QuickSpecs

HP 3PAR StoreServ 7000 Storage

Overview

HP 3PAR StoreServ 7000 Storage extends the innovative HP 3PAR StoreServ product line to the midrange with industry leading performance and features at the price you need. Spend less time managing storage, get more features for less money, and do it all without sacrificing performance or future scalability. HP 3PAR StoreServ 7000 Storage provides high performance and guarantees to double your virtual machine density. With hardware assisted thin storage it is the only platform that guarantees a 50% reduction in capacity requirements. HP 3PAR StoreServ is also the first product family with a common architecture that meets SMB needs and spans to the largest global enterprise giving you access to the same features as the world's largest service providers. You can start small and grow without painful upgrades down the road.

HP 3PAR StoreServ 7000 is storage made effortless.

HP 3PAR StoreServ 7200 Storage HP 3PAR StoreServ 7400 Storage

Summary

Number of Controller Nodes HP 3PAR Gen4 ASICs Processors Cache Maximum Host Ports Fibre Channel Host Ports 10Gb/s iSCSI Host Ports Maximum Initiators Supported 2U Controller Enclosure SAS Drive Capacity Number of Disk Drives Number of Solid State Drives Raw Capacity (approx.)

3PAR StoreServ 7200 3PAR StoreServ 7400

2 2

2 four-core 1.8 GHz

24 GB

12 ports 24 ports

4 - 12 ports 4 - 24 ports

0 - 4 ports 0 - 8 ports

512

24 24

81 - 144 drives

81 - 120

1.2 - 250 TB

2 - 4 six-core 1.8 GHz

2 or 4 2 or 4

32 - 64 GB

512 or 1024

81 - 480 drives

81 - 240

1.2 - 864 TB

DA - 14433 North America — Version 6 — February 19, 2013

Page 1

QuickSpecs

Overview

HP 3PAR StoreServ 7000 Storage

Capacity Details

RAID Levels RAID 5 Data to Parity Ratios RAID 6 Data to Parity Ratios Drive Capacities (approximate GB3)

(RAID levels, parity ratios, and drive capacities all mixable within the same Storage System)

Number of Add-on Drive Enclosures (Each Drive Enclosure holds up to 24 drives in 2U for small form factor drives and 4U for large form factor drives)

The minimum drive quantity is permitted as long as the total raw capacity is at least 1.2 TB.

Maximum raw capacity currently supported with any and all drive types.

For storage capacity, 1 GB = 1,000,000,000 bytes and 1 TB = 1,000 GB.

SSDs are Solid State Drives.

NL drives are 7200 RPM Enterprise SAS drives.

Ports are FCoE ready. FCoE support will be available in a later release.

NOTE:

Specifications are subject to change without notice.

Host OS Support

Citrix® XenServer® | HP-UX® | IBM® AIX® Microsoft® Windows® Server, including Microsoft® Hyper-V™ Oracle® Linux® (UEK and RHEL compatible kernels) | Oracle® Solaris Red Hat® Enterprise Linux® | Red Hat® Enterprise Virtualization SUSE® Linux Enterprise | VMware vSphere™

For the latest information on supported operating systems refer to Single Point of Connectivity Knowledge for HP Storage Products (SPOCK):

http://www.hp.com/storage/spock

3PAR StoreServ 7200 3PAR StoreServ 7400

RAID 0, 1, 5, 6 RAID 0, 1, 5, 6

2:1 - 8:1 2:1 - 8:1

4:2, 6:2, 8:2, 10:2, 14:2 4:2, 6:2, 8:2, 10:2, 14:2

100 SSD4, 200 SSD4,

300 SAS, 450 SAS, 900 SAS, 2000

NL5,3000 NL

0 - 5 enclosures

100 SSD4, 200 SSD4,

300 SAS, 450 SAS, 900 SAS, 2000

NL5,3000 NL

0 - 18 enclosures

DA - 14433 North America — Version 6 — February 19, 2013

Page 2

QuickSpecs

Features

HP 3PAR StoreServ 7000 Storage

Efficient

Autonomic

Get thin and stay thin - Thin technologies unique to the HP 3PAR StoreServ family can reduce capacity requirements by 50%. Purchase only what you need, as you need it so you can focus resources on growing your business, not maintaining your storage. Additionally, the HP 3PAR ASIC with Thin Built In features an efficient, silicon-based zero-detection mechanism. This unique hardware capability gives HP 3PAR StoreServ Storage the power to remove allocated but unused space without impacting performance.

Data center virtualization - Increase virtualization return on investment. Double virtual machine density on your physical servers, spend up to 90 percent less time managing your storage, and support your virtualization deployment with 50 percent less storage capacity. HP 3PAR StoreServ is built from the ground up to deliver performance that exceeds the demands of virtualized data centers along with transformative levels of simplicity, agility, and efficiency.

Service levels - With policy-based autonomic sub-LUN tiering, you can balance the cost of capacity and the cost of performance and put the right data on the right storage tier at the right time.

Do more with less - With HP 3PAR StoreServ Storage you can purchase up to 75 percent less capacitymeaning less equipment to house, fewer disks to power and cool, less hardware to retire after it has reached its end of life, and a reduced carbon footprint.

It's like breathing-you don't even have to think about it. Simplify, automate, and expedite storage management by handling storage provisioning, tiering, and change management autonomicallyintelligently, at a sub-system level, and without administrator intervention.

SmartStart Software - software designed to get you off to a quick start with your new HP 3PAR StoreServ 7000 system.

Resilient

Common architecture - Access the same features as the world's largest service providers with a common architecture that meets SMB needs and spans to the largest global enterprise.

Secure multi-tenancy - Consolidate with confidence. Achieve higher service levels for more users and applications with less infrastructure. HP 3PAR StoreServ Storage is designed to support massive consolidation by supporting mixed workloads and secure administrative segregation of users, hosts, and application data. Deliver higher performance levels, greater availability, and next-generation functionality to multiple user groups and applications from a single storage system.

Scalable - HP 3PAR StoreServ 7000 provides affordable entry pricing and unique, non-disruptive scalability to four nodes.

High Availability - Featuring the same mesh-active architecture as all HP 3PAR StoreServ products, HP 3PAR StoreServ 7000 offers the highest levels of data availability and protection for the midrange. Intelligent data striping across all available enclosures provides HA Cage, the ability to maintain availability even when a whole drive enclosure fails. HP 3PAR Persistent Cache in four node configurations eliminates performance impacts that result from unplanned component failures, making it a must-have for maintaining service levels in the virtual data center-a feature that you can't get from any other midrange storage platform.

Storage federation - Meet the needs of today's data center with the ability to move data and workloads between arrays without impact to applications, users, or services. Simply and non-disruptively shift data between any model HP 3PAR StoreServ system without additional management layers or appliances.

DA - 14433 North America — Version 6 — February 19, 2013

Page 3

QuickSpecs

Features

Storage federation on HP 3PAR StoreServ Storage can also help you improve availability in clustered VMware environments.

Mixed workload - Mixed workload support serves transactional and throughput-intensive workloads from a single device. The purpose-built HP 3PAR ASIC delivers mixed workload support to alleviate performance concerns and cut traditional array costs. Transaction- and throughput-intensive workloads run on the same storage resources without contention, thereby cutting array purchases in half.

HP 3PAR StoreServ 7000 Storage

DA - 14433 North America — Version 6 — February 19, 2013

Page 4

QuickSpecs

Service and Support, HP Care Pack, and Warranty Information

HP 3PAR StoreServ 7000 Storage

Warranty

Service and Support

3 Year, On-site Warranty Service. 7x24 4-hour remote response with next business day on-site response

HP 3PAR StoreServ 7000 drive (SSD, SAS performance and Nearline) warranty is 3 years, parts only.

HP warrants only that the Software media will be free of physical defects for a period of ninety (90) days from delivery.

For more information about HP's Global Limited Warranty and Technical Support, visit:

http://www.hp.com/products/storageworks/warranty

Technology Services for increased uptime, productivity and ROI

Trust HP storage technology experts for every level of service and support. Our integrated portfolio of services for storage help customers reduce costs, optimize data, streamline storage management, and improve backup and recovery. Capitalizing on HP Storage Systems' capabilities requires a service partner who understands your increasingly complex environment. Team with the people who know HP infrastructure hardware and software best-the experienced professionals at HP Services.

Protect your business beyond warranty

Warranty protects against manufacturer defects, however warranty uplifts, such as HP Care Pack Services protect the business-by reducing downtime risks and providing operational consistency for missioncritical and standard business computing.

What HP Storage Technology Services can do for you

HP Storage Technology Services can help you design, deploy, test, integrate, support, and manage IT and infrastructure solutions. HP storage lifecycle support services offers a full spectrum of customer carefrom technology support to complex migrations to complete managed services.

Optimized Care

best performance and stability through deployment and proactive management practices

- delivers

Choose the right level of support, deployment and integration services

HP support recommendations are designed to help you enhance technology operations and lower risk-and make it easier for you to seek the right balance between affordability and service-level commitments. Depending on your individual support needs, choose from three levels of care that cover the entire lifecycle to better address your needs-Optimized Care, Standard Care, and Basic Care. If none of our support recommendations meet your needs, we can tailor a service solution for your unique support requirements. Only HP brings together deep expertise, proactive and business critical support and a strong partner network-together with, a full set of infrastructure services designed to power a Converged Infrastructure

HP Critical Service -

when uninterrupted uptime is essential. We implement improvement projects to mitigate risks and reduce incidents to maximize uptime. If outages do occur, they will be addressed immediately through access to our dedicated critical support escalation resources, with a six-hour call-to-repair commitment from our mission-critical call center.

Additional Option: 10 Proactive Select credits per year per array

to fit your particular environment or situation. Working with an HP Account Support Manager, you select a package of services in the form of services credits that include proactive services spanning many technologies and processes, such as on-site firmware upgrades, health checks, assessments, and education. You tailor the service delivery to improve time to production, optimize performance, or build in

This service delivers 24x7 monitoring of your environment, making it the right choice

- HP Proactive Select is a flexible way to purchase services

DA - 14433 North America — Version 6 — February 19, 2013

Page 5

QuickSpecs

Service and Support, HP Care Pack, and Warranty Information

continuous improvements.

Standard Care

high level of uptime, along with expert help to cut the cost and complexity of implementation and support

- maintains

HP Proactive Care 24x7

and software support services designed specifically for your technology; rapid access to Advanced Solution Center Specialists plus, Firmware/Software management and best practice advice. Customers can optimize the return on their IT investment and realize the advantage of running their business critical applications on virtualized infrastructure. Plus, HP Proactive Select 20 credits per year, select from an extensive menu of consultancy and technical services, such as onsite firmware upgrades, health checks, assessments, and education.

Additional Option: HP Proactive Care Personalized Support

an increased personalization of the Proactive Care support experience through the assignment of an Account Service Manager (ASM) who provides IT best practice advice to help address IT issues and projects. The ASM will develop an annual support plan, provide four days of operational and technical advice, and conduct semi-annual support reviews to ensure the Proactive Care service deliverables address the customer's priorities. This option is only available for Proactive Care customers and may be purchased once per environment.

- for a higher return on your storage investment, Proactive Care delivers hardware

- The HP Proactive Care Personalized Support option allows for

HP 3PAR StoreServ 7000 Storage

Basic Care

recommended support

Implementation

- Minimum

HP Personalized Support Additional Day

Personalized Support option can elect to purchase additional days through the Personalized Support Additional Day option. The time may be used to provide extra support reviews and/or more operational & technical advice.

HP Proactive Care 24x7 -

and software support services designed specifically for your technology; rapid access to Advanced Solution Center Specialists plus, Firmware/Software management and best practice advice. Customers can optimize the return on their IT investment and realize the advantage of running their business critical applications on virtualized infrastructure. Plus, 10 credits per year, select from an extensive menu of consultancy and technical services, such as onsite firmware upgrades, health checks, assessments, and education.

Additional Option: HP Proactive Care Personalized Support -

an increased personalization of the Proactive Care support experience through the assignment of an Account Service Manager (ASM) who provides IT best practice advice to help address IT issues and projects. The ASM will develop an annual support plan, provide four days of operational and technical advice, and conduct semi-annual support reviews to ensure the Proactive Care service deliverables address the customer's IT priorities. This option is only available for Proactive Care customers and may be purchased once per environment.

HP Personalized Support Additional Day

Installation:

Whichever level of care you select, consider our Installation and Startup Services for a smooth implementation.

for a higher return on your storage investment, Proactive Care delivers hardware

- Customers who require more time than is provided by the

The HP Proactive Care Personalized Support option allows for

- Customers who require more time than is provided by the

DA - 14433 North America — Version 6 — February 19, 2013

Page 6

QuickSpecs

Service and Support, HP Care Pack, and Warranty Information

HP 3PAR StoreServ 7000 Storage

Related Services

HP 3PAR StoreServ 7000 Storage Installation and Startup Service

provides you with deployment of your HP 3PAR StoreServ 7000 Storage, ensuring proper installation into your storage environment and helping you realize the maximum benefit from your storage investment.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2568ENW.pdf

HP Storage Data Migration Service-

or around the globe. Take the burden of migration off your shoulders and put it in the capable hands of expert HP storage migration consultants. Our proven approach helps orchestrate the complete data migration and consolidation process while maintaining consistent data availability during the transfer process.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-0774ENW.pdf

HP Enhanced Implementation Service for SANs -

services for Fibre Channel, FCoE, FCIP, SAS, and iSCSI storage area network (SAN) connectivity components. This service includes three levels of support based on the type of environment, ranging from simple to more complex. A trained service specialist guides the implementation of the storage switches in the SAN environment according to HP quality standards.

http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-8527EN.pdf

HP Data Replication Solution Service for 3PAR Virtual Copy-

3PAR Virtual Copy Software helps create, manage and configure local replication data mirroring and snapshot capabilities of 3PAR storage systems. This service enables snapshots and mirroring to facilitate data restores, minimize downtime for backups, perform application testing, support data mining use with decision-support tools.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-0217ENW.pdf

HP expertise and tools help you migrate data across your data center

HP delivers complete design and implementation

- For smooth startup, this service

HP Data Replication Solution Service for HP

HP Data Replication Solution Service for 3PAR Remote Copy

3PAR Remote Copy Software configures real-time data mirroring between local and remote 3PAR storage systems to safeguard critical business information. Provides scalable deployment of HP Remote Copy Software real-time data mirroring between a local and a remote 3PAR storage system.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-8627ENW.pdf http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA0-9431ENW.pdf

HP 3PAR 7000 Replication Software Suite Installation and Startup Service

of the HP 3PAR 7000 Replication Software Suite product. Replication Suite includes 3PAR Remote Copy, 3PAR Virtual Copy, and 3PAR Peer Persistence. The service is designed to help get HP 3PAR 7000 Replication Software Suite up and running quickly and to provide a demonstration of the product's key features using sample or test data only.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2570ENW.pdf

HP 3PAR Peer Persistence Software Installation and Startup Service

HP 3PAR Peer Persistence Software product. The service is designed to help get HP 3PAR Peer Persistence up and running quickly and to provide a demonstration of the product's key features using sample or test data only.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2772ENW.pdf

HP 3PAR Adaptive Optimization Policy Implementation Service -

Implementation Service provides analysis, recommendations, and implementation of HP 3PAR Adaptive Optimization policies to enable storage tiering using data collected from the HP 3PAR Storage system over time. With the assistance of a designated IT storage administrator, a service specialist works with the

- HP Data Replication Solution Service for

- Provides implementation

- Provides implementation of the

HP 3PAR Adaptive Optimization Policy

DA - 14433 North America — Version 6 — February 19, 2013

Page 7

QuickSpecs

Service and Support, HP Care Pack, and Warranty Information

customer to implement Adaptive Optimization policies on the HP 3PAR Storage system to help deliver service level optimization for virtual and cloud data centers while reducing cost, increasing agility and minimizing risk.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENW.pdf

HP 3PAR StoreServ 7000 Storage

HP Storage Virtual Volume Design and Implementation Service

Disk Array, the HP Virtual Volume Design and Implementation Service provides the necessary activities required to design and implement a new virtual volume configuration.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3764ENN.pdf

HP Thin Volume Conversion Service

thin provisioned virtual volumes for HP 3PAR Storage. A service specialist advises the customer on HP thin provisioning best practices, provides evaluation of potential disk capacity savings if target virtual volumes are converted, and plans and implements thin conversion processing. The service leverages 3PAR thin provisioning capabilities to help optimize storage capacity, reduce cost, increase agility and maintain performance.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENW.pdf

HP Performance Analysis Service for HP Disk Arrays

analysis and enhancement recommendations for HP 3PAR StoreServ Storage disk arrays, HP EVA P6000 Storage disk arrays and HP XP P9000 Storage disk arrays. HP Performance Analysis Service for HP Storage Disk Arrays provides a single engagement concerning the performance of a single HP 3PAR StoreServ Storage disk array, HP EVA P6000 Storage disk array and HP XP P9000 Storage disk array

http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6668EN.pdf

HP 3PAR Health Check Service-

providing data collection, analysis, report creation, and a briefing session concerning the performance of a single HP 3PAR StoreServ Storage System. This health check service is best for HP 3PAR StoreServ Storage Systems that have been installed and are in normal production mode. It can also be used to establish a baseline for future reference to improve the effective use of your storage system.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-3225ENW.pdf

- Provides evaluation and execution of conversion from standard to

- The service provides data collection, detailed I/O

The HP 3PAR Health Check service is delivered as a single engagement,

- When redeploying an HP StorageWorks

HP 3PAR Storage Assessment Service-

single HP 3PAR StoreServ Storage System and does not include performance analysis, testing, or modeling. The service requires that remote monitoring be enabled on the HP 3PAR StoreServ Storage System being assessed. The assessment findings are compared to HP best practices and a summary report is provided that includes recommendations intended to improve availability and ongoing management of your HP 3PAR StoreServ Storage System.

http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA3-2346ENW.pdf

HP 3PAR Storage Rebalance Service

3PAR StoreServ Storage to take advantage of the capabilities of the array architecture. The service provides analysis, planning, and implementation of data movement and/or physical movement of drive magazines within the array.

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-0280ENW.pdf

HP EVA to 3PAR Acceleration Service

even execute data migration activities on your behalf that can not only optimize, but provide OPEX and CAPEX savings as a result of your journey from EVA to 3PAR. This service provides customers with an alternative DIY ("do-it-yourself") data migration option with guidance from TS Storage migration specialists. With the help of migration experts, this service allows customers to execute an EVA to 3PAR data migration at their own pace and lowered cost.

DA - 14433 North America — Version 6 — February 19, 2013

The HP 3PAR Assessment Service is delivered remotely for a

- The HP 3PAR Rebalance Service helps balance data across your HP

- The HP EVA to 3PAR Acceleration Service can help guide you or

Page 8

QuickSpecs

Service and Support, HP Care Pack, and Warranty Information

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-4234ENW.pdf

HP 3PAR StoreServ 7000 Storage

For more information

HP 3PAR Adaptive Optimization I&S

Adaptive Optimization policies; policy design, creation, and implementation can be accommodated using the HP 3PAR Adaptive Optimization Policy Implementation Service, which is available via HP Proactive Select. The Service has further been described in the HP 3PAR 7000 Software Installation and Startup Service Datasheet:

HP 3PAR Dynamic Optimization I&S -

to balance the HP 3PAR storage system; the service provides the Customer with a product overview, advice, and suggested strategies for use of Dynamic Optimization, and extended/ongoing analysis and/or implementation of Dynamic Optimization strategies can be accommodated at additional cost The Service has further been described in the HP 3PAR 7000 Software Installation and Startup Service Datasheet:

www.hp.com/services/storage

To learn more on HP Storage Services, please contact your HP sales representative or HP Authorized Channel Partner

HP Care Pack Services are sold by HP and HP Authorized Service Partners

http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-2569ENW.pdf

Services for customers purchasing from HP or an enterprise reseller are quoted using HP order configuration tools. Customers purchasing from a commercial reseller can find HP Care Pack Services at:

www.hp.com/go/lookuptool

-For Adaptive Optimization, design, creation, and implementation of

For Dynamic Optimization, implementation by HP of tasks required

DA - 14433 North America — Version 6 — February 19, 2013

Page 9
