HPE ProLiant DL20 Gen10 Server
The dense and compact HPE ProLiant DL20 Gen10 Server powered by Intel® Xeon® E Processor, Pentium and Core i3 processors
provides a unique blend of enterprise class capabilities & value. It offers outstanding configuration flexibility to cater to
riety
of business requirements at an affordable price point.
platform for diverse workloads in space constrained
environments and maintain it with ease by automating the most essential server lifecycle management tasks with HPE iLO 5.
2 LFF Front View
1.
Access Panel
7.
Health LED
2.
Optical drive bay
8.
NIC Status LED
3.
Serial number/iLO information pull tab
9.
USB 3.0 Port
4.
Front Fan Assembly
10.
iLO Service Port (USB)
5.
System Power LED
11.
Two-bay LFF hot-plug drive bays
6.
UID LED
4 (+2) SFF Front View
1.
Access Panel
7.
Health LED
2.
2 SFF hot plug drive bays (optional)
8.
NIC Status LED
3.
Serial number/iLO information pull tab
9.
USB 3.0 Port
4.
Front Fan Assembly
iLO Service Port (USB)
5.
System Power LED
11.
4 SFF hot plug drive bays
6.
UID LED
a wide va
Deploy this dense
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Overview
Page 2
Internal View - Standard for all DL20 Gen10
1.
Fan cage shown with 2 fans
7.
Optional Smart Storage Battery
2.
Processor shown with heat sink
8.
Modular Smart Array connector
3.
Four DDR4 DIMM Slots
9.
Optional TPM 2.0
4.
System Battery
10.
PCIe Riser
5.
Central fan assembly (3rd fan)
11.
Option: Dedicated iLO/M.2 SSD
6.
Power Supply (1x290W)
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Overview
Page 3
Rear View – Standard for all DL20 Gen10
1.
Slot 1 PCIe 3.0
6.
Two USB 3.0 Ports
2.
Slot 2 PCIe 3.0
7.
NIC Port (1Gb)
3.
Option: Serial Port
8.
NIC port (1Gb) /iLo port
4.
290W Non hotplug Power Supply
9.
VGA port
5.
UID LED
10.
Option: Dedicated iLO Management Port
What’s New
•
Intel® Software Guard Extensions.
•
•
•
dant Power Supplies
•
•
Introducing support for Intel® Xeon® E Processors and 2666MHz UDIMM with support for
Intel® SGX is an architecture extension designed to increase the security of application code and data.
Storage Enhancements in the form of increased capacity of up to 6 SFF drives & M.2 SSDs for boot
Dedicated iLO Management Port as an option kit for faster and more secure data transmission
More choice of Power Supplies with 500W 94% efficiency and 800W 48VDC 96% efficiency Flex Slot Redun
Warranty increased from 1yr to 3yrs (parts, labor & Onsite support)
New SMB focussed solutions
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Platform
Information
Page 4
Platform Information
Form Factor
1U rack
Chassis Types
4 SFF with options supporting: +2 SFF
2 LFF Hot Plug
2 LFF Non Hot Plug
System Fans
Includes
NOTE: This applies for all three chassis: 2LFF NHP, 2LFF HP and 4SFF HP
3 standard single rotor non-hot plug and non-redundant fans
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Standard Features
Page 5
Standard Features
in
i3 dual core processors. Choose one
Chipset
http://www.intel.com/products/server/chipsets/
On System Management Chipset
Memory
Type
HPE DDR4 Unbuffered (UDIMM)
DIMM Slots Available
4
4 DIMM slots per processor, 2 channels per processor,
2 DIMMs per channel
Maximum capacity (UDIMM)
64 GB
4 x 16 GB UDIMM @ 2666 MT/s
NOTE: For General Server Memory and DIMM Population Rules and Guidelines for Gen10 see details here:
http://www.hpe.com/docs/memory-population-rules.
Memory Protection
Network Controller
upgrade with a variety of
networking options.
Processors – Intel® Xeon® processor E-Series processor family is designed to deliver the best combination of performance, builtcapabilities, and cost-effectiveness. The product also supports Intel® Pentium® and Intel® Coreof the following processors based on the model.
NOTE: For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon
NOTE: This table covers the public Intel offering only.
Intel Xeon Models CPU Frequency Cores L3 Cache Power DDR4 Intel® SGX
G5400 3.7GHz 2 4MB 58W 2400 No
i3-8300 3.7GHz 4 8MB 62W 2400 No
E-2124 3.3GHz 4 8MB 71W 2666 No
E-2126G 3.3GHz 6 12MB 80W 2666 No
E-2134 3.5GHz 4 8MB 71W 2666 No
E-2136 3.3GHz 6 12MB 80W 2666 No
E-2144G 3.6GHz 4 8MB 71W 2666 No
E-2174G 3.8GHz 4 8MB 71W 2666 Yes
.
Intel® C242 Chipset
NOTE: For more information regarding Intel® chipsets, please see the following
E-2186G 3.8GHz 6 12MB 95W 2666 Yes
URL:
.
HPE iLO 5 ASIC
NOTE: Read and learn more in the iLO QuickSpecs.
ECC
HPE Ethernet 1Gb 2-port 332i network Adapter or BCM5720.
The HPE ProLiant DL20 Gen10 server offers the customer a dual-port NIC standard with the option to
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Standard Features
Page 6
Expansion Slots
Primary
FIO LP Riser
Expansion
Slots #
Technology
Bus Width
Connector
Width
Processor
Slot Form Factor
1 PCIe 3.0
X8
X8
CPU1
Low profile
2 PCIe 3.0
x8
X16
CPU1
Full height half length
Flexible LOM
Riser
Expansion
Slots #
Technology
Bus Width
Connector
Width
Processor
Slot Form Factor
NOTE: This riser is mandatory for installing FlexibleLOMs.
NOTE: Bus Width indicates the number of physical electrical lanes running to the connector.
Storage Controllers
only. For legacy support an additional controller
disk RAID 1 boot volume.
Essential RAID Controllers
HPE Smart Array E208e-p SR Gen10 Controller
Performance RAID Controllers
NOTE: For additional details, please see HPE Smart Array Gen10 Controllers Data Sheet.
Internal Storage Devices
Optical Drive
Available on 4 SFF and 2 LFF CTO Servers as an option (DVD-ROM or DVD-RW)
Hard Drives
None ship standard
Maximum Storage
STORAGE
CAPACITY
CONFIGURATION
Hot Plug SFF SAS HDD
14.4 TB
4 + 2 x 2.4 TB (with optional +2 drive option)
Hot Plug SFF SATA HDD
12 TB
4+2 x 2.0 TB (with optional + 2 drive option)
Hot Plug SFF SAS SSD
91.8 TB
4+2 x 15.3 TB (with optional + 2 drive option)
Hot Plug SFF SATA SSD
23.04 TB
4+2 x 3.84 TB (with optional + 2 drive option)
Hot Plug LFF SAS HDD
24 TB
2 x 12 TB
Hot Plug LFF SATA HDD
24 TB
2 x 12 TB
Hot Plug LFF SAS SSD
1.6 TB
2 x 800 GB
Hot Plug LFF SATA SSD
3.84 TB
2 x 1.92 TB
1 PCIe 3.0 X8 X8 CPU 1 Flexible LOM
2 PCIe 3.0 X8 x16 CPU 1 Full height half length
Software RAID
HPE Smart Array S100i SR Gen10 SW RAID
NOTE: HPE Smart Array S100i SR Gen10 SW RAID will operate in UEFI mode
will be needed, and for CTO orders please also select the Legacy mode settings part, 758959-B22.
NOTE: HPE Smart Array S100i SR Gen10 SW RAID is off by default and must be enabled by selecting 784308-B21.
NOTE: The S100i is a 14-port SATA controller, but only 12 ports are accessible as 2 are leveraged to support the 2 M.2 options
on the Primary Riser.
NOTE: The S100i supports windows only.
NOTE: For Linux users, HPE offers a solution that uses in-distro open-source software to create a two-
For more information visit: https://downloads.linux.hpe.com/SDR/project/lsrrb/
HPE Smart Array E208i-a SR G10 LH Controller
HPE Smart Array P408i-a SR G10 LH Controller
HPE Smart Array P408e-p SR Gen10 Controller
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Standard Features
Page 7
Power Supply
cost options for customers trying to balance their need for enterprise class efficiency
Level power supply options have been
y with 80Plus Silver Certification. It features 92%
less
efficiency operation and
This flexibility helps
14 jumper cord (A0K02A). This jumper cord is also included with
Interfaces
Serial
1 port - Optional
Video
1 Rear - VGA port (standard on all chassis types)
Network Ports
2x 1GbE embedded NIC (standard on all chassis types)
iLO Remote Mgmt Port
1 Gb Dedicated - Optional
USB 3.0
5 USB ports (standard)
Internal: 1x USB 3.0
Operating Systems and Virtualization Software
ClearOS allows you to build a fully functional server that is just right for you at no upfront cost. For more information on
d and Supported ProLiant Servers for OS and Virtualization
HPE 290W FIO Power Supply
NOTE: Available in 92% efficiency.
