Desktop Management Guide
HP Client Management Solutions provides standards-based solutions
for managing and controlling desktops, workstations, and notebook
PCs in a networked environment. HP pioneered desktop
manageability in 1995 with the introduction of the industry’s first
fully manageable desktop personal computers. HP is a patent holder
of manageability technology. Since then, HP has led an industry-wide
effort to develop the standards and infrastructure required to
effectively deploy, configure, and manage desktops, workstations, and
notebook PCs. HP Client Management Solutions are an important
aspect of our broad commitment to providing you with PC Lifecycle
Solutions that assist you during the four phases of the desktop PC
lifecycle—planning, deployment, management, and transitions.
The key capabilities and features of desktop management are:
■ Initial configuration and deployment
■ Remote system installation
■ Software updating and management
■ ROM flash
■ Asset tracking and security
■ Fault notification and recovery
Support for specific features described in this guide may vary by
✎
model or software version.
Desktop Management Guide www.hp.com 1
Desktop Management Guide
Initial Configuration and Deployment
The computer comes with a preinstalled system software image. After
a brief software “unbundling” process, the computer is ready to use.
You may prefer to replace the preinstalled software image with a
customized set of system and application software. There are several
methods for deploying a customized software image. They include:
■ Installing additional software applications after unbundling the
preinstalled software image.
■ Using software deployment tools, such as Altiris Deployment
Solution, to replace the preinstalled software with a customized
software image.
■ Using a disk cloning process to copy the contents from one hard
drive to another.
The best deployment method depends on your information
technology environment and processes. The PC Deployment section
of the HP Lifecycle Solutions Web site
(
http://whp-sp-orig.extweb.hp.com/country/us/en/solutions.html)
provides information to help you select the best deployment method.
The Restore Plus! CD, ROM-based setup, and ACPI hardware
provide further assistance with recovery of system software,
configuration management and troubleshooting, and power
management.
Altiris Deployment Solution Agent
If the computer is running Windows® XP Professional, Altiris
Deployment Solution Agent is pre-loaded on the computer. When
installed, it enables communication with the administrator
Deployment Solution console.
To install Altiris Deployment Solution Agent:
1. Click Start.
2. Click All Programs.
3. Click Software Setup.
4. Click Next.
5. Scroll down and click on the link to install Altiris AClient.
2 www.hp.com Desktop Management Guide
HP Local Recovery
Local Recovery backs-up data and system files to a protected area on
the hard drive. If data or files are lost, deleted, or corrupted, Local
Recovery can be used to retrieve data or restore the last good system
image.
To install this pre-loaded program:
1. Click Start.
2. Click Local Recovery.
3. Click Next.
4. Scroll down and click on the link to install HP Local Recovery.
Remote System Installation
Remote System Installation allows you to set up the system using the
software and configuration information located on a network server
by initiating the Preboot Execution Environment (PXE). The Remote
System Installation feature is usually used as a system setup and
configuration tool, and can be used for the following tasks:
Desktop Management Guide
■ Formatting a hard drive
■ Deploying a software image on one or more new PCs
■ Remotely updating the system BIOS in flash ROM (“Remote
ROM Flash” on page 11)
■ Configuring the system BIOS settings
To initiate Remote System Installation, press
F12 when the
F12 = Network Service Boot message appears in the lower-right
corner of the HP logo screen. Follow the instructions on the screen
to continue the process. The default boot order is a BIOS
configuration setting that can be changed to always attempt to PXE
boot.
HP and Altiris have partnered to provide tools designed to make the
task of corporate PC deployment and management easier and less
time-consuming, ultimately lowering the total cost of ownership and
making HP PCs the most manageable client PCs in the enterprise
environment.
Desktop Management Guide www.hp.com 3
Desktop Management Guide
Software Updating and Management
HP provides several tools for managing and updating software on
desktops, workstations, and notebooks:
■ HP System Software Manager
■ HP Client Manager
■ HP Client Management Solutions using Altiris
■ HP Local Recovery
■ Dantz Backup and Recovery
■ HP Proactive Change Notification
■ HP Subscriber's Choice
HP System Software Manager
HP System Software Manager (SSM) is a free utility that automates
remote deployment of device drivers and BIOS updates for your
networked HP business PCs. When SSM runs, it silently (without
user interaction) determines the revision levels of drivers and BIOS
installed on each networked client system and compares this
inventory against system software SoftPaqs that have been tested and
stored in a central file store. SSM then automatically updates any
down-revision system software on the networked PCs to the later
levels available in the file store. Since SSM only allows distribution
of SoftPaq updates to the correct client system models, administrators
can confidently and efficiently use SSM to keep system software
updated.
System Software Manager integrates with enterprise software
distribution tools such as HP OpenView and Microsoft® Systems
Management Server (SMS). Using SSM, you can distribute
customer-created or third-party updates that have been packaged in
the SSM-format.
SSM may be downloaded at no charge by visiting
www.hp.com/go/ssm.
4 www.hp.com Desktop Management Guide
HP Client Manager
HP Client Manager, developed with Altiris, is available free for all
supported HP business desktop, notebook, and workstation models.
SSM is integrated into HP Client Manager, and enables central
tracking, monitoring, and management of the hardware aspects of HP
client systems.
Use HP Client Manager to:
■ Get valuable hardware information such as CPU, memory, video,
and security settings
■ Monitor system health to fix problems before they occur
■ Automatically collect and remotely distribute SoftPaqs that will
update the hardware's BIOS, drivers, and security settings
■ Remotely configure BIOS and security settings
■ Automate processes to quickly resolve hardware problems
HP Client Manager uses the same Altiris infrastructure as the other
Altiris client lifecycle management solutions. This design provides a
significant benefit for the IT staff, since only one infrastructure needs
to be setup and maintained. Since information is stored in one
database, you get complete and consistent inventory reports as well as
system health and security information. You use a single, consistent
console interface for scheduling and tracking progress of both
hardware and software management tasks for your client systems.
Desktop Management Guide
For more information on HP Client Manager, visit
http://h18000.www1.hp.com/im/client_mgr.html.
Desktop Management Guide www.hp.com 5
Desktop Management Guide
HP Client Management Solutions using Altiris
Additional Altiris client management solutions can be purchased
through HP that complement the hardware management capabilities
of HP Client Manager. These Altiris solutions address client IT
lifecycle challenges including:
■ Inventory assessment
■ Software license compliance
■ Personality migration
■ Software image deployment
■ Software distribution
■ Asset management
■ Client backup and recovery
■ Problem resolution
For more information on HP Client Management Solutions using
Altiris, visit
HP and Altiris have a unique alliance that extends beyond sales and
marketing to include joint development and technology sharing that
spans HP Client, Server, OpenView, and Services groups to provide
best-of-breed solutions for HP partners and customers.
www.hp.com/go/easydeploy.
