HP ProBook 4535s Quickspecs

1.

WWAN antennas (select models)

14.

Touchpad

2.

WLAN antennas

15.

Touchpad pick buttons

3.

Dual-microphone array

16.

Touchpad on/off button with LED indicator

4.

Webcam LED indicator (with webcam)

17.

Stereo microphone in

5.

720p HD webcam

18.

Stereo headphone/line out

6.

Stereo speakers

19.

Media Card Reader

7.

HP QuickWeb button with LED indicator

20.

Hard drive activity LED indicator

8.

Wireless on/off button with LED indicator

21.

Power button with LED indicator

9.

Optical drive (select models)

22.

HP Power Assistant function key

10.

Numeric keypad

23.

Volume mute function key

11.

Optional RJ-11/modem port

24.

Volume down function key

12.

(2) USB 2.0 ports

25.

Volume up function key

13.

Optional HP Fingerprint Sensor

QuickSpecs

HP ProBook 4535s Notebook PC

Overview

DA - 14044 North America — Version 12 — August 2, 2012

Page 1

1.

Battery charging LED indicator

6.

RJ-45/Ethernet port

2.

HDMI 1.4a port

7.

VGA/external monitor connector

3.

USB 2.0 port

8.

Vent

4.

USB 2.0 port

9.

Power connector

5.

ExpressCard/34 slot

10.

Security lock slot

1.

Battery and access cover release latches

4.

Vents

2.

Battery bay

5.

Hard drive bay

3.

SIM card slot (select units, located inside battery bay)

QuickSpecs

HP ProBook 4535s Notebook PC

Overview

DA - 14044 North America — Version 12 — August 2, 2012

Page 2

At A Glance

Genuine Windows 7 versions, SUSE Linux, or FreeDOS
Thin, lightweight design with metallic gray brushed aluminum finish for durability and style; wear-resistant HP DuraFinish
Full-sized spill-resistant keyboard with full separate numeric keypad
HP 3D DriveGuard to protect hard drive against impact, bumps or drops
Larger Touchpad with gestures support, on/off button with LED indicator
Enhanced security features including HP ProtectTools, HP Face Recognition, HP Fingerprint Sensor, and optional HP Privacy
Filter
SRS Premium Sound optimized for high fidelity audio
HDMI port for connecting to high-resolution displays
ArcSoft TotalMedia Suite for playing, creating, and editing video and audio files
HD webcam with dual-microphone array for video conferencing

15.6-inch diagonal LED-backlit HD anti-glare display with 16:9 aspect ratio
Accelerated Processing Unit and graphics powered by VISION Pro Technology from AMD
HP QuickWeb for convenient online access without the standard boot-up time
Flexible wireless connectivity options controlled by HP Connection Manager:

Integrated HP Mobile Broadband Module
Integrated 802.11 b/g/n wireless LAN module
Integrated 802.11 a/b/g/n or b/g/n with Bluetooth 3.0 High Speed (HS) combo card

*

HP DayStarter for calendar display during startup
HP Power Assistant to conserve power, increase battery run-time, monitor power needs, report workforce power consumption
BFR/PVC-free,** ENERGY STAR® qualified,

***

and EPEAT® Gold registered in the U.S. EPEAT status varies by country—please

see

epeat.net

.

* Available on select models.
** This notebook is brominated flame retardant and polyvinyl chloride-free (BFR/PVC-free) on notebooks that are non-WWAN; meeting
the evolving definition of 'BFR/PVC-free' as set forth in the "iNEMI Position Statement on the 'Definition of Low-Halogen' Electronics
(BFR/CFR/PVC-Free)'". Plastic parts contain < 1000 ppm (0.1%) of bromine [if the Br source is from BFRs] and < 1000 ppm (0.1%) of
chlorine [if the Cl source is from CFRs or PVC or PVC copolymers]. Power supply and power cords are not BFR/PVC-free. Service parts
after purchase may not be BFR/PVC-free.
*** Microsoft® Windows® required for ENERGY STAR qualification.

QuickSpecs

HP ProBook 4535s Notebook PC

Overview

DA - 14044 North America — Version 12 — August 2, 2012

Page 3

Accelerated Processing
Unit (APU)

VISION Technology from AMD

AMD Quad-Core A6-3400M with Radeon HD 6520G Graphics
(2.3 GHz/1.4 GHz, 4 MB L2 cache, 35W)

AMD Dual-Core A4-3300M with Radeon HD 6480G Graphics
(2.5 GHz/1.9 GHz, 2 MB L2 cache, 35W)

NOTE:

APU speed denotes maximum performance mode; APUs will run at lower speeds in battery

optimization mode.

Operating System

Preinstalled

Genuine Windows 7 Professional 32

*

Genuine Windows 7 Professional 64

*

Genuine Windows 7 Home Premium 32

*

Genuine Windows 7 Home Premium 64

*

Genuine Windows 7 Home Basic 32* (select countries)
SUSE Linux Enterprise Desktop 11
FreeDOS

Supported

Genuine Vista Home Basic
Genuine Windows XP Professional 32

* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality.
See:

http://www.microsoft.com/windows/windows-7/

for details.

Fusion Controller Hub
(Chipset)

AMD A70M FCH

Graphics
included with Accelerated
Processing Unit (APU)

AMD Radeon HD 6520G Graphics (with AMD Quad-Core A6-3400M APU)
AMD Radeon HD 6480G Graphics (with AMD Dual-Core A4-3300M APU)

Display

Internal

15.6-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Optional HP Privacy Filter

External

Up to 32-bit per pixel color depth

VGA

port supports resolutions up to 2048 x 1536 at 75 Hz, and lower

resolutions at up to 100 Hz.

HDMI

port supports direct connection to high-definition displays with up to
1920 x 1080 resolution and 7-channel audio with one convenient cable (not
included).

NOTE:

Resolutions are dependent upon monitor capability, and resolution and

color depth settings.