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
NOTE: Available in 94% efficiency.
HPE 800W Flex Slot -48VDC Platinum Hot Plug Low Halogen Power Supply Kit
NOTE: Flex Slot -48VDC power supplies support power efficiency of up to 94%.
HPE Entry-Level Power Supplies provide lowerand reliability while maintaining lowest possible hardware costs. The above mentioned Entrydesigned specifically for HPE ProLiant DL20 Gen10 Server.
The HPE 290W FIO Power Supply is the standard, non-redundant AC power suppl
power efficiency with a set of features optimized for the DL20 Gen10 rack server.
HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, toolinstallation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for highoffer multiple power output options, allowing users to "right-size" a power supply for specific server configurations.
to reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center.
All pre-configured servers ship with a standard 6-foot IEC C-13/Ceach standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page.
To review the power requirements for your selected system, please use the HPE Power Advisor Tool.
For information on power specifications and technical content visit HPE Server power supplies.
Front: 1xUSB 3.0, 1xUSB iLO Service Port
Rear: 2xUSB 3.0
Windows Server 2016 (Most Recent Version)
VMware vSphere 6.7 and 6.5 U2
NOTE: VMware support is available on Intel Xeon E-Series processors only.
Red Hat Enterprise Linux (RHEL) 7.5
SUSE Linux Enterprise Server (SLES) 15 and 12 SP3
ClearOS/VM 7.5
NOTE:
ClearOS, please visit http://www.hpe.com/servers/clearos.
CentOS 7.5
NOTE: For more information on Hewlett Packard Enterprise Certifie
Software and latest listing of software drivers available for your server.
http://www.hpe.com/info/ossupport
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Standard Features
Page 8
Industry Standard Compliance
NOTE: For additional technical thermal details regarding ambient temperatures, humidity and features support please
visit: http://www.hpe.com/servers/ashrae.
Upgradeability
Graphic
4 Gbit DDR3 with ECC protection
Embedded Management
• ACPI 6.1 Compliant
• PCIe 3.0 Compliant
• WOL Support
• Microsoft® Logo certifications
• PXE Support
• USB 3.0 Compliant
• USB 2.0 Compliant
• SMBIOS 3.1
• UEFI 2.6 (Unified Extensible Firmware Interface Forum)
• Redfish API
• IPMI 2.0
• Secure Digital 4.0
• TPM 1.2 and 2.0 support
• Advanced Encryption Standard (AES)
• Triple Data Encryption Standard (3DES)
• SNMP v3
• TLS 1.2
• DMTF Systems Management Architecture for Server Hardware Command Line (SMASH CLP)
• Active Directory v1.0
• ASHRAE A3/A4
• Energy Star
One of the following depending on model
FlexibleLOM connector for 1 or 10 or 25 Gigabit networking options
Up to 4 DIMM slots available for higher memory capacity
Up to 4SFF (+2SFF optional) Drive bays or 2LFF Drive bays
HPE Smart Array or Smart HBA Controller
Redundant Power Supply
Dedicated iLO Management Port
M.2 NVMe SSDs for boot
Integrated Matrox G200 video standard
• Video modes up to 1920 x 1200 @ 60 Hz (32 bpp)
16 MB Video Memory
HPE iLO 5 on system management memory
• 32 MB Flash
HPE Integrated Lights-Out (HPE iLO)
Monitor your servers for ongoing management, service alerting, reporting and remote management with HPE iLO.
Learn more at http://www.hpe.com/info/ilo.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Standard Features
Page 9
UEFI
Learn more at http://www.hpe.com/servers/uefi.
Intelligent Provisioning
iLO RESTful API
Redfish API conformance and offers simplified server management automation such as configuration and
http://www.hpe.com/info/restfulapi
Server Utilities
ive
Active Health System Viewer
repair
http://www.hpe.com/servers/ahsv
Smart Update
Keep your servers up to date with the HPE Smart Update solution by using Smart Update Manager (SUM) to optimize the firmware
iLO Amplifier Pack
e,
E
http://www.hpe.com/servers/iLOamplifierpack
HPE iLO Mobile Application
s.
http://www.hpe.com/info/ilo/mobileapp
RESTful Interface Tool
at scale.
Learn more at http://www.hpe.com/info/resttool.
Scripting Tools
Provision one to many servers using your own scripts to discover and deploy with Scripting Tool (STK) for Windows and Linux or
http://www.hpe.com/servers/stk
http://www.hpe.com/servers/powershell
HPE OneView Standard
nitor
defined
NOTE: HPE OneView on DL20 Gen10 will be available in 1H 2019.
Configure and boot your servers securely with industry standard Unified Extensible Firmware Interface (UEFI).
Hassle free server and OS provisioning for one or more servers with Intelligent Provisioning.
Learn more at
http://www.hpe.com/servers/intelligentprovisioning.
iLO RESTful API is
maintenance tasks based on modern industry standards. Learn more at
Active Health System
The HPE Active Health System (AHS) is an essential component of the iLO management portfolio that provides continuous, proact
health monitoring of HPE servers. Learn more at http://www.hpe.com/servers/ahs.
Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed problem resolution with HPE selfrecommendations, to learn more visit:
.
.
and driver updates of the Service Pack for ProLiant (SPP). Learn more at http://www.hpe.com/info/smartupdate.
Designed for large enterprise and service provider environments with hundreds of HPE servers, the iLO Amplifier Pack is a fre
downloadable open virtual application (OVA) that delivers the power to discover, inventory and update Gen8, Gen9 and Gen10 HP
servers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities.
Learn more at
.
Enables the ability to access, deploy, and manage your server anytime from anywhere from select smartphones and mobile device
For additional information please visit:
.
RESTful Interface tool (iLOREST) is a single scripting tool to provision using iLO RESTful API to discover and deploy servers
Scripting Tools for Windows PowerShell.
Learn more at
or
.
HPE OneView Standard can be used for inventory, health monitoring, alerting, and reporting without additional fees. It can mo
multiple HPE server generations. The user interface is similar to the HPE OneView Advanced version, but the softwarefunctionality is not available. Learn more at http://www.hpe.com/info/oneview.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Standard Features
Page 10
HPE Systems Insight Manager (HPE SIM)
ity
HPE servers. HPE SIM also integrates with Smart Update Manager to provide
quick and seamless firmware updates. Learn more at http://www.hpe.com/info/hpesim.
Security
• Intel® Software Guard Extensions (Intel® SGX)
Warranty
Hewlett Packard
Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of
vices
available through HPE Pointnext operational services or customized service agreements. Hard drives have either a one year or
Year Onsite support with next business day response. Warranty
repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1)
rts are designed for easy replacement. A travel and labor charge will result when customers decline to replace
a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity.
replace Optional CSR parts at no charge. Additional information
Ideal for environments already using HPE SIM, it allows you to monitor the health of your HPE ProLiant Servers and HPE Integr
Servers. Also provides you with basic support for non-
• UEFI Secure Boot and Secure Start support
• Immutable Silicon Root of Trust
• FIPS 140-2 validation
• Common Criteria certification
• Configurable for PCI DSS compliance
• Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
• Support for Commercial National Security Algorithms (CNSA)
• iLO Security Modes including a New iLO Advanced Premium Security License
• Granular control over iLO interfaces
• Smart card (PIV/CAC) and Kerberos based 2-factor Authentication
• Tamper-free updates – components digitally signed and verified
• Secure Recovery – recover critical firmware to known good state on detection of compromised FW
• Ability to rollback firmware
• Secure erase of NAND
• TPM (Trusted Platform Module) 1.2 option
• TPM (Trusted Platform Module) 2.0 option
• Bezel Locking Kit
• Chassis Intrusion detection option
This product is covered by a global limited warranty and supported by HPE Services and a worldwide network of
Enterprise
purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty ser
are
three year warranty; refer to the specific hard drive QuickSpecs for details.
NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-
Mandatory CSR pa
Customers may choose to have Hewlett Packard Enterprise
regarding worldwide limited warranty and technical support is available at:
http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Optional Features
Page 11
Server Management
udes
user collaboration, console record and replay,
based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management
HPE iLO Advanced Premium Security Edition
end security modes, unique security
m
http://www.hpe.com/servers/ilopremium
HPE OneView Advanced
isioning,
featured licenses which can be purchased
NOTE: HPE OneView on DL20 Gen10 will be available in 1H 2019.
HPE InfoSight for Servers
Health System (AHS) and iLO to optimize performance and predict and prevent problems. The end result is an intelligent
environment that modernizes IT operations and enhances the support experience by predicting and preventing the infrastructure
Learn more at https://www.hpe.com/servers/infosight
HPE Insight Cluster Management Utility (CMU)
management framework that includes software for the centralized
http://www.hpe.com/info/cmu
Rack and Power Infrastructure
and business grow. We’ve reinvented our
secure, more practical, and more efficient. In other words,
ry leader,
the key concerns of power, cooling, cable management and system
HPE G2 Advanced and Enterprise Racks are perfect for the server room or today’s modern data center with enhanced airflow and
coded outlets and
effective power protection for any type workload. Some UPSs include options for remote
s to
HPE iLO Advanced
HPE iLO Advanced licenses offer smart remote functionality without compromise, for all HPE ProLiant servers. The license incl
the full integrated remote console, virtual keyboard, video, and mouse (KVM), multiand GUIfunctionality. Learn more about HPE iLO Advanced at http://www.hpe.com/servers/iloadvanced.
HPE iLO Advanced Premium Security Edition for iLO 5 includes iLO Advanced License plus highcapabilities, like Automatic FW recovery; Runtime FW verification, and Secure erase. Learn more about HPE iLO Advanced Premiu
Security Edition at:
HPE OneView brings a new level of automation to infrastructure management by taking a template driven approach to prov
updating, and integrating compute, storage, and networking infrastructure. It provides fullfor managing Gen8, Gen9 and Gen10 servers. To learn more visit http://www.hpe.com/info/oneview.
HPE InfoSight for Servers combines the cloud-based machine learning of InfoSight with the health and performance monitoring of
Active
.
issues that lead to application disruptions, wasted IT staff time and missed business opportunities.
HPE Insight Cluster Management Utility is a HyperScale
provisioning, management and monitoring of nodes and infrastructure. Learn more at
.
The story may end with servers, but it starts with the foundation that makes compute go –
entire portfolio of rack and power products to make IT infrastructure more
we’ve created a stronger, smarter, and simpler infrastructure to help you get the most out of your IT equipment. As an indust
Hewlett Packard Enterprise is uniquely positioned to address
access.
thermal management, flexible cable management, and a 10 year Warranty to support higher density computing.
HPE G2 PDUs offer reliable power in flexible form factors that operate at temperatures up to 60°, include colorload segments and a low-profile design for optimal access to the rack and support for dense rack environments.
HPE Uninterruptible Power Systems are costmanagement and runtime modules so you’re critical dense data center is covered in power outages.
HPE KVM Solutions include a console and switches designed to work with your server and IT equipment reliably. We’ve got a costeffective KVM switch for your first rack and multiple connection IP switches with remote management and security capabilitie
keep your data center rack up and running.
Learn more about HPE Racks, KVM, PDUs and UPSs at HPE Rack and Power Infrastructure.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Optional Features
Page 12
One Config Simple (SCE)
technical people provide customers with initial configurations in 3 to 5 minutes.
stom"
Hewlett Packard Enterprise Customer Business
SCE is a guided self-service tool to help sales and nonYou may then send the configuration on for configuration help, or use in your existing ordering processes. If you require "cu
rack configuration or configuration for products not available in SCE, please contact
Center or an Authorized Partner for assistance.
https://h22174.www2.hpe.com/SimplifiedConfig/Welcome#
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Service and Support
Page 13
HPE Pointnext - Service and Support
Protect your business beyond warranty with HPE Pointnext
HPE Pointnext provides a comprehensive portfolio including Advisory and Transformational, Professional, and Operational Services
to help accelerate your digital transformation. From the onset of your transformation journey, Advisory and Transformational Services
focus on designing the transformation and creating a solution roadmap. Professional Services specializes in creative configurations
with flawless and on
provides innovative new approaches
like Flexible Capacity and Datacenter Care, to keep your business at peak performance. HPE is ready to bring together all the pieces
of the puzzle for you, with an eye on the future, and make the complex simple.
Connect your devices:
p to
reduction in down time, near 100%2 diagnostic accuracy and a single consolidated view of your environment. By connecting,
failure alerts, automatic call logging, and automatic parts dispatch. HPE Proactive Care Service
imization.
Recommended Services
This service
urs. In addition, Collaborative
ur
HPE Foundation Care 24x7, three-year Support Service
ervice
his service
rience
HPE Proactive Care* with 24x7 coverage, three year Support Service
enhanced call experience. When your products are connected to HPE, Proactive Care helps
Service
rting and advice with our 24x7 coverage, four hour hardware response time when there is a
problem. This service also includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare,
https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf
HPE Proactive Care* - Next Business Day service, three year Support Service
nhanced call experience. When your products are connected to HPE, Proactive Care helps
service
authorized representative will arrive at the Customer's
has
(Red Hat, VMWare,
Operational Service
-time implementation, and on-budget execution. Finally, operational services
Unlock all of the benefits of your technology investment by connecting your products to Hewlett Packard Enterprise. Achieve u
77%1
you will receive 24x7monitoring, preand HPE Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase opt
All of these benefits are already available to you with your server storage and networking products, securely connected to HPE support.
NOTE:1. DC 2 – HP CSC reports 2014 – 2015
Learn more about getting connected at http://www.hpe.com/services/getconnected
HPE Foundation Care NBD, three-year Support Service
HPE Foundation Care Next Business Day connects you to HPE during business hours for assistance on resolving issues –
features need based next business day hardware onsite response and software call back within two ho
software support and provides troubleshooting assistance on industry leading software running on your HPE server. Simplify yo
support experience and make HPE your first call to help resolve hardware or software problems.
https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en
.
HPE Foundation Care 24x7 gives you access to HPE 24 hours a day, seven days a week for assistance on resolving issues. This s
includes need based Hardware onsite response within four hours. In addition, collaborative software support is included in t
that provides troubleshooting assistance on industry leading software running on your HPE server. Simplify your support expe
and make HPE your first call to help resolve hardware or software problems.
https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en
HPE Proactive Care gives customers an
prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice This
combines three years proactive repo
Microsoft, etc.) running on your HPE servers.
HPE Proactive Care gives customers an e
prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice. This
combines three years of Hardware Support where a Hewlett Packard Enterprise
site during the onsite coverage window to begin hardware maintenance service the next coverage day after the service request
been logged. This service also includes collaborative software support for Independent Software Vendors (ISVs),
Microsoft, etc.) running on your HPE servers.
https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf
NOTE:*HPE Proactive Care and HPE Proactive Care Advanced require that the customer connect their devices to make the most
of these services and receive all the deliverables.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Service and Support
Page 14
Other related Services
bringing
https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-9356EN.pdf
HPE Installation and Startup Service
delivery
technician will connect the product to a LAN as appropriate and enable remote support to allow for automatic case creation for
ype (Windows®
or Linux).
HPE Datacenter Care service
is a structured
services “building blocks.” You can deploy, operate, and evolve your datacenter
ngle
HPE GreenLake Flex Capacity
public cloud in the privacy of your data center.
based payment, rapid scalability without worrying about capacity constraints.
dvantages that IT provides the business (i.e., control,
d manage
the cost of IT. And, you have the option to use the public cloud when needed.
DC for Hyperscale
with
is environment support tailored to their
operating model.
HPE Factory Express for Servers and storage
ucts.
vices as
s, such as image loading, asset tagging, and custom packaging. HPE products supported through
des,
s as well as the MSAxxxx3PAR suite, XP, rackable tape libraries and configurable network switches.
HPE Service Credits
at is
T. Offered
HPE Education Services
and learn
HPE Server Hardware Installation
Provides for the basic hardware installation of HPE branded servers, storage devices and networking options to assist you in
your new hardware into operation in a timely and professional manner.
