPE Trusted Platform Module 2.0 Gen10 Option (864279-B21), if it needs to be operated in TPM 1.2 Mode.

BIOS Mode

HPE Legacy FIO Mode Setting

758959-B22

NOTE: UEFI is the default, this FIO part can be used for CTO to enable Legacy mode.

HPE Converged Infrastructure Management Software

HPE OneView including 3yr 24x7 Support Physical 1-server LTU

E5Y34A

HPE OneView w/o iLO including 3yr 24x7 Support 1-server FIO LTU

P8B31A

Step 4: Choose additional options for Factory Integration from Core and Additional Options sections below

NOTE: The embedded SATA controller works only in the AHCI mode and does not support SW RAID.

mother board.

NOTE: This is an FIO option only.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Core Options

NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for additional information.

HPE Unique Options

HPE DL325 Gen10 PCIe Low Profile Riser Kit

P04849-B21

NOTE: This riser cannot be used when Modular Smart Array is chosen.

HPE DL325 Gen10 2SFF NVMe Enablement Kit

P04979-B21

NOTE: This option provides support for up to 2 NVMe drives, and can only be populated in SFF or NVMe model only.

HPE DL325 Gen10 2SFF SAS/SATA Enablement Kit

P05050-B21

NOTE: This option can be selected only on 8SFF CTO or NVMe SFF CTO. NOTE: NOTE: NOTE:

HPE DL325 Gen10 Serial Port Enablement Kit

P05045-B21

NOTE: This kit would take up the position of Slot 3 and thus cannot be selected in conjunction with Low Profile Riser Kit.

HPE DL325 Gen10 GPU Enablement Kit

P10779-B21

NOTE: This option kit requires addition of standard fans if 4LFF model is chosen NOTE:

Memory Selection

To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability, HPE recommends memory from the list located here: Best product availability is limited to US, Canada, and Latin America at this time.

HPE Memory

HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

838079-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

838089-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

838083-B21

HPE 64GB (1x64GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

P05592-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

838081-B21

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666 CAS-19-19-19 Load Reduced Smart Memory Kit

838085-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2666 CAS-22-19-19 3DS Load Reduced Smart Memory Kit

838087-B21

NOTE: Memory DIMM availability with a server platform is dependent upon completion of certification testing. NOTE:

HPE Optical Drives

HPE 9.5mm SATA DVD-ROM Optical Drive

726536-B21

HPE 9.5mm SATA DVD-RW Optical Drive

726537-B21

HPE DL325 Gen10 4LFF Optical Disk Drive Cable Kit

P05968-B21

NOTE: This cable kit must be selected if Optical Drive is chosen on the 4LFF CTO Model

HPE Mobile USB DVD-RW Optical Drive

701498-B21

NOTE: This is only supported on USB 3.0 ports.

HPE 1U Gen10 8SFF Optical Disk Drive Enablement Kit

873961-B21

NOTE: This enablement kit must be selected if Optical Drive is chosen on the 8SFF or NVMe CTO Model

This is an Field Upgrade option only. This option kit will enable 2SFF SAS/SATA drives.

This option kit contains the necessary cables to connect to controllers

This option kit requires addition of performance fans if 8LFF model is chosen

http://www.hpe.com/products/recommend.

The maximum memory speed is a function of the memory type, memory configuration, and processor model.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Core Options

HPE Drives

Enterprise - 12G SAS - SFF Drives

HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870753-B21

HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872475-B21

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870757-B21

HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872477-B21

HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870759-B21

HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872479-B21

HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

872481-B21

HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

881457-B21

Midline - 12G SAS - SFF Drives

HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD

832514-B21

HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD

765466-B21

Enterprise - 12G SAS - LFF Drives

HPE 900GB SAS 12G Enterprise 15K LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware HDD

870761-B21

Midline - 12G SAS - LFF Drives

HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD

833926-B21

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD

833928-B21

HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD

861746-B21

HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e Digitally Signed Firmware HDD

834031-B21

HPE 10TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD

P09149-B21

HPE 12TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD

881781-B21

HPE 14TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD

P09155-B21

Midline - 6G SATA - SFF Drives

HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD

655710-B21

HPE 2TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

765455-B21

Midline - 6G SATA - LFF Drives

HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD

861686-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD

861681-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD

861683-B21

HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD

861742-B21

HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e Digitally Signed Firmware HDD

834028-B21

HPE 10TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD

P09161-B21

HPE 12TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD

881787-B21

HPE 14TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD

P09165-B21

SSD Selection To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability, HPE recommends SSDs from the list located here: http://www.hpe.com/products/recommend

Read Intensive - 12G SAS - SFF - Solid State Drives

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06584-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04517-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04519-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06586-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06588-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04521-B21