QuickSpecs

HP ProBook 4535s Notebook PC

Standard Features (availability may vary by country)

DA - 14044 North America — Version 12 — August 2, 2012

Page 4

Memory

Standard

DDR3 PC3-10600 SDRAM (1333 MHz)
Two SODIMM slots supporting dual-channel memory
2 GB, 3 GB, and 4 GB SODIMMs

Maximum

Upgradeable to 8 GB with 4 GB SODIMMs
in slots 1 and 2

Dual-channel

Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.

NOTE:

Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or
Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your
configuration, so that above 3 GB all memory may not be available due to system resource requirements.

Communications

Realtek Ethernet (10/100/1000 NIC)

*

Optional 56K V.92 modem

**

* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.

** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.

Wireless Devices

Support for a broad range of secure, integrated wireless options featuring support for the latest industry
standards.

Mobile Broadband
options

Mobile Broadband (WWAN) requires a Windows operating system and is
available in select countries as a factory configurable feature for the HP
ProBook 4535s. Two 850/900/1575/1700/1800/ 1900/2100 MHz antennas
integrated in the top of the display panel support current and future WWAN
technologies.

NOTE:

Separately purchased mobile network operator service is required.

HP hs2340 HSPA+ Mobile
Broadband Module

Integrated mobile broadband module that provides connectivity to both HSPA
and HSPA+ (UMTS) networks. It also provides standalone, Internet and
network assisted GPS functionality for various mapping applications and
security applications such as Computrace Pro for HP ProtectTools.

HP un2430 EV-DO/HSPA
Mobile Broadband Module

Integrated mobile broadband module with Gobi global mobile Internet
technology that provides connectivity to both CDMA (EVDO) and UMTS (HSPA)
networks. It also provides GPS functionality for various mapping applications
and security applications such as Computrace Pro for HP ProtectTools.

802.11 integrated
wireless LAN options

Wi-Fi certified

*

Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Dual antennas integrated in the display enclosure

QuickSpecs

HP ProBook 4535s Notebook PC

Standard Features (availability may vary by country)

DA - 14044 North America — Version 12 — August 2, 2012

Page 5

Realtek 8188GN 802.11
b/g/n 1x1 WiFi Adapter

Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate

Ralink 5390GN 802.11
b/g/n 1x1 WiFi Adapter

Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate

Ralink 3592BC8 802.11
a/b/g/n 2x2 WiFi and
Bluetooth 3.0+HS Combo
Adapter

*

Integrated support for 802.11 a, b, g, and n
Up to 300 mbps data rate
Bluetooth Specification 3.0 High Speed (HS)* and 2.1 compliant
Works with a wide range of Bluetooth devices

Atheros 9285GN

802.11 b/g/n
1x1 WiFi and 3011
Bluetooth 3.0+HS Combo
Adapter

*

Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate
Bluetooth Specification 3.0 High Speed (HS)* and 2.1 compliant
Works with a wide range of Bluetooth devices

Realtek 8188BC8 802.11
b/g/n 2x2 WiFi and
Bluetooth 3.0+HS Combo
Adapter

*

Integrated support for 802.11 b, g, and n
Up to 150 mbps data rate
Bluetooth Specification 3.0 High Speed (HS)* and 2.1 compliant
Works with a wide range of Bluetooth devices

* Bluetooth 3.0+HS support requires a Windows operating system.

Keyboard

The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain
system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage
to sensitive components underneath. The 101/102-key compatible keyboard features a full-pitch key
layout with desktop keyboard features, such as editing keys, both left and right control and alt keys,
function keys, and an integrated numeric keypad. US and International key layouts are available.

Launch Buttons and
Function Keys

Separate launch buttons provide easy access to wireless on/off and HP QuickWeb. Function keys provide
control of features including: standby mode, display brightness, external display, HP Power Assistant,
volume mute, volume down, volume up, and media control.

Pointing device

Touchpad with gestures support, on/off button with LED indicator, two-way scroll, two pick buttons

Expansion card slots

ExpressCard/34 slot

Supports ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes

Media Card Reader

Supports High Speed SD 3.0 (Secure Digital), MultiMediaCard, Memory Stick,
Memory Stick Pro, Memory Stick Pro Duo*, SD Micro, MultiMediaCard Micro

* Memory Stick Pro Duo Adapters are required and sold separately. Inserting a Memory Stick Pro Duo Card
directly into your notebook could damage the memory card and/or notebook.

QuickSpecs

HP ProBook 4535s Notebook PC

Standard Features (availability may vary by country)

DA - 14044 North America — Version 12 — August 2, 2012

Page 6

Internal Storage

Hard drives

320/500/750 GB 7200 rpm SMART SATA II
320 GB 5400 rpm SMART SATA II

NOTE:

Up to 15 GB is reserved for the system recovery software.

HP 3D DriveGuard

(Windows models only)

The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.

Removable Storage

Fixed optical drives

Blu-ray ROMDVD+/-RW SuperMulti DL Drive
DVD+/-RW SuperMulti DL Drive
DVD-ROM Drive

Interfaces

VGA

One

HDMI 1.4a

One

Stereo microphone in

One

Stereo headphone/line
out

One

Power connector

One

RJ-11/modem (optional)

One

RJ-45/Ethernet

One

USB 3.0

One

USB 2.0

Three

Audio/Visual

SRS Premium Sound™
Integrated stereo speakers
Integrated microphone (dual-microphone array)
Function keys for volume mute, volume up, volume down; play, rewind, and fast-forward of video and
audio files
Stereo headphone/line out
Stereo microphone/line in

HD webcam

HD format (widescreen)
Supports web casting and still image capture
High-quality fixed focus lens
M-JPEG compression supports higher frame rates for video capture and web casting
Improved low light sensitivity
Improved dynamic range

QuickSpecs

HP ProBook 4535s Notebook PC

Standard Features (availability may vary by country)

DA - 14044 North America — Version 12 — August 2, 2012

Page 7

Software

Preinstalled software
with Windows Operating
System

HP Recovery Manager
HP Support Assistant
HP ProtectTools Security Manager
HP ProtectTools for Central Management
HP Face Recognition
HP Hotkey Support
HP QuickWeb
HP Power Assistant
HP Connection Manager
HP DayStarter
Microsoft Office 2010 preloaded (purchase of a Product
Key required to activate a full Office 2010 suite)

*

Norton Internet Security 2011

**

PDF Complete Special Edition

***

ArcSoft Total Media Suite
HP Webcam Software (select models)
Skype
ArcSoft Total Media Suite

Additional software
available from the web

HP SoftPaq Download Manager

* Microsoft Office 2010 Preloaded includes reduced functionality versions of Word and Excel. Purchase of
Product Key required to activate full Office 2010 suite available at participating resellers/retailers and

www.office.com

.
** Norton Internet Security 2011 includes 60 days of complimentary live updates; subscription required for
live updates thereafter. Internet access required to receive updates.
*** PDF Complete Special Edition 60 day trial; purchase license afterwards for full functionality.