Provides for the installation of your HPE hardware according to product specifications including options. The HPE service
hardware failures. Installation and start up services also includes the installation of one supported operating system t
HPE Datacenter Care helps improve IT stability and security, increase the value of IT, and enable agility and innovation. It
framework of repeatable, tested, and globally available
wherever you are on your IT journey. With HPE Datacenter Care, you benefit from a personalized relationship with HPE via a si
point of accountability for HPE and others’ products. For more information, visit
http://www.hpe.com/services/datacentercare
With HPE GreenLake Flex Capacity, you get the speed, scalability, and economics of the
Gain the advantages of the public cloud—consumptionReduce the “heavy lifting” needed to operate a data center. And retain the a
security). Deliver the right user experience, choose the right technology for the business, manage privacy and compliance, an
Datacenter Care for Hyperscale is available for Service Providers and HPC customers who use a scale out approach to computing
a high volume homogenous infrastructure and resilient architecture can take advantage of th
HPE Factory Express offers configuration, customization, integration and deployment services for HPE servers and storage prod
Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design ser
well as individual factory service
Factory Express include a wide array of servers and storage: HPE Integrity, HPE ProLiant, HPE Apollo, HPE ProLiant Server Bla
HPE BladeSystem, HPE 9000 server
HPE Service Credits offers flexible services and technical skills to meet your changing IT demands. With a menu of service th
tailored to suit your needs, you get additional resources and specialist skills to help you maintain peak performance of your I
as annual credits, you can plan your budgets while proactively responding to your dynamic business.
Keep your IT staff trained making sure they have the right skills to deliver on your business outcomes. Book on a class today
how to get the most from your technology investment.
http://www.hpe.com/ww/learn
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Service and Support
Page 15
HPE Support Center
usiness
s, access support resources or collaborate with
at
HPE Support Center Mobile
covered under the HPE Service Contract applied to the HPE ProLiant Server. No
support
under
s needed.
t is only required
lue options
here.
Parts and Materials
supported replacement parts and materials necessary to maintain the covered hardware
the
repaired, or replaced
Hewlett Packard
Enterprise due to malfunction.
The HPE Support Center is a personalized online support portal with access to information, tools and experts to support HPE b
products. Submit support cases online, chat with Hewllet Packard Enterprise expert
peers.Learn more http://www.hpe.com/support/hpesc.
The HPE Support Center Mobile App* allows you to resolve issues yourself or quickly connect to an agent for live support. Now, you
can get access to personalized IT support anywhere, anytime. HPE Insight Remote Support and HPE Support Center are available
no additional cost with a HPE warranty, HPE Support Service or HPE contractual support agreement.*
App is subject to local availability.For more information: http://www.hpe.com/services.
NOTE:* HPE ProLiant DL20 Gen10 Server is
separate HPE support services need to be purchased.
Warranty and Support Services will extend to include HPE options configured with your server or storage device. The price of
service is not impacted by configuration details. HPE sourced options that are compatible with your product will be covered
your server support at the same level of coverage allowing you to upgrade freely. Installation for HPE options is available a
To keep support costs low for everyone, some high value options will require additional support. Additional suppor
on select high value workload accelerators, fibre switches, InfiniBand and UPS batteries over 12KVA. See the specific high va
that require additional support
Hewlett Packard Enterprise will provide HPEproduct in operating condition, including parts and materials for available and engineering improvements.
Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in
manufacturer's operating manual, product QuickSpecs, or the technical product data sheet will not be provided,
as part of these services.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Pre
-configured Models
Page 16
1. Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section of
additional options
3. If you desire a custom configuration please see "Configuration Information - Factory Integrated Models" section of this QuickSpecs.
Entry Models
Performance Models
[SKU Number]
P06476-B21
P08335-B21
P06477-B21
P06478-B21
Model Name
HPE DL20 Gen10
Svr
HPE DL20 Gen10 E-
Svr
HPE DL20 Gen10 E-
HPE DL20 Gen10 E-
Processor
Intel® Pentium® G5400
Intel® Xeon® E-2124
Intel® Xeon® E-2124
Intel® Xeon® E-2136
Number of Processors
One
Memory
8GB (1x8GB UDIMM,
2666 MHz)
8GB (1x8GB UDIMM,
2666 MHz)
16GB (1x16GB
UDIMM, 2666 MHz)
16GB (1x16GB UDIMM,
2666 MHz)
Network Controller
HPE embedded 1Gb 2-port 332i network Adapter
Storage Controller
Embedded 14-port S100i
NOTE: SATA only
Hard Drive
None ship standard; includes 2 LFF hard drive
blanks
None ship standard
Internal Storage
2 LFF HDD Bays (Non Hot Plug)
2 LFF HDD Bays (Hot
Plug)
4 SFF HDD Bays (Hot
Plug)
Optical Drive Bay
1; (Optional: DVD-ROM, DVD-RW)
Optical Drive
None
PCI-Express Slots
2 PCIe 3.0 slots
Power Supply
(1) 290W Non Hot Plug Power Supply
1 x 500W
Fans
3 non hot plug, non-redundant
Management
iLO Management (standard), Intelligent Provisioning (standard), iLO Essentials (optional), iLO Scale-out
(optional only for DL), iLO Advanced (optional)
Form Factor
Rack (1U), HPE Short Friction Rail Kit
Warranty
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day
response
this QuickSpecs.
2.Hewlett Packard Enterprise does not allow factory integration of options into pre-configured models. Any
purchased will be shipped separately.
G5400 1P 8G NHP Ety
2124 1P 8G NHP Ety
2124 1P 16G Perf Svr
2136 1P 16G Perf Svr
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Pre
-configured Models
Page 17
Solution Model
[SKU Number]
P06479-B21
Model Name
HPE DL20 Gen10 E-2134 1P 16G Soln Svr
Processor
Intel® Xeon® E-2134
Number of
One
Memory
16GB (1x16GB UDIMMs, 2666 MHz)
Network Controller
HPE embedded 1Gb 2-port 332i network Adapter
Storage Controller
Embedded 14-port S100i
NOTE:
Hard Drive
None ship standard
Internal Storage
4 SFF HDD Bays
Optical Drive Bay
1; (Optional: DVD-ROM, DVD-RW)
Optical Drive
None
PCI-Express Slots
2 PCIe 3.0 slots
Power Supply
(1) HPE 500W Redundant Power Supply
Fans
3 non hot plug, non-redundant
Management
iLO Management (standard), Intelligent Provisioning (standard),
out
(optional only for DL), iLO Advanced (optional)
Energy Star
Meets Energy Star requirements
Form Factor
Rack (1U), HPE Short Friction Rail Kit
Warranty
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response
Country Code Key
xx1 = B21
Worldwide
xx1 = 291
Japan
xx1 = AA1
xx1 = 371
PRC
India
NOTE: The -B21 WW SKU is to be ordered in all countries other than Japan, PRC or India.
Processors
SATA only
iLO Essentials (optional), iLO Scale-
QuickSpecs
HPE ProLiant DL20 Gen10 Server
SMB
Models
Page 18
1. New SMB focused offers regionally released as “Smart Buy Express” in the U.S. and Canada, “Top Value” in Europe, and “Intelligent
2. SMB Models ship with the configurations below. Options can be selected from the Core or Additional options section of this
ls. Any additional options purchased will
4. If you desire to custom configure an SMB Model please consult your preferred reseller.
Entry Model
Performance Models
Solution Model
[SKU Number]
P08335-B21
P06477-B21
P06478-B21
P06479-B21
Model Name
HPE DL20 Gen10 E-2124
HPE DL20 Gen10 E-
HPE DL20 Gen10 E-2136
HPE DL20 Gen10 E-
Svr
Processor
Intel® Xeon® E-2124
Intel® Xeon® E-2124
Intel® Xeon® E-2136
Intel® Xeon® E-2134
Number of
Processors
Memory
8GB (1x8GB UDIMM,
2666 MHz)
16GB (1x16GB UDIMM,
2666 MHz)
16GB (1x16GB UDIMM,
2666 MHz)
16GB (1x16GB
UDIMM, 2666 MHz)
Network
Controller
HPE embedded 1Gb 2-port 332i network Adapter
Storage Controller
Embedded 14-port S100i
NOTE: SATA only
Hard Drive
None ship standard
Internal Storage
2 LFF HDD Bays (Non Hot
Plug)
2 LFF HDD Bays (Hot
Plug)
4 SFF HDD Bays (Hot Plug)
Optical Drive Bay
1; (Optional: DVD-ROM, DVD-RW)
Optical Drive
None
PCI-Express Slots
2 PCIe 3.0 slots
Power Supply
(1) 290W Non Hot Plug Power Supply
1 x 500W
Fans
3 non hot plug, non-redundant
Management
(optional only for DL), iLO Advanced (optional)
Form Factor
Rack (1U), HPE Short Friction Rail Kit
Warranty
Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day
response
Country Code Key
xx1 = B21
Worldwide
xx1 = 291
Japan
xx1 = AA1
PRC
xx1 = 371
India
NOTE: The -B21 WW SKU is to be ordered in all countries other than Japan, PRC or India.
