HP Z230 SFF Workstation Quickspecs

1.

External 5.25" bay

2.

External/internal shared 3.5" bay

3.

Power button

4.

Front I/O (top to bottom order): 2 USB 2.0 ports, 2 USB 3.0 ports, Microphone/Headphone, Headphone

5.

Optional SFF tower stand

QuickSpecs

HP Z230 SFF Workstation

Overview

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 1

1.

1 Audio Line In, 1 Audio Line Out

2.

2 USB 3.0, 2 USB 2.0

3.

1 serial port

4.

3 DisplayPort (DP 1.2) outputs from Intel HD graphics (available on specific processors only)

5.

RJ-45 to integrated GBE

6.

2 USB 2.0

7.

PS/2 ports (keyboard, mouse)

Form Factor

Small Form Factor

Operating Systems

Preinstalled:

Windows 7 Ultimate 64-bit
Windows 7 Professional 32/64
Windows 7 Home Premium 32/64
Windows 8 Pro 64-bit
Windows 8 Simplified Chinese Edition 64-bit
Windows 8 Pro Downgrade to Windows 7 Professional 32-bit
Windows 8 Pro Downgrade to Windows 7 Professional 64-bit
Windows 8.1 Pro 64-bit
Windows 8.1 Simplified Chinese Edition 64-bit
Windows 8.1 Pro Downgrade to Windows 7 Professional 32-bit
Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit

QuickSpecs

HP Z230 SFF Workstation

Overview

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 2

Windows 8.1 Pro Downgrade to Windows 7 Professional 32-bit (National Academic)
Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit (National Academic)
HP Installer Kit for Linux [includes drivers for 64-bit OS versions of Red Hat Enterprise Linux 6 and
SUSE Linux Enterprise Desktop (SLED) 11]
SUSE Linux Enterprise Desktop 11 64-bit (90 day license)
Red Hat Enterprise Linux Workstation (1 year paper license available; Preinstall not available)

Supported:

Genuine Windows® 7 Enterprise 32/64

Notes: For detailed OS/hardware support information for Linux, see:

http://www.hp.com/support/linux_hardware_matrix

Name

Cores

Clock

Speed

(GHz)

Intel® Turbo

Boost

Technology

1

Cache

(MB)

Memory

Speed

(MHz)

Hyper-

Threading

Integrated

Graphics

Featuring

Intel®

vPro™

Technology

TDP

(W)

Intel® Xeon® processor E3-1280v3

4

3.6 4.0

8 1600

Y

N/A

Y

80W

Intel® Xeon® processor E3-1270v3

4

3.5 3.9

8 1600

Y

N/A

Y

80W

Intel® Xeon® processor E3-1245v3

4

3.4 3.8

8 1600

Y

Intel HD

Graphics

P4600

Y

84W

Intel® Xeon® processor E3-1240v3

4

3.4 3.8

8 1600

Y

N/A

Y

80W

Intel® Xeon® processor E3-1230v3

4

3.3 3.7

8 1600

Y

N/A

Y

80W

Intel® Xeon® processor E3-1225v3

4

3.2 3.6

8 1600

N

Intel HD

Graphics

P4600

Y

84W

Intel® CoreTM i7-4771 processor

4

3.5 3.9

8 1600

Y

Intel HD

Graphics

4600

Y

84W

Intel® CoreTM i7-4770 processor

4

3.4 3.9

8 1600

Y

Intel HD

Graphics

4600

Y

84W

Intel® CoreTM i5-4670 processor

4

3.4 3.8

6 1600

N

Intel HD

Graphics

4600

Y

84W

Intel® CoreTM i5-4570 processor

4

3.2 3.6

6 1600

N

Intel HD

Graphics

4600

Y

84W

Intel® CoreTM i3-4330 processor

2

3.5

NA

4 1600

Y

Intel HD

Graphics

4600

N

54W

Intel® Core TM i3-4130 processor

2

3.4

NA

3 1600

Y

Intel HD

Graphics

4400

N

54W

Intel® Pentium® G3220 processor

2

3.0

NA

3 1333

N

Intel HD

Graphics

N

54W

1

The specifications shown in this column represent the maximum turbo frequency with one core active. Turbo boost stepping occurs

in 100MHz increments. Processors that do not have turbo functionality are denoted as N/A.