HP Recovery Manager

Models shipped with Windows 7 include HP Recovery Manager. HP Recovery Manager enables fast
recovery of the factory preinstalled image if the system becomes corrupted or if important system files
are accidentally deleted. Up to 20 GB of the hard drive is reserved for the system recovery software.

Security

Standard Features

HP ProtectTools Security Manager (standard modules include)

Credential Manager
Computrace* Pro
Device Access Manager
Drive Encryption
Face Recognition (webcam configurations only)
File Sanitizer
Privacy Manager

HP Fingerprint Sensor
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
Security lock slot

Optional Features

HP Privacy Filter

QuickSpecs

HP ProBook 4535s Notebook PC

Standard Features (availability may vary by country)

DA - 14044 North America — Version 12 — August 2, 2012

Page 8

* The Computrace agent is shipped turned off, and must be activated by customers when they purchase a
subscription with terms ranging from one to five years. For more information on HP security solutions
refer to:

www.hp.com/products/security

.

HP ProtectTools Security
Manager with Central
Management

HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. The ProtectTools modules are available on the hard drive
(also downloadable from the web) and can be configured in Software Setup.

HP ProtectTools is centrally manageable with the capability to manage notebooks from a single point. HP
ProtectTools is management ready out of the box, in partnership with Digital Persona. Features address
requirements that customers expect from a centrally managed security solution such as user provisioning,
credential reset, and credential revocation.

HP ProtectTools provides two separate management solutions, targeted at the enterprise and the SMB:

Digital Persona Pro AD: Designed for the enterprise customer. Integrates with Active Directory and
gives IT Managers the ability to provision users, create login policies based on passwords,
biometrics or smartcards. Management features also include remote credential recovery in case the
user forgets the password, loses the smartcard or cannot use the fingerprint reader for any reason.
In addition, advanced auditing capabilities are also built in. Digital Persona Pro AD is available now.
Digital Persona Pro Workgroup: Designed for the small business customer. Provides features
similar to the Active Directory version, but for workgroups. Workgroup activation is built into HP
ProtectTools, and activation of up to 5 seats is completely free.

For more information on Central Management for HP ProtectTools, refer to:

www.hp.com/products/security

.

Power Supply

External 65-watt Smart AC adapter
6-foot (1.8-meter) power cord included; total length including external AC adapter is 12 feet (3.66 meter)
HP Fast Charge

*

* HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast
Charge does not apply to the HP 9-cell battery.

Battery

Primary battery

HP 9-cell (93 WHr) Li-Ion battery
HP 6-cell (47 WHr) Li-Ion battery

Battery Life

9-cell battery 93 WHr

Up to 11 hours and 15 Minutes

6-cell battery 47 WHr

Up to 6 hours

NOTE:

Battery life will vary depending on the product model, configuration, loaded applications, features,
use, wireless functionality and power management settings. The maximum capacity of the battery will
naturally decrease with time and usage. See MobileMark07 battery benchmark

www.bapco.com/products/mobilemark2007

for additional details.

System Standby Time

Up to 1 week

QuickSpecs

HP ProBook 4535s Notebook PC

Standard Features (availability may vary by country)

DA - 14044 North America — Version 12 — August 2, 2012

Page 9

Power Conservation

Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum Performance
Mode, or Automatic mode)

ATI PowerPlay technology
Hibernation
Standby
ACPI compliance

Service and Support

HP Services offers limited 3-year and 1-year warranty options depending on country; 1-year limited
warranty on primary battery. Warranty upgrades are also available. HP Care Pack Services extend service
contracts beyond the standard warranties. To choose the right level of service for your HP product, use the
HP Care Pack Services Lookup Tool at:

www.hp.com/go/lookuptool

. Additional HP Care Pack Services

information by product is available at:

www.hp.com/services/carepack

.

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

QuickSpecs

HP ProBook 4535s Notebook PC

Standard Features (availability may vary by country)

DA - 14044 North America — Version 12 — August 2, 2012

Page 10

NOTE:

Options/capabilities listed in the QuickSpecs represent those capabilities available through Base Units or Build to Order
configurations. The various product features and capabilities will vary in terms of configurable vs. aftermarket options (AMOs). There
may be options and capabilities available through CTO that are not available as AMOs.

Memory

HP 1 GB (DDR3 1333 MHz) SODIMM

AT911AA#xxx

HP 2 GB (DDR3 1333 MHz) SODIMM

AT912AA#xxx

HP 2 GB PC3-12800 (DDR3 1600 MHz) SODIMM

H2P63AA

HP 4 GB PC3-12800 (DDR3 1600 MHz) SODIMM

H2P64AA

NOTE:

Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or Linux. With Windows 32-bit operating
systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available
due to system resource requirements. Due to system limitations, DDR3-1600 MHz memory will only be supported at DDR3-1333 MHz.