Buy” in Asia Pacific and Japan”
QuickSpecs.
3. Hewlett Packard Enterprise does not provide factory integration of options into SMB Mode
be shipped separately and would need to be field integrated.
1P 8G NHP Ety Svr
2124 1P 16G Perf Svr
1P 16G Perf Svr
2134 1P 16G Soln
One
iLO Management (standard), Intelligent Provisioning (standard), iLO Essentials (optional), iLO Scale-out
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Configuration Information
- Factory Integrated Models
Page 19
This section lists some of the steps required to configure a Factory Integrated Model.
configurator.
4. Some options may not be integrated at the factory. Contact your local sales representative for additional information
Step 1: Base Configuration (choose one of the following configurable models)
[Chassis]
HPE ProLiant DL20 Gen10 Non-
Server
HPE ProLiant DL20 Gen10 2LFF
HPE ProLiant DL20 Gen10 4SFF
SKU Number
P06961-B21
P06962-B21
P06963-B21
Processor
1 1 1
DIMM Slots
4 DIMM slots for UDIMM DDR4 Memory
Storage Controller
Embedded 14-port S100i
PCIe
2 PCIe 3.0 Slots
Drive Cage
2LFF Non Hot Plug
2LFF Hot Plug
4SFF Hot Plug
Network Controller
HPE embedded 1Gb 2-port 332i network Adapter
Fans
3 non hot plug, non-redundant
Management
iLO Management (standard), Intelligent Provisioning (standard)
USB
2 front, 1 internal, 2 rear
Ears
HPE Thumbscrew Ears
Step 2a: Choose Processor Options
Processor Option Kits
Required Processor
Intel Xeon-E Series
HPE DL20 Gen10 Intel Xeon E-2124 (3.3GHz/4-core/71W) FIO Processor Kit
P06642-L21
HPE DL20 Gen10 Intel Xeon E-2134 (3.5GHz/4-core/71W) FIO Processor Kit
P06646-L21
HPE DL20 Gen10 Intel Xeon E-2144G (3.6GHz/4-core/71W) FIO Processor Kit
P06650-L21
HPE DL20 Gen10 Intel Xeon E-2174G (3.8GHz/4-core/71W) FIO Processor Kit
P06656-L21
HPE DL20 Gen10 Intel Xeon E-2126G (3.3GHz/6-core/80W) FIO Processor Kit
P06648-L21
HPE DL20 Gen10 Intel Xeon E-2136 (3.3GHz/6-core/80W) FIO Processor Kit
P06652-L21
HPE DL20 Gen10 Intel Xeon E-2186G (3.8GHz/6-core/95W) FIO Processor Kit
P08171-B21
Intel® Core® i3 series Processors
HPE DL20 Gen10 Intel Core i3-8300 (3.7GHz/4-core/62W) FIO Processor Kit
P06638-L21
Intel® Pentium® G5000 series Processors
HPE DL20 Gen10 Intel Pentium G5400 (3.7GHz/2-core/54W) FIO Processor Kit
P06632-L21
To ensure valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved
Contact your local sales representative for information on configurable product offerings and requirements.
1. Factory Integrated Models must start with a CTO Server.
2. FIO indicates that this option is only available as a factory installable option.
3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on number of drives ordered with server.
hot Plug 2LFF Configure-to-order
Configure-to-order Server
Configure-to-order Server
Please select one –L21 processor required below.
NOTE: Only one processor supported.
NOTE: DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on the quantity and
type of DIMMs installed.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Configuration Information
- Factory Integrated Models
Page 20
Step 2b: Choose Memory Options
Please select one or more memory from below.
NOTE:
NOTE: HPE Standard Memory (UDIMM) is required to realize the memory performance improvements and enhanced functionality
listed in this document for th
NOTE:
Unbuffered DIMMs (UDIMMs) – 2666 MHz
HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Unbuffered Standard Memory Kit
879505-B21
HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Unbuffered Standard Memory Kit
879507-B21
Step 2c: Choose Power Supplies
Please select one or two power supplies from below.
NOTE: Mixing of 2 different power supplies are NOT allowed.
HPE ProLiant Gen10 Essential Server Power Supplies - Non-Redundant
HPE DL20 Gen10 290W FIO Power Supply Unit Kit
P06731-B21
NOTE: 290W PSU is a Non hot plug power supply
NOTE: This FIO option can only be bought integrated in the server. It cannot be ordered as a standalone option
after server purchase.
HPE Flex Slot Power Supplies -
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
865408-B21
HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply Kit
865434-B21
HPE DL20 Gen10 RPS Enablement FIO Kit
P06722-B21
NOTE: It is mandatory to choose the RPS enablement kit to support redundant power supply.
NOTE:
option after server purchase.
Step 3: Choose Additional (FIO) Factory Integratable Options
Each of the following may be selected if desired at time of factory integration
HPE Trusted Platform Module 2.0 Gen10 Option
864279-B21
NOTE: HPE Trusted Platform Module 2.0 option works with Gen10 servers with UEFI Mode not Legacy Mode.
It is not compatible with HPE ProLiant Gen8 servers or earlier
NOTE: HPE server systems can have a TPM module (of any type) installed only once. It cannot be replaced
with any other TPM module.
HPE Gen10 TPM 1.2 FIO Setting
872108-B21
NOTE: TPM 2.0 is set as default, for 1.2 TPM setting instead, please select this option.
HPE Legacy FIO Mode Setting
758959-B22
NOTE: UEFI is the default, this FIO part can be used for CTO to enable Legacy mode.
Step 4: Choose Additional Options for Factory Integration from Core and Additional Option sections below
HPE memory from previous generation servers is not qualified or warranted with this HPE ProLiant Server.
is HPE ProLiant Server.
With one processor installed, four DIMMs slots are available.
This RPS FIO option can only be bought integrated in the server. It cannot be ordered as a standalone
generation variants.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Core
Options
Page 21
NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard
sales representative
for additional information.
HPE Unique Options
Risers
HPE DL20 Gen10 PCIe Low Profile Riser Kit
P09145-B21
HPE DL20 Gen10 x8x16 FlexibleLOM Riser Kit
P06667-B21
NOTE: One of the riser from above has to be selected mandatorily.
Riser Information
Slot Bus width
(Gen3 lanes)
Optical Drive Options
HPE Mobile USB DVD-RW Optical Drive
701498-B21
NOTE: This kit is only supported on USB 3.0 ports only.
HPE 9.5mm SATA DVD-ROM Optical Drive
726536-B21
HPE 9.5mm SATA DVD-RW Optical Drive
726537-B21
HPE DL20 Gen10 LFF ODD Cable Kit
P06681-B21
NOTE: This option kit is required for Optical Drive option (LFF model only).
HPE DL20 Gen10 SFF ODD Enablement Kit
P06677-B21
NOTE: This option kit is required to support ODD on SFF chassis.
SFF Drive Option Kit
HPE DL20 Gen10 2SFF HDD Enablement Kit
P06671-B21
NOTE: This option is required to upgrade 4SFF chassis to support additional 2SFF drives.
Dedicated iLO Port / M.2 NVMe SSD / COM Port Upgrade Kit
HPE DL20/ML30 Gen10 M.2/Dedicated iLO and Serial Port Kit
P06687-B21
NOTE: This option is required to support M.2 NVMe drives, Dedicated iLO Port or Serial/COM Port.
temperature should be under 30°C (86°F).
Security
HPE Trusted Platform Module 2.0 Gen10 Option
864279-B21
HPE DL20 Gen10 Latch Ear FIO Kit
P06716-B21
NOTE: This FIO option can only be bought integrated in the server. It cannot be ordered as a standalone option
after server purchase. This Option is required either of the two options below.
HPE 1U Gen10 Bezel Kit
867998-B21
HPE Bezel Lock Kit
875519-B21
NOTE: HPE DL20 Gen10 Latch Ear FIO Kit (P06716-B21) is required to support both the Bezel Kits above.
Enterprise recommends the use of an Hewlett Packard Enterprise approved configurator. Contact your local
Part number Description Riser
#1 #2
P09145-B21 HPE DL20 Gen10 x16/x8 Low Profile Riser Optional X8 X8
P06667-B21 HPE DL20 Gen10 x16/x8 Flexible LOM Riser Kit Optional X8 X8
NOTE: When installing Seagate NVMe x4 M.2 400/480 GB SSD module, the supporting ambient
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Core
Page 22
Cable Kits
HPE DL20 Gen10 M.2 SATA/LFF AROC Cbl Kit
P06683-B21
NOTE: This cable kit has two cables, one is required to support M.2 SATA option kit and the other for AROC
and LFF drives.
