The HP t5630w Thin Client delivers great value with a familiar Windows experience at the right performance level. Microsoft
Windows Embedded Standard operating system combined with a full-featured browser, HP Remote Graphics Software (RGS), HP
Remote Desktop Protocol (RDP) Enhancements Software, Add/Remove Programs utility, Enhanced Write Filter, Symantec Endpoint
Protection, terminal emulation, native dual monitor and widescreen support make the t5630w the optimum choice for business
environments requiring a cost-effective thin client with flexibility and power.
Front
Front
FrontFront
1.
Secure USB compartment (2 USB connectors)
2.
Power button with LED
3.
Flash storage activity indicator
4.
Audio connector (mic in)
5.
Audio connector (headphone out)
6.
USB connectors (2)
7.
Vertical stand (removable)
8.
VESA mounting points (4)
DA - 13262 Canada — Version 6 — August 19, 2009
Back
Back
BackBack
1.
Cable lock slot
2.
10/100/1000 Ethernet RJ-45 connector
3.
PS/2 connectors (2)
4.
Parallel port
5.
Cable management feature
6.
USB connectors (2)
7.
VGA connector
8.
Serial port
9.
DVI-D connector
10.
+12V DC power input
Page 1
QuickSpecs
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
Overview
At A Glance
At A Glance
At A GlanceAt A Glance
VIA Eden 1 GHz processor for great performance
2 GB Flash memory provides ample storage for applications and drivers
1 GB System memory (64 MB reserved for video)
Built in dual monitor support (VGA and DVI-D native)
Highly extensible Windows Embedded Standard OS with support for local applications
Excellent rich multimedia experience and enhanced USB device support in blade PC and VDI environments
ENERGY STAR® qualified
Enhanced Write Filter and Symantec Endpoint Protection Agent for enhanced data security
Enterprise class HP Device Manager, lets you remotely manage devices from a central location.
Altiris Deployment Solution helps reduce the costs of deploying, updating, and maintaining your thin clients. A free client
license is included with each HP thin client.
Exclusive HP ThinState Tools offers in-box, easy-to-use image deployment and recovery tools.
Support for HP Client Automation (available separately) for quick and easy deployment of images and thin client
management. For more details visit:
HP Universal Print Driver (available as add-on) for HP PCL5 printers
Includes one parallel, one serial, two PS/2, and six USB 2.0 ports (two in back, two in front, and two in secure USB
compartment)
MIC in and Audio out ports in front
HP Total Care Warranty and Services: limited three-year hardware warranty in most regions. HP Care Pack Services extend
service contracts beyond your standard warranties. For more details visit:
http://www.hp.com
.
http://www.hp.com/go/lookuptool
.
DA - 13262 Canada — Version 6 — August 19, 2009
Page 2
QuickSpecs
Models
VC069AA#ABA
VC069AA#ABA
VC069AA#ABAVC069AA#ABA
VC069AT#ABA
VC069AT#ABA
VC069AT#ABAVC069AT#ABA
(SmartBuy or Promo)
Model Name
Model Name
Model NameModel Name
Processor
Processor
ProcessorProcessor
Flash
Flash
FlashFlash
System Memory
System Memory
System MemorySystem Memory
Operating System
Operating System
Operating SystemOperating System
Keyboard
Keyboard
KeyboardKeyboard
Mouse
Mouse
MouseMouse
Panels
Panels
PanelsPanels
HP t5630w Thin Client
VIA Eden 1 GHz
2 GB
1 GB (64 MB reserved for video)
Microsoft Windows Embedded Standard
Keyboard (USB or PS/2) varies by region
Mouse (USB or PS/2) varies by region
VESA standard mounting holes
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
DA - 13262 Canada — Version 6 — August 19, 2009
Page 3
QuickSpecs
Options
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
Accessories
Accessories
AccessoriesAccessories
Third-party
Third-party
Third-partyThird-party
Communications
Communications
CommunicationsCommunications
Touch Screens
Touch Screens
Touch ScreensTouch Screens
Security
Security
SecuritySecurity
NOTE:
NOTE:
Optional accessories are available as separate purchase.