Storage

HP 250 GB Pocket Media Drive

FE477AA

HP Mobile USB DVD

XQ543AA

HP Mobile USB DVDRW

BU516AA

Power

HP 65W Slim Adapter

AX727AA#xxx

Carrying Cases

HP Basic Carrying Case

AJ078AA

HP Business Nylon Case

BP848AA

HP Professional Slim Top Load Case

AY530AA

Security

HP Notebook Combo Lock

AY475AA#xxx

HP Keyed Cable Lock

BV411AA

HP 15.6-inch Display Privacy Filter

AU103AA#xxx

Input/Output Devices

HP USB Optical Travel Mouse

RH304AA

HP USB/PS2 Optical 2-Button Scroll Mouse

DC369A

HP USB Keyboard & Mouse Bundle

RC465AA#xxx

QuickSpecs

HP ProBook 4535s Notebook PC

Options (availability may vary by country)

DA - 14044 North America — Version 12 — August 2, 2012

Page 11

System Unit

Dimensions

(HxWxD)

1.13 in (at front) x 14.76 in x 10.09 in

2.87 cm (at front) x 37.50 cm x 25.62 cm

Weight

Starting at 5.14 lb (2.33 kg) without optical drive
or 5.45 lb (2.47 kg) with optical drive

NOTE:

Height varies depending upon where on the notebook the measurement is made. Weight varies by

configuration and components.

Stand-Alone Power
Requirements

(AC Power)

Nominal Operating Voltage

18.5 V

Average Operating Power

with integrated graphics: TBD W
with discrete graphics: TBD W

Max Operating Power

< 90 W or < 65W

Temperature

Operating

*

32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)

Non-operating

-4° to 140° F (-20° to 60° C)

Relative Humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb
temperature

Shock

Operating

125 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random Vibration

Operating

0.75 grms

Non-operating

1.50 grms

Altitude

(unpressurized)

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Planned
Industry Standard
Certifications

UL

Yes

CSA

Yes

FCC Compliance

Yes

ENERGY STAR®

Select models

*

EPEAT®

Registered Gold in United States

**

ICES

Yes

Australia / NZ A-Tick
Compliance

Yes

CCC

Yes

Japan VCCI Compliance

Yes

KCC

Yes

BSMI

Yes

CE Marking Compliance

Yes

* Configurations of the HP ProBook 4535s that are ENERGY STAR qualified are identified as HP ProBook
4535s ENERGY STAR on HP websites and on

www.energystar.gov

. Microsoft Windows required for

ENERGY STAR qualification.

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 12

** EPEAT registration varies by country. See

www.epeat.net

for registration status by country. EPEAT

status listed above applies to U.S.

NOTE:

For accessibility information on HP products, please visit:

www.hp.com/accessibility

.

Audio

SRS Premium Sound

Hardware

Implementation

IDT 92HD87 High Definition CODEC

Touch-Sensitive Volume
Controls

Volume up, volume down, and mute

Full Duplex

Yes

Microphone In

Stereo

Headphone/Line Out

Stereo

Integrated Microphone

Yes, dual digital microphone array when equipped with webcam

Audio Output Quality

Frequency Response

20 Hz – 20 kHz

Signal to Noise Ratio

>85 dB

Total Harmonic Distortion

0.01%

Noise Floor

–110 dB

Play/Record Sampling
Rate

(s)

8 kHz – 48kHz

DAC

16, 20 or 24-bit

ADC

16 or 20-bit

Integrated Stereo
Speakers

Power Rating

2 Watts

Impedance

4 Ohms

Power

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 13

HP 65W Smart AC Adapter

Dimensions

4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)

Weight

0.62 lb (280 g)

Input

100 to 240 VAC
Input Efficiency

87% min at 115 VAC

Input frequency range

47 to 63 Hz

Input AC current

1.7 A at 90 VAC, 0.85 A at 180 VAC

Output

Output power

65W

DC output

18.5V

Hold-up time

5 msec at 115 VAC input

Output current limit

<11A, Over voltage protection- 29V max
automatic shutdown

Connector

3 pin/grounded, mates with interchangeable cords

Environmental Design

Operating temperature

32° to 104° F (0° to 40° C)

Non-operating (storage)
temperature

-4° to 149° F (-20° to 65° C)

Altitude

0 to 10,000 ft (0 to 3,048 m)

Humidity

20% to 80%

Storage Humidity

10% to 90%

EMI and Safety
Certifications

CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals ­C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.

NOTE:

Unless otherwise noted, temperature limits listed in the following component specifications relate to the internal temperatures
of these components and not to the environment in which the PC is operating.

9-Cell (93 WHr) Lithium­Ion battery

Dimensions

(H x W x L)

0.8 x 2.9 x 8.3 in (2.0 x 7.3 x 21.0 cm)

Weight

1.07 lb (0.488 kg)

Cells/Type

9-cell Lithium-Ion

Energy

Watt-hour Capacity

93 WHr

Temperature

Operating (Charging)

32° to 113° F (0° to 45° C)

Operating (Discharging)

14° to 140° F (–10° to 60° C)

Non-operating

–4° to 140° F (–20° to 60° C)

Battery Re-Charge Time

System in OFF mode or
Standby

3 to 4 hours

System ON

4 to 6 hours (depending on system power
consumption)

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 14

6-Cell (47 WHr) Lithium­Ion battery

Dimensions

(H x W x L)

0.8 x 1.8 x 10.4 in (2 x 4.5 x 26.5cm)

Weight

(max)

.70lb, (.312kg)

Cells/Type

Lithium-Ion

Energy

Voltage

10.8V

Amp-hour capacity

4.4Ah

Watt-hour capacity

47Wh

Temperature

Operating (Charging)

32° to 113° F (0° to 45° C)

Operating (Discharging)

14° to 122° F(-10° to 50° C)

Non-operating

-4° to 122° F (-20° to 50° C)

Battery Re-Charge Time

System in OFF or Standby
Mode

2.5 hours

System ON

3 to 5 hours

Fuel Gauge LED

No

Warranty

1 year

Optional Travel Battery
Available

No

Displays

15.6-inch LED HD (1366 x

768)
anti-glare

Dimensions

(W x H)

13.54 x 7.59 in (34.4 x 19.4 cm)

Diagonal Size

15.6 in (39.6cm)

Surface Treatment

Anti-glare

Contrast Ratio

400:1 (min)

Refresh Rate

60 Hz

Brightness

210 nit (typical)

Pixel Resolution

Pitch

0.252 mm

Format

1366 x 768

Configuration

RGB Stripe

Backlight

LED

PPI

101 ppi

Viewing Angle

±30° Horizontal, ±10° Vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)