QuickSpecs

HP Z230 SFF Workstation

Overview

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 3

Available Processor
Disclaimers

Integrated Intel® HD graphics is not supported on the Intel® Xeon Processor E3-1230v3, E3-1240v3, E3­1270v3 or E3-1280v3.

Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.

Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features
within each processor family, not across different processor families. See:

http://www.intel.com/products/processor_number/

for details.

64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See:

http://www.intel.com/info/em64t

for more

information.

Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software
products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benefits; check with software provider to determine suitability; Not all customers
or software applications will necessarily benefit from use of these technologies.

Color

Jack Black

Convertibility

The Z230 SFF can either be placed flat on the desktop or made to stand on the desk with the optional
tower stand.

Expansion Slots (see
system board section for
more details)

1 PCIe Gen3 x16 slot
1 PCIe Gen2 x4 slot /x16 connector
1 PCIe Gen2 x1 slot/x4 connector
1 PCIe Gen2 x1 slot

(all slots are Low Profile)

Note: In the PCIe Gen3 x16 slot, if it is not being used for a graphics card, only cards certified as After
Market Options for this platform are supported.

Expansion Bays (see
storage section for more
details)

1 external Half Height 5.25" bay
1 shared internal/external 3.5" bay
1 internal 3.5" bay
1 internal 2.5" bay (for SSD only)

Front I/O

2 USB 3.0, 2 USB 2.0, 1 Headphone, and 1 Microphone

Internal I/O

1 USB 3.0 and 3 USB 2.0 ports available as 2 separate 2x10(3.0 x1, 2.0 x1) and 2x5(2.0 x2) header:
supports one HP Internal USB 2.0 Port Kit and one USB 3.0 Media Card Reader.

Rear I/O

3 DisplayPort (DP 1.2) outputs from Intel HD graphics (available on specific processors only); 2 USB 3.0
ports, 4 USB 2.0 ports, 2 serial ports (1 standard, 1 optional), 1 parallel port (optional), 2 PS/2, RJ-45 (LoM),
1 Audio Line-in, and 1 Audio Line-out; 2 IEEE 1394b ports (optional).

Interfaces Supported

14-in-1 Media Card Reader (optional)

Chassis Dimensions
(H x W x D)

Standard desktop orientation: 100 x 337 x 384 mm (3.95 x 13.3 x 15.1 in); Optional SFF Tower orientation
(excluding stand dimension): 337 x 100 x 384 mm (13.3 x 3.95 x 15.1 in)

QuickSpecs

HP Z230 SFF Workstation

Overview

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 4

Weight

Exact weights depend upon configuration;
Typical Weight* 7.2 kg (15.87 lbs)
Shipping Weight* 9.8 kg (21.6 lbs)
Max Supported Weight (desktop orientation) 35 kg (77 lb)

Note*: Configured with 2 3.5" hard drives, 1 optical drive, 2 DIMMs and 1 NVIDIA Quadro K600 graphics card

Temperature

Operating: 5° to 35°C (40° to 95°F)
Non-operating: -40° to 60°C ( -40° to 140°F)

Notes: Derate the maximum operating temperature by one degree C (1.8 degrees F) for every 305m (1,000
ft) altitude over 1,524m (5,000 ft).

Humidity

Operating: 8% to 85%
Non-operating: 8% to 90%

Maximum Altitude
(non-pressurized)

Operating: 3,000 m; 10,000 ft
Non-operating: 9,100 m; 30,000 ft

Power Supply

240W 92% Efficiency wide-ranging, active Power Factor Correction (PFC)

240W Standard Efficiency wide-ranging, active PFC Power Supply option available in some countries.
The Power Supply Efficiency Report for the 240W, 92% efficiency power supply may be found at these
links:

http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD%20COMPANY_PS-4241­1HA_240W_ECOS%203449_Report.pdf

http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD_D12­240P2A_240W_ECOS%203384_Report.pdf

http://www.plugloadsolutions.com/psu_reports/Hewlett-Packard%20Company_DPS-240AB­3%20A_240W_ECOS%203416_Report.pdf

http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD%20COMPANY_PCC002­020H2_240W_ECOS%203440_Report.pdf

Backup Devices

For a complete listing of compatible DAT tape drives, LTO tape drives and RDX Removable Disk Backup
System offerings, please visit

http://www.hp.com/go/connect

Chipset

Intel® C226 chipset

Memory

4 DIMM slots, supporting up to 32GB ECC/non-ECC, DDR3 1600 MHz

Memory disclaimers

The CPUs determine the speed at which the memory is clocked. If a 1333 MHz capable CPU is used in the
system, the maximum speed the memory will run at is 1333 MHz regardless of the specified speed of the
memory.

