QuickSpecs
HPE D3000 Enclosures
Overview
Page 1
HPE D3000 Enclosures
Manage your small and midrange business growing storage needs by deploying the next generation 12Gb SAS low cost, flexible
ental locations as well
HPE H222 and the H241 Host Bus Adapters are also supported with the D3600/D3700 Enclosures. With the H241 HBA and the
What's New
• Introducing D3610/D3710 + Hard Disk Drive bundles
- HPE D3710 2TB 12G 7.2K SAS SC 50TB Bundle
Models
HPE D3000 Enclosures
Disk Enclosures for HPE Gen10 ProLiant Servers
HPE D3610 Enclosure
Q1J09A
HPE D3710 Enclosure
Q1J10A
NOTE: For external expansion behind HPE Gen10 ProLiant servers and
BladeSystems the D3610 (LFF) and the D3710 (SFF) are the enclosures.
HPE D3000 Enclosures
Supported with HPE Gen8 and Gen9 ProLiant Servers and BladeSystems
HPE D3600 Enclosure
QW968A
HPE D3700 Enclosure
QW967A
tiered external storage system. Ideal for small application environments in SMBs, remote offices and departm
as tier 2 or 3 storage for enterprise customers. The 12Gb SAS enclosures - Large Form Factor (LFF) D3600 with 12 drive bays
and Small Form Factor (SFF) D3700 with 25 drive bays - offer modular solutions to simplify capacity expansion of HPE Gen8 and
Gen9 ProLiant server environments to external storage without having to make the full move to SAN or NAS. The Gen10 ProLiant
server environments will be supported with the Large Form Factor D3610 and the Small Form Factor D3710 enclosures. The
D3610 and the D3710 are aligned with the Gen10 ProLiant branding and industrial design.
This allows you to buy what is needed today and purchase additional capacity as data storage needs grow. With the addition of
HPE StoreVirtual VSA you can use the power of virtualization to create a virtual array within your host server with the D3000. A 3year limited license for HPE StoreVirtual VSA software with 1TB of capacity included at no extra cost.
The D3000 enclosures support direct attach storage to ProLiant Servers with the HPE Smart Array P421, P431, P441, P822 or
the P841 Controllers. Blade 6Gb SAS connectivity is enabled using a HPE Smart Array P721m, P731m or the P741m Controllers,
6Gb SAS BL Switches and the D3000 enclosures. Gen10 branded supported controllers are the HPE Smart Array E208e-p SR
Gen10 Controller and the HPE Smart Array P408e-p SR Gen10 Controller.
P741m (in HBA mode) deployment of software defined storage such as Microsoft Storage Spaces can be enabled with Gen9
servers. See the
Windows Server Catalog for the latest supported configurations. The HPE D3000 Enclosures support HPE
SmartDrive Carrier (Gen8 HPE ProLiant drives). Total support can grow as needed to up to 96 LFF drives or 200 SFF drives.
- HPE D3610 4TB 12G SAS MDL SC 48TB Bundle
- HPE D3610 6TB 12G SAS MDL SC 72TB Bundle
- HPE D3610 8TB 12G SAS MDL SC 96TB Bundle
- HPE D3610 10TB 12G SAS MDL SC 120TB Bundle
- HPE D3710 600GB 12G 10K SAS SC 15TB Bundle
- HPE D3710 1.2TB 12G 10K SAS SC 30TB Bundle
- HPE D3710 1.8TB 12G 10K SAS SC 45TB Bundle
- HPE D3710 1TB 12G 7.2K SAS SC 25TB Bundle
QuickSpecs
HPE D3000 Enclosures
Overview
Page 2
Smart Buys
Smart Buys are pre-discounted SKU’s available in participating North and South
American countries. Please check with your local authorized partner for availability.
HPE D3600 Enclosure/S-Buy
QW968SB
HPE D3700 Enclosure/S-Buy
QW967SB
HPE D3600 Enclosure +
D3610 Bundles (For use with Gen10 ProLiant servers)
HPE D3610 w/12 4TB 12G SAS 7.2K LFF (3.5in) Midline Smart Carrier HDD 48TB
Bundle
Q1J11A
HPE D3610 w/12 6TB 12G SAS 7.2K LFF (3.5in) Midline Smart Carrier HDD 72TB
Bundle
Q1J12A
HPE D3610 w/12 8TB 12G SAS 7.2K LFF (3.5in) Midline Smart Carrier HDD 96TB
Bundle
Q1J13A
HPE D3610 w/12 10TB 12G SAS 7.2K LFF (3.5in) Midline Smart Carrier HDD
120TB Bundle
Q1J14A
HPE D3700 Enclosure +
D3710 Bundles (for use with Gen10 ProLiant servers)
HPE D3710 w/25 600GB 12G SAS 10K SFF (2.5in) Enterprise Smart Carrier HDD
15TB Bundle
Q1J15A
HPE D3710 w/25 1.2TB 12G SAS 10K SFF (2.5in) Enterprise Smart Carrier HDD
30TB Bundle
Q1J17A
HPE D3710 w/25 1.8TB 12G SAS 10K SFF (2.5in) Enterprise Smart Carrier HDD
45TB Bundle
Q1J18A
HPE D3710 w/25 1TB 6G SAS 7.2K SFF (2.5in) Midline Smart Carrier HDD 25TB
Bundle
Q1J19A
HPE D3710 w/25 2TB 6G SAS 7.2K SFF (2.5in) Midline Smart Carrier HDD 50TB
Bundle
Q1J20A
HPE D3000 Enclosure (SFF)
Hard Drive Bundles
Hard Drive Bundles
QuickSpecs
HPE D3000 Enclosures
Overview
Page 3
HPE D3000 Enclosure (LFF)
HPE D3000 Enclosure (Large and Small Form factor Features)
1.
Disk drive in bay 1
2.
System health LED
3.
UID push button and LED
HPE D3000 Enclosure (Large and Small Form factor Features)
same layout
1. Metal cover with fan module ID
NOTE: A pull tab is provided for label placement.
6. Rear UID push button
2.
Fan
7.
Rear system health ID
3. I/O Module A
8. Power Supply
4.
I/O Module B
9.
Power Supply
5.
Fan
Rear Panel components
NOTE: The I/O modules for both the HPE D3600/D3610 LFF and HPE D3700/D3710 SFF enclosures share the
QuickSpecs
HPE D3000 Enclosures
At a Glance
Page 4
Affordable, low cost
• Purchase only what you need today and avoid up-front costs. Modular platform provides
(SSD). Number of Solid State drives is limited to twenty five (25) SSDs per controller.
Flexible/Scalable
•
Flexibility to
Manage
• Support for HPE SmartDrive Carrier (HPE ProLiant drives)
• Easy removal of parts provides better serviceability.
High performance 6Gb
• 12Gb SAS host connectivity enables a higher data transfer rate.
that caches the most frequently accessed data ("hot" data) onto lower latency SSDs to
Storage
investment protection and by purchasing only what is needed today, allows for growth as
storage requirements evolve. Buying storage only when needed simplifies planning and
relieves budget pressures.
• HPE D3700/D3710: Maximum storage capacity of 60 TB SAS (2.4 TB SAS), 50 TB SAS MDL
(2TB SAS MDL) or SATA (2TB SATA MDL) per enclosure scalable to 360TB SAS, 400 TB
SAS MDL or SATA (dependent on the Smart Array Controller).
• HPE D3600/D3610: Maximum storage capacity of 7.2 TB SAS (600GB SAS) or 120 TB SAS
MDL or SATA MDL (10TB SAS or SATA HDD) per enclosure scalable to 57.6 TB SAS, or 960
TB SAS MDL or SATA MDL.
• Enterprise-class dual port SAS or archival-class SATA drives as the need and budget dictates
• All D3000 enclosure (LFF and SFF) models also support SAS and SATA Solid State Drives
Grow storage capacity easily by attaching up to eight D3600/D3610 or D3700/D3710
enclosures from a single Controller port, for expansion of up to 8 enclosures or 96 drives with
the D3600/D3610 or 200 drives with the D3700/D3710, allowing for room to grow as storage
demands increase behind a single controller/SAS HBA.
• Smart Array Controllers P431, P441, P822 or P841 support the mixing of the D3600 and the
D3700 for expansion, Supports four (4) D3600 and four (4) D3700 (4xLFF and 4xSFF)
allowing for expansion up to 148 drives. (Total of 8 enclosures in any combination).
mix and match SAS and SATA drives in the same enclosure.
