HPE StoreVirtual 4000
Storage
Versatile storage for your virtualized
environments
Data sheet
In today’s virtualized environments, traditional
storage cannot adapt to the increasing
requirements of performance, availability,
and management. You need a simple, flexible
storage solution ideally suited to the demands
of your virtual data center.
HPE StoreVirtual 4000 Storage, based on the
LeftHand operating system, is a scale-out
storage platform designed for the fluctuating
needs of your virtualized environment. It’s a
solution that delivers on all fronts: availability, data
mobility, disaster recovery, manageability, and
growth. The StoreVirtual’s all-inclusive feature
set adapts to business demands and allows
for aordable growth of storage as needed.
With inherent enterprise-class storage
software functionality and leading
virtualization software integration, StoreVirtual
can support virtualization growth at all stages.
Intuitive, common management simplifies
storage administration. And, storage federation
enables data mobility across tiers, locations,
and between physical and virtual storage.
StoreVirtual is also one of the most versatile
storage platforms in the market today. Its
software-defined storage Virtual Storage
Appliance (VSA) software, and HPE ProLiant
rack and HPE BladeSystem-based hardware
models provide options to fit any infrastructure
and budget.
Key features and benefits
Easy storage management for virtualized
environments
•Platform integration with VMware® and
Microsoft® increases storage functionality
and ease of use while application integration
simplifies storage management for
applications. Backup and recovery is equally
easy with snapshot and Remote Copy
integration for virtualization platforms and
Microsoft Windows® applications.
•Managing hundreds of nodes in your
environment is just as simple as managing
your first two; whether they are on the
same site or across multiple sites. The
centralized management console (CMC) lets
you configure, manage, and monitor your
storage easily, making everyday operations
simple and eicient.
•Updates and upgrades are stress-free.
Update software with a single click. Migrate
data online to another cluster of storage
hardware. Swap nodes within a cluster for
maintenance, or upgrade to new generation
technology without any downtime.
StoreVirtual is designed to give you peace
of mind.
Data sheet
Page 2
Scale array capacity and performance
without disrupting applications
•Scale linearly in both capacity and
performance with the scale-out architecture
of StoreVirtual. Scaling storage is as simple
as adding nodes to the cluster, so you can
seamlessly and non-disruptively grow as
your business grows.
•Network RAID technology aggregates
all resources and capacity into a single
storage pool. So, every volume in the cluster
can access all available capacity. This
also means all cluster resources—CPUs,
RAID controllers, NICs, caches, and disk
spindles—can contribute to performance.
•To remove any single point of failure, the
Network RAID functionality also stripes
and protects multiple copies of data across
a storage cluster. Redundancy is managed
on a per-volume basis—to improve
storage utilization, and match the data
protection of the volume to the application’s
requirements.
•With iSCSI and optional Fibre Channel
connectivity, StoreVirtual works great even
in mixed protocol environments. You can
deploy a single, flexible storage solution for
all locations. Be prepared for what the future
may bring—migrate from one protocol to
the other without having to redesign or
replace your storage.
High data availability and superior
disaster recovery
•With proven 99999 percent1 high availability
and reliability, the storage cluster can sustain
multiple concurrent failures and still keep
data online and accessible to applications.
What this means to you is worry-free storage
for your centralized data center, as well as for
remote and branch oices.
•VMware certified multi-site disaster recovery
delivers business continuity with failover
that is transparent to users and applications.
The multi-site configuration maintains data
availability beyond a single physical or
logical site, and validates full compatibility
with VMware High Availability (HA) features.
•LeftHand Remote Copy lets you
asynchronously replicate thin provisioned,
reservationless snapshots between primary
and remote locations. You can centralize
backup and disaster recovery on a per-volume
basis while using application-integrated
snapshots for faster recovery.
•With LeftHand Peer Motion, an online data
mobility technology, you can move volumes
across all deployed StoreVirtual nodes
regardless of platform or drive type.
StoreVirtual is the only product that oers
data mobility across tiers, locations, and
between virtual and physical storage.
Aordable enterprise functionality
with a comprehensive feature set
•The all-inclusive license of StoreVirtual
covers enterprise-class storage features,
management, and value-add tools. You don’t
need to purchase additional software—buy
only the storage you need today and grow
non-disruptively in the future.
•Scale from software-defined storage
VSA software to ProLiant rack and
BladeSystem-based hardware models. Mix
and match product models that best fit
your infrastructure. The result is simplified
management and feature consistency.
•Transform the internal storage of your
existing VMware vSphere® and Hyper-V
servers into fully featured shared storage.
HPE StoreVirtual VSA creates a converged
infrastructure that enables data mobility
across virtualized servers, sites, and between
virtual and physical storage platforms.