Workstation ISV
Certifications

See the latest list of certifications at

http://www.hp.com/united-states/campaigns/workstations/partnerships.html

QuickSpecs

HP Z230 SFF Workstation

Overview

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 5

Processors

Factory

Configured

Option

Kit

Support

Notes

Intel® Xeon® processor E3-1200 v3 family (Z230)

Intel® Xeon® processor E3-1280v3, Quad-Core, 8 MB cache, 3.6 GHz, up
to 4.0 GHz with Intel Turbo Boost Technology

Y

N

See Note

2

Intel® Xeon® processor E3-1270v3, Quad-Core, 8 MB cache, 3.5 GHz, up
to 3.9 GHz with Intel Turbo Boost Technology

Y

N

See Note

2

Intel® Xeon® processor E3-1245v3, Quad-Core, 8 MB cache, 3.4 GHz, up
to 3.8 GHz with Intel Turbo Boost Technology

Y

N

See Note

2

Intel® Xeon® processor E3-1240v3, Quad-Core, 8 MB cache, 3.4 GHz, up
to 3.8 GHz with Intel Turbo Boost Technology

Y

N

See Note

2

Intel® Xeon® processor E3-1230v3, Quad-Core, 8 MB cache, 3.3 GHz, up
to 3.7 GHz with Intel Turbo Boost Technology

Y

N

See Note

2

Intel® Xeon® processor E3-1225v3, Quad-Core, 8 MB cache, 3.2 GHz, up
to 3.6 GHz with Intel Turbo Boost Technology

Y

N

See Note

2

4th generation Intel® Core™ processor family

Intel® Core™ i7-4771 processor, Quad-Core, 8 MB cache, 3.5 GHz, up to

3.9 GHz with Intel Turbo Boost Technology

Y

N

See Note

3

Intel® Core™ i7-4770 processor, Quad-Core, 8 MB cache, 3.4 GHz, up to

3.9 GHz with Intel Turbo Boost Technology

Y

N

See Note

3

Intel® Core™ i5-4670 processor, Quad-Core, 6 MB cache, 3.4 GHz, up to

3.8 GHz with Intel Turbo Boost Technology

Y

N

See Note

3

Intel® Core™ i5-4570 processor, Quad-Core, 6 MB cache, 3.2 GHz, up to

3.6 GHz with Intel Turbo Boost Technology

Y

N

See Note

3

Intel® Core™ i3-4330 processor, Dual-Core, 4 MB cache, 3.5 GHz

Y

N

See Note

2

Intel® Core™ i3-4130 processor, Dual-Core, 4 MB cache, 3.4 GHz

Y

N

See Note

2

Dual Core Intel® Pentium® Processors (Z230)

Intel® Pentium® G3220 processor, Dual-Core, 3 MB cache, 3.0 GHz

Y

N

See Note

2

NOTE 1:

Intel HD Graphics P4600 supports workstation-specific graphics drivers for improved

compatibility and performance on select professional applications, compared to Intel HD Graphics 4600.

NOTE 2:

These processors support either ECC or non-ECC memory

NOTE 3:

These processors support only non-ECC memory

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 6

Monitors / Displays

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP DreamColor LP2480zx Professional Display
HP Z Display Z30i 30-inch IPS LED Backlit Monitor
HP Z Display Z27i 27-inch IPS LED Backlit Monitor
HP Z Display Z24i 24-inch IPS LED Backlit Monitor
HP Z Display Z23i 23-inch IPS LED Backlit Monitor
HP Z Display Z22i 21.5-inch IPS LED Backlit Monitor
HP ZR2740w 27-inch LED Backlit IPS Monitor
HP ZR2440w 24-inch LED Backlit IPS Monitor
HP ZR2330w 23-inch IPS LED Backlit Monitor

Supported by all Operating Systems available from HP

Screen Size Diagonally Measured

Hard Drives

SATA Hard Drives

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

SATA (Serial ATA) Hard Drives for HP Workstations

500GB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y

LQ036AA

1TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y

LQ037AA

2.0TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y

QB576AA

3.0TB SATA 7200 rpm 6Gb/s 3.5" HDD

Y Y

QF298AA

250GB SATA 10K rpm SFF HDD

Y Y

B8X18AA

500GB SATA 10K rpm SFF HDD

Y Y

B8X19AA

1TB SATA 10K rpm SFF HDD

Y Y

B8X20AA

500GB SATA 7.2K SED SFF HDD

Y

N

(not

available

today as

After

Market

Option)

Sub-Section
Description/Notes

Note: The 2.5" internal drive bay on the Z230 SFF only supports a Solid State Drive, and not a 10K rpm
HDD.