• The D3610 and D3710 support the Gen10 E208e-p and the P408e-p controllers
• Software defined storage services such as HPE VSA (license required) and Microsoft Storage
Spaces can be enabled.
- A 3-year limited license for HPE StoreVirtual VSA software with 1TB of capacity is
included at no extra cost. To download the VSA Software see:
https://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do?productNumber=V
SA1TB-9
- Microsoft Storage Spaces can be enabled with the H241 HBA, or the HPE P741m Smart
Array Controller (in the HBA mode) and Gen9 servers See the Windows Server Catalog
for the latest supported configurations
• Hassle free expansion - little IT expertise required.
• D3600/D3700 compatible with Gen8/Gen9 HPE Smart Array SAS controllers (P431, P441,
P822, P841, P731m and P741m).
• D3610/D3710 compatible with the Gen10 HPE Smart Array SR controllers (E208e-p, and
the P408e-p controllers.
• The D3600/D3700 are also compatible with HPE H222 and the H241 Host Bus Adapters
(HBAs) Familiar ProLiant management tools provided via the Smart Controller - SIM, ACU,
ORCA.
SAS host connectivity
• End-to-end 12Gb SAS connectivity ensures a high performance storage solution using a
Gen8/Gen9 P431, P441, P822, P841, P731m or the P741m Smart Array controller and the
D3600/D3700 enclosures. D3600/D3700 enclosure are also supported with the HPE H222
and the H241 Host Bus adapters (HBA).
• D3610/D3710 support Gen10 controllers only– E208e, E408e-m
• HPE Smart Cache feature is a controller-based read caching solution in a DAS environment
QuickSpecs
HPE D3000 Enclosures
A
t a Glance
Page 5
dynamically accelerate application workloads.
large distances.
HPE Reliability
• Deploy with confidence. Hewlett Packard Enterprise offers a complete end-to-end storage
P822,
spanned disk (JBOD) environments.
• HPE SSD Smart Path feature included in the Smart Array software stack improves SSD read
for all RAID levels and RAID 0 write operations by optimizing the path to each SSD attached
to the controller.
• HPE Secure Encryption, available as an option, is a Smart Array controller-based data
encryption solution for ProLiant Gen9 servers that protects sensitive, mission critical data is
supported as an option.
• SAS disk enclosure support for c-Class BladeSystem utilizing the HPE 6Gb SAS BL Switch
with the P731m or the P741m Smart Array Controllers.
• Since storage is contained within the rack, latency is reduced as data does not travel over
solution including the D3600 and D3700 storage enclosures, Smart Array P431, P441,
P841, P731m or the P741m Controllers and HPE ProLiant Servers.
• Hewlett Packard Enterprise also offers a complete end-to-end storage solution including the
D3610/D3710 storage enclosures, Smart Array E208e-p and the P408e-p and Hen10 HPE
ProLiant servers.
• Familiar Smart Array technology of the P431, P441, P822, P841, P731m, P741m, E208e-p
or the P408e-p Controllers enable support for RAID levels 0, 1, 1+0, 5 and RAID 6 with ADG,
50 and 60. Optional battery-backed write cache.
• Advanced Data Guarding (RAID 6): This is the highest level of fault tolerance. It allocates two
sets of parity data across drives and allows simultaneous write operations. This level of fault
tolerance can withstand two simultaneous drive failures without downtime or data loss.
• Distributed Data Guarding (RAID 5): This allocates parity data across multiple drives and
allows simultaneous write operations.
• Receive pre-failure alerts with HPE SIM. When drives installed in D3000 disk enclosures are
used in conjunction with the P431, P441, P822, P841, P731m, P741m, E208e-p or the
P408e-p Smart Array Controller and Systems Insight Manager, the Smart Array firmware in
HPE hard drives enables extensive fault prediction capabilities. If potential problems develop
in one of the drives, the Smart Array Controller, Systems Insight Manager and/or Smart hard
disk drive lets you know in advance so you can have the drive replaced, before it fails, under
warranty.
• Remove / replace/ add components when system is running without service disruption with
hot Plug drives, power and cooling.
• Redundant power and cooling provides increased reliability as failure of a power supply or
fans does not interrupt system functioning.
• Dual domain SAS creates redundant pathways from servers to storage devices. The
redundant paths created by these configurations reduce or eliminate single points of failure
within the storage network. This provides increased levels of high availability with redundant
paths from the controller to the drives. Dual domain SAS implementations make it possible to
tolerate host bus adapter (HBA) failure, external cable failure, expander failure, failure in a
QuickSpecs
HPE D3000 Enclosures
HPE D3000 Enclosure Components
Page 6
HPE D3000 Enclosures
The HPE D3000 Enclosures (hereafter referred to as "D3000") is a family of disk drive storage
enclosure with 12Gb SAS host connectivity. The D3000 is a 2U direct attach, external storage solution
workloads such as reference data, archival, and disk-to-disk backup.
High Levels of Storage
Density, Data Protection,
• Storage Capacity - The SFF Gen8/Gen9 D3700 and the Gen10 D3710 enclosures support
SAS MDL or SATA MDL drives. D3700 also supports 12G
GB SAS drives or
ed for a high level of data protection. It includes redundant
without downtime or data loss.
Low Total Cost of
The modular, scalable design of the D3000 disk enclosure family provides an extremely flexible
easily added as your needs dictate.
• Cascading - The D3700, D3710, D3600 and the D3610 have the unique capability of
The D3000 family utilizes the standard,
expertise necessary to install and maintain HPE server storage.
D3000 Disk Enclosures
HPE D3600/D3610 (LFF)
The 2U array houses up to twelve (12) 3.5 inch HPE SmartDrive Carrier
• D3600/D3610 base enclosure with redundant power supplies
and Functionality
designed for small to medium size deployments or remote locations. These enclosures deliver industryleading availability, storage density, and upgradeability to meet customers' demanding and growing
storage needs. The D3000 delivers the ideal mix of low-cost and high capacity, for minimum I/O
up to 25 (twenty five) 12G SFF SAS drives for a maximum capacity of 60 TB with 12G 2.4 TB
SAS drives or 50 TB with 2 TB 12G
SAS and 6G SATA Solid State Drives. Number of Solid State drives is limited to twenty five
(25) per controller.
• The LFF Gen8/Gen9 D3600 and the Gen10 D3610 disk enclosures support up to 12
(twelve) 12 LFF SAS drives for a maximum capacity of 7.2 TB with 12G 600
120 TB with 12G 10 TB SAS MDL or 6G 10 TB SATA MDL drives.
• Data Protection - D3000 is design
fans and power supplies (standard), and supports various RAID levels including RAID6 with
ADG, 50 & 60 (depending upon the Smart Array Controller used).
• Storage Manageability - The D3000 features familiar configuration and management tools
such as Array Configuration Utility (ACU) and HPE Systems Insight Manager (SIM). Online
Management Features include: Online Capacity Expansion, Online RAID Level Migration,
Online Stripe Size Migration, Online Spares (Global).
• Choice of Computing Platform - The D3000 is designed and qualified for HPE ProLiant
servers.
• Advanced Data Guarding (RAID 6 with ADG).
• Fault Tolerance - It allocates two sets of parity data across drives and allows simultaneous
write operations. This level of fault tolerance can withstand two simultaneous drive failures
Ownership
platform. You can buy what you need today and purchase additional capacity as your data storage
needs grow, instead of making a large up-front investment. Additional drives and enclosures can be
cascading up to eight (8) enclosures behind a single SAS port (depends on the Smart Array
Controller).
• Pre-Failure Warranty - Drives installed in either the D3600, D3610, D3700 or the D3710
and monitored under HPE Systems Insight Manager are supported by a Pre-Failure
(replacement) Warranty (3 years for SAS drives). Pre-Failure Warranty allows for the
replacement of designated drives in the D3600 or the D3700 before they actually fail when
using HPE Systems Insight Manager on HPE ProLiant servers.
NOTE: Some operating systems may not support all of these features.
• Integrated Configuration and Management Tools -
integrated set of Smart Array management and utility software for HPE ProLiant Servers.