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06590-B21

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04523-B21

HPE 15.3TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06592-B21

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Core Options

Mixed Use - 12G SAS - SFF - Solid State Drives

HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04525-B21

HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09088-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04527-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09090-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04553-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09092-B21

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09094-B21

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04537-B21

HPE 6.4TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04539-B21

HPE 6.4TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09096-B21

Write Intensive - 12G SAS - SFF - Solid State Drives

HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04541-B21

HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09098-B21

HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04543-B21

HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09100-B21

HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04545-B21

HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09102-B21

HPE 3.2TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04547-B21

Mixed Use - 12G SAS - LFF - Solid State Drives

HPE 800GB SAS 12G Mixed Use LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD

P04531-B21

HPE 1.6TB SAS 12G Mixed Use LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD

P04535-B21

Read Intensive - 12G Value SAS - SFF - Solid State Drives

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10440-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10442-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10444-B21

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10446-B21

Mixed Use - 12G Value SAS - SFF - Solid State Drives

HPE 1.92TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10454-B21

HPE 3.84TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10460-B21

Read Intensive - 6G SATA - SFF - Solid State Drives

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875503-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18420-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06194-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18422-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06196-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06198-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18426-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04474-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04476-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18424-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04478-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04480-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06200-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18428-B21

HPE 7.68TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04482-B21

HPE 7.68TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18430-B21

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Core Options

Read Intensive - 6G SATA - SFF - Solid State Drives

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04556-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05924-B21

HPE 960GB SAS 12G Mixed Use SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10448-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04560-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05928-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04564-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05932-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04566-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05938-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04570-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05946-B21

Mixed Use - 6G SATA - SFF - Solid State Drives

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09712-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05976-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18432-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09716-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05980-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18434-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09722-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18436-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P00896-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18438-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P07922-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P07926-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P07930-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05986-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05994-B21

Read Intensive - 6G SATA - LFF - Solid State Drives

HPE 960GB SATA 6G Read Intensive LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD

P09691-B21

Mixed Use - 6G SATA - LFF - Solid State Drives

HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD

P09726-B21

HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD

P07934-B21

Read Intensive - NVMe - SFF - Solid State Drives

HPE 960GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10208-B21

HPE 960GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07190-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10214-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10210-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07192-B21

HPE 2TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13695-B21

HPE 3.84TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10212-B21

HPE 3.84TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10216-B21

HPE 3.84TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07194-B21

HPE 4TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13697-B21

HPE 7.68TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10218-B21

HPE 7.68TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07196-B21

HPE 15.36TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07198-B21

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Core Options

Mixed Use - NVMe - SFF - Solid State Drives

HPE 800GB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07179-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10222-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07181-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13699-B21

HPE 3.2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10224-B21

HPE 3.2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07183-B21

HPE 3.2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13701-B21

HPE 6.4TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10226-B21

HPE 6.4TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07185-B21

HPE 6.4TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13703-B21

Write Intensive - NVMe - SFF - Solid State Drives

HPE 375GB NVMe x4 Lanes Write Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

878014-B21

HPE 750GB NVMe x4 Lanes Write Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P06952-B21

Hard Drive Blank Kits

HPE Gen9 LFF HDD Spade Blank Kit

807878-B21

HPE Small Form Factor Hard Drive Blank Kit

666987-B21

Internal Dual M.2 Kit

HPE Universal SATA HHHL 3yr Wty M.2 Kit

878783-B21

NOTE: The Universal SATA M.2 Kit above will require a PCIe slot and support up to two of the same M.2 cards below.

Read Intensive - M.2 - Solid State Drives

HPE 480GB SATA 6G Read Intensive M.2 2280 3yr Wty Digitally Signed Firmware SSD

875498-B21

HPE 960GB SATA 6G Read Intensive M.2 2280 3yr Wty Digitally Signed Firmware SSD

875500-B21

Mixed Use - M.2 - Solid State Drives

HPE 240GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD

875488-B21

HPE 480GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD

875490-B21

HPE 960GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD

875492-B21

HPE Networking

1 Gigabit Ethernet adapters

HPE Ethernet 1Gb 4-port 331T Adapter

647594-B21

HPE Ethernet 1Gb 4-port 366T Adapter

811546-B21

HPE Ethernet 1Gb 2-port 332T Adapter

615732-B21

HPE Ethernet 1Gb 2-port 361T Adapter

652497-B21

10 Gigabit Ethernet adapters

HPE Ethernet 10Gb 2-port 530T Adapter

656596-B21

HPE Ethernet 10Gb 2-port 530SFP Adapter

652503-B21

HPE Ethernet 10Gb 2-port 535T Adapter

813661-B21

HPE Ethernet 10Gb 2-port 521T Adapter

867707-B21

HPE Ethernet 10Gb 2-port 562T Adapter

817738-B21

HPE Ethernet 10Gb 2-port 562SFP+ Adapter

727055-B21

HPE Ethernet 10Gb 2-port 524SFP+ Adapter

P08446-B21

HPE Ethernet 10Gb 2-port 548SFP+ Adapter

P11338-B21

25 Gigabit Ethernet adapters

HPE Ethernet 10/25Gb 2-port 631SFP28 Adapter

817718-B21

HPE Ethernet 10/25Gb 2-port 640SFP28 Adapter

817753-B21

HPE Ethernet 10/25Gb 2-port 621SFP28 Adapter

867328-B21

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Core Options

100 Gigabit Ethernet adapters

HPE Ethernet 100Gb 1-port 842QSFP28 Adapter

874253-B21

NOTE: The DL325 Gen10 ships with 4x 1 Gb Embedded. NOTE: NOTE: NOTE:

optic environments must be

purchased separately. Please see the related NIC QuickSpecs for Technical Specifications and additional information:

http://www.hpe.com/us/en/product

FlexibleLOM adapters

HPE Ethernet 1Gb 4-port 331FLR Adapter

629135-B22

HPE Ethernet 1Gb 4-port 366FLR Adapter

665240-B21

HPE FlexFabric 10Gb 2-port 533FLR-T Adapter

700759-B21

HPE FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter

700751-B21

HPE Ethernet 10Gb 2-port 535FLR-T Adapter

817721-B21

HPE FlexFabric 10Gb 4-port 536FLR-T Adapter

764302-B21

HPE Ethernet 10/25Gb 2-port 631FLR-SFP28 Adapter

817709-B21

HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter

817749-B21

NOTE: The DL325 Gen10 chassis ships with 4x 1 Gb embedded. NOTE: Only one FlexibleLOM can be added to the server. These options are upgradeable and can be changed from the original

configuration after the server is shipped.

NOTE:

optic environments must be

purchased separately. Please see the related NIC QuickSpecs for Technical Specifications and additional information:

http://www.hpe

HPE Ethernet 10Gb 2-port 562FLR-T Adapter

817745-B21

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter

727054-B21

HPE Ethernet 10/25Gb 2-port 622FLR-SFP28 Converged Network Adapter

867334-B21

NOTE: The DL325 Gen10 chassis ships with 4x 1 Gb embedded. NOTE: Only one FlexibleLOM can be added to the server. These options are upgradeable and can be changed from the original

configuration after the server is shipped.

NOTE:

optic environments must be

purchased separately. Please see the related NIC QuickSpecs for Technical Specifications and additional information:

NOTE:

8, CN1300R & CN1200R adapters with FCoE used in conjunction with all Red Hat 7.x version OS's are not

supported at this time. http://www.hpe.com/us/en/product-catalog/servers/server-adapters.hits-12.html.

HPE InfiniBand

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+FLR-QSFP Adapter

764285-B21

HPE InfiniBand FDR/Ethernet 40/50Gb 2-port 547FLR-QSFP Adapter

879482-B21

HPE InfiniBand EDR 100Gb 1-port 841QSFP28 Adapter

872725-B21

HPE InfiniBand EDR/Ethernet 100Gb 2-port 841QSFP28 Adapter

872726-B21

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+QSFP Adapter

764284-B21

HPE InfiniBand EDR/Ethernet 100Gb 1-port 840QSFP28 Adapter

825110-B21

HPE InfiniBand EDR/Ethernet 100Gb 2-port 840QSFP28 Adapter

825111-B21

4-port adapters go only into Slot 1. A minimum of two Gigabytes (2 GB) of server memory is required per each adapter. Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-

-catalog/servers/server-adapters.hits-12.html.

Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-

.com/us/en/product-catalog/servers/server-adapters.hits-12.html.

Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-

622FLR-SFP2

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Core Options

HPE Power Supplies

HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, tool-less installation into HPE ProLiant Gen10

efficiency operation and offer multiple power output options, allowing users to "right-size" a power supply for specific server configurations. This flexibility helps to reduce power was

NOTE: Prior to making a power supply selection it is highly recommended that the HPE Power Advisor is run to determine the

right size power supply for your server configuration. The HPE Power Advisor is located at:

http://www.hpe.com/info/hppoweradvisor

NOTE: NOTE: NOTE: NOTE:

IEC power cord used for rack mounting with Power Distribution Units (PDUs).

Visit

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865408-B21

NOTE: Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard C-14 power inlet connector. NOTE: HPE DL325 Gen10 RPS Enablement Kit (P04983-B21) is mandatory to use this power supply.

HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit

865438-B21

NOTE: Flex Slot Titanium power supplies support power efficiency of up to 96% and include a standard C-14 power inlet connector. NOTE: HPE DL325 Gen10 RPS Enablement Kit (P04983-B21) is mandatory to use this power supply.