SATA Solid State Drives

HP Solid State Drives (SSDs) for Workstations

HP 128GB SATA 6Gb/s SSD

Y Y

A3D25AA

HP 256GB SATA 6Gb/s SSD

Y Y

A3D26AA

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 7

HP 256GB SATA 6Gb/s SED SSD

Y Y

(not

available

as After

Market

Option)

Intel Pro 1500 180GB SATA SSD

Y Y

F5Z70AA

Samsung SM843T 240GB SATA SSD

Y Y

F0W94AA

Samsung SM843T 480GB SATA SSD

Y Y

TBD

Intelligent Disk Caching Intelligent Disk Caching

64GB SSD Disk Cache Module

Y

N

(not

available

today as

After

Market

Option)

Hard Drive Controllers

Factory

Configured

Option Kit

Support

Notes

Integrated SATA Controller (Z230)

Integrated SATA Controller, RAID 0,1 supported: 5x 6 Gb/s ports

Y

N

Factory integrated RAID on motherboard for SATA drives

RAID 0 Configuration – Striped Array

Y

N

RAID 1 Configuration – Mirrored Array

Y

N

NOTE 1

: Windows OS only; Supported only with two drives of identical type and capacity.

SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID,
provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please
visit

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf

for RAID

capabilities with Linux.

Graphics

Factory

Configured

Option

Kit

Option
Kit Part
Number

Support

Notes

Supported

# of

cards

Mixed

Integrated Intel HD Graphics Media Accelerators (Z230)

Intel HD Graphics P4600

Y

N

Available

on Intel®

Xeon® E3-

12x5 v3

processors

only. See

Note 1.

1

NO

Intel HD Graphics 4600

Y

N

Available

on Intel

1

NO

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 8

CoreTM i7­4xxx/ Core

i5-4xxx/

Core i3-

4330

processors.

See Note

1.Available
on Intel

CoreTM i7­4xxx/ Core

i5-4xxx/

Core i3-

4330

processors.

See Note 1.

Intel HD Graphics 4400

Y

N

Available

on Intel

Core i3-

4130

processor.

See Note 1.

1

NO

Intel HD Graphics

Y

N

Available

on Intel

Pentium®

3220

processor.

See Note 1

1

NO

Professional 2D

NVIDIA NVS 310 512MB Graphics

Y Y

A7U59AA

Can be

mixed with

one NVS

510

2

YES

NVIDIA NVS 315 1GB Graphics

Y Y

E1U66AA

2

NO

NVIDIA NVS 510 2GB Graphics

Y Y

C2J98AA

Can be

mixed with

one NVS

310

1

YES

Graphics Cable Adapters

HP DisplayPort To DVI-D Adapter

Y Y

FH973AA

1

HP DisplayPort To DVI-D Adapter (2­Pack)

Y

N

1

HP DisplayPort To DVI-D Adapter (4­Pack)

Y

N

1

HP DisplayPort To VGA Adapter

Y Y

AS615AA

1

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 9

HP DisplayPort to Dual Link DVI
Adapter

Y Y

NR078AA

1

Entry 3D

AMD FirePro V3900 1GB Graphics

Y Y

A6R69AA

1

NO

NVIDIA Quadro 410 512MB Graphics

Y Y

A7U60AA

1

NO

NVIDIA Quadro K600 1GB Graphics

Y Y

C2J92AA

1

NO

Note 1:

Intermixing integrated Intel HD graphics and discrete graphics cards in order to drive more than
three displays can be enabled using the Computer (F10) Setup Utility. However, HP recommends using only
discrete graphics when four or more displays are required to be supported. Utility. However, HP
recommends using only discrete graphics cards when four or more displays are required to be supported.

Memory

Sub-Section Description/Notes

Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.

