HP Stream Notebook PC 13
Maintenance and Service Guide
IMPORTANT! This document is intended for
HP authorized service providers only.
© Copyright 2014, 2015 HP Development
Company, L.P.
Bluetooth is a trademark owned by its
proprietor and used by HP under license. Intel
and Core are U.S. registered trademarks of Intel
Corporation. Microsoft and Windows are U.S.
registered trademarks of Microsoft
Corporation. SD Logo is a trademark of its
proprietor.
The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in the
express warranty statements accompanying
such products and services. Nothing
herein should be construed as constituting an
additional warranty. HP shall not be liable for
technical or editorial errors or omissions
contained herein.
Second Edition: September 2015
First Edition: November 2014
Document Part Number: 793463-002
For any further information or to request a full
refund of the computer, please contact your
local point of sale (the seller).
Product notice
This user guide describes features that are
common to most models. Some features may
not be available on your computer.
Not all features are available in all editions of
Windows. This computer may require upgraded
and/or separately purchased hardware, drivers
and/or software to take full advantage of
Windows functionality. Go to
http://www.microsoft.com for details.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to be
bound by the terms of the HP End User License
Agreement (EULA). If you do not accept these
license terms, your sole remedy is to return the
entire unused product (hardware and software)
within 14 days for a full refund subject to the
refund policy of your seller.
For any further information or to request a full
refund of the price of the computer, please
contact your seller.
This computer may require upgraded and/ or
separately purchased hardware and/or a DVD
drive to install the Windows 7 software and
take full advantage of Windows 7 functionality.
See http://windows.microsoft.com/en-us/
windows7/get-know-windows-7 for details.
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not place the
device directly on your lap or obstruct the device air vents. Use the device only on a hard, at surface. Do not
allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or
clothing, to block airow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as
pillows or rugs or clothing, during operation. The device and the AC adapter comply with the user-accessible
surface temperature limits dened by the International Standard for Safety of Information Technology
Equipment (IEC 60950).
iii
iv Safety warning notice
Table of contents
1 Product description ....................................................................................................................................... 1
2 External component identication .................................................................................................................. 4
Front ....................................................................................................................................................................... 4
Left side ................................................................................................................................................................. 6
Right side ............................................................................................................................................................... 7
Rear ........................................................................................................................................................................ 7
Labels ..................................................................................................................................................................... 8
3 Illustrated parts catalog ................................................................................................................................ 9
Computer major components ................................................................................................................................ 9
Display assembly components – non-touch screen ........................................................................................... 12
Display assembly components – touch screen ................................................................................................... 14
Miscellaneous parts ............................................................................................................................................. 15
Sequential part number listing ........................................................................................................................... 16
4 Removal and replacement procedures preliminary requirements .................................................................... 25
Tools required ...................................................................................................................................................... 25
Service considerations ......................................................................................................................................... 25
Plastic parts ....................................................................................................................................... 25
Cables and connectors ...................................................................................................................... 25
Grounding guidelines ........................................................................................................................................... 26
Electrostatic discharge damage ........................................................................................................ 26
Packaging and transporting guidelines .......................................................................... 27
Workstation guidelines ................................................................................ 27
5 Removal and replacement procedures for Authorized Service Provider parts ................................................... 29
Component replacement procedures .................................................................................................................. 29
Keyboard/top cover ........................................................................................................................... 29
TouchPad ........................................................................................................................................... 35
Power button board .......................................................................................................................... 36
WLAN module .................................................................................................................................... 37
WWAN/GPS module ........................................................................................................................... 39
Battery ............................................................................................................................................... 41
USB/card reader board ...................................................................................................................... 42
Speakers ............................................................................................................................................ 43
v
Heat sink ............................................................................................................................................ 44
System board .................................................................................................................................... 46
Display assembly – non-touch screen models ................................................................................. 48
Display assembly – touch screen models ......................................................................................... 56
Power connector cable ...................................................................................................................... 61
6 Using Setup Utility (BIOS) in Windows 8.1 ...................................................................................................... 63
Starting Setup Utility (BIOS) ................................................................................................................................ 63
Updating the BIOS ................................................................................................................................................ 63
Determining the BIOS version ........................................................................................................... 63
Downloading a BIOS update .............................................................................................................. 63
7 Using Setup Utility (BIOS) in Windows 10 ....................................................................................................... 65
Starting Setup Utility (BIOS) ................................................................................................................................ 65
Updating Setup Utility (BIOS) .............................................................................................................................. 65
Determining the BIOS version ........................................................................................................... 65
Downloading a BIOS update .............................................................................................................. 66
Synchronizing a tablet and keyboard (select products only) .............................................................................. 67
8 Specications .............................................................................................................................................. 68
Computer specications ...................................................................................................................................... 68
33.8-cm (13.3-in), HD display specications ...................................................................................................... 69
9 Backing up, restoring, and recovering in Windows 8.1 .................................................................................... 70
Creating recovery media and backups ................................................................................................................ 70
Creating HP Recovery media (select models only) ........................................................................... 70
Using Windows tools ........................................................................................................................................... 71
Restore and recovery ........................................................................................................................................... 71
Recovering using HP Recovery Manager ........................................................................................... 72
What you need to know before you get started ............................................................. 72
Using the HP Recovery partition (select models only) ................................................... 73
Using HP Recovery media to recover .............................................................................. 73
Changing the computer boot order ................................................................................ 73
Removing the HP Recovery partition (select models only) ............................................ 74
10 Backing up, restoring, and recovering in Windows 10 .................................................................................... 75
Creating recovery media and backups ................................................................................................................ 75
Creating HP Recovery media (select products only) ......................................................................... 75
Using Windows tools ........................................................................................................................................... 76
Restore and recovery ........................................................................................................................................... 77
vi
Recovering using HP Recovery Manager ........................................................................................... 77
What you need to know before you get started ............................................................. 77
Using the HP Recovery partition (select products only) ................................................. 78
Using HP Recovery media to recover .............................................................................. 78
Changing the computer boot order ................................................................................ 79
Removing the HP Recovery partition (select products only) ......................................... 79
11 Using HP PC Hardware Diagnostics (UEFI) ..................................................................................................... 80
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device .................................................................... 81
12 Power cord set requirements ...................................................................................................................... 82
Requirements for all countries ............................................................................................................................ 82
Requirements for specic countries and regions ................................................................................................ 82
13 Recycling .................................................................................................................................................. 84
Index ............................................................................................................................................................. 85
vii
viii
1 Product description
Category Description Non-
touch
Product Name HP Stream Notebook PC 13 √ √
Processor Intel Bay Trail-M
Intel Celeron N2840 (2.16 GHz, turbo up to 2.58 GHz), 1333 MHz/1 MB L2 cache), Dual-Core
Intel Braswell
Intel Celeron N3050 (1.6 GHz, turbo up to 2.16 GHz), 1600 MHz/2 MB L2 cache), Dual-Core
Chipset Intel Bay Trail-M SoC √ √
Intel Braswell SoC √
Graphics Internal Graphics: Intel HD Graphics
Support for DX11, HD decode, and HDMI
Support for DX12, HD decode, and HDMI (Braswell processors only) √
Panel All displays 16:9 ultra-wide aspect ratio √ √
13.3-in (1368×768), AntiGlare, high-denition (HD), light-emitting diode (LED), low-voltage
dierential-signalling (LVDS), at 3.6 mm, 200 nits
Touch screen with ush glass, multitouch enabled √
Support LVDS as default, co-layout with eDP1.3 √ √
Touch
√ √
√
√ √
√ √
Memory On-board system memory
DDR3L-1600MHz support
Supports up to 4-GB maximum on-board system memory √
Supports up to 2-GB maximum on-board system memory √
Hard drive Support for on-board eMMC drives √ √
64-GB √
32-GB √ √
Optical drive External, 9.5-mm tray load, SATA, USB, DVD±RW DL SuperMulti Drive √ √
Audio and video Webcam: HP TrueVision HD, xed (no tilt), with activity light, 1280×720 by 30 frames
per second
Dual digital microphones with appropriate echo-cancellation and noisesuppression software
DTS Studio Sound
Dual speakers
Wireless Integrated wireless local area network (WLAN) options by way of wireless module
Support for the following single antenna (in display assembly) WLAN modules:
●
Broadcom BCM43142 802.11 bgn 1x1 Wi-Fi + BT4.0 HMC Combo Adapter
√ √
√ √
1
Category Description Non-
touch
●
Realtek RT8723BE 802.11bgn 1x1 Wi-Fi + BT 4.0 Combo Adapter
Support for the following dual antenna (in display assembly) WLAN module:
●
Intel Dual Band Wireless-AC 3160 802.11 ac 1×1 WiFi + Bluetooth 4.0 Combo Adapter
Touch
WWAN 3G module (with two antennas):
●
HP hs3110 HSPA+ Mobile Broadband Module
●
HP hs3114 HSPA+ Mobile Broadband Module
Compatible with Miracast-certied devices
External media
cards
Internal
expansion
Ports AC adapter HP Smart plug (4.5 mm barrel)
Keyboard/
pointing devices
HP Multiformat Digital Media Card Reader with push-push technology.
Support SD/SDHC/SDXC with UHS-1
One half-size mini-card for WLAN
One M.2 card slot for WWAN
Audio: one combo audio-out (headphone)/audio-in (microphone) jack, supports jack autodetection
High-denition multimedia interface (HDMI) v.1.4, supporting up to 1080p, 1920×1080 at 60
Hz
RJ-45/Ethernet
USB 3.0 (1)
USB 2.0 (2)
Full-size, island keyboard
Touchpad requirements:
●
Clickpad with image sensor
●
Taps enabled as default
●
Multi-touch gestures enabled – ability to turn on and o
●
Support for Microsoft® Windows® 8.1 modern TouchPad gestures
●
Support for PS/2, SMBus
●
Default on for 2-nger scroll and pinch
√ √
√ √
√ √
√ √
√ √
Power
requirements
Security Kensington Lock slot
Operating
system
Microsoft Windows 8.1 with Bing √
Microsoft Windows 8.1 with one year of Oce 365 Personal √ √
Microsoft Windows 8.1 √ √
65-W HP Smart adapter (non-PFC, EM, 3-wire, 4.5-mm) and 45-W HP Smart adapter (nonPFC, RC, 3-wire, 4.5-mm)
3-cell, 37-WHr, 3.25-AHr, Li-ion battery
Support for Trust Platfom Module (TPM) 2.0 (except for the People’s Republic of China and
Russia)
Microsoft Windows 8.1 with Bing and one year of Oce 365 Personal √
2 Chapter 1 Product description
√ √
√ √
Category Description Non-
touch
Touch
Windows 10 Home Step-up NB Entry ML Compact
Windows 10 Home with OneDrive Entry NB ML Compact
Windows 10 Home with Oce365 Personal Entry NB ML Compact
Windows 10 Home Value NB EM/SL Compact
Windows 10 Home with OneDrive Entry NB EM/SL Compact
Windows 10 Home with Oce365 Personal Entry NB EM/SL Compact
Windows 10 Home CH/SL Compact (CPPP)
Windows 10 Home Value NB CH/SL Compact
Serviceability End user replaceable parts:
AC adapter
SIM card
√
√ √
3
2 External component identication
Front
Item Component Description
(1) Internal microphones (2) Record sound.
(2) WLAN antennas (2)* Send and receive wireless signals to communicate with WLANs.
(3) Mute light
(4) TouchPad zone Reads your nger gestures to move the pointer or activate items
(5) Windows key Returns you to the Start screen from an open app or the Windows
(6) Power button
4 Chapter 2 External component identication
●
Amber: Computer sound is o.
●
O: Computer sound is on.
on the screen.
NOTE: The TouchPad also supports edge-swipe gestures.
desktop.
NOTE: Pressing the Windows key again will return you to the
previous screen.
●
When the computer is o, press the button to turn on
the computer.
Item Component Description
●
When the computer is on, press the button briey to initiate
Sleep.
●
When the computer is in the Sleep state, press the button
briey to exit Sleep.
●
When the computer is in Hibernation, press the button briey
to exit Hibernation.
CAUTION: Pressing and holding down the power button will
result in the loss of unsaved information.
If the computer has stopped responding and Windows shutdown
procedures are ineective, press and hold the power button down
for at least 5 seconds to turn o the computer.
To learn more about your power settings, see your power options:
Windows 8.1::
▲
From the Start screen, type power, select Power and sleep
settings, and then select Power and sleep from the list of
applications.
‒ or –
From the Windows desktop, right-click the Start button, and
then select Power Options.
Windows 10:
▲
Type power in the taskbar search box, and then select
Power and sleep settings.
‒ or –
Right-click the Start button, and then select Power Options.
(7) Webcam light On: The webcam is in use.
(8) Webcam
– or –
3D camera (select products only)
*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the
antennas free from obstructions. For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices
that applies to your country or region.
To access this document in Windows 8.1:
From the Start screen, type support, and then select the HP Support Assistant app.
‒ or –
From the Windows desktop, click the question mark icon in the notication area, at the far right of the taskbar.
Records video and captures photographs. Some models allow you
to video conference and chat online using streaming video. To use
the webcam or 3D camera:
▲
Windows 8.1: From the Start screen, type camera, and then
select Camera from the list of applications.
▲
Windows 10: Type camera in the taskbar search box, and
then select Camera.
NOTE: A 3D camera captures 3D images and displays them on
the computer screen. It includes additional hardware (a 3D camera
sensor and a 3D laser projector) plus special software. To learn
more about using a 3D camera, open the Intel RealSense app
Welcome to Intel RealSense. To access the 3D camera apps, go to
the Intel RealSense Technology app.
Front 5
Item Component Description
To access this document in Windows 10:
Select Start, select All apps, select HP Help and Support, and then select HP Documentation.
Left side
Item Component Description
(9) Security cable slot Attaches an optional security cable to the computer.
(10) HDMI port Connects an optional video or audio device, such as a
The security cable is designed to act as a deterrent, but it may not
prevent the computer from being mishandled or stolen.
highdenition television, any compatible digital or audio
component, or a high-speed HDMI device.
(11) USB 3.0 port Connects an optional USB device, such as a keyboard, mouse,
external drive, printer, scanner or USB hub.
(12) Audio-out (headphone)/Audio-in (microphone)
jack
Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also connects an
optional headset microphone. This jack does not support optional
microphone-only devices.
WARNING! To reduce the risk of personal injury, adjust the
volume before putting on headphones, earbuds, or a headset. For
additional safety information, refer to the Regulatory, Safety, and
Environmental Notices. To access this guide:
Windows 8.1:
From the Start screen, type support, and then select the HP
Support Assistant app.
‒ or –
From the Windows desktop, click the question mark icon in the
notication area, at the far right of the taskbar.
Windows 10:
Select Start, select All apps, select HP Help and Support, and
then select HP Documentation.
NOTE: When a device is connected to the jack, the computer
speakers are disabled.
NOTE: Be sure that the device cable has a 4-conductor connector
that supports both audio-out (headphone) and audio-in
(microphone).
(13) Memory card reader Reads optional memory cards that store, manage, share, or access
6 Chapter 2 External component identication
information.
Item Component Description
To insert a card: Hold the card label-side up, with connectors
facing the slot, insert the card into the slot, and then push in on
the card until it is rmly seated.
To remove a card:
Press in on the card it until it pops out.
(14) Power light
Right side
Item Component Description
(15) SIM slot Supports a wireless subscriber identity module (SIM).
(16) USB 2.0 ports (2) Each USB 3.0 port connects an optional USB device, such as a
●
On: The computer is on.
●
Blinking: The computer is in the Sleep state, a power saving
state. The computer shuts o power to the display and other
unneeded components.
●
O: The computer is o or in Hibernation. Hibernation is a
power-saving state that uses the least amount of power.
keyboard, mouse, external drive, printer, scanner or USB hub.
Rear
(17) AC adapter light
(18) Power connector Connects an AC adapter.
Item Component Description
(19) Speakers (2) Produce sound.
●
On: The AC adapter is connected and the battery is charged.
●
O: The computer is using battery power.
Right side 7
Labels
The labels axed to the computer provide information you may need when you troubleshoot system
problems or travel internationally with the computer.
IMPORTANT: Check the following locations for the labels described in this section: the bottom of the
computer, inside the battery bay, under the service door, or on the back of the display.
●
Service label—Provides important information to identify your computer. When contacting support, you
will probably be asked for the serial number, and possibly for the product number or the model number.
Locate these numbers before you contact support.
Your service label will resemble one of the examples shown below. Refer to the illustration that most
closely matches the service label on your computer.
Component
(1) Serial number
(2) Product number
(3) Warranty period
(4) Model number (select products only)
Component
(1) Model name (select products only)
(2) Product number
(3) Serial number
(4) Warranty period
●
Regulatory label(s)—Provide(s) regulatory information about the computer.
●
Wireless certication label(s)—Provide(s) information about optional wireless devices and the approval
markings for the countries or regions in which the devices have been approved for use.
8 Chapter 2 External component identication
3 Illustrated parts catalog
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Computer major components
Computer major components 9
Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see Display assembly components – non-touch screen on page 12.
(2) TouchPad (includes cable)
For use in models without WWAN 795911-001
For use in models with WWAN 792776-001
TouchPad cable 838683-001
(3) Keyboard/top cover (includes keyboard cable):
For a list of keyboard country codes, see Keyboard/top cover on page 29 or Sequential part number listing on page 16.
Orchid magenta models (does not include touchpad) 792792-xxx
Horizon blue models (does not include touchpad) 792791-xxx
Cobalt blue models (includes touchpad) 830646-xxx
Violet purple models (includes touchpad) 830647-xxx
Horizon blue models (includes touchpad) 836872-xxx
Orchid magenta models (includes touchpad) 836873-xxx
(4) Power button board (includes cable) 792777-001
(5) Battery, 3-cell, 37-WHr, 3.25-AHr, Li-ion (includes cable) 787521-005
(6) Heat sink (includes thermal cloth)
For use in models with Bay Trail (Celeron N2840) processors 792773-001
For use in models with Braswell (Celeron N3050) processors 832476-001
(7) WLAN module:
Broadcom BCM43142 802.11 bgn 1x1 Wi-Fi + BT4.0 HMC Combo Adapter 753076-005
Realtek RT8723BE 802.11bgn 1x1 Wi-Fi + BT 4.0 Combo Adapter 753077-005
Intel Dual Band Wireless-AC 3160 802.11 ac 1×1 WiFi + Bluetooth 4.0 Combo Adapter 784638-005
Broadcom BCM43142 802.11 b/g/n 1x1 Wi-Fi + BT4.0 M.2 Combo Adapter 792608-005
Intel Dual Band Wireless-AC 3165 802.11 ac 1x1 WiFi + BT 4.0 Combo Adapter 806723-005
(8) WWAN/GPS module:
HP hs3110 HSPA+ Mobile Broadband Module 748599-005
HP hs3114 HSPA+ Mobile Broadband Module 748600-005
(9) System board (includes a graphics subsystem with UMA memory, thermal grease, and thermal pads):
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 64 GB eMMC
hard drive, and the Windows 8.1 Standard operating system
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 64 GB eMMC
hard drive, and Windows 7 or a non-Windows operating system
792786-501
792786-001
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC
hard drive, and the Windows 8.1 Professional or Windows 10 operating system
10 Chapter 3 Illustrated parts catalog
792785-601
Item Component Spare part number
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC
hard drive, and the Windows 8.1 Standard operating system
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC
hard drive, and Windows 7 or a non-Windows operating system
Equipped with an Intel Celeron N3050 processor with 2 GB system memory, 32 GB eMMC
hard drive, and the Windows 8.1 or Windows 10 operating system
Equipped with an Intel Celeron N3050 processor with 2 GB system memory, 32 GB eMMC
hard drive, and Windows 7 or a non-Windows operating system
(10) USB/card reader board (includes cable)
For use in models without WWAN 792778-001
For use in models with WWAN 792769-001
(11) Speakers (include left and right speakers and cables) 792784-001
(12) Power connector cable (includes tape) 796086-001
(13) Base enclosure
For use in blue non-touch screen models without WWAN 792763-001
For use in blue non-touch screen models with WWAN 792764-001
For use in magenta models without a touch screen and without WWAN 792765-001
For use in magenta models without a touch screen and with WWAN 792766-001
792785-501
792785-001
830639-601
830639-001
For use in magenta models with a touch screen 792770-001
For use in blue touch screen models without WWAN 798213-001
For use in horizon blue touch screen models with WWAN 798214-001
For use in cobalt blue non-touch screen models without WWAN 830642-001
For use in violet purple non-touch screen models without WWAN 830643-001
Rubber Kit (not illustrated; includes bottom screw covers and computer feet)
For use in horizon blue and orchid magenta models 792782-001
For use in cobalt blue and violet purple models 830713-001
Computer major components 11
Display assembly components – non-touch screen
Item Description Spare part number
(1) Display bezel (includes Mylar screw covers)
For use in magenta models 792768-001
For use in horizon blue models 792767-001
For use in cobalt blue models 830644-001
For use in purple models 830645-001
(2) Display bezel screw covers: The display bezel screw covers are included in all display spare part kits.
(3) Webcam/microphone module (includes Mylar screw covers) 793616-001
12 Chapter 3 Illustrated parts catalog
Item Description Spare part number
(4) Raw display panel (includes Mylar screw covers) 792779-001
(5) Display Hinge Kit (includes left and right display hinges and Mylar screw covers) 792774-001
(6) Display panel cable (includes Mylar screw covers)
For use in models without a touch screen and without WWAN 792771-001
For use in models without a touch screen and with WWAN 798215-001
(7) Antenna Kit (includes wireless antenna cable, transceiver, Mylar screw covers, and screws)
WLAN 792758-001
WWAN 792757-001
(8) Display back cover (includes screws)
For use in magenta models 792760-001
For use in horizon blue models 792761-001
For use in cobalt blue models 830640-001
For use in violet purple models 830641-001
Display assembly components – non-touch screen 13
Display assembly components – touch screen
Item Description Spare part number
(1) Display panel assembly, includes bezel and Mylar screw covers
For use in horizon blue models 792780-001
For use in orchid magenta models 792781-001
(2) Display bezel screw covers: The display bezel screw covers are included in all display spare part kits.
(3) Webcam/microphone module (includes Mylar screw covers) 792793-001
(4) Display panel cable (includes Mylar screw covers)
For use in touch screen models without WWAN 792772-001
14 Chapter 3 Illustrated parts catalog
Item Description Spare part number
For use in touch screen models with WWAN 798216-001
(5) Display Hinge Kit (includes left and right display hinges) 792775-001
(6) Antenna Kit (includes wireless antenna cable, transceiver, Mylar screw covers, and screws)
WLAN 792758-001
WWAN 792757-001
(7) Display back cover (includes Mylar screw covers and screws)
For use in horizon blue models 792759-001
For use in orchid magenta models 792762-001
Miscellaneous parts
Component Spare part number
AC adapter:
65-W HP Smart adapter (non-PFC, EM, 3-wire, 4.5-mm) 714657-001
45-W HP Smart adapter (non-PFC, RC, 3-wire, 4.5-mm) 741727-001
HP HDMI-to-VGA adapter 701943-001
RJ-45/USB adapter dongle 539614-001
HP USB external DVD±RW DL SuperMulti Drive 747080-001
Power cord (3-pin, black, 1.00-m):
For use in Australia 755530-011
For use in Denmark 755530-081
For use in Europe 755530-021
For use in India 755530-D61
For use in Israel 755530-BB1
For use in Italy 755530-061
For use in Japan 755530-291
For use in North America 755530-001
For use in the People's Republic of China 755530-AA1
For use in South Africa 755530-AR1
For use in South Korea 755530-AD1
For use in Switzerland 755530-111
For use in Taiwan 755530-AB1
For use in Thailand 755530-201
For use in the United Kingdom and Singapore 755530-031
Miscellaneous parts 15
Component Spare part number
Rubber Feet Kit (includes bottom cover screw covers and computer feet)
For use in horizon blue and orchid magenta models 792782-001
For use in cobalt blue and violet purple models 830713-001
Screw Kit 792783-001
HP 14.0 Spectrum Blue Sleeve 787585-001
HP 14.0 Spectrum Magenta Sleeve 787587-001
Sequential part number listing
Spare part
number
539614-001 RJ-45/USB adapter dongle
701943-001 HP HDMI-to-VGA adapter
714657-001 65-W HP Smart adapter (non-PFC, EM, 3-wire, 4.5-mm)
741727-001 45-W HP Smart adapter (non-PFC, RC, 3-wire, 4.5-mm)
747080-001 HP USB external DVD±RW DL SuperMulti Drive
748599-005 HP hs3110 HSPA+ Mobile Broadband Module
748600-005 HP hs3114 HSPA+ Mobile Broadband Module
753076-005 Broadcom BCM43142 802.11 bgn 1x1 Wi-Fi + Bluetooth Combo Adapter
753077-005 Realtek RT8723BE 802.11bgn 1x1 Wi-Fi + BT 4.0 Combo Adapter
755530-001 Power cord for use in North America (3-pin, black, 1.00-m)
755530-011 Power cord for use in Australia (3-pin, black, 1.00-m)
755530-021 Power cord for use in Europe (3-pin, black, 1.00-m)
755530-031 Power cord for use in the United Kingdom and Singapore (3-pin, black, 1.00-m)
755530-061 Power cord for use in Italy (3-pin, black, 1.00-m)
755530-081 Power cord for use in Denmark (3-pin, black, 1.00-m)
Description
755530-111 Power cord for use in Switzerland (3-pin, black, 1.00-m)
755530-201 Power cord for use in Thailand (3-pin, black, 1.00-m)
755530-291 Power cord for use in Japan (3-pin, black, 1.00-m)
755530-AA1 Power cord for use in the People's Republic of China (3-pin, black, 1.00-m)
755530-AB1 Power cord for use in Taiwan (3-pin, black, 1.00-m)
755530-AD1 Power cord for use in South Korea (3-pin, black, 1.00-m)
755530-AR1 Power cord for use in South Africa (3-pin, black, 1.00-m)
755530-BB1 Power cord for use in Israel (3-pin, black, 1.00-m)
755530-D61 Power cord for use in India (3-pin, black, 1.00-m)
16 Chapter 3 Illustrated parts catalog
Spare part
number
784638-005 Intel Dual Band Wireless-AC 3160 802.11 ac 1×1 WiFi + Bluetooth 4.0 Combo Adapter
787521-005 3-cell, 37-WHr, 3.25-AHr, Li-ion battery (includes cable)
792608-005 Broadcom BCM43142 802.11 b/g/n 1x1 Wi-Fi + BT4.0 M.2 Combo Adapter
792757-001 WWAN antenna Kit (includes wireless antenna cable, transceiver, Mylar screw covers, and screws)
792758-001 WLAN antenna Kit (includes wireless antenna cable, transceiver, Mylar screw covers, and screws)
792759-001 Display back cover for use in horizon blue models with a touch screen (includes Mylar screw covers and screws)
792760-001 Display back cover for use in magenta models without a touch screen (includes Mylar screw covers and screws)
792761-001 Display back cover for use in horizon blue models without a touch screen (includes Mylar screw covers and screws)
792762-001 Display back cover for use in orchid magenta models with a touch screen (includes Mylar screw covers and screws)
792763-001 Base enclosure for use in blue non-touch screen models without WWAN
792764-001 Base enclosure for use in blue non-touch screen models with WWAN
792765-001 Base enclosure for use in magenta models without a touch screen and without WWAN
792766-001 Base enclosure for use in magenta models without a touch screen and with WWAN
792767-001 Display bezel for use in horizon blue models (includes screws)
792768-001 Display bezel for use in magenta models (includes screws)
Description
792769-001 USB/card reader board for use in models with WWAN (includes cable)
792770-001 Base enclosure for use in magenta models with a touch screen
792771-001 Display panel cable for use in models without a touch screen and without WWAN (includes Mylar screw covers)
792772-001 Display panel cable for use in models with a touch screen and without WWAN (includes Mylar screw covers)
792773-001 Heat sink for use with Bay Trail (Celeron N2840) processors (includes thermal cloth)
792774-001 Display Hinge Kit for use in models without a touch screen (includes left and right display hinges and Mylar screw
covers)
792775-001 Display Hinge Kit for use in models with a touch screen (includes left and right display hinges and Mylar screw
covers)
792776-001 TouchPad for use in models with WWAN (includes cable)
792777-001 Power button board (includes cable)
792778-001 USB/card reader board for use in models without WWAN (includes cable)
792779-001 Raw display panel (13.3-in) for use in non-touch screen models (includes Mylar screw covers)
792780-001 Raw display panel (13.3-in) for use in horizon blue touch screen models (includes bezel and Mylar screw covers)
792781-001 Raw display panel (13.3-in) for use in orchid magenta touch screen models (includes bezel and Mylar screw
covers)
792782-001 Rubber Kit for use in horizon blue and orchid magenta models (includes bottom cover screw covers and computer
feet)
792783-001 Screw Kit
792784-001 Speakers (include left and right speakers and cables)
Sequential part number listing 17
Spare part
number
Description
792785-001 System board equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC hard drive,
792785-501 System board equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC hard drive,
792785-601 System board equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC hard drive,
792786-001 System board equipped with an Intel Celeron N2840 processor with 2 GB system memory, 64 GB eMMC hard drive,
792786-501 System board equipped with an Intel Celeron N2840 processor with 2 GB system memory, 64 GB eMMC hard drive,
792791-001 Keyboard/top cover (does not include touchpad) for use in horizon blue models in the United States (includes
792791-031 Keyboard/top cover (does not include touchpad) for use in horizon blue models in the United Kingdom and
792791-041 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Germany (includes keyboard
792791-051 Keyboard/top cover (does not include touchpad) for use in horizon blue models in France (includes keyboard cable)
792791-061 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Italy (includes keyboard cable)
792791-071 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Spain (includes keyboard cable)
792791-131 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Portugal (includes keyboard
and the Windows 7 or non-Windows operating systems (includes thermal grease and thermal pads)
and the Windows 8.1 Standard operating system (includes thermal grease and thermal pads)
and the Windows 8.1 Professional or Windows 10 operating system (includes thermal grease and thermal pads)
and the Windows 7 or non-Windows operating systems (includes thermal grease and thermal pads)
and the Windows 8.1 Standard operating system (includes thermal grease and thermal pads)
keyboard cable)
Singapore (includes keyboard cable)
cable)
cable)
792791-141 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Turkey (includes keyboard
cable)
792791-151 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Greece (includes keyboard
cable)