HPE Drives
Enterprise - 12G SAS - SFF Drives
HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD
881457-B21
HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD
872481-B21
HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872479-B21
HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872477-B21
HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872475-B21
HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
870759-B21
HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
870757-B21
HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
870753-B21
Midline - 6G SATA - LFF Drives
HPE 12TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD
881787-B21
HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e Digitally Signed Firmware HDD
834028-B21
HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD
861742-B21
HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
861683-B21
HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
861681-B21
HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
861686-B21
6G SATA - LFF NHP/Raw Drives
HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) RW 1yr Wty HDD
801882-B21
HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) RW 1yr Wty HDD
801888-B21
Midline 6G SATA - SFF Drives
HPE 2TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD
765455-B21
HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD
655710-B21
Midline - 12G SAS - LFF Drives
HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
833926-B21
HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
833928-B21
HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e Digitally Signed Firmware HDD
834031-B21
HPE 12TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD
881781-B21
HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD
861746-B21
Midline - 12G SAS - SFF Drives
HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD
765466-B21
HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD
832514-B21
HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD
765464-B21
Options
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Core
Page 23
SSD Selection
To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability, HPE
recommends SSDs from the list located here: http://www.hpe.com/products/recommend.
Read Intensive - 12G SAS - SFF - Solid State Drives
HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06584-B21
HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06586-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06588-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06590-B21
HPE 15.3TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06592-B21
Mixed Use - 12G SAS - SFF - Solid State Drives
HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05976-B21
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05980-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05986-B21
HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05994-B21
Write Intensive - 12G SAS - SFF - Solid State Drives
HPE 960GB SAS 12G Mixed Use SC 3yr Wty Value SAS Digitally Signed Firmware SSD
P10448-B21
HPE 1.92TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD
P10454-B21
HPE 3.84TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD
P10460-B21
HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD
P10440-B21
HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD
P10442-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD
P10444-B21
HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD
P10446-B21
Read Intensive - SATA - SFF - Solid State Drives
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04570-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06198-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04566-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06196-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04564-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06194-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04560-B21
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
875503-B21
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04556-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06200-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04474-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04476-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04478-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04480-B21
HPE 7.68TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04482-B21
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05924-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05928-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05932-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05938-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P05946-B21
Options
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Core
Options
Page 24
Read Intensive - SATA - LFF - Solid State Drives
HPE 480GB SATA 6G Read Intensive LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD
P04499-B21
HPE 1.92TB SATA 6G Read Intensive LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD
P04501-B21
Mixed Use - SATA - SFF - Solid State Drives
HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P00896-B21
HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P07922-B21
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P07926-B21
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P07930-B21
Mixed Use - SATA - LFF - Solid State Drives
HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD
P07934-B21
Read Intensive - NVMe - M.2 - Solid State Drives
HPE 480GB NVMe x4 Lanes Read Intensive M.2 22110 3yr Wty Digitally Signed Firmware SSD
875579-B21
NOTE: HPE DL20/ML30 Gen10 M.2/Dedicated iLO and Serial Port Kit (P06687-B21).
When installing Seagate NVMe x4 M.2 400/480 GB SSD module, the supporting ambient temperature should be under
30°C (86°F).
Write Intensive - NVMe - M.2 - Solid State Drives
HPE 400GB NVMe x4 Lanes Mixed Use M.2 22110 3yr Wty Digitally Signed Firmware SSD
875583-B21
NOTE: HPE DL20/ML30 Gen10 M.2/Dedicated iLO and Serial Port Kit (P06687-B21).
When installing Seagate NVMe x4 M.2 400/480 GB SSD module, the supporting ambient temperature should be under
30°C (86°F).
Internal Dual M.2 Kit
HPE Universal SATA HHHL 3yr Wty M.2 Kit
878783-B21
NOTE: The Universal SATA M.2 Kit above will require a PCIe slot and support up to two of the same M.2 cards below.
NOTE: M.2 SATA Cable kit (P06683-B21) is required to support this option.
Read Intensive - M.2 - Solid State Drives (2280 type)
HPE 480GB SATA 6G Read Intensive M.2 2280 3yr Wty Digitally Signed Firmware SSD
875498-B21
HPE 960GB SATA 6G Read Intensive M.2 2280 3yr Wty Digitally Signed Firmware SSD
875500-B21
Mixed Use - M.2 - Solid State Drives (2280 type)
HPE 240GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD
875488-B21
HPE 480GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD
875490-B21
HPE 960GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD
875492-B21
Hard Drive Blank Kits
HPE Gen9 LFF HDD Spade Blank Kit
807878-B21
HPE Small Form Factor Hard Drive Blank Kit
666987-B21
HPE Networking
25 Gigabit Ethernet adapters
HPE Ethernet 10/25Gb 2-port 622FLR-SFP28 Converged Network Adapter
867334-B21
HPE Ethernet 10/25Gb 2-port 621SFP28 Adapter
867328-B21
NOTE: Running at PCIe 3.0 x2 speed on DL20 Gen10.
NOTE: Not supported by HPE Smart Array controllers.
NOTE:
NOTE: Running at PCIe 3.0 x2 speed on DL20 Gen10.
NOTE: Not supported by HPE Smart Array controllers.
NOTE:
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Core
Page 25
10 Gigabit Ethernet adapters
HPE Ethernet 10Gb 2-port 562T Adapter
817738-B21
HPE Ethernet 10Gb 2-port 562SFP+ Adapter
727055-B21
HPE Ethernet 10Gb 2-port 535T Adapter
813661-B21
HPE Ethernet 10Gb 2-port 530SFP Adapter
652503-B21
HPE Ethernet 10Gb 2-port 530T Adapter
656596-B21
HPE Ethernet 10Gb 2-port 521T Adapter
867707-B21
1 Gigabit Ethernet adapters
HPE Ethernet 1Gb 4-port 366T Adapter
811546-B21
NOTE: A maximum of one 366T is supported on DL20 Gen10
HPE Ethernet 1Gb 2-port 361T Adapter
652497-B21
HPE Ethernet 1Gb 2-port 332T Adapter
615732-B21
FlexibleLOM Adapters
HPE Ethernet 10/25Gb 2-port 622FLR-SFP28 Converged Network Adapter
867334-B21
HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter
727054-B21
HPE Ethernet 10Gb 2-port 562FLR-T Adapter
817745-B21
HPE FlexFabric 10Gb 4-port 536FLR-T Adapter
764302-B21
HPE Ethernet 10Gb 2-port 535FLR-T Adapter
817721-B21
HPE FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter
700751-B21
HPE FlexFabric 10Gb 2-port 533FLR-T Adapter
700759-B21
HPE Ethernet 1Gb 4-port 366FLR Adapter
665240-B21
NOTE: FlexibleLOM riser kit (P06667-B21) is required for above.
er is installed on a server with default iLO settings, the port 1 of FlexibleLOM adapter will be
configured as shared iLO port.
Options
NOTE: When a FlexibleLOM adapt
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Additional Options
Page 26
NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard
Contact your local sales representative for additional
information.
Embedded Management
HPE iLO Advanced
HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
512485-B21
HPE iLO Advanced Flexible Quantity License with 1yr Support on iLO Licensed Features
512486-B21
HPE iLO Advanced AKA Tracking License with 1yr Support on iLO Licensed Features
512487-B21
HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
BD505A
HPE iLO Advanced Flexible Quantity License with 3yr Support on iLO Licensed Features
BD506A
HPE iLO Advanced AKA Tracking License with 3yr Support on iLO Licensed Features
BD507A
HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
E6U59ABE
HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
E6U64ABE
HPE Converged Infrastructure Management Software
HPE OneView Advanced (with HPE iLO Advanced)
HPE OneView including 3yr 24x7 Support Physical 1-server LTU
E5Y34A
HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU
E5Y35AAE
HPE OneView Advanced (without HPE iLO Advanced)
HPE OneView w/o iLO including 3yr 24x7 Support 1-server LTU
P8B24A
HPE OneView w/o iLO including 3yr 24x7 Support Track 1-server LTU
P8B25A
HPE OneView w/o iLO including 3yr 24x7 Support Flexible Quantity E-LTU
P8B26AAE
HPE OneView Physical Media Kit LTU
E5Y37A
NOTE: Licenses ship without media. The HPE OneView Media Kit can be ordered separately, or can be downloaded at:
separately, or can be downloaded at:
https://www.hpe.com/us/en/integrated-systems/software.html.