These tools consistently lower the cost of ownership by reducing training and technical
Disk Enclosures
(Gen8 HPE ProLiant) hot pluggable SAS and SATA drives.
Each D3600/D3610 includes the following standard components:
QuickSpecs
HPE D3000 Enclosures
HPE D3000 Enclosure Components
Page 7
and fan modules
HPE D3700/D3710 (SFF)
The 2U array houses up to twenty five (25) 2.5 inch HPE SmartDrive
HPE Smart Array P431
• The SA-P431 Controller supports up to 200 physical drives
http://h18000.www1.hp.com/products/QuickSpecs/14625_div/14625_div.pdf
HPE Smart Array P441
• The SA-P441 Controller supports up to 200 physical drives
caching with indefinite write cache data retention in the case of unexpected power outage
• Two (2) integrated 12Gb SAS IO Modules
• Rack mounting hardware kit
• Two (2) 0.5m HD Mini-SAS cables
• Two (2) PDU interconnect cords
Disk Enclosures
Features
• The SA-P431 Controller supports the HPE D3600 and the HPE D3700 Disk Enclosure (up to
8 daisy chained). Seamless upgrades to current or next generation HPE high performance
and high capacity Serial Attached SCSI Smart Array controllers.
• 12 Gb/s SAS technology delivers high performance and data bandwidth and contains full
compatibility with 6 Gb/s SATA technology
• PCI Express Gen3 x8 link width delivers high performance and data bandwidth up to 8GT/s
theoretical maximum bandwidth
• 2 GiBytes Flash Backed Write Cache (FBWC) provides read ahead caching and write back
caching with indefinite write cache data retention in the case of unexpected power outage
• Standard on the P431 are RAID 6, RAID 60, RAID 1 ADM, Capacity Expansion, mirror split,
recombine and rollback in Online Mode, Drive Erase, Performance Optimization-Degraded
Reads and Read Coalescing, Move/Delete any individual LUNs
• The HPE SSD Smart Path feature included in the Smart Array software stack improves SSD
reads for all RAID levels and RAID 0 write operations by optimizing the path to each SSD
attached to the controller
• The HPE SmartCache feature (HPE Smart Cache license is required on P431) is a controller-
based read caching solution in a DAS environment that caches the most frequently accessed
data ("hot" data) onto lower latency SSDs to dynamically accelerate application workloads
• Mix-and-match SAS and SATA hard drives lets you deploy drive technology as needed to fit
your computing environment
• For more information see:
Carrier (Gen8 HPE ProLiant) hot pluggable SAS, SATA and Solid State
drives.
Each D3700/D3710 includes the following standard components:
• D3700/D3710 base enclosure with redundant power supplies
and fan modules
• Two (2) integrated 12Gb SAS IO Modules
• Rack mounting hardware kit
• Two (2) 0.5m HD Mini-SAS cables
• Two (2) PDU interconnect cords
Features
• The SA-P441 Controller supports the MSA2040 (Shared storage), HPE D3600 Disk
Enclosure and HPE D3700 Disk Enclosure (up to 8 daisy chained in dual domain
configuration). Seamles upgrades to current or next generation HPE high performance and
high capacity Serial Attached SCSI Smart Array controllers.
• 12Gb/s SAS technology delivers high performance and data bandwidth and contains full
compatibility with 6Gb/s SATA technology
• PCI Express Gen3 x8 link width delivers high performance and data bandwidth up to 8GT/s
theoretical maximum bandwidth
• 4 GiBytes Flash Backed Write Cache kit (FBWC) provides read ahead caching and write back
QuickSpecs
HPE D3000 Enclosures
HPE D3000 Enclosure Components
Page 8
• Supports legacy and UEFI boot operation on Gen9 servers
• For more information see: HPE Smart Array P441 Controller (QuickSpecs/c04346300.pdf)
HPE Smart Array P822
• Second Generation 6Gb/s SAS Controllers
http://h18000.www1.hp.com/products/QuickSpecs/14341_div/14341_div.html
HPE Smart Array P841
• The SA-P841 Controller supports up to 200 physical drives
• HBA mode
• Standard on the P441 are RAID 6, RAID 60, RAID 1 ADM, Capacity Expansion, mirror split,
recombine, and rollback in Online Mode, Drive Erase, Performance Optimization-Degraded
Reads and Read Coalescing, Move/Delete any individual LUNS
• The HPE SSD Smart Path feature included in the Smart Array software stack improves SSD
reads for all RAID levels and RAID 0 write operations by optimizing the path to each SSD
attached to the controller
• The HPE SmartCache feature (HPE Smart Cache license is required on P441) is a controller-
based read and write caching solution in a DAS environment that caches the most frequently
accessed data ("hot" data) onto lower latency SSDs to dynamically accelerate application
workloads
• HPE Secure Encryption is a Smart Array controller-based data encryption solution for
ProLiant Gen9 servers that protects sensitive, mission critical data.
• Mix-and-match SAS and SATA hard drives lets you deploy drive technology as needed to fit
your computing environment
• Software consistency on most current shipping Smart Array products: HPE Smart Storage
Administrator (HPE SSA), HPE Systems Insight Manager, and HPE Intelligent Provisioning.
The HPE Smart Storage Administrator configures and manages a host of Smart Array
controllers and other storage devices using a single interface. It replaces the HPE Array
Configuration Utility (ACU) with an updated design and configuration enhancements
• Low-profile PCI Express form factor - ships with a full size (attached) and a low profile bracket
for deployment flexibility based on slot availability
• Rapid rebuild
• HBA or RAID mode
• Power efficiency
Features
Features
• The SA-P822 Controller supports up to 200 drives
• PCIe 3.0 with DDR3-1333 cache.
• Write-back caching (with FBWC)
• For more information:
• PCI Express Gen3 x8 link width delivers high performance and data bandwidth up to 8GT/s
theoretical maximum bandwidth
• 4 GiBytes Flash Backed Write Cache kit (FBWC) provides read ahead caching and write back
caching with indefinite write cache data retention in the case of unexpected power outage
• Supports legacy and UEFI boot operation on Gen9 servers
• Standard on the P841 are RAID 6, RAID 60, RAID 1 ADM, Capacity Expansion, mirror split,
recombine, and rollback in Online Mode, Drive Erase, Performance Optimization-Degraded
Reads and Read Coalescing, Move/Delete any individual LUNS
• The HPE SSD Smart Path feature included in the Smart Array software stack improves SSD
reads for all RAID levels and RAID 0 write operations by optimizing the path to each SSD
attached to the controller
• The HPE SmartCache feature (HPE Smart Cache license is not required on P841) is a
controller-based read and write caching solution in a DAS environment that caches the most
frequently accessed data ("hot" data) onto lower latency SSDs to dynamically accelerate
application workloads
• Optional HPE Secure Encryption is a Smart Array controller-based data encryption solution
for ProLiant Gen9 servers that protects sensitive, mission critical data.
