HP Thin Client t5545 User Manual

QuickSpecs

HP t5545 Thin Client

HP t5545 Thin ClientHP t5545 Thin Client

Overview

Introduction

IntroductionIntroduction

The HP t5545 is an all inclusive access device designed for mainstream business. The HP t5545 offers convenient access to Windows or Citrix environments, the most common VDI ecosystems, mainframes, mid-range servers, and Unix/Linux hosts The ThinPro operating system provides a single console interface with dashboard access to all user and administrative touch points. The t5545 includes dual monitor support, legacy ports, a secure USB compartment, Gigabit Ethernet support and a choice of client side or server based remote management solutions to simplify deployment and maintenance.

Front

FrontFront

Secure USB compartment (2 USB connectors)

Power button with LED

Flash activity indicator

Audio connector (mic in)

Audio connector (headphone out)

USB connectors (2)

Vertical stand (removable)

VESA mounting points (4)

DA - 13148 North America — Version 15 — August 19, 2009

Back

BackBack

Cable lock slot

10/100/1000 Ethernet RJ-45 connector

PS/2 connectors (2)

Parallel port

Cable management feature

USB connectors (2)

VGA connector

Serial port

DVI-D connector

10.

+12V DC power input

Page 1

QuickSpecs

HP t5545 Thin Client

HP t5545 Thin ClientHP t5545 Thin Client

Overview

At A Glance

At A GlanceAt A Glance

HP ThinPro operating system supports modular software updates that can be applied remotely over the network for rapid deployment VIA Eden 1 GHz processor for great performance 512 MB System memory (64 MB reserved for video) 512 MB Flash memory Includes one parallel, one serial, two PS/2, and six USB 2.0 ports (two in back, two in front, and two in secure USB compartment – great for safeguarding USB wireless and Flash devices) MIC in and Audio out ports in front Built in dual monitor support (VGA and DVI-D native) ENERGY STAR® qualified Native HP RDP Enhancements provide streaming media and USB redirection through RDP connections HP Remote Graphics Software (RGS) support for a business class multimedia experience VDI broker support includes VMware View Manager, Citrix XenDesktop (with CDA mode utility), LeoStream, Provision Netowkrs HP Session Allocation Manager (SAM) HP Device Manager lets you remotely manage client devices from a central location HP's alliance with Altiris brings a leading management solution to the thin client market. Altiris Deployment Solution's standards-based, advanced thin client management solution helps reduce the costs of deploying, updating, and maintaining your thin clients. A free client license is included with each HP thin client. Exclusive HP ThinState Tools offers in-box, easy-to-use image deployment and recovery tools HP Total Care Warranty and Services: limited three-year hardware warranty in most regions. HP Care Pack Services extend service contracts which go beyond your standard warranties. For more details visit:

www.hp.com/go/lookuptool

DA - 13148 North America — Version 15 — August 19, 2009

Page 2

QuickSpecs

Models

VN134AA#ABA

VN134AA#ABAVN134AA#ABA

VN134AT#ABA

VN134AT#ABAVN134AT#ABA (SmartBuy or Promo)

Model Name

Model NameModel Name Processor

Processor

ProcessorProcessor Flash

Flash

FlashFlash System Memory

System Memory

System MemorySystem Memory Operating System

Operating System

Operating SystemOperating System Keyboard

Keyboard

KeyboardKeyboard Mouse

Mouse

MouseMouse Side Panels

Side Panels

Side PanelsSide Panels

HP t5545 Thin Client VIA Eden 1 GHz 512 MB 512 MB (64 MB reserved for video) HP ThinPro Keyboard (USB or PS/2) varies by region Mouse (USB or PS/2) varies by region VESA standard mounting holes

HP t5545 Thin Client

HP t5545 Thin ClientHP t5545 Thin Client

DA - 13148 North America — Version 15 — August 19, 2009

Page 3

QuickSpecs

Options

HP t5545 Thin Client

HP t5545 Thin ClientHP t5545 Thin Client

Accessories

AccessoriesAccessories

Communications

CommunicationsCommunications

Touch Screens

Touch ScreensTouch Screens

NOTE:

Options are available as separate purchase

NOTE:NOTE:

HP Quick Release Kit HP Quick Release/VESA Panels Kit

(for mounting models that ship with non-VESA panels) HP Integrated Work Center Stand 50 Watt External Power Supply

Belkin USB Wireless 802.11b/g (North America, Singapore, Hong Kong, Malaysia, Philippines, India, Korea, China, Taiwan, Australia, New Zealand) To order, visit www.belkin.com

Belkin USB Wireless 802.11b/g (Germany, Netherlands, Spain, Italy, France, Poland, Hungary, Czech, Russia, Bulgaria, Romania, United Kingdom, Sweden/Scandinavia) To order, visit www.belkin.com

USB 802.11a/b/g Wireless Ethernet Adapter – European Channel Configuration USB 802.11a/b/g Wireless Ethernet Adapter – North American Channel

Configuration

ELO Touch 1529L Flat Panel HP L5006tm LCD Touchscreen (available in selected countries)

2,3

(Security: WEP, WPA & WPA2 Only)

, search for HP4050, and order online

2,3

(Security: WEP, WPA & WPA2 only)

, search for HP4050ea, and order online

Part Number

Part NumberPart Number

EM870AA

FV248AA

GN783AA

FJ851AA#ABA

Belkin part

number:

HP4050

Belkin part

number:

HP4050ea

AK256AA#ABA

AK257AA

E926109 RB146AA

Security

SecuritySecurity

Input Devices

Input DevicesInput Devices

HP USB Smartcard Keyboard SCM USB Smart Card Reader SCR331 HP/Kensington Cable Lock

HP PS/2 Standard Keyboard HP USB Standard Keyboard HP USB Smartcard Keyboard HP PS/2 2-Button Scroll Mouse HP PS/2 2-Button Optical Scroll Mouse HP USB 2-Button Optical Scroll Mouse

ED707AA

ED707AA#ABA

904622

PC766A

DT527A#ABA DT528A#ABA

DD440B

EY703AA

DC172B

DA - 13148 North America — Version 15 — August 19, 2009

Page 4