HPE Security
HPE 1U Gen10 Bezel Kit
867998-B21
HPE Bezel Lock Kit
875519-B21
NOTE: HPE DL20 Gen10 Latch Ear FIO Kit (P06716-B21) is required to support both the Bezel Kits above.
HPE 1U Gen10 Chassis Intrusion Detection Kit
866473-B21
NOTE: This provides a physical connection from the chassis board and hood and detects any physicalintrusion into the chassis,
providing security during the entire supply chain process of shipping, receiving, distribution, and operation.
HPE Trusted Platform Module 2.0 Gen10 Option
864279-B21
NOTE: HPE Trusted Platform Module 2.0 option works with Gen10 servers with UEFI Mode not Legacy Mode. It is not compatible
with any other TPM module.
HPE Gen10 TPM 1.2 FIO Setting
872108-B21
NOTE: This is a FIO setting to allows the TPM 2.0 module to operate in a TPM 1.2 mode
Enterprise recommends the use of an HPE approved configurator.
https://www.hpe.com/us/en/integrated-systems/software.html.
NOTE: Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single activation key.
NOTE: Licenses ship without media. The HPE OneView Media Kit can be ordered
with HPE ProLiant Gen8 servers or earlier generation variants.
NOTE: HPE server systems can have a TPM module (of any type) installed only once. It cannot be replaced
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Additional Options
Page 27
HPE Storage Controllers
HPE Flexible Smart Array Controllers -
HPE Smart Array P408i-a SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS Modular LH Controller
869081-B21
HPE Smart Array E208i-a SR Gen10 (8 Internal Lanes/No Cache) 12G SAS Modular LH Controller
869079-B21
HPE Smart Array Controllers -
HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller
804405-B21
HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller
804398-B21
HPE Smart Array Controller Batteries
782961-B21
HPE Cable Options -
HPE DL20 Gen10 M.2 SATA/LFF AROC Cbl Kit
P06683-B21
NOTE: This cable kit has two cables, one is required to support M.2 SATA option kit and the other for AROC and LFF drives.
HPE DL20 Gen10 LFF ODD Cable Kit
P06681-B21
NOTE: This option kit is required for Optical Drive option (LFF model only).
Optional Software
HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU
Q2F26AAE
HPE Smart Array SR SmartCache (Single Key/Single Server) LTU
D7S26A
HPE Smart Array SR SmartCache (Single Key/Multiple Servers) LTU
D7S27A
HPE Smart Array SR SmartCache (Single Key/Multiple Servers) E-LTU
D7S27AAE
NOTE: SmartCache is offered on HPE Smart Array performance RAID controllers and comes standard (no licensing is required) if
the HPE Smart Array P816i-a SR Gen10 Controller is installed in the server.
HPE Storage Options
Emulex Fibre Channel HBAs -
HPE StoreFabric SN1200E 16Gb Single Port Fibre Channel Host Bus Adapter
Q0L13A
HPE StoreFabric SN1200E 16Gb Dual Port Fibre Channel Host Bus Adapter
Q0L14A
HPE StoreFabric SN1600E 32Gb Single Port Fibre Channel Host Bus Adapter
Q0L11A
HPE StoreFabric SN1600E 32Gb Dual Port Fibre Channel Host Bus Adapter
Q0L12A
QLogic Fibre Channel HBAs -
HPE StoreFabric SN1100Q 16Gb Single Port Fibre Channel Host Bus Adapter
P9D93A
HPE StoreFabric SN1100Q 16Gb Dual Port Fibre Channel Host Bus Adapter
P9D94A
HPE StoreFabric SN1600Q 32Gb Single Port Fibre Channel Host Bus Adapter
P9M75A
Converged Network Adapter -
HPE StoreFabric CN1100R Dual Port Converged Network Adapter
QW990A
HPE StoreFabric CN1100R 10GBASE-T Dual Port Converged Network Adapter
N3U52A
HPE StoreFabric CN1200E 10Gb Converged Network Adapter
E7Y06A
HPE StoreFabric CN1200E 10GBASE-T Dual Port Converged Network Adapter
N3U51A
HPE Rack Options
Rail Kits -
HPE 1U Short Friction Rail Kit
775612-B21
NOTE: For additional details, please see HPE Smart Array Gen10 Controllers Data Sheet at:
https://www.hpe.com/h20195/v2/Getdocument.aspx?docname=a00017196ENW
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Additional Options
Page 28
HPE Racks
for information on these products and their
for information on these products and their
for information on these products and
for information on these products and
HPE USB and SD Options
HPE Enterprise Mainstream Flash Media Kits for Memory Cards -
HPE 8GB microSD Flash USB Drive
737953-B21
HPE 8GB Dual microSD Flash USB Drive
741279-B21
HPE Support Services
Installation & Start-up Services
HPE Installation ML/DL Series 10 Service
U7WZ5E
HPE Startup ML/DL Series 10 Service
U7WZ7E
Proactive Care
HPE 3 Year Foundation Care Next Business Day DL20 Gen10 Service
HC5N8E
HPE 3 Year Foundation Care Next Business Day with DMR DL20 Gen10 Service
HC5N9E
HPE 3 Year Foundation Care 24x7 DL20 Gen10 Service
HC5P9E
HPE 3 Year Foundation Care 24x7 with DMR DL20 Gen10 Service
HC5Q0E
HPE 3 Year Proactive Care 24x7 DL20 Gen10 Service
HC5Q2E
HPE 3 Year Proactive Care 24x7 with DMR DL20 Gen10 Service
HC5Q3E
HPE 3 Year Foundation Care Next Business Day with CDMR DL20 Gen10 Service
HC5P0E
HPE 3 Year Foundation Care 24x7 with CDMR DL20 Gen10 Service
HC5Q1E
HPE 3 Year Proactive Care 24x7 with CDMR DL20 Gen10 Service
HC5Q4E
NOTE: For a full listing of support services available for this server, please visit https://ssc.hpe.com/
Please see the HPE Advanced Series Racks QuickSpecs for information on additional racks options and rack specifications.
Please see the HPE Enterprise Series Racks QuickSpecs for information on additional racks options and rack specifications.
Please see the HPE Standard Series Racks QuickSpecs for information on additional racks options and rack specifications.
HPE Power Distribution Units (PDUs)
Please see the HPE Basic Power Distribution Units (PDU) QuickSpecs for information on these products and their specifications.
Please see the HPE Metered Power Distribution Units (PDU) QuickSpecs
specifications.
Please see the HPE Intelligent Power Distribution Unit (PDU) QuickSpecs
specifications.
Please see the HPE Metered and Switched Power Distribution Units (PDU) QuickSpecs
their specifications.
HPE Uninterruptible Power Systems (UPS)
To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web page.
Please see the HPE DirectFlow Three Phase Uninterruptible Power System QuickSpecs
their specifications.
Please see the HPE Line Interactive Single Phase UPS QuickSpecs for information on these products and their specifications.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Memory
Page 29
HPE Standard Memory UDIMMs has passed the rigorous Hewlett Packard Enterprise qualification and testing processes.
DDR4 UDIMMs operating at
Intel Gen10 Supported Memory Bandwidth for HPE ProLiant Gen10 Intel® Xeon® E Series Processor Family
[DIMM Type]
Unbuffered with ECC DIMMs (UDIMMs)
HPE SKU P/N
879505-B21
879507-B21
DIMM Rank
Single Rank
Dual Rank
DIMM Capacity
8GB
16GB
Voltage
Std Voltage 1.2V
Std Voltage 1.2V
DIMM Native Speed (MT/S)
2666
2666
Slots That Can Be Populated
4 slot servers
4
4
Maximum Capacity (Gb)
32
64
Populated Dimm Speed (MT/S)
1 DIMM Per Channel
2666
2666
2 DIMM Per Channel
2666
2666
3 DIMM Per Channel
n/a
DIMM slot and configuration diagram
CPU 1
Slot #
Population order
Chnl 2
1
B
2
D
Chnl 1
3
A
4
C
Memory Speed by Processor Model
Processor Models
Supported Memory Speeds
E-2124, E-2134, E-2126G, E-2144G, E-2136, E-2174G, E-2186G,
2666MT/s
i3-8300, G5400
2400MT/s
The memory subsystem in this server supports UDIMMs. The server supports single-rank and dual-rank
up to 2666 MHz DIMM speeds.
Memory Population guidelines
The server supports two channels per processor with two DIMMs per channel for a total of four DIMMs per DL20 Gen10 Server.