• PCIe form factor – Full height, half-length card
• Rapid rebuild
QuickSpecs
HPE D3000 Enclosures
HPE D3000 Enclosure Components
Page 9
• Power efficiency capabilities
controllers/productdetail.html?oid=6995463#!tab=features
HP Smart Array E208e-p
• Storage interface (SAS/SATA)
• Seamless upgrades to HPE Smart Array P-class Controllers
HP Smart Array P408e-p
• Storage interface (SAS/SATA)
•
Smart Array P741m
Feature
• Eight (8) 12Gb/s SAS physical links distributed equally across 4 external 2x ports to support
For more information see:
http://www8.hp.com/us/en/products/iss-
SR Gen10 Controller
SR Gen10 Controller
• 8 SAS lanes across 2 x4 external Mini-SAS HD ports
• 12Gb/s SAS, 6Gb/s SATA technology
• Mix-and-match SAS and SATA drives to the same controller
• Support for SAS tape drives
• PCI Express 3.0 x8 link
• RAID 0, 1, 5, 10
• Mixed Mode (RAID logic drives and HBA physical drives simultaneously)
• Legacy and UEFI boot operation
• UEFI System Utilities (storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR Secure Encryption (optional license)
• HPE SSD Smart Path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive Sanitize
• Performance Optimization-Degraded Reads and Read Coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array Software RAID
• 8 SAS lanes across 2 x4 external Mini-SAS HD ports
• 12Gb/s SAS, 6Gb/s SATA technology
• Mix-and-match SAS and SATA drives to the same controller
• Support for SAS tape drives, SAS tape autoloaders and SAS tape libraries
• 4 GB Flash-Backed Write Cache (FBWC)
• PCI Express 3.0 x8 link
• RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM (Advanced Data Mirroring)
• Mixed Mode (RAID logic drives and HBA physical drives simultaneously)
• Legacy and UEFI boot operation
• UEFI System Utilities (storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR SmartCache (optional license)
• HPE Smart Array SR Secure Encryption (optional license)
• HPE SSD Smart Path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive Sanitize
• Performance Optimization-Degraded Reads and Read Coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array S-class and E-class controllers
FIPS 140-2 Level 1 Implementation Under Test (expected validation complete in 2018)
up to four 6Gb/s SAS Switches
QuickSpecs
HPE D3000 Enclosures
HPE D3000 Enclosure Components
Page 10
• 12Gb/s SAS technology delivers up to 1200 MB/s theoretical bandwidth per physical lane
based read caching solution in a DAS environment that caches the most frequently
detail.html?oid=7797736#!tab=features
HPE H222 Host Bus
• SAS technology delivers high performance and data bandwidth up to 6 Gb/s per physical link
http://h18004.www1.hp.com/products/QuickSpecs/14337_div/14337_div.pdf
HPE H241 Host Bus
• SAS technology delivers high performance and data bandwidth up to 12Gb/s per physical link
(QuickSpecs/c04375840.pdf)
6Gb SAS BL Switch
• Hot Pluggable 6Gb/s SAS Switch for HPE c-Class BladeSystem
• 6 GB/s SATA technology delivers up to 600 MB/s theoretical bandwidth per physical lane for
directly attached SATA drives.
• RAID 0, 1, 10, 5, 50, 6, 60, 1 ADM, 10 ADM
• P741m can support HBA mode which enables deployment of Software Defined Storage such
as Microsoft Storage Spaces and VMWare VSAN
• HPE Smart Cache feature (HPE Smart Cache license is not required on P741m) is a
controlleraccessed data ("hot" data) onto lower latency SSDs to dynamically accelerate application
workloads.
• HPE SSD Smart Path feature included in the Smart Array software stack improves SSD read
for all RAID levels and RAID 0 write operations by optimizing the path to each SSD attached
to the controller
• HPE Secure Encryption, available as an option, is a Smart Array controller-based data
encryption solution for ProLiant Gen9 servers that protects sensitive, mission critical data is
supported as an option
• PCI Express Gen3 x8 link
• 4 GiBytes Flash Backed Write Cache (FBWC) provides read ahead caching and write back
caching with indefinite write cache data retention in the case of unexpected power outage.
• For more information see:
• http://www8.hp.com/us/en/products/iss-controllers/product-
Adapter
Adapter
• Mix-and-match SAS and SATA hard drives; deploy drive technology as needed
• PCIe x8 ( 8 GB/s bandwidth)
• PCIe 3.0 x8 capable
• For more information see:
• Mix-and-match SAS and SATA hard drives; deploy drive technology as needed
• PCIe 3.0 x8 ( 8GB/s bandwidth)
• Enables deployment of Software Defined Storage such as Microsoft Storage Spaces for the
D3000 enclosures with Gen9 servers
• For more information see: HPE H241 Smart Host Bus Adapter
• Sixteen internal blade bay ports containing 2x 6Gb/s SAS links
• Eight external Mini-SAS ports containing 4x 6Gb/s SAS links
• Use the embedded Virtual SAS Manager GUI or CLI interface to zone switch ports or drive
bays to server bays.
• Supported by c3000 and c7000 c-Class BladeSystem enclosures
• For more information see:
http://h18000.www1.hp.com/products/QuickSpecs/13960_div/13960_div.html
QuickSpecs
HPE D3000 Enclosures
HPE D3000 Enclosure Components
Page 11
HPE SmartDrive Carrier
HPE SmartDrive Carrier features:
• New drive mechanical design
• Drive error log NVRAM with black-box recorder, for better failure analysis and resolution
RAID
Several fault tolerant configurations keep data available and servers running while drives are being
replaced - RAID levels that offer fault tolerance include:
• RAID 50 (RAID 5+0) protects against failure of one drive (and failure of particular multiple
requires less rebuild time than single RAID 5 arrays RAID 50 requires a minimum of six drives.
data across multiple drives and allows simultaneous write operations. Drive Mirroring (RAID 1
mirrored data, providing two copies of every file.
Dual Domain
• Dual domain SAS creates redundant pathways from servers to storage devices. The
environments. Requires FW v 3.x
Common Slot Power
The D3000 Disk enclosures use the 460W Common Slot Power supply.
Plus independently tests power supply efficiency and publicly posts the results on 80Plus.org.
Utilities
The D3000 disk enclosure family utilizes a single, consistent set of utility software for storage and
server storage solution.
Configuration Utilities
Array Configuration Utility (ACU) [On-line for Microsoft and Linux,
Remote Web
Option ROM Configuration for Arrays (ORCA), NetWare ACU CPQONLIN
(only online support no Web based support)
Management/Health
HPE Systems Insight Manager
(Gen8)
• Enhanced display of self-describing icons with intuitive and improved LED function
• Hard drive status indicator
• Animated drive activity spinner
• "Do not remove" indicator reduces logical drive failures due to accidental removal of a drive
• Smart carrier authentication to verify that both drive and carrier are HPE-qualified options
drives). RAID 50 is a nested RAID method that uses RAID 0 striping across RAID 5 arrays.
RAID 50 tolerates one drive failure in each spanned array without loss of data. RAID 50
• RAID 60 (RAID 6+0) allows administrators to split the RAID 6 storage across multiple
external boxes. RAID 60 requires a minimum of eight drives. RAID 60 is a nested RAID
method that uses RAID 0 block-level striping across multiple RAID 6 arrays with dual
distributed parity. With the inclusion of dual parity, RAID 60 will tolerate the failure of two
disks in each spanned array without loss of data.
• RAID 6 with ADG: Allocates the equivalent of two parity drives across multiple drives and
allows simultaneous write operations Distributed Data Guarding (RAID 5): Allocates parity
and 1+0 Striped Mirroring): Allocates half of the drive array to data and the other half to
redundant paths created by these configurations reduce or eliminate single points of failure
within the storage network. This provides increased levels of high availability with redundant
paths from the controller to the drives. Dual domain SAS implementations make it possible to
tolerate external cable failure, expander failure, failure in a spanned disk (JBOD)
Supply
HPE's Common Slot Power supplies meet multiple Energy Efficiency Initiatives:
• 460W, 92%: Climate Savers Computing Initiative GOLD and ECOS Consulting 80PLUS GOLD
NOTE: The 80 PLUS program is a unique forum that unites electric utilities, the computer industry,
and consumers in an effort to bring energy efficient technology solutions to the marketplace. 80
RAID management, setup, configuration and troubleshooting. This consistency reduces the cost of
ownership by reducing the training and technical expertise necessary to install and maintain your HPE
-Based & Off-line]
QuickSpecs
HPE D3000 Enclosures
HPE D3000 Enclosure Components
Page 12
Utilities
Array Configuration Utility
• Provides a graphical view of HPE drive array configurations.
HPE Systems Insight
•
Insight Manager console.
Supported Operating
Gen8/Gen9 HPE ProLiant Servers
NOTE: For information on supported Operating Systems, see the following Smart Array QuickSpecs:
P441: HPE Smart Array P441 Controller (QuickSpecs/c04346300.pdf)
P822: http://h18004.www1.hp.com/products/QuickSpecs/14341_div/14341_div.html
P841: http://www8.hp.com/us/en/products/iss-controllers/product
detail.html?oid=6995463#!tab=features
H222: http://h18004.www1.hp.com/products/QuickSpecs/14337_div/14337_div.pdf
H241: HPE H241 Smart Host Bus Adapter (QuickSpecs/c04375840.pdf)
Gen10 HPE ProLiant Servers – Only supported with D3610/D3710
HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller
HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller
HPE BladeSystem Servers
NOTE: For Information on Supported Operating Systems, see the following Smart Array QuickSpecs:
P731m: http://h18000.www1.hp.com/products/QuickSpecs/14626_div/14626_div.pdf
P741m: http://www8.hp.com/us/en/products/iss-controllers/product-
detail.html?oid=7797736#!tab=features
Systems
(ACU)
Manager (SIM)
• Easy to use Wizards for configuration.
• Web Based ACU supports On-Line, Remote Web Based and
Off-line configuration.
• Supports on-line configuration for Microsoft, NetWare and
Linux.
Powerful storage, server and server option management tool.
• Monitor storage from a remote central location.
• Browser based Insight Manager 7 provides full access from
anywhere on the Intranet, eliminating the need for a dedicated
QuickSpecs
HPE D3000 Enclosures
Service and Support
Page 13
Storage Software
HPE StoreVirtual VSA:
With HPE StoreVirtual VSA you can use the power of virtualization to create a virtual array within your
B-9
For more information and positioning HPE StoreVirtual VSA see:
17_HPSD_Positioning_Microsoft_WS2012_Storage_Spaces_March_2015_Final.pptx
Microsoft Windows 2012, Storage Spaces:
Software Defined Storage implementation, included in Microsoft Windows 2012
R2 software
Microsoft Storage Spaces can be enabled with the H241 HBA, or the HPE P741m Smart Array
Controller (in the HBA mode) and Gen9 servers.
See: the Windows Server Catalog for the latest supported configurations.
Warranty
Three-year limited parts only warranty, including hardware diagnostic support, pre-failure warranty
airable parts to minimize repair time and provide
's limited warranty Statement
http://h18006.www1.hp.com/products/storageworks/warranty.html
Service and Support
Services to accelerate time to results
storage technology to work for you. We work closely with you as your strategic partner, leveraging our
support your business demands.
Discover, plan, and
Choose from a rich portfolio of services to make the most of HPE D3000 Disk Enclosures so you can
HPE Storage Efficiency Analysis - The HPE Storage Efficiency Analysis provides customers with a
host server. Manage it as a single pool of shared storage capacity, and scale it to match your evolving
needs. HPE ProLiant Gen9 servers include a 3-year limited license for HPE StoreVirtual VSA software
with 1TB of capacity at no extra cost. Simply select to install HPE StoreVirtual VSA software during
server setup within Intelligent Provisioning.
More information, instructional videos, and free console management software are available at
http://www.hp.com/go/unlock1TB
To download the Free 1TB VSA Software see:
https://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do?productNumber=VSA1T
https://pit.houston.hp.com/PIT/ESSN/Document_Storage/SalesTools/2015-03-
.
(coverage of hard drives, memory and processors). The warranty is fully supported by HPE Services
and a worldwide network of resellers and service providers. In addition 90-day's getting started
software telephone support may be covered under the warranty or available for an additional fee.
Enhancements to warranty services are available through HPE Pointnext operational services.
NOTE: The D3000 family has a limited 3 year parts only warranty. SAS and Solid State drives have
3 year warranty. SAS MDL and SATA MDL and SATA Solid State Drives have 1 year warranty.
The D3000 has been designed with customer self-rep
greater flexibility in performing defective parts replacement. Refer to HPE
and parts replacement instructions for further details.
HPE Storage Services bring you a rich portfolio of consulting and support services designed to add
value to our core storage products and solutions. We have the know-how and experience to put
full services portfolio to make sure that everything works to optimize your enterprise.
Choose from services aligned to our storage product offerings and lifecycle. From mission-critical
onsite services to innovative web-based remote support, you choose the precise level of attention and
design
efficiently and affordably consolidate, manage, and extract value from unstructured data.
HPE Services can help you discover needs and create a plan for simplifying the environment,
reducing risk, and maximizing your storage investments
QuickSpecs
HPE D3000 Enclosures
Service and Support
Page 14
view of their storage infrastructure and operating environment; highlighting recommendations for
xecutive summary presentation. The goal of this service is to help provide
https://www.hpe.com/h20195/V2/GetPDF.aspx/4AA3-4620ENW.pdf
Deploy and integrate
We can help you configure, set up, and efficiently use your HPE D3000 Enclosures as well as help
Strategic augmentation of your current environment with
Operate and support
Choose the right support to maximize uptime, free up your resources, and achieve improved
improvements. The report provides extensive insight about the existing storage environment,
opportunities for efficiency gains, asset aging and replacement through interaction with key decision
makers
https://www.hpe.com/h20195/V2/GetPDF.aspx/4AA3-6727ENW.pdf
HPE Storage Impact Analysis (SIA): The HPE Storage Impact Analysis service provides a 2-4 week
discovery engagement with e
customers guidance on storage related issues and develop remediation plans.
https://www.hpe.com/h20195/V2/GetPDF.aspx/4AA4-1174ENW.pdf
HPE Storage Modernization Service: The HPE Storage Modernization service is a 4-6 week service
that defines the customers envisioned target storage environment based on a proven solution design
methodology. Hewlett Packard Enterprise architects will quickly perform tool-assisted automatic
discovery and facilitate a two-day strategy workshop with all key stakeholders involved in the storage
infrastructure initiative
migrate data, improve capacity utilization, and establish information management standards used
across backup, replication, and archiving needs.
HPE Storage Data Migration Services - End-to-end data migration service providing seamless
discovery, assessment, planning, and design, completely customizable to your organization's storage
area network or network attached storage environment and using innovative software to help you
migrate to HPE storage quickly and efficiently.
https://www.hpe.com/h20195/V2/GetPDF.aspx/4AA3-0774ENW.pdf
HPE Storage and Data Residency Service -
HPE resources who become your trusted advisor to provide answers that are right for your storage
and backup environment. http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-9481ENW.pdf
HPE Proactive Select - A flexible way to purchase services to fit your environment with an extensive
menu of HPE Proactive Select event and technical services, such as onsite firmware upgrades, health
checks, assessments, and education.
3842ENW.pdf
https://www.hpe.com/h20195/V2/GetPDF.aspx/4AA2-
value-as you get the most out of the existing IT assets while accelerating time-to-revenue.
HPE Proactive Care 24x7 - Hardware and software support services designed specifically for your
technology with rapid access to Advanced Solution Center Specialists plus firmware and software
management and best practice advice
https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-
8855ENW.pdf
HPE Proactive Care Personalized Support - An option-if you have HPE Proactive Care- to bring
increased personalization of the Proactive Care support experience through the assignment of an
Account Service Manager (ASM) who provides IT best practice advice to help address IT issues and
projects.
HPE Support Plus 24 - Support for environments where proactive help from Hewlett Packard
Enterprise is not required, with 24x7 hardware and software support onsite that includes third-party
https://www.hpe.com/h20195/V2/GetPDF.aspx/4AA4-3446ENW.pdf
support with a maximum four-hour onsite response.
https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-6638EN.pdf
QuickSpecs
HPE D3000 Enclosures
Service and Support
Page 15
HPE Education Services - Comprehensive training for new, as well as experienced, storage
http://education.hp.com/curr-storsan.htm
Optimized Care - Delivers
Choose from three levels of operate and support care
Proactive Select credits per year
Standard Care - maintains
high level of uptime, along
with expert help to cut the
support
HPE Proactive Care 24x7-Plus, 10 credits per year
Basic Care - Minimum
HPE Support Plus 24- Plus, 10 credits per year
Additional options - 10 HPE Proactive Select credits per year
Remote
HPE Automation provides 24x7 coverage, proactive problem prevention, accurate problem diagnosis
edge capabilities to make it better.
For more information
administrators designed to expand your skills and keep you up to speed with the latest storage and
virtualization technology from HPE Storage.
the highest levels of
performance and stability
through deployment and
proactive management
practices
cost and complexity of
implementation and
recommended support
Support Automation
HPE Proactive Care 24x7-Plus, 20 credits per year
Additional options -HPE Proactive Care Personalized Support (once per Proactive Care support
new environment), an additional day of HPE Personalized Support, and 10 additional HPE
Additional options -HPE Proactive Care Personalized Support (once per Proactive Care support
new environment), an additional day of HPE Personalized Support, and 10 additional HPE
Proactive Select credits per year
and faster problem resolution, as well as interactive support portals and tools. This is an integral, and
cost-free, part of your HPE support relationship and we are continually investing in additional cutting-
http://www.hp.com/services/storage
To learn more on HPE Storage Services, please contact your Hewlett Packard Enterprise sales
representative or Hewlett Packard Enterprise Authorized Channel Partner
HPE Pointnext operational services are sold by HPE and Hewlett Packard Enterprise Authorized
Service Partners:
• Services for customers purchasing from HPE or an enterprise reseller are quoted using HPE
order configuration tools.