Internal Storage

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 15

750 GB 7200 rpm SATA
Hard Drive

Drive Weight

0.25 lbs (115g)

Capacity

750 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Transfer Rate

Synchronous

(maximum)

300 MB/s (Drive Capability)

Seek Time

(typical reads, including
settling)

Single Track

1.5 ms

Average

11 ms

Maximum

22 ms

Rotational Speed

7200 rpm

Logical Blocks

1,465,149,168

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security

500 GB 7200 rpm SATA
Hard Drive

Drive Weight

0.25 lbs (115g)

Capacity

500 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Transfer Rate

Synchronous

(maximum)

300 MB/s (Drive Capability)

Seek Time

(typical reads, including
settling)

Single Track

1.5 ms

Average

11 ms

Maximum

22 ms

Rotational Speed

7200 rpm

Logical Blocks

976,773,168

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 16

320 GB 7200 rpm SATA
Hard Drive

Drive Weight

0.25 lbs (115 g)

Capacity

320 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Transfer Rate

Synchronous

(maximum)

300 MB/s (Drive Capability)

Seek Time

(typical reads, including
settling)

Single Track

1.5 ms

Average

11 ms

Maximum

22 ms

Rotational Speed

7200 rpm

Logical Blocks

625,142,448

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security

320 GB 5400 rpm SATA
Hard Drive

Drive Weight

0.22 lb (101 g)

Capacity

320 GB

Height

0.37 in (9.5 mm)

Width

2.75 in (70 mm)

Interface

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Transfer Rate

Synchronous

(maximum)

300 MB/s (Drive Capability)

Seek Time

(typical reads, including
settling)

Single Track

3 ms

Average

13ms

Maximum

24 ms

Rotational Speed

5400 rpm

Logical Blocks

625,142,448

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security

Optical Drives

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 17

DVD-ROM Drive

Access Times

Random

< 140 ms CD (typical)
< 160 ms DVD (typical)

Max Data Transfer Rate

24X CD-ROM
8X-DVD

Transfer Mode

UDMA Mode 5

Interface

Gen 1 SATA

Supported Media

(read)

CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R,
CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R,
DVD-RW, DVD+R, DVD+RW, DVD-RAM

Supported Media

(write)

None

Max Media Capacity

(read)

8.5GB

Transport

Tray Loading

DVD+/-RW SuperMulti DL
Drive

Access Times

Random

<140ms CD (typical)
< 160 ms DVD (typical)

Max Data Transfer Rate

24X CD-ROM
8X DVD
24X CD-R
24X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
6X - DVD+R Dual Layer
6X - DVD-R Dual Layer
5X DVD-RAM

Transfer Mode

UDMA Mode 5

Interface

Gen 1 SATA

Supported Media

(read)

CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R,
CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R,
DVD-RW, DVD+R, DVD+RW, DVD-RAM

Supported Media

(write)

CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM, DVD+R DL, DVD-R
DL

Max Media Capacity

(read)

8.5 GB

Max Media Capacity

(write)

8.5 GB

Transport

Tray Loading

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 18

Blu-ray ROM DVD+/-RW
SuperMulti DL Drive

Access Times

Random

<190 ms CD-ROM (typical)
< 180ms DVD-ROM (typical)
<230 ms BD-ROM (typical)

Max Data Transfer Rate

24X CD-ROM
8X DVD-ROM
24X CD-R
16X CD-RW
8X DVD+R
8X DVD+RW
8X DVD-R
6X DVD-RW
4X - DVD+R Dual Layer
4X - DVD-R Dual Layer
5X DVD-RAM
6X BD-ROM

Transfer Mode

UDMA Mode 5

Interface

Gen 1 SATA

Supported Media

(read)

CD-DA, , CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R,
CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R,
DVD-RW, DVD+R, DVD+RW. DVD-RAM, BD-ROM, BD-R, BD-RE

Supported Media

(write)

CD-R, CD-RW, DVD+R, DVD+R DL, DVD+RW, DVD-R, DVD-R DL, DVD-RW, DVD­RAM

Max Media Capacity

(read)

50.0 GB

Max Media Capacity

(write)

8.5GB

Transport

Tray Loading

Security

HP Fingerprint Sensor

Mobile Voltage Operation

3.0V–3.6V single supply

Operating Temperature

32° – 158°F (0° – 70°C)

Current Consumption @

3.3V

Less than 70 mA peak imaging and scrolling
Less than 25 mA hardware finger detection
Advanced Power Management

High-Rate Image Capture

Up to 240 image frames /sec

ESD Resistance

IEC 61000-4-2 Level 4 (±15KV)

Detection Matrix

192 x 16 Pixels

9.7 mm x 0.81 mm
500 ppi High-Resolution Images

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 19

Communications

V.92 56K Data/Fax Modem

Form Factor

MDC 1.5 Daughtercard

Power Management
Support

APM Revision 1.2, ACPI

Approvals/
Certifications

UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class
B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other
Countries

Data Mode Capabilities

V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)

Optional symbol rates

:
2800, 3429
Asymmetric Symbol rates

Synchronous primary channel data signaling rates

:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J

Fax Mode Capabilities

TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
T.31

Command Set

V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 20

HP un2430
EV-DO/HSPA Mobile
Broadband Module

Technology/Operating
Bands

GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS), 1900MHz
(PCS)
UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900MHz
(UTRA FDD Band II), AWS (UTRA FDD Band IV), 900MHz(UTRA FDD Band VIII),
850MHz (UTRA FDD Band V)
1xEVDO/1xRTT with receive diversity: 850MHz (Band Class0-Cell), 1900MHz
(Band Class1-PCS)

Wireless Protocol
Standards

GSM/GPRS/EDGE: Class A, Multi-slot class 10 operation, coding schemes CS1 ­CS4 and MSC1 - MSC9.
UMTS/WCDMA: Release 99 and Release 6
CDMA: 1xEVDO Release 0 and Release A, IS-95A, IS-95B, IS-856, IS-2000