General Memory Population Rules and Guidelines:
Only UDIMMs are supported on DL20 Gen10. No support for RDIMMs and LRDIMMs.
All the channels in a system run at the fastest common frequency.
Both single DIMM per channel and dual DIMMs per channel are supported at 2666MHz.
n/a
UDIMM maximum configuration (1 CPU model)
Population order; start with "A" first, "B" second, "C" third, etc.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Memory
Page 30
Standard and Maximum Memory Capacity (Pre-configured Models)
Pre Configured
Models
Maximum Memory Plus
Optional Memory
Standard Memory Replaced
with Optional Memory
P06476-B21
8GB (1x8GB)
56GB (3x16GB, 1x8GB)
64GB (4x16GB)
P08335-B21
8GB (1x8GB)
56GB (3x16GB, 1x8GB)
64GB (4x16GB)
P06477-B21
16GB (1x16GB)
64GB (3x16GB, 1x16GB)
64GB (4x16GB)
P06478-B21
16GB (1x16GB)
64GB (3x16GB, 1x16GB)
64GB (4x16GB)
P06479-B21
16GB (1x16GB)
64GB (3x16GB, 1x16GB)
64GB (4x16GB)
Standard Memory
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Storage
Page 31
4 SFF device bay numbering
4 SFF + 2SFF device bay numbering
2LFF Hot Plug device bay numbering
2LFF Non Hot Plug device bay numbering
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Technical
Specifications
Page 32
System Unit
Dimensions
4.32 x 43.46 x 38.22 cm
1.70 x 17.11 x 15.05 in
SFF Drives
4.32 x 43.46 x 38.22 cm
LFF Drives
Weight (approximate)
7.88 kg
17.37 lb
Non hot Plug 2 LFF fully loaded (all hard drives, power supplies, and
processors installed)
7.9 kg
17.41 lb
Hot Plug 2LFF fully loaded (one hard drive, power supply, and processor
installed)
Hot Plug 4SFF fully loaded (two hard drives, power supply, and processor
installed)
290W Non-hot Plug Power Supply
Input Requirements
Rated Line Voltage
100 to 120 VAC
200 to 240 VAC
Rated Input Current
5.5 A max (at 100 VAC)
Rated Input Frequency
50 to 60 Hz
Rated Input Power
550 W (at 100 VAC)
BTU Rating
Maximum
1130 BTU per hr (at 115 VAC)
1126 BTU per hr (at 230 VAC)
Power Specifications
To review typical system power ratings use the Power Advisor which is available via the online tool located
Power Supply Output
Rated Steady-State Power
290 W Max
Maximum Peak Power
366 W within 10 seconds
500W/800W Redundant Power Supply
Input Requirements
(per power supply)
Rated Line Voltage
100 to 120 VAC
200 to 240 VAC
BTU Rating
Maximum
For 800W Power Supply: 3207 BTU/hr (at 100 VAC), 3071 BTU/hr (at 200
VAC), 3112 BTU/hr (at 240 VDC) for China Only
For 500W Power Supply: 1979 BTU/hr (at 100 VAC), 1911 BTU/hr (at 200
VAC), 1965 BTU/hr (at 240 VDC) for China Only
Power Supply Output
Rated Steady-State Power
For 800W Power Supply: 800W (at 100 VAC), 800W (at 240 VAC), 800W
(at 240 VDC) input for China only
For 500W Power Supply: 500W (at 100 VAC), 500W (at 240 VAC), 500W
(at 240 VDC) input for China only
Maximum Peak Power
For 800W Power Supply: 800W (at 100 VAC), 800W (at 240 VAC), 800W
(at 240 VDC) input for China only
For 500W Power Supply: 500W (at 100 VAC), 500W (at 240 VAC), 500W
(at 240 VDC) input for China only
For 800W Power Supply: 800W (at 100 VAC), 800W (at 240 VAC), 800W
(at 240 VDC) input for China only
(Height x Width x
Depth)
1.70 x 17.11 x 15.05 in
(per power supply)
(per power supply)
at: http://www.hpe.com/info/hppoweradvisor -Click on the system of interest. Example: DL20 Gen10 Follow the instructions of the next screens.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Technical Specifications
Page 33
System Inlet
Standard Operating Support
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per
every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of
3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change
/hr). The upper limit and rate of change may be limited by
System performance during standard operating support may be reduced if
operating above 30°C (86°F).
Extended Ambient
For approved hardware configurations, the supported system inlet range is
to be: 5° to 10°C (41° to 50°F) and 35° to 40°C (95° to 104°F) at sea level
with an altitude derating of 1.0°C per every 175 m (1.8°F per every 574 ft)
m (10,000 ft). The approved
For approved hardware configurations, the supported system inlet range is
40° to 45°C (104° to 113°F) at sea level with an altitude derating of
1.0°C per every 125 m (1.8°F per every 410 ft) above 900 m (2953 ft) to a
maximum of 3050 m (10,000 ft). The approved hardware configurations for
System performance may be reduced if operating in the ambient operating
range.
Non-operating
-30°C to 60°C (-22°F to 140°F) Maximum rate of change is 20°C/hr
(36°F/hr).
Relative Humidity
Operating
8% to 90% - Relative humidity (Rh), 28°C maximum wet bulb temperature,
non-condensing.
Non-operating
5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb
temperature, non-condensing.
Altitude
Operating
3050 m (10,000 ft). This value may be limited by the type and number of
options installed. Maximum allowable altitude change rate is 457 m/min
(1500 ft/min).
Non-operating
9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min
(1500 ft/min).
Acoustic Noise
Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position
Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment.
asured in accordance with ISO 7779 (ECMA 74) and declared in accordance with
ISO 9296 (ECMA 109). The listed sound levels apply to standard shipping configurations. Additional
e provide information
from the HPE EMESC website for further technical details regarding the configurations listed below.
Configuration
SKU
P06476-B21
P08335-B21
P06477-B21
P06478-B21
P06479-B21
Idle
LWAd
3.8 B
3.8 B
3.7 B
3.8 B
3.8 B
LpAm
21 dBA
20 dBA
21 dBA
20 dBA
20 dBA
Operating
LWAd
4.3 B
4.5 B
4.5 B
4.6 B
4.4 B
LpAm
26 dBA
28 dBA
28 dBA
28 dBA
27 dBA
Temperature
is 20°C/hr (36°F
the type and number of options installed.
Operating Support
above 900 m (2953 ft) to a maximum of 3050
hardware configurations for this system are listed at the URL:
http://www.hpe.com/servers/ashrae
to be:
this system are listed at the URL:
http://www.hpe.com/servers/ashrae
(non-condensing)
ANoise emissions were me
options may result in increased sound levels. Please have your HPE representativ
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Technical Specifications
Page 34
NOTE: Acoustics levels presented here are generated by the test configuration only. Acoustics levels will vary depending on
system configuration. Values are subject to change without notification and are for reference only.
Emissions Classification (EMC)
Power,
QuickSpecs
Environment-friendly Products and Approach - End-of-life Management and Recycling
, in many geographic areas, for our
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by
These instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM
customers who integrate and re-sell Hewlett Packard Enterprise equipment.
To view the regulatory information for your product, view the Safety and Compliance Information for Server, Storage,
Networking, and Rack Products, available at the Hewlett Packard Enterprise Support Center:
http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts
For information on the HPE Smart Array Controller please refer to their
Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling programs
products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.
treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site.
.
QuickSpecs
HPE ProLiant DL20 Gen10 Server
Summary of Changes
Page 35
Date
Version History
Action
Description of Change
05-Aug-2019
Version 4
Changed
Configuration Information - Factory Integrated Models section was modified.
Obs
The U.S. version of QuickSpecs is no longer being updated, please reference
the Worldwide QuickSpecs for latest information.
02-Apr-2019
Version 3
Changed
Core Option section was updated
04-Feb-2019
Version 2
Changed
Optional Features section was updated.
05-Nov-2018
Version 1
New
New QuickSpecs.
Sign up for updates
© Copyright 2019 Hewlett Packard Enterprise Development LP. The information contained herein is subject
to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set
forth in the express warranty statements accompanying such pr
be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for
technical or editorial errors or omissions contained herein. Intel® and Xeon® are registered trademarks of In
Corporation in the U.S. and other countries.
Microsoft®, Windows®, and Windows Server® are U.S. registered trademarks of the Microsoft group of
companies. For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less
a00053820enw - 16302 - Worldwide - V4 - 05-August-2019
oletes SKUs were removed.
oducts and services. Nothing herein should
tel
Loading...