CTO

Support Notes

DDR3-1600 nECC Unbuffered DIMMs CTO

HP 32GB (4x8GB) DDR3-1600 nECC RAM
HP 16GB (2x8GB) DDR3-1600 nECC RAM
HP 16GB (4x4GB) DDR3-1600 nECC RAM
HP 8GB (2x4GB) DDR3-1600 nECC RAM
HP 4GB (1x4GB) DDR3-1600 nECC RAM

DDR3-1600 ECC Unbuffered DIMMs - CTO

HP 32GB (4x8GB) DDR3-1600 ECC RAM
HP 16GB (2x8GB) DDR3-1600 ECC RAM
HP 16GB (4x4GB) DDR3-1600 ECC RAM
HP 8GB (2x4GB) DDR3-1600 ECC RAM
HP 8GB (1x8GB) DDR3-1600 ECC RAM
HP 4GB (2x2GB) DDR3-1600 ECC RAM
HP 4GB (1x4GB) DDR3-1600 ECC RAM

Sub-Section Description/Notes

Two channels of DDR3 memory are supported. To realize full performance at least one DIMM must be
inserted into each channel.
The CPUs determine the speed at which the memory is clocked. If a 1333 MHz capable CPU is used in the
system, the maximum speed the memory will run at is 1333 MHz regardless of the specified speed of the
memory.

AMO

Option Kit Part

Number

Support Notes

DDR3-1600 nECC Unbuffered DIMMs AMO

HP 8GB (1x8GB) DDR3-1600 non-ECC RAM

B1S54AA

HP 4GB (1x4GB) DDR3-1600 nECC RAM

B1S53AA

DDR3-1600 ECC Unbuffered DIMMs - AMO

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 10

HP 8GB (1x8GB) DDR3-1600 ECC RAM

A2Z50AA

HP 4GB (1x4GB) DDR3-1600 ECC RAM

A2Z48AA

NOTE:

Only unbuffered DDR3 DIMMs are supported.

Multimedia and Audio
Devices

Factory

Configured

Option Kit

Option Kit

Part

Number

Support

Notes

HP Thin USB Powered Speakers, Low Halogen

Y Y

KK912AA

Integrated Realtek HD ALC221 Audio

Y

N

Optical and Removable
Storage

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP 16X DVD-ROM SATA Drive (non Lightscribe)

Y Y

AR629AA

HP 16X DVD+/-RW SuperMulti SATA Drive

Y Y

QS208AA

HP Blu-ray Writer

Y Y

AR482AA

HP 14-in-1 Media Card Reader

Y Y

E5G19AA

Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright
protected materials. Intended for creation and storage of your original material and other lawful uses.
Double Layer discs can store more data than single layer discs. However, double-layer discs burned with
this drive may not be compatible with many existing single-layer DVD drives and players.
As Blu-ray is a new format containing new technologies, certain disc, digital connection, compatibility
and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on
all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI
digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this
workstation.

Controller Cards

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

HP IEEE 1394b FireWire PCIe Card

Y Y

NK653AA

See Note

1

HP Thunderbolt-2 PCIe 1-port I/O Card

Y Y

F3F43AA

See Note

2

NOTE 1:

: Four USB 3.0 ports are available integrated on the motherboard (2 front, 2 rear). Integrated USB

3.0 ports are supported under Microsoft Windows 7 or Microsoft Windows 8 operating systems only.

NOTE 2:

Thunderbolt™ 2 is available via an optional add-in card. Thunderbolt is new technology.
Thunderbolt cable and Thunderbolt device (sold separately) must be compatible with Windows. To
determine whether your device is Thunderbolt Certified for Windows, see

https://thunderbolttechnology.net/products

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 11

Networking and
Communications

Factory

Configured

Option

Kit

Option

Kit Part

Number

Support

Notes

Integrated Intel I217LM PCIe GbE Controller

Y

N N

See Notes

1, 2, 3

Intel Ethernet I210-T1 PCIe NIC

Y Y

E0X95AA

See Notes

3, 4

Intel 6205 802.11 a/b/g/n PCIe x1 WLAN Card

N

Y

E0X93AA

NOTE 1

: The integrated network connection is required to support Intel vPro Technology.

NOTE 2

: If AMT is enabled network teaming with the integrated LAN port is not possible.

NOTE 3

: "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does
not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit
Ethernet server and network infrastructure is required.

NOTE 4

: The Intel Ethernet I210-T1 PCIe NIC is supported on the following operating systems:

Microsoft Windows 7 and Windows 8 32-bit and 64-bit versions
Red Hat Enterprise Linux(RHEL)
SLED 11.