Wireless Parametric
Standards

Meets or exceeds TIA/EIA IS-98-D

Maximum Data Rates

UMTS (HSPA) - 14.4 Mbps (Download ), 5.76Mbps (Upload)
CDMA (EVDO Release A) - 3.1 Mbps (Download), 1.8Mbps (Upload)

GPS

Standalone GPS enabled
gpsOneXTRATM™

GPS Bands

L1 - 1575.42 MHz

Maximum Output Power

GSM/GPRS/EDGE: 32dBm (+/-1)
WCDMA: 24dBm (+0.7/-2.3)
CDMA: 24dBm (+0.7/-2)

Maximum Power
Consumption

2750mA (peak); 1100mA (average)

Power Consumption, Idle
Not Connected

20 mA

Power Management

USB selective suspend
Integrated notebook wireless button

Antenna Type

Dual high efficiency 5 band antennae with spatial diversity, mounted in the
display enclosure

Form Factor

PCI-Express MiniCard, USB 2.0 interface

Weight

11.5 g

Dimensions

(Length x

Width x Thickness)

2.01 x 1.18 x 0.18 in (51 x 30 x 5 mm)

Voltage, Operating

3.3v +/- 10%

Temperature, Operating

(from TIA/EIA/IS-98-D)

-22° to 158° F (-30° to 70° C) (full RF performance)

-22° to 167° F (-30° to 75° C) (reduced RF performance)

Temperature, Non­operating, 96 hours

(from

MIL-STD 202 Method 108)

-40° to 185° F (-40° to 85° C)

Humidity, Non-operating

95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

Configuration Utilities

HP Connection Manager

LED Activity

LED Off - Radio Off;
Solid LED On - Radio On

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 21

HP hs2340 HSPA+ Mobile
Broadband Module

Technology/Operating
Bands

GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS), 1900MHz
(PCS)
UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900Mhz
(UTRA FDD Band II), 900Mhz(UTRA FDD Band VIII), 850 MHz (UTRA FDD Band V)

Wireless Protocol
Standards

GSM/GPRS/EDGE: Class B, Multi-slot class 10 operation, coding schemes CS1 ­CS4 and MSC1 - MSC9.
UMTS/WCDMA: Release 99 and Release 7
Advanced Receiver Type 3i

Wireless Parametric
Standards

Complies with 3GPP specifications

Maximum Data Rates

UMTS (HSPA) - 21 Mbps (Download ), 5.76Mbps (Upload)

GPS

Standalone, A-GPS (Internet- and Network assisted)

GPS Bands

1575.42 MHz (± 1.023 MHz)

Maximum Output Power

GSM/EDGE
GSM850 & GSM900 bands
GPRS: +33 dBm ± 2 dBm (class 4)
EGPRS: +27 dBm ± 3 dBm (class E2)

DCS1800 & PCS1900 bands
GPRS: +30 dBm ± 2 dBm (class 1)
EGPRS: +26 dBm +4 / -3 dBm (class E2)

UMTS
UTRA FDD Bands
+24 dBm +4 / -3 dBm (class 3)

Maximum Power
Consumption

2000mA (peak); 600mA (average)

Power Consumption,
Sleep Mode

5 mA

Power Management

USB selective suspend
Integrated notebook wireless button

Antenna Type

Dual high efficiency 5 band antennae with spatial diversity, mounted in the
display enclosure

Form Factor

PCI-Express MiniCard, USB 2.0 interface

Weight

< 12 g

Dimensions

(Length x

Width x Thickness)

2.01 x 1.18 x 0.18 in (51 x 30 x 5 mm)

Voltage, Operating

3.3v +/- 9%

Temperature, Operating

14° to 149° F (-10° to 65° C) (full RF performance)
14° to 167° F (-10° to 75° C) (reduced RF performance)

Temperature, Non­operating, 96 hours

(from

MIL-STD 202 Method 108)

-22° to 185° F (-30° to 85° C)

Humidity, Non-operating

85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

Configuration Utilities

HP Connection Manager

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 22

LED Activity

LED Off - Radio Off;
Solid LED On - Radio On

Intel Centrino Advanced-N
6230 WiFi and Bluetooth
Combo Adapter

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

Interoperability

Wi-Fi certified
Cisco Compatible Extensions Program compliantwith Microsoft Windows Vista
and XP (details at:

http://www.hp.com/go/notebooks/WLAN

)

Frequency Band

2.4 GHz and 5GHz

Data Rates

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: 66 possible data rates, ranging from 6 Mbps to 300 Mbps, depending
on the combination of Bandwidth, Modulation Coding Scheme, and Guard
Interval used, as defined in IEEE 802.11n specification

Modulation

Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Security

1

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,

802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2,
LEAP, EAP-FAST.

Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows Vista and XP only.

Sub-channels

Multinational support with frequency bands and channels compliant to local
regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for CCK and

OFDM)

2

17 dBm , nominal

Output Power

(for OFDM;

power varies by data rate)

2

15 dBm , nominal

Power Consumption

Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit: 2.0 W (max)
Receive: 2.0 W (max)

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

3

54 Mbps: -71 dBm, 11 Mbps: -85 dBm , 1 Mbps: -95 dBm

Antenna type

High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 23

1.

2.

3.

4.

Form Factor

PCI-Express Half-MiniCard

Weight

0.013 lb (6 g)

Dimensions

0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)

Operating Voltage

3.3v +/- 10%

Temperature

Operating
Non-operating

14° to 149° F (-10° to 65° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

Configuration Utility

4

Microsoft Windows XP
Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco Compatible
Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager
Broadcom IHV extensions for Windows Vista available to support Cisco
Compatible Extensions.

LED Activity

LED Off - Radio OFF; Solid LED On - Radio ON

Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN
supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows
Vista.

Bluetooth 2.1 and 3.0
Wireless Technology

Bluetooth Specification

2.1+EDR and 3.0+HS Compliant

Dimensions

1.18 x 0.26 x 0.13 in (30 x 6.5 x 3.25 mm)

Frequency Band

2402 to 2480 MHz

Number of Available
Channels

79 (1 MHz) available channels

Data Rates and
Throughput

3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or

1306.9 kbps symmetric

Transmit Power

Max 5.5 dBm (Bluetooth Class I)

Receiver Sensitivity

Better than -80 dBM at 0.1 % raw bit error rate

Power Consumption

Average 165mW
Sleep <1 mW

Antenna

Internally integrated within module

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 24

1.