NOTE:NOTE:
HP Quick Release Kit
HP Quick Release/VESA Panels Kit
(for mounting models that ship with non-VESA panels)
HP Integrated Work Centre Stand
50 Watt External Power Supply
Belkin USB Wireless 802.11b/g
(Security: WEP, WPA & WPA2 Only)
North America, Singapore, Hong Kong, Malaysia, Philippines, India, Korea, China,
Taiwan, Australia, New Zealand)
To order, visit:
Belkin USB Wireless 802.11b/g
(Security: WEP, WPA & WPA2 Only)
(Germany, Netherlands, Spain, Italy, France, Poland, Hungary, Czech, Russia,
Bulgaria, Romania, United Kingdom, Sweden/Scandinavia)
To order, visit:
ELO Touch 1529L Flat Panel - USB /serial combo
HP L5006tm LCD Touchscreen - USB/serial combo
HP USB Smartcard Keyboard
SCM USB Smart Card Reader SCR331
HP/Kensington Cable Lock
www.belkin.com
www.belkin.com
1,2
, search for HP4050, and order online
1,2
, search for HP4050ea, and order online
1
1
Part Number
Part Number
Part NumberPart Number
EM870AA
FV248AA
GN783AA
FJ851AA
Belkin part
number:
HP4050
Belkin part
number:
HP4050ea
E926109
RB146AA
ED707AA
904622
PC766A
Input Devices
Input Devices
Input DevicesInput Devices
Care Pack Services
Care Pack Services
Care Pack ServicesCare Pack Services
1
This is a third party option. Option, warranty and support available directly from third party vendor.
2
A standard WLAN (Wi-Fi) infrastructure with wireless access points is required and is not included. Roaming not supported. See
Administrator's Guide for supported wireless features.
3
Service levels and response times for HP Care Pack Services may vary depending on your geographic location. Restrictions and
limitations apply. For details, visit:
4
4U4847E is available in all regions; U4849E is available in Americas and Asia-Pacific/Japan.
HP PS/2 Standard Keyboard
HP USB Standard Keyboard
HP USB Smartcard Keyboard
HP PS/2 2-Button Optical Scroll Mouse
HP USB 2-Button Optical Scroll Mouse
9x5 Next-Business-Day3Advanced Exchange - 3 Years
9x5 Next-Business-Day3 On-Site Coverage - 3 Years
http://www.hp.com/go/carepack
DA - 13262 Canada — Version 6 — August 19, 2009
.
DT527A
DT528A
ED707AA
EY703AA
DC172B
331653-001;
U4847E
331655-001;
U4849E
Page 4
4
4
QuickSpecs
Technical Specifications
Processor
Processor
ProcessorProcessor
Chipsets
Chipsets
ChipsetsChipsets
Memory
Memory
MemoryMemory
Graphics
Graphics
GraphicsGraphics
Input/Output/
Input/Output/
Input/Output/Input/Output/
Peripheral Support
Peripheral Support
Peripheral SupportPeripheral Support
Audio
Audio
AudioAudio
Hardware Security
Hardware Security
Hardware SecurityHardware Security
Networking
Networking
NetworkingNetworking
VIA Eden 1 GHz
VIA VX800 north/south bridge unified chip
Flash
Flash
FlashFlash
System Memory
System Memory
System MemorySystem Memory
VIA Chrome9 HC3 DX9 Graphics
Mode
Mode
ModeMode
640 x 480
800 x 600
848 x 480
1024 x 480
1024 x 768
1280 x 720
1280 x 768
1280 x 1024
1360 x 768
1368 x 768
1400 x 1050
1440 x 900
1600 x 1200
1680 x 1050
1920 x 1080
1920 x 1200
NOTE:
NOTE:
The table represents a sample of possible modes that this controller is capable of displaying but
NOTE:NOTE:
various factors such as the capability and EDID info returned by the attached monitor, the interface used
(D-SUB/DVI-D), and dual monitor mode may limit the availability of modes, colour depth, and or
refresh rate.
Keyboard
Keyboard
KeyboardKeyboard
Mouse
Mouse
MouseMouse
Printer
Printer
PrinterPrinter
Video
Video
VideoVideo
Output
Output
OutputOutput
Input
Input
InputInput
Security lock slot (cable lock sold separately)
Secure USB compartment with 2 USB 2.0 ports
10/100/1000 Ethernet (RJ-45)
TCP/IP with DNS and DHCP
Point-to-Point Protocol (PPP), Point-to-Point over Ethernet (PPPoE),
Point-to-Point Tunneling Protocol (PPTP), Layer-2 Tunneling Protocol (L2TP), Wake on LAN (WOL), PXE
Keyboard (USB or PS/2) varies by region.