Racking and Physical
Security

Factory

Configured

Option Kit

Option Kit

Part

Number

Support

Notes

HP Solenoid Lock and Hood (SFF) Sensor

Y Y

E0X97AA

HP Business PC Security Lock Kit

N

Y

PV606AA

The HP

Business

PC

Security

Lock Kit

does not

work with

the

Integrated

Work

Center

stand.

HP UltraSlim Cable Lock Kit

N

Y

H4D73AA

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 12

Input Devices

Factory

Configured

Option Kit

Option Kit

Part

Number

Support

Notes

HP SpacePilot Pro 3D USB Intelligent Controller

N

Y

WH343AA

HP SpaceMouse Pro USB 3D Input Device

N

Y

B4A20AA

HP USB 1000dpi Laser Mouse

Y Y

QY778AA

HP USB Optical 3-Button Mouse

Y Y

DY651A

HP USB Optical Mouse

Y Y

QY777AA

HP PS/2 Mouse

Y Y

QY775AA

HP 2.4GHz Wireless Keyboard & Mouse

N

Y

NB896AA

HP USB CCID SmartCard Keyboard

Y Y

BV813AA

HP USB Keyboard

Y Y

QY776AA

HP PS/2 Keyboard

Y Y

QY774AA

Other Hardware

Factory

Configured

Option Kit

Option Kit

Part

Number

Support

Notes

HP Power Cord Kit

N

Y

DM293A

HP Workstation Mouse Pad

Y

N

Japan

only

HP Serial Port Adapter

Y Y

PA716A

HP ENERGY STAR Qualified Configuration

Y

N

HP Parallel Port Adapter Kit

N

Y

KD061AA

HP Internal USB Port Kit

N

Y

EM165AA

HP eSATA PCI Cable Kit

Y Y

FH966AA

HP (SFF) Tower Stand

Y Y

VN569AA

Software

Factory

Configured

Option Kit

Support Notes

HP Performance Advisor

Y

N

See Note 1

HP Remote Graphics Software (RGS) 6.0

Y

N

See Note 2

PDF Complete - Corporate Edition

Y

N

MS Office Home & Business 2013

Y

N

Cyberlink PowerDVD and Power2Go

Y

N

HP PC Hardware Diagnostics UEFI

Y

N

Windows OS only

NOTE 1

: Supports, and preinstalled with, Windows 7 and Windows 8 only. Also available as a free
download from

www.hp.com/go/performanceadvisor

NOTE 2

: Supported Operating Systems:

Windows 7 Professional
Windows 8 Pro
RHEL v5.2 - v6.3

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 13

SLED 11 SP2

Operating Systems

Support Notes

Genuine Windows® 7 Ultimate 64-bit
Genuine Windows® 7 Professional 32-bit

See

http://www.microsoft.com/windows/windows-7/

for support details.

Genuine Windows® 7 Professional 64-bit

See

http://www.microsoft.com/windows/windows-7/

for support details.

Genuine Windows® 7 Home Premium 32-bit

See

http://www.microsoft.com/windows/windows-7/

for support details.

Genuine Windows® 7 Home Premium 64-bit

See

http://www.microsoft.com/windows/windows-7/

for support details.
Windows 8.1 Pro 64-bit
Windows 8.1 Simplified Chinese Edition 64-bit
Windows 8.1 Pro Downgrade to Windows 7

Professional 32-bit
Windows 8.1 Pro Downgrade to Windows 7

Professional 64-bit
Windows 8.1 Pro Downgrade to Windows 7

Professional 32-bit (National Academic)
Windows 8.1 Pro Downgrade to Windows 7

Professional 64-bit (National Academic)
HP Linux Installer Kit

See

http://h20331.www2.hp.com/hpsub/cache/537200-0-

0-225-121.html

Red Hat Enterprise Linux (RHEL) Workstation ­Paper License (1yr)

See

http://www.redhat.com/rhel/desktop/

SUSE Linux Enterprise Desktop 11

See

http://www.suse.com/products/desktop/

QuickSpecs

HP Z230 SFF Workstation

Supported Components

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 14

System Board

System Board Form Factor

ATX 24.38 x 24.38 mm (9.6 x 9.6 inches)

Processor Socket

Single LGA 1150

CPU Bus Speed

DMI

Chipset

Intel® PCH C226

Memory Expansion Slots

4 DDR3 memory slots

Memory Type Supported

DDR3, UDIMM (Unbuffered), ECC& non-ECC

Memory Modes

Non-Interleaved for single channel. Interleaved when both channels are populated.