792791-161 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Latin America (includes
keyboard cable)
792791-171 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Saudi Arabia (includes keyboard
cable)
792791-211 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Hungary (includes keyboard
cable)
792791-251 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Russia (includes keyboard cable)
792791-261 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Bulgaria (includes keyboard
cable)
792791-271 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Romania (includes keyboard
cable)
792791-281 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Thailand (includes keyboard
cable)
792791-291 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Japan (includes keyboard cable)
792791-A41 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Belgium (includes keyboard
cable)
18 Chapter 3 Illustrated parts catalog
Spare part
number
Description
792791-AB1 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Taiwan (includes keyboard
792791-AD1 Keyboard/top cover (does not include touchpad) for use in horizon blue models in South Korea (includes keyboard
792791-B31 Keyboard/top cover (does not include touchpad) for use in horizon blue models internationally (includes keyboard
792791-BA1 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Slovenia (includes keyboard
792791-BB1 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Israel (includes keyboard cable)
792791-BG1 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Switzerland (includes keyboard
792791-DB1 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Canada (includes keyboard
792791-DH1 Keyboard/top cover (does not include touchpad) for use in horizon blue models in Denmark, Finland, and Norway
792791-FL1 Keyboard/top cover (does not include touchpad) for use in horizon blue models in the Czech Republic and Slovakia
792792-001 Keyboard/top cover for use in magenta models in the United States (includes keyboard cable)
792792-031 Keyboard/top cover for use in magenta models in the United Kingdom and Singapore (includes keyboard cable)
792792-041 Keyboard/top cover for use in magenta models in Germany (includes keyboard cable)
cable)
cable)
cable)
cable)
cable)
cable)
(includes keyboard cable)
(includes keyboard cable)
792792-051 Keyboard/top cover for use in magenta models in France (includes keyboard cable)
792792-061 Keyboard/top cover for use in magenta models in Italy (includes keyboard cable)
792792-071 Keyboard/top cover for use in magenta models in Spain (includes keyboard cable)
792792-131 Keyboard/top cover for use in magenta models in Portugal (includes keyboard cable)
792792-141 Keyboard/top cover for use in magenta models in Turkey (includes keyboard cable)
792792-151 Keyboard/top cover for use in magenta models in Greece (includes keyboard cable)
792792-161 Keyboard/top cover for use in magenta models in Latin America (includes keyboard cable)
792792-171 Keyboard/top cover for use in magenta models in Saudi Arabia (includes keyboard cable)
792792-211 Keyboard/top cover for use in magenta models in Hungary (includes keyboard cable)
792792-251 Keyboard/top cover for use in magenta models in Russia (includes keyboard cable)
792792-261 Keyboard/top cover for use in magenta models in Bulgaria (includes keyboard cable)
792792-271 Keyboard/top cover for use in magenta models in Romania (includes keyboard cable)
792792-281 Keyboard/top cover for use in magenta models in Thailand (includes keyboard cable)
792792-291 Keyboard/top cover for use in magenta models in Japan (includes keyboard cable)
792792-A41 Keyboard/top cover for use in magenta models in Belgium (includes keyboard cable)
792792-AB1 Keyboard/top cover for use in magenta models in Taiwan (includes keyboard cable)
792792-AD1 Keyboard/top cover for use in magenta models in South Korea (includes keyboard cable)
Sequential part number listing 19
Spare part
number
792792-B31 Keyboard/top cover for use in magenta models internationally (includes keyboard cable)
792792-BA1 Keyboard/top cover for use in magenta models in Slovenia (includes keyboard cable)
792792-BB1 Keyboard/top cover for use in magenta models in Israel (includes keyboard cable)
792792-BG1 Keyboard/top cover for use in magenta models in Switzerland (includes keyboard cable)
792792-DB1 Keyboard/top cover for use in magenta models in Canada (includes keyboard cable)
792792-DH1 Keyboard/top cover for use in magenta models in Denmark, Finland, and Norway (includes keyboard cable)
792792-FL1 Keyboard/top cover for use in magenta models in the Czech Republic and Slovakia (includes keyboard cable)
792793-001 Webcam/microphone module for use in models with a touch screen (includes Mylar screw covers)
793616-001 Webcam/microphone module for use in models without a touch screen (includes Mylar screw covers)
795911-001 TouchPad for use in models without WWAN (includes cable)
796086-001 Power connector cable (includes tape)
797585-001 HP 14.0 Spectrum Blue Sleeve
797587-001 HP 14.0 Spectrum Magenta Sleeve
798213-001 Base enclosure for use in blue touch screen models without WWAN
798214-001 Base enclosure for use in blue touch screen models with WWAN
Description
798215-001 Display panel cable for use in models without a touch screen and with WWAN (includes Mylar screw covers)
798216-001 Display panel cable for use in models with a touch screen and with WWAN (includes Mylar screw covers)
806723-005 Intel Dual Band Wireless-AC 3165 802.11 ac 1x1 WiFi + BT 4.0 Combo Adapter
830639-001 System board equipped with an Intel Celeron N3050 processor with 2 GB system memory, 32 GB eMMC hard drive,
and the Windows 7 or a non-Windows 10 operating system (includes thermal grease and thermal pads)
830639-601 System board equipped with an Intel Celeron N3050 processor with 2 GB system memory, 32 GB eMMC hard drive,
and the Windows 8.1 or Windows 10 operating system (includes thermal grease and thermal pads)
830640-001 Display back cover for use in cobalt blue models without a touch screen (includes Mylar screw covers and screws)
830641-001 Display back cover for use in violet purple models without a touch screen (includes Mylar screw covers and screws)
830642-001 Base enclosure for use in cobalt blue non-touch screen models without WWAN
830643-001 Base enclosure for use in violet purple non-touch screen models without WWAN
830644-001 Display bezel for use in cobalt blue models (includes screws)
830645-001 Display bezel for use in purple models (includes screws)
830646-001 Keyboard/top cover with touchpad for use in cobalt blue models in the United States (includes keyboard cable)
830646-031 Keyboard/top cover with touchpad for use in cobalt blue models in the United Kingdom and Singapore (includes
keyboard cable)
830646-041 Keyboard/top cover with touchpad for use in cobalt blue models in Germany (includes keyboard cable)
830646-051 Keyboard/top cover with touchpad for use in cobalt blue models in France (includes keyboard cable)
830646-061 Keyboard/top cover with touchpad for use in cobalt blue models in Italy (includes keyboard cable)
830646-071 Keyboard/top cover with touchpad for use in cobalt blue models in Spain (includes keyboard cable)
20 Chapter 3 Illustrated parts catalog
Spare part
number
830646-131 Keyboard/top cover with touchpad for use in cobalt blue models in Portugal (includes keyboard cable)
830646-141 Keyboard/top cover with touchpad for use in cobalt blue models in Turkey (includes keyboard cable)
830646-151 Keyboard/top cover with touchpad for use in cobalt blue models in Greece (includes keyboard cable)
830646-161 Keyboard/top cover with touchpad for use in cobalt blue models in Latin America (includes keyboard cable)
830646-171 Keyboard/top cover with touchpad for use in cobalt blue models in Saudi Arabia (includes keyboard cable)
830646-211 Keyboard/top cover with touchpad for use in cobalt blue models in Hungary (includes keyboard cable)
830646-251 Keyboard/top cover with touchpad for use in cobalt blue models in Russia (includes keyboard cable)
830646-261 Keyboard/top cover with touchpad for use in cobalt blue models in Bulgaria (includes keyboard cable)
830646-271 Keyboard/top cover with touchpad for use in cobalt blue models in Romania (includes keyboard cable)
830646-281 Keyboard/top cover with touchpad for use in cobalt blue models in Thailand (includes keyboard cable)
830646-291 Keyboard/top cover with touchpad for use in cobalt blue models in Japan (includes keyboard cable)
830646-A41 Keyboard/top cover with touchpad for use in cobalt blue models in Belgium (includes keyboard cable)
830646-AB1 Keyboard/top cover with touchpad for use in cobalt blue models in Taiwan (includes keyboard cable)
830646-AD1 Keyboard/top cover with touchpad for use in cobalt blue models in South Korea (includes keyboard cable)
830646-B31 Keyboard/top cover with touchpad for use in cobalt blue models internationally (includes keyboard cable)
Description
830646-BA1 Keyboard/top cover with touchpad for use in cobalt blue models in Slovenia (includes keyboard cable)
830646-BB1 Keyboard/top cover with touchpad for use in cobalt blue models in Israel (includes keyboard cable)
830646-BG1 Keyboard/top cover with touchpad for use in cobalt blue models in Switzerland (includes keyboard cable)
830646-DB1 Keyboard/top cover with touchpad for use in cobalt blue models in Canada (includes keyboard cable)
830646-DH1 Keyboard/top cover with touchpad for use in cobalt blue models in Denmark, Finland, and Norway (includes
keyboard cable)
830646-FL1 Keyboard/top cover with touchpad for use in cobalt blue models in the Czech Republic and Slovakia (includes
keyboard cable)
830647-001 Keyboard/top cover with touchpad for use in purple models in the United States (includes keyboard cable)
830647-031 Keyboard/top cover with touchpad for use in purple models in the United Kingdom and Singapore (includes
keyboard cable)
830647-041 Keyboard/top cover with touchpad for use in purple models in Germany (includes keyboard cable)
830647-051 Keyboard/top cover with touchpad for use in purple models in France (includes keyboard cable)
830647-061 Keyboard/top cover with touchpad for use in purple models in Italy (includes keyboard cable)
830647-071 Keyboard/top cover with touchpad for use in purple models in Spain (includes keyboard cable)
830647-131 Keyboard/top cover with touchpad for use in purple models in Portugal (includes keyboard cable)
830647-141 Keyboard/top cover with touchpad for use in purple models in Turkey (includes keyboard cable)
830647-151 Keyboard/top cover with touchpad for use in purple models in Greece (includes keyboard cable)
830647-161 Keyboard/top cover with touchpad for use in purple models in Latin America (includes keyboard cable)
830647-171 Keyboard/top cover with touchpad for use in purple models in Saudi Arabia (includes keyboard cable)
Sequential part number listing 21
Spare part
number
830647-211 Keyboard/top cover with touchpad for use in purple models in Hungary (includes keyboard cable)
830647-251 Keyboard/top cover with touchpad for use in purple models in Russia (includes keyboard cable)
830647-261 Keyboard/top cover with touchpad for use in purple models in Bulgaria (includes keyboard cable)
830647-271 Keyboard/top cover with touchpad for use in purple models in Romania (includes keyboard cable)
830647-281 Keyboard/top cover with touchpad for use in purple models in Thailand (includes keyboard cable)
830647-291 Keyboard/top cover with touchpad for use in purple models in Japan (includes keyboard cable)
830647-A41 Keyboard/top cover with touchpad for use in purple models in Belgium (includes keyboard cable)
830647-AB1 Keyboard/top cover with touchpad for use in purple models in Taiwan (includes keyboard cable)
830647-AD1 Keyboard/top cover with touchpad for use in purple models in South Korea (includes keyboard cable)
830647-B31 Keyboard/top cover with touchpad for use in purple models internationally (includes keyboard cable)
830647-BA1 Keyboard/top cover with touchpad for use in purple models in Slovenia (includes keyboard cable)
830647-BB1 Keyboard/top cover with touchpad for use in purple models in Israel (includes keyboard cable)
830647-BG1 Keyboard/top cover with touchpad for use in purple models in Switzerland (includes keyboard cable)
830647-DB1 Keyboard/top cover with touchpad for use in purple models in Canada (includes keyboard cable)
830647-DH1 Keyboard/top cover with touchpad for use in purple models in Denmark, Finland, and Norway (includes keyboard
Description
cable)
830647-FL1 Keyboard/top cover with touchpad for use in purple models in the Czech Republic and Slovakia (includes keyboard
cable)
830713-001 Rubber Kit for use in cobalt blue and violet purple models
832476-001 Heat sink for use with Braswell (Celeron N3050) processors (includes thermal cloth)
836872-001 Keyboard/top cover with touchpad for use in horizon blue models in the United States (includes keyboard cable)
836872-031 Keyboard/top cover with touchpad for use in horizon blue models in the United Kingdom and Singapore (includes
keyboard cable)
836872-041 Keyboard/top cover with touchpad for use in horizon blue models in Germany (includes keyboard cable)
836872-051 Keyboard/top cover with touchpad for use in horizon blue models in France (includes keyboard cable)
836872-061 Keyboard/top cover with touchpad for use in horizon blue models in Italy (includes keyboard cable)
836872-071 Keyboard/top cover with touchpad for use in horizon blue models in Spain (includes keyboard cable)
836872-131 Keyboard/top cover with touchpad for use in horizon blue models in Portugal (includes keyboard cable)
836872-141 Keyboard/top cover with touchpad for use in horizon blue models in Turkey (includes keyboard cable)
836872-151 Keyboard/top cover with touchpad for use in horizon blue models in Greece (includes keyboard cable)
836872-161 Keyboard/top cover with touchpad for use in horizon blue models in Latin America (includes keyboard cable)
836872-171 Keyboard/top cover with touchpad for use in horizon blue models in Saudi Arabia (includes keyboard cable)
836872-211 Keyboard/top cover with touchpad for use in horizon blue models in Hungary (includes keyboard cable)
836872-251 Keyboard/top cover with touchpad for use in horizon blue models in Russia (includes keyboard cable)
836872-261 Keyboard/top cover with touchpad for use in horizon blue models in Bulgaria (includes keyboard cable)
22 Chapter 3 Illustrated parts catalog
Spare part
number
836872-271 Keyboard/top cover with touchpad for use in horizon blue models in Romania (includes keyboard cable)
836872-281 Keyboard/top cover with touchpad for use in horizon blue models in Thailand (includes keyboard cable)
836872-291 Keyboard/top cover with touchpad for use in horizon blue models in Japan (includes keyboard cable)
836872-A41 Keyboard/top cover with touchpad for use in horizon blue models in Belgium (includes keyboard cable)
836872-AB1 Keyboard/top cover with touchpad for use in horizon blue models in Taiwan (includes keyboard cable)
836872-AD1 Keyboard/top cover with touchpad for use in horizon blue models in South Korea (includes keyboard cable)
836872-B31 Keyboard/top cover with touchpad for use in horizon blue models internationally (includes keyboard cable)
836872-BA1 Keyboard/top cover with touchpad for use in horizon blue models in Slovenia (includes keyboard cable)
836872-BB1 Keyboard/top cover with touchpad for use in horizon blue models in Israel (includes keyboard cable)
836872-BG1 Keyboard/top cover with touchpad for use in horizon blue models in Switzerland (includes keyboard cable)
836872-DB1 Keyboard/top cover with touchpad for use in horizon blue models in Canada (includes keyboard cable)
836872-DH1 Keyboard/top cover with touchpad for use in horizon blue models in Denmark, Finland, and Norway (includes
836872-FL1 Keyboard/top cover with touchpad for use in horizon blue models in the Czech Republic and Slovakia (includes
836873-001 Keyboard/top cover with touchpad for use in orchid magenta models in the United States (includes keyboard
Description
keyboard cable)
keyboard cable)
cable)
836873-031 Keyboard/top cover with touchpad for use in orchid magenta models in the United Kingdom and Singapore
(includes keyboard cable)
836873-041 Keyboard/top cover with touchpad for use in orchid magenta models in Germany (includes keyboard cable)
836873-051 Keyboard/top cover with touchpad for use in orchid magenta models in France (includes keyboard cable)
836873-061 Keyboard/top cover with touchpad for use in orchid magenta models in Italy (includes keyboard cable)
836873-071 Keyboard/top cover with touchpad for use in orchid magenta models in Spain (includes keyboard cable)
836873-131 Keyboard/top cover with touchpad for use in orchid magenta models in Portugal (includes keyboard cable)
836873-141 Keyboard/top cover with touchpad for use in orchid magenta models in Turkey (includes keyboard cable)
836873-151 Keyboard/top cover with touchpad for use in orchid magenta models in Greece (includes keyboard cable)
836873-161 Keyboard/top cover with touchpad for use in orchid magenta models in Latin America (includes keyboard cable)
836873-171 Keyboard/top cover with touchpad for use in orchid magenta models in Saudi Arabia (includes keyboard cable)
836873-211 Keyboard/top cover with touchpad for use in orchid magenta models in Hungary (includes keyboard cable)
836873-251 Keyboard/top cover with touchpad for use in orchid magenta models in Russia (includes keyboard cable)
836873-261 Keyboard/top cover with touchpad for use in orchid magenta models in Bulgaria (includes keyboard cable)
836873-271 Keyboard/top cover with touchpad for use in orchid magenta models in Romania (includes keyboard cable)
836873-281 Keyboard/top cover with touchpad for use in orchid magenta models in Thailand (includes keyboard cable)
836873-291 Keyboard/top cover with touchpad for use in orchid magenta models in Japan (includes keyboard cable)
836873-A41 Keyboard/top cover with touchpad for use in orchid magenta models in Belgium (includes keyboard cable)
Sequential part number listing 23
Spare part
number
836873-AB1 Keyboard/top cover with touchpad for use in orchid magenta models in Taiwan (includes keyboard cable)
836873-AD1 Keyboard/top cover with touchpad for use in orchid magenta models in South Korea (includes keyboard cable)
836873-B31 Keyboard/top cover with touchpad for use in orchid magenta models internationally (includes keyboard cable)
836873-BA1 Keyboard/top cover with touchpad for use in orchid magenta models in Slovenia (includes keyboard cable)
836873-BB1 Keyboard/top cover with touchpad for use in orchid magenta models in Israel (includes keyboard cable)
836873-BG1 Keyboard/top cover with touchpad for use in orchid magenta models in Switzerland (includes keyboard cable)
836873-DB1 Keyboard/top cover with touchpad for use in orchid magenta models in Canada (includes keyboard cable)
836873-DH1 Keyboard/top cover with touchpad for use in orchid magenta models in Denmark, Finland, and Norway (includes
836873-FL1 Keyboard/top cover with touchpad for use in orchid magenta models in the Czech Republic and Slovakia (includes
838683-001 TouchPad cable
Description
keyboard cable)
keyboard cable)
24 Chapter 3 Illustrated parts catalog
4 Removal and replacement procedures
preliminary requirements
Tools required
You will need the following tools to complete the removal and replacement procedures:
●
Flat-bladed screw driver
●
Magnetic screw driver
●
Phillips P0 screw driver
Service considerations
The following sections include some of the considerations that you must keep in mind during disassembly
and assembly procedures.
NOTE: As you remove each subassembly from the tablet, place the subassembly (and all accompanying
screws) away from the work area to prevent damage.
Plastic parts
CAUTION: Using excessive force during disassembly and reassembly can damage plastic parts. Use care
when handling the plastic parts. Apply pressure only at the points designated in the
maintenance instructions.
Cables and connectors
CAUTION: When servicing the tablet, be sure that cables are placed in their proper locations during the
reassembly process. Improper cable placement can damage the tablet.
Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat
the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases, avoid
bending, twisting, or tearing cables. Be sure that cables are routed in such a way that they cannot be caught
or snagged by parts being removed or replaced. Handle ex cables with extreme care; these cables tear
easily.
Tools required 25
Grounding guidelines
Electrostatic discharge damage
Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine
the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many
cases, ESD contains enough power to alter device parameters or melt silicon junctions.
A discharge of static electricity from a nger or other conductor can destroy static-sensitive devices or
microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.
An electronic device exposed to ESD may not be aected at all and can work perfectly throughout a normal
cycle. Or the device may function normally for a while, then degrade in the internal layers, reducing its life
expectancy.
CAUTION: To prevent damage to the tablet when you are removing or installing internal components,
observe these precautions:
Keep components in their electrostatic-safe containers until you are ready to install them.
Before touching an electronic component, discharge static electricity by using the guidelines described in this
section.
Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.
If you remove a component, place it in an electrostatic-safe container.
The following table shows how humidity aects the electrostatic voltage levels generated by
dierent activities.
CAUTION: A product can be degraded by as little as 700 V.
Typical electrostatic voltage levels
Relative humidity
Event 10% 40% 55%
Walking across carpet 35,000 V 15,000 V 7,500 V
Walking across vinyl oor 12,000 V 5,000 V 3,000 V
Motions of bench worker 6,000 V 800 V 400 V
Removing DIPS from plastic tube 2,000 V 700 V 400 V
Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V
Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V
Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V
Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V
26 Chapter 4 Removal and replacement procedures preliminary requirements
Packaging and transporting guidelines
Follow these grounding guidelines when packaging and transporting equipment:
●
To avoid hand contact, transport products in static-safe tubes, bags, or boxes.
●
Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging.
●
Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.
●
Place items on a grounded surface before removing items from their containers.
●
Always be properly grounded when touching a component or assembly.
●
Store reusable ESD-sensitive parts from assemblies in protective packaging or nonconductive foam.
●
Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that mechanized
equipment used for moving materials is wired to ground and that proper materials are selected to avoid
static charging. When grounding is not possible, use an ionizer to dissipate electric charges.
Workstation guidelines
Follow these grounding workstation guidelines:
●
Cover the workstation with approved static-shielding material.
●
Use a wrist strap connected to a properly grounded work surface and use properly grounded tools and
equipment.
●
Use conductive eld service tools, such as cutters, screw drivers, and vacuums.
●
When xtures must directly contact dissipative surfaces, use xtures made only of static-safe materials.
●
Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids
and Styrofoam.
●
Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle these
items only at static-free workstations.
●
Avoid contact with pins, leads, or circuitry.
●
Turn o power and input signals before inserting or removing connectors or test equipment.
Grounding guidelines 27
Equipment guidelines
Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.
●
When seated, wear a wrist strap connected to a grounded system. Wrist straps are exible straps with a
minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap
snugly against the skin at all times. On grounded mats with banana-plug connectors, use alligator clips
to connect a wrist strap.
●
When standing, use foot straps and a grounded oor mat. Foot straps (heel, toe, or boot straps) can be
used at standing workstations and are compatible with most types of shoes or boots. On conductive
oors or dissipative oor mats, use foot straps on both feet with a minimum of one megohm resistance
between the operator and ground. To be
The following grounding equipment is recommended to prevent electrostatic damage:
●
Antistatic tape
●
Antistatic smocks, aprons, and sleeve protectors
●
Conductive bins and other assembly or soldering aids
●
Nonconductive foam
●
Conductive tabletop workstations with ground cords of one megohm resistance
●
Static-dissipative tables or oor mats with hard ties to the ground
●
Field service kits
eective, the conductive must be worn in contact with the skin.
●
Static awareness labels
●
Material-handling packages
●
Nonconductive plastic bags, tubes, or boxes
●
Metal tote boxes
●
Electrostatic voltage levels and protective materials
The following table lists the shielding protection provided by antistatic bags and oor mats.
Material Use Voltage protection level
Antistatic plastics Bags 1,500 V
Carbon-loaded plastic Floor mats 7,500 V
Metallized laminate Floor mats 5,000 V
28 Chapter 4 Removal and replacement procedures preliminary requirements
5 Removal and replacement procedures for
Authorized Service Provider parts
NOTE: Components described in this chapter should only be accessed by an authorized service provider.
Accessing these parts can damage the computer or void the warranty.
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service tag at the bottom of your computer. See Labels on page 8 for details.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Component replacement procedures
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
There are as many as 52 screws that must be removed, replaced, and/or loosened when servicing the
computer. Make special note of each screw size and location during removal and replacement.
Keyboard/top cover
For use in country or region Spare part number For use in country or region Spare part number
Does not include touchpad; for use in magenta models:
For use in Belgium 792792-A41 For use in Portugal 792792-131
For use in Bulgaria 792792-261 For use in Romania 792792-271
For use in Canada 792792-DB1 For use in Russia 792792-251
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 792792-051 For use in South Korea 792792-AD1
For use in Germany 792792-041 For use in Spain 792792-071
For use in Greece 792792-151 For use in Switzerland 792792-BG1
For use in Hungary 792792-211 For use in Taiwan 792792-AD1
For use in Israel 792792-BB1 For use in Thailand 792792-281
For use in Italy 792792-061 For use in Turkey 792792-141
For use in Latin America 792792-161 For use in the United Kingdom
For use in Japan 792792-291 For use in the United States 792792-001
792792-FL1 For use in Saudi Arabia 792792-171
792792-DH1 For use in Slovenia 792792-BA1
792792-031
and Singapore
For use in the Netherlands 792792-B31
Component replacement procedures 29
For use in country or region Spare part number For use in country or region Spare part number
Includes touchpad; for use in orchid magenta models:
For use in Belgium 836873-A41 For use in Portugal 836873-131
For use in Bulgaria 836873-261 For use in Romania 836873-271
For use in Canada 836873-DB1 For use in Russia 836873-251
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 836873-051 For use in South Korea 836873-AD1
For use in Germany 836873-041 For use in Spain 836873-071
For use in Greece 836873-151 For use in Switzerland 836873-BG1
For use in Hungary 836873-211 For use in Taiwan 836873-AD1
For use in Israel 836873-BB1 For use in Thailand 836873-281
For use in Italy 836873-061 For use in Turkey 836873-141
For use in Latin America 836873-161 For use in the United Kingdom
For use in Japan 836873-291 For use in the United States 836873-001
For use in the Netherlands 836873-B31
For use in Belgium 792791-A41 For use in Portugal 792791-131
For use in Bulgaria 792791-261 For use in Romania 792791-271
For use in Canada 792791-DB1 For use in Russia 792791-251
836873-FL1 For use in Saudi Arabia 836873-171
836873-DH1 For use in Slovenia 836873-BA1
836873-031
and Singapore
Does not include touchpad; for use in horizon blue models:
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 792791-051 For use in South Korea 792791-AD1
For use in Germany 792791-041 For use in Spain 792791-071
For use in Greece 792791-151 For use in Switzerland 792791-BG1
For use in Hungary 792791-211 For use in Taiwan 792791-AD1
For use in Israel 792791-BB1 For use in Thailand 792791-281
For use in Italy 792791-061 For use in Turkey 792791-141
For use in Latin America 792791-161 For use in the United Kingdom
For use in Japan 792791-291 For use in the United States 792791-001
For use in the Netherlands 792791-B31
792791-FL1 For use in Saudi Arabia 792791-171
792791-DH1 For use in Slovenia 792791-BA1
and Singapore
30 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
792791-031
For use in country or region Spare part number For use in country or region Spare part number
Includes touchpad; for use in horizon blue models:
For use in Belgium 836872-A41 For use in Portugal 836872-131
For use in Bulgaria 836872-261 For use in Romania 836872-271
For use in Canada 836872-DB1 For use in Russia 836872-251
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 836872-051 For use in South Korea 836872-AD1
For use in Germany 836872-041 For use in Spain 836872-071
For use in Greece 836872-151 For use in Switzerland 836872-BG1
For use in Hungary 836872-211 For use in Taiwan 836872-AD1
For use in Israel 836872-BB1 For use in Thailand 836872-281
For use in Italy 836872-061 For use in Turkey 836872-141
For use in Latin America 836872-161 For use in the United Kingdom
For use in Japan 836872-291 For use in the United States 836872-001
For use in the Netherlands 836872-B31
For use in Belgium 830646-A41 For use in Portugal 830646-131
For use in Bulgaria 830646-261 For use in Romania 830646-271
For use in Canada 830646-DB1 For use in Russia 830646-251
836872-FL1 For use in Saudi Arabia 836872-171
836872-DH1 For use in Slovenia 836872-BA1
836872-031
and Singapore
Includes touchpad; for use in cobalt blue models:
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 830646-051 For use in South Korea 830646-AD1
For use in Germany 830646-041 For use in Spain 830646-071
For use in Greece 830646-151 For use in Switzerland 830646-BG1
For use in Hungary 830646-211 For use in Taiwan 830646-AD1
For use in Israel 830646-BB1 For use in Thailand 830646-281
For use in Italy 830646-061 For use in Turkey 830646-141
For use in Latin America 830646-161 For use in the United Kingdom
For use in Japan 830646-291 For use in the United States 830646-001
For use in the Netherlands 830646-B31
830646-FL1 For use in Saudi Arabia 830646-171
830646-DH1 For use in Slovenia 830646-BA1
830646-031
and Singapore
Component replacement procedures 31
For use in country or region Spare part number For use in country or region Spare part number
Includes touchpad; for use in violet purple models:
For use in Belgium 830647-A41 For use in Portugal 830647-131
For use in Bulgaria 830647-261 For use in Romania 830647-271
For use in Canada 830647-DB1 For use in Russia 830647-251
For use in the Czech Republic
and Slovakia
For use in Denmark, Finland,
and Norway
For use in France 830647-051 For use in South Korea 830647-AD1
For use in Germany 830647-041 For use in Spain 830647-071
For use in Greece 830647-151 For use in Switzerland 830647-BG1
For use in Hungary 830647-211 For use in Taiwan 830647-AD1
For use in Israel 830647-BB1 For use in Thailand 830647-281
For use in Italy 830647-061 For use in Turkey 830647-141
For use in Latin America 830647-161 For use in the United Kingdom
For use in Japan 830647-291 For use in the United States 830647-001
For use in the Netherlands 830647-B31
830647-FL1 For use in Saudi Arabia 830647-171
830647-DH1 For use in Slovenia 830647-BA1
830647-031
and Singapore
Before removing the disassembling, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
NOTE: When replacing the keyboard/top cover, be sure that the TouchPad assembly (see TouchPad
on page 35) and power button board (see Power button board on page 36) are removed from the
defective keyboard/top cover and installed on the replacement keyboard/top cover:
Remove the keyboard/top cover:
1. Close the computer.
2. Turn the computer upside down with the front toward you.
3. Remove the four larger computer feet (1) from the corners of the computer bottom.
4. Remove the two smaller computer rear feet (2) from near the rear corners of the computer bottom.
32 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
5. Remove one screw cover (3) from the middle rear of the computer bottom.
The screw covers and the computer rear feet are included in the Rubber Kit, spare part number
792782-001 for horizon blue and orchid magenta models or 830713-001 for cobalt blue and violet
purple models.
6. Remove the 13 Phillips PM2.5×6.0 screws that secure the keyboard/top cover to the bottom cover.
7. Turn the computer right side up, with the front toward you.
8. Open the computer.
CAUTION: Do not completely separate the keyboard/top cover from the bottom cover in the next step.
There are ribbon cables connecting the keyboard/top cover to the system board that can be damaged if
too much separation is achieved.
9. Lift the front edge (1) of the keyboard/top cover until it (2) separates from the bottom cover.
Component replacement procedures 33
10. Disconnect the following cables from the system board:
(3): Battery cable
(4): Touchpad cable
(5): Keyboard cable
(6): Power button board cable
11. Remove the keyboard/top cover from the computer (7).
Reverse this procedure to install the keyboard/top cover.
34 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
TouchPad
Before removing the TouchPad, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
Remove the TouchPad:
1. Position the keyboard/top cover upside down with the front toward you.
2. Remove the two Philllips PM2.0×2.0 broad head screws (1) that secure the TouchPad to the
Description Spare part number
TouchPad for use in models without WWAN (includes cable) 795911-001
TouchPad for use in models with WWAN (includes cable) 792776-001
TouchPad cable 838683-001
computer on, and then shut it down through the operating system.
keyboard/top cover.
NOTE: When removing the TouchPad, make sure the cable is released through the opening in the
keyboard/top cover.
3. Remove the TouchPad and cable (2) by releasing them downward (3) from the top surface of the
keyboard/top cover.
Reverse this procedure to install the TouchPad.
Component replacement procedures 35
Power button board
Description Spare part number
Power button board (includes cable) 792777-001
Before removing the power button board, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
Remove the power button board:
1. Position the keyboard/top cover upside down.
2. Remove the PM2.0×2.0 broad head screw (1) that secures the power button board to the keyboard/
top cover.
3. Lift the board to disengage it from the posts built into the top cover (2) and then remove the board (3).
Reverse this procedure to install the power button board.
36 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
WLAN module
Description Spare part number
Broadcom BCM43142 802.11 bgn 1x1 Wi-Fi + BT4.0 HMC Combo Adapter 753076-005
Realtek RT8723BE 802.11bgn 1x1 Wi-Fi + BT 4.0 Combo Adapter 753077-005
Intel Dual Band Wireless-AC 3160 802.11 ac 1×1 WiFi + Bluetooth 4.0 Combo Adapter 784638-005
Broadcom BCM43142 802.11 b/g/n 1x1 Wi-Fi + BT4.0 M.2 Combo Adapter 792608-005
Intel Dual Band Wireless-AC 3165 802.11 ac 1x1 WiFi + BT 4.0 Combo Adapter 806723-005
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless module
authorized for use in the computer by the governmental agency that regulates wireless devices in your
country or region. If you replace the module and then receive a warning message, remove the module to
restore device functionality, and then contact technical support.
Before removing the WLAN module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29). Make sure the battery cable is
disconnected from the system board.
Remove the WLAN module:
1. Disconnect the WLAN antenna cables (1) from the terminal on the WLAN module.
NOTE: The 1/black WLAN antenna cable is connected to the WLAN module 1/Main terminal.
Either one or two antennas may be connected to the module.
2. Remove the Phillips PM2.0×3.0 screw (2) that secures the WLAN module to the computer. (The WLAN
module tilts up.)
Component replacement procedures 37
3. Remove the WLAN module (3) by pulling the module away from the slot at an angle.
NOTE: If the WLAN antenna is not connected to the terminal on the WLAN module, a protective sleeve must
be installed on the antenna connector, as shown in the following illustration.
Reverse this procedure to install the WLAN module.
38 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
WWAN/GPS module
Description Spare part number
HP hs3110 HSPA+ Mobile Broadband Module 748599-005
HP hs3114 HSPA+ Mobile Broadband Module 748600-005
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless module
authorized for use in the computer by the governmental agency that regulates wireless devices in your
country or region. If you replace the module and then receive a warning message, remove the module to
restore device functionality, and then contact technical support.
Before removing the WWAN module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29). Make sure the battery cable is
disconnected from the system board.
Remove the WWAN module:
1. Disconnect the antenna cables (1) from the terminals on the WWAN module.
2. Remove the Phillips PM2.0×3.0 screw (2) that secures the WLAN module to the computer.
Component replacement procedures 39
3. Remove the WWAN module (3) by pulling the module away from the slot at an angle.
NOTE: If the WLAN antenna is not connected to the terminal on the WWAN module, a protective sleeve must
be installed on the antenna connector, as shown in the following illustration.
Reverse this procedure to install the WWAN module.
40 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
Battery
Description Spare part number
Battery, 3-cell, 37-WHr, 3.25-AHr, Li-ion (includes cable) 787521-005
Before removing the battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
Remove the battery:
1. Remove the eight PM2.0×3.0 screws (1) that secure the battery to the bottom cover.
2. Lift the battery from the computer (2).
Reverse this procedure to install the battery.
Component replacement procedures 41
USB/card reader board
Description Spare part number
USB/card reader board for use in models without WWAN (includes cable) 792778-001
USB/card reader board for use in models with WWAN (includes cable) 792769-001
Before removing the USB/card reader board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
5. Remove the battery (see Battery on page 41).
6. Remove the WWAN/GPS module (see WWAN/GPS module on page 39).
Remove the USB/card reader board:
1. Disconnect the cable from the system board (1).
2. Remove the three Phillips PM2.0×3.0 screws (2) that secure the USB/card reader board to the computer.
3. Rotate left side of board up and pull it toward the left to remove it from connectors, and then remove
the board from the computer (3).
Reverse this procedure to install the USB/card reader board.
42 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
Speakers
Before removing the speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
5. Remove the battery (see Battery on page 41).
Remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. Remove the two Phillips PM2.0×3.0 screws (2) that secure the speakers to the bottom cover.
3. Lift the speakers from the computer (3).
Description Spare part number
Speakers (include left and right speakers and cables) 792784-001
computer on, and then shut it down through the operating system.
unplugging the AC adapter from the computer.
Reverse this procedure to install the speakers.
Component replacement procedures 43
Heat sink
Before removing the heat sink, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
5. Remove the battery (see Battery on page 41).
Remove the heat sink:
1. Remove the two Phillips PM2.0×2.0 screws (1) that secure the heat sink to the system board.
2. Lift the heat sink o the system board (2).
Description Spare part number
Heat sink for use with Bay Trail (Celeron N2840) processors (includes thermal cloth) 792773-001
Heat sink for use with Braswell (Celeron N3050) processors (includes thermal cloth) 832476-001
computer on, and then shut it down through the operating system.
unplugging the AC adapter from the computer.
NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink and the system
board each time the heat sink is removed. Thermal material is used on the processor (1) and the heat sink
section (2) that services it.
44 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
Reverse this procedure to install the heat sink.
Component replacement procedures 45
System board
Description Spare part number
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 64 GB eMMC hard drive, and
the Windows 8.1 Standard operating system (includes thermal grease and thermal pads)
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 64 GB eMMC hard drive, and
Windows 7 or a non-Windows operating system (includes thermal grease and thermal pads)
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC hard drive, and
the Windows 8.1 Professional or Windows 10 operating system (includes thermal grease and thermal
pads)
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC hard drive, and
the Windows 8.1 Standard operating system (includes thermal grease and thermal pads)
Equipped with an Intel Celeron N2840 processor with 2 GB system memory, 32 GB eMMC hard drive, and
Windows 7 or a non-Windows 8.1 operating system (includes thermal grease and thermal pads)
Equipped with an Intel Celeron N3050 processor with 2 GB system memory, 32 GB eMMC hard drive, and
the Windows 8.1 or Windows 10 operating system (includes thermal grease and thermal pads)
Equipped with an Intel Celeron N3050 processor with 2 GB system memory, 32 GB eMMC hard drive, and
Windows 7 or a non-Windows operating system (includes thermal grease and thermal pads)
792786-501
792786-001
792785-601
792785-501
792785-001
830639-601
830639-001
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29), and then remove the following
components:
a. Battery (see Battery on page 41)
b. WLAN module (see WLAN module on page 37)
c. WWAN/GPS module (see WWAN/GPS module on page 39)
d. Heat sink (see Heat sink on page 44)
Remove the system board:
1. Disconnect the following cables from the system board:
(1): Display cable
(2): Power connector cable
(3): USB/card reader board cable
(4): Speaker cable
46 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
2. Remove the ve Phillips PM2.0×2.0 broad head screws (1) that secure the system board to the bottom
cover.
3. Lift the right side of the system board (2), and then pull the system board toward the right to remove it
from the computer (3).
Reverse this procedure to install the system board.
Component replacement procedures 47
Display assembly – non-touch screen models
NOTE: The display assembly is spared at the subcomponent level only. For display assembly spare part
information, see the individual removal subsections.
Before removing the display assembly, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
5. Disconnect the battery cable from the system board (see Battery on page 41).
Remove the display assembly:
1. Disconnect the display cable from the system board (1).
2. Disconnect the WLAN and WWAN/GPS antenna cables (2) from the terminals on the WLAN and
WWAN/GPS modules.
3. Release the display panel cable and the wireless antenna cables from the routing channels and clips (3)
built into the bottom cover.
4. Remove the four Phillips PM2.5×4.5 screws (4) that secure the display assembly to the bottom cover.
5. Remove the display assembly (5).
6. If it is necessary to replace the display back cover or any of the display assembly internal components:
a. Remove the display bezel screw covers (1).
48 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
b. Remove the two Phillips PM2.0×3.0 screws (2) that secure the bezel to the display assembly.
NOTE: The screw covers may be dicult to remove. If you need to replace the covers, they are
available in the Rubber Kit, spare part number 792782-001 for horizon blue and orchid magenta
models or 830713-001 for cobalt blue and violet purple models.
c. Flex the inside edges of the top edge (1), the left and right sides (2), and the bottom edge (3) of
the display bezel until the bezel disengages from the display back cover.
d. Remove the display bezel (4).
The display bezel is available using spare part number 792768-001 for magenta models,
792767-001 for horizon blue models, 830644-001 for cobalt blue models, and 830645-001 for
purple models.
Component replacement procedures 49
7. If it is necessary to replace the webcam/microphone module:
a. Disconnect the webcam/microphone module cable (1) from the module.
b. Detach and remove the module (2) from the display back cover. (The webcam/microphone module
is attached to the display back cover with double-sided adhesive.)
The webcam/microphone module is available using spare part number 793616-001 for models
without a touch screen.
8. If it is necessary to replace the display panel:
50 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
a. Remove the four Phillips PM1.5×2.5 screws (1) that secure the display panel to the
display back cover.
CAUTION: Before turning the display panel upside down, make sure the work surface is clear of
tools, screws, and any other foreign objects. Failure to follow this caution can result in damage to
the display panel.
b. Lift the top edge of the display panel (2) and swing it up and forward until it rests upside down in
front of the display back cover.
c. Release the adhesive strip (1) that secures the display panel cable connector to the display panel.
d. Disconnect the display panel cable (2) from the display panel.
Component replacement procedures 51
e. Remove the display panel (3).
The display panel is available using spare part number 792779-001 for models without a-touch
screen.
The display back cover is available using the following spare part numbers:
792760-001: Orchid magenta models
792761-001: Horizon blue models
830640-001: Cobalt blue models
830641-001: Violet purple models
9. If it is necessary to replace the display hinges:
a. Remove the four Phillips PM2.5×3.0 broad head screws (1) that secure the display hinges to the
display back cover.
b. Remove the two Phillips PM2.0×2.5 screws (2) on the bottom of the hinges and the two Phillips
PM2.0×2.5 screws (3) at the top of the hinges that secure the hinges to the display back cover.
52 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
c. Remove the display hinges (4).
The display hinges are included in the Display Hinge Kit, spare part number 792774-001 for
models without a touch screen.
10. If it is necessary to replace the display panel cable:
a. Release the display panel cable from the retention clips (1) and channel built into the display back
cover.
Component replacement procedures 53
b. Remove the display panel cable (2).
The display panel cable includes the webcam/microphone module cable and is available using the
following spare part numbers:
792771-001: Models without a touch screen and without WWAN
798215-001: Models without a touch screen and with WWAN
11. If it is necessary to replace the WLAN antenna cable and transceiver:
a. Detach the antenna transceivers (1) from the display back cover. (The transceivers are attached to
the display back cover with double-sided adhesive.)
b. Release the shielding tape (2) that secures the antenna cables to the display back cover.
54 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
c. Release the antenna cables from the retention clips (2) and channel built into the top edge and
right side of the display back cover.
The antenna cables and transceivers are included in the WLAN Antenna Kit, spare part number
792758-001 and WWAN Antenna Kit, spare part number 792757-001.
Reverse this procedure to reassemble and install the display assembly.
Component replacement procedures 55
Display assembly – touch screen models
NOTE: The display assembly is spared at the subcomponent level only. For display assembly spare part
information, see the individual removal subsections.
Before removing the display assembly, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
5. Disconnect the battery cable from the system board (see Battery on page 41).
Remove the display assembly:
1. Disconnect the display cable from the system board (1).
2. Disconnect the WLAN and WWAN/GPS antenna cables (2) from the terminals on the WLAN and
WWAN/GPS modules.
3. Release the display panel cable and the wireless antenna cables from the routing channels and clips (3)
built into the bottom cover.
4. Remove the four Phillips PM2.5×4.5 screws (4) that secure the display assembly to the bottom cover.
5. Remove the display assembly (5).
6. If it is necessary to replace the display back cover or any of the display assembly internal components:
a. Remove the display screw covers (1).
56 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
b. Remove the two Phillips PM2.0×3.0 screws (2) that secure the to the display assembly.
NOTE: The screw covers may be dicult to remove. If you need to replace the covers, a Mylar
screw cover kit is included in all display spare part kits.
c. Lift the top of the rear cover upward (1), and then lift the cover from the display (2).
The display rear cover is available using spare part number 792759-001 for horizon blue models
and 792762-001 for orchid magenta models.
7. If it is necessary to replace the webcam/microphone module:
a. Disconnect the webcam/microphone module cable (1) from the module.
Component replacement procedures 57
b. Detach and remove the module (2) from the display back cover. (The webcam/microphone module
is attached to the display back cover with double-sided adhesive.)
The webcam/microphone module is available using spare part number 792793-001 for models
with a touch screen.
8. If it is necessary to replace the display hinges:
a. Remove the four Phillips PM2.5×3.0 broad head screws (1) that secure the display hinges to the
display back cover.
b. Remove the two Phillips PM2.0×2.5 screws (2) on the bottom of the hinges and the two Phillips
PM2.0×2.5 screws (3) at the top of the hinges that secure the hinges to the display back cover.
58 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
c. Remove the display hinges (4).
The display hinges are included in the Display Hinge Kit, spare part number 792775-001 for touch
screen models.
9. If it is necessary to replace the display panel cable:
a. Lift the Mylar tape from atop the connector on the panel (1), and then disconnect the cable from
the connector (2).
b. Disconnect the cable from the webcam module (3).
Component replacement procedures 59
c. Remove the cable from the clips on the side of the display panel (4), and then remove the display
cable from the display (5).
The display panel cable includes the webcam/microphone module cable and is available using the
following spare part numbers:
792772-001: Models with a touch screen and without WWAN
798216-001: Models with a touch screen and with WWAN
10. If it is necessary to replace the WLAN antenna cable and transceiver:
a. Detach the antenna transceivers (1) from the display back cover. (The transceivers are attached to
the display back cover with double-sided adhesive.)
b. Release the shielding tape (2) that secures the antenna cables to the display back cover.
60 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
c. Release the antenna cables from the retention clips (2) and channel built into the top edge and
right side of the display back cover.
The antenna cables and transceivers are included in the WLAN Antenna Kit, spare part number
792758-001 and WWAN Antenna Kit, spare part number 792757-001.
Reverse this procedure to reassemble and install the display assembly.
Power connector cable
Description Spare part number
Power connector cable (includes tape) 796086-001
Before removing the power connector cable, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 29).
5. Disconnect the battery cable from the system board (see Battery on page 41).
6. Remove the display assembly (see Display assembly – non-touch screen models on page 48) or Display
assembly – touch screen models on page 56.
Remove the power connector cable:
Component replacement procedures 61
1. Disconnect the power connector cable (1) from the system board.
2. Release the power connector (2) from the retention clips built into the bottom cover.
3. Remove the power connector cable (3).
Reverse this procedure to install the power connector cable.
62 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
6 Using Setup Utility (BIOS) in Windows 8.1
Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output
devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility (BIOS)
includes settings for the types of devices installed, the startup sequence of the computer, and the amount of
system and extended memory.
Starting Setup Utility (BIOS)
CAUTION: Use extreme care when making changes in Setup Utility (BIOS). Errors can prevent the computer
from operating properly.
▲
Turn on or restart the computer, quickly press esc, and then press f10.
Updating the BIOS
Updated versions of the BIOS may be available on the HP website.
Most BIOS updates on the HP website are packaged in compressed les called SoftPaqs.
Some download packages contain a le named Readme.txt, which contains information regarding installing
and troubleshooting the le.
Determining the BIOS version
To determine whether available BIOS updates contain later BIOS versions than the one currently installed on
the computer, you need to know the version of the system BIOS that is installed.
BIOS version information (also known as ROM date and System BIOS) can be revealed from the Start screen by
typing support, selecting the HP Support Assistant app, selecting My computer, and then selecting
System Information, or by using Setup Utility (BIOS).
1. Start Setup Utility (BIOS) (see Starting Setup Utility (BIOS) on page 63).
2. Select Main, and then make note of your BIOS version.
3. Select Exit, select Exit Discarding Changes, and then follow the on-screen instructions.
Downloading a BIOS update
CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download and
install a BIOS update only when the computer is connected to reliable external power using the AC adapter. Do
not download or install a BIOS update while the computer is running on battery power, docked in an optional
docking device, or connected to an optional power source. During the download and installation, follow these
instructions:
●
Do not disconnect power from the computer by unplugging the power cord from the AC outlet.
●
Do not shut down the computer or initiate Sleep.
●
Do not insert, remove, connect, or disconnect any device, cable, or cord.
NOTE: If your computer is connected to a network, consult the network administrator before installing any
software updates, especially system BIOS updates.
Starting Setup Utility (BIOS) 63
1. From the Start screen, type support, and then select the HP Support Assistant app.
‒ or –
From the Windows desktop, click the question mark icon in the notication area, at the far right of the
taskbar.
2. Click Updates and tune-ups, and then click Check for HP updates now.
3. Follow the on-screen instructions.
4. At the download area, follow these steps:
a. Identify the most recent BIOS update and compare it to the BIOS version currently installed on your
computer. If the update is more recent than your BIOS, make a note of the date, name, or other
identier. You may need this information to locate the update later, after it has been downloaded
to your hard drive.
b. Follow the on-screen instructions to download your selection to the hard drive.
If the update is more recent than your BIOS, make a note of the path to the location on your hard
drive where the BIOS update is downloaded. You will need to access this path when you are ready
to install the update.
BIOS installation procedures vary. Follow any instructions that appear on the screen after the download is
complete. If no instructions appear, follow these steps:
1. From the Start screen, type file, and then select File Explorer.
‒ or –
From the Windows desktop, right-click the Start button, and then select File Explorer.
2. Click your hard drive designation. The hard drive designation is typically Local Disk (C:).
3. Using the hard drive path you recorded earlier, open the folder on your hard drive that contains the
update.
4. Double-click the le that has an .exe extension (for example, lename.exe).
The BIOS installation begins.
5. Complete the installation by following the on-screen instructions.
NOTE: After a message on the screen reports a successful installation, you can delete the downloaded le
from your hard drive.
64 Chapter 6 Using Setup Utility (BIOS) in Windows 8.1
7 Using Setup Utility (BIOS) in Windows 10
Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output
devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility (BIOS)
includes settings for the types of devices installed, the startup sequence of the computer, and the amount of
system and extended memory.
NOTE: To start Setup Utility on convertible computers, your computer must be in notebook mode and you
must use the keyboard attached to your notebook. The on-screen keyboard, which displays in tablet mode,
cannot access Setup Utility.
Starting Setup Utility (BIOS)
CAUTION: Use extreme care when making changes in Setup Utility (BIOS). Errors can prevent the computer
from operating properly.
NOTE: To start Setup Utility on convertible computers, your computer must be in notebook mode and you
must use the keyboard attached to your notebook. The on-screen keyboard, which displays in tablet mode,
cannot access Setup Utility.
●
Computers or tablets with keyboards:
▲
Turn on or restart the computer, quickly press esc, and then press f10.
●
Tablets without keyboards:
1. Turn on or restart the tablet, and then quickly hold down the volume down button.
- or -
Turn on or restart the tablet, and then quickly hold down the Windows button.
2. Tap f10.
Updating Setup Utility (BIOS)
Updated versions of Setup Utility (BIOS) may be available on the HP website.
Most BIOS updates on the HP website are packaged in compressed les called SoftPaqs.
Some download packages contain a le named Readme.txt, which contains information regarding installing
and troubleshooting the le.
Determining the BIOS version
To decide whether you need to update Setup Utility (BIOS), rst determine the BIOS version on your computer.
To reveal the BIOS version information (also known as ROM date and System BIOS):
1. Type support in the taskbar search box, and then select the HP Support Assistant app.
– or –
Starting Setup Utility (BIOS) 65
Click the question mark icon in the taskbar.
2. Select My PC, and then select Specications.
– or –
▲
Use Setup Utility (BIOS).
To use Setup Utility (BIOS):
1. Start Setup Utility (BIOS) (see Starting Setup Utility (BIOS) on page 65).
2. Select Main, select System Information, and then make note of the BIOS version.
3. Select Exit, select No, and then follow the on-screen instructions.
To check for later BIOS versions, see Downloading a BIOS update on page 66.
Downloading a BIOS update
CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download and
install a BIOS update only when the computer is connected to reliable external power using the AC adapter. Do
not download or install a BIOS update while the computer is running on battery power, docked in an optional
docking device, or connected to an optional power source. During the download and installation, follow these
instructions:
●
Do not disconnect power from the computer by unplugging the power cord from the AC outlet.
●
Do not shut down the computer or initiate Sleep.
●
Do not insert, remove, connect, or disconnect any device, cable, or cord.
NOTE: If your computer is connected to a network, consult the network administrator before installing any
software updates, especially system BIOS updates.
1. Type support in the taskbar search box, and then select the HP Support Assistant app.
– or –
Click the question mark icon in the taskbar.
2. Click Updates, and then click Check for updates and messages.
3. Follow the on-screen instructions.
4. At the download area, follow these steps:
a. Identify the most recent BIOS update and compare it to the BIOS version currently installed on your
computer. If the update is more recent than your BIOS version, make a note of the date, name, or
other identier. You may need this information to locate the update later, after it has been
downloaded to your hard drive.
b. Follow the on-screen instructions to download your selection to the hard drive.
Make a note of the path to the location on your hard drive where the BIOS update is downloaded.
You will need to access this path when you are ready to install the update.
BIOS installation procedures vary. Follow any instructions that appear on the screen after the download is
complete. If no instructions appear, follow these steps:
1. Type file in the taskbar search box, and then select File Explorer.
2. Click your hard drive designation. The hard drive designation is typically Local Disk (C:).
3. Using the hard drive path you recorded earlier, open the folder that contains the update.
66 Chapter 7 Using Setup Utility (BIOS) in Windows 10
4. Double-click the le that has an .exe extension (for example, lename.exe).
The BIOS installation begins.
5. Complete the installation by following the on-screen instructions.
NOTE: After a message on the screen reports a successful installation, you can delete the downloaded le
from your hard drive.
Synchronizing a tablet and keyboard (select products only)
For a tablet with a detachable keyboard, when you attach the tablet to the keyboard and restart the
computer, Setup Utility (BIOS) checks to see if the Embedded Controller rmware on the keyboard needs to be
synchronized. If so, synchronization begins. If the synchronization is interrupted, a notication screen
displays for 10 seconds before the tablet restarts and attempts to synchronize again.
NOTE: The Embedded Controller rmware will synchronize ONLY if the tablet or keyboard battery is more
than 50% charged, or if your tablet is connected to AC power.
Synchronizing a tablet and keyboard (select products only) 67
8 Specications
Computer specications
Metric U.S.
Tablet dimensions
Width 33.32 cm 13.11 in
Depth 22.44 cm 8.84 in
Height (front to rear) 0.69 to 2.14 cm 0.27 to 0.84 in
Weight (equipped with hard drive) 1.70 kg 3.75 lbs
Weight (equipped with solid-state drive) 1.55 kg 3.42 lbs
Input power
Operating voltage and current 19.5 V dc @ 2.31 A – 45 W
Temperature
Operating 5°C to 35°C 41°F to 95°F
19.5 V dc @ 3.33 A – 65 W (select models only)
Nonoperating ‑20°C to 60°C ‑4°F to 140°F
Relative humidity (noncondensing)
Operating 10% to 90%
Nonoperating 5% to 95%
Maximum altitude (unpressurized)
Operating ‑15 m to 3,048 m ‑50 ft to 10,000 ft
Nonoperating ‑15 m to 12,192 m ‑50 ft to 40,000 ft
NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The device operates well within this range of
temperatures.
68 Chapter 8 Specications
33.8-cm (13.3-in), HD display specications
Metric U.S.
Active diagonal size 33.8-cm 13.3-in
Resolution 1280x800
Display colors 262K
Surface treatment Anti-glare
Contrast ratio 300:1 (typical)
Brightness 200 nits (typical)
Viewing angle SVA
Backlight LED
Response time 5.5 ms/10.5 ms (Typ)(Tr/Td)
Viewing angle 45/45/15/35 (Typ)(L/R/U/D)
33.8-cm (13.3-in), HD display specications 69
9 Backing up, restoring, and recovering in
Windows 8.1
This chapter provides information about the following processes. The information in the chapter is standard
procedure for most models.
●
Creating recovery media and backups
●
Restoring and recovering your system
For additional information, refer to the HP Support Assistant.
▲
From the Start screen, type support, and then select the HP Support Assistant app.
- or -
From the Windows desktop, click the question mark icon in the notication area, at the far right of the
taskbar.
Creating recovery media and backups
The following methods of creating recovery media and backups are available on select models only. Choose
the available method according to your computer model.
●
Use HP Recovery Manager after you successfully set up the computer to create HP Recovery media. This
step creates a backup of the HP Recovery partition on the computer. The backup can be used to reinstall
the original operating system in cases where the hard drive is corrupted or has been replaced. For
information on creating recovery media, see Creating HP Recovery media (select models only)
on page 70. For information on the recovery options that are available using the recovery media, see
Recovering using HP Recovery Manager on page 72.
●
Use Windows tools to create system restore points and create backups of personal information.
For more information, see Using Windows tools on page 71.
NOTE: If storage is 32 GB or less, Microsoft System Restore is disabled by default.
Creating HP Recovery media (select models only)
IMPORTANT: If your computer does not list a Recovery Media Creation option, you can obtain recovery
media for your system from support. See the Worldwide Telephone Numbers booklet included with the
computer. You can also nd contact information from the HP website. Go to http://www.hp.com/support,
select your country or region, and follow the on-screen instructions.