2.

Range

Up 33 ft (10 m)

Electrical Interface

USB 2.0 compliant
Microsoft Windows Plug and Play compliant

Bluetooth Software
Supported

Broadcom Bluetooth for Windows
Microsoft Windows Bluetooth Software

Link Topology

Point to Point, Multipoint Pico Nets up to 7 slaves

Security

Full support of Bluetooth Security Provisions

Power Management

Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,

including Standby, Hold, Park, and Sniff

Certifications

All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark

Temperature

Operating
Non-operating

-4° to 158° F (-20° to 70° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating
Non-operating

10% to 90%
5% to 95%

Altitude

Operating
Non-operating

15,000 ft (4,572 m)
40,000 ft (12,192 m)

Bluetooth Profiles
Supported

Serial Port Profile (SPP)

1

Service Discovery Applicaton Profile (SDAP)
Dial-Up Networking (DUN)

1,2

Generic Object Exchange Profile (GOEP)

1,2

Object Push Profile (OPP)

1,2

File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)

1,2

Personal Area Networking Profile (PAN)

1,2

Human Interface Device Profile (HID)

1,2,3

FAX Profile (FAX)
Basic Imaging Profile (BIP)

2

Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

indicates the profile is supported by Microsoft Windows XP SP2
indicates the profile is part of Windows Vista

Atheros 9285GN

802.11b/g/n + BT 3.0 HS
Combo Adapter

Wireless LAN Standards

IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 25

Combo Adapter

Interoperability

Wi-Fi certified

Frequency Band

2.4 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: many possible data rates, ranging from 6 Mbps to 300 Mbps,
depending on the combination of Bandwidth, Modulation Coding Scheme, and
Guard Interval used, as defined in IEEE 802.11n specification

Modulation

Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Security

1

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,

802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2,
LEAP, EAP-FAST.

Sub-channels

Multinational support with frequency bands and channels compliant to local
regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for CCK and

OFDM)

2

17 dBm, nominal

Output Power

(for OFDM;

power varies by data rate)

2

15 dBm, nominal

Power Consumption

Transmit: 1.5 W (max)
Receive: 1.0 W (max)
Associated to Access Point, Idle: 300 mW nominal
Wireless Button Off: 75 mW nominal

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

3

54 Mbps: -75 dBm, 11 Mbps: -88 dBm , 1 Mbps: -93 dBm

Antenna type

High efficiency antenna with spatial diversity, mounted in the display
enclosure

Form Factor

PCI-Express Half-MiniCard

Weight

0.013 lb (6 g)

Dimensions

0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 149° F (-10° to 65° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Off - Radio OFF; Solid LED On - Radio ON

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 26

1.

2.

3.

Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).

Ralink 3592BC8

802.11a/b/g/n 2x2 WiFi
and Bluetooth 3.0+HS
Combo Adapter

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

Interoperability

Wi-Fi certified
Cisco Compatible Extensions Program compliantwith Microsoft Windows Vista
and XP (details at:

http://www.hp.com/go/notebooks/WLAN

)

Frequency Band

2.4 GHz and 5GHz

Data Rates

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: from 6 Mbps to 300 Mbps, depending on the combination of
Bandwidth, Modulation Coding Scheme, and Guard Interval used, as defined in
IEEE 802.11n specification

Modulation

Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Security

1

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,

802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2,
LEAP, EAP-FAST.

Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows Vista and XP only.

Sub-channels

Multinational support with frequency bands and channels compliant to local
regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for CCK and

OFDM)

2

17 dBm , nominal

Output Power

(for OFDM;

power varies by data rate)

2

15 dBm , nominal

Power Consumption

Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit: 2.0 W (max)
Receive: 2.0 W (max)

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

3

54 Mbps: -71 dBm, 11 Mbps: -85 dBm , 1 Mbps: -95 dBm

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 27

1.

2.

3.

4.

Antenna type

High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure

Form Factor

PCI-Express Half-MiniCard

Weight

0.013 lb (6 g)

Dimensions

0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)

Operating Voltage

3.3v +/- 10%

Temperature

Operating
Non-operating

14° to 149° F (-10° to 65° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

Configuration Utility

4

Microsoft Windows XP
Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco Compatible
Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager
Broadcom IHV extensions for Windows Vista available to support Cisco
Compatible Extensions.

LED Activity

LED Off - Radio OFF; Solid LED On - Radio ON

Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN
supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows
Vista.

Bluetooth 2.1 and 3.0
Wireless Technology

Bluetooth Specification

2.1+EDR and 3.0+HS Compliant

Dimensions

1.18 x 0.26 x 0.13 in (30 x 6.5 x 3.25 mm)

Frequency Band

2402 to 2480 MHz

Number of Available
Channels

79 (1 MHz) available channels

Data Rates and
Throughput

3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or

1306.9 kbps symmetric

Transmit Power

-6 dBm to 4 dBm (Bluetooth Class II)

Receiver Sensitivity

Better than -80 dBM at 0.1 % raw bit error rate

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 28

1.

2.

Power Consumption

Peak (Tx) 175 mW
Peak (Rx) 160 mW
Sleep <1 mW

Antenna

Internally integrated within module

Range

Up 33 ft (10 m)

Electrical Interface

USB 2.0 compliant
Microsoft Windows Plug and Play compliant

Bluetooth Software
Supported

Broadcom Bluetooth for Windows
Microsoft Windows Bluetooth Software

Link Topology

Point to Point, Multipoint Pico Nets up to 7 slaves

Security

Full support of Bluetooth Security Provisions

Power Management

Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,

including Standby, Hold, Park, and Sniff

Certifications

All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark

Temperature

Operating
Non-operating

-4° to 158° F (-20° to 70° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating
Non-operating

10% to 90%
5% to 95%

Altitude

Operating
Non-operating

15,000 ft (4,572 m)
40,000 ft (12,192 m)

Bluetooth Profiles
Supported

Serial Port Profile (SPP)

1

Service Discovery Applicaton Profile (SDAP)
Dial-Up Networking (DUN)

1,2

Generic Object Exchange Profile (GOEP)

1,2

Object Push Profile (OPP)

1,2

File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)

1,2

Personal Area Networking Profile (PAN)

1,2

Human Interface Device Profile (HID)

1,2,3

FAX Profile (FAX)
Basic Imaging Profile (BIP)

2

Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

indicates the profile is supported by Microsoft Windows XP SP2
indicates the profile is part of Windows Vista

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 29

1.