Memory Speed Supported

1600MHz DDR3

Memory Protection

ECC available on data

Maximum Memory

32GB

Memory Configuration

(Supported)

4GB and 8GB non-ECC/ 2GB, 4GB and 8GB ECC unbuffered DIMMs are supported.
ECC and non-ECC memory DIMMs cannot be mixed on the same system.

NOTE:

* Maximum memory capacities assume 64-bit operating systems, such as Genuine Windows® 7

Professional 64-Bit or Red Hat Linux 64-bit. 32-bit Windows Operating Systems support up to 4 GB.

PCI Express Connectors

1 PCI Express Gen3 x16 LP slot (x16 electrical/x16 mechanical)
1 PCI Express Gen2 x16 LP slot (x4 electrical/x16 mechanical)
1 PCI Express Gen2 x1 LP slot (x1 electrical/x4 mechanical)
1 PCI Express Gen2 x1 LP slots (x1 electrical/x1 mechanical)

NOTE:

LP = Low Profile

NOTE:

In the PCIe Gen3 slot (x16 electrical/x16 mechanical) slot, if it is not being used for a graphics card,

only cards certified as After Market Options for this platform are supported.

Supported Drive
Interfaces

SATA

Integrated (5) Serial ATA interfaces (6Gb/s SATA). One port can
optionally be used for eSATA.
RAID 0 and 1 supported. Factory integrated RAID is Microsoft
Windows only.

Serial Attached SCSI

None

Integrated RAID

NOTE:

Requires identical hard drives (speeds, capacity,

interface)

Integrated Graphics

Integrated Intel HD Graphics 4600 (on Core i5/i7-4xxx
processors); Integrated Intel HD Graphics P4600 (on Intel Xeon
E3-12x5v3 processors).

Based on Unified Memory Architecture (UMA)- A region of
system memory is reserved and dedicated to the graphics
display.
Support for Microsoft DirectX 11, OpenGL 4.0 and OpenCL 1.2
on Intel HD Graphics P4600;
3 DP 1.2 graphics ports integrated in motherboard; Supports up
to three simultaneous displays across DP outputs. Max.
resolution supported: 3840x2160 @60Hz

QuickSpecs

HP Z230 SFF Workstation

System Technical Specifications

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 15

Network Controller

Integrated Ethernet PHY Connection I217LM. Management
capabilities: WOL, PXE 2.1 and AMT 9.0

External SATA (eSATA)

1 port eSATA capable with optional eSATA After-Market Option
cable kit.

IDE connector

No

Floppy connector

No

Serial

1 rear port

2nd Serial

Yes- requires optional Serial Port Adapter Kit

Parallel

1 internal header (optional Parallel Port Adapter required)

CD-ROM input (Audio)

No

AUX input (Audio)

No

IEEE 1394 Connector(s)

Rear

2 IEEE 1394b (requires optional PCIe 1394b card)

Internal

No

USB Connector(s)

Front

2 USB 3.0, 2 USB 2.0

Rear

2 USB 3.0, 4 USB 2.0

Internal

1 USB 3.0, 2 USB 2.0

HD Integrated Audio

Yes

Flash ROM

Yes, 16MB

Chassis Fan Header

Not applicable

Front Control
Panel/Speaker Header

Yes

CMOS Battery Holder ­Lithium

Yes

Integrated Trusted
Platform Module

Integrated TPM 1.2.

Power Supply Headers

Yes

Power Switch, Power LED
& Hard Drive LED Header

Yes

Clear Password Jumper

Yes

Keyboard/Mouse

USB or PS/2

240W, 92% efficiency, wide-ranging, active PFC Power Supply;

(Note: 240W Standard Efficiency wide-ranging, active PFC Power Supply option available in some
countries).

The Z230 SFF 92% PSU Efficiency Report can be found at these links:

http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD%20COMPANY_PS-4241­1HA_240W_ECOS%203449_Report.pdf

http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD_D12­240P2A_240W_ECOS%203384_Report.pdf

http://www.plugloadsolutions.com/psu_reports/Hewlett-Packard%20Company_DPS-240AB-

QuickSpecs

HP Z230 SFF Workstation

System Technical Specifications

DA - 14630 Worldwide — Version 14 — April 1, 2014

Page 16