1
HPE Storage qualit y review weekly dat a,
December 2014
Data sheet
Technical specifications
Page 3
HPE StoreVirtual 4000 Storage
Drive description (800) SFF SAS or
Capacity 24 TB starting
Storage expansion options Add incremental nodes into the storage cluster to expand capacity or performance (always done without disruption)
Host interface 1GbE iSCSI (128) Ports
Compatible operating systems Windows Ser ver® 2012 R2
(256) SFF MDL SAS or
(384) LFF MDL SAS
Maximum drives supported
1536 TB maximum
Maximum per management group
10GbE iSCSI (64) Ports
8 Gb Fibre Channel (64) Ports
Maximum, depending on model
Optional upgrade to 10GbE iSCSI (64) Ports
Windows Ser ver 2012
Windows Ser ver 2008 R2
Windows Ser ver 2008
VMware vSphere 55 and 50
Red Hat® Enterprise Virtualization
Red Hat Enterprise Linux® 6
SUSE Linux Enterprise Server 11
Ubuntu Server Edition 1004 LTS, 1204 LTS
Citrix® XenServer 62
Oracle VM 32
All major operating systems and hypervisors are supported. For more information, visit hp.com/go/storevirtualcompatibility
Clustering support Hyper-redundant clustered storage
Availability Redundant, hot swap power supplies redundant fans
Thin Provisioning support LeftHand Thin Provisioning
Snapshot support LeftHand Application Managed Snapshots
Replication support Remote Copy asynchronous replication with bandwidth throttling
Sub-volume auto tiering Adaptive Optimization
Management Centralized Management Console (CMC)
Warranty 3-year parts, 3-year labor, 3-year onsite
Redundant, hot plug hard drives
Integrated storage controller with flash backed write cache
Disk RAID 5, 6, and 10
Hyper-redundant clustered storage
Network RAID levels (per volume) 0, 5, 6, 10, 10+1, and 10+2 for up to four copies of your data allows it to remain available in the
event of a disk, controller, storage node, power, network, or site failure
Multi-site disaster recovery with synchronous replication
HPE ProLiant Integrated Lights-Out 4 (iLO 4) Remote Management
Baseboard Management Controller IPMI 20
Data sheet
Optimize your IT investment strategy
with new ways to acquire, pay for and
use technology, in lock-step with your
business and transformation goals.
hpe.com/solutions/hpefinancialservices
HPE Factory Express provides
customization and deployment services
along with your storage and ser ver
purchases. You can customize hardware
to your exact specifications in the
factory—helping speed deployment.
hp.com/go/factoryexpress
Gain the skills you need with ExpertOne
training and cer tification from HPE. With
HPE Converged Storage training, you will
accelerate your technology transition,
improve operational performance, and get
the best return on your HPE investment.
Our training is available when and where
you need it, through flexible delivery
options and a global training capability.
hp.com/learn/storage
Services and support
HPE Technology Services
Expert HPE storage consultants and service
professionals sit down with you and your
team to map your storage needs. Not only
can we help you accelerate implementation
and reduce deployment risk, but we can also
help you realize the full value of your storage
purchases as you transform storage for the
idea economy.
Advice, transform, and integrate
Navigate through the complexities of storage,
backup, archive, disaster recovery, and
Big Data with advisory, transformation, and
integration consulting.
Deploy and implement
Access expertise to support deployment,
operations, relocation, sanitization, and
disposal, plus improvement-focused
education.
Operate and support
Find the level of personalized, proactive, and
simplified support right for your business.
Note: Specific service availability varies by
product.
HPE Foundation Care
System-level IT hardware and software
support delivers flexible coverage window and
response time for more choice and simplicity.
HPE Proactive Care
Combined reactive and proactive services
provide easy-to-purchase, cost-eicient
system-level support coupled with
personalized expert advice and products
connected to Hewlett Packard Enterprise to
help prevent problems and reduce downtime.
HPE Proactive Care Advanced
Builds and incorporates on Proactive Care and
also gives customers personalized technical
and operational advice from an assigned, local
Account Support Manager for personalized
technical collaboration, flexible access to
specialist skills to help optimize business
critical IT, and enhanced Critical Incident
Management to help so the business is not
aected if there is a system or device outage.
HPE Datacenter Care
Get the support you need to deploy,
operate, and evolve your data center
environment to be hybrid-cloud ready with
single-point-of-accountability for Hewlett
Packard Enterprise and others’ product.
Get connected and get back to business—
HPE Storage Technology Services provide the
path to get your HPE Storage solutions and
your business connected to Hewlett Packard
Enterprise. Once connected, our experts
are able to scan your system and run
health checks, then use that data to create
personalized reports and recommendations
for actions to take to prevent problems and
downtime.
If none of our support recommendations meet
your needs, we can tailor a service solution
for your unique support requirements.
Only Hewlett Packard Enterprise brings
together deep expertise, proactive, and
business-critical support and a strong partner
network—plus, a full set of infrastructure
services designed to power a converged
infrastructure. For more information, visit
hp.com/services/storage.
Learn more at
hp.com/go/storevirtual4000
Sign up for updates
© Copyright 2012–2013, 2015–2016 Hewlett Packard Enterprise Development LP. The information contained herein is subject to
change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty
statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Microsoft, Windows, and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries. Oracle is a registered trademark of Oracle and/or its ailiates. Red Hat is a registered trademark of Red Hat, Inc.
in the United States and other countries. Citrix is a registered trademark of Citrix Systems, Inc. and/or one more of its subsidiaries and
may be registered in the United States Patent and Trademark Oice and in other countries. Linux is the registered trademark of Linus
Torvalds in the U.S. and other countries. VMware and VMware vSphere are registered trademarks or trademarks of VMware, Inc. in the
United States and/or other jurisdictions. All other third-party trademark(s) is/are property of their respective owner(s).
4AA4-4220ENW, October 2016, Rev. 4
Loading...