Starting in 1999, Compaq personal systems group and Altiris entered
into an alliance to combine the strength of Compaq as a pioneer in PC
hardware and manageability with the strength of Altiris' PC
deployment and migration capabilities. The relationship expanded
into a strategic alliance with the introduction of comprehensive
cost-reducing IT lifecycle management solutions including the jointly
developed HP Client Manager, which provides best-of-breed
hardware management for HP PCs.
Building upon the success of the personal systems group, in 2001 the
industry standard servers group introduced the ProLiant Essentials
Rapid Deployment Pack, an OEM version of Altiris Deployment
Solution combined with HP's SmartStart Toolkit. HP utilizes this
solution for provisioning ProLiant servers (including blade servers) as
well as Blade PCs, a core component of HP's Consolidated Client
Infrastructure.
6 www.hp.com Desktop Management Guide
Desktop Management Guide
Following the HP and Compaq merger, the alliance has continued to
expand with the following offerings:
■ Altiris Deployment Solution is available for a free 30-day trial for
HP business PCs, after which a license may be purchased.
■ HP Local Recovery, a client backup/recovery utility, is available
for free with HP business PCs.
■ Altiris Connector for HP OpenView provides client inventory
and event integration with HP OpenView Network Node
Manager, Operations, and Service Desk.
■ Altiris Connector for HP Systems Insight Manager enables
consolidated deployment and management of HP clients and
servers from the HP Systems Insight Manager console.
HP leads the market by offering a single management solution and
console for deploying and configuring PCs, handhelds, thin clients,
and Windows and Linux servers plus rich integration with HP
enterprise management tools. HP offers extensive training and
services expertise available from the HP Services organization and
Altiris. This combination of HP Client Management Solutions and
services capability provides the best choice for customers trying to
reduce the cost and complexity of managing client systems.
HP Local Recovery
Local Recovery provides data and system file protection for HP
business desktops, notebooks, and workstations. With Local
Recovery, you can quickly recover and get back to work when
information is accidentally deleted or your operating system is
corrupted. Designed for disconnected or seldom-connected users,
Local Recovery protects your HP computer's data and system state
through scheduled snapshots stored in a protected area on the local
hard disk. You can initiate a backup or restore by simply clicking your
mouse or pressing the F11 key in a pre-boot environment. System
backup and disaster recovery is now easy for all users regardless of
connectivity.
Local Recovery is available for free with HP business PCs. Two
additional client recovery products are also available. Upgrading to
these products provides you with additional recovery features:
Desktop Management Guide www.hp.com 7
Desktop Management Guide
■ Local Recovery Pro—Provides all the capabilities of Local
Recovery plus support for backup and recovery to a secondary
hard drive and for open and locked files. During a backup
snapshot, open/locked file support preserves information in open
applications such as E-mail messages, presentations, and word
processing documents.
■ Recovery Solution—Provides complete enterprise-level backup
and recovery of PC's from a central administrative console. The
solution supports data backup to a protected area on the local hard
disk drive as well as to a network storage area. This
network-based recovery feature provides a high level of
protection against data lost due to hard drive failure or stolen and
misplaced PCs.
For more information on HP Local Recovery, visit
www.hp.com/go/easydeploy.
Dantz Retrospect Express
Dantz Retrospect Express protects a single Windows desktop or
notebook computer. Retrospect Express allows recovery from data
loss due to viruses, newly installed software, user error, damaged
hardware, hardware upgrades, hackers, and lost or stolen computers.
It offers a choice between simple duplicates or comprehensive
backups and an intuitive setup wizard to get you up and running in
minutes. Retrospect Express comes with Disaster Recovery built into
the product for the best protection available.
of hardware manufacturers who bundle Retrospect with their products
and to learn where to buy these products.
Click here to view a list
Install Retrospect Express and perform your first backup in less than
two minutes. With Retrospect, you can implement a backup plan by
answering a few simple questions. Restores are quick and painless.
When you need to perform a restore, Retrospect Express
automatically locates files even if you do not know which piece of
backup media contains the files.
Duplicate Files and Folders to an External Hard Drive with the Push
of a Button. The duplicate operation copies information from the
computer's hard drive to the external hard drive. (For external hard
drives with a built-in backup button, duplicates can be initiated
simply by pressing the button.) With duplicates, the files and folders
on the external hard drive can be easily viewed, manipulated, and
8 www.hp.com Desktop Management Guide
restored by using Windows Explorer. The duplication process saves
space by overwriting any previous backup data on the external drive
and saves time by copying only files that are new or that have changed
since the last backup.
Back Up Multiple Versions of Files and Folders. Comprehensive
backups retain prior versions of files and folders and allow you to roll
back a computer to any prior point in time before a data-corrupting
event occurred. Each time a backup operation is performed,
Retrospect Express creates a restore point, which can contain all the
information a user needs to retrieve files or restore an entire computer
(disaster recovery)—including all operating system files and settings,
device drivers, and applications and their settings. Restore points are
captured quickly and they provide 100% accurate restores to any
point in time that a backup was performed—exceeding the capability
of other backup software.
For more information on Dantz Retrospect Express, visit
http://www.dantz.com/en/products/win_express/index.dtml.
Proactive Change Notification
Desktop Management Guide
The Proactive Change Notification program uses the Subscriber's
Choice Web site in order to proactively and automatically:
■ Send you Proactive Change Notification (PCN) E-mails
informing you of hardware and software changes to most
commercial computers and servers, up to 60 days in advance
■ Send you E-mail containing Customer Bulletins, Customer
Advisories, Customer Notes, Security Bulletins, and Driver alerts
for most commercial computers and servers
You create your own profile to ensure that you only receive the
information relevant to a specific IT environment. To learn more
about the Proactive Change Notification program and create a custom
profile, visit
Desktop Management Guide www.hp.com 9
http://www.hp.com/go/pcn.
Desktop Management Guide
Subscriber’s Choice
Subscriber’s Choice is a client-based service from HP. Based on
your profile, HP will supply you with personalized product tips,
feature articles, and/or driver and support alerts/notifications.
Subscriber’s Choice Driver and Support Alerts/Notifications will
deliver E-mails notifying you that the information you subscribed to
in your profile is available for review and retrieval. To learn more
about Subscriber’s Choice and create a custom profile, visit
http://www.hp.com/go/pcn.
Retired Solutions
The Desktop Management Task Force (DMTF) introduced the
Desktop Management Interface (DMI) standard almost ten years ago.
Due to new standards adoption such as the Common Information
Model (CIM), the DMTF has initiated end-of-life for DMI. Given
other advancements in HP Client Management Solutions, HP
Systems Insight Manager, and Microsoft's implementation of CIM,
known as Windows Management Instrumentation (WMI), the HP
Insight Management Agent is no longer being provided on new HP
commercial desktop, workstation, and notebook models introduced
after January 1, 2004.
The Insight Management (IM) Agent provided the following features:
■ DMI support allowed a client system to be managed by Insight
Manager 7 or other DMI-compliant management applications.
■ A Web agent allowed the system to be managed both locally and
remotely by a web browser.
■ Health alerting could notify the user locally or be sent to a central
console.
Insight Manager has been replaced by HP Systems Insight Manager
Software (HP SIM). HP SIM uses WMI to retrieve client system
information. The Altiris Connector for HP Systems Insight Manager
is available and enables the HP Client Management Solutions through
the HP SIM console.
10 www.hp.com Desktop Management Guide
ROM Flash
Ä
Desktop Management Guide
While local alerting is currently not supported with HP Client
Management Solutions, health alerts are reported to a system
management console. Microsoft WMI is standard with Windows XP.
WMI provides hardware inventory and alert information directly
through the Windows OS to a system management application.
The computer comes with a programmable flash ROM (read only
memory). By establishing a setup password in the Computer Setup
(F10) Utility, you can protect the ROM from being unintentionally
updated or overwritten. This is important to ensure the operating
integrity of the computer. Should you need or want to upgrade the
ROM, you may:
■ Order an upgraded ROMPaq diskette from HP.
■ Download the latest ROMPaq images from HP driver and support
http://www.hp.com/support/files.
page,
CAUTION: For maximum ROM protection, be sure to establish a setup
password. The setup password prevents unauthorized ROM upgrades.
System Software Manager allows the system administrator to set the setup
password on one or more PCs simultaneously. For more information, visit
http://www.hp.com/go/ssm.
Remote ROM Flash
Remote ROM Flash allows the system administrator to safely
upgrade the ROM on remote HP computers directly from the
centralized network management console. Enabling the system
administrator to perform this task remotely, on multiple computers
and personal computers, results in a consistent deployment of and
greater control over HP PC ROM images over the network. It also
results in greater productivity and lower total cost of ownership.
The computer must be powered on, or turned on through Remote
✎
Wakeup, to take advantage of Remote ROM Flash.
For more information on Remote ROM Flash, refer to HP Client
Manager or System Software Manager at
http://h18000.www1.hp.com/im/prodinfo.html.
Desktop Management Guide www.hp.com 11
Desktop Management Guide
HPQFlash
The HPQFlash utility is used to locally update or restore the system
ROM on individual PCs through a Windows operating system.
For more information on HPQFlash, visit
http://www.hp.com/support/files and enter the name of the computer
when prompted.
FailSafe Boot Block ROM
The FailSafe Boot Block ROM allows for system recovery in the
unlikely event of a ROM flash failure, for example, if a power
failure were to occur during a ROM upgrade. The Boot Block is
a flash-protected section of the ROM that checks for a valid system
ROM flash when power to the system is turned on.
■ If the system ROM is valid, the system starts normally.
■ If the system ROM fails the validation check, the FailSafe Boot
Block ROM provides enough support to start the system from a
ROMPaq diskette, which will program the system ROM with a
valid image.
Some models also support recovery from a ROMPaq CD. ISO
✎
ROMPaq images are included with some models in the downloadable
ROM softpaqs.
When the boot block detects an invalid system ROM, the System
Power LED blinks RED 8 times, one every second, followed by a
2-second pause. Also 8 simultaneous beeps will be heard. A Boot
Block recovery mode message is displayed on the screen (some
models).
To recover the system after it enters Boot Block recovery mode,
complete the following steps:
1. If there is a diskette in the diskette drive or a CD in the CD drive,
remove the diskette and CD and turn off the power.
2. Insert a ROMPaq diskette into the diskette drive or, if permitted
on this computer, a ROMPaq CD into the CD drive.
12 www.hp.com Desktop Management Guide
Desktop Management Guide
3. Turn on the computer.
If no ROMPaq diskette or ROMPaq CD is found, you will be
prompted to insert one and restart the computer.
If a setup password has been established, the Caps Lock light will
turn on and you will be prompted to enter the password.
4. Enter the setup password.
If the system successfully starts from the diskette and
successfully reprograms the ROM, then the three keyboard lights
will turn on. A rising tone series of beeps also signals successful
completion.
5. Remove the diskette or CD and turn the power off.
6. Turn the power on again to restart the computer.
The following table lists the various keyboard light combinations
used by the Boot Block ROM (when a PS/2 keyboard is attached to
the computer), and explains the meaning and action associated with
each combination.
Keyboard Light Combinations Used by Boot Block ROM
FailSafe Boot
Block Mode
Num Lock Green On ROMPaq diskette or ROMPaq CD
Caps Lock Green On Enter password.
Num, Caps,
Scroll Lock
Num, Caps,
Scroll Lock
Diagnostic lights do not flash on USB keyboards.
✎
Desktop Management Guide www.hp.com 13
Keyboard
LED Color
Green Blink On in
Green On Boot Block ROM Flash successful.
Keyboard
LED Activity State/Message
not present, is bad, or drive not
ready.
Keyboard locked in network mode.
sequence, one at
a time—N, C, SL
Turn power off, then on to reboot.
Desktop Management Guide
Replicating the Setup
The following procedures give an administrator the ability to easily
copy one setup configuration to other computers of the same model.
This allows for faster, more consistent configuration of multiple
computers.
Both procedures require a diskette drive or a supported USB flash
✎
media device, such as an HP Drive Key.
To collect and replicate BIOS settings on multiple computers, use
✎
System Software Manager or HP Client Manger Software. For more
information visit http://www.hp.com/go/EasyDeploy.
Copying to Single Computer
CAUTION: A setup configuration is model-specific. File system
Ä
corruption may result if source and target computers are not the same
model. For example, do not copy the setup configuration from an
Ultra-Slim Desktop to a Microtower.
1. Select a setup configuration to copy. Turn off the computer. If
you are in Windows, click Start > Shut Down > Shut Down.
2. If you are using a USB flash media device, insert it now.
3. Turn on the computer.
4. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
5. If you are using a a diskette, insert it now.
6. Click File > Replicated Setup > Save to Removable Media.
Follow the instructions on the screen to create the configuration
diskette or USB flash media device.
14 www.hp.com Desktop Management Guide
F10 when the monitor light turns green to
F10 when the
Enter to
Desktop Management Guide
7. Turn off the computer to be configured and insert the
configuration diskette or USB flash media device.
8. Turn on the computer to be configured.
9. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
10. Click File > Replicated Setup > Restore from Removable
Media, and follow the instructions on the screen.
11. Restart the computer when the configuration is complete.
Copying to Multiple Computers
CAUTION: A setup configuration is model-specific. File system
Ä
corruption may result if source and target computers are not the same
model. For example, do not copy the setup configuration from an
Ultra-Slim Desktop to a Microtower.
This method takes a little longer to prepare the configuration diskette
or USB flash media device, but copying the configuration to target
computers is significantly faster.
A bootable diskette is required for this procedure or to create a
✎
bootable USB flash media device. If Windows XP is not available to
use to create a bootable diskette, use the method for copying to a
single computer instead (see “Copying to Single Computer” on
page 14).
F10 when the
Enter to
1. Create a bootable diskette or USB flash media device. See
“Supported USB Flash Media Device” on page 17, “Supported
USB Flash Media Device” on page 17, or “Unsupported USB
Flash Media Device” on page 20.
Desktop Management Guide www.hp.com 15
Desktop Management Guide
Ä
CAUTION: Not all computers can be booted from a USB flash media
device. If the default boot order in the Computer Setup (F10) Utility lists
the USB device before the hard drive, the computer can be booted from a
USB flash media device. Otherwise, a bootable diskette must be used.
Some Systems allow the boot device to be selected during POST. As soon
as the computer is turned on, press
green, then follow the on screen instructions when prompted.
F9 when the monitor light turns
2. Select a setup configuration to copy. Turn off the computer. If
you are in Windows, click Start > Shut Down > Shut Down.
3. If you are using a USB flash media device, insert it now.
4. Turn on the computer.
5. As soon as the computer is turned on, press
F10 when the
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
F10 when the monitor light turns green to
access the utility.
6. If you are using a a diskette, insert it now.
7. Click File > Replicated Setup > Save to Removable Media.
Follow the instructions on the screen to create the configuration
diskette or USB flash media device.
8. Download a BIOS utility for replicating setup (repset.exe) and
copy it onto the configuration diskette or USB flash media
device. To obtain this utility, go to
http://welcome.hp.com/support/files
and enter the model
number of the computer.
9. On the configuration diskette or USB flash media device, create
an autoexec.bat file containing the following command:
repset.exe
10. Turn off the computer to be configured. Insert the configuration
diskette or USB flash media device and turn the computer on.
The configuration utility will run automatically.
Enter to
11. Restart the computer when the configuration is complete.
16 www.hp.com Desktop Management Guide
Creating a Bootable Device
Supported USB Flash Media Device
Supported devices, such as an HP Drive Key or a DiskOnKey, have a
preinstalled image to simplify the process of making them bootable.
If the USB flash media device being used does not have this image,
use the procedure later in this section (see “Unsupported USB Flash
Media Device” on page 20).
CAUTION: Not all computers can be booted from a USB flash media
Ä
device. If the default boot order in the Computer Setup (F10) Utility lists
the USB device before the hard drive, the computer can be booted from a
USB flash media device. Otherwise, a bootable diskette must be used.
To create a bootable USB flash media device, you must have:
■ a supported USB flash media device
■ a bootable DOS diskette with the FDISK and SYS programs (If
SYS is not available, FORMAT may be used, but all existing files
on the USB flash media device will be lost.)
Desktop Management Guide
■ a PC that is bootable from a USB flash media device
CAUTION: Some older PCs may not be bootable from a USB flash
Ä
media device. If the default boot order in the Computer Setup (F10) Utility
lists the USB device before the hard drive, the computer can be booted
from a USB flash media device. Otherwise, a bootable diskette must be
used.
1. Turn off the computer.
2. Insert the USB flash media device into one of the computer's
USB ports and remove all other USB storage devices except USB
diskette drives.
3. Insert a bootable DOS diskette with FDISK.COM and either
SYS.COM or FORMAT.COM into a diskette drive and turn on
the computer to boot to the DOS diskette.
4. Run FDISK from the A:\ prompt by typing
Enter. If prompted, click Yes (Y) to enable large disk support.
Desktop Management Guide www.hp.com 17
FDISK and pressing
Desktop Management Guide
Ä
5. Enter Choice [5] to display the drives in the system. The USB
flash media device will be the drive that closely matches the size
of one of the drives listed. It will usually be the last drive in the
list. Note the letter of the drive.
USB flash media device drive: __________
CAUTION: If a drive does not match the USB flash media device, do
not proceed. Data loss can occur. Check all USB ports for additional
storage devices. If any are found, remove them, reboot the computer,
and proceed from step 4. If none are found, either the system does not
support the USB flash media device or the USB flash media device is
defective. DO NOT proceed in attempting to make the USB flash media
device bootable.
6. Exit FDISK by pressing the Esc key to return to the A:\ prompt.
7. If your bootable DOS diskette contains SYS.COM, go to step 8.
Otherwise, go to step 9.
8. At the A:\ prompt, enter
letter noted above.
CAUTION: Be sure that you have entered the correct drive letter for the
Ä
USB flash media device.
After the system files have been transferred, SYS will return to
the A:\ prompt. Go to step 13.
9. Copy any files you want to keep from your USB flash media
device to a temporary directory on another drive (for example,
the system's internal hard drive).
10. At the A:\ prompt, enter
drive letter noted before.
CAUTION: Be sure that you have entered the correct drive letter for the
Ä
USB flash media device.
FORMAT will display one or more warnings and ask you each
time whether you want to proceed. Enter
will format the USB flash media device, add the system files, and
ask for a Volume Label.
11. Press
Enter for no label or enter one if desired.
SYS x: where x represents the drive
FORMAT /S X: where X represents the
Y each time. FORMAT
18 www.hp.com Desktop Management Guide
Desktop Management Guide
12. Copy any files you saved in step 9 back to your USB flash media
device.
13. Remove the diskette and reboot the computer. The computer will
boot to the USB flash media device as drive C.
The default boot order varies from computer to computer, and it can
✎
be changed in the Computer Setup (F10) Utility.
If you have used a DOS version from Windows 9x, you may see a
brief Windows logo screen. If you do not want this screen, add a
zero-length file named LOGO.SYS to the root directory of the USB
flash media device.
Return to “Copying to Multiple Computers” on page 15.
Desktop Management Guide www.hp.com 19
Desktop Management Guide
Ä
Ä
Unsupported USB Flash Media Device
CAUTION: Not all computers can be booted from a USB flash media
device. If the default boot order in the Computer Setup (F10) Utility lists
the USB device before the hard drive, the computer can be booted from a
USB flash media device. Otherwise, a bootable diskette must be used.
To create a bootable USB flash media device, you must have:
■ a USB flash media device
■ a bootable DOS diskette with the FDISK and SYS programs (If
SYS is not available, FORMAT may be used, but all existing files
on the USB flash media device will be lost.)
■ a PC that is bootable from a USB flash media device
CAUTION: Some older PCs may not be bootable from a USB flash
media device. If the default boot order in the Computer Setup (F10) Utility
lists the USB device before the hard drive, the computer can be booted
from a USB flash media device. Otherwise, a bootable diskette must be
used.
1. If there are any PCI cards in the system that have SCSI, ATA
RAID or SATA drives attached, turn off the computer and unplug
the power cord.
CAUTION: The power cord MUST be unplugged.
Ä
2. Open the computer and remove the PCI cards.
3. Insert the USB flash media device into one of the computer's
USB ports and remove all other USB storage devices except USB
diskette drives. Close the computer cover.
4. Plug in the power cord and turn on the computer.
5. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
20 www.hp.com Desktop Management Guide
F10 when the monitor light turns green to
F10 when the
Enter to
Desktop Management Guide
6. Go to Advanced > PCI Devices to disable both the PATA and
SATA controllers. When disabling the SATA controller, note the
IRQ to which the controller is assigned. You will need to reassign
the IRQ later. Exit setup, confirming the changes.
SATA IRQ: __________
7. Insert a bootable DOS diskette with FDISK.COM and either
SYS.COM or FORMAT.COM into a diskette drive and turn on
the computer to boot to the DOS diskette.
8. Run FDISK and delete any existing partitions on the USB flash
media device. Create a new partition and mark it active. Exit
FDISK by pressing the
Esc key.
9. If the system did not automatically restart when exiting FDISK,
press
Ctrl+Alt+Del to reboot to the DOS diskette.
10. At the A:\ prompt, type
FORMAT C: /S and press Enter. Format
will format the USB flash media device, add the system files, and
ask for a Volume Label.
11. Press
Enter for no label or enter one if desired.
12. Turn off the computer and unplug the power cord. Open the
computer and re-install any PCI cards that were previously
removed. Close the computer cover.
13. Plug in the power cord, remove the diskette, and turn on the
computer.
14. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
F10 when the
Enter to
bypass the title screen, if necessary.
15. Go to Advanced > PCI Devices and re-enable the PATA and
SATA controllers that were disabled in step 6. Put the SATA
controller on its original IRQ.
16. Save the changes and exit. The computer will boot to the USB
flash media device as drive C.
Desktop Management Guide www.hp.com 21
Desktop Management Guide
The default boot order varies from computer to computer, and it can
✎
be changed in the Computer Setup (F10) Utility. Refer to the
Computer Setup Guide on the Documentation CD for instructions.
If you have used a DOS version from Windows 9x, you may see a
brief Windows logo screen. If you do not want this screen, add a
zero-length file named LOGO.SYS to the root directory of the USB
flash media device.
Return to “Copying to Multiple Computers” on page 15.
Dual-State Power Button
With Advanced Configuration and Power Interface (ACPI) enabled,
the power button can function either as an on/off switch or as a
standby button. The stand-by feature does not completely turn off
power, but instead causes the computer to enter a low-power standby
state. This allows you to power down quickly without closing
applications and to return quickly to the same operational state
without any data loss.
To change the power button’s configuration, complete the following
steps:
1. Left click on the Start Button, then select Control Panel >
Power Options.
2. In the Power Options Properties, select the Advanced tab.
3. In the Power Button section, select Stand by.
After configuring the power button to function as a standby button,
press the power button to put the system in a very low power state
(standby). Press the button again to quickly bring the system out of
standby to full power status. To completely turn off all power to the
system, press and hold the power button for four seconds.
CAUTION: Do not use the power button to turn off the computer unless
Ä
the system is not responding; turning off the power without operating
system interaction could cause damage to or loss of data on the hard
drive.
22 www.hp.com Desktop Management Guide
World Wide Web Site
HP engineers rigorously test and debug software developed by HP
and third-party suppliers, and develop operating system specific
support software, to ensure performance, compatibility, and
reliability for HP computers.
When making the transition to new or revised operating systems,
it is important to implement the support software designed for that
operating system. If you plan to run a version of Microsoft Windows
that is different from the version included with the computer, you
must install corresponding device drivers and utilities to ensure that
all features are supported and functioning properly.
HP has made the task of locating, accessing, evaluating, and installing
the latest support software easier. You can download the software
from
http://www.hp.com/support.
The Web site contains the latest device drivers, utilities, and flashable
ROM images needed to run the latest Microsoft Windows operating
system on the HP computer.
Building Blocks and Partners
Desktop Management Guide
HP management solutions integrate with other systems management
applications, and are based on industry standards, such as:
■ Web-Based Enterprise Management (WBEM)
■ Windows Management Interface (WMI)
■ Wake on LAN Technology
■ ACPI
■ SMBIOS
■ Pre-boot Execution (PXE) support
Desktop Management Guide www.hp.com 23
Desktop Management Guide
Asset Tracking and Security
Asset tracking features incorporated into the computer provide key
asset tracking data that can be managed using HP Systems Insight
Manager, HP Client Manager or other system management
applications. Seamless, automatic integration between asset tracking
features and these products enables you to choose the management
tool that is best suited to the environment and to leverage the
investment in existing tools.
HP also offers several solutions for controlling access to valuable
components and information. ProtectTools Embedded Security, if
installed, p
integrity and authenticates third-party users attempting system access.
(Refer to the HP ProtectTools Security Manager Guide at
www.hp.com for more information.) Security features such as
ProtectTools, the Smart Cover Sensor and the Smart Cover Lock,
available on some models, help to prevent unauthorized access to the
internal components of the personal computer. By disabling parallel,
serial, or USB ports, or by disabling removable media boot capability,
you can protect valuable data assets. Memory Change and Smart
Cover Sensor alerts can be automatically forwarded to system
management applications to deliver proactive notification of
tampering with a computer’s internal components.
revents unauthorized access to data and checks system
Protect Tools, the Smart Cover Sensor, and the Smart Cover Lock are
✎
available as options on some systems.
Use the following utilities to manage security settings on the HP
computer:
■ Locally, using the Computer Setup Utilities. See the Computer
Setup (F10) Utility Guide on the Documentation CD included
with the computer for additional information and instructions on
using the Computer Setup Utilities.
■ Remotely, using HP Client Manager or System Software
Manager. This software enables the secure, consistent
deployment and control of security settings from a simple
command-line utility.
24 www.hp.com Desktop Management Guide
Desktop Management Guide
The following table and sections refer to managing security features
of the computer locally through the Computer Setup (F10) Utilities.
Security Features Overview
Option Description
Setup Password Allows you to set and enable setup (administrator) password.
If the setup password is set, it is required to change
✎
Computer Setup options, flash the ROM, and make
changes to certain plug and play settings under Windows.
See the Troubleshooting Guide on the Documentation CD for
more information.
Power-On Password Allows you to set and enable power-on password.
See the Troubleshooting Guide on the Documentation CD for
more information.
Password Options
(This selection will appear
only if a power-on password
is set.)
Pre-Boot Authorization
(available on some models)
Smart Cover
(available on some models)
For more information about Computer Setup, see the Computer Setup (F10) Utility Guide on the
✎
Documentation CD.
Support for security features may vary depending on the specific computer configuration.
Allows you to specify whether the password is required for
warm boot (CTRL+ALT+DEL).
Allows you to enable/disable the Smart Card to be used in
place of the Power-On Password.
Allows you to:
• Enable/disable the Cover Lock.
• Enable/disable the Cover Removal Sensor.
Notify User alerts the user that the sensor has detected that
✎
the cover has been removed. Setup Password requires that
the setup password be entered to boot the computer if the
sensor detects that the cover has been removed.
This feature is supported on some models only.
Desktop Management Guide www.hp.com 25
Desktop Management Guide
Security Features Overview (Continued)
Option Description
Embedded Security
(available on some models)
Device Security Enables/disables serial ports, parallel port, front USB ports,
Network Service Boot
(available on some models)
System IDs Allows you to set:
Allows you to:
• Enable/disable the Embedded Security device.
• Reset the device to Factory Settings.
This feature is supported on some models only. See the HP
ProtectTools Security Manager Guide at www.hp.com for
more information.
system audio, network controllers (some models), MultiBay
devices (some models), and SCSI controllers (some models).
Enables/disables the computer’s ability to boot from an
operating system installed on a network server. (Feature
available on NIC models only; the network controller must
reside on the PCI bus or be embedded on the system board.)
• Asset tag (18-byte identifier) and ownership Tag (80-byte
identifier displayed during POST).
• Chassis serial number or Universal Unique Identifier
(UUID) number. The UUID can only be updated if the
current chassis serial number is invalid. (These ID
numbers are normally set in the factory and are used to
uniquely identify the system.)
Keyboard locale setting (for example, English or German) for
System ID entry.
For more information about Computer Setup, see the Computer Setup (F10) Utility Guide on the
✎
Documentation CD.
Support for security features may vary depending on the specific computer configuration.
26 www.hp.com Desktop Management Guide
Security Features Overview (Continued)
Option Description
Desktop Management Guide
DriveLock
(available on some models)
For more information about Computer Setup, see the Computer Setup (F10) Utility Guide on the
✎
Documentation CD.
Support for security features may vary depending on the specific computer configuration.
Allows you to assign or modify a master or user password for
MultiBay hard drives (not supported on SCSI hard drives).
When this feature is enabled, the user is prompted to provide
one of the DriveLock passwords during POST. If neither is
successfully entered, the hard drive will remain inaccessible
until one of the passwords is successfully provided during a
subsequent cold-boot sequence.
This selection will only appear when at least one MultiBay
✎
drive that supports the DriveLock feature is attached to the
system.
Desktop Management Guide www.hp.com 27
Desktop Management Guide
Password Security
The power-on password prevents unauthorized use of the computer
by requiring entry of a password to access applications or data each
time the computer is turned on or restarted. The setup password
specifically prevents unauthorized access to Computer Setup, and can
also be used as an override to the power-on password. That is, when
prompted for the power-on password, entering the setup password
instead will allow access to the computer.
A network-wide setup password can be established to enable the
system administrator to log in to all network systems to perform
maintenance without having to know the power-on password.
System Software Manger and HP Client Manger Software allow
✎
remote management of Setup Passwords and other BIOS settings in a
networked environment. For more information, visit
http://www.hp.com/go/EasyDeploy.
Establishing a Setup Password Using Computer Setup
If the system is equipped with an embedded security device, refer to
the HP ProtectTools Security Manager Guide at
Establishing a setup password through Computer Setup prevents
reconfiguration of the computer (use of the Computer Setup (F10)
utility) until the password is entered.
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart.
2. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
3. Select Security, then select Setup Password and follow the
instructions on the screen.
4. Before exiting, click File > Save Changes and Exit.
28 www.hp.com Desktop Management Guide
F10 when the monitor light turns green to
www.hp.com.
F10 when the
Enter to
Establishing a Power-On Password Using Computer Setup
Establishing a power-on password through Computer Setup prevents
access to the computer when power is turned on, unless the password
is entered. When a power-on password is set, Computer Setup
presents Password Options under the Security menu. Password
options include Password Prompt on Warm Boot. When Password
Prompt on Warm Boot is enabled, the password must also be entered
each time the computer is rebooted.
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart.
Desktop Management Guide
2. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
3. Select Security, then Power-On Password and follow the
instructions on the screen.
4. Before exiting, click File > Save Changes and Exit.
Entering a Power-On Password
To enter a power-on password, complete the following steps:
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart the Computer.
2. When the key icon appears on the monitor, type the current
password, then press
Type carefully; for security reasons, the characters you type do not
✎
appear on the screen.
F10 when the
Enter to
F10 when the monitor light turns green to
Enter.
If you enter the password incorrectly, a broken key icon appears. Try
again. After three unsuccessful tries, you must turn off the computer,
then turn it on again before you can continue.
Desktop Management Guide www.hp.com 29
Desktop Management Guide
Entering a Setup Password
If the system is equipped with an embedded security device, refer to
the HP ProtectTools Security Manager Guide at
If a setup password has been established on the computer, you will be
prompted to enter it each time you run Computer Setup.
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart.
www.hp.com.
2. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
3. When the key icon appears on the monitor, type the setup
password, then press
Type carefully; for security reasons, the characters you type do not
✎
appear on the screen.
If you enter the password incorrectly, a broken key icon appears. Try
again. After three unsuccessful tries, you must turn off the computer,
then turn it on again before you can continue.
F10 when the monitor light turns green to
Enter.
F10 when the
Enter to
30 www.hp.com Desktop Management Guide
Changing a Power-On or Setup Password
If the system is equipped with an embedded security device, refer to
the HP ProtectTools Security Manager Guide at
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart the Computer.
Desktop Management Guide
www.hp.com.
2. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
3. When the key icon appears, type the current password, a slash (/)
or alternate delimiter character, the new password, another slash
(/) or alternate delimiter character, and the new password again
as shown:
current password/new password/new password
Type carefully; for security reasons, the characters you type do not
✎
appear on the screen.
4. Press
The new password takes effect the next time you turn on the
computer.
Refer to the “National Keyboard Delimiter Characters” on page 32
✎
for information about the alternate delimiter characters. The
power-on password and setup password may also be changed using
the Security options in Computer Setup.
Enter.
F10 when the monitor light turns green to
F10 when the
Enter to
Desktop Management Guide www.hp.com 31
Desktop Management Guide
Deleting a Power-On or Setup Password
If the system is equipped with an embedded security device, refer to
the HP ProtectTools Security Manager Guide at
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart the Computer.
www.hp.com.
2. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
3. When the key icon appears, type the current password followed
by a slash (/) or alternate delimiter character as shown:
current password/
4. Press Enter.
Refer to “National Keyboard Delimiter Characters” for information
✎
about the alternate delimiter characters. The power-on password and
setup password may also be changed using the Security options in
Computer Setup.
F10 when the monitor light turns green to
National Keyboard Delimiter Characters
Each keyboard is designed to meet country-specific requirements.
The syntax and keys that you use to change or delete the password
depend on the keyboard that came with the computer.
F10 when the
Enter to
National Keyboard Delimiter Characters
Arabic / Greek - Russian /
Belgian = Hebrew . Slovakian BHCSY* - Hungarian - Spanish Brazilian / Italian - Swedish/Finnish /
Chinese / Japanese / Swiss Czech - Korean / Taiwanese /
Danish - Latin American - Thai /
32 www.hp.com Desktop Management Guide
National Keyboard Delimiter Characters
Arabic / Greek - Russian /
French ! Norwegian - Turkish .
French
Canadian
German - Portuguese - U.S. English /
* For Bosnia-Herzegovina, Croatia, Slovenia, and Yugoslavia
Clearing Passwords
If you forget the password, you cannot access the computer. Refer to
the Troubleshooting Guide on the Documentation CD for instructions
on clearing passwords.
If the system is equiped with an embedded security device, refer to
the HP ProtectTools Security Manager Guide at
DriveLock
DriveLock, available on some models, is an industry-standard
security feature that prevents unauthorized access to the data on
MultiBay hard drives. DriveLock has been implemented as an
extension to Computer Setup. It is only available when
DriveLock-capable hard drives are detected.
Desktop Management Guide
é Polish - U.K. English /
www.hp.com.
DriveLock is intended for HP customers for whom data security is the
paramount concern. For such customers, the cost of the hard drive
and the loss of the data stored on it is inconsequential when compared
with the damage that could result from unauthorized access to its
contents. In order to balance this level of security with the practical
need to accomodate a forgotten password, the HP implementation of
DriveLock employs a two-password security scheme. One password
is intended to be set and used by a system administrator while the
other is typically set and used by the end-user. There is no
“back-door” that can be used to unlock the drive if both passwords
are lost. Therefore, DriveLock is most safely used when the data
contained on the hard drive is replicated on a corporate information
system or is regularly backed up.
Desktop Management Guide www.hp.com 33
Desktop Management Guide
Using DriveLock
In the event that both DriveLock passwords are lost, the hard drive
is rendered unusable. For users who do not fit the previously defined
customer profile, this may be an unacceptable risk. For users who do
fit the customer profile, it may be a tolerable risk given the nature of
the data stored on the hard drive.
The DriveLock option appears under the Security menu in Computer
Setup. The user is presented with options to set the master password
or to enable DriveLock. A user password must be provided in order
to enable DriveLock. Since the initial configuration of DriveLock is
typically performed by a system administrator, a master password
should be set first. HP encourages system administrators to set a
master password whether they plan to enable DriveLock or keep
it disabled. This will give the administrator the ability to modify
DriveLock settings if the drive is locked in the future. Once the
master password is set, the system administrator may enable
DriveLock or choose to keep it disabled.
If a locked hard drive is present, POST will require a password to
unlock the device. If a power-on password is set and it matches the
device’s user password, POST will not prompt the user to re-enter the
password. Otherwise, the user will be prompted to enter a DriveLock
password. Either the master or the user password may be used. Users
will have two attempts to enter a correct password. If neither attempt
succeeds, POST will continue but the drive will remain inaccessible.
DriveLock Applications
The most practical use of the DriveLock security feature is in a
corporate environment where a system administrator provides users
with MultiBay hard drives for use in some computers. The system
administrator would be responsible for configuring the MultiBay hard
drive which would involve, among other things, setting the
DriveLock master password. In the event that the user forgets the user
password or the equipment is passed on to another employee, the
master password can always be used to reset the user password and
regain access to the hard drive.
HP recommends that corporate system administrators who choose to
enable DriveLock also establish a corporate policy for setting and
maintaing master passwords. This should be done to prevent a
34 www.hp.com Desktop Management Guide
situation where an employee intentionally or unintentionally sets both
DriveLock passwords before leaving the company. In such a scenario,
the hard drive would be rendered unusable and require replacement.
Likewise, by not setting a master password, system administrators
may find themselves locked out of a hard drive and unable to perform
routine checks for unauthorized software, other asset control
functions, and support.
For users with less stringent security requirements, HP does not
recommend enabling DriveLock. Users in this category include
personal users or users who do not maintain sensitive data on their
hard drives as a common practice. For these users, the potential loss
of a hard drive resulting from forgetting both passwords is much
greater than the value of the data DriveLock has been designed to
protect. Access to Computer Setup and DriveLock can be restricted
through the Setup password. By specifying a Setup password and not
giving it to end users, system administrators are able to restrict users
from enabling DriveLock.
Smart Cover Sensor
Smart Cover Sensor, available on some models, is a combination
of hardware and software technology that can alert you when the
computer cover or side panel has been removed. There are three
levels of protection, as described in the following table.
Desktop Management Guide
Smart Cover Sensor Protection Levels
Level Setting Description
Level 0 Disabled Smart Cover Sensor is disabled (default).
Level 1 Notify User When the computer is restarted, the screen
displays a message indicating that the computer
cover or side panel has been removed.
Level 2 Setup Password When the computer is restarted, the screen
displays a message indicating that the computer
cover or side panel has been removed. You must
enter the setup password to continue.
These settings can be changed using Computer Setup. For more information about Computer
✎
Setup, see the Computer Setup (F10) Utility Guide on the Documentation CD.
Desktop Management Guide www.hp.com 35
Desktop Management Guide
Setting the Smart Cover Sensor Protection Level
To set the Smart Cover Sensor protection level, complete the
following steps:
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart.
2. As soon as the computer is turned on, press
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
3. Select Security > Smart Cover > Cover Removal Sensor, and
4. Before exiting, click File > Save Changes and Exit.
Smart Cover Lock
The Smart Cover Lock is a software-controllable cover lock featured
on some HP computers. This lock prevents unauthorized access to the
internal components. Computers ship with the Smart Cover Lock in
the unlocked position.
CAUTION: For maximum cover lock security, be sure to establish a
Ä
setup password. The setup password prevents unauthorized access to the
Computer Setup utility.
F10 when the
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
F10 when the monitor light turns green to
select the desired security level.
Enter to
The Smart Cover Lock is available as an option on some systems.
✎
36 www.hp.com Desktop Management Guide
Locking the Smart Cover Lock
To activate and lock the Smart Cover Lock, complete the following
steps:
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart.
Desktop Management Guide
2. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
3. Select Security > Smart Cover > Cover Lock > Lock option.
4. Before exiting, click File > Save Changes and Exit.
Unlocking the Smart Cover Lock
1. Turn on or restart the computer. If you are in Windows, click
Start > Shut Down > Restart.
2. As soon as the computer is turned on, press
monitor light turns green to enter Computer Setup. Press
bypass the title screen, if necessary.
If you do not press F10 at the appropriate time, you must restart the
✎
computer and again press
access the utility.
F10 when the
Enter to
F10 when the monitor light turns green to
F10 when the
Enter to
F10 when the monitor light turns green to
3. Select Security > Smart Cover > Cover Lock > Unlock.
4. Before exiting, click File > Save Changes and Exit.
Desktop Management Guide www.hp.com 37
Desktop Management Guide
Using the Smart Cover FailSafe Key
If you enable the Smart Cover Lock and cannot enter the password to
disable the lock, you will need a Smart Cover FailSafe Key to open
the computer cover. You will need the key in any of the following
circumstances:
■ Power outage
■ Startup failure
■ PC component failure (such as processor or power supply)
■ Forgotten password
CAUTION: The Smart Cover FailSafe Key is a specialized tool available
Ä
from HP. Be prepared; order this key before you need one at an
authorized reseller or service provider.
To obtain the FailSafe Key, do any one of the following:
■ Contact an authorized HP reseller or service provider.
■ Call the appropriate number listed in the warranty.
For more information about using the Smart Cover FailSafe Key,
consult the Hardware Reference Guide on the Documentation CD.
Cable Lock Provision
The rear panel of the computer accommodates a cable lock so that the
computer can be physically secured to a work area.
For illustrated instructions, please see the Hardware Reference Guide
on the Documentation CD.
38 www.hp.com Desktop Management Guide
Fingerprint Identification Technology
Eliminating the need to enter user passwords, HP Fingerprint
Identification Technology tightens network security, simplifies the
login process, and reduces the costs associated with managing
corporate networks. Affordably priced, it is not just for high-tech,
high-security organizations anymore.
Support for Fingerprint Identification Technology varies by model.
✎
For more information, visit:
http://h18004.www1.hp.com/products/security/.
Fault Notification and Recovery
Fault Notification and Recovery features combine innovative
hardware and software technology to prevent the loss of critical data
and minimize unplanned downtime.
If the computer is connected to a network managed by HP Client
Manager, the computer sends a fault notice to the network
management application. With HP Client Manager, you can also
remotely schedule diagnostics to automatically run on all managed
PCs and create a summary report of failed tests.
Desktop Management Guide
Drive Protection System
The Drive Protection System (DPS) is a diagnostic tool built into the
hard drives installed in some HP computers. DPS is designed to help
diagnose problems that might result in unwarranted hard drive
replacement.
When HP computers are built, each installed hard drive is tested using
DPS, and a permanent record of key information is written onto the
drive. Each time DPS is run, test results are written to the hard drive.
The service provider can use this information to help diagnose
conditions that caused you to run the DPS software. Refer to the
Troubleshooting Guide on the Documentation CD for instructions on
using DPS.
Desktop Management Guide www.hp.com 39
Desktop Management Guide
Surge-Tolerant Power Supply
An integrated surge-tolerant power supply provides greater reliability
when the computer is hit with an unpredictable power surge. This
power supply is rated to withstand a power surge of up to 2000 volts
without incurring any system downtime or data loss.
Thermal Sensor
The thermal sensor is a hardware and software feature that tracks the
internal temperature of the computer. This feature displays a warning
message when the normal range is exceeded, which gives you time to
take action before internal components are damaged or data is lost.
40 www.hp.com Desktop Management Guide
Index
A
access to computer, controlling 24
6
Altiris
AClient 2
Deployment Solution Agent 2
asset tracking 24
B
bootable device
creating 17 to 21
DiskOnKey 17 to 22
HP Drive Key 17 to 22
USB flash media device 17 to 22
C
cable lock provision 38
cautions
cover lock security 36
FailSafe Key 38
protecting ROM 11
change notification 9
changing operating systems, important
information
changing password
clearing password
cloning tools, software
Computer Setup Utilities
configuring power button
controlling access to computer
cover lock security, caution
cover lock, smart
customizing software
23
31
33
2
14
22
24
36
36
2
D
Dantz Retrospect Express 8
deleting password
delimiter characters, table
deployment tools, software
diagnostic tool for hard drives
disk, cloning
DiskOnKey
see also HP Drive Key
bootable 17 to 22
drive, protecting 39
Drivelock
dual-state power button
33 to 35
32
32
2
39
2
22
E
entering
power-on password 29
setup password 30
F
FailSafe Boot Block ROM 12
FailSafe Key
caution 38
ordering 38
fault notification 39
fingerprint identification technology
H
hard drives, diagnostic tool 39
HP Client Management Solutions
HP Client Manager
5
6
39
Desktop Management Guide www.hp.com Index–1
Index
HP Drive Key
see also DiskOnKey
bootable 17 to 22
HP Lifecycle solutions 2
HP Local Recovery
HP System Software Manager
7
4
I
initial configuration 2
internal temperature of computer
Internet addresses, See Web sites
invalid system ROM
12
40
K
keyboard delimiter characters, national 32
keyboard lights, ROM, table
13
L
Local Recovery 3
locking Smart Cover Lock
37
M
Multibay security 33 to 35
N
national keyboard delimiter characters 32
notification of changes
9
O
operating systems, important information
about
23
ordering FailSafe Key
38
P
password
changing 31
clearing 33
deleting 32
power-on 29
security 28
setup 28, 30
PC deployment 2
PCN (Proactive Change Notification)
power button
configuring 22
dual-state 22
power supply, surge-tolerant 40
power-on password
changing 31
deleting 32
entering 29
Preboot Execution Environment (PXE) 3
preinstalled software image
Proactive Change Notification (PCN)
protecting hard drive
protecting ROM, caution
PXE (Preboot Execution Environment)
2
39
11
9
9
3
R
recovering system 12
recovery, software
Remote ROM Flash
remote setup
Remote System Installation
accessing 3
retired solutions 10
ROM
invalid 12
keyboard lights, table 13
Remote Flash 11
upgrading 11
2
11
3
3
S
security
DriveLock 33 to 35
features, table 25
MultiBay 33 to 35
password 28
settings, setup of 24
Smart Cover Lock 36 to 38
Smart Cover Sensor 35
Index–2 www.hp.com Desktop Management Guide
Index
setup
initial 2
replicating 14
setup password
changing 31
deleting 32
entering 30
setting 28
Smart Cover FailSafe Key, ordering 38
Smart Cover Lock
locking 37
unlocking 37
Smart Cover Sensor 35
protection levels 35
setting 36
software
Altiris AClient 2
Altiris Deployment Solution Agent 2
asset tracking 24
Computer Setup Utilities 14
Drive Protection System 39
FailSafe Boot Block ROM 12
Fault Notification and Recovery 39
HP Local Recovery 3
integration 2
recovery 2
Remote ROM Flash 11
Remote System Installation 3
updating and management 4
Subscriber’s Choice 10
surge-tolerant power supply
system recovery
36 to 38
40
12
T
temperature, internal computer 40
thermal sensor
40
U
unlocking Smart Cover Lock 37
upgrading ROM
URLs (Web sites). See Web sites
USB flash media device, bootable
11
17 to 22
W
Web sites
Dantz Retrospect Express 9
Fingerprint Identification Technology 39
HP Client Manager 5
HP Client Managment Solutions using
Altiris
6
HP Lifecycle Solutions 2
HP Local Recovery 8
HPQFlash 12
PC deployment 2
Proactive Change Notification 9
remote management 28
Remote ROM Flash 11
replicating setup 14, 16, 17
ROM Flash 11
ROMPaq images 11
software support 23
Subscriber’s Choice 10
System Software Manager 4
Desktop Management Guide www.hp.com Index–3
Loading...