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865414-B21

NOTE: Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard C-14 power inlet connector. NOTE:

HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply Kit

865434-B21

NOTE: Flex Slot -48VDC power supplies support power efficiency of up to 94%. NOTE:

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

830272-B21

NOTE: Flex Slot Platinum Plus power supplies support power efficiency of up to 94% and include a C-14 power inlet connector that can support HPE Power Discovery Services (blue connector). NOTE: HPE DL325 Gen10 RPS Enablement Kit (P04983-B21) is mandatory to use this power supply.

HPE DL325 Gen10 Redundant Power Supply Enablement Kit

P04983-B21

NOTE: This enablement kit is required to use the Flex Slot power supplies

HPE 800W Flex Slot Universal Hot Plug Low Halogen Power Supply Kit

865428-B21

NOTE: Flex Slot universal power supplies support power efficiency of up to 94% and support both 277VAC/380VDC power inputs. NOTE: HPE DL325 Gen10 RPS Enablement Kit (P04983-B21) is mandatory to use this power supply.

GPU Information

Part

Card

Qty

Processor

HPE ProLiant DL325 Gen10 Server Configuration

4LFF

8SFF

8+2 SFF SAS/SATA

8SFF SAS/SATA+2NVMe

8SFF NVMe

SFF NVMe

R0W29A

HPE NVIDIA

16GB Module

1 (Slot1)

All

30C

25C

30C

25C

HPE Computation and Graphics Accelerators

HPE NVIDIA Tesla T4 16GB Computational Accelerator

R0W29A

NOTE: HPE DL325 Gen10 GPU Enablement Kit (P10779-B21) is mandatory to use this accelerator

Performance Servers. Flex Slot power supplies are certified for high-

te, lower overall energy costs, and avoid "trapped" power capacity in the data center.

. All power supplies in a server should match. Mixing Power Supplies is not supported. Option kits contain the specified power supply and a PDU IEC cable. 1600W power supplies only support high line voltage. HPE ProLiant servers ship with an IEC-

HPE power cords for a full list of optional HPE power cords.

HPE DL325 Gen10 RPS Enablement Kit (P04983-B21) is mandatory to use this power supply.

Number

Supported

Tesla T4

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Additional Options

Embedded Management

HPE iLO Advanced

HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features

E6U59ABE

HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features

512485-B21

HPE iLO Advanced Flexible Quantity License with 1yr Support on iLO Licensed Features

512486-B21

HPE iLO Advanced AKA Tracking License with 1yr Support on iLO Licensed Features

512487-B21

HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features

E6U64ABE

HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features

BD505A

HPE iLO Advanced Flexible Quantity License with 3yr Support on iLO Licensed Features

BD506A

HPE iLO Advanced AKA Tracking License with 3yr Support on iLO Licensed Features

BD507A

HPE Converged Infrastructure Management Software

HPE OneView Physical Media Kit LTU

E5Y37A

HPE OneView including 3yr 24x7 Support Physical 1-server LTU

E5Y34A

HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU

E5Y35AAE

HPE OneView w/o iLO including 3yr 24x7 Support 1-server LTU

P8B24A

HPE OneView w/o iLO including 3yr 24x7 Support Track 1-server LTU

P8B25A

HPE OneView w/o iLO including 3yr 24x7 Support Flexible Quantity E-LTU

P8B26AAE

NOTE: Licenses ship without media. The HPE OneView Media Kit can be ordered separately, or can be downloaded.

HPE PCIe Workload Accelerator Options

HPE 750GB PCIe x4 Lanes Write Intensive HHHL 3yr Wty Digitally Signed Firmware Card

878038-B21

HPE 1.6TB NVMe x8 Lanes Mixed Use HHHL 3yr Wty Digitally Signed Firmware Card

P10264-B21

HPE 3.2TB NVMe x8 Lanes Mixed Use HHHL 3yr Wty Digitally Signed Firmware Card

P10266-B21

HPE 6.4TB NVMe x8 Lanes Mixed Use HHHL 3yr Wty Digitally Signed Firmware Card

P10268-B21

HPE Security

HPE 1U Gen10 Bezel Kit

867998-B21

HPE Bezel Lock Kit

875519-B21

HPE Trusted Platform Module 2.0 Gen10 Option

864279-B21

NOTE: HPE Trusted Platform Module 2.0 option works with Gen10 servers with UEFI Mode not Legacy Mode. It is not compatible

systems can have a TPM module (of any type) installed only once. It cannot be replaced with any other TPM

NOTE:

HPE 1U Gen10 Chassis Intrusion Detection Kit

866473-B21

NOTE: This provides a physical connection from the chassis board and hood and detects any physical intrusion into the chassis,

providing security during the entire supply chain process of shipping, receiving, distribution, and operation.

with HPE ProLiant Gen8 servers or earlier generation variants. NOTE: HPE server module.

There is a FIO setting to allow this TPM module to operate in a TPM 1.2 mode (872108-B21).