HP Recovery Manager is a software program that allows you to create recovery media after you successfully
set up the computer. HP Recovery media can be used to perform system recovery if the hard drive becomes
corrupted. System recovery reinstalls the original operating system and the software programs installed at
the factory and then congures the settings for the programs. HP Recovery media can also be used to
customize the system or restore the factory image if you replace the hard drive.
70 Chapter 9 Backing up, restoring, and recovering in Windows 8.1
●
Only one set of recovery media can be created. Handle these recovery tools carefully, and keep them in a
safe place.
●
HP Recovery Manager examines the computer and determines the required storage capacity for the
media that will be required.
●
To create recovery discs, your computer must have an optical drive with DVD writer capability, and you
must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do not use rewritable
discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-ray) discs; they are not
compatible with HP Recovery Manager software. Or, instead, you can use a high-quality blank USB ash
drive.
●
If your computer does not include an integrated optical drive with DVD writer capability, but you would
like to create DVD recovery media, you can use an external optical drive (purchased separately) to create
recovery discs, or you can obtain recovery discs for your computer from support. See the Worldwide
Telephone Numbers booklet included with the computer. You can also nd contact information from the
HP website. Go to http://www.hp.com/support, select your country or region, and follow the on-screen
instructions. If you use an external optical drive, it must be connected directly to a USB port on the
computer; the drive cannot be connected to a USB port on an external device, such as a USB hub.
●
Be sure that the computer is connected to AC power before you begin creating the recovery media.
●
The creation process can take an hour or more. Do not interrupt the creation process.
●
If necessary, you can exit the program before you have nished creating all of the recovery DVDs. HP
Recovery Manager will nish burning the current DVD. The next time you start HP Recovery Manager,
you will be prompted to continue, and the remaining discs will be burned.
To create HP Recovery media:
1. From the Start screen, type recovery, and then select HP Recovery Manager.
2. Select Recovery Media Creation, and then follow the on-screen instructions.
If you ever need to recover the system, see Recovering using HP Recovery Manager on page 72.
Using Windows tools
You can create system restore points and create backups of personal information using Windows tools.
NOTE: If storage is 32 GB or less, Microsoft System Restore is disabled by default.
▲
From the Start screen, type help, and then select Help and Support.
‒ or –
From the Windows desktop, click the question mark icon in the notication area, at the far right of the
taskbar.
For more information and steps, see Help and Support.
Restore and recovery
There are several options for recovering your system. Choose the method that best matches your situation
and level of expertise:
IMPORTANT: Not all methods are available on all models.
●
Windows oers several options for restoring from backup, refreshing the computer, and resetting the
computer to its original state. For more information see Help and Support.
Using Windows tools 71
▲
From the Start screen, type support, and then select the HP Support Assistant app.
- or -
From the Windows desktop, click the question mark icon in the notication area, at the far right of
the taskbar.
●
If you need to correct a problem with a preinstalled application or driver, use the Drivers and
Applications Reinstall option of HP Recovery Manager to reinstall the individual application or driver.
▲
From the Start screen, type recovery, select HP Recovery Manager, select Drivers and
Applications Reinstall, and then follow the on-screen instructions.
●
On select models, if you want to reset your computer using a minimized image, you can choose the HP
Minimized Image Recovery option from the HP Recovery partition or HP Recovery media. Minimized
Image Recovery installs only drivers and hardware-enabling applications. Other applications included in
the image continue to be available for installation through the Drivers and Applications Reinstall option
in HP Recovery Manager.
For more information, see Recovering using HP Recovery Manager on page 72.
●
If you want to recover the Windows partition to original factory content, you can choose the System
Recovery option from the HP Recovery partition (select models only) or use the HP Recovery media. For
more information, see Recovering using HP Recovery Manager on page 72. If you have not already
created recovery media, see Creating HP Recovery media (select models only) on page 70.
●
On select models, if you want to recover the computer's original factory partition and content , or if you
have replaced the hard drive, you can use the Factory Reset option of HP Recovery media. For more
information, see Recovering using HP Recovery Manager on page 72.
●
On select models, if you want to remove the recovery partition to reclaim hard drive space, HP Recovery
Manager oers the Remove Recovery Partition option.
For more information, see Removing the HP Recovery partition (select models only) on page 74.
Recovering using HP Recovery Manager
HP Recovery Manager software allows you to recover the computer to its original factory state by using the
HP Recovery media that you either created or that you obtained from support, or by using the HP Recovery
partition (select models only). If you have not already created recovery media, see Creating HP Recovery
media (select models only) on page 70.
What you need to know before you get started
●
HP Recovery Manager recovers only software that was installed at the factory. For software not provided
with this computer, you must either download the software from the manufacturer's website or reinstall
the software from the media provided by the manufacturer.
IMPORTANT: Recovery through HP Recovery Manager should be used as a nal attempt to correct
computer issues.
●
HP Recovery media must be used if the computer hard drive fails. If you have not already created
recovery media, see Creating HP Recovery media (select models only) on page 70.
●
To use the Factory Reset option (select models only), you must use HP Recovery media. If you have not
already created recovery media, see Creating HP Recovery media (select models only) on page 70.
●
If your computer does not allow the creation of HP Recovery media or if the HP Recovery media does not
work, you can obtain recovery media for your system from support. See the Worldwide Telephone
Numbers booklet included with the computer. You can also nd contact information from the HP
72 Chapter 9 Backing up, restoring, and recovering in Windows 8.1
website. Go to http://www.hp.com/support, select your country or region, and follow the on-screen
instructions.
IMPORTANT: HP Recovery Manager does not automatically provide backups of your personal data. Before
beginning recovery, back up any personal data you want to retain.
Using HP Recovery media, you can choose from one of the following recovery options:
NOTE: Only the options available for your computer display when you start the recovery process.
●
System Recovery—Reinstalls the original operating system, and then congures the settings for the
programs that were installed at the factory.
●
Minimized Image Recovery (select models only)—Reinstalls the operating system and all hardwarerelated drivers and software, but not other software applications.
●
Factory Reset—Restores the computer to its original factory state by deleting all information from the
hard drive and re-creating the partitions. Then it reinstalls the operating system and the software that
was installed at the factory.
The HP Recovery partition (select models only) allows System Recovery and Minimized Image Recovery
(select models only).
Using the HP Recovery partition (select models only)
The HP Recovery partition allows you to perform a system recovery or minimized image recovery (select
models only) without the need for recovery discs or a recovery USB ash drive. This type of recovery can be
used only if the hard drive is still working.
To start HP Recovery Manager from the HP Recovery partition:
1. From the Start screen, type recovery, select HP Recovery Manager, and then select HP Recovery
Environment
- or-
Press f11 while the computer boots, or press and hold f11 as you press the power button.
2. Select Troubleshoot from the boot options menu.
3. Select Recovery Manager, and then follow the on-screen instructions.
.
Using HP Recovery media to recover
You can use HP Recovery media to recover the original system. This method can be used if your system does
not have an HP Recovery partition or if the hard drive is not working properly.
1. If possible, back up all personal les.
2. Insert the HP Recovery media, and then restart the computer.
NOTE: If the computer does not automatically restart in HP Recovery Manager, change the computer
boot order. See Changing the computer boot order on page 73.
3. Follow the on-screen instructions.
Changing the computer boot order
If your computer does not restart in HP Recovery Manager, you can change the computer boot order, which is
the order of devices listed in BIOS where the computer looks for startup information. You can change the
selection for an optical drive or a USB ash drive.
Restore and recovery 73
To change the boot order:
1. Insert the HP Recovery media.
2. Start Computer Setup:
▲
Turn on or restart the computer, quickly press esc, and then press f9 for boot options.
3. Select the optical drive or USB ash drive from which you want to boot.
4. Follow the on-screen instructions.
Removing the HP Recovery partition (select models only)
HP Recovery Manager software allows you to remove the HP Recovery partition to free up hard drive space.
IMPORTANT: After you remove the HP Recovery partition, you can no longer use the Windows Refresh
option or the Windows option to remove everything and reinstall Windows. In addition, you will not be able to
perform System Recovery or Minimized Image Recovery from the HP Recovery partition. So before you
remove the Recovery partition, create HP Recovery media; see Creating HP Recovery media (select models
only) on page 70.
Follow these steps to remove the HP Recovery partition:
1. From the Start screen, type recovery, and then select HP Recovery Manager.
2. Select Remove Recovery Partition, and then follow the on-screen instructions.
74 Chapter 9 Backing up, restoring, and recovering in Windows 8.1
10 Backing up, restoring, and recovering in
Windows 10
This chapter provides information about the following processes. The information in the chapter is standard
procedure for most products.
●
Creating recovery media and backups
●
Restoring and recovering your system
For additional information, refer to the HP support assistant app.
▲
Type support in the taskbar search box, and then select the HP Support Assistant app.
‒ or –
Click the question mark icon in the taskbar.
IMPORTANT: If you will be performing recovery procedures on a tablet, the tablet battery must be at least
70% charged before you start the recovery process.
IMPORTANT: For a tablet with a detachable keyboard, connect the keyboard to the keyboard dock before
beginning any recovery process.
Creating recovery media and backups
The following methods of creating recovery media and backups are available on select products only. Choose
the available method according to your computer model.
●
Use HP Recovery Manager to create HP Recovery media after you successfully set up the computer. This
step creates a backup of the HP Recovery partition on the computer. The backup can be used to reinstall
the original operating system in cases where the hard drive is corrupted or has been replaced. For
information on creating recovery media, see Creating HP Recovery media (select products only)
on page 75. For information on the recovery options that are available using the recovery media, see
Using Windows tools on page 76.
●
Use Windows tools to create system restore points and create backups of personal information.
For more information, see Recovering using HP Recovery Manager on page 77.
NOTE: If storage is 32 GB or less, Microsoft System Restore is disabled by default.
Creating HP Recovery media (select products only)
If possible, check for the presence of the Recovery partition and the Windows partition. From the Start menu,
select File Explorer, and then select This PC.
●
If your computer does not list the Windows partition and the Recovery partition, you can obtain recovery
media for your system from support. See the Worldwide Telephone Numbers booklet included with the
computer. You can also nd contact information on the HP website. Go to http://www.hp.com/support,
select your country or region, and follow the on-screen instructions.
Creating recovery media and backups 75
You can use Windows tools to create system restore points and create backups of personal information,
see Using Windows tools on page 76.
●
If your computer does list the Recovery partition and the Windows partition, you can use HP Recovery
Manager to create recovery media after you successfully set up the computer. HP Recovery media can be
used to perform system recovery if the hard drive becomes corrupted. System recovery reinstalls the
original operating system and software programs that were installed at the factory and then congures
the settings for the programs. HP Recovery media can also be used to customize the system or restore
the factory image if you replace the hard drive.
◦
Only one set of recovery media can be created. Handle these recovery tools carefully, and keep
them in a safe place.
◦
HP Recovery Manager examines the computer and determines the required storage capacity for
the media that will be required.
◦
To create recovery discs, your computer must have an optical drive with DVD writer capability, and
you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do not use
rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-ray)
discs; they are not compatible with HP Recovery Manager software. Or, instead, you can use a highquality blank USB ash drive.
◦
If your computer does not include an integrated optical drive with DVD writer capability, but you
would like to create DVD recovery media, you can use an external optical drive (purchased
separately) to create recovery discs. If you use an external optical drive, it must be connected
directly to a USB port on the computer; the drive cannot be connected to a USB port on an external
device, such as a USB hub. If you cannot create DVD media yourself, you can obtain recovery discs
for your computer from HP. See the Worldwide Telephone Numbers booklet included with the
computer. You can also nd contact information on the HP website. Go to http://www.hp.com/
support, select your country or region, and follow the on-screen instructions.
◦
Be sure that the computer is connected to AC power before you begin creating the recovery media.
◦
The creation process can take an hour or more. Do not interrupt the creation process.
◦
If necessary, you can exit the program before you have nished creating all of the recovery DVDs.
HP Recovery Manager will nish burning the current DVD. The next time you start HP Recovery
Manager, you will be prompted to continue.
To create HP Recovery media:
IMPORTANT: For a tablet with a detachable keyboard, connect the keyboard to the keyboard dock before
beginning these steps.
1. Type recovery in the taskbar search box, and then select HP Recovery Manager.
2. Select Create recovery media, and then follow the on-screen instructions.
If you ever need to recover the system, see Recovering using HP Recovery Manager on page 77.
Using Windows tools
You can create recovery media, system restore points, and backups of personal information using Windows
tools.
NOTE: If storage is 32 GB or less, Microsoft System Restore is disabled by default.
For more information and steps, see the Get started app.
▲
Select the Start button, and then select the Get started app.
76 Chapter 10 Backing up, restoring, and recovering in Windows 10
Restore and recovery
There are several options for recovering your system. Choose the method that best matches your situation
and level of expertise:
IMPORTANT: Not all methods are available on all products.
●
Windows oers several options for restoring from backup, refreshing the computer, and resetting the
computer to its original state. For more information see the Get started app.
▲
Select the Start button, and then select the Get started app.
●
If you need to correct a problem with a preinstalled application or driver, use the Reinstall drivers and/or
applications option (select products only) of HP Recovery Manager to reinstall the individual application
or driver.
▲
Type recovery in the taskbar search box, select HP Recovery Manager, select Reinstall drivers
and/or applications
●
If you want to recover the Windows partition to original factory content, you can choose the System
Recovery option from the HP Recovery partition (select products only) or use the HP Recovery media.
For more information, see Recovering using HP Recovery Manager on page 77. If you have not already
created recovery media, see Creating HP Recovery media (select products only) on page 75.
●
On select products, if you want to recover the computer's original factory partition and content, or if you
have replaced the hard drive, you can use the Factory Reset option of HP Recovery media. For more
information, see Recovering using HP Recovery Manager on page 77.
, and then follow the on-screen instructions.
●
On select products, if you want to remove the recovery partition to reclaim hard drive space, HP
Recovery Manager oers the Remove Recovery Partition option.
For more information, see Removing the HP Recovery partition (select products only) on page 79.
Recovering using HP Recovery Manager
HP Recovery Manager software allows you to recover the computer to its original factory state by using the
HP Recovery media that you either created or that you obtained from HP, or by using the HP Recovery
partition (select products only). If you have not already created recovery media, see Creating HP Recovery
media (select products only) on page 75.
What you need to know before you get started
●
HP Recovery Manager recovers only software that was installed at the factory. For software not provided
with this computer, you must either download the software from the manufacturer's website or reinstall
the software from the media provided by the manufacturer.
IMPORTANT: Recovery through HP Recovery Manager should be used as a nal attempt to correct
computer issues.
●
HP Recovery media must be used if the computer hard drive fails. If you have not already created
recovery media, see Creating HP Recovery media (select products only) on page 75.
●
To use the Factory Reset option (select products only), you must use HP Recovery media. If you have not
already created recovery media, see Creating HP Recovery media (select products only) on page 75.