• Customers purchasing from a commercial reseller can find HPE Pointnext operational services
at: http://www.hp.com/go/lookuptool
QuickSpecs
HPE D3000 Enclosures
Configuration Information
Page 16
Step 1: Base Configuration
Model
Model Description
Part Number
HPE D3610 Enclosure
HPE D3610 Enclosure
Q1J09A
NOTE: Gen10 branded D3000 enclosure for use with Gen10 ProLiant servers
HPE D3610 SAS Dual
HPE D3610 w/12 4TB 12G SAS 7.2K LFF (3.5in) Midline Smart Carrier HDD 48TB
Bundle
Q1J11A
HPE D3610 w/12 6TB 12G SAS 7.2K LFF (3.5in) Midline Smart Carrier HDD 72TB
Bundle
Q1J12A
HPE D3610 w/12 8TB 12G SAS 7.2K LFF (3.5in) Midline Smart Carrier HDD 96TB
Bundle
Q1J13A
HPE D3610 w/12 10TB 12G SAS 7.2K LFF (3.5in) Midline Smart Carrier HDD
120TB Bundle
Q1J14A
HPE D3600 Enclosure
HP D3600 Enclosure
QW968A
HPE D3710 Enclosure
HPE D3710 Enclosure
Q1J10A
NOTE: Gen10 branded D3000 enclosure for use with Gen10 ProLiant servers.
HPE D3710 SAS Dual
HPE D3710 w/25 600GB 12G SAS 10K SFF (2.5in) Enterprise Smart Carrier HDD
15TB Bundle
Q1J15A
HPE D3710 w/25 1.2TB 12G SAS 10K SFF (2.5in) Enterprise Smart Carrier HDD
Q1J17A
HPE D3710 w/25 1.8TB 12G SAS 10K SFF (2.5in) Enterprise Smart Carrier HDD
45TB Bundle
Q1J18A
HPE D3710 w/25 1TB 6G SAS 7.2K SFF (2.5in) Midline Smart Carrier HDD 25TB
Bundle
Q1J19A
NOTE: HPE SKU name in some systems incorrectly indicates that these bundles are
10K drives. Both bundles are shipped with 7.2K SFF drives.
HPE D3710 w/25 2TB 6G SAS 7.2K SFF (2.5in) Midline Smart Carrier HDD 50TB
Bundle
Q1J20A
NOTE: HPE SKU name in some systems incorrectly indicates that these bundles are
10K drives. Both bundles are shipped with 7.2K SFF drives.
HPE D3700 Enclosure
HP D3700 Enclosure
QW967A
Configure to Order Program Information
The HPE D3000 models and options may or may not be factory installed in a rack with add-on controllers, and hard drives. The
D3000 enclosures may be integrated with ProLiant servers or as standalone storage.
Model
Model Description
Part Number
HPE D3610
HPE D3610 Enclosure
Q1J09A-#0D1
HPE D3710
HPE D3710 Enclosure
Q1J10A-#0D1
HPE D3600
HPE D3600 Enclosure
QW968A-#0D1
HPE D3700
HPE D3700 Enclosure
QW967A-#0D1
Port MDL drives bundles
Port Drive Bundles
30TB Bundle
QuickSpecs
HPE D3000 Enclosures
Configuration
Information
Page 17
Step 2: Array Controllers
Smart Array Controllers
Description
Part Number
Gen8/Gen9 HPE ProLiant Servers
HP Smart Array P441/4GB FBWC 12Gb 2-ports Ext SAS Controller
726825-B21
HP Smart Array P841/4GB FBWC 12Gb 4-ports Ext SAS Controller
726903-B21
Gen10 HPE ProLiant Servers – only supported with D3610/D3710 Enclosures
HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe
Plug-in Controller
804405-B21
NOTE: Firmware version 2.0 or higher required on the listed Smart Array
drives (total of 8 enclosures in any combination).
HPE Host Bus Adapters
HP H222 Host Bus Adapter
650926-B21
HP H241 12Gb 2-ports Ext Smart Host Bus Adapter
726911-B21
Gen10 HPE ProLiant Servers
HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe
Plug-in Controller
804398-B21
Smart Array Controllers
BladeSystem Servers
HP Smart Array P731m/2GB FBWC 6Gb 4-ports Ext Mezzanine SAS Controller
698535-B21
HP Smart Array P741m/4GB FBWC 12Gb 4-ports Ext Mezzanine SAS Controller
726782-B21
HP 6Gb SAS Switch Single Pack for HP BladeSystem c-Class
BK763A
HP 6Gb SAS Switch Dual Pack for HP BladeSystem c-Class
BK764A
NOTE: D3600/D3700 6Gb SAS BL Switch support requires Firmware version 1.34.
NOTE: HPE Smart Array P741m/4GB FBWC controller option kit does not include
your Gen9 server.
Step 3: Choose HPE ProLiant Servers/MSA Arrays/HPE Integrity Servers
HPE ProLiant Server
D3600/D3700 only
HPE ProLiant Servers: For up to date compatibility, see the following URL for complete Smart Array
http://h18004.www1.hp.com/products/servers/proliantstorage/arraycontrollers/index.html
Supported
(HBAs)
Controllers.
NOTE:
• Up to eight (8) D3600 can be cascaded for a total of 96 drives.
• Up to eight (8) D3700 can be cascaded for a total of 200 drives.
• Smart Array Controllers P421, P43, P44, P822 and P841 support the
mixing of the D3600 and the D3700 for expansion.
• Supports eight (8) D3600 and/or D3700 allowing for expansion up to 148
/Switches
the HPE Smart Storage Battery the backup power source necessary to protect the
Compatibility
data on the Flash-backed Write Cache. HPE Smart Storage Battery is an item that
has to be purchased separately if this is the first P-series Smart Array controller on
P431, P441, P822, P841, P721m, P741m Controller and HBA H221, H222compatibility and support
information:
QuickSpecs
HPE D3000 Enclosures
Configuration
Information
Page 18
BladeSystem Server
HPE ProLiant BL420c Gen8
http://h18000.www1.hp.com/products/QuickSpecs/division/12534.html
Step 4: Choose Hard Drives
HPE D3600/D3610 Enclosures - Large Form Factor (LFF)
15K SAS LFF (3.5in) Hard Disk Drives
HP 300GB 12G SAS 15K rpm LFF (3.5-inch) SC Converter Enterprise 3yr Warranty
Hard Drive
737261-B21
HP 450GB 12G SAS 15K rpm LFF (3.5-inch) SC Converter Enterprise 3yr Warranty
Hard Drive
737394-B21
HP 600GB 12G SAS 15K rpm LFF (3.5-inch) SC Converter Enterprise 3yr Warranty
Hard Drive
765424-B21
7.2K SAS Midline LFF (3.5in) Hard Disk Drives
HPE 10TB 12G SAS 7.2K rpm LFF (3.5-inch) SC Midline 512e 1yr Warranty Hard
Drive
857644-B21
HPE 8TB 12G SAS 7.2K rpm LFF (3.5-inch) SC Midline 512e 1yr Warranty Hard
Drive
819201-B21
HPE 8TB 12G SAS 7.2K rpm LFF (3.5-inch) SC 512e Helium 1yr Warranty Hard
861590-B21
HPE 6TB 12G SAS 7.2K rpm LFF (3.5-inch) SC 1yr Warranty Hard Drive
861754-B21
HPE 6TB 12G SAS 7.2K rpm LFF (3.5-inch) SC 1yr Warranty Hard Drive
846514-B21
HPE 6TB 12G SAS 7.2K rpm LFF (3.5-in) 3yr SC SGT Kit
808727-B21
HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware
HDD
872487-B21
HPE 4TB 12G SAS 7.2K rpm LFF (3.5-inch) SC Midline 1yr Warranty Hard Drive
818367-B21
HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware
HDD
872485-B21
HPE 2TB 12G SAS 7.2K rpm LFF (3.5-inch) SC Midline 1yr Warranty Hard Drive
818365-B21
HPE 1TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware
HDD
846524-B21
7.2K SATA LFF (3.5in) Hard Disk Drives
HPE 10TB 6G SATA 7.2K rpm LFF (3.5-inch) SC 512e 1yr Warranty Hard Drive
HPE 8TB 6G SATA 7.2K rpm LFF (3.5-inch) SC Midline 512e 3yr Warranty Hard
Drive
857370-B21
HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed
Firmware HDD
861752-B21
HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware
872491-B21
Compatibility - P731m
Controller
HPE ProLiant BL460c Gen8
HPE ProLiant BL465c Gen8
HPE ProLiant BL660cGen8
NOTE:
For BL420c Gen8 & BL460c Gen8 - P731m is a Type B mezzanine .It can only be installed on
mezzanine slot 2 which requires a second processor for functionality. The BL420c, BL465c, and
BL460c Gen8 can only support one Type B mezzanine.
For BL465 Gen8 - P731m is a Type B mezzanine and can only be installed on mezzanine slot 2
For BL660c Gen8 - P731m is a Type B mezzanine. It can only be supported on mezzanine slot 2
and mezzanine slot 3. The BL660c Gen8 can support up to two Type B mezzanines.
NOTE: For more information on internal vs external connections, please refer to proper blade
QuickSpecs visit:
Drive
HDD
857648-B21
QuickSpecs
HPE D3000 Enclosures
Configuration
Information
Page 19
HP 1TB 6G SATA 7.2K rpm LFF (3.5-inch) SC Midline 1yr Warranty Hard Drive
861691-B21
HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware
HDD
872489-B21
HP 3TB 6G SATA 7.2K rpm LFF (3.5-inch) SC Midline 1yr Warranty Hard Drive
861693-B21
Large Form Factor Solid State Drives
SAS Mixed Use LFF (3.5in) Solid State Drive
HPE 800GB SAS 12G Mixed Use LFF (3.5in) 3yr Wty Digitally Signed Firmware SSD
872378-B21
SATA Read Intensive LFF (3.5in) Solid State Drive
HPE 3.84TB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed
Firmware SSD
868830-B21
HPE 1.6TB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed
Firmware SSD
869388-B21
HPE 480GB 6G SATA Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed
Firmware SSD
869380-B21
SATA Mixed Use- LFF (3.5in) Solid State Drive
HPE 1.92 SATA Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD
875480-B21
HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware
SSD
872350-B21
HPE 480GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware
SSD
872346-B21
SATA Write Intensive LFF (3.5in) Solid State Drive
HPE 1.6TB SATA 6G Write Intensive SFF (2.5in) SCC 3yr Wty Digitally Signed
Firmware SSD
872365-B21
HPE 800GB SATA 6G Write Intensive SFF (2.5in) SCC 3yr Wty Digitally Signed
Firmware SSD
872361-B21
HPE 400GB SATA 6G Write Intensive SFF (2.5in) SCC 3yr Wty Digitally Signed
Firmware SSD
872357-B21
HPE 400GB 6G SATA Write Intensive-3 LFF 3.5-in SCC 3yr Wty Solid State Drive
867817-B21
HPE D3700/D3710 - Small Form Factor (SFF)
10K SAS SFF (2.5in) Hard Disk Drives
HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e DS HDD
872481-B21
HPE 1.8TB 12G SAS 10K rpm SFF (2.5-inch) SC Enterprise 512e 3yr Warranty Hard
Drive
791034-B21
HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3Yr Wty DS HDD
872478-B21
HPE 1.2TB 12G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive
781518-B21
HPE 900GB 12G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive
785069-B21
HPE 600GB SAS 12G Enterprise 10K SFF (2.5in ) SC 1yr Wty DS HDD
872477-B21
HPE 600GB 12G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive
781516-B21
HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3Yr Wty DS HDD
872475-B21
HPE 300GB 12G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive
785067-B21
15K SAS SFF (2.5in) Hard Disk Drives
HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty DS HDD
870753-B21
HP 300GB 12G SAS 15K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive
759208-B21
HP 450GB 12G SAS 15K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive
759210-B21
HP 600GB 12G SAS 15K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive
759212-B21
HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty DS HDD
870757-B21
HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e DS HDD
870763-B21
QuickSpecs
HPE D3000 Enclosures
Configuration
Information
Page 20
HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty DS HDD
870759-B21
HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e DS HDD
870765-B21
7.2K SAS Midline SFF (2.5in) Hard Disk Drives
HPE 2TB 12G SAS 7.2K rpm SFF (2.5-inch) SC 512e 1yr Warranty Hard Drive
765466-B21
HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed
Firmware HDD
765464-B21
HPE 1TB 12G SAS 7.2K rpm SFF (2.5-inch) SC 512e 1yr Warranty Hard Drive
832514-B21
7.2K SATA Midline SFF (2.5in) Hard Disk Drives
HPE 1TB 6G SATA 7.2K rpm SFF (2.5-inch) SC Midline 1yr Warranty Hard Drive
765453-B21
HPE 2TB 6G SATA 7.2K rpm SFF (2.5-inch) SC 512e 1yr Warranty Hard Drive
765455-B21
NOTE: SATA drives are single ported and therefore do not have a fail-over path
Domain environment.
Small Form Factor 12G SAS Solid State Drives
SAS Mixed Use SFF (2.5in) Solid State Drives
HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
873367-B21
HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
872386-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
873365-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
872382-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
873363-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
872376-B21
HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
873359-B21
HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
872376-B21
SAS Read Intensive SFF (2.5in) Solid State Drives
HPE 7.68TB SAS Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
870144-B21
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
872394-B21
HPE 3.84TB SAS Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
875330-B21
HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
872392-B21
HPE 1.92TB SAS Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
875326-B21
HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
872390-B21
Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
875313-B21
Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
875311-B21
intrinsic to their design. Only Dual Port (DP) SAS drives will work in the Dual
SSD
HPE 960GB SAS
HPE 480GB SAS
QuickSpecs
HPE D3000 Enclosures
Configuration
Information
Page 21
SAS Write Intensive SFF (2.5in) Solid State Drives
HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
873357-B21
HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
873355-B21
HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
873351-B21
NOTE: Number of drives is limited to twenty five (25) per controller.
NOTE: SAS Solid State drives are dual path and dual domain.
NOTE: Cascading is supported in both single and dual domain environments.
Small Form Factor 6G SATA Solid State Drives
SATA Mixed Use- SFF (2.5in) Solid State Drives
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
872352-B21
HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware
SSD
872344-B21
SATA Read Intensive- SFF (2.5in) Solid State Drives
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
FirmwareSSD
868826-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
871770-B21
HPE 1.6TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
869386-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
FirmwareSSD
871768-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
868822-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
869378-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
868818-B21
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
868814-B21
HPE 150GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
869374-B21
SATA Write Intensive- SFF (2.5in) Solid State Drives
HPE 1.6TB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
872363-B21
HPE 800GB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
872359-B21
HPE 400GB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed
Firmware SSD
872355-B21
NOTE: Number of drives is limited to twenty five (25) per controller.
Firmware SSD
FirmwareSSD
Firmware SSD
QuickSpecs
HPE D3000 Enclosures
Configuration
Information
Page 22
Step 5: Choose Rack Option
Refer to the HPE Infrastructure products page for more information on HPE racks and rack options:
http://h18004.www1.HPE.com/products/servers/platforms/rackandpower.html
Step 6: Choose Cables
Cable Options
Cables to be used for connecting the HPE D3600/D3700 with the HPE Smart
Array P822, Controllers and H222 Host Bus Adapters
HPE 0.5m External Mini SAS High Density to Mini SAS Cable
691971-B21
HPE 1.0m External Mini SAS High Density to Mini SAS Cable
716189-B21
HPE 2.0m External Mini SAS High Density to Mini SAS Cable
716191-B21
HPE 4.0m External Mini SAS High Density to Mini SAS Cable
716193-B21
Cables to be used for connecting D3600/D3700/D3610/D3710 with the Smart
(HD connector)
HPE External 1.0m (3ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable
716195-B21
HPE External 2.0m (6ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable
716197-B21
HPE External 4.0m (13ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable
716199-B21
* #0D1 will appear after this part number on your sales order if factory integration
is indicated.
Power Cord Options
If customers require a power cord other than the included PDU style cords, they can
matrix for details http://www.hpe.com/products/powercords.
NOTE: An optional longer 2meter PDU power cable (C14 to C13 style connector)
quantity to order is 1 AF573A HPE RDNT 2m,10A, C13-C14 JMPR CORD
Array P431, P441,
P841, P731m, P741m, E208e, P408e Controllers, and H241 Host Bus Adapter
check the power cord matrix for the appropriate SKU. See the following power cord
for customers who would like additional length for connections to existing power
distribution modules located on the right side of the rack. This is purely optional as
the included .7meter power cables will also reach the right sides of the rack.
(D3700 power supplies are on the left side of the enclosures). If desired, the
QuickSpecs
HPE D3000 Enclosures
Technical Specifications
Page 23
LED Indicators for HDDs
HPE SmartDrive Carrier Drives
LED Indicators on Front
Bi-color green/amber for health/fault
Blue for UID
Heartbeat LED
Fault LED
UID button/LED
LED Indicators on Rear
I/O Module LED (2) identify/On/Fault; Port (2) Link good/ link fault
UID button/LED
Heartbeat LED
Fault LED
Fan LED
Power supply LED
Host Interface
8 x wide SAS 12Gb/s ports
Maximum Number of
Drives
Up to 12 3.5 inch (D3600/D3610) or 25 2.5 inch (D3700/D3710) SAS or SATA drives
Acoustics Noise
Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander
configurations. Additional options may result in increased sound levels.
Idle Acoustic Noise
(sound power)
LWAd= 7.0 B
Idle Acoustic Noise
(sound pressure)
LpAm - 53 dBA
Operating Acoustic
LWAd= 7.0 B
Operating Acoustic
Noise (sound pressure)
LpAm - 53 dBA
Operating
50° to 104° F (10° to 40° C)
Shipping
-22° to 149° F (-30° to 65° C)
Relative Humidity
Operating
10% to 90%
Non-operating
0% to 95%
Maximum wet bulb
Long-term storage
(operating)
82.4° F (28° C)
Short-term storage
(non-operating)
101.6° F (38.7° C)
Input Power
Rated Input Voltage
100 to 240 VAC (Common- slot Power Supply)
Rated Input Frequency
50 to 60 Hz (Common-slot Power Supply)
Rated Input Current
6A/3A
Input Power max
403W
Heat Dissipation
(maximum)
1331/Btu/hr.1160.Btu/hr
NOTE: standard conversion from Watts to Btu/hr = 3.413 Btu/hr per Watt.
RAID Support
See QuickSpecs for Smart Array Controllers P431, P822, P731m, P408e-p, E208e-p
http://h18004.www1.hpe.com/products/servers/proliantstorage/arraycontrollers/index.html
Panel
Panel
Temperature Range
temperature
Up to 25 2.5 inch (Solid State Drives per controller
position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient
environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared
in accordance with ISO 9296 (ECMA 109). The listed sound levels apply to standard shipping
Noise (sound power)
NOTE: Rated 1°C per 1000 feet of elevation to 10,000 ft.
Requirements
QuickSpecs
HPE D3000 Enclosures
Technical Specifications
Page 24
http://h18006.www1.hpe.com/products/servers/proliantstorage/arraycontrollers/index.html
Upgradeable Firmware
Yes, Offline only. Firmware updates available through hpe.com
Disk Drives and
Support
HPE 3.5 inch (D3600/D3610) or 2.5 inch (D3700/D3710) SAS 6/12Gb/s
I/O Module
Connector Type
IPass (mini-SAS)
Number of Ports
Two (one IN, other is OUT)
Bandwidth
SAS-3 (12Gb/s)
Protocols supported
SAS 3.0
2U Rack Form Factor
Large Form Factor
Dimensions (HxWxD)
3.44" x 17.64" x 23.54" in (8.7 x 44.8 x 59.8 cm )
Weight (base unit)
38 lb (17.2 kg)
Weight (with all LFF
drives)
60 lb (27.2 kg)
HPE D3700 Enclosure
2U Rack Form Factor
Small Form Factor
Dimensions (HxWxD)
3.44" x 17.64" x 21.48" in (8.7 x 44.8 x 54.6 cm )
Weight (base unit)
38 lb (17.2 kg)
Weight (with all SFF
drives)
54.90 lb (24.9 kg)
D3600/D3700
Shipping package
dimensions
D3600 - 11.13" x 23.75" x 38.12" (LFF)
D3700 - 11.13" x 23.75" x 36.12" (SFF)
Shipping weight
(Gross)
78lbs (35.38kg)
Enclosure Protocol
NOTE: For up to date compatibility, see the following URL for complete Smart Array Controller
compatibility and support information:
HPE D3600/ Enclosure
QuickSpecs
HPE D3000 Enclosures
Summary of Changes
Page 25
Date
Version History
Action
Description of Change
05-Mar-2018
From Version 26 to 27
Changed
The descriptions of Q1J19A and Q1J20A SKUs were updated.
05-Feb-2018
From Version 25 to 26
Changed
At a Glance section was revised.
04-Dec-2017
From Version 24 to 25
Changed
Overview, At a Glance, D3000 Enclosure Components, and
Configuration Information were revised.
23-Oct-2017
From Version 23 to 24
Changed
Care Pack naming and Service and Support- Parts and Materials
updated.
25-Sept-2017
From Version 22 to 23
Changed
Changes made throughout QuickSpecs.
07-Aug-2017
From Version 21 to 22
Changed
Changes made throughout QuickSpecs.
11-Jul-2017
From Version 20 to 21
Changed
Changed made to the entire document
27-Mar-2017
From Version 19 to 20
Changed
SKUs added and some other deleted.
28-Nov-2016
From Version 18 to 19
Changed
Changed made to the entire document
30-Sept-2016
From Version 17 to 18
Changed
Changes made in the Configuration Section
13-May-2016
From version 16 to 17
Changed
Changes made to the Product Highlights and Configuration Info
Sections.
23-Oct-2015
From Version 15 to 16
Changed
Changes made to the Product Highlights and Configuration
Information Sections.
02-Oct-2015
From Version 14 to 15
Changed
Changed made to the Overview and Configuration Information
Sections.
04-Sept-2015
From Version 13 to 14
Changed
Changed the firmware from 2.02 to 1.72
10-Jul-2015
From Version 12 to 13
Changed
Changed the Step 4 in the Configuration Information Section.
SKUs descriptions were updated.
01-Jun-2015
From Version 11 to 12
Changed
Changes made to the D3000 Enclosure Components, At a
Glance, Product Highlights, Configuration and Overview Sections
30-Mar-2015
From Version 10 to 11
Changed
Changes made to the D3000 Enclosure Components, At a
Glance, Product Highlights and Configuration Sections.
13-Feb-2015
From Version 9 to 10
Added
added the new 12G HDDs, Obsolete SKUs removed and SKUs
descriptions updated
12-Dec-2014
From Version 8 to 9
Changed
Changes made to the Configuration Information section,
1-Dec-2014
From Version 7 to 8
Changed
Changes made through all QuickSpecs.
3-Oct-2014
From Version 6 to 7
Changed
Changes made through all QuickSpecs.
22-Aug-2014
From Version 5 to 6
Changed
Updated the following: What’s new; At a Glance – Affordable,
759210-B21, 759212-B21, 761477-B21, 753874-B21
13-Aug-2014
From Version 4 to 5
Changed
Formatting Change
16-May-2014
From Version 3 to 4
Changed
At A Glance and Configuration Information were revised.
18-Apr-2014
From Version 2 to 3
Changed
Product descriptions were revised.
11-Apr-2014
From Version 1 to 2
Added
HPE Smart Array P431/4GB FBWC 6GB=2 ports Ext SAS
Controller was added to Smart Array Controllers Supported.
SKU descriptions were updated, Obsolete SKUs were removed.
low cost Storage – D3600 maximum storage changed from
48TB to 72TB and 384TB to 576TB; D2000 enclosure
components – High Levels of Storage Density, Data Protection
and Functionality – changed 48TB to 72TB and 4TB to 6TB;
Configuration Information – Step 4 Choose Hard Drives – added
737261-B21, 737394-B21, 765424-B21, 759208-B21,
QuickSpecs
HPE D3000 Enclosures
Summary of Changes
Page 26
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting
shall not be liable for technical or editorial errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
c04227611
an additional warranty. Hewlett Packard Enterprise
- 14866 - Worldwide - V27 - 5-March-2018
Loading...