Mouse (USB or PS/2) varies by region.
Local and/or network printers (RDP, ICA, LPD)
VGA-type video output (DB-15)
DVI-D digital video output
Internal amplified speaker
Colour DepthColour Depth
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
8, 16, 32 bit
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
DA - 13262 Canada — Version 6 — August 19, 2009
Page 5
QuickSpecs
Technical Specifications
Server Network Time Protocol (SNTP)
Simple Network Management Protocol (SNMP)
I/O ports and connectors
I/O ports and connectors
I/O ports and connectorsI/O ports and connectors
Languages (MUI)
Languages (MUI)
Languages (MUI)Languages (MUI)
Server OS Compatibility/
Server OS Compatibility/
Server OS Compatibility/Server OS Compatibility/
Support
Citrix XenDesktop 2.x and 3
Citrix Presentation Server 4.0
Windows Server 2008 Terminal Services
Windows 2000/2003 Server families; Windows 2000/2003 Server Terminal Services
Other add-on software available (see:
HP TeemTalk Terminal Emulator supports these emulations. SSH is supported in terminal emulation
mode allowing users to secure their connections to the host.
Emulation
Emulation
EmulationEmulation
ADDS Viewpoint A2
AIXTerm
ANSI BBS
AT&T AT 386
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
Windows Embedded Standard
Citrix ICA 11.0 (XenApp Plugin for Hosted Apps 11.0)
Microsoft RDP 6.1
Microsoft Internet Explorer 7
Windows Media Player 11
HP TeemTalk Terminal Emulator 7.1
Citrix ICA 11.1 (Desktop Receiver 11.1) available as an add-on
Preinstalled:
HP Session Allocation Manager (SAM) 2.3
Citrix Desktop Delivery Controller enabled through web browser
VMware View Manager 3.0 (previously known as VDM broker)
3rd Party Add-on:
Leostream Desktop Connection Broker (contact vendor directly for broker
sale and support)
Provision Networks (Quest) broker (contact vendor directly for broker sale
and support)
HP Remote Graphics Software Receiver 5.2 for VMware View and Microsoft
Terminal Services
HP RDP Multimedia and USB Redirection software enhancements for
VMWare View
Citrix HD-X support for XenApp
Citrix HD-X support for XenDesktop
HP Device Manager agent 4.0
Altiris Deployment Solution (full client license). Management console
available as free download from Altiris at:
HP ThinState for rapid deployment
HP Client Automation agent
Terminal ID
Terminal ID
Terminal IDTerminal ID
ADDS-A2
aixterm
ansi
at386-m
www.hp.com/support
for latest list of available add-ons)
www.altiris.com/hptc
DA - 13262 Canada — Version 6 — August 19, 2009
Page 6
QuickSpecs
Technical Specifications
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
AT&T Dataspeed 4410
Bull BQ3107
Data General Dasher
Prime PT250
SCO Console
Siemens 97801
Stratus V102
Tandem TA6526, TA6530
Televideo 910
Televideo 920
DA - 13262 Canada — Version 6 — August 19, 2009
pt250
ansi
97801
v102
tn6530-8
TVI910
TVI920
Page 7
QuickSpecs
Technical Specifications
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
Dimensions H x W x D
Dimensions H x W x D
Dimensions H x W x DDimensions H x W x D
Weight
Weight
(approximate)
WeightWeight
Power
Power
*
PowerPower
Environmental
Environmental
EnvironmentalEnvironmental
Regulatory Compliances
Regulatory Compliances
Regulatory CompliancesRegulatory Compliances
Televideo 925
Televideo 950
Televideo 955
Unisys T27
Viewdata 40
Viewdata 80
Viewdata Split
DEC VT PCTerm
DEC VT100
DEC VT100+
DEC VT500 7-bit
DEC VT500 8-bit
DEC VT 52
VT HP220
VT UTF8
Wyse WY370
Wyse WY50
Wyse WY50+
Wyse WY60
Wyse PCTerm
Without stand
Without stand
Without standWithout stand
With stand
With stand
With standWith stand
With stand
With stand
With standWith stand
Operating voltage range
Operating voltage range
Operating voltage rangeOperating voltage range
Rated line frequency
Rated line frequency
Rated line frequencyRated line frequency
Power output (max)
Power output (max)
Power output (max)Power output (max)
Rated output current
Rated output current
Rated output currentRated output current
(max)
(max)
(max)(max)
Output voltage
Output voltage
Output voltageOutput voltage
Power consumption
Power consumption
Power consumptionPower consumption
* The actual power consumption at your location could vary and is dependent on many factors including
but not limited to software load on the thin client, attached peripherals, and environmental factors.