●
If your computer does not allow the creation of HP Recovery media or if the HP Recovery media does not
work, you can obtain recovery media for your system from support. See the Worldwide Telephone
Numbers booklet included with the computer. You can also nd contact information from the HP
Restore and recovery 77
website. Go to http://www.hp.com/support, select your country or region, and follow the on-screen
instructions.
IMPORTANT: HP Recovery Manager does not automatically provide backups of your personal data. Before
beginning recovery, back up any personal data you want to retain.
Using HP Recovery media, you can choose from one of the following recovery options:
NOTE: Only the options available for your computer display when you start the recovery process.
●
System Recovery—Reinstalls the original operating system, and then congures the settings for the
programs that were installed at the factory.
●
Factory Reset—Restores the computer to its original factory state by deleting all information from the
hard drive and re-creating the partitions. Then it reinstalls the operating system and the software that
was installed at the factory.
The HP Recovery partition (select products only) allows System Recovery only.
Using the HP Recovery partition (select products only)
The HP Recovery partition allows you to perform a system recovery without the need for recovery discs or a
recovery USB ash drive. This type of recovery can be used only if the hard drive is still working.
To start HP Recovery Manager from the HP Recovery partition:
IMPORTANT: For a tablet with a detachable keyboard, connect the keyboard to the keyboard dock before
beginning these steps (select products only).
1. Type recovery in the taskbar search box, select Recovery Manager, and then select HP Recovery
Environment
- or-
For computers or tablets with keyboards attached, press f11 while the computer boots, or press and
hold f11 as you press the power button.
For tablets without keyboards:
Turn on or restart the tablet, and then quickly hold down the volume down button; then select f11.
- or -
Turn on or restart the tablet, and then quickly hold down the Windows button; then select f11.
2. Select Troubleshoot from the boot options menu.
3. Select Recovery Manager, and then follow the on-screen instructions.
.
Using HP Recovery media to recover
You can use HP Recovery media to recover the original system. This method can be used if your system does
not have an HP Recovery partition or if the hard drive is not working properly.
1. If possible, back up all personal les.
2. Insert the HP Recovery media, and then restart the computer.
NOTE: If the computer does not automatically restart in HP Recovery Manager, change the computer
boot order. See Changing the computer boot order on page 79.
3. Follow the on-screen instructions.
78 Chapter 10 Backing up, restoring, and recovering in Windows 10
Changing the computer boot order
If your computer does not restart in HP Recovery Manager, you can change the computer boot order, which is
the order of devices listed in BIOS where the computer looks for startup information. You can change the
selection to an optical drive or a USB ash drive.
To change the boot order:
IMPORTANT: For a tablet with a detachable keyboard, connect the keyboard to the keyboard dock before
beginning these steps.
1. Insert the HP Recovery media.
2. Access BIOS:
For computers or tablets with keyboards attached:
▲
Turn on or restart the computer or tablet, quickly press esc, and then press f9 for boot options.
For tablets without keyboards:
▲
Turn on or restart the tablet, and then quickly hold down the volume down button; then select f9.
- or -
Turn on or restart the tablet, and then quickly hold down the Windows button; then select f9.
3. Select the optical drive or USB ash drive from which you want to boot.
4. Follow the on-screen instructions.
Removing the HP Recovery partition (select products only)
HP Recovery Manager software allows you to remove the HP Recovery partition to free up hard drive space.
IMPORTANT: After you remove the HP Recovery partition, you will not be able to perform System Recovery
or create HP recovery media from the HP Recovery partition. So before you remove the Recovery partition,
create HP Recovery media; see Creating HP Recovery media (select products only) on page 75.
NOTE: The Remove Recovery Partition option is only available on products that support this function.
Follow these steps to remove the HP Recovery partition:
1. Type recovery in the taskbar search box, and then select HP Recovery Manager.
2. Select Remove Recovery Partition, and then follow the on-screen instructions.
Restore and recovery 79
11 Using HP PC Hardware Diagnostics (UEFI)
HP PC Hardware Diagnostics is a Unied Extensible Firmware Interface (UEFI) that allows you to run diagnostic
tests to determine whether the computer hardware is functioning properly. The tool runs outside the
operating system so that it can isolate hardware failures from issues that are caused by the operating system
or other software components.
NOTE: To start BIOS on a convertible computer, your computer must be in notebook mode and you must use
the keyboard attached to your tablet. The on-screen keyboard, which displays in tablet mode, cannot access
BIOS.
To start HP PC Hardware Diagnostics UEFI:
1. Start BIOS:
●
Computers or tablets with keyboards:
▲
Turn on or restart the computer, quickly press esc.
●
Tablets without keyboards:
▲
Turn on or restart the tablet, and then quickly hold down the volume down button.
- or -
Turn on or restart the tablet, and then quickly hold down the Windows button.
2. Press or tap f2.
The BIOS searches three places for the diagnostic tools, in the following order:
a. Connected USB drive
NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see Downloading
HP PC Hardware Diagnostics (UEFI) to a USB device on page 81.
b. Hard drive
c. BIOS
3. When the diagnostic tool opens, select the type of diagnostic test you want to run, and then follow the
on-screen instructions. On a tablet, press the volume down button to stop a diagnostic test.
NOTE: If you need to stop a diagnostic test on computers or tablets with a keyboard, press esc.
80 Chapter 11 Using HP PC Hardware Diagnostics (UEFI)
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device
There are two options to download HP PC Hardware Diagnostics to a USB device:
Download the latest UEFI version:
1. Go to http://www.hp.com/go/techcenter/pcdiags. The HP PC Diagnostics home page is displayed.
2. In the HP PC Hardware Diagnostics section, click the Download link, and then select Run.
Download any version of UEFI for a specic product:
1. Go to http://www.hp.com/support, and then select your country. The HP Support page is displayed.
2. Click Drivers & Downloads.
3. In the text box, enter the product name, and then click Go.
– or –
Click Find Now to let HP automatically detect your product.
4. Select your computer, and then select your operating system.
5. In the Diagnostic section, follow the on-screen instructions to select and download the UEFI version
you want.
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device 81
12 Power cord set requirements
The wide-range input feature of the computer permits it to operate from any line voltage from 100 to 120
volts AC, or from 220 to 240 volts AC.
The 3-conductor power cord set included with the computer meets the requirements for use in the country or
region where the equipment is purchased.
Power cord sets for use in other countries and regions must meet the requirements of the country or region
where the computer is used.
Requirements for all countries
The following requirements are applicable to all countries and regions:
●
The length of the power cord set must be at least 1.0 m (3.3 ft) and no more than 2.0 m (6.5 ft).
●
All power cord sets must be approved by an acceptable accredited agency responsible for evaluation in
the country or region where the power cord set will be used.
●
The power cord sets must have a minimum current capacity of 10 amps and a nominal voltage rating of
125 or 250 V AC, as required by the power system of each country or region.
●
The appliance coupler must meet the mechanical conguration of an EN 60 320/IEC 320 Standard Sheet
C13 connector for mating with the appliance inlet on the back of the computer. Requirements for all
countries 113
Requirements for specic countries and regions
Country/region Accredited agency Applicable note number
Australia EANSW 1
Austria OVE 1
Belgium CEBC 1
Canada CSA 2
Denmark DEMKO 1
Finland FIMKO 1
France UTE 1
Germany VDE 1
Italy IMQ 1
Japan METI 3
The Netherlands KEMA 1
Norway NEMKO 1
The People's Republic of China COC 5
82 Chapter 12 Power cord set requirements
Country/region Accredited agency Applicable note number
South Korea EK 4
Sweden CEMKO 1
Switzerland SEV 1
Taiwan BSMI 4
The United Kingdom BSI 1
The United States UL 2
1. The exible cord must be Type HO5VV-F, 3-conductor, 1.0-mm² conductor size. Power cord set ttings (appliance coupler and
wall plug) must bear the certication mark of the agency responsible for evaluation in the country or region where it will be used.
2. The exible cord must be Type SPT-3 or equivalent, No. 18 AWG, 3-conductor. The wall plug must be a two-pole grounding type
with a NEMA 5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) conguration.
3. The appliance coupler, exible cord, and wall plug must bear a “T” mark and registration number in accordance with the Japanese
Dentori Law. The exible cord must be Type VCT or VCTF, 3-conductor, 1.00-mm² conductor size. The wall plug must be a twopole grounding type with a Japanese Industrial Standard C8303 (7 A, 125 V) conguration.
4. The exible cord must be Type RVV, 3-conductor, 0.75-mm² conductor size. Power cord set ttings (appliance coupler and wall
plug) must bear the certication mark of the agency responsible for evaluation in the country or region where it will be used.
5. The exible cord must be Type VCTF, 3-conductor, 0.75-mm² conductor size. Power cord set ttings (appliance coupler and wall
plug) must bear the certication mark of the agency responsible for evaluation in the country or region where it will be used.
Requirements for specic countries and regions 83
13 Recycling
When a non-rechargeable or rechargeable battery has reached the end of its useful life, do not dispose of the
battery in general household waste. Follow the local laws and regulations in your area for battery disposal.
HP encourages customers to recycle used electronic hardware, HP original print cartridges, and rechargeable
batteries. For more information about recycling programs, see the HP Web site at http://www.hp.com/recycle.
84 Chapter 13 Recycling
Index
A
AC adapter light 7
AC adapter, spare part numbers 15,
16
antenna
location 4
removal 54, 60
spare part number 13, 15, 17,
55, 61
Antenna Kit, spare part number 13,
15, 17, 55, 61
audio, product description 1
audio-in jack 6
audio-out jack 6
B
backups 70, 75
base enclosure, spare part number
11
battery
removal 41
spare part number 10, 17, 41
BIOS
determining version 63, 65
downloading an update 63, 66
starting the Setup Utility 63, 65
updating 63, 65
Bluetooth label 8
boot order
changing 73, 79
bottom 8
buttons
power 4
C
cables, service considerations 25
chipset, product description 1
components
display 4
left side 6
rear 7
right side 7
computer
major components 9
specications 68
connectors, service considerations
25
D
display assembly
removal 48, 56
spare part numbers 12, 14
display back cover, spare part
number 13, 15, 17
display bezel
removal 48, 56
spare part number 12, 17, 20,
49, 57
Display Hinge Kit, spare part
number 13, 15, 17, 53, 59
display panel
product description 1
removal 50
spare part number 13, 14, 17,
52
display panel cable
removal 53, 59
spare part number 13, 14, 17,
20, 54, 60
display specications 69
display, exterior components 4
DVD±RW DL SuperMulti Drive, spare
part number 15, 16
E
electrostatic discharge 26
equipment guidelines 28
external media cards, product
description 2
F
feet
removal 32
G
GPS module
removal 39
spare part numbers 39
graphics, product description 1
grounding guidelines 26
guidelines
equipment 28
grounding 26
packaging 27
transporting 27
workstation 27
H
hard drive
product description 1
HDMI port 6
HDMI-to-VGA adapter, spare part
number 15, 16
headphone jack 6
heat sink
removal 44
spare part number 10, 17, 44
hinge
removal 52, 58
spare part number 13, 15, 17,
53, 59
HP PC Hardware Diagnostics (UEFI)
using 80
HP Recovery Manager
correcting boot problems 73, 79
starting 73, 78
HP Recovery media
creating 70, 75
recovery 73, 78
HP Recovery partition
recovery 73, 78
removing 74, 79
J
jacks
audio-in 6
audio-out 6
headphone 6
microphone 6
K
keyboard/top cover
removal 29
spare part numbers 10, 18, 19,
20, 21, 22, 23, 24, 29
Index 85
keys
Windows 4
L
labels
Bluetooth 8
regulatory 8
serial number 8
service 8
wireless certication 8
WLAN 8
left-side components 6
lights
AC adapter 7
mute 4
power 7
webcam 5
M
memory card reader 6
memory, product description 1
microphone
location 4
product description 1
microphone jack 6
minimized image recovery 73, 78
minimized image, creating 72, 77
model name 1
mute light 4
O
operating system, product
description 2
optical drive
product description 1
spare part number 15, 16
original system recovery 72, 77
P
packaging guidelines 27
plastic parts, service
considerations 25
ports
HDMI 6
product description 2
USB 2.0 6, 7
power button 4
power button board
removal 36
spare part number 10, 17, 36
power connector 7
power connector cable
removal 61
spare part number 11, 20, 61
power cord
set requirements 82
spare part numbers 16
power light 7
power requirements, product
description 2
processor, product description 1
product description
audio 1
chipset 1
display panel 1
external media cards 2
graphics 1
hard drive 1
memory 1
microphone 1
operating system 2
optical drive 1
ports 2
power requirements 2
processors 1
product name 1
security 2
serviceability 3
video 1
wireless 1
product name 1
product name and number,
computer 8
R
rear components 7
recover
options 71, 77
recovery
discs 71, 73, 76, 78
HP Recovery Manager 72, 77
media 73, 78
starting 73, 78
supported discs 71, 76
system 72, 77
USB ash drive 73, 78
using HP Recovery media 71, 76
recovery media
creating 70, 75
creating using HP Recovery
Manager 71, 76
recovery partition
removing 74, 79
regulatory information
regulatory label 8
wireless certication labels 8
removal/replacement
procedures 29
right-side components 7
Rubber Feet Kit, spare part number
16
Rubber Kit, spare part number 11,
17
S
Screw Kit, spare part number 16, 17
security cable slot 6
security, product description 2
serial number 8
serial number, computer 8
service considerations
cables 25
connectors 25
plastic parts 25
service labels, locating 8
serviceability, product description 3
SIM slot, identifying 7
speakers
location 7
removal 43
spare part number 11, 17, 43
specications
display 69
supported discs, recovery 71, 76
system board
removal 46
spare part numbers 18, 20, 46
system recovery 72, 77
system restore point
creating 71, 76
system restore point, creating 70,
75
T
tools required 25
TouchPad
removal 35
spare part number 10, 17, 20,
35
TouchPad cable
spare part number 10, 24, 35
86 Index
TouchPad zone 4
transporting guidelines 27
traveling with the computer 8
U
USB 2.0 port 7
USB 3.0 port 6
USB/card reader board
removal 42
spare part number 11, 17, 42
V
video, product description 1
W
webcam light 5
webcam, location 5
webcam/microphone module
removal 50, 57
spare part number 12, 14, 20,
50, 58
Windows
system restore point 70, 71, 75,
76
Windows key 4
Windows tools
using 71, 76
wireless antenna
location 4
removal 54, 60
spare part number 13, 15, 17,
55, 61
wireless certication label 8
wireless, product description 1
WLAN device 8
WLAN label 8
WLAN module
removal 37
spare part numbers 10, 16, 17,
37
workstation guidelines 27
WWAN module
removal 39
spare part numbers 10, 39
Index 87
Loading...