2.

Realtek 8188GN

802.11b/g/n 1x1 WiFi
Adapter

Wireless LAN Standards

IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

Interoperability

Wi-Fi certified

Frequency Band

2.4 GHz

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: many possible data rates, ranging from 6 Mbps to 150 Mbps,
depending on the combination of Bandwidth, Modulation Coding Scheme, and
Guard Interval used, as defined in IEEE 802.11n specification

Modulation

Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Security

1

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,

802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2,
LEAP, EAP-FAST.

Sub-channels

Multinational support with frequency bands and channels compliant to local
regulations.

Media Access Protocol

CSMA/CA (Collision Avoidance) with ACK

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

(for CCK)217 dBm, nominal

Output Power

(for OFDM;

power varies by data rate)

2

15 dBm, nominal

Power Consumption

Transmit: 1.5 W (max)
Receive: 1.0 W (max)
Associated to Access Point, Idle: 152 mW nominal
Wireless Button Off: 33 mW nominal

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity

3

54 Mbps: -73 dBm, 11 Mbps: -82 dBm , 1 Mbps: -93 dBm, MCS7_HT20: -69dBm
, MCS7_HT40: -67dBm

Antenna type

High efficiency antenna with spatial diversity, mounted in the display
enclosure

Form Factor

PCI-Express Half-MiniCard

Weight

0.007 lb (3 g)

Dimensions

0.14 x 1.06 x 1.18 in (3.5 x 26.8 x 30 mm)

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 149° F (-10° to 65° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 30

1.

2.

3.

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Off - Radio OFF; Solid LED On - Radio ON

Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g/n (OFDM modulation).

Environmental Data

Eco-Label Certifications

This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:

US ENERGY STAR®
IT ECO declaration
EPEAT - Gold where HP registers commercial notebook products. See

http://www.epeat.net

for registration status in your country.

System Configuration

The configuration used for the Energy Consumption and Declared Noise
Emissions data for the Convertible Mini tower Desktop model is based on a
"Typically Configured Notebook"

Energy Consumption

115 VAC 230 VAC 100 VAC

Normal Operation

7.85 W 8.11 W 7.48 W

Sleep (Energy Star low
power mode)

0.89 W 1.04 W 0.92 W

Off

0.43 W 0.55 W 0.46 W

Heat Dissipation

*

115 VAC 230 VAC 100 VAC

Normal Operation

27 BTU/hr 28 BTU/hr 25 BTU/hr

Sleep

3 BTU/hr 3 BTU/hr 3 BTU/hr

Off

1 BTU/hr 2 BTU/hr 1 BTU/hr

* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.

Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)

System Fan Off

Sound Power

(LWAd, bels)

Sound Pressure

(LpAm, decibels)

Idle

3.4

25.4

Fixed Disk
(random writes)

3.4

25.9

System fan is usually off except when charging the battery

Batteries

This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain:

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 31

Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight

The battery type and chemistry used in the product is:
CR2032 (coin cell), Li-ion
6-cell high capacity Lithium-Ion battery (optional 8 cell available)

Additional
information

This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive - 2002/95/EC.

This HP product is designed to comply with the Waste Electrical and Electronic
Equipment (WEEE) Directive - 2002/96/EC.

This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).

This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold
level, see

www.epeat.net

Plastics parts weighing over 25 grams used in the product are marked per ISO
11469 and ISO1043.

This product contains 0% post consumer recycled plastic (by wt.)

This product is greater than 95.1% recycle-able when properly disposed of at
end of life.

Packaging Materials

External:

Corrugated 115 g
Corrugated carton 455 g
CANON bags - several layers 5 g

Internal:

Polyethylene low density 15 g

Molded Pulp 190 g
The Corrugated packaging material is made from 80% recycled content.
The Corrugated carton packaging material is made from 80% recycled
content.
The CANON bags - several layers packaging material is made from 80%
recycled content.
The Polyethylene low density packaging material is made from 60%
recycled content.
The Molded Pulp packaging material is made from 60% recycled
content.

HP follows these guidelines to decrease the environmental impact of product
packaging:

Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 32

materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.

Material Usage

This product does not contain any of the following substances in excess of
regulatory limits (for reference of these limits please refer to the HP General
Specification of the Environment:
(

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/

gen_specifications.html

):

Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Nickel finishes that release greater than 0.5 µgrams/cm2/week,
measured according to EN 1811:1998, are not used on any product
surface designed to be frequently handled or touched by users.

End-of-life Management
and Recycling

Hewlett-Packard offers end-of-life HP product return and recycling programs
in many geographic areas. To recycle your product, please go to:

http://www.hp.com/go/reuse-recycle

or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at:

http://www.hp.com/go/recyclers

. These instructions may

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 33

be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.

Hewlett-Packard
Corporate Environmental
Information

For more information about HP's commitment to the environment:
Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Environment website

http://www.hp.com/environment

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/
ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/
envmanagement.html

Copyright © 2012 Hewlett-Packard Development Company, L.P.

All rights reserved. Microsoft, Windows, Windows Vista, and Windows XP are U.S. registered trademarks of Microsoft Corporation. AMD
is a trademark of Advanced Micro Devices. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company
under license. All other product names mentioned herein may be trademarks of their respective companies.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in
the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

QuickSpecs

HP ProBook 4535s Notebook PC

Technical Specifications

DA - 14044 North America — Version 12 — August 2, 2012

Page 34