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Additional Options

HPE Smart Array Controllers

The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed breakout

Smart Array Controllers

HPE 96W Smart Storage Battery (up to 20 Devices) with 145mm Cable Kit

B21), which supports multiple

devices and is sold separately.

HPE Smart Array P816i-a SR Gen10 (16 Int Lanes/4GB Cache/SmartCache) 12G SAS Modular LH Controller

869083-B21

NOTE: Does not occupy a PCIe expansion slot and includes SmartCache license. NOTE:

HPE Smart Array P408i-a SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS Modular LH Controller

869081-B21

NOTE: Does not occupy a PCIe expansion slot.

HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller

804405-B21

HPE Smart Array P408i-p SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS PCIe Plug-in Controller

830824-B21

Essential RAID Controllers

HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804398-B21

HPE Smart Array E208i-p SR Gen10 (8 Internal Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804394-B21

HPE Smart Array E208i-a SR Gen10 (8 Internal Lanes/No Cache) 12G SAS Modular LH Controller

869079-B21

NOTE: Does not occupy a PCIe expansion slot.

HPE Cable Options

HPE DL325 Gen10 10SFF Smart Array SAS Cable Kit

P05042-B21

HPE 1U Gen10 4LFF Smart Array SAS Cable Kit

866452-B21

HPE 1U Gen10 8SFF Smart Array SAS Cable Kit

866448-B21

HPE Smart Storage Hybrid Capacitor with 145mm Cable Kit

P02377-B21

HPE DL325 Gen10 4LFF Smart Array S100i SATA FIO Cable Kit

P09409-B21

NOTE: HPE DL325 Gen10 4LFF Smart Array S100i SATA FIO Cable Kit must be selected in order to support HPE Smart Array S100i SR Gen10 SW RAID on 4LFF CTO chassis

Optional Software

HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU

Q2F26AAE

HPE Smart Array SR SmartCache (Single Key/Single Server) LTU

D7S26A

HPE Smart Array SR SmartCache (Single Key/Multiple Servers) LTU

D7S27A

HPE Smart Array SR SmartCache (Single Key/Multiple Servers) E-LTU

D7S27AAE

NOTE: SmartCache is offered on HPE Smart Array performance RAID controllers and comes standard (no licensing is required) if the HPE Smart Array P816i-a SR Gen10 Controller is installed in the server.

of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet.

NOTE: All performance RAID controllers are supported by the HPE Smart Storage Battery (P01366-

The P816i-a cable ships in the 8SFF chassis only.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Additional Options

Optional Upgrades

HPE 96W Smart Storage Battery (up to 20 Devices) with 145mm Cable Kit

P01366-B21

NOTE: Provides backup power for multiple HPE Smart Array controllers or other devices. Is required with performance RAID controllers.

HPE Tape Backup

HPE Disk-Based Backup

HPE RDX 1TB External Disk Backup System

B7B69B

HPE RDX External Docking Station

C8S07B

HPE RDX 2TB External Disk Backup System

E7X53B

HPE Storage Options

Emulex Fibre Channel HBAs

HPE StoreFabric SN1200E 16Gb Single Port Fibre Channel Host Bus Adapter

Q0L13A

HPE StoreFabric SN1200E 16Gb Dual Port Fibre Channel Host Bus Adapter

Q0L14A

HPE StoreFabric SN1600E 32Gb Single Port Fibre Channel Host Bus Adapter

Q0L11A

HPE StoreFabric SN1600E 32Gb Dual Port Fibre Channel Host Bus Adapter

Q0L12A

QLogic Fibre Channel HBAs

HPE StoreFabric SN1100Q 16Gb Single Port Fibre Channel Host Bus Adapter

P9D93A

HPE StoreFabric SN1100Q 16Gb Dual Port Fibre Channel Host Bus Adapter

P9D94A

HPE StoreFabric SN1600Q 32Gb Single Port Fibre Channel Host Bus Adapter

P9M75A

HPE StoreFabric SN1600Q 32Gb Dual Port Fibre Channel Host Bus Adapter

P9M76A

Converged Network Adapters

HPE StoreFabric CN1100R Dual Port Converged Network Adapter

QW990A

HPE StoreFabric CN1100R 10GBASE-T Dual Port Converged Network Adapter

N3U52A

HPE StoreFabric CN1200E 10Gb Converged Network Adapter

E7Y06A

HPE StoreFabric CN1200E 10GBASE-T Dual Port Converged Network Adapter

N3U51A

HPE StoreFabric CN1200R 10GBASE-T Converged Network Adapter

Q0F26A

HPE StoreFabric CN1300R 10/25Gb Dual Port Converged Network Adapter

Q0F09A

NOTE: For the complete listing of Fibre Channel Converged Network Adapters please see:

SFP28, CN1300R & CN1200R adapters with FCoE used in conjunction with all Red Hat 7.x version OS's are not

supported at this time.

HPE Racks

For the complete range of tape drives, autoloaders, libraries and media see:

https://www.hpe.com/us/en/storage/storeever-tape-storage.html.

For hardware and software compatibility of Hewlett Packard Enterprise tape backup products

http://www.hpe.com/storage/BURAcompatibility.

https://www.hpe.com/us/en/product-catalog/servers/adapters/pip.models.hpe-storefabric-converged-networkadapters.4118472.html

NOTE: 622FLR-

Please see the HPE Advanced Series Racks QuickSpecs for information on additional racks options and rack specifications. Please see the HPE Enterprise Series Racks QuickSpecs for information on additional racks options and rack specifications. Please see the HPE Standard Series Racks QuickSpecs for information on additional racks options and rack specifications.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Additional Options

HPE Power Distribution Units (PDUs)

for information on these products and their specifications.

for information on these products and their

nformation on these products and

their specifications.

HPE Uninterruptible Power Systems (UPS)

for information on these products and

HPE Rack Options

NOTE: Please see the HPE KVM Switches web page for information on these products and their specifications.

Rail Kits

wo people are required for all Rack Server installations. Please

refer to your installation instructions for proper tools and number of people to use for any installation.

HPE 1U Small Form Factor Easy Install Rail Kit

734807-B21

NOTE: HPE 1U Cable Management Arm for Rail Kit (734811-B21).

HPE 1U Cable Management Arm for Rail Kit

734811-B21

HPE USB and SD Options

HPE Enterprise Mainstream Flash Media Kits for Memory Cards

HPE 32GB microSD Flash Memory Card

700139-B21

HPE 8GB microSD Flash Memory Card

726116-B21

HPE 8GB microSD Flash USB Drive

737953-B21

HPE 8GB Dual microSD Flash USB Drive

741279-B21

HPE Support Services

Proactive Care

HPE 3 Year Proactive Care 24x7 DL325 Gen10 Service

HB4H1E

HPE 3 Year Proactive Care 24x7 with DMR DL325 Gen10 Service

HB4H2E

HPE 3 Year Proactive Care 24x7 with CDMR DL325 Gen10 Service

HB4H3E

Foundation Care

HPE 3 Year Foundation Care 24x7 DL325 Gen10 Service

HB4G8E

HPE 3 Year Foundation Care 24x7 with DMR DL325 Gen10 Service

HB4G9E

HPE 3 Year Foundation Care 24x7 with CDMR DL325 Gen10 Service

HB4H0E

Installation & Startup Services

HPE Install ProLiant DL3xx Service

U4506E

HPE Installation and Startup DL3xx Service

U4507E

NOTE: For a full listing of support services available for this server, please visit https://ssc.hpe.com/

Please see the HPE Basic Power Distribution Units (PDU) QuickSpecs for information on these products and their specifications. Please see the HPE Metered Power Distribution Units (PDU) QuickSpecs Please see the HPE Intelligent Power Distribution Unit (PDU) QuickSpecs specifications. Please see the HPE Metered and Switched Power Distribution Units (PDU) QuickSpecs for i

To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web page. Please see the HPE DirectFlow Three Phase Uninterruptible Power System QuickSpecs their specifications. Please see the HPE Line Interactive Single Phase UPS QuickSpecs for information on these products and their specifications.

NOTE: Ball bearing and Easy Install rail kits contain telescoping rails which allow for in-rack serviceability. NOTE: To assist in the installation of the server into the rack an optional installation tool is available by contacting your local

services representative (695539-001). NOTE:Hewlett Packard Enterprise recommends that a minimum of t

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Memory

DIMM Type

HPE SKU P/N

838079-B21

838081-B21

838089-B21

838083-B21

P05592-B32

SKU Description

19 Registered

HPE 16GB

2666

Memory Kit

HPE 16GB

(1x16GB) Dual Rank

Memory Kit

HPE 32GB

(1x32GB) Dual Rank

Memory Kit

HPE 64GB

19 Registered Smart

Memory Kit

DIMM Rank ->

Single Rank (1R)

Dual Rank (2R)

DIMM Capacity

8GB

16GB

32GB

64GB

Voltage

1.2V

DRAM depth [bit]

2G 1G 2G 4G

DRAM Width [bit]

DRAM Density

8Gb

16Gb

CAS Latency

19-19-19

DIMM Native Speed (MT/s)

2666 MT/s

AMD EPYC® 7000 Processors Officially Supported Memory Speed (MT/s)

1 DIMM Per Channel

2666 MT/s

2400 MT/s

2 DIMM Per Channel

2133 MT/s

HPE 8GB (1x8GB)

Single Rank x8

DDR4-2666 CAS-

19-19-

Smart Memory Kit

2666 MT/s

(1x16GB) Single

Rank x4 DDR4-

CAS-19-19-19

Registered Smart

x8 DDR4-2666

CAS-19-19-19

Registered Smart

x4 DDR4-2666

CAS-19-19-19

Registered Smart

(1x64GB) Dual

Rank x4 DDR4-

2666 CAS-19-19-

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Memory

NOTE: The maximum memory speed is a function of the memory type, memory configuration, and processor model. NOTE:

For details on the HPE Server Memory speed, visit: http://www.hpe.com/docs/amd-speed-tables

DIMM Type

HPE SKU P/N

SKU Description

HPE 64GB (1x64GB) Quad Rank x4

Reduced Smart Memory Kit

HPE 128GB (1x128GB) Octal Rank x4

Reduced Smart Memory Kit

DIMM Rank

DIMM Capacity

Voltage

DRAM depth [bit]

DRAM Width [bit]

DRAM Density

8Gb

CAS Latency

19-19-19

22-19-19

DIMM Native Speed (MT/s)

2666

AMD EPYC® 7000 Processors Officially Supported Memory Speed (MT/s)

1 DIMM Per Channel

2666 MT/s

2 DIMM Per Channel

2133 MT/s

NOTE: NOTE:

For details on the HPE Server Memory speed, visit:

DDR4 memory options part number decoder

NOTE:

For more information on memory, please see the Memory Quickspecs:

Model 7251 1 DIMM per channel is 2400 MT/s.

Load Reduced (LRDIMM)

838085-B21 838087-B21

DDR4-2666 CAS-19-19-19 Load

DDR4-2666 CAS-22-19-19 3DS Load

Quad Rank (4R) Octal Rank (8R)

64GB 128GB

1.2V 1.2V 2G 2G

The maximum memory speed is a function of the memory type, memory configuration, and processor model. Model 7251 1 DIMM per channel is 2400 MT/s.

http://www.hpe.com/docs/amd-speed-tables

Capacity references are rounded to the common gigabyte (GB) values.

• 8GB = 8,192 MB

• 16GB = 16,384 MB

• 32GB = 32,768 MB

• 64GB = 65,536 MB

HPE DDR4 SmartMemory

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Storage

4LFF drives

8SFF + Optional 2SFF (SAS/SATA or NVMe) Shown

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Technical Specifications

System Unit

Dimensions

4.29 x 43.46 x 61.49 cm

1.69 x 17.11 x 24.21 in

Weight (approximate)

10 kg

Minimum: 8 SFF chassis with 8 HDD blanks, 2x Drive Bay blanks, 1x processor including standard heatsink,

1x power supply (plus

blank), 1x Smart Array, 1x Riser installed, cables for the above)

15.60 kg

Maximum: 10 SFF hard drives, 1x processors, 2x power supplies, 1x Smart Array, 2x Risers installed, 16x DIMMs, 2x power supply, cables for the above)

Input Requirements

Rated Line Voltage

100 to 120 VAC

200 to 240 VAC

BTU Rating

Maximum

For 800W Power Supply: 3207 BTU/hr (at 100 VAC), 3071 BTU/hr (at 200 VAC), 3112 BTU/hr (at 240 VAC) for China Only

For 500W Power Supply: 1979 BTU/hr (at 100 VAC), 1911 BTU/hr (at 200 VAC), 1965 BTU/hr (at 240 VAC) for China Only

Power Supply Output

Rated Steady-State Power

For 1600W Power Supply: 1600W (at 240 VAC), 1600W (at 240 VAC)

For 800W Power Supply: 800W (at 100 VAC), 800W (at 240 VAC), 800W (at 240 VAC) input for China only

For 500W Power Supply: 500W (at 100 VAC), 500W (at 240 VAC), 500W (at 240 VAC) input for China only

Maximum Peak Power

For 1600W Power Supply: 1600W (at 200 to 240 1VAC), 1600W (at 240 VAC) input for China only

For 800W Power Supply: 800W (at 100 to 127 VAC), 800W (at 200 to 240 1VAC), 800W (at 240 VAC) input for China only

For 500W Power Supply: 500W (at 100 to 127 VAC), 500W (at 200 to 240 VAC), 500W (at 240 VAC) input for China only

System Inlet Temperature

Standard Operating

10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 20°C/hr (36°F/hr). The upper limit and rate of change may be limited by the type and number of opti System performance during standard operating support may be reduced if operating with a fan fault or above 30°C (86°F).

Extended Ambient

For approved hardware configurations, the supported system inlet range is extended to be: 5° to 10°C (41° to 50°F) and 35° to 40°C (95° to 104°F) at sea level with an altitude derating of 1.0°C per every 175 m (1.8°F per every 574 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware configurations for this system are listed at the URL:

http://www.hpe.com/servers/ashrae

For approved hardware configurations, the supported system inlet range is extended to be: 40° to 45°C (104° to 113°F) at sea level with an altitude derating of 1.0°C per every 125 m (1.8°F per every 410 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware configurations for this system are listed at the URL:

http

System performance may be reduced if operating in the extended ambient operating range or with a fan fault.

Non-operating

-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).

(per power supply)

22.05 lb

35.27 lb

2x DIMMs,

Temperature

Operating Temperature

://www.hpe.com/servers/ashrae

ons installed.

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Technical Specifications

Relative Humidity

Operating

8% to 90% - Relative humidity (Rh), 28°C maximum wet bulb temperature, non-condensing.

(non-condensing)

Non-operating

5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing..

Altitude

Operating

3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min).

Non-operating

9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).

Acoustic Noise

Listed are the declared A-Weighted sound power levels (L

) and declared average bystander

) when the product is operating in a 23°C ambient

accordance with ISO 7779 (ECMA 74) and declared

in accordance with ISO 9296 (ECMA 109). The listed sound levels apply to standard shipping

Additional options may result in increased sound levels. Please have your HPE

information from the HPE EMESC website for further technical details

regarding the configurations listed below.

Idle

LWAd

4.8 B Entry

4.8 B Base

4.8 B Perf

LpAm

32 dBA Entry

34 dBA Base

35 dBA Perf

Operating

LWAd

5.2 B Entry

5.2 B Base

5.2 B Perf

LpAm

37 dBA Entry

38 dBA Base

37 dBA Perf

NOTE: Acoustics levels presented here are generated by the test configuration only. Acoustics levels will vary depending on system configuration. Values are subject to change without

oduct specifications is based on sample (type) testing,

evaluation, or assessment. This product or family of products is eligible to bear the appropriate

The Listed sound levels apply to standard shipping configurations. Additional options may

result in increased sound levels.

WAd

position A-Weighted sound pressure levels (L environment. Noise emissions were measured in

configurations. representative provide

pAm

notification and are for reference only.

NOTE: Product conformance to cited pr

compliance logos and statements.

NOTE:

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Technical Specifications

Emissions Classification (EMC) – Regulatory Information

Safety and Compliance Information for Server, Storage, Power,

http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts

HPE Smart Array

For latest information on HPE Smart Array Gen10 Controllers for HPE ProLiant DL, ML and Apollo Servers please refer to their QuickSpecs. (E208i-a,E208i-p,E208e-p,P408i-a,P408i-p,P408e-p,P816i-a)

Environment-friendly Products and Approach - End-of-life Management and Recycling

, in many geographic areas, for our

) requires manufacturers to provide treatment information for each product type for use by

e. These

yclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM customers who

integrate and re-sell Hewlett Packard Enterprise equipment.

To view the regulatory information for your product, view the Networking, and Rack Products, available at the Hewlett Packard Enterprise Support Center:

Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling programs products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web sit instructions may be used by rec

Page

QuickSpecs

HPE ProLiant DL325 Gen10 Server

Summary of Changes

Date

Version History

Action

Description of Change

05-Aug-2019

Version 12

Changed

Configuration Information and Core Options sections were updated.

01-Jul-2019

Version 11

Changed

SKUs description were updated The U.S. version of QuickSpecs is no longer being updated, please reference the Worldwide QuickSpecs for latest information

03-Jun-2019

Version 10

Changed

Overview, Standard Features, Optional Features, Service and Support, Configuration Information, Core Options, Additional Options and Memory sections were updated.

15-Apr-2019

Version 9

Changed

SKUs were updated.

02-Apr-2019

Version 8

Changed

Overview, Standard Features, Core Options and Aditional Options sections were updated.

04-Feb-2019

Version 7

Changed

Optional Features section was updated.

10-Dec-2018

Version 6

Changed

SKU 829335-B21 was deleted from Core Options section

03-Dec-2018

Version 5

Changed

Overview and Standard Features sections were updated SKUs were Added and deleted in Core Options

01-Oct-2018

Version 4

Changed

Standard Features, Pre-configured Models, Configuration Information, Additional

SKU descriptions were updated.

13-Aug-2018

Version 3

Added

HPE Support Services section was added to the QuickSpecs.

06-Aug-2018

Version 2

Changed

Configuration Information – Factory Integrated Models, Core Options, and Additional Options were revised.

02-Jul-2018

Version 1

New

New QuickSpecs.

© Copyright 2019 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

AMD® and EPYC® are registered trademarks of Advanced Micro Devices Corporation in the U.S. and other countries.

Microsoft®, Windows®, and Windows Server® are U.S. registered trademarks of the Microsoft group of companies.

For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less

a00045498enw - 16225 - Worldwide - V12 - 05-August-2019

Options, Memory and Core Options sections were updated.

Page

HPE P17201-B21 Product Data Sheet

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Optional Features

Service and Support

Configuration Information

Core Options

Additional Options

Memory

Storage

Technical Specifications

Summary of Changes

a00045498enw - 16225 - Worldwide - V12 - 05-August-2019