+12V DC
Average power consumption of this thin client in a typical setup is 14.0 W.
50° to 104° F (10° to 40° C)
-22° to 140° F (-30 to 60° C)
10% to 90% operating/5% to 95% non-operating
International: IEC60950-1, 12:2005, with CB Certificate and all National
DA - 13262 Canada — Version 6 — August 19, 2009
Page 8
QuickSpecs
Technical Specifications
Ergonomics
Ergonomics
ErgonomicsErgonomics
RF Interference
RF Interference
RF InterferenceRF Interference
Warranty
Warranty
WarrantyWarranty
Three-year limited hardware warranty.
NOTE:
NOTE:
Certain restrictions apply. Consult the HP Customer Support Centre for details.
NOTE:NOTE:
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
Deviations
US and Canada: UL 60950-1 / CAN/CSA 22.2 No. 60950-1-03,
07:2006, Bi-National Standard for ITE Safety in the US and Canada and
is published jointly by UL and CSA.
Europe: EN 60950-1, 06:2003, Information Technology Equipment
The product has been tested and found to comply with all applicable GS
ergonomic requirements.
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
ENERGY STAR® Category B
This product is in compliance with:
Restrictions of Hazardous Substances (RoHS) directive - 2002/95/EC.
Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC.
California Proposition 65 (State of California; Safe Drinking Water and Toxic Enforcement Act of
1986).
Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and
ISO1043.
Idle State:
Off Mode:
NOTE:
NOTE:
This product is in compliance with US executive order 13221, WOL (wake on LAN) disabled.
NOTE:NOTE:
NOTE:
NOTE:
The actual power consumption at your location could vary and is dependent on many factors
NOTE:NOTE:
including, but not limited to, software load on the thin client, attached peripherals, and environmental
factors.
Idle State:
Off Mode:
NOTE:
NOTE:
Heat dissipation is calculated based on the measured watts, assuming the service level is
NOTE:NOTE:
attained for one hour.
This product complies with ISO standards:
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
115 VAC
115 VAC230 VAC
115 VAC115 VAC
13.90 W14.32 W13.70 W
1.95 W1.93 W1.94 W
47.43 BTU/hr48.86 BTU/hr46.75 BTU/hr
6.66 BTU/hr6.57 BTU/hr6.62 BTU/hr
230 VAC100 VAC
230 VAC230 VAC
100 VAC
100 VAC100 VAC
Recycled material
Recycled material
Recycled materialRecycled material
EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000ppm by weight.
This product contains 0% recycled materials (by weight).
This product is 98.1% (by weight) recyclable when disposed of
properly at end of life.
The EPE foam packaging material contains at least 5% (by weight)
post-consumer recycled content.
The corrugated paper packaging materials contains at least 80% (by
weight) post-consumer recycled content.
The packaging for this product is 94% (by weight) recyclable when
disposed of properly.
DA - 13262 Canada — Version 6 — August 19, 2009
Page 10
QuickSpecs
Technical Specifications – Environmental Data
RoHS Compliance
RoHS Compliance
RoHS ComplianceRoHS Compliance
Material Usage
Material Usage
Material UsageMaterial Usage
Packaging
Packaging
PackagingPackaging
Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations,
including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to
exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis.
From July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits)
for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that
there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
This product does not contain any of the following substances in excess of regulatory limits (refer to the
HP General Specification for the Environment at:
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel - finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
HP follows these guidelines to decrease the environmental impact of product packaging:
HP t5630w Thin Client
HP t5630w Thin Client
HP t5630w Thin ClientHP t5630w Thin Client
):
End-of-life Management
End-of-life Management
End-of-life ManagementEnd-of-life Management
and Recycling
and Recycling
and Recyclingand Recycling
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in packaging materials.
Use readily recyclable packaging materials such as paper and corrugated materials.
Reduce size and weight of packages to improve transportation fuel efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas.
To recycle your product, please go to:
office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each
product type for use by treatment facilities. This information (product disassembly instructions) is posted
on the Hewlett Packard web site at:
recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP
