HP ProOne 600 G3 Maintenance & Service Guide
Maintenance & Service Guide
HP ProOne 600 G3 21 inch All-in-One Business PC
© Copyright 2017 HP Development Company,
L.P.
AMD is a trademark of Advanced Micro Devices,
Inc. Bluetooth is a trademark owned by its
proprietor and used by HP Inc. under license.
Intel, Celeron, and Pentium are trademarks of
Intel Corporation in the U.S. and other
countries. Microsoft and Windows are
trademarks of the Microsoft group of
companies.
The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in the
express warranty statements accompanying
such products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable for
technical or editorial errors or omissions
contained herein.
First Edition: July 2017
Document Part Number: 913339-001
Product notice
This user guide describes features that are
common to most models. Some features may
not be available on your computer.
Not all features are available in all editions of
Windows. This computer may require upgraded
and/or separately purchased hardware, drivers
and/or software to take full advantage of
Windows functionality. Go to
http://www.microsoft.com for details.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to be
bound by the terms of the HP End User License
Agreement (EULA). If you do not accept these
license terms, your sole remedy is to return the
entire unused product (hardware and software)
within 14 days for a full refund subject to the
refund policy of your seller.
For any further information or to request a full
refund of the price of the computer, please
contact your seller.
About This Book
WARNING! Text set o in this manner indicates that failure to follow directions could result in bodily harm or
loss of life.
CAUTION: Text set o in this manner indicates that failure to follow directions could result in damage to
equipment or loss of information.
NOTE: Text set o in this manner provides important supplemental information.
iii
iv About This Book
Table of contents
1 Product features ........................................................................................................................................... 1
Overview ................................................................................................................................................................ 1
Front components .................................................................................................................................................. 2
Side components ................................................................................................................................................... 3
Rear components ................................................................................................................................................... 4
Labels ..................................................................................................................................................................... 5
2 Illustrated parts catalog ................................................................................................................................ 6
System parts .......................................................................................................................................................... 6
Mass storage devices ............................................................................................................................................. 8
Processors and memory modules ......................................................................................................................... 9
Cables ..................................................................................................................................................................... 9
Keyboards and mice ............................................................................................................................................. 10
3 Routine care, SATA drive guidelines, and disassembly preparation .................................................................. 11
Electrostatic discharge information .................................................................................................................... 11
Generating static ............................................................................................................................... 12
Preventing electrostatic damage to equipment ............................................................................... 12
Personal grounding methods and equipment .................................................................................. 13
Grounding the work area ................................................................................................................... 13
Recommended materials and equipment ........................................................................................ 13
Operating guidelines ........................................................................................................................................... 14
Routine care ......................................................................................................................................................... 14
General cleaning safety precautions ................................................................................................ 14
Cleaning the Computer Case ............................................................................................................. 15
Cleaning the keyboard ....................................................................................................................... 15
Cleaning the display .......................................................................................................................... 15
Cleaning the mouse ........................................................................................................................... 16
Service considerations ......................................................................................................................................... 16
Tools and software Requirements .................................................................................................... 16
Screws ............................................................................................................................................... 16
Cables and connectors ...................................................................................................................... 16
Hard Drives ........................................................................................................................................ 16
Lithium coin cell battery .................................................................................................................... 17
SATA hard drive cables ......................................................................................................................................... 18
SATA data cable ................................................................................................................................. 18
v
Cable management .............................................................................................................................................. 18
4 Removal and Replacement Procedures .......................................................................................................... 19
Preparing to disassemble the computer ............................................................................................................. 19
Attaching and removing a stand ......................................................................................................................... 20
Attaching and removing an easel stand ........................................................................................... 20
Attaching an easel stand ................................................................................................ 20
Removing an easel stand ................................................................................................ 20
Attaching and removing an adjustable height stand ........................................................................ 21
Attaching an adjustable height stand ............................................................................ 21
Removing an adjustable height stand ............................................................................ 22
Rear port cover .................................................................................................................................................... 23
Access panel ......................................................................................................................................................... 24
Locating internal components ............................................................................................................................ 25
Drives ................................................................................................................................................................... 26
Replacing a hard disc drive ................................................................................................................ 26
Removing a 2.5-inch hard disc drive .............................................................................. 26
Installing a 2.5-inch hard disc drive ................................................................................ 28
Replacing the optical drive ................................................................................................................ 29
System board (EMI) shield ................................................................................................................................... 30
Memory ................................................................................................................................................................ 31
Battery ................................................................................................................................................................. 33
WLAN module ...................................................................................................................................................... 34
Heat sink .............................................................................................................................................................. 35
Processor ............................................................................................................................................................. 36
Serial/PS2 board .................................................................................................................................................. 38
System board ....................................................................................................................................................... 39
System board callouts ......................................................................................................................................... 42
VESA mounting bracket ....................................................................................................................................... 43
Power supply ....................................................................................................................................................... 44
Fan assembly ....................................................................................................................................................... 45
Drive cable ........................................................................................................................................................... 46
Top trim ................................................................................................................................................................ 47
Webcam module .................................................................................................................................................. 48
Antennas .............................................................................................................................................................. 49
Right trim ............................................................................................................................................................. 50
Left trim ............................................................................................................................................................... 51
Feet, rear I/O bracket, and bottom panel ............................................................................................................ 52
Speakers .............................................................................................................................................................. 54
Bezel, bezel bottom trim, display panel ............................................................................................................. 55
vi
5 Computer Setup (F10) Utility ........................................................................................................................ 59
Computer Setup (F10) Utilities ............................................................................................................................ 59
Using Computer Setup (F10) Utilities ................................................................................................ 59
Computer Setup–Main ....................................................................................................................... 61
Computer Setup—Security ............................................................................................................... 63
Computer Setup—Advanced ............................................................................................................. 65
Recovering the Conguration Settings ............................................................................................................... 70
6 Using HP PC Hardware Diagnostics (UEFI) ....................................................................................................... 71
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device .................................................................... 72
7 Troubleshooting without diagnostics ............................................................................................................ 73
Safety and comfort .............................................................................................................................................. 73
Before you call for technical support .................................................................................................................. 73
Helpful hints ........................................................................................................................................................ 74
Solving general problems .................................................................................................................................... 75
Solving power problems ...................................................................................................................................... 79
Solving hard drive problems ................................................................................................................................ 80
Solving audio problems ....................................................................................................................................... 82
Solving printer problems ..................................................................................................................................... 83
Solving keyboard and mouse problems .............................................................................................................. 84
Solving hardware installation problems ............................................................................................................. 85
Solving network problems .................................................................................................................................. 86
Solving memory problems .................................................................................................................................. 88
Solving USB ash drive problems ........................................................................................................................ 90
Solving Internet access problems ....................................................................................................................... 91
Solving software problems .................................................................................................................................. 92
8 Backing up, restoring, and recovering ........................................................................................................... 93
Creating recovery media and backups ................................................................................................................ 93
Creating HP Recovery media (select products only) ......................................................................... 93
Using Windows tools ........................................................................................................................................... 94
Restore and recovery ........................................................................................................................................... 95
Recovering using HP Recovery Manager ........................................................................................... 95
What you need to know before you get started ............................................................. 95
Using the HP Recovery partition (select products only) ................................................. 96
Using HP Recovery media to recover .............................................................................. 96
Changing the computer boot order ................................................................................ 97
Removing the HP Recovery partition (select products only) ......................................... 97
vii
9 POST error messages and diagnostic front panel LEDs and audible codes ......................................................... 98
POST numeric codes and text messages ............................................................................................................. 98
Interpreting system validation diagnostic front panel LEDs and audible codes .............................................. 103
10 Password security and resetting CMOS ...................................................................................................... 105
Resetting the password jumper ........................................................................................................................ 105
Clearing and resetting the BIOS ........................................................................................................................ 107
Appendix A Power cord set requirements ....................................................................................................... 108
General requirements ........................................................................................................................................ 108
Japanese power cord requirements .................................................................................................................. 108
Country-specic requirements .......................................................................................................................... 109
Appendix B Statement of memory volatility ................................................................................................... 110
Nonvolatile memory usage ............................................................................................................................... 112
Questions and answers ..................................................................................................................................... 114
Using HP Sure Start (select models only) .......................................................................................................... 115
Appendix C Specications ............................................................................................................................. 116
Index ........................................................................................................................................................... 117
viii
1 Product features
Overview
CAUTION: When the All One (AiO) is mounted using a VESA arm, horizontal operation of the AiO is not
supported and may lead to thermal issues.
NOTE: For the latest specications or additional specications on this product, go to
http://www.hp.com/go/ quickspecs/ and search for your specic display model to nd the model-specic
QuickSpecs.
Overview 1
Front components
Component Component
1 Webcam LED 4 Webcam microphone
2 Webcam shutter (select models only) 5 Speakers (select models only)
3 Webcam lens
2 Chapter 1 Product features
Side components
Component Component
1 Power button 5 HP SD media card reader
2 USB Type-A charging ports 6 Optical disc drive
3 USB Type-A ports 7 Optical disc drive eject button
4 Headset jack
Side components 3
Rear components
Component Component
1 Security cable slot 6 DisplayPort port
2 Serial port 7 USB Type-A ports (2)
3 PS/2 keyboard connector 8 USB Type-A ports (2)
4 PS/2 mouse connector 9 RJ-45 (network) jack
5 Power connector
4 Chapter 1 Product features
Labels
The labels axed to the computer provide information you may need when you troubleshoot system
problems or travel internationally with the computer.
IMPORTANT: All labels described in this section will be located under the stand or axed to the bottom of
the computer.
1. Microsoft® Certicate of Authenticity label (select models only prior to Windows 8)—Contains the
Windows Product Key. You may need the Product Key to update or troubleshoot the operating system.
HP platforms preinstalled with Windows 8 or Windows 8.1 do not have the physical label, but have a
Digital Product Key electronically installed.
NOTE: This Digital Product Key is automatically recognized and activated by Microsoft Operating
Systems on a reinstall of the Windows 8 or Windows 8.1 operating system with HP-approved recovery
methods.
2. Service label—Provides important information to identify your computer. When contacting support, you
will probably be asked for the serial number, and possibly for the product number or the model number.
Locate these numbers before you contact support.
Component
(1) Serial number
(2) Product number
(3) Warranty period
3. Serial number label
Labels 5
2 Illustrated parts catalog
Component appearance may vary.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
System parts
6 Chapter 2 Illustrated parts catalog
Item Description
(1) Front bezel
(2) Rear cover (main)
(3) Rear bottom panel
Trims
(4) Top trim
(5) Left
(6) Right
(7) Bottom bezel trim
(8) Rear I/O bracket
(9) Feet (left and right)
(10) Rear port cover
(11) Speakers (left and right)
(12) Heat sink (thermal module) (includes replacement thermal material)
(13) Webcam module
(14) Serial port and PS/2 connector board
(15) Display panel
(16) System board
(17) Power supply, 160 W
(18) Fan
* WLAN modules
Intel Dual Band Wireless-AC 7265 NV
Intel Dual Band Wireless-AC 8265 (vPro)
Intel Dual Band Wireless-AC 8265 (non-vPro)
Intel Dual Band Wireless-AC 3168
802.11bgn, 1x1, single band, Bluetooth 4.1 combo module
* Optical drive bezel blank (for use in models without an optical drive)
* Optical drive bezel
* Mylar cover (for use in models without speakers)
* Card reader cover
* Hard drive isolation grommets
* VESA cover (for use in models without a stand)
* HP ultraslim keyed cable lock
* Power cord
System parts 7
Mass storage devices
Description
Optical drive (does not include bezel)
DVD±RW drive
DVD-ROM drive
Hard drive
1 TB, hybrid SSD drive
1 TB, 7200 rpm
500 GB, hybrid SSD drive
500 GB, 7200 rpm hard drive, self-encrypting (SED)
500 GB, 7200 rpm hard drive
500 GB, 5400 rpm hard drive, FIPS
Solid-state drive (not illustrated)
1-TB solid-state drive, TLC
512-GB solid-state drive, PCIe, SS, TLC
512-GB solid-state drive, PCIe, DS
512-GB solid-state drive, SATA-3, OPAL 2.0, self-encrypting (SED), TLC
512-GB solid-state drive, SATA-3, FIPS, TLC
256-GB solid-state drive, PCIe
256-GB solid-state drive, PCIe, TLC
256-GB solid-state drive, SATA-3, TLC
256-GB solid-state drive, FIPS, TLC
256-GB solid-state drive, OPAL 2.0, self-encrypting (SED), TLC
8 Chapter 2 Illustrated parts catalog
Processors and memory modules
Description
Memory modules (SODIMM; PC4-2400)
16-GB
8-GB
4-GB
Intel Processors (include replacement thermal material)
Intel Core i7-7700 (3.6-GHz)
Intel Core i5-7600 (3.5-GHz)
Intel Core i3-7320 (4.1-GHz)
Intel Core i3-7300 (4.0-GHz)
Intel Core i3-7100 (3.9-GHz)
Intel Core i7-6700 (3.4-GHz)
Intel Core i5-6600 (3.3-GHz)
Intel Core i5-6500 (3.2-GHz)
Intel Core i3-6100 (3.7-GHz)
Cables
Intel Pentium G4620 (3.7-GHz)
Intel Pentium G4600 (3.6-GHz)
Intel Pentium G4560 (3.5-GHz)
Intel Pentium G4400 (3.3-GHz)
Intel Celeron G3950 (3.0-GHz)
Intel Celeron G3930 (2.9-GHz)
Intel Celeron G3900 (2.8-GHz)
Description
Backlight cable
BOE
LGD
AUO
Serial port cable
Hard drive + optical drive SATA data cable
DVI cable
LVDS (display) cable
Processors and memory modules 9
Description
DisplayPort cable
Adapter, DisplayPort to VGA
Adapter, DisplayPort to DVI
Adapter, DisplayPort to HDMI 1.4
Adapter, USB to serial port
Keyboards and mice
Description
Keyboard
USB
USB, slim
USB Washable
USB Essential
Conferencing
Wireless with mouse
Smartcard
PS/2, slim
Healthcare
Antimicrobial
Mouse
Gray
Antimicrobial
USB/PS2 Washable
Hardened
USB, optical
PS/2, optical
USB, laser
10 Chapter 2 Illustrated parts catalog
3 Routine care, SATA drive guidelines, and
disassembly preparation
This chapter provides general service information for the computer. Adherence to the procedures and
precautions described in this chapter is essential for proper service.
CAUTION: When the computer is plugged into an AC power source, voltage is always applied to the system
board. You must disconnect the power cord from the power source before opening the computer to prevent
system board or component damage.
Electrostatic discharge information
A sudden discharge of static electricity from your nger or other conductor can destroy static-sensitive
devices or microcircuitry. Often the spark is neither felt nor heard, but damage occurs. An electronic device
exposed to electrostatic discharge (ESD) may not appear to be aected at all and can work perfectly
throughout a normal cycle. The device may function normally for a while, but it has been degraded in the
internal layers, reducing its life expectancy.
Networks built into many integrated circuits provide some protection, but in many cases, the discharge
contains enough power to alter device parameters or melt silicon junctions.
Electrostatic discharge information 11
Generating static
The following table shows that:
●
Dierent activities generate dierent amounts of static electricity.
●
Static electricity increases as humidity decreases.
Relative Humidity
Event 55% 40% 10%
Walking across carpet
Walking across vinyl oor
Motions of bench worker
Removing DIPs from plastic tube
Removing DIPs from vinyl tray
Removing DIPs from Styrofoam
Removing bubble pack from PCB
Packing PCBs in foam-lined box
These are then multi-packaged inside plastic tubes, trays, or Styrofoam.
NOTE: 700 volts can degrade a product.
Preventing electrostatic damage to equipment
Many electronic components are sensitive to ESD. Circuitry design and structure determine the degree of
sensitivity. The following packaging and grounding precautions are necessary to prevent damage to electric
components and accessories.
●
To avoid hand contact, transport products in static-safe containers such as tubes, bags, or boxes.
7,500 V
3,000 V
400 V
400 V
2,000 V
3,500 V
7,000 V
5,000 V
15,000 V
5,000 V
800 V
700 V
4,000 V
5,000 V
20,000 V
11,000 V
35,000 V
12,000 V
6,000 V
2,000 V
11,500 V
14,500 V
26,500 V
21,000 V
●
Protect all electrostatic parts and assemblies with conductive or approved containers or packaging.
●
Keep electrostatic sensitive parts in their containers until they arrive at static-free stations.
●
Place items on a grounded surface before removing them from their container.
●
Always be properly grounded when touching a sensitive component or assembly.
●
Avoid contact with pins, leads, or circuitry.
●
Place reusable electrostatic-sensitive parts from assemblies in protective packaging or conductive
foam.
12 Chapter 3 Routine care, SATA drive guidelines, and disassembly preparation
Personal grounding methods and equipment
Use the following equipment to prevent static electricity damage to equipment:
●
Wrist straps are exible straps with a maximum of one-megohm ± 10% resistance in the ground cords.
To provide proper ground, a strap must be worn snug against bare skin. The ground cord must be
connected and t snugly into the banana plug connector on the grounding mat or workstation.
●
Heel straps/Toe straps/Boot straps can be used at standing workstations and are compatible with
most types of shoes or boots. On conductive oors or dissipative oor mats, use them on both feet with
a maximum of one-megohm ± 10% resistance between the operator and ground.
Static Shielding Protection Levels
Method Voltage
Antistatic plastic
Carbon-loaded plastic
Metallized laminate
Grounding the work area
To prevent static damage at the work area, use the following precautions:
●
Cover the work surface with approved static-dissipative material. Provide a wrist strap connected to the
work surface and properly grounded tools and equipment.
●
Use static-dissipative mats, foot straps, or air ionizers to give added protection.
●
Handle electrostatic sensitive components, parts, and assemblies by the case or PCB laminate. Handle
them only at static-free work areas.
●
Turn o power and input signals before inserting and removing connectors or test equipment.
●
Use xtures made of static-safe materials when xtures must directly contact dissipative surfaces.
●
Keep work area free of nonconductive materials such as ordinary plastic assembly aids and Styrofoam.
●
Use eld service tools, such as cutters, screwdrivers, and vacuums, that are conductive.
Recommended materials and equipment
Materials and equipment that are recommended for use in preventing static electricity include:
1,500
7,500
15,000
●
Antistatic tape
●
Antistatic smocks, aprons, or sleeve protectors
●
Conductive bins and other assembly or soldering aids
●
Conductive foam
●
Conductive tabletop workstations with ground cord of one-megohm +/- 10% resistance
●
Static-dissipative table or oor mats with hard tie to ground
●
Field service kits
●
Static awareness labels
●
Wrist straps and footwear straps providing one-megohm +/- 10% resistance
Electrostatic discharge information 13
●
Material handling packages
●
Conductive plastic bags
●
Conductive plastic tubes
●
Conductive tote boxes
●
Opaque shielding bags
●
Transparent metallized shielding bags
●
Transparent shielding tubes
Operating guidelines
To prevent overheating and to help prolong the life of the computer:
●
Keep the computer away from excessive moisture, direct sunlight, and extremes of heat and cold.
●
Operate the computer on a sturdy, level surface. Leave a 10.2-cm (4-inch) clearance on all vented sides
of the computer and above the display to permit the required airow.
●
Never restrict the airow into the computer by blocking any vents or air intakes. Do not place the
keyboard, with the keyboard feet down, directly against the front of the desktop unit as this also
restricts airow.
●
Occasionally clean the air vents on all vented sides of the computer. Lint, dust, and other foreign matter
can block the vents and limit the airow. Be sure to unplug the computer before cleaning the air vents.
●
Never operate the computer with the cover or side panel removed.
●
Do not stack computers on top of each other or place computers so near each other that they are subject
to each other’s re-circulated or preheated air.
●
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be
provided on the enclosure, and the same operating guidelines listed above will still apply.
●
Keep liquids away from the computer and keyboard.
●
Never cover the ventilation slots on the display with any type of material.
●
Install or enable power management functions of the operating system or other software, including
sleep states.
Routine care
General cleaning safety precautions
1. Never use solvents or ammable solutions to clean the computer.
2. Never immerse any parts in water or cleaning solutions; apply any liquids to a clean cloth and then use
the cloth on the component.
3. Always unplug the computer when cleaning with liquids or damp cloths.
4. Always unplug the computer before cleaning the keyboard, mouse, or air vents.
5. Disconnect the keyboard before cleaning it.
6. Wear safety glasses equipped with side shields when cleaning the keyboard.
14 Chapter 3 Routine care, SATA drive guidelines, and disassembly preparation
Cleaning the Computer Case
Follow all safety precautions in General cleaning safety precautions on page 14 before cleaning the computer.
To clean the computer case, follow the procedures described below:
●
To remove light stains or dirt, use plain water with a clean, lint-free cloth or swab.
●
For stronger stains, use a mild dishwashing liquid diluted with water. Rinse well by wiping it with a cloth
or swab dampened with clear water.
●
For stubborn stains, use isopropyl (rubbing) alcohol. No rinsing is needed as the alcohol will evaporate
quickly and not leave a residue.
●
After cleaning, always wipe the unit with a clean, lint-free cloth.
●
Occasionally clean the air vents on the computer. Lint and other foreign matter can block the vents and
limit the airow.
Cleaning the keyboard
Follow all safety precautions in General cleaning safety precautions on page 14 before cleaning the keyboard.
To clean the tops of the keys or the keyboard body, follow the procedures described in Cleaning the Computer
Case on page 15.
When cleaning debris from under the keys, review all rules in General cleaning safety precautions on page 14
before following these procedures:
CAUTION: Use safety glasses equipped with side shields before attempting to clean debris from under the
keys.
●
Visible debris underneath or between the keys may be removed by vacuuming or shaking.
●
Canned, pressurized air may be used to clean debris from under the keys. Caution should be used as too
much air pressure can dislodge lubricants applied under the wide keys.
●
If you remove a key, use a specially designed key puller to prevent damage to the keys. This tool is
available through many electronic supply outlets.
CAUTION: Never remove a wide leveled key (like the space bar) from the keyboard. If these keys are
improperly removed or installed, the keyboard may not function properly.
●
Cleaning under a key may be done with a swab moistened with isopropyl alcohol and squeezed out. Be
careful not to wipe away lubricants necessary for proper key functions. Use tweezers to remove any
bers or dirt in conned areas. Allow the parts to air dry before reassembly.
Cleaning the display
●
Wipe the display screen with a clean cloth moistened with water or with a towelette designed for
cleaning displays. Do not use sprays or aerosols directly on the screen; the liquid may seep into the
housing and damage a component. Never use solvents or ammable liquids on the display.
●
To clean the display body follow the procedures in Cleaning the Computer Case on page 15.
Routine care 15
Cleaning the mouse
Before cleaning the mouse, ensure that the power to the computer is turned o.
●
Clean the mouse ball by rst removing the retaining plate and the ball from the housing. Pull out any
debris from the ball socket and wipe the ball with a clean, dry cloth before reassembly.
●
To clean the mouse body, follow the procedures in Cleaning the Computer Case on page 15.
Service considerations
Listed below are some of the considerations that you should keep in mind during the disassembly and
assembly of the computer.
Tools and software Requirements
To service the computer, you need the following:
●
Torx T-15 screwdriver
●
Torx T-15 screwdriver with small diameter shank (for certain front bezel removal)
●
Flat-bladed screwdriver (may sometimes be used in place of the Torx screwdriver)
●
Phillips #2 screwdriver
●
Diagnostics software
●
Tamper-resistant T-15 wrench
Screws
The screws used in the computer are not interchangeable. They may have standard or metric threads and may
be of dierent lengths. If an incorrect screw is used during the reassembly process, it can damage the unit. HP
strongly recommends that all screws removed during disassembly be kept with the part that was removed,
then returned to their proper locations.
CAUTION: Metric screws have a black nish. U.S. screws have a silver nish and are used on hard drives only.
CAUTION: As each subassembly is removed from the computer, it should be placed away from the work area
to prevent damage.
Cables and connectors
Most cables used throughout the unit are at, exible cables. These cables must be handled with care to
avoid damage. Apply only the tension required to seat or unseat the cables during insertion or removal from
the connector. Handle cables by the connector whenever possible. In all cases, avoid bending or twisting the
cables, and ensure that the cables are routed in such a way that they cannot be caught or snagged by parts
being removed or replaced.
CAUTION: When servicing this computer, ensure that cables are placed in their proper location during the
reassembly process. Improper cable placement can damage the computer.
Hard Drives
Handle hard drives as delicate, precision components, avoiding all physical shock and vibration. This applies
to failed drives as well as replacement spares.
16 Chapter 3 Routine care, SATA drive guidelines, and disassembly preparation
●
If a drive must be mailed, place the drive in a bubble-pack mailer or other suitable protective packaging
and label the package “Fragile: Handle With Care.”
●
Do not remove hard drives from the shipping package for storage. Keep hard drives in their protective
packaging until they are actually mounted in the CPU.
●
Avoid dropping drives from any height onto any surface.
●
If you are inserting or removing a hard drive, turn o the computer. Do not remove a hard drive while the
computer is on or in standby mode.
●
Before handling a drive, ensure that you are discharged of static electricity. While handling a drive, avoid
touching the connector. For more information about preventing electrostatic damage, refer to
Electrostatic discharge information on page 11
●
Do not use excessive force when inserting a drive.
●
Avoid exposing a hard drive to liquids, temperature extremes, or products that have magnetic elds
such as displays or speakers.
Lithium coin cell battery
The battery that comes with the computer provides power to the real-time clock and has a minimum lifetime
of about three years.
See the appropriate removal and replacement chapter for the chassis you are working on in this guide for
instructions on the replacement procedures.
WARNING! This computer contains a lithium battery. There is a risk of re and chemical burn if the battery is
handled improperly. Do not disassemble, crush, puncture, short external contacts, dispose in water or re, or
expose it to temperatures higher than 140ºF (60ºC). Do not attempt to recharge the battery.
NOTE: Batteries, battery packs, and accumulators should not be disposed of together with the general
household waste. In order to forward them to recycling or proper disposal, please use the public collection
system or return them to HP, their authorized partners, or their agents.
Service considerations 17
SATA hard drive cables
SATA data cable
Always use an HP approved SATA 6.0 Gb/s cable as it is fully backwards compatible with the SATA 1.5 Gb/s
drives.
Current HP desktop products ship with SATA 6.0 Gb/s hard drives.
SATA data cables are susceptible to damage if overexed. Never crease a SATA data cable and never bend it
tighter than a 30 mm (1.18 in) radius.
The SATA data cable is a thin, 7-pin cable designed to transmit data for only a single drive.
Cable management
Always follow good cable management practices when working inside the computer.
●
Keep cables away from major heat sources like the heat sink.
●
Do not jam cables on top of expansion cards or memory modules. Printed circuit cards like these are not
designed to take excessive pressure on them.
●
Keep cables clear of sliding or moveable parts to prevent them from being cut or crimped when the parts
are moved.
●
When folding a at ribbon cable, never fold to a sharp crease. Sharp creases may damage the wires.
●
Some at ribbon cables come prefolded. Never change the folds on these cables.
●
Do not bend any cable sharply. A sharp bend can break the internal wires.
●
Never bend a SATA data cable tighter than a 30 mm (1.18 in) radius.
●
Never crease a SATA data cable.
●
Do not rely on components like the drive cage, power supply, or computer cover to push cables down
into the chassis. Always position the cables to lay properly by themselves.
18 Chapter 3 Routine care, SATA drive guidelines, and disassembly preparation
4 Removal and Replacement Procedures
The following sections provide information about disassembling various components of the computer.
Preparing to disassemble the computer
To avoid injury and equipment damage, always complete the following steps in order, when opening the HP
All-in-One.
1. Remove all media from the computer.
2. Shut down the computer.
3. After the system has completely shut down, disconnect the power adapter from the back of the
computer.
4. If a cable lock is installed on the rear of the unit, remove the lock.
5. Disconnect all other attached cables from the back of the computer.
6. Place the computer face down on a soft at surface. HP recommends that you set down a blanket, towel,
or other soft cloth to protect the screen surface from scratches or other damage.
WARNING! Beware of sharp edges inside the chassis.
Preparing to disassemble the computer 19
Attaching and removing a stand
Two stands are available for the computer:
●
Attaching and removing an easel stand
●
Attaching and removing an adjustable height stand
Attaching and removing an easel stand
Attaching an easel stand
To install the stand:
1. Place the computer face down on a soft at surface. HP recommends that you set down a blanket, towel,
or other soft cloth to protect the bezel and screen surface from scratches or other damage.
2. Engage the hooks in the top of the stand in the two large holes in the upper part of the back of the
computer (1).
3. Rotate the stand down until it clicks into place (2).
Removing an easel stand
To remove the stand:
1. Remove all removable media, such as optical discs or USB ash drives, from the computer.
2. Turn o the computer properly through the operating system, then turn o any external devices.
3. Disconnect the AC power cord from the AC outlet and disconnect any external devices.
4. Place the computer face down on a soft at surface. HP recommends that you set down a blanket, towel,
or other soft cloth to protect the bezel and screen surface from scratches or other damage.
5. Remove the rear port cover, if it is installed. For instructions, see Rear port cover on page 23.
6. Press the release latch under the stand (1).
20 Chapter 4 Removal and Replacement Procedures
7. Lift the stand up (2), and then pull the stand hooks out of the computer (3).
Attaching and removing an adjustable height stand
Attaching an adjustable height stand
To install the stand:
1. Place the computer face down on a soft at surface. HP recommends that you set down a blanket, towel,
or other soft cloth to protect the bezel and screen surface from scratches or other damage.
2. Engage the hooks in the top of the stand in the two large holes in the upper part of the back of the
computer (1).
3. Rotate the stand down until it clicks into place (2).
Attaching and removing a stand 21
Removing an adjustable height stand
To remove the stand:
1. Remove all removable media, such as optical discs or USB ash drives, from the computer.
2. Turn o the computer properly through the operating system, then turn o any external devices.
3. Disconnect the AC power cord from the AC outlet and disconnect any external devices.
4. Place the computer face down on a soft at surface. HP recommends that you set down a blanket, towel,
or other soft cloth to protect the bezel and screen surface from scratches or other damage.
5. Remove the rear port cover, if it is installed. For instructions, see Rear port cover on page 23.
6. Press the release latch under the stand (1).
7. Lift the stand up (2), and then pull the stand hooks out of the computer (3).
22 Chapter 4 Removal and Replacement Procedures
